RS/6000 7046 Model B50 IBM

Service Guide

SA38-0564-00

RS/6000 7046 Model B50 IBM

Service Guide

SA38-0564-00

First Edition (September 1999)

The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: THIS PUBLICATION IS PROVIDED “AS

IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. The manufacturer may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time, without notice.

It is possible that this publication may contain reference to, or information about, products (machines and programs), programming, or services that are not announced in your country. Such references or information must not be construed to mean that these products, programming, or services will be announced in your country. Any reference to a specific licensed program in this publication is not intended to state or imply that you can use only that licensed program. You can use any functionally equivalent program instead.

Requests for technical information about products should be made to your authorized reseller or marketing representative.

Note to U.S. Government Users -- Documentation related to restricted rights -- Use, duplication or disclosure is subject to restrictions set forth is GSA ADP Schedule Contract with IBM Corp.

Communications Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Federal Communications Commission (FCC) Statement ............... vii

European Union (EU) Statement ............................. vii

International Electrotechnical Commission (IEC) Statement ............. viii

United Kingdom Telecommunications Safety Requirements ............. viii

Avis de conformité aux normes du ministère des Communications du Canada . viii

Canadian Department of Communications Compliance Statement ......... viii

VCCI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Electromagnetic Interference (EMI) Statement - Taiwan ................ ix

Radio Protection for Germany ............................... x

Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Laser Safety Information .................................. xii

Environmental Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

Product Recycling and Disposal ............................. xiii

Environmental Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

About This Book ...................................... xv

ISO 9000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xv

Online Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xv

Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xv

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi

Chapter 1. Reference Information . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

System Board Locations ................................. 1-6

System Board Jumper Settings ............................. 1-8

Riser Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

SCSI Bus Termination .................................. 1-9

Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

Service Inspection Guide ................................ 1-10

Chapter 2. Maintenance Analysis Procedures (MAPs) ............. 2-1

Entry MAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

MAP 1020: Problem Determination ........................... 2-6

MAP 1240: Memory Problem Resolution ........................ 2-9

MAP 1520: Power .................................... 2-12

MAP 1540: Minimum Configuration .......................... 2-17

Chapter 3. Error Code to FRU Index ........................ 3-1

Preface iii

Bus SRN to FRU Reference Table .......................... 3-12

Firmware Checkpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14

Boot Problems or Concerns .............................. 3-27

Chapter 4. Location Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Physical Location Codes ................................. 4-1

AIX Location Codes .................................... 4-3

Chapter 5. Loading the System Diagnostics ................... 5-1

Loading Diagnostics in Service Mode Boot ...................... 5-2

Working with Standalone versus Online Diagnostics ................. 5-3

Chapter 6. Using System Management Services ................. 6-1

Graphical System Management Services ....................... 6-1

Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

MultiBoot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6

Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11

Hard Disk Spin Up Delay ................................ 6-15

Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16

RIPL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17

SCSI ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

Firmware Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21

Text-Based System Management Services ..................... 6-23

Display Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24

MultiBoot Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25

Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29

Select Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-39

Open Firmware Command Line ............................ 6-40

Chapter 7. Removal and Replacement Procedures ............... 7-1

Handling Static–Sensitive Devices ........................... 7-2

Removing the Cover ................................... 7-3

DASD 2-Pack Assembly ................................. 7-6

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7

Riser Card Support Bracket .............................. 7-10

Riser Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11

System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

Fansink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13

Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15

Setting the SCSI Security Jumpers .......................... 7-16

Front Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17

Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18

Reset Button and Operator Panel Display Assembly ................ 7-19

iv 7046 Model B50 Service Guide

Activity LED and Cable Assemblies .......................... 7-20

I/O Port Cable Assembly ................................ 7-21

Diskette Drive Assembly ................................ 7-22

CD-ROM Drive Assembly ............................... 7-23

Internal Disk Drives ................................... 7-24

Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-25

Memory Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-26

Changing the Battery .................................. 7-31

Chapter 8. Parts Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Appendix A. Interpreting Firmware Error Codes ................. A-1

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X-1

Reader's Comments — We'd Like to Hear From You ............... X-3

Preface v

vi 7046 Model B50 Service Guide

Communications Statements

The following statement applies to this product. The statement for other products intended for use with this product appears in their accompanying documentation.

Federal Communications Commission (FCC) Statement

Note: This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Neither the provider nor the manufacturer are responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

European Union (EU) Statement

This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. The manufacturer cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of option cards supplied by third parties. Consult with your dealer or sales representative for details on your specific hardware.

This product has been tested and found to comply with the limits for Class A Information Technology Equipment according to CISPR 22 / European Standard EN

55022. The limits for Class A equipment were derived for commercial and industrial

Communications vii

environments to provide reasonable protection against interference with licensed communication equipment.

Attention: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

International Electrotechnical Commission (IEC) Statement

This product has been designed and built to comply with IEC Standard 950.

United Kingdom Telecommunications Safety Requirements

This equipment is manufactured to the International Safety Standard EN60950 and as such is approved in the UK under the General Approval Number NS/G/1234/J/100003 for indirect connection to the public telecommunication network.

The network adapter interfaces housed within this equipment are approved separately, each one having its own independent approval number. These interface adapters, supplied by the manufacturer, do not use or contain excessive voltages. An excessive voltage is one which exceeds 70.7 V peak ac or 120 V dc. They interface with this equipment using Safe Extra Low Voltages only. In order to maintain the separate (independent) approval of the manufacturer's adapters, it is essential that other optional cards, not supplied by the manufacturer, do not use main voltages or any other excessive voltages. Seek advice from a competent engineer before installing other adapters not supplied by the manufacturer.

Avis de conformité aux normes du ministère des Communications du Canada

Cet appareil numérique de la classe A respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada.

Canadian Department of Communications Compliance Statement

This Class A digital apparatus meets the requirements of the Canadian Interference–Causing Equipment Regulations.

viii 7046 Model B50 Service Guide

VCCI Statement

The following is a summary of the VCCI Japanese statement in the box above. This is a Class A product based on the standard of the Voluntary Control Council for

Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.

Electromagnetic Interference (EMI) Statement - Taiwan

The following is a summary of the EMI Taiwan statement above. Warning: This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user will be required to take adequate measures.

Communications ix

Radio Protection for Germany

Dieses Gerät ist berechtigt in Übereinstimmung mit Dem deutschen EMVG vom

9.Nov.92 das EG–Konformitätszeichen zu führen. Der Aussteller der Konformitätserklärung ist die IBM Germany. Dieses Gerät erfüllt die Bedingungen der EN 55022 Klasse A. Für diese von

Geräten gilt folgende Bestimmung nach dem EMVG: Geräte dürfen an Orten, für die sie nicht ausreichend entstört sind, nur mit

besonderer Genehmigung des Bundesministers für Post und Telekommunikation oder des Bundesamtes für Post und Telekommunikation betrieben werden. Die Genehmigung wird erteilt, wenn keine elektromagnetischen Störungen zu erwarten sind.

(Auszug aus dem EMVG vom 9.Nov.92, Para.3, Abs.4) Hinweis Dieses Genehmigungsverfahren ist von der Deutschen Bundespost noch nicht

veröffentlicht worden.

x 7046 Model B50 Service Guide

Safety Notices

A danger notice indicates the presence of a hazard that has the potential of causing death or serious personal injury. Danger notices appear on the following pages:

2-12 7-1 7-7

A caution notice indicates the presence of a hazard that has the potential of causing moderate or minor personal injury. Caution notices appear on the following pages:

xii 2-12 7-1 7-31

Safety Notices xi

Laser Safety Information

The optical drive in the RS/6000 7046 Model B50 is a laser product. The optical drive has a label that identifies its classification. The label, located on the drive, is shown below.

CLASS 1 LASER PRODUCT LASER KLASSE 1 LUOKAN 1 LASERLAITE APPAREIL A LASER DECLASSE 1

IEC 825:1984 CENELEC EN 60 825:1991

The optical drive in the RS/6000 7046 Model B50 is certified in the U.S. to conform to the requirements of the Department of Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 (1st edition 1984) and CENELEC EN 60 825:1991 for Class 1 laser products.

CAUTION: A class 3 laser is contained in the device. Do not attempt to operate the drive while it is disassembled. Do not attempt to open the covers of the drive as it is not serviceable and is to be replaced as a unit.

Class 1 laser products are not considered to be hazardous. The optical drive contains internally a Class 3B gallium-arsenide laser that is nominally 0.14 milliwatts at 830 nanometers. The design incorporates a combination of enclosures, electronics, and redundant interlocks such that there is no exposure to laser radiation above a Class 1 level during normal operation, user maintenance, or servicing conditions.

xii 7046 Model B50 Service Guide

Environmental Notices

Product Recycling and Disposal

This unit contains materials such as circuit boards and connectors with lead that require special handling and disposal at end of life. Before this unit is disposed of, these materials must be removed and recycled or discarded according to applicable regulations. This manual contains specific information on batteries where applicable. This product may contain nickel-cadmium and/or lithium batteries. The battery(s) must be recycled or disposed of properly. Recycling facilities may not be available in your area. In the United States, IBM has established a collection process for reuse, recycling, or proper disposal of used sealed lead acid, nickel cadmium and nickel metal hydride batteries and battery packs from IBM equipment. For information on proper disposal of the nickel cadmium batteries in this product, please contact IBM at 1-800-426-4333. For information on battery disposal outside the United States, contact your local waste disposal facility.

Environmental Design

The environmental efforts that have gone into the design of this system signify IBM's commitment to improve the quality of its products and processes. Some of these accomplishments include the elimination of the use of Class I ozone-depleting chemicals in the manufacturing process and reductions in manufacturing wastes. For more information, contact an IBM account representative.

Environmental Notices xiii

xiv 7046 Model B50 Service Guide

About This Book

This book provides reference information, maintenance analysis procedures (MAPs), error codes, and removal and replacement procedures. This book also provides information on diagnostics, System Management Services, and firmware flow. A parts catalog is also included.

Note: MAPs that are common to all systems are contained in Diagnostics

Information for Multiple Bus Systems, order number SA38-0509.

This book is used by the service technician to repair system failures. This book assumes that the service technician has had training on the server.

ISO 9000

ISO 9000 registered quality systems were used in the development and manufacturing of this product.

Online Publications

RS/6000 publications are available online. To access the online books, visit our Web site at: http://www.rs6.ibm.com/resource/hardware_docs/

Related Publications

The following publications are available for purchase:

 Diagnostics Information for Multiple Bus Systems, order number SA38-0509,

contains common diagnostic procedures, error codes, service request numbers, and failing function codes. This manual is intended for trained service technicians.

 Adapters, Devices, and Cable Information for Multiple Bus Systems, order

number SA38-0516, contains information about adapters, external devices, and cabling. This manual is intended to supplement information found in the Diagnostics Information for Multiple Bus Systems.

 RS/6000 7046 Model B50 Setup Guide, order number SA38-0562, is a pictorial

guide designed to help system users set up their systems.

 RS/6000 7046 Model B50 User's Guide, order number SA38-0563, provides

information about installing options, system operation, and running diagnostics.

About This Book xv

Trademarks

The following trademarks apply to this information:

 AIX is a registered trademark of International Business Machines Corporation.  PowerPC is a trademark of International Business Machines Corporation.

xvi 7046 Model B50 Service Guide

Chapter 1. Reference Information

Front View

10 9 8 611

1 Power Switch: Turns server power on and off.

2 Hard Disk Drive Status Light:

Glows when server is reading from or writing to the hard disk.

3 Power-On Light: Glows when server is on.

4 Disk Drive Bay Cover: Covers the hard disk drive bays.

5 Reset Button: Function depends upon the operating system installed.

6 Operator Panel Display: Function depends upon the operating system installed; may display current status of server startup, or diagnostic information in the event of a hardware problem.

7 CD-ROM Eject Button: Releases the CD-ROM from the CD-ROM drive.

8 CD-ROM Emergency Eject: Ejects CD-ROM from the CD-ROM drive if power is not available.

9 CD-ROM Status Light: Indicates when the CD-ROM drive is active.

10 CD-ROM Volume Control:

Controls the volume for the CD-ROM headphone jack.

11 CD-ROM Headphone Jack:

CD-ROM Headphone connector.

12 Diskette-Drive Status Light:

Glows when server is reading from or writing to a diskette.

13 Diskette Eject Button: Releases diskette from 3.5-inch diskette drive.

Chapter 1. Reference Information 1-1

Rear View

789

1 2

1 Keyboard Port: ( ): For keyboard connection.

2 Mouse Port ( ): For mouse connection.

3 Parallel Port ( ): For connecting a parallel printer or other parallel devices.

4 Ethernet Port ( ): For attaching your server to an Ethernet/Twisted pair connection through a 100/10 Base T connector.

5 External SCSI Port ( ): For connecting external SCSI devices.

6 Audio Ports:

Headphone Microphone

Audio line out Audio line in

7 9-Pin Serial Ports

( 1 and

): For a TTY terminal,

Modem, or other serial devices.

8 Tablet Port ( ): For attaching a digitizing tablet to your server.

9 Ethernet Port ( ): For attaching your server to an Ethernet thick connection (or Ethernet thin connection, using an optional transceiver) through a 100/10 Base 5 connector.

