MULTIMEDIA MODEM PLUS USER'S GUIDE

FOR USAGE TO UPGRADE IBM MULTIMEDIA MODEM

(MOD 715 P/N - 13H6715)

FIRST EDITION (DECEMBER 1995)

Note to U.S. Government Users -- Documentation related to restricted rights -- Use, duplication or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Page 1 of 47

Table of Contents

ABOUT THIS BOOK................................................................................................................................................. 4

INTRODUCTION....................................................................................................................................................... 4

MWAVE SOFTWARE FEATURES........................................................................................................................ 5

BEFORE YOU BEGIN ............................................................................................................................................5

RELEASE INFORMATION.................................................................................................................................... 5

MINIMUM SYSTEM REQUIREMENTS............................................................................................................... 6

PREPARING FOR SOFTWARE INSTALLATION.............................................................................................. 7

INSTALLING THE SOFTWARE............................................................................................................................ 7

CONFIGURING YOUR MULTIMEDIA MODEM PLUS FOR WINDOWS....................................................... 10

MANUALLY CONFIGURING YOUR MULTIMEDIA MODEM PLUS FOR WINDOWS ................................. 11

CONFIGURING MWAVE DOS.......................................................................................................................... 12

INSTALLING THE SOFTWARE UNDER OS/2 WARP ..................................................................................... 13

CONFIGURING YOUR MULTIMEDIA MODEM PLUS FOR OS/2 WARP ..................................................... 15

UPDATING THE MMPM/2 FOR MULTIMEDIA MODEM PLUS .................................................................... 17

Configuring Your Multimedia Modem Plus for WIN-OS/2................................................................................. 18

INSTALLING APPLICATIONS SOFTWARE..................................................................................................... 19

UNINSTALLING MULTIMEDIA MODEM PLUS SOFTWARE......................................................................... 19

USING VOICE, FAX AND DATA.......................................................................................................................... 21

MANUAL DISCRIMINATION............................................................................................................................. 21

SETTING MWAVE DISCRIMINATOR OPTIONS.............................................................................................22

CALLER ID IDENTIFICATION......................................................................................................................... 22

DTMF CODE DISCRIMINATION...................................................................................................................... 23

DISCRIMINATOR SETTINGS.............................................................................................................................24

USING IBM WAKE-UP ON RING ........................................................................................................................ 25

USING MWAVE DSVD........................................................................................................................................... 25

USING THE MWAVE MODEM............................................................................................................................ 26

USING THE MWAVE MODEM COMMAND REFERENCE............................................................................ 27

USING AUDIO.......................................................................................................................................................... 27

SETTING WINDOWS AUDIO CONTROLS........................................................................................................ 27

SELECTING THE INPUT SOURCE..................................................................................................................... 28

CONTROLLING VOLUME AND BALANCE..................................................................................................... 28

SETTING TONE CONTROLS .............................................................................................................................. 28

ADDING SPECIAL AUDIO EFFECTS ................................................................................................................ 29

OS/2 AUDIO CONTROLS..................................................................................................................................... 29

PLAYING A CD..................................................................................................................................................... 30

USING DOS APPLICATIONS................................................................................................................................ 30

USING THE FASTCFG SCREEN......................................................................................................................... 30

FREEING MEMORY FOR DOS APPLICATIONS.............................................................................................. 31

USING THE JPEG IMAGE VIEWER.................................................................................................... ............... 32

TROUBLESHOOTING........................................................................................................................................... 33

INSTALLATION PROBLEMS.............................................................................................................................. 33

OPERATION PROBLEMS.................................................................................................................................... 34

Page 2 of 47

HELPFUL HINTS....................................................................................................................................................36

INSTALLATION.................................................................................................................................................... 36

FAXWORKS FOR OS/2 USERS........................................................................................................................... 39

AUDIO APPLICATIONS ...................................................................................................................................... 40

SPECIFICATIONS................................................................................................................................................... 41

CARD FEATURES ................................................................................................................................................ 41

INTERNAL I/O CONNECTIONS ......................................................................................................................... 41

SUPPORTED INTERNAL CD-ROM DRIVES..................................................................................................... 41

EXTERNAL I/O CONNECTIONS........................................................................................................................ 41

POWER REQUIREMENTS................................................................................................................................... 42

