IBM 6288, 6268, 6278 User Manual

Technical Information Manual

PC 300GL Types 6268, 6278, and 6288

Note

Before using this information and the product it supports, be sure to read the general information under
Appendix E, “Notices and trademarks” on page 42.

First Edition (September 1999)

The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with
local law: INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied
warranties in certain transactions, therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information
herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the
product(s) and/or the program(s) described in this publication at any time.

This publication was developed for products and services offered in the United States of America. IBM may not offer the products,
services, or features discussed in this document in other countries, and the information is subject to change without notice. Consult
your local IBM representative for information on the products, services, and features available in your area.

Requests for technical information about IBM products should be made to your IBM reseller or IBM marketing representative.

 Copyright International Business Machines Corporation September 1999. All rights reserved.

Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to
restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Terminology usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Chapter 1. System overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Major features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Other features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Network support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Wake on LAN .................................................. 2

Wake on Ring .................................................. 2

Chapter 2. System board features ...................................... 3

Celeron microprocessor with MMX technology ................................. 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

L2 cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chip set control ................................................... 3

System memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PCI bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

IDE bus master interface ............................................ 5

USB interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Low pin count (LPC) bus ............................................ 5

Video subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Graphics memory controller hub (Super Video Graphics Array) ..................... 6

Monitor support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Video memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Audio subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Super input/output controller ........................................... 10

Diskette drive interface ............................................. 10

Serial ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Parallel port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Keyboard and mouse ports .......................................... 11

Network connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Real-time clock and CMOS ............................................ 12

Flash EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Expansion adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Physical layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

System board, types 6268, 6278, and 6288 ................................. 13

Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Cable connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Connector panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Chapter 3. Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

PC 300GL — desktop ............................................. 15

PC 300GL — tower ............................................... 16

Cabling requirements for Wake on LAN adapters ............................. 16

Chapter 4. Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Power input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Power output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Component outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

 Copyright IBM Corp. September 1999 iii

Output protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Connector description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Chapter 5. System software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Plug and Play .................................................... 20

POST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Configuration/Setup Utility program ....................................... 21

Advanced Power Management (APM) ...................................... 21

Advanced Configuration and Power Interface ................................. 21

Flash update utility program ............................................ 21

Diagnostic program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Chapter 6. System compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Hardware compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Hardware interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Diskette drives and controller ......................................... 23

Hard disk drives and controller ........................................ 23

Software compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Software interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Machine-sensitive programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Appendix A. Connector pin assignments .................................. 25

Monitor connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Memory connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

PCI connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

IDE connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Diskette drive connector .............................................. 32

Power supply connector .............................................. 32

Modem/Ring Wakeup and Wake on LAN connectors ............................. 33

USB port connectors ................................................ 33

Mouse and keyboard port connectors ...................................... 33

Serial port connector ................................................ 34

Parallel port connector ............................................... 34

Appendix B. System address maps ..................................... 36

System memory map ............................................... 36

Input/output address map ............................................. 36

DMA I/O address map ............................................... 38

PCI configuration space map ........................................... 39

Appendix C. IRQ and DMA channel assignments ............................. 40

Appendix D. Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

POST error codes ................................................. 41

POST beep codes ................................................. 41

Appendix E. Notices and trademarks .................................... 42

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

iv Technical Information Manual

Figures

1. Memory configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Video subsystem resources ........................................ 6

3. Supported VGA video modes ....................................... 7

4. Supported Enhanced VGA video modes ................................. 7

5. Serial port assignments ........................................... 11

6. Parallel port assignments .......................................... 11

7. BIOS configuration jumper (J7A1) ..................................... 13

8. Power Input Requirements ......................................... 17

9. Power Output (145 Watt) .......................................... 17

10. System board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

11. Keyboard port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

12. Auxiliary device port ............................................. 18

13. PCI-bus adapters (Per Slot) either/or ................................... 18

14. USB port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

15. Internal DASD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

16. Video port pin 9 ............................................... 18

17. 3.5-inch diskette drive reading, writing, and formatting capabilities .................. 23

18. Monitor port connector pin assignments ................................. 25

19. System Memory Connector Pin Assignments .............................. 25

20. System memory connector pin input/output ............................... 27

21. PCI bus connector .............................................. 29

22. PCI connector pin assignments ...................................... 29

23. IDE connector pin assignments ...................................... 31

24. Diskette Drive Connector Pin Assignments ................................ 32

25. Power Supply Connector Pin Assignments ................................ 32

26. J13 Modem/Ring Wakeup Connector Pin Assignments ........................ 33

27. J22 Wake on LAN Connector Pin Assignments ............................. 33

28. USB Port Connector Pin Assignments .................................. 33

29. Mouse port connector pin assignments .................................. 33

30. Keyboard port connector pin assignments ................................ 34

31. Serial Port Connector Pin Assignments .................................. 34

32. Parallel port connector pin assignments ................................. 34

33. System memory map ............................................ 36

34. I/O address map ............................................... 36

35. DMA I/O address map ........................................... 38

36. IRQ channel assignments ......................................... 40

37. DMA channel assignments ......................................... 40

 Copyright IBM Corp. September 1999 v

Preface

This

Technical Information Manual

6288. It is intended for developers who want to provide hardware and software products to operate with
these IBM computers and provides an in-depth view of how these IBM computers work. Users of this
publication should have an understanding of computer architecture and programming concepts.

Related publications

In addition to this manual, the following IBM publications provide information related to the operation of the
IBM PC 300GL.



PC 300GL User Guide

This publication contains information about configuring, operating, and maintaining the PC 300GL, as
well as installing new options in the PC 300GL. Also included are warranty information, instructions
for diagnosing and solving problems, and information on how to obtain help and service.



Understanding Your Personal Computer

This online document includes general information about using computers and detailed information
about the features of the PC 300GL.

provides information for the IBM PC 300GL Types 6268, 6278, and



About Your Software

This publication (provided only with computers that have IBM-preinstalled software) contains
information about the preinstalled software package.



Hardware Maintenance Manual

This publication contains information for trained service technicians. It is available at
http://www.ibm.com/pc/us/cdt/hmm.html on the World Wide Web, and it can also be ordered from IBM.
To purchase a copy, refer to the "Getting Help, Service, and Information" section in

Guide

.



Compatibility Report

This publication contains information about compatible hardware and software for the PC 300GL. It is
available at http://www.ibm.com/pc/us/cdt on the World Wide Web.



Network Administrator's Guide

This publication contains information for network administrators who configure and service local area
networks (LANs). Look for this publication at http://www.ibm.com/pc/us/cdt on the World Wide Web.

Terminology usage

Attention: The term

Use of reserved areas can cause compatibility problems, loss of data, or permanent damage to the
hardware. When the contents of a register are changed, the state of the reserved bits must be preserved.
When possible, read the register first and change only the bits that must be changed.

reserved

describes certain signals, bits, and registers that should not be changed.

PC 300GL User

In this manual, some signals are represented in a small, all-capital-letter format (-ACK). A minus sign in
front of the signal indicates that the signal is active low. No sign in front of the signal indicates that the
signal is active high.

The use of the term
“M” and “G“ are used, they typically indicate powers of 2, not powers of 10. For example, 1 KB equals
1024 bytes (210), 1 MB equals 1048576 bytes (220), and 1 GB equals 1073741824 bytes (230).

hex

indicates a hexadecimal number. Also, when numerical modifiers such as “K”,

vi  Copyright IBM Corp. September 1999

When expressing storage capacity, MB equals 1 000 KB (1024000). The value is determined by counting
the number of sectors and assuming that every two sectors equals 1 KB.

Note: Depending on the operating system and other system requirements, the storage capacity available

to the user might vary.

Preface vii

viii Technical Information Manual

Chapter 1. System overview

Chapter 1. System overview

PC 300GL Types 6268, 6278, and 6288 are computer systems designed to provide state-of-the-art
computing power with room for future growth.

Major features

The major features are:

 An Intel Celeron microprocessor with MMX technology, with 128 KB L2 cache
 Up to 512 MB of system memory
 Integrated IDE bus master controller, ATA 66 capable
 EIDE hard disk drive

 System management

– Wake on LAN support
– DMI (Desktop Management Interface) BIOS and DMI software
– Integrated network protocols
– Enablement for remote administration
– Universal Management Agent (UMA) and UMA Plus
– Wake on Ring support

 IDE CD-ROM1 drive, standard on some models

 Asset security

– Security settings provided by the Configuration/Setup Utility program

- Power-on and administrator password protection

- Startup sequence control

- Hard disk drive and diskette drive access control

- I/O port control
– Cover lock loop
– U-bolt and security cabling (optional)
– Operating system security

– Diskette write-protection

– Alert on LAN support

 Integrated video controller with 4 MB of video display cache memory
 Integrated 16-bit, stereo Analog Devices, Inc. audio controller and built-in high quality speaker in all

models (supports SoundBlaster, DirectX, and Microsoft Windows Sound System applications)

 Networking

– IBM 10/100 Mbits per second (Mbps), PCI Ethernet adapter with Wake on LAN in some models.
– IBM PCI token ring adapter with Wake on LAN is optional.

 Expansion: Four drive bays, four PCI expansion slots
 PCI I/O bus compatibility

 EnergyStar compliance

1

Variable read rate. Actual playback speed will vary and is often less than the maximum possible.

 Copyright IBM Corp. September 1999

1

 3.5-inch, 1.44 MB diskette drive

 Input/output features

– One 25-pin, parallel port with Extended Capabilities Port (EPP)/Extended Parallel Port (EPP)

support

– Two 9-pin, Universal asynchronous receiver/transmitter (UART) serial ports
– Two 4-pin, Universal Serial Bus (USB) ports
– One 6-pin, keyboard port (PS/2 compatible)
– One 6-pin, mouse port
– One 15-pin, DDC2B-compliant monitor port
– Three 3.5 mm audio jacks (line/headphone out, line in, microphone)

Other features

The following features might be supported by the PC 300GL.

Chapter 1. System overview

Network support

PC 300GL computers are enabled to support management over a network. The following is a list of
supported functions:

 Selectable startup sequence
 Selectable Automatic Power On Startup Sequence
 Update POST/BIOS from network
 Wake on LAN
 CMOS Save/Restore utility program
 CMOS setup over LAN
 Wake on Ring

Wake on LAN

The power supply of the computer supports the Wake on LAN feature. With the Wake on LAN feature,
the computer can be turned on when a specific LAN frame is passed to the PC over the LAN.

To use the Wake on LAN feature, the computer must be equipped with a network adapter that supports
Wake on LAN. Some models come with a network adapter that supports Wake on LAN.

