ERserver

򔻐򗗠򙳰

IBM xSeries 455 Type 8855

Hardware Maintenance Manual and Troubleshooting Guide

ER s e r v e r

򔻐򗗠򙳰

IBM xSeries 455 Type 8855

Hardware Maintenance Manual and Troubleshooting Guide

Note

Before using this information and the product it supports, read Appendix C, “Notices,” on page 255.

Fourth Edition (February 2005) The most recent version of this document is available on the World Wide Web at

http://www.ibm.com/pc/support. The following paragraph does not apply the United Kingdom or any country where such provisions are

inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION ″AS IS″ WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time.

This publication was developed for products and services offered in the United States of America. IBM may not offer the products, services, or features discussed in this document in other countries, and the information is subject to change without notice. Consult your local IBM representative for information on the products, services, and features available in your area.

Requests for technical information about IBM products should be made to your IBM reseller or IBM marketing representative.

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

About this manual

This manual contains diagnostic information, a Symptom-to-FRU index, service information, error codes, error messages, and configuration information for the IBM

Eserver

™

xSeries

Important: The field replaceable unit (FRU) procedures are intended for trained

servicers who are familiar with IBM products. Before servicing an IBM product, be sure to review “Safety information” on page 215.

Important safety information

Be sure to read all caution and danger statements in this book before performing any of the instructions. See “Safety information” on page 215.

Leia todas as instruções de cuidado e perigo antes de executar qualquer operação.

Prenez connaissance de toutes les consignes de type Attention et Danger avant de procéder aux opérations décrites par les instructions.

Lesen Sie alle Sicherheitshinweise, bevor Sie eine Anweisung ausführen.

455 Type 8855 server.

Online support

Accertarsi di leggere tutti gli avvisi di attenzione e di pericolo prima di effettuare qualsiasi operazione.

Lea atentamente todas las declaraciones de precaución y peligro ante de llevar a cabo cualquier operación.

WARNING: Handling the cord on this product or cords associated with accessories

sold with this product will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash

hands after handling.

ADVERTENCIA: El contacto con el cable de este producto o con cables de

accesorios que se venden junto con este producto, pueden exponerle al plomo, un elemento químico que en el estado de California de los Estados Unidos está considerado como un causante de cancer y de defectos congénitos, además de otros riesgos reproductivos. Lávese las manos después de usar el producto.

You can download the most current diagnostic, system abstraction layer/extensible firmware interface (SAL/EFI) flash, and device driver files from http://www.ibm.com/pc/support on the World Wide Web.

iv IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Contents

About this manual . . . . . . . . . . . . . . . . . . . . . . . iii

Important safety information . . . . . . . . . . . . . . . . . . . . iii

Online support . . . . . . . . . . . . . . . . . . . . . . . . . iii

Chapter 1. General information . . . . . . . . . . . . . . . . . . .1

Related publications . . . . . . . . . . . . . . . . . . . . . . .1

Notices and statements used in this book . . . . . . . . . . . . . . .2

Features and specifications . . . . . . . . . . . . . . . . . . . . .3

What your server offers . . . . . . . . . . . . . . . . . . . . . .4

Active Memory . . . . . . . . . . . . . . . . . . . . . . . . .5

Memory scrubbing and Memory ProteXion . . . . . . . . . . . . . .5

Memory mirroring . . . . . . . . . . . . . . . . . . . . . . .5

Hot-swap memory . . . . . . . . . . . . . . . . . . . . . . .5

Server controls, LEDs, and power . . . . . . . . . . . . . . . . . .6

Front view . . . . . . . . . . . . . . . . . . . . . . . . . .6

Rear view . . . . . . . . . . . . . . . . . . . . . . . . . .7

Server power features . . . . . . . . . . . . . . . . . . . . . .9

Chapter 2. Configuring the server . . . . . . . . . . . . . . . . .11

Using the EFI Firmware Boot Manager . . . . . . . . . . . . . . . .12

Using the Configuration/Setup Utility program . . . . . . . . . . . . .12

Starting the Configuration/Setup Utility program . . . . . . . . . . . .12

Configuration/Setup Utility menu choices . . . . . . . . . . . . . .13

Passwords . . . . . . . . . . . . . . . . . . . . . . . . .15

Using the RAID configuration programs . . . . . . . . . . . . . . . .16

Using the LSI Logic Configuration Utility program . . . . . . . . . . .16

Using ServeRAID Manager . . . . . . . . . . . . . . . . . . .17

Setting up the Remote Supervisor Adapter . . . . . . . . . . . . . . .20

Remote Supervisor Adapter features . . . . . . . . . . . . . . . .20

Setup requirements . . . . . . . . . . . . . . . . . . . . . .20

Cabling and configuring the Remote Supervisor Adapter . . . . . . . . .21

Using the ASM interconnect network . . . . . . . . . . . . . . . .29

Configuring the Gigabit Ethernet controller . . . . . . . . . . . . . . .33

Configuring scalable partitions . . . . . . . . . . . . . . . . . . .34

Creating a scalable partition . . . . . . . . . . . . . . . . . . .34

Deleting a scalable partition . . . . . . . . . . . . . . . . . . .36

Chapter 3. Diagnostics . . . . . . . . . . . . . . . . . . . . .37

General checkout . . . . . . . . . . . . . . . . . . . . . . . .37

Diagnostic tools overview . . . . . . . . . . . . . . . . . . . . .39

POST error codes and messages . . . . . . . . . . . . . . . . . .39

System-error logs . . . . . . . . . . . . . . . . . . . . . . . .40

Light Path Diagnostics feature . . . . . . . . . . . . . . . . . . .40

The diagnostics panel . . . . . . . . . . . . . . . . . . . . .41

LEDs on the top of the server . . . . . . . . . . . . . . . . . .41

LEDs on the system boards . . . . . . . . . . . . . . . . . . .41

Diagnostic display . . . . . . . . . . . . . . . . . . . . . . . .42

Diagnostic programs, error codes, and messages . . . . . . . . . . . .42

Text messages . . . . . . . . . . . . . . . . . . . . . . . .42

Starting the AMIDiag program . . . . . . . . . . . . . . . . . .42

AMIDiag menus . . . . . . . . . . . . . . . . . . . . . . .44

System diagnostic tests . . . . . . . . . . . . . . . . . . . . .46

Memory diagnostic tests . . . . . . . . . . . . . . . . . . . .47

IDE device diagnostic tests . . . . . . . . . . . . . . . . . . .48

SCSI diagnostic tests . . . . . . . . . . . . . . . . . . . . .50

Video diagnostic tests . . . . . . . . . . . . . . . . . . . . .53

USB diagnostic tests . . . . . . . . . . . . . . . . . . . . . .54

Miscellaneous diagnostic tests . . . . . . . . . . . . . . . . . .61

Options menu . . . . . . . . . . . . . . . . . . . . . . . .64

Ethernet diagnostic tests . . . . . . . . . . . . . . . . . . . .71

Diagnostic error code tables . . . . . . . . . . . . . . . . . . .71

Small computer system interface (SCSI) messages . . . . . . . . . . .71

Recovering SAL/EFI code . . . . . . . . . . . . . . . . . . . . .71

Clearing a power-on password . . . . . . . . . . . . . . . . . . .73

Clearing CMOS . . . . . . . . . . . . . . . . . . . . . . . . .74

Power checkout . . . . . . . . . . . . . . . . . . . . . . . .74

Troubleshooting the Ethernet controller . . . . . . . . . . . . . . . .75

Network connection problems . . . . . . . . . . . . . . . . . .75

Ethernet controller troubleshooting chart . . . . . . . . . . . . . .76

Ethernet controller messages . . . . . . . . . . . . . . . . . .76

Chapter 4. Installing options . . . . . . . . . . . . . . . . . . .77

Installation guidelines . . . . . . . . . . . . . . . . . . . . . .77

System reliability considerations . . . . . . . . . . . . . . . . .77

Working inside a server with power on . . . . . . . . . . . . . . .78

Handling static-sensitive devices . . . . . . . . . . . . . . . . .78

Major components of the xSeries 455 server . . . . . . . . . . . . . .79

Midplane board LEDs . . . . . . . . . . . . . . . . . . . . . .80

Processor board internal connectors and LEDs . . . . . . . . . . . . .80

PCI-X board internal connectors and LEDs . . . . . . . . . . . . . .82

Memory board internal connectors and LEDs . . . . . . . . . . . . . .82

Memory switch card LEDs . . . . . . . . . . . . . . . . . . . . .83

I/O-board internal connectors . . . . . . . . . . . . . . . . . . . .83

Opening the cover . . . . . . . . . . . . . . . . . . . . . . .84

Removing and replacing the bezel . . . . . . . . . . . . . . . . . .85

Removing and replacing a hot-swap power supply . . . . . . . . . . . .86

Installing an adapter . . . . . . . . . . . . . . . . . . . . . . .88

Cabling a ServeRAID adapter . . . . . . . . . . . . . . . . . . .91

Installing a hot-swap hard disk drive . . . . . . . . . . . . . . . . .93

Installing a CD-ROM or DVD-ROM drive . . . . . . . . . . . . . . .94

Installing memory . . . . . . . . . . . . . . . . . . . . . . . .95

Hot-replacing DIMMs . . . . . . . . . . . . . . . . . . . . . . .98

Installing and replacing a microprocessor and power module . . . . . . . .99

Replacing and troubleshooting fans . . . . . . . . . . . . . . . . . 107

Replacing fan 1 or 2 . . . . . . . . . . . . . . . . . . . . . 107

Replacing fan 3 or 4 . . . . . . . . . . . . . . . . . . . . . 108

Replacing the battery . . . . . . . . . . . . . . . . . . . . . . 109

Completing the installation . . . . . . . . . . . . . . . . . . . . 111

Closing the cover . . . . . . . . . . . . . . . . . . . . . . . 111

Connecting the cables . . . . . . . . . . . . . . . . . . . . .112

Updating your server configuration . . . . . . . . . . . . . . . . 125

Installing the server in a rack . . . . . . . . . . . . . . . . . . 125

Chapter 5. Field replaceable units . . . . . . . . . . . . . . . . 127

Memory-board assembly . . . . . . . . . . . . . . . . . . . . . 127

Memory switch card and cable . . . . . . . . . . . . . . . . . . 128

Processor-board assembly . . . . . . . . . . . . . . . . . . . . 129

Microprocessor and power module . . . . . . . . . . . . . . . . 131

Processor-board VRM . . . . . . . . . . . . . . . . . . . . . 132

vi IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

PCI-X board assembly . . . . . . . . . . . . . . . . . . . . . 133

Midplane board . . . . . . . . . . . . . . . . . . . . . . . 135

Midplane-board VRM . . . . . . . . . . . . . . . . . . . . . 136

PCI-X board . . . . . . . . . . . . . . . . . . . . . . . . 137

Active PCI assembly . . . . . . . . . . . . . . . . . . . . . 140

I/O board, riser card, and Remote Supervisor Adapter . . . . . . . . . 141

Restoring the nonvolatile EFI variables . . . . . . . . . . . . . . 145

To p cover assembly . . . . . . . . . . . . . . . . . . . . . . 148

To p power board . . . . . . . . . . . . . . . . . . . . . . . . 149

Hard disk drive backplane . . . . . . . . . . . . . . . . . . . . 150

Media bay card . . . . . . . . . . . . . . . . . . . . . . . . 152

Memory-board retaining latches . . . . . . . . . . . . . . . . . . 152

AC box assembly mechanism . . . . . . . . . . . . . . . . . . . 154

Media-extract mechanism . . . . . . . . . . . . . . . . . . . . 155

Power/reset card assembly . . . . . . . . . . . . . . . . . . . . 156

Light Path card . . . . . . . . . . . . . . . . . . . . . . . . 157

Chapter 6. Symptom-to-FRU index . . . . . . . . . . . . . . . . 159

Light Path LED errors . . . . . . . . . . . . . . . . . . . . . . 159

System-error log entries . . . . . . . . . . . . . . . . . . . . . 163

SAL/EFI messages . . . . . . . . . . . . . . . . . . . . . . 163

Service processor messages . . . . . . . . . . . . . . . . . . 170

Diagnostic error codes . . . . . . . . . . . . . . . . . . . . . 175

System-error codes . . . . . . . . . . . . . . . . . . . . . . 176

IDE CD test error codes . . . . . . . . . . . . . . . . . . . . 178

ATAPI removables test error codes . . . . . . . . . . . . . . . . 179

IDE DVD-ROM drive test error codes . . . . . . . . . . . . . . . 181

SCSI test error codes . . . . . . . . . . . . . . . . . . . . . 181

Video test error codes . . . . . . . . . . . . . . . . . . . . . 184

USB test error codes . . . . . . . . . . . . . . . . . . . . . 184

Serial port test error codes . . . . . . . . . . . . . . . . . . . 186

Advanced System Management error codes . . . . . . . . . . . . 187

Scalability port and RXE port error codes . . . . . . . . . . . . . . 190

Memory test error codes . . . . . . . . . . . . . . . . . . . . 193

LED error codes . . . . . . . . . . . . . . . . . . . . . . . 195

Error symptoms . . . . . . . . . . . . . . . . . . . . . . . . 196

Power supply LED errors . . . . . . . . . . . . . . . . . . . . . 200

Diagnostic display error codes . . . . . . . . . . . . . . . . . . . 201

Hardware status error codes . . . . . . . . . . . . . . . . . . 201

SAL/EFI progress codes . . . . . . . . . . . . . . . . . . . . 203

SCSI error messages . . . . . . . . . . . . . . . . . . . . . . 205

Ethernet error messages . . . . . . . . . . . . . . . . . . . . . 205

Undetermined problems . . . . . . . . . . . . . . . . . . . . . 205

Chapter 7. Parts listing xSeries 455 Type 8855 . . . . . . . . . . . . 207

System . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

Figure A . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

Figure B . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Keyboard CRUs . . . . . . . . . . . . . . . . . . . . . . . .211

Power cord CRUs . . . . . . . . . . . . . . . . . . . . . . . 212

Appendix A. Getting help and technical assistance . . . . . . . . . . 213

Before you call . . . . . . . . . . . . . . . . . . . . . . . . 213

Using the documentation . . . . . . . . . . . . . . . . . . . . . 213

Getting help and information from the World Wide Web . . . . . . . . . 214

Software service and support . . . . . . . . . . . . . . . . . . . 214

Contents vii

Hardware service and support . . . . . . . . . . . . . . . . . . . 214

Appendix B. Related service information . . . . . . . . . . . . . . 215

Safety information . . . . . . . . . . . . . . . . . . . . . . . 215

General safety . . . . . . . . . . . . . . . . . . . . . . . 215

Electrical safety . . . . . . . . . . . . . . . . . . . . . . . 216

Safety inspection guide . . . . . . . . . . . . . . . . . . . . 217

Handling static-sensitive devices . . . . . . . . . . . . . . . . . 218

Grounding requirements . . . . . . . . . . . . . . . . . . . . 218

Safety notices (multilingual translations) . . . . . . . . . . . . . . 219

Appendix C. Notices . . . . . . . . . . . . . . . . . . . . . . 255

Edition notice . . . . . . . . . . . . . . . . . . . . . . . . . 255

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . 256

Important notes . . . . . . . . . . . . . . . . . . . . . . . . 256

Product recycling and disposal . . . . . . . . . . . . . . . . . . 257

Battery return program . . . . . . . . . . . . . . . . . . . . . 257

Electronic emission notices . . . . . . . . . . . . . . . . . . . . 258

Federal Communications Commission (FCC) statement . . . . . . . . 258

Industry Canada Class A emission compliance statement . . . . . . . . 258

Australia and New Zealand Class A statement . . . . . . . . . . . . 258

United Kingdom telecommunications safety requirement . . . . . . . . 258

European Union EMC Directive conformance statement . . . . . . . . 258

Taiwanese Class A warning statement . . . . . . . . . . . . . . . 259

Chinese Class A warning statement . . . . . . . . . . . . . . . . 259

Japanese Voluntary Control Council for Interference (VCCI) statement 259

Power cords . . . . . . . . . . . . . . . . . . . . . . . . . 259

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263

viii IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Chapter 1. General information

™

Your IBM Eserver high-availability 64-bit database processing.

Performance, ease of use, reliability, and expansion capabilities were key considerations in the design of your server. These design features make it possible for you to customize the system hardware to meet your needs today and provide flexible expansion capabilities for the future.

Your server contains IBM Enterprise X-Architecture increase performance and reliability. For more information, see “What your server offers” on page 4.

You can obtain up-to-date information about your server and other IBM server products at http://www.ibm.com/eserver/xseries/.

For service, assistance, or additional information on the World Wide Web, see Appendix A, “Getting help and technical assistance,” on page 213.

Related publications

xSeries 455 Type 8855 is a four U-high

rack model server for

™

technologies, which help

This Hardware Maintenance Manual and Troubleshooting Guide contains information to help you solve the problem yourself or to provide helpful information to a service technician.

In addition to this Hardware Maintenance Manual and Troubleshooting Guide, the following xSeries 455 Type 8855 documentation is provided with your server:

v Installation Guide

This printed publication contains setup and installation instructions.

v Rack Installation Instructions

This printed publication contains the instructions to install your server in a rack.

v Safety Book

This multilingual publication is provided in Portable Document Format (PDF) on

the IBM xSeries Documentation CD. It contains translated versions of the caution

and danger statements that appear in the documentation for your server. Each

caution and danger statement has an assigned number, which you can use to

locate the corresponding statement in your native language.

v User’s Guide

This publication is provided in PDF on the IBM xSeries Documentation CD. It

contains general information about your server, including information about

features, how to configure your server, and how to get help.

v Option Installation Guide

This publication is provided in PDF on the IBM xSeries Documentation CD. It

contains instructions to install, remove, and connect optional devices supported

by your server.

Depending on your server model, additional publications might be included on the IBM xSeries Documentation CD.

1. Racks are marked in vertical increments of 1.75 inches each. Each increment is referred to as a unit, or ″U.″ A one-U-high device is 1.75 inches tall.

Notices and statements used in this book

The caution and danger statements that appear in this book are also in the multilingual Safety Information book, which is on the IBM xSeries Documentation CD. Each statement is numbered for reference to the corresponding statement in the Safety Information book.

The following notices and statements are used in the documentation:

v Notes: These notices provide important tips, guidance, or advice. v Important: These notices provide information or advice that might help you avoid

inconvenient or problem situations.

v Attention: These notices indicate potential damage to programs, devices, or

data. An attention notice is placed just before the instruction or situation in which damage could occur.

v Caution: These statements indicate situations that can be potentially hazardous

to you. A caution statement is placed just before the description of a potentially hazardous procedure step or situation.

v Danger: These statements indicate situations that can be potentially lethal or

extremely hazardous to you. A danger statement is placed just before the description of a potentially lethal or extremely hazardous procedure step or situation.

2 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Features and specifications

The following information is a summary of the features and specifications of your server. Depending on your server model, some features might not be available, or some specifications might not apply.

Microprocessor:

™®

v Intel

Itanium 2 1.3 GHz or higher,

depending on server model

v 3 MB (minimum) Level-3 cache v 200 MHz front-side bus (FSB), at two data

transfers per cycle, yielding a 400 MHz system bus (minimum)

v Support for up to four microprocessors

™

v XceL4

Note:

Server Accelerator Cache: 64 MB

Use the Configuration/Setup Utility

program to determine the type and speed of the microprocessors in your server.

