IBM ThinkVision™ L150/150p Monitor
L150/150p
User's Guide
English
First Edition (June/2003)
Note: For important information, refer to the Monitor Safety and Warranty manual that comes with
this monitor.
Contents
Safety (Read first) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Setting up the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Handling Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Workplace Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Adjusting the Monitor Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Working Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Caring for your Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting your Monitor for Analog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting your Monitor for Digital . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Switching on your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Device Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Windows 95/98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Windows 2000/Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Auto Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Auto Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Auto Setup for DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Auto Setup for Windows95, Windows98, Windows 2000, Windows NT,
Windows Me or Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
DEUTSCH
Manual Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adjusting Your LCD Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
User controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
On-screen display (OSD) controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Further Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Display modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Product Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Further Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Notices and Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
1
í í í
2
Setting up the monitor
Product Description
The IBM ThinkVision TFT LCD L150/L150p Color Monitor works with a computer
with a suitable on-board sub-system or Video Adapter card that can support
XGA 1024 x 768, SVGA 800 x 600, or VGA 640 x 480 at 60 Hz
The product package should include the following items:
• User's Guide and Installation Files CD
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
• Monitor Safety and Warranty Information Manual
• IBM ThinkVision L150/L150p monitor Setup Guide
• Power Cord
• IBM ThinkVision L150/L150p Monitor
• Analog Interface Cable - Attached to Monitor
Handling Instructions
Do not support the monitor
within the screen area. The
Liquid Crystal Display is
glass and can be damaged
by rough handling or
excessive pressure.
1. Lift the monitor by placing your hands where indicated below.
DEUTSCH
2. Before using your monitor for the first time, remove the clear protective
film from the front of the screen.
3
3. Remove the shipping clip for L150p as shown below
Workplace Preparation
This section gives advice on
what you should consider
before you set up your monitor.
Height
Position the monitor so that the top of the screen is slightly below your eye
level when you sit at your workstation.
Orientation
Choose a position that gives the least reflection from lights and windows,
usually at a right angle to any windows. Position the monitor directly in front of
you so that you do not have to twist your body to use it. Tilt the monitor to a
comfortable viewing angle.
Adjusting the Monitor Position
The monitor offers the adjusting height, rake, and rotation possibility that enable
the monitor to be optimally adjusted for the respective user and the respective
situation.
4
L150
You can tilt the screen backward and forward as shown below.
o
40
o
4
L150p
You can tilt the screen backward and forward, swivel left and right, as well as lift up
and down as shown below.
Working Practices
This section gives
advice on how you can
work comfortably and reduce
fatigue.
o
0
30
o
125mm
o
90
o
210
Rest
Take regular breaks. Vary your posture, stand up and stretch occasionally as
prolonged use of computer workstations can be tiring.
5
Back
Sit back in your chair and use the backrest.
Hands
Adjust the seat height so that your forearms are approximately horizontal and
your wrists are straight when using the keyboard. Your upper arms should be
relaxed with your elbows near your body.
Use a light touch on the keyboard, keeping your hands and fingers relaxed.
Allow a space in front of the keyboard to rest your wrists when not typing.
Consider using a wristpad.
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
Eyesight
Working with monitors, in common with any prolonged close work, can be
visually demanding. Look away from the screen periodically and have your
eyesight checked regularly.
Screen settings
Set the screen brightness and contrast to a comfortable level. You may have
to adjust this as the lighting changes during the day. Many application
programs let you select color combinations which can help you to view in
comfort. See the User controls section on page 15 for more information.
Caring for your Monitor
Be sure to turn off the power before you perform any maintenance on the
monitor. Clean your monitor as follows:
• Gently wipe the device covers and the screen with a soft cloth.
• Remove finger marks and grease with a damp cloth and mild detergent;
do not use solvents or abrasives.
• Never use flammable cleaning material to clean your IBM monitor or any
other electrical apparatus.
DEUTSCH
6
Connecting your Monitor for Analog ( for L150 and L150p)
Be sure to read the ‘Safety
Information’ at the front of
this User Guide before
carrying out this procedure.
1. Turn off your computer and all attached devices.
2. Connect the signal cable to the video port on the back of your computer.
This port might be directly attached to your computer (figure A), or it
might be part of a video adapter card (figure B). The video port on your
computer or video adapter card might be blue to match the blue
connector on your monitor’s video cable.