You can find the menu used for setting the Wake on LAN feature in the Configuration/Setup Utility
program.

Wake on Ring

All models are configurable to turn on the computer after a ring is detected from an external or internal
modem. The menu used for setting the Wake Up on Ring feature is found in the Configuration/Setup
Utility program. Two options control this feature:

 Serial Ring Detect: Use this option if the computer has an external modem connected to serial port

1.

 Modem Ring Detect: Use this option if the computer has an internal modem that supports the Wake

on Ring feature.

2 Technical Information Manual

Chapter 2. System board features

Chapter 2. System board features

This section includes information about system board features. For an illustration of the system board,
see “System board, types 6268, 6278, and 6288” on page 13.

Celeron microprocessor with MMX technology

PC 300GL Types 6268, 6278, and 6288 comes with an Intel Celeron microprocessor. The
microprocessor, which has a heat sink attached, plugs directly into a connector on the system board.

More information about this microprocessor is available at http://www.intel.com on the World Wide Web.

Features

The features of this microprocessor are as follows:

 Optimization for 32-bit software
 Operation at a lower voltage level than previous microprocessors
 64-bit microprocessor data bus
 66 MHz FSB
 128 KB L2 cache integrated into the microprocessor
 Cache operates at processor core speed

– 4-way set associative

– Nonblocking

 32-bit microprocessor address bus

 Math coprocessor

 MMX technology, which boosts the processing of graphic, video, and audio data

L2 cache

The Celeron microprocessor provides 128 KB L2 cache. (For information on overriding settings, see
Configuration/Setup Utility program, in

PC 300GL User Guide

.)

Chip set control

The Intel 810 chip set is the interface between the microprocessor and the following:
 Memory subsystem

 PCI bus

 IDE Bus Master connection
 Low Pin Count (LPC) bus

 USB ports
 SMBus

 Enhanced DMA controller
 Real-time clock (RTC)
 Audio coder/decoder (codec)

 Copyright IBM Corp. September 1999 3

Chapter 2. System board features

System memory

The system memory interface is controlled by the Intel 82810 chip set. PCI 100 synchronous dynamic
random access memory (SDRAM) is standard.

The maximum amount of system memory is 512 MB. For memory expansion, the system board provides
two dual inline memory module (DIMM) connectors. 100 MHz DIMMs in sizes of 32 MB, 64 MB, 128 MB,
and 256 MB are supported. The amount of memory preinstalled varies by model.

The following information applies to system memory:

 SDRAM, nonparity, unbuffered, 3.3V memory is standard.
 The maximum height of memory modules is 6.35 cm (2.5 in.).
 Only PC 100 industry-standard, gold-contact DIMMs are supported.
 The PC 300GL does not support error correcting code (ECC).
 Auto-configure, auto-detect maximum system memory, using serial presence detect and configuration

interface (BIOS specific).

For information on the pin assignments for the memory module connectors, see “Memory connectors” on
page 25.

The following figure shows some possible configurations for the supported DIMMs.
Note: Values in the following table are represented in megabytes (MB).

Figure 1. Memory configurations

Total memory (MB) DIMM 0 DIMM 1

32 32 0
64 32 32
64 64 0

96 64 32
128 64 64
128 128 0
160 128 32
192 128 64
256 128 128
384 256 128
512 256 256

PCI bus

The fully synchronous 33 MHz PCI bus originates in the Intel 82801 chip. Features of the PCI bus are:

 Integrated arbiter with multitransaction PCI arbitration acceleration hooks
 Zero-wait-state, microprocessor-to-PCI write interface for high performance graphics
 Built-in PCI bus arbiter with support for up to five masters
 Microprocessor-to-PCI memory write posting with 5-Dword-deep buffers
 Converts back-to-back sequential microprocessor-to-PCI memory write to PCI burst write
 PCI-to-DRAM posting 18 Dwords
 PCI-to-DRAM up to 100+ MB/sec bandwidth
 Multitransaction timer to support multiple short PCI transactions within one PCI ARB cycle
 PCI 2.2/2.3 compliant

4 Technical Information Manual

Chapter 2. System board features

 Delayed transaction

 PCI parity checking and generation support

IDE bus master interface

The system board incorporates a PCI-to-IDE interface that complies with the

Extensions

The
PCI 2.1 compliant. It connects directly to the PCI bus and is designed to allow concurrent operations on
the PCI bus and IDE bus. The chip set is capable of supporting PIO mode 0–4 devices and IDE DMA
mode 0–3 devices, ATA 66 transfers up to 66 Mbytes/sec.

The IDE devices receive their power through a four-position power cable containing +5, +12, and ground
voltage. When adding devices to the IDE interface, one device is designated as the master device and
another is designated as the slave or subordinate device. These designations are determined by switches
or jumpers on each device. There are two IDE ports, one designated 'Primary' and the other 'Secondary,'
allowing for up to four devices to be attached. The total number of physical IDE devices is dependent on
the mechanical package to a maximum of four.

For the IDE interface, no resource assignments are given in the system memory or the direct memory
access (DMA) channels. For information on the resource assignments, see “Input/output address map” on
page 36 and Figure 36 on page 40 (for IRQ assignments).

.

bus master

for the IDE interface is integrated into the I/O hub of the Intel 810 chipset. The chip set is

AT Attachment Interface with

USB interface

Universal serial bus (USB) technology is a standard feature of the computer. The system board provides
the USB interface with two connectors integrated into the ICH (I/O controller hub) in the chip set. A
USB-enabled device can attach to each connector, and if that device is a hub, multiple peripherals can
attach to the hub and be used by the system. The USB connectors use Plug and Play technology for
installed devices. The speed of the USB is up to 12 Mbps with a maximum of 127 peripherals. The USB
is compliant with Universal Host Controller Interface Guide 1.0.

Features provided by USB technology include:

 Support for hot-pluggable devices
 Support for concurrent operation of multiple devices
 Suitable for different device bandwidths
 Support for up to five meters length from host to hub or from hub to hub
 Guaranteed bandwidth and low latencies appropriate for specific devices
 Wide range of packet sizes
 Limited power to hubs

For information on the connector pin assignments for the USB interface, see “USB port connectors” on
page 33.

Low pin count (LPC) bus

On the system board, the Intel ICH1 bridge provides the interface between the peripheral component
interface (PCI) and LPC buses. The chip set is used to convert PCI bus cycles to ISA bus cycles; the
chip set also includes all the subsystems of the ISA bus, including two cascaded interrupt controllers, two
DMA controllers with four 8-bit and three 16-bit channels, three counters equivalent to a programmable
interval timer, and power management. The PCI bus operates at 33 MHz.

Chapter 2. System board features 5

Chapter 2. System board features

Video subsystem

The video subsystem includes the Intel 810 graphics controller integrated in the Graphics Memory
Controller Hub (GMCH) and 4MB of 100MHz local graphics display cache SDRAM.

Graphics memory controller hub (Super Video Graphics Array)

The video subsystem uses system memory for display buffer, commands, and 3D textures on
AGP-enabled operating systems via Dynamic Video Memory Technology (DVMT). The Intel 810 graphics
controller drivers will adjust the memory footprint depending on available system memory, current desktop
resolution, and presence of the display cache local memory. DVMT employs direct AGP and intelligent
arbitration to dynamically allocate and deallocate memory for textures for applications requiring additional
texture memory.

The operating system requires allocation of up to 1MB of system memory to support legacy VGA. System
properties will display up to 1MB less than physical system memory available to the operating system.

The integrated graphics memory controller hub supports all video graphics array (VGA) modes and is
compliant with super video graphics array (SVGA) modes and Video Electronics Standards Association
(VESA) 1.2. Some of the features are:

 2D and 3D hardware acceleration with hardware cursor
 Integrated 230 MHz RAMDAC for up to 1600x1200 at 85Hz resolution
 Hardware Motion Compensation via Intel HWMC Software Development Kit
 Advanced Power Management (APM)
 Advanced Configuration and Power Interface (ACPI)
 On Now (Suspend to RAM)
 Plug and Play
 VESA Display Data Channel version DDC2B
 GDI, Direct X, and OpenGL v1.1 Application Programming Interfaces

The integrated graphics memory controller subsystem supports the VESA Display Data Channel (DDC)
standard 1.1 and uses DDC1 and DDC2B to determine optimal values during automatic monitor detection.

The video subsystem has the following resource assignments:

Figure 2. Video subsystem resources

Resource Assignment

ROM (hex) C0000–C7FFF (32KB)
RAM (hex) A0000–BFFFF
I/O (hex) 3B0–3BB, 3C0–3DF
IRQ PCI interrupt #A (default assigned to ISA IRQ #1)
DMA None

For further information on resource assignments, see Appendix B, “System address maps” on page 36
and Appendix C, “IRQ and DMA channel assignments” on page 40.

6 Technical Information Manual

Chapter 2. System board features

The PC 300GL supports the following video subsystem modes:

Figure 3. Supported VGA video modes

Mode (hex) Display Mode Screen Resolution Colors Refresh Rate

(Hz)

00 Text 40 x 25 characters B/W 70
01 Text 40 x 25 characters 16 70
02 Text 80 x 25 characters B/W 70
03 Text 80 x 25 characters 16 70
04 Graphics 320 x 200 pixels 4 70
05 Graphics 320 x 200 pixels 4 70
06 Text 640 x 200 pixels 2 70
07 Text 80 x 25 characters Mono 70
0D Graphics 320 x 200 pixels 16 70
0E Graphics 640 x 200 pixels 16 70
0F Graphics 640 x 350 pixels Mono 70
10 Graphics 640 x 350 pixels 16 70
11 Graphics 640 x 480 pixels 2 60
12 Graphics 640 x 480 pixels 16 60
13 Graphics 320 x 200 pixels 256 70

Figure 4 (Page 1 of 3). Supported Enhanced VGA video modes

Mode (hex) Display Mode Screen Resolution Colors Refresh Rate

(Hz)

100 Graphics 640x400 8 70
101 Graphics 640x480 8 60
101 Graphics 640x480 8 70
101 Graphics 640x480 8 72
101 Graphics 640x480 8 75
101 Graphics 640x480 8 85
102 Graphics 800x600 4 60
102 Graphics 800x600 4 72
102 Graphics 800x600 4 75
102 Graphics 800x600 4 85
103 Graphics 800x600 8 60
103 Graphics 800x600 8 70
103 Graphics 800x600 8 75
103 Graphics 800x600 8 85
105 Graphics 1024x768 8 60
105 Graphics 1024x768 8 70
105 Graphics 1024x768 8 75
105 Graphics 1024x768 8 85
107 Graphics 1280x1024 8 60
107 Graphics 1280x1024 8 70
107 Graphics 1280x1024 8 72