Active Memory™:

v Minimum: 1 GB v Maximum: 56 GB v Type: 2-way interleaved PC2100, ECC DDR

SDRAM, registered DIMMs only

v Supports 512 MB, 1 GB, and 2 GB dual inline

memory modules (DIMMs)

Drives

standard:

DVD/CD-RW: IDE

Expansion bays:

v Two removable media bays (one DVD/CD-RW

preinstalled)

v Supports up to two internal Ultra320 SCSI

hard disk drives

™

Active

PCI-X expansion slots:

Six 64-bit Active PCI-X expansion slots:

v Two 66 MHz PCI-X slots v Two 100 MHZ PCI-X slots v Two 133 MHZ PCI-X slots

Cooling:

Four hot-swap fans

v Two 150 mm x 51 mm fans v Two 150 mm x 38 mm fans

Acoustical

noise emissions:

v Declared sound power, idle: 6.5 bels v Declared sound power, operating: 6.5 bels v Bystander sound pressure, idle: 49 dBa v Bystander sound pressure, operating: 49 dBa

Power supply:

Two power supplies: 550 watts at 100-127 V ac or 1050 watts at 200-240 V ac (hot-swappable and redundant at 200-240 V ac only)

Video:

v Integrated ATI RageXL video v PCI bus interface v Compatible with SVGA v 8 MB SDRAM video memory

Size

(4 U):

v Height: 17.5 cm (6.9 inches, 4 U) v Depth: 71.3 cm (28.1 inches) v Width: 44 cm (17.3 inches) v Maximum weight: 54.3 kg (120 lb),

depending on your configuration

Integrated

v Broadcom 5704 10/100/1000 dual port

Ethernet controller

v Light path diagnostics v One external and one internal Ultra320 SCSI

port (dual-channel integrated controller with RAID capabilities)

v Remote Supervisor Adapter (service

processor) – ASM interconnect (peer-to-peer) port – Ethernet port – Serial port

v IDE controller v RXE Management Port v RXE Expansion Ports v USB ports v Serial port v SMP Expansion Ports v Wake on LAN

Environment:

v Air temperature:

– Server on: 10° to 35°C (50.0° to 95.0°F).

– Server on: 10° to 32°C (50.0° to 89.6°F).

– Server off: -40° to 60°C

Humidity:

– Server on: 8% to 80% – Server off: 5% to 100%

functions:

Altitude: 0 to 914 m (2998.7 ft)

Altitude: 0 to 2133 m (6998.0 ft)

(-104° to 140°F). Maximum altitude: 2133 m (6998.0 ft)

Heat output:

Approximate heat output in British thermal units (Btu) per hour

v Minimum configuration: 854 Btu (250 watts) v Maximum configuration: 2646 Btu (775 watts)

Electrical

input:

v Sine-wave input (50-60 Hz) required v Input voltage low range:

– Minimum: 100 V ac – Maximum: 127 V ac

v Input voltage high range:

– Minimum: 200 V ac – Maximum: 240 V ac

Input kilovolt-amperes (kVA) approximately:

– Minimum: 0.250 kVA – Maximum: 1.3 kVA

Notes:

1. Power consumption and heat output vary depending on the number and type of optional features installed and the power-management optional features in use.

2. These levels were measured in controlled acoustical environments according to the procedures specified by the American National Standards Institute (ANSI) S12.10 and ISO 7779 and are reported in accordance with ISO 9296. Actual sound-pressure levels in a given location might exceed the average values stated because of room reflections and other nearby noise sources. The declared sound-power levels indicate an upper limit, below which a large number of computers will operate.

Chapter 1. General information 3

What your server offers

Your server includes the following features and technologies:

v IBM Enterprise X-Architecture technology

Enterprise X-Architecture technology combines proven, innovative IBM designs to make your Intel-processor-based server powerful, scalable, and reliable. For more information, go to http://www.ibm.com/pc/us/eserver/xseries/xarchitecture/enterprise/index.html

– Active Memory

The Active Memory feature improves the reliability of memory through hot-swap memory, memory mirroring, memory scrubbing, and the Memory ProteXion feature. For more information, see “Active Memory” on page 5.

– Large system-memory capacity

The memory bus supports up to 56 GB of system memory. The memory controller provides error code correcting (ECC) support for up to 28 industry-standard PC2100, 2.5 V, 184-pin, 133 megahertz (MHz), registered, double data rate (DDR), synchronous dynamic random access memory (SDRAM) dual inline memory modules (DIMMs).

– XceL4

The XceL4 Server Accelerator Cache provides 64 MB of external Level-4 cache, which increases effective memory bandwidth.

v Integrated network support

Your server comes with an integrated Broadcom Gigabit Ethernet controller, which supports connection to a 10-Mbps, 100-Mbps, or 1000-Mbps network. For more information, see “Configuring the Gigabit Ethernet controller” on page 33.

v Light path diagnostics

Light path diagnostics provides LEDs to help you isolate problems. For more information, see the section about light path diagnostics in the Installation Guide.

v Scalable partitions

Up to four xSeries 455 servers can be connected together, providing a symmetric multiprocessor system with up to 16 microprocessors, 224 GB memory, and 48 I/O slots.

v Systems-management capabilities

The server comes with a Remote Supervisor Adapter installed in a dedicated connector. This adapter, when used with the system-management software that comes with the server, enables you to manage the functions of the server locally and remotely. The Remote Supervisor Adapter also provides system monitoring, event recording, and dial-out alert capability.

™

Server Accelerator Cache

4 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Active Memory

Active Memory is an IBM feature that improves the reliability of memory through hot-swap memory, memory mirroring, memory scrubbing, and the Memory ProteXion feature.

Memory scrubbing and Memory ProteXion

Memory scrubbing tests the memory at regular intervals to detect and report recoverable memory ECC errors before they can cause server outages.

If the recoverable ECC error rate exceeds the system-defined threshold, the Memory ProteXion feature replaces the failing bit positions, maintaining reliable operation. If the recoverable ECC error rate exceeds the threshold again, light path diagnostics LEDs are lit to indicate the failing DIMM.

You do not have to enable memory mirroring to use memory scrubbing and the Memory ProteXion feature.

Memory mirroring

Memory mirroring stores data in memory port 1 and memory port 2 simultaneously. To support memory mirroring, you must install identical dual inline memory modules (DIMMs) in memory port 1 and memory port 2. For more information, see the section about installing memory modules in the Option Installation Guide on the IBM

xSeries Documentation CD.

To enable memory mirroring through the Configuration/Setup Utility program, select Advanced Setup from the main menu, and select Memory Configuration. For more information about using the Configuration/Setup Utility program, see Chapter 2, “Configuring the server,” on page 11.

Hot-swap memory

You can replace a failed DIMM while the server is turned on, provided that you have enabled memory mirroring and that you have installed all DIMMs in the sequence to support memory mirroring.

If a problem with a DIMM is detected, light path diagnostics LEDs are lit to indicate the failing DIMM. When this occurs, identify the defective DIMM, and then remove and replace the DIMM. For more information, see the information about installing memory modules in the Option Installation Guide on the IBM xSeries

Documentation CD.

Chapter 1. General information 5

Server controls, LEDs, and power

This section describes the controls and light-emitting diodes (LEDs) on the front and rear of your server. It also describes how to turn the server on and off.

Front view

The following illustration shows the controls, LEDs, and connectors on the front of the server.

Note: The illustrations in this document might differ slightly from your hardware.

Power-on LED Power-control

button Reset button

Hard disk drive activity LED (green)

Hard disk drive error LED (amber)

Power-supply latch

Drive eject button

DVD/CD-RW drive activity LED

Drive eject button

DVD/CD-RW eject button

System-error LED (amber)

Information LED (amber)

SCSI activity LED (green)

Locator LED (blue)

USB connector

Power-on LED: When this LED is lit and not flashing, it indicates that the server is

turned on. When this LED is flashing, it indicates that the server is turned off and still connected to an ac power source. When this LED is off, it indicates that ac power is not present.

Note: If this LED is off, it does not mean that there is no electrical power in the

server. The LED might be burned out or the server might have malfunctioned. To remove all electrical power from the server, you must disconnect the power cords from the electrical outlets.

Hard disk drive activity LED: When this LED is lit, it indicates that the hard disk

drive is in use.

Hard disk drive error LED: On some server models, each hot-swap hard disk

drive has an error LED. The interpretation of a flashing error LED depends on the SCSI controller connected to the hot-swap drive. When the drive is connected to the integrated SCSI controller with RAID capabilities, a flashing error LED indicates that the drive is a secondary drive in a mirrored pair and the drive is being synchronized.

USB connector: Connect a USB device to this connector.

System-error LED: When this LED is lit, it indicates a system error has occurred.

Information LED: When this LED is lit, it indicates that information about a system

error has been entered in the System Error log.

6 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

SCSI activity LED: When this LED is lit, it indicates that there is activity on the

SCSI bus.

Locator LED: Use this LED to visually locate the server if it is in a location with

numerous other servers.

In multi-node configurations, when this LED flashes during startup, it indicates that the server is the primary node. When this LED is lit during startup, it indicates that the server is a secondary node.

Drive eject button: Press this button to release the drive from the server.

DVD/CD-RW eject button: Press this button to release a DVD or CD from the

drive.

DVD/CD-RW drive activity LED: When this LED is lit, it indicates that the

DVD/CD-RW drive is in use.

Drive eject button: Press this button to release a drive from the server.

Power-supply latch: This latch secures the power supply in place.

Rear view

Reset button: Press this button to reset the server and run the power-on self-test

(POST). You might have to use a pen or the end of a straightened paper clip to press the button.

Power-control button: Press this button to turn the server on and off manually. A

power-control-button shield comes with your server. You can install this disk-shaped shield to prevent the server from being turned off accidentally.

The following illustration shows the connectors and LEDs on the rear of the server.

System power connector (1)

SMP Expansion Port 1 connector

SMP Expansion Port 2 connector

SMP Expansion Port 3 connector

SCSI connector

RXE Management Port connector

System power connector (2)

USB 1 connector

USB 2 connector

Video connector

RXE Expansion Port (B) connector

Serial connector

Remote Supervisor Adapter connectors and LEDs

Ethernet LEDs

Gigabit Ethernet connectors

RXE Expansion Port (A) connector

System power connectors (1 and 2): Connect the power cords to these two

connectors to provide power to the server.

Chapter 1. General information 7

RXE Expansion Port (B) connector: Connect a remote I/O enclosure to this

connector.

Serial connector: Connect the signal cable for a modem or other serial device to

this connector.

Remote Supervisor Adapter connectors and LEDs: This group of connectors

and LEDs on the back of the server are used for system management information and control.

External power supply connector

Error LED (amber)

RS-485 connector (RJ14)

Ethernet activity LED (green)

Ethernet link LED (green)

Power LED (green)

System-management

connector

Ethernet connector

v External power supply connector: This connector is not supported on this

server.

v Error LED: When this amber LED is lit, it indicates an error on the Remote

Supervisor Adapter.

v ASM RS-485 connector (RJ-14): Connect signal cables for managing expansion

module resources to this connector.

v Ethernet activity LED: When this green LED flashes, it indicates that there is

activity on the Ethernet LAN.

v Ethernet link LED: When this green LED is lit, it indicates that there is an active

link connection.

v Ethernet connection: Connect Ethernet signal cables to this connector. v System-management connector: Connect signal cables for modems or other

serial devices to this connector.

v Power LED: This LED indicates the status of the power connection.

Ethernet

LEDs: When these LEDs are amber, they indicate that there is activity on

the Ethernet LAN. When these LEDs are green, they indicate that there is an active link connection on the Gigabit Ethernet controller.

Gigabit Ethernet connectors: Use these connectors to connect the server to a

network.

RXE Expansion Port (A) connector: Connect a remote I/O enclosure to this

connector.

Video connector: Connect a monitor to this connector.

USB 2 connector: Connect a USB device to this connector.

USB 1 connector: Connect a USB device to this connector.

8 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

RXE Management Port connector: Connect a remote I/O enclosure to this

connector.

SCSI connector: Connect a SCSI device to this connector.

SMP Expansion Port 3 connector: Use this connector to connect the server to

other servers and form multi-node configurations.

SMP Expansion Port 2 connector: Use this connector to connect the server to

other servers and form multi-node configurations.

SMP Expansion Port 1 connector: Use this connector to connect the server to

other servers and form multi-node configurations.

Server power features

When the server is connected to an ac power source but is not turned on, the operating system does not run, and all core logic except for the service processor is shut down; however, the server can respond to requests from the service processor, such as a remote request to turn on the server. The power-on LED flashes to indicate that the server is connected to ac power but is not turned on.

Turning on the server

Approximately 20 seconds after the server is connected to ac power, the power-control button becomes active, and you can turn on the server and start the operating system by pressing the power-control button. The server can also be turned on in any of the following ways:

v If a power failure occurs while the server is turned on, the server will restart

automatically when power is restored.

v If ac power is present, the server can be turned on from the Remote Supervisor

Adapter user interface.

v The Wake on LAN feature can turn on the server.

Notes:

1. The power supplies are hot-swappable and redundant only at 200-240 V ac.

2. Both power supplies must be connected to the power source for operation at 100-127 V ac.

3. During normal operation, both power supplies must be installed for proper operation.

4. While the server is powering up, the power-on LED on the front of the server is lit. When the server is connected to ac power but is not turned on, the power-on LED on the front of the server flashes.

5. When you press the power-control button on any server in a scalable partition, all servers in the scalable partition will be turned on. If the servers do not turn on when the power-control button is pressed, see “Error symptoms” on page

196.

Turning off the server

When you turn off the server and leave it connected to ac power, the server can respond to requests from the service processor, such as a remote request to turn on the server. To remove all power from the server, you must disconnect it from the power source.

Chapter 1. General information 9

Some operating systems require an orderly shutdown before you turn off the server. See your operating-system documentation for information about shutting down the operating system.

Statement 5:

CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.

2 1

The server can be turned off in any of the following ways:

v You can turn off the server from the operating system, if your operating system

supports this feature. After an orderly shutdown of the operating system, the server will be turned off automatically.

v You can press the power-control button to start an orderly shutdown of the

operating system and turn off the server, if your operating system supports this feature.

v If the operating system stops functioning, you can press and hold the

power-control button for more than 4 seconds to turn off the server.

v If the server is connected to an Advanced System Management interconnect

network, the server can be turned off using the Remote Supervisor Adapter user interface.

Notes:

1. You might need to press and hold the power-control button for more than 4 seconds to cause an immediate shutdown of the server. You can use this feature if the operating system stops functioning.

2. If you disconnect the server from the power source, wait approximately 15 seconds for the server to stop running before you open the cover. Watch for the power-on LED on the front of the server to stop flashing.

3. When you press the power-control button on any server in a scalable partition, all servers in the scalable partition will be turned off. If the servers do not turn off when the power-control button is pressed, see “Error symptoms” on page

196.

10 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Chapter 2. Configuring the server

The following configuration programs and capabilities come with your server:

v Extensible Firmware Interface (EFI) Firmware Boot Manager

Use the EFI Firmware Boot Manager to select a startup operating system, configure a variety of startup options, and access utility programs. See “Using the EFI Firmware Boot Manager” on page 12.

v Configuration/Setup Utility program

The Configuration/Setup Utility program is an EFI utility that comes with your server. Use it to enable memory mirroring, configure scalable partitions, set the date and time, and set passwords. For more information about using this utility program, see “Using the Configuration/Setup Utility program” on page 12.

Note: In a multi-node configuration, some options or settings are defined through

the primary server, and others must be defined on the individual (secondary) servers. Make sure that options and settings on the secondary servers are correct before creating a scalable partition.

v RAID configuration programs

™

– ServeRAID

The ServeRAID programs come with your server. If you are using the integrated SCSI controller with RAID capabilities as a RAID controller, you must use the ServeRAID Manager program to define and configure your disk-array subsystem before you install your operating system. See “Using the RAID configuration programs” on page 16 for more information.

Manager

Note: If your server model comes with an operating system installed, see the

software documentation that comes with your server for configuration information.

– LSI Logic Configuration Utility program

Use the LSI Logic Configuration Utility program to configure the integrated SCSI controller with RAID capabilities and the devices that are attached to it. For information about using this utility program, see “Using the LSI Logic Configuration Utility program” on page 16.

v Remote Supervisor Adapter configuration

For information about setting up and cabling the Remote Supervisor Adapter for use in an Advanced System Management (ASM) network, see “Setting up the Remote Supervisor Adapter” on page 20.

v Ethernet controller configuration

For information about configuring the integrated Ethernet controller, see “Configuring the Gigabit Ethernet controller” on page 33.

v Scalable-partition configuration

For information about creating and removing scalable partitions, see “Configuring scalable partitions” on page 34.

Using the EFI Firmware Boot Manager

Use the EFI Firmware Boot Manager to select an operating system to start to, configure a variety of startup options, and access utility programs. The following choices are available from the EFI Firmware Boot Manager:

v Boot Option Maintenance

Select this choice and specify a variety of startup options. For example, define a startup option to be used for the next startup operation only.

v Diagnostics

Select this choice to access the system diagnostic programs.

v EFI Shell

Select this choice to access the EFI Shell.

v Configuration/Setup

Select this choice to access the Configuration/Setup Utility program.

v Driver Setup

Select this choice to configure device drivers. For example, access the LSI Logic Configuration Utility program.

v Flash

Select this choice to perform a flash update of the SAL/EFI firmware or the diagnostic programs.

Complete the following steps to access the EFI Firmware Boot Manager:

1. Turn on the server.

2. Follow the instructions on the screen.

Using the Configuration/Setup Utility program

Use the Configuration/Setup Utility program to:

v Enable memory mirroring v Set the date and time v Configure scalable partitions v View configuration information v Set and change passwords and Remote Control Security settings v Set and change settings for advanced hardware features v View and clear error logs

following sections provide instructions for starting the Configuration/Setup Utility

The program and descriptions of the menu choices that are available.

Starting the Configuration/Setup Utility program

Complete the following steps to start the Configuration/Setup Utility program:

1. Turn on the server.

Note: In a multi-node configuration, some options or settings are defined

12 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

through the primary server, and others must be defined on the individual (secondary) servers. Make sure that options and settings on the secondary servers are correct before creating a scalable partition.

2. From the EFI Firmware Boot Manager, select the Configuration/Setup Utility program.

3. Follow the instructions on the screen.

Configuration/Setup Utility menu choices

The following choices are on the Configuration/Setup Utility main menu. Depending on the version of the system abstraction layer/extensible firmware interface (SAL/EFI) code in your server, some menu choices might differ slightly from these descriptions.

v System Summary

Select this choice to display configuration information. This includes the type and speed of the microprocessor and the amount of memory that is installed.

v System Information

– System Product Data

Select this choice to view system information, such as the machine type and model, the server serial number, and the revision level, date, and build level of the SAL/EFI code, diagnostic code, and ASM adapter code.

– System Card Data

Select this choice to view identifying information about the PCI-X board, processor board, memory board, power supplies, hard disk drive backplane, and power backplane.

Date and Time

Select this choice to set the system date and time and to change the system time that is sent to the Remote Supervisor Adapter when the server is started.

The system time is in a 24-hour format (hour:minute:second). All fields are required.

v System Security

Select this choice to set or change the power-on or administrator password. See “Passwords” on page 15 for more information.

Note: In a multi-node configuration, security settings are defined through the

primary server. If you bypass the multi-node configuration during startup or start the servers in a stand-alone configuration, you must define the security setting on each individual server.

The Remote Control Security Settings menu is in System Security. Use this menu to set the failed login threshold and the automatic lockout delay. You can also use this menu to save, change, or delete a remote-control password.

v Advanced Setup

Select this choice to change values for advanced hardware features, such as memory configuration, cache control, PCI configuration, system management settings, scalability port configuration, and service processor settings.

– Memory Configuration

Select this choice to manually enable a bank of four DIMMs used for memory mirroring and to enable memory mirroring.

If a memory error is detected during POST or memory configuration, the server can automatically disable the failing DIMM bank and continue operating with reduced memory capacity. After the problem is corrected, you must manually enable the DIMM bank. Use the arrow keys to highlight the bank that you want to enable. Press Enter to view detailed information about your selection; then, use the arrow keys to select Enable.

Chapter 2. Configuring the server 13

– System Cache Control

Select this choice to enable or disable the Xcel4 cache.

– PCI Slot Information

Select this choice to configure and view information about the PCI-X slots and devices in your server and those located in the remote expansion enclosure, if one is attached.

– System Management Settings

Select this choice to set the server to restart automatically after a nonmaskable interrupt (NMI) occurs. You can also enable the system to assign the memory mapped I/O (MMIO) above 4 GB.

– Scalable Partition Settings

Select this choice to view a summary of current scalable partition settings and to configure or delete partition settings.

Notes:

1. Partition settings are called partition descriptors in some IBM documentation.

2. See “Configuring scalable partitions” on page 34 for more information about creating, deleting, and configuring scalable partitions.

Service Processor Information

–

Select this choice to view or change the service processor settings. For example, you can view or change the IP address or gateway address.