10 Expansion Slots: For adding PCI adapters.

1-2 7046 Model B50 Service Guide

Front View without Covers

Chapter 1. Reference Information 1-3

Specifications

The mechanical packaging, cooling, power supply, and environmental requirements for the workstation are as follows:

Dimensions

In horizontal orientation, the dimensions are:

 Height - 88.0 mm (3.5 inches)  Width - 447.0 mm (17.6 inches)  Depth - 612.0 mm (24.1 inches) Minimum  Depth - 751.8 mm (29.6 inches) Maximum (includes covers and cables)

Weight

14.5 kg (32 lb) Minimum to 15.9 kg (35 lb) Maximum

Maximum Support Capacity (Horizontal Position)

27.3 kg (60 lbs)

Operating Environment - Class C

Temperature - 10° to 40°C (50° to 104°F)

Humidity - 8% to 80% noncondensing Wet Bulb - 27 degrees C (80 degrees F) operating and nonoperating

Maximum Altitude - 2135 m (7000 feet)

Power Source Loading

0.3k VA typical

0.5k VA maximum

The upper limit of the dry bulb temperature must be derated 1° C per 137m (450 ft.) above 915m (3000 ft.).

The upper limit of the wet bulb temperature must be derated 1° C per 274m (900 ft.) above 305m (1000 ft.).

1-4 7046 Model B50 Service Guide

Power Supply

250 watts

Operating Voltage

100 to 127V ac; 50 to 60 Hz 200 to 240V ac; 50 to 60 Hz

Heat Output (Maximum)

Operating 478 BTUs per hour

Acoustics

 Average sound-pressure levels:

– At operator position:

Operating n/a Idle n/a

– At bystander position (1 meter)

Operating 35 dBA Idle 30 dBA

 Declared (upper limit) sound power levels:

Operating 5.2 Bels Idle 4.7 Bels

Chapter 1. Reference Information 1-5

System Board Locations

J59 J56 J49 J45 J38 J22 J17 J13 J3

J31

J14

J29

J139

J50

J20

J19

J53

J28

J11

J43

J40

J39

J15

J32

J35

J33

J25

J36

J23

J24

J16

J10

J44

J41J26

J42

J46J12

J18J27J30

1-6 7046 Model B50 Service Guide

B1 Battery connector

J26 CPU fansink connector J1 Not used J2 5x5 Auxiliary 5v connector J3 Audio input connector J4 Internal SCSI connector #2 J5 CD-ROM audio connector J6 CD-ROM audio connector J7 Power connector J8 Power connector J9 Not used J10 Media Fan connector J11 Memory Connector 1 J12 Not used J13 Audio output connector J14 Not used J15 Remote Power-up Jumper J16 Diskette drive connector J17 Microphone jack J18 Reset Connector J19 Memory Connector 3 J20 Power-on password jumper J22 Headphone jack J23 Serial port connector 2 J24 Serial port connector 1 J25 Tablet port connector

J27 System fan connector

J28 Memory Connector 2

J29 Not used

J30 System fan connector

J31 Not used

J32 Privileged-access password

jumper

J33 Internal SCSI 16-bit connector

J35 SCSI security jumper

J36 SCSI security jumper

J38 External SCSI connector

J39 Riser card connector

J40 Power Switch connector

J41 Op Panel Connector

J42 Power Indicator LED connector

J43 Hard-disk activity LED connector

J44 Voltage Regulator connector

J45 Ethernet twisted pair connector

J46 Internal Speaker connector

J49 Parallel port connector

J50 Ethernet AUI

J53 Ethernet EPROM connector

J56 Mouse port connector

J59 Keyboard port connector

J139 Memory Connector 4

Chapter 1. Reference Information 1-7

System Board Jumper Settings

For a more complete description of the function of these jumpers, see "Installing and Removing Options" in the RS/6000 7046 Model B50 User's Guide.

Jumper Description Settings

J15 Remote Power-up Default: Remote power-up disabled.

To enable Remote power-up, place jumper on the two pins closest to the rear of the server.

J20 Power-On Password Default: power-on password enabled

(can be set). To disable the power-on password

(for instance, if it has been forgotten), place jumper on the two rightmost pins.

J32 Privileged-Access Password Default: disabled.

To enable the writing or changing of the privileged-access password, place jumper on the two pins closest to the rear of the server.

J35, J36 SCSI Security Default: external SCSI enabled

To disable external SCSI connector, move the jumper on J35 to the front two pins, and the jumper on J36 to the right two pins.

1-8 7046 Model B50 Service Guide

Riser Card

Slot Location Code/Comments 2 10-90 PCI Primary 1 10-B0 PCI Secondary, short card only

SCSI Bus Termination

The Model B50 has an Ultra SCSI bus which can support internal and external SCSI devices. However, each controller on these SCSI busses must have a unique SCSI ID. The external SCSI busses must be properly terminated to ensure SCSI signal integrity.

For directions on setting the SCSI ID on each device, consult the documentation for that device, as well as the Adapters, Devices, and Cable Information for Multiple Bus Systems.

Note: Internal SCSI IDs cannot be used on the external SCSI connector (J38). The

internal SCSI IDs are as follows:

SCSI ID Internal Device 2 Upper Hard-Disk Drive 3 CD-ROM Drive 4 Lower Hard-Disk Drive

Chapter 1. Reference Information 1-9

Power Cables

To avoid electrical shock, a power cable with a grounded attachment plug is provided. Use only properly grounded outlets.

Power cables used in the United States and Canada are listed by Underwriter's Laboratories (UL) and certified by the Canadian Standards Association (CSA). These power cords consist of:

 Electrical cables, Type SVT or SJT.  Attachment plugs complying with National Electrical Manufacturers Association

(NEMA) 5-15P, that is:

"For 115 V operation, use a UL listed cable set consisting of a minimum 18 AWG, Type SVT or SJT three-conductor cord a maximum of 15 feet in length and a parallel blade, grounding type attachment plug rated at 15 A, 127 V."

"For 240 V operation in the United States use a UL listed cable set consisting of a minimum 18 AWG, Type SVT or SJT three-conductor cable a maximum of 15 feet in length, and a tandem blade, grounding type attachment plug rated at 15 A, 250 V."

 Appliance couplers complying with International Electrotechnical Commission

(IEC) Standard 320, Sheet C13.

Power cables used in other countries consist of the following:

 Electrical cables, Type HD21.  Attachment plugs approved by the appropriate testing organization for the

specific countries where they are used.

"For units set at 230 V (outside of U.S.): use a cable set consisting of a minimum 18 AWG cable and grounding type attachment plug rated 15 A, 250 V. The cable set should have the appropriate safety approvals for the country in which the equipment will be installed and should be marked HAR."

Refer to Chapter 8, “Parts Information” on page 8-1 to find the power cables that are available.

Service Inspection Guide

Perform a service inspection on the server when:

 The server is inspected for a maintenance agreement.  Service is requested and service has not recently been performed.  An alterations and attachments review is performed.

1-10 7046 Model B50 Service Guide

 Changes have been made to the equipment that may affect the safe operation of

the equipment.

 External devices with separate power supplies have been attached.

If the inspection indicates an unacceptable safety condition, the condition must be corrected before anyone can service the machine.

Note: The owner of the server is responsible to correct any unsafe conditions. Perform the following checks:

1. Check the covers for sharp edges and for damage or alterations that expose the internal parts of the server.

2. Check the covers for proper fit to the server. They should be in place and secure.

3. Gently rock the server from side to side to determine if it is steady.

4. Set the power switch of the server to Off.

5. Disconnect the power cable.

6. Remove the covers.

7. Check for alterations or attachments. If there are any, check for obvious safety hazards, such as broken wires, sharp edges, or broken insulation.

8. Check the internal cables for damage.

9. Check for dirt, water, and any other contamination within the server.

10. Check the external power cable for damage.

11. With the external power cable connected to the server, check for 0.1 ohm or less resistance between the ground lug on the external power cable plug and the metal frame.

12. Perform the following checks on each device that has its own power cables:

a. Check for damage to the power cord. b. Check for the correct grounded power cable. c. With the external power cable connected to the device, check for 0.1 ohm or

less resistance between the ground lug on the external power cable plug and the metal frame of the device.

13. Install the covers.

Chapter 1. Reference Information 1-11

1-12 7046 Model B50 Service Guide

Chapter 2. Maintenance Analysis Procedures (MAPs)

This chapter contains Maintenance Analysis Procedures (MAPs) for the RS/6000 7046 Model B50.

Entry MAP

Notes:

1. When possible, run Online Diagnostics in Service Mode. Online Diagnostics perform additional functions, compared to Standalone Diagnostics. This ensures that the error state of the system is captured in nonvolatile random access memory (NVRAM) for your use in fixing the problem. The AIX error log and SMIT are only available when diagnostics are run from the hard drive.

D 2. Online Diagnostics are only available when the AIX operating system is used. If D you have another operating system, run the Standalone Diagnostics from the D CD-ROM or the network.

3. Licensed programs frequently rely on either network configuration, vital product data (VPD) stored on the operator control panel assembly, or system board information to authorize program use. If the MAPs indicate that the network adapter, operator panel, system board, or network adapter should be replaced, notify the system owner that new keys for licensed programs may be required.

4. If a network adapter or the system board is replaced, the network administrator must be notified so that the client IP addresses used by the server can be changed. In addition, the operating system configuration of the network controller may need to be changed in order to enable system startup. In addition, check to ensure that any client or server that addresses this system is updated.

5. After completing the recommended actions in this chapter, go to "MAP 0410: Repair Checkout" in Diagnostics Information for Multiple Bus Systems.

Problem Description Page No.

Service Actions 2-2 System Stops or Hangs with Alternating Numbers Displayed in the Operator

Panel Display System Stops With an Error or Checkpoint Code Displayed 2-2 There Appears to be a Display Problem (Distortion, Blurring, etc.) 2-3 Power and Cooling Problems 2-3 Other Symptoms or Problems 2-3 You Cannot Find the Symptom in this Table 2-5

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-1

2-2

Use the following table to determine your starting point.

Symptom Action

Service Actions

You have parts to exchange or a corrective action to perform.

You need to verify that a part exchange or corrective action corrected the problem.

You need to verify correct system operation. Go to "MAP 0410: Repair Checkout" in the

System Stops or hangs with alternating numbers displayed in the Operator Panel display.

The Operator Panel display alternates between the code "E1FD" and another "Exxx" code.

The Operator Panel display alternates between the codes "E1DE" and "E1AD".

System Stops with an Error or Checkpoint Code Displayed

The system stops with an 8-digit error code starting with the number "2" displayed on the system console.

The system stops and a 4-digit number beginning with the characters "FF" is displayed in the operator panel display.

The system stops and a 4-digit number beginning with the character "E" is displayed in the operator panel display.

The system stops and a 4-digit number not beginning with the characters "FF" or "E" is displayed in the operator panel display.

The system stops and a 3-digit number is displayed in the operator panel display.

1. Go to Chapter 7, “Removal and Replacement Procedures” on page 7-1.

2. Go to "MAP 0410: Repair Checkout" in the

Diagnostics Information for Multiple Bus Systems.

Go to "MAP 0410: Repair Checkout" in the

Diagnostics Information for Multiple Bus Systems.

Record both codes. Go to the entry for "E1FD" on page 3-23.

Record the error codes. Go to the entry for "E1DE" on page 3-21,

Record the error code. Go to Chapter 3, “Error Code to FRU Index” on page 3-1.

Go to “MAP 1540: Minimum Configuration” on page 2-17.

Record the code. Go to “Firmware Checkpoints” on page 3-14.

Record SRN 101-xxx, where xxx is the last three digits of the 4-digit number displayed, then go to the "Fast Path MAP" in the Diagnostics Information for Multiple Bus Systems.

If the number is 000, 185 or 888, go to “MAP 1540: Minimum Configuration” on page 2-17.

Record SRN 101-xxx, where xxx is the number displayed, then go to the "Fast Path MAP" in

Diagnostics Information for Multiple Bus Systems.

2-2 7046 Model B50 Service Guide

Symptom Action

Flashing 888 is displayed in the control panel followed by additional error codes. Record in sequence each code that is displayed after the flashing 888 goes away. Stop recording when the flashing 888 reappears.

There Appears to be a Display Problem (Blank, Distortion, Blurring, Etc.)

All display problems. 1. If using a graphics display:

Power and Cooling Problems

The power LEDs on the operator panel and power supply do not come on or stay on.

The power LED on the operator panel comes on and the system powers on automatically when A/C power is applied.

The power LED on the operator panel comes on and stays on but the system does not power on.

The cooling fan(s) do not come on or come on but do not stay on.

Go to the Fast Path MAP in the Diagnostics Information for Multiple Bus Systems.

a. Go to the Problem Determination

Procedures for the display.

b. If you do not locate the problem, replace

the display adapter.

2. If using an ASCII terminal: a. Make sure that the ASCII terminal is

connected to Serial Port 1.

b. If the problems persist, go to the

Problem Determination Procedures for the terminal.

3. If you do not locate the problem, suspect

the system board. Go to “MAP 1540: Minimum Configuration” on page 2-17.

Go to “MAP 1520: Power” on page 2-12.

Automatic power-up is a feature on the Model B50. Refer to “System Board Jumper Settings” on page 1-8 for the correct settings. If the jumper is set in the disabled position, replace the system board.

Go to “MAP 1520: Power” on page 2-12.

MAP 1020: Problem Determination

Purpose of This MAP

Use this MAP to get an error code if you were not provided one by the customer or you are unable to load diagnostics. If you are able to load the diagnostics, go to MAP 0020 in Diagnostics Information for Multiple Bus Systems.

Be prepared to record code numbers and use those numbers in the course of analyzing a problem. Go to “Step 1020-1.”

Step 1020-1

The following steps analyze a failure in loading the diagnostic programs. Note: Be prepared to answer questions regarding the operator panel display and to

perform certain actions based on displayed POST indicators. Please be observant of these conditions.

