CMX158886 cpuModules™

User’s Manual

BDM-610000049 Revision G

www.rtd.com

An ISO9001:2000 Company

“Accessing the Analog World”

CMX158886 cpuModules™ User’s Manual

RTD Document Number: BDM-610000049 Revision G

Trademarks

Advanced Digital I/O, aDIO, a2DIO, Autonomous SmartCal, cpuModule, dspFramework, dspModule, IDAN, HiDAN, HiDANplus, “MIL Value for COTS prices”, multiPort, and PC/104EZ are trademarks, and “Accessing the Analog World”, dataModule, RTD, and the RTD logo are registered trademarks of RTD Embedded Technologies, Inc. PS/2, PC/XT, PC/AT, and IBM are trademarks of International Business Machines Inc. MS-DOS, Windows, Windows 95, Windows 98, and Windows NT are trademarks of Microsoft Corporation. Linux is a registered trademark of Linus Torvalds. ROM-DOS is a trademark of Datalight, Inc. Intel is a registered trademark of Intel Corporation. PC/104 is a registered trademark of PC/104 Consortium. All other trademarks appearing in this document are the property of their respective owners.

Contents and specifications within this manual are subject to change without notice.

Revision History

Revision Date Reason for Change

A 12/13/06 Initial release

B 07/26/06 Added section to Chapter 3 with instructions for installing an ATA/IDE Disk Chip

Removed the “Preliminary” tag on the cover sheet Added section describing proper grounding techniques

C 10/02/06 Added block diagrams to Appendix C to show the dimensions and connectors of the IDAN

CMX158886 that includes a PCI to ISA bridge board Added “Network Boot” bullet to list of board features Removed references to 1.1 GHz Pentium M processor

D 11/29/06 Described +3.3 V source for FP_VCC, and added footnote for DDC signals (see Table 13 on page 33)

Added section to Chapter 4: DVMT Mode Select—page 79 Removed table describing solder jumpers (see footnote of Table 62 on page 87) Added height of Mini Fan Heatsink (see Physical Dimensions on page 89) Made correction to IDAN SVGA connector pinout table (see Table 71 on page 101) Added dimension of heatsink fins on IDAN frames (see page 96 and page 104)

E 2/23/07 Removed Thermal Throttling. Corrected multiPort Floppy setup. Removed EEPROM section.

Updated board name.

F 1/9/08 Added 1024 MB versions. Combined PX and CX manuals. Added support for dual serial ports.

Corrected storage temperatures.

G 5/21/08 Corrected Table 26, COM A (RS-422/485) and COM B (RS-422/485)—41

Added User EEPROM on page 80 Corrected aDIO Connector in Figure 10, IDAN-CMX158886-BRG Connectors —104 Added information for ECC verison.

ii CMX158886 cpuModule BDM-610000049 Rev G

CMX158886 cpuModules™

www.rtd.com

An ISO9001:2000 Company

“Accessing the Analog World”

iv CMX158886 cpuModule BDM-610000049 Rev G

Table of Contents

Chapter 1 Introduction

CMX158886 cpuModules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Enhanced Intel SpeedStep (PX only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Thermal Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Error-Correction Codes (Selected Models Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

aDIO with Wake-on-aDIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

CMX158886 Model Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cable Kits and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Board Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

BIOS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Operating Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Chapter 2 Getting Started

Connector Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting the Utility Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connecting a Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connecting to the PC/104-Plus (PCI) Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Slot Selection Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

PCI Bus Expansion Card Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

+5 Volt DC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

+3.3 Volt DC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

PCI Bus Signaling Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Booting the CMX158886 cpuModule for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 3 Connecting the cpuModule

Proper Grounding Techniques. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connector Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Auxiliary Power (CN3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Utility Port Connector (CN5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Speaker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Mouse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

System Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

BDM-610000049 Rev G :v

Soft Power Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

SVGA Video Connector (CN18) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

LVDS Flat Panel Video Connector (CN19) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

EIDE Connector (CN10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

ATA/IDE Disk Chip Socket (U16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Installing and Configuring the ATA/IDE Disk Chip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Serial Port 1 (CN7) and Serial Port 2 (CN8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Serial Port UART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

RS-232 Serial Port (Default) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

RS-422 or RS-485 Serial Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

RS-422 and RS-485 Mode Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Dual Serial Port Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

multiPort™ (CN6). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

multiPort Configured as an Advanced Digital I/O (aDIO™) Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

multiPort Configured as a Parallel Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

multiPort Configured as a Floppy Drive Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

USB 2.0 Connector (CN17) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Ethernet (10/100Base-T and -TX) Connector (CN20). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Audio (CN11). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

PC/104-Plus PCI Bus (CN16). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

PC/104-Plus PCI Bus Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Address and Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Interface Control Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Error Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Arbitration (Bus Masters Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Power Supplies and VIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

ATX Power Management Signals (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Bridge Link (CN4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

External Power Management (CN12). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Optional RTC Battery Input (CN13) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Fan Power, +5 V (CN14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Fan Power, Switched (CN15). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Chapter 4 Using the cpuModule

The RTD Enhanced AMI BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Configuring the RTD Enhanced AMI BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Entering the BIOS Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Field Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Main Menu Setup Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Power On Self Test (POST) Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Booting to Boot Block Flash with Fail Safe Boot ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

vi CMX158886 cpuModule BDM-610000049 Rev G

Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

I/O Address Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Hardware Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

multiPort: Advanced Digital I/O Ports (aDIO™) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Digital I/O Register Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Port 1 Data register is a read/write byte direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Advanced Digital Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Event Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Match Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Strobe Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Wake-on-aDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

multiPort: Parallel Port Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

multiPort: Floppy Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

AC’97 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Ethernet (10/100Base-T and -TX). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

IDE Controller Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Cable Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Cable Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Device and Host Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Host Determination of Cable Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Device Detect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Legacy Mode and Native Mode IDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Legacy Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Native Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Configuring the ATA/IDE Disk Chip Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Real Time Clock Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Accessing the RTC Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Watchdog Timer Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Thermal Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Thermal Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Fan Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Further Temperature Reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Enabling Enhanced Intel SpeedStep Technology (PX only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Advanced Configuration and Power Interface (ACPI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Power Button Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Low-Power Wake Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

AT vs. ATX Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

ATX Power Supply Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Reducing Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Multi-Color LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Reset Status Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

DVMT Mode Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

BDM-610000049 Rev G :vii

User EEPROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Features and Settings That Can Affect Boot Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Quick Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Add-On Cards With BIOS Extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

VGA Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Hard Drive Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Monitor Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

NVRAM Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Boot Device Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

System Recovery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Loading Default BIOS Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Booting to the Fail Safe Boot ROM (FSBR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Basic Interrupt Information for Programmers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

What happens when an interrupt occurs? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

How long does it take to respond to an interrupt? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Interrupt Request Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Intel 8259 Programmable Interrupt Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

PCI Interrupts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Writing an Interrupt Service Routine (ISR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Sample Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Appendix A Hardware Reference

Jumper Settings and Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Onboard PCI Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Physical Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Appendix B Troubleshooting

Common Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Troubleshooting a PC/104-Plus System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

How to Obtain Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Appendix C IDAN™ Dimensions and Pinout

IDAN Dimensions and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

External I/O Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

IDAN Dimensions and Connectors (BRG version only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

External I/O Connections (BRG version only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Appendix D Additional Information

Application Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Drivers and Example Programs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Interrupt Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Serial Port Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

viii CMX158886 cpuModule BDM-610000049 Rev G

PC/104 and PC/104-Plus Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Appendix E Limited Warranty

BDM-610000049 Rev G :ix

x CMX158886 cpuModule BDM-610000049 Rev G

Chapter 1 Introduction

This manual provides comprehensive hardware and software information for users developing with the CMX158886 PC/104-Plus cpuModule.

Note Read the specifications beginning on page 12 prior to designing with the cpuModule.

This manual is organized as follows:

Chapter 1 Introduction

introduces main features and specifications

Chapter 2 Getting Started

provides abbreviated instructions to get started quickly

Chapter 3 Connecting the cpuModule

provides information on connecting the cpuModule to peripherals

Chapter 4 Using the cpuModule

provides information to develop applications for the cpuModule, including general cpuModule information, detailed information on storing both applications and system functions, and using utility programs

Appendix A Hardware Reference

lists jumper locations and settings, physical dimensions, and processor thermal management

Appendix B Troubleshooting

offers advice on debugging problems with your system

Appendix C IDAN™ Dimensions and Pinout

provides connector pinouts for the cpuModule installed in an RTD Intelligent Data Acquisition Node (IDAN) frame

Appendix D Additional Information

lists sources and websites to support the cpuModule installation and configuration

Appendix E Limited Warranty

BDM-610000049 Rev G Chapter 1: Introduction 1

CMX158886 cpuModules

RTD's CMX158886 cpuModule represents the latest in high-performance embedded computing solutions. It includes 400 MHz source-synchronous Front Side Bus (FSB), on-die 2 MB (PX) or 512kB (CX) L2 cache, and data pre-fetch logic. It uses a 333MHz DDR-SDRAM controller that can support up to 2.7 G-Bytes per second of memory bandwidth. All memory chips are soldered directly onto the board. The Pentium-M (PX) processor features Enhanced Intel SpeedStep® technology, which enables real-time dynamic switching between multiple voltage and frequency points. This results in optimal performance without compromising low power.

The video interface is provided by an Analog SVGA output and an LVDS flat panel output. The two outputs are independent, and can display separate images and display timings. Maximum resolution is 2048 x 1536.

High-speed peripheral connections include USB 2.0, with up to 480 Mb/sec data throughput. An ATA-100/66/33 IDE controller provides a fast connection to the hard drive. Network connectivity is provided by an integrated 10/100 Mbps Ethernet controller. Other features include two RS-232/422/485 COM ports, Parallel Port, and AC97 audio.

RTD has gone the extra mile to include additional advanced features for maximum flexibility. These include an ATA/IDE Disk Chip socket that allows a true IDE drive to be attached to the board, either socketed or soldered. A MultiPort can be configured as a standard EPP/ECP parallel port, a floppy drive port, or an Advanced Digital I/O (aDIO) port. The DDR-SDRAM controller on selected models uses Error-Correcting-Codes (ECC) to correct single bit memory errors, and detect two-bit memory errors, providing for a more robust memory system. SDRAM is soldered directly to the board for high vibration resistance. The CMX158886 is also available in a rugged, fanless IDAN enclosure.

SVGA Video

(CN18)

LVDS Flat

Panel

(CN19)

COM2

(CN8)

USB 2.0 (CN17)

Ethernet

(CN20)

ATA /I D E

Disk Chip

(U16)

Cont. Fan

(CN14)

Power

Mngmt.

(CN12)

Auxiliary Power

(CN3)

PCI Bus (CN16)

Battery (CN13)

EIDE (CN10)

Audio

(CN11)

COM1

(CN7)

Switched

Fan

(CN15)

multiPort

(CN6)

Multi-

Function

(CN5)

ISA Bridge Link

(CN4)

Figure 1 CMX158886 cpuModule (top view)

2 CMX158886 cpuModule BDM-610000049 Rev G

Enhanced Intel SpeedStep (PX only)

Enhanced Intel® SpeedStep® Technology has revolutionized thermal and power management by giving application software greater control over the processor’s operating frequency and input voltage. Systems can easily manage power consumption dynamically. Today’s embedded systems are demanding greater performance at equivalent levels of power consumption. Legacy hardware support for backplanes, board sizes and thermal solutions have forced design teams to place greater emphasis on power and thermal budgets. Intel has extended architectural innovation for saving power by implementing new features such as Enhanced Intel SpeedStep Technology. Enhanced Intel SpeedStep Technology allows the processor performance and power consumption levels to be modified while a system is functioning. This is accomplished via application software, which changes the processor speed and the processor core voltage while the system is operating. A variety of inputs such as system power source, processor thermal state, or operating system policy are used to determine the proper operating state.

The software model behind Enhanced Intel SpeedStep Technology has ultimate control over the frequency and voltage transitions. This software model is a major step forward over previous implementations of Intel SpeedStep technology. Legacy versions of Intel SpeedStep technology required hardware support through the chipset. Enhanced Intel SpeedStep Technology has removed the chipset hardware requirement and only requires the support of the voltage regulator, processor and operating system. Centralization of the control mechanism and software interface to the processor, and reduced hardware overhead has reduced processor core unavailability time to 10 μs from the previous generation unavailability of 250 μs.

Thermal Monitor

The Intel ® Thermal Monitor is a feature on the CMX158886 that automatically initiates a SpeedStep transition or throttles the CPU when the CPU exceeds its thermal limit. The maximum temperature of the processor is defined as the temperature that the Thermal Monitor is activated. The thermal limit and duty cycle of the Thermal Monitor cannot be modified.

Error-Correction Codes (Selected Models Only)

The Graphics and Memory Controller Hub (GMCH) may be configured in the BIOS setup to operate in an Error-Correction-Code (ECC) data integrity mode. ECC mode allows multiple bit error detection and single bit error correction. The GMCH generate an 8-bit code word for each 64-bit Qword of memory, and performs a full Qword write at a time so that an 8-bit code is sent with each write. Since the code word covers a full Qword, writes of less than a Qword require a read-merge-write operation. Consider a Dword write to memory. In this case, when in ECC mode, GMCH will read the Qword where the addressed Dword will be written, merge in the new Dword, generate a code covering the new Qword and finally write the entire Qword and code back to memory. Any correctable (single-bit) errors detected during the initial Qword read are corrected before merging the new Dword.

Memory with ECC enabled requires additional system memory resources. This will cause the integrated graphics engine to have less memory bandwidth for access to the graphics frame buffer. Because of this, the display may flicker at high resolutions when the graphics processor is fully utilized and ECC is enabled. ECC memory is supported with internal graphics only.

aDIO with Wake-on-aDIO

RTD’s exclusive multiPort™ allows the parallel port to be configured as an Advanced Digital I/O (aDIO™), ECP/ EPP parallel port, or a floppy drive. aDIO™ is 16 digital bits configured as 8 bit-direction programmable and 8-bit port-direction programmable I/O giving you any combination of inputs and outputs. Match, event, and strobe interrupt modes mean no more wasting valuable processor time polling digital inputs. Interrupts are generated when the 8 bit-direction programmable digital inputs match a pattern or on any value change event. Bit masking

BDM-610000049 Rev G Chapter 1: Introduction 3

allows selecting any subgroup of eight bits. The strobe input latches data into the bit-programmable port and generates an interrupt. Any of the interrupt modes can be used to generate a wake event from any standby/powerdown mode.

4 CMX158886 cpuModule BDM-610000049 Rev G

Ordering Information

The CMX158886 cpuModule is available with a 1.4 GHz Pentium-M processor, or a 1.0 GHz Celeron-M processor and 512 or 1024 MB of DDR SDRAM. The cpuModule can also be purchased as part of an Intelligent Data Acquisition Node (IDAN™) building block, which consists of the cpuModule and a milled aluminum IDAN frame. The IDAN building block can be used in just about any combination with other IDAN building blocks to create a simple but rugged PC/104 stack. Refer to Appendix C, IDAN™ Dimensions and Pinout, for more information. The CMX158886 cpuModule can also be purchased as part of a custom-built RTD HiDAN™ or HiDANplus High Reliability Intelligent Data Acquisition Node. Contact RTD for more information on its high reliability PC/PCI-104 systems.

CMX158886 Model Options

The basic cpuModule model options are shown below. Refer to the RTD website (www.rtd.com) for more detailed ordering information.

Part Number Description

CMX158886PX1400HR-512 1.4 GHz Pentium-M, 512MB DDR-SDRAM cpuModule

CMX158886PX1400HR-E512 1.4 GHz Pentium-M, 512MB DDR-SDRAM cpuModule with ECC

CMX158886PX1400HR-1024 1.4 GHz Pentium-M, 1024MB DDR-SDRAM cpuModule

CMX158886CX1000HR-512 1.0 GHz Celeron-M, 512MB DDR-SDRAM cpuModule

Table 1 CMX158886 cpuModule Model Options

CMX158886CX1000HR-E512 1.0 GHz Celeron-M, 512MB DDR-SDRAM cpuModule with ECC

CMX158886CX1000HR-1024 1.0 GHz Celeron-M, 1024MB DDR-SDRAM cpuModule

BDM-610000049 Rev G Chapter 1: Introduction 5

Cable Kits and Accessories

For maximum flexibility, RTD does not provide cables with the cpuModule. You may wish to purchase the CMX158886 cpuModule cable kit (P/N XK-CM65), which contains:

• Multi-function utility harness (keyboard socket, battery, reset, speaker)

• Two serial port cables (D I L-1 0 t o D S U B -9)

• Parallel port cable (DIL-26 to DSUB-25)

• Two IDE cables

• VGA monitor cable (DIL-10 to high density 15-pin DSUB)

• Power cable (DIL-12 to wire leads)

• Two USB cables (5-pin SIL to USB A)

• Audio Cable (DIL-10 to three Mini-Jacks)

• One Ethernet cable (DIL-10 to RJ-45)

A floppy drive cable kit (P/N XK-CM49) is also available for connecting to the multiPort. This cable kit comes with:

• 3.5” HDD Floppy Drive with a multiPort interface board

• Two floppy cables

For additional accessories, refer to the RTD website.