System Event and Error Log

Select this choice to view or clear the System Error Log and enable or disable debug options. Use the debug options to define the severity level of messages viewable during POST.

– View System Error Log

Select this choice to view the System Error Log. The System Error Log contains all the system error and warning messages that the system has generated. You can use the arrow keys to move between pages in the System Error Log.

– Clear System Error Log

Select this choice to clear the System Error Log.

Save Settings

Select this choice to save the changes you have made in the settings (except PCI-X Slot Information changes, Scalable Partition Settings changes, the date and time, and password settings).

v Save Settings and Reboot

Select this choice to save the changes you have made in the settings (except PCI-X Slot Information changes, Scalable Partition Settings changes, the date and time, and password settings) and restart the server.

v Restore Settings

Select this choice to cancel the changes you have made in the settings (except PCI-X Slot Information changes, the date and time, and password settings) and restore the previous settings.

v Load Default Settings

Select this choice to cancel the changes you have made in the settings and restore the factory settings (except PCI-X Slot Information changes, the date and time, and password settings).

14 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Passwords

v Exit Setup

Select this choice to exit from the Configuration/Setup Utility program, if you have not saved the changes you have made in the settings (except PCI-X Slot Information changes, the date and time, and password settings). Yo u are asked whether you want to save the changes or exit without saving them.

After you select this choice, you can set a power-on password and an administrator password.

Note: In a multi-node configuration, security settings are defined through the

primary server. If you bypass the multi-node configuration during startup or start the servers in a stand-alone configuration, you must define the security setting on each individual server.

Power-on password

You can use any combination of up to seven characters (A–Z, a–z, and 0–9) for your power-on password. Keep a record of your password in a secure place. When a power-on password is set, POST cannot be completed until you type the password. If you forget the power-on password, you can regain access to the server in either of the following ways:

v Remove the battery and then reinstall it (see ″Replacing the battery″ in the

Option Installation Guide on the IBM xSeries Documentation CD for more

information).

Attention: Before changing any switch settings or moving any jumpers, turn off

the server and peripheral devices, and disconnect all power cords and external cables.

v Move the jumper on J20 to positions 2 and 3; then, restart the server. This

removes the power-on password. Move the jumper on J20 back to positions 1 and 2, restart the server, and start the Configuration/Setup Utility program to set the power-on password. See “Clearing a power-on password” on page 73 for the location of the jumper.

Administrator password

Select this choice to set an administrator password. The administrator password provides access to all choices on the Configuration/Setup Utility main menu. Yo u can set, change, or delete both the administrator and power-on passwords and allow a power-on password to be changed by the user. Yo u can use any combination of up to seven characters (A–Z, a–z, and 0–9) for your power-on password. Keep a record of your password in a secure place.

Attention: If you set an administrator password and then forget it, there is no way

to change, override, or remove it. Yo u must replace a system board.

Chapter 2. Configuring the server 15

Using the RAID configuration programs

Use the LSI Logic Configuration Utility program and ServeRAID Manager to configure and manage redundant array of independent disks (RAID) arrays. Be sure to use these programs as described in this book.

v Use the LSI Logic Configuration Utility program to:

– Perform a low-level format on a SCSI hard disk drive – View or change SCSI IDs for attached devices – Set SCSI protocol parameters on SCSI hard disk drives

Use ServeRAID Manager to:

– Configure arrays – View your RAID configuration and associated devices – Monitor operation of your RAID controllers

Consider

the following information when using the LSI Logic Configuration Utility

program and ServeRAID Manager to configure and manage arrays:

v The integrated SCSI controller with RAID capabilities in your server supports only

RAID level 1.

v You must configure your SCSI controller with RAID capabilities before you install

your operating system to use RAID level 1.

v If you install a different type of RAID adapter in your server, follow the

configuration instructions in the documentation that comes with the adapter to view or change SCSI settings for attached devices.

v The IBM ServeRAID-6M Controller RAMDrive Support CD includes code you

must install if you have installed a ServeRAID-6M controller and you plan to install Microsoft

Windows

Server 2003, Enterprise Edition (64-bit) on hard disk drives controlled by the ServeRAID-6M controller. Install the code after you have configured your RAID arrays. See the README file on the IBM ServeRAID-6M

Controller RAMDrive Support CD for instructions.

Using the LSI Logic Configuration Utility program

Use the LSI Logic Configuration Utility program to:

v Perform a low-level format of a SCSI hard disk drive v Set a SCSI device scan order v View or change SCSI IDs for attached devices v Create a mirrored pair of SCSI hard disk drives with or without a hot-spare drive v Set SCSI protocol parameters on SCSI hard disk drives

integrated SCSI controller with RAID capabilities supports redundant array of

The independent disks (RAID). You can use the LSI Logic Configuration Utility program to configure RAID level 1 for a single pair of attached devices. If you install a different type of RAID adapter, follow the configuration instructions in the documentation that comes with the adapter to view or change SCSI settings for attached devices.

The following sections provide instructions for starting the LSI Logic Configuration Utility program and performing selected functions.

16 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Starting the LSI Logic Configuration Utility program

Complete the following steps to start the LSI Logic Configuration Utility program:

1. Turn on the server.

2. From the EFI Firmware Boot Manager, select Driver setup.

3. From the device driver menu, select the LSI Logic Ultra320 SCSI device driver.

you have finished changing settings, press Esc to exit from the program;

When select Save to save the settings that you have changed.

Formatting a SCSI hard disk drive

Low-level formatting removes all data from the hard disk. If there is data on the disk that you want to save, back up the hard disk before performing this procedure.

Note: Before you format a SCSI hard disk, make sure that the disk is not part of a

mirrored pair. From the list of adapters, select the controller (channel) for the drive that you want to format. Select Mirroring Properties and make sure that the mirroring value for the drive is None.

Complete the following steps to format a drive:

1. From the list of adapters, select the controller (channel) for the drive that you

want to format.

2. Select Device Properties.

3. Use the arrow keys (— and –) to highlight the drive that you want to format.

4. Use the arrow keys (“ and ”) or the End key to scroll to the right.

5. Select Format; then, press Enter to start the low-level formatting operation.

Creating a mirrored pair of SCSI hard disk drives

Complete the following steps to create a mirrored pair of SCSI hard disk drives:

1. From the list of adapters, select the controller (channel) for the drives that you

want to mirror.

2. Select Mirroring Properties.

3. Use the arrow keys to highlight the first drive in the pair; then, press the Minus

key to change the mirroring value to Primary.

4. Use the arrow keys to highlight the second drive in the pair; then, press the

Minus key to change the mirroring value to Secondary.

Using ServeRAID Manager

Use ServeRAID Manager, which is on the IBM ServeRAID Support CD, to:

v Configure a redundant array of independent disks (RAID) v View your RAID configuration and associated devices v Monitor the operation of your RAID controllers

perform some tasks, you can run ServeRAID Manager as an installed program.

To However, to configure the integrated SCSI controller with RAID capabilities and perform an initial RAID configuration on your server, you must run ServeRAID Manager in Startable CD mode, as described in the instructions in this section. If you install a different type of RAID adapter in your server, use the configuration method described in the instructions that come with that adapter to view or change SCSI settings for attached devices.

Chapter 2. Configuring the server 17

See the ServeRAID documentation on the IBM ServeRAID Support CD for additional information about RAID technology and instructions for using ServeRAID Manager to configure your integrated SCSI controller with RAID capabilities. Additional information about ServeRAID Manager is also available from the Help menu. For information about a specific object in the ServeRAID Manager tree, select the object and click Actions ” Hints and tips.

Configuring the controller

By running ServeRAID Manager in Startable CD mode, you can configure the controller before you install your operating system. The information in this section assumes that you are running ServeRAID Manager in Startable CD mode.

Complete the following steps to run ServeRAID Manager in Startable CD mode:

1. Make sure that the IBM ServeRAID Support CD is inserted in the drive.

2. Turn on the server.

3. Select EFI Shell from the EFI Firmware Boot Manager.

ServeRAID Manager detects an unconfigured controller and ready drives, the

If Configuration wizard starts, and a window similar to that shown in the following illustration opens.

In the Configuration wizard, you can select express configuration or custom configuration. Express configuration automatically configures the controller by grouping the first two physical drives in the ServeRAID Manager tree into an array and creating a RAID level 1 logical drive. If you select custom configuration, you can select the two physical drives that you want to group into an array.

18 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Using express configuration: Complete the following steps to use express

configuration:

1. In the ServeRAID Manager tree, click the controller.

2. Click Express configuration.

3. Click Next. The “Configuration summary” window opens.

4. Review the information in the “Configuration summary” window. To change the

configuration, click Modify arrays.

5. Click Apply; then, click Yes when asked if you want to apply the new

configuration. The configuration is saved in the controller and in the physical drives.

6. Exit from ServeRAID Manager and remove the CD from the CD-ROM drive.

7. If you have installed a ServeRAID-6M controller and you plan to install Microsoft

Windows Server 2003, Enterprise Edition (64-bit) on hard disk drives controlled by the ServeRAID-6M controller, insert the IBM ServeRAID-6M Controller

RAMDrive Support CD and restart the server. See the README file on the IBM ServeRAID-6M Controller RAMDrive Support CD for instructions. Otherwise,

restart the server.

custom configuration: Complete the following steps to use custom

Using

configuration:

1. In the ServeRAID Manager tree, click the controller.

2. Click Custom configuration.

3. Click Next. The “Create arrays” window opens.

4. From the list of ready drives, select the two drives that you want to group into the array.

5. Click

6. Click Next. The “Configuration summary” window opens.

7. Review the information in the “Configuration summary” window. To change the

(Add selected drives) to add the drives to the array.

configuration, click Back.

8. Click Apply; then, click Yes when asked if you want to apply the new configuration. The configuration is saved in the controller and in the physical drives.

9. Exit from ServeRAID Manager and remove the CD from the CD-ROM drive.

10. If you have installed a ServeRAID-6M controller and you plan to install Microsoft Windows Server 2003, Enterprise Edition (64-bit) on hard disk drives controlled by the ServeRAID-6M controller, insert the IBM ServeRAID-6M

Controller RAMDrive Support CD and restart the server. See the README file

on the IBM ServeRAID-6M Controller RAMDrive Support CD for instructions. Otherwise, restart the server.

Viewing the configuration

You can use ServeRAID Manager to view information about RAID controllers and the RAID subsystem (such as arrays, logical drives, hot-spare drives, and physical drives). When you click an object in the ServeRAID Manager tree, information about that object appears in the right pane. To display a list of available actions for an object, click the object and click Actions.

Chapter 2. Configuring the server 19

Setting up the Remote Supervisor Adapter

This section describes the Remote Supervisor Adapter features and its prerequisites. It also explains how to cable and configure the adapter for use on an Advanced System Management (ASM) network so that you can manage the server from a remote location. For more detailed information, see the Remote Supervisor

Adapter User’s Guide on the IBM xSeries Documentation CD.

Attention: After you install your operating systems and fully configure your server,

be sure to make a backup copy of the nonvolatile EFI variables stored in NVRAM on the Remote Supervisor Adapter. In the unlikely event that you need to remove or replace the Remote Supervisor Adapter or clear NVRAM, you can use the backup copy to restore the variables. See “Backing up and restoring the nonvolatile variables” in the Option Installation Guide on the IBM xSeries Documentation CD for more information.

Remote Supervisor Adapter features

The Remote Supervisor Adapter has the following features:

v Continuous health monitoring and control v Advanced Predictive Failure Analysis v Configurable notification and alerts v Event logs that are time stamped, saved in nonvolatile memory, and can be

attached to e-mail alerts

v Remote graphics console redirection v LAN, serial, and Advanced System Management (ASM) interconnect remote

access

v Point-to-point protocol (PPP) support v Simple Network Management Protocol (SNMP) v Domain Name System (DNS) and Dynamic Host Configuration Protocol (DHCP)

support

v Remote power control

v Microsoft Windows v Remote firmware update and access to critical server settings v Optional, independent power, which enables around-the-clock access to the

server, even if the server is turned off

Server 2003, Enterprise Edition (64-bit) blue-screen capture

(PFA)

Setup requirements

Before you set up the Remote Supervisor Adapter, you must download the EFI Remote Supervisor Utility program from http://www.ibm.com/pc/support/ and create a CD.

Complete the following tasks before you set up the Remote Supervisor Adapter:

v Install the operating system on the server, using the documentation that comes

with the operating system.

v Make sure that the remote alert recipients are IBM Director-enabled servers with

UM Server Extensions, if you are configuring remote alert recipients for Director over LAN or Director over modem.

20 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

v The Remote Supervisor Adapter supports the following Web browsers for remote

access. The Web browser that you use must be Java™-enabled and must support JavaScript™.

– Microsoft Internet Explorer version 4.0 (with Service Pack 1), or later – Netscape Navigator version 4.72, or later (version 6.x is not supported)

Notes:

1. Java plug-in version 1.4 or later is required.

2. The Remote Supervisor Adapter Web Interface does not support the

double-byte character set (DBCS) languages.

Cabling and configuring the Remote Supervisor Adapter

Complete the following tasks to cable and configure the Remote Supervisor Adapter.

Note: After you initially configure the adapter, use the Web-based interface to

create a backup copy of the configuration. If you need to replace the adapter in the future, you can use the backup copy to restore the configuration and resume normal operation more quickly. See the Remote Supervisor Adapter

User’s Guide on the IBM xSeries Documentation CD for details.

Task 1.

Connect the Ethernet and serial port cables. See “Cabling the Ethernet LAN port and serial port.”

Task 2.

Perform the initial configuration to enable remote access to the Remote Supervisor Adapter. See “Enabling remote access to the adapter” on page

23. After you complete this task, you can configure the Ethernet and serial (COM) ports and set up the point-to-point protocol.

Task 3.

Configure the remote-control password to enable the ASM Web interface remote-control features. See “Configuring the remote-control password” on page 28.

Task 4.

Install the ASM device drivers. See “Installing Advanced System Management device drivers” on page 28.

service, assistance, or additional information, see Appendix A, “Getting help and

For technical assistance,” on page 213.

Cabling the Ethernet LAN port and serial port

You can manage the server remotely through the Remote Supervisor Adapter using one of the user interfaces and one of the connection methods that are described in Table 1 on page 22. Perform the cabling procedure for the interface method you want to use.

If you plan to set up an ASM interconnect network, before you begin cabling the server, see “Using the ASM interconnect network” on page 29 for instructions for cabling the ASM interconnect port and setting up the network. You might want to review the information in “ASM interconnect network configuration examples” on page 32 before you connect the cables. Then, return to these instructions to start the cabling procedures.

Chapter 2. Configuring the server 21

Table 1. Cabling tasks to enable remote access to the Remote Supervisor Adapter

User interface to Remote Supervisor Adapter

ASM Web interface using HTTP

Connection to Remote Supervisor Adapter

For the cabling procedure, see

LAN using the Ethernet port “Cabling the Ethernet LAN port”

on page 22

Text-based user interface using Telnet

Text-based user interface using a modem or a null

Serial (COM) port “Cabling the serial (COM) port”

on page 23

modem ASM Web interface using

point-to-point protocol (PPP)

Text-based user interface using the Telnet protocol over PPP

Cabling the Ethernet LAN port: Complete the following steps to attach the

Ethernet cables.

Attention: To avoid damage to the Ethernet connector on the Remote Supervisor

Adapter, do not connect the ASM Interconnect module to the Ethernet connector.

1. Connect one end of a Category 3 or Category 5 Ethernet cable to the Ethernet connector on the Remote Supervisor Adapter. Connect the other end of the Ethernet cable to the network.

2. Check the Ethernet LEDs to ensure that the network connection is working. The following illustration shows the locations of the LEDs.

External power supply connector

Power LED (green)

ASM Interconnect port

Ethernet activity

LED (green)

Error LED

(amber)

Serial

connector

(COM)

(RJ-14)

Ethernet link

LED (green)

Ethernet connector (RJ-45)

Lithium battery

Ethernet activity LED

When the green Ethernet activity LED flashes, it indicates that there is Ethernet activity.

Ethernet link LED

you want to use the serial port connection, continue with “Cabling the serial

If (COM) port” on page 23; otherwise, go to “Configuring the adapter” on page 23.

22 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

When the green Ethernet link LED is lit, it indicates that the Ethernet cable is connected properly.

Cabling the serial (COM) port: To cable the serial (COM) port, connect a modem

or null modem cable to the serial connector on the Remote Supervisor Adapter.

Continue with “Configuring the adapter.”

Configuring the adapter

This section describes how to enable remote access to the Remote Supervisor Adapter and install ASM device drivers. These procedures assume that you have a keyboard and pointing device attached to the server.

Enabling remote access to the adapter: The Remote Supervisor Adapter must

be configured to enable remote access through the Ethernet connector or the serial connector. Perform the configuration procedure for the interface method you want to use.

Note: For detailed information about using the ASM Web interface and the

text-based interface, see the Remote Supervisor Adapter User’s Guide on the IBM xSeries Documentation CD.

Table 2. Configuration tasks to enable remote access to the Remote Supervisor Adapter

User interface to Remote Supervisor Adapter

ASM Web interface using HTTP

Text-based user interface

Connection to Remote Supervisor Adapter

For the configuration procedure, see

LAN using the Ethernet port “Configuring the Ethernet

settings for Web-based remote

access” using Telnet Text-based user interface

using a modem or a null modem

ASM Web interface using point-to-point protocol

Serial (COM) port “Configuring the serial port for

text-based remote access” on

page 25 and “Setting up

point-to-point protocol” on page

26 (PPP) Text-based user interface

using the Telnet protocol over PPP

Configuring the Ethernet settings for Web-based remote access: If you have

an accessible, active, and configured Dynamic Host Configuration Protocol (DHCP) server on the network, the host name, IP address, gateway address, subnet mask, and DNS server IP address are set automatically. The default value has no effect on whether you have to do any other configuration. If you need to configure the serial port, go to “Configuring the serial port for text-based remote access” on page 25; otherwise, go to “Configuring the remote-control password” on page 28.

If you do not have a DHCP server on the network, complete the following steps to configure the Ethernet settings:

1. Insert the CD containing the EFI Remote Supervisor Utility program into the drive; then, turn on the server.

2. Select EFI Shell from the EFI Firmware Boot Manager.

Note: If EFI shell is not a choice in the list, the server has a customized

3. Change to the file system for the formatted media and the directory where the program is located.

startup configuration. Contact your system administrator for instructions.

Chapter 2. Configuring the server 23

4. Type the following EFI command:

flash2

5. Use the Up Arrow and Down Arrow keys (— and –) to select Configuration Settings; then, press Enter. The Configuration Settings window opens.

6. Use the arrow keys to select Ethernet Settings; then, press Enter. The Ethernet Settings window opens, as shown in the following illustration.

Note: The settings in the window are only examples; your settings might be

different.

7. Use the arrow keys to navigate to each field. Your system administrator can provide the information for the following fields:

Network Interface

The default setting is Enabled; verify that it is still set to Enabled.

IP Address

Type the IP address of the Remote Supervisor Adapter.

Subnet Mask

Type the subnet mask used by the Remote Supervisor Adapter. The default value is 255.255.255.0.

Gateway

Type the IP address of the gateway.

Host Name

Type the host name of the Remote Supervisor Adapter. The default host name is ASMA burned-in MAC address.

For detailed information about the Ethernet settings, see the Remote

Supervisor Adapter User’s Guide on the IBM xSeries Documentation CD.

8. Change the DHCP Setting field to Disabled. The default setting is Enabled.

9. Press F6 to apply the change.

10. Press Esc. After the Warning window opens, press Enter to restart the Remote Supervisor Adapter.

11. Press Esc to return to the Configuration Settings window. If you need to

configure the serial port, go to “Configuring the serial port for text-based remote access” on page 25..

12. Press Esc to return to the main window.

24 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

13. Use the arrow keys to select Exit Utility from the menu or press Esc to exit

from the program.

14. Remove the CD from the server.

you also want to configure the serial port, continue with “Configuring the serial

If port for text-based remote access.” Otherwise, go to “Installing Advanced System Management device drivers” on page 28.

Configuring the serial port for text-based remote access: Complete the

following steps to configure the Remote Supervisor Adapter serial port for access using a modem or null modem. If you completed the procedure for configuring the Ethernet port and the Configuration Settings window is open, go to step 6..