1. Insert the diagnostic CD-ROM disc into the CD-ROM drive.

2. Turn off the power.

3. Turn on the power.

4. If the keyboard indicator is displayed (the word keyboard on an ASCII terminal or the keyboard and hand icon on a graphical display), press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal.

5. Enter any requested passwords.

6. Wait until the diagnostics are loaded or the system appears to stop.

7. Find your symptom in the following table; then follow the instructions given in the Action column.

Symptom Action

The disk LED is blinking rapidly, or E1EA or E1EB is displayed on the operator panel.

The system stops with a prompt to enter a password.

The diagnostics loaded. Go to MAP 0020 in Diagnostics Information for

The flash EPROM data is corrupted. The recovery procedure for the flash EPROM should be performed. See “Firmware Recovery” on page 6-22.

Enter the password. You will not be allowed to continue until a correct password has been entered. When you have entered a valid password go to the beginning of this table and wait for one of the other conditions to occur.

Multiple Bus Systems

2-6 7046 Model B50 Service Guide

Symptom Action

The system login prompt is displayed. You may not have pressed the correct key, or

you may not have pressed the key soon enough when you were to indicate a Service Mode IPL of the diagnostic programs. If this is the case, start over at the beginning of this Step.

Note: Perform the system shutdown procedure

before turning off the system.

If you are sure you pressed the correct key in a timely manner, go to “Step 1020-2” on page 2-8.

The system does not respond when the password is entered.

The system stopped. A POST indicator is displayed on the system console and

 an eight-digit error code is not displayed on

the system console.

 a four-digit error code is not displayed on

the operator panel.

 a three-digit error code is not displayed on

the operator panel.

The system stops and an 8-digit error code starting with the number "2" displayed.

The system stops and a 4-digit number beginning with the characters "FF" is displayed in the operator panel display.

The system stops and a 4-digit number beginning with the character "E" is displayed in the operator panel display.

The system stops and a 4-digit number not beginning with the characters "FF" or "E" is displayed in the operator panel display.

The system stops and a 3-digit number is displayed in the operator panel display.

The System Management Services application appears on the screen.

All other symptoms. If you were directed here from the Entry MAP,

Go to “Step 1020-2” on page 2-8.

Go to “MAP 1540: Minimum Configuration” on page 2-17.

Record the error code. Go to Chapter 3, “Error Code to FRU Index” on page 3-1.

Go to “MAP 1540: Minimum Configuration” on page 2-17.

Record the error code. Go to “Firmware Checkpoints” on page 3-14.

Record SRN 101-xxx, where xxx is the last three digits of the four digit number displayed. Then go to the "Fast Path MAP" in Diagnostics Information for Multiple Bus Systems.

If the number is 000, 185 or 888, go to “MAP 1540: Minimum Configuration” on page 2-17.

Record SRN 101-xxx, where xxx is the three digits displayed. Then go to the "Fast Path MAP" in Diagnostics Information for Multiple Bus Systems.

Go to sub-step 3 in “Step 1020-3” on page 2-8.

go to “MAP 1540: Minimum Configuration” on page 2-17. Otherwise, find the symptom in the “Entry MAP” on page 2-1.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-7

Step 1020-2

There is a problem with the keyboard. Find the type of keyboard you are using in the following table; then follow the

instructions given in the Action column.

Keyboard Type Action

Type 101 keyboard (U.S.). Identified by the size of the Enter key, which extends into only one horizontal row.

Type 102 keyboard (W.T.). Identified by the size of the Enter key, which extends into two horizontal rows.

Type 106 keyboard. (Identified by the Japanese characters.)

ASCII terminal keyboard Go to the documentation that came with the

Replace the type 101 keyboard.

Replace the type 102 keyboard.

Replace the type 106 keyboard.

ASCII terminal and continue problem determination.

Step 1020-3

Take the following actions:

1. Turn off, then turn on the system unit.

2. When the keyboard indicator appears, press the F1 key on a directly attached keyboardor the 1 key on an ASCII terminal.

3. When the System Management Services appear, check the error log for any errors.  Choose Utilities

 Choose Error Log  If an error is logged, check the time stamp.  If the error was logged during the current boot attempt, record it.  Look up the error in Chapter 3, “Error Code to FRU Index” on page 3-1 and

do the listed action.

 If no recent error is logged in the error log, go to “MAP 1540: Minimum

Configuration” on page 2-17.

2-8 7046 Model B50 Service Guide

MAP 1240: Memory Problem Resolution

Note: The firmware checkpoint that sent you here could be one of the following:

 E122, E213, E214, E218, E220 or E3xx

Each of these checkpoints is referred to as a memory checkpoint in this MAP.

Purpose of this MAP

This MAP is used to troubleshoot a problem during the memory test when the system stops at a memory checkpoint and no error code is displayed on the system console.

General Memory Information

Be sure to unplug the power cable before removing or installing the memory modules to avoid damage to them.

The memory modules do not need to be installed in pairs and can be installed in any slot on the system board. There is no requirement that one slot be installed before the other.

Refer to “Memory Modules” on page 7-26 for locations of the memory modules and instructions on removing and installing modules.

Note: If the symptom changes while using this MAP, check for loose cards, cables,

and obvious problems. If you do not find a problem, go to “MAP 1540: Minimum Configuration” on page 2-17.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-9

Step 1240-1

1. Ensure that the diagnostics and the operating system are shut down.

2. Power off the system.

3. Remove and reinstall any installed memory modules.

4. Power on the system.

Does the system stop with a memory checkpoint displayed on the operator panel?

NO Reseating the memory modules has corrected the problem. Go to "MAP

0410: Repair Checkout" in Diagnostics Information for Multiple Bus Systems.

YES If there is only one memory module installed, go to “Step 1240-3” on

page 2-11. If there is more than one memory module installed, go to “Step 1240-2.”

Step 1240-2

1. Power off the system.

2. Remove all but one of the installed memory modules. Record the position of the memory modules removed so that when instructed to reinstall them, they can be installed in their original positions.

3. Power on the system.

Does the system stop with a memory checkpoint displayed on the operator panel?

NO Repeat this step until all the memory modules are installed and tested.

If all the memory modules have been installed, reseating the memory modules has corrected the problem.

Go to "MAP 0410: Repair Checkout" in Diagnostics Information for Multiple Bus Systems.

YES Go to “Step 1240-3” on page 2-11.

2-10 7046 Model B50 Service Guide

Step 1240-3

The failure may be caused by the last memory module installed or the system board. To isolate the failing FRU, do the following:

1. Power off the system.

2. Exchange the last memory module installed.

3. Power on the system.

Does the system stop with a memory checkpoint displayed on the operator panel?

NO Go to "MAP 0410: Repair Checkout" in Diagnostics Information for

Multiple Bus Systems.

YES Go to “Step 1240-4.”

Step 1240-4

One of the FRUs remaining in the system unit is defective.

1. Power off the system.

2. Exchange the following FRUs in the order listed.  System Board  Power Supply

3. Power on the system.

Does the system stop with a memory checkpoint displayed on the operator panel?

NO Go to "MAP 0410: Repair Checkout" in Diagnostics Information for

Multiple Bus Systems.

YES Reinstall the original FRU.

Repeat this step until the defective FRU is identified or all the FRUs have been exchanged.

If the symptom did not change and all the FRUs have been exchanged, go to “MAP 1540: Minimum Configuration” on page 2-17.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-11

MAP 1520: Power

Notes:

1. This is not a start of call MAP. Use this Power MAP only if you have been directed here from a MAP step in this book or the Diagnostics Information for Multiple Bus Systems.

2. The 7046 model B50 has a power LED located on the operator panel. When the system is powered on, the LED should be on solid.

This procedure is used to locate power problems in servers. If a problem is detected, this procedure helps you isolate the problem to a failing unit.

Observe the following safety notices during service procedures.

DANGER

An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock.

Before installing or removing signal cables, ensure that the power cords for the server and all attached devices are unplugged.

When adding or removing any additional devices to or from the system, ensure that the power cords for those devices are unplugged before the signal cables are connected. You must disconnect all power cords from the existing system before you add a device.

Use one hand, when possible, to connect or disconnect signal cables to prevent a possible shock from touching two surfaces with different electrical potentials.

During an electrical storm, do not connect cables for display stations, printers, telephones, or station protectors for communication lines.

CAUTION:

This product is equipped with a three-wire power cord and plug for the user's safety. Use this power cable with a properly grounded electrical outlet to avoid electrical shock.

2-12 7046 Model B50 Service Guide

DANGER

To prevent electrical shock hazard, disconnect the power cord from the electrical outlet before relocating the system.

Step 1520-1

You may be directed to this MAP for several reasons:

1. There is no indication of activity when the power button on the operator panel is pressed. The power LED does not come on and none of the fans, including the fan in the power supply, start to turn.

Go to “Step 1520-2.”

2. When the power button on the operator panel is pressed, the system begins to power on, but the power does not stay on.

Go to “Step 1520-2.”

Step 1520-2

1. Unplug the power cord from the Power Distribution Unit (PDU)/Power Distribution Bus (PDB) and the power outlet.

2. Unplug the power cord from the PDU/PDB and the power supply.

3. Check that the power cord from the power outlet to the PDU/PDB has continuity.

4. Check that the power cord from the PDU/PDB to the power supply has continuity.

5. Check that the power outlet has been wired correctly with the correct voltage.

6. Plug the power cord into the PDU/PDB and the power supply.

7. Plug the power cord into the PDU/PDB and the power outlet.

Did you find a problem? NO Go to “Step 1520-3” on page 2-14. YES Correct the problem. Go to "MAP 0410: Repair Checkout" in the

Diagnostics Information for Multiple Bus Systems.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-13

Step 1520-3

1. Unplug the power cord from the server.

2. Disconnect all external cables (parallel, serial 1, serial 2, keyboard, mouse, AUI/RJ45 ethernet, SCSI, and so on).

3. Remove the server from the rack, as described in “Removing the Cover” on page 7-3.

4. Record the slot numbers of the PCI adapters. Label and record the location of any cables attached to the adapters. Disconnect any cables attached to the adapters and remove all the adapters.

5. Remove all the memory modules.

6. Remove the riser card from the system board, as described in “Riser Card” on page 7-11.

7. Unplug the SCSI cables from the system board.

8. Unplug the diskette drive signal cable and diskette drive power cable from the system board.

9. Unplug the power cables from all the SCSI devices.

10. Unplug the internal serial port and Ethernet cable from the system board.

11. Unplug the cooling fan power connectors.

12. Unplug the speaker. Note: Do not disconnect the power-on LED or the power switch.

13. Plug the power cord into the server.

14. Turn on the power.

Does the fan in the power supply turn on and the power LED come on and stay on?

NO Go to “Step 1520-4” on page 2-15. YES Go to “Step 1520-5” on page 2-16.

2-14 7046 Model B50 Service Guide

Step 1520-4

Either the power supply, the power switch, the system fan, or the system board is defective.

Exchange the FRUs that have not already been exchanged in the following order:  Power supply

 Power switch  System fan

 System board (See notes on page 2-1)

To test each FRU:

1. Unplug the power cord from the server.

2. Exchange one of the FRUs in the list.

3. Plug the power cord into the server.

4. Turn on the power.

Does the fan in the power supply turn on and the power LED come on and stay on?

NO Reinstall the original FRU.

Repeat this step until the defective FRU is identified or all the FRUs have been exchanged.

If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.

If the symptom has changed, check for loose cards, cables, and obvious problems. If you do not find a problem, return to “Step 1520-1” on page 2-13 and follow the instructions for the new symptom.

YES Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for

Multiple Bus Systems.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-15

Step 1520-5

One of the parts that was removed or unplugged is causing the problem. Install or connect the parts in the following order:

1. Fans

2. Riser card

3. Memory module(s)

4. System board cables (SCSI signal cables, diskette drive signal cable, serial port, Ethernet, speaker)

5. Diskette drive power cable

6. SCSI power cable(s), lowest bay to highest bay

7. Adapter cards, lowest slot to highest slot

8. External cable(s) Turn on the power after each part is installed or connected. If the system does not

power on or the power does not stay on, the most recently installed or connected part is causing the failure.

1. Turn off the power.

2. Unplug the power cord from the server.

3. Install or connect one of the parts in the list.

4. Plug the power cord into the server.

5. Turn on the power.

Does the fan in the power supply turn on and the power LED come on and stay on?

NO Replace the last part you installed or connected. (If this part was a

network adapter, see notes on page 2-1.) Repeat these steps until all the parts have been installed or connected. If the symptom did not change and all the parts have been installed or

connected, call your service support person for assistance. If the symptom has changed, check for loose cards, cables, and obvious

problems. If you do not find a problem, return to “Step 1520-1” on page 2-13 and follow the instructions for the new symptom.

YES Repeat these steps until all the parts have been installed or connected.

Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for Multiple Bus Systems.

2-16 7046 Model B50 Service Guide

MAP 1540: Minimum Configuration

Note: If you were sent to this MAP from the Diagnostics Information for Multiple Bus

Systems as a result of an SRN 101-xxx problem, go to “Boot Problems or Concerns” on page 3-27 and follow the instructions there before using the MAP 1540 steps.

Purpose of this MAP

This MAP is used to locate defective FRUs not found by normal diagnostics. For this procedure, diagnostics are run on a minimally configured system. If a failure is detected on the minimally configured system, the remaining FRUs are exchanged one at a time until the failing FRU is identified. If a failure is not detected, FRUs are added back until the failure occurs. The failure is then isolated to the failing FRU.

Notes:

1. Be sure to unplug the power cable before removing or installing the memory module(s), riser card, or system board to avoid damage to them.