6 CMX158886 cpuModule BDM-610000049 Rev G

Board Features

• 1.4 GHz Intel Pentium M with thermal throttling

– 400 MHz, source-synchronous Front Side Bus

–Math coprocessor

– Internal Cache

• 1.0 GHz Intel Celeron M with thermal throttling

– 400 MHz, source-synchronous Front Side Bus

–Math coprocessor

– Internal Cache

• 512 or 1024 Mbytes BGA DDR SDRAM

– Up to 333 MHz Data Rate

– ECC corrects single-bit memory errors and detects 2-bit errors (selected models)

• Stackable 120-pin PCI bus

– 4 Bus master add-on cards capable

– 3.3V or 5V PCI bus signaling

• Advanced power management features including Enhanced Intel SpeedStep Technology (PX only)

• Advanced Thermal Management

– Auto Fan Control only runs fan when needed

– SMBus Temperature Monitor for CPU and board temperature

– Mini Fan Heatsink with Auto Fan control

– Passive Structural Heatsink & Heatpipes in IDAN and HiDAN System Configurations

• Advanced Programmable Interrupt Controller (APIC)

– High resolution 100 MHz APIC timer

– 24 interrupt channels with APIC enabled (15 in legacy PIC mode)

• Advanced Configuration and Power Interface (ACPI)

– ACPI 1.0 Compliant

– Supported power down modes: S1 (Power On Suspend), S3 (Suspend to RAM), S4 (Hibernate),

– CPU Clock Throttling and Clock Stop for C0 to C3 Support

– Wake events include:

• Network Boot supported by Intel PXE

• Supports MMX and SSE2 instructions

• L1 - 32KB of instruction and 32KB data; L2 - 2 MB

• Supports MMX and SSE2 instructions

• L1 - 32KB of instruction and 32KB data; L2 - 512kB

and S5 (Soft-Off)

• aDIO Interrupt

• Wake-on-LAN

• Real Time Clock

• COM port Ring

• Power Switch

• etc.

BDM-610000049 Rev G Chapter 1: Introduction 7

• Three (3) counter/timers (Intel 8254 compatible)

• Seven (7) DMA channels (Intel 8237 compatible)

• Y2K compliant Real-Time Clock (external battery required)

• Nonvolatile storage of CMOS settings without battery

• Watchdog timer

• Complete PC-compatible Single Board Computer

I/O

• AC97 Audio Support

– Selectable Headphone or Line level output

– Line level input

– Microphone input

• Fast Ethernet

– Ethernet Controller

• Intel 82562 Fast Ethernet PCI Controller

• Integrated 3KByte Transmit and 3Kbyte Receive FIFOs

–Physical Layer

• 100Base-Tx and 10Base-T

• Full Duplex support

–Easy to Use

• Low Power Features

• LED Status

• Software configuration

• 855GME SVGA controller Onboard with 3D Acceleration

– DirectX & OpenGL 3D Accelerator

–Analog SVGA Output

–LVDS Flat Panel output

– Resolution up to 2048 x 1536 pixels with 32K colors

– VGA, SVGA, XGA, SXGA, UXGA

– Up to 16 million colors

– 64-bit AGP Hardware graphics-accelerator

– 1MB to 64MB of shared DDR high-performance memory

• Software-configurable RS-232/422/485 serial ports

– 16550 compatible UARTs for high-speed

– Termination resistors for RS-422/485

– Each serial port connector can be configured as two limited serial ports, for a total of four serial

ports

• multiPort function connector

– Parallel port

• SPP, PS/2 bi-directional, EPP & ECP

– Advanced Digital I/O (aDIO)

8 CMX158886 cpuModule BDM-610000049 Rev G

• One 8-bit port programmable as input or output

• Eight bit-programmable I/O with Advanced Digital Interrupt Modes

• Event Mode Interrupt generates an interrupt when any input bit changes

• Match Mode Interrupt generates an interrupt when input bits match a preset value

• External Strobe Mode latches 8 data inputs and generates and interrupt

• Two Strobes can be configured as readable inputs

– Floppy controller interface

• Interfaces with RTD's multiPort Floppy Drive and Cable Kit

– ESD protection

• Two USB 2.0 (Universal Serial Bus) Ports

– Supports 480 Mb/s (high-speed), 12Mb/s (full-speed), and 1.5Mbs (low speed) peripherals

– 500 mA @ 5 Vdc provided per port

– USB Boot capability

• UltraDMA-100 / 66 / 33 Master Mode PCI EIDE Controller

– Transfer rate up to 100MB/sec using UltraDMA

– Increased reliability using UltraDMA-66 transfer protocols

– Support ATAPI compliant devices including DVD drives

– 48-bit LBA support for hard drives up to 2.2 terabytes.

• 32 pin ATA/IDE Disk Chip Socket

– Miniature ATA/IDE Flash Disk Chip

– Capacities up to 4GB

– Natively supported by all major operating systems

• Utility port

– PC/AT compatible keyboard port

–PS/2 Mouse Port

–Speaker port (0.1W output)

–Hardware Reset input

– Battery input for Real Time Clock

– Soft Power Button input

• Power I/O

– Access to PCI-104 Bus pins

– Power ground, ±12, 5 & 3.3 VDC

BIOS

• RTD Enhanced AMI BIOS

• User-configurable using built-in Setup program

• Nonvolatile storage of CMOS settings without battery

• Boot Devices

– Standard Devices (floppy disk, hard disk, etc.)

– ATA/IDE Disk Chip

1. During the time of this manual’s publication, 4GB was the largest available ATA/IDE Disk Chip capacity

BDM-610000049 Rev G Chapter 1: Introduction 9

–USB Device

–Network

– Fail Safe Boot ROM

• Surface-mount Flash chip that holds ROM-DOS™

• Quick Boot mode

10 CMX158886 cpuModule BDM-610000049 Rev G

Block Diagram

The next figure shows a simplified block diagram of the CMX158886 cpuModule.

Inte l P ro ce s s or

2 x USB 2.0

PCI Bus 32-bit, 33 MHz

RTD aDIO/ W atchdog

2 x RS-232/422/485

Parallel Port

Figure 2 CMX158886 cpuModule Simplified Block Diagram

855 GM E NorthBridge

IC H -4 South Bridge

LPC B us

Super I/O

DDR SDRAM 333 MH z

SVGA/ LVDS Flat Panel

EIDE AC97 A udio 10/100 Ethernet

RTD Enhanced BIOS / Failsafe Boot RO M

Keyboard/Mouse Floppy Drive

You can easily customize the cpuModule by stacking PCI-104 modules such as video controllers, modems, LAN controllers, or analog and digital data acquisition modules. Stacking modules onto the cpuModule avoids expensive installations of backplanes and card cages, and preserves the module's compactness.

The cpuModule uses the RTD Enhanced AMI BIOS. Drivers in the BIOS allow booting from floppy disk, hard disk, ATA/IDE Disk Chip, or boot block flash, thus enabling the system to be used with traditional disk drives or nonmechanical drives. Boot from USB devices and network are also supported.

The cpuModule and BIOS are also compatible with most real-time operating systems for PC compatible computers, although these may require creation of custom drivers to use the aDIO and watchdog timer.

BDM-610000049 Rev G Chapter 1: Introduction 11

Specifications

Physical Characteristics

• Dimensions: 117mm L x 97mm W x 15mm H (4.6"L x 3.8"W x 0.6"H)

• Weight: Approximately 0.19 Kg (0.40 lbs.)

Power Consumption

Exact power consumption depends on the actual application. Table 2 lists power consumption for typical configurations and clock speeds.

Operating Conditions

Tabl e 2 cp u Mo d ule P o wer C o nsu m pt i on

Module Speed RAM Power, typ. Power, Max.

CMX158886PX 1.4 GHz 512 MB 12.7 W 15.2 W

CMX158886CX 1.0 GHz 512 MB 10.9 W 12.2 W

Table 3 Operating Conditions

Symbol Parameter Tes t C o nd i ti o n Min. Max.

CC5

CC3

CC12

CC-12

CCSTBY

Ta Ambient Operating

Ts Storage Temperature -40C +85C

Rh Humidity Non-Condensing 0 90%

MTBF Mean Time Before

1. The 12V, -12V, and external +3.3V rails are not used by the cpuModule. Any requirements on

2. 5V Standby is used to power the board when the main supply is turned off (power down modes

5V Supply Voltage 4.75V 5.25V

3.3V Supply Voltage n/a

12V Supply Voltage n/a

-12V Supply Voltage n/a

5V Standby Voltage

5V Standby Current

Tem p e ra tu re

Failure

these signals are driven by other components in the system, such as an LVDS Flat Panel or PCI device.

S3-S5). It is not required for board operation.

Standard -40C +85C

23 C 110,000

4.75V 5.25V

-500mA

hours

n/a

Electrical Characteristics

The table below lists the Electrical Characteristics of the CMX158886. Operating outside of these parameters may cause permanent damage to the cpuModule.

12 CMX158886 cpuModule BDM-610000049 Rev G

Table 4 Electrical Characteristics

Symbol Parameter Tes t C o nd i ti o n Min. Max.

PCI

3.3V

Ioc Overcurrent Limit Total of both

Vos Offset Voltage 1.125 V 1.375 V

vcc

BKLT

Output Voltage High IOH = –0.5 mA 2.9 V 3.3 V

Output Voltage Low IOL = 6.0 mA 0.0 V 0.55 V

Input Voltage High — 1.8 V 5.5 V

Input Voltage Low — -0.5 V 0.9

3.3V supplied to PCI

——2 A

bus from power connector (CN3)

Bridge Link (CN4)

Output Voltage High IOH = –0.5 mA 2.4 V 3.3 V

Output Voltage Low IOL = 6.0 mA 0.0 V 0.55 V

Input Voltage High — 2.0 V 5.5 V

Input Voltage Low — -0.5 V 0.8 V

IDE & ATA/IDE Disk Chip Socket

Output Voltage High IOH = –6.0 mA 2.8 V 3.3 V

Output Voltage Low IOL = 6.0 mA 0.0 V 0.51 V

Input Voltage High — 2.0 V 5.5 V

Input Voltage Low — -0.5 V 0.8 V

USB Ports

1.0A 5.0A ports on a connector

LVD S Po r t

Differential Output

250 mV 450 mV

Volt age

Supply Current for

——2 A

Panel Electronics

Supply Current for

——2 A

Backlight

Output Voltage High

IOH = –1.0 mA 2.97 V 3.3 V

DDC_*, FP_ENABLK

Output Voltage Low

IOL = 1.0 mA 0 0.33 V

DDC_*, FP_ENABLK

Input Voltage High

—2.03.6 V

DDC_*

Input Voltage Low

—-0.30.8 V

DDC_*

BDM-610000049 Rev G Chapter 1: Introduction 13

Table 4 Electrical Characteristics

Symbol Parameter Tes t C o nd i ti o n Min. Max.

SVGA Port

Output Voltage High HSYNC, VSYNC

Output Voltage Low HSYNC, VSYNC

Output Voltage High DDC_*

Output Voltage Low DDC_*

Input Voltage High DDC_*

Input Voltage Low DDC_*

DDCvcc

Supply Current for DDC Electronics

OD1

OD2

Output Voltage High RL = 3 k 5.0 V 10.0 V

Output Voltage Low RL = 3 k -10.0 V -5.0 V

Input Voltage High — 2.4 V 25 V

Input Voltage Low — -25 V 0.8 V

Differential Output RL = 50 Ohm 2.0 V 6.0 V

Differential Output RL = 27 Ohm 1.5 V 6.0 V

Common Mode Output

Differential Input Threshold

Absolute Max Input Volt age

ADIOvcc

Output Voltage High IOH = –4.0 mA 2.4 V 3.3 V

Output Voltage Low IOL = 8.0 mA 0.0 V 0.4 V

Input Voltage High

Input Voltage Low

Supply current — 500 mA

Utility Port Connector (CN5)

RTC

UTILvcc

Input RTC Voltage

Utility Supply Current

External Power Management (CN12) - PME#

1. Applies to modes up to UltraDMA Mode 4 (ATA/66)

Input Voltage High — 2.0 V 5.5 V

Input Voltage Low — -0.5 V 0.8 V

IOH = –32.0 mA 3.8 V 5.0 V

IOL = 32.0 mA 0.0 V 0.55 V

IOH = –4.0 mA 2.4 V 3.3 V

IOL = 8.0 mA 0.0 V 0.4 V

— 2.0 V 5.5 V

— -0.3 V 0.8 V

—100 mA

Serial Ports - RS-232

Serial Ports - RS-422/485

RL = 27 or 50

0.0 V 3.0 V

Ohm

-7V < VCM < 7V -0.3 V 0.3 V

— -25 V 25 V

multiPort - all modes

— 2.0 V 5.5 V

— -0.5 V 0.8 V

— 2.0V 3.6 V

—500 mA

14 CMX158886 cpuModule BDM-610000049 Rev G

2. Maximum DC undershoot below ground must be limited to either 0.5V or 10mA. During transitions, the device pins may undershoot to -2.0V or overshoot to 7.0V, provided it is less than 10ns, with the forcing current limited to 200 mA.

3. Only required to maintain date and time when p ower is completely removed f rom the system. Not required for board operation.

Contact Information

RTD Embedded Technologies, Inc. 103 Innovation Blvd. State College, PA 16803-0906 USA

Phone: +1-814-234-8087 Fax: +1-814-234-5218

E-mail:sales@rtd.com

techsupport@rtd.com

Internet:http://www.rtd.com

BDM-610000049 Rev G Chapter 1: Introduction 15

16 CMX158886 cpuModule BDM-610000049 Rev G

Chapter 2 Getting Started

For many users, the factory configuration of the CMX158886 cpuModule can be used to get a PC/104 system operational. You can get your system up and running quickly by following the simple steps described in this chapter, which are:

1. Before connecting the cpuModule, the user must be properly grounded to prevent electrostatic discharge (ESD). For more information, refer to Proper Grounding Techniques on page 24.

2. Connect power.

3. Connect the utility harness.

4. Connect a keyboard.

5. Default BIOS configuration.

6. Fail Safe Boot ROM.

7. Connect a VGA monitor to the SVGA connector.

Refer to the remainder of this chapter for details on each of these steps.

BDM-610000049 Rev G Chapter 2: Getting Started 17

Connector Locations

Figure 3 shows the connectors and the ATA/IDE Disk Chip socket of the CMX158886 cpuModule.

SVGA Video

(CN18)

LVDS Flat

Panel

(CN19)

COM2

(CN8)

USB 2.0 (CN17)

Ethernet

(CN20)

ATA /I D E

Disk Chip

(U16)

Cont. Fan

(CN14)

Power

Mngmt.

(CN12)

Auxiliary Power

(CN3)

PCI Bus (CN16)

Battery (CN13)

EIDE (CN10)

Audio

(CN11)

COM1

(CN7)

Switched

Fan

(CN15)

multiPort

(CN6)

Multi-

Function

(CN5)

ISA Bridge Link

(CN4)

Figure 3 CMX158886 Connector Locations

Note Pin 1 of each connector is indicated by a white silk-screened square on the top side of the board and a square solder pad on the bottom side of the board. Pin 1 of the bus connectors match when stacking PC104-Plus or PCI-104 modules.

18 CMX158886 cpuModule BDM-610000049 Rev G

Table 5 CMX158886 Basic Connectors

Connector Function Size

CN3 Auxiliary Power 12-pin

CN4 Bridge Link 4-pin

CN5 Utility Port 10-pin

CN6 multiPort 26-pin

CN7 Serial Port 1 (COM1) 10-pin

CN8 Serial Port 2 (COM2) 10-pin

CN10 EIDE Connector 44-pin

CN11 Audio Connector 10-pin

CN12 External Power Management 3-pin

CN13 RTC Battery Input (optional) 2-pin

CN14 Fan Power (+5V) 2-pin

CN15 Fan Power (switched) 2-pin

CN16 PC/104-Plus (PCI) Bus 120-pin

CN17 USB 2.0 10-pin

CN18 Video (SVGA) 10-pin

CN19 Flat Panel Video (LVDS) 30-pin

CN20 Ethernet 10-pin

U16 ATA/IDE Disk Chip Socket 32-pin

WARNING If you connect power incorrectly, the module will almost certainly be damaged or destroyed. Such damage is not covered by the RTD warranty! Please verify connections to the module before applying power.

Power is normally supplied to the cpuModule through the PCI bus connectors (CN16). If you are placing the cpuModule onto a PC/104-Plus or PCI-104 stack that has a power supply, you do not need to make additional connections to supply power.

If you are using the cpuModule without a PCI-104 or PC/104-Plus stack or with a stack that does not include a power supply, refer to Auxiliary Power (CN3) on page 26 for more details.

Some PCI-104 and PC/104-Plus expansion cards may require +3.3V supplied on the PC/104-Plus (PCI) connector (CN16). To learn how to supply this voltage, refer to Auxiliary Power (CN3) on page 26 and Jumper Settings and Locations on page 86.