3. For L150, if the power cord is not attached to the monitor, please follow
the instructions below:
a
b
a. Tilt monitor all the way forward.
b. Hold the top of the cable cover (a) and pull it off.
c. Gently lift the stand cover (b) along the top and then slide it
backwards and off the stand.
d. Connect the power cord to the power port on the back of your monitor.
e. Replace the rear covers.
4.
For L150p, if the power cord is not attached to the monitor, connect it to
the power port on the back of the monitor.
5. Insert the plug into a properly grounded electrical outlet.
7
Connecting your Monitor for Digital
Purchase an industry standard DVI-D cable from your local computer
1.
supply store.
2. Turn off your computer and all attached devices.
3. Tilt monitor all the way forward.
Connect the DVI connector to the DVI port located on the back of the
4.
Monitor. See picture below.
Connecting DVI Cable
DVI
Cable
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
DEUTSCH
5. Connect the DVI connector at the other end of the signal cable to the
DVI port located on the back of the graphics adapter. See picture below
graphics adapter
DVI
Signal Cable
8
Switching on your Monitor
1. Switch on the power source and your computer.
2. Switch on your monitor by pushing and releasing the power switch
marked .
(To switch off your monitor, push and release the power switch again.)
3. To update or install device drivers, follow the instructions in the Device
Driver Installation section on page 10.
4. To optimise the displayed image, run Auto Setup by following the
instructions in the Auto Setup section on page 13.
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
DEUTSCH
9
Device Driver Installation
Driver installation for Windows 95 or Windows 98
This section must be
completed before
continuing with the
Windows 95 or Windows 98
Auto Setup on page 15
On LCD monitors, unlike
CRTs, a faster refresh rate
does not improve display quality.
IBM recommends using either
1024 x 768 at a refresh rate of
60Hz or 640 x 480 at a refresh
rate of 60Hz.
To use the Plug and Play feature in Microsoft® Windows® 95 or Windows 98,
files should be loaded from the IBM Monitor CD.
1. Turn off the computer and all attached devices.
2. Ensure that the monitor is connected correctly.
3. Turn on the monitor and then the system unit. Allow the system to boot
into Windows 95 or Windows 98.
Your computer’s Plug and Play code may warn you that your system
hardware has changed. This means that it has detected your new
monitor for the first time.
4. Open the
CONTROL PANEL
DISPLAY PROPERTIES window by clicking START, SETTINGS,
and then double - clicking on the DISPLAY icon.
5. Click the SETTINGS tab.
• In case of Windows 95 :
6. 1. Click the
2. Click the
CHANGE DISPLAY TYPE button.
CHANGE MONITOR TYPE button.
• In case of Windows 98 :
6. 1. Click the
2. Click the
3. Open the
on
ADVANCED button.
MONITOR tab.
UPGRADE DEVICE DRIVER WIZARD window by clicking
CHANGE button and then select the NEXT button.
4. Click the “Display a list of the known drivers for this device so that
I can choose a specific driver” and then select the NEXT button.
10
7. Insert the Setup CD into the CD driver: and click the
HAVE DISK button.
8. Click OK.
9. Ensure that the CD drive letter is selected, and then select ‘Drivers’
folder.
10. Choose IBM ThinkVision L150/150p monitor and Click OK. The
files will be copied from the CD to your hard disk drive.
11. Close all open windows and remove the CD.
12. Restart the system.
The system will automatically select the maximum refresh rate and
corresponding Color Matching Profiles.
Driver Installation for Windows 2000 or Windows Me
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
This section must be
completed before
continuing with the
Windows 2000, Windows
Auto Setup on page 15
Me
On LCD monitors, unlike
CRTs, a faster refresh rate
does not improve display quality.
IBM recommends using either
1024 x 768 at a refresh rate of
60Hz or 640 x 480 at a refresh
rate of 60Hz.
To use the Plug and Play feature in Microsoft® Windows® 2000 or Microsoft
Windows Millennium Edition(Me) files should be loaded from the IBM
Monitor CD.
1. Turn off the computer and all attached devices.
2. Ensure that the monitor is connected correctly.
3. Turn on the monitor and then the system unit. Allow the system to boot
into Windows 2000 or Windows Me.
4. Open the DISPLAY PROPERTIES window by clicking START, SETTINGS,
CONTROL PANEL and then double-clicking the DISPLAY icon.
5. Click the
6. Click the
7. Click the
8. Click the
9. Click the
10. Open the
UPDATE DRIVER and then Click the NEXT button.
SETTINGS tab.
ADVANCED button.