2. This MAP assumes that a CD-ROM drive is installed and connected to the integrated SCSI adapter, and a Diagnostics CD-ROM disc is available.

3. If a power-on password or privileged-access password is installed, you are prompted to enter the password before the diagnostic CD-ROM can load.

4. The term POST indicators refer to the icons (graphic display) or device mnemonics (ASCII terminal) that appear during the power-on self-test (POST).

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-17

Step 1540-1

1. Ensure that the diagnostics and the operating system are shut down.

2. Turn off the power.

3. Turn the power on.

4. Insert the diagnostic CD-ROM into the CD-ROM drive. Note: If you are unable to insert the diagnostic CD-ROM, go to “Step 1540-2.”

5. When the keyboard indicator is displayed (the word keyboard on an ASCII terminal or the keyboard and hand icon on a graphical display), press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal.

6. If the Console Selection screen is displayed, choose the system console.

7. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Go to “Step 1540-2.” YES Go to “Step 1540-13” on page 2-28.

Step 1540-2

Notes:

1. If an ASCII terminal has been defined as the system console, do not disconnect the ASCII terminal cable from the connector for serial port 1 at the rear of the server.

2. If a display attached to a display adapter has been defined as the system console, do not disconnect the display from the display adapter or the keyboard from the keyboard connector on the rear of the server.

1. Turn off the power.

2. Disconnect all external cables (parallel, serial 1, serial 2, keyboard, mouse, tablet, AUI/RJ45 ethernet, SCSI, audio, etc).

3. Label and record the location of any external cables attached to the PCI adapters. Disconnect all the cables from the adapters.

4. Turn on the power.

5. Insert the diagnostic CD-ROM into the CD-ROM drive. Note: If you are unable to insert the CD-ROM, go to “Step 1540-3” on

page 2-19.

2-18 7046 Model B50 Service Guide

6. When the keyboard indicator is displayed (the word keyboard on an ASCII terminal or the keyboard and hand icon on graphical display), press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal.

7. If the Console Selection screen is displayed, choose the system console.

8. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Go to “Step 1540-3.” YES Go to “Step 1540-13” on page 2-28.

Step 1540-3

1. Turn off the power.

2. If an ASCII terminal has been defined as the system console, disconnect the ASCII terminal connected to serial 1.

3. If a display attached to a display adapter has been defined as the system console, disconnect the display from the display adapter and the keyboard from the keyboard connector on the rear of the server.

4. Remove the server from the rack, as described in “Removing the Cover” on page 7-3.

5. Record the slot numbers of any adapter cards installed in the server. Label and record the location of any cables attached to the adapters and disconnect the cables. Remove all the adapters from the server.

6. Remove the riser card from the system board, as described in “Riser Card” on page 7-11.

7. Record the slot numbers of the memory modules. Then remove all but one of the memory modules.

8. Disconnect the SCSI cables from the SCSI connectors (J4 and J33) on the system board.

9. Disconnect the diskette drive cable from the diskette drive connector (J16) on the system board.

10. Disconnect the internal serial, tablet, and ethernet port cables (J23, J24, J25 and J50).

11. Turn on the power.

Does the operator panel do one of the following:

 Stop with any code other than E1DC, E1F2, E1F3, E1F7 or E14D?  Alternate between E1FD and any other code?

NO Go to “Step 1540-5” on page 2-21. YES Go to “Step 1540-4” on page 2-20.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-19

Step 1540-4

One of the FRUs remaining in the server is defective.

1. Turn off the power.

2. Exchange one of the FRUs in the following list:  System board (see note 3 on page 2-1).

 Memory module

3. Turn on the power.

Note: You are asked questions regarding the operator panel display. You are

also asked to perform certain actions based on displayed POST indicators. Please be observant of these conditions.

Does the operator panel do one of the following:

 Stop with any code other than E1DC, E1F2, E1F3, E1F7 or E14D?  Alternate between E1FD and any other code?

NO Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for

Multiple Bus Systems.

YES Reinstall the original FRU.

Repeat the FRU replacement steps until the defective FRU is identified or all the FRUs have been exchanged.

If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.

If the symptom has changed, check for loose cards, cables, and obvious problems. If you do not find a problem, return to “Step 1540-1” on page 2-18, and follow the instructions for the new symptom.

2-20 7046 Model B50 Service Guide

Step 1540-5

No failure was detected with this configuration.

1. Turn off the power.

2. Install a memory module.

3. Turn on the power.

Does the operator panel do one of the following:

 Stop with any code other than E1DC, E1F2, E1F3, E1F7 or E14D?  Alternate between E1FD and any other code?

NO Repeat this step until all the memory modules are installed and tested.

After all the memory modules are installed and tested, go to “Step 1540-8” on page 2-22.

YES Go to “Step 1540-6”

Step 1540-6

The failure may be caused by the last memory module installed. To isolate the failing FRU, do the following:

1. Turn off the power.

2. Exchange the last memory module installed.

3. Turn on the power.

Does the operator panel do one of the following:

 Stop with any code other than E1DC, E1F2, E1F3, E1F7 or E14D?  Alternate between E1FD and any other code?

NO Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for

Multiple Bus Systems.

YES Go to “Step 1540-7” on page 2-22.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-21

Step 1540-7

One of the FRUs remaining in the server is defective.

1. Turn off the power.

2. Exchange one of the FRUs in the following list:  System board (see note 3 on page 2-1).

 Power supply.

3. Turn on the power.

Does the operator panel do one of the following:

 Stop with any code other than E1DC, E1F2, E1F3, E1F7 or E14D?  Alternate between E1FD and any other code?

NO Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for

Multiple Bus Systems.

YES Reinstall the original FRU.

Repeat the FRU replacement steps until the defective FRU is identified or all the FRUs have been exchanged.

If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.

Step 1540-8

1. Turn off the power.

2. Install the riser card.

3. Install connector P10 to back of the riser card.

4. Turn on the power.

Does the operator panel do one of the following:

 Stop with any code other than E1DC, E1F2, E1F3, E1F7 or E14D?  Alternate between E1FD and any other code?

NO Go to “Step 1540-9” on page 2-23

2-22 7046 Model B50 Service Guide

YES One of the FRUs remaining in the server is defective.

In the following order, exchange the FRUs that have not been exchanged:

1. Riser card

2. System board (see note 3 on page 2-1).

Repeat this step until the defective FRU is identified or all the FRUs have been exchanged.

If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.

Step 1540-9

1. Turn off the power.

2. Reconnect the system console.

Notes:

a. If an ASCII terminal has been defined as the system console, attach the

ASCII terminal cable to the serial port 1 connector on the rear of the server. Also connect the internal serial (J23 and J24), tablet port (J25), and ethernet (J50) cables to the system board.

b. If a display attached to a display adapter has been defined as the system

console, install the display adapter and connect the display to it. Plug the keyboard into the keyboard connector on the rear of the server.

3. Turn on the power.

4. If the ASCII terminal or graphics display (including display adapter) are connected differently than before, the Console Selection screen will appear and require that a new console be selected.

5. When the keyboard indicator is displayed, press the F1 key on the directly attached keyboard or the number 1 key on an ASCII terminal. This starts the System Management Services (SMS) application.

6. Enter the appropriate password if you are prompted to do so.

7. Wait until the SMS screen is displayed or the system appears to stop.

Is the SMS screen displayed?

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-23

NO One of the FRUs remaining in the server is defective.

In the following order, exchange the FRUs that have not been exchanged:

1. Go to the Problem Determination Procedures (test procedures) for the device attached to the serial port 1 connector or the display attached to the graphics adapter, and test those devices. If a problem is found, follow the procedures for correcting the problem on that device.

2. Graphics adapter (if installed).

3. Cable (async or graphics, including internal async cable).

4. Riser card.

5. System board (see note 3 on page 2-1).

6. Power supply. Repeat this step until the defective FRU is identified or all the FRUs have

been exchanged. If the symptom did not change and all the FRUs have been exchanged,

call your service support person for assistance. If the symptom has changed, check for loose cards, cables, and obvious

problems. If you do not find a problem, return to “Step 1540-1” on page 2-18, and follow the instructions for the new symptom.

YES Go to “Step 1540-10” on page 2-25.

2-24 7046 Model B50 Service Guide

Step 1540-10

1. Make sure the diagnostic CD-ROM is inserted into the CD-ROM drive.

2. Turn off the power.

3. Plug the SCSI cables (J4 and J33) into the SCSI connectors on the system board.

4. Disconnect the signal and power connectors from all the SCSI devices except the CD-ROM drive.

5. Turn on the power.

6. After the keyboard indicator is displayed, press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal keyboard.

7. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO One of the FRUs remaining in the server is defective.

In the following order, exchange the FRUs that have not been exchanged:

1. SCSI cable

2. Last SCSI device connected (CD-ROM drive, tape drive, and so on)

3. Graphics adapter (if the system console is defined as a graphical display)

4. Riser card

5. System board (see note 3 on page 2-1).

6. Power Supply. Repeat this step until the defective FRU is identified or all the FRUs have

been exchanged. If the symptom did not change and all the FRUs have been exchanged,

call your service support person for assistance. If the symptom has changed, check for loose cards, cables, and obvious

problems. If you do not find a problem, return to “Step 1540-1” on page 2-18, and follow the instructions for the new symptom.

YES Repeat this step, adding one SCSI device at a time, until all the SCSI

devices that were attached to the integrated SCSI adapter are connected and tested.

Go to “Step 1540-11” on page 2-26.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-25

Step 1540-11

The server is working correctly with this configuration. The diskette drive may be defective.

1. Make sure the diagnostic CD-ROM disc is inserted into the CD-ROM drive.

2. Turn off the power.

3. Plug the diskette drive cable into the diskette drive connector on the system board.

4. Turn on the power.

5. After the keyboard indicator is displayed, press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal keyboard.

6. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO One of the FRUs remaining in the server is defective.

In the following order, exchange the FRUs that have not been exchanged.

1. Diskette drive

2. Diskette drive cable

3. System board (see note 3 on page 2-1).

4. Power supply Repeat this step until the defective FRU is identified or all the FRUs have

been exchanged. If the symptom did not change and all the FRUs have been exchanged,

call your service support person for assistance. If the symptom has changed, check for loose cards, cables, and obvious

problems. If you do not find a problem, return to “Step 1540-1” on page 2-18, and follow the instructions for the new symptom.

YES Go to “Step 1540-12” on page 2-27.

2-26 7046 Model B50 Service Guide

Step 1540-12

The server is working correctly with this configuration. One of the FRUs (adapters) that you removed is probably defective,

1. Turn off the power.

2. Replace the riser card support bracket, as described in “Riser Card Support Bracket” on page 7-10.

3. Install a FRU (adapter), and connect any internal cables and devices that were attached to it.

4. Turn on the power.

5. Make sure the diagnostic CD-ROM disc is inserted into the CD-ROM drive.

6. If the Console Selection screen is displayed, choose the system console.

7. After the keyboard indicator is displayed, press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal keyboard.

8. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Go to “Step 1540-13” on page 2-28. YES Repeat this step until all of the FRUs (adapters) are installed.

Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for Multiple Bus Systems.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-27

Step 1540-13

1. Make sure the diagnostic CD-ROM disc is inserted into the CD-ROM drive.

2. Turn off the power.

3. Starting with the last-installed adapter, disconnect one attached device and cable.

4. Turn on the power.

5. If the Console Selection screen is displayed, choose the system console.

6. After the keyboard indicator begins blinking, press the F5 key on the directly attached keyboard or the number 5 key on an ASCII terminal keyboard.

7. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Repeat this step until the defective device or cable is identified or all the

devices and cables have been disconnected. If all the devices and cables have been removed, then one of the FRUs

remaining in the server is defective. To test each FRU, exchange the FRUs in the following order:

1. Adapter (last one installed)

2. Riser card

3. System board (see note 3 on page 2-1).

4. Power supply If the symptom did not change and all the FRUs have been exchanged,

call your service support person for assistance. If the symptom has changed, check for loose cards, cables, and obvious

problems. If you do not find a problem, return to “Step 1540-1” on page 2-18, and follow the instructions for the new symptom.

YES The last device or cable that you disconnected is defective.

Exchange the defective device or cable. Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for

Multiple Bus Systems.

2-28 7046 Model B50 Service Guide

Step 1540-14

1. Follow the instructions on the screen to select the system console.

2. When the DIAGNOSTIC OPERATING INSTRUCTIONS screen is displayed, press Enter.

3. If the terminal type has not been defined, you must use the Initial Terminal option on the FUNCTION SELECTION menu to initialize the AIX operating system environment before you can continue with the diagnostics. This is a separate and different operation than selecting the console display.

4. Select Advanced Diagnostics Routines.

5. If the NEW RESOURCE screen displays, select an option from the bottom of the screen.

Note: Adapters or devices that require supplemental media are not shown in

the new resource list. If the server has adapters or devices that require supplemental media, select option 1.

6. When the DIAGNOSTIC MODE SELECTION screen is displayed, press Enter.

7. Select All Resources (if you were sent here from “Step 1540-15” on page 2-30 select the Adapter or Device you loaded from the supplemental media).

Did you get an SRN? NO Choose the one of the following that applies:

 The server has adapters or devices that require supplemental media.

Go to “Step 1540-16” on page 2-30.

 All the adapters or devices that require supplemental supplemental

media have been tested. Go to “Step 1540-18” on page 2-31.

 The server does not have adapters or devices that require

supplemental media. Go to “Step 1540-18” on page 2-31.

YES Go to “Step 1540-15” on page 2-30.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-29

Step 1540-15

Look at the FRU part numbers associated with the SRN in "Diagnostics Numbers and Codes" in Diagnostics Information for Multiple Bus Systems.

