BladeCenter HS12

Type 8014 or 8028

Installation and User’s Guide

Welcome.

Thank you for buying an IBM blade server. server features superior performance, availability, and scalability.

This

Installation and User’s Guide

contains information for setting up, configuring, and using your blade server.

Your blade

Before you install the BladeCenter HS12 Type 8014 or 8028 blade server in a BladeCenter unit, complete the following procedures:

Install and configure the rack according to the documentation that came with the rack. Install the BladeCenter unit into the rack and configure it, according to the documentation that comes with the BladeCenter unit. Supply power to the BladeCenter unit.

Install the latest firmware in all BladeCenter components.

Before you install the blade server into the BladeCenter unit, install devices such as drives, memory modules, and processor or expansion cards in the blade server, if applicable. Install the blade server in the BladeCenter unit. See Chapter 3 for more information.

Configure the blade server. See Chapter 4 for more information.

Additionally, a service information label is attached to each BladeCenter unit and blade server. This label provides a graphical summary of many of the installation and service activities that are associated with each device.

For more information about your BladeCenter components and features, you can view the publications on the

Documentation

CD or download them from the IBM support Web site.

Go to

http://www.ibm.com/systems/support/.

Install the operating system. See Chapter 5 for more information.

Install additional applications according to the instructions that comes with the applications.

The blade server is now

ready to use. Be sure to

blade server on the

IBM support Web site.

Server Support

Is the server working

correctly?

Ye s

Check all cables for loose connections and verify that all optional devices you installed are on the ServerProven list at

http://www.ibm.com/servers/eserver/ serverproven/compat/us/.

Is the problem

solved?

Ye s

http://www.ibm.com/support/mysupport/.

View information about IBM Support Line at

http://www.ibm.com/services/sl/products/

or view support telephone numbers at

http://www.ibm.com/planetwide/.

See the troubleshooting information that comes with the server to determine the cause of the problem and the action to take.

Is the problem

solved?

Ye s

Update the firmware to the latest level. You can download firmware from

http://www.ibm.com/systems/ support/

Ye s

Is the problem

solved?

View support telephone numbers at

http://www.ibm.com/planetwide/.

Hardware

No Software

Hardware or

software problem?

BladeCenter HS12 Type 8014 or 8028

Installation and User's Guide



Note: Before using this information and the product it supports, read the general information in “Notices” on page 55 and the Warranty and Support Information document for your blade server type on the IBM Documentation CD.

Sixth edition (May 2010)

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

Contents

Safety ...............v

Safety statements ............vi

Chapter 1. Introduction ........1

Related documentation

Use this information to identify and locate related blade server documentation.

This Installation and User’s Guide contains general information about the blade server, including how to install supported optional devices and how to configure the blade server. The following documentation also comes with the blade server:

v Problem Determination and Service Guide

This document is in Portable Document Format (PDF) on the IBM Documentation CD. It contains information to help you solve problems yourself, and it contains information for service technicians.

v Safety Information

This document is in PDF on the IBM Documentation CD. It contains translated caution and danger statements. Each caution and danger statement that appears in the documentation has a number that you can use to locate the corresponding statement in your language in the Safety Information document.

v Warranty and Support Information

This document is in PDF on the IBM Documentation CD. It contains information about the terms of the warranty and getting service and assistance.

Depending on your BladeCenter product, additional documents might be included on the IBM Documentation CD. In addition to the documentation in this library, be sure to review the Planning and Installation Guide for your BladeCenter unit for information to help you prepare for system installation and configuration. To check for updated documentation and technical updates, complete the following steps.

Note: Changes are made periodically to the IBM Web site. The actual procedure might vary slightly from what is described in this document.

1. Go to http://www.ibm.com/systems/support/.

2. Under Product support, click BladeCenter.

3. Under Popular links, click Publications lookup.

4. From the Product family menu, select BladeCenter HS12 and click Continue.

The IBM Documentation CD

Use the IBM Documentation CD to access the blade server documentation in PDF format.

You can run the IBM Documentation CD on any personal computer that meets the hardware and software requirements.

The IBM Documentation CD contains documentation for your blade server in Portable Document Format (PDF) and includes the IBM Documentation Browser to help you find information quickly.

Chapter 1. Introduction 3

Hardware and software requirements

Use this information to determine the minimum hardware and software requirements for the blade server.

The IBM Documentation CD requires the following minimum hardware and software: v Microsoft

Windows®XP, Windows 2000, or Red Hat Enterprise Linux®5 Server

v 100 MHz microprocessor v 32 MB of RAM v Adobe

Acrobat Reader 3.0 (or later) or xpdf, which comes with Linux operating

systems

Using the Documentation Browser

Use these instructions to start the Documentation Browser.

Use the Documentation Browser to browse the contents of the CD, read brief descriptions of the documents, and view documents, using Adobe Acrobat Reader or xpdf. The Documentation Browser automatically detects the regional settings in use in your system and displays the documents in the language for that region (if available). If a document is not available in the language for that region, the English-language version is displayed.

Use one of the following procedures to start the Documentation Browser: v If Autostart is enabled, insert the CD into the CD drive. The Documentation

Browser starts automatically.

v If Autostart is disabled or is not enabled for all users, use one of the following

procedures: – If you are using a Windows operating system, insert the CD into the CD or

DVD drive and click Start → Run.IntheOpen field, type

e:\win32.bat

where e is the drive letter of the CD or DVD drive, and click OK.

– If you are using Red Hat Linux, insert the CD into the CD or DVD drive;

then, run the following command from the /mnt/cdrom directory:

sh runlinux.sh

Select your blade server from the Product menu. The Available Topics list displays all the documents for your blade server. Some documents might be in folders. A plus sign (+) indicates each folder or document that has additional documents under it. Click the plus sign to display the additional documents.

When you select a document, a description of the document is displayed under Topic Description. To select more than one document, press and hold the Ctrl key while you select the documents. Click View Book to view the selected document or documents in Acrobat Reader or xpdf. If you selected more than one document, all the selected documents are opened in Acrobat Reader or xpdf.

To search all the documents, type a word or word string in the Search field and click Search. The documents in which the word or word string appears are listed in order of the most occurrences. Click a document to view it, and press Crtl+F to use the Acrobat search function, or press Alt+F to use the xpdf search function within the document.

Click Help for detailed information about using the Documentation Browser.

4 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Notices and statements in this document

Use this information to understand the most common documentation notices and statements and how they are used.

The caution and danger statements in this document are also in the multilingual Safety Information document, which is on the IBM Documentation CD. Each statement is numbered for reference to the corresponding statement in the Safety Information document.

The following notices and statements are used in this document:

v Note: These notices provide important tips, guidance, or advice. v Important: These notices provide information or advice that might help you

avoid inconvenient or problem situations.

v Attention: These notices indicate possible damage to programs, devices, or data.

An attention notice is placed just before the instruction or situation in which damage might occur.

v Caution: These statements indicate situations that can be potentially hazardous

to you. A caution statement is placed just before the description of a potentially hazardous procedure step or situation.

v Danger: These statements indicate situations that can be potentially lethal or

extremely hazardous to you. A danger statement is placed just before the description of a potentially lethal or extremely hazardous procedure step or situation.

Features and specifications

Use this table to view specific information about the blade server, such as, blade server hardware features and the dimensions of the blade server.

Notes:

1. Power, cooling, removable-media drives, external ports, and advanced system management are provided by the BladeCenter unit.

2. The operating system in the blade server must provide USB support for the blade server to recognize and use the removable-media drives. The BladeCenter unit uses USB for internal communications with these devices.

The following table is a summary of the features and specifications of the blade server.

Chapter 1. Introduction 5

Table 1. Features and specifications

Microprocessor: Supports one Intel LGA-771 microprocessor

Note: Use the Configuration/Setup Utility program to determine the type and speed of the microprocessors in the blade server.

Memory:

v Dual-channel, dual inline memory

modules (DIMMs): 6 DIMM connectors

v Type: ECC double-data rate (DDR2

667) DRAM. Supports 512 MB, 1 GB, 2 GB, and 4 GB DIMMs with up to 24 GB of total memory on the system board

Drives: Support for a pair of one of the following storage drives:

v Hot-swap, small form factor (SFF)

Serial Attached SCSI (SAS) hard disk drives, and hot-swap solid state storage drives.

v Fixed SFF Serial Advanced

Technology Attachment (SATA) hard disk drives

v Fixed SFF SATA solid state storage

drives

Predictive Failure Analysis (PFA) alerts:

v Microprocessor v Memory v Hard disk drives

Electrical input: 12Vdc

Integrated functions:

v Expansion card interface v Local service processor: Baseboard

management controller (BMC) with Intelligent Platform Management Interface (IPMI) firmware

v ATI ES1000 video controller v LSI 1064E SAS controller (type

8028 and 1916)

v SATA controller (type 8014) v Concurrent keyboard/video/

mouse (cKVM) support when optional cKVM feature card is installed

v Light path diagnostics v RS-485 interface for

communication with the management module

v Automatic server restart (ASR) v USB 2.0 for communication with

the cKVM and removable media drives

v Serial over LAN (SOL) v Redundant buses for

communication with keyboard, mouse, and removable media drives

Environment:

v Air temperature:

– Blade server on: 10°C to 35°C

(50°F to 95°F). Altitude:0mto

914.4 m (0 ft to 3000 ft)

– Blade server on: 10°C to 32°C

(50°F to 89.6°F). Altitude: 914.4 m to 2133.6 m (3000 ft to 7000 ft)

– Blade server off: 10°C to 43°C

(50°F to 89.6°F). Altitude: 914.4 m to 2133.6 m (3000 ft to 7000 ft)

– Blade server shipping: -40°C to

60°C (-40°F to 140°F)

v Humidity:

– Blade server on: 8% to 80% – Blade server off: 8% to 80%

Size:

v Height: 24.5 cm (9.7 inches) v Depth: 44.6 cm (17.6 inches) v Width: 2.9 cm (1.14 inches) v Maximum weight: 4.8 kg (10 lb)

What your blade server offers

Your blade server offers features, such as, the Baseboard management controller, storage disk drive support, IBM microprocessor technology, integrated network support, I/O expansion, large system-memory capacity, Light path diagnostics, PCI Express, and power throttling.

v Baseboard management controller (BMC)

The baseboard management controller (BMC) is on the system board of the blade server. The BMC operates as the service processor for the blade server and performs several tasks, including the following:

– Provides RS-485 interfaces to the management module – Provides the following support:

- Intelligent Platform Management Interface (IPMI)

- Power control and advanced power management

- Reliability, availability, and serviceability (RAS) features

- Serial over LAN (SOL)

6 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Director, IBM Enterprise X-Architecture®,

v Hard disk drive support

The blade server supports up to two of any one of the following types of storage devices:

– 2.5-inch fixed SATA SFF solid state storage drives or SATA SFF hard disk

drives, up to 80 GB (8014 model)

– 2.5-inch hot-swap SAS SFF hard disk drives, RAID 0 and RAID 1 support, up

to 146 GB (8028 model)

– 2.5-inch hot-swap SAS SFF solid state storage drives, up to 146 GB (8028

model)

v IBM

Director

IBM Director is a workgroup-hardware-management tool that you can use to centrally manage servers. For more information, see the IBM

Director

documentation on the IBM®Director CD.

v IBM Enterprise X-Architecture

IBM Enterprise X-Architecture technology combines proven, innovative IBM designs to make your x86-processor-based blade server powerful, scalable, and reliable. For more information, see http://www.ibm.com/servers/eserver/ xseries/xarchitecture/enterprise/index.html.

v IBM ServerGuide Setup and Installation CD

The ServerGuide Setup and Installation CD that comes with the blade server provides programs to help you set up the blade server and install a Windows operating system. The ServerGuide program detects installed optional hardware devices and provides the correct configuration programs and device drivers. For more information about the ServerGuide Setup and Installation CD, see “Using the ServerGuide Setup and Installation CD” on page 39.

v Microprocessor technology

The blade server supports an Intel LGA-771 microprocessor. Depending on the model, the blade server comes with one of six specialty of Intel microprocessors. For more information about supported microprocessors and their part numbers, see the Problem Determination and Service Guide.

v Integrated network support

The blade server comes with one integrated Broadcom 5714S dual Gigabit Ethernet controller, which support connection to a 10 Mbps network through an Ethernet-compatible switch module in the BladeCenter unit. The controller supports Wake on LAN technology.

v I/O expansion

The blade server has connectors on the system board for optional expansion cards for adding more network communication capabilities to the blade server.

v Large system-memory capacity

The blade server system board supports up to 24 GB of system memory. The memory controller provides support for up to six industry-standard registered ECC DDR2 667 on Very Low Profile (VLP) form factor DIMMs installed on the system board. For the most current list of supported DIMMs, see the ServerProven

list at http://www.ibm.com/servers/eserver/serverproven/

compat/us/.

v Light path diagnostics

Light path diagnostics provides light-emitting diodes (LEDs) to help you diagnose problems. For more information, see the Problem Determination and Service Guide.

v PCI Express

Chapter 1. Introduction 7

PCI Express is a serial interface that is used for chip-to-chip interconnect and expansion adapter interconnect. With the blade expansion connector you can add optional I/O and storage devices.

v Power throttling

Each blade server is powered by two BladeCenter redundant power-supply modules. By enforcing a power policy known as power-domain oversubscription, the BladeCenter unit can share the power load between two power modules to ensure sufficient power for each device in the BladeCenter unit. This policy is enforced when the initial power is applied to the BladeCenter unit or when a blade server is inserted into the BladeCenter unit.