1. Insert the CD containing the EFI Remote Supervisor Utility program into the drive; then, turn on the server.

2. Select EFI Shell from the EFI Firmware Boot Manager.

Note: If EFI shell is not a choice in the list, the server has a customized

startup configuration. Contact your system administrator for instructions.

3. Change to the file system for the formatted media and the directory where the program is located.

4. Type the following EFI command:

flash2

5. Use the Up Arrow and Down Arrow keys (— and –) to select Configuration Settings; then, press Enter.

The Configuration Settings window opens.

6. Use the arrow keys to select Modem Settings; then, press Enter. The Modem Settings window opens, as shown in the following illustration.

Note: The settings in the window are only examples; your settings might be

different.

Chapter 2. Configuring the server 25

7. Verify the following serial port values:

Baud Rate

The default is 57600. Make sure that the baud rate matches the baud rate of the device you are connecting to the serial port on the Remote Supervisor Adapter.

Dedicated to ASM

The default is Disabled. If you are using point-to-point protocol (PPP), set this field to Enabled. If the value in this field is Enabled when the server is restarted, the serial port remains dedicated to system management and is not returned to the operating system.

Note: To use this serial port, you must first install the ASM device

drivers as described in “Installing Advanced System Management device drivers” on page 28.

If the serial port is shared with the operating system, it is dedicated to the Remote Supervisor Adapter only while the server is turned off or during POST. The port is returned to the operating system after POST is completed. Yo u can view information about the port using the operating system or any application. The Remote Supervisor Adapter takes over the port from the operating system only when information about a critical event is received. The Remote Supervisor Adapter dials out and transmits an alert and keeps the port dedicated until the server is restarted. The port is no longer available to the operating system or applications.

Parity The default is None. Stop Bits

The default is 1.

The data bits value is preset to 8 and cannot be changed.

Note:

For detailed information about the serial port and modem settings, see the

Remote Supervisor Adapter User’s Guide on the IBM xSeries Documentation

CD.

8. If you made changes to the serial port settings, press F6 to apply the changes.

9. Press Esc to return to the Configuration Settings window. If you need to set up point-to-point protocol, go to “Setting up point-to-point protocol.”

10. Press Esc to return to the main window.

11. Use the arrow keys to select Exit Utility from the menu, or press Esc to exit

from the program.

12. Remove the CD from the drive.

Continue

with “Setting up point-to-point protocol.”

Setting up point-to-point protocol: The Remote Supervisor Adapter serial port

supports point-to-point protocol (PPP). PPP enables TCP/IP communication over the serial port, which enables Web-based management and Telnet sessions over a modem. To set up PPP, complete the following steps. If you completed the procedure for configuring the serial port and the Configuration Settings window is open, go to step 6 on page 27.

1. Insert the CD containing the EFI Remote Supervisor Utility program into the drive; then, turn on the server.

26 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

2. Select EFI Shell from the EFI Firmware Boot Manager.

Note: If EFI shell is not a choice in the list, the server has a customized

startup configuration. Contact your system administrator for instructions.

3. Change to the file system for the formatted media and the directory where the program is located.

4. Type the following EFI command:

flash2

5. Use the Up Arrow and Down Arrow keys (— and –) to select Configuration Settings; then, press Enter.

The Configuration Settings window opens.

6. Use the arrow keys to select PPP Settings; then, press Enter. The PPP Settings window opens, as shown in the following illustration.

Note: The settings in the window are only examples; your settings might be

different.

7. Use the arrow keys to navigate to each field. Verify the values in the following fields:

Network Interface

The default is Disabled. Change this field to Enabled.

IP Address

The default value is 192.96.1.1. Yo u can use the default value or another value, but the server must be able to establish a connection to that address. The default IP address (local and remote) is easily reconfigurable.

Subnet Mask

The default value is 255.255.255.255.

Line Type

The default value is PPP.

Remote IP Address

The default value is 192.96.1.2.

Chapter 2. Configuring the server 27

Authentication Protocol

The default is CHAP then PAP. Make sure that the value in this field matches your client settings.

For detailed information about the PPP settings, see the information about configuring PPP access over a serial port in the Remote Supervisor Adapter

User’s Guide on the IBM xSeries Documentation CD.

8. Press F6 to apply the changes.

9. Press Esc. After the Warning window opens, press Enter to restart the Remote Supervisor Adapter.

10. Press Esc to return to the Configuration Settings window. If you need to configure the serial port, go to “Configuring the serial port for text-based remote access” on page 25.

11. Press Esc to return to the main window.

12. Use the arrow keys to select Exit Utility from the menu or press Esc to exit from the program.

13. Remove the CD from the drive.

Continue

with “Installing Advanced System Management device drivers.”

Installing Advanced System Management device drivers: You must install the

ASM device drivers for the server. The device drivers enable communication between the Remote Supervisor Adapter and the server in which it is installed. You can obtain the most current device drivers from the World Wide Web at http://www.ibm.com/pc/support/.

Note: If you are installing device drivers manually, note the following requirements:

v You must install the operating system on the server before you install the

ASM device drivers. For information about installing the operating system, see the documentation that comes with the operating system.

v Before installing the ASM device drivers for the Remote Supervisor

Adapter, stop any system-management application.

you install the ASM device drivers, go to “Configuring the remote-control

After password” to set the remote-control password.

Configuring the remote-control password: If you want to use the remote-control

features of the Remote Supervisor Adapter ASM Web interface, you must configure the remote-control password using the Configuration/Setup Utility program.

To set up a remote-control password, complete the following steps:

1. Start the server.

2. From the EFI Firmware Boot Manager, select the Configuration/Setup Utility

program.

3. Use the Up Arrow and Down Arrow keys (— and –) to select System Security;

then, press Enter. The System Security window opens.

4. Select Remote Control Security Settings; then, press Enter. The Remote

Control Security Settings window opens.

5. Enter the remote-control password that you will use each time you log in to the

remote-control features of the Remote Supervisor Adapter ASM Web Interface.

6. Select Save New Remote Control Password; then, press Enter.

7. In the System Security window, press Esc.

28 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

8. Select Save Settings; then, press Enter.

9. Confirm your selection; then, exit the Configuration/Setup Utility.

Continue with “Completing the configuration.”

Completing the configuration: To complete the configuration of the Remote

Supervisor Adapter, see the Remote Supervisor Adapter User’s Guide on the IBM xSeries Documentation CD. Completing the configuration consists of the following

tasks:

v Defining the login IDs and passwords v Selecting the events that will receive alert notification v Monitoring remote server status using the ASM Web interface or a text-based

user interface

v Controlling the server remotely

you want to set up an ASM interconnect network and have not already done so,

If continue with “Using the ASM interconnect network.” If you do not want to set up an ASM interconnect network, Remote Supervisor Adapter configuration is now complete. To start managing the server remotely, see the Remote Supervisor

Adapter User’s Guide on the IBM xSeries Documentation CD.

Using the ASM interconnect network

This section explains how to configure and connect the server to function within an ASM interconnect network.

The ASM interconnect network can include as many as 12 individual ASM connections in a single bus. These connections can include Remote Supervisor Adapters, ASM processors, and ASM PCI Adapters. When the clients and servers are connected, they use the ASM interconnect network to share ASM resources, information, and alerts among multiple servers, without requiring additional communications hardware or network interface adapters.

An ASM interconnect network provides two levels of functionality. First, the ASM interconnect network enables you to configure settings and to control the servers where other Remote Supervisor Adapters, ASM processors, and ASM PCI Adapters on the network are. Second, the ASM interconnect network enables other interconnect network devices to use the resources (Ethernet or modem) of other Remote Supervisor Adapters, ASM processors, and ASM PCI Adapters in the ASM interconnect network for sending alerts. This interconnect network is used when Remote Supervisor Adapters, ASM processors, or ASM PCI Adapters cannot send an alert and must forward the information to another one of these devices to send the alert.

Planning and cabling the interconnect network

To support the most recent ASM features, a Remote Supervisor Adapter must be the main gateway interconnect to the ASM interconnect bus if the bus also includes servers with ASM PCI adapters or ASM processors. The Remote Supervisor Adapter forwards the ASM information generated by the servers attached to the ASM interconnect bus to other servers on the Ethernet network. The connected ASM processors and ASM PCI Adapters are managed through the new user interface and Web browser access of the Remote Supervisor Adapter.

Chapter 2. Configuring the server 29

Note: To ensure the stability of the system, the most current level of firmware must

be installed on the Remote Supervisor Adapter that is the main interconnect gateway for the ASM interconnect network. The most current level of firmware is available from http://www.ibm.com/pc/support. For more information about updating firmware, see the Remote Supervisor Adapter

User’s Guide on the IBM xSeries Documentation CD.

You must connect an ASM Interconnect module to the Remote Supervisor Adapter and to each xSeries 455 server that you connect to the ASM interconnect network bus.

Attention: To avoid damage to the Ethernet connector on the Remote Supervisor

Adapter, do not connect the ASM Interconnect module to the Remote Supervisor Adapter Ethernet connector.

To connect the servers, note the following setup and configuration information:

v Make sure that the ASM interconnect network is set up as a bus topology. You

must connect the servers to the ASM interconnect network in a series, with terminated beginning and end points.

v Make sure that the total combined length of all Ethernet cables connecting the

server in the ASM interconnect network does not exceed 91 m (300 ft).

v Each Remote Supervisor Adapter, ASM PCI adapter, or ASM processor that is

connected to the ASM interconnect network bus counts as one connection. For example, if an ASM PCI adapter is installed in a server that has an ASM processor, the processor and the adapter connect to each other using one ASM interconnect connection, but the processor and the adapter count as two connections on the ASM interconnect network bus.

Forwarding alerts

Remote Supervisor Adapters, ASM PCI adapters, and ASM processors that are connected to an ASM interconnect network share resources and systems-management information. This section provides information about how alerts are forwarded in the ASM interconnect network.

During normal operation, each Remote Supervisor Adapter, ASM processor, or ASM PCI adapter on the ASM interconnect network communicates with the other processors and adapters on the network. Processors or adapters that have modems or Ethernet connections notify the other processors and adapters that these communications resources are available for use by other servers on the ASM interconnect network. These resources are then used as ASM interconnect network resources, enabling Remote Supervisor Adapters, ASM processors, or ASM PCI adapters on the ASM interconnect network to send alerts using a modem or the network, even if they do not have a modem or network connection physically attached.

When alerts are generated, they are forwarded to the Remote Supervisor Adapter, ASM processor, or ASM PCI adapter on the ASM interconnect network that has the communication resources to forward the alert. If no system on the ASM interconnect network meets the requirements, the alert is set for transmission if the connection type is configured or becomes available later.

If there are multiple modems or network connections in the ASM interconnect network, you cannot specify which system will receive an alert or which will use its modem or network connection to forward the alert. If an alert is forwarded to a Remote Supervisor Adapter, ASM processor, or ASM PCI adapter that is unable to

30 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

deliver the alert (for example, the modem it is configured to use has failed or the network cannot resolve the destination IP address), the processor or adapter attempts to forward the alert to another system on the ASM interconnect network that has the communication resources to forward the alert.

Alerts are typically sent only once (per connection type), but an alert is forwarded to another interconnect device if the resources are on other interconnect devices in the network. For example, on a three-ASM-processor network where ASM processor 1 generates a modem alert but does not have a modem and the other ASM processors have modems, the following scenario might occur:

If ASM processor 1 generates an alert and the modem is disconnected from ASM processor 2 within 45 seconds before ASM processor 1 generates the alert, ASM processor 1 forwards the alert to ASM processor 2, having previously determined that ASM processor 2 has an available modem. When ASM processor 2 receives the forwarded alert, it determines that a modem is attached to ASM processor 3 and forwards the alert. Therefore, depending upon the time frame (45 seconds) within which a resource (modem) fails, the alert might be forwarded multiple times until an interconnect device can send the alert.

Connecting the ASM Interconnect module to the xSeries 455 server

The ASM Interconnect module connects the Remote Supervisor Adapter to the ASM interconnect network. Yo u must purchase this module separately. To connect the ASM interconnect module to the Remote Supervisor Adapter, complete the following steps.

Attention: To avoid damage to the Ethernet connector, do not connect the ASM

interconnect module into the Remote Supervisor Adapter Ethernet connector.

1. Connect the ASM Interconnect module 1 to the Remote Supervisor Adapter ASM interconnect (peer-to-peer) connector 2 as shown in the following illustration. This connector is on the edge of the Remote Supervisor Adapter that is accessible from the rear of the server and is labeled “RS485”.

Chapter 2. Configuring the server 31

2. Connect one or two Category 3 or Category 5 Ethernet cables to the other end of the ASM Interconnect module.

Continue with “ASM interconnect network configuration examples.”

ASM interconnect network configuration examples

The illustrations in this section show sample ASM interconnect network configurations.

The following illustration shows an Ethernet cable connecting the remote administrator system to the Remote Supervisor Adapter that is installed in an xSeries 455 server. Server 1 uses the LAN connection to forward system-management data generated by the other xSeries 455 servers in the ASM interconnect network bus to the remote system-management administrator.

Remote system management administrator system

Ethernet

xSeries 455

server 3

xSeries 455

server 2

xSeries 455

server 1

RS-485 terminator plug

Note: The ASM Interconnect module is connected to the RS485 connector

on the back panel of the Remote Supervisor Adapter in each server.

ASM Interconnect modules

RS-485 terminator plug

32 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

The following illustration shows a modem connected to the serial port of the Remote Supervisor Adapter in the xSeries 455 server on the left, a modem connected to the serial port of the Remote Supervisor Adapter in the xSeries 455 server on the right, and a modem connected to the remote administrator system. Placing modems at opposite ends of the ASM interconnect network bus ensures that if an ASM interconnect connection in the bus fails, all of the servers on the ASM interconnect network have access to a modem to forward system-management data to the remote system-management administrator.

Remote system management administrator system

Modem

Note: A Remote Supervisor Adapter is required in each server.

Note: The ASM Interconnect module is connected to the RS485 port on the back panel of the Remote Supervisor Adapter in each server.

xSeries 455

server

Configuring the Gigabit Ethernet controller

The Ethernet controller is integrated on the system board. It provides an interface for connecting to a 10-Mbps, 100-Mbps, or 1-Gbps network and provides full-duplex (FDX) capability, which enables simultaneous transmission and reception of data on the network. If the Ethernet ports in your server support auto-negotiation, the controller detects the data-transfer rate (10BASE-T, 100BASE-TX, or 1000BASE-T) and duplex mode (full-duplex or half-duplex) of the network and automatically operates at that rate and mode.

xSeries 455

server

xSeries 455

server

ASM Interconnect modules

You do not need to set any jumpers or configure the controller. However, you must install a device driver to enable the operating system to address the controller. For device drivers and information about configuring the Ethernet controller, see the

Chapter 2. Configuring the server 33

Resource CD that comes with your server. For updated information about

configuring the controller, go to http://www.ibm.com/pc/support/.

The following illustration shows the Ethernet controller port assignments, connectors, and LEDs.

Ethernet LED (port 0)

Ethernet LED (port 1)

Configuring scalable partitions

This section provides information and instructions for creating and deleting scalable partitions through the Configuration/Setup Utility program.

Ethernet connector (port 1)

Ethernet connector (port 0)

Note: The Scalable Systems Manager program, when available, is an extension to

IBM Director that provides a graphical user interface for creating and managing scalable partitions. See the Scalable Systems Manager Installation

and Users Guide for information about how to use that program to configure

scalable partitions.

Before you create or delete scalable partitions, read the following information:

v The Remote Supervisor Adapters must be connected to a network through a

management console device. This connection is needed so that the Remote Supervisor Adapters can communicate and manage scalable partitions.

v PCI slot numbering starts with the primary node, including attached remote I/O

enclosures, and continues with the secondary nodes, in numeric order of the logical node IDs.

v To change the primary node, delete the scalable partition from the current

primary node; then, create a new scalable partition from the new primary node.

Creating a scalable partition

Complete the following steps to create a scalable partition:

1. If you have not already done so, connect the SMP Expansion, RXE Expansion, and RXE Management cables. See the Option Installation Guide on the IBM

xSeries Documentation CD for information about RXE cabling.

2. Start the Configuration/Setup Utility program.

3. From the main menu, select Advanced Setup.

4. Select Scalable Partition Settings.

5. Select Create Scalable Partition Settings.

34 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

6. Use one of the following procedures, depending on the configuration.

v Single-chassis configuration:

a. Select 1 x455 chassis as the scalable partition configuration. b. Type a scalable partition ID. c. If a remote I/O enclosure is attached, complete the following steps:

1) Select the number of PCI-X slots available to each RXE Expansion Port on the remote I/O enclosure.

2) Select the destination of Expansion Port A on the remote I/O enclosure.

3) Select the destination of Expansion Port B on the remote I/O enclosure.

v Two-chassis configuration:

a. Select 2 x455 chassis as the scalable partition configuration. b. Type a scalable partition ID. c. Type the ASM host name or IP address for the secondary node. d. If a remote I/O enclosure is attached, complete the following steps:

1) Select the number of PCI-X slots available to each RXE Expansion Port on the remote I/O enclosure.

2) Select the destination of Expansion Port A on the remote I/O enclosure.

3) Select the destination of Expansion Port B on the remote I/O enclosure.

Four-chassis configuration:

a. Select 4 x455 chassis as the scalable partition configuration. b. Type a scalable partition ID. c. Type the ASM host names or IP addresses for the secondary nodes. d. If a remote I/O enclosure is attached in the first RXE configuration,

complete the following steps:

1) Select the number of PCI-X slots available to each RXE Expansion Port on the remote I/O enclosure.

2) Select the destination of Expansion Port A on the remote I/O enclosure.

3) Select the destination of Expansion Port B on the remote I/O enclosure.

If a remote I/O enclosure is attached in the second RXE configuration,

complete the following steps:

1) Select the number of PCI-X slots available to each RXE Expansion Port on the remote I/O enclosure.

2) Select the destination of Expansion Port A on the remote I/O enclosure.

3) Select the destination of Expansion Port B on the remote I/O enclosure.

Select Write Scalable Partition Settings and follow the prompts to exit the

7. menu item.

8. Save the changes and exit the Configuration/Setup Utility program.

Note: See the software documentation that comes with your operating system

to install your operating system.

Chapter 2. Configuring the server 35

Deleting a scalable partition

Complete the following steps to delete the scalable partition:

1. Start the Configuration/Setup Utility on the primary server.

2. From the main menu, select Advanced Setup.

3. Select Scalable Partition Settings.

4. Select either Delete ALL Scalable Partition Settings if started up as a multinode partition or Delete Local Scalable Partition Settings if started up as a single node partition or in standalone mode.

Note: Do not select Write Scalable Partition Settings when you delete the

scalable partition.

5. Exit the Configuration/Setup Utility program.

6. Turn off the servers.

7. If necessary, remove the SMP Expansion cables and reconnect them according to your new configuration. See the Option Installation Guide on the IBM xSeries

Documentation CD for information.

8. Restart the servers.

36 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Chapter 3. Diagnostics

This section provides basic troubleshooting information to help you resolve some common problems that might occur with your server.

If you cannot locate and correct the problem using the information in this section, see Appendix A, “Getting help and technical assistance,” on page 213 for more information.

General checkout

The server diagnostic programs are stored in the upgradeable electronically erasable programmable read-only memory (EEPROM) on the I/O board and on the

Resource CD. These programs provide the primary methods of testing the major

components of the server.

If you cannot determine whether a problem is caused by the hardware or by the software, run the diagnostic programs to confirm that the hardware is working properly.

Note: A single problem might cause several error messages. When this occurs,

work to correct the cause of the first error message. After you correct the cause of the first error message, the other error messages usually will not occur the next time you run the test.

A failed server might be part of a shared hard disk drive cluster (two or more servers sharing one or more external storage devices). Before you run diagnostics, verify that the failing server is not part of a shared storage device cluster.

A server might be part of a cluster if:

v The server is identified as part of a cluster. v One or more external storage units are attached to the server and at least one of

the attached storage units is also attached to another server or unidentifiable source.

v One or more servers are located near the failing server.

