IBM Infoprint 1000 family
IBM Infoprint 1120 and Infoprint 1125
Pr oviding unma tched reliability t o meet your pr inting demands
Capitalising on outstanding printer dependability and
performance
To compete effectively in e-business, workgroups need fast,
affordable printers with advanced features, broad expansion
capabilities and functional network connections.
Ideal for small to medium-sized work-groups, the IBM
Infoprint* 1120 and Infoprint 1125 offer a smart
implementation of network options to help ensure high-
speed communication and broad compatibility with the rest
of the Infoprint 1000 family. With features such as quick
output production, small footprints, various input options,
duplex capability, flexible connections and low cost, these
printers deliver exceptional reliability, performance and
value.
Provide print speeds of up to 20ppm and 25ppm to help
•
optimise productivity
Enable printing flexibility with a wide range of options
•
Offer seamless connections for effective communication
•
Leverage workgroup laser printer investment with
•
multifunction capabilities
Provid e exper t onsite repair from special l y t rained
•
professionals.
Enabling a productive environment with high speeds and
superior print quality
The impressive output speeds and excellent print quality of
the Infoprint 1120 and Infoprint 1125 can help make your
workgroup more productive. The Infoprint 1120 produces up
to 20 page-per-minute (ppm) output and has a first-page-
print time of less than nine seconds for quick turnaround.
The Infoprint 1125 provides on-demand convenience and
efficiency with up to 25ppm output speed and equally
quick first-page-out time. With 1,200 x 1,200 dots-per-inch
(dpi) resolution, you can consistently produce high-quality
graphics and crisp text.
The Infoprint 1120 and Infoprint 1125 offer PCL 6 and
PostScript 3 as standard features. Optional IBM Intelligent
Printer Data Stream* (IPDS*) print capability enables better
error handling and recovery by interpreting data from
applications and using it to identify what data has or has
not printed.
Upgrade the IBM Infoprint 1120 with the IBM
M20 MFP Option to add full-function copy, fax
and network scan capabilities. (Photo includes T
Scanner shelf).
2
Delivering printing flexibility
Modular paper-handling capabilities,
including high-capacity drawers and
automatic duplex, provide a flexible
printing solution. Flash memory and
hard-drive options allow you to
manage large files while maintaining
rapid output speed. The duplex option
and high-yield, single-element toner
cartridges help minimise costs and
operator intervention. Additionally, a
print-and-hold function facilitates
secure printing of confidential
documents in a network environment.
Customisable MarkVision Professional
print management software enables
easy setup, control and monitoring.
MarkVision provides features including
realtime printer monitoring and e-mail
and pager notification of printer and
mass-device configuration.
Enabling effective communication with
seamless network connections
A broad scope of application solutions
is available, including ImageQuick,
which helps ensure quality printing of
Web-based images as well as PDF,
TIFF and other popular document
formats. Remote printer configuration,
management and monitoring can help
reduce network administration costs
and network-ready Ethernet and
parallel/USB base models offer
tailored solutions for popular office
environments.
Offering multifunction options that grow
with your business
Upgrading the Infoprint 1120 and
Infoprint 1125 with the IBM M20,
M25 and M30 MFP Options can help
increase productivity, improve process
times, reduce costs and optimise
device and space utilisation. These
MFP Options add full-function copy,
fax and network scan capabilities,
including fax from workstation, scan to
e-mail and FTP.
The M20, M25 and M30 feature
intuitive user interfaces (the M30 has
a colour touchscreen), easy-to-use
address book (the M30 adds
enterprise directory integration),
enhanced image processing and easy
integration with the Infoprint 1120
and Infoprint 1125 for demanding
workflow requirements. Consolidated
supplies for print, copy and fax can
help reduce costs, user intervention
and stock management. An optional,
robust software application integrates
into your workflow process to help
eliminate manual tasks by automating
document workflow activities, such as
routing, indexing and archiving.
Relying on world-class service
With IBM onsite repair service
upgrades, you can be confident
that specially trained IBM customer
engineers will come to your location
and correct any problems. Often, other
companies send third-party vendors
– who may be unfamiliar with their
products – to perform repairs. With
IBM service, you receive exceptional,
reliable support from experts with
comprehensive knowledge of IBM
printers, software and supplies and the
ability to get you up and running as
quickly as possible. While standard
hours of service are 11 hours a day, 5
days a week, you can upgrade to 24
hours a day, 7 days a week.