MONITOR tab.
PROPERTIES button.
DRIVER tab.
UPGRADE DEVICE DRIVER WIZARD window by clicking on
11. Select the “Display a list of the known drivers for this device so that I can
choose a specific driver” and then Click the NEXT button.
12. Insert the Setup CD into the CD drive : and click the
HAVE DISK button.
13. Click OK.
14. Ensure that the CD drive letter is selected, and then select the ‘Drivers’
folder.
15. Choose IBM ThinkVision L150/150p monitor and Click OK. The
files will be copied from the CD to your hard disk drive.
16. Close all open windows and remove the CD.
17. Restart the system.
The system will automatically select the maximum refresh rate and
corresponding Color Matching Profiles.
DEUTSCH
11
Driver Installation for Windows XP
This section must be
completed before
continuing with the
Windows XP
on page 15
On LCD monitors, unlike
CRTs, a faster refresh rate
does not improve display quality.
IBM recommends using either
1024 x 768 at a refresh rate of
60Hz or 640 x 480 at a refresh
rate of 60Hz.
Auto Setup
To use the Plug and Play feature in Microsoft® Windows® XP files should be
loaded from the IBM Monitor CD.
1. Turn off the computer and all attached devices.
2. Ensure that the monitor is connected correctly.
3. Turn on the monitor and then the system unit. Allow the system to boot
into Windows XP.
4. Open the
CONTROL PANEL
DISPLAY PROPERTIES window by clicking START, SETTINGS,
and then double-clicking the DISPLAY icon.
5. Click the SETTINGS tab.
6. Click the
7. Click the
8. Click the
9. Click the
10. Open the Hardware Update Wizard window by clicking on
DRIVER
ADVANCED button.
MONITOR tab.
PROPERTIES button.
DRIVER tab.
UPDATE
and then Click the NEXT button.
11. Select the “Install from a list or Specific location(Advanced)” and then
Click the NEXT button.
12. Insert the Setup CD into the CD drive : and click the
HAVE DISK button.
13. Click OK.
14. Ensure that the CD drive letter is selected, and then select the ‘Drivers’
folder.
15. Choose IBM ThinkVision L150/150p monitor and Click OK. The
files will be copied from the CD to your hard disk drive.
16. Close all open windows and remove the CD.
17. Restart the system.
The system will automatically select the maximum refresh rate and
corresponding Color Matching Profiles.
12
Auto Setup
Auto Setup
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
The Setup Utility
included on the installation
CD is for displaying dot patterns.
They do not replace or modify the
display driver.
The Auto Setup instructions
require the monitor to be warmed
up for 15 minutes. This is not
required for normal operation.
By pressing the Auto key, you will
have direct access to Auto
Adjustment.
Auto setup is not required when using digital input.
When you first use your monitor you must perform Auto Setup. This
procedure sets up your monitor to process the video signals from your
computer without image discoloration or smearing. After you perform Auto
Setup, the settings are stored and used each time you turn on the monitor.
To optimise the displayed image a set-up utility is provided on the CD.
Operation of the utility is dependent on the operating system on your
computer. For correct operation locate the operating system on your
computer from the table below and follow the appropriate instructions. You
can choose to run
AUTO SETUP for each operating system that you use. This
means that if you sometimes use your monitor while running any version of
Windows and sometimes also use it from within DOS (not a DOS window),
you must run
AUTO SETUP in any order.
Operating System Corresponding Auto Setup procedure
DOS
Windows 95, WIndows 98,
Windows 2000,
Microsoft Windows NT®,
Windows Me or Windows XP
AUTO SETUP for both Windows and DOS. You can run versions of
Auto Setup for DOS on page 14
Auto Setup for Windows 95, Windows 98,
Windows NT, Windows 2000, Windows Me or
Windows XP on page 15
DEUTSCH
The
AUTO SETUP
only applies to the current
screen mode. When a new mode
is selected, repeat this section to
reset the monitor.
process
Before you begin AUTO SETUP for your computer:
1. Make sure the computer’s video mode is set in the range of the
supported screen resolution shown in the Table on page 23.
You should perform AUTO SETUP for each screen mode you use.
13
Auto Setup for DOS
To set up the monitor automatically in DOS, do the following:
If the monitor is in standby
mode (STANDBY ON), it
may automatically turn off while
you are waiting for it to warm up. If
this happens, switch off the
monitor and switch it on again
after a few seconds.