If the failing server is suspected to be part of a shared hard disk drive cluster, run all diagnostic tests except those that test the storage unit (storage device residing in the storage unit) or the storage adapter attached to the storage unit.

Notes:

1. For servers that are part of a shared hard disk drive cluster, run one test at a time in looped mode. Do not run all tests in looped mode, because this could enable the hard disk drive diagnostic tests.

2. If multiple error codes are displayed, diagnose the first error code that is displayed.

3. If the server stops with a POST error, see “SAL/EFI messages” on page 163.

4. If the server stops and no error is displayed, see “Undetermined problems” on page 205.

5. For power supply problems, see “Power checkout” on page 74.

6. For safety information, see “Safety information” on page 215.

7. For intermittent problems, check the system-error log.

Follow the steps in this procedure to identify system problems.

001 IS THE SERVER PART OF A CLUSTER?

YES. Schedule maintenance for the system. Shut down all systems related

to the cluster.

NO. Go to step 002.

002 IF THE SERVER IS NOT PART OF A CLUSTER:

If the operating system is running, do the following:

1. Check the Light Path. Go to “Light Path Diagnostics feature” on page 40 for more information.

2. Check the service processor system-error logs. a. If the system-error log indicates a damaged field replaceable unit

(FRU), replace the FRU, and run the AMIDiag program to confirm that the problem has been solved.

b. If the system-error log does not indicate a damaged FRU, check the

Light Path.

If the operating system is not running, do the following:

1. Check the Light Path. Go to “Light Path Diagnostics feature” on page 40 for more information.

2. Check the service processor system-error logs. a. If the error log indicates a damaged field replaceable unit (FRU),

replace the FRU, and run the AMIDiag program to confirm that the problem has been solved.

b. If the error log does not indicate a damaged FRU, see

“Undetermined problems” on page 205

3. Turn off the server and all external devices.

4. Check all cables and power cords.

5. Set all display controls to the middle position.

6. Turn on all external devices.

7. Turn on the server.

8. Monitor the screen and the serial port for POST errors, and record any POST error messages that are displayed on the screen. If an error is displayed, look up the first error in the “SAL/EFI messages” on page

163.

9. When the EFI Boot Manager starts, select Diagnostic from the menu, and press Enter to start the AMIDiag program.

DID THE DIAGNOSTIC PROGRAM START?

003

NO. Find the failure symptom in “Error symptoms” on page 196. YES. Run the diagnostic programs. If necessary, see “Diagnostic programs,

error codes, and messages” on page 42. If you receive an error, see Chapter 6, “Symptom-to-FRU index,” on page

159.

If the diagnostic programs were completed successfully and you still suspect a problem, see “Undetermined problems” on page 205.

If the server does not turn on, see “Error symptoms” on page 196.

38 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Diagnostic tools overview

The following tools are available to help you identify and resolve hardware-related problems:

v POST error messages

The power-on self-test (POST) generates error messages to indicate the detection of a problem. See “POST error codes and messages” for more information.

v System-error logs

The system-error log contains all the error messages that were issued during POST. See “System-error logs” on page 40.

v Light Path Diagnostics feature

Use the Light Path Diagnostics feature to identify system errors quickly (see “Light Path Diagnostics feature” on page 40).

v Diagnostic display

If a problem is detected with system power on or during initialization, an error code might be present in the two-hex character diagnostic display on the midplane board. See “Diagnostic display error codes” on page 201 for more information.

v Diagnostic programs and error messages

The AMIDiag program is the primary method of testing the major components of the server. The AMIDiag program is stored in the EEPROM on the I/O board. Yo u can download the latest version of this program and copy it to a CD so that you can update the AMIDiag program. See “Starting the AMIDiag program” on page 42 for more information.

The diagnostic program for the Ethernet controller is on the Resource CD. For instructions about using this CD, see “Troubleshooting the Ethernet controller” on page 75.

v Product support page

The IBM Web site has up-to-date information about IBM xSeries products, services, and support at http://www.ibm.com/eserver/xseries/ on the World Wide Web.

You can find service information for your IBM products, including supported options, at http://www.ibm.com/pc/support/.

POST error codes and messages

When you turn on the server, it performs a series of tests to check the operation of server components and some of the options installed in the server. This series of tests is called the power-on self-test, or POST.

Notes:

1. This server does not produce beep codes.

2. Depending on system configuration, POST might run for several minutes before the video console is enabled. During this time, POST operation is indicated by the flashing blue locator LED on the front panel. Diagnostic display error codes track the startup progress until video is enabled.

POST finishes without detecting any problems, the EFI Boot Manager screen

If appears. If POST detects a problem, an error message will be sent to either the serial port or the display screen. See “SAL/EFI messages” on page 163 for more information.

Chapter 3. Diagnostics 39

System-error logs

The system-error log contains all messages issued during system initialization or normal system operation.

You can view the contents of the system-error log from the Configuration/Setup Utility program or from the service processor. To view error logs from the Configuration/Setup Utility program, start the Configuration/Setup Utility program; then, select Error Logs from the main menu. See “Starting the Configuration/Setup Utility program” on page 12 for more information.

You can also use the error-log viewer in the AMIDiag program. For information about viewing diagnostic program error logs from the AMIDiag program, see “Error-log viewer” on page 46.

Light Path Diagnostics feature

The Light Path Diagnostics panel is inside the Light Path Diagnostics drawer on the front right of the server. To access the light path diagnostics panel, press on the front of the panel.

The following illustration shows the location of the diagnostics panel. See “The diagnostics panel” on page 41 for information about identifying problems using the Light Path Diagnostic LEDs.

40 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

The system-error LED on the operator information panel is lit when certain system errors occur. If the system-error LED on the server is lit, one or more LEDs inside the server might be lit. Use the Light Path Diagnostics panel to identify the type of error that occurred, and see “Light Path LED errors” on page 159 to help determine the cause of the error and the action you should take.

To view the LEDs on the various main boards, look at the board indicated by the diagnostic panel.

To acknowledge a system error but not take immediate action, press the REMIND button, and place the Light Path Diagnostics feature in Remind mode. The system-error LED flashes in Remind mode. If a new failure occurs, the system-error LED is lit again.

The diagnostics panel

The diagnostics panel should be the first place you look for help with identifying problems. If a system error occurs, the system-error LED on the front of this panel is lit. Press the front of the panel to open the diagnostics panel, and look for any lit LEDs. These lit LEDs can help you identify the possible cause of the error. Make a note of any LEDs that are lit, and then close the panel.

LEDs on the top of the server

You can also use the LEDs on the top of the server to find an error. If the BOARD LED on the diagnostics panel is lit, pull the server out, and view the top cover. In the center of the top cover is a set of six LEDs and the system service labels. The numbers next to the LEDs correspond to the numbers on the system service label. Note the lit LED, and see the numbered block on the system service label that corresponds to the lit LED. Then, follow the instructions, if any, in the numbered block.

LEDs on the system boards

To locate the actual component that caused the error, locate the lit LED next to that component.

For example:

A system error has occurred, and you have noted that the CPU LED is lit on the diagnostics panel. Referring to the LEDs on the top cover, you see that LED 2 is lit. You then locate the panel on the system service label with the number 2 on it. In this case, the instructions in the panel tell you that the problem occurred with one of the microprocessors. Follow the instructions to remove the processor-board assembly. See “Processor-board assembly” on page 129. Located on the circuit board is the light-path capacitor switch. Press and hold the switch until you locate the lit LED next to the defective microprocessor. Follow the instructions in “Microprocessor and power module” on page 131 and “Installing and replacing a microprocessor and power module” on page 99 to remove and replace the microprocessor.

For more information about LEDs and connectors, see “Major components of the xSeries 455 server” on page 79.

Chapter 3. Diagnostics 41

Diagnostic display

If a problem is detected with system power on or during initialization, the two-hex character diagnostic display on the midplane board might show an error code. See “Midplane board LEDs” on page 80 and “Diagnostic display error codes” on page 201 for more information.

Diagnostic programs, error codes, and messages

Diagnostic error messages indicate that a problem exists. They are not intended to be used to identify a failing part. Troubleshooting and servicing of complex problems that are indicated by error messages should be performed by trained service personnel.

Sometimes the first error to occur causes additional errors. In this case, the server displays more than one error message. Always follow the suggested action instructions for the first error message that appears.

Chapter 6, “Symptom-to-FRU index,” on page 159 contains the error codes that might appear in the detailed test log and summary log when the diagnostic programs are run.

Text messages

The diagnostic text message format is as follows:

Function Name: Result (test specific string)

where:

Function Name

is the name of the function being tested when the error occurred. This corresponds to the function code (fff) shown in the error code format in the previous section.

Result

can be one of the following:

Passed This result occurs when the diagnostic test is completed

Failed This result occurs when the diagnostic test discovers an

Aborted This result occurs when you stop the diagnostic test before

Starting the AMIDiag program

The AMIDiag program is stored in the EEPROM of the server. You can download the latest version from http://www.ibm.com/eserver/xseries/ on the World Wide Web.

without any errors.

error.

it is complete.

Starting the AMIDiag program from the server

Complete the following steps to start the AMIDiag program:

1. Turn on the server, and watch the screen.

Note: To run the AMIDiag program, you must start the server with the highest

42 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

level password that is set. That is, if an administrator password is set, you must type the administrator password, not the user password, to run the diagnostic programs.

2. When the Shell> prompt appears on the screen, type d to highlight the diagnostic entry at the bottom of the screen, and press Enter.

3. When the AMIDiag program screen appears, select the test you want to run from the menu that appears, and follow the instructions on the screen.

Notes:

a. Press F1 while running the AMIDiag program to obtain help information.

Press F1 from within a help screen to obtain online documentation from which you can select different categories. To exit from the help information and return to where you left off, press Esc.

b. If the server stops during testing and you cannot continue, restart the server

and try running the AMIDiag program again. If the problem remains, replace the component that was being tested when the server stopped.

c. When you exit the AMIDiag program, the server resets automatically. If the

server does not reset automatically, manually reset the server before starting the operating system.

the diagnostic programs do not detect any hardware errors but the problem

If persists during normal server operations, a software error might be the cause. If you suspect a software problem, see ″Software problems″ at “Error symptoms” on page 196 and the information that comes with the software package.

Updating the firmware

If you have downloaded the latest version of the AMIDiag program from the World Wide Web, you can create a CD or save it to a valid file system on your server so that you can update the AMIDiag program on the server.

Before you can create a CD, you might need to enable the CD creating feature. For instructions to enable the CD creating feature using Microsoft Windows Server 2003, see “Setup requirements” on page 20. For instructions using another operating system, see the documentation for the operating system.

To create a CD with the latest version of the AMIDiag program, unzip the file that you downloaded from the World Wide Web, and copy it to a CD.

To use the service processor to update SAL/EFI, AMIDiag, or service processor firmware, complete the following steps:

1. Open the Remote Supervisor Adapter Web browser, and click Firmware Update.

2. Click Browse, and select flash2.efi; then, click Update. A loader popup window is displayed.

3. When the Confirm Firmware Update window displays, click Continue. A message indicating that the update has completed displays when the update is finished.

update the firmware from the EFI Shell, complete the following steps:

1. Unzip the file you downloaded, and save all the components of the file package to a valid file system.

2. From the EFI Boot Manager, select EFI Shell [Built-In], and press Enter.

3. Locate the file system on which the file you downloaded was saved, and type cd fsn:, where n is the file system number where the file is saved.

4. Locate the directory where the file is saved, and go to that directory.

Chapter 3. Diagnostics 43

AMIDiag menus

5. Type flash2, and press Enter. A menu is displayed.

6. Select Update System Firmware, and press Enter. A Warning screen is

displayed.

7. Press Enter to continue. The Firmware Update Options Menu is displayed.

8. Select Normal Flash - All Subsystems, and press Enter. Follow the

instructions on the screen.

9. Restart the server.

The AMIDiag main menu displays the following nine main menu items:

v System v Memory v IDE v SCSI v Video v USB v Miscellaneous v User v Options

menu item has a sub-menu that displays when you select one of the menu

Each items in the main menu.

Press the Up Arrow (—) or Down Arrow (–) keys to select a menu choice, and press Enter. Press the Right Arrow (”) or Left Arrow (“) keys to display a different AMIDiag menu.

Using AMIDiag keys

The following table shows the AMIDiag keys and a brief description of their function.

Key Description

Esc Halt a currently running test. Exits the AMIDiag program if no test is running. Enter Run the selected AMIDiag test. F1 Display Help screens. F2 Edit batch parameters. F3 Load batch parameters. F4 Save batch parameters. F5 Select or deselect the current test. F6 Select or deselect the tests on a specific AMIDiag menu. F7 Select or deselect all AMIDiag tests. F8 Select or deselect all tests necessary to run a system quick test. F9 Display a list of the AMIDiag function keys. F10 Run the selected test or tests.

44 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Running AMIDiag tests

To run this test or test group... Do the following

Run all AMIDiag tests. Press F7, then F10. Run a complete overall system quick

Press F8, then F10.

test . Run all processor board diagnostic tests.

1. Select System, and press Enter.

2. Press F6, then press F10.

Run all memory diagnostic tests.

1. Select Memory, and press Enter.

2. Press F6, and then press F10.

Run all IDE drive diagnostic tests.

1. Select IDE, and press Enter.

2. Press F6, and then press F10.

Run all USB diagnostic tests.

1. Select USB, and press Enter.

2. Press F6.

3. Press F10.

Run all video diagnostic tests.

1. Select Video, and press Enter.

2. Press F6.

3. Press F10.

Run all serial, expansion port, and ASM diagnostic tests.

1. Select the Misc. menu, and press Enter.

2. Press F6.

3. Press F10.

Enable logging of test session.

1. Select Options, and press Enter.

2. Select Generate Reports, and press Enter.

3. Select the output device, and press Enter.

Note: Logging to a file requires a writeable

file system to be available from the EFI environment.

Exit the AMIDiag program. Press Esc, and select Yes at the prompt.

Running the AMIDiag program in Batch Mode

When your server is experiencing an intermittent problem that no diagnostic software test has been able to identify, run AMIDiag tests over an extended period of time. Many server problems (especially memory problems) are not evident when a test is run only once. Yo u can use the AMIDiag program to run diagnostic tests on only a certain part of the server, a specific part of memory, or a specific part of a disk drive. Yo u can also use the AMIDiag program to build script (.INI) files that contain test configuration information. After you have created an AMIDiag script file, you can run the diagnostic tests listed in the .INI file automatically.

To run the AMIDiag program in batch mode, complete the following steps:

1. Select the AMIDiag tests to be run.

2. Select the test parameters, such as the drives and the I/O ports. These parameters differ for each test.

3. Press F10 to run the tests.

4. Save the current AMIDiag test configuration to a .INI file. Yo u can then run this set of AMIDiag tests at any time.

Chapter 3. Diagnostics 45

Error-log viewer

If you have enabled logging with the Generate Report option, you can display the log while still running the AMIDiag program. The AMIDiag error log contains all diagnostic errors that the AMIDiag program has found during the current AMIDiag session. The error-log viewer offers some text search capability.

To display the error log, select Display Error Log File on the AMIDiag Options menu. Type the name of the error log file. The default error log filename is amidiag.log. The AMIDiag error log file will be displayed.

If you get a message that says that the log file is damaged, complete the following steps to correct the problem:

1. From the main menu, select Options.

2. Select Generate Report, and press Enter.

3. Select Report Destination, and press Enter.

Note: Yo u must be able to write to the file system to which you are saving the

report.

4. Select File, and press Enter.

access Help for more information about an error, browse to the error that you

To want to see in the error window (on the right side of the screen), and press F1.

Quitting tests

Press Esc to quit the testing process. Testing stops after any test in progress has been completed.

System diagnostic tests

This section describes individual system diagnostic tests.

Note: Each test on the System menu can generate error codes. For system-error

codes, see “System-error codes” on page 176.

PCI Test

Use the PCI Test to make sure that the PCI bus and all PCI devices in the server are working properly.

To make sure that the PCI adapter slots are functioning correctly, complete the following steps:

1. From the AMIDiag main menu, select System.

2. Select PCI Test, and press Enter.

System Board Tests

Select this choice to run a DMA controller test.

This test is a series of read and write tests on the memory address registers and page registers of direct memory address (DMA) controllers 1 and 2. The DMA controller manages the flow of information directly to and from system memory and an ″intelligent″ peripheral device, without passing through the microprocessor. On error, the AMIDiag program displays the register number, data written, and data read. To perform this test, complete the following steps:

1. From the main menu, select System.

2. Select DMA Controller Test, and press Enter.

46 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Processor Tests

Use Processor Tests to make sure that all microprocessors are functioning properly.

Use the CPU Functionality Test to make sure that microprocessors in the server are operating correctly and efficiently in all address modes. To run the CPU Functionality Test, complete the following steps:

1. From the AMIDiag main menu, select System.

2. Select Processor Tests, and press Enter.

3. Select CPU Functionality Test, and press Enter.

the CPU Speed Test to check the microprocessor speed. When you run this

Use test, the screen displays the expected processor speed and the actual microprocessor clock speed. To run the CPU Speed Test, complete the following steps:

1. From the AMIDiag main menu, select System.

2. Select Processor Tests, and press Enter.

3. Select CPU Speed Test, and press Enter.

4. Make sure that the test parameters are set correctly, and select CONTINUE; then, press Enter.

Multiprocessor Test

Select this test when running the AMIDiag program in a server that has more than one microprocessor. This test performs a variety of diagnostic tests on all microprocessors. To perform this test, select Multiprocessor Tests from the System menu, and press Enter. Follow the directions on the screen.

Memory diagnostic tests

Use the memory diagnostic tests to make sure that the memory board and installed memory are properly seated and functioning correctly. You can test all memory and the memory board on any node, or you can isolate a single memory bank on any node to verify that it functions correctly. The following test modes are available:

v Quick test runs two test patterns through the entire free, installed memory space

of the banks selected.

v Full test runs 18 patterns, including pseudo-random patterns through the entire

free, installed memory space of the banks selected.

run the Quick Memory Test on all memory banks, complete the following steps:

1. From the AMIDiag main menu, select Memory.

2. Select Node n Quick Memory Test, where n is the node that you are testing, and press Enter.

3. Select All Banks, Quick Test, and press Enter.

run full diagnostic tests over all memory banks, complete the following steps:

1. From the AMIDiag main menu, select Memory.

2. Select Node n Full Memory Test, where n is the node that you are testing, and press Enter.

3. Select All Banks, Full Test, and press Enter.

Chapter 3. Diagnostics 47

To run the Quick Memory Test on a single memory bank, complete the following steps:

1. From the AMIDiag main menu, select Memory.

2. Select Node n Quick Memory Test, where n is the node that you are testing,

and press Enter.

3. Select the individual bank you want to test or select Bank n, Quick Test, and

press Enter.

To run the Full Memory Test on a single memory bank, complete the following steps:

1. From the AMIDiag main menu, select Memory.

2. Select Full Memory Test, and press Enter.

3. Select the individual banks you want to test or select Node m Bank n, Full

Test, where m is the node that you are testing, and press Enter.

IDE device diagnostic tests

The IDE device diagnostic tests work only with CD-ROM, DVD, and removable devices that use the ATAPI interface.

IDE CD-ROM tests

Use the IDE CD-ROM tests to make sure that the IDE CD-ROM drive is functioning properly. Yo u can test the functionality of the CD-ROM drive tray and the data and audio read functions of the CD-ROM drive. The IDE CD-ROM tests include the following:

v IDE CD Tray Test

Select this test to make sure that the CD-ROM drive auto-eject feature can eject a CD. The CD tray should open and close.

To run the CD tray test for an IDE CD-ROM drive, complete the following steps:

1. From the main menu, select IDE.

2. Select IDE CD Test, and press Enter.

3. Select CD Tray Test, and press Enter.

v IDE CD Data Test

Use the IDE CD data test to make sure that the CD-ROM drive is reading correctly. This test reads all logical blocks on a CD if the starting and ending block are not specified. Place any CD in the CD-ROM drive before running this test, and follow the screen instructions. This test does not play audio CDs.

To run the IDE CD data test to diagnose an IDE CD-ROM drive, complete the following steps:

1. From the main menu, select IDE.

2. Select IDE CD Test, and press Enter.

3. Select CD Data Test, and press Enter.

v IDE CD Audio Test

A speaker must be attached to the CD-ROM drive before running this test. This test plays all logical blocks if the starting and ending block are not specified.

