IBM FAStT Host Adapter
Installation and User's Guide
IBM
IBM
IBM FAStT Host Adapter
Installation and User's Guide
Note: Before using this information and the product it supports, be sure to read the general information under Appendix D,
“Warranty information” on page 35 and Appendix E, “Notices” on page 47.
Fourth Edition (June 2002)
Copyright International Business Machines Corporation 1998, 2002. All rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to
restrictions set forth in GSA ADP Schedule Contract with IBM Corp.
Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
About this book ..................................... ix
How this book is organized ............................... ix
Notices used in this book ................................ x
Part I. Hardware installation ....................................... 1
Chapter 1. Hardware overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
What is Fibre Channel? ................................. 3
Fibre Channel adapter features
............................. 3
Chapter 2. Installing the adapter
Preinstallation procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the IBM FAStT Host Adapter ........................ 6
Chapter 3. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Hardware problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System configuration problems ............................. 9
Fibre Channel problems ................................. 9
.......................... 5
Part II. Software installation ....................................... 11
Chapter 4. Software overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 5. Installing the Windows NT and Windows 2000 device drivers 15
Installing Windows NT and Windows 2000 ..................... 16
Adding the Windows NT driver ............................ 16
Adding the Windows 2000 driver ........................... 17
Updating the Windows NT device driver ...................... 17
Updating the Windows 2000 device driver ..................... 18
Chapter 6. Installing the Novell NetWare device driver ........... 19
NetWare device driver files and parameters .................... 19
Installing the NetWare 5.1 device driver ....................... 19
Part III. Appendices ............................................. 21
Appendix A. Fast!UTIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Fast!UTIL options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Appendix B. Adapter operating environment and specifications ..... 31
Appendix C. Getting help and technical assistance ............. 33
Before you call ..................................... 33
Appendix D. Warranty information . . . . . . . . . . . . . . . . . . . . . . . . 35
Warranty period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Copyright IBM Corp. 1998, 2002 iii
IBM Statement of Limited Warranty ......................... 38
Appendix E. Notices
Edition Notice
Trademarks
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Electronic emission notices .............................. 48
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
iv FAStT Host Adapter Installation and User's Guide
Safety Information
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d'installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.
Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Copyright IBM Corp. 1998, 2002 v
1
DANGER
Electrical current from power, telephone, and communication
cables is hazardous.
To avoid a shock hazard:
– Do not connect or disconnect any cables or perform
installation, maintenance, or reconfiguration of this product
during an electrical storm.
– Connect all power cords to a properly wired and grounded
electrical outlet.
– Connect to properly wired outlets any equipment that will be
attached to this product.
– When possible, use one hand only to connect or disconnect
signal cables.
– Never turn on any equipment when there is evidence of fire,
water, or structural damage.
– Disconnect the attached power cords, telecommunications
systems, networks, and modems before you open the
device covers, unless instructed otherwise in the installation
and configuration procedures.
– Connect and disconnect cables as described in the
following table when installing, moving, or opening covers
on this product or attached devices.
To Connect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
To Disconnect:
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
vi FAStT Host Adapter Installation and User's Guide
3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic
devices, or transmitters) are installed, note the following:
– Do not remove the covers. Removing the covers of the laser
product could result in exposure to hazardous laser radiation.
There are no serviceable parts inside the device.
– Use of controls or adjustments or performance of procedures other
than those specified herein might result in hazardous radiation
exposure.
DANGER
Some laser products contain an embedded Class 3A or Class
3B laser diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not
view directly with optical instruments, and avoid direct
exposure to the beam.
Class 1 laser statement
Class 1 Laser Product
Laser Klasse 1
Laser Klass 1
Luokan 1 Laserlaite
Appareil A Laser de Classe 1
IEC 825-1:1993 CENELEC EN 60 825
Safety Information
vii
viii FAStT Host Adapter Installation and User's Guide
About this book
This book provides instructions for installing and customizing the configuration of
your IBM FAStT Host Adapter and connected devices, and for installing and
updating the device drivers. It also provides information on troubleshooting your
IBM FAStT Host Adapter. To set up your IBM FAStT Host Adapter, see Chapter 2,
“Installing the adapter” on page 5 for detailed information.