If you are using PC-DOS/V,
change to U.S. mode by
typing
‘CHEV US’
ENTER at the command prompt.
The size and diversity of the
dot pattern varies with the
screen resolution.
and pressing
1. Turn on the monitor first; then turn on the computer.
If the message CHECK SIGNAL CABLE is displayed, or if nothing is
displayed, check:
• that the video interface cable is connected properly.
• the correct video adapter card is installed.
• the correct supported display mode is selected for your computer.
2. Wait approximately 15 minutes, until the monitor warms up.
3. Insert the User’s Guide and Installation Files CD into the computer CDROM drive.
4. Display the command prompt screen of the DOS full-screen display.
5. Type d:\ (change the drive letter to match your CD-ROM drive if it is not
drive D).
6. Type TESTPATD and press ENTER.
7. Select from the screen the number for the color or text mode you want to
set up.
8. Select from the screen the number for the video mode you want to set
up. You can repeat this process for as many of the color and video
modes as you need.
9. When the dot pattern appears, press the Image Setup ( ) button at
the bottom of the monitor. This activates the
AUTO SETUP procedure,
which will optimize the display settings with the provided dot-patterns.
The screen will momentarily turn black while auto adjustment proceeds.
14
10. When finished, the Auto Adjustment menu disappears and the screen
returns to a normal display.
11. Press the ESCAPE key to exit the test pattern program.
12. Type Exit at the command prompt to return to Windows.
If you use other operating systems, perform the appropriate Auto Setup for
those systems using instructions given in "
dows 98, Windows NT, Windows 2000, Windows Me or Windows XP
Auto Setup for Windows 95, Win-
on page
15".
Auto Setup for Windows 95, Windows 98, Windows NT, Windows 2000,
Windows Me or Windows XP
To set up the monitor automatically in Windows 95, Windows 98,
Windows NT, Windows 2000, Windows Me, or Windows XP, do the following:
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
If the monitor is in standby
mode (STANDBY ON), it
may automatically turn off while
you are waiting for it to warm up.
The size and diversity of the
dot pattern varies with the
screen resolution.
1. Turn on the monitor first; then the computer.
If the message CHECK SIGNAL CABLE is displayed, or if nothing is
displayed, check:
• that the video interface cable is connected properly.
• the correct video adapter card is installed.
• the correct supported display mode is selected for your computer.
2. Wait approximately 15 minutes, until the monitor warms up.
3. Drag the icon bar and tool bar, if they are displayed, to the bottom of the
screen.
4. Insert the User's Guide and Installation CD into the computer CD-
ROM drive.
5. Check the operating system installed on your computer and follow the
instructions from the table below.
Operating system
Operating System Step1 Step2 Step3
Windows 95,
Windows 98,
Windows 2000,
Windows NT,
Windows Me or
Windows XP
Select
S
TART
installation steps
Typ e D:\TESTPAT (change
Select
R
UN
the drive letter to match your
CD-ROM drive if it is not drive
D) and press ENTER
DEUTSCH
6. When the test pattern appears, press the Image Setup ( ) button at
the bottom of the monitor. This activates the
AUTO SETUP procedure,
which will optimize the display settings with the provided test patterns.
The screen will momentarily turn black while auto adjustment proceeds.
7. When finished, the Auto Adjustment menu disappears and the screen
returns to a normal display.
8. Press the
ESC key to return to Windows.
You have completed the monitor setup for Windows. If you are using the DOS
operating system, go to
Auto Setup for DOS on page 14.
15
Manual Setup
Manual setup is not required when using digital input.
Normally, you can complete the setup procedure using AUTO SETUP; however,
If the monitor is in standby
mode (STANDBY ON), it
might automatically turn off while
you are waiting for it to warm up.
if your screen image is still distorted after you perform
Installation CD does not run on your system, perform MANUAL SETUP.
1. Have your monitor turned on for about 15 minutes, until the monitor
2.
3. Press the OSD Enter button at the bottom of the monitor to display
4. Use the or button to select the Image Setup icon and press
5.
AUTO SETUP or the
warms up.
Display the image you most frequently use on the screen then go to
windows shut down mode.
the initial OSD menu.
the OSD Enter button to access.
Use the or button to select Clock and Phase to adjustment.
(a) "Clock" (pixel frequency) controls the number of pixels scanned
by one horizontal sweep.
If the frequency is not correct, the screen shows vertical stripes
and the picture does not have the correct width.