The following settings for this policy are available: – Redundant without performance impact – Redundant with performance impact – Nonredundant You can configure and monitor the power environment by using the

management module. For more information about configuring and using power throttling, see the management-module documentation or http:// www.ibm.com/systems/support/.

Reliability, availability, and serviceability features

Reliability, availability, and serviceability features help to ensure the integrity of the data that is stored in the blade server, the availability of the blade server when you need it, and the ease with which you can diagnose and correct problems.

Three of the most important features in server design are reliability, availability, and serviceability (RAS). These RAS features help to ensure the integrity of the data that is stored in the blade server, the availability of the blade server when you need it, and the ease with which you can diagnose and correct problems.

The blade server has the following RAS features:

v Advanced Configuration and Power Interface (ACPI) v Automatic BIOS recovery (ABR) v Automatic server restart (ASR) v Built-in monitoring for temperature, voltage, hard disk drives. v Customer support center 24 hours per day, 7 days a week.

v Customer-upgradeable basic input/output system (BIOS) code and diagnostics v Diagnostic support of Ethernet controllers v ECC protection on the L2 cache v Error codes and messages v Hot-swap SAS or solid state storage drives, fixed SATA or solid state storage

drives

v Light path diagnostics feature v Memory parity testing v Microprocessor built-in self-test (BIST) during power-on self-test (POST) v Microprocessor serial number access v PCI PMI 2.2 v PCI-X 1.0a v PCI Express 1.0a v POST v ROM resident diagnostics v Registered ECC DDR2 667 memory

1. Service availability will vary by country. Response time will vary depending on the number and nature of incoming calls.

8 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

IBM®Director

v Service processor that communicates with the management module to enable

remote blade server management

v System error logging v Wake on LAN capability v Wake on PCI (PME) capability v Wake on USB 2.0 capability

Use this information to understand how IBM®Director works with the blade server.

With IBM

Director, a network administrator can perform the following tasks:

v View the hardware configuration of remote systems, in detail v Monitor the usage and performance of critical components, such as

microprocessors, disks, and memory

v Centrally manage individual or large groups of IBM and non-IBM

x86-processor-based servers, desktop computers, workstations, and notebook computers on a variety of platforms

Director provides a comprehensive entry-level workgroup hardware

IBM manager. It includes the following key features:

v Advanced self-management capabilities for maximum system availability. v Multiple operating-system platform support, including Microsoft Small Business

Server, Microsoft Windows 2000 Server, Windows Server 2003, AIX

, i5/OS®, Red Hat Linux, SUSE Linux, and VMware. For a complete list of operating systems that support IBM Director, see the IBM Director Compatibility Document. This document is in Portable Document Format (PDF) at http://www.ibm.com/systems/management/director/resources/. It is updated every 6 to 8 weeks.

v Support for IBM and non-IBM servers, desktop computers, workstations, and

notebook computers.

v Support for systems-management industry standards. v Integration into leading workgroup and enterprise systems-management

environments.

v Ease of use, training, and setup.

Director also provides an extensible platform that supports advanced server

IBM tools that are designed to reduce the total cost of managing and supporting networked systems. By deploying IBM ownership costs through the following benefits:

v Reduced downtime v Increased productivity of IT personnel and users v Reduced service and support costs

For more information about IBM Director CD that comes with the server, the IBM®Director Information Center at http://publib.boulder.ibm.com/infocenter/eserver/v1r2/topic/diricinfo_all/ diricinfoparent.html and the IBM xSeries http://www.ibm.com/servers/eserver/xseries/systems_management/, which presents an overview of IBM Systems Management and IBM

Director, you can achieve reductions in

Director, see the documentation on the IBM

Systems Management Web page at

Director.

Chapter 1. Introduction 9

Major components of the blade server

Use this information to locate the major components on the blade server. The major components of the blade server include Field Replaceable Units (FRUs), Customer Replaceable Units (CRUs), and optional devices.

The following illustration shows the major components of the blade server.

Expansion card

S L L

S I N

A R

H E

Cover

Heat sink

Microprocessor

Concurrent KVM Card

DIMM

Storage drives

Bezel

10 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Chapter 2. Power, controls, and indicators

Use this information to view power features, turn on and turn off the blade server, and view the functions of the controls and indicators.

Blade server controls and LEDs

Use this information for details about the controls and LEDs on the blade server.

Note: The control panel door is shown in the closed position in the following illustration. To access the power-control button, you must open the control panel door.

Activity LED

Location LED

KVM select button

Information LED

Blade-error LED

Media-tray select button

Power-control button

Power-on LED

Keyboard/video/mouse (KVM) select button: Press this button to associate the shared BladeCenter unit keyboard port, video port, and mouse port with the blade server. The LED on this button flashes while the request is being processed and then is lit when the ownership of the keyboard, video, and mouse has been transferred to the blade server. It can take approximately 20 seconds to switch the keyboard, video, and mouse control to the blade server.

Using a keyboard that is directly attached to the management-module, you can press keyboard keys in the following sequence to switch KVM control between blade servers instead of using the KVM select button:

NumLock NumLock blade_server_number Enter blade_server_number is the two-digit number of the blade-server bay in which

the blade server is installed. A blade server that occupies more than one blade-server bay is identified by the lowest bay number that it occupies.

If there is no response when you press the KVM select button, you can use the management-module Web interface to determine whether local control has been disabled on the blade server. See http://www-03.ibm.com/systems/management/ for more information.

Notes:

1. The operating system in the blade server must provide USB support for the blade server to recognize and use the keyboard and mouse, even if the keyboard and mouse have PS/2-style connectors.

2. If you install a supported Microsoft Windows operating system on the blade server while it is not the current owner of the keyboard, video, and mouse, a delay of up to 1 minute occurs the first time that you switch the keyboard, video, and mouse to the blade server. All subsequent switching takes place in the normal KVM switching time frame (up to 20 seconds).

Activity LED: When this green LED is lit, it indicates that there is activity on the hard disk drive or network.

Location LED: The system administrator can remotely turn on this blue LED to aid in visually locating the blade server. When this LED is lit, the location LED on the BladeCenter unit is also lit. The location LED can be turned off through the management-module Web interface at or through IBM

Director Console. For more information about the management-module Web interface, see http://www-03.ibm.com/systems/management/. For more information about

Director, see the documentation on the IBM®Director CD that comes with

IBM the server, or visit the IBM®Director Information Center at http:// publib.boulder.ibm.com/infocenter/eserver/v1r2/topic/diricinfo_all/ diricinfoparent.html .

Information LED: When this amber LED is lit, it indicates that information about a system error in the blade server has been placed in the management-module event log. The information LED can be turned off through the management-module Web interface at or through IBM management-module Web interface, see http://www-03.ibm.com/systems/ management/. For more information about IBM

Director Console. For more information about the

Director, see the documentation on the IBM®Director CD that comes with the server, or visit the IBM®Director Information Center at http://publib.boulder.ibm.com/infocenter/eserver/v1r2/ topic/diricinfo_all/diricinfoparent.html .

Blade-error LED: When this amber LED is lit, it indicates that a system error has occurred in the blade server. The blade-error LED turns off only after the error is corrected.

Media-tray select button: Press this button to associate the shared BladeCenter unit media tray (removable-media drives) with the blade server. The LED on the button flashes while the request is being processed and then is lit when the ownership of the media tray has been transferred to the blade server. It can take approximately 20 seconds for the operating system in the blade server to recognize the media tray.

If there is no response when you press the media-tray select button, you can use the management-module Web interface to determine whether local control has been disabled on the blade server.

Note: The operating system in the blade server must provide USB support for the blade server to recognize and use the removable-media drives.

Power-control button: This button is behind the control panel door. Press this button to turn on or turn off the blade server.

12 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Note: The power-control button has effect only if local power control is enabled for the blade server. Local power control is enabled and disabled through the management-module Web interface.

Power-on LED: This green LED indicates the power status of the blade server in the following manner:

v Flashing rapidly: The service processor (BMC) on the blade server is

communicating with the management module.

v Flashing slowly: The blade server has power but is not turned on. v Lit continuously: The blade server has power and is turned on.

Turning on the blade server

Use this information to turn on the blade server.

After you connect the blade server to power through the BladeCenter unit, the blade server can start in any of the following ways:

v You can press the power-control button on the front of the blade server (behind

the control panel door, see “Blade server controls and LEDs” on page 11) to start the blade server.

Notes:

1. Wait until the power-on LED on the blade server flashes slowly before you press the power-control button. While the service processor in the management module is initializing, the power-on LED does not flash, and the power-control button on the blade server does not respond.

2. While the blade server is starting, the power-on LED on the front of the blade server is lit. See “Blade server controls and LEDs” on page 11 for the power-on LED states.

v If a power failure occurs, the BladeCenter unit and then the blade server can

start automatically when power is restored, if the blade server is configured through the management module to do so.

v You can turn on the blade server remotely by using the management module. v If the blade server is connected to power (the power-on LED is flashing slowly),

the operating system supports the Wake on LAN feature, and the Wake on LAN feature has not been disabled through the management module, the Wake on LAN feature can turn on the blade server.

Turning off the blade server

Use this information to turn off the blade server.

When you turn off the blade server, it is still connected to power through the BladeCenter unit. The blade server can respond to requests from the service processor, such as a remote request to turn on the blade server. To remove all power from the blade server, you must remove it from the BladeCenter unit. Shut down the operating system before you turn off the blade server. See the operating-system documentation for information about shutting down the operating system.

The blade server can be turned off in any of the following ways:

Chapter 2. Power, controls, and indicators 13

v You can press the power-control button on the blade server (behind the control

panel door; see “Blade server controls and LEDs” on page 11). This starts an orderly shutdown of the operating system, if this feature is supported by the operating system.

v If the operating system stops functioning, you can press and hold the

power-control button for more than 4 seconds to turn off the blade server.

v The management module can turn off the blade server through the

management-module Web interface. For additional information, see the IBM BladeCenter Management Module User’s Guide or go to http://www-03.ibm.com/ systems/management/ for more information.

Blade server connectors

Use this information to locate blade server system-board components and connectors for optional devices.

The following illustration shows the system-board components, including connectors for user-installable optional devices, in the blade server.

Concurrent KVM connector (J149)

Expansion unit connector (J132)

DIMM 1

DIMM 2

DIMM 3

DIMM 4

DIMM 5

DIMM 6

I/O expansion option connectors

Storage interface connector

Microprocessor

Storage drive 0 connector

Storage drive 1 connector

Control panel connector

14 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Chapter 3. Installing options

Use this information for instructions about installing optional hardware devices in the blade server. Some option-removal instructions are provided in case you have to remove one option to install another.

Installation guidelines

Use these guidelines before you install the blade server or optional devices.