How this book is organized
This book is comprised of the following parts:
Part I. Hardware installation
Chapter 1, “Hardware overview,” describes the IBM FAStT Host Adapter.
This chapter includes an overview of the IBM FAStT Host Adapter features.
Chapter 2, “Installing the adapter,” contains the information and instructions
needed to prepare and install the IBM FAStT Host Adapter.
Chapter 3, “Troubleshooting,” covers the type of installation problems that
can cause the IBM FAStT Host Adapter to function incorrectly.
Part II. Software installation
Chapter 4, “Software overview,” provides preinstallation information for
installing the device drivers.
Chapter 5, “Installing the Windows NT and Windows 2000 device drivers,”
provides instructions for installing Microsoft Windows NT and Windows
2000 device drivers.
Chapter 6, “Installing the Novell NetWare device driver,” provides
instructions for installing the NetWare device driver in a system that is
running Novell NetWare.
Part III. Appendices
Appendix A, “Fast!UTIL,” provides detailed configuration information for
users who want to customize the configuration of the IBM FAStT Host
Adapter and connected devices.
Appendix B, “Adapter operating environment and specifications,” contains
the IBM FAStT Host Adapter operating environment and specification
information.
Appendix C, “Getting help and technical assistance,” provides information
about getting help, service, technical assistance, or additional product
information.
Appendix D, “Warranty information,” provides information about product
warranty service and support.
Appendix E, “Notices,” contains product notices and trademarks.
Copyright IBM Corp. 1998, 2002 ix
Notices used in this book
The caution and danger statements used in this book also appear in the
multilingual Safety Information book that comes with the IBM FAStT Host Adapter.
Each caution and danger statement is numbered for easy reference to the
corresponding statements in the safety book.
The following types of notices and statements are used in this book:
Note: These notices provide important tips, guidance, or advice.
Important: These notices provide information or advice that might help you
avoid inconvenient or problem situations.
Attention: These notices indicate possible damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in
which damage could occur.
Caution: These statements indicate situations that can be potentially
hazardous to you. A caution statement is placed just before the description of
a potentially hazardous procedure step or situation.
Danger: These statements indicate situations that are potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
x FAStT Host Adapter Installation and User's Guide
Part I. Hardware installation
Chapter 1. Hardware overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
What is Fibre Channel? ................................. 3
Fibre Channel adapter features ............................. 3
Chapter 2. Installing the adapter .......................... 5
Preinstallation procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Handling static-sensitive devices .......................... 5
What you need for the installation ......................... 5
Adapter layouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing the IBM FAStT Host Adapter ........................ 6
Chapter 3. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Hardware problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System configuration problems ............................. 9
Fibre Channel problems ................................. 9
Copyright IBM Corp. 1998, 2002 1
2 FAStT Host Adapter Installation and User's Guide
Chapter 1. Hardware overview
The IBM FAStT Host Adapter is a high-performance, direct memory access
(DMA), bus-master, host adapter designed for high-end systems. The function and
performance are derived from the ISP2200A chip, making this FAStT Host Adapter
a leading-edge host adapter.
The ISP2200A chip combines a powerful RISC processor, a Fibre Channel protocol
manager (FPM) with gigabit transceivers, and a 64-bit peripheral component
interconnect (PCI) local bus interface in a single-chip solution. The IBM FAStT
Host Adapter supports all Fibre Channel (FC) peripheral devices that support
private-loop direct attach (PLDA) and fabric-loop attach (FLA).
What is Fibre Channel?