FAX MODEM ........................................................................................................................................................ 42

DATA MODEM..................................................................................................................................................... 42

TELEPHONY SUBSYSTEM................................................................................................................................. 42

AUDIO FEATURES............................................................................................................................................... 43

IBM MULTIMEDIA MODEM PLUS SETTINGS TABLE.................................................................................. 43

RECOMENDED SETTINGS FOR THE AMBRA SERIES.................................................................................. 43

GLOSSARY OF TERMS AND ABBREVIATIONS............................................................................................ .44

LICENSE INFORMATION .................................................................................................................................... 46

NOTICES................................................................................................................................................................ 46

TRADEMARKS........................................................................................................................................................ 47

Page 3 of 47

ABOUT THIS BOOK

This book is intended to explain how to install and use the IBM Multimedia Modem Plus. You should have some experience with installing adapters in computers and be familiar with using the operating system on your computer before attempting to install this product.

This book contains:

An introduction

How to install and configure the software

How to use the Multimedia Modem Plus features

Troubleshooting information

Specifications

Be sure to read through the software installation sections before you start the installation procedure. If you are still unsure of your ability to install the Multimedia Modem Plus after reading the installation sections, ask an experienced technician for help or contact your technical support representative. The following terms are used in this book.

IMPORTANT: A condition that can adversely impact the operation of your computer.

NAVIGATION: Identifies instructions on how to get to the function that is described.

WARNING: A word for calling attention to the possibility of damage to a program, device, or system, or to data.

NOTE: The illustrations in this publication might be slightly different from your hardware.

INTRODUCTION

The IBM Multimedia Modem Plus combines high-quality audio and telephony functions on a single 16-bit ISA adapter in your computer. The adapter is based on the IBM Mwave DSP, and makes it easy to control telephone, fax, and data communication and to enjoy high-quality stereo sound, all from your computer desktop. The Multimedia Modem Plus provides the capabilities of a reliable 28 800 bps modem and 14 400 bps fax. Mwave DSVD allows you to share voice and data over the same phone line. High quality audio is provided with 32 voice, 128 instrument MIDI wavetable synthesis with special effects features including QSOUND, chorus, reverb, and base and treble controls. In addition, major audio standards are supported including Sound Blaster Pro and MPU-401.

Page 4 of 47

MWAVE SOFTWARE FEATURES

The Multimedia Modem Plus function is controlled by software downloaded to the DSP. Important functions provided by the Mwave software include:

Sound Blaster, Sound Blaster ADPCM, MIDI, and Sound Blaster Pro emulation device

drivers EMU sound samples

MCI-standard compliant audio device driver

Automatic 3-way incoming call discrimination

Caller ID

Fax and modem drivers with autostart capability and dynamic rate renegotiations to maintain

the highest possible speed by adjusting the transfer rate to compensate for telephone line fluctuations User-level card diagnostics

Enhanced Mwave Audio Mixer

Telephone answering machine support

Support for TAPI to allow compatibility with other applications that conform to TAPI

Enhanced full-duplex speakerphone for clear two-way conversation while you work

JPEG image viewer for viewing JPEG compressed image files (.JPG)

BEFORE YOU BEGIN

You might need information about the current system board settings and settings for other options that are installed in your computer. Make sure you have access to the documentation that comes with your computer and installed options.

Except for a standard screwdriver, everything you need to connect and begin using the Multimedia Modem Plus is included in this package.

RELEASE INFORMATION

Read the Release Notes found in the Multimedia Modem Plus group in Windows or the README file found in the Multimedia Modem Plus folder in OS/2 after you have completed the software installation process. These files contain important information about using your Multimedia Modem Plus that is not included in this User's Guide.

For additional information about installing and using the Multimedia Modem Plus that is not in the README file or in this User's Guide, see "Helpful Hints".

Page 5 of 47

MINIMUM SYSTEM REQUIREMENTS

The Multimedia Modem Plus has the following minimum hardware and software requirements:

AT-compatible computers with a 386SX-33MHz microprocessor (a minimum 486SX-

33MHz is recommended) One empty, 16-bit Busmaster ISA slot

VGA monitor and a 3.5-inch diskette drive

6 MB of memory (8 MB of memory is recommended)

17 MB of available hard disk space

Windows 3.1 or 3.11 running in 386 enhanced mode, under DOS 5.0 or higher, OR Windows

95, OR OS/2 Warp with Multimedia support installed (WIN-OS/2 software is optional) Optional Rapid Resume and Wake-Up on Ring compatibility

Many IBM computer models include the Rapid Resume and Wake-Up on Ring features. See the documentation that comes with your computer to determine if these features are available for your model.