Have you exchanged all the FRUs that correspond to the failing function codes?

NO Exchange the next FRU that has not been changed.

Repeat this step until all the FRUs associated with the SRN have been exchanged or diagnostics run with no trouble found. Run diagnostics after each FRU is exchanged.

If a network adapter or system board is replaced, see note 3 on page 2-1. Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for

Multiple Bus Systems.

YES If the symptom did not change and all the FRUs have been exchanged,

call your service support person for assistance.

Step 1540-16

Select Task Selection. Select Process Supplemental Media, and follow the onscreen instructions to process

the media. Supplemental media must be loaded and processed one at a time.

Did the system return to the TASKS SELECTION LIST after the supplemental media was processed?

NO Go to “Step 1540-17” on page 2-31. YES Press F3 to return to the FUNCTION SELECTION screen.

Go to “Step 1540-14” on page 2-29, substep 4.

2-30 7046 Model B50 Service Guide

Step 1540-17

The adapter or device is probably defective. If the supplemental media is for an adapter, replace the FRUs in the following order:

1. Adapter

2. Riser card

3. System board (see note 3 on page 2-1).

If the supplemental media is for a device, replace the FRUs in the following order:

1. Device and any associated cables

2. The adapter the device is attached to.

Repeat this step until the defective FRU is identified or all the FRUs have been exchanged.

If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.

Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for Multiple Bus Systems.

Step 1540-18

Did you disconnect any external devices in Step 1540-2? NO Go to “Step 1540-22” on page 2-34. YES Go to “Step 1540-19” on page 2-32.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-31

Step 1540-19

1. Insert the diagnostic CD-ROM into the CD-ROM drive.

2. Turn off the power.

3. Connect the following external devices that were disconnected in “Step 1540-2” on page 2-18: a. Keyboard b. Mouse c. Tablet d. Ethernet

4. Turn on the power.

6. If the Console Selection screen is displayed, choose the system console.

7. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Either the last external device that you connected or the system board is

probably defective. To test each FRU, exchange the FRUs in the following order:

1. Device (last one connected)

2. System board (see note 3 on page 2-1).

Repeat this step until all the listed devices are connected.

Yes Go to “Step 1540-20” on page 2-33.

2-32 7046 Model B50 Service Guide

Step 1540-20

1. Insert the diagnostic CD-ROM into the CD-ROM drive.

2. Turn off the power.

3. Connect one of the external devices that was disconnected in “Step 1540-2” on page 2-18 in the following order:

Note: If the device has a power switch, ensure that the device is turned on.

a. SCSI devices connected to the external SCSI connector b. Device connected to serial 1 c. Device connected to serial 2 d. Device connected to parallel port

4. Turn on the power.

6. If the Console Selection screen is displayed, choose the system console.

7. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Either the last external device that you connected or the system board is

probably defective. To test each FRU, exchange the FRUs in the following order:

1. If the failure is related to an external device that you are responsible for servicing, follow the service procedures for that device. Otherwise, contact the vendor (or have the customer contact the vendor) to have the device serviced.

2. System board (see note 3 on page 2-1).

Repeat this step until all the listed devices are connected.

YES Repeat this step until all the listed devices are connected.

Go to “Step 1540-21” on page 2-34.

Chapter 2. Maintenance Analysis Procedures (MAPs) 2-33

Step 1540-21

1. Insert the diagnostic CD-ROM into the CD-ROM drive.

2. Turn off the power.

3. Connect one of the external devices that was disconnected from a PCI adapter in “Step 1540-2” on page 2-18.

Note: If the device has a power switch, ensure that the device is turned on.

4. Turn on the power.

6. If the Console Selection screen is displayed, choose the system console.

7. Enter the appropriate password if you are prompted to do so.

Is the "Please define the System Console" screen displayed? NO Either the last external device that you connected, the adapter, or system

board is probably defective. To test each FRU, exchange the FRUs in the following order:

1. If the failure is related to an external device that you are responsible for servicing, then follow the service procedures for that device. Otherwise, contact the vendor (or have the customer contact the vendor) to have the device serviced.

2. System board (see note 3 on page 2-1).

Repeat this step until all the listed devices are connected.

YES Repeat this step until all the listed devices are connected.

Go to “Step 1540-22.”

Step 1540-22

Consult the PCI adapter configuration documentation for your operating system to verify that all installed adapters are configured correctly.

Go to "MAP 0410: Repair Checkout" in the Diagnostics Information for Multiple Bus Systems.

If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.

2-34 7046 Model B50 Service Guide

Chapter 3. Error Code to FRU Index

The Error Code to FRU Index lists error symptoms and possible causes. The most likely cause is listed first. Use this index to help you decide which FRUs to replace when you are servicing the system.

If the codes in the following tables indicate a device which is present more than once in the server, a location code is needed to specify which device generated the error. Go to “Step 1020-3” on page 2-8 to display the System Management Services error log and obtain a location code. Location code descriptions can be found under Chapter 4, “Location Codes” on page 4-1.

Once you have the location code, see Chapter 8, “Parts Information” on page 8-1 for the part number.

Notes:

1. If more than eight digits are displayed in the operator panel, use only the first eight digits to find the error in the tables. The digits that display beyond the first eight digits are location codes that can assist you in diagnosing the problem. See Chapter 4, “Location Codes” on page 4-1.

2. Licensed programs frequently rely on network configuration and system information stored on the VPD on the operator panel. If the MAPs indicate that the operator panel should be replaced, swap the VPD from the old operator panel to the new one. If the old VPD module has to be replaced, call technical support for recovery instructions. If recovery is not possible, notify the system owner that new keys for licensed programs may be required.

If you replace FRUs and the problem is still unresolved, go to “Step 1540-1” on page 2-18, unless otherwise indicated in the tables. If you replace FRUs and the problem has been resolved, go to "MAP 0410: Repair Checkout" in the Diagnostics Information for Multiple Bus Systems, unless otherwise indicated in the tables.

Error Code Function

/Description

20A80xxx Remote Initial

program load (RIPL) errors

20A80000 Insufficient

information to boot.

20A80001 Client IP address is

already in use by another network device.

Chapter 3. Error Code to FRU Index 3-1

Repair Action/Possible Failing FRU

Verify the IP address.

Change IP address.

Error Code Function

/Description

20A80002 Cannot get gateway

IP address.

20A80003 Cannot get server

hardware address

20A80004 Bootp failed Refer to “Firmware Checkpoints” on page 3-14, using

20A80005 File transmission

(TFTP) failed

20A80006 Boot image too

large. Ran out of available firmware memory resources loading boot image.

20D00xxx Unknown or

Unrecognized device

20D0000F Self-test failed on

device, no error/location code information available.

20D00010 Self-test failed on

device, cannot locate package

20D00011 Cannot determine

Machine Model.

20E00xxx Security 20E00000 Power-on password

entry error.

20E00001 Privileged-access

password entry error.

20E00002 Privileged-access

password jumper not enabled.

20E00003 Power-on password

must be set for Unattended mode.

20E00004 Battery drained or

needs replacement.

Repair Action/Possible Failing FRU

Refer to “Firmware Checkpoints” on page 3-14, using code E174.

code E174. Check network connection and try again.

Verify boot server configuration.

Check the SMS error log entry for this error code. The location code (if present) in the error log entry should identify the location of the failing device.

Software Error (Contact your service representative for assistance.)

The Machine Model is part of the System Vital Product Data. Perform corrective actions listed for errors 2BA00050, 2BA00051.

The password has been entered incorrectly. Retry installing the password. The password has been entered incorrectly. Retry installing the password.

The privileged-access password jumper is not in the correct position for password initial entry.

Consult the server User's Guide for pin location and jumper position.

Unattended mode requires setting the Power-on password before it is enabled.

1. Replace battery

2. Replace system board (see note 3 on page 2-1).

3-2 7046 Model B50 Service Guide

Error Code Function

/Description

20E00005 EEPROM locked. 1. Turn off, then turn on the server.

20E00008 CMOS corrupted or

tampering evident, CMOS initialized.

20E00009 Invalid password

entered - system locked.

20E0000A EEPROM lock

problem.

20E0000B EEPROM write

problem.

20E0000C EEPROM read

problem.

20E00017 Cold boot needed

for password entry. 20EE0xxx Informational 20EE0003 IP parameter

requires 3 dots "." 20EE0004 Invalid IP parameter. Enter valid (numeric) IP parameter

20EE0005 Invalid IP parameter

(>255).

20EE0006 No SCSI controllers

present.

20EE0007 Keyboard not found. 1. Plug in keyboard

20EE0008 No configurable

adapters found in

the system.

Repair Action/Possible Failing FRU

2. Replace system board (see note 3 on page 2-1). Check your machine for evidence of tampering. If NO tampering:

1. Replace battery, restore NVRAM data (passwords,

startup data).

2. Replace system board (see note 3 on page 2-1). The password has been entered incorrectly 3 times. Turn off, then turn on the server, then enter the

password correctly. If for privileged-access password install, is jumper in

correct position? Consult the server User's Guide for pin location and

jumper position.

1. Turn off, then turn on the server.

2. Replace system board (see note 3 on page 2-1).

1. Turn off, then turn on the server.

2. Replace system board (see note 3 on page 2-1).

1. Turn off, then turn on the server.

2. Replace system board (see note 3 on page 2-1). Turn off, then turn on the server.

Enter valid IP parameter Example: 000.000.000.000

Example: 000.000.000.000 Enter valid (numeric) IP parameter in the range of 0 to

255 Example: 255.199.002.000 The system board should always have at least 2

integrated PCI SCSI controllers. Replace the system board (see note 3 on page 2-1).

2. Replace system board (see note 3 on page 2-1). This warning occurs when the selected SMS function

cannot locate any devices/adapters supported by the function. If a supported device is installed:

1. Replace the device or adapter.

2. Replace system board (see note 3 on page 2-1).

Chapter 3. Error Code to FRU Index 3-3

Error Code Function

/Description

20EE000A Pointer to the

operating system not found in non volatile storage.

20EE000B The system was not

able to find an Operating System on the boot list that was attempted.

21A00xxx SCSI Device Errors SCSI device error notes:

Repair Action/Possible Failing FRU

Values normally found in nonvolatile storage that point to the location of an Operating System were not found. This can happen for either of two reasons:

 Your installed Operating System does not support

storing the values.

 Some event occurred that caused the system to

lose nonvolatile storage information (drainage or replacement of the battery).

If you are running AIX, this information can be reconstructed by running the bootlist command specifying the device that the Operating System is installed on. Please refer to your AIX documentation for the exact syntax and usage of the bootlist command.

To boot the Operating System so that these values can be reconstructed, power down the system and power it back up again. This should cause the system to look for the Operating System in the devices contained in the custom boot list or in the default boot list, depending on the condition of the system. If this is not successful, use the System Management Services Menus to modify the Boot Sequence (also known as boot list) to include devices that are known to contain a copy of the Operating System. For example, select a hard disk known to have a copy of the Operating System as the first and only device in the boot sequence (boot list) and attempt to boot again.

Modify the Boot Sequence (also known as boot list) to include devices that are known to contain a copy of the Operating System. This can be accomplished by powering down the system, powering it back up again, and using the System Management Services Menus. For example, select a hard disk known to have a copy of the Operating System as the first and only device in the boot sequence (boot list) and attempt to boot again.

1. Before replacing any system components: a. Ensure that the controller and each device on

the SCSI bus is assigned a unique SCSI ID. b. Ensure SCSI bus is properly terminated. c. Ensure SCSI signal and power cables are

securely connected and not damaged.

2. The location code information is required to identify the ID of SCSI device failures, as well as to indicate the location of the controller to which the device is attached.

3-4 7046 Model B50 Service Guide

Error Code Function

/Description

21A00001 Test Unit Ready

Failed - hardware error

Repair Action/Possible Failing FRU

Refer to 21A00xxx through 21A0004.

1. Replace the SCSI device.

2. Replace the SCSI cable.

3. Replace the SCSI controller.

| 4. Replace the power supply.

21A00002 Test Unit Ready

Failed - sense data available.

21A00003 Send Diagnostic

Failed

21A00004 Send Diagnostic

Failed - DevOfl cmd

21E00xxx SCSI Tape Refer to error codes 21A00xxx through 21A0004 for a

21ED0xxx SCSI Changer Refer to error codes 21A00xxx through 21A0004 for a

21EE0xxx Other SCSI device

type

21F00xxx SCSI CD-ROM Refer to error codes 21A00xxx through 21A0004 for a

21F20xxx SCSI Read/Write

Optical

2200xxxx Network Controller

problem

22000001 Internal wrap test

failed.

22001001 Internal wrap test

failed.

22002001 Adapter failed to

complete hardware initialization.

22010001 Adapter failed to

complete hardware initilization.

22011001 Adapter failed to

complete hardware initilization.

Refer to 21A00xxx through 21A0004.

1. Replace the media (Removable media devices).

2. Replace the SCSI device.

Refer to 21A00xxx through 21A0004. Replace the SCSI device.

description and repair action for the specific “xxx” value.

Refer to error codes 21A00xxx through 21A0004 for a description and repair action for the specific “xxx” value.

description and repair action for the specific “xxx” value.

Refer to error codes 21A00xxx through 21A0004 for a description and repair action for the specific “xxx” value.

Replace the adapter.

Chapter 3. Error Code to FRU Index 3-5

Error Code Function

/Description

25000xxx Memory Controller

problem

25000000 Memory controller

failed

25010xxx Flash Update

problem

25010000 No diskette in drive. Insert diskette containing firmware update file. 25010001 Diskette seek error. 1. Retry function.