(b) "Phase" adjust the phase of the pixel clock signal. With a wrong
phase adjustment the picture has horizontal disturbances in
light picture.
16
6.
Use a select ( or ) button to manually adjust to correct and execute
save go to up menu then press the Exit ( ) button to leave OSD menu.
You have completed monitor setup.
Adjusting Your LCD Monitor
User controls
Thinkvision
ENGLISHFRANÇAIS
User control features
• Dirct access controls
When OSD is not displayed,
Icon
1
2
• Main OSD me
When OSD is displayed,
Icon Control
Control
Image Setup
Brightness
OSD Enter
Power Switch
Input Signal
Exit
Left Arrow
Description
Activates automatic image adjustment.
Directly accesses to Brightness on the OSD main
menu.
Displays the OSD main menu.
Switches the monitor on and off.
Switches the video input source (Only for L150p)
Description
Exits from menus and sub-menus Exits the
OSD.
Moves the cursor to highlight icons and
other options.
DEUTSCH
ESPAÑOLITALIANO
JAPANESECOMPL & WARR
Right Arrow
OSD Enter
Moves the cursor to highlight icons and
other options.
Enters menus and sub-menus and selects
the highlighted option.
17
The image is already
optimized for many display
modes; however the user controls
can be used to adjust the image to
your liking.
Operation
• Press the OSD Enter button to display the main OSD menu.
• Use the Arrow buttons to move among the icons. Select an icon and press
OSD Enter to access that function. If there is a sub-menu, you can move
between options using the Arrow buttons, then press OSD Enter
to select
that function. Use the Arrow buttons to make adjustments. Press the
button to save.
• Press the Exit ( ) button to move backwards through the sub-menus
and exit from the OSD.
OSD Lock / Unlock
•
This feature allows you to secure the current control settings, so that they
cannot be changed, while allowing you to adjust the brightness and contrast.
You can unlock the OSD controls at any time using the same procedure
•
Push and hold the OSD Enter ( ) button for 10 seconds to Lock or to Unlock.
When unlocked, a "Menu is Unlocked" message will be displayed. When
locked, a "Menu is Locked" message will be displayed.
18
On-screen display (OSD) controls
The settings adjustable with the user controls are viewed through the OnScreen Display (OSD). Press the OSD Enter button ( ) to activate the
OSD.
The LCD monitor needs
time to become thermally
stable the first time you turn it on
each day. Thus, to achieve more
accurate adjustments for
parameters, allow the LCD
monitor to warm up (be On) for at
least 15 minutes before making
any screen adjustments.
OSD Icon on
Main Menu
Brightness/
Contrast
Submenu Description
Brightness
Initial appearance of OSD
Ex i t OK
OSD functions
Adjusts brightness. Same as Analog
Br i ght nes s / Cont r a st
Controls and
Adjustments (Analog)
Controls and
Adjustments (Digital)
Image Position
Contrast
Horizontal Position
Vertical Position
Adjusts contrast. Controls Locked
Moves the screen left or right.
Controls Locked
Moves the screen up or down.
Controls Locked
19
OSD Icon on
Main Menu
Submenu Description
Controls and
Adjustments (Analog)
Controls and
Adjustments (Digital)
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
Image Setup Automatic
Manual
• Clock
• Phase
Color
Properties
Options
1. Preset Mode
• 6500K
• 7200K
• 9300K
2. Custom
•Red
• Green
•Blue
Input video signal
Information
Activates automatic image adjustment.
Use the
If satisfactory results are not obtained using the Phase
adjustment, use the Clock adjustment and then use Phase
again.
Adjusts intensity of red, green and blue. Controls Locked
6500K adjusts the screen more red.
7200K adjusts the screen to the default color settings.
9300K adjusts the screen more blue.
Increases or decreases 'red'.
Increases or decreases 'green'.
Increases or decreases 'blue'.
Use or to select video
signa. (Analog or Digital.)
With this function, switch the
screen from the analog to
the digital mode or vice versa.
The condition is that the
graphic card used supports
this function.
Shows resolution, refresh rate, and product details.
Note: This screen does not allow any changes to the
settings.
or button to adjust away the interference.
1 - selects D-SUB
(Analog)
2 - selects DVI-Digital
(Digital)
Controls Locked
Same as Analog
Same as Analog
DEUTSCH
20
Language
The language chosen affects
only the language of the OSD.
It has no effect on any
software running on the
computer.
Select one of the 5
languages (English,
French, Italian, German
and Spanish) to use for
the OSD.