BDM-610000049 Rev G Chapter 2: Getting Started 19

Connecting the Utility Cable

The multi-function connector (CN5) implements the following interfaces:

• PC/AT compatible keyboard

• PS/2 mouse port

• Speaker port (0.1W output)

• Hardware Reset input

• Battery input for Real Time Clock

• Soft Power Button input

To use these interfaces, you must connect to the utility port connector (CN5). The utility harness from the RTD cable kit provides a small speaker, two connectors for the keyboard and mouse, a push-button for resetting the PCI-104 system, a soft-power button, and a lithium battery to provide backup power for the real time clock.

Refer to Utility Port Connector (CN5) on page 28 to connect devices to the utility port connector.

Connecting a Keyboard

You may plug a PC/AT compatible keyboard directly into the PS/2 connector of the utility harness in the cable kit.

Note Many keyboards are switchable between PC/XT and AT operating modes, with the mode usually selected by a switch on the back or bottom of the keyboard. For correct operation with this cpuModule, you must select AT mode.

Connecting to the PC/104-Plus (PCI) Bus

Other PC/104-Plus or PCI-104 expansion boards may be connected to the cpuModule’s PC/104-Plus (PCI) bus connector. To connect expansion modules to the PC/104-Plus bus, follow the procedure below to ensure that stacking of the modules does not damage connectors or electronics.

WARNING Do not force the module onto the stack! Wiggling the module or applying too much pressure may damage it. If the module does not readily press into place, remove it, check for bent pins or out-of-place keying pins, and try again.

1. Turn off power to the PC/104-Plus or PCI-104 system or stack.

2. Select and install stand-offs to properly position the cpuModule on the stack.

3. Touch a grounded metal part of the rack to discharge any buildup of static electricity.

4. Remove the cpuModule from its anti-static bag.

5. Check that keying pins in the bus connector are properly positioned.

6. Check the stacking order; if a PCI to ISA bridge card is used to connect any PC/104 modules, make sure an XT bus card will not be placed between two AT bus cards or it will interrupt the AT bus signals.

7. Hold the cpuModule by its edges and orient it so the bus connector pins line up with the matching connector on the stack.

8. Gently and evenly press the cpuModule onto the PC/104-Plus or PCI-104 stack.

There are three additional considerations to make when using the PCI bus:

• Slot selection switches on add-in boards

20 CMX158886 cpuModule BDM-610000049 Rev G

• PCI bus expansion card power

• PCI bus signaling levels

Slot Selection Switches

Unlike PC/104 cards, PC/104-Plus and PCI-104 expansion cards have a “slot” selection switch or jumpers. In total, there are 4 PCI cards that can be stacked onto the cpuModule with switch positions 0 through 3. The distance from the CPU determines these switch settings. The card closest to the CPU is said to be in slot 0, the next closest slot 1 and so on to the final card as slot 3.

Note This requirement means that all PC/104-Plus and PCI-104 cards must be stacked either on the top or the bottom of the CPU, not on both sides.

The “slot” setting method may vary from manufacturer to manufacturer, but the concept is the same. The CPU is designed to provide the correct delay to the clock signals to compensate for the bus length. The correct switch setting ensures the proper clock delay setting, interrupt assignment, and bus grant/request channel assignment. Refer to the expansion board’s manual for the proper settings. Each expansion card must be in a different slot.

PCI Bus Expansion Card Power

+5 Volt DC

The +5 V power pins on the PC/104-Plus (PCI) bus are connected directly to the +5 V pins on the auxiliary power connector, CN3 (pins 2 and 8).

+3.3 Volt DC

Th e +3 .3V p ins on th e PCI bus c an be conf igur ed to be su ppl ied fr om t he po wer c onn ec tor (CN3) or the onboard +3.3V power supply. The factory default configuration connects the +3.3 V pins on the PCI bus to the auxiliary power connector (CN3). This is to ensure that the cpuModule’s onboard +3.3V supply will not supply power to the PC/104-Plus connector while a PC/104-Plus or PCI-104 power supply is already powering the +3.3V pins.

For more information on configuring the +3.3V pins on the PCI bus, contact RTD Technical Support.

PCI Bus Signaling Levels

The PCI bus can operate at +3.3 V or +5 V signaling levels. The default PCI bus signaling level is +3.3 V. For more information, contact RTD Technical Support.

WARNING You will have to ensure that all your expansion cards can operate together at a single signaling level.

BDM-610000049 Rev G Chapter 2: Getting Started 21

Booting the CMX158886 cpuModule for the First Time

You can now apply power to the cpuModule. You will see:

• A greeting message from the VGA BIOS (if the VGA BIOS has a sign-on message)

• The cpuModule BIOS version information

• A message requesting you press Delete to enter the Setup program

If you don’t press Delete, the cpuModule will try to boot from the current settings. If you press Delete, the cpuModule will enter Setup. Once you have configured the cpuModule using Setup, save your changes and reboot.

Note You may miss the initial sign-on messages if your monitor takes a while to power on.

Note By default, cpuModules are shipped with Fail Safe Boot ROM enabled. When Fail Safe Boot ROM

is enabled, the system will boot to it exclusively.

22 CMX158886 cpuModule BDM-610000049 Rev G

Chapter 3 Connecting the cpuModule

This chapter provides information on all CMX158886 cpuModule connectors.

Proper Grounding Techniques—page 24

Connector Locations—page 24

Auxiliary Power (CN3)—page 26

Utility Port Connector (CN5)—page 28

SVGA Video Connector (CN18)—page 31

LVDS Flat Panel Video Connector (CN19)—page 33

EIDE Connector (CN10)—page 34

ATA/ID E D isk Chip Socket ( U 1 6 ) —page 35

Serial Port 1 (CN7) and Serial Port 2 (CN8) —page 37

multiPort™ (CN6) —page 42

USB 2.0 Connector (CN17)—page 45

Ethernet (10/100Base-T and -TX) Connector (CN20)—page 47

Audio (CN11)—page 48

PC/104-Plus PCI Bus (CN16)—page 49

Bridge Link (CN4) —page 52

External Power Management (CN12)—page 53

Optional RTC Battery Input (CN13) —page 53

Fan Power, +5 V (CN14)—page 53

Fan Power, Switched (CN15)—page 54

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 23

Proper Grounding Techniques

Before removing the CMX158886 from its static bag, proper grounding techniques must be used to prevent electrostatic discharge (ESD) damage to the cpuModule. Common grounding procedures include an anti-static mat on a workbench, which may connect to an anti-static wrist strap (also known as an ESD wrist strap) on the wrist of the technician or engineer.

Connector Locations

Figure 4 shows the connectors and the ATA/IDE Disk Chip socket of the CMX158886 cpuModule.

SVGA Video

(CN18)

LVDS Flat

Panel

(CN19)

COM2

(CN8)

USB 2.0 (CN17)

Ethernet

(CN20)

ATA /I D E

Disk Chip

(U16)

Cont. Fan

(CN14)

Power

Mngmt.

(CN12)

Auxiliary Power

(CN3)

PCI Bus (CN16)

Battery (CN13)

EIDE (CN10)

Audio

(CN11)

COM1

(CN7)

Switched

Fan

(CN15)

multiPort

(CN6)

Multi-

Function

(CN5)

ISA Bridge Link

(CN4)

Figure 4 CMX158886 Connector Locations

24 CMX158886 cpuModule BDM-610000049 Rev G

Table 6 CMX158886 Basic Connectors

Connector Function Size

CN3 Auxiliary Power 12-pin

CN4 Bridge Link 4-pin

CN5 Utility Port 10-pin

CN6 multiPort 26-pin

CN7 Serial Port 1 (COM1) 10-pin

CN8 Serial Port 2 (COM2) 10-pin

CN10 EIDE Connector 44-pin

CN11 Audio Connector 10-pin

CN12 External Power Management 3-pin

CN13 RTC Battery Input (optional) 2-pin

CN14 Fan Power (+5V) 2-pin

CN15 Fan Power (switched) 2-pin

CN16 PC/104-Plus (PCI) Bus 120-pin

CN17 USB 2.0 10-pin

CN18 Video (SVGA) 10-pin

CN19 Flat Panel Video (LVDS) 30-pin

CN20 Ethernet 10-pin

U16 ATA/IDE Disk Chip Socket 32-pin

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 25

Auxiliary Power (CN3)

The Auxiliary Power connector (CN3) can be used to supply power to devices that are attached to the cpuModule. These devices include hard drive, front-end boards for data acquisition systems, and other devices.

Power can also be conveyed to the module through the Auxiliary Power connector (CN3). The cpuModule only requires +5 V –12 V be used to supply these voltages.

If using the Auxiliary Power connector to power the system, care must be taken to ensure a good power connections. The power and ground leads must be twisted together, or as close together as possible to reduce lead inductance. A separate lead must be used for each of the power pins. Both 5V pins must be connected. The gauge of wire must be selected taking into account the total power of the system. A good rule of thumb is to use wire that can supply twice the power required by the system, and do not use less than 18 gauge wire. The length of the wire must not exceed 3 ft. The power supply solution must be verified by measuring voltage at the Auxiliary Power Connector and verifying that it does not drop below 4.75 V. The voltage at the connector should be checked with an oscilloscope while the system is operational.

DC and ground for operation; however, other modules in the system may require +3.3V, +12 VDC,

DC, and –5 VDC. In these instances, the corresponding pins on the Auxiliary Power Connector (CN3) may

Note Although it is possible to power the cpuModule through the Auxiliary Power connector, the preferred method is to power it through the bus connector from a power supply in the stack. The cpuModule can have large current transients during operation, which make powering it through wires difficult. Powering through the bus eliminates such problems as voltage drop and lead inductance.

WARNING If you connect power incorrectly, the module will almost certainly be destroyed. Please verify power connections to the module before applying power.

Table 7 Auxiliary Power Connector (CN3)

Pin Signal Function

1 GND Ground

2 +5 V +5 Volts DC

3 +5V_STDBY +5V Standby (ATX)

4 +12 V +12 Volts DC

5 Reserved Reserved

6 –12 V –12 Volts DC

7 GND Ground

8 +5 V +5 Volts DC

9 GND Ground

10 +3.3 V See note below

11 PSON# Power Supply On (ATX)

12 +3.3 V See note below

1. For more information on the ATX style signals, +5V Standby and PSON#, refer to the Power Management section in Chapter 4, Using the cpuModule.

26 CMX158886 cpuModule BDM-610000049 Rev G

Note The +3.3 V pins (10 and 12) on the auxiliary power connector (CN3) are connected to the +3.3 V pins on the PC/104-Plus bus by default. These pins are also configured to supply +3.3V to FP_VCC on the LVDS Flat Panel Video connector (CN19).

Note For more information on configuring the +3.3V pins on the auxiliary power connector (CN3) the PCI bus connector (CN16), or the LVDS FLat Panel Video connector (CN19), contact RTD Technical Support.

Facing the connector pins, the pinout of the Auxiliary Power connector is:

1197531

PSON# GND GND Reserved +5V_STDBY GND

+3.3 V +3.3 V +5 V –12 V +12 V +5 V

12108642

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 27

Utility Port Connector (CN5)

The utility port connector implements the following functions:

• PC/AT compatible keyboard port

• PS/2 mouse port

• Speaker port (0.1W output)

• Hardware Reset input

• Battery input for Real Time Clock

• Soft Power Button input

Table 8 provides the pinout of the multi-function connector.

Table 8 Utility Port Connector (CN5)

Pin Signal Function In/Out

1 SPKR+ Speaker Output (open collector) out

2 PWR +5 V out

3 RESET Manual Push-Button Reset in

4 PWRSW Soft Power Button in

5KBDKeyboard Data in/out

6KBCKeyboard Clock out

7 GND Ground —

8MSCMouse Clock out

9BATRTC Battery Input in

10 MSD Mouse Data in/out

Facing the connector pins, the pinout is:

9 7 531

BAT GND KBD RESET SPKR+

MSD MSC KBC PWRSW PWR

10 8 642

Speaker

A speaker output is available on pins 1 and 2 of the multi-function connector. These outputs are controlled by a transistor to supply 0.1 W of power to an external speaker. The external speaker should have 8 Ω impedance and be connected between pins 1 and 2.

28 CMX158886 cpuModule BDM-610000049 Rev G

Keyboard

A PS/2 compatible keyboard can be connected to the multi-function connector. Usually PC keyboards come with a cable ending with a 5-pin male PS/2 connector. Table 9 lists the relationship between the multi-function connector pins and a standard PS/2 keyboard connector.

Table 9 Keyboard Connector Pins (CN5)

Pin Signal Function PS/2

5KBDKeyboard Data 1

6KBCKeyboard Clock 5

7 GND Ground 3

2 PWR Keyboard Power (+5 V) 4

To ensure correct operation, check that the keyboard is either an AT compatible keyboard or a switchable XT/AT keyboard set to AT mode. Switchable keyboards are usually set by a switch on the back or bottom of the keyboard.

Mouse

A PS/2 compatible mouse can be connected to the multi-function connector. Table 10 lists the relationship between the multi-function connector pins and a standard PS/2 mouse connector.

Table 10 Mouse Connector Pins (CN5)

Pin Signal Function PS/2

10 MSD Mouse Data 1

8MSCMouse Clock 5

7 GND Ground 3

2 PWR Keyboard Power (+5 V) 4

System Reset

Pin 3 of the multi-function connector allows connection of an external push-button to manually reset the system. The push-button should be normally open, and connect to ground when pushed.

Soft Power Button

Pin 4 of the multi-function connector allows connection of an external push-button to send a soft power signal to the system. The push-button should be normally open, and connect to ground when pushed. For more information on the modes of the Soft Power Button, refer to the Power Management section in Chapter 4, Using the cpuModule.

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 29

Battery

Pin 9 of the multi-function connector is the connection for an external backup battery. This battery is used by the cpuModule when system power is removed in order to preserve the date and time in the real time clock.

Connecting a battery is only required to maintain time when power is completely removed from the cpuModule. A battery is not required for board operation.

WARNING The optional RTC battery input connector (CN13) should be left unconnected if the multi-function connector (CN5) has a battery connected to pin 9.

30 CMX158886 cpuModule BDM-610000049 Rev G

SVGA Video Connector (CN18)

Table 11 provides the pinout of the video connector.

Table 11 SVGA Video Connector (CN18)

Pin Signal Function In/Out

1VSYNCVertical Sync out

2 HSYNC Horizontal Sync out

3 DDCSCL Monitor Communications Clock out

4 RED Red Analog Output out

5 DDCSDA Monitor Communications Data bidirectional

6 GREEN Green Analog Output out

7 PWR +5 V out

8 BLUE Blue Analog Output out

9 GND Ground out

10 GND Ground out

Facing the connector pins of the SVGA Video connector (CN18), the pinout is:

97531

GND PWR DDCSDA DDCSCL VSYNC

GND BLUE GREEN RED HSYNC

108642

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 31

The following table lists the supported video resolutions.

Tabl e 12 SV G A Vi d eo R e so l uti o ns

Resolution Colors Refresh Rates

640 x 480 16, 256, 64k, 16M 60, 70, 72, 75, 85, 100, 120 Hz

720 x 480 256, 64k, 16M 60 Hz

720 x 576 256, 64k, 16M 50 Hz

800 x 600 16, 256, 64k, 16M 60, 70, 72, 75, 85, 100, 120 Hz

960 x 540 256, 64k, 16M 60 Hz

1024 x 768 256, 64k, 16M 60, 70, 75, 85, 100, 120 Hz

1152 x 864 256, 64k, 16M 60, 70, 72, 75, 85, 100 Hz

1280 x 720 256, 64k, 16M 60, 75, 85, 100 Hz

1280 x 768 256, 64k, 16M 60, 75, 85 Hz

1280 x 960 256, 64k, 16M 60, 75, 85 Hz

1280 x 1024 256, 64k, 16M 60, 70, 72, 75, 85, 100, 120 Hz

1400 x 1050 256, 64k, 16M 60, 75, 85 Hz

1600 x 900 256, 64k, 16M 60, 75, 85, 100, 120 Hz

1600 x 1200 256, 64k, 16M 60, 65, 70, 72, 75, 85, 100, 120 Hz

1856 x 1392 256, 64k, 16M 60, 75 Hz

1920 x 1080 256, 64k, 16M 50, 60, 75, 85, 100 Hz

1920 x 1200 256, 64k, 16M 60, 75 Hz

1920 x 1440 256, 64k, 16M 60, 75, 85 Hz

2048 x 1536 256, 64k, 16M 60, 75 Hz

32 CMX158886 cpuModule BDM-610000049 Rev G

LVDS Flat Panel Video Connector (CN19)

Table 13 provides the pinout of the Flat Panel Video connector (CN19). FP_VCC is configured for +3.3V by default. Contact RTD to have FP_VCC configured for +5 V. FP_VBKLT can be either +5 V or +12 V, and can be selected with JP9. See Jumper Settings and Locations on page 86 for more details.