Fibre Channel technology is outlined in the Information Systems - Fibre Channel
Protocol for SCSI (small computer system interface - FCP) standard, revision 12,
30 May 1995. Fibre Channel is a high-speed data transport technology used for
mass storage and networking. The IBM FAStT Host Adapter connects:
Mainframe computers
Super computers
Workstations
Storage devices
Servers
Using a Fibre Channel arbitrated loop (FC-AL), 126 devices can be supported,
compared to 15 devices with Ultra SCSI.
Fibre Channel supports data transfer rates of 100 MB per second, which is more
than twice that of Ultra SCSI (40 MB per second). A multimode optical interface is
used for distances up to 500 meters. With increased connectivity and performance,
Fibre Channel is the technology preferred and used by system designers.
Fibre Channel adapter features
Fibre Channel adapter features include:
Compliance with Third Generation Fibre Channel Physical and Signaling
Interface - 3 (PC-PH-3), revision 9.2
Compliance with Fibre Channel Arbitrated Loop (FC-AL-2) standard
Compliance with Intel PCI version 2.2 specification
Compliance with U.S. and international safety and emissions standards
Support for bus-master DMA
Fast!UTIL basic input/output system (BIOS) utility program to customize the
configuration parameters on the IBM FAStT Host Adapter and attached drives
Supports Fibre Channel SCSI (FCP-SCSI) and internet protocol (IP) protocols
Supports point-to-point fabric connection (F-PORT FABRIC LOGIN)
Supports Fibre Channel service (Classes 2 and 3)
Copyright IBM Corp. 1998, 2002 3
32 bit or 64 bit, 66 or 33 MHz operation
Simultaneous mixed-peripheral configurations and startable device support for
Fibre Channel devices that meet the following standards:
– Fibre Channel — Private Loop Direct Attach Technical Report (FC-PLDA)
revision 1.10, 17 February 1997
– Fibre Channel — Fabric Loop Attachment Technical Report (FC-FLA)
revision 2.1, 12 July 1997
4 FAStT Host Adapter Installation and User's Guide
Chapter 2. Installing the adapter
This chapter contains instructions for preparing and installing the IBM FAStT Host
Adapter.
Preinstallation procedures
Before you begin
Read “Handling static-sensitive devices.”
Read “What you need for the installation.”
Handling static-sensitive devices
Attention: Static electricity can damage electronic devices and your system. To
avoid damage, keep static-sensitive devices in their static-protective package until
you are ready to install them.
To reduce the possibility of electrostatic discharge, observe the following
precautions:
Limit your movement. Movement can cause static electricity to build up around
you.
Handle the device carefully, holding it by its edges or its frame.
Do not touch solder joints, pins, or exposed printed circuitry.
Do not leave the device where others can handle and possibly damage the
device.
While the device is still in its static-protective package, touch it to an unpainted
metal part of the system unit for at least two seconds. (This drains static
electricity from the package and from your body.)
Remove the device from its package and install it directly into your system unit
without setting it down. If it is necessary to set the device down, place it in its
static-protective package. Do not place the device on your system unit cover
or on a metal table.
Take additional care when handling devices during cold weather because
heating reduces indoor humidity and increases static electricity.
What you need for the installation
To install the IBM FAStT Host Adapter in your server, you need an optical,
multimode cable with an SC-style duplex connector.
Copyright IBM Corp. 1998, 2002 5
Adapter layouts
The following figure identifies the adapter components referred to in this chapter.
J1
ISP2200
Installing the IBM FAStT Host Adapter
Before you begin the installation, write down the serial number of the IBM FAStT
Host Adapter. In the event that the nonvolatile random access memory (NVRAM)
is damaged, the system will prompt you for the IBM FAStT Host Adapter serial
number.
Attention: To avoid damage to your fiber-optic cables, follow these guidelines:
Do not route the cable along a folding cable-management arm.
When attaching fiber-optic cables to a device on slide rails, leave enough slack
in the cables so that they do not bend to a radius smaller than 76 mm (3 in.)
when extended or become pinched when retracted.
Route the cable away from places where it can snag on other devices in the
rack.
Do not over tighten the cable straps or bend the cables to a radius smaller than
76 mm (3 in.).