OSD Icon on
Main Menu
(Continued)
Submenu Description
Controls and
Adjustments (Analog)
Controls and
Adjustments (Digital)
Options
Adjusts menu location on the screen.
Menu Position
1. Default
2. Custom
• Horizontal Changes the horizontal
• Vertical Changes the vertical position
Factory Reset
• Cancel
• Reset
Accessibility
Returns the menu position to the default settings.
position of OSD.
of OSD.
Resets monitor to the origital settings.
Does not make the adjustment.
Resets the settings.
Changes button repeat rate
and menu time out setting.
Same as Analog
• Button repeat
rate
• Menu time out
Selects
repeating rate.
Sets the length of time the
OSD will remain active after
the last time a button is
pressed.
or button
Off - increases by 1
each time the button is
pressed.
Default - increases
continuously while the
button is pressed.
Slow - increases by 1
every 2 seconds while
the button is pressed.
Use the
button to select time
from 5 to 60 seconds.
or
21
Further Information
Display modes
The display mode the monitor uses is controlled by the computer. Therefore,
refer to your computer documentation for details on how to change display
modes.
The image size, position and shape might change when the display mode
changes. This is normal and the image can be readjusted using
and the monitor controls.
Unlike CRT monitors, which require a high refresh rate to minimize flicker,
TFT technology is inherently flicker-free. If possible, configure your computer
for 1024 × 768 addressability at 60Hz vertical refresh rate.
For the display modes listed on the next page, the screen image has been
optimized during manufacture.
AUTO SETUP
22
For image problems, you
may want to run AUTO
Setup again before consulting this
section. In most cases, AUTO
SETUP can fix the problems. See
Auto Setup for DOS
for details.
on page 12
Factory Set Display Modes
Addressability Refresh Rate
640 × 350 70 Hz
640 × 480 60 Hz
640 × 480
640 × 480 75 Hz
720 × 400 70 Hz
800 × 600 60 Hz
800 × 600
800 × 600
1024 × 768
†
72 Hz
72 Hz
75 Hz
60 Hz
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
DEUTSCH
1024 x 768
1024 x 768
† Recommended
70 Hz
75 Hz
Note: VESA timings are as detailed in the VESA “Display Monitor Timing
Specification”. Version 1.0, Revision 0.8, dated 09/17/98.
23
Power Management
If your computer has
previously been used
with a CRT monitor and is
currently configured to a
display mode outside the
range that the Flat Panel
monitor can display, you
may need to re-attach the
CRT monitor temporarily
until you have re-configured
the computer, preferably to
1024 x 768 at 60Hz.
To benefit from power management, the monitor must be used in conjunction
with a computer that implements the Video Electronics Standards Association
(VESA) Display Power Management Signalling (DPMS) Standard.
The power management feature is invoked when the computer recognizes
that you have not used your mouse or keyboard for a user-definable period.
There are several states as described in the table below.
ENERGY STAR
As an
ENERGY STAR
®
®
Partner, IBM has determined that this product meets the
guidelines for energy efficiency.
For optimal performance, switch off your monitor at the end of each working
day, or whenever you expect to leave it unused for long periods during the
day.
State
ON
Active Off
Power
Indicator
Steady Green
Blinking green
Screen
Norma
Blank
Restoring
Operation
Press a key or
move the mouse.
*
Compliance
NERGY S TAR
E
®
Product Disposal
24
* There may be a slight delay before the picture reappears.
The fluorescent lamp in the liquid crystal display contains a small amount of
mercury. Dispose of it as required by local ordinances and regulations.
Troubleshooting
If you have a problem setting up or using your monitor, you might be able to
solve it yourself. Before calling your retailer or IBM, try the suggested actions
that are appropriate to your problem.
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
Problem
Computer does
not boot after
the graphics
adapter is
installed
The screen
image is
garbled or
unusable
(rolling screen
images,
overlapping
screen images
or a blank
screen)
Screen is blank
and power
indicator is off
Possible
Cause
There is
another
graphics
adapter in the
computer
The display
driver is trying
to use a
setting your
monitor does
not support
No power to
monitor
Suggested Action Reference
Remove the other
graphics adapter plugged
into one of the expansion
slot.
If the card is built-in to
the motherboard, check
your system manual for
instructions on how to
disable the built-in adapter.
Connecting
your Monitor
section on
page 7 ~ 8
Connecting
Select the correct
monitor.
your Monitor
section on
page 7 ~ 8
Ensure that the
electrical outlet and the
monitor are both switched
on.