Chapter 2. System board features 7

Figure 4 (Page 2 of 3). Supported Enhanced VGA video modes

Mode (hex) Display Mode Screen Resolution Colors Refresh Rate

(Hz)

107 Graphics 1280x1024 8 75
107 Graphics 1280x1024 8 85
108 Graphics NS 70
109 Text 132x25 chars 4 70
10A Text 132x43 chars 4 70
10B Text 132x50 chars 4 70
10C Text 132x60 chars 4 70
110 Graphics 640x480 15 60
110 Graphics NS 72
110 Graphics 640x480 15 75
110 Graphics 640x480 15 85
111 Graphics 640x480 16 60
111 Graphics 640x480 16 70
111 Graphics 640x480 16 72
111 Graphics 640x480 16 75
111 Graphics 640x480 16 85
112 Graphics 640x480 24 60
112 Graphics 640x480 24 70
112 Graphics 640x480 24 72
112 Graphics 640x480 24 75
112 Graphics 640x480 24 85
113 Graphics 800x600 15 56
113 Graphics 800x600 15 60
113 Graphics NS 72
113 Graphics 800x600 15 75
113 Graphics 800x600 15 85
114 Graphics NS 56
114 Graphics 800x600 16 60
114 Graphics 800x600 16 70
114 Graphics 800x600 16 72
114 Graphics 800x600 16 75
114 Graphics 800x600 16 85
115 Graphics NS 56
115 Graphics 800x600 24 60
115 Graphics 800x600 24 70
115 Graphics 800x600 24 72
115 Graphics 800x600 24 75
115 Graphics 800x600 24 85
116 Graphics 1024x768 15 60
116 Graphics NS 70
116 Graphics 1024x768 15 75
116 Graphics 1024x768 15 85

Chapter 2. System board features

8 Technical Information Manual

Chapter 2. System board features

Figure 4 (Page 3 of 3). Supported Enhanced VGA video modes

Mode (hex) Display Mode Screen Resolution Colors Refresh Rate

(Hz)

117 Graphics 1024x768 16 60
117 Graphics 1024x768 16 70
117 Graphics 1024x768 16 72
117 Graphics 1024x768 16 75
117 Graphics 1024x768 16 85
118 Graphics 1024x768 24 60
118 Graphics 1024x768 24 70
118 Graphics 1024x768 24 72
118 Graphics 1024x768 24 75
118 Graphics 1024x768 24 85
119 Graphics 1280x1024 15 60
119 Graphics 1280x1024 15 75
119 Graphics NS 85
11A Graphics 1280x1024 16 60
11A Graphics 1280x1024 16 70
11A Graphics 1280x1024 16 72
11A Graphics 1280x1024 16 75
11A Graphics 1280x1024 16 85
11B Graphics 1280x1024 24 60
11B Graphics 1280x1024 24 70
11B Graphics 1280x1024 24 72
11B Graphics 1280x1024 24 75
11B Graphics 1280x1024 24 85

Graphics 600X1200 8 60
Graphics 1600X1200 8 70
Graphics 1600X1200 8 72
Graphics 1600X1200 8 75
Graphics 1600X1200 8 85
Graphics 1600X1200 15 NS
Graphics 1600X1200 16 NS

Monitor support

The video subsystem provides a 15-pin monitor connector on the system board. For information on
connector pin assignments, see Appendix A, “Connector pin assignments” on page 25.

Video memory

The video subsystem has 4MB of 100MHz SDRAM on the system board for 2D and 3D graphics display
cache.

Chapter 2. System board features 9

Audio subsystem

Some PC 300GL models come with an Analog Devices, Inc. integrated audio controller. These models,
which are capable of playing and recording sounds, support DirectX and Microsoft Windows Sound
System applications. SoundBlaster applications are supported in a DOS window only.

The device drivers for the audio controller are on the hard disk drive. The device drivers are also
available on the

The following connectors are available on the audio adapter or integrated audio controller:



Line/Headphone out

speakers or headphones connected to the Line/Headphone out port in order to hear audio from the
system. These speakers must be powered with a built-in amplifier. In general, any powered speakers
designed for use with personal computers can be used with your audio system. These speakers are
available with a wide range of features and power outputs.



Line in



Microphone

Software Selections

port for connecting powered speakers. Your audio system requires a set of

port for connecting musical devices, such as a portable CD-ROM or stereo system.

for connecting a microphone.

CD provided with all models.

Chapter 2. System board features

Super input/output controller

Control of the integrated input/output (I/O) and diskette drive controllers is provided by a single module,
the Super Input/Output Controller. This module supports Plug and Play and controls the following
features:

 Diskette drive interface
 Serial port
 Parallel port

 Keyboard and mouse ports

 General purpose I/O ports

Diskette drive interface

The following is a list of devices that the diskette drive subsystem supports:

 1.44 MB, 3.5 inch diskette drive

 1.44 MB, 3.5 inch, 3-mode drive for Japan (no BIOS support for 3-mode drive)

 1 Mbps, 500 Kbps, or 250 Kbps internal tape drive

One connector is provided on the system board for diskette drive support. For information on the
connector pin assignments, see “Diskette drive connector” on page 32.

Serial ports

Two universal asynchronous receiver/transmitter (UART) serial port are integrated into the system board.
The serial ports include 16-byte data, first-in first-out (FIFO) buffers and have programmable baud rate
generators. The serial ports are NS16450 and PC16550A compatible.

For information on the connector pin assignments, see “Serial port connector” on page 34.
Note: Current loop interface is not supported.
The following figure shows the serial port assignments in the configuration.

10 Technical Information Manual

Chapter 2. System board features

Figure 5. Serial port assignments

Port assignment Address range (hex) IRQ level

Serial 1 03F8–03FF IRQ4
Serial 2 02F8–02FF IRQ3
Serial 3 03E8–03FF IRQ4
Serial 4 02E8–02FF IRQ3

The default setting for the serial port is COM1.

Parallel port

Integrated in the system board is support for extended capabilities port (ECP), enhanced parallel port
(EPP), and standard parallel port (SPP) modes. The modes of operation are selected through the
Configuration/Setup Utility program with the default mode set to ECP. The ECP and EPP modes are
compliant with IEEE 1284.

The following figure shows the parallel port assignments used in the configuration.

Figure 6. Parallel port assignments

Port assignment Address range (hex) IRQ level

Parallel 1 03BC–03BE IRQ7
Parallel 2 0378–037F IRQ5
Parallel 3 0278–027F IRQ5

The default setting for the parallel port is Parallel 1.
The system board has one connector for the parallel port. For information on the connector pin

assignments, see “Parallel port connector” on page 34.

Keyboard and mouse ports

The keyboard and mouse subsystem is controlled by a general purpose 8-bit microcontroller; it is
compatible with 8042AH. The controller consists of 256 bytes of data memory and 2 KB of read-only
memory (ROM).

The controller has two logical devices: one controls the keyboard and the other controls the mouse. The
keyboard has two fixed I/O addresses and a fixed IRQ line and can operate without the mouse. The
mouse cannot operate without the keyboard because, although it has a fixed IRQ line, the mouse relies on
the addresses of the keyboard for operation. For the keyboard and mouse interfaces, no resource
assignments are given in the system memory addresses or DMA channels. For information on the
resource assignments, see “Input/output address map” on page 36 and Figure 36 on page 40 (for IRQ
assignments).

The system board has one connector for the keyboard port and one connector for the mouse port. For
information on the connector pin assignments, see “Mouse and keyboard port connectors” on page 33.

Chapter 2. System board features 11

Chapter 2. System board features

Network connection

Some PC 300GL models are equipped with an Ethernet adapter that supports the Wake on LAN feature.
Features of the optional Ethernet adapter are:

 Operates in shared 10BASE-T or 100BASE-TX environment

 Transmits and receives data at 10 Mbps or 100 Mbps

 RJ-45 connector for LAN attachment

 Operates in symmetrical multiprocessing (SMP) environments

 Wake on LAN support

 Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP) support

Features of the optional token ring adapter are:

 Transmits and receives data at 4 Mbps or 16 Mbps

 RJ-45 and D-shell connectors for LAN attachment

 Wake on LAN support

 Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP) support

Real-time clock and CMOS

The real-time clock is a low-power clock that provides a time-of-day clock and a calendar. The clock
settings are maintained by an external battery source of 3 V DC.

The system uses 242 bytes of memory to store complementary metal-oxide semiconductor (CMOS)
memory. Moving a jumper on the system board erases CMOS memory.

To locate the battery, see “System board, types 6268, 6278, and 6288” on page 13.

Flash EEPROM

The system board uses a 2 MB flash electrically erasable, programmable, read-only memory (EEPROM)
to store the basic input/output system (BIOS), video BIOS, IBM logo, Configuration/Setup Utility, and Plug
and Play data.

If necessary, the EEPROM can be easily updated using a stand-alone utility program that is available on a

3.5-inch diskette.

Expansion adapters

Each PCI-expansion connector is a 32–bit slot. PCI-expansion connectors support the 32–bit 5 V DC,
local-bus signalling environment that is defined in

PCI Local Bus Specification 2.2

.

The PC 300GL has four PCI slots to support the addition of adapters. For information on installing
adapters, see
connectors” on page 29.

PC 300GL User Guide

. For information on the connector pin assignments, see “PCI

12 Technical Information Manual

Chapter 2. System board features

Physical layout

The system board might look slightly different from the one shown.
Note: A diagram of the system board, including switch and jumper settings, is attached to the underside

of the computer cover.

System board, types 6268, 6278, and 6288

.1/Microprocessor
.2/DIMM 0
.3/DIMM 1
.4/Alert on LAN connector
.5/Secondary EIDE connector
.6/Diskette connector
.7/Primary EIDE connector
.8/Power connector
.9/Fan connector
.1ð/Battery
.11/Wake on LAN connector
.12/PC/PCI legacy audio adapter
.13/Clear CMOS/recovery jumper
.14/PCI adapter slot 4
.15/PCI adapter slot 3
.16/PCI adapter slot 2
.17/Chassis speaker connector
.18/PCI adapter slot 1
.19/CD-ROM connector

Jumper

Jumpers on the system board are used for custom configurations. For the location of the CMOS recovery
jumper, refer to the “System board, types 6268, 6278, and 6288,” above.

Figure 7. BIOS configuration jumper (J7A1)

Pins Description

1 and 2 Normal (Factory default)
2 and 3 Clear CMOS/Password

Cable connectors

Connections for attaching devices are provided on the back of the computer. The connectors are:
 USB (2)

 Mouse
 Keyboard
 Serial
 Parallel
 Monitor

 Some models only: Ethernet adapter with an RJ-45 connector
 Integrated Analog Devices, Inc. audio controller with line in, line out, and microphone connectors

Chapter 2. System board features 13

Connector panel

Connectors for features that are integrated into the system board can be identified by a symbol directly
below the connector. Connectors provided by an adapter might not have an identifying symbol. For
pinout details on connectors, see Appendix A, “Connector pin assignments” on page 25.