Before you install optional devices, read the following information: v Before you begin, read “Safety” on page v and “Installation guidelines.” This

information will help you work safely.

v When you install your new blade server, take the opportunity to download and

apply the most recent firmware updates. This step will help to ensure that any known issues are addressed and that your blade server is ready to function at maximum levels of performance.

To download firmware updates for your blade server, complete the following steps.

Note: Changes are made periodically to the IBM Web site. The actual procedure might vary slightly from what is described in this document.

1. Go to http://www.ibm.com/systems/support/.

2. Under Product support, click BladeCenter.

3. Under Popular links, click Software and device drivers.

4. Click BladeCenter HS12 to display the matrix of downloadable files for the

blade server.

v Observe good housekeeping in the area where you are working. Place removed

covers and other parts in a safe place.

v Back up all important data before you make changes to disk drives. v Before you remove a blade server from the BladeCenter unit, you must shut

down the operating system and turn off the blade server. You do not have to shut down the BladeCenter unit itself.

v Blue on a component indicates touch points, where you can grip the component

to remove it from or install it in the blade server, open or close a latch, and so on.

v Orange on a component or an orange label on or near a component indicates

that the component can be hot-swapped, which means that if the server and operating system support hot-swap capability, you can remove or install the component while the server is running. (Orange can also indicate touch points on hot-swap components.) See the instructions for removing or installing a specific hot-swap component for any additional procedures that you might have to perform before you remove or install the component.

v For a list of supported optional devices for the blade server, see

http://www.ibm.com/servers/eserver/serverproven/compat/us/.

System reliability guidelines

Use this information to make sure that the blade server meets the proper cooling and reliability guidelines.

To help make sure that proper cooling and system reliability requirements are met, review the following guidelines:

v To ensure proper cooling, do not operate the BladeCenter unit without a blade

server, expansion unit, or blade filler installed in each blade-server bay. See the documentation for your BladeCenter unit for additional information

v The blade server battery must be operational. If the battery becomes defective,

replace it immediately. For instructions, see the Problem Determination and Service Guide.

Handling static-sensitive devices

Use this information to observe the static-sensitive device requirements.

Attention: Static electricity can damage the blade server and other electronic devices. To avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them.

To reduce the possibility of damage from electrostatic discharge, observe the following precautions:

v When you work on a BladeCenter unit that has an electrostatic discharge (ESD)

connector, use a wrist strap, especially when you handle modules, optional devices, or blade servers. To work correctly, the wrist strap must have a good contact at both ends (touching your skin at one end and firmly connected to the ESD connector on the front or back of the BladeCenter unit).

v Limit your movement. Movement can cause static electricity to build up around

you.

v Handle the device carefully, holding it by its edges or its frame. v Do not touch solder joints, pins, or exposed circuitry. v Do not leave the device where others can handle and damage it. v While the device is still in its static-protective package, touch it to an unpainted

metal part of the BladeCenter unit or any unpainted metal surface on any other grounded rack component in the rack in which you are installing the device for at least 2 seconds. This drains static electricity from the package and from your body.

v Remove the device from its package and install it directly into the blade server

without setting down the device. If it is necessary to set down the device, put it back into its static-protective package. Do not place the device on the blade server cover or on a metal surface.

v Take additional care when you handle devices during cold weather. Heating

reduces indoor humidity and increases static electricity.

Removing the blade server from the BladeCenter unit

Use these instructions to remove the blade server from the BladeCenter unit.

If you need an unpopulated I/O-module bay in your BladeCenter unit to install your new blade server, remove an existing blade server or filler module from the BladeCenter unit. The following illustration shows how to remove a blade server or filler module from a BladeCenter unit. The appearance of your BladeCenter unit might be different; see the documentation for your BladeCenter unit for additional information.

16 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Release handles (open)

Attention:

v To maintain proper system cooling, do not operate the BladeCenter unit without

a blade server, expansion unit, or filler module installed in each blade server bay.

v When you remove the blade server, note the blade-server bay number.

Reinstalling a blade server into a different blade server bay from the one it was removed from can have unintended consequences. Some configuration information and update options are established according to blade-server bay number; if you reinstall the blade server into a different bay, you might have to reconfigure the blade server.

To remove the blade server, complete the following steps:

1. If the blade server is operating, shut down the operating system; then, press the power-control button (behind the blade server control panel door) to turn off the blade server (see “Turning off the blade server” on page 13 for more information).

Attention: Wait at least 30 seconds, until the storage devices stop spinning, before you proceed to the next step.

2. Open the two release handles as shown in the illustration. The blade server moves out of the blade server bay approximately 0.6 cm (0.25 inch).

3. Pull the blade server out of the bay.

4. Place either a blade filler or another blade server in the blade server bay within

1 minute.

Opening the blade server cover

Use these instructions to open the blade server cover.

To open the blade server cover, complete the following steps.

Note:

1. The following illustration shows how to open the cover on the blade server.

2. The illustrations in this document might differ slightly from your hardware.

Chapter 3. Installing options 17

Blade server cover

Cover pins

Blade server cover release

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. If the blade server is installed in a BladeCenter unit, remove it (see “Removing the blade server from the BladeCenter unit” on page 16 for instructions).

3. If the blade server has an expansion unit in place of the cover, remove it (see “Removing an optional expansion unit”).

4. Carefully lay the blade server on a flat, static-protective surface, with the cover side up.

5. Press the blade server cover release on each side of the blade server or expansion unit and lift the cover open, as shown in the illustration.

6. Lay the cover flat, or lift it from the blade server and store for future use.

Statement 21

CAUTION: Hazardous energy is present when the blade server is connected to the power source. Always replace the blade cover before installing the blade server.

Removing an optional expansion unit

Use these instructions to remove the optional expansion unit from the blade server.

To remove the optional expansion unit, complete the following steps.

Note:

1. The following illustration shows how to remove an optional expansion unit from a blade server.

2. The illustrations in this document might differ slightly from your hardware.

18 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Expansion unit

Blade server cover release

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. If the blade server is installed in a BladeCenter unit, remove it (see “Removing the blade server from the BladeCenter unit” on page 16 for instructions).

3. Carefully lay the blade server on a flat, static-protective surface, with the cover side up.

4. Open the blade server cover, if one is installed (see “Opening the blade server cover” on page 17 for instructions).

5. Remove the expansion unit: a. Press the blade server cover release on each side of the blade server. b. Use the extraction device on the expansion unit, if one is present, to

disengage the expansion unit from the system board. These extraction devices can be of several types, including thumbscrews or levers.

c. Rotate the expansion unit open; then, lift the expansion unit from the blade

server.

6. If you are instructed to return the cover or an optional expansion unit, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing a fixed-storage drive

Use these instructions to install a fixed-storage drive, such as solid state storage drive or SATA storage drive, in the blade server.

Notes:

1. The following illustration shows how to install a fixed-storage drive in a blade server.

2. The illustrations in this document might differ slightly from your hardware.

3. You must have a SATA interface card installed to control the storage drives.

This interface card comes preinstalled in the blade server.

The blade server (machine type 8014) has two storage bays for installing fixed-storage drives, such as solid state storage drives or SATA storage drives. To install a fixed-storage drive, complete the following steps.

Chapter 3. Installing options 19

1. Before you begin, read “Safety” on page v and “Installation guidelines” on page 15.

2. If the blade server is installed in a BladeCenter unit, remove it (see “Removing the blade server from the BladeCenter unit” on page 16 for instructions).

3. Carefully lay the blade server on a flat, static-protective surface.

4. Open the blade server cover (see “Opening the blade server cover” on page 17

for instructions).

5. If an optional expansion unit is installed, remove it (see “Removing an optional expansion unit” on page 18).

6. Touch the static-protective package that contains the storage drive to any unpainted metal surface on the BladeCenter unit or any unpainted metal surface on any other grounded rack component; then, remove the storage drive from the package.

7. Open the storage drive release lever on the system board; then, put the drive into the storage bay and push it, from the rear edge of the drive, into the connector until the drive moves past the storage drive release lever and is firmly seated in the connector.

Attention: Do not press on the top of the drive. Pressing on the top might damage the drive.

8. Lock the storage drive into place by making sure that the storage drive release lever is secure.

If you have other devices to install or remove, do so now; otherwise, go to “Completing the installation” on page 30.

Installing a hot-swap storage drive

Use these instructions to install hot-swap storage devices, such as SAS storage drives, in the blade server.

Notes:

1. The following illustration shows how to install a hot-swap storage drive in a blade server.

2. The illustrations in this document might differ slightly from your hardware.

3. You must have a SAS interface card installed to control the storage drives. This

interface card comes preinstalled in the blade server.

The blade server (machine type 8028) has two storage bays for installing hot-swap storage devices, such as SAS storage drives. One storage drive might already be

20 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

installed in the blade server in storage bay 0. If the blade server is equipped with one storage drive, you can install an additional drive in storage bay 1. These two SAS hard disk drives support RAID 0 and RAID 1 (use to implement and manage a redundant array of independent disks (RAID) level-1 array). See “Configuring a SAS RAID array” on page 42 for information about SAS RAID configuration.

To install a hot-swap hard disk drive, complete the following steps.

Hot-swap storage bay 1

Hot-swap storage bay 0

Storage drive filler

Storage drive

Hot-swap storage drive

release handle

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. Identify the blade server storage bay (hot-swap storage bay 0 or hot-swap storage bay 1) in which the hard disk drive will be installed.

3. If a storage-bay filler is installed, remove it from the blade server by lifting the release levers and pulling it away from the blade server.

4. Touch the static-protective package that contains the hard disk drive to any unpainted metal surface on the BladeCenter unit or any unpainted metal surface on any other grounded rack component; then, remove the hard disk drive from the package.

5. Open the release lever on the hot-swap hard disk drive and slide the drive into the storage bay until it is firmly seated in the connector.

6. Lock the hard disk drive into place by closing the release lever.

If you have other devices to install or remove, do so now; otherwise, go to “Completing the installation” on page 30.

Installing a memory module

Use these instructions to install memory modules in the blade server.

The following notes describe the types of direct inline memory modules (DIMMs) that the blade server supports and other information that you must consider when you install DIMMs:

Note:

1. The following illustration shows the location of the DIMM connectors on the system board.

2. The illustrations in this document might differ slightly from your hardware.

v The system board has DIMM connectors. v The server supports two-way memory interleaving.

Chapter 3. Installing options 21

v The optional DIMMs that are available for the blade server are 512 MB, 1 GB, 2

GB, and 4 GB. Depending on the memory configuration that is set in the Configuration/Setup Utility program, the blade server can support a minimum of 1 GB and a maximum of 24 GB of system memory on the system board.

v When you install memory, you must install a pair of matched DIMMs. Some

blade server models come with one DIMM installed in DIMM slot 1. In this case, you must order and install a second matched DIMM in DIMM slot 2. Install the DIMMs in the order shown in the following table.

Table 2. DIMM configuration

Pair DIMM pairs and location

First DIMM 1 and DIMM 2 Second DIMM 3 and DIMM 4 Third DIMM 5 and DIMM 6

Table 3. DIMM Population Rule

DIMM 5 and DIMM6DIMM 3 and DIMM4DIMM 1 and DIMM

Configuration

1 X X Single rank 2 X Single rank Single rank 3 Single rank Single rank Single rank 4 X X Dual rank 5 X Dual rank Dual rank 6 Dual rank Dual rank Dual rank 7 X Dual rank Single rank 8 X Single rank Dual rank 9 Dual rank Single rank Single rank

10 Dual rank Dual rank Single rank

v All DIMMs in a pair or group must be the same size, speed, type, technology,

and physical design. You can use compatible DIMMs from different manufacturers.

v Install only ECC DDR2 667 DRAM with ECC DIMMs. For a current list of

supported DIMMs for the blade server, see http://www.ibm.com/servers/ eserver/serverproven/compat/us/.

v Installing or removing DIMMs changes the configuration information of the

blade server. After you install or remove a DIMM, you must change and save the new configuration information by using the Configuration/Setup Utility program. When you restart the blade server, a message indicates that the memory configuration has changed. Start the Configuration/Setup Utility program and select Save Settings (see “Configuration/Setup Utility menu” on page 36 for more information) to save changes.

