Draft Document for Review May 23, 2008 10:14 am SG24-7645-00

Maximo Asset Management Essentials V7.1 Implementer’s Guide

Melissa Christensen

Abesolom Fidel

Nihar Jain

Rutger Mons

Venkat Ram

Vikas Sharma

Bart Jacob

Offering targeted for general business clients

Start planning a deployment

Learn about configuring the environment

Front cover

Maximo Essentials V7.1 - Implementer’s Guide

May 2008

International Technical Support Organization

Draft Document for Review May 23, 2008 10:14 am 7645edno.fm

SG24-7645-00

7645edno.fm Draft Document for Review May 23, 2008 10:14 am

Note to U.S. Government Users Restricted Rights -- Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

First Edition (May 2008)

This edition applies to Maximo Asset Management Essentials Version 7.1.

This document created or updated on May 23, 2008.

Note: Before using this information and the product it supports, read the information in “Notices” on page vii.

Draft Document for Review May 23, 2008 10:14 am 7645TOC.fm

Contents

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

The team that wrote this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Become a published author . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Comments welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Chapter 1. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Enterprise asset management overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.2 Maximo Asset Management Essentials . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2.1 General Functional Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.2.2 Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2.3 Integrating with Existing Enterprise Applications . . . . . . . . . . . . . . . . 7

Chapter 2. Maximo Asset Management Essentials 7.1 . . . . . . . . . . . . . . . . 9

2.1 Differences with Maximo Asset Management Enterprise . . . . . . . . . . . . . 10

Chapter 3. Project Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.1 Required Skills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.2 Solution Description and Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.3 Task Break Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 4. Solution Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.1 Hardware and Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.2 Typical deployment environments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.2.1 Single-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.2.2 Multi-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.3 Sizing Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.4 Maximo Asset Management Essentials Supported Platforms. . . . . . . . . . 34

Chapter 5. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

5.1 Pre-Installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

5.1.1 Hardware/Software considerations . . . . . . . . . . . . . . . . . . . . . . . . . . 38

5.1.2 Verifying the DVD Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

5.1.3 Backup/Snapshot Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.1.4 JDK/JRE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.1.5 Internet Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.1.6 Disabling the firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7645TOC.fm Draft Document for Review May 23, 2008 10:14 am

iv Maximo Essentials V7.1 - Implementer’s Guide

5.1.7 Deleting the TEMP and TMP user environment variables . . . . . . . . 39

5.1.8 Verifying the required rpm-build package is installed . . . . . . . . . . . . 40

5.1.9 Setting the ulimit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

5.1.10 Setting shared memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

5.1.11 Enabling remote configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

5.2 Installation flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

5.3 Middleware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

5.3.1 Installing middleware overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

5.3.2 Tivoli middleware installer logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5.4 Installing Maximo corfe components (TPAP) . . . . . . . . . . . . . . . . . . . . . . 57

5.4.1 Maximo Asset Management Essentials Installation Overview . . . . . 57

5.4.2 Maximo Asset Management Essentials Installation . . . . . . . . . . . . . 58

5.4.3 Post Maximo Asset Management Essentials base services installation 74

5.5 Process solution package installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

5.5.1 Pre-Process solution package installation checklist . . . . . . . . . . . . . 76

5.5.2 Enable Maximo Asset Management Essentials License. . . . . . . . . . 77

5.6 Post Installation Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

5.6.1 Ensure all relevant Maximo services are running . . . . . . . . . . . . . . . 83

5.6.2 Ensure connectivity to the Maximo Asset Management Essentials

application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

5.6.3 Ensure the Language pack installation is functional . . . . . . . . . . . . . 85

5.6.4 Ensure Client Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

5.6.5 Report Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

5.6.6 Attached Documents Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 90

5.6.7 Ensure relevant cron tasks are working and enabled . . . . . . . . . . . . 93

5.6.8 Create Backup/Image of the environment. . . . . . . . . . . . . . . . . . . . . 94

5.6.9 Automate the Backup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

5.6.10 Assess the server workload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

5.6.11 Client Local/Regional Settings Properties. . . . . . . . . . . . . . . . . . . . 94

5.6.12 Internet and Firewall Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

5.6.13 SMTP mail exchange server setup . . . . . . . . . . . . . . . . . . . . . . . . . 96

5.6.14 Users LDAP Authentication through Virtual Member Management 96

5.7 Setting the System and Logging properties . . . . . . . . . . . . . . . . . . . . . . . 97

5.7.1 System Properties Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

5.7.2 Logging Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Chapter 6. Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

6.1 Getting started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

6.1.1 User Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

6.1.2 Organization and Site setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

6.1.3 Initial Configuration and Data import sequence . . . . . . . . . . . . . . . 108

Contents v

Draft Document for Review May 23, 2008 10:14 am 7645TOC.fm

6.2 Reporting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

6.2.1 Report Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

6.2.2 BIRT Configure Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

6.2.3 BIRT Run Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Appendix A. Summary of Maximo Asset Management Essentials modules

and applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

IBM Redbooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Other publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Online resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

How to get Redbooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Help from IBM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

7645TOC.fm Draft Document for Review May 23, 2008 10:14 am

vi Maximo Essentials V7.1 - Implementer’s Guide

Draft Document for Review May 23, 2008 10:14 am 7645spec.fm

Notices

This information was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in other countries. Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead. However, it is the user's responsibility to evaluate and verify the operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter described in this document. The furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing, IBM Corporation, North Castle Drive, Armonk, NY 10504-1785 U.S.A.

The following paragraph does not apply to the United Kingdom or any other country where such provisions are inconsistent with local law: INTERNATIONAL BUSINESS MACHINES CORPORATION

PROVIDES THIS PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time without notice.

Any references in this information to non-IBM Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this IBM product and use of those Web sites is at your own risk.

IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.

Information concerning non-IBM products was obtained from the suppliers of those products, their published announcements or other publicly available sources. IBM has not tested those products and cannot confirm the accuracy of performance, compatibility or any other claims related to non-IBM products. Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products.

This information contains examples of data and reports used in daily business operations. To illustrate them as completely as possible, the examples include the names of individuals, companies, brands, and products. All of these names are fictitious and any similarity to the names and addresses used by an actual business enterprise is entirely coincidental.

This information contains sample application programs in source language, which illustrate programming techniques on various operating platforms. You may copy, modify, and distribute these sample programs in any form without payment to IBM, for the purposes of developing, using, marketing or distributing application programs conforming to the application programming interface for the operating platform for which the sample programs are written. These examples have not been thoroughly tested under all conditions. IBM, therefore, cannot guarantee or imply reliability, serviceability, or function of these programs.

7645spec.fm Draft Document for Review May 23, 2008 10:14 am

viii Maximo Essentials V7.1 - Implementer’s Guide

Trademarks

IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corporation in the United States, other countries, or both. These and other IBM trademarked terms are marked on their first occurrence in this information with the appropriate symbol (® or ™), indicating US registered or common law trademarks owned by IBM at the time this information was published. Such trademarks may also be registered or common law trademarks in other countries. A current list of IBM trademarks is available on the Web at http://www.ibm.com/legal/copytrade.shtml

The following terms are trademarks of the International Business Machines Corporation in the United States, other countries, or both:

Redbooks (logo) ® AIX 5L™ AIX® DB2®

Enterprise Asset Management® IBM® Maximo® Redbooks®

System z™ Tivoli® WebSphere®

The following terms are trademarks of other companies:

SAP, and SAP logos are trademarks or registered trademarks of SAP AG in Germany and in several other countries.

Oracle, JD Edwards, PeopleSoft, Siebel, and TopLink are registered trademarks of Oracle Corporation and/or its affiliates.

ITIL is a registered trademark, and a registered community trademark of the Office of Government Commerce, and is registered in the U.S. Patent and Trademark Office.

Acrobat, Adobe, and Portable Document Format (PDF) are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States, other countries, or both.

J2EE, Java, JavaServer, JDK, JSP, Solaris, Sun, and all Java-based trademarks are trademarks of Sun Microsystems, Inc. in the United States, other countries, or both.

Active Directory, Expression, Internet Explorer, Microsoft, SQL Server, Windows Server, Windows Vista, Windows, and the Windows logo are trademarks of Microsoft Corporation in the United States, other countries, or both.

Intel, Pentium, Intel logo, Intel Inside logo, and Intel Centrino logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States, other countries, or both.

UNIX is a registered trademark of The Open Group in the United States and other countries.

Linux is a trademark of Linus Torvalds in the United States, other countries, or both.

Other company, product, or service names may be trademarks or service marks of others.

Draft Document for Review May 23, 2008 10:14 am 7645pref.fm

Preface

This book is a guide to assist those interested in implementing Maximo Asset Management Essentials. It provides general information about the offering and overviews the planning, installation and initial configuration processes.

With Essentials, smaller organizations can take advantage of proven Maximo Asset Management technology, while also enjoying cost savings.

IBM Maximo Asset Management Essentials enables smaller organizations and departments to organize, track, and manage their asset and work management processes, and to implement a maintenance regimen based on industry-leading technology and best practices.

IBM Maximo Asset Management Essentials is an integrated solution for all assets. It helps eliminate paper- and spreadsheet-based processes and custom applications by standardizing on the Maximo unified platform.

Unlike competing solutions that are unable to grow with your organization, forcing you to throw away your initial expenditure, Essentials allows you to build on your Maximo investment by leveraging Maximo’s scalable architecture. Maximo Asset Management Essentials can grow with your company so you can continue to manage all asset classes and work tasks from a single, unified platform.

The team that wrote this book

This book was produced by a team of specialists from around the world working at the International Technical Support Organization, Austin Center.

7645pref.fm Draft Document for Review May 23, 2008 10:14 am

x Maximo Essentials V7.1 - Implementer’s Guide

Figure 1 (From l to r ) Abby Fidel, Venkat Ram, Rutger Mons, Melissa Christensen, Nihar Jain, Vikas Sharma, Bart Jacob

Bart Jacob is a Senior Consulting IT Specialist at IBM® Corp - International Technical Support Organization, Austin Center. He has over 25 years of experience providing technical support across a variety of IBM products and technologies, including communications, object-oriented software development, and systems management. He joined the ITSO in 1989, where he has been writing IBM Redbooks® publications and creating and teaching workshops around the world on a variety of topics. He holds a Masters degree in Numerical Analysis from Syracuse University.

Melissa Christensen is a Senior Project Manager for EMA, based in California. Melissa has over 11 years of experience in Project Management, specifically implementing Tivoli® Maximo®. Melissa holds degrees in both Anthropology/History and Liberal Studies. Her areas of expertise include Utilities and Facilities Maintenance Management in both the private and public sectors.

Abesolom ’Abby’ Fidel is a SAP® Production Process certified with over 11 years work in implementing enterprise solution on Unix/Linux® platforms. Abby is currently employed as Enterprise Solution Consultant for Avenue Business IT Solutions based out of Ho Chi Minh City, Vietnam. He holds a degree in Physics and Mathematics. In his spare time, Abby volunteers for Habitat for Humanity International - Vietnam office.

Preface xi

Draft Document for Review May 23, 2008 10:14 am 7645pref.fm

Nihar Jain is a Techno Functional Consultant with Birlasoft (India) Ltd. He has over 3 years of experience with Maximo in Asset and Service Management domain. He holds a degree in Computers and certifications in ITIL® and IBM Maximo Deployment.

Rutger Mons is a IBM Certified Tivoli Deployment Consultant based at Stork Asset Management Solutions in the Benelux region.He has close to 9 years of functional and technical experience in the Maximo field.He holds a diploma in Financial Management and has various certifications in Project Management and Programming and is currently completing a degree in Informatics.

Venkatesan Ramamoorthy is an IBM-certified solutions expert with years of customer implementation experience inside and outside IBM. He is currently a next generation IT Service Management solution leader in IBM Tivoli. He is ITIL certified and works closely with customer and globally distributed Maximo teams in architecting and developing service management solutions. He holds several patents in his area of expertise.

Vikas Sharma is a Solutions Consultant for Birlasoft Inc, USA. He has around 5 years of experience primarily in designing complex and innovative IT solutions primarily in the fields of Enterprise Asset Management®, IT Asset and Service Management. He holds a Masters degree in Computer Applications from IP University, India. His areas of expertise include Solution Designing, Project Management, Customer Relationship Management.