Do not put excess weight on the cable at the connection point and be sure that
the cable is well supported.
Follow these steps to install the IBM FAStT Host Adapter in your server:
1. Check the system board and make any configuration changes needed to
accommodate the IBM FAStT Host Adapter.
2. Turn off the peripheral devices, then the server.
3. Disconnect the power cords.
4. Remove the server cover.
5. Remove the slot cover.
6. Choose any PCI bus slot that supports 32 or 64-bit adapters. You can install
the adapter in a 64-bit PCI slot if one is available. If a 64-bit slot is not
available, then you can use a 32-bit PCI slot.
7. Align the adapter with the expansion slot. Carefully press the adapter into the
slot until it is fully seated.
6 FAStT Host Adapter Installation and User's Guide
8. Secure the adapter in place.
9. Connect one end of the fiber-optic cable from the device to the J1 connector on
the adapter.
10. Carefully install and secure the server cover.
11. Connect the power cables.
12. Turn on all external Fibre Channel devices; then, turn on the server. The
following information displays:
QLogic Corporation
QLA2xxx PCI Fibre Channel ROM BIOS Version X.XX
Copyright (C) QLogic Corporation 1998 All rights reserved.
www.qlc.com
Press <Alt+Q> for Fast!UTIL
BIOS for Adapter X is disabled.
ROM BIOS not installed.
To display the Fibre Channel devices, press Alt+Q; then, use the utility program.
See Appendix A, “Fast!UTIL” on page 23 for detailed utility information.
See “Part II. Software installation” on page 11 for detailed instructions on how to
install the device drivers.
If the information displayed is not correct and you have checked the adapter
configuration, see Chapter 3, “Troubleshooting” on page 9 for troubleshooting
information.
Chapter 2. Installing the adapter 7
8 FAStT Host Adapter Installation and User's Guide
Chapter 3. Troubleshooting
There are three types of installation problems that might cause your adapter to
function incorrectly.
Hardware problems
System configuration problems
Fibre Channel (FC) problems
If you are having problems, use the following information to help you determine the
cause of the problem and the action to take.
Hardware problems
The following is a list to help you determine if your installation problem is caused by
the hardware:
Verify that all adapters are installed securely.
Verify that all cables are attached securely to the correct connectors. Be sure
that the Fibre Channel connectors that attach from the J1 connector on the
adapter to the device are connected securely.
Verify that the adapter is installed correctly and fully seated in the expansion
slot. Check for interference due to nonstandard PCI connectors.
Verify that all peripheral devices are turned on. See “Scan Fibre Channel
devices” on page 28 for information about displaying attached devices.
System configuration problems
To find out if your installation problem was caused by the system configuration,
check your system board to ensure that it is configured properly (see “Installing the
IBM FAStT Host Adapter” on page 6).
Fibre Channel problems
To determine if your installation problem is caused by the Fibre Channel, verify that
all of the Fibre Channel devices were turned on before you turned on the server.
Also, ensure that all cables are connected properly.
Copyright IBM Corp. 1998, 2002 9
10 FAStT Host Adapter Installation and User's Guide
Part II. Software installation
Chapter 4. Software overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 5. Installing the Windows NT and Windows 2000 device drivers 15
Installing Windows NT and Windows 2000 ..................... 16
Adding the Windows NT driver ............................ 16
Adding the Windows 2000 driver ........................... 17
Updating the Windows NT device driver ...................... 17
Updating the Windows 2000 device driver ..................... 18
Chapter 6. Installing the Novell NetWare device driver ........... 19
NetWare device driver files and parameters .................... 19
Installing the NetWare 5.1 device driver ....................... 19
Copyright IBM Corp. 1998, 2002 11
12 FAStT Host Adapter Installation and User's Guide
Chapter 4. Software overview
After installing your IBM FAStT Host Adapter, you are ready to install the device
drivers for the adapter.