To run the IDE CD audio test, complete the following steps:

1. Place an audio CD in the CD-ROM drive.

2. From the main menu, select IDE.

3. Select IDE CD Test, and press Enter.

4. Select CD Audio Test, and press Enter.

48 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

For the IDE CD test error codes, see “IDE CD test error codes” on page 178.

ATAPI removables test

This test verifies that the removable disk drive, such as an Iomega ZIP drive, is operating correctly. The tests include:

v Format test

The format test verifies that the removable drive is properly formatted for operation.

Attention: This test formats the media in the device being tested. Use this test

only if you want to format the media.

v Write test

This test verifies the ability of the removable disk drive to write data correctly to a disk. Use a disk that you know is good for this test. This test is normally hidden from view because it erases the data on the disk. To make this menu item viewable so that you can run this test, complete the following steps:

1. From the AMIDiag main menu, select Options, and press Enter.

2. Select Toggle Hidden Test Display, and press Enter.

Attention: This test erases all data on the disk.

Select the drive or drives to be tested, and run the test.

Read test

Use this test to verify the ability of the removable media drive to read data correctly in both block and random sequential format from a removable disk. Use a disk that you know is good for this test. Select the drive or drives to be tested, and run the test. You can select the starting and ending clocks of data to be read, or you can select the percentage of the drive to be read in a sequential or random order. You can also run a random or sequential read test.

v Seek test

Use this test to verify the ability of the removable media drive to seek blocks of data sequentially or randomly. Select the test parameters, and run the test. Yo u can specify the number of times this test is to be run (repeat count), or you can specify Quick Test to test only 1% of the disk.

v Eject test

Use this test to verify that the auto-eject feature of the removable media drive is working properly. You can set the Execution Count parameter to run this test a number of times. Select the test parameters, and select Continue to run the test.

For the ATAPI removables test error codes, see “ATAPI removables test error codes” on page 179.

IDE DVD tests

The IDE DVD-ROM drive tests include the following:

v IDE DVD Seek Test

Select this test to make sure that the DVD-ROM drive can seek to all sectors of the DVD. Yo u can change the size to seek by adjusting the Block Interleave parameter value.

v IDE DVD Read Test

Select this test to make sure that the DVD-ROM drive can read to all sectors of the DVD. This test works with both encrypted and unencrypted DVDs.

For the IDE DVD-ROM drive test error codes, see “IDE DVD-ROM drive test error codes” on page 181.

Chapter 3. Diagnostics 49

SCSI diagnostic tests

The AMIDiag program tests all SCSI devices installed in your server. The SCSI tests detect and test a combination of up to 120 SCSI hard disk drives.

SCSI diagnostic tests consist of the following tests

v SCSI Disk Tests v SCSI Tape Tests

diagnostic tests consists of the following tests:

SCSI

v SCSI Disk Buffer Test v SCSI Disk Self Test v SCSI Disk Read Test v SCSI Disk Quick Test

SCSI Disk Tests

For the SCSI test error codes, see “SCSI test error codes” on page 181.

SCSI Disk Buffer Test: This test writes logical blocks of data to the internal buffer

on the disk drive. The same logical blocks of data are then read from the drive buffer and compared to the original data. If the SCSI hard disk drive does not have an internal buffer, you cannot select this test.

SCSI Disk Self Test: Select this choice to run the diagnostic tests on the SCSI

disk drive.

To run the test, complete the following steps:

1. Select SCSI Disk Self Test, and press Enter.

2. Choose the parameters on the screen, and select Continue.

Note: Yo u cannot quit the SCSI Disk Self Diagnostic Test. You must wait until

the entire disk self test completes.

Disk Read Test: Use this test to make sure that the SCSI drive is reading

SCSI

correctly. This test sequentially and randomly reads logical blocks from the SCSI hard disk drive. If you do not specify a starting and ending block number, block 0 through the last block are tested.

50 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

To run the SCSI disk read test, complete the following steps:

1. From the main menu, select SCSI, and press Enter.

2. Select SCSI Disk Read Test, and press Enter. A default parameter screen appears.

3. Set the parameters that you want.

Parameter Description

overall % Specifies the drivewise % or common % as set for

each drive. If Drivewise is selected, the drive parameters are specified for each drive used. If

Common is selected, all drive parameters use the %

parameters, which are entered in the % for Common fields. This reduces the need to set each drive

parameter if the server has a large number of drives. Common: Use the term % to specify all drives SCSI Disk n Specify an individual drive parameter.

4. Select Continue, and press Enter.

start and end block number fields are 0 and the last block on the disk or the

The values set the last time this test was run. As the test runs, the current block number, number of blocks tested, and number of blocks left are updated. Also, the block tested is marked with a different character. The random test is performed on the specified percentage of blocks between the specified start and end blocks.

SCSI Disk Quick Test: Use this test to perform an abbreviated read test on all

SCSI disks installed in the server.

Chapter 3. Diagnostics 51

SCSI Tape Test

Use the SCSI Tape Test to diagnose functions of a SCSI tape device. The SCSI Tape tests include the following:

v SCSI Tape Buffer Test

This test writes logical blocks of data to the internal buffer on the tape drive. The same logical blocks of data are then read from the tape drive buffer and compared to the original data. If the tape drive does not have an internal buffer, you cannot select this test.

v SCSI Tape Self Test

Select this choice to run the diagnostic tests on the SCSI tape drive. To run the test, complete the following steps:

1. Select SCSI Tape Self Test, and press Enter.

2. Choose the parameters on the screen, and select Continue.

Note: Yo u cannot quit the SCSI Tape Self Test. You must wait until the entire

disk self test completes.

v SCSI Tape Read Test

Use this test to make sure that the SCSI tape drive is reading correctly. This test reads sequential logical blocks from the SCSI tape. With default parameters, this test requires fully written media to be installed in the device being tested. Partially written media will result in a read error at the end of data. If only blank media is available, use the SCSI Tape Write Test to write a test pattern onto the blank media.

To run the SCSI Tape Read Test, complete the following steps:

1. From the main menu, select SCSI, and press Enter.

2. Select SCSI Tape Read Test, and press Enter. A default parameter screen

appears:

Select SCSI Disk

Overall % Parameters 100

Overall % Parameters

SCSI Disk 0

SCSI Disk 0 CONTINUE

CONTINUE

100

Parameter Description

overall % Specifies drivewise % as set for each drive. Common: Use the term % to specify all drives SCSI Tape n Specify an individual drive parameter.

The following screen appears when you specify an individual drive:

Test Tape 0

Start Block

End Block

CONTINUE

A prompt for the percentage of the drive to be tested appears.

52 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

SCSI Tape Read Test

: YES

:YES

: 000000000

: 002028000

3. Specify the percentage of the drive to be tested, select CONTINUE, and

press Enter. If the tape is not positioned at the beginning of the starting block, a tape

rewind command is issued before the test begins.

SCSI Tape Quick Test

Use this test to perform an abbreviated read test on all SCSI tape drives installed in the server.

Video diagnostic tests

Select this choice to run diagnostic tests on the display and the video controller.

To diagnose video display problems, complete the following steps:

1. From the main menu, select Video.

2. Select Video Memory Test, and press Enter.

For the video test error codes, see “Video test error codes” on page 184.

Running video tests

The video test you run depends on the type of monitor installed on your server.

Video Monitor Test

These tests verify the video controller output in addition to the communication between the controller and the display device.

Attribute Test: Use this test to make sure that the video display attributes, such

as blinking, bold, and reverse video, are working correctly. You can run this test on all monochrome and all color monitors.

To run the attribute test, complete the following steps:

1. From the main menu, select Video.

2. Select Attribute Test, and press Enter.

Test: This test displays the possible colors in foreground, background, and

Color

border. Yo u can run this test on all color monitors.

Text Mode Test: Use the Text Mode test to make sure that text displays correctly.

The text mode tests are shown on the following table:

Test Name Test Description Type of Monitor

80 x 25 Display Test Tests the 80 x 25 character set of the

display adapter, displaying the entire

All monochrome and all

color monitors. character set in black and white, then in reverse video in video mode 3 (mode 7 if monochrome).

40 x 25 Display Test Tests the 40 x 25 character set of the

display adapter in black and white,

All monochrome and all

color monitors. displaying the entire character set in black and white, then in reverse video.

Chapter 3. Diagnostics 53

Graphics mode tests: Use the graphics mode tests to make sure that graphics

display correctly. The following subtests appear in all Graphics Mode Tests (320 x 200, 640 x 200, 640 x 350, 640 x 480):

Subtest Description

Text and Attribute Test Makes sure all characters are displayed in the proper

color. Grid Test Verifies the graphic dot spacing for each mode. Aspect Ratio and Display

Centers the monitor display. Centering

Circular Pattern Test Centers the monitor display. Resolution Reports the screen resolution. Animation and Flicker Reports the video controller speed. Pixel Throughput Reports the speed at which complex patterns are

drawn on the screen.

These video tests might not appear correctly when displaying high-resolution VESA video modes on a multisync monitor. The monitor must be adjusted for each individual video mode. After the video mode you will be using appears, you must run the Aspect Ratio and Display Centering subtest to center the monitor.

The graphics mode tests are shown in the following table:

Test Name Test Description Type of Monitor

320 x 200 Graphics Test

Displays a black and white 9 x 13 window and redisplays it in reverse video. Then displays a

All color monitors.

three-color screen, a screen of random colors, then a black and white screen, and finally 256 colors

640 x 200 Graphics Test

Displays three black and white boxes, then goes from a black screen to a white screen,

All color monitors

and back to a black screen.

640 x 350 Graphics Test

Displays a 16-color screen, then fills the screen with random colors, then returns to a

EGA and VGA adapters only.

blank screen.

640 x 480 Graphics Test

Displays a 16-color screen, then fills the screen with random colors, then returns to a

Only VGA adapters.

blank screen.

Video Controller Test

This test verifies the functionality of the graphics controller in VGA mode and the video memory. The video controller test verifies vertical synchronization, horizontal synchronization, the graphics controller, the attribute controller, and the DAC register.

USB diagnostic tests

The USB tests diagnose problems with USB devices.

For the USB test error codes, see “USB test error codes” on page 184.

54 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

USB Functionality Test

Select USB Test from the USB menu to diagnose problems with USB devices and to make sure that USB support is provided in the SAL/EFI.

USB Keyboard Test

Use this test to diagnose USB keyboard hardware functionality and to determine the data transfer rate between the USB host controller and the USB keyboard. This procedure tests the USB keyboard key codes and keystrokes.

To run the test, complete the following steps:

1. Select USB from the main menu.

2. Select USB Keyboard Test, and press Enter.

3. Select CONTINUE, and press Enter.

USB Keyboard Test determines if a pressed key matches the Scan and ASCII

The codes for that key. Every time you press a key to verify its code, both the scan code and ASCII code of the pressed key is displayed. The key symbol is also displayed.

Perform this test to identify faulty keys.

To run the test, complete the following steps:

1. Select USB from the main menu, and press Enter.

2. Select USB Keyboard Test, and press Enter to display a keyboard layout. Scan

code and ASCII code appear above the keyboard layout.

3. Press the keys on the keyboard. The scan codes and ASCII codes display in the appropriate fields for each key as it is pressed. Use this test to verify the codes with their respective keys. Use the tables on pages 55 through 60 for the correct scan and ASCII codes.

4. Press Ctrl+Break to exit this test.

the following tables to verify that the displayed scan and ASCII codes are

Use correct.

Table 3. Lower case keyboard scan/ASCII codes

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Esc 01 1B 1 02 31

2 03 32 3 04 33 4 05 34 5 06 35 6 07 36 7 08 37 8 09 38 9 0A 39 0 0B 30 - 0C 2D = 0D 3D Backspace 0E 08

Ta b 0F 09 q 10 71

w 11 77 e 12 65

r 13 72 t 14 74

y 15 79 u 16 75

i 17 69 o 18 6F

p 19 70 [ 1A 5B

Chapter 3. Diagnostics 55

Table 3. Lower case keyboard scan/ASCII codes (continued)

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

} 1B 5D Return 1C 0D

Ctrl ‡ ‡ a 1E 61

s 1F 73 d 20 64

f 21 66 g 22 67 h 23 68 j 24 6A k 25 6B l 26 6C

; 27 3B ’ 28 27

’ 29 60 Shift ‡ ‡

\ 2B 5C z 2C 7A x 2D 78 c 2E 63 v 2F 76 b 30 62 n 31 6E m 32 6D

, 33 2C . 34 2E

/ 35 2F * 37 2A

Alt ‡ ‡ Space 39 20

Caps Lock ‡ ‡ F1 3B 00

F2 3C 00 F3 3D 00 F4 3E 00 F5 3F 00 F6 40 00 F7 41 00

F8 42 00 F9 43 00 F10 44 00 F11 85 00 F12 86 00 Num Lock ‡ ‡

Scroll Lock ‡ ‡ Home 47 00

48 00 PgUp 49 00

_ 4A 2D 4B 00

Center key 4C 00 4D 00

+ 4E 00 4F 00

50 00 PgDn 51 00

Ins 52 00 Del 53 00

SysReq no key no key Key 45 56 5C

Enter E0 0D / E0 2F

Print Screen ‡ ‡ Pause ‡ ‡

Home 47 E0 48 E0

PgUp 49 E0 4B E0

‡ Combination provides no keystroke for the application; performs another action.

-- No function is assigned to this combination.

56 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Table 4. Upper case (shift) keyboard scan/ASCII codes

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Shift+Esc 01 1B ! 02 21

@ 03 40 # 04 23

$ 05 24 % 06 25 ^ 07 5E & 08 26

* 09 2A ( 0A 28 ) 0B 29 _ 0C 5F

+ 0D 2B Shift+

0E 08

Backspace

Shift+Tab 0F 00 Q 10 51

W 11 57 E 12 45

R 13 52 T 14 54 Y 15 59 U 16 55

I 17 49 O 18 4F

P 19 50 { 1A 7B

} 1B 7D Shift+Return 1C 0D

Shift+Ctrl ‡ ‡ A 1E 41

S 1F 53 D 20 44 F 21 46 G 22 47 H 23 48 J 24 4A K 25 4B L 26 4C

: 27 3A ″ 28 22

~ 29 7e | 2B 7C Z 2C 5A X 2D 58 C 2E 43 V 2F 56 B 30 42 N 31 4E M 32 4D < 33 3C

> 34 3E ? 35 3F

* 37 2A Shift+Alt ‡ ‡

Shift+Space 39 20 Shift+Caps

‡ ‡

Lock Shift+F1 54 00 Shift+F2 55 00 Shift+F3 56 00 Shift+F4 57 00 Shift+F5 58 00 Shift+F6 59 00 Shift+F7 5A 00 Shift+F8 5B 00 Shift+F9 5C 00 Shift+F10 5D 00

Shift+F11 87 00 Shift+F12 88 00

Shift+Num

Lock

‡ ‡ Shift+Scroll

Lock

‡ ‡

Shift+7 47 37 Shift+8 48 38 Shift+9 49 39 Shift+ - 4A 2D Shift+4 4B 34 Shift+5 4C 35

Chapter 3. Diagnostics 57

Table 4. Upper case (shift) keyboard scan/ASCII codes (continued)

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Shift+6 4D 36 Shift++ 4E 2B Shift+1 4F 31 Shift+2 50 32 Shift+3 51 33 Shift+0 52 30

Shift+. 53 2E Shift+Sys

no key no key

Req

Shift+key 45 56 7C Shift+Enter E0 0D

Shift+/ E0 2F Shift+Print

‡ ‡

Screen

Shift+Pause ‡ ‡ Shift+Home 47 E0

Shift 48 E0 Shift+PgUp 49 E0 Shift 4B E0 Shift 4D E0

Shift+End 4F E0 Shift 50 E0

Shift+PgDn 51 E0 Shift+Ins 52 E0

Shift+Del 53 E0

‡ Combination provides no keystroke for the application; performs another action.

-- No function is assigned to this combination.

Table 5. Ctrl keyboard ASCII/scan codes

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Ctrl+Esc 01 1B Ctrl+1 -- --

Ctrl+2 (NUL) 03 00 Ctrl+3 -- --

Ctrl+4 -- -- Ctrl+5 -- --

Ctrl+6 (RS) 07 1E Ctrl+7 -- --

Ctrl+8 -- -- Ctrl+9 -- -- Ctrl+0 -- -- Ctrl+_ 0C 1F

Ctrl+

0E 7F Ctrl+Tab 94 00

Backspace

(Del)

Ctrl+Tab 0F 00 Ctrl+Q 10 51

Ctrl+q (DC1) 10 11 Ctrl+w (ETB) 11 17

Ctrl+e (ENQ) 12 05 Ctrl+r (DC2) 13 12

Ctrl+t (DC4) 14 14 Ctrl+y (EM) 15 19

Ctrl+u (NAK) 16 15 Ctrl+i (HT) 17 9

Ctrl+o (SI) 18 0F Ctrl+p (DLE) 19 10

Ctrl+[ (ESC) 1A 1B Ctrl+] (GS) 1B 1D

Ctrl+Return 1C 0A Ctrl+a 1E 01

Ctrl+s (DC3) 1F 13 Ctrl+d (EOT) 20 04

Ctrl+f (ACK) 21 06 Ctrl+g (BEL) 22 07

Ctrl+h

23 08 Ctrl+j (LF) 24 0A

(Backspace)

Ctrl+k (VT) 25 0B Ctrl+1 26 0C

58 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Table 5. Ctrl keyboard ASCII/scan codes (continued)

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Ctrl+; -- -- Ctrl+’ -- -- Ctrl+` -- -- Ctrl+Shift ‡ ‡

Ctrl+\ (FS) 2B 1C Ctrl+z (SUB) 2C 1A

Ctrl+x (CAN) 2D 18 Ctrl+c (ETX) 2E 03

Ctrl+v (SYN) 2F 16 Ctrl+b (STX) 30 02

Ctrl+n (SO) 31 0E Ctrl+m (CR) 32 0D

Ctrl+. -- -- Ctrl+. -- -- Ctrl+/ -- -- Ctrl+* 96 00

Ctrl+Alt ‡ ‡ Ctrl+Space 39 20

Ctrl+Caps

-- -- Ctrl+F1 5E 00

Lock Ctrl+F2 5F 00 Ctrl+F3 60 00 Ctrl+F4 61 00 Ctrl+F5 62 00 Ctrl+F6 63 00 Ctrl+F7 64 00 Ctrl+F8 65 00 Ctrl+F9 66 00

Ctrl+F10 67 00 Ctrl+F11 89 00 Ctrl+F12 8A 00 Ctrl+Num

-- --

Lock

Ctrl+Scroll

-- -- Ctrl+Hme 77 00

Lock

Ctrl 8D 00 Ctrl+PgUp 84 00

Ctrl+Keypad - 8E 00 Ctrl 73 00

Ctrl+Center 8F 00 Ctrl 74 00

Ctrl+Keypad

90 00 Ctrl+End 75 00

Ctrl 91 00 Ctrl+PgDn 76 00

Ctrl+Ins 92 00 Ctrl+Del 93 00

Ctrl+Sys Req (no key) (no key) Ctrl+Key 45 -- --

Ctrl+Enter E0 Ctrl+/ 95 00

Ctrl+Print

72 00 Ctrl+Break 00 00

Screen

Ctrl+Home 77 E0 Ctrl 8D E0

Ctrl+PgUp 84 E0 Ctrl 73 E0

Ctrl 74 E0 Ctrl+End 75 E0 Ctrl 91 E0 Ctrl+PgDn 76 E0

Ctrl+Ins 92 E0 Ctrl+Del 93 E0

‡ Combination provides no keystroke for the application; performs another action.

-- No function is assigned to this combination.