Thanks to the following people for their contributions to this project:

Don Busiek, IBM Dave Calvert, IBM Tom Davis, IBM Anthony Honaker, IBM Sharad Joshi, Birlasoft Alfons Kemper, Stork - AMS Michael Kuijl, Stork - AMS Dean La Porte, IBM Carlos Marin, IBM Dan Matlis, Axendia Inc Colleen McCretton, IBM John Pasini, EMA Inc Kumar Rampura, Birlasoft John Reeve, TAIC Eyco Rogge, Avenue Business IT Solutions Tom Sarasin, IBM Mohamed Skandaji, Groupe Createch Sampath Sriramadhesikan, IBM Vikas Srivastava, Birlasoft

7645pref.fm Draft Document for Review May 23, 2008 10:14 am

xii Maximo Essentials V7.1 - Implementer’s Guide

Become a published author

Join us for a two- to six-week residency program! Help write a book dealing with specific products or solutions, while getting hands-on experience with leading-edge technologies. You will have the opportunity to team with IBM technical professionals, Business Partners, and Clients.

Your efforts will help increase product acceptance and customer satisfaction. As a bonus, you will develop a network of contacts in IBM development labs, and increase your productivity and marketability.

Find out more about the residency program, browse the residency index, and apply online at:

ibm.com/redbooks/residencies.html

Comments welcome

Your comments are important to us!

We want our books to be as helpful as possible. Send us your comments about this book or other IBM Redbooks in one of the following ways:

򐂰 Use the online Contact us review Redbooks form found at:

ibm.com/redbooks

򐂰 Send your comments in an e-mail to:

redbooks@us.ibm.com

򐂰 Mail your comments to:

IBM Corporation, International Technical Support Organization Dept. HYTD Mail Station P099 2455 South Road Poughkeepsie, NY 12601-5400

Draft Document for Review May 23, 2008 10:14 am 7645introduction.fm

Chapter 1. Introduction

This chapter introduces the basic concepts of Asset Management and how Maximo Asset Management Essentials as a product can be used as an enabler for those processes. We also talk about the functional layout of Maximo Asset Management Essentials.

1.1 Enterprise asset management overview

Enterprise asset management is the process of managing an organization’s assets throughout their life cycle - right from requisition to retirement. The word “Enterprise” relates to multiple organizations, departments, functions, and in some cases can even mean business units. “Assets” in this context can be defined as any equipment or facility which plays a key role in the core business of the enterprise. The concept of “Management” is basically applied to improve utilization and performance of an asset and thereby improve return on investment (ROI).

Asset life cycle typically contains the following phases

a. Requisition - At this stage some one or some function in an organization

raises a request for an asset. At this stage the asset can be either procured from a vendor or it can be an inter department transfer.

b. Procurement - The complete purchasing process is the second stage in

the asset life cycle. This process includes creation of purchase requisition,

7645introduction.fm Draft Document for Review May 23, 2008 10:14 am

2 Maximo Essentials V7.1 - Implementer’s Guide

creation of request for quotation, generation of purchase order, receiving an asset at a location and creation of an invoice.

c. Commissioning - At this stage of the asset life cycle, it is assigned to a

location, user or group of users. The cost of operating the asset is now attributed the owner of the asset. Also, asset availability is now the responsibility of the owner. This includes maintaining the asset regularly to ensure the asset is up and running whenever business needs it. The various activities that are typically undertaken at this point are Work orders, job plans, safety planning, preventive maintenance, emergency maintenance and / or seasonal maintenance

d. Retirement - Some enterprises call this decommissioning too, this is the

stage where an enterprise decides to replace or remove the asset. However, the importance of this stage from an enterprise asset management perspective is to be able to calculate the residual cost of the asset and also in certain cases being able to transfer parts of the asset to another asset. For instance, say few months ago someone just replaced a critical and expensive part of an asset because of a fault and that part can now be re-used since it not very old but is expensive.

The concept of Enterprise Asset Management evolved from Computerized Maintenance Management System (CMMS). An enterprise’s assets are very critical and with the global competition it s becoming imperative for companies to maintain and plan various stages of the asset life cycle strategically. Thus, the reason for having Enterprise Asset Management as a dedicated function within an organization which encompasses purchasing, engineering, accounting and maintenance management.

Broadly, the benefits of enterprise asset management can be summarized as:

򐂰 Cost Reduction 򐂰 Legal Requirements 򐂰 Better Planning 򐂰 Competitive Advantage 򐂰 Information Availability

1.2 Maximo Asset Management Essentials

IBM Maximo Asset Management Essentials is an asset management system that provides asset management, maintenance management, inventory management, purchasing capabilities that help corporations maximize productivity and increase the life of assets.

Chapter 1. Introduction 3

Draft Document for Review May 23, 2008 10:14 am 7645introduction.fm

This solution is targeted towards small-to-medium businesses who do not have multiple sites and just need a subset of the core functionality of Maximo. Maximo Asset Management Enterprise has been a leader in enterprise asset management for many years. IBM Maximo is the only solution to have been placed in the EAM Leader’s Quadrant 11 times since 1998.

However, smaller businesses can benefit from the core functionality of Maximo and do not need an enterprise level solution for asset management. Thus, Maximo Asset Management Essentials has been created, which is a lighter, less complex version of Maximo Asset Management Enterprise 7.1. The differences in functionality will be discussed in subsequent sections of this book.

Maximo allows companies to manage assets by providing information and real time data thereby enabling creation of a strategy for maintenance management by information based decision making capabilities, help in predicting impacts of asset downtime on productivity for all categories of assets.

1.2.1 General Functional Overview

IBM Maximo Asset Management Essentials is an integrated productivity tool and database that helps you achieve maximum efficiency in asset management by managing all of your asset types on a single software platform. Built on a service oriented architecture (SOA), Maximo Asset Management Essentials delivers a comprehensive view of all asset types, locations, and the work processes which support them, to provide you with optimal planning, control, audit, and compliance capability.

The Maximo database provides critical information about asset resources, including key attributes, their configuration, and their physical and logical relationships to other resources. You can also include attachments, such as maps, pictures, and URLs to each record or task to further enhance communication and productivity.

IBM Maximo Asset Management Essentials allows you to effectively manage end-to-end asset operations and business processes to deliver efficient and effective services aligned with your business goals. It provides a comprehensive and modular approach to integrated asset control and visibility by providing an enterprise platform for storing standardized data on asset histories to help integrate people, processes, information, and technology. Maximo Asset Management Essentials offerings include tools, best practices, and service offerings for incremental value.

Managing assets through Maximo Asset Management Essentials gives your business a competitive advantage.

7645introduction.fm Draft Document for Review May 23, 2008 10:14 am

4 Maximo Essentials V7.1 - Implementer’s Guide

1.2.2 Modules

Maximo Asset Management Essentials is a subset of Maximo Asset Management for Enterprise. Both the products have the same look and feel, similar navigation and functionality.

The product is composed of Modules, which in turn contain applications or sub-applications. Users access the lowest level, whether it is an application or sub-application for functionality.

The Maximo Asset Management Essentials solution has multiple modules to assist the end user. Six of these key management modules are:

򐂰 Asset 򐂰 Work 򐂰 Service 򐂰 Contract 򐂰 Materials 򐂰 Procurement Management

Together, these modules help you capture and analyze your asset and work data and help you optimize maintenance and service initiatives throughout your organization. These six management modules are packaged in an enhanced service oriented architecture that helps simplify the creation of Web services and supports additional Web service standards such as WS-Security.

Built on a Java™ Platform, Enterprise Edition (Java EE) component-based Internet architecture, Maximo Asset Management Essentials fits in any modern enterprise technology infrastructure and integrates easily with your business systems. With a significant focus on configuration tooling, such as Application Designer for modifying the user interface and Database Configuration for adding new tables, columns and rows. Maximo Asset Management Essentials makes it easier to tailor the software to your needs without programming. Furthermore, your configurations are upgraded with the Upgrade Utility, thus keeping you from being locked in from one application release to another.

Each key module and the business goals for which you can use it are as described in the following sections.

Asset Management

Achieve the control you need to more efficiently track and manage asset and location data throughout the asset life cycle.

򐂰 Track asset detail—including location, work, cost and other attributes and

their histories— over time, to help maximize productivity and extend asset life.

Chapter 1. Introduction 5

Draft Document for Review May 23, 2008 10:14 am 7645introduction.fm

򐂰 Establish location and asset hierarchies to roll up costs across systems,

subsystems, departments and locations, enabling a better understanding of the true cost of assets (initial cost, financial value, cost to maintain, and so on).

򐂰 Monitor asset and location conditions to enable proactive—rather than

reactive—maintenance that helps reduce unplanned downtime.

򐂰 Support both conventional and linear assets.

Work Management

Manage both planned and unplanned maintenance activities, from initial work request and work order generation through completion and recording of actuals. Work planners can match job tasks to available resources, estimate and obtain approval of costs, establish priorities, and initiate maintenance activities across the enterprise. Work management supports your business goals by providing the following benefits:

򐂰 Tracking tools enable more detailed analysis of resources, inventory and

equipment use and costs, helping decrease labor and materials costs.

򐂰 Multiple assets, locations and configuration items are allowed per work order

or ticket. Work management also supports work order tracking, task sequencing, attaching documents at the task level and generating work orders from asset information.

򐂰 A graphical assignment manager helps optimize maintenance schedules and

labor use by assigning the right person with the right skills to the right job.

򐂰 Preventive maintenance (PM) functionality allows you to put PM schedules in

place with the right job steps and resource requirements, facilitating the planning as well as the work, to help reduce unplanned downtime and reactive maintenance.

򐂰 Newly developed work management tools enable job plan hierarchies,

automated workflow processes, enhanced status control, and support for linear assets.

򐂰 Contract correlation links SLAs to vendor contracts, helping you identify

unreliable vendors as well as low-quality products. It also enables you to reference SLA performance metrics when renegotiating vendor terms.

򐂰 A terms and conditions library allows you to more consistently apply

standardized policies across the organization.

򐂰 Automatic notifications and alerts help you meet vendor terms, avoid

penalties and get the most value out of every contract.

7645introduction.fm Draft Document for Review May 23, 2008 10:14 am

6 Maximo Essentials V7.1 - Implementer’s Guide

Materials Management

Know the details—what, when, where, how many, how valuable—about asset-related inventory and its usage. Materials management functionality records material movements and adjustments, allowing for real-time inventory tracking, reporting and auditing. This module also allows embedded images of an asset to be displayed in the catalog search. You can also use it to:

򐂰 Track inventory transactions to help streamline parts and materials

management.

򐂰 Help decrease costs by eliminating excess or obsolete inventory. 򐂰 Help optimize and plan inventory to more accurately meet maintenance

demand, making the right parts available at the right location when needed. As a result, you can help reduce stock-outs, inventory shrinkage and carrying costs, as well as help foster economies of scale through shared resources.

Procurement Management

Support the phases of enterprise-wide procurement, including direct purchasing and inventory replenishment. You can provide buyers with more extensive requisition, quotation, vendor, purchase order and contract capabilities, thereby allowing them to plan work more proactively. Maximo Asset Management Essentials easily integrates with enterprise business systems from vendors such as Oracle® and SAP, and also connects to online marketplaces, supplier systems and exchanges. This module provides:

򐂰 Vendor management and vendor performance analysis tools that can help

reduce costly off-contract buying, and help verify the reliability of vendors and the quality of inventory and services.

򐂰 Automated interval-based, meter-based or event-driven purchasing

capabilities to help you order the right parts and services at the right time, which can improve purchasing efficiency.

򐂰 Global purchasing support that can enable group purchasing savings and

efficiencies, and can help lower sourcing costs.

򐂰 Analysis tools and key performance indicators (KPIs) which measure

procurement performance such as order processing times, invoice accuracy and order delivery times.

Service Management

Allow end users to submit new service requests, as well as to track and update open service requests. Though service management is provided as part of the enterprise version of maximo Asset Management, the Maximo Asset Management Essentials product does not provide all of this capability.

Chapter 1. Introduction 7

Draft Document for Review May 23, 2008 10:14 am 7645introduction.fm

Contract Management

Have enhanced control over your vendor contracts with this integrated contract management system. Provide comprehensive contract management support for purchase, lease, rental, warranty, labor rate, software, master, blanket and user defined contracts.