To install a DIMM, complete the following steps:

1. Before you begin, read “Safety” on page v and “Installation guidelines” on page 15.

2. Read the documentation that comes with the DIMMs.

3. If the blade server is installed in a BladeCenter unit, remove it (see “Removing

the blade server from the BladeCenter unit” on page 16 for instructions).

22 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

4. Carefully lay the blade server on a flat, static-protective surface.

5. Open the blade server cover (see “Opening the blade server cover” on page 17

for instructions).

6. If an expansion unit is installed and you are installing DIMMs on the system board, remove the expansion unit (see “Removing an optional expansion unit” on page 18).

7. Locate the DIMM connectors. Determine the connector into which you will install the DIMM.

DIMM 1

DIMM 2

DIMM 3

DIMM 4

DIMM 5

DIMM 6

8. Touch the static-protective package that contains the DIMM to any unpainted

metal surface on the BladeCenter unit or any unpainted metal surface on any other grounded rack component in the rack in which you are installing the DIMM for at least 2 seconds; then, remove the DIMM from its package.

9. To install the DIMMs, repeat the following steps for each DIMM that you install:

DIMM

Retaining clip

a. Turn the DIMM so that the DIMM keys align correctly with the connector

on the system board. Attention: To avoid breaking the retaining clips or damaging the DIMM

connectors, handle the clips gently.

b. Make sure that the small tabs on the retaining clips are in the notches on

the DIMM. If there is a gap between the DIMM and the retaining clips, the DIMM has not been correctly installed. Press the DIMM firmly into the connector, and then press the retaining clips toward the DIMM until the

Chapter 3. Installing options 23

tabs are fully seated. When the DIMM is correctly installed, the retaining clips are parallel to the sides of the DIMM.

Important: If there is a gap between the DIMM and the retaining clips, the DIMM has not been correctly installed. In this case, open the retaining clips and remove the DIMM; then, reinsert the DIMM.

If you have other devices to install or remove, do so now; otherwise, go to “Completing the installation” on page 30.

Installing a concurrent KVM card

Use these instructions to install a concurrent KVM (CKVM) card in the blade server.

To install a cKVM card, complete the following steps.

Notes:

1. The following illustration shows the location and how to install a cKVM card in the system board.

2. The illustrations in this document might differ slightly from your hardware.

cKVM card

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. If the blade server is installed in a BladeCenter unit, remove it (see “Removing the blade server from the BladeCenter unit” on page 16 for instructions).

3. Carefully lay the blade server on a flat, static-protective surface.

4. Open the blade server cover (see “Opening the blade server cover” on page 17

for instructions).

24 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

5. If an optional expansion unit is installed, remove it (see “Removing an optional expansion unit” on page 18).

6. If an I/O expansion card or a high-speed expansion card is installed, remove it.

7. Touch the static-protective package that contains the cKVM card to any unpainted metal surface on the BladeCenter unit or any unpainted metal surface on any other grounded rack component; then, remove the card from the package.

8. Locate the cKVM connector and orient the cKVM card.

9. Slide the right side of the card (the side of the card that is away from the

cKVM connector) between the two tabs at the right side of the expansion card bracket; then, gently pivot the card into the connector.

Note: For device-driver and configuration information to complete the installation of the cKVM card, see the documentation that comes with the card.

10. If you removed a small-form-factor expansion card or a high-speed expansion card in step “Installing a concurrent KVM card” on page 24, reinstall it (see “I/O expansion cards”).

If you have other devices to install or remove, do so now; otherwise, go to “Completing the installation” on page 30.

I/O expansion cards

Use this information to install an I/O expansion card, such as a SAS connectivity card, in the blade server.

The illustrations show installation of the SAS connectivity card in the system board; installing the card in an expansion unit is similar.

The blade server supports various types of I/O expansion cards. See http://www.ibm.com/servers/eserver/serverproven/compat/us/ for a list of available I/O expansion cards and their form-factor types. The following notes describe information that you must consider when you install an I/O expansion card:

v The system board supports two I/O expansion cards. The supported cards are

the SAS connectivity card and the high-speed expansion card.

v If an expansion unit is installed, you cannot install a high-speed expansion card

in the blade server; however, some expansion units do support installation of additional I/O expansion cards. See the documentation for your expansion unit for information.

Make sure that the BladeCenter unit and the I/O modules to which the I/O expansion card is mapped support the network-interface type of the I/O expansion card. For example, if you add an Ethernet expansion card to a blade server in a Type 8677 BladeCenter unit, the I/O modules in I/O-module bays 3 and 4 on the BladeCenter unit must both be compatible with the expansion card. All other expansion cards that are installed in other blade servers in the BladeCenter unit must also be compatible with these I/O modules. In this example, you can then install two Ethernet switch modules, two pass-thru modules, or one Ethernet switch module and one pass-thru module. Because pass-thru modules are compatible with a variety of I/O expansion cards, installing two pass-thru

Chapter 3. Installing options 25

modules enables the use of several types of compatible I/O expansion cards in blade servers within the same BladeCenter unit.

Installing an I/O expansion card

Use these instructions to install an I/O expansion card, such as a SAS connectivity card, a high-speed expansion card, or an InfiniBand high-speed I/O expansion card, in the blade server.

The illustrations show installing a SAS connectivity card and a high-speed expansion card on the system board; installing the cards in an expansion unit is similar.

The blade server supports various types of I/O expansion cards. See http://www.ibm.com/servers/eserver/serverproven/compat/us/ for a list of available I/O expansion cards and their form-factor types.

Before you install the I/O expansion card in a blade server, consider the following BladeCenter expansion card, blade server, and other related device information:

v The appearance of your blade server or system boards might be different from

the illustrations in this document.

v Depending on the model of blade server in which the I/O expansion card is

being installed, the specific location of connectors and other components might be different from the illustrations in this document or your BladeCenter documentation.

The following illustration shows how to install an I/O expansion card.

To install the I/O expansion card in a blade server, complete the following steps.

26 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Expansion card

Expansion card connectors

PRESS

HERE

INSTALLING

WHEN

CARD

HEN

CARD

PRESSHERE W

INSTALLING

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. Turn off the blade server.

3. If the blade server is installed in a BladeCenter unit, remove it (see“Removing

the blade server from the BladeCenter unit” on page 16 for instructions).

4. Open the blade server cover. (see “Opening the blade server cover” on page 17 for instructions).

5. If an optional expansion unit is installed, remove it (see “Removing an optional expansion unit” on page 18).

6. If the system board in the blade server contains an I/O expansion card, such as a high-speed expansion card, remove the expansion card that is blocking access to these connectors.

7. If you have not already done so, touch the static-protective package that contains the I/O expansion card to any unpainted metal surface of the BladeCenter unit or any unpainted metal surface on any other grounded rack-component for at least 2 seconds.

8. Remove the I/O expansion card from its static-protective package.

9. Locate the three I/O expansion-card connectors on the system board in the

blade server. Note that two of these card connectors are identical.

10. Align the I/O expansion card over the system board in the blade server, so that the three connectors on the reverse side of the card are correctly aligned above the three matching expansion card connectors on the system board in the blade server.

ATTENTION: When you apply pressure to both sides of the expansion card to seat it in the blade server in step, press the card gently, so that you do not damage it.

11. To correctly seat the I/O expansion card in the blade server, press down

firmly on all four corners of the card. The two labels on the top ends of the card are blue touch points on the I/O expansion card. One of these labels contains the following statement: PRESS TO INSTALL. The I/O expansion card is automatically secured to the system board through the retention clip that is located on the reverse side of the card.

Chapter 3. Installing options 27

Note: The retention clip is permanently attached to the reverse side of the I/O expansion card. Do not attempt to remove the retention clip.

12. If you removed an expansion card that was blocking access to the three I/O expansion-card connectors on the blade-server system board, reinstall the expansion card.

13. Reinstall the cover on the blade server. For instructions, see the Installation and User’s Guide that comes with your blade server. Turn on the blade server, and

continue with your BladeCenter system activities.

Note: For device-driver and configuration information to complete the installation of the I/O expansion card, see the documentation that comes with the expansion card.

If you have other devices to install or remove, do so now; otherwise, go to “Completing the installation” on page 30.

Installing a high-speed expansion card

Use these instructions to install a high-speed expansion card in the blade server.

To install a high-speed expansion card, complete the following steps.

Note:

1. The following illustration shows the location and installation of a high-speed

expansion card, such as an InfiniBand high-speed expansion card, in the system board.

2. The illustrations in this document might differ slightly from your hardware.

Expansion card

Blade server expansion connector cover

Expansion card standoff

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. If the blade server is installed in a BladeCenter unit, remove it (see “Removing

the blade server from the BladeCenter unit” on page 16 for instructions).

3. Carefully lay the blade server on a flat, static-protective surface.

4. Open the blade server cover (see “Opening the blade server cover” on page 17

for instructions).

28 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

5. Locate the blade server expansion connector and remove the blade server expansion connector cover and set it aside.

6. Touch the static-protective package that contains the expansion card to any unpainted metal surface on the BladeCenter unit or any unpainted metal surface on any other grounded rack component; then, remove the expansion card from the package.

7. Orient the expansion card and slide the slots at the back end of the card onto the pins on the expansion-card standoff; then, gently pivot the card into the blade server expansion connector.

8. Firmly press on the indicated locations to seat the expansion card.

Note: For device-driver and configuration information to complete the installation of the expansion card, see the documentation that comes with the expansion card.

If you have other devices to install or remove, do so now; otherwise, go to “Completing the installation” on page 30.

Installing an optional expansion unit

Use these instructions to install an optional expansion unit.

The optional expansion units supported for this blade server are the PCI I/O expansion unit and the Storage and I/O expansion unit.

Attention: If a high-speed expansion card is installed on the blade server system board, you cannot install an optional expansion unit.

Notes:

1. The following illustration shows an optional expansion unit in a blade server.

2. The illustrations in this document might differ slightly from your hardware.

To install an optional expansion unit, complete the following steps.

Expansion unit

Blade server cover release

1. Before you begin, read “Safety” on page v and “Installation guidelines” on

page 15.

2. If the blade server is installed in a BladeCenter unit, remove it (see “Removing the blade server from the BladeCenter unit” on page 16 for instructions).

Chapter 3. Installing options 29

3. Remove the protective covers from the blade server expansion connectors, if any are present.

4. Touch the static-protective package that contains the optional expansion unit to any unpainted metal surface on the BladeCenter unit or any unpainted metal surface on any other grounded rack component; then, remove the optional expansion unit from the package.

5. Orient the optional expansion unit as shown in the illustration.

6. Lower the optional expansion unit so that the slots at the rear slide down onto

the cover pins at the rear of the blade server.

7. Close the optional expansion unit (see the expansion unit documentation for information and instructions):

v If the optional expansion unit has an extraction device, pivot the expansion

unit closed; then, use the extraction device to fully seat the expansion unit on the system board. These extraction devices can be of several types, including thumbscrews or levers.

v If the optional expansion unit has no extraction device, pivot the expansion

unit closed; then, press the expansion unit firmly into place until the blade server cover releases click.

The connectors on the expansion unit automatically align with and connect to the connectors in the system board.

If you have other expansion units to install, do so now; otherwise, go to “Completing the installation.”

Completing the installation

To complete the installation, complete the following tasks.

1. Reinstall the optional expansion unit, if you removed one to install other devices (see “Installing an optional expansion unit” on page 29 for information on installing the expansion unit).

2. Close the blade server cover, unless you installed an optional expansion unit that has its own cover (see “Closing the blade server cover” on page 31).

Statement 21

CAUTION: Hazardous energy is present when the blade server is connected to the power source. Always replace the blade server cover before installing the blade server.

3. Reinstall the blade server into the BladeCenter unit (see “Installing the blade server in a BladeCenter unit” on page 31).

4. Turn on the blade server (see “Turning on the blade server” on page 13).

5. For certain devices, run the blade server Configuration/Setup Utility program

(see Chapter 4, “Configuring the blade server,” on page 35).