Table 13 Flat Panel Video Connector (CN19)

Pin Signal Function In/Out

1 Y0P LVDS Data 0+ out

2 Y0M LVDS Data 0- out

3DDC_CLK

4 GND Ground GND

5 Y1P LVDS Data 1+ out

6 Y1M LVDS Data 1- out

7 DDC_DATA

8 GND Ground GND

9 Y2P LVDS Data 2+ out

10 Y2M LVDS Data 2- out

11 GND Ground GND

12 GND Ground GND

13 YCP LVDS Clock+ out

14 YCM LVDS Clock- out

15 Y3P LVDS Data 3+ out

16 Y3M LVDS Data 3- out

17 GND Ground GND

18 FP_VCC

19 FP_VBKLT Power for flat panel backlight out

20 FP_ENABLK Enable for Backlight Power out

1. The DDC signals use a +3.3 V signal level, and are not +5 V tolerant.

2. When configured for +3.3 V, FP_VCC is sourced from the auxiliary p ower connector (CN3) or PC/104-Plus connector (CN16).

Panel Detection Clock out

Panel Detection Data in/out

Power for flat panel electronics out

Tab le 14 l ist s sev eral LVDS pane ls t hat wer e te ste d wit h th is c puMo dule. Whe n eva luating a pan el t o be u sed wi th this cpuModule, review the specifications of the tested panels to assure compatability.

Tab l e 1 4 Test e d LVDS Pan e ls

Manufacturer Model Number Resolution Color Depth

Optrex T-51756D121J-FW-A-AA 1024 x 768 18 bit

Optrex T-51639D084JU-FW-A-AB 1024 x 768 24 bit

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 33

EIDE Connector (CN10)

The EIDE connector is a 44-pin, 2 mm connector that can connect to a variety of EIDE or IDE devices. The connector provides all signals and power needed to use a 2.5-inch form factor (laptop) hard drive. Also, the first 40 pins of the connector provide all of the signals needed to interface to a 3.5-inch or 5-inch form factor hard drive, CD-ROM drive, or other EIDE device. The larger form factors use a 40-pin, 0.1 inch spacing connector, so an adapter cable or adapter board is needed to connect to CN10.

Pin Signal Pin Signal

1RESET# 2GND

3 DD7 4 DD8

5 DD6 6 DD9

7 DD5 8 DD10

9 DD4 10 DD11

11 DD3 12 DD12

13 DD2 14 DD13

15 DD1 16 DD14

17 DD0 18 DD15

19 GND 20 N/C

Table 15 EIDE Connector (CN10)

21 DMARQ 22 GND

23 DIOW#:STOP 24 GND

25 DIOR#:HDMARDY#:HSTROBE 26 GND

27 IORDY:DDMARDY#:DSTROB 28 GND

29 DMACK# 30 GND

31 INTRQ 32 N/C

33 DA1 34 PDIAG

35 DA0 36 DA2

37 CS0# 38 CS1#

39 DASP# 40 GND

41 +5 V (logic) 42 +5 V (motor)

43 GND 44 N/C

1. Signals marked with (#) are active low.

34 CMX158886 cpuModule BDM-610000049 Rev G

ATA/IDE Disk Chip Socket (U16)

The ATA/IDE Disk Chip socket is a 32-pin socket that supports +3.3V or +5V miniature ATA/IDE flash disk chips. The socket allows a true IDE device to be attached to the board with either a socketed or soldered connection. Such true IDE devices are supported by all major operating systems, and do not require special drivers.

WARNING The ATA/IDE Disk Chip socket does not support conventional SSD memory devices or devices that install as a BIOS extension (such as the M-Systems DiskOnChip®). I f such a device is installed, the cpuModule and device will almost certainly be destroyed.

Table 16 ATA/IDE Disk Chip Socket (U16)

Pin Signal Pin Signal

1 RESET# 32 VDD

2D7 31D8

3D6 30D9

4D5 29D10

5D4 28D11

6D3 27D12

7D2 26D13

8D1 25D14

9D0 24D15

10 DMARQ/WP# 23 IOWR#

11 IORD# 22 DMACK/CSEL

12 INTRQ 21 IOCS16#

13 A1 20 PDIAG#

14 A0 19 A2

15 CS1FX# 18 CS3FX#

16 GND 17 DASP#

1. Signals marked with (#) are active low.

2. The hardware default configuration for VDD is +3.3 V, but this pin may also be configured as +5 V. For more information, contact RTD Technical Support.

Installing and Configuring the ATA/IDE Disk Chip

To ensure proper installation and of the ATA/IDE Disk Chip, follow the following configuration steps. Note that the first few steps must be performed before installing the Disk Chip.

1. Before installing the ATA/IDE Disk Chip in the Disk Chip Socket (U16), verify that cpuModule is

configured for the correct Disk Chip supply voltage. The hardware default configuration is +3.3V. To use a +5 V Disk Chip with cpuModules, contact RTD Technical Support.

2. Next, apply power to the system, and press the delete key repeatedly to enter the BIOS setup screen. Once in the BIOS, specify the following settings:

a. Enable the cpuModule’s secondary IDE channel.

b. Specify the IDE mode of the ATA/IDE Disk Chip. For more information on the supported IDE

modes, refer to Configuring the ATA/IDE Disk Chip Socket section of this manual on page 68.

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 35

c. Save the settings in the BIOS setup

3. Remove power from the system.

WARNING The preceding steps should be performed before installing the Disk Chip in the ATA/IDE Disk Chip Socket. These steps ensure that the system is properly configured for the correct device and supply voltage, so neither the Disk Chip or cpuModule are damaged.

4. Insert the Disk Chip in the ATA/IDE Disk Chip Socket (U16) aligning pin 1 with the square solder pad on the board.

5. Apply power to the system.

6. Re-enter the BIOS and set the boot order of the system accordingly.

ATA/IDE Disk Chip Socket (U16)

Pin 1 indicated by arrow

Figure 5 CMX158886 before and after ATA/IDE Disk Chip Installation

ATA/ IDE Disk C hip

Pin 1 indicated by arrow

36 CMX158886 cpuModule BDM-610000049 Rev G

Serial Port 1 (CN7) and Serial Port 2 (CN8)

Serial Port 1 (COM1) is implemented on connector CN7, and Serial Port 2 is implemented on connector CN8. The serial ports are normally configured as PC compatible full-duplex RS-232 ports, but you may use the BIOS Setup program to reconfigure these ports as half-duplex RS-422 or full-duplex RS-422 or RS-485. If you reconfigure the ports, you must also select the I/O address and corresponding interrupt using Setup. Table 17 provides the available I/O addresses and corresponding interrupts.

Tabl e 17 Seria l Por t Se tt i ng s

I/O Address (hex) IRQ

03F8 IRQ4

02F8 IRQ3

03E8 IRQ4

02E8 IRQ3

Serial Port UART

The serial ports are implemented with a 16550-compatible UART (Universal Asynchronous Receiver/Transmitter). This UART is capable of baud rates up to 115.2 kbaud in 16450 and 16550A compatible mode, and includes a 16-byte FIFO. Refer to any standard PC-AT hardware reference for the register map of the UART. For more information about programming UARTs, refer to Appendix D.

RS-232 Serial Port (Default)

The default serial port mode is full-duplex RS-232. With this mode enabled, the serial port connectors must be connected to RS-232 compatible devices. Table 18 provides the serial port connector pinout and shows how to connect to an external DB-25 or DB-9 compatible serial connector.

Table 18 Serial Port in RS-232 Mode

Pin Signal Function In/Out DB-25 DB-9

1 DCD Data Carrier Detect in 8 1

2DSRData Set Ready in66

3RXDReceive Data in32

4RTSRequest To Send out47

5 TXD Transmit Data out 2 3

6CTSClear To Send in58

7 DTR Data Terminal Ready out 20 4

8RIRing Indicate in229

9,10 GND Signal Ground — 7 5

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 37

Facing the serial port’s connector pins, the pinout is:

9 7531

GND DTR TXD RXD DCD

GND RI CTS RTS DSR

108642

RS-422 or RS-485 Serial Port

You may use Setup to configure the serial ports as RS-422 or RS-485. In this case, you must connect the serial port to an RS-422 or RS-485 compatible device.

When using RS-422 or RS-485 mode, you can use the serial ports in either half-duplex (two-wire) or full-duplex (four-wire) configurations. For half-duplex (2-wire) operation, you must connect RXD+ to TXD+, and connect RXD– to TXD–.

Note The cpuModule has a 120 Ω termination resistor. Termination is usually necessary on all RS-422 receivers and at the ends of the RS-485 bus.

Note If required, the termination resistor can be enabled by closing jumper JP1 for Serial Port 1 (COM1),JP2 for Serial Port 2 (COM2), JP11 for Serial Port 3 (COM3), and JP13 for Serial Port 4 (COM4).

When using full-duplex (typically in RS-422 mode), connect the ports as shown in Table 19.

Table 19 Full-Duplex Connections

Port 1 Port 2

RXD+ TXD+

TXD+ RXD+

RXD– TXD–

TXD– RXD–

When using half-duplex in RS-485 mode, connect the ports as shown in Table 20.

Table 20 Half-Duplex RS-485 Mode

From To

Port 1 TXD+ Port 1 RXD+

Port 1 TXD– Port 1 RXD–

Port 1 TXD+ Port 2 RXD+

Port 1 RXD– Port 2 TXD–

38 CMX158886 cpuModule BDM-610000049 Rev G

RS-422 and RS-485 Mode Pinout

Table 21 provides the serial port connector pinout when RS-422 or RS-485 modes are enabled.

Table 21 Serial Port in RS-422/485 Mode

Pin Signal Function In/Out DB-9

1—Reserved —1

2—Reserved —6

3 RXD– Receive Data (–) in 2

4TXD+Transmit Data (+)out7

5TXD–Transmit Data (–)out3

6 RXD+ Receive Data (+) in 8

7—Reseved —4

8—Reseved —9

9,10 GND Signal Ground out 5

Facing the serial port connector, the pinout is:

97531

GND Rsvd TXD- RXD- Rsvd

GND Rsvd RXD+ TXD+ Rsvd

10 8 6 4 2

Note When using the serial port in RS-485 mode, the serial transmitters are enabled and disabled under software control. The transmitters are enabled by manipulating the Request To Send (RTS*) signal of the serial port controller. This signal is controlled by writing bit 1 of the Modem Control Register (MCR) as follows:

•

If MCR bit 1 = 1, then RTS* = 0, and serial transmitters are disabled

• If MCR bit 1 = 0, then RTS* = 1, and serial transmitters are enabled

Note For more information on the serial port registers, including the MCR, refer to the Serial Port Programming reference in Appendix D.

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 39

Dual Serial Port Modes

The serial port connectors can be configured as dual serial ports in the BIOS. The mapping between the connectors and COM port numbers is shown in Table 22. The supported combinations of serial port modes are listed in Table 23, which also includes a reference to the corresponding connector pinout. For the configurations that have RS-422 or RS-485 on COM B, a jumper must be installed.

Table 22 Dual Serial Port Connections

Connector COM A COM B

CN7 COM 1 COM 3

CN8 COM 2 COM 4

Table 23 Dual Serial Port Modes

COM A COM B Pinout

Reference

RS-232 RS-232 Table 24 Not Installed

RS-422 RS-232 Table 25 Not Installed

RS-422 RS-422 Table 26 CN7: JP12

RS-485 RS-232 Table 25 Not Installed

RS-485 RS-485 Table 26 CN7: JP12

JP12/JP14

CN8: JP14

Table 24 COM A (RS-232) and COM B(RS-232)

Pin Signal Function In/Out DB-9

1 DCD1 COM A- Data Carrier Detect in 1

2 RXD2 COM B- Receive Data in 6

3 RXD1 COM A - Receive Data in 2

4 RTS1 COM A - Request To Send out 7

5 TXD1 COM A - Transmit Data out 3

6 CTS1 COM A - Clear To Send in 8

7 TXD2 COM B - Transmit Data out 4

8 RI1 COM A - Ring Indicate in 9

9,10 GND Signal Ground — 5

40 CMX158886 cpuModule BDM-610000049 Rev G

Table 25 COM A (RS-422/485) and COM B (RS-232)

Pin Signal Function In/Out DB-9

1 DCD1 COM A - Data Carrier Detect in 1

2 RXD2 COM B - Receive Data in 6

3 RXD1- COM A - Receive Data (–) in 2

4 TXD1+ COM A - Transmit Data (+) out 7

5 TXD1- COM A - Transmit Data (–) out 3

6RXD1+COM A - Receive Data (+) in8

7 TXD2 COM B - Transmit Data out 4

8 RI1 COM A - Ring Indicate in 9

9,10 GND Signal Ground — 5

Table 26 COM A (RS-422/485) and COM B (RS-422/485)

Pin Signal Function In/Out DB-9

1 RXD2+ COM B - Receive Data (+) in 1

2 RXD2- COM B - Receive Data (–) in 6

3 RXD1- COM A - Receive Data (–) in 2

4 TXD1+ COM A - Transmit Data (+) out 7

5 TXD1- COM A - Transmit Data (–) out 3

6RXD1+COM A - Receive Data (+) in8

7 TXD2- COM B - Transmit Data (–) out 4

8 TXD2+ COM B - Transmit Data (+) out 9

9,10 GND Signal Ground — 5

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 41

multiPort™ (CN6)

RTD’s exclusive multiPort can be configured as an Advanced Digital I/O (aDIO™), a parallel port, or a floppy drive. Refer to Chapter 4, Using the cpuModule, to configure the multiPort.

multiPort Electrostatic Discharge (ESD) and Undershoot Protection

The multiPort interface provides electrostatic discharge (ESD) protection allowing the aDIO port, parallel port, and floppy port circuits to be protected from electrically charged external objects that may come in contact with the cpuModule.

The ESD protection minimizes susceptibility of the circuitry to ESD from human contact, and is rated to withstand up to 2000V with the Human Body Model (HBM) standardized ESD test. The protected circuitry is also rated to protect against up to 1000V with the Charged Device Model (CDM) standardized ESD test.

In addition to the ESD protection, the circuitry also provides -2V undershoot protection by ensuring that the pins remain in the off state when such voltage levels are connected as inputs to the cpuModule.

For specific electrical characteristics, refer to Table 4 on page 13.

multiPort Configured as an Advanced Digital I/O (aDIO™) Port

The mulitPort connector (CN6) can be configured as an aDIO port. aDIO is 16 digital bits configured as 8-bit programmable and 8-bit port programmable I/O, providing any combination of inputs and outputs. Match, event, and strobe interrupt modes mean no more wasting valuable processor time polling digital inputs. Interrupts are generated when the 8-bit programmable digital inputs match a pattern, or on any value change event. Bit masking allows selecting any subgroup of 8 bits. The strobe input latches data into the bit programmable port and generates an interrupt. Refer to multiPort: Advanced Digital I/O Ports (aDIO™) on page 62 for information on programming the multiPort.

Tab l e 2 7 mul tiPo rt aD I O Pi nou t

CN6 Pin Function CN6 Pin Function

1strobe 02 P0-4

3P1-04P0-5

5P1-16P0-6

7P1-28P0-7

9P1-310strobe 1

11 P1-4 12 GND

13 P1-5 14 GND

15 P1-6 16 GND

17 P1-7 18 GND

19 P0-0 20 GND

21 P0-1 22 GND

23 P0-2 24 GND

25 P0-3 26 +5 V

42 CMX158886 cpuModule BDM-610000049 Rev G

multiPort Configured as a Parallel Port

The parallel port is available on connector CN6. Make sure the multiPort in the BIOS Setup is configured to parallel port. You can use the BIOS Setup to select the parallel port’s address and associated interrupt, and choose between its operational modes (SPP, ECP, EPP 1.7, and EPP 1.9).

The pinout of the connector enables a ribbon cable to be connected directly to a DB-25 connector, thus providing a standard PC compatible port.

Note For correct operation, keep the length of the cable connecting the cpuModule and parallel device less than 3 meters (10 feet).

Table 28 lists the parallel port signals and explains how to connect it to a DB-25 connector to obtain a PC compatible port.

Table 28 multiPort Connector (CN6) as a Parallel Port

CN6 Pin Signal Function In/Out DB-25

1STBStrobe Data out1

2AFDAutofeed out14

3 PD0 Printer Data 0 (LSB) out 2

4ERRPrinter Error in15

5 PD1 Parallel Data 1 out 3

6 INIT Initialize Printer out 16

7 PD2 Printer Data 2 out 4

8SLINSelect Printer out17

9 PD3 Printer Data 3 out 5

10 GND Signal Ground — 18

11 PD4 Printer Data 4 out 6

12 GND Signal Ground — 19

13 PD5 Printer Data 5 out 7

14 GND Signal Ground — 20

15 PD6 Printer Data 6 out 8

16 GND Signal Ground — 21

17 PD7 Printer Data 7 (MSB) out 9

18 GND Signal Ground — 22

19 ACK Acknowledge in 10

20 GND Signal Ground — 23

21 BSY Busy in 11

22 GND Signal Ground — 24

23 PE Paper End in 12

24 GND Signal Ground — 25

25 SLCT Ready To Receive in 13

26 — +5 V — —

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 43

multiPort Configured as a Floppy Drive Controller

The multiPort (CN6) can be configured to be a floppy drive controller. This can be configured in the BIOS Setup under Integrated Peripherals. For more information on configuring the multiPort in the BIOS Setup, refer to page 66

Table 29 shows the pin assignments to connect a floppy drive to the multiPort.