Chapter 3. Diagnostics 59

Table 6. Alt keyboard scan/ASCII codes

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Alt+Esc 01 00 Alt+1 78 00

Alt+2 79 00 Alt+3 7A 00 Alt+4 7B 00 Alt+5 7C 00 Alt+6 7D 00 Alt+7 7E 00 Alt+8 7F 00 Alt+9 80 00 Alt+0 81 00 Alt+ - 82 00 Alt+= 83 00 Alt+

0E 00

Backspace

Alt+Tab A5 00 Alt+q 10 00

Alt+w 11 00 Alt+e 12 00

Alt+r 13 00 Alt+t 14 00

Alt+y 15 00 Alt+u 16 00

Alt+I 17 00 Alt+o 18 00

Alt+p 19 00 Alt+[ 1A 00

Alt+] 1B 00 Alt+Return 1C 00

Alt+Ctrl ‡ ‡ Alt+a 1E 00

Alt+s 1F 00 Alt+d 20 00

Alt+f 21 00 Alt+g 22 00 Alt+h 23 00 Alt+j 24 00 Alt+k 25 00 Alt+l 26 00

Alt+; 27 00 Alt+’ 28 00

Alt+` 29 00 Alt+Shift ‡ ‡

Alt+\ 2B 00 Alt+z 2C 00 Alt+x 2D 00 Alt+c 2E 00 Alt+v 2F 00 Alt+b 30 00 Alt+n 31 00 Alt+m 32 00

Alt+, 33 00 Alt+. 34 00

Alt+/ 35 00 Alt+* 37 00

Alt+Space 39 00 Alt+Caps

‡ ‡

Lock

Alt+F1 68 00 Alt+F2 69 00

Alt F3 6A 00 Alt+F4 6B 00 Alt+F5 6C 00 Alt+F6 6D 00 Alt+F7 6E 00 Alt+F8 6F 00 Alt+F9 70 00 Alt+F10 71 00

Alt+F11 7B 00 Alt+F12 8C 00

Alt+Num Lock ‡ ‡ Alt+Scroll

‡ ‡

Lock

Alt+Keypad - 4A 00 Alt+Keypad + 4E 00

Alt+Keypad

# 00 Alt+Del -- --

Numbers

60 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Table 6. Alt keyboard scan/ASCII codes (continued)

Keystroke Scan Code ASCII Code Keystroke Scan Code ASCII Code

Alt+SysReq (no key) (no key) Alt+key 45 -- --

Alt+Enter A6 00 Alt+/ A4 00

Alt+Print

‡ ‡ Alt+Pause ‡ ‡

Screen

Alt+Home 97 00 Alt 98 00

Alt+PgUp 99 00 Alt 9B 00

Alt 9D 00 Alt+End 9F 00 Alt A0 00 Alt+PgDn A1 00

Alt+Ins A2 00 Alt+Del A3 00

‡ Combination provides no keystroke for the application; performs another action.

-- No function is assigned to this combination.

USB Mouse Test

Select the USB Mouse Test to test the USB mouse on your server.

To run the test, complete the following steps:

1. From the main menu, select USB.

2. Select USB Mouse Test, and press Enter.

3. Select CONTINUE, and press Enter.

Parameter Action

Test This Device Select YES to run the USB Mouse Test. Sensitivity Test Select YES to run the Sensitivity test. PnP Test Select YES to run the USB Mouse Plug and Play (PnP) test. This

Miscellaneous diagnostic tests

The Miscellaneous diagnostic tests include the Serial Port Test, the LED Test, the RXE Port Test, and the Advanced System Management Test.

Serial port test

The Serial Port test checks to see if the serial port is functioning properly.

To diagnose serial port problems, complete the following steps:

1. From the main menu, select Miscellaneous.

2. Select Serial Port Test, and press Enter.

The test routines check all serial port controllers at speeds from 300 to 115,200 bps (up to 460,800 bps if a 16550 UART is installed).

3. Select the number of data bits, number of stop bits, and parity type for the serial port.

4. Select a field using the – and + keys, and set the parameters.

5. Select Continue, and press Enter.

test makes sure that the USB mouse Plug and Play feature works properly. The Plug and Play feature automatically configures the USB device when the device is attached to the server.

Chapter 3. Diagnostics 61

The serial port tests include the following:

v Serial Port Hardware Test

The serial port hardware test diagnoses hardware attached to the serial port.

v Internal Loopback Test

This test verifies the proper functionality of the transmitter and receiver register in the serial port using the internal loopback mechanism.

Attention: Running this test with console redirection might slow down the

server.

v External LoopBack Test

This test verifies the proper functionality of the transmitter and receiver register in the serial port. This test requires an external loopback connector to be physically connected to the serial port.

Attention: Running this test with console redirection might slow down the

server.

v FIFO Test

This test verifies that the first-in first-out (FIFO) function in the serial port is functioning properly. This test is enabled only for UART 16550 and above.

v Baud Rate Test

This test verifies the accuracy of the data being transferred by the serial port at different baud rates.

the serial port test error codes, see “Serial port test error codes” on page 186.

For

LED Test

Use this test to diagnose all LEDs that can be set using software and visible after the server is assembled. This test lights all LEDs in the server and prompts you to check that they are all lit; then, it turns off all LEDs and prompts you to check that they have been turned off.

ECC Test

This choice tests error correction for the selected server node.

Memory Mirroring

This choice tests the functionality of memory mirroring for the selected server node.

SCAL/RXE Port Test

Use this test to diagnose problems with the scalability and RXE ports. This test consists of the following sub-tests:

v Node N SCAL/RXE port test

This test verifies the quality of the connection from any selected scalability or RXE port to the destination port for node n.

v Show SCAL Cabling

This choice shows the cabling of the server node scalability ports.

v Show RXE Cabling

This choice shows the cabling of the RXE Expansion ports and the remote I/O enclosures for all nodes in the system.

v Show Recommended SCAL Cabling

This choice shows the recommended cabling of the scalability ports for the number of nodes on this system.

62 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

v Recommend RXE Cabling

This choice shows the recommended cabling of the RXE Expansion ports to the RXE100s for the maximum number of RXE100s for this system.

Advanced System Management Test

The Advanced System Management (ASM) Test consists of the following sub-tests:

v I2C Bus Test

This test queries the status of the I2C subsystem within the x455 node. It reports back on any internal integrated circuit (I2C) radials that either are untested or tested bad.

v ASM Built-In Self Test (BIST)

This test queries the ASM for the status of its last-run BIST. Non-disruptive portions of BIST are run periodically on the ASM adapter. Failing BIST results will be reported so that you can determine which, if any, of the major subsystems of the ASM adapter are malfunctioning.

v ASM Restart Test

Use this test to restart the ASM adapter without disconnecting ac power from the xSeries 455 server.

v ISMP BIST

This test queries the ISMP for the status of its last-run BIST. Failing BIST results will be reported so that you can determine which, if any, of the major subsystems of the ISMP are malfunctioning.

v RXE I2C Bus Test

This test queries the status of the I2C subsystem within attached RXE-100 units. It reports back on any I2C radials that are either untested or tested bad.

Note: To run this test, the ASM adapter must be cabled correctly to the RXE-100

unit using the RS-485 bus and appropriate Category 3 or Category 5 cables with proper termination.

v RXE ISMP Self Test

This test queries the ISMP controllers of attached RXE-100 units for the last BIST status. Failing RXE-100 BIST results will be reported so that you can determine if the ISMP subsystem is malfunctioning due to microcontroller problems.

Note: To run this test, the ASM adapter must be cabled correctly to the RXE-100

unit using the RS-485 bus and appropriate Category 3 or Category 5 cables with proper termination.

Chapter 3. Diagnostics 63

Options menu

The Options menu items are as follows:

Edit Batch Parameters

You can customize a set of diagnostic tests to run on your server and save it as a batch file to be run later. You can set the type of AMIDiag test to be run, the number of times each test is run, and the test parameters (for example, you can specify the starting and ending hard disk drive heads and cylinders to be tested).

To set or display AMIDiag runtime parameters, complete the following steps:

1. From the AMIDiag main menu, select Options.

2. Select Edit Batch Parameters, and press Enter. The Edit Batch Parameters

menu appears.

3. Select Batch Parameters, and press Enter. The following menu is displayed:

Cycle Mode

Specifies the number of test cycle scripts in the file. In each cycle there can be a different set of test parameters.

64 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Cycle Number

Specifies whether to test through all of the cycles or just one cycle. This field can be set to All or One.

Test Mode

The Test mode refers to the overall control, not individual cycles. The test modes are:

Mode Description

Continuous The specified tests run until Esc or Ctrl+Break is pressed. Timebound Specify how long the test is to run. Type the hours in the Time

Limit Hrs field and the minutes in the Time Limit Min field, and

press Enter. The maximum setting for number of hours is 999. The maximum setting for number of minutes is 59.

Passbound Set the number of passes (up to 65,535) for the selected AMIDiag

tests in the Number of Passes field, or press Enter to accept the default (run each selected diagnostic test once).

Test Limit Hrs

Specifies the time period in hours in case of cycle Timebound test mode.

Test Limit Min

Specifies the time period in minutes in case of cycle Timebound test mode.

Number of Passes

Specifies the number of passes of cycles in case of Passbound test mode.

Break All on Error

This field can be set to YES or NO. If set to YES, the AMIDiag program stops running all tests after it finds an error.

Cycle Test Mode

Specifies the test mode in a cycle. The cycle test modes are:

Mode Description Timebound Specify how long the test is to run. Type the hours in the Time

Limit Hrs field and the minutes in the Time Limit Min field, and

press Enter. The maximum setting for the number of hours is 999. The maximum setting for the number of minutes is 59.

Passbound Set the number of passes (up to 65,535) for the selected AMIDiag

tests in the Number of Passes field, or press Enter to accept the default (run each selected diagnostic test once).

Cycle TLimit Hrs

Specifies the time period in hours in case of Timebound test mode.

Cycle TLimit Min

Specifies the time period in minutes in case of Timebound test mode.

Passes in Cycle

Specifies the number of passes in a cycle, in case of cycle Passbound test mode. Individual tests also have a count specifying how many times they are to be run.

Chapter 3. Diagnostics 65

Test Order

The test order parameters are:

Parameter Description

Default The selected AMIDiag tests are run in exactly the same order in

which they were selected. Random The selected AMIDiag tests are run in a random manner. Testwise The selected AMIDiag tests are run in the order in which they

appear on the AMIDiag menus.

Wait on Error

This field can be set to YES or NO. If set to YES, the AMIDiag program waits for you to press any key after finding every error.

Break Test on Error

This field can be set to YES or NO. If set to YES, the AMIDiag program stops running after it finds an error.

Interactive

Select this parameter to run the interactive tests in interactive mode. Your input is required in an interactive test. The default value for this parameter is No.

If this parameter is set to NO, all diagnostic tests that support the interactive flag and cannot be run without your input will not run. If the test can be run without your input but it is impossible to decide if the test has passed or failed without your input, the test will run, but it will always pass.

If this parameter is set to YES and the test cannot be run without your input, it runs and will wait for your input as appropriate. If the test can be run without your input but it is impossible to decide if the test has passed or failed without your input, the test runs and it will wait for your decision whether the test passed.

Quick test

This parameter specifies that tests must be run in quick test mode. Abbreviated versions of the diagnostic tests are run in quick test mode. The selected tests are run in quick test mode if the tests support quick mode. You can use the quick test parameter in two ways:

Quick Test use Description

Complete a system test in a shorter time.

Select the diagnostic tests you want to run, or press F7 to select all diagnostic tests on an AMIDiag menu. Set the Quick Test parameter to Yes. If you press F10 to run the tests, all tests except the tests that support Quick Test will run normally. The tests that support Quick Test run in quick mode. If your server has several IDE and SCSI hard disk and CD-ROM drives, testing all drives will take a long time. When you select Quick Test, the IDE and SCSI devices will be tested quickly, saving time.

Use quick test mode for fast system verification

Press F8 when the AMIDiag main menu is displayed to set this parameter to Yes and to select the tests defined as System Quick Test Components. You can either press F4 to script this test, or press F10 to run the tests in batch mode.

66 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Execution count: The Execution Count menu appears when you select

Execution Count from the Edit Batch Parameters menu.

Choose the number of times that you want to run the AMIDiag tests on the associated AMIDiag menus. Yo u can run each test up to 255 times. If you have set the Passbound parameters (see the previous screen) to 5 and you set the repeat count to 5, the test will be run a total of 25 times.

Interactive Test: When you select Interactive Test, and press Enter, the following screen is displayed:

Select the test group. A list of all tests appears. Tests that support interactive test have Yes beside them. Select the tests to run, and press Enter.

Chapter 3. Diagnostics 67

Quick Test: When you select Quick Test, the following Quick Test menu is displayed:

Select the test group. A list of all tests appears. Tests that support Quick Test have

Yes beside them. Select the tests to run, and press Enter.

Test Parameters: The Test Parameters menu is displayed when you select Edit Batch Parameters from the Options menu.

Each item in this menu is the name of an AMIDiag menu. When you select an AMIDiag menu choice, all AMIDiag tests on the menu are listed. Select the tests to run in batch mode, and press Enter.

If you select a test, the parameters for that test are displayed. Set the parameters, and select another diagnostic test. Select CONTINUE, and press Enter when you have set all test parameters for the AMIDiag test to be run in batch mode.

68 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Load Batch Parameters

Choose this option to load previously saved AMIDiag batch diagnostic test parameters. The Load Batch Parameters dialogue box appears:

Press Enter to accept the default batch parameter file (Diagnostic Utility.INI), or type the appropriate AMIDiag batch parameter filename. Yo u can use any valid filename. The filename extension does not have to be .INI. Yo u can then press F10 to run the AMIDiag tests that are specified in this file.

Save Batch Parameters

Select this choice to save all batch mode parameters, selected tests, selected devices, and error logging information to an AMIDiag batch parameter file. You can then load this ASCII file later and use the same saved options and test parameters every time you perform a AMIDiag session. To save batch parameters, complete the following steps:

1. From the AMIDiag main menu, select Options.

2. Select Save Batch Parameters, and press Enter. The following appears:

3. Press Enter to accept the default batch parameter file (Diagnostic Utility.INI), or type the appropriate AMIDiag batch parameter filename.

Chapter 3. Diagnostics 69

Generate Report

To generate a report of the diagnostic test and all errors found, complete the following steps:

1. From the main menu, select Options.

2. Select Generate Report to specify the output device: disk file or serial port.

Note: If a file is selected as an output device, you must ensure that a writeable

file system is available to write the report to from EFI.

The report generation parameters are as follows:

3. Select CONTINUE after setting report parameters, and press Enter.

can customize how the errors are logged and where the logs are saved using

You the choices in this menu. Yo u can define the destination for the output, log which tests are conducted, when the test is started, when the test completes, and whether the test will log only errors.

Toggle All Tests in Menu

Select this choice to display the list of test menus and to select a menu. When you select a menu, the tests for that menu display.

Toggle All Tests

Select Toggle all tests to select all tests.

Toggle All Quick Tests

Select Toggle all quick tests to select all quick tests. Quick tests are abbreviated versions of the complete test.

Run Selected Tests

Select this choice to run the tests that you have selected.

Toggle Hidden Test Display

Select this choice to display all hidden tests.

70 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Ethernet diagnostic tests

Ethernet diagnostic programs are stored on the Resource CD. To use this CD, complete the following steps:

1. Insert the CD into the DVD/CD-ROM drive, and restart the server.

2. Go to the EFI shell; then, change to the file system on the CD, and navigate to the x455 subdirectory on the CD.

3. Type enet_diag.nsh, and press Enter to run the program from the CD.

See the documentation on the Resource CD for more information about Ethernet diagnostic tests and error codes.

Diagnostic error code tables

For descriptions of the error codes that might appear when you run the AMIDiag program, see “Diagnostic error codes” on page 175.

Notes:

1. Depending on your server configuration, some of the error codes might not appear when you run the diagnostic programs.

2. If diagnostic error codes appear that are not listed in the tables, make sure that your server has the latest levels of SAL/EFI code, Remote Supervisor Adapter, and diagnostics microcode installed.

Small computer system interface (SCSI) messages

If you receive a SCSI error message, see “SCSI error messages” on page 205.

Note: If your server does not have a hard disk drive, ignore any message that

indicates that the SAL/EFI is not installed.

Recovering SAL/EFI code

If the SAL/EFI code has become damaged, such as from a power failure during a flash update, you can recover the SAL/EFI code using the SAL/EFI code page jumper (J28 on the I/O board) and the recovery program on the Resource CD that comes with the xSeries 455 server.

You can download the latest version of the SAL/EFI flash utility program from the World Wide Web. Go to http;//www.ibm.com/eserver/xseries/, click IBM Server Support, and make the selections for the server.

To perform a full recovery of the SAL/EFI code, complete the following steps.

Note: The server power must be on for the DVD/CD-RW drive to work.

1. Review the safety information beginning on page 215.

Attention: When you handle static-sensitive devices, take precautions to

avoid damage from static electricity. For details about handling these devices, see “Handling static-sensitive devices” on page 78.

Note: Yo u will not see anything displayed on the monitor when you perform

2. Insert the Resource CD into the DVD/CD-RW drive. You can write the SAL/EFI image to the root directory of the new CD.

3. Turn off the server and peripheral devices, and disconnect all external cables and power cords; then, open the cover (see “Opening the cover” on page 84).

this procedure.

Chapter 3. Diagnostics 71

4. Remove fans 3 and 4. For instructions, see “Replacing fan 3 or 4” on page

108.

5. Locate the SAL/EFI Boot Recovery jumper (J28) on the I/O board. This jumper is labeled ″Boot Recovery″ on the I/O board.

6. If there is a jumper on J28, move the jumper from pins 1 and 2 to pins 2 and 3

Jumper (J28)

to enable the SAL/EFI backup code page. If there is no jumper, add one to J28 pins 2 and 3.

7. Replace fans 3 and 4, and reconnect all external cables and power cords; then, turn on the peripheral devices.

8. Start up the server. The server will post normally through the memory detection/configuration. The video display will show the progress of the recovery and when the recovery is complete, you will be prompted to remove the jumper and reset the server.

9. If the green access LED on the DVD/CD-RW drive does not blink to indicate that the recovery flash image is being read within 2 minutes, try this process again using a different CD. If the LED fails to blink again, the SAL/EFI backup code page might be damaged, and you might need to replace the I/O board to correct the problem. See “I/O board, riser card, and Remote Supervisor Adapter” on page 141 for instructions.

10. Remove the Resource CD from the drive, and repeat steps 3 on page 71 through 6. Then, continue with step 11.

11. Move the jumper on J28 to pins 1 and 2 to return to normal startup mode.

12. Replace the fans, and close the cover (see “Closing the cover” on page 111).

13. Reconnect all external cables and power cords, and turn on the peripheral devices.

14. Turn on the server.

Note: Yo u might need to update the system firmware to the current level. For

72 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

instructions, see “Updating the firmware” on page 43.

Clearing a power-on password

This section applies to lost or forgotten passwords. For more information about lost or forgotten passwords, see “Using the Configuration/Setup Utility program” on page

12.

Complete the following steps to clear the power-on password:

1. Review the safety information beginning on page 215.

Attention: When you handle static-sensitive devices, take precautions to

avoid damage from static electricity. For details about handling these devices, see “Handling static-sensitive devices” on page 78.

2. Turn off the server and all attached devices.

3. Unplug the power cord, and disconnect all external cables.

4. Open the top cover (see “Opening the cover” on page 84).

5. Remove fans 3 and 4. For instructions, see “Replacing fan 3 or 4” on page

108.

6. Locate the clear password jumper (J20) on the I/O board. The following illustration shows the location of the jumper on the I/O board.

Clear password

7. Move the clear password jumper from pins 1 and 2 to pins 2 and 3.

8. Replace fans 3 and 4, and reconnect all external cables and power cords;

jumper (J20)

then, turn on the peripheral devices.

9. Turn on the server. The EFI Boot Manager program starts.

10. Follow the instructions to create a new password.

11. Repeat steps 1 through 5.

12. Return the clear password jumper to pins 1 and 2.

Note: The password will be cleared on every startup until the jumper is

replaced to pins 1 and 2.

13. Repeat steps 8 through 10.

14. Close the cover (see “Closing the cover” on page 111).

15. Connect the server to a power source, keyboard, monitor, and mouse.

16. Turn on the server.

Chapter 3. Diagnostics 73

Clearing CMOS

Complete the following steps to set the CMOS recovery jumper:

1. Review the safety information beginning on page 215.

Attention: When you handle static-sensitive devices, take precautions to

avoid damage from static electricity. For details about handling these devices, see “Handling static-sensitive devices” on page 78.