Taking advantage of industry-leading
output solutions
The dependability, fast output speeds,
excellent print quality and flexible
paper handling features of the IBM
Infoprint 1120 and Infoprint 1125 can
help make your workgroup more
productive. You can leverage your
existing printer investment by adding
the IBM M20, M25 and M30 MFP
Options for an affordable, scalable
upgrade to copy, fax and network scan
functionality.
For more information
To learn more about the IBM Infoprint
1120 and Infoprint 1125, as well
as the M20, M25 and M30 MFP
Options, contact your local IBM
Printing Systems representative or visit:
ibm.com/printers
3
MFP Options at a glance IBM M20 IBM M25 IBM M30
Input document handling
Automatic document feeder
– Capacity 25 sheets 50 sheets 50 sheets
– Maximum speed 10ppm black/7ppm colour 21ppm black/10ppm colour 23ppm black/14ppm colour
Maximum original size
– ADF 216 x 356mm 216 x 356mm 216 x 356mm
– Flatbed 210 x 297mm (A4) 210 x 297mm (A4) 210 x 297mm (A4)
Input Simplex Duplex (single pass) Duplex (single pass)
Console type LCD LCD Touchscreen
Scanning capabilities
Maximum optical resolution 600 x 600dpi 300 x 300dpi 300 x 300dpi
Scan file forma ts JPEG, TIFF, P DF , JPEG, TIFF, P DF , JPEG, TIFF , PDF ,
Adobe PostScript Level 2 Adobe PostScript Level 2 Adobe PostScript Level 2
T ype Colour and monochrome Colour and monochrome Colour and monochrome
Scan destinations/archiving FTP server, workstation, e-mail FTP server, workstation, e-mail FTP server, workstation, e-mail
LDAP integration Via internal web browser Via internal web browser Directly on the panel
Custom scan profiles Yes Yes Y es
Fax capabilities
Maximum fax resolution 400 x 400dpi 400 x 400dpi 400 x 400dpi
Modem speed 33.6Kbps 33.6Kbps 33.6Kbp s
Receive fax/receive to memory Yes/Yes Yes/Yes Yes /Yes
Send hard copy fax Platen or ADF Platen or ADF Platen or ADF
Send soft copy fax From PostScript 3 print From PostScript 3 print From PostScript 3 print
driver at workstation driver at workstation driver at workstation
Send to fax server Y es Yes Yes
Memory send Yes Yes Yes
Group fax/retry Yes/Yes Yes/Yes Yes/Yes
Shortcut keys Up to 245 shortcuts Up to 245 shortcuts Up to 9,999 shortcuts
Selectable quality modes Standard, Fine, Standard, Fine, Standard, Fine,
Superfine, Ultrafine Superfine, Ultrafine Superfine, Ultrafine
Transmission and receive log Yes Yes Y es
Delayed send No No Set time and date
Automatic and customisable No No Yes
cover she ets
Internal faxing (scan to FTP) Yes Yes Y es
Fax-server integration Biscom, Equisys, Omtool, Biscom, Equisys, Omtool, Biscom, Equisys, Omtool,
RightFax RightFax RightFax
Physical characteristics
– Dimensions (WxDxH) 498 x 365 x 275mm 570 x 430 x 190mm 845 x 521 x 305mm
– Weight 5.3kg 7kg 11.8kg
Scanner duty cycle 2,000 scan s/month 10,000 s cans/mont h 10 ,000 s cans/mont h
Warranty One year on site exchange One year on site exchange One year on site service
(upgrades are available) (upgrades are available) (upgrades are available)
4
Printers at a glance IBM Infoprint 1120 IBM Infoprint 1125
Maximum speed (up to) 20ppm 25ppm
Process or 200MHz 250MHz
First-page-out time <9 se co nd s <9 s ec o nd s
Technology Monochrome laser Monochrome laser
Maximum monthly usage
Print resolution 300, 600, 1,200 x 1,200dpi 300, 600, 1,200 x 1,200dpi
– Image Quality 1,200dpi 1,200dpi
Models Base, duplex (d), network (n), duplex network (dn) Base, network (n), duplex network (dn)
Memory (st d/max) 8/264MB (base, d); 1 6/272MB (base);
16/272MB (n, dn) 32/288MB (n, dn)
– Opti ons Hard Drive/Flash Hard Drive/Flash
Paper handling
2
– Input capacity (std/max) 250+100/3,850 sheets 500+100/4,100 sheets
– Input sources (std/max) 2/6 2/6