The connector panel for the tower model:

Chapter 2. System board features

Keyboard

USB

Monitor

Printer

Serial 1

Headphone/

Line Out

Line In

Microphone

1

Mouse

2

Serial 2

The connector panel for the desktop model:

Mouse

USB 2

Parallel

Serial 2

2

1

Serial 1

Headphone/
Line Out

Microphone

Line In

Keyboard

Monitor

USB 1

14 Technical Information Manual

Chapter 3. Physical specifications

Chapter 3. Physical specifications

This section lists the physical specifications for the PC 300GL Types 6268, 6278, and 6288. The PC
300GL has four expansion slots and four drive bays.

Notes:

 The maximum altitude, 2133.6 m (7000 ft.), is the maximum altitude at which the specified air

temperatures apply. At higher altitudes, the maximum air temperatures are lower than those
specified.

 The PC 300GL computers comply with FCC Class B.

PC 300GL — desktop

Dimensions

 Height: 138 mm (5.43 in.)
 Width: 400 mm (15.75 in.)
 Depth: 429 mm (16.9 in.)

Weight

 Minimum configuration as shipped: 9.53 kg (21 lb)
 Maximum configuration: 10.4 kg (23 lb)

Environment

 Air temperature:

– System on: 10° to 35°C (50° to 95°F)
– System off: 10° to 43°C (50° to 110°F)

 Humidity:

– System on: 8% to 80%
– System off: 8% to 80%

 Maximum altitude: 2134 m (7000 ft)

Electrical input

 Input voltage:

– Low range:

- Minimum: 90 V ac

- Maximum: 137 V ac

- Input frequency range: 57-63 Hz

- Voltage switch setting: 115 V

– High range:

- Minimum: 180 V ac

- Maximum: 265 V ac

- Input frequency range: 47-53 Hz

- Voltage switch setting: 230 V

– Input kilovolt-amperes (kVA) (approximately):

- Minimum configuration as shipped: 0.08 kVA

- Maximum configuration: 0.51 kVA

Note: Power consumption and heat output vary depending

on the number and type of optional features installed
and the power-management optional features in use.

Heat output

 Approximate heat output in British thermal units (Btu) per

hour:

– Minimum configuration: 256 Btu/hr (75 watts)
– Maximum configuration: 706 Btu/hr (207 watts)

Airflow

 Approximately 0.5 cubic meters per minute (18 cubic feet

per minute)

Acoustical noise-emission values

 Average sound-pressure levels:

– At operator position:

- Idle: 38 dBA

- Operating: 43 dBA

– At bystander position–1 meter (3.3 ft):

- Idle: 33 dBA

- Operating: 37 dBA

 Declared (upper limit) sound power levels:

– Idle: 4.8 bels
– Operating: 5.1 bels

Note: These levels were measured in controlled acoustical
environments according to procedures specified by the
American National Standards Institute (ANSI) S12.10 and
ISO 7779, and are reported in accordance with ISO 9296.
Actual sound-pressure levels in your location might exceed
the average values stated because of room reflections and
other nearby noise sources. The declared sound power
levels indicate an upper limit, below which a large number
of computers will operate.

Note: PC 300GL computers do not support IDE expansion adapters or the IBM PCMCIA adapter for PCI.

 Copyright IBM Corp. September 1999 15

PC 300GL — tower

Chapter 3. Physical specifications

Dimensions

 Height: 383 mm (15.1 in.)
 Width: 192 mm (7.6 in.)
 Depth: 378 mm (14.9 in.)

Weight

 Minimum configuration as shipped: 8.30 kg (18.3 lb)
 Maximum configuration: 10.2 kg (22.5 lb)

Environment

 Air temperature:

– System on: 10° to 35°C (50° to 95°F)
– System off: 10° to 43°C (50° to 110°F)

 Humidity:

– System on: 8% to 80%
– System off: 8% to 80%

 Maximum altitude: 2134 m (7000 ft)

Electrical input

 Input voltage:

– Low range:

- Minimum: 90 V ac

- Maximum: 137 V ac

- Input frequency range: 57-63 Hz

- Voltage switch setting: 115 V

– High range:

- Minimum: 180 V ac

- Maximum: 265 V ac

- Input frequency range: 47-53 Hz

- Voltage switch setting: 230 V

– Input kilovolt-amperes (kVA) (approximately):

- Minimum configuration as shipped: 0.08 kVA

- Maximum configuration: 0.51 kVA

Note: Power consumption and heat output vary depending

on the number and type of optional features installed
and the power-management optional features in use.

Heat output

 Approximate heat output in British thermal units (Btu) per

hour:

– Minimum configuration: 256 Btu/hr (75 watts)
– Maximum configuration: 706 Btu/hr (207 watts)

Airflow

 Approximately 0.5 cubic meters per minute (18 cubic feet

per minute)

Acoustical noise-emission values

 Average sound-pressure levels:

– At operator position:

- Idle: 38 dBA

- Operating: 43 dBA

– At bystander position–1 meter (3.3 ft):

- Idle: 33 dBA

- Operating: 37 dBA

– Declared (upper limit) sound power levels:

- Idle: 4.8 bels

- Operating: 5.1 bels

Note: These levels were measured in controlled acoustical
environments according to procedures specified by the
American National Standards Institute (ANSI) S12.10 and
ISO 7779, and are reported in accordance with ISO 9296.
Actual sound-pressure levels in your location might exceed
the average values stated because of room reflections and
other nearby noise sources. The declared sound power
levels indicate an upper limit, below which a large number
of computers will operate.

Note: PC 300GL computers do not support IDE expansion adapters or the IBM PCMCIA adapter for PCI.

Cabling requirements for Wake on LAN adapters

The PC 300GL has a 3-pin header on the system board that provides the Auxiliary 5 volts (AUX5) and
wakeup signal connections. Newer Wake on LAN adapters have a single 3-pin header that connects to a
3-pin header on the system board. Some Wake on LAN adapters have two headers: a 3-pin, right-angle
header for providing AUX5, and a 2-pin straight header for connecting the wakeup signal to the system
board. These Wake on LAN adapter options will provide a Y-cable that has the 3-pin system board
connector on one end and splits into the 3-pin and 2-pin connectors required to interface with the card.

16 Technical Information Manual

Chapter 4. Power supply

Chapter 4. Power supply

The power supply requirements are supplied by a 145-watt power supply. The power supply provides

3.3-volt power for the system memory, Super I/O, and core chip set and 5-volt power for PCI adapters, the
hard disk, and diskette drive. Also included is an auxiliary 5-volt (AUX 5) supply to provide power to
power standby circuitry and a Wake on LAN adapter. The power supply converts the AC input voltage
into four DC output voltages and provides power for the following:

 System board
 Adapters
 Internal drives

 Keyboard and auxiliary devices

 USB devices
A logic signal on the power connector controls the power supply; the front panel switch is not directly

connected to the power supply.
The power supply connects to the system board with a 2 x 10 connector.

Power input

The following figure shows the input power specifications. The power supply has a manual switch to
select the correct input voltage.

Figure 8. Power Input Requirements

Specification Measurements

Input voltage, low range 100 (min) to 127 (max) V AC
Input voltage, high range 200 (min) to 240 (max) V AC
Input frequency 50 Hz ± 3 Hz or 60 Hz ± 3 Hz

Power output

The power supply outputs shown in the following figures include the current supply capability of all the
connectors, including system board, DASD, PCI, and auxiliary outputs.

Figure 9. Power Output (145 Watt)

Output voltage Regulation Minimum current Maximum current

+5 volts +5% to −5% 1.5 A 18.0 A
+12 volts +5% to −5% 0.02 A 4.2 A

−12 volts +10% to −10% 0.0 A 0.4 A
+3.3 volts +5% to −5% 0.0 A 10.0 A
+5 volt (auxiliary) +5% to −5% 0.0 A 0.720 A

The total combined 3.3 V and 5 V power should not exceed 100 watts.

 Copyright IBM Corp. September 1999 17

Chapter 4. Power supply

Component outputs

The power supply provides separate voltage sources for the system board and internal storage devices.
The following figures show the approximate power that is provided for specific system components. Many
components draw less current than the maximum shown.

Figure 10. System board

Supply voltage Maximum current Regulation limits

+3.3 V DC 3000 mA +5.0% to −5.0%
+5.0 V DC 4000 mA +5.0% to −4.0%
+12.0 V DC 25.0 mA +5.0% to −5.0%

−12.0 V DC 25.0 mA +10.0% to −9.0%

Figure 11. Keyboard port

Supply voltage Maximum current Regulation limits

+5.0 V DC 275 mA +5.0% to −4.0%

Figure 12. Auxiliary device port

Supply voltage Maximum current Regulation limits

+5.0 V DC 300 mA +5.0% to −4.0%

Figure 13. PCI-bus adapters (Per Slot) either/or

Supply voltage Maximum current Regulation limits

+5.0 V dc 2000 mA +5.0% to −4.0%
+3.3 V dc 3030 mA +5.0% to −4.0%

Note: For each PCI connector, the maximum power consumption is rated at 10 watts for +5 V dc and

+3.3 V dc combined. Typical power budget assumptions use 7.5 watts per adapter. If maximum
power is used, then the overall system configuration will be limited in performance.

Figure 14. USB port

Supply voltage Maximum current Regulation limits

+5.0 V DC 500 mA +5.0% to −4.0%

Figure 15. Internal DASD

Supply voltage Maximum current Regulation limits

+5.0 V DC 1400 mA +5.0% to −5.0%
+12.0 V DC 1500 mA at startup, 400 mA when

active

+5.0% to −5.0%

Figure 16. Video port pin 9

Supply voltage Maximum current Regulation limits

+5.0 V DC 1100mA +5.0% to − 5.0%

18 Technical Information Manual

Chapter 4. Power supply

Note: Some adapters and hard disk drives draw more current than the recommended limits. These

adapters and drives can be installed in the system; however, the power supply will shut down if the
total power used exceeds the maximum power that is available.

Output protection

The power supply protects against output overcurrent, overvoltage, and short circuits. See the power
supply specifications on the previous pages for details.

A short circuit that is placed on any dc output (between outputs or between an output and DC return)
latches all dc outputs into a shutdown state, with no damage to the power supply. If this shutdown state
occurs, the power supply returns to normal operation only after the fault has been removed and the power
switch has been turned off for at least one second.