1.2.3 Integrating with Existing Enterprise Applications

From a functional standpoint, most businesses already have huge IT investments. There is often the question - “Does installing Maximo mean I get rid of existing applications?” The answer is - No. Maximo offers a very robust integration platform to integrate with any existing applications and maintain a ‘single version of truth’.

Some of the integration with leading enterprise systems are already available in the form of adapters where as some have to be custom built, as the need may be. Maximo is a Java based solution with an open architecture and therefore custom building integrations is not a daunting task.

Maximo Asset Management Essentials provides support for a set of standard integrations, but does not ship with the capability to customize those adapters or build new ones. The Integration Framework, previously known as the Maximo Enterprise Adapter (MEA) be procured as an add-on from IBM to facilitate these integrations.

7645introduction.fm Draft Document for Review May 23, 2008 10:14 am

8 Maximo Essentials V7.1 - Implementer’s Guide

Draft Document for Review May 23, 2008 10:14 am 7645New.fm

Chapter 2. Maximo Asset Management

Essentials 7.1

This chapter provides details of Maximo Asset Management Essentials 7.1 and an overview of each of the features available for Asset Management. Maximo Asset Management Essentials is a lighter version of Maximo Enterprise Asset Management.

An entry-level member of the IBM Maximo Asset Management product family, Essentials, is ideal for smaller organizations that require a subset of the extensive range of features in the IBM Maximo Asset Management Product. With Essentials, smaller organizations can take advantage of proven Maximo Asset Management technology, while also enjoying cost savings. Small organizations, with smaller asset management needs are good candidates to choose Maximo Asset Management Essentials compared to the fully blown enterprise version of the product which is predominantly implemented for larger organizations with multiple companies, sites, and process complexity.

The following are the main areas of focus for Maximo Asset Management Essentials

򐂰 Optimum for the small-to-medium business 򐂰 Has a licensing restriction of a maximum of 25 named users. 򐂰 Limited functions, and therefore reduced implementation planning and

deployment effort.

7645New.fm Draft Document for Review May 23, 2008 10:14 am

10 Maximo Essentials V7.1 - Implementer’s Guide

򐂰 Has enterprise wide capability for asset management with simplicity for a

small medium business

򐂰 Has straight-forward licensing 򐂰 Leverages the enterprise architecture and allows for upgrade to enterprise

solution wherever required.

򐂰 Allows maximum of two languages - Base language +1 򐂰 Allows maximum of two currencies - Base currency + 1

Advanced applications not included nor available with Essentials:

򐂰 Workflow 򐂰 Condition Monitoring 򐂰 Desktop Requisitions 򐂰 Financial - Cost Management 򐂰 Routes 򐂰 Hazards 򐂰 Precautions 򐂰 Lock Out/Tag Out 򐂰 Safety Plans

Components not available for purchase with Essentials:

򐂰 Industry Solutions 򐂰 Spatial 򐂰 Linear 򐂰 Calibration 򐂰 Change and Corrective Action Manager 򐂰 SLA Manager 򐂰 ERP Integration (SAP, Oracle)

Customers needing the above functionality must purchase the Maximo Asset Management Enterprise product.

2.1 Differences with Maximo Asset Management Enterprise

The following table provides a summary of the various modules, applications and sub-applications, and identifies those that are included in both the Maximo Asset Management enterprise version and those in the Maximo Asset Management Essentials offering.

Chapter 2. Maximo Asset Management Essentials 7.1 11

Draft Document for Review May 23, 2008 10:14 am 7645New.fm

Table 2-1 Summary of modules by offering

Maximo Asset Management

Module Application Sub-Application Enterprise Essentials

Administration Sets Y Y

Organizations Y Y

Calendars Y Y

Resources Labor Y Y

Qualifications Y Y

People Y Y

Person Groups Y Y

Crafts Y Y

Bulletin Board Y Y

Communication Te m pl a t e s

Reporting KPI Manager Y Y

Report Administration

Conditional Expression® Manager

Classifications Y Y

CI Types Y N

Work View Y Y

Assets Assets Y Y

Locations Y Y

Features Y N

Meters Y Y

Meter Groups Y Y

Condition Monitoring

7645New.fm Draft Document for Review May 23, 2008 10:14 am

12 Maximo Essentials V7.1 - Implementer’s Guide

Failure Codes Y Y

Change Activities and

Tasks

Contracts Purchase

Contracts

Lease/Rental Contracts

Labor Rate Contracts

Master Contracts Y Y

Warranty Contracts

Financial Currency Codes Y Y

Exchange Rates Y Y

Chart of Accounts Y Y

Cost Management Y N

IT Infrastructure

Configuration Items

Relationships Y N

Collections Y N

Integration Object Structures Y Y

Publish Channels Y Y

Invocation Channels

Enterprise Services

Web Services Library

End Points Y Y

External Systems Y Y

Maximo Asset Management

Chapter 2. Maximo Asset Management Essentials 7.1 13

Draft Document for Review May 23, 2008 10:14 am 7645New.fm

Logical Management Operations

Integration Modules

Launch in Context Y Y

Message Tracking Y Y

Message Reprocessing

Inventory Item Master Y Y

Service Items Y Y

To o ls Y Y

Stocked Tools Y Y

Inventory Y Y

Issues and Transfers

Condition Codes Y Y

Storerooms Y Y

Planning Job Plans Y Y

Routes Y N

Safety Hazards Y N

Precautions Y N

Lock Out / Tag Out

Safety Plans Y N

Preventive Maintenance

Master PM Y Y

Purchasing Purchase

Requisitions

Maximo Asset Management

7645New.fm Draft Document for Review May 23, 2008 10:14 am

14 Maximo Essentials V7.1 - Implementer’s Guide

Purchase Orders Y Y

Receiving Y Y

Invoices Y Y

Request for Quotations

Companies Y Y

Company Master Y Y

Release Activities and

Tasks

Security Security Groups Y Y

Users Y Y

Self Service Desktop

Requisitions

Create Requisition

View Requisition Y N

View Templates Y N

View Drafts Y N

Service Requests Create Service

Requests

View Service Requests

Service Desk Activities and

Tasks

Service Requests Y Y

Ticket Templates Y Y

System Configuration

Platform Configuration

System Properties

Logging Y Y

Domains Y Y

Database Configuration

Maximo Asset Management

Chapter 2. Maximo Asset Management Essentials 7.1 15

Draft Document for Review May 23, 2008 10:14 am 7645New.fm

Application Designer

Communication Te mp l a te s

Actions Y Y

Roles Y Y

Escalations Y Y

Workflow Designer

Workflow Administration

Cron Task Set-up Y Y

E-mail Listeners Y N

Object Structures Y N

Web Services Library

Launch in Context

Migration Migration

Manager

Migration Groups Y Y

Object Structures Y Y

Task Management

Activities and Tasks

Work Orders Work Order

Tracking

Labor Reporting Y Y

Quick Reporting Y Y

Activities and Tasks

Assignment Manager

Maximo Asset Management

7645New.fm Draft Document for Review May 23, 2008 10:14 am

16 Maximo Essentials V7.1 - Implementer’s Guide

Service Requests Y Y

Maximo Asset Management

Draft Document for Review May 23, 2008 10:14 am 7645ProjPlan.fm

Chapter 3. Project Planning

This chapter describes various parameters that should be considered in planning an implementation right from technical options in terms of database, application server and operating system to required skills. A Maximo Asset Management Essentials implementation is assumed to be simpler and less time consuming than an enterprise wide implementation. The underlying assumption in this chapter is a basic implementation with out of box components for middleware, database and so on. After reading this chapter, the implementation team should be able to create a high level project plan with ballpark effort and time estimates for a typical implementation.

We have not created an implementation plan which fits for each implementation since all of them are different. Each customer is unique and the requirement set of each customer differs. However, for the purpose of this chapter and to maintain simplicity as Essentials is not supposed to be as complex as a Maximo enterprise implementation, the following parameters have been taken into consideration:

򐂰 Infrastructure Selected

– Operating System - Windows® – Database - DB2® – Application Server - WebSphere

򐂰 No integration with other third party systems 򐂰 Existing data sets for data migration

7645ProjPlan.fm Draft Document for Review May 23, 2008 10:14 am

18 Maximo Essentials V7.1 - Implementer’s Guide

򐂰 Customer will follow processes as the tool guides them

Although the tool also support other operating system, database platforms and leading application servers, these combinations can greatly impact the project schedule. These parameters shall be carefully examined during the requirements gathering.

Keeping the project simple, typically there will be the following phases in an implementation:

򐂰 Phase 1: Requirement Gathering and Analysis 򐂰 Phase 2: Solution Design 򐂰 Phase 3: Deployment 򐂰 Phase 4: Testing and Go-Live 򐂰 Phase 5: Support

The subsequent sections will talk about the people, process and technology that are required in each of the above phases.

3.1 Required Skills

The project delivery team is most fundamental to success of a project. The exact number of people required will vary with project, organization experience, reusable components and methodology. Nevertheless, the people comprising the team shall be playing the following roles:

Project Manager

The project manager shall perform the following activities:

򐂰 Own the implementation end-to-end. 򐂰 Be the single point of contact for the customer 򐂰 Facilitate customer interactions. 򐂰 Project status reporting. 򐂰 Monitor project progress on regular intervals. 򐂰 Escalate issues to the right people. 򐂰 Change control agent for scope creep. 򐂰 Make available resources, man and material, for the project.

Business Analyst

The business analyst is a functional person who understands the product and also the customer’s domain. This person can speak with the customer in his language and have the ability to translate customer’s requirements to the technical team. This is a very key role and is vital to success of the project. The following are the attributes of this role:

Chapter 3. Project Planning 19

Draft Document for Review May 23, 2008 10:14 am 7645ProjPlan.fm

򐂰 Domain Knowledge. 򐂰 Functional knowledge of Maximo. 򐂰 Working knowledge of UML. 򐂰 Knowledge of industry best practices to suggest to client.

Solution Architect

The solution architect is the person who designs the complete solution. This includes the integration with various third party systems. The various attributes and tasks this role undertakes are:

򐂰 Strong technical skills on Maximo 򐂰 The ability to map business processes to technology 򐂰 Understand functional integration points 򐂰 Understand technical integration points 򐂰 Build the overall solution design 򐂰 Walk the team on how the various aspects of implementation will be achieved 򐂰 Resolve technical issues

Maximo Developer

This group of people will actually install and configure the software to work in accordance with the customer’s needs. The major tasks to be performed by the developers are:

򐂰 Maximo installation 򐂰 Configuration of screens, information flow 򐂰 Work on integration 򐂰 Develop custom classes, if required 򐂰 System optimization

Testers

Critical to every project is testing - System Integration, Functional and Performance. Depending on the complexity of the project this role can be played by the developer or there can be a specialized group for this. The major tasks include:

򐂰 Functional Testing: Testing the flows, communication templates, data flow

between screens and functions for accuracy.

򐂰 System Integration: Testing the integrations to ensure the data between

systems is flowing accurately.

򐂰 Performance Testing: This test ensures response times are accurate and the

system is responding in the most optimum way.

Database Administrators

Like any enterprise system, Maximo’s database will be accessed by multiple people and multiple times. The uptime of the database is very critical and the

7645ProjPlan.fm Draft Document for Review May 23, 2008 10:14 am

20 Maximo Essentials V7.1 - Implementer’s Guide

transaction processing capabilities have to be at their best at all times. The DBA shall perform the following activities:

򐂰 Trouble shoot database creation 򐂰 Database installation if other than DB2 򐂰 Database optimization 򐂰 Facilitate Database level integrations with enterprise systems

Application Server Specialist

Depending on choice of application server, WebSphere or WebLogic, part time involvement of application server specialist or administrator may be required. This becomes more important if the implementation is complex with many integrations and in a clustered environment.

Integration Specialist

This is an optional group of people and the size and skill of the integration team may vary from customer to customer. Some special systems such as SAP, Oracle and other niche products may require technical experts. Depending on the project the main task will be to facilitate integration with external systems and ensure bidirectional movement of data

The above list of various roles is not a permanent fixture for each project. There can be more roles that are required and more than one person in a role. As mentioned before each project is different and it is hard to generalize, however, we have tried to cover most scenarios that we have encountered in our implementation experiences.

3.2 Solution Description and Assumptions

This section will talk about a high level solution architecture and the standard assumptions that are taken while project planning.

The following figure represents the Maximo Asset Management Essentials solution architecture.