Table 29 multiPort Connector Floppy Pinout (CN6)

CN6 Pin Function DB-25 Floppy Drive Pin

1DS0#1 14

2DR014 2

3INDEX#2 8

4 HDSEL# 15 32

5 TRK0# 3 26

6DIR#16 18

7 WRTPRT# 4 28

8 STEP# 17 20

9RDATA#5 30

10 GND 18 —

11 DSKCHG 6 34

12 GND 19 odd pins

13 — 7 —

14 GND 20 odd pins

15 MTR0# 8 10

16 GND 21 odd pins

17 — 9 —

18 GND 22 odd pins

19 DS1# 10 12

20 GND 23 odd pins

21 MTR1# 11 16

22 GND 24 odd pins

23 WDATA# 12 22

24 GND 25 odd pins

25 WGATE# 13 24

26 +5 V — —

1. Signals marked with (#) are active low.

2. These signals must be pulled to 5V with separate 470 Ohm resistors.

44 CMX158886 cpuModule BDM-610000049 Rev G

USB 2.0 Connector (CN17)

Two USB 2.0 compliant connectors are available on connector CN17. Table 30 provides the pinout of the USB connector.

Note For proper operation at USB 2.0 speeds, be sure to use a cable that is rated for USB 2.0, such as the cable kit supplied by RTD.

Pin Signal Function In/Out

1 VCC1 Supply +5 V to USB1 out

2 VCC2 Supply +5 V to USB2 out

3 DATA1– Bidirectional data line for USB1 in/out

4 DATA2– Bidirectional data line for USB2 in/out

5 DATA1+ Bidirectional data line for USB1 in/out

6 DATA2+ Bidirectional data line for USB2 in/out

7 GND Ground out

8 GND Ground out

9 GND Ground out

10 GND Ground out

Table 30 USB Connector (CN17)

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 45

Facing the connector pins, the pinout of CN17 is:

97 5 3 1

G ND G ND DATA 1 + D ATA1 – V CC 1

G ND G ND DATA 2 + D ATA2 – V CC 2

108642

46 CMX158886 cpuModule BDM-610000049 Rev G

Ethernet (10/100Base-T and -TX) Connector (CN20)

The functionality of the Ethernet port is based on the Intel 82562 Fast Ethernet PCI controller. Table 31 provides the pinout of the Ethernet connector.

Table 31 Ethernet Connector (CN20)

RJ-45 Pin 10-Pin DIL Pin Signal Function In/Out

31RX+Receive+ in

62RX–Receive– in

1 5 TX+ Transmit+ out

26TX–Transmit– out

4 3 CT Termination connected to pin 4 —

5 4 CT Termination connected to pin 3 —

7 7 CT Termination connected to pin 8 —

8 8 CT Termination connected to pin 7 —

— 9 AGND Ground —

—10AGNDGround —

97 5 3 1

AGND CT TX+ CT RX+

AGND CT TX– CT RX–

108642

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 47

Audio (CN11)

A full featured AC97 compliant audio port is available on CN11. It provides a mono microphone input, stereo line level input, and a stereo output that can be configured as line level or headphone level. The output is configured in the BIOS setup utility. When used as a headphone output, it will drive 32 Ohm speaker at 50mW.

Table 32 Audio Connector (CN11)

10-Pin DIL Pin Signal Function In/Out

1 MIC_VREF 2.2V Supply to bias

microphones. 5mA max.

2MIC_IN Microphone input. 1V RMS or

0.1V RMS.

3 GND Signal GND GND

4 LINE_IN_LEFT Line level input for left channel.

1V RMS nominal.

5 GND Signal GND GND

6 LINE_IN_RIGHT Line level input for right channel.

1V RMS nominal.

7 GND Signal GND GND

8 OUTPUT_LEFT Left channel output. Selectable

as line level (1V RMS) or headphone.

9 GND Signal GND GND

10 OUTPUT_RIGHT Left channel output. Selectable

as line level (1V RMS) or headphone.

97531

out

GND GND GND GND MIC_VREF

OUTPUT_RIGHT OUTPUT_LEFT LINE_IN_RIGHT LINE_IN_LEFT MIC_IN

108642

48 CMX158886 cpuModule BDM-610000049 Rev G

PC/104-Plus PCI Bus (CN16)

Connector CN16 carries the signals of the PC/104-Plus PCI bus. These signals match definitions of the PCI Local Bus specification Revision 2.1. Table 33 list the pinouts of the PC/104-Plus bus connector.

Table 33 PC/104-Plus Bus Signal Assignments

Pin A B C D

1GNDReserved/+5V_STDBY

+5 V AD00

2 VIO AD02 AD01 +5 V

3 AD05 GND AD04 AD03

4C/BE0# AD07 GND AD06

5 GND AD09 AD08 GND

6AD11 VIO AD10 M66EN

7 AD14 AD13 GND AD12

8 +3.3 V C/BE1# AD15 +3.3 V

9SERR# GND Reserved / PSON#

10 GND PERR# +3.3 V Reserved / PME#

PAR

11 STOP# +3.3 V LOCK# GND

12 +3.3 V TRDY# GND DEVSEL#

13 FRAME# GND IRDY# +3.3 V

14 GND AD16 +3.3 V C/BE2#

15 AD18 +3.3 V AD17 GND

16 AD21 AD20 GND AD19

17 +3.3 V AD23 AD22 +3.3 V

18 IDSEL0 GND IDSEL1 IDSEL2

19 AD24 C/BE3# VIO IDSEL3

20 GND AD26 AD25 GND

21 AD29 +5 V AD28 AD27

22 +5 V AD30 GND AD31

23 REQ0# GND REQ1# VIO

24 GND REQ2# +5 V GNT0#

25 GNT1# VIO GNT2# GND

26 +5V CLK0 GND CLK1

27 CLK2 +5 V CLK3 GND

28 GND INTD# +5 V RST#

29 +12 V INTA# INTB# INTC#

30 –12V REQ3# GNT3# GND

1. Signals marked with (#) are active low.

2. Optional signals for ATX power management

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 49

PC/104-Plus PCI Bus Signals

The following are brief descriptions of the PC/104-Plus PCI bus signals.

Address and Data

AD[31:00] — Address and Data are multiplexed. A bus transaction consists of an address cycle followed by

one or more data cycles.

C/BE[3:0]# — Bus Command/Byte Enables are multiplexed. During the address cycle, the command is defined. During the Data cycle, they define the byte enables.

PAR — Parity is even on AD[31:00] and C/BE[3:0]# and is required.

Interface Control Pins

FRAME# — Frame is driven by the current master to indicate the start of a transaction and will remain

active until the final data cycle.

TRDY# — Target Ready indicates the selected devices ability to complete the current data cycle of the transaction. Both IRDY# and TRDY# must be asserted to terminate a data cycle.

IRDY# — Initiator Ready indicates the master's ability to complete the current data cycle of the transaction.

STOP# — Stop indicates the current selected device is requesting the master to stop the current

transaction.

DEVSEL# — Device Select is driven by the target device when its address is decoded.

IDSEL[3:0] — Initialization Device Select is used as a chip-select during configuration.

LOCK# — Lock indicates an operation that may require multiple transactions to complete.

Error Reporting

PERR# — Parity Error is for reporting data parity errors.

SERR# — System Error is for reporting address parity errors.

Arbitration (Bus Masters Only)

REQ[3:0]# — Request indicates to the arbitrator that this device desires use of the bus.

GNT[3:0]# — Grant indicates to the requesting device that access has been granted.

System

CLK — Clock provides timing for all transactions on the PCI bus.

RST# — Reset is used to bring PCI-specific registers to a known state.

Interrupts

INTA# — Interrupt A is used to request Interrupts.

INTB# — Interrupt B is used to request Interrupts only for multi-function devices.

INTC# — Interrupt C is used to request Interrupts only for multi-function devices.

INTD# — Interrupt D is used to request Interrupts only for multi-function devices.

50 CMX158886 cpuModule BDM-610000049 Rev G

Power Supplies and VIO

+5 V — +5 V supply connected to the PC/104 bus and Auxiliary Power Connector (CN3) +5 V supplies. This

is the only power supply that is required for board operation.

+12 V — +12 V supply connected to the PC/104 bus and Auxiliary Power Connector (CN3) +12 V supplies.

–12 V — –12 V supply connected to the PC/104 bus and Auxiliary Power Connector (CN3) –12 V supplies.

+3.3 V — The +3.3 V pins on the PC/104-Plus (PCI) connector are connected to the Auxiliary Power

Connector (CN3) by default. To supply +3.3V via the onboard +3.3V power supply, contact RTD Technical Support.

VIO — This signal is typically the I/O power to the bus drivers on a PCI bus card, or used by the clamp diodes on a PCI bus card. This is always driven by the cpuModule. By default, the signaling level is set to +3.3 V. For information on configuring VIO for +5 V, contact RTD Technical Support.

ATX Power Management Signals (optional)

If an ATX power supply is connected to the system, the following signals listed below may be used to wake the system from low power modes. For more information on these signals, refer to the Power Management section on page 73.

+5V_STDBY — Some low power modes require that +5 V standby power is applied to the cpuModule during the wake event. This signal is an input to the CPU.

PME# — Power Management Event input

PSON# — This is an active low open-drain output used to turn the power supply on when the system is

exiting a low power state.

Note Use of these signals will require board customization. For more information, contact the RTD.

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 51

Bridge Link (CN4)

The Bridge Link connector allows devices that requires Legacy/ISA interrupts to interface with the cpuModule. When ISA devices are installed in the system (via a PCI to ISA bridge card), the Bridge Link connector provides Legacy/ISA DMA request signals, as well as a serial interrupt signal which permits access to all available system interrupts.

Multiple devices may utilize the serial interrupt signal, SERIRQ, which is decoded on the cpuModule. Only one device may use the DMA request and grant signal pair.

Facing the connector pins, the pinout is:

Table 34 Bridge Link (CN4)

Pin Signal Function

1GNDGround

2 DMAREQ Legacy/ISA DMA Request

3 SERIRQ Serial Interrupt Request

4 DMAGNT Legacy/ISA DMA Grant

SERIRQ GND

DMAGNT DMAREQ

52 CMX158886 cpuModule BDM-610000049 Rev G

External Power Management (CN12)

An external power management connector (CN12) is available for external devices to wake the system from low power states. Some low power modes require that +5 V standby power is applied to the cpuModule during the wake event.

For more information on power management, including a description of the board’s supported wake options, refer to the Power Management section on page 73.

Table 35 External Power Management (CN12)

Pin Signal Function

1 +5V_STDBY +5 V standby Power

2 GND Ground

2PME#Power Management Event input

Optional RTC Battery Input (CN13)

The optional RTC battery input is the connection for an external backup battery. This battery is used by the cpuModule when system power is removed in order to preserve the date and time in the real time clock.

Connecting a battery is only required to maintain time when power is completely removed from the cpuModule. A battery is not required for board operation.

Table 36 Optional RTC Battery Input (CN13)

WARNING This optional RTC battery connector (CN13) should be left unconnected if the utility port connector (CN5) has a battery connected.

Fan Power, +5 V (CN14)

If a fan is required to cool the cpuModule, it can be wired to CN14, which provides a continuous connection to +5 V and ground.

Pin Signal Function

1 BAT RTC Battery Input

2 GND Ground

Tabl e 37 Fa n Power, +5 V ( CN14 )

Pin Signal Function

1 +5V +5 Volts DC

2 GND Ground

Note To utilize the thermal fan mode feature in the BIOS, the fan must be connected to CN15

BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 53

Fan Power, Switched (CN15)

The switched fan power connector (CN15) is an optional fan connector which allows the system to power the fan only when the processor temperature reaches high temperatures.

To utilize this connector, refer to the Thermal Management section on page 72.

Table 38 Fan Power, Switched (CN15)

Pin Signal Function

1 CPU_FAN_PWM +5 Volts DC, switched

2 GND Ground

54 CMX158886 cpuModule BDM-610000049 Rev G

Chapter 4 Using the cpuModule

This chapter provides information for users who wish to develop their own applications programs for the CMX158886 cpuModule.

This chapter includes information on the following topics:

The RTD Enhanced AMI BIOS —page 56

Memory Map—page 59

I/O Address Map—page 60

Hardware Interrupts—page 61

multiPort: Advanced Digital I/O Ports (aDIO™)—page 62

multiPort: Parallel Port Control—page 66

multiPort: Floppy Drive —page 66

AC’97 Audio —page 66

Ethernet (10/100Base-T and -TX)—page 66

IDE Controller Configuration —page 67

Real Time Clock Control—page 69

Watchdog Timer Control —page 71

Thermal Management—page 72

Power Management—page 73

Multi-Color LED —page 76

Reset Status Register—page 77

DVMT Mode Select—page 79

User EEPROM—page 80

Features and Settings That Can Affect Boot Time—page 81

System Recovery—page 82

Basic Interrupt Information for Programmers —page 83

BDM-610000049 Rev G Chapter 4: Using the cpuModule 55

The RTD Enhanced AMI BIOS

The RTD Enhanced AMI BIOS is software that interfaces hardware-specific features of the cpuModule to an operating system (OS). Physically, the BIOS software is stored in a Flash EPROM on the cpuModule. Functions of the BIOS are divided into two parts.

The first part of the BIOS is known as POST (power-on self-test) software, and it is active from the time power is applied until an OS boots (begins execution). POST software performs a series of hardware tests, sets up the machine as defined in Setup, and begins the boot of the OS.

The second part of the BIOS is known as the CORE BIOS. It is the normal interface between cpuModule hardware and the OS which is in control. It is active from the time the OS boots until the cpuModule is turned off. The CORE BIOS provides the system with a series of software interrupts to control various hardware devices.

Configuring the RTD Enhanced AMI BIOS

The cpuModule Setup program allows you to customize the cpuModule's configuration. Selections made in Setup are stored on the board and are read by the BIOS at power-on.

Entering the BIOS Setup

You can run Setup by rebooting the cpuModule and repeatedly pressing the Delete key. When you are finished with Setup, save your changes and exit. The system will automatically reboot

Field Selection

To move between fields in Setup, use the keys listed below.

Tabl e 39 Setup K e ys

Key Function

Æ, Å, È, Ç Move between fields

+, –, PgUp, PgDn

Enter Go to the submenu for the field

Esc To previous menu then to exit menu

Selects next/previous values in fields

56 CMX158886 cpuModule BDM-610000049 Rev G

Main Menu Setup Fields

The following is a list of Main Menu Setup fields.

Table 40 Main Menu Setup Fields

Field Active Keys Selections

Main Press Enter to select Access system information such as BIOS version, EPLD

version, and CMOS time and date settings

Advanced Press Enter to select Setup advanced cpuModule features

PCIPnP Press Enter to select Set PnP and PCI options and control system resources

Boot Press Enter to select Set the system boot sequence

Security Press Enter to select Setup the supervisor and user access passwords or

enable boot sector virus protection

Power Press Enter to select Control power management settings, including power

supply type, and system wake functions

Thermal Press Enter to select Monitor the cpuModule temperature, or activate

thermal or fan modes.

Exit Press Enter to select Save or discard changes and exit the BIOS, or load the

default BIOS settings

Note Future BIOS versions may have slightly different setup menus and options.

Power On Self Test (POST) Codes

Each POST Code represents a series of events that take place in a system during the POST. If the POST fails during a particular POST Code, the system will not boot as expected.

The BIOS uses I/O port 80h to store the active POST Code. A POST Code board is a tool that is used to display the POST Codes on I/O port 80h. This is usually accomplished with two 7-segment LEDs. Such a board is useful for debugging a system that is unable to boot.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 57

Booting to Boot Block Flash with Fail Safe Boot ROM

Note Boards are shipped with Fail Safe Boot ROM enabled. When Fail Safe Boot ROM is enabled, the system will boot to it exclusively.

The Fail Safe Boot ROM is a minimal build of ROM-DOS™ located inside a surface-mounted Boot Block Flash chip. Boot Block Flash is a write-protected flash device that contains the BIOS and extra room where the Fail Safe Boot ROM is stored. Additionally, Fail Safe Boot ROM is an emergency interface accessible by an external computer. The ROM DISK contains utilities for remote access to the system’s disk drives. Due to the size of the flash chip, Fail Safe Boot ROM contains an abbreviated selection of the ROM-DOS™ utilities; however, the complete ROM-DOS™ is contained on a CD shipped with the cpuModule.