If an overvoltage fault occurs (in the power supply), the power supply latches all DC outputs into a
shutdown state before any output exceeds 130% of the nominal value of the power supply.

Connector description

The power supply for the PC 300GL has four, 4-pin connectors for internal devices. The total power used
by the connectors must not exceed the amount shown in “Component outputs” on page 18. For
connector pin assignments, see Appendix A, “Connector pin assignments” on page 25.

Chapter 4. Power supply 19

Chapter 5. System software

Chapter 5. System software

This section briefly describes some of the system software included with the computer.

BIOS

The computer uses the IBM basic input/output system (BIOS), which is stored in flash electrically erasable
programmable read-only memory (EEPROM). Some features of the BIOS are:

 PCI support according to PCI BIOS Specification 2.2

 Microsoft's PCI IRQ Routing Table

 Plug and Play support according to Plug and Play BIOS Specification 1.1a

 Advanced Power Management (APM) support according to APM BIOS Interface Specification 1.2

 Wake on LAN support

 Wake on Ring support

 Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP)

 Startable CD-ROM support
 Flash-over-LAN support

 Alternate Startup Sequence

 IBM Look and Feel – Screen arrangements, etc.

 ACPI (Advanced Configuration and Power Interfaces)

 IDE Logical Block Addressing (LBA support)

 LSA 2.0 support

 Bootable CD ROM support
 LS120 support

 DM BIOS 2.1 (DMI 2.0 compliant)
 PC98 compliant

Plug and Play

Support for Plug and Play conforms to the following:

 Plug and Play BIOS Specification 1.1a and 1.0

 Plug and Play BIOS Extension Design Guide 1.0

 Plug and Play BIOS Specification, Errata, and Clarifications 1.0

 Guide to Integrating the Plug and Play BIOS Extensions with system BIOS 1.2

 Plug and Play Kit for DOS and Windows

POST

IBM power-on self-test (POST) code is used. Also, initialization code is included for the on-board system
devices and controllers.

POST error codes include text messages for determining the cause of an error. For more information, see
Appendix D, “Error codes” on page 41.

20  Copyright IBM Corp. September 1999

Chapter 5. System software

Configuration/Setup Utility program

The Configuration/Setup Utility program provides menus for selecting options for devices, I/O ports, date
and time, system security, start options, advanced setup, and power management.

More information on using the Configuration/Setup Utility program is provided in

PC 300GL User Guide

.

Advanced Power Management (APM)

The PC 300GL computers come with built-in energy-saving capabilities. Advanced Power Management
(APM) is a feature that reduces the power consumption of systems when they are not being used. When
enabled, APM initiates reduced-power modes for the monitor, microprocessor, and hard disk drive after a
specified period of inactivity.

The BIOS supports APM 1.2. This enables the system to enter a power-managed state, which reduces
the power drawn from the AC wall outlet. Advanced Power Management is enabled through the
Configuration/Setup Utility program and is controlled by the individual operating system.

For more information on APM, see

PC 300GL User Guide

and

Understanding Your Personal Computer

.

Advanced Configuration and Power Interface

Advanced Configuration and Power Interface (ACPI) BIOS mode enables the operating system to control
the power management features of your computer. Not all operating systems support ACPI BIOS mode.
See your operating system documentation to determine if ACPI is supported. ACPI is enabled by default
if your computer comes with Windows 98 preinstalled.

Flash update utility program

The flash update utility program is a stand-alone program to support flash updates. This utility program
updates the BIOS code in flash and the Machine Readable Information (MRI) to different languages.

The flash update utility program is available on a 3.5 inch diskette.

Diagnostic program

The diagnostic program that comes with PC 300PL and PC 300GL computers is provided as a startable

IBM Enhanced Diagnostic

operating system. The user interface for running the diagnostics and utilities is provided by WaterGate
Software's PC-Doctor. It can also be downloaded from
http://www.ibm.com/pc/support/desktop/desktop_support.html on the World Wide Web. For more
information on this diagnostic program, see

diskette image on the IBM

PC 300GL User Guide

Software Selection

.

CD. It runs independently of the

Chapter 5. System software 21

Chapter 6. System compatibility

Chapter 6. System compatibility

This chapter discusses some of the hardware, software, and BIOS compatibility issues for the computer.
Refer to

Hardware compatibility

This section discusses hardware, software, and BIOS compatibility issues that must be considered when
designing application programs.

Many of the interfaces are the same as those used by the IBM Personal Computer AT. In most cases,
the command and status organization of these interfaces is maintained.

The functional interfaces are compatible with the following interfaces:

 Intel 8259 interrupt controllers (edge-triggered mode)

 National Semiconductor NS16450 and NS16550A serial communication controllers

Compatibility Report

for a list of compatible hardware and software options.

 Motorola MC146818 Time of Day Clock command and status (CMOS reorganized)

 Intel 8254 timer, driven from a 1.193 MHz clock (channels 0, 1, and 2)

 Intel 8237 DMA controller, except for the Command and Request registers and the Rotate and Mask

functions; the Mode register is partially supported

 Intel 8272 or 82077 diskette drive controllers

 Intel 8042 keyboard controller at addresses hex 0060 and hex 0064

 All video standards using VGA, EGA, CGA, MDA, and Hercules modes

 Parallel printer ports (Parallel 1, Parallel 2, and Parallel 3) in compatibility mode

Use the above information to develop application programs. Whenever possible, use the BIOS as an
interface to hardware to provide maximum compatibility and portability of applications among systems.

Hardware interrupts

Hardware interrupts are level-sensitive for PCI interrupts. The interrupt controller clears its in-service
register bit when the interrupt routine sends an End-of-Interrupt (EOI) command to the controller. The EOI
command is sent regardless of whether the incoming interrupt request to the controller is active or
inactive.

The interrupt-in-progress latch is readable at an I/O-address bit position. This latch is read during the
interrupt service routine and might be reset by the read operation or it might require an explicit reset.

Note: For performance and latency considerations, designers might want to limit the number of devices

sharing an interrupt level.

With level-sensitive interrupts, the interrupt controller requires that the interrupt request be inactive at the
time the EOI command is sent; otherwise, a new interrupt request will be detected. To avoid this, a
level-sensitive interrupt handler must clear the interrupt condition (usually by a read or write operation to
an I/O port on the device causing the interrupt). After processing the interrupt, the interrupt handler:

1. Clears the interrupt

2. Waits one I/O delay

22  Copyright IBM Corp. September 1999

Chapter 6. System compatibility

3. Sends the EOI

4. Waits one I/O delay

5. Enables the interrupt through the Set Interrupt Enable Flag command

Hardware interrupt IRQ9 is defined as the replacement interrupt level for the cascade level IRQ2.
Program interrupt sharing is implemented on IRQ2, interrupt hex 0A. The following processing occurs to
maintain compatibility with the IRQ2 used by IBM Personal Computer products:

1. A device drives the interrupt request active on IRQ2 of the channel.

2. This interrupt request is mapped in hardware to IRQ9 input on the second interrupt controller.

3. When the interrupt occurs, the system microprocessor passes control to the IRQ9 (interrupt hex 71)
interrupt handler.

4. This interrupt handler performs an EOI command to the second interrupt controller and passes control
to the IRQ2 (interrupt hex 0A) interrupt handler.

5. This IRQ2 interrupt handler, when handling the interrupt, causes the device to reset the interrupt
request before performing an EOI command to the master interrupt controller that finishes servicing
the IRQ2 request.

Diskette drives and controller

The following figures show the reading, writing, and formatting capabilities of the diskette drive.

Figure 17. 3.5-inch diskette drive reading, writing, and formatting capabilities

Diskette drive type 720 KB Mode 1.44 MB Mode

1.44 MB drive RWF RWF

2.88 MB drive RWF RWF

Copy protection The following methods of copy protection might not work in systems using the 3.5-inch

1.44 MB diskette drive.
 Bypassing BIOS routines

– Data transfer rate: BIOS selects the proper data transfer rate for the media being used.
– Diskette parameter table: Copy protection, which creates its own diskette parameter table, might

not work in these drives.

 Diskette drive controls

– Rotational speed: The time between two events in a diskette drive is a function of the controller.
– Access time: Diskette BIOS routines must set the track-to-track access time for the different types

of media that are used in the drives.

– ‘Diskette change’ signal: Copy protection might not be able to reset this signal.

 Write-current control: Copy protection that uses write-current control does not work, because the

controller selects the proper write current for the media that is being used.

Hard disk drives and controller

Reading from and writing to the hard disk is initiated in the same way as in IBM Personal Computer
products; however, new functions are supported.

Chapter 6. System compatibility 23

Chapter 6. System compatibility

Software compatibility

To maintain software compatibility, the interrupt polling mechanism that is used by IBM Personal Computer
products is retained. Software that interfaces with the reset port for the IBM Personal Computer
positive-edge interrupt sharing (hex address 02Fx or 06Fx, where x is the interrupt level) does not create
interference.

Software interrupts

With the advent of software interrupt sharing, software interrupt routines must daisy chain interrupts. Each
routine must check the function value, and if it is not in the range of function calls for that routine, it must
transfer control to the next routine in the chain. Because software interrupts are initially pointed to
address 0:0 before daisy chaining, check for this case. If the next routine is pointed to address 0:0 and
the function call is out of range, the appropriate action is to set the carry flag and do a RET 2 to indicate
an error condition.

Machine-sensitive programs

Programs can select machine specific features, but they must first identify the machine and model type.
IBM has defined methods for uniquely determining the specific machine type. The machine model byte
can be found through Interrupt 15H, Return System Configuration Parameters function (AH)=C0H).

24 Technical Information Manual

Appendix A. Connector pin assignments

Appendix A. Connector pin assignments

The following figures show the pin assignments for various system board connectors.