Check that the power
cord is firmly plugged into
the electrical outlet and the
power supply unit.
If the power cord plug
has a removable fuse,
replace it.
Connecting
your Monitor
section on
page 7 ~ 8
Try another power
cord.
Try another electrical
outlet.
DEUTSCH
25
Problem
Possible
Cause
Suggested Action Reference
Screen is blank
and power
indicator is
steady green
Screen is blank
and power
indicator is
blinking green.
Brightness
and Contrast
may be too
low
The monitor is
in the Power
Management
Standby state
The monitor is
not receiving
a video signal
The monitor is
in the Power
Management
Suspend or
Off state
Adjust brightness and
contrast.
Press any key on the
keyboard or move the
mouse to restore
operation.
Check the Power
Management software on
your computer
Check that the signal
cable is firmly connected to
the computer.
Check that no pins are
bent in the signal cable
connector.
Press any key on the
keyboard or move the
mouse to restore
operation.
Check the Power
Management software on
your computer.
User
controls
section on
page 17
Power
Management
section on
page 24
Connecting
your Monitor
section on
page 7 ~ 8
Power
Management
section on
page 24
26
Image appears
to be smeared
Image appears
to be
discolored
Display mode
of the
computer is
outside the
range of the
monitor
There are
noises in the
video signal
The Color
setting may
be incorrect
Reconfigure the
computer to use a
supported display mode.
Select Image Setup
menu in the OSD. Then
select MANUAL to adjust
Phase/Clock settings.
Adjust the Color
settings.
Further
Information
section on
page 22
User
Controls
setion on page
17
User
Controls
setion on page
17
Problem
Possible
Cause
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESE
Suggested Action Reference
A few dots are
missing,
discolored, or
inappropriately
lighted.
A small number of missing, discolored, or
lighted dots may be present on the screen,
which is an intrinsic characteristic of the TFT
LCD technology and is not an LCD defect.
DEUTSCH
27
COMPL & WARR
Further Help
If you are unable to correct the problem yourself, you may seek further help
as follows:
Call the IBM HelpCenter
®
.
In the US call 1-800-772-2227
In Canada (Toronto Only) call 416-383-3344
In Canada (all others) call 1-800-565-3344
If possible, stay by your
computer. Your Technical
Support Representative may wish
to go through the problem with
you during the call.
More help, late-breaking
news and details of the latest
accessories for these products
may be found on the worldwide
web at:
http://www.pc.ibm.com/us/
accessories
In other countries contact your dealer, retailer, or other IBM authorized
Servicer.
Before calling, please have available as much of the following information as
possible:
1. Model and serial number from the label on your monitor.
2. Purchase receipt.
3. Description of problem.
4. Computer type and model.
5. System configuration (hardware fitted, etc.).
6. System BIOS version number.
7. Operating System and version number.
8. Display driver version number.
9. Video Adapter Type.
28
Specifications
This color monitor (Type-model 6636-**1) uses a 15-inch TFT LCD
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
Power consumption figures
are for the monitor and the
power supply combined.
Dimensions
Weight
Power Input
Power
Consumption
Video Input
(Analog)
Video Input
Communications
Contents
(Digital)
Model
Height :
Depth:
Width:
Unpackaged:
Packaged:
Viewable Image Size:
Maximum Height:
Maximum Width:
Pixel Pitch:
Supply Voltage:
Supply Current:
Normal Operation:
DPMS Stand-by:
DPMS Suspend:
DPMS off:
Input Signal:
Horiz. Addressability:
Vert. Addressability:
Clock Frequency:
Interface:
Input Signal:
Horiz. Addressability:
Vert. Addressability:
Clock Frequency:
VESA DDC: 2 B
L150
370.0 mm (14.57 in.)
214.0 mm ( 8.43 in.)
363.6 mm (14.31 in.)
4.8 Kg (10.58 lb)
6.3 Kg (13.89 lb)
381.0 mm (15.0 in.)
228.1 mm (8.98 in )
304.1 mm (11.97 in )
0.297 mm (.012 in.) (H)
× 0.297 mm (.012 in.) (V)
100 - 240 V ac,
60/50 ± 3 Hz
1.5 A at 120 V ac
< 30 W
< 2 W
< 2 W
< 1 W
Analog Direct Drive,
75 ohm 0.7 V
1024 pixels (max)
768 lines (max)
80 MHz
N/A
L150p
H: 439.7 mm (14.25 in )
L: 314.7 mm (12.39 in )
237.0 mm ( 9.33 in )
363.6 mm (14.31 in )
5.3 Kg (11.69 lb)
6.8 Kg (14.99 lb)
381.0 mm (15.0 in.)