Chapter 3. Project Planning 21

Draft Document for Review May 23, 2008 10:14 am 7645ProjPlan.fm

Figure 3-1 Solution architecture

Maximo being a browser based application can be accessed remotely.

The three layers above can be complicated depending on a customer’s requirements and network set-up. All or some of the Modules of Maximo Asset Management Essentials may be implemented. The integration layer separates the enterprise applications from the core Maximo engine.

Some standard assumptions while project planning are:

򐂰 The software is procured prior to project initiation 򐂰 There are three environments - Development, Testing and Production 򐂰 The application server, database server and reporting engine are all kept in

separate physical servers

򐂰 Customer shall own any configurations required in the enterprise systems to

facilitate integrations

򐂰 Customer’s involvement during the initial project stages is pretty high because

a lot of the functional and business process knowledge specific to the customer needs to transferred to the implementation team

7645ProjPlan.fm Draft Document for Review May 23, 2008 10:14 am

22 Maximo Essentials V7.1 - Implementer’s Guide

򐂰 There is a management buy-in for this project. 򐂰 A dedicated single point of contact and project manager is appointed from the

customer to manage interactions with end users

򐂰 Historic data migration can be done by implementation team but data

cleansing and scrubbing needs to be owned by the customer.

3.3 Task Break Down

The standard phases of a Maximo Essentials implementation project are:

򐂰 Phase 1: Requirement Gathering and Analysis 򐂰 Phase 2: Solution Design 򐂰 Phase 3: Deployment 򐂰 Phase 4: Testing and Go-Live 򐂰 Phase 5: Support

The key activities in each of the phases are explained in the following sections.

Phase 1: Requirement Gathering and Analysis

Roles Involved: Project Manager, Business Analyst, Solution Architect

Key Activities: 򐂰 Understand current business processes for

– Maintenance Management, – Procurement, – Inventory Management – Asset Management

򐂰 Document pain areas with existing business processes 򐂰 Demo the vanilla product 򐂰 Understand and document the end goal and vision of the customer 򐂰 Document ‘To-Be’ business processes for each of the functions mentioned

above

򐂰 Analyze the points of integration 򐂰 Analyze the current data sources 򐂰 Creation of a SRS (Software Requirements Specification) document

Phase 2: Solution Design

Roles Involved: Project Manager, Business Analyst, Solution Architect

Chapter 3. Project Planning 23

Draft Document for Review May 23, 2008 10:14 am 7645ProjPlan.fm

Key Activities:

򐂰 Identify module requirements 򐂰 Identify configuration requirements in terms of:

–Roles – Security groups – Escalations – Communication Templates – Work Order Templates – Job plans –SLAs – Vendors and Contracts – Screen configurations – GL Codes

򐂰 Create a detailed implementation plan 򐂰 Identify methodology for integration 򐂰 Identify scripting or manual data migration approach from identified data

sources

򐂰 Create a solution architecture diagram

Phase 3: Deployment

Roles Involved: Project Manager, Solution Architect, Maximo Developers

Optional Roles: DBA, Application Server Specialist (depending on environment)

Key Activities:

This phase consists of the following activities: 򐂰 Software Installation

– Install the various components if doing a Manual install – Run the launchapd for an automated install – Test if the installation is successful

The software installation will be different for various deployment topologies single server, multi-server, clustered environment. It will also depend on what infrastructure is selected.

򐂰 Software Configuration

– Basic operation configuration which includes, but is not limited to:

• Creation of organization

• Creation of locations

• Creation of GL Codes

7645ProjPlan.fm Draft Document for Review May 23, 2008 10:14 am

24 Maximo Essentials V7.1 - Implementer’s Guide

• Creation of users, roles and security groups

• Configure role based start centers

• Creation of Job plans, work orders

– Configuration of the tool to map to business processes which includes, but

is not limited to:

• Addition or deletion (as the case may be) of fields on screen and database

• Create communication templates

• Create escalation points and define SLAs in the system

• Create and test data migration scripts

• Migrate data from its existing source to Maximo

• Build integration interfaces - either using custom code or MEA (as the case may be)

• Creation and deployment of reports

Phase 4: Testing and Go-Live

Role Involved: Project Manager, Solution Architect, Testers, Maximo Developers

Optional Roles: DBA, Application Server Specialist

Key Activities: 򐂰 Te st in g

The first key task is migration from development environment to test environment. Depending on the customer’s environment and the complexity of implementation, customer may decide to use automated tools for testing or a manual approach, nevertheless all or some of the following types of testing needs to be carried out:

– Functional Testing

• Test validations in new fields

• Test emails being sent on escalations

• Test accuracy of data flowing between modules in the system

• Test data accuracy in reports

– System Integration Testing

• Test accuracy of data coming from external systems

• Test accuracy of data going into external systems

• Scenario testing to ensure there is nothing that affects availability of any system

– Performance Testing

• Page Load time

• Peak load

Chapter 3. Project Planning 25

Draft Document for Review May 23, 2008 10:14 am 7645ProjPlan.fm

• Concurrent users

• Transaction processing time with database and external data sources

򐂰 Go-Live

– Plan cut-over strategy – Migration to production environment – Execute each of the above test cases introduction environment to ensure

zero-performance glitch in the live environment

– Training needs to be provided to all or some of the users. Recommended

approach is ‘Train-the-Trainer’. Training to 3 types of users:

• End Users: Functional training to the user community on how to use various functional aspects of the software. This can be done with focussed groups or general groups depending on how the client organization is structured

• Role Based Training: This training is specific to certain groups. Support Purchase Administrator, Supervisor and so on, on how they can approve or disapprove certain tasks, manage their queue and so on

• Administrative Training: Once the implementation team walks out, there has to be an internal designated person to manage the system. This person will be responsible for system availability, creation of new reports, enhancements, adding users, roles security groups and so on.

Phase 5: Support

Key Roles: Project Manager, Maximo Developers

Optional Roles: Business Analyst, Solution Architect

Key Activities:

Some organizations do not have strong IT presence and opt for the implementation team to provide continued system support. The basic tasks the support team has to perform are, but are not limited to:

– Manage system availability – Make enhancements to accommodate evolving business processes – Create and deploy new reports – Build new integrations – Capacity planning for additional users and or organizations

The above five phase methodology is generic but includes most of the basic activities that need to be considered and planned for in an implementation. However, what the section does not include is how and what is the customer’s

7645ProjPlan.fm Draft Document for Review May 23, 2008 10:14 am

26 Maximo Essentials V7.1 - Implementer’s Guide

involvement at each stage. For each of the above mentioned phases, the expectations from the customer are given in the below table

Table 3-1 Expectations from the customer

Phase Expectations from the Customer

Requirement Gathering and Analysis

򐂰 Assign a single point of contact from within 򐂰 Explain the project vision, short term and

long term objective

򐂰 Facilitate meetings with individual process

owners

򐂰 Facilitate meetings with tool owners 򐂰 Procure hardware and software required for

the project

򐂰 Review documentation

Solution Design 򐂰 Review solution architecture

򐂰 Review documentation and project plan

Deployment 򐂰 Provide hardware and software

򐂰 Provide administrative access to systems

wherever required

򐂰 Monitor project progress 򐂰 Participate in reviews

Testing and Go-Live 򐂰 Provide test and production environment

򐂰 Provide data for User Acceptance Testing 򐂰 Facilitate in UAT 򐂰 Attend training 򐂰 Provide man and material resources

required for training

Support 򐂰 Define support scope of work boundaries

򐂰 Review support plan and SLAs

Draft Document for Review May 23, 2008 10:14 am 7645SolEnv.fm

Chapter 4. Solution Environment

Maximo Asset Management Essentials requires multiple software servers that can be installed on separate, dedicated server machines (for best performance), or the same physical server. The different components of the Maximo Asset Management Essentials environment are listed below:

򐂰 Database: The Maximo database serves as the repository for all CI

information.

򐂰 Application Server: Maximo Asset Management Essentials is built using

Java 2 Enterprise Edition (J2EE™) technology, which requires a commercial application server, such as IBM WebSphere® Application Server. The Application Server consists of Maximo Asset Management Essentials applications using JavaServer™ Pages (JSP™), XML, and Maximo Asset Management Essentials-application-specific business components.

򐂰 HTTP server: A separate, dedicated HTTP server can be configured to work

with the J2EE application server.

򐂰 Directory server: A directory server can be configured to work with Maximo

Asset Management Essentials to maintain lists of users and groups for security purposes.

򐂰 Administrative system: The administrative system is used to deploy Maximo

Asset Management Essentials. After the initial deployment, the administrative system is used to make updates or changes to the deployment. Changes to the Maximo Asset Management Essentials deployment typically require that

7645SolEnv.fm Draft Document for Review May 23, 2008 10:14 am

28 Maximo Essentials V7.1 - Implementer’s Guide

Maximo Asset Management Essentials Enterprise Archive (EAR) files be rebuilt, which can only be done from the administrative system.

The administrative system can only be implemented as a Windows system.

4.1 Hardware and Software Requirements

Maximo Asset Management Essentials hardware and software requirements are listed below. Each product version listed reflects the minimum requirement for use with Maximo Asset Management Essentials. Maximo Asset Management Essentials components are designed to run within 32-bit environments only, with the exception of AIX® 5.3 which is a 64-bit environment.

Maximo Asset Management Essentials supported software can be run on any hardware platform supported by the database software listed in the Software column, provided the system is hosting a supported operating system, listed in the Operating System column. If available, the Maximo Asset Management Essentials administrative workstation and systems hosting Maximo Asset Management Essentials middleware can support IPv6 network configuration.

Browser

Maximo Asset Management Essentials supports Microsoft® Internet Explorer® version 6 and above.

Database

Software Operating System

򐂰 DB2 UDB 9.1.3 or v8.2.8 򐂰 Oracle 9.2.0.8,Oracle 10.2.0.3 or

Oracle 10.1.0.5, Standard or Enterprise version

򐂰 Microsoft SQL Server® 2005 SP2,

Standard or Enterprise version.

Refer to Vendor Specifications

Chapter 4. Solution Environment 29

Draft Document for Review May 23, 2008 10:14 am 7645SolEnv.fm

Directory server

Software Operating System

The following products can serve as the Directory server component of a Maximo Asset Management Essentials 7.1 deployment.

򐂰 IBM Tivoli Directory Server v6.1 FP1 򐂰 Microsoft Windows Server® 2003

SP2 Active Directory® Microsoft Active Directory Application Mode (ADAM) is not supported.

򐂰 Windows Server 2003 SP2 (Standard,

Enterprise or DataCenter) (32-bit, 64-bit)

򐂰 Windows Vista® (Business,

Enterprise, Ultimate) (32-bit, 64-bit)

򐂰 Windows XP Professional SP2 (32-bit,

64-bit)

򐂰 Red Hat Enterprise Linux v4

(Enterprise or Advanced) (update 4+5 or later) (Intel®) (32-bit)

򐂰 IBM AIX 5L™ V5.3 ML level 5300-06 򐂰 SuSE Linux (SLES) 9.0 Enterprise

Server System z™ SP4 or later (manual install only)

7645SolEnv.fm Draft Document for Review May 23, 2008 10:14 am

30 Maximo Essentials V7.1 - Implementer’s Guide

J2EE Application Server

This is where you install WebSphere Application Server and where Maximo Asset Management Essentials runs

Administrative system

Hardware Software

򐂰 2-4 dedicated Intel-based Pentium®

processors

򐂰 2 GB RAM per processor 򐂰 1.5 GB or greater of disk space for

Maximo and Java/Web Server components

򐂰 Windows Server 2003 (Standard,

Enterprise or DataCenter) (32-bit, 64-bit)

򐂰 IBM AIX5.3 or 6.1 򐂰 Red Hat Enterprise Linux 4 and 5 (x86

and x64 processor-based systems)

򐂰 SuSE Linux (SLES) 9.0 Enterprise

Server System z SP4 or later (manual install only)

Note: Although Maximo Asset Management Essentials supports the following operating systems, if you are using IBM DB2 Universal database with Maximo Asset Management Essentials

7.1, you cannot use either of the following operating systems on your application server: 򐂰 HP-UX 11i v2 (PA-RISC

processor-based systems

򐂰 Sun™ Solaris™ version 9 or 10

(SPARC processor-based systemsv

򐂰 IBM WebSphere Network Deployment

6.1.0.11 (provided by IBM Corporation)

򐂰 BEA Weblogic 9.2.2 (provided by

Customer)

Hardware Software

򐂰 Intel-based Pentium processor 򐂰 1GB RAM 򐂰 SVGA 1024 x 768 resolution; if used

for Application Designer 1280 x 1024 resolution

򐂰 Windows Vista (Business, Enterprise,

Ultimate) (32-bit, 64-bit)

򐂰 Windows XP Professional SP2 (32-bit,

64-bit)

򐂰 Adobe®

Acrobat® Reader 6.0

Chapter 4. Solution Environment 31

Draft Document for Review May 23, 2008 10:14 am 7645SolEnv.fm

Client system

4.2 Typical deployment environments

Maximo Asset Management Essential can be deployed primarily in two different topologies with in an enterprise.