Monitor connector

5

10 6

15 11

1

Figure 18. Monitor port connector pin assignments

Pin Signal I/O Pin Signal I/O

1 Red O 2 Green O
3 Blue O 4 Monitor ID 2 - Not

used
5 Ground NA 6 Red ground NA
7 Green ground NA 8 Blue ground NA
9 +5 V, used by DDC2B NA 10 Ground NA
11 Monitor ID 0 - Not

used
13 Horizontal sync O 14 Vertical sync O
15 DDC2B clock I/O

Memory connectors

85

I 12 DDC2B serial data I/O

168

I

1

84

Figure 19 (Page 1 of 3). System Memory Connector Pin Assignments

Pin x64 Non-Parity x72 ECC Pin x64 Non-Parity x72 ECC

1 VSS VSS 85 VSS VSS
2 DQ0 DQ0 86 DQ32 DQ32
3 DQ1 DQ1 87 DQ33 DQ33
4 DQ2 DQ2 88 DQ34 DQ34
5 DQ3 DQ3 89 DQ35 DQ35
6 VCC VCC 90 VCC VCC
7 DQ4 DQ4 91 DQ36 DQ36
8 DQ5 DQ5 92 DQ37 DQ37
9 DQ6 DQ6 93 DQ38 DQ38
10 DQ7 DQ7 94 DQ39 DQ39
11 DQ8 DQ8 95 DQ40 DQ40
12 VSS VSS 96 VSS VSS

 Copyright IBM Corp. September 1999 25

Figure 19 (Page 2 of 3). System Memory Connector Pin Assignments

Pin x64 Non-Parity x72 ECC Pin x64 Non-Parity x72 ECC

13 DQ9 DQ9 97 DQ41 DQ41
14 DQ10 DQ10 98 DQ42 DQ42
15 DQ11 DQ11 99 DQ43 DQ43
16 DQ12 DQ12 100 DQ44 DQ44
17 DQ13 DQ13 101 DQ45 DQ45
18 VCC VCC 102 VCC VCC
19 DQ14 DQ14 103 DQ46 DQ46
20 DQ15 DQ15 104 DQ47 DQ47
21 NC CB0 105 NC CB4
22 NC CB1 106 NC CB5
23 VSS VSS 107 VSS VSS
24 NC NC 108 NC NC
25 NC NC 109 NC NC
26 VCC VCC 110 VCC VCC
27 /WE /WE0 111 /CAS /CAS
28 DQMB0 DQMB0 112 DQMB4 DQMB4
29 DQMB1 DQMB1 113 DQMB5 DQMB5
30 /S0 /S0 114 NC /S1
31 DU NC 115 /RAS /RAS
32 VSS VSS 116 VSS VSS
33 A0 A0 117 A1 A1
34 A2 A2 118 A3 A3
35 A4 A4 119 A5 A5
36 A6 A6 120 A7 A7
37 A8 A8 121 A9 A9
38 A10/AP A10/AP 122 BA0 BA0
39 NC BA1 123 NC A11
40 VCC VCC 124 VCC VCC
41 VCC VCC 125 CK1 CK1
42 CK0 CK0 126 A12 A12
43 VSS VSS 127 VSS VSS
44 DU NC 128 CKE0 CKE0
45 /S2 /S2 129 NC /S3
46 DQMB2 DQMB2 130 DQMB6 DQMB6
47 DQMB3 DQMB3 131 DQMB7 DQMB7
48 DU NC 132 A13 A13
49 VCC VCC 133 VCC VCC
50 NC NC 134 NC NC
51 NC NC 135 NC NC
52 NC CB2 136 NC CB6
53 NC CB3 137 NC CB7
54 VSS VSS 138 VSS VSS
55 DQ16 DQ16 139 DQ48 DQ48

Appendix A. Connector pin assignments

26 Technical Information Manual

Appendix A. Connector pin assignments

Figure 19 (Page 3 of 3). System Memory Connector Pin Assignments

Pin x64 Non-Parity x72 ECC Pin x64 Non-Parity x72 ECC

56 DQ17 DQ17 140 DQ49 DQ49
57 DQ18 DQ18 141 DQ50 DQ50
58 DQ19 DQ19 142 DQ51 DQ51
59 VCC VCC 143 VCC VCC
60 DQ20 DQ20 144 DQ52 DQ52
61 NC NC 145 NC NC
62 NC NC 146 NC NC
63 NC CKE1 147 NC NC
64 VSS VSS 148 VSS VSS
65 DQ21 DQ21 149 DQ53 DQ53
66 DQ22 DQ22 150 DQ54 DQ54
67 DQ23 DQ23 151 DQ55 DQ55
68 VSS VSS 152 VSS VSS
69 DQ24 DQ24 153 DQ56 DQ56
70 DQ25 DQ25 154 DQ57 DQ57
71 DQ26 DQ26 155 DQ58 DQ58
72 DQ27 DQ27 156 DQ59 DQ59
73 VCC VCC 157 VCC VCC
74 DQ28 DQ28 158 DQ60 DQ60
75 DQ29 DQ29 159 DQ61 DQ61
76 DQ30 DQ30 160 DQ62 DQ62
77 DQ31 DQ31 161 DQ63 DQ63
78 VSS VSS 162 VSS VSS
79 CK2 CK2 163 CK3 CK3
80 NC NC 164 NC NC
81 NC NC 165 SA0 SA0
82 SDA SDA 166 SA1 SA1
83 SCL SCL 167 SA2 SA2
84 VCC VCC 168 VCC VCC

Figure 20 (Page 1 of 3). System memory connector pin input/output

Pin Signal Name I/O Pin Signal Name I/O

1 GND N/A 85 GND N/A
2 MD0 I/O 86 MD32 I/O
3 MD1 I/O 87 MD33 I/O
4 MD2 I/O 88 MD34 I/O
5 MD3 I/O 89 MD35 I/O
6 VDD I/O 90 VDD N/A
7 MD4 I/O 91 MD36 N/A
8 MD5 I/O 92 MD37 I/O
9 MD6 I/O 93 MD38 I/O
10 MD7 I/O 94 MD39 I/O
11 MD8 (PAR0) I/O 95 MD40 I/O

Appendix A. Connector pin assignments 27

Figure 20 (Page 2 of 3). System memory connector pin input/output

Pin Signal Name I/O Pin Signal Name I/O

12 GND N/A 96 GND N/A
13 MD9 I/O 97 MD41 I/O
14 MD10 I/O 98 MD42 I/O
15 MD11 I/O 99 MD43 I/O
16 MD12 I/O 100 MD44 I/O
17 MD13 I/O 101 MD45 I/O
18 VDD N/A 102 VDD N/A
19 MD14 I/O 103 MD46 I/O
20 MD15 I/O 104 MD47 I/O
21 NC I/O 105 NC I/O
22 NC I/O 106 NC I/O
23 GND I/O 107 GND N/A
24 NC N/A 108 NC N/A
25 NC N/A 109 NC N/A
26 VDD N/A 110 VDD N/A
27 WE# I 111 CAS# N/A
28 DQMB0# I 112 DQMB4# I
29 DQMB1# I 113 DQMB4# I
30 S0# I 114 S1# I
31 OE0# i 115 RAS# N/A
32 GND N/A 116 GND N/A
33 A0 I 117 A1 I
34 A2 I 118 A3 I
35 A4 I 119 A5 I
36 A6 I 120 A7 I
37 A8 I 121 A9 I
38 A10/AP I 122 A11 I
39 NC BA1 123 NC A11
40 VDD N/A 124 VDD N/A
41 NC N/A 125 CK1 N/A
42 CK0 N/A 126 A14 O
43 GND N/A 127 GND N/A
44 OE2# I 128 CKE0 N/A
45 S2# I 129 S3# I
46 DQMB2# I 130 DQMB6# I
47 DQMB3# I 131 DQMB7# I
48 WE2# I 132 A15 I
49 VDD N/A 133 VDD N/A
50 NC N/A 134 NC N/A
51 NC N/A 135 NC N/A
52 NC I/O 136 NC I/O
53 NC I/O 137 NC I/O
54 GND NA 138 GND N/A

Appendix A. Connector pin assignments

28 Technical Information Manual

Appendix A. Connector pin assignments

Figure 20 (Page 3 of 3). System memory connector pin input/output

Pin Signal Name I/O Pin Signal Name I/O

55 MD16 I/O 139 MD48 I/O
56 MD17 I/O 140 MD49 I/O
57 MD18 I/O 141 MD50 I/O
58 MD19 I/O 142 MD51 I/O
59 VDD N/A 143 VDD N/A
60 MD20 I/O 144 MD52 I/O
61 CKE1 N/A 145 NC N/A
62 VREF N/A 146 VREF N/A
63 (CKE1)* N/A 147 NC N/A
64 GND N/A 148 GND N/A
65 MD21 I/O 149 MD53 I/O
66 MD22 I/O 150 MD54 I/O
67 MD23 I/O 151 MD55 I/O
68 GND N/A 152 GND N/A
69 MD24 I/O 153 MD56 I/O
70 MD25 I/O 154 MD57 I/O
71 MD26 I/O 155 MD58 I/O
72 MD27 I/O 156 MD59 I/O
73 VDD N/A 157 VDD N/A
74 MD28 I/O 158 MD60 I/O
75 MD29 I/O 159 MD61 I/O
76 MD30 I/O 160 MD62 I/O
77 MD31 I/O 161 MD63 I/O
78 GND N/A 162 GND N/A
79 CK2 O 163 CK3 O
80 NC N/A 164 NC N/A
81 NC O 165 SA0 O
82 SDA O 166 SA1 O
83 SCL O 167 SA0 O
84 VDD N/A 168 VDD N/A

PCI connectors

A1

A2

B1

B2

A62

B62

Figure 21. PCI bus connector

Figure 22 (Page 1 of 3). PCI connector pin assignments

Pin Signal I/O Pin Signal I/O

A1 TRST# O B1 −12 V DC NA

Appendix A. Connector pin assignments 29

Figure 22 (Page 2 of 3). PCI connector pin assignments

Pin Signal I/O Pin Signal I/O

A2 +12 V DC NA B2 TCK O
A3 TMS O B3 Ground NA
A4 TDI O B4 TDO I
A5 +5 V DC NA B5 +5 V DC NA
A6 INTA# I B6 +5 V DC NA
A7 INTC# I B7 INTB# I
A8 +5 V DC NA B8 INTD# I
A9 Reserved NA B9 PRSNT1# I
A10 +5 V DC (I/O) NA B10 Reserved NA
A11 Reserved NA B11 PRSNT2 I
A12 Ground NA B12 Ground NA
A13 Ground NA B13 Ground NA
A14 +3.3V AUX NA B14 Reserved NA
A15 RST# O B15 Ground NA
A16 +5 V DC (I/O) NA B16 CLK O
A17 GNT# O B17 Ground NA
A18 Ground NA B18 REQ# I
A19 PCIPME NA B19 +5 V DC (I/O) NA
A20 Address/Data 30 I/O B20 Address/Data 31 I/O
A21 +3.3 V DC NA B21 Address/Data 29 I/O
A22 Address/Data 28 I/O B22 Ground NA
A23 Address/Data 26 I/O B23 Address/Data 27 I/O
A24 Ground I/O B24 Address/Data 25 NA
A25 Address/Data 24 I/O B25 +3.3 V DC NA
A26 IDSEL O B26 C/BE 3# I/O
A27 +3.3 V DC NA B27 Address/Data 23 I/O
A28 Address/Data 22 I/O B28 Ground NA
A29 Address/Data 20 I/O B29 Address/Data 21 I/O
A30 Ground I/O B30 Address/Data 19 NA
A31 Address/Data 18 I/O B31 +3.3 V DC NA
A32 Address/Data 16 I/O B32 Address/Data 17 I/O
A33 +3.3 V DC NA B33 C/BE 2# I/O
A34 FRAME# I/O B34 Ground NA
A35 Ground NA B35 IRDY# I/O
A36 TRDY# I/O B36 +3.3 V DC NA
A37 Ground NA B37 DEVSEL# I/O
A38 STOP# I/O B38 Ground NA
A39 +3.3 V DC NA B39 LOCK# I/O
A40 SDONE I/O B40 PERR# I/O
A41 SBO# I/O B41 +3.3 V DC NA
A42 Ground NA B42 SERR# I/O
A43 +3.3 V DC NA B43 +3.3 V DC NA
A44 C/BE(1)# I/O B44 C/BE 1# I/O