25010002 Diskette in drive

does not contain an *.IMG file.

25010003 Cannot open

OPENPROM package.

25010004 Cannot find

OPENPROM node.

25010006 System ID does not

match image system ID.

25010007 Image has bad

CRC.

25010008 Flash is write

protected, update cancelled.

25010009 Flash module is

unsupported or not recognized.

2501000A Flash write

protected.

Repair Action/Possible Failing FRU

Replace system board (see note 3 on page 2-1).

2. Replace diskette drive.

3. Replace diskette cable.

4. Replace system board (see note 3 on page 2-1).

Insert diskette with firmware update file

Replace system board (see note 3 on page 2-1).

Make sure correct firmware update diskette is being used with this system.

Replace firmware update diskette.

1. Turn off, then turn on the server and retry.

2. Replace system board (see note 3 on page 2-1).

Make sure correct firmware update diskette is being used with this system.

1. Turn off, then turn on the server and retry.

2. Replace system board (see note 3 on page 2-1).

3-6 7046 Model B50 Service Guide

Error Code Function

/Description

25A80xxx NVRAM problem Notes:

25A80000 Initialization failed,

device test failed.

25A80001 init-nvram invoked,

ALL of NVRAM initialized.

25A80002 init-nvram invoked,

some data partitions may have been preserved.

25A80011 Data corruption

detected, ALL of NVRAM initialized.

25A80012 Data corruption

detected, some data partitions may have been preserved.

25A80100 NVRAM data

validation check failed.

25A80201 Unable to expand

target partition while saving configuration variable.

25A80202 Unable to expand

target partition while writing error log entry.

Repair Action/Possible Failing FRU

1. Errors reported against NVRAM can be caused by low battery voltage and (more rarely) power outages that occur during normal system usage. With the exception of the 25A80000 error, these errors are really just warnings that the NVRAM data content had to be re-established and do not require any FRU replacement unless the error is persistent. When one of these errors occurs, any system customization (for example boot device list) information has been lost. The system may need to be reconfigured.

2. If the error is persistent, replace the battery.

3. If the error is persistent after battery replacement, or the error code is 25A80000, replace the system board (see note 3 on page 2-1).

Refer to 25A80xxx.

Turn off, then turn on the server and retry the operation before replacing any system components.

Refer to 25A80xxx. Refer to 25A80xxx.

Refer to 25A80xxx.

Chapter 3. Error Code to FRU Index 3-7

Error Code Function

/Description

25A80203 Unable to expand

target partition while writing VPD data.

25A80210 Setenv/$Setenv

parameter error name contains a null character.

25A80211 Setenv/$Setenv

parameter error value contains a null character.

25A80998 NVRAMRC script

evaluation error command line execution error

25A80999 NVRAMRC script

evaluation error stack unbalanced on completion.

Repair Action/Possible Failing FRU

Refer to 25A80xxx.

Execution of a command line within the nvram configuration variable “nvramrc” (script) resulted in a “throw” being executed. This script can be modified by the system firmware SMS utilities, the operating system, PCI adapter rom code or utility, or an operator (via the open firmware script editing command nvedit). It may not be possible to resolve the problem without a detailed analysis of the nvram script, the current system configuration, and device tree contents.

1. The problem can be caused by a SCSI adapter,whose SCSI bus ID has been changed from the default setting, no longer appearing in the system. This can be caused either by removing a SCSI adapter, or a problem with a SCSI adapter.

a. Select the SCSI ID utility from the SMS

menu(s).

1) Verify the list of SCSI controllers/adapters. If the list is not correct, suspect a problem with the adapter(s) installed but not listed.

2) Select the option to save the configuration information.

3) Restart the system.

b. If the problem persists, boot the operating

system and verify the SCSI bus IDs of any installed/available SCSI controllers (change as necessary), and restart the system.

2. Contact your service support representative for further assistance.

This is a firmware debug environment error. There is no user action or FRU replacement for this error.

3-8 7046 Model B50 Service Guide

Error Code Function

/Description

25AA0xxx EEPROM problem Notes:

25AA0000 Unable to unlock

EEPROM 25AA0001 Read-Recv error Refer to 25AA0xxx. 25AA0002 Read-Trans error Refer to 25AA0xxx. 25AA0003 Write-enable error Refer to 25AA0xxx. 25AA0004 Write-recv error Refer to 25AA0xxx. 25AA0005 Write-disable error Refer to 25AA0xxx. 25AA0006 Write-Trans error Refer to 25AA0xxx. 25AA0007 Unable to lock

EEPROM 25Cyyxxx Memory errors Use the location code obtained from the SMS Error

25Cyy002 Memory dimm failed

memory test

Repair Action/Possible Failing FRU

1. Ensure that the EEPROM Security jumper is in the correct position if doing a privileged-access password installation.

2. Retry the operation.

3. If retries do not solve the problem, replace the system board (see note 3 on page 2-1).

Refer to 25AA0xxx.

Log utility (described in “Step 1020-3” on page 2-8) to identify which memory dimm the error is reported against.

Memory error codes are in the form 25Cyyxxx where yy indicates memory dimm PD-bits and xxx indicates the last three digits of the error code.

See “Memory PD Bits” on page 3-13 for information on how to interpret PD bits.

1. Replace memory dimm

2. Replace system board (see note 3 on page 2-1). See “Memory PD Bits” on page 3-13 for

information on how to interpret PD bits.

Chapter 3. Error Code to FRU Index 3-9

Error Code Function

/Description

2602000x PCI Adapter

Problem

26020001 Invalid PCI adapter

Vendor ID

26020002 Invalid PCI adapter

Device ID.

26020003 Invalid PCI adapter

Class Code

26020007 Unable to allocate

Bus resources to PCI adapter (partial allocation may have succeeded)

28030xxx RTC Errors Notes:

Repair Action/Possible Failing FRU

Notes:

1. Move card to another slot (behind a different PCI bridge).

2. Check for available firmware updates for adapter. Apply update if available.

3. Run AIX diagnostics on the adapter. Replace if indicated.

4. Replace the adapter.

5. Check for system firmware updates. Apply if update is available.

6. Replace power supply

7. Replace system board (see note 3 on page 2-1).

Refer to 2602000x.

1. Errors reported against the Real Time Clock (RTC) can be caused by low battery voltage and (more rarely) power outages that occur during normal system usage. Most of these errors are only warnings that the RTC data content needs to be re-established and do not require any FRU replacement unless the error is persistent. When one of these errors occurs, the Power-On Password and Time and Date information has probably been lost.

2. If the error is persistent, replace the battery.

3. If the error is persistent after battery replacement, replace the system board (see note 3 on page 2-1).

 To set or restore a Power-on password, use

the SMS utility.

 To set or restore the Time and Date, use the

Operating System facility.

3-10 7046 Model B50 Service Guide

Error Code Function

/Description

28030001 RTC initialization

required - RTC not updating, corrected.

28030002 Bad time/date

values

28030003 RTC initialization

required - RTC not updating, not corrected

28030004 RTC operating

mode parameters changed (ie. data format)

28030005 RTC Battery error 1. Replace the battery.

28A00040 Fan failure Check on the following:

28A00050 Power Supply

Failure

29xxxxxx Keyboard/Mouse

problems

29000002 Keyboard/Mouse

controller failed self-test.

29A00003 Keyboard not

present/detected.

29A00004 Keyboard stuck key

detected.

29B00004 Mouse not

present/detected

Repair Action/Possible Failing FRU

Refer to action for 28030xxx.

1. Set the Time and Date

2. Refer to action for 28030xxx if problem persists.

Replace the system board (see note 3 on page 2-1).

1. Set or Restore the Time and Date

2. Refer to action for 28030xxx if problem persists.

Note: Password, Time, and Date needs to be set .

2. Refer to action for 28030xxx if problem persists.

 Ensure fans (CPU fansink connector J26 and

System fan connector J27) are properly connected to the I/O planar.

 Reseat all suspected fan(s) connectors.  Look for obstructions that may prevent the fans

from normal operations. (For example, a cable caught in the fan preventing it from spinning.)

 Replace any suspected fan(s) that may cause this

error.

 If after replacing the suspected fan(s) and the

problem still exists, then replace the system board (see note 3 on page 2-1).

Replace the power suppply

Replace system board (see note 3 on page 2-1).

1. Keyboard

2. Replace system board (see note 3 on page 2-1).

1. Keyboard

2. Replace system board (see note 3 on page 2-1).

1. Mouse

2. Replace system board (see note 3 on page 2-1).

Chapter 3. Error Code to FRU Index 3-11

Bus SRN to FRU Reference Table

This table is used to locate defective FRUs within the system board PCI and ISA buses, and indicates which devices should be tested for each SRN. For this procedure, if possible, diagnostics are run on the riser card bus devices with all adapters removed from the failing bus. If a failure is detected on this system with all adapters removed from the failing bus, the riser card is the isolated FRU. If a failure is not detected, the adapters are added back one at a time, to their original slot location, and the configuration is tested until a failure is detected. The failure is then isolated to the failing FRU.

If a failure has not been detected and all the FRUs have been tested, call your technical service support person for assistance.

SRN Bus ID Possible Failing Device and

AIX Location Code

9CC-100 PCI Bus 00 Internal SCSI port 1 (10-80) system board (see note 3 on

Internal/External SCSI port 2 (30-58)

Internal Ethernet port (10-60) system board (see note 3 on

Device installed in I/O Slot 2 (10-90 to 10-97). Device installed in I/O Slot 1 (10-b0 to 10-b7).

651-730 ISA Bus Diskette Drive port/device

(01-D1-00-00)

Parallel port/device (01-R1) system board (see note 3 on

Serial ports (1-2)/device (01-S1 to 01-S2).

Mouse port/device (01-K1-01-00).

Keyboard port/device (01-K1-00-00).

Audio port/device (01-Q2). system board (see note 3 on

Associated FRU

page 2-1, and at the end of this table). system board (see note 3 on page 2-1, and at the end of this table).

page 2-1, and at the end of this table).

Adapter

system board (see note 3 on page 2-1, and at the end of this table).

page 2-1, and at the end of this table). system board (see note 3 on page 2-1, and at the end of this table). system board (see note 3 on page 2-1, and at the end of this table). system board (see note 3 on page 2-1, and at the end of this table).

page 2-1, and at the end of this table).

3-12 7046 Model B50 Service Guide

SRN Bus ID Possible Failing Device and

AIX Location Code

Tablet port/device (01-Q1). system board (see note 3 on

Note: If a network adapter or the system board is replaced, the network administrator must be notified so that the client IP addresses used by the server can be changed. In addition, the operating system configuration of the network controller may need to be changed in order to enable system startup. Also check to ensure that any client or server that addresses this system is updated.

Associated FRU

page 2-1, and at the end of this table).

Memory PD Bits

The following table expands the firmware error code 25Cyyrrr on page 3-9, where yy is the PD value listed in the following table. Use these values to identify the type

of memory that generated the error. If you replace FRUs and the problem is still not corrected, go to MAP 0030 in the

Diagnostics Information for Multiple Bus Systems unless otherwise indicated in the tables.

PD Value Size Speed (nsecs) Parity/ECC

58 34MB 10 ECC 38 128MB 10 ECC

Chapter 3. Error Code to FRU Index 3-13

Firmware Checkpoints

The following table contains a list of checkpoints issued by the firmware during initialization.

Checkpoint (hex)

E100 Reserved/Unused See “Unresolved problems” on page 3-26

E101 Video-enabled,

E102 Firmware restart

E103 Set memory refresh

E104 Set memory refresh

E105 Transfer control to

E108 Run recovery block

E109 Copy CRC

E10A Turn on cache See “Unresolved problems” on page 3-26

Description Repair Action

See “Unresolved problems” on page 3-26 extended memory test (Quick restart path)

See “Unresolved problems” on page 3-26 with cfg'd parms (Quick restart path)

See “Unresolved problems” on page 3-26 (composite img)

See “Unresolved problems” on page 3-26 (recovery block)

See “Boot Problems or Concerns” on page 3-27 O.S. (normal boot)

See “Unresolved problems” on page 3-26 base memory (test 2k), set stack

See “Unresolved problems” on page 3-26 verification code to RAM

E10B Flush cache See “Unresolved problems” on page 3-26

E10C Jump to CRC

verification code in RAM

E10D Compute composite

image CRC

E10E Jump back to ROM See “Unresolved problems” on page 3-26

E10F Transfer control to

Open Firmware

E110 Turn off cache,

Check if composite image CRC is valid

See “Unresolved problems” on page 3-26

3-14 7046 Model B50 Service Guide

Checkpoint (hex)

E111 GOOD CRC - jump

E112 BAD CRC - initialize

E113 BAD CRC - copy

E114 BAD CRC - jump to

E115 BAD CRC - turn on

E116 BAD CRC - copy

E117 BAD CRC -

E118 BAD CRC - branch

E119 Initialize base

E11A Copy uncompressed

E11B Jump to code in

E11C Turn on cache See “Unresolved problems” on page 3-26

Description Repair Action

See “Unresolved problems” on page 3-26

to composite image

See “Unresolved problems” on page 3-26

base memory, stack

See “Unresolved problems” on page 3-26 uncompressed recovery block code to RAM

See “Unresolved problems” on page 3-26 code in RAM

See “Unresolved problems” on page 3-26 cache

See “Unresolved problems” on page 3-26 recovery block data section to RAM

See “Unresolved problems” on page 3-26 Invalidate and flush cache, set TOC

See “Unresolved problems” on page 3-26 to high-level recovery control routine

See “Unresolved problems” on page 3-26 memory, stack

See “Unresolved problems” on page 3-26 recovery block code to RAM

See “Unresolved problems” on page 3-26 RAM

E11D Copy recovery block

data section to RAM

E11E Invalidate and flush

cache, set TOC

E11F Branch to high-level

control routine

E120 Initialize I/O and

early memory block

Chapter 3. Error Code to FRU Index 3-15

See “Unresolved problems” on page 3-26

Checkpoint (hex)