4.2.1 Single-server

The single-server topology consists of loading all Maximo Asset Management Essentials components onto one machine. This would be done typically for proof-of-concept purposes, as a demonstration, or as a learning environment. For managing enterprise assets and processes, you would typically implement a multi-server topology.

The following figure details the Application Server MXServer running Maximo Asset Management Essentials on a single physical machine.

Hardware Software

򐂰 Intel-based Pentium processor 򐂰 1GB RAM 򐂰 SVGA 1024 x 768 resolution

򐂰 Windows Vista (Business, Enterprise,

Ultimate) (32-bit, 64-bit)

򐂰 Windows XP Professional SP2 (32-bit,

64-bit)

򐂰 Adobe Acrobat Reader 6.0 and above

7645SolEnv.fm Draft Document for Review May 23, 2008 10:14 am

32 Maximo Essentials V7.1 - Implementer’s Guide

Figure 4-1 Single Server Deployment

4.2.2 Multi-server

The multi-server topology consists of splitting Maximo Asset Management Essentials components across several different machines. This is beneficial as it optimizes resource use and decreases each system’s workload. This type of deployment would be typical for production use within an enterprise.

Maximo Asset Management Essentials should be deployed on multiple machines in order to provide load balancing, availability, reuse, and redundancy. This is the recommended deployment topology for a production environment.

When contemplating your deployment strategy, you must determine if it will include systems already established in your network. Implementing Maximo Asset Management Essentials by installing all new components using the Maximo Asset Management Essentials middleware and Maximo Asset Management Essentials installation programs will simplify the deployment. If you plan to reuse or migrate resources that already exist in your network, make adjustments to your rollout plan to allow time for things such as bringing the existing resources to version levels that are compatible with Maximo Asset Management Essentials.

In a disparate environment, the collection of machines in this deployment could be a mixture of Windows and UNIX® machines. Only the Administrative system must be hosted on a Windows system.

Chapter 4. Solution Environment 33

Draft Document for Review May 23, 2008 10:14 am 7645SolEnv.fm

Following figure displays the typical multi-server deployment environment.

Figure 4-2 Multi-Server Deployment

A typical deployment life cycle might begin with a single-server topology that would move through phases of demonstration, functional proof-of-concept, and testing integration within the existing environment, and then gradually move towards a pilot multi-server environment before finally implementing a production deployment within the enterprise.

4.3 Sizing Considerations

Sizing hardware for an application is a very critical task. One of the major objectives of sizing is to get right performance and the other is being able to support the enterprise's growth in terms of number of users for the application. Capacity Planning and Availability management are two important functions that need to be considered while sizing hardware for an application. Following are the few factors that one should consider for hardware sizing.

򐂰 Cron Task: Cron tasks are behind-the-scene jobs set to run automatically

and on a fixed schedule. These jobs might process a number of records depending on the nature of the job. As the complexity and number of these jobs increases they consume a lot of resources and therefore become an important point for hardware sizing.

7645SolEnv.fm Draft Document for Review May 23, 2008 10:14 am

34 Maximo Essentials V7.1 - Implementer’s Guide

򐂰 Integrations: There can be multiple integration points in an implementation

like HRMS, Invoicing, and Finance. and these can be both inbound as well as outbound. Only the generic integration adapters are available with Maximo Asset Management Essentials.

򐂰 Modules: Not all the implementations comprise of usage of each and every

module within Maximo Asset Management. This may depend on the business process of the organization and if there are any existing maintenance management software in place.

򐂰 Level of Customization: The customization of different applications may

vary from minor field re-labeling to cloning an entire application. Before the implementation begins, the implementation team should calculate the deviation of standard Maximo application from the requirements in place to decide on the necessary hardware to support this.

򐂰 Reports: Reporting is an important component of any Maximo

implementation. Management takes all the business decisions based on the data that is produced to them in the form of reports which is extracted using highly complex methods and scripts from the database. The number of such reports makes a huge impact on the performance of the system.

򐂰 Language: Depending on the different languages that need to be supported

by the system the complexity increases. System needs to ensure that data is stored in supported languages and when it is being displayed on the user interface it is in the language of the logged in user. Maximo Asset Management Essentials supports only the Base Language +1.

򐂰 Add-ons: All the Add-ons that the implementation might require should be

identified and listed to ensure that hardware sizing is done taking into account these as well.

򐂰 Link Documents: If the organization decides to configure link documents

and use this feature as a practice, then it should be ensured that the servers have necessary storage space and also attaching the documents is not creating storage and retrieval performance issues.

4.4 Maximo Asset Management Essentials Supported Platforms

Refer to the table below to find the supported platforms by IBM Maximo Asset Management Essentials.

Maximo 6.1 Maximo 6.2.1 Maximo 7.1

Operating Systems

Chapter 4. Solution Environment 35

Draft Document for Review May 23, 2008 10:14 am 7645SolEnv.fm

AIX 5.2 (32 bit) x x

AIx 5.3 (32 bit) x x x

AIX 5.3 (64 bit) x x x

Solaris 9 (Sparc) x x x

Solaris 10 (Sparc) x x x

HP-UX 11i v1 (PA-RISC) x

HP-UX 11i v2 (PA-RISC) x

Windows Server 2000 x x

Windows Server 2003 Enterprise Edition x x

Windows Server 2003 Enterprise x64 Edition x x

Red Hat Enterprise Linux 3 (x86, 32 bit) x x

Red Hat Enterprise Linux 4 (x86, 32 bit) x

Red Hat Enterprise Linux 4 (zLinux) x

Red Hat Enterprise Linux 5 (x86, 32 bit) x

Application Server

IBM WebSphere 6.0 x x

IBM WebSphere 6.1 x

BEA WebLogic 8.1 x x

BEA WebLogic 9.2 x

Databases

IBM DB2 UDB 8.2 for Linux, UNIX and Windows x x

IBM DB2 UDB 9.2 for Linux, UNIX and Windows x

Oracle 9i v2 x x x

Oracle 10 Rel1 x x x

Oracle 10 Rel2 x x x

Microsoft SQL Server 2000 x x

Microsoft SQL Server 2005 (32bit) x x x

Maximo 6.1 Maximo 6.2.1 Maximo 7.1

7645SolEnv.fm Draft Document for Review May 23, 2008 10:14 am

36 Maximo Essentials V7.1 - Implementer’s Guide

Microsoft SQL Server 2005 (64bit) x x

Browsers & Client Operating Systems

Internet Explorer 6.0.x x x

Internet Explorer 7.0.x x x

Windows Vista x

Windows XP Pro(Client) x x x

Report Writers

Actuate iServer 8 x x

Actuate iServer 9 (for existing users only) x

BIRT 2.1.2 x

Maximo 6.1 Maximo 6.2.1 Maximo 7.1

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Chapter 5. Installation

In this chapter we will discuss installation of the pre-requisite middleware, the Maximo base set of services (sometimes referred to as the Tivoli Process Automation Platform) and the Maximo Asset Management Essentials-specific process solution package.

Our examples will based on the following software components:

– Windows 2003 Server – WebSphere 6.1 Application Server – DB2 Database Platform – Maximo Asset Manager Essentials 7.1 application

Though our examples will primarily demonstrate a single server environment, we realize most production environments will be (and should be) comprised of multiple servers. The process is much the same, and we will highlight those areas where a variation in the process might exist.

For more information refer to the following installation guides:

򐂰 Installation Guide IBM WebSphere Application Server (MAM

Essentials71_install_was.pdf)

򐂰 Installation Guide BEA WebLogic Server (MAM Essentials71_install_bea.pdf)

7645install.fm Draft Document for Review May 23, 2008 10:14 am

38 Maximo Essentials V7.1 - Implementer’s Guide

5.1 Pre-Installation checklist

Before we start, we need to re-assess our pre-installation checklist carefully consider the following:

5.1.1 Hardware/Software considerations

Before proceeding with installation please ensure that the system configuration adheres to the required specifications as laid out by IBM and mentioned in the previous chapter

5.1.2 Verifying the DVD Content

The following DVDs contain files for the Maximo Asset Management Essentials product:

Maximo Asset Management Essentials V7.1

Contains:

򐂰 Launchpad 򐂰 Maximo Asset Management Essentials middleware installer 򐂰 Maximo Asset Management Essentials installer, IBM Agent Controller

installer

򐂰 Maximo Asset Management Essentials language pack installation program

for Windows 2003.

Middleware for Windows 2003

Contains prerequisite middleware software for Windows 2003.

Middleware for Red Hat Linux V4 and V5

Contains prerequisite middleware software for Red Hat Linux version 4.

Middleware for AIX V5.3 and V6.1

Contains prerequisite middleware software for AIX version 5.3.

Maximo Asset Management Essentials V7.1 Quick Start

Contains copies of the Quick Start guide in all languages and a copy of the information center.

Chapter 5. Installation 39

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

5.1.3 Backup/Snapshot Management

It is recommended to take a backup of your system before installing any Maximo Asset Manager 7.1 component on your system. Notably there is no automated uninstall feature supplied with IBM Tivoli Maximo Asset Manager 7.1. If the installation fails at any point, you need to restore your system from the backup or reinstall the respective OS on your machine.

5.1.4 JDK/JRE

It is recommended to have IBM Java 5.1 installed on your system.When implementing BEA WebLogic you will be required to have the update SUN JDK™

1.5.0 version installed.

5.1.5 Internet Browser

Maximo Asset Manager Essentials 7.1 currently supports Firefox and Mozilla internet browsers on Linux and Internet Explorer on Windows.

5.1.6 Disabling the firewall

This procedure describes how to disable the firewall if one is present on the system. You must disable the firewall for the system to which you are installing Maximo Asset Management Essentials middleware. You must disable the firewall prior to using the Tivoli middleware installer.

The firewall must be disabled on the following platforms.

–Windows –Linux

5.1.7 Deleting the TEMP and TMP user environment variables

The existence of the TEMP and TMP user variables can cause errors with the installation of DB2 on a Windows system. Prior to using the Tivoli middleware installer to install DB2, you must remove these variables for the user ID that will perform the installation. These are user environment variables that must be deleted, not system variables. To remove the TEMP and TMP user variables on a Windows system, complete the following steps:

1. Access the System Properties dialog by right-clicking the My Computer icon on your desktop and selecting Properties.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

40 Maximo Essentials V7.1 - Implementer’s Guide

2. From the System Properties dialog, first select the Advanced tab, and then click Environment Variables.

3. In the User variables section, select TEMP, and then click Delete. Repeat the process for the TMP variable.

4. Click OK.

5. Exit the System Properties dialog by clicking OK.

5.1.8 Verifying the required rpm-build package is installed

This procedure describes how to verify that the rpm-build package is installed on Linux. This package must be installed before you run the Tivoli middleware installer. This applies only if you are installing on Linux. To verify that the rpm-build package is installed, perform the following steps:

1. 1. Run rpm -qa | grep build

2. If the command returns a value like "rpm-build-4.3.3.-18_nonptl", the rpm-build package is installed. If nothing is returned, you must install the rpm-build package which is located on disk 3 (of 5) of the Red Hat Essentials Advanced Server version 4 installation CDs using the rpm tool with the -i option

5.1.9 Setting the ulimit

This section details how to set the ulimit in Linux, which is used to define user system and process resource limits. For Linux systems, you must set the ulimit for the system prior to using the Tivoli middleware installer. To set the ulimit, complete the following steps: 1. From a command line, type ulimit -f unlimited 2. From a command line, type ulimit -n 8192If you set the ulimit in the .profile for root, the ulimit setting will apply to all processes. Setting the swap size

Maximo Asset Management Essentials can be a resource-intensive application. It is recommended that you configure and tune your system for maximum performance. This section details how to set the size of the swap space used in Linux systems. Typically, the swap size set for Linux systems should be equivalent to twice the amount of physical RAM in the machine. Additional swap space can be made available to the system by:

򐂰 increasing the size of the existing swap partition 򐂰 creating a new, additional swap partition 򐂰 creating a swap file

Chapter 5. Installation 41

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Refer to the product documentation for your Linux distribution for more information.