Appendix A. Connector pin assignments

30 Technical Information Manual

Appendix A. Connector pin assignments

Figure 22 (Page 3 of 3). PCI connector pin assignments

Pin Signal I/O Pin Signal I/O

A45 Address/Data 14 I/O B45 Address/Data 14 I/O
A46 Ground NA B46 Ground NA
A47 Address/Data 12 I/O B47 Address/Data 12 I/O
A48 Address/Data 10 I/O B48 Address/Data 10 I/O
A49 Ground NA B49 Ground NA
A50 Key NA B50 Key NA
A51 Key NA B51 Key NA
A52 Address/Data 8 I/O B52 Address/Data 8 I/O
A53 Address/Data 7 I/O B53 Address/Data 7 I/O
A54 +3.3 V DC NA B54 +3.3 V DC NA
A55 Address/Data 5 I/O B55 Address/Data 5 I/O
A56 Address/Data 3 I/O B56 Address/Data 3 I/O
A57 Ground NA B57 Ground NA
A58 Address/Data 1 I/O B58 Address/Data 1 I/O
A59 +5 V DC (I/O) NA B59 +5 V DC (I/O) NA
A60 ACK64# I/O B60 ACK64# I/O
A61 +5 V DC NA B61 +5 V DC NA
A62 +5 V DC NA B62 +5 V DC NA

IDE connectors

2

1

40

39

Figure 23 (Page 1 of 2). IDE connector pin assignments

Pin Signal I/O Pin Signal I/O

1 RESET O 21 NC NA
2 Ground NA 22 Ground NA
3 Data bus bit 7 I/O 23 I/O write O
4 Data bus bit 8 I/O 24 NC NA
5 Data bus bit 6 I/O 25 I/O read O
6 Data bus bit 9 I/O 26 Ground NA
7 Data bus bit 5 I/O 27 I/O channel ready I
8 Data bus bit 10 I/O 28 ALE O
9 Data bus bit 4 I/O 29 NC NA
10 Data bus bit 11 I/O 30 Ground NA
11 Data bus bit 3 I/O 31 IRQ I
12 Data bus bit 12 I/O 32 CS16# I
13 Data bus bit 2 I/O 33 SA1 O
14 Data bus bit 13 I/O 34 PDIAG# I

Appendix A. Connector pin assignments 31

Figure 23 (Page 2 of 2). IDE connector pin assignments

Pin Signal I/O Pin Signal I/O

15 Data bus bit 1 I/O 35 SA0 O
16 Data bus bit 14 I/O 36 SA2 O
17 Data bus bit 0 I/O 37 CS0# O
18 Data bus bit 15 I/O 38 CS1 O
19 Ground NA 39 Active# I
20 Key (Reserved) NA 40 Ground NA

Diskette drive connector

Figure 24. Diskette Drive Connector Pin Assignments

Pin Signal I/O Pin Signal I/O

1 Drive 2 installed # I 2 High density select O
3 Not connected NA 4 Not connected NA
5 Ground NA 6 Data rate 0 NA
7 Ground NA 8 Index# I
9 Reserved NA 10 Motor enable 0# O
11 Ground NA 12 Drive select 1# O
13 Ground NA 14 Drive select 0# O
15 Ground NA 16 Motor enable 1# O
17 MSEN1 I 18 Direction in# O
19 Ground NA 20 Step# O
21 Ground NA 22 Write data# O
23 Ground NA 24 Write enable# O
25 Ground NA 26 Track0# I
27 MSEN0 I 28 Write protect# I
29 Ground NA 30 Read data# I
31 Ground NA 32 Head 1 select# O
33 Data rate 1 NA 34 Diskette change# I

Appendix A. Connector pin assignments

Power supply connector

Figure 25 (Page 1 of 2). Power Supply Connector Pin Assignments

Pin Signal Name Pin Signal Name

1 +3.3 V 11 +3.3 V
2 +3.3 V 12 −12 V
3 Ground 13 Ground
4 +5 V 14 ON/OFF
5 Ground 15 Ground
6 +5 V 16 Ground
7 Ground 17 Ground
8 PWR GOOD 18 Reserved

32 Technical Information Manual

Appendix A. Connector pin assignments

Figure 25 (Page 2 of 2). Power Supply Connector Pin Assignments

Pin Signal Name Pin Signal Name

9 +5 V AUX 19 +5 V
10 +12 V 20 +5 V

Modem/Ring Wakeup and Wake on LAN connectors

Figure 26. J13 Modem/Ring Wakeup Connector Pin Assignments

Pin Description

1 Internal Modem Wake Up on Ring
2 Ground

Figure 27. J22 Wake on LAN Connector Pin Assignments

Pin Description

1 +5v AUX
2 Ground
3 Internal Wake on LAN

USB port connectors

1

3

Figure 28. USB Port Connector Pin Assignments

Pin Signal

1 VCC
2 -Data
3 +Data
4 Ground

Mouse and keyboard port connectors

6

4

2

2

4

5
3

1

Figure 29 (Page 1 of 2). Mouse port connector pin assignments

Pin Signal I/O Pin Signal I/O

1 Data I/O 2 Reserved I/O
3 Ground NA 4 +5 V DC NA

Appendix A. Connector pin assignments 33

Figure 29 (Page 2 of 2). Mouse port connector pin assignments

Pin Signal I/O Pin Signal I/O

5 Clock I/O 6 Reserved NA

Figure 30. Keyboard port connector pin assignments

Pin Signal I/O Pin Signal I/O

1 Keyboard data I/O 2 Mouse data I/O
3 Ground NA 4 +5 V DC NA
5 Keyboard clock I/O 6 Mouse clock I/O

Serial port connector

Appendix A. Connector pin assignments

1

69

5

Figure 31. Serial Port Connector Pin Assignments

Pin Signal I/O Pin Signal I/O

1 Data carrier detect I 2 Receive data# I
3 Transmit data# O 4 Data terminal read O
5 Ground NA 6 Data set ready I
7 Request to send O 8 Clear to send I
9 Ring indicator I

Parallel port connector

13

25

Figure 32 (Page 1 of 2). Parallel port connector pin assignments

Pin Signal I/O Pin Signal I/O

1 STROBE# I/O 2 Data bit 0 I/O
3 Data bit 1 I/O 4 Data bit 2 I/O
5 Data bit 3 I/O 6 Data bit 4 I/O
7 Data bit 5 I/O 8 Data bit 6 I/O
9 Data bit 7 I/O 10 ACK# I
11 BUSY I 12 PE I
13 SLCT I 14 AUTO FD XT# O
15 ERROR# I 16 INIT# O
17 SLCT IN# O 18 Ground NA
19 Ground NA 20 Ground NA
21 Ground NA 22 Ground NA

1

14

34 Technical Information Manual

Appendix A. Connector pin assignments

Figure 32 (Page 2 of 2). Parallel port connector pin assignments

Pin Signal I/O Pin Signal I/O

23 Ground NA 24 Ground NA
25 Ground NA

Appendix A. Connector pin assignments 35

Appendix B. System address maps

Appendix B. System address maps

System memory map

The first 640 KB of system board RAM is mapped starting at address hex 0000000. A 256 byte area and
a 1 KB area of this RAM are reserved for BIOS data areas. Memory can be mapped differently if POST
detects an error.

Figure 33. System memory map

Address range (decimal) Address range (hex) Size Description

0 K – 512 K 00000–7FFFF 512 KB Conventional
512 K – 639 K 80000–9FBFF 127 KB Extended conventional
639 K – 640 K 9FC00–9FFFF 1 KB Extended BIOS data
640 K – 767 K A0000–BFFFF 128 KB Dynamic video memory

display cache

768 K – 800 K C0000 to C7FFF 32 KB Video ROM BIOS

(shadowed)

800 K – 896 K C8000–DFFFF 96 KB PCI space, available to

adapter ROMs

896 K – 1 MB E0000–FFFFF 128 KB System ROM BIOS (main

memory shadowed)
1 MB – 16 MB 100000–FFFFFF 15 MB PCI Space
16 MB – 4095.872 MB 1000000–FFF7FFFF 4079.5 MB MB PCI Space (positive decode)
FFF80000 –FFFFFFFF 512 KB System ROM BIOS

Input/output address map

The following figure lists resource assignments for the I/O address map. Any addresses that are not
shown are reserved.