The purpose of the Fail Safe Boot ROM is to make the cpuModule bootable upon receipt. The Fail Safe Boot ROM can be used as an indicator of the module’s functionality when booting problems arise with another operating system. This test can be accomplished by enabling the Fail Safe Boot ROM in the Boot section of the BIOS Setup Utility. Enabling this option forces the cpuModule to boot to Fail Safe Boot ROM.

To boot to the Fail Safe Boot ROM, install jumper JP5, and apply power to the system.

Note If power is applied to the system while JP5 is installed, the multi-color LED will turn red.

58 CMX158886 cpuModule BDM-610000049 Rev G

Memory Map

Table 41 shows how memory in the first megabyte is allocated in the system.

Address (hex) Description

C0000–FFFFFh ROM 256 KB BIOS in Flash EPROM, shadowed into DRAM during runtime.

C0000–EFFFFh Run time user memory space. Usually, memory between C0000h and CFFFFh

A0000–BFFFFh Normally used for video RAM as follows:

Table 41 First Megabyte Memory Map

is used for the BIOS of add-on VGA video cards.

EGA/VGA Monochrome CGA

00502–9FFFFh DOS reserved memory area

00400–00501h BIOS data area

00000–003FFh Interrupt vector area

0A0000–0AFFFFh 0B0000–0B7FFFh 0B8000–0BFFFFh

Memory beyond the first megabyte can be accessed in real mode by using EMS or a similar memory manager. See your OS or programming language references for information on memory managers.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 59

I/O Address Map

As with all standard PC/104 boards, the I/O total I/O space is 64k in size. However, because early processors only addressed 0 address lines (SA0–SA9), the first 1k is used for legacy I/O devices. Any ISA add-on modules you install must therefore use I/O addresses in the range of 0–1023 (decimal) or 000–3FF (hex). The upper I/O addresses are used for PCI I/O devices, and are automatically assigned by the BIOS or operating system at boot time.

Note If you add any PC/104 modules or other peripherals to the system you must ensure they do not use re ser ved a ddr ess es l isted belo w, or mal fun cti ons wil l occ ur. Th e ex cep tio n to thi s is if t he res our ce h as b een released by the user.

Table 42 lists I/O addresses reserved for the CMX158886 cpuModule.

Table 42 I/O Addresses Reserved for the CMX158886 cpuModule

Address Range (hex) Bytes Device

1. If a floppy or IDE controller is not connected to the system, the I/O addresses listed will not be occupied.

2. If a PS/2 mouse is not connected to the system, the I/O addresses listed will not be occupied.

3. The I/O addresses for the serial port are selected in the BIOS Setup utility.

4. If aDIO is disabled, the I/O addresses listed will not be occupied.

5. If watchdog timer is disabled, the I/O addresses listed will not be occupied.

000–00Fh 16 DMA Controller

010–01Fh 16 Reserved for CPU

020–021h 2 Interrupt Controller 1

022–02Fh 13 Reserved

040–043h 4 Timer

060–064h 5 Keyboard Interface

070–071h 2 Real Time Clock Port

080–08Fh 16 DMA Page Register

0A0–0A1h 2 Interrupt Controller 2

0C0–0DFh 32 DMA Controller 2

0F0–0FFh 16 Math Coprocessor

100–101h 2 Video Initialization

1F0–1FFh 16 Hard Disk

200–201h 2 Reserved

238–23Bh 4 Bus Mouse

2E8–2EFh 8 Serial Port

2F8–2FFh 8 Serial Port

3E8–3EFh 8 Serial Port

3F0–3F7h 8 Floppy Disk

3F8–3FFh 8 Serial Port

450-454h 4 aDIO

455h 1 Watchdog Timer

456-45F 9 EPLD

60 CMX158886 cpuModule BDM-610000049 Rev G

Hardware Interrupts

Note If you add any expansion modules or other peripherals to the system, you must ensure they do not use interrupts needed by the cpuModule, or malfunctions will occur.

The CMX158886 cpuModule supports the standard PC interrupts listed in Table 43. Interrupts not in use by hardware on the cpuModule itself are listed as available. Similarly, if the operating system is using APIC, more IRQs will be available.

Table 43 Hardware Interrupts Used on the CMX158886 cpuModule

Interrupt Normal Use

0Timer 0

1Keyboard

2 Cascade of IRQ 8–15

3COM2

4COM1

5 Available

6Floppy

7Printer

8Real Time Clock

9 Available, routed to IRQ 2

10 Available

11 Available

12 Bus Mouse

1. IRQs 14 and 15 may be available if the IDE controller is configured in Native Mode (refer to IDE Controller Configuration—page 67)

Primary IDE hard disk

ATA/IDE Disk Chip socket

Note The cpuModule has onboard PCI devices that will claim IRQ lines. In some instances, a PCI device will claim an IRQ line that is required by a legacy device. To reserve an IRQ for a legacy device, refer to the PnP/PCI Configuration Setup fields in the BIOS.

Note A device’s hardware interrupt will be available for use if the given device is not present in the system and the device is disabled in Setup.

For external devices that require Legacy/ISA interrupts, a serial interrupt signal is available which permits access to the CPU’s hardware interrupts. One pair of Legacy/ISA DMA request/grant signals are also available. For more information on the serial interrupt signal, and the DMA request/grand pair, refer to Bridge Link (CN4) in Chapter 3, Connecting the cpuModule

BDM-610000049 Rev G Chapter 4: Using the cpuModule 61

multiPort: Advanced Digital I/O Ports (aDIO™)

Ensure that the BIOS setup has the multiPort set to aDIO mode. This board supports 16 bits of TTL/CMOS compatible digital I/O (TTL signaling). These I/O lines are grouped into two ports, Port 0 and Port 1. Port 0 is bit programmable; Port 1 is byte programmable. Port 0 supports RTD’s Advanced Digital Interrupt modes. The three modes are strobe, match and event. Strobe mode generates an interrupt and latches Port 0 when the strobe input transitions from low to high. Match mode generates an interrupt when an 8-bit pattern is received in parallel that matches the match mask register. Event mode generates an interrupt when a change occurs on any bit. In any mode, masking can be used to monitor selected lines.

When the CPU boots, all digital I/O lines are programmed as inputs, meaning that the digital I/O line’s initial state is undetermined. If the digital I/O lines must power up to a known state, an external 10 kΩ resistor must be added to pull the line high or low.

The 8-bit control read/write registers for the digital I/O lines are located from I/O address 450h to 454h. These registers are written to zero upon power up. From 450h to 454h, the name of these registers are Port 0 data, Port 1 data, Multi-Function, DIO-Control, and Wake Control register.

Note RTD provides drivers that support the aDIO interface on popular operating systems. RTD recommends using these drivers instead of accessing the registers directly.

Digital I/O Register Set

Table 44 Port 0 Data I/O Address 450h

D7 D6 D5 D4 D3 D2 D1 D0

P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0

Port 0 Data register is a read/write bit direction programmable register. A particular bit can be set to input or output. A read of an input bit returns the value of port 0. A read of an output bit returns the last value written to Port 0. A write to an output bit sends that value to port 0.

Table 45 Port 1 Data I/O Address 451h

D7 D6 D5 D4 D3 D2 D1 D0

P1.7 P1.6 P1.5 P1.4 P1.3 P1.2 P1.1 P1.0

Port 1 Data register is a read/write byte direction programmable register. A read on this register when it is programmed to input will read the value at the aDIO connector. A write on this register when it is programmed as output will write the value to the aDIO connector. A read on this register when it is set to output will read the last value sent to the aDIO connector.

Table 46 Multi-Function I/O Address 452h

D7 D6 D5 D4 D3 D2 D1 D0

The multi-function register is a read/write register whose contents are set by the DIO-Control register. See the DIO-Control register description for a description of this register.

62 CMX158886 cpuModule BDM-610000049 Rev G

Table 47 DIO-Control I/O Address 453h—Read Access

D7 D6 D5 D4 D3 D2 D1 D0

Strobe 0 Status

0 = no strobe 1 = strobe

Digital IRQ Status

0 = no digital interrupt 1 = digital interrupt

Strobe 1 Status

0 = no strobe 1 = strobe

Digital IRQ Mode

00 = Disabled 01 = strobe Mode 10 = event mode 11 = match mode

Port 1 Direction

0 = input 1 = output

Multi-Function Register Select

00 = clear mode 01 = port 0 direction 10 = mask register 11 = compare register

Table 48 DIO-Control I/O Address 453h—Write Access

D7 D6 D5 D4 D3 D2 D1 D0

Reserved

Digital IRQ Mode

00 = Disabled 01 = strobe Mode 10 = event mode 11 = match mode

Port 1 Direction

0 = input 1 = output

Multi-Function Register Select

00 = clear mode 01 = port 0 direction 10 = mask register 11 = compare register

Table 49 Multi-Function at Address 452h

read/write 00 clear

0 in, 1 out 01 Port 0 direction

0 no mask, 1 mask 10 DIO mask

read/write 11 compare

XXXXXXXX

I/O I/O I/O I/O I/O I/O I/O I/O

M7 M6 M5 M4 M3 M2 M1 M0

C7 C6 C5 C4 C3 C2 C1 C0

1. Contents based on bits D0 and D1 of DIO-Control.

Clear Register:

A read to this register Clears the IRQs and a write to this register sets the DIO-Compare, DIO- Mask, DIO-Control, Port 1, and Port 0 to zeros. A write to this register is used to clear the board.

Port 0 Direction Register:

Writing a zero to a bit in this register makes the corresponding pin of the aDIO connector an input. Writing a one to a bit in this register makes the corresponding pin of the aDIO connector an output.

Mask Register:

Writing a zero to a bit in this register will not mask off the corresponding bit in the DIO-Compare register. Writing a one to a bit in this register masks off the corresponding bit in the DIO-Compare register. When all bits are masked off the aDIOs comparator is disabled. This condition means Event and Match mode will not generate an interrupt. This register is used by Event and Match modes.

Compare Register:

A Read/Write register used for Match Mode. Bit values in this register that are not masked off are compared against the value on Port 0. A Match or Event causes bit 6 of DIO-Control to be set and if the aDIO is in Advanced interrupt mode, the Match or Event causes an interrupt.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 63

Table 50 Wake Control I/O Address 451h

D7 D6 D5 D4 D3 D2 D1 D0

Reserved Int Mask

1 = Interrupt is masked 0=Interrupt is enabled

Port 1 Data register is a read/write byte direction

1=Interrupt triggers a Wake Event 0=Interrupt does not trigger a wake event.

Wake Enable

Interrupts

In order to use an interrupt with aDIO, the interrupt must first be selected in the BIOS setup utility under Advanced, I/O Devices, aDIO Configuration, aDIO Interrupt. The Digital I/O can use interrupts 3, 5, 6, 7, 10, 11, and 12. The interrupt must also be reserved so that is it not assigned to PCI devices. To reserve the interrupt, enter the BIOS under PCIPnP and change the interrupt you wish to use to “Reserved.” Then, select the appropriate interrupt mode in the DIO Control register. Also, verify that the Int Mask bit is cleared in the Wake Control register

Advanced Digital Interrupts

There are three Advanced Digital Interrupt modes available. These three modes are Event, Match, and Strobe. The use of these three modes is to monitor state changes at the aDIO connector. Interrupts are enabled by writing to the Digital IRQ Mode field in the DIO-Control register.

Event Mode

When this mode is enabled, Port 0 is latched into the DIO-Compare register at 8.33 MHz. The aDIO circuitry includes deglitching logic. The deglitching requires pulses on Port 0 to be at least 120 ns in width. As long as changes are present longer than that, the event is guaranteed to register. Pulses as small as 60 ns can register as an event, but they must occur between the rising and falling edge of the 8.33 MHz clock. To enter Event mode, set bits [4:3] of the DIO-Control register to “10”.

Match Mode

When this mode is enabled, Port 0 is latched into the DIO-Compare register at 8.33 MHz. The aDIO circuitry includes deglitching logic. The deglitching requires pulses on Port 0 to be at least 120 ns in width. As long as changes are present longer than that, the match is guaranteed to register. Pulses as small as 60 ns can register as a match, but they must occur between the rising and falling edge of the 8.33 MHz clock. To enter Match mode, set bits [4:3] of the DIO-Control register to “11”.

Note Make sure bits [4:3] are set BEFORE writing the DIO-Compare register. If you do not set them first, the contents of the DIO-Compare register could be lost because the Event mode latches in Port 0 into the DIO-Compare register.

64 CMX158886 cpuModule BDM-610000049 Rev G

Figure 6 aDIO Match Mode

Strobe Mode

Another interrupt mode supported by aDIO is Strobe mode. This allows the strobe pin of the DIO connector to trigger an interrupt. A low to high transition on the strobe pin will cause an interrupt request. The request will remain high until the Clear Register is read from. Additionally, the Compare Register latched in the value at Port 0 when the Strobe pin made a low to high transition. No further strobes will be available until a read of the Compare Register is made. You must read the Compare Register, and then clear interrupts so that the latched value in the compare register is not lost. To enter Strobe mode, set bits [4:3] of the DIO-Control register to “01”.

Wake-on-aDIO

The aDIO Strobe, Match and Event interrupt can be used to generate a wake event. This event can wake the CPU from any power-down mode, including Soft-Off (S5). Wake from aDIO will work as long at +5V Standby power is applied to the board. To use the aDIO to wake the system, Wake from aDIO must first be enabled in the BIOS setup utility. Then the aDIO is configured in the appropriate interrupt mode. The “Wake Enable” bit is then set in the Wake Control Register at 0x454. The CPU can then be placed in a standby mode, and the aDIO interrupt will wake the system.

During system standby, a 32kHz clock is used for the aDIO instead of an 8.33 MHz clock. Therefore, transitions must be at least 30 us in order to trigger a wake event.

If the aDIO is to be used for a wake event only, and not an interrupt, the “Int Mask” bit can be set in the Wake Control Register. This will block the interrupt, but still allow a wake event to occur. The various settings for “Wake Enable” and “Int Mask” are shown in Table 51 below.

Table 51 Interrupt and Wake Event Generation

Wake Enable Int Mask Function

0 0 Interrupt Only

0 1 No Interrupt or Wake event is generated

1 0 Interrupt and Wake Event

11 Wake Event Only

BDM-610000049 Rev G Chapter 4: Using the cpuModule 65

multiPort: Parallel Port Control

The parallel port may be operated in SPP (output-only), EPP (bidirectional), and ECP (extended capabilities) modes. The mode may be selected in the BIOS, or by application software.

To configure the parallel port in the BIOS, enter the BIOS, and follow the steps below:

1. Under the “Advanced” menu in the BIOS, select the “I/O Device Configuration” submenu

2. Set the multiPort mode to “Parallel Port”

3. When a new “Parallel Port Configuration” appears, select it and configure the parallel port base address, parallel port mode, and IRQ

multiPort: Floppy Drive

The multiPort connector can be configured as a floppy drive. To utilize the floppy controller, the multiPort mode must be first be set to Floppy Drive in the BIOS. The complete process for setting up the multiPort as a floppy drive is described below.

1. With the system powered off, attach a floppy drive with an adapter board to CN6.

2. Power on the system and enter the BIOS setup screen by pressing the delete key as the system boots.

3. Set Drive A to 1.44 MB in the Standard CMOS Settings section of BIOS Setup.

4. Set the multiPort to Floppy in the BIOS Setup.

5. If booting to the floppy drive is required, set the first boot device in the boot sequence to floppy drive

When the floppy drive is enabled, a special cable and adapter board is required. For more information about this cable kit, refer to the Cable Kits and Accessories section in page 6.

AC’97 Audio

To use the CPU’s onboard audio, it must first be enabled in the BIOS. Two signaling levels are supported, so a line out connection can be used for powered speakers, as well as a headphone connection for non-powered speakers.

Once enabled, two audio output modes can be selected:

• Line Out: This signaling level should be used for powered speakers.

• Headphone: This signaling level should be used for non-powered speakers.

Ethernet (10/100Base-T and -TX)

To use the onboard 10/100 Ethernet controller, Ethernet must first be enabled in the BIOS.

When enabled, the multi-color LED will blink to indicate an Ethernet connection. For more information, refer to the Multi-Color LED section on page 76.

66 CMX158886 cpuModule BDM-610000049 Rev G

IDE Controller Configuration

The CPU’s onboard EIDE connector (CN10) supports several different drive speed modes, which are BIOS configurable. Supported drive modes will depend on whether a 40-conductor or 80-conductor cable is connecting the EIDE device. The modes and cable detection schemes described below may be set in the BIOS Setup. Similarly, the ATA/IDE Disk Chip socket (U16) is BIOS configurable.

Cable Modes

There are two types of cables that may be used for connecting drives to the EIDE connector: 40 conductor cables or 80 conductor cables. Depending on the cable used, different drive speeds are supported. A 40 conductor cable can be used for speeds up to UDMA Mode 2 (Ultra ATA/33).

In order to use drive speeds faster than UDMA Mode 2 (Ultra ATA/33), an 80 conductor cable is required. The BIOS can be configured to detect the presence of an 80 conductor cable. The 80 conductor cable adds a ground wire between each signal, and uses standard 40 pin connectors.