Note: If you have just connected the power cords of the BladeCenter unit to electrical outlets, you must wait until the power-on LED on the blade server flashes slowly before you press the power-control button.

30 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Closing the blade server cover

Use these instructions for information about how to close the blade server cover.

Attention: You cannot insert the blade server into the BladeCenter unit until the cover is installed and closed or an expansion unit is installed. Do not attempt to override this protection.

To close the blade server cover, complete the following steps:

Blade server cover

Cover pins

1. Read the safety information that begins on page “Safety” on page v and

“Installation guidelines” on page 15.

2. Lower the cover so that the slots at the rear slide down onto the pins at the rear of the blade server, as shown in the illustration. Before you close the cover, make sure that all components are installed and seated correctly and that you have not left loose tools or parts inside the blade server.

3. Pivot the cover to the closed position, as shown in the illustration, until it clicks into place.

Installing the blade server in a BladeCenter unit

Use these instructions to install the blade server in a BladeCenter unit.

The following illustration shows how to install a blade server into a BladeCenter unit. The appearance of your BladeCenter unit might be different; see the documentation for your BladeCenter unit for additional information. To install a blade server in a BladeCenter unit, complete the following steps.

Chapter 3. Installing options 31

Release handles (open)

Statement 21

CAUTION: Hazardous energy is present when the blade server is connected to the power source. Always replace the blade cover before installing the blade server.

1. Before you begin, read “Safety” on page v and “Installation guidelines” on page 15.

2. If you have not done so already, install any optional devices that you want, such as hard disk drives, memory, or an InfiniBand high-speed expansion card, in the blade server.

3. Select the I/O-module bay for the blade server; at least one I/O-module bay is required.

Notes:

a. When any blade server or device is in any I/O-module bay 7 through 14,

power modules must be installed in all four power-module bays. For additional information, see the Installation and User’s Guide that comes with the BladeCenter unit.

b. To help ensure proper cooling, performance, and system reliability, make

sure that each I/O-module bay on the front of the BladeCenter unit contains a blade server, expansion unit, or blade filler. Do not operate a BladeCenter unit for more than 1 minute without a blade server, expansion unit, or blade filler in each I/O-module bay.

4. Make sure that the release handles on the blade server are in the open position (perpendicular to the blade server).

5. Slide the blade server into the I/O-module bay until it stops.

6. Push the release handles on the front of the blade server to the closed position.

7. Turn on the blade server (see “Turning on the blade server” on page 13 for

instructions).

8. Make sure that the power-on LED on the blade server control panel is lit continuously, indicating that the blade server is receiving power and is turned on.

9. If you have other blade servers to install, do so now.

32 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

If you reinstall a blade server that you removed, you must install it in the same blade server bay from which you removed it. Some blade server configuration information and update options are established according to blade server bay number. Reinstalling a blade server into a different blade server bay number from the one from which it was removed can have unintended consequences, and you might have to reconfigure the blade server.

If this is the initial installation of the blade server in the BladeCenter unit, you must configure the blade server through the Configuration/Setup Utility program and install the blade server operating system. See “Updating the blade server configuration” and Chapter 5, “Installing the operating system,” on page 45 for details. If you have changed the configuration of the blade server or if you are installing a different blade server from the one that you removed, you must configure the blade server through the Configuration/Setup Utility, and you might have to install the blade server operating system. For more information, see “Using the Configuration/Setup Utility program” on page 35.

Updating the blade server configuration

Use this information to update the blade server configuration.

When the blade server starts for the first time after you add or remove an internal device, you might receive a message that the configuration has changed. The Configuration/Setup Utility program automatically starts so that you can save the new configuration settings. See “Using the Configuration/Setup Utility program” on page 35 for more information about the Configuration/Setup Utility program.

Some options have device drivers that you must install. See the documentation that comes with each device for information about installing device drivers.

The blade server operates as a symmetric multiprocessing (SMP) server, regardless of how many microprocessors are installed. For optimum performance, you must upgrade the operating system to support SMP. See Chapter 5, “Installing the operating system,” on page 45 and your operating-system documentation for additional information.

Input/output connectors and devices

Use this information to locate the input/output connectors and devices.

See the documentation that comes with the BladeCenter unit for information about the input/output connectors.

The input/output connectors that are available to the blade server are supplied by the BladeCenter unit. The blade server has two selection buttons on the control panel: the media tray select button and the keyboard/video/mouse select button. See “Blade server controls and LEDs” on page 11 for information about these buttons and their functions.

The Ethernet controllers on the blade server communicate with the network through the Ethernet-compatible I/O modules in the BladeCenter unit. Network signals to and from the blade server or any expansion cards are automatically routed to a same-network-interface I/O module through circuitry in the BladeCenter unit.

Chapter 3. Installing options 33

34 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Chapter 4. Configuring the blade server

Use this information for details about the configuration requirements of the blade server.

Before you continue, make sure that the blade server has the latest version of firmware code. For additional information, see “Firmware updates” on page 41.

The following configuration programs come with the blade server:

v Configuration/Setup Utility program

The Configuration/Setup Utility program is part of the basic input/output system (BIOS). Use it to change system settings, such as interrupt requests (IRQ), date and time, and password. See “Using the Configuration/Setup Utility program” for more information.

v LSI Logic Configuration Utility program

The LSI Logic Configuration Utility program is part of the BIOS. Use it to set the device scan order and to set the storage drive controller IDs. See “Using the LSI Logic Configuration Utility program” on page 43 for more information.

v IBM ServerGuide Setup and Installation CD

The ServerGuide program provides software-setup tools and installation tools that are designed for the blade server. Use this CD during the installation of the blade server to configure basic hardware features and to simplify the installation of the operating system. For information about using this CD, see “Using the ServerGuide Setup and Installation CD” on page 39.

v Preboot Execution Environment (PXE) boot agent utility program

The PXE boot agent utility program is part of the BIOS. Use it to select the boot protocol and other boot options and to select a power-management option. For information about using this utility program, see “Using the PXE boot agent utility program” on page 41.

The IBM Remote Deployment Manager (RDM) Version 4.20 program is available for purchase. You can use IBM RDM Version 4.20 (or later) to install a BIOS code update onto a blade server by following the instructions in the documentation that comes with the RDM program. To determine whether an operating system supports the RDM program or for updated information about RDM and information about purchasing the software, go to http://www.ibm.com/systems/ management/.

Using the Configuration/Setup Utility program

Use these instructions to start the Configuration/Setup Utility program.

To start the Configuration/Setup Utility program, complete the following steps:

1. Turn on the blade server (see “Turning on the blade server” on page 13).

2. Immediately give the blade server control of the BladeCenter unit shared

keyboard, video, and mouse ports. v If you are managing the blade server by using the BladeCenter system

console, press the KVM select button on the blade server (see “Blade server controls and LEDs” on page 11 for information).

v If you are managing the blade server from a remote location, see the IBM

BladeCenter Management Module User’s Guide, IBM BladeCenter Management Module Command-Line Interface Reference Guide,orIBM BladeCenter Serial over LAN Setup Guide for information and instructions.

3. When the Configuration/Setup utility message is displayed, press F1.

4. Follow the instructions on the screen.

Configuration/Setup Utility menu

Use the Configuration/Setup Utility main menu to view and configure blade server configuration data and settings.

The following menu items are on the Configuration/Setup Utility main menu. Depending on the version of the BIOS, some menu items might differ slightly from these descriptions.

v System Summary

Select this menu item to view configuration information, including the type, speed, and cache sizes of the microprocessors and the amount of installed memory. When you make configuration changes through other choices in the Configuration/Setup Utility program, the changes are reflected in the system summary; you cannot change settings directly in the system summary.

– Processor Summary

Select this menu item to view information about the microprocessor in the blade server.

– USB Device Summary

Select this menu item to view information about the USB devices in the blade server.

v System Information

Select this menu item to view information about the blade server. When you make configuration changes through other options in the Configuration/Setup Utility program, some of those choices are reflected in the system information; you cannot change settings directly in the system information.

– Product Data

Select this menu item to view the machine type and model of the blade server, the serial number, and the revision level or issue date of the BIOS and diagnostics code that are stored in electrically erasable programmable ROM (EEPROM).

v Devices and I/O Ports

Select this menu item to view or change assignments for devices and input/output (I/O) ports.

You can also enable or disable the integrated SAS and Ethernet controllers, all standard ports (such as serial), and the I/O-expansion card. Enable is the default setting for all controllers. If you disable a device, it cannot be configured, and the operating system will not be able to detect it (this is equivalent to disconnecting the device). If you disable the Ethernet controller, the blade server will have no Ethernet capability.

– Remote Console Redirection

Select this menu item to enable Serial over LAN (SOL) and to set remote console communication parameters.

– Video

Select this menu item to view information about the integrated video controller.

36 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

– System MAC Addresses

Select this menu item to set and view the MAC addresses for the Ethernet controllers on the blade server.

Note: MAC addresses are displayed only for those devices with PXE enabled

v Date and Time

Select this menu item to set the system date and time, in 24-hour format (hour:minute:second).

v System Security

Select this menu item to set a power-on password. See “Using passwords” on page 38 for more information about passwords.

v Start Options

Select this menu item to view or change the start options. Changes in the start options take effect when you start the blade server.

– Startup Sequence Options

Select this menu item to view the startup device sequence that is set for the blade server.

You can set keyboard operating characteristics, such as whether the blade server starts with the keyboard number lock on or off. You can enable the blade server to run without a diskette drive or keyboard.

You can enable or disable the PXE option for all of the Ethernet controllers in the blade server. The default settings enable the PXE option for the two Ethernet controllers on the system board.

If you enable the boot fail count, the BIOS default settings will be restored after three consecutive failures to find a boot record.

You can enable a virus-detection test that checks for changes in the boot record when the blade server starts.

v Advanced Setup

Select this menu item to change settings for advanced hardware features. Important: The blade server might malfunction if these settings are incorrectly

configured. Follow the instructions on the screen carefully. – Memory Settings

Select this menu item to manually enable a pair of memory connectors. If a memory error is detected during POST or memory configuration, the

blade server automatically disables the failing pair of memory connectors and continues operating with reduced memory. After the problem is corrected, you must enable the memory connectors. Use the arrow keys to highlight the pair of memory connectors that you want to enable, and use the arrow keys to select Enable.

To maintain optimum system operation in the event of a memory failure, you can set memory configuration to mirroring or sparing. Memory mirroring stores duplicate data on two DIMMs to prevent data loss if a DIMM fails. Memory sparing removes the failed memory from the system configuration and activates a hot spare pair of DIMMs to replace the failed pair of DIMMs. Before you can enable memory mirroring or sparing, at least two pairs of DIMMs must be installed in the blade server that adhere to the special requirements that are described in “Installing a memory module” on page 21. Set Memory Configuration to Flat to disable memory mirroring and sparing.

– Microprocessor Options

Chapter 4. Configuring the blade server 37

Select this menu item to disable the microprocessor cache or to set the microprocessor cache to use the write-back or write-through method. Write-back caching generally provides better system performance.

You can also select this menu item to enable or disable hyper-threading and adjust microprocessor performance settings. If hyper-threading is enabled, it is active only if it is supported by your operating system.

– PCI Bus Control

Select this menu item to view and set interrupts for PCI devices and to configure the master-latency-timer value for the blade server.

– Baseboard Management Controller (BMC) Settings

You can select this menu item to enable or disable and set the timeouts for the POST and OS loader watchdog timers and view BMC version information.

- BMC Network Configuration Select this menu item to set the network addresses of the BMC.

- BMC System Event Log Select this menu item to view and clear BMC event log entries.

v Save Settings

Select this menu item to save the changes that you have made in the settings.

v Restore Settings

Select this menu item to cancel the changes that you have made in the settings and restore the previous settings.

v Load Default Settings

Select this menu item to cancel the changes that you have made in the settings and restore the factory settings.

v Exit Setup

Select this menu item to exit from the Configuration/Setup Utility program. If you have not saved the changes that you have made in the settings, you are asked whether you want to save the changes or exit without saving them.

Using passwords

Use this information to set, change, or delete a power-on password.

From the System Security choice, you can set, change, and delete a power-on password.