Page 6 of 47

PREPARING FOR SOFTWARE INSTALLATION

If you are upgrading from the Multimedia Modem or have any other Mwave software installed in your computer, you must remove the old Mwave software to avoid conflicts with the new Mwave software. The setup program that is part of your installation package should be used to remove the old Multimedia Modem Mwave software from your hard disk drive.

INSTALLING THE SOFTWARE

Note: If you are upgrading from the Multimedia Modem or have any other Mwave software installed in your computer, you must remove the old Mwave software to avoid conflicts with the new Mwave software. The setup program that is part of your installation package should be used to remove the old Multimedia Modem Mwave software from your hard disk drive.

You can use the Multimedia Modem Plus with the following operating systems:

DOS 5.0 or higher

Microsoft Windows 3.1 or 3.11 under DOS 5.0 or higher

Microsoft Windows 95

OS/2 Warp with Windows or WIN-OS/2 installed

NOTE: During the installation process some message windows (boxes) may appear which are not addressed in this documentation, choose the default to proceed with the install process.

WHAT TO DO NEXT

If you are installing or updating under any version of Windows, go to "Installing the

Software Under Windows 3.x or Windows 95."

If you are installing or updating under OS/2 Warp, go to "Installing the Software Under OS/2

Warp."

If you are installing WIN-OS/2 support under OS/2 Warp with Windows application support

(Blue Spine), install OS/2 support first. Then install Windows support from a WIN-OS/2 full screen session. If you are installing WIN-OS/2 support under OS/2 Warp for Windows (Red Spine), install

Windows first in native DOS/Windows, then install OS/2 support using the Windows configuration values. If you are installing QuickLink Message Center or software applications that are not part of

this package, read "Installing Applications Software."

Page 7 of 47

INSTALLING THE SOFTWARE UNDER WINDOWS 3.X OR WINDOWS 95

The setup program:

Removes any previous version of the Multimedia Modem Mwave Modem software, if

installed Installs the new software on your hard disk drive

Configures your Multimedia Modem Plus

Creates the Multimedia Modem program group in the Windows Program Manager

The following instructions are used to install under Windows 3.1, 3.11, or Windows 95:

1. Start Windows. a. Insert Windows Disk 1 in your diskette drive. This sample procedure uses drive A. b. For Windows 3.x, go to the Program Manager and click on RUN from the File menu.

Continue with 3.

c. For Windows 95, click on Start Button then click RUN from the Start menu. Continue

with 3.

d. From the Windows 95 main window, select MY COMPUTER, click on the A drive

object and select SETUP from the list of programs and then start the Setup program. Continue with 4.

2. To start the setup program, type:

A:\SETUP Click on OK or press ENTER.

3. Do one of the following: a. Click on the Complete Installation icon, to install all Mwave software then and go to 5 to

continue the installation process. Complete installation is the normal selection for new installations or upgrading from Multimedia Modem.

b. Click on the Selective Installation icon for a partial installation.

Clear the selection boxes for the products you do not want to install. Some of the following windows might not apply depending on the components you choose for your selective installation.

c. Click on the Uninstall icon to remove any previous versions of the Multimedia Modem

software from your computer. If you ever remove the Multimedia Modem Plus adapter from your computer, you must use the uninstall process to be sure that the Mwave software is removed from all directories on your hard disk drive.

d. Click on the Exit icon to end the Setup program.

4. If you are updating from Multimedia Modem, the Setup program does the following: a. Informs you that it is removing the existing Mwave software without changing the

Multimedia Modem data. Click on YES to continue.

Page 8 of 47

b. Asks you to verify that you want to restart Windows to remove the Mwave drivers from

memory. Click on YES to continue. Windows restarts and reloads the Setup program c. Informs you that the Mwave software is being removed. Click on OK. d. Informs you that the Multimedia Modem software has been removed. Click on OK. e. If you are asked if you want to overwrite the Multimedia Modem settings and message

files, click on NO to protect your existing settings and message files.