5.1.10 Setting shared memory

This section details how to set a minimum shared memory value in Linux. For Linux systems, you must set a minimum shared memory value for the system prior to using the Tivoli middleware installer. To set the minimum shared memory value, complete the following steps:

򐂰 From a command line, type sysctl -w kernel.shmmax and determine if the

value is less than 268435456 bytes (256Mb).

򐂰 If you need to increase the value, from a command line, type sysctl -w

kernel.shmmax=268435456.

򐂰 Update the value in /etc/sysctl.conf.

5.1.11 Enabling remote configuration

If you plan to take advantage of the Maximo Asset Management Essentials installation program feature that automates the configuration of Maximo Asset Management Essentials middleware, you must enable a Remote Execution and Access (RXA) service for each system on which you intend to install Maximo Asset Management Essentials middleware. RXA requires that the target system enable at least one of the protocols supported by RXA, which include rsh, rexec, SSH and Windows SMB. Before you start the Maximo Asset Management Essentials installation program, ensure that one of these protocols is running and will accept remote logins using a user name and password configured on the target machine

If the remote system is a Windows machine, you must configure RXA to work over SMB. For Windows machines, you cannot use Cygwin ssh. If Cygwin is present on the Windows machine, the installation will fail. Default installations of AIX systems might not include a suitable protocol and will need to have RXA compatible protocols enabled. RXA does not support accessing network drives on the local or remote system.

5.2 Installation flowchart

The flowchart shown in Figure 5-1 on page 43 defines the installation flow required to successfully install IBM Tivoli Asset Management for IT. There is a Launchpad utility that will lead you through the installation of various components of the product. In general, there are three phases of the installation:

7645install.fm Draft Document for Review May 23, 2008 10:14 am

42 Maximo Essentials V7.1 - Implementer’s Guide

1. Installing the required middleware Through the launchpad, you can install an appropriate configuration of

WebSphere, DB2 and Tivoli Directory Server. Though you can change default parameters, if you take the default options, the installation of these middleware components through the launchpad is simple and straightforward.

2. Installing the base services There are a set of common base services that provide the general functions

for all Maximo-based applications. These base services comprise a set of modules that reside on an application server. The two supported application servers are:

– BEA WebLogic – IBM WebSphere

and utilize any the following database platforms:

–DB2 – Oracle – SQL Server 2005

3. The third phase of the installation is to enable or add the Maximo Asset Management Essentials specific package solutions to the base services installed in step 2. Again, the launchpad will guide you through this process, helping ensure that all appropriate parameters are specified for your target environment.

Note: If you used the Launchpad to install the middleware, then the launchpad will ‘remember’ the configuration that was installed and utilize that to simplify the installation of the base services.

If you installed the middleware separately and/or used other products namely Oracle/SQL Server or BEA Weblogic, then you can still use the Launchpad, but will have to specify the appropriate parameters for the middleware environment you have installed.

Chapter 5. Installation 43

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-1 Installation Flowchart

In the above diagram, the Maximo Asset Management Essentials installation relates to the installation of base services compoents of Maximo, now called Tivoli Process Automation Platform (TPAP), that are the common facilities used by this and other Maximo applications. The Process Solution Package, is the piece that enables the application specific (in this case Maximo Asset Management Essentials) functions on top of the base services.

Middleware Installation

• Database Server

• J2EE Server

Tivoli Process Automation Platform Installation

• Maximo Application

Process Solution Package Installation

•Maximo Essentials License enabler

Maximo Essentials Language pack installation

Post installation tasks

Note: Based on defined topology, all components can be installed on

same or different machines

* Launchpad not available on AIX

Prepare the Topology

Topology Plan

Pre-Installation Checklist

Automatic

Manual

Legend

*Launchpad

/GUI

Manual

7645install.fm Draft Document for Review May 23, 2008 10:14 am

44 Maximo Essentials V7.1 - Implementer’s Guide

5.3 Middleware Installation

The first step in the installation is to ensure all the necessary middleware is installed and properly configured.The following sections describe how to do this.

5.3.1 Installing middleware overview

Before you can install IBM Maximo Asset Management Essentials, there are several middleware products that must be deployed.

Specifically, you must install and deploy the following software:

Database server

Maximo Asset Management Essentials uses the Maximo database to store details about the attributes and history of each configuration item and the details about the relationships between configuration items.

You can manually install a new instance of DB2 UDB 9.1, or use a preexisting instance of DB2 UDB 8.2 or DB2 UDB 9.1, or install and configure Oracle 10 or MS SQL Server 2005 for your Maximo Asset Management Essentials deployment.

Directory server

The directory server is used to secure the Maximo Asset Management Essentials J2EE application. You have the choice of configuring a preexisting MS Active Directory server. Note,this installation step is applicable only if you are enabling J2EE security.

J2EE server

The J2EE server is the application server used to serve and manage the Maximo Asset Management Essentials application.You must have an instance of BEA WebLogic Server or IBM WebSphere installed in your environment.

The Maximo Asset Management Essentials product provides a Middleware Installer, that will provide a standard installation of the middleware listed above with minimal effort. It installs the following versions of middleware:

1. DB2

– DB2-ESE_9.1.0 – DB2-ESE_9.1.0_FP4

2. IBM Agent Controller

– Rational®-AgentController_7.0.3.1

Chapter 5. Installation 45

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

3. Tivoli Directory Server

– TIV-DirectoryServer_6.1.0 – TIV-DirectoryServer_6.1.0_FP0001

4. WebSphere V 6.1

– WS-ESS_6.1_GA – WS-WAS_IHS_6.1.0_FP13 – WS-WAS_ND_6.1.0.13_Custom_ISCAE71 – WS-WAS_ND_6.1.0_Supplemental – WS-WAS_Plugins_6.1.0_FP13WS-WAS_UpdateInstaller_6.1.0_FP13

This middleware installer could be used on different systems to install the individual components, thus simplifying the install of a multi-server environment. The following section will describe the use of the middleware installer on a single system.

You don’t have to use the middleware installer. You can install the middleware through normal methods. You will need to do this, if you plan on using other vendors products or different versions than listed above. We will not discuss considerations for manual installation of the middleware in this book. Please refer to the appendix to look at the manual configuration of Maximo Asset Management Essentials on the IBM WebSphere platform. For more details or other platforms please refer to the following install guides:

򐂰 Installation Guide IBM WebSphere Application Server

(mam71_install_was.pdf)

򐂰 Installation Guide BEA WebLogic Server (mam71_install_bea.pdf)

Note, you can also refer to the Maximo Asset Management Essentials installation guide for details of using the middleware installer. The following section summarizes the steps you will perform to install the middleware:

Using the Middleware Installer

To install the prerequisite middleware products for Maximo Asset Management Essentials, follow these steps:

1. Login as a user with administrative authority.

2. Launch the Tivoli middleware installer from the launchpad (included on the distribution media).

On Windows navigate to the root directory of the product disc or the downloaded installation image, and run the following command: launchpad.exe. On Linux or other platforms, the program will be named similarly.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

46 Maximo Essentials V7.1 - Implementer’s Guide

On Linux navigate to the root directory of the downloaded installation image and run following command:

chmod -R +755 * ./launchpad.sh

You will be led through a series of screens including language selection, welcome, license agreement and so on.

Be aware that the installation images for the middleware must be available and may be located on another DVD within your product media. During this installation process you will be prompted for the location of the middleware images.You will also be prompted for information such as the workspace to be used by the middleware installer.

3. From the Deployment Choices panel as shown in Figure 5-2, select the features to deploy on this machine, and then click Next. Choices include:

Database Server: The Maximo Asset Management Essentials database is used to store information about Assets.

J2EE Server: The J2EE server is used to host and manage the Maximo Asset Management Essentials application. If you choose to only install the J2EE server portion of the middleware, you will be prompted to supply the directory server you will use to secure it. Your choices will be to secure with an existing instance of IBM Tivoli Directory Server, or an existing instance of Microsoft Active Directory.

Directory Server: Data maintained by the directory server is used to secure Maximo Asset Management Essentials.

Note, for a multiple server environment, you could launch this installer on separate systems and choose to install individual middleware components on the individual systems.

Important: The launchpad can be run on either Windows or Linux. However, oonly the options to install the middleware will function on both platforms. The options to install the Maximo components will only work from the launchpad when running on Windows.

Basically, the deployment of the Maximo components requires the dynamic building of .EAR and other support files. These processes currently only work on a Windows platform. If they are to be installed on a Linux target, then the launchpad (running on Windows) will communicate to the target system and direct the install of the .EAR and other files through the remote connection.

Chapter 5. Installation 47

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-2 Middleware features selection

4. If you are not using IBM Tivoli Directory Server not implementing directory services de-select the Directory Server check box.

5. From the Deployment Plan Summary window, click Next to configure the parameters displayed. The deployment plan is generated and you will be provided details about the plan.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

48 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-3 Deployment Plan with Directory services selected

6. From the Credentials panel, enter the Username and Password you will use to deploy the plan with, and then click Next.

You can choose to enable the option of using the same password as the default user password value in all panels of the Tivoli middleware installer. This provides a common password for all of your middleware components installed through this process.

Chapter 5. Installation 49

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-4 Middleware Password Selection

At this point, you will be presented with a series of pre-filled in panels with default values for each of the middleware components that you are installing. For simple environments, you can take the defaults and move through these panels quickly. If you have special requirements, such as non-standard port numbers, userids, and so on, then you can make the appropriate changes. The following table, includes a summary of the parameters that you will be presented.

Parameter Default Value (if any)

Install location Enter the location to install DB2.

C:\Program Files\IBM\SQQLIB

DB2 Administration Server username db2admin

DB2 Administration Server password

Fenced user (Linux only)

Maximo Asset Management Essentials database instance name

ctginst1

Database port 50005

Database instance username

Instance username password

DB2 administrators group DB2ADMNS

7645install.fm Draft Document for Review May 23, 2008 10:14 am

50 Maximo Essentials V7.1 - Implementer’s Guide

DB2 users group (Windows only) DB2USERS

Location to install IBM Tivoli Directory Server.

C:\Program Files\IBM\LDAP\V6.1 Default is /opt/IBM/ldap/V6.1

Administrator distinguished name: Default for all platforms is cn=root.

Administrator password

Organizational unit: Default for all platforms is ou=SWG.

Organization and country suffix: Default for all platforms is o=IBM,c=US.

Directory server port: Default for all platforms is 389.

Directory server secure port Default for all platforms is 636.

Administration port Default for all platforms is 3538.

Administration secure port Default for all platforms is 3539.

TDS Database name Default for all platforms is security.

Instance name Default for all platforms is idsccmdb.

Port Default for all platforms is 50006.

Instance user password

LDAP Host Name

Directory server port Default is 389.

LDAP base entity Default is ou=SWG,o=IBM,c=US

User suffix Default is

ou=users,ou=SWG,o=IBM,c=US

Group suffix Default is

ou=groups,ou=SWG,o=IBM,c=US

Organization Default is ou=SWG,o=IBM,c=US

WebSphere Application Server Bind distinguished name

Default is cn=root

Bind password

Install location Windows: Default is C:\Program

Files\IBM\WebSphere\AppServer Linux: Default is /opt/IBM/WebSphere/AppServer

Parameter Default Value (if any)

Chapter 5. Installation 51

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

7. Specify the location of the Maximo Asset Management Essentials middleware images, and then click Next.

– Copy the middleware install images from the source media to a specified

directory. Select this option to copy the Maximo Asset Management Essentials middleware images from the product media to a directory that you will specify.

– Specify a directory containing all the required middleware install images.

Select this option if you intend to specify a filesystem directory that already contains all of the Maximo Asset Management Essentials middleware installation images.

WebSphere Administration username Default for all platforms is wasadmin.

WebSphere Administration password

Deployment Manager profile name Default for all platforms is ctgDmgr01.

Application server profile name Default for all platforms is ctgAppSrv01.