– Input options 250-, 400-, 500- and 2,000 sheet drawer 250-, 400-, 500- and 2,000 sheet drawer
– Output capacity (std/max) 250/250 sheets 250/250 sheets
– Output sources (std/max) 1/1 1/1
Duplex Option Option
PC interfaces
– Base, d USB port, bidirectional parallel port IEEE 1284-B
– Network, dn USB port, Ethernet 10BaseT/1 00BaseTx
Printer attachments (optional) Ethernet 10/100Base Tx, Ethernet 10/100Base Tx/10Base2, Ethernet 10BaseT/2, Token-Ring,
USB/Parallel 1284-C Interface Card, Coax/Twinax Adapter for SCS, Tri-Port Adapter with
RS-232/422 Serial, LocalTalk and IR (infrared) Adapter ports, Fiber Print Server SC and
MTRJ connector
External Print Server Token-Ring UTP/STP – 3 Port, Ethernet 10/100BaseT x – 1 Port or 3 Port, Ethernet
10/100BaseTx/Base2 – 1 Port, infrared adapter, serial adapter
Network environment Microsoft
Linux, Mac OS 8.6 or higher, Novell NetWare 3.x, 4.x, 5.x including NDS and NDPS support
Printer Languages (standard) PCL 6 Emulation, PostScript 3 Emulation, PPDS Migration Tool with Euro Support
Application Solutions Options AFP/IPDS Card, ImageQuick Card (standard on ‘in’ models), Optra Forms, Bar Code Card ,
Prescribe
Media sizes A4, A5, JIS B5, Letter, Legal, executive, folio statement and custom sizes 76 x 127mm
to 216 x 356mm
Media
– T ypes Plain paper, bond, envelopes, card stock, transparencies and labels
– Weight 60 to 216g/m² 60 to 2 16g/m²
Physical characteristics
– Dimensions (WxDxH) 400 x 483 x 340mm 41 8 x 51 3 x 379mm
– Weight 16.8kg 18.2kg
Environmental characteristics 51 dBA/30dBA (idle) 55dBA/31 dBA (idle)
Supplies³
– Ships with 5K print cartridge 5K print cartridge
– Available 7 .5K and 20K print cartridges 7 .5K and 20K print cartridges
Cost-saving and High yield print cartridges, IBM Return Program, selectable Print Darkness levels (up to 50%
environmental features toner savings), Print and Hold (Verify Print), optional two-sides printing, Multi-up printing, alert
driven printer management, power saver mode
Warranty one year on site service one year on site service
For expanded specifications, visit ibm.com /printers/workgroup
1
IBM does not recommend printing this monthly maximum on a consistent basis.
2
Printer stands are available for improved stability.
3
Assumes 5 percent toner coverage per page.
1
100,000 pag es 12 0,000 page s
**
Windows** XP , 2000, Me, 98, 95, Windows NT** 4.0 or higher, UNIX**,
5
IBM United Kingdom Limited
1 New Square
Bedfont Lakes
Feltham
Middlesex
TW14 8HB
United Kingdom
The IBM home page can be found at ibm.com
*
IBM, the IBM logo, e logo, Infoprint, Intelligent
Printer Data Stream and IPDS are trademarks of
International Business Machines Corporation in
the United States, other countries, or both.
**
Microsoft, Windows and Windows NT are
trademarks of Microsoft Corporation.
**
UNIX is a registered trademark of The Open
Group.
Other company, product and service names may
be trademarks, or service marks of others.
References in this publication to IBM products,
programs or services do not imply that IBM
intends to make these available in all countries
in which IBM operates. Any reference to an
IBM product, program or service is not intended
to imply that only IBM’s product, program or
service may be used. Any functionally equivalent
product, program or service may be used
instead.
IBM hardware products are manufactured from
new parts, or new and used parts. In some
cases, the hardware product may not be new and
may have been previously installed. Regardless,
IBM warrant y terms apply.
This publication is for general guidance only.
Photographs may show design models.
© Copyright IBM Corporation 2002.
PRBEE31-0602-LO
Loading...