5. Click on OK to install the Mwave software in the default directory or type a new directory and click on OK.

If the directory is not on your hard disk drive, click on YES to create it or click on NO and type another directory name. NOTE: If your computer does not meet the minimum system requirements for the Multimedia Modem Plus, the Setup program displays a list of deficiencies. For optimum operation of the Multimedia Modem Plus, exit the Setup program and upgrade your computer to meet the minimum system requirements. If you choose not to update, click on CONTINUE.

6. Insert Windows Disk 2 when prompted by the Setup program.

7. When the MIDI EMU Wave Samples prompt is displayed, insert EMU Disk 1 and click on OK.

8. When you are prompted for the name of the MIDI samples directory, click on OK to install them in the default directory, or type another directory name and click on OK.

9. When prompted, insert EMU Disk 2 and click on OK.

If OS/2 is installed on your computer, you will be asked if the EMU Samples should be used for OS/2 also, click on YES

10. When the Setup program prompts you for the Mwave DOS diskette, insert DOS Disk 1 and click on OK.

If you are upgrading from the Multimedia Modem, you are asked if you want to update your existing Mwave installation. When asked if you want to continue, Click on YES. If the Setup program prompts you for the location of the Mwave DOS files, click on OK to install them in the default directory, or type another directory name and click on OK.

11. Click on YES, if you want to automatically update the AUTOEXEC.BAT file.

12. When prompted, insert DOS Disk 2 and click on OK.

13. When asked if you want to install the MIDI EMU Wave sound samples, click on YES.

14. When the Mwave DOS software installation is complete, click on OK to return to the Setup program.

15. When the message is displayed that tells you to exit Windows, click on OK.

16. When the Installation Exit is displayed, click on YES.

Page 9 of 47

CONFIGURING YOUR MULTIMEDIA MODEM PLUS FOR WINDOWS

NOTE: If you are upgrading from the Multimedia Modem or have any other Mwave software installed in your computer, you must remove the old Mwave software to avoid conflicts with the new Mwave software. The setup program that is part of your installation package should be used to remove the old Multimedia Modem Mwave software from your hard disk drive.

NOTE: You must run the CONFIG.EXE program after running Setup or your Multimedia Modem Plus will not operate properly. Your mouse does not work when you are running the CONFIG.EXE program. Use the arrow > and tab keys to move the cursor.

The configuration program CONFIG.EXE analyzes your operating system to determine and resolve any conflicts with the Multimedia Modem Plus. For most computers you can choose the Automatic Setup and Test option and the configuration program selects the correct settings.

For known conflicts and solutions, see "Troubleshooting."

To configure the Multimedia Modem Plus for Windows operating systems:

1. Do one of the following:

In Windows 95, select SHUTDOWN from the start menu, then select RESTART THE

COMPUTER IN DOS MODE, and click on YES. In Windows 3.x, exit Windows.

2. At the DOS prompt, change to directory C:\DSP2\SOLO.

If you did not install the Mwave software in C:\DSP2\SOLO, change to the appropriate directory.

3. At the directory prompt, type CONFIG and press ENTER.

4. Select OK to enter the CONFIG.EXE program.

5. Select AUTOMATIC SETUP AND TEST and press ENTER. After tests are complete, press ENTER to continue.

NOTE: If you connected your CD-ROM to the Multimedia Modem Plus, you must complete the CD-ROM information fields in the Setup window. For more information about these fields, see "Manually Configuring Your Multimedia Modem Plus for

Windows."

If the CONFIG.EXE program appears to hang your computer while testing the DSP DMA channel or the SB DMA channel, restart your computer. The CONFIG.EXE program stores the DMA channel conflict that occurred and avoids reselecting the DMA channel that caused the device conflict. Start the CONFIG.EXE program again and reselect the Automatic Setup and Test option.

6. If the automatic setup was successful, select EXIT to end the configuration program.

Record the configuration information. You will it if you plan to install the Multimedia Modem Plus under both OS/2 Warp and Windows in the same computer.