If you set a power-on password, you must type the power-on password to complete the system startup and to have access to the Configuration/Setup Utility menu.

You can use any combination of up to seven characters (A - Z,a-z,and0-9)for the password. Keep a record of your password in a secure place.

If you forget the power-on password, you can regain access to the blade server either by removing the blade server battery and then reinstalling it or by using the power-on password override switch (see the Problem Determination and Service Guide on the Documentation CD for instructions).

38 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Using the ServerGuide Setup and Installation CD

Use this information as an overview for using the ServerGuide Setup and Installation CD.

The ServerGuide Setup and Installation CD contains a setup and installation program that is designed for your blade server. The ServerGuide program detects the blade server model and optional hardware devices that are installed and uses that information during setup to configure the hardware. The ServerGuide program simplifies operating-system installations by providing updated device drivers and, in some cases, installing them automatically.

If a later version of the ServerGuide program is available, you can download a free image of the ServerGuide Setup and Installation CD, or purchase the CD from the fulfillment Web site at http://www.ibm.com/systems/management/serverguide/ sub.html. To download the free image, click IBM Service and Support Site.

Note: Changes are made periodically to the IBM Web site. The actual procedure might vary slightly from what is in this document.

The ServerGuide program performs the following tasks:

v An easy-to-use interface v Diskette-free setup and configuration programs that are based on detected

hardware

v Device drivers that are provided for the blade server model and detected

hardware

v Operating-system partition size and file-system type that are selectable during

setup

ServerGuide features

Use this information to determine the ServerGuide features.

Features and functions can vary slightly with different versions of the ServerGuide program. To learn more about the version that you have, start the ServerGuide Setup and Installation CD and view the online overview. Not all features are supported on all blade server models.

The ServerGuide program requires a supported IBM blade server that is associated with an enabled startable (bootable) CD drive. In addition to the ServerGuide Setup and Installation CD, you must have the operating-system CD to install the operating system.

The ServerGuide program has the following features:

v Sets system date and time v Detects installed optional hardware devices and provides updated device drivers

for most adapters and devices

v Provides diskette-free installation for supported Windows operating systems v Includes an online readme file with links to tips for the hardware and

operating-system installation

Setup and configuration overview

Use this information to setup and configure the blade server.

Chapter 4. Configuring the blade server 39

When you use the ServerGuide Setup and Installation CD, you do not need setup diskettes. You can use the CD to configure any supported IBM blade server model. The setup program provides a list of tasks that are required to set up the blade server.

Note: Features and functions can vary slightly with different versions of the ServerGuide program.

When you start the ServerGuide Setup and Installation CD, the program prompts you to complete the following tasks:

v Select your language. v Select your keyboard layout and country. v View the overview to learn about ServerGuide features. v View the readme file to review installation tips for your operating system and

adapter.

v Start the operating-system installation. You will need your operating-system CD.

Typical operating-system installation

Use this information for a typical ServerGuide operating-system installation.

Note: Features and functions can vary slightly with different versions of the ServerGuide program.

The ServerGuide program can reduce the time it takes to install an operating system. It provides the device drivers that are required for the hardware and for the operating system that you are installing. This section describes a typical ServerGuide operating-system installation.

1. After you have completed the setup process, the operating-system installation program starts. (You will need the operating-system CD to complete the installation.)

2. The ServerGuide program stores information about the blade server model, service processor, hard disk drive controllers, and network adapters. Then, the program checks the CD for newer device drivers. This information is stored and then passed to the operating-system installation program.

3. The ServerGuide program presents operating-system partition options that are based on the operating-system selection and the installed hard disk drives.

4. The ServerGuide program prompts you to insert the operating-system CD and restart the server. At this point, the installation program for the operating system takes control to complete the installation. The BladeCenter CD drive must be associated with the blade server before you perform this step.

Installing the operating system without using ServerGuide

Use these instructions to install the operating system on the blade server without using a ServerGuide.

If you have already configured the blade server hardware and you are not using the ServerGuide program to install the operating system, complete the following steps to download the latest operating-system installation instructions from the IBM Web site.

Note: Changes are made periodically to the IBM Web site. The actual procedure might vary slightly from what is described in this document.

40 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

1. Go to http://www.ibm.com/systems/support/.

2. Under Product support, click BladeCenter.

3. From the menu on the left side of the page, click BladeCenter support search.

4. From the Task menu, select Install.

5. From the Product family list, select BladeCenter HS12.

6. From the Operating system list, select your operating system and click Search

to display the available installation documents.

Using the PXE boot agent utility program

Use these instruction to start the PXE boot agent utility program.

Use the Preboot Execution Environment (PXE) boot agent utility program to select the boot protocol and other boot options and to select a power-management option.

Notes:

1. The blade server does not support Remote Program Load (RPL) selection for the boot protocol option.

2. Enabling PXE might reduce the number of optional expansion modules that your blade server can manage.

To start the PXE boot agent utility program, complete the following steps:

1. Turn on the server.

2. When the Broadcom NetXtreme Boot Agent vX.X.X prompt is displayed, press

Ctrl+S. You have 2 seconds (by default) to press Ctrl+S after the prompt is displayed.

If the PXE setup prompt is not displayed, use the Configuration/Setup Utility program to set the Enable Ethernet PXE/DHCP option.

3. Use the arrow keys or press Enter to select a choice from the menu.

4. Follow the instructions on the screen to change the settings of the selected

items; then, press Enter.

Firmware updates

Use this information to update the blade server to the latest levels of BIOS code and firmware updates.

IBM periodically makes BIOS code, service processor (BMC) firmware, and diagnostic firmware updates available for the blade server. Before you install the blade server in a BladeCenter unit, go to http://www.ibm.com/systems/support/ to download the latest firmware for the blade server. Install the updates, using the instructions that are included with the downloaded files.

Important: To avoid problems and to maintain system performance, always make sure that the BIOS code, service processor (BMC) firmware, and diagnostic firmware levels are consistent for all blade servers within the BladeCenter unit.

Configuring the Gigabit Ethernet controller

Use this information to locate the device drivers for the Gigabit Ethernet controller.

Chapter 4. Configuring the blade server 41

One Ethernet controller is integrated on the blade server system board. A controller provides a 1000 Mbps full-duplex interface for connecting to one of the Ethernet-compatible I/O modules in I/O-module bays 1 and 2, which enables simultaneous transmission and reception of data on the Ethernet local area network (LAN). The Ethernet controller on the system board is routed to a different I/O module in I/O-module bay 1 or bay 2. The routing from an Ethernet controller to an I/O-module bay varies according to the blade server type and the operating system that is installed.

You do not have to set any jumpers or configure the controller for the blade server operating system. However, you must install a device driver to enable the blade server operating system to address the Ethernet controller. For device drivers and information about configuring the Ethernet controller, see the Broadcom NetXtreme Gigabit Ethernet Software CD that comes with the blade server.

To find updated information about configuring the controller, complete the following steps.

Note: Changes are made periodically to the IBM Web site. The actual procedure might vary slightly from what is described in this document.

1. Go to http://www.ibm.com/systems/support/.

2. Under Product support, click BladeCenter.

3. Under Popular links, click Publications lookup.

4. From the Product family menu, select BladeCenter HS12, and click Continue.

Configuring a SAS RAID array

Use this information to configure a SAS RAID array.

Configuring a SAS RAID array applies only to a blade server (machine type 8028) in which two SAS storage drives are installed.

You can use two SAS storage drives in the blade server to implement and manage RAID level-0 (striping) or RAID level-1 (mirror) arrays in operating systems that are listed on the ServerProven list at http://www.ibm.com/servers/eserver/ serverproven/compat/us/. For the blade server, you must configure the SAS RAID by using the LSI Configuration Utility program.

If an optional expansion unit is installed, you can use it to control all of the SAS storage drives that are installed in the blade server. Enable this feature by using the Device and I/O Ports choice in Configuration/Setup Utility program (see “Configuration/Setup Utility menu” on page 36 for information and instructions).

Important: You must create the RAID array before you install the operating system on the blade server.

You can use the LSI Logic Configuration Utility program to configure the SAS storage drives and the SAS controller. To start the LSI Logic Configuration Utility, complete the following steps:

1. Turn on the blade server (make sure that the blade server is the owner of the keyboard, video, and mouse). See “Turning on the blade server” on page 13.

42 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

2. When the message Press Ctrl-C to start LSI Logic Configuration Utility is displayed, press F1. If an administrator password has been set, you must type the administrator password to access the full LSI Logic Configuration Utility menu.

3. Follow the instructions on the screen to modify the SAS storage drive and SAS controller settings.

Using the LSI Logic Configuration Utility program

Use these instructions to start the LSI Logic Configuration Utility program.

You can use the LSI Logic Configuration Utility program to perform the following tasks:

v Set the SAS device scan order v Set the SAS ID for the controller v Manage the SAS RAID configuration

To start the LSI Logic Configuration Utility program, complete the following steps:

1. Turn on the blade server, and make sure that the blade server is the owner of the keyboard, video, and mouse.

2. When the <<<Press Ctrl-C to start LSI Logic Configuration Utility>>> prompt is displayed, press Ctrl+C.

3. Use the arrow keys to select the controller from the list of adapters; then, press Enter.

4. Follow the instructions on the screen to change the settings of the selected items; then, press Enter. If you select SAS Topology or Advanced Adapter Properties, additional screens are displayed.

Chapter 4. Configuring the blade server 43

44 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Chapter 5. Installing the operating system

Use these instructions to install the operating system on the blade server.

To install the operating system on a blade server, you can use any of the following methods:

v Use the ServerGuide Setup and Installation CD to install a supported Microsoft

Windows operating system.

v Use Remote Deployment Manager (RDM) Version 4.20 (or later) to install a

supported operating system. To determine whether RDM supports an operating system, see http://www.ibm.com/systems/management/.

v Download the latest operating-system installation instructions and install the

operating system.

Important: The operating system in the blade server must provide USB support for the blade server to recognize and use the keyboard, mouse, and removable-media drives. The BladeCenter unit uses USB for internal communication with these devices.

Using the ServerGuide Setup and Installation CD to install the operating system

Use these instructions for using the ServerGuide Setup and Installation CD to install the blade server operating system.

To use the ServerGuide Setup and Installation CD, complete the following steps:

1. While the blade server is on, press the KVM select button on the front of the blade server to associate the BladeCenter unit CD drive with the blade server.

2. Insert the CD, and restart the blade server. If the CD does not start, see “ServerGuide problems” on page 49.

3. Follow the instructions on the screen to complete the following tasks: a. Select your language. b. Select your keyboard layout and country. c. View the overview to learn about ServerGuide features. d. View the readme file to review installation tips about your operating system

and adapter.

e. Start the setup and hardware configuration programs. f. Start the operating-system installation. You will need your operating-system

CD.

Using RDM to install the operating system

Use this information if you are using RDM to install the blade server operating system.

You can use RDM to install a supported operating system on a blade server.

Follow the instructions in the documentation that comes with RDM to install a supported operating system.

Note: To determine whether an RDM supports an operating system, see http://www.ibm.com/systems/management/.

Downloading installation instructions

Use these instructions to download the operating-system installation instructions.

To download operating-system installation instructions, complete the following steps.

Note: Changes are made periodically to the IBM Web site. The actual procedure might vary slightly from what is described in this document.

1. Go to http://www.ibm.com/systems/support/.

2. Under Product support, click BladeCenter.

3. From the menu on the left side of the page, click BladeCenter support search.

4. From the Task menu, select Install.

5. From the Product family list, select BladeCenter HS12.

6. From the Operating system list, select your operating system and click Search

to display the available installation documents.

46 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Chapter 6. Solving problems

Use these instructions to resolve any problems you may encounter while installing the blade server.

If you install the blade server in the BladeCenter unit and the blade server does not start, perform the following actions:

v Make sure that the BladeCenter unit is correctly connected to a power source. v Reseat the blade server in the BladeCenter unit (see “Installing the blade server

in a BladeCenter unit” on page 31).

v If the power-on LED is flashing slowly, turn on the blade server (see “Turning

on the blade server” on page 13).

v If you have just added a new optional device or component, make sure that it is

correctly installed and compatible with the blade server and its components. If the device or component is not compatible, remove it from the blade server, reinstall the blade server in the BladeCenter unit, and then restart the blade server.