Cable Detection

Every time the cpuModule is powered on or a hardware reset is issued, the BIOS will automatically detect the presence of a 80 conductor cable connecting a device to CN10. The user selectable cable detection modes are described below.

Device and Host Mode

For this method, there is a capacitor on the CBLID pin at the CPU, and a pull-up at the hard drive. The CPU sends a command to the hard drive to drive the CBLID pin low, and then release it. The CPU then waits a certain amount of time, and instructs the hard drive to read the status of the CBLID pin. If an 80 conductor cable is attached, the CBLID signal is not connected between the CPU and the hard drive, and the hard drive will read the signal as a logic high. If a 40 conductor cable is attached, the CBLID pin is connected between the CPU and the hard drive, the capacitor delays the signal from going high, and the hard drive reads it as a logic low.

Host Determination of Cable Type

For this method of detection, the CPU reads the CPBLID pin, which determines if a 40-conductor or 80conductor cable is connected between the CPU and device. An 80-conductor cable has this signal grounded at the CPU end, and not connected to the hard drive. A 40-conductor cable connects the CBLID signal to the hard drive, where it is pulled to a logic high.

Device Detect

For device detect mode, the CPU issues a command to the device, which tells the CPU the fastest drive speed mode it can use. The CPU then sets the transfer mode to the fastest speed supported by the device.

WARNING When this cable detection method is enabled, the highest transfer speed supported by the device will be us ed rega rdless of whe ther a 40-cond uctor or 80-conductor cable is used. If the device speed does not match the cable, data corruption and unexpected behaviors may occur. This mode should not be selected unless the user knows the cable type and the modes supported by the connected EIDE device.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 67

Legacy Mode and Native Mode IDE

The onboard EIDE controller may be configured as a either a Legacy or Native Mode IDE controller in the BIOS Setup. However, the operating system must support the selected mode for the device to operate correctly. The default configuration for the controller is Legacy Mode, as this is supported by most operating systems.

Legacy Mode

Legacy mode is the default configuration of the onboard EIDE controller. When in this mode, the controller will be fixed to use two interrupts: IRQs 14 and 15. Similarly, the I/O address of the controller will be fixed in the system. When in Legacy Mode, only a primary and secondary channel may be used in the system.

Native Mode

Native Mode allows more flexibility, as the system resources used by the IDE controller may be modified. When in Native Mode, the IDE controller only requires a single IRQ. Unlike Legacy Mode, this IRQ may be changed by the user or the operating system for better distribution of the system IRQs. When IRQs in the system are more evenly distributed, interrupt latency is minimized. The base address of the controller may also be modified.

Configuring the ATA/IDE Disk Chip Socket

The cpuModule was designed to be used in embedded computing applications. In such environments, rotating media like hard disks and floppy disks are not very desirable. It is possible to eliminate rotating storage devices by placing your operating system and application software into the cpuModule's ATA/IDE Disk Chip socket.

WARNING Before installing a device in the ATA/IDE Disk Chip socket, the system must be configured in the correct mode. For details on configuring the socket, refer to Chapter 4, Using the cpuModule

Before installing a device in the ATA/IDE Disk Chip socket, it is highly recommend to first configure the secondary IDE controller and device mode in the BIOS setup.

The secondary IDE controller must be enabled in the BIOS to allow read and write access to the device. When a device is installed in the socket, it will always appear as a master on the cpuModule’s secondary IDE controller.

From the BIOS setup screen, the user can also configure whether the socket contains a DMA mode or PIO mode device.

• DMA Mode: DMA mode will reduce CPU overhead.

• PIO Mode: When the socket is in PIO mode, PIO transfers are supported. PIO mode supports write

protection.

68 CMX158886 cpuModule BDM-610000049 Rev G

Real Time Clock Control

Overview

The cpuModule is equipped with a Real Time Clock (RTC) which provides system date and time functions. When the cpuModule is turned off, a battery must be attached to the utility connector to provide power to the RTC. Without power, the RTC will lose the date/time information when the system is turned off.

The RTC also provides an “alarm” function. This may be used to generate an interrupt at a particular time and day. This feature is commonly used to wake up the system from Sleep/Standby to run a scheduled task (defragment the hard drive, back up files, etc.).

In addition to the date/time/alarm functions, the RTC contains several bytes of battery-backed RAM, commonly called CMOS memory. In a typical desktop PC, the CMOS memory is used by the BIOS to store user settings. This RTD cpuModule uses onboard flash to store user BIOS settings. To preserve compatibility with traditional PCs, the RTD Enhanced BIOS also mirrors the user settings from flash in CMOS. Therefore, the contents of CMOS may be overwritten at boot time, and should be treated as “read only”.

Accessing the RTC Registers

You may access the RTC date/time and CMOS memory using the Index and Data Registers located at I/O addresses 70h and 71h.

• Address 70h is the Index register. It must be written with the number of the register to read or write.

Valid values are 00h to 7Fh.

• Address 71h is the Data register. It contains the contents of the register pointed to by the Index.

To read/write an RTC register, you must first set the Index register with the register number, and then read/write the Data register.

A list of key RTC registers is shown in Table 52 below:

Table 52 Real Time Clock Registers

Registers

(hex)

00h 0 RTC Seconds

02h 2 RTC Minutes

04h 4 RTC Hours

06h 6 RTC Day of Week

07h 7 RTC Day of Month

08h 8 RTC Month

09h 9 RTC Year

0Ah 10 RTC Status Register A

Registers

(decimal)

Function

• Bit 7: RTC Update In Progress (Read Only) - RTC registers

should not be accessed when this bit is high.

• Bits 6-4: Divider for 32.768 KHz input (should always be 010)

• Bits 3-0: Rate select for periodic interrupt.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 69

Table 52 Real Time Clock Registers

Registers

(hex)

0Bh 11 RTC Status Register B

Registers

(decimal)

Function

• Bit 7: Inhibit Update - When high, the RTC is prevented from

updating.

• Bit 6: Periodic Interrupt Enable - When high, the RTC IRQ will

be asserted by the periodic interrupt.

• Bit 5: Alarm Interrupt Enable - When high, the RTC IRQ will be

asserted when the current time matches the alarm time.

• Bit 4: Update Ended Interrupt Enable - When high, the RTC IRQ

will be asserted every time the RTC updates (once per second).

• Bit 3: Square Wave Enable - Not used.

• Bit 2: Data Mode - Sets the data format of the RTC

clock/calendar registers (0=BCD, 1=binary). This is typically set to BCD mode.

• Bit 1: Hours Byte Format - Sets the hour byte to 12 or 24 hour

time (0=12 hour, 1=24 hour). This is typically set to 24 hour mode.

• Bit 0: Daylight Savings Enable - When high, the RTC will

automatically update itself for Daylight Savings Time. It is recommended to leave this bit low and let the operating system manage time zones and DST.

0Ch 12 RTC Status Register C (Read Only)

• Bit 7: IRQ Flag - Indicates that the Real Time Clock IRQ is

asserted. Goes high whenever one of the enabled interrupt conditions in Register B occurs.

• Bit 6: Periodic Flag

• Bit 5: Alarm Flag

• Bit 4: Update Ended Flag

• Bit 3-0: Reserved

Reading this register will also clear any of set flag (IRQ, Periodic, Alarm, Update Ended). Note that even if the interrupt source is not enabled in Register B, the flags in Register C bits 4, 5, and 6 may still be set.

0Dh 13 RTC Status Register D

• Bit 7: Valid Time/Date (always reads 1)

• Bit 6: Reserved

• Bits 5-0: RTC Alarm Day of the Month

Note RTC registers that are not listed above are used by the BIOS and should be considered “Reserved”. Altering the contents of any unlisted RTC register may interfere with the operation of your cpuModule. The specific uses of the unlisted RTC registers will depend on the BIOS version loaded on the cpuModule. Contact RTD's technical support for more information.

70 CMX158886 cpuModule BDM-610000049 Rev G

Watchdog Timer Control

The cpuModule includes a watchdog timer, which provides protection against programs “hanging”, or getting stuck in an execution loop where they cannot respond correctly. When enabled, the watchdog timer must be periodically reset by your application program. If it is not refreshed before the time-out period expires, it will cause a hardware reset of the cpuModule.

The watchdog time-out period is typically 1.1 seconds, but can vary between 550 ms and 1.65 seconds. Because of operating system latency, it is recommended that the watchdog be refreshed at half of the period, or every 275 ms.

Before using the Watchdog timer, it must be enabled in the BIOS setup utility. When it is disabled in the BIOS, the watchdog register does not appear in I/O space and it will not generate an a reset.

Note Enabling the watchdog timer in the BIOS does not actually arm it. The watchdog timer can be armed by accessing I/O address 455h, as explained below.

Three functions have been implemented on the cpuModule for controlling watchdog timer control. These are:

• Arm: The watchdog timer can be enabled by writing a 1 to bit 7 of I/O port 0x455. To ensure

compatability with future designs, you should read the register and only change the bit you need to change.

• Disarm: The watchdog timer is disabled by writing a 0 to bit 7 of I/O port 0x455. To ensure

compatability with future designs, you should read the register and only change the bit you need to change.

• Refresh: The watchdog timer is refreshed by reading from I/O port 0x455. After you enable the

watchdog timer, you must refresh it at least once every 550 ms.

Table 53 Watchdog Timer Control I/O Address 455h

D7 D6 D5 D4 D3 D2 D1 D0

Watchdog Enable

0=Watchdog timer is disabled and will not

generate an interrupt

1=Watchdog Timer is enabled and needs

to be refreshed

Reserved

BDM-610000049 Rev G Chapter 4: Using the cpuModule 71

Thermal Management

The cpuModule has several thermal features which can be used to monitor and control the board’s temperature when extreme operating conditions are prevalent.

Thermal Monitor

Note The CPU and PCB temperatures displayed in the BIOS are approximate and should not be used to validate a cooling solution.

Fan Mode

The CPU fan can be controlled by the CPU when connected to the switched fan power connector (CN15). Three fan modes are supported, which can be toggled in the BIOS setup. When the fan is not always on, the CPU’s power consumption is reduced, and the life of the fan is increased.

• Always On: When in this mode, the fan is always powered by the CPU.

• On At 70C: This mode allows the system to keep the fan turned off until the CPU reaches 70C. In this

mode, the fan will slowly transition between on and off to prevent oscillations. This is the best mode for applications that will spend most of the time below 0C.

• Varia ble: The fan will spin slowly until the CPU reaches 60C, and then will increase speed. Maximum

speed is reached when the CPU reaches 75C.

Note If the CPU fan is connected to the continuous +5 V fan connector (CN14), changing the fan mode options in the BIOS will not affect the fan, as it will always be turned on.

Further Temperature Reduction

The cpuModule’s temperature is directly related to power consumption. Reducing the power consumption of the CPU will have an effect on the CPU’s temperature. Suggested methods for reducing the CPU’s power consumption can be found in the Power Management section on page 73.

72 CMX158886 cpuModule BDM-610000049 Rev G

Power Management

The CMX158886 cpuModule supports various powering mechanisms which allow the cpuModule to monitor power consumption and temperature, and achieve minimal power consumption states. These unique features include Enhanced Intel® SpeedStep® Technology (PX only), thermal monitoring and thermal throttling, as well as low power modes including ACPI configurations. Various wake options are also available to resume normal system power.

Enabling Enhanced Intel SpeedStep Technology (PX only)

When enabled, Enhanced Intel® SpeedStep® Technology can give application software greater control over the processor’s operating frequency and input voltage. This allows the system to easily manage power consumption dynamically. This feature can be enabled or disabled in the BIOS. When enabled, the feature can be set to several different modes, which are described below.

• Maximum Speed: The processor speed is set to its maximum operating frequency.

• Minimum Speed: The processor speed is set to its minimum operating frequency.

• Automatic: When set to automatic mode, the processor speed is controlled by the operating system.

Advanced Configuration and Power Interface (ACPI)

The cpuModule supports several different ACPI low power modes, including the S1, S3, S4, and S5 sleeping states. The BIOS setup utility provides an option to select between S1 and S3 as the Standby state. Sleep modes S4 and S5 are setup by the operating system.

The cpuModule’s ACPI suspend modes are described below

• S1 (Power on Suspend): The S1 low power state consumes the most power of all supported ACPI sleep

modes. In this mode, the CPU stops executing instructions, but power to the CPU and RAM is maintained.

• S3 (Suspend to RAM): Everything in the system is powered off except for the system memory. When

the system wakes from this mode, operating systems allow applications to resume where they left off, as the state of the application is preserved in memory.

• S4 (Hibernate): When the system enters this state, the operating system will save the current state of

applications and relevant data to disk, thus allowing the system RAM to be powered down.

• S5 (Soft-Off): The system is in a soft off state, and must be rebooted when it wakes.

Power Button Modes

The soft power button input of the utility port connector (CN5) can be configured by the operating system as a suspend button (transition to S1 or S3) or as soft power button (transition to S5). Consult your operating system documentation for information on how to configure it. The power button will always cause a transition to S5 if pressed for 4 seconds or longer, without interaction from the operating system.

Low-Power Wake Options

The cpuModule supports several methods of waking from a low power state. Several of these wake options are BIOS configurable, and can be accessed directly from the “Power” menu in the BIOS setup:

• Resume on Ring: While in a low power mode, the ring indicator input of either COM port may be used

to wake the system.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 73

• Resume on aDIO: This option allows the system to use an aDIO Strobe, Match, or Event interrupt to

generate a wake event. This event can wake the CPU from any power-down mode, including Soft-Off (S5). For more information, refer to the section titled Wake-on-aDIO on page 65.

• Resume on PME#: When enabled, the system can wake when a signal is applied to the External Power

Management connector (CN12). This includes wake-up on onboard LAN controller. The PME# signal is also available on the PC/104-Plus (PCI) bus connector.

• Resume on RTC Alarm: The RTC Alarm allows the system to turn on at a certain time every day.

AT vs . AT X Pow er S uppli es

Both AT and ATX power supplies may be used with the CMX158886 cpuModule, however AT power supplies do not provide any standby power to the cpuModule. When an AT power supply is used to power the system, low power modes that require a standby power to wake the system will not be fully supported.

ATX power supplies do provide a standby power, thus allowing the system to utilize all low power modes supported by the hardware. When an ATX supply is used to power the cpuModule, lower power modes can be achieved. During these low power modes, the standby power from the ATX power supply provides power to a small circuit on the CPU, which is used to watch for a system wake event.

ATX Power Supply Signals

The auxiliary power connector (CN3) provides two ATX style signals., +5V Standby and PSON#. The +5V Standby rail is used to power certain parts of the cpuModule when the main power supply is turned off, i.e. during Suspend-to-RAM (S3), Hibernate (S4), or Soft-Off (S5) power modes. The PSON# signal is an active low open-drain output that signals the power supply to turn on. Use of these signals allows the power consumption to drop to below 1W during standby modes, and still enable any of the wake events.

74 CMX158886 cpuModule BDM-610000049 Rev G

Reducing Power Consumption

In addition to the CPU’s low power modes, power consumption can further be reduced by making some modifications to the BIOS setup. When the following features are modified, the CPU’s power consumption will decreases:

• CPU Speed: Setting the processor to its minimum speed in the BIOS will reduce power consumption

• Memory Speed: Changing the DDR DRAM clock frequency will reduce power consumption, however

memory performance will also be reduced.

• Ethernet: Can be disabled in the BIOS

• Serial Ports: Can be disabled in the BIOS

• LVDS Flat Panel: If an LVDS panel is not connected to the cpuModule while using a VGA monitor,

setting the BIOS to use only a CRT (VGA) monitor will reduce power consumption.

• Fan Mode: Set the fan to auto mode so it is used only when the processor reaches high temperatures.

This option will only effect the fan if it is connected to the switched fan power connector (CN15).

• Multi-Color LED: Can be disabled in the BIOS

BDM-610000049 Rev G Chapter 4: Using the cpuModule 75

Multi-Color LED

The CMX158886 has a Multi-Color LED located beside the EIDE connector (CN10) which can be enabled or disabled in the BIOS setup screen. The color of the LED indicates the status of the board, as shown in Table 54.

Green Normal Operation

Blue On Board IDE Activity

Red cpuModule is in reset

Yellow (Red + Green) cpuModule is in Standby

White (R+G+B) cpuModule is approaching thermal limit

Cyan (Blue + Green) Ethernet Link at 10 Mbps

Magenta (Blue + Red) Ethernet Link at 100 Mbps

Blink Ethernet Activity

1. If power is applied to the cpuModule while jumper JP5 is installed, the LED will be red. This do es not

2. The LED will remain White until the system is shut down.

The LED can also be controlled manually by writing to I/O Port 456h, as shown in Table 55 and Table 56.

Tab l e 5 4 LED C ol o rs

Color Description

indicate that the board is in reset

Table 55 Multi-Color LED I/O Address 456h

D7 D6 D5 D4 D3 D2 D1 D0

Reserved

(User

EEPROM)

Reserved

(User

EEPROM)

Reserved

(User

EEPROM)

Reserved Reserved Multi-Color LED

Note When writing to I/O Port 456h, only the lower three bits of the register should be modified. Modifying the upper bits will effect the User EEPROM

The following table lists the color displayed and the value written.