Cell name Default for all platforms is ctgCell01.

Deployment Manager node name Default for all platforms is

ctgCellManager01.

Application server node name Default for all platforms is ctgNode01.

Update Installer install location . Windows: Default is C:\Program

Files\IBM\WebSphere\UpdateInstaller Linux: Default is /opt/IBM/WebSphere/UpdateInstaller

HTTP Server Windows: Default is C:\Program

Files\IBM\HTTPServer Linux: Default is /opt/IBM/HTTPServer

HTTP port Default for all platforms is 80.

Admin Server port Default for all platforms is 8008.

HTP server Profile name Default for all platforms is ctgAppSvr01.

this value cannot be changed

IBM Agent Controller Install location Windows: Default is C:\Program

Files\IBM\AgentControllerLinux: Default is /opt/IBM/AgentController

Parameter Default Value (if any)

7645install.fm Draft Document for Review May 23, 2008 10:14 am

52 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-5 Middleware Installer Image

8. For Linux Only, the Middleware installer will create number of temporary files and will extract the middleware images to a temporary directory. Specify a directory or accept the default /tmp.

9. From the Deployment Plan Operation panel, select Deploy the plan, and then click Next. You can also elect to make changes to the deployment plan or parameters you have previously configured from this panel.

Tip: Make sure /tmp or specified location has enough disk space.

Chapter 5. Installation 53

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-6 Manage Middleware Deployment Plan

10.From the Deployment Plan and Parameter Configuration summary panel, review the contents of the summary, and then click Deploy to initiate the installation and configuration of the middleware you selected.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

54 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-7 Middleware Deployment Plan

11.Once the deployment completes successfully, click Finish to exit.

Chapter 5. Installation 55

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-8 Middleware Installation completed

5.3.2 Tivoli middleware installer logs

Tivoli middleware installer log files are located in the workspace directory that was defined in the Tivoli middleware installer. The different types of log files are described below.

User interface logs

The logs generated by the Tivoli middleware installer user interface are located in the workspace directory. The mwi.log file is the high-level log file that was generated by the most recent invocation of the Tivoli middleware installer. If an error occurs, examine this log file first. An entry in this log file may direct you to a lower-level log file. Log files named mwi.logX, where X is a number, are copies of the mwi.log file from earlier invocations of the Tivoli middleware installer So, for example, mwi.log0 is produced after the first invocation of Tivoli middleware installer, mwi.log1 is produced after the second invocation of Tivoli middleware installer, and so on.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

56 Maximo Essentials V7.1 - Implementer’s Guide

Logs for steps run by the user interface

In addition to collecting input from the user, the user interface of the Tivoli middleware installer also performs several system checks. Examples of system checks run by the user interface runs include: v dependency checking to ensure the operating system meets the deployment requirements v inventorying the software on the system to locate existing instances of middleware products deployed by the Tivoli middleware installer v checking the available disk space to ensure there is enough for the deployment

Each of these checks is produced in the form of a step so that it can also be run as part of the deployment plan. When the user interface runs a step, it copies the step into a subdirectory of the workspace directory. The log files generated by a step are located in the same subdirectory and follow the same pattern as a step that is run as part of the deployment plan.

Deployment plan logs

The deployment plan is located in the directory <Workspace Directory>/hostname/deploymentPlan, where hostname is the hostname of the current system. Each time the deployment plan is used to install or uninstall middleware products, a process ID is assigned and log files are generated.

The log files for the deployment plan are located in the subdirectory logs/processID. The primary log file for the deployment plan is DeploymentPlan.log, a high-level log file that lists the steps invoked as part of the deployment plan.

Machine plan logs

The machine plan is located in the directory <Workspace Directory>/hostname/deploymentPlan/MachinePlan_hostname. The log files for the machine plan are located in the logs subdirectory. The primary log files for the machine plan are named MachinePlan_hostname_processID. These log files contain the output generated by ANT when running the machine plan ANT script.

Deployment plan logs

Each step in the deployment plan is located in a directory named <Workspace Directory>/hostname/deploymentPlan/MachinePlan_hostname/stepNum_stepID where stepNum is the sequence number of this step in install processing order of the deployment plan and stepID identifies the step. The log files for the step are located in the logs subdirectory.

Some steps may provide a message log file named stepID_processID.message, which contains a few entries that summarize the result of invoking the step. All steps will provide a trace log file named stepID_processID.log, which contains

Chapter 5. Installation 57

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

many entries, usually including information about the input parameters and the substeps invoked.

Logs for substeps

Each step contains one or more substeps. The substeps perform the actual install, uninstall and checking work for the Tivoli middleware installer.

Each substep is located in the directory <Workspace Directory>/hostname/deploymentPlan/MachinePlan_hostname/stepNum_stepID /operation/substepNum_substepID, where operation is the ANT target in the step ANT script that invokes this substep. substepNum is the sequence number of this substep in the processing order of the step, and substepID identifies the substep. Typical values for operation are install, uninstall, and check.

The log files for the substep are usually located in a subdirectory named processID/logs. Log files generated by the native middleware installation programs will also be kept here.

5.4 Installing Maximo corfe components (TPAP)

This section describes the process to install the core maximo function, formerly known as Maximo Base Serverces and now called Tivoli Process Automation Platform through the launchpad.

5.4.1 Maximo Asset Management Essentials Installation Overview

This procedure explains how to use the Maximo Asset Management Essentials installation program to install Maximo. In addition to configuring new instances of Maximo middleware products installed by the Tivoli middleware installer, the Maximo Asset Management Essentials installation program can configure existing instances of prerequisite products, including those from other vendors, that you wish to use with Maximo.

The instructions provided are for either a single or multiple machine installation using default values and assume that you choose to have the Maximo Asset Management Essentials installation program automatically configure middleware across multiple machines to work with Maximo.

If you do not allow the Maximo Asset Management Essentials installation program to automatically configure middleware, it will still perform programmatic checks to verify that the documented manual steps were performed properly.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

58 Maximo Essentials V7.1 - Implementer’s Guide

If any errors are encountered, a dialog box detailing the error will appear. You will not be permitted to continue in the Maximo Asset Management Essentials installation task until the errors are resolved. The Maximo Asset Management Essentials installation program can only be run from a Windows-based system.

5.4.2 Maximo Asset Management Essentials Installation

Avoid using localhost for host name values in the install program. Specify the actual fully qualified host name of the system for all host name values. To install Maximo Asset Management Essentials base services, follow these steps:

1. Login as a user with administrative authority. Launch the Tivoli middleware installer from the launchpad. In the launchpad navigation pane, click Install

the Product → Maximo Asset Management Essentials.

2. You will now be presented with a series of screens prompting you for parameters related to your middleware environment. If you used the middleware installer, then most of these parameters will be pre-filled. If you installed your middleware manually, you will need to provide the appropriate values for each of the middleware components.

3. A special installation application (called Install Anywhere) will be installed and initiated for installing the rest of the components. Install Anywhere is based on IBM’s Autonomic installation technology, which helps drive complex, multi-step installations.

4. You will be prompted information related to your middleware environment. If you had used the Middleware installer, you will be prompted to use the configuration information that was saved by the middleware installer to automatically prefill many of these parameters.

From the Import Middleware Configuration Information panel, specify that you want to use the field values you input into the Tivoli Middleware installer as default values for those same fields in the Maximo Asset Management Essentials installation program.

– The middleware default information will not be used if you select the

Simple deployment path.

– Host name: Enter the host name of the system where the Tivoli

middleware installer was run.

– User ID: Enter the User ID that was used to run the Tivoli middleware

installer.

– Password: Enter the password of the User ID that was used to run the

Tivoli middleware installer.

– Workspace Location: Enter the location of the topology file that contains

the values entered for the Tivoli middleware installer. This file is found in

Chapter 5. Installation 59

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

the workspace that was defined during the Maximo middleware installation task. For example, C:\ibm\tivoli\mwi\workspace. Click Next

5. From the Choose Deployment panel, select the Custom deployment topology, and then click Next.

Select Simple if you want to deploy all Maximo Asset Management Essentials components on a single system. This deployment option is typically only used for demonstration, proof-of-concept, or training purposes.

Select Custom if you wish to deploy Maximo Asset Management Essentials components across several systems. This deployment option is typically used in a production environment. In our example, we chose Custom to allow us to specify a different host name for the database server, as if we were installing in a multi server environment

From the Automate Database Configuration panel, select Automate database configuration if you would like to have the database automatically created, and then click Next. If you choose not to automate the database creation then this step assumes you have already created a database instance, a database, tablespaces, a user, and schema for use with Maximo Asset Management Essentials. If you have not manually configured the database prior to selecting

Choose Install Folder By default, this value is

C:\IBM\SMP.

Description

Maximo Database Type DB2 Select the database vendor/product. Each

database will have its own unique set of configurable parameters and values.

DB2 Host name Enter the host name of the machine hosting

DB2.The host name must be fully qualified.

Port The default is 50005.

Database Name The default database

name is maxdb71.

The database will be created if it does not already exist.

Instance Enter the name of the database instance to

be used with Maximo. After you have entered configuration information for the database that was selected, the Maximo Asset Management Essentials installation program will connect to the database server to validate the information you have entered.

Database User ID

Database Password

7645install.fm Draft Document for Review May 23, 2008 10:14 am

60 Maximo Essentials V7.1 - Implementer’s Guide

Do not automate database configuration from within the Maximo Asset

Management Essentials installation program, the installation will check to see if you have not completed these pre-install tasks and you will be reminded to complete them prior to restarting the Maximo Asset Management Essentials installation program.

Figure 5-9 Automate Database Configuration

6. DB2 Database Information: Enter the Windows services user ID and passwords only if the DB2 Server is installed on a Windows machine, click

Next.

Chapter 5. Installation 61

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-10 DB2 Administration

7. From the Database Configuration panel specify the table space configuration properties if the DB2 database will be automatically created

7645install.fm Draft Document for Review May 23, 2008 10:14 am

62 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-11 DB2 Tablespace

8. From the Maximo Application Server Type panel select the relevant application server you wish to deploy your Maximo application on, choose IBM WebSphere Application Server, click Next

Chapter 5. Installation 63

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-12 Maximo Application Server Type

9. From the WebSphere Connectivity panel, enter host information about the WebSphere server, and then click Next.

– Host name: Enter the fully-qualified host name of the system hosting

WebSphere. Alternatively, you can provide the IP address for the system.

– SOAP port: Enter the SOAP port of the WebSphere system. The default

value for this field is 8879

7645install.fm Draft Document for Review May 23, 2008 10:14 am

64 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-13 WebSphere Connectivity

10.From the Remote Access Authorization panel, enter authorization information for WebSphere configuration, and then click Next.

Operating system user ID: Enter a valid user ID that will allow the Maximo Asset Management Essentials installation program to access the system that is hosting WebSphere. This user ID should have administrative rights on the machine you are accessing.

Operating system password: Enter the password for the system user ID.

Chapter 5. Installation 65

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-14 WebSphere Remote Access Authorization panel

11.From the Automate WebSphere configuration panel, select Automate WebSphere configuration, and then click Next. If you choose not to have the Maximo Asset Management Essentials installation program automatically configure the middleware, you will have had to configure WebSphere manually prior to the installation of Maximo. Configuration tasks include creating a profile, running WebSphere as a Windows service, copying the WebSphere keystore file from the machine where WebSphere is installed to the administrative workstation, setting up JMS queues, and so on.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

66 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-15 Automate WebSphere configuration

12.From the WebSphere Deployment Manager configuration panel, enter values for the following fields, and then click Next.

– WebSphere installation directory: Enter the directory where WebSphere

is installed on the host system. Windows On Windows, this value might be C:\Program Files\IBM\WebSphere\AppServer Linux On Linux, this value might be /opt/IBM/WebSphere/AppServer.AIX On AIX, this value might be /usr/AppServer HP-UX On HP-UX, this value might be /AppServer Sun Solaris On Sun Solaris, this value mightAppServer.

– User: Enter the administrative user ID used to Default for all platforms is

wasadmin.

– Password: Enter the password for the administrative WebSphere server. – Profile name: Enter the name of the WebSphere profile. Default for all

platforms is ctgDmgr01.

Chapter 5. Installation 67

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-16 WebSphere Deployment Manager configuration

13.From the WebSphere Application Server Configuration panel, enter the following information, and then click Next.