E122 No memory

E123 No SIMM found in

E124 Disable defective

E125 Clear PCI devices

E126 Check valid image -

E127 Check valid image -

E128 Disable interrupts,

E129 Validate target RAM

E12A Copy ROM to RAM,

E12B Set MP operational

E12C Set MP CPU node

E12D Park secondary

E12E Primary processor

E12F Unexpected return

E130 Build device tree See “Unresolved problems” on page 3-26

Description Repair Action

1. Replace memory dimm(s) detected (system lockup) Note: Harddisk light is on continuously

the socket

memory bank

command reg, go forth

start

successful

set int vectors for O.F.

address

flush cache

parameters (eg. L.E.?, Real?)

characteristics

processors in parking lot

sync

from Open Firmware (system lockup)

2. Replace System Planar

3. Replace System Planar

See “Unresolved problems” on page 3-26

E131 Create ROOT node See “Unresolved problems” on page 3-26

E132 Create CPUs node See “Unresolved problems” on page 3-26

3-16 7046 Model B50 Service Guide

Checkpoint (hex)

E133 Create L2 Cache

E134 Create memory

E135 Create memory

E136 Test memory See “Unresolved problems” on page 3-26

Description Repair Action

See “Unresolved problems” on page 3-26

node

See “Unresolved problems” on page 3-26

node

See “Unresolved problems” on page 3-26

SIMM/DIMM node

E137 Create openprom

node

E138 Create options node See “Unresolved problems” on page 3-26

E139 Create aliases node

and system aliases

E13A Create packages

node

E140 PReP style load See “Unresolved problems” on page 3-26

E149 Create boot mgr

node

E14C Create

terminal-emulator node

E14D Load boot image See “Boot Problems or Concerns” on page 3-27

E14E Create Client

Interface node/dictionary

E14F NVRAM validation,

config variable token generation

E150 Create host

(primary) PCI controller node

E151 Probe primary PCI

bus

E152 Probe for adapter

FCODE, evaluate if present

E153 End adapter FCODE

probe/evaluation

See “Unresolved problems” on page 3-26

1. Replace PCI Adapter(s)

2. Replace system board (see note 3 on page 2-1).

See “Unresolved problems” on page 3-26

1. Replace PCI Adapter(s)

2. Replace system board (see note 3 on page 2-1). See “Unresolved problems” on page 3-26 See “Unresolved problems” on page 3-26

Chapter 3. Error Code to FRU Index 3-17

Checkpoint (hex)

E154 Create PCI bridge

E155 Probe PCI bridge

E156 Create PCI ethernet

E15A Create 64 bit host

E15B Transfer control to

E15C Probe primary 64 bit

E15D Create host PCI

E15E Create MPIC node See “Unresolved problems” on page 3-26

E15F Adapter VPD probe See “Unresolved problems” on page 3-26

Description Repair Action

See “Unresolved problems” on page 3-26

node

1. Replace PCI Adapter(s)

secondary bus

node

(primary) PCI controller node

O.S. (Service mode boot)

PCI bus

controller node

2. Replace system board (see note 3 on page 2-1). See “Unresolved problems” on page 3-26 See “Unresolved problems” on page 3-26

See “Unresolved problems” on page 3-26

See “Boot Problems or Concerns” on page 3-27

See “Unresolved problems” on page 3-26

E160 CPU Node VPD

Creation

E161 ROOT Node VPD

Creation

E162 SP Node VPD

Creation

E164 Create PCI graphics

node (P9)

E168 Create PCI graphics

node (S3)

E16C GXT1000P

Subsystem Open request

E16D GXT1000P Planar

not detected/failed diagnostics

E16E GXT1000P

Subsystem Open successful

E16F GXT1000P Close

Subsystem

See “Unresolved problems” on page 3-26

3-18 7046 Model B50 Service Guide

Checkpoint (hex)

E170 Start of PCI Bus

E171 Executing PCI-Delay

E172 First pass PCI

E174 Establish host

E175 BootP request Refer to “Boot Problems or Concerns” on page 3-27

E176 TFTP file transfer See “Unresolved problems” on page 3-26

Description Repair Action

See “Unresolved problems” on page 3-26

Probe

See “Unresolved problems” on page 3-26

function

See “Unresolved problems” on page 3-26

device probe

Refer to “Boot Problems or Concerns” on page 3-27

connection

for some general information concerning network booting.

1. Power Off, then Power On and retry the boot operation.

2. Verify the network connection

3. Have network administrator verify the server configuration for this client.

E177 Transfer failure due

to TFTP error condition

E178 Create PCI token

ring node

E17B Processor frequency

measurement

E180 SP Command setup See “Unresolved problems” on page 3-26

E183 SP Post See “Unresolved problems” on page 3-26

E190 Create ISA node See “Unresolved problems” on page 3-26

E193 Initialize Super I/O See “Unresolved problems” on page 3-26

E196 Probe ISA bus See “Unresolved problems” on page 3-26

E19C Create tablet node See “Unresolved problems” on page 3-26

E19D Create nvram node See “Unresolved problems” on page 3-26

E19E RTC node creation

and initialization

See “Unresolved problems” on page 3-26

1. Replace battery, restore NVRAM data(passwords, startup data)

2. Replace I/O Planar.

Refer to Error Code 28030xxx

Chapter 3. Error Code to FRU Index 3-19

Checkpoint (hex)

E19F Create eeprom node See “Unresolved problems” on page 3-26

Description Repair Action

E1AD See description of

checkpoint E1DE.

E1B0 Create lpt node See “Unresolved problems” on page 3-26

E1B1 Create serial node See “Unresolved problems” on page 3-26

E1B2 Create audio node See “Unresolved problems” on page 3-26

E1B3 Create 8042 node See “Unresolved problems” on page 3-26

E1B6 Probe for (ISA)

keyboard

E1BA Enable L2 cache See “Unresolved problems” on page 3-26

E1BB Set cache parms for

burst

E1BC Set cache parms for

512KB

E1BD Probe for (ISA)

mouse

E1BE Create op-panel

node

E1BF Create pwr-mgmt

node

E1C0 Create ISA ethernet

node

E1C5 Create ISA interrupt

controller (pic) node

E1C6 Create dma node See “Unresolved problems” on page 3-26

See “Unresolved problems” on page 3-26

E1D0 Create PCI scsi

node

E1D3 Create (* wildcard *)

SCSI block device node (SD)

E1D4 Create (* wildcard *)

SCSI byte device node (ST)

E1DB Create floppy

controller (fdc) node

See “Unresolved problems” on page 3-26

3-20 7046 Model B50 Service Guide

Checkpoint (hex)

E1DC Dynamic console

E1DD Early processor

E1DE Alternating pattern

E1DF Create diskette drive

E1E0 Program flash See “Unresolved problems” on page 3-26

Description Repair Action

If a console is attached but nothing is displayed on it,

selection

exception

of E1DE and E1AD is used to indicate a "Default Catch" condition before the Open Firmware "checkpoint" word (function) is available.

(disk) node

follow the steps associated with “All display problems” in the Entry MAP tables.

If selection screen(s) can be seen on the terminals and the appropriate key on the input device associated with the desired display or terminal is pressed, within approximately 60 seconds, but there is no response to the keystrokes:

1. If selecting the console with a keyboard attached to the system, replace the keyboard. If replacing the keyboard does not fix the problem, replace system board (see note 3 on page 2-1).

2. If selecting the console with an ASCII terminal, suspect the ASCII terminal. Use the Problem Determination Procedures for the terminal. Replace system board (see note 3 on page 2-1). if these procedures do not reveal a problem.

Note: Terminal settings should be set to :  9600 Baud  No Parity

 8 Data bits  1 Stop bit

Replace system board (see note 3 on page 2-1). See “Unresolved problems” on page 3-26 Replace system board (see note 3 on page 2-1). See “Unresolved problems” on page 3-26

See “Unresolved problems” on page 3-26

E1E1 Flash update

complete

E1E2 Initialize System I/O See “Unresolved problems” on page 3-26

E1E3 PReP boot image

initialization

E1E4 Initialize Super I/O

with default values

Chapter 3. Error Code to FRU Index 3-21

See “Unresolved problems” on page 3-26

Checkpoint (hex)

E1E5 XCOFF boot image

E1E6 Set up early

E1E7 PE boot image

E1E8 Initialize primary

E1E9 ELF boot image

E1EA Load flash EPROM

E1EB Verify flash EPROM

E1EC Get recovery image

E1ED Invalidate instruction

E1EE Jump to composite

Description Repair Action

initialization

memory allocation heap

initialization

diskette drive (polled mode)

initialization

recovery image from diskette

recovery image

entry point

cache


See “Unresolved problems” on page 3-26

1. Firmware flash image corrupted, load recovery image from diskette.

2. Ensure diskette installed contains a recovery image appropriate for this machine.

3. The recovery procedure for the flash EEPROM should be executed. See “Firmware Recovery” on page 6-22.

4. If diskette installed with correct recovery image

a. Try another diskette b. Replace diskette drive c. Replace diskette cable d. Replace system board (see note 3 on page

2-1).

See “Unresolved problems” on page 3-26

1. Firmware flash recovery image on disktte corrupted or invalid for this system.

2. Ensure diskette installed contains a recovery image appropriate for this machine.

3. The recovery procedure for the flash EEPROM should be executed. See “Firmware Recovery” on page 6-22.

4. If diskette installed with correct recovery image

a. Try another diskette b. Replace diskette drive c. Replace diskette cable d. Replace system board (see note 3 on page

2-1). See “Unresolved problems” on page 3-26 See “Unresolved problems” on page 3-26

See “Unresolved problems” on page 3-26

3-22 7046 Model B50 Service Guide

Checkpoint (hex)

E1EF Erase flash See “Unresolved problems” on page 3-26

E1F0 Start O.B.E. See “Unresolved problems” on page 3-26

Description Repair Action

E1F1 Begin self-test

sequence on boot device(s)

E1F2 Power-On Password

prompt

E1F3 Privileged Access

Password prompt

E1F5 Build boot device list See “Unresolved problems” on page 3-26

E1F6 Determine boot

device sequence

E1F7 No boot image

located

E1FB Scan SCSI bus for

attached devices

E1FD Default Catch The operator panel will alternate between the code

E201 Setup PHB BARC

addresses

E202 Initialize PHB

registers and PHB's PCI configuration registers

E203 Look for PCI to ISA

bridge

E204 Setup ISA bridge

PCI config. registers and initialize

E206 Look for PRISM on

PCG and switch to 50MHz

 If the power light is flashing, see Firmware error

code "28A00040" repair action.

 If the power light is on solid, see “Unresolved

problems” on page 3-26. Prompt should be visible on the system console. If a console is attached but nothing is displayed on it,

follow the steps associated with “All display problems” in the Entry MAP tables.

Prompt should be visible on the system console. If a console is attached but nothing is displayed on it,

follow the steps associated with “All display problems” in the Entry MAP tables.

See “Unresolved problems” on page 3-26

“E1FD” and another “Exxx” code where “Exxx” is the initialization point at which the error occurred. If the “Exxx” code is not listed in this table, go to “MAP 1540: Minimum Configuration” on page 2-17.

Replace system board (see note 3 on page 2-1).

Chapter 3. Error Code to FRU Index 3-23

Checkpoint (hex)

E207 Setup Data gather

E208 Assign bus number

E209 Assign PCI I/O

E20A Assign PCI I/O

E20B Check MCERs stuck

E20C Testing L2 cache Replace system board (see note 3 on page 2-1).

Description Repair Action

Replace system board (see note 3 on page 2-1). mode and 64/32-bit mode on PCG

Replace system board (see note 3 on page 2-1). on PCG

Replace system board (see note 3 on page 2-1). addresses on PCI

Replace system board (see note 3 on page 2-1). addresses on PCG

Replace system board (see note 3 on page 2-1). at fault

E210 Processors L1 data

cache array test fails. System Hangs.

E211 IPL ROS CRC

checking

E212 Processor POST Replace system board (see note 3 on page 2-1).

E213 Initial memory

configuration

E214 Memory test See “MAP 1240: Memory Problem Resolution” on

E216 Copy ROS into

RAM. Set up Translation and C environment

E21A System has some

good memory

E220 Final memory

configuration

E240 Set up Winbond ISA

bridge

E241 Reset PCI Bus Replace system board (see note 3 on page 2-1).

Replace system board (see note 3 on page 2-1).

See “MAP 1240: Memory Problem Resolution” on

page 2-9

See “MAP 1240: Memory Problem Resolution” on

page 2-9

See “Unresolved problems” on page 3-26

Replace system board (see note 3 on page 2-1).

See “MAP 1240: Memory Problem Resolution” on

page 2-9

Replace system board (see note 3 on page 2-1).

E242 Initialize ISA DMA

channel

E243 Set up Grackle

configuration registers

Replace system board (see note 3 on page 2-1).

3-24 7046 Model B50 Service Guide

Checkpoint (hex)

E244 Enable system

E246 System firmware

E247 Capture DIMM

E249 Enter recover path's

E24C L2 cache array test

E24D L2 cache array test

E298 Take firmware

E299 Start C code

E3xx Memory test See “MAP 1240: Memory Problem Resolution” on

E440 Validate nvram,

E441 Generate /options

E442 Validate nvram

E443 Generate nvram

E600 SSA PCI adapter

E601 SSA PCI adapter

Description Repair Action

Replace system board (see note 3 on page 2-1). speaker and send a beep

Replace system board (see note 3 on page 2-1). corrupted, take recover path

Replace system board (see note 3 on page 2-1). SPDs into NVRAM

Replace system board (see note 3 on page 2-1). main code

Replace system board (see note 3 on page 2-1). fails. System hangs.