2. Turn off the server and all attached devices.

3. Unplug the power cord, and disconnect all external cables.

4. Open the top cover (see “Opening the cover” on page 84).

5. Remove fans 3 and 4. For instructions, see “Replacing fan 3 or 4” on page

108.

6. Locate the CMOS recovery jumper (J19) on the I/O board. The following illustration shows the location of the jumper on the I/O board.

Power checkout

CMOS recovery

7. Move the CMOS recovery jumper from pins 1 and 2 to pins 2 and 3.

8. Wait 60 seconds; then, return the CMOS recovery jumper to pins 1 and 2.

9. Replace fans 3 and 4.

jumper (J19)

10. Close the cover (see “Closing the cover” on page 111).

11. Connect the server to a power source, keyboard, monitor, and mouse.

12. Turn on the server. The EFI Boot Manager program starts.

13. Follow the instructions to erase the existing password or create a new password.

14. Select Save Settings, and press Enter.

Power problems can be difficult to solve. For example, a short circuit can exist anywhere on any of the power distribution buses. Usually a short circuit will cause the power subsystem to shut down because of an overcurrent condition.

Follow this general procedure for troubleshooting power problems:

1. Turn off the server, and disconnect all ac power cords.

2. Check for loose cables in the power subsystem. Also check for short circuits; for

example, a loose screw might be causing a short circuit on a circuit board.

74 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

3. Remove adapters and disconnect the cables and power connectors to all internal and external devices until the server is at the minimum configuration required to start the server (see the note about minimum operating requirements on page 200).

4. Reconnect all ac power cords, and turn on the server. If the server starts successfully, replace adapters and devices one at a time until the problem is isolated. If the server does not start up from the minimal configuration, replace FRUs of the minimal configuration one at a time until the problem is isolated.

To use this method, it is important to know the minimum configuration required for a system to start (see the minimum configuration requirements at “Undetermined problems” on page 205).

Troubleshooting the Ethernet controller

If a problem occurs with the 10/100/1000 Mbps Ethernet controller, use the Ethernet diagnostic program on the Resource CD to diagnose the problem. For more information about this CD, see “Ethernet diagnostic tests” on page 71. For information about the Ethernet error codes and actions to take, see the documentation on the Resource CD.

Network connection problems

If the Ethernet controller cannot connect to the network, check the following conditions:

v Make sure that the cable is installed correctly.

The network cable must be securely attached at all connections. If the cable is attached but the problem remains, try a different cable.

If you set the Ethernet controller to operate at either 100 Mbps or 1000 Mbps, you must use Category 5 or higher cabling.

v Determine whether the hub supports auto-negotiation. If it does not, try

configuring the integrated Ethernet controller manually to match the speed and duplex mode of the hub.

v Check the Ethernet controller LEDs on the rear of the server.

These LEDs indicate whether a problem exists with the connector, cable, or hub. – The Ethernet transmit/receive activity LED on the rear of the server is lit when

the Ethernet controller sends or receives data over the Ethernet network. If the Ethernet transmit/receive activity LED is off, make sure that the hub and network are operating and that the correct device drivers are installed.

– The Ethernet link status LED on the rear of the server is lit when the Ethernet

controller receives a LINK pulse from the hub. If the LED is off, there might be a defective connector or cable or a problem with the hub.

v Make sure that you are using the correct device drivers, which are supplied with

your server.

v Check for operating-system-specific causes for the problem. v Make sure that the device drivers on the client and server are using the same

protocol.

v Test the Ethernet controller.

The way the Ethernet controller is tested depends on which operating system you are using (see the Ethernet controller device driver README files).

Chapter 3. Diagnostics 75

Ethernet controller troubleshooting chart

Use the following troubleshooting chart to find solutions to 10/100/1000 Mbps Ethernet controller problems that have definite symptoms.

Ethernet controller problems FRU/actions

The server stops running when loading device drivers.

Ethernet link status LED does not work.

The Ethernet transmit/receive activity LED does not work.

Data is incorrect or sporadic. Check the following:

Check the following:

v Make sure that you are using the most recent device driver available from the

World Wide Web.

v Reseat or replace the adapter.

Check the following:

v Make sure that the hub is turned on. v Check all connections at the Ethernet controller and at the hub. v Use another port on the hub. v If the hub does not support auto-negotiation, manually configure the Ethernet

controller to match the hub.

v If you manually configured the Duplex mode, make sure that you also

manually configure the speed.

v Reseat or replace the adapter.

Check the following:

v Make sure that you have loaded the network device drivers. v The network might be idle. Try sending data from this server.

v Make sure that you are using Category 5 or higher cabling when operating the

server at 100 Mbps or at 1000 Mbps.

v Make sure that the cables do not run close to noise-inducing sources like

fluorescent lights.

Ethernet controller messages

The integrated Ethernet controller might display messages from certain device drivers. The latest information available concerning these messages will be made available at the IBM Support Web site at http://www.ibm.com/eserver/xseries.

76 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Chapter 4. Installing options

This chapter provides detailed instructions for installing hardware options in your server.

Installation guidelines

Before you begin to install options in your server, read the following information:

v Read the safety information beginning on page 215 and the guidelines in

“Handling static-sensitive devices” on page 78. This information will help you work safely with your server or options.

v Make sure that you have an adequate number of properly grounded electrical

outlets for your server, monitor, and any other devices that you will connect to the server.

v Back up all important data before you make changes to disk drives. v You do not need to turn off the server to install or replace hot-swap or hot-plug

components, or hot-plug Universal Serial Bus (USB) devices.

v The orange color on components and labels identifies hot-swap or hot-plug

components. You can install or remove hot-swap and hot-plug components while the server is running, provided that the server is configured to support this capability. See the instructions in this chapter for more information about removing and installing hot-swap and hot-plug components.

v For a list of supported options for your server, go to

http://www.ibm.com/pc/us/compat/.

Some preconfigured servers have a unique list of supported options. See the

Note:

software documentation provided with those servers for more information.

System reliability considerations

To help ensure proper cooling and system reliability, make sure that:

v The top cover is closed during normal operation. v Each of the drive bays has either a drive or a filler panel installed. v There is space around the server to allow the cooling system to work properly. v Cables for optional adapters are routed according to the instructions that are

provided with the adapters.

v All microprocessors have the same cache size and type and the same clock

speed.

v For proper cooling, do not leave the cover open for more than 15 minutes. v A failed fan is replaced within 48 hours. v The top cover is closed during normal operation. v Do not remove a defective power supply until a replacement is available. v For redundant and hot-swappable operation, the power supplies are connected to

200-240 V ac.

v If you replace a hot-swap drive, remove the defective drive and wait 15 seconds

before you install a new drive.

Working inside a server with power on

Your server supports hot-swap devices and is designed to operate safely while turned on with the cover removed. Follow these guidelines when you work inside a server that is turned on:

v Avoid loose-fitting clothing on your forearms. Button long-sleeved shirts before

working inside the server; do not wear cuff links while you are working inside the server.

v Do not allow your necktie or scarf to hang inside the server. v Remove jewelry, such as bracelets, rings, necklaces, and loose-fitting wrist

watches.

v Remove items from your shirt pocket (such as pens or pencils) that could fall into

the server as you lean over it.

v Avoid dropping any metallic objects, such as paper clips, hair pins, or screws,

into the server.

Handling static-sensitive devices

Attention: Static electricity can damage electronic devices and your system. To

avoid damage, keep static-sensitive devices in their static-protective package until you are ready to install them.

To reduce the possibility of electrostatic discharge, observe the following precautions:

v Limit your movement. Movement can cause static electricity to build up around

you.

v Handle the device carefully, holding it by its edges or its frame. v Do not touch solder joints, pins, or exposed printed circuitry. v Do not leave the device where others can handle and damage it. v While the device is still in its anti-static package, touch it to an unpainted metal

part of the system unit for at least 2 seconds. This drains static electricity from the package and from your body.

v Remove the device from its package, and install it directly into the system unit

without setting down the device. If it is necessary to set down the device, place it in to its static-protective package. Do not place the device on your system unit cover or on a metal surface.

v Take additional care when handling devices during cold weather. Heating reduces

indoor humidity and increases static electricity.

v Wear a properly grounded wrist strap against your skin to help eliminate static

electricity from your body.

78 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Major components of the xSeries 455 server

The orange color on components and labels in the server indicates hot-swap or hot-plug components. Yo u can install or remove these components while the server is running, provided that the server is configured to support hot-swap and hot-plug features.

The blue color on components and labels indicates touch points, where a component can be gripped, a latch moved, and so on.

The following illustration shows the location of major components in your server.

DIMM

DIMM access doors

Fan 1

O T

F O R

F R

O N

Fan 2

O P

E R A

O W, R

F B

O X

Fan 3

T E

P R

P E

F R

N T

F B

P L

E F

A N

I T

2 M

I R F

O W, R

T E

Fan 4

P L

C E

A N

H IN

2 M

U T

Microprocessor

Microprocessor baffle

Powe r module

VRM

E S

Retention bracket

Thumbscrews

EMC shield

Bezel

Hard disk

drive Hot-swap power supply

DVD-ROM drive

Chapter 4. Installing options 79

Midplane board LEDs

The following illustration shows the LEDs on the midplane board.

VRM error LED

Diagnostic display

I/O board error LED

Remote Supervisor Adapter error LED

PCI-X board error LED

Midplane board error LED

Processor board error LED

Memory board error LED

Processor board internal connectors and LEDs

The following illustrations show the internal connectors and LEDs on the processor board.

Microprocessor 3 socket

Microprocessor 1 socket

Microprocessor 3 power module socket

Microprocessor 3 power module cable connector

Microprocessor 1 power module socket

Microprocessor 1 power module cable connector

80 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Power-good LED

VRM error LED

Microprocessor 1 error LED

Reverse side

Microprocessor 4 power module socket

Microprocessor 4 power module cable connector

Microprocessor 3 error LED

Microprocessor 3 power module error LED

Microprocessor 1 power module error LED

Microprocessor 4 socket

Microprocessor 2 power module socket

Microprocessor 2 power module cable connector

Microprocessor 4 power module error LED

Microprocessor 2 power module error LED

Microprocessor 2 socket

Microprocessor 4 error LED

Microprocessor 2 error LED

Chapter 4. Installing options 81

PCI-X board internal connectors and LEDs

The following illustration shows the internal connectors and LEDs on the PCI-X board.

PCI-X slot 6 (133 MHz)

PCI-X slot 4 (100 )MHz

PCI-X slot 5 (133 )MHz

PCI-X slot 3 (100 )MHz

PCI-X slot 2 (66 )MHz

Attention LED Power LED

PCI-X slot 1 (66 )MHz

Memory board internal connectors and LEDs

The following illustration shows the internal connectors and LEDs on the memory board.

DIMM error LED (14 places)

DIMM slots

DIMM error LED (14 places)

82 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Memory switch card LEDs

The following illustration shows the LEDs on the memory switch card.

Port 1 power LED

I/O-board internal connectors

The following illustration shows the internal connectors on the I/O board.

SCSI B connector

Memory hot-plug

enabled LED

Port 2 power LED

Riser card connector

I/O VRM

Fan 4 connector

Fan 3 connector

Power/reset connector

SCSI A connector

Fans 1 and 2 connectors

USB cable connector

Media bays connector

Chapter 4. Installing options 83

Opening the cover

Complete the following steps to open the server cover:

1. Read the safety information beginning on page 215 and “Installation guidelines”

2. Slide the server out from the rack.

3. Pull the release latch on the left side of the top cover to the right.

4. Using the finger hole in the release latch, open the left side of the cover; then,

on page 77.

open the right side of the cover.

Latch

P E

IR F

O T

E :

A C

F O R

O P

N T

IT N T

W, R

T E

E P LA

E F

A N

H IN

2 M

U T

E S

Attention: For proper cooling and airflow, close the cover before turning on

the server. Operating the server for extended periods of time (over 15 minutes) with the cover open might damage server components.

84 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Removing and replacing the bezel

Complete the following steps to remove the bezel:

1. Press on the two tabs at the top edge of the bezel, and pull the top of the bezel slightly away from the server.

2. Press on the two tabs at the bottom edge of the bezel, and pull the bezel off the server. Store the bezel in a safe place.

NOTE: FOR PROPE

FRONT OF BOX

R AIRFLO

W, REPLACE FANWITHIN

P C

I B

a r

I /O

a r

b e

NOT

E: FO

R PR

PER AIR

FLO

W, R

EPLA

E FANWITHIN 2 MINUTES

FRONT OF BO

2 MINUTES

s t

a n

a g

e m

t B

r d

M id

n e

g h

-P a

t h

i a

g n

t ic

L o

e r

Complete the following steps to replace the bezel:

1. Align the four tabs on the bezel with the slots in the server chassis.

2. Press firmly against the front of the bezel until it snaps into place.

r d

s t

e m

a n

n t

r d

i d

e B

-P a

t h

i a

g n

o s

t ic

p p

r C

o w

r C

n F

b e

NOTE: FOR PROPER AIRFLOW, REPLACE FANWITHIN 2 MINUTES

FRONT OF BOX

I /O

Chapter 4. Installing options 85

Removing and replacing a hot-swap power supply

Your server comes with two hot-swap power supplies, which you can remove and replace without turning off the server. The following illustration shows the locations of the power supplies on the front of the server.

Power LEDs Power supply 1

Power supply 2

Power-on LED

Power-control button

Reset button

Power-supply latch

Handle

Before you remove or replace a power supply, review the following information.

Notes:

1. The power supplies are hot-swappable and redundant only at 200-240 V ac.

2. Both power supplies must be connected to the power source for operation at 100-127 V ac.

3. During normal operation, both power supplies must be installed for proper operation and cooling.

If you install or remove a power supply, observe the following precautions.

Statement 8:

CAUTION: Never remove the cover on a power supply or any part that has the following label attached.

Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician.

86 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Complete the following steps to remove and replace a power supply:

1. Read the safety information beginning on page 215 and “Installation guidelines” on page 77.

2. Remove the front bezel (see “Removing and replacing the bezel” on page 85 for instructions about removing the front bezel).

3. To remove the power supply from the server, press the latch; then, lift the handle on the power supply to the open position and pull the power supply out from the server.

4. Install the new power supply: a. Place the handle on the power supply in the open position. b. Slide the power supply into the chassis and press the handle to the closed

position.

Power supply

Power-supply latch

AC LED

DC LED

Power-supply handle (in open position)

5. Verify that the dc power LED and the ac power LED on the power supply are lit, indicating that the power supply is operating properly.

6. Replace the front bezel on the server (see “Removing and replacing the bezel” on page 85 for instructions).

Chapter 4. Installing options 87

Installing an adapter

The following notes describe the types of adapters that your server supports and other information that you must consider when installing an adapter:

v The following illustration shows the location and bus speeds of the PCI-X

expansion slots on the PCI-X board.

PCI-X slot 6 (133 MHz)

PCI-X slot 5 (133 )MHz

PCI-X slot 4 (100 )MHz

PCI-X slot 3 (100 )MHz

PCI-X slot 2 (66 )MHz

Attention LED Power LED

PCI-X slot 1 (66 )MHz

v Locate the documentation that comes with the adapter, and follow those

instructions in addition to the instructions in this section. If you need to change the switch settings or jumper settings on your adapter, follow the instructions that come with the adapter.

v Video adapters are not supported. v Some full-length adapters have extension handles or brackets installed. Before

installing the adapter, you must remove the extension handle or bracket.

v Your server supports six hot-plug 64-bit adapters in the expansion slots on the

PCI-X board. The PCI device mapping for the xSeries 455, including attached RXE-100s, is

shown in the following tables. Actual bus numbers are obtained by adding the bus number offset associated with each node to the bus number indicated in the device mapping table.

Table 7. Bus number offset table

Node Bus number offset

1 0x00 2 0x40 3 0x80 4 0xC0

88 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide

Table 8. Device mapping table

Bus Device Device number IDSEL

Via82C686B 5 AD21

0 (0x00)

Video 3 AD19 Service processor 4 AD20

1 (0x01)

A (0x02)

LS11030 SCSI RAID 3 AD19 Broadcom 5704 4 AD20 PCI slot 1 (66 MHz) 1 AD17 PCI slot 2 (66 MHz) 2 AD18

B (0x09) PCI slot 3 (100 MHz) 1 AD17

PCI slot 4 (100 MHz) 2 AD18 C (0x07) PCI slot 5 (133 MHz) 3 AD19 D (0x05) PCI slot 6 (133 MHz) 4 AD20

E (0x12)

F (0x0F)

G (0x0C)

H (0x1B)

I (0x18)

J (ox15)

RXE-100 PCI slot 1 (100 MHz*) 1 AD17

RXE-100 PCI slot 2 (100 MHz*) 2 AD18

RXE-100 PCI slot 3 (100 MHz*) 1 AD17

RXE-100 PCI slot 4 (100 MHz*) 2 AD18

RXE-100 PCI slot 5 (100 MHz*) 1 AD17

RXE-100 PCI slot 6 (100 MHz*) 2 AD18

RXE-100 PCI slot 7 (100 MHz*) 1 AD17

RXE-100 PCI slot 8 (100 MHz*) 2 AD18

RXE-100 PCI slot 9 (100 MHz*) 1 AD17

RXE-100 PCI slot 10 (100 MHz*) 2 AD18

RXE-100 PCI slot 11 (100 MHz*) 1 AD17

RXE-100 PCI slot 12 (100 MHz*) 2 AD18 * 133 MHz operation with only one adapter installed on this PCI bus at system power on.

v You can install both PCI and PCI-X adapters on the same bus. However, if you

install a PCI adapter and a PCI-X adapter on the same bus, the PCI-X features of the PCI-X adapter will be disabled, and the adapter will function as a PCI adapter.

v You can install PCI or PCI-X adapters of speeds faster than what is labeled for a

particular PCI-X bus. For example, if you install two 133 MHz adapters into slots that are labeled as 100 MHz slots, the adapters will operate at 100 MHz.

v If you install a 33 MHz and a 66 MHz adapter on the same bus, the bus speed

will match that of the slowest adapter.

v If a single 133 MHz adapter is installed on PCI-X bus B (slots 3 and 4) and the

other slot on PCI-X bus B is empty, the adapter will operate at 133 MHz.

v The server scans PCI-X slots in the following order: the xSeries 455 integrated

devices are scanned first; then, PCI-X slots 1, 2, 3, 4, 5, and 6. If an RXE-100 enclosure is attached to an xSeries 455 server, the scan order is as follows: the xSeries 455 integrated devices are scanned first; then, PCI-X slots 1, 2, 3, 4, 5, and 6; then, the RXE-100 slots 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, and 12.

v Your server supports 3.3 V and universal adapters; it does not support 5.0 V

adapters.

Chapter 4. Installing options 89

Complete the following steps to install an adapter:

1. Read the safety information beginning on page 215 and “Installation guidelines” on page 77.

Attention: When you handle static-sensitive devices, take precautions to

avoid damage from static electricity. For details about handling these devices, see “Handling static-sensitive devices” on page 78.

2. Disable the PCI-X slot through your operating system before you insert or remove a PCI or PCI-X adapter.

Note: Some operating systems do not support the enabling and disabling of a

PCI-X slot. If your operating system does not support this function, turn off the server and peripheral devices, and disconnect the power cords and all external devices from the back of the server before proceeding.

3. Open the top cover.

4. Follow the cabling instructions, if any, that come with the adapter. Route the adapter cables before you install the adapter.

5. Follow the instructions that come with the adapter to set jumpers or switches, if any.

6. Install the adapter:

Adapter guide

Ta b

PCI-X divider

Adapter retention latch

Attention LED

Power LED

NOTE:FO

R PR

OPER AIRFLOW, REPLACE FANW

NOTE:FOR PROPER AIRFLOW, REPLACE FANWITHIN 2 M

FRONT OF BOX

ITHIN 2 MINUTES

INUTES

a. If you are installing a full-length adapter, open the blue adapter guide by

lifting the front edge, as shown in the illustration.

b. Push the orange adapter-retention latch toward the rear of the server, and

open the tab.

c. Remove the expansion-slot cover.

90 IBM xSeries 455 Type 8855: Hardware Maintenance Manual and Troubleshooting Guide