Figure 34 (Page 1 of 3). I/O address map

Address (Hex) Size Description

0000–000F 16 bytes DMA 1
0010–001F 16 bytes General I/O Locations — available to PCI bus
0020–0021 2 bytes Interrupt controller 1
0022–003F 30 bytes General I/0 locations — available to PCI bus
0022–002F 2 bytes SMC SIO index/data register
0040–0043 4 bytes Counter/timer 1
0044–00FF 28 bytes General I/0 locations — available to PCI bus
0060 1 byte Keyboard controller byte - reset IRQ
0061 1 byte PIIX4, System port B
0064 1 byte Keyboard controller, CMD/STAT byte
0070, bit 7 1 bit Enable NMI
0070, bits 6:0 1 bit Real time clock, address
0071 1 byte Real time clock, data
0072–007F 14 bytes General I/O locations — available to PCI bus

36  Copyright IBM Corp. September 1999

Appendix B. System address maps

Figure 34 (Page 2 of 3). I/O address map

Address (Hex) Size Description

0080 1 byte POST checkpoint register during POST only
008F 1 byte Refresh page register
0080–008F 16 bytes ICH1, DMA page registers
0090–0091 15 bytes General I/O locations — available to PCI bus
0092 1 byte PS/2 keyboard controller registers
0093–009F 15 bytes General I/O locations
00A0–00A1 2 bytes Interrupt controller 2
00A2–00BF 30 bytes APM control
00C0–00DF 31 bytes DMA 2
00E0–00EF 16 bytes General I/O locations — available to PCI bus
00F0 1 byte BX, Coprocessor Error Register
00F1–016F 127 bytes General I/O locations — available to PCI bus
0170–0177 8 bytes Secondary IDE channel
01F0–01F7 8 bytes Primary IDE channel
0200–0207 8 bytes Available
0220–0227 8 bytes SMC 37C673, Serial port 3 or 4
0228–0277 80 bytes General I/O locations — available to PCI bus
0278–027F 8 bytes SMC 27C673, LPT3
0280–02E7 102 bytes Available
02E8–02EF 8 bytes SMC PC37C673, Serial port 3 or 4
02F8–02FF 8 bytes COM2
0338–033F 8 bytes SMC PC37C673, Serial port 3 or 4
0340–036F 48 bytes Available
0372–0375 4 bytes Available
0376–0377 2 bytes IDE channel 1 command
0378–037F 8 bytes LPT2
0380–03B3 52 bytes Available
03B4–03B7 4 bytes Video
03BA 1 byte Video
03BC–03BE 16 bytes LPT1
03C0–03CF 16 bytes Video
03D4–03D7 4 bytes Video
03DA 1 byte Video
03D0–03DF 11 bytes Available
03E0–03E7 8 bytes Available
03E8–03EF 8 bytes COM3 or COM4
03F0–03F5 6 bytes Diskette channel 1
03F6 1 byte Primary IDE channel command port
03F7 (Write) 1 byte Diskette channel 1 command
03F7, bit 7 1 bit Diskette disk change channel
03F7, bits 6:0 7 bits Primary IDE channel status port
03F8–03FF 8 bytes COM1
0400–047F 128 bytes Available

Appendix B. System address maps 37

Figure 34 (Page 3 of 3). I/O address map

Address (Hex) Size Description

0480–048F 16 bytes DMA channel high page registers
0490–0CF7 1912 bytes Available
0CF8–0CFB 4 bytes PCI Configuration address register
0CFC–0CFF 4 bytes PCI Configuration data register
LPTn + 400h 8 bytes ECP port, LPTn base address + hex 400
0CF9 1 byte Turbo and reset control register
0D00–FFFF 62207 bytes Available

DMA I/O address map

The following figure lists resource assignments for the DMA address map. Any addresses that are not
shown are reserved.

Figure 35 (Page 1 of 2). DMA I/O address map

Address (Hex) Description Bits Byte pointer

0000 Channel 0, Memory Address register 00–15 Yes
0001 Channel 0, Transfer Count register 00–15 Yes
0002 Channel 1, Memory Address register 00–15 Yes
0003 Channel 1, Transfer Count register 00–15 Yes
0004 Channel 2, Memory Address register 00–15 Yes
0005 Channel 2, Transfer Count register 00–15 Yes
0006 Channel 3, Memory Address register 00–15 Yes
0007 Channel 3, Transfer Count register 00–15 Yes
0008 Channels 0–3, Read Status/Write Command register 00–07
0009 Channels 0–3, Write Request register 00–02
000A Channels 0–3, Write Single Mask register bits 00–02
000B Channels 0–3, Mode register (write) 00–07
000C Channels 0–3, Clear byte pointer (write) N/A
000D Channels 0–3, Master clear (write)/temp (read) 00–07
000E Channels 0–3, Clear Mask register (write) 00–03
000F Channels 0–3, Write All Mask register bits 00–03
0081 Channel 2, Page Table Address register
0082 Channel 3, Page Table Address register
0083 Channel 1, Page Table Address register
0087 Channel 0, Page Table Address register
0089 Channel 6, Page Table Address register
008A Channel 7, Page Table Address register
008B Channel 5, Page Table Address register
008F Channel 4, Page Table Address/Refresh register 00–07
00C0 Channel 4, Memory Address register 00–15 Yes
00C2 Channel 4, Transfer Count register 00–15 Yes
00C4 Channel 5, Memory Address register 00–15 Yes
00C6 Channel 5, Transfer Count register 00–15 Yes

2
2
2
2
2
2
2

00–07
00–07
00–07
00–07
00–07
00–07
00–07

Appendix B. System address maps

38 Technical Information Manual

Appendix B. System address maps

Figure 35 (Page 2 of 2). DMA I/O address map

Address (Hex) Description Bits Byte pointer

00C8 Channel 6, Memory Address register 00–15 Yes
00CA Channel 6, Transfer Count register 00–15 Yes
00CC Channel 7, Memory Address register 00–15 Yes
00CE Channel 7, Transfer Count register 00–15 Yes
00D0 Channels 4–7, Read Status/Write Command register 00–07
00D2 Channels 4–7, Write Request register 00–02
00D4 Channels 4–7, Write Single Mask register bit 00–02
00D6 Channels 4–7, Mode register (write) 00–07
00D8 Channels 4–7, Clear byte pointer (write) N/A
00DA Channels 4–7, Master clear (write)/temp (read) 00–07
00DC Channels 4–7, Clear Mask register (write) 00–03
00DE Channels 4–7, Write All Mask register bits 00–03
00DF Channels 5–7, 8- or 16-bit mode select 00–07

PCI configuration space map

Bus number (hex) Device number

(hex)

00 00 00 Intel 82810-DC 100 Host bridge
00 01 00 Intel 84440BX VGA graphics
00 1E 00 Intel 82801 PCI–to–PCI bridge
00 1F 00 Intel 82810 PCI–to–LPC bridge
00 1F 1 IDE controller
00 1F 2 USB
00 00 3 Intel 82801 SMBus
00 1F 5 Audio multimedia

Function number
(hex)

Description

2

Upper byte of memory address register.

Appendix B. System address maps

39

Appendix C. IRQ and DMA channel assignments

The following figures list the interrupt request (IRQ) and direct memory access (DMA) channel
assignments.

Figure 36. IRQ channel assignments

IRQ System resource

NMI Critical system error
SMI System management interrupt — power management
0 Reserved (interval timer)
1 Reserved (keyboard)
2 Reserved, Cascade interrupt from slave PIC
3 COM2
4 COM1
5 Available to user
6 Diskette controller
7 LPT1
8 Real-time clock
9 ACPI BIOS
10 Audio
11 Video
12 Mouse port
13 Reserved (math coprocessor)
14 Primary IDE (if present)
15 Secondary IDE (if present)

3
3

3

Appendix C. IRQ and DMA channel assignments

Figure 37. DMA channel assignments

DMA channel Data width System resource

0 8 bits Open
1 8 bits Open
2 8 bits Diskette drive
3 8 bits Parallel port (for ECP or EPP)
4 – Reserved (cascade channel)
5 16 bits Open
6 16 bits Open
7 16 bits Open

3

Default, can be changed to another IRQ.

40  Copyright IBM Corp. September 1999

Appendix D. Error Codes

Appendix D. Error codes

A complete list of POST error codes is provided in

Manual

.

PC 300GL User Guide

and in

Hardware Maintenance

POST error codes

POST error messages appear when POST finds problems with the hardware during power-on or when a
change in the hardware configuration is found. POST error messages are 3-, 4-, 5-, 8-, or 12-character
alphanumeric messages.

POST beep codes

One beep and the appearance of text on the monitor indicate successful completion of POST. More than
one beep indcates that POST detected an error.

A complete list of beep codes is provided in

Hardware Maintenance Manual

.

 Copyright IBM Corp. September 1999 41

Appendix E. Notices and trademarks

Appendix E. Notices and trademarks

References in this publication to IBM products, programs, or services do not imply that IBM intends to
make these available in all countries in which IBM operates. Any reference to an IBM product, program,
or service is not intended to state or imply that only that IBM product, program, or service may be used.
Subject to IBM’s valid intellectual property or other legally protectable rights, any functionally equivalent
product, program, or service may be used instead of the IBM product, program, or service. The evaluation
and verification of operation in conjunction with other products, except those expressly designated by IBM,
are the responsibility of the user.

IBM may have patents or pending patent applications covering subject matter in this document. The
furnishing of this document does not give you any license to these patents. You can send license
inquiries, in writing, to:

IBM Director of Licensing

IBM Corporation

North Castle Drive
Armonk, NY 10504-1785
U.S.A.

Any references in this publication to non-IBM Web sites are provided for convenience only and do not in
any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part
of the materials for this IBM product and use of those Web sites is at your own risk.

The following terms are trademarks of the IBM Corporation in the United States or other countries or both:
Alert on LAN PC 300

IBM PS/2
PC 100 Wake on LAN

Intel, Celeron, LANDesk, and MMX are trademarks of Intel Corporation in the United States, other
countries, or both.

Microsoft, Windows, OnNow, and Windows NT are trademarks of Microsoft Corporation in the United
States, other countries, or both.

Other company, product, and service names may be trademarks or service marks of others.

42  Copyright IBM Corp. September 1999

References



Advanced Power Management (APM) BIOS
Interface Specification 1.2/

Source: Intel Corporation



AT Attachment Interface with Extensions

Source: American National Standard of Accredited
Standards Committee



Extended Capabilities Port: Specification Kit

Source: Microsoft Corporation



Intel Microprocessor and Peripheral Component
Literature

Source: Intel Corporation



PCI BIOS Specification 2.0

Source: PCI Special Interest Group



PCI Local Bus Specification 2.1

Source: PCI Special Interest Group



Plug and Play BIOS Specification 1.1

Source: Microsoft Corporation; available at

http://www.microsoft.com/hwdev



Plug and Play BIOS Specification, Errata and
Clarifications 1.0

Source: Microsoft Corporation



Universal Serial Bus Specifications

Source:



Video Electronics Standards Association 1.2

Source:



AT24RF08A- PCID Specification



Low Pin Count Interface Specification 1.1

http://www.usb.org

http://www.vesa.org

 Copyright IBM Corp. September 1999 43

Index

Index

A

ACPI 21
address map

DMA 38
I/O 36

system memory 36
advanced configuration and power interface 21
advanced power management 21
APM 21
audio 10

B

beep codes 41
BIOS 20
BIOS data areas 36
bus

IDE 5

LPC 5

PCI 4, 12

universal serial bus 5
bypassing BIOS 23

C

Celeron microprocessor with MMX technology 3
chip set 3, 10
clock, real-time 12
CMOS RAM 12
compatibility

hardware 22

software 24
component maximum current 18
configuration/setup utility program 21
connector

DIMM 25

diskette drive 32

IDE 31

keyboard/mouse ports 33

modem/ring wakeup 33

monitor 25

parallel port 34

PCI 29

power supply 32

serial ports 34

USB 33

Wake on LAN 33
controller

diskette drive 10, 23

I/O 10

keyboard/mouse 11

parallel 11

controller

copy protection 23

(continued)

serial 10

D