Replace Softload Image soft-load path

See “Unresolved problems” on page 3-26 execution.

page 2-9

1. Verify that the system firmware is at the current initialize partitions as needed

node nvram configuration variable properties

partitions

configuration variable dictionary words

open firmware has run successfully.

BIST has been started but failed to complete after 4 seconds.

release level. Update as necessary.

2. See “Unresolved problems” on page 3-26

1. Verify that the system firmware is at the current

release level. Update as necessary.

2. See “Unresolved problems” on page 3-26

1. Verify that the system firmware is at the current

release level. Update as necessary.

2. See “Unresolved problems” on page 3-26

1. Suspect a system firmware problem. If problem

persists, verify that the system firmware is at current release level. Update downlevel system firmware.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

Chapter 3. Error Code to FRU Index 3-25

Checkpoint (hex)

E602 SSA PCI adapter

E603 SSA PCI adapter

E604 SSA PCI adapter

E605 SSA PCI adapter

E60E SSA PCI adapter

E60F SSA PCI adapter

E6FF SSA PCI adapter

Description Repair Action

open firmware has started.

BIST has completed with an error.

BIST and subsequent POSTs have completed successfully.

BIST has completed successfully but the subsequent POSTs have failed.

open firmware about to exit (no stack corruption)

open firmware has run unsuccessfully.

open firmware about to exit ( with stack corruption ).

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

1. Replace the adapter.

2. See “Unresolved problems” on page 3-26

Unresolved problems: Go to “MAP 1540: Minimum Configuration” on page

2-17 for any of the following conditions:

 A 4-digit code in the range of “E100” through “EFFF” is displayed on the operator

panel display but is not listed in the table that lists firmware checkpoints on page 3-14.

 A 4-digit code is displayed and is listed in the table that lists firmware

checkpoints on page 3-14, but there are no repair actions or FRUs listed for the code.

 All of the FRUs listed in repair actions have been replaced, and the problem has

not been corrected.

3-26 7046 Model B50 Service Guide

Boot Problems or Concerns

Depending on the boot device, a checkpoint may be displayed on the operator panel for an extended period of time while the boot image is retrieved from the device. This is particularly true for Tape and Network boot attempts. If booting from CD-ROM or Tape, watch for activity on the drive's LED indicator. A blinking LED indicates that the loading of either the boot image or additional information required by the operating system being booted is still in progress. If the checkpoint is displayed for an extended period of time and the drive LED is not indicating any activity, there may be a problem loading the boot image from the device.

Note: For network boot attempts, if the system is not connected to an active

network or if the target server is inaccessible (this can also result from incorrect IP parameters being supplied), the system will still attempt to boot. Because time-out durations are necessarily long to accommodate retries, the system may appear to be hung.

This section assumes that a CD-ROM drive is installed and a Diagnostics CD-ROM is available.

1. Restart the system and get to the Firmware SMS Main Menu. Select Multiboot.

 Check if the intended boot device is correctly specified in the boot sequence.  Verify that a boot image resides on the media of the specified boot devices.

– Unload any removable (ie. Diskette, CD-ROM, or Tape) media that can

not be verified.

– If the intended boot device is not correctly identified in the boot

sequence, add it to the boot sequence using the SMS menus. If the intended boot device cannot be added to the boot sequence go to step

3. – If attempting to boot from the network go to step 2. – If attempting to boot from a disk drive or CD-ROM go to step 3.

2. If attempting to boot from the network:

 Verify that IP parameters are correct.  Attempt to "Ping" the target server using the SMS Ping utility. If the ping is

successful, have the network administrator verify the server configuration for this client.

 Turn power Off, then On and retry the boot operation.  Check the network cabling to adapter.

3. Try to boot and run standalone diagnostics against the system, particularly against the intended boot device.

Chapter 3. Error Code to FRU Index 3-27

 If the intended boot device is not listed in the NEW RESOURCE list, go to

"MAP 0290: Missing Resource Problem Resolution" in Diagnostics

Information for Multiple Bus Systems.

 If an SRN, not an 8-digit error code, is reported, go to Diagnostics

Information for Multiple Bus Systems.

 If the diagnostics are successful, it may be necessary to perform an

operating system-specific recovery process, or reinstall the operating system.

 If unable to load standalone diagnostics:

a. Verify that the SCSI bus is properly terminated. b. Check the SCSI cabling. c. It is possible that another attached SCSI device is causing the problem.

– Disconnect the signal and power cables from any other SCSI devices

attached to the SCSI adapter that the CD-ROM drive is attached to. – Try to boot the standalone diagnostics again. – If unable to load standalone diagnostics, go to step 4. – If standalone diagnostics load, one of the disconnected devices is

causing the problem, reconnect the devices one at a time. Retry the

boot operation until the problem recurs and replace the device that

caused the problem. If the problem appears to be one of the SCSI

devices, be aware it could be either the SCSI device or the SCSI

adapter. Go to "MAP 0410: Repair Checkout" in Diagnostics

Information for Multiple Bus Systems.

4. It is possible that another installed adapter is causing the problem.  Remove all installed adapters except the one the CD-ROM drive is attached

to and the one used for the console.

 Try to boot the standalone diagnostics again.  If unable to load standalone diagnostics, go to step 5.  If standalone diagnostics load, reinstall adapters (and attached devices as

applicable) one at a time. Retry the boot operation until the problem recurs. Then replace the adapter or device that caused the problem (the system board can also cause the device or adapter to fail). Go to "MAP 0410: Repair Checkout" in Diagnostics Information for Multiple Bus Systems.

5. Either the CD-ROM drive, SCSI adapter, the graphics adapter, or the system

board is most likely defective. A tty terminal attached to serial port 1 also can be used to determine if the graphics adapter is causing the problem. This is done by removing the graphics adapter, attaching a tty terminal to serial port 1, and retrying standalone diagnostics. If the standalone diagnostics load, replace the graphics adapter.

 If the CD-ROM drive is attached to a SCSI adapter card rather than the

integrated SCSI adapter on the system board:

– Replace the SCSI adapter. – Replace the riser card.

3-28 7046 Model B50 Service Guide

 Replace system board (see note 3 on page 2-1).  If you replaced the indicated FRUs and the problem is still not corrected, or

the above descriptions did not address your particular situation, go to “MAP 1540: Minimum Configuration” on page 2-17.

 Go to "MAP 0410: Repair Checkout" in Diagnostics Information for Multiple

Bus Systems.

Chapter 3. Error Code to FRU Index 3-29

3-30 7046 Model B50 Service Guide

Chapter 4. Location Codes

The RS/6000 7046 Model B50 uses physical location codes in conjunction with AIX location codes to provide mapping of the failing field replaceable units. The location codes are produced by the system unit's firmware and AIX.

Physical Location Codes

Physical location codes provide a mapping of logical functions in a platform (or expansion sites for logical functions, such as connectors or ports) to their specific locations within the physical structure of the platform.

Location Code Format

The format for the location code is a string of alphanumeric characters separated by a dash (-), slash (/), pound sign (#), or period (.).

 The base location is all of the information before the slash (/) or pound sign (#).

It identifies a device that is connected or plugged into the parent.

 Extended location information follows the slash (/). It identifies a device that is

part of the parent, a connector, or a cable.

 Cable information follows the pound sign (#). It identifies a cable that is

connected to the parent.

The following are examples:

P1-C1 Identifies a CPU card C1 plugged into planar P1. P1-M1 Identifies a memory card M1 plugged into planar P1. P1-K1 Identifies a keyboard attached to connector K1 on planar P1. P1/S1 Identifies serial port 1 controller on planar P1, the connector for serial port

1, or the cable attached to the connector for serial port 1.

P1-I2/E3 Identifies Ethernet controller 3 on the card plugged into slot 2 (I2) on

planar P1, the connector for Ethernet controller 3, or the cable attached to Ethernet controller 3.

P1-I2#E3 Identifies the cable attached to Ethernet controller 3 plugged into slot 2

(I2) on planar P1.

Sub-locations, such as memory modules on a base memory card or a specific SCSI address, are identified by a period (.). The following are examples:

P1-M1.4 Identifies DIMM 4 on memory card 1 on planar 1.

Chapter 4. Location Codes 4-1

1-C1.1 Identifies CPU 1 on CPU card 1 on planar 1. P2/Z1-A3.1 Identifies a SCSI device with a SCSI address of LUN 1 at SCSI ID 3

attached to SCSI bus 1 from planar 2.

P1-I2#E3.2 Identifies the second cable in a series of cables attached to Ethernet

controller 3 in slot 2 (I2) on planar 1.

Depending on the AIX and firmware levels, AIX Diagnostics may include extended location information when identifing a planar or card. The extended location information is always included when identifing a cable or connector. Location codes with extended location information that display without a description identifing the devices, always identify the cable attached to the port.

Name AIX

Location Code

System Planar 00-00 P1 Riser Card P1.1 J39 Memory DIMM 1 00-00 P1-M1 J11 Memory DIMM 2 00-00 P1-M2 J28 Memory DIMM 3 00-00 P1-M3 J19 Memory DIMM 4 00-00 P1-M4| J139| Diskette Drive 01-D1-00-00 P1-D1 J16 Base Address

Keyboard 01-K1-00-00 P1-K1 J59 Base Address

Mouse 01-K1-01-00 P1-O1 J56 Base Address

Audio Port 01-Q2 P1/Q2 Diskette Port 01-D1 P1/D1 J16 Base Address

Keyboard Port 01-K1-00 P1/K1 J59 Base Address

Mouse Port 01-K1-01 P1/O1 J56 Base Address

Serial Port 1 01-S1 P1/S1 J24 Base Address

Serial Port 2 01-S2 P1/S2 J23 Base Address

Parallel Port 01-R1 P1/R1 J49 Base Address

Ethernet Port 10-60 P1/E1 J45 Host Bridge ID00,

Location Code

Physical Connection

Logical Identification

0x03F0

0x0060

0x03F0

0x0060

0x03F8

0x02F8

0x0378

Device 12

4-2 7046 Model B50 Service Guide

Name AIX

Location Code

SCSI Port 10-80 P1/Z1 J33/J38 Host Bridge ID00,

Tablet Port 01-Q1 P1/Q1 Card in PCI Slot 2 10-90 P1.1-I2 J3 on Riser

Card in PCI Slot 1 10-b0 P1.1-I1 J2 on Riser

CD-ROM P1-Z1-A3 Primary SCSI Bus ID

Upper DASD P1-Z1-A2 Primary SCSI Bus ID

Lower DASD P1-Z1-A4 Primary SCSI Bus ID

Fan # 1 F1 J27/J30 Operator Panel L1 J41 Power Supply V1 J7/J8/J2/J9

Location Code

Physical Connection

Card (Top Connector)

Card (Bottom Connector)

Logical Identification

Device 16

PCI Bridge ID01, Device 18

Host Bridge ID00, Device 22

AIX Location Codes

The basic formats of the AIX location codes are:

 For non-SCSI devices/drives:

AB-CD-EF-GH

 For SCSI devices/drives:

AB-CD-EF-G,H

Non-SCSI Devices/Drives

The location code for for planars, cards, and non-SCSI devices is defined as:

AB-CD-EF-GH

Chapter 4. Location Codes 4-3

 The AB value identifies a bus type or PCI parent bus as assigned by the

firmware.

 The CD value identifies adapter number, adapter's devfunc number, or physical

location. The devfunc number is defined as the PCI device number times 8, plus the function number.

 The EF value identifies a connector.  The GH value identifies a port, address, device, or FRU.

Adapters and cards are identified with AB-CD. The possible values for AB are:

00 Processor bus 01 ISA bus 02 EISA bus 03 MCA bus 04 PCI bus used in the case where the PCI bus cannot be identified 05 PCMCIA buses xy For PCI adapters where x is equal to or greater than 1. The x and y are

characters in the range of 0-9, A-H, J-N, P-Z (O, I, and lowercase are omitted) and are equal to the parent bus's ibm, aix-loc Open Firmware Property.

The possible values for CD depend on the adapter/card:

 For pluggable PCI adapters/cards, CD is the device's devfunc number (PCI

device number times 8, plus the function number). The C and D are characters in the range of 0-9, and A-F (hex numbers). Location codes therefore uniquely identify multiple adapters on individual PCI cards.

 For pluggable ISA adapters, CD is equal to the order the ISA cards

defined/configured either by SMIT or the ISA Adapter Configuration Service Aid.

 For integrated ISA adapters, CD is equal to a unique code identifying the ISA

adapter. In most cases, this code is equal to the adapter's physical location code. In cases where a physical location code is not available, CD is FF.

EF is the connector ID, used to identify the adapter's connector to which a resource is attached.

GH is used to identify a port, device, or FRU. For example:

4-4 7046 Model B50 Service Guide

 For async devices, GH defines the port on the fanout box. The values are 00 to

15.

 For a diskette drive, H identifies either diskette drive 1 or 2. G is always 0.  For all other devices, GH is equal to 00.

For integrated adapter, EF-GH is the same as the definition for a pluggable adapter. For example, the location code for a diskette drive is 01-D1-00-00. A second diskette drive is 01-D1-00-01.

SCSI devices/drives

The location code for SCSI devices and drives is defined as:

AB-CD-EF-G,H