7. Answer yes to the questions about updating your system files when you are prompted by the program.

8. Shutdown and restart Windows or Windows 95.

Page 10 of 47

9. If a conflict was found:

a. Identify the conflict. Refer to the documentation that comes with your computer and your

devices to find a setting that you can use for the Multimedia Modem Plus. For example, for COM port or IRQ conflicts, check your computer manual to find an unused COM port and IRQ pair.

b. After resolving the conflict, continue with “Manually Configuring Your Multimedia Modem

Plus for Windows."

MANUALLY CONFIGURING YOUR MULTIMEDIA MODEM PLUS FOR WINDOWS

NOTE: If you are upgrading from the Multimedia Modem or have any other Mwave software installed in your computer, you must remove the old Mwave software to avoid conflicts with the new Mwave software. The setup program that is part of your installation package should to used to remove the old Multimedia Modem Mwave software from your hard disk drive.

Normally you should use the Automatic Setup and Test option to configure your Multimedia Modem Plus. However, if a conflict is found or you are using the CD-ROM controller interface, you must manually change the appropriate configuration settings.

NOTE: Use this procedure to change settings other than the CD-ROM parameters only if you are familiar with the setup of your operating system.

Depending on the complexity of your system, the configuration program might not accurately detect all system parameters.

To manually change the settings:

1. At the DOS prompt, Type CONFIG and press ENTER

2. Select OK to enter the CONFIG.EXE program.

3. Press TAB to go to Setup, and then press ENTER.

Use the TAB keys to move the cursor. Your mouse does not work while the CONFIG.EXE program is running. Tab to the setting that you want to change. When the setting is highlighted, press the ENTER key and choose the desired value using the up and down arrow keys. When finished, press ENTER. The CD-ROM TYPE and BASE I/O ADDRESS must be set manually.

4. Select OK, and then press ENTER.

5. Select TEST and then press ENTER to start the configuration tests. If the tests do not complete successfully, change the settings and retest.

Page 11 of 47

6. When the configuration is complete and all test have successfully completed: Record the configuration information. You will need it if you plan to install Multimedia Modem Plus under OS/2 Warp and Windows in the same computer. a. Select EXIT, and press ENTER to end the configuration program and save your

configured settings.

b. Answer yes to the questions about updating your system files when you are prompted by

the program.

c. Shutdown and restart Windows or Windows 95.

CONFIGURING MWAVE DOS

If you want to change your Multimedia Modem Plus settings to use advanced audio, telegaming, or another supported application, you must access the Mwave DOS configuration window. This window is displayed when you you start DOS or close Windows with the Multimedia Modem Plus installed. To access this window and change the DOS parameters for your session:

1. Exit Windows and start your computer in DOS.

2. From any directory, type FASTCFG and press Enter.

3. When the Fastcfg-Current Mwave DOS Settings window is displayed, select the appropriate application type for your session. Use the ARROW > and TAB keys to move the cursor.

4. Select OK to save the setting and return to DOS.

NOTE: For further information on FASTCFG, see "Using DOS Applications."

5. Start your application. For information about how to run an application, see the documentation that comes with the application.

You have completed the software installation process for Windows and are ready to use the Multimedia Modem Plus.

WHAT TO DO NEXT

If you want to install the Multimedia Modem Plus

software under OS/2 Warp continue with the next section. For information about using the Multimedia

Modem Plus, see "Using Voice, Fax and Data." If you are installing QuickLink Message Center or

software applications that are not part of this package, read "Installing Applications Software."

Page 12 of 47

INSTALLING THE SOFTWARE UNDER OS/2 WARP

NOTE: The Multimedia Modem Plus software only supports OS/2 Warp Version 3.0 or higher.

The instructions in this section explain the installation and configuration process for the Mwave software under OS/2 Warp

The setup program:

Removes the Multimedia Modem Mwave software, if installed

Installs the new software on your hard disk drive

Configures your Multimedia Modem

Creates the Multimedia Modem program desktop group

Follow this procedure to install the Multimedia Modem Plus software under OS/2 Warp:

1. Start OS/2 and verify that the IBM Multimedia Presentation Manager/2 (MMPM/2) is installed in your computer. For information about MMPM/2, see your OS/2 user's manual.