228.1 mm (8.98 in )
304.1 mm (11.97 in )
0.297 mm (.012 in.) (H)
× 0.297 mm (.012 in.) (V
100 - 240 V ac,
60/50 ± 3 Hz
1.5 A at 120 V ac
< 30 W
< 2 W
< 2 W
< 1 W
Analog Direct Drive,
75 ohm 0.7 V
1024 pixels (max)
768 lines (max)
80 MHz
DVI
VESA TMDS (Panel Link TM)
1024 pixels (max)
768 lines (max)
80 MHz
2 B
DEUTSCH
Supported Display
Modes
VESA Standard
modes between
Horiz. Frequency:
Vert. Frequency:
30 kHz - 63 kHz
55 Hz - 75 Hz
30 kHz - 63 kHz
55 Hz - 75 Hz
29
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
Contents
Environment
Lift
Swivel
Tilt
Temperature:
Operating:
Storage:
Shipping:
Humidity:
Operating:
Storage:
Shipping:
Model
L150
10 to 35° C (5 to 95° F)
- 20 to 60° C (-4 to 140° F )
- 20 to 60° C (-4 to 140° F )
10 to 80%
10 to 90%
10 to 90%
N/A
N/A
– 5° / + 40°
L150p
10 to 35° C (5 to 95° F)
- 20 to 60° C (-4 to 140° F)
- 20 to 60° C (-4 to 140° F
10 to 80%
10 to 90%
10 to 90%
125mm
–150° / +150°
– 0° / + 30°
DEUTSCH
30
Service Information
The following parts are for use by IBM service, or IBM authorized dealers, to support
the customer warranty. Parts are for service use only.
Model Type 6636-XX1
P/N Description
06P4037
06P4043
06P4045 Black WWFRU Video Cable 6636-XX1
73P2363 WW6636-HX1FRU Stand Digital SB
06P4047 User's Guide CD
06P4048 Steup Guide
FRU Monitor
FRU Stand
Video
Analog SB
Hybrid
Analog
Analog
Hybrid
Color Geography
SB06P4040 FRU Monitor
SB
MTM
6636-AB1
6636-AX1
6636-XX1
6636-XX1
WW
WW6636-HB1
WW
Multilingual
WW
31
Notices and Trademarks
This section contains information on notices and trademarks.
Notices
IBM may not offer the products, services, or features discussed in this document in all
countries. Consult your local IBM representative for information on the products and services
currently available in your area. Any reference to an IBM product, program, or service is not
intended to state or imply that only that IBM product, program, or service may be used. Any
functionally equivalent product, program, or service that does not infringe any IBM intellectual
property right may be used instead. However, it is the user’s responsibility to evaluate and
verify the operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter described in this
document. The furnishing of this document does not give you any license to these patents. You
can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
ENGLISHFRANÇAISESPAÑOLITALIANOJAPANESECOMPL & WARR
DEUTSCH
32
The following paragraph does not apply to the United Kingdom or any country where
such provisions are inconsistent with local law: INTERNATIONAL BUSINESS MACHINES
CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied
warranties in certain transactions, therefore, this statement may not apply to you.
This information could include technical inaccuracies or typographical errors. Changes are
periodically made to the information herein; these changes will be incorporated in new editions
of the publication. IBM may make improvements and/or changes in the product(s) and/or the
program(s) described in this publication at any time without notice.
IBM may use or distribute any of the information you supply in any way it believes appropriate
without incurring any obligation to you.
Any references in this publication to non-IBM Web sites are provided for convenience only and
do not in any manner serve as an endorsement of those Web sites. The materials at those
Web sites are not part of the materials for this IBM product, and use of those Web sites is at
your own risk.
Trademarks
The following terms, used in this publication, are trademarks or service marks
of the IBM Corporation in the United States, other countries, or both:
HelpCenter IBM
ENERGY STAR® is a U.S. Govt. registered trademark.
Microsoft® Windows®, and Windows NT are trademarks of Microsoft
Corporation in the United States, other countries, or both.
Other company, product, and service names may be trademarks or service
marks of others.
© Copyright International Business Machines Corporation 2003. All
rights reserved.
33
Loading...