Tabl e 56 Manu a l LED C olo r s

I/O Port 456h Value Color

0x00 Automatic (see Table 54)

0x08 Off (will reduce system power consumption.)

0x09 Blue

0x0A Green

0x0B Cyan (Green + Blue)

0x0C Red

0x0D Magenta (Red + Blue)

0x0E Yellow (Red + Green)

0x0F White (Red + Green + Blue)

76 CMX158886 cpuModule BDM-610000049 Rev G

Reset Status Register

The cpuModule has several different signals on board which can cause a system reset. If a reset occurs, the reset status register can be used to see which reset or resets have been asserted on the cpuModule.

The user has the ability to see which resets have been asserted. Resets can also be cleared.

• Examine Resets: Reading from I/O port 0x457 will indicate if a reset has been asserted. If a 1 is read, the

corresponding reset has been asserted. If a 0 is read from the bit, the reset has not been asserted

• Clear Reset: Each reset can be cleared by writing a 1 to the selected bit of I/O port 0x457.

Table 57 Reset Status I/O Address 457h - Read Access

D7 D6 D5 D4 D3 D2 D1 D0

Main Power (+5V)

1 = reset asserted 0 = no reset

CPU Core Power

1 = reset asserted 0 = no reset

Non-Standby Power

1 = reset asserted 0 = no reset

Memory Power

1 = reset asserted 0 = no reset

Standby Power

1 = reset asserted 0 = no reset

Reserved

PCI Reset

1 = reset asserted 0 = no reset

Table 58 Reset Status I/O Address 457h - Write Access

D7 D6 D5 D4 D3 D2 D1 D0

Main Power (+5V)

1 = clear reset

CPU Core Power

1 = clear reset

Non-Standby Power

1 = clear reset

Memory Power

1 = clear reset

Standby Power

1 = clear reset

Reserved

PCI Reset

1 = clear reset

Utility Reset

1 = reset asserted 0 = no reset

Utility Reset

1 = clear reset

BDM-610000049 Rev G Chapter 4: Using the cpuModule 77

Table 59 Reset Status Description and Priorities

I/O Address

457h

Reset

Signal

Reset

Priority

Description

D7 Main Power (+5V) 2 Main input power to cpuModule (+5V)

D6 CPU Core Power 3 CPU core powers supply

D5 Non-Standby Power 3 Power supplies that are not for standby

power

D4 Memory Power 3 Power to onboard memory banks

D3 Standby Power 1 Standby power supplies

D2 reserved - reserved

D1 PCI Reset 4 PCI bus reset signal

D0 Utility Reset - Utility connector push button reset

1. When a reset is asserted, all resets with a higher reset priority will also be asserted. For example, if the standby power reset is asserted, all other resets will also be asserted.

2. The BI OS allows the user to change the f unction of the uti lity connector’s push button res et. Even if the push button is not configured as a reset, this bit will always read a 1(asserted) when the reset button has been pushed.

78 CMX158886 cpuModule BDM-610000049 Rev G

DVMT Mode Select

The CMX158886 supports Dynamic Video Memory Technology (DVMT). DVMT allows the CPU to allocate memory to system processing or graphics processing on the fly based on changing processing requirements.

For example, a graphics intensive program will require the operating system to request a larger amount of video memory than one that does not require large amounts of graphics processing. For the graphics intensive process, DVMT will allocate a larger portion of system memory. When the process is complete, DVMT will allocate the memory back to the system.

The CMX158886 supports three user-selectable modes, including Fixed Mode, DVMT Mode, and Combo Mode.

• Fixed Mode: A fixed amount of system memory is reserved for video.

• DVMT Mode: Video memory is dynamically allocated as needed.

• Combo Mode: A fixed amount of memory is allocated, but more can be claimed as needed.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 79

User EEPROM

A 512kB serial EEPROM (Atmel AT93C66) is available on the cpuModule for the user to save nonvolatile parameters on the cpuModule. The EEPROM can be accessed by reading and writting to I/O address 456h, as shown in the following table.

D7 D6 D5 D4 D3 D2 D1 D0

CS SK DI DO Reserved (Multi-Color LED)

Table 60 User EEPROM I/O Address 456h

Tab l e 6 1 EEP R OM R e gi ste r De sc r ip tio n

Bit Signal Function Read / Write

D7 CS Chip Select Read / Write

D6 SK Serial Data Clock Read / Write

D5 DI Serial Data Input Read / Write

D4 DO Serial Data Output Read Only

D3 Reserved

D2 (Multi-Color LED)

D1 (Multi-Color LED)

D0 (Multi-Color LED)

80 CMX158886 cpuModule BDM-610000049 Rev G

Features and Settings That Can Affect Boot Time

The boot time of a system is dependent upon numerous system settings as well as devices attached to a system. This section addresses some devices and settings that can increase or decrease a system’s boot time.

Quick Boot

The BIOS contains a Quick Boot option that minimizes the boot time of the system. Quick Boot eliminates the exhaustive tests that are performed during Power On Self Test (POST) while maintaining the functionality of the board. By enabling the Quick Boot feature, your system can achieve 5-second boot times.

Add-On Cards With BIOS Extensions

Some add-on cards have an integrated BIOS extension. The most common examples are SCSI controllers and network cards with boot ROMs. During POST, the BIOS executes the card's extension code. This extension code is third-party code, which is beyond RTD's control. The BIOS extension will most likely increase the boot time. Exactly how much it increases boot time will depend on the particular card and firmware version.

VGA Controller

VGA controllers have a VGA BIOS that must be initialized during POST. It can take some time to initialize the VGA BIOS. Exactly how long will depend on the particular VGA controller and BIOS version.

Hard Drive Type

During IDE initialization, each IDE device must be probed. Some devices take longer to probe. 2.5-inch hard drives tend to take longer than 3.5-inch ones, because they spin at a lower RPM.

Monitor Type

Some monitors take a while to power on. Desktop flat panels are especially slow. This does not affect the actual boot time of the CPU. However, the CPU may boot before the monitor powers on.

NVRAM Updates

System configuration data is stored in the onboard NVRAM. When the system configuration changes, this information must be updated. If an update is necessary, it will happen at the end of POST (the BIOS will display an “Updating NVRAM…” message). The NVRAM update takes a few seconds and increases the boot time. Once the NVRAM is updated, boot times will return to normal.

NVRAM updates only happen when the system configuration changes. They do not happen spuriously. They are usually triggered by adding or removing a PCI device from a stack. Updates can also be triggered by altering the Plug-n-Play configuration of the BIOS.

Boot Device Order

The BIOS contains a list of devices to try booting from. If you wish to boot to a particular device (for example, a hard drive), make sure that it is first in the boot order. This will speed up boot times.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 81

System Recovery

Loading Default BIOS Settings

The default BIOS can be restored either by using the “Load Defaults” option in the BIOS, or by installing jumper JP5 (s ee Fi gure 7 on pag e 87) . In most ca ses, the e asie st wa y to load defau lt s etti ngs i s by s etti ng t hem in th e BIO S. For other unique cases, jumper JP5 provides an alternative method of restoring the BIOS settings.

To restore the default BIOS settings with jumper JP5, follow the procedure below.

1. Remove power from the system.

2. Install JP5.

3. Apply power to the system. The cpuModule will then load its default settings. Note that the

multi-color LED will be red if power is applied while JP5 is installed.

4. Reboot and press Delete to enter BIOS Setup.

5. Save the BIOS settings and exit, allowing the system to boot to the FSBR.

6. The next time the system is powered, the BIOS Setup will be configured to use the default settings.

Booting to the Fail Safe Boot ROM (FSBR)

If your system is in configuration that will not allow it to boot, the Fail Safe Boot ROM is a minimal build of ROM-DOS which can be booted to for system debugging. To boot to the FSBR, follow the instructions below.

1. Reboot the system and press Delete to enter BIOS Setup.

2. In the Boot menu, select Bootup Options, and change RTD Fail Safe Boot ROM to Enabled.

3. Save the BIOS settings and exit.

If you are unable to enter the BIOS Setup, an alternate method is to use JP5 as described below:

1. Remove power from the system.

2. Install JP5. This will force the cpuModule to boot using the default BIOS configuration.

3. Apply power to the system. The cpuModule will then boot to the Fail Safe Boot ROM image. Note that

the multi-color LED will be red if power is applied while JP5 is installed.

4. Press the Delete key to enter Setup, or allow the cpuModule to boot to Failsafe

82 CMX158886 cpuModule BDM-610000049 Rev G

Basic Interrupt Information for Programmers

An interrupt is a subroutine called asynchronously by external hardware (usually an I/O device) during the execution of another application. The CPU halts execution of its current process by saving the system state and next instruction, and then jumps to the interrupt service routine, executes it, loads the saved system state and saved next instruction, and continues execution. Interrupts are good for handling infrequent events such as keyboard activity. Interrupts on this cpuModule are controlled by two Intel 8259-equivalent interrupt controllers containing 13 available interrupt request lines.

What happens when an interrupt occurs?

An IRQx pin on the PC/104 bus makes a low to high transition while the corresponding interrupt mask bit is unmasked and the PIC determines that the IRQ has priority, that is, the PIC interrupts the processor. The current code segment (CS), instruction pointer (IP), and flags are pushed onto the stack. The CPU then reads the 8-bit vector number from the PIC, and a new CS and IP are loaded from a vector—indicated by the vector number— from the interrupt vector table that exists in the lowest 1024 bytes of memory. The processor then begins executing instructions located at CS:IP. When the interrupt service routine is completed the CS, IP, and flags that were pushed onto the stack are popped from the stack into their appropriate registers and execution resumes from the point where it was interrupted.

How long does it take to respond to an interrupt?

A DOS system can respond to an interrupt between 6 and 15 μs. A Windows system can take a much longer time when a service routine has been installed by a device driver implemented as a DLL—from 250 to 1500 μs or longer. The time the CPU spends in the interrupt depends on the efficiency of the code in the ISR. These numbers are general guidelines and will fluctuate depending on operating system and version. Minimum time between two IRQ requests is 125 ns per ISA specification.

Interrupt Request Lines

To allow different peripheral devices to generate interrupts on the same computer, the ISA bus has eight different interrupt request (IRQ) lines. On the ISA bus, a transition from low to high on one of these lines generates an interrupt request, which is handled by the PC’s interrupt controller. On the PCI bus, an interrupt request is level-triggered.

The interrupt controller checks to see if interrupts are to be acknowledged from that IRQ and, if another interrupt is already in progress, it decides if the new request should supersede the one in progress or if it has to wait until the one in progress is done. This prioritizing allows an interrupt to be interrupted if the second request has a higher priority. The priority level is based on the number of the IRQ; IRQ0 has the highest priority, IRQ1 is second-highest, and so on through IRQ7, which has the lowest. Many of the IRQs are used by the standard system resources. IRQ0 is used by the system timer, IRQ1 is used by the keyboard, IRQ3 by COM2, IRQ4 by COM1, and IRQ6 by the disk drives. Therefore, it is important to know which IRQ lines are available in your system for use by the cpuModule.

BDM-610000049 Rev G Chapter 4: Using the cpuModule 83

Intel 8259 Programmable Interrupt Controller

The chip responsible for handling interrupt requests in the PC is the Intel 8259 Programmable Interrupt Controller. To use interrupts, you need to know how to read and set the Intel 8259’s interrupt mask register (IMR) and how to send the end-of-interrupt (EOI) command to the Intel 8259.

Each bit in the IMR contains the mask status of an IRQ line; bit 0 is for IRQ0, bit 1 is for IRQ1, and so on. If a bit is set (1), then the corresponding IRQ is masked and will not generate an interrupt. If a bit is clear (0), then the corresponding IRQ is unmasked and can generate interrupts. The IMR is programmed through port 21h.

Note When in APIC mode, the PIC is programmed differently, and IRQ routing behaves differently. For more information, refer to the APIC datasheets and specifications provided by Intel.

PCI Interrupts

PCI devices can share interrupts. The BIOS or operating system may assign multiple PCI devices to the same IRQ line. Any interrupt service routine (ISR) written for PCI devices must be able to handle shared interrupts. Refer to Interrupt-Driven PC System Design (ISBN: 0-929392-50-7) for more information on PCI interrupts.

Writing an Interrupt Service Routine (ISR)

The first step in adding interrupts to your software is to write the ISR. This is the routine that will automatically be executed each time an interrupt request occurs on the specified IRQ. An ISR is different than standard routines that you write. First, on entrance, the processor registers should be pushed onto the stack BEFORE you do anything else. Second, just before exiting your ISR, you must clear the interrupt status flag and write an end-of-interrupt command to the Intel 8259 controller. Finally, when exiting the ISR, in addition to popping all the registers you pushed on entrance, you must use the IRET instruction and not a plain RET. The IRET automatically pops the flags, CS, and IP that were pushed when the interrupt was called.

Most C compilers allow you to identify a procedure (function) as an interrupt type and will automatically add these instructions to your ISR, with one important exception: most compilers do not automatically add the end-of-interrupt command to the procedure; you must do this yourself. Other than this and the few exceptions discussed below, you can write your ISR just like any other routine. It can call other functions and procedures in your program and it can access global data. If you are writing your first ISR, RTD recommends focusing on the basics, such as incrementing a global variable.

Most operating systems have restrictions on what instructions can be called in your ISR. Consult your OS documentation for details on writing your ISR.

Note A complete explanation of interrupt programming is beyond the scope of this manual. For more information on interrupts, refer to the Appendix.

Sample Code

RTD’s drivers provide examples of ISR’s and interrupt handling. Refer to them as working examples. These drivers were shipped with your cpuModule, but they can also be downloaded from RTD’s website (www.rtd.com).

84 CMX158886 cpuModule BDM-610000049 Rev G

Appendix A Hardware Reference

This appendix provides information on CMX158886 cpuModule hardware, including:

Jumper Settings and Locations—page 86

Onboard PCI Devices—page 88

Physical Dimensions—page 89

BDM-610000049 Rev G Appendix A: Hardware Reference 85

Jumper Settings and Locations

Many cpuModule options are configured by positioning jumpers. Jumpers are labeled on the board as JP followed by a number.

Some jumpers have three pins, allowing three settings:

• Pins 1 and 2 connected (indicated as “1–2”)

• Pins 2 and 3 connected (indicated as “2–3”)

• No pins connected

Some jumpers have two pins, allowing two settings:

• Pins 1 and 2 connected (indicated as “closed”)

• Pins 1 and 2 unconnected (indicated as “open”)

Figure 7 shows the jumper locations that are used to configure the cpuModule. Table 62 lists the jumpers and their settings.

JP9

JP1

JP12

JP11

JP2

JP13

JP14

JP5

JP6

86 CMX158886 cpuModule BDM-610000049 Rev G

Figure 7 CMX158886 Jumper Locations (top side)

Table 62 CMX158886 Jumpers

Jumper Pins Function Default

JP1 2 Enable/disable 120 Ω series termination to COM1 (CN7) in RS-422/485 modes open

JP2 2 Enable/disable 120 Ω series termination to COM2 (CN8) in RS-422/485 modes open

JP5 2 Install to load the default BIOS settings and boot to Fail Safe (for more

information, refer to System Recovery—page 82). Note that the multi-color LED will be red if JP5 is installed.

JP6 2Reserved open

JP9 3 Select power for flat panel backlight

pins 1–2: +12 V pins 2–3: +5 V

JP11 2 Enable/disable 120 Ω series termination to second serial port on CN7 in

RS-422/485 modes

JP12 2 Install to support RS-422/485 modes for second serial port on CN7 open

JP13 2 Enable/disable 120 Ω series termination to second serial port on CN8 in

RS-422/485 modes

JP14 2 Install to support RS-422/485 modes for second serial port on CN8 open

open

pins 2–3

open

BDM-610000049 Rev G Appendix A: Hardware Reference 87

Onboard PCI Devices

The CMX158886 cpuModule has several onboard PCI devices, all of which are listed in the table below.

Device ID Vendor ID Description

Tab l e 6 3 On b oa rd P CI D evi ce s

103E 8086 LAN Controller

244E 8086 Hub to PCI Bridge

24C0 8086 PCI to LPC Bridge

24C2 8086 USB UHCI Controller

24C3 8086 SMBus Controller

24C5 8086 AC’97 Audio Controller

24CB 8086 IDE Controller

24CD 8086 USB EHCI Controller

3580 8086 Host-Hub

3582 8086 Graphics Device

3584 8086 Main Memory

3585 8086 Configuration Process

- -PCI Slot 1

- -PCI Slot 2

- -PCI Slot 3

- -PCI Slot 4

88 CMX158886 cpuModule BDM-610000049 Rev G

Physical Dimensions

Figure 8 shows the mechanical dimensions of the CMX158886 cpuModule.

Figure 8 CMX158886 Physical Dimensions (±0.005 inches)