2. Insert OS/2 Disk 1 in drive A.

3. Open an OS/2 window.

4. At the command prompt, type: A:\SETUP and press ENTER. The Setup program takes some time to initialize. NOTE: If you had a Multimedia Modem previously installed in your computer, you are asked if you want to continue and overwrite the previous installation. Click on YES. NOTE: If you are upgrading from the Multimedia Modem or have any other Mwave software installed in your computer, you must remove the old Mwave software to avoid conflicts with the new Mwave software. The setup program that is part of your installation package should be used to remove the old Multimedia Modem Mwave software from your hard disk drive.

5. Select one of the following installation types:

Select the complete installation option to install all Mwave software and continue with 6.

Complete installation is the normal selection for new installations or upgrading from Multimedia Modem. Select the selective installation option if you only want to install part of the Mwave

software. Clear the selection boxes for the software you do not want to install. Some of the following windows might not apply depending on the components you choose for your selective installation. Select the uninstall option if you want to remove the Multimedia Modem software from

your computer. If you ever remove the Multimedia Modem Plus adapter from your computer, you must use the uninstall process to be sure that the Mwave software is removed from all directories on your hard disk drive.

Page 13 of 47

6. Click on OK to install the Mwave software in the default directory or type a new directory and click on OK. If the directory is not on your hard disk drive, click on YES to create it or click on NO and type another directory name.

7. Insert OS/2 Disk 2 when prompted by the Setup program. Click on OK to continue.

8. When prompted, insert EMU Disk 1 and click on OK.

9. When you are prompted for the name of the MIDI Samples directory, click on OK to install them in the default directory, or type another directory name and click on OK.

10. If you are asked if you want your OS/2 Mwave synthesizer to use the MIDI Samples, click on YES.

11. When prompted, Insert EMU Disk 2 and click on OK.

12. When the install successful message is displayed, click on OK.

13. When you receive the message instructing you to run CONFIGO.EXE, note the directory location and click on OK

IMPORTANT: Before shutting down OS/2 Warp, you must run the CONFIGO.EXE program located in the C:\DSP2\MWOS2\BIN directory to reconfigure your operating system.

Page 14 of 47

CONFIGURING YOUR MULTIMEDIA MODEM PLUS FOR OS/2 WARP

The configuration program CONFIGO.EXE is used to configure the Multimedia Modem Plus.

To configure the Multimedia Modem Plus for OS/2 Warp:

1. Open a DOS full screen session from the OS/2 Desktop.

2. At the command prompt, type:

CD\DSP2\MWOS2\BIN then press ENTER. If you installed your software in a different directory, change to that directory.

3. To start the OS/2 configuration program, type CONFIGO at the command prompt and press ENTER. Select OK using the ENTER key.

Use the ARROW > and TAB keys to move the cursor. Your mouse does not work when you are running the CONFIGO.EXE program.

4. The CONFIGO.EXE program displays the default values to be used by your Multimedia Modem Plus. a. If you have Microsoft Windows installed, you need to make your OS/2 configuration

settings match the Windows configuration settings determined by the CONFIG.EXE program. The Windows configuration settings are the settings you recorded when you configured your computer under Windows.

b. If you do not have Windows installed you might have to change the default settings. If

you connected a CD-ROM to your modem you need to change the CD-ROM TYPE and BASE I/O ADDRESS fields. If a CD-ROM base I/O address is part of your CD-ROM driver statement in the OS/2 CONFIG.SYS file, make sure the CONFIGO CD-ROM Base I/O Address in the list of settings matches the address in the CONFIG.SYS file. Use an editor, such as the OS/2 System Editor to open your CONFIG.SYS file and check the address.

c. If you are aware of a COM port, IRQ, or Base I/O address conflict then check the list of

valid settings that you recorded for the Multimedia Modem Plus. If you are not aware of any conflicts, select EXIT and go to 6.

5. To change settings, select Setup and press ENTER.

Use the TAB key to highlight the setting you want to change. Press ENTER and choose a value using the up and down arrow keys. Press ENTER to accept the new value. When you finish changing the settings, select OK. Then select EXIT to end the CONFIGO.EXE program. Accept the changes and select YES to update the operating system files.

6. When the configuration for OS/2 is complete, remove the diskette, shutdown and restart your computer. NOTE: You must restart your computer when you change configuration settings using the CONFIGO.EXE program.

Page 15 of 47

+ 32 hidden pages