If the blade server does not start after you have performed the preceding actions, see the Problem Determination and Service Guide for your blade server on the IBM Documentation CD.

Diagnostic tools overview

Use this overview to locate specific diagnostic tools to diagnose and solve hardware-related problems.

The following tools are available to help you diagnose and solve hardware-related problems:

v POST beep codes

The power-on self-test beep codes can indicate the detection of a problem. – One beep indicates successful completion of POST – Repeating long beeps indicate a memory error. Make sure that all DIMMs are

correctly installed. For more information, see “Installing a memory module” on page 21.

– See the Problem Determination and Service Guide for more information about

beep codes.

v POST error codes

See the Problem Determination and Service Guide for more information.

The POST error codes table in “ServerGuide problems” on page 49 lists problem symptoms and steps to correct the problems.

For more information about POST error problem symptoms and steps to correct the problems, see the Problem Determination and Service Guide for your blade server.

v Troubleshooting tables

Use the troubleshooting tables to find solutions to problems that have identifiable symptoms. For more information about troubleshooting tables, see the Problem Determination and Service Guide for your blade server.

v Diagnostic programs and error messages

Real Time Diagnostics tests the major components of the BladeCenter unit, including the management modules, I/O modules, removable-media drives, and the blade servers, while the operating system is running. Real Time Diagnostics can be plugged into an existing IBM Director environment or installed without IBM Director present. For documentation and download information for Real Time Diagnostics, see http://www.ibm.com/systems/management/. For more information about diagnostic programs and error messages, see the Problem Determination and Service Guide for your blade server.

The IBM Dynamic System Analysis (DSA) diagnostic programs are the primary method of testing the major components of the blade server. The diagnostic programs are available in the preboot environment by pressing F2 during the boot process. The Preboot DSA diagnostic programs are stored in integrated USB memory and collect and analyze system information to aid in diagnosing blade server problems. The diagnostic programs collect the following information about the blade server:

– System configuration – Network interfaces and settings – Installed hardware – Light path diagnostics status – Vital product data, firmware, and BIOS configuration – Storage drive health – Baseboard Management Controller logs The diagnostic programs create a merged log that includes events from all

collected logs. The information is collected into a file that you can send to the IBM Support Center. Additionally, you can view the blade server information locally through a generated text report file. You can also copy the log to removable media and view the log from a Web browser.

Note: If you are unable to find the system-error logs in the blade server firmware code, view the system-event log in the BladeCenter management module.

v Light path diagnostics

Use light path diagnostics LEDs on the system board to diagnose system errors. If the system-error LED on the system LED panel on the front or rear of the BladeCenter unit is lit, one or more error LEDs on the BladeCenter unit components also might be lit. These LEDs help identify the cause of the problem. Blade server error LEDs are described in the Problem Determination and Service Guide for your blade server.

48 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

ServerGuide problems

Use this information to locate ServerGuide problems and suggested actions.

The following table lists problem symptoms and suggested solutions.

Symptom Suggested action

The ServerGuide Setup and Installation CD will not start.

The RAID configuration program cannot view all installed drives, or the operating system cannot be installed.

The operating-system installation program continuously loops.

The ServerGuide program will not start the operating-system CD.

The operating system cannot be installed; the option is not available.

v Make sure that the CD drive is associated with the blade server that you are

configuring.

v Make sure that the blade server supports the ServerGuide program and has a

bootable CD (or DVD) drive.

v If the startup (boot) sequence settings have been changed, make sure that the

CD drive is first in the startup sequence.

v Make sure that there are no duplicate SCSI/SAS IDs or interrupt request (IRQ)

assignments. See “Configuring a SAS RAID array” on page 42.

v Make sure that the storage drive is connected correctly. See “Blade server

connectors” on page 14 to locate the storage drive connector.

Make more space available on the hard disk.

Make sure that the operating-system CD is supported by the ServerGuide program. See the ServerGuide Setup and Installation CD label for a list of supported operating-system versions.

Make sure that the operating system is supported on the blade server. If the operating system is supported, either no logical drive is defined (SCSI/SAS RAID systems) or the ServerGuide System Partition is not present. Run the ServerGuide program and make sure that setup is complete.

Chapter 6. Solving problems 49

50 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Appendix. Getting help and technical assistance

If you need help, service, or technical assistance or just want more information about IBM products, you will find a wide variety of sources available from IBM to assist you.

Use this information to obtain additional information about IBM and IBM products, determine what to do if you experience a problem with your BladeCenter product or optional device, and determine whom to call for service, if it is necessary.

Before you call

Before you call, make sure that you have taken these steps to try to solve the problem yourself.

If you believe that you require IBM to perform warranty service on your IBM product, the IBM service technicians will be able to assist you more efficiently if you prepare before you call.

v Check for updated BIOS, firmware, or operating system device drivers for your

system. The IBM Warranty terms and conditions state that you, the owner of the IBM product, are responsible for maintaining and updating all software and firmware for the product (unless it is covered by an additional maintenance contract). Your IBM service technician will request that you upgrade your software and firmware if the problem has a documented solution within a software upgrade.

You can obtain the latest downloads for your system from http:// www.ibm.com/systems/support/supportsite.wss/docdisplay?brandind=5000008 &lndocid=MIGR-63017 .

v If you have installed new hardware or software in your environment, check

http://www.ibm.com/servers/eserver/serverproven/compat/us/eserver.html to make sure that the hardware and software is supported by your BladeCenter product.

v Use the troubleshooting information in your system documentation, and use the

diagnostic tools that come with your system. Information about diagnostic tools is in the Problem Determination and Service Guide on the IBM Documentation CD that comes with your system.

v Go to http://www.ibm.com/systems/support/ to check for information to help

you solve the problem.

v Gather the following information to provide to IBM service. This data will help

IBM service quickly provide a solution to your problem and ensure that you receive the level of service for which you might have contracted.

– Hardware and Software Maintenance agreement contract numbers, if

applicable – Machine type number (IBM 4-digit machine identifier) – Model number – Serial number – Current system BIOS and firmware levels – Other pertinent information such as error messages and logs

v Submit an Electronic Service Request.

1. Go to http://www.ibm.com/systems/support/.

2. Under Support & downloads, click Open service request.

3. Follow the prompts.

Submitting an Electronic Service Request will start the process of determining a solution to your problem by making the pertinent information available to IBM service quickly and efficiently. IBM service technicians can start working on your solution as soon as you have completed and submitted an Electronic Service Request.

Using the documentation

Information about your IBM BladeCenter system and preinstalled software, if any, or optional device is available in the documentation that comes with the product. That documentation can include printed documents, online documents, readme files, and help files.

See the troubleshooting information in your system documentation for instructions for using the diagnostic programs. The troubleshooting information or the diagnostic programs might tell you that you need additional or updated device drivers or other software. IBM maintains pages on the World Wide Web where you can get the latest technical information and download device drivers and updates. To access these pages, go to http://www.ibm.com/systems/support/.

You can find the most up-to-date product information for the IBM BladeCenter HS12 Type 8014, 8028 and 1916 in http://publib.boulder.ibm.com/infocenter/ bladectr/documentation/index.jsp.

Getting help and information from the World Wide Web

On the World Wide Web, the IBM website has up-to-date information about IBM BladeCenter systems, optional devices, services, and support at http://www.ibm.com/systems/bladecenter. For service information, click Support.

You can find the most up-to-date product information for the IBM BladeCenter HS12 Type 8014, 8028 and 1916 in http://publib.boulder.ibm.com/infocenter/ bladectr/documentation/index.jsp.

Software service and support

Through IBM Support Line, you can get telephone assistance, for a fee, with usage, configuration, and software problems with BladeCenter products.

For information about which products are supported by Support Line in your country or region, see http://publib.boulder.ibm.com/infocenter/bladectr/ documentation/index.jsp.

For more information about Support Line and other IBM services, see http://www.ibm.com/services/us/index.wss or see http://www.ibm.com/ planetwide/ for support telephone numbers. In the U.S. and Canada, call 1-800-IBM-SERV (1-800-426-7378).

52 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Hardware service and support

You can receive hardware service through your IBM reseller or IBM Services.

To locate a reseller authorized by IBM to provide warranty service, go to http://www.ibm.com/partnerworld/ and click Find Business Partners on the right side of the page. For IBM support telephone numbers, see http://www.ibm.com/planetwide/. In the U.S. and Canada, call 1-800-IBM-SERV (1-800-426-7378).

In the U.S. and Canada, hardware service and support is available 24 hours a day, 7 days a week. In the U.K., these services are available Monday through Friday, from 9 a.m. to 6 p.m.

IBM Taiwan product service

Use this information to contact IBM Taiwan product service.

IBM Taiwan product service contact information:

v IBM Taiwan Corporation v 3F, No 7, Song Ren Rd. v Taipei, Taiwan v Telephone: 0800-016-888

Appendix. Getting help and technical assistance 53

54 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Notices

This information was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in other countries. Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead. However, it is the user's responsibility to evaluate and verify the operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter described in this document. The furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing IBM Corporation North Castle Drive Armonk, NY 10504-1785 U.S.A.

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time without notice.

Any references in this information to non-IBM websites are provided for convenience only and do not in any manner serve as an endorsement of those websites. The materials at those websites are not part of the materials for this IBM product, and use of those websites is at your own risk.

IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.

Trademarks

IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corporation in the United States, other countries, or both. If these and other IBM trademarked terms are marked on their first occurrence in this information with a trademark symbol ( indicate U.S. registered or common law trademarks owned by IBM at the time this information was published. Such trademarks may also be registered or common law trademarks in other countries.

®or™

), these symbols

A current list of IBM trademarks is available on the web at “Copyright and trademark information” at http://www.ibm.com/legal/copytrade.shtml.

Adobe and PostScript are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Cell Broadband Engine is a trademark of Sony Computer Entertainment, Inc., in the United States, other countries, or both and is used under license therefrom.

Intel, Intel Xeon, Itanium, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Java and all Java-based trademarks are trademarks of Sun Microsystems, Inc., in the United States, other countries, or both.

Linux is a registered trademark of Linus Torvalds in the United States, other countries, or both.

Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in the United States, other countries, or both.

UNIX is a registered trademark of The Open Group in the United States and other countries.

Other company, product, or service names may be trademarks or service marks of others.

Important notes

Processor speed indicates the internal clock speed of the microprocessor; other factors also affect application performance.

CD or DVD drive speed is the variable read rate. Actual speeds vary and are often less than the possible maximum.

When referring to processor storage, real and virtual storage, or channel volume, KB stands for 1024 bytes, MB stands for 1,048,576 bytes, and GB stands for 1,073,741,824 bytes.

When referring to hard disk drive capacity or communications volume, MB stands for 1,000,000 bytes, and GB stands for 1,000,000,000 bytes. Total user-accessible capacity can vary depending on operating environments.

Maximum internal hard disk drive capacities assume the replacement of any standard hard disk drives and population of all hard disk drive bays with the largest currently supported drives that are available from IBM.

Maximum memory might require replacement of the standard memory with an optional memory module.

IBM makes no representation or warranties regarding non-IBM products and services that are ServerProven, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. These products are offered and warranted solely by third parties.

56 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM.

Some software might differ from its retail version (if available) and might not include user manuals or all program functionality.

Particulate contamination

Attention: Airborne particulates (including metal flakes or particles) and reactive gases acting alone or in combination with other environmental factors such as humidity or temperature might pose a risk to the device that is described in this document.

Risks that are posed by the presence of excessive particulate levels or concentrations of harmful gases include damage that might cause the device to malfunction or cease functioning altogether. This specification sets forth limits for particulates and gases that are intended to avoid such damage. The limits must not be viewed or used as definitive limits, because numerous other factors, such as temperature or moisture content of the air, can influence the impact of particulates or environmental corrosives and gaseous contaminant transfer. In the absence of specific limits that are set forth in this document, you must implement practices that maintain particulate and gas levels that are consistent with the protection of human health and safety. If IBM determines that the levels of particulates or gases in your environment have caused damage to the device, IBM may condition provision of repair or replacement of devices or parts on implementation of appropriate remedial measures to mitigate such environmental contamination. Implementation of such remedial measures is a customer responsibility.