– Web server port: Enter the Web server port used by WebSphere. Default

for all platforms is 80

– Web server name: Enter the name of the Web server. Default for all

platforms is webserver1

– Node name: Enter the name of the WebSphere node containing the

application server. Default for all platforms is ctgNode01.:

– Cluster name: Enter the name of the WebSphere cluster containing the

application server. Default for all platforms is MAXIMOCLUSTER. The cluster name is optional. The cluster and application server will be created if they do not exist.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

68 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-17 WebSphere Application Server Configuration

14.From the Security panel, indicate whether application server security should be enabled automatically, and then click Next.

Note: This step is only applicable if you are implementing the Tivoli Directory Server or Microsoft Active Directory server for security.

Chapter 5. Installation 69

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-18 Security

15.From the Integration Adapter JMS Configuration panel, enter the following information, and then click Next.

– JMS DataSource name: A JMS server requires a DB2 data repository to

be configured to maintain messages. Enter the name of the database to be used by JMS. Default is intjmsds. Select whether the JMS datastore should be persisted.

– Persist JMS messages: Select this option of you want the Maximo Asset

Management Essentials installation program to set the JMS implementation to persist messages.

– Do not persist JMS messages: Select this option if you do not want the

Maximo Asset Management Essentials installation program to set the JMS implementation to persist messages automatically. A database will not be used to persist messages. If you later decide that you would like to persist JMS messages, you will have to configure the JMS implementation manually.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

70 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-19 Integration Adapter JMS Configuration

16.From the Input Summary panel, review the information you have provided to the Maximo Asset Management Essentials installation program, and then click Next.

Chapter 5. Installation 71

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-20 Input Summary

17.From the Pre-Installation Summary panel, review the installation information presented, and then click Install. The installation task will begin. Progress can be monitored by viewing messages displayed above the progress bar. Click Next.

The installation will now take place, and may take quite some time. (The duration of the install is mostly dependant on the physical capacity of the server you are installing the base services on.) in our test environment, it took 1-2 hours.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

72 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-21 Pre-Installation Summary

18.You will be prompted to install additional language packs over and above the base language. Click No.

Chapter 5. Installation 73

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-22 Language Support

19.From the Install Complete panel, click Done.Once the Maximo Asset Management Essentials installation program has completed installation and configuration tasks, it will exit. Logs can be found at <MAM_Home>/logs.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

74 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-23 Install Complete

5.4.3 Post Maximo Asset Management Essentials base services installation

1. Before logging into the newly installed Maximo Asset Management Essentials application, go to your windows services and ensure that the relevant services are started. These services are:

– DB2 COPY Services – DB2 Governor – DB2 License Server – DB2 Management Service – DB2 Remote Command Server – DB2 Security Server – DB2DAS – IBM HTTP Server 6.1 – IBM HTTP Administration 6.1 – IBM WebSphere Application Server V6.1 – IBM WebSphere Application Server V6.1 Node Agent – IBM Rational Agent Controller – IBM Tivoli Directory Admin Daemon V6.1

Chapter 5. Installation 75

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

– IBM Tivoli Directory Server Instance V6.1

2. Although not required, you can optionally start the node agent as a Windows service.

To create a node agent as a Windows service, perform the following on the WebSpheree application server:

– Open a command prompt – Change directory to <WAS_HOME>\bin – Run the following command (as a single line):

WASService add NodeAgent serverName nodeagent profilePath C:\Program Files\IBM\WebSphere\AppServer\profiles\ctgAppSrv01 wasHome <C:>\IBM\WebSphere\AppServer logRoot <C:>\IBM\WebSphere\AppServer\logs\nodeagent logFile <C:>\IBM\WebSphere\AppServer\logs\nodeagent\ startServer.log restart true

– Close the Command Prompt.

3. Once all the relevant services are started up login to the URL http://servername:9080/maximo and see if you connect to the Maximo Asset Manager

Figure 5-24 Maximo Asset Manager Login page

Tip: When having implemented the Tivoli Directory Server take note that if you haven’t resumed your Tivoli services you might not be able to access the WebSphere console as the administrator username and password has not been validated. Make sure your service is running.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

76 Maximo Essentials V7.1 - Implementer’s Guide

5.5 Process solution package installation

Process solutions are versioned software components. The process solution installation programs support a variety of software life cycle operations that may be applied against process solutions.

A process solution package is a self-contained ZIP file of installation artifacts and deployment logic that can be deployed using the process solution installation program. Installation artifacts are the files and content that are installed into your Maximo environment to enable the services management functionality of the Process Manager Product or Integration Module. The deployment logic are the actions that are carried out in order to deploy the process solution into the Maximo environment. Typically, these actions include building and deploying J2EE applications, running database scripts that load the process solution content into the Maximo database, and adding users and groups for security. Additionally, optional sample data can be installed.

The Base Install operation installs and deploys a new process solution into your Maximo environment. Once installed, a process solution may be updated in several ways.

The process solution installation programs are able to process the following package types:

򐂰 Base Install Package - Required to install a new process solution using the

Base Install operation.

򐂰 Incremental Update Package - Required when performing an Upgrade

operation.

򐂰 Fix Package - Required when applying an interim fix to a process solution. 򐂰 Full Update Package - Used to perform a Base Install operation if no instance

of the process solution is currently installed or it may be used to perform an Upgrade operation on a currently installed process solution. The process solution installation programs ensure that the appropriate package type is processed for any given operation.

5.5.1 Pre-Process solution package installation checklist

When you perform a deployment operation using the process solution installation program, you are running actions that modify the configuration and content of your J2EE, database, and directory middleware servers. The following steps should be reviewed before invoking the process solution installation program.

Chapter 5. Installation 77

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Have Middleware Login Information Available

The process solution installation program requires access to middleware servers in order to automate the deployment of the process solution package. You will need to know the administrative user IDs and passwords for the impacted middleware servers. The actual middleware servers whose login information is required will depend on the process solution package being installed. The process solution installation program ensures that any required login information is specified before continuing with the deployment operation.

Backup Middleware Servers and Administrative Workstation

You should create backups for impacted J2EE, database, and directory servers before you deploy a process solution package using the process solution installation program.

Ensure Middleware Servers Are Started

Start any impacted middleware servers before running the process solution installer.

5.5.2 Enable Maximo Asset Management Essentials License

Only after installing the Process solution package will you be entitled to use Maximo according to the license you have purchased. Complete the following steps to install a process solution package into Maximo using the process solution installation wizard:

1. From the Launchpad, launch the process solution installation program by clicking the link under 3. Enable Maximo Asset Management Essentials License for usage. The Process Solution Installation Install Anywhere Installer executes on the Maximo administrative workstation. The launch script is deployed and configured by the Maximo Asset Management Essentials installation program.

In our case, the PSI package selected is a base install of the Maximo Asset Management Essentials 7.1 package. The process solution installation program performs a series of validation checks to verify that the package you selected is valid. The system is checked to ensure that the package has not already been deployed.

Author Comment: All of the screen images in this section need to be replaced with those for Maximo Asset Management Essentials. Functionally, they are identical to thos shown here, but will have a different title referring to the Esssentials product.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

78 Maximo Essentials V7.1 - Implementer’s Guide

2. Allow the package to be validated, click Next.

Figure 5-25 Package Validation

3. From the Middleware Login Information panel, enter the credentials for which you are being prompted, and then click Next. Once you have entered the requested user IDs and passwords, the process solution installation wizard will validate the credentials by connecting to the middleware servers using the supplied credentials.

Chapter 5. Installation 79

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-26 Middleware Login information-WebSphere Admin

7645install.fm Draft Document for Review May 23, 2008 10:14 am

80 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-27 Middleware Login information-WebSphere Remote

4. After the credentials have been verified, a Package Options panel is displayed that details the deployment options that the package supports. Leave both the Supported Package Options boxes unchecked to have the EAR files deployed and Maximo database updated by the process solution installation program and click Next.

򐂰 Supported Package Options Definitions:

– Defer Maximo Application Redeployment

If you intend to apply more than one package solution select this checkbox by doing so you will only redeploy the ear files once after all the package solutions have been installed

– Defer the update of the Maximo Database

If you intend to apply more than one package solution select this checkbox by doing so you will only update the database once after all the package solutions have been installed

Chapter 5. Installation 81

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-28 Package Options

5. From the Pre-Install Summary panel, review and verify the information displayed, and then click Next.

6. At this point, the process solution installation program begins the package installation process. The Deployment progress panel will inform you of the deployment progress of the installation.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

82 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-29 Deployment Progress

7. When the installation has completed successfully, from the Package Successfully Deployed panel, click Done to exit the process solution

installation wizard. If there is a package failure, a message will be displayed for the step that failed.You might see an installation progress bar displayed briefly after you click Done. The Process Solution Installation Wizard is actually terminating and no installation activities are being performed. The deployment of the Process Solution Package you were installing has already completed and the progress bar can be safely ignored.

Chapter 5. Installation 83

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

Figure 5-30 Package Successfully Deployed

5.6 Post Installation Tasks

Prior to assuming the configuration stage of your Maximo Asset Management Essentials deployment, take the time to ensure that the basic installation is functional, to confirm this read through the following section and verify and adjust where necessary:

5.6.1 Ensure all relevant Maximo services are running

Before you can attempt to access Maximo, ensure that all the relevant services are running:

Tip: It is recommended you document all you findings carefully and meticulously. Once all your tasks have been completed, store all your installation instructions and properties for future reference.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

84 Maximo Essentials V7.1 - Implementer’s Guide

5.6.2 Ensure connectivity to the Maximo Asset Management Essentials application

Once you have successfully resumed the requested services, ensure connectivity by accessing the login panel and logging into the Maximo Asset Manager.

The default Maximo system administrator user ID and passwords are as follows

򐂰 User ID :maxadmin 򐂰 Password:maxadmin

Tip: From Windows Services, set the following services to automatic startup:

򐂰 DB2 COPY Services 򐂰 DB2 Governor 򐂰 DB2 License Server 򐂰 DB2 Management Service 򐂰 DB2 Remote Command Server 򐂰 DB2 Security Server 򐂰 DB2DAS 򐂰 IBM HTTP Server 6.1 򐂰 IBM HTTP Administration 6.1 򐂰 IBM WebSphere Application Server V6.1 򐂰 IBM WebSphere Application Server V6.1 Node Agent 򐂰 IBM Rational Agent Controller 򐂰 IBM Tivoli Directory Admin Daemon V6.1 򐂰 IBM Tivoli Directory Server Instance V6.1

If you’re running a demo Maximo Asset Manager installation on limited resources, for example, a labtop or a virtual machine, it is recommended that you do not run the above specified services as automatic but rather keep these services configured to start manually.

Tip: It is highly suggested for the system administrator to change their password on a regular interval. Also, if the maxadmin user is administering on a multi-language implementation, take careful to note in which locales he is applying the changes. Aim wherever possible to remain and administer in the base language.

Chapter 5. Installation 85

Draft Document for Review May 23, 2008 10:14 am 7645install.fm

5.6.3 Ensure the Language pack installation is functional

To determine if the language pack installation is successful ensure you can login into the various languages listed on your Maximo login page. Carefully assess if all the language packs are installed as planned. If some of your languages are not installed carefully re-assess and implement those languages.

5.6.4 Ensure Client Connectivity

As the Maximo Asset Manager has a client-server infrastructure, it is imperative to verify accessibility from the clients who will be accessing Maximo. Ensure the users can access the login page of Maximo. There are a list of client hardware/software considerations that have also to be assumed to confirm this task.

5.6.5 Report Administration

Prior to the configuration phase of the deployment, carry out the following report administration checks.

Generate Request pages

Request pages are the parameter inputs required for each report. Before the reports can be accessed from with Maximo the request pages have to be generated.

1. Login into Maximo as the System Administrator

2. From the Start Center navigate to the Go To function and select

Administration → Reporting Administration.

Tip: Refer to Chapter 4 for information regarding Hardware and Software

requirements.

7645install.fm Draft Document for Review May 23, 2008 10:14 am

86 Maximo Essentials V7.1 - Implementer’s Guide

Figure 5-31 Reporting Administration

3. In the center of the page you will see a button called Generate Request Pages, click Generate Request Pages.

Figure 5-32 Generate Request pages success

At this stage the request pages have been successfully generated.

IBM MAXIMO SG24-7645-00, Maximo Asset Management Essentials V7.1 Implementation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