Table 4. Limits for particulates and gases

Contaminant Limits

Particulate

Gaseous

1 ASHRAE 52.2-2008 - Method of Testing General Ventilation Air-Cleaning Devices for Removal Efficiency by Particle Size. Atlanta: American Society of Heating, Refrigerating and Air-Conditioning Engineers, Inc.

2 The deliquescent relative humidity of particulate contamination is the relative humidity at which the dust absorbs enough water to become wet and promote ionic conduction.

3 ANSI/ISA-71.04-1985. Environmental conditions for process measurement and control systems: Airborne contaminants. Instrument Society of America, Research Triangle Park, North Carolina, U.S.A.

v The room air must be continuously filtered with 40% atmospheric

dust spot efficiency (MERV 9) according to ASHRAE Standard 52.21.

v Air that enters a data center must be filtered to 99.97% efficiency or

greater, using high-efficiency particulate air (HEPA) filters that meet MIL-STD-282.

v The deliquescent relative humidity of the particulate contamination

must be more than 60%2.

v The room must be free of conductive contamination such as zinc

whiskers.

v Copper: Class G1 as per ANSI/ISA 71.04-19853 v Silver: Corrosion rate of less than 300 Å in 30 days

Notices 57

Documentation format

The publications for this product are in Adobe Portable Document Format (PDF) and should be compliant with accessibility standards. If you experience difficulties when you use the PDF files and want to request a web-based format or accessible PDF document for a publication, direct your mail to the following address:

Information Development IBM Corporation 205/A015 3039 E. Cornwallis Road P.O. Box 12195 Research Triangle Park, North Carolina 27709-2195 U.S.A.

In the request, be sure to include the publication part number and title.

When you send information to IBM, you grant IBM a nonexclusive right to use or distribute the information in any way it believes appropriate without incurring any obligation to you.

Electronic emission notices

Federal Communications Commission (FCC) statement

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that might cause undesired operation.

Industry Canada Class A emission compliance statement

This Class A digital apparatus complies with Canadian ICES-003.

Avis de conformité à la réglementation d'Industrie Canada

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

58 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Australia and New Zealand Class A statement

Attention: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

European Union EMC Directive conformance statement

This product is in conformity with the protection requirements of EU Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a nonrecommended modification of the product, including the fitting of non-IBM option cards.

Attention: This is an EN 55022 Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

Responsible manufacturer:

International Business Machines Corp. New Orchard Road Armonk, New York 10504 914-499-1900

European Community contact:

IBM Technical Regulations, Department M456 IBM-Allee 1, 71137 Ehningen, Germany Telephone: +49 7032 15-2937 Email: tjahn@de.ibm.com

Germany Class A statement

Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU-Richtlinie zur Elektromagnetischen Verträglichkeit

Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein.

Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der IBM verändert bzw. wenn Erweiterungskomponenten von Fremdherstellern ohne Empfehlung der IBM gesteckt/eingebaut werden.

EN 55022 Klasse A Geräte müssen mit folgendem Warnhinweis versehen werden: “Warnung: Dieses ist eine Einrichtung der Klasse A. Diese Einrichtung kann im Wohnbereich Funk-Störungen verursachen; in diesem Fall kann vom Betreiber verlangt werden, angemessene Maßnahmen zu ergreifen und dafür aufzukommen.”

Notices 59

Deutschland: Einhaltung des Gesetzes über die elektromagnetische Verträglichkeit von Geräten

Dieses Produkt entspricht dem “Gesetz über die elektromagnetische Verträglichkeit von Geräten (EMVG)”. Dies ist die Umsetzung der EU-Richtlinie 2004/108/EG in der Bundesrepublik Deutschland.

Zulassungsbescheinigung laut dem Deutschen Gesetz über die elektromagnetische Verträglichkeit von Geräten (EMVG) (bzw. der EMC EG Richtlinie 2004/108/EG) für Geräte der Klasse A

Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-Konformitätszeichen - CE - zu führen.

Verantwortlich für die Einhaltung der EMV Vorschriften ist der Hersteller:

International Business Machines Corp. New Orchard Road Armonk, New York 10504 914-499-1900

Der verantwortliche Ansprechpartner des Herstellers in der EU ist:

IBM Deutschland Technical Regulations, Department M456 IBM-Allee 1, 71137 Ehningen, Germany Telephone: +49 7032 15-2937 Email: tjahn@de.ibm.com

Generelle Informationen:

Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse A.

Taiwan Class A compliance statement

People's Republic of China Class A electronic emission statement

60 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Japan VCCI Class A statement

This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which case the user may be required to take corrective actions.

Korea Communications Commission (KCC) statement

Please note that this equipment has obtained EMC registration for commercial use. In the event that it has been mistakenly sold or purchased, please exchange it for equipment certified for home use.

Japan Electronics and Information Technology Industries Association (JEITA) statement

Japan Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guidelines (products less than or equal to 20 A per phase)

Notices 61

62 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

Index

accessible documentation 58 advanced configuration settings 36 advanced setup 36 array, SAS 20 assistance, getting 51 Australia Class A statement 59

blade filler 31 blade server

installing 31 removing 16

blade server cover

closing 31 opening 17

BladeCenter HS12

specifications 5 BMC controller settings 36 buttons

keyboard/video/mouse 11

media-tray select 11

power-control 11

China Class A electronic emission

statement 60

cKVM card

installing 24 Class A electronic emission notice 58 completing the blade server

installation 30

components

illustrated 10

system board 14 configuration

Configuration/Setup Utility 35

PXE Boot Agent Utility program 35

updating 33

with ServerGuide 40 Configuration/Setup Utility program 35 configuring

SAS RAID array 42 configuring a SAS RAID array 42 configuring your blade server 35 connectors

I/O expansion card 14

input/output 33

memory 14

microprocessor 14

SAS hard disk drives 14

SATA storage drives 14

solid state storage drives 14

system board 14 contamination, particulate and

gaseous 57

controller

enable or disable Ethernet 36

controller (continued)

enable or disable SCSI 36 Ethernet 42 memory 6

cover

closing 31 opening 17

date and time 36 devices and I/O ports 36 diagnostic tools 47 DIMM. 21 documentation

using 52 Documentation Browser, using 4 documentation CD 3 documentation format 58 documentation, related 3 drive

connectors 14

option, SAS 20

electronic emission Class A notice 58 Electronic emission notices 58 error log 47 Ethernet controller 6

configuring 42 European Union EMC Directive

conformance statement 59 event log 47 exit configuration utility 36 expansion card

installing 26, 27

expansion unit

removing 18

FCC Class A notice 58 features

ServerGuide 39 features, blade server 6 filler

blade 17

microprocessor heat sink 16 filler, blade 31 firmware

updates 1 firmware updates 41 fixed storage device

SATA hard disk drive 19

solid state storage drive 19 forgotten power-on password,

bypassing 38

gaseous contamination 57 Germany Class A statement 59 getting help 52

hard disk drive

connectors 14 hot swap, installing 20

hardware and software

requirements 4 hardware problems 47 hardware service and support telephone

numbers 53

help

getting 51 help, World Wide Web 52 high-speed expansion card

I/O expansion card 26, 28

installing 26, 28 hot-spare memory 36 hot-swap storage device

SAS hard disk drive 20

I/O expansion card

connectors 14

high-speed expansion card 26, 28

installing 25

SAS connectivity card 26

types supported 25 I/O expansion card, InfiniBand

high-speed card

installing 25 I/O expansion card, SAS connectivity

card

installing 25 IBM Director 6, 9 IBM Taiwan product service 53 important notices 56 Industry Canada Class A emission

compliance statement 58

InfiniBand high-speed card, I/O

expansion card

installing 25 information center 52 installation

completing 30

procedure 26, 27 installation instructions 46 installation order for memory

modules 21

installing

blade server 31

cKVM card 24

fixed storage device 19

high-speed expansion card 26, 28

hot-swap hard disk drives 20

installing (continued)

I/O expansion card 25 memory module 21 optional expansion unit 29 options 15 SAS connectivity card 26, 27 SAS hard disk drive 20 SATA hard disk drive 19 solid state storage drive 19

integrated functions 5

Japan Electronics and Information

Technology Industries Association

statement 61 Japan VCCI Class A statement 61 Japan Voluntary Control Council for

Interference Class A statement 61 JEITA statement 61

Korea Communications Commission

statement 61

LEDs

activity 11 blade-error 11 information 11 location 11

power-on 11 Light path diagnostics 47 load default settings 36 load-sharing

power throttling 6 LSI logic configuration utility program

description 35 LSI Logic Configuration Utility

program 43

major components

system board 10 media-tray select button 11 memory

configuration changes 21

hot-spare 36

specifications 5 memory module

installing 21

order of installation 21

specifications 5, 6

supported 5, 21 memory settings 36 microprocessor

connectors 14

specifications 5 microprocessor options 36

New Zealand Class A statement 59 NOS installation

with ServerGuide 40

without ServerGuide 40 notes, important 56 notices 55

electronic emission 58

FCC, Class A 58

online documentation 1 opening the blade server cover 17 operating system

install using RDM 45

installing 45 option

installing 15 optional expansion unit

installing 29 order of installation for memory

modules 21

particulate contamination 57 password

power-on 38 PCI bus control settings 36 People's Republic of China Class A

electronic emission statement 60

port

input/output 33 power

throttling 6 power-on password 38 Preboot eXecution Environment (PXE)

option 36

disabling 36

enabling 36 problems

hardware 47 problems, solving 47 processor summary information 36 product data 36 product service, IBM Taiwan 53 publications

online 1

product data 1

related 3 PXE boot agent utility program 35

using 41

RDM, using 45 redundant array of independent disks

(RAID)

SAS array 20 related documentation 3 reliability

features 8 remote console redirection 36 Remote Deployment Manager, using 45

removing

blade server 16

requirements

hardware 4 hardware and software 4 software 4

restore settings 36

safety v safety statements v, vi SAS

array

type supported 20

SAS connectivity card

I/O expansion card 26 installing 26, 27 seating in the blade server 26

SAS connectivity card, I/O expansion

card

installing 25

SAS hard disk drive

hot-swap storage device 20 installing 20

SAS hard disk drives

support 6

SATA

hard disk drive

connectors 14

SATA hard disk drive

fixed storage device 19 installing 19

SATA hard disk drives

support 6 save settings 36 SCSI 20 SCSI RAID

configure an array 42 seating the SAS connectivity card in the

blade server 26

Serial Attached SCSI (SAS)

hard disk drive

connectors 14

hot-swap hard disk drive

installing 20

ServerGuide 45

error symptoms 49

features 39

NOS installation 40

using 39 ServerGuide CD 6 service and support

before you call 51

hardware 53

software 52 setup

with ServerGuide 40 software service and support telephone

numbers 52

solid state

storage drive

connectors 14

solid state storage drive

fixed storage device 19 solid state storage drives

support 6

64 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide

specifications

BladeCenter HS12 5 start options 36 starting the blade server 13 startup sequence options 36 startup sequence, setting 36 static electricity 16 static-sensitive devices, handling 16 stopping the blade server 13 storage drive

connectors 14

support 6 system information 36 system MAC addresses 36 system reliability 16 system security 36 system summary information 36 system-board components

location of 10 system-board connectors 14 systems management 9

Taiwan Class A compliance statement 60 trademarks 56 troubleshooting

Light path diagnostics 47

Problem isolation tables 47 turning off the blade server 13 turning on the blade server 13

United States electronic emission Class A

notice 58 United States FCC Class A notice 58 updating firmware 41 updating the configuration 33 USB device summary information 36 using

Documentation Browser 4

utility

Configuration/Setup Utility

program 35

PXE boot agent program, using 41

Web site

ServerGuide 39

Index

66 BladeCenter HS12 Type 8014 or 8028: Installation and User's Guide



Part Number: 60Y1600

Printed in USA

(1P) P/N: 60Y1600

IBM HS12, BladeCenter HS12 Type 8014, BladeCenter HS12 Type 8028 Installation And User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