The device drivers for the following supported operating systems are provided with
your IBM FAStT Host Adapter:
Windows 2000
Windows NT Version 4.0
Novell NetWare Version 5.1
Note: The latest versions of the device drivers, utilities, and documentation are
available at http://www.ibm.com/pc/support/.
Before you begin
Create driver diskettes by copying the image you need from the IBM FAStT
Host Adapter Support CD for the following:
– FAStT Host Adapter for Windows 2000
– FAStT Host Adapter for Windows NT 4.0
– FAStT Host Adapter for NetWare 5.1
Note: You will be prompted for the driver diskettes during the operating
system installation process.
Read through the software installation chapters to determine which device
driver you want to install.
Use the following steps if you need to create driver diskettes to support the
installation of Novell NetWare version 5.1, Microsoft Windows NT 4.0, or Windows
2000:
1. Insert the IBM FAStT Host Adapter Support CD into the CD-ROM drive.
2. To create the IBM FAStT Host Adapter device driver diskette:
For Windows NT 4, at the command prompt, type:
d:\tools\dsk4w32 d:\images\nt4\nt4_7444.img a:
Where d is the CD-ROM drive and a is the diskette drive.
For Windows 2000, at the command prompt, type:
d:\tools\dsk4w32 d:\images\w2k\w2k_7432.img a:
Where d is the CD-ROM drive and a is the diskette drive.
For NetWare 5.1, at the command prompt, type:
d:\tools\dsk4w32 d:\images\nw51\nw51_55v.img a:
Where d is the CD-ROM drive and a is the diskette drive.
3. Press Enter.
4. Remove the diskette from the diskette drive and label the diskette
appropriately.
5. Remove the IBM FAStT Host Adapter Support CD from the CD-ROM drive.
Copyright IBM Corp. 1998, 2002 13
14 FAStT Host Adapter Installation and User's Guide
Chapter 5. Installing the Windows NT and Windows 2000 device drivers
This section provides instructions for installing the Windows NT and Windows 2000
device drivers under the following operating system conditions:
Initial installation of the operating system and the device driver
Installation of the device driver in a previously installed operating system
Installing an updated device driver in a previously installed operating system
that has an older version of the device driver
The following files are provided on the IBM FAStT Host Adapter driver diskette that
you created in Chapter 4 for the Windows NT device driver installation.
TXTSETUP.OEM: Driver installation script for initial Windows NT text setup
QLOGIC: Identification file for Windows NT setup program
\NT\OEMSETUP.INF: Driver installation script for the Windows NT setup
program
\NT\QL2200.SYS: Windows NT 4.0 device driver
\NT\README.TXT: Helpful hints about the Windows NT device driver
\NT\RELEASE.TXT: History of release fixes
The following files are provided on the IBM FAStT Host Adapter driver diskette that
you created in Chapter 4 for the Windows 2000 device driver installation.
TXTSETUP.OEM: Driver installation script for initial Windows 2000 text setup
QLOGIC: Identification file for Windows 2000 setup program
\WK2\OEMSETUP.INF: Driver installation script for the Windows 2000 setup
program
\WK2\QL2200.SYS: Windows 2000 device driver
\WK2\README.TXT: Helpful hints about the Windows 2000 device driver
\WK2\RELEASE.TXT: History of release fixes
Copyright IBM Corp. 1998, 2002 15
Installing Windows NT and Windows 2000
Perform the following steps to install Windows NT 4.0 or Windows 2000 on the
drive that is attached to the IBM FAStT Host Adapter.
1. Insert the Windows NT or Windows 2000 setup diskette or insert the Windows
NT or Windows 2000 installation CD into the CD-ROM drive.
2. After the standard devices have been detected and configured, use the S
option to Specify Additional Device.
3. Select Other; then, press Enter.
4. Insert the FAStT Host Adapter device driver diskette that you created in
Chapter 4; then, press Enter.
5. Select QLogic QLA2200; then, press Enter.
6. Select the standard installation procedure.
Adding the Windows NT driver
Perform the following steps to add the Windows NT device driver to a previously
installed Windows NT 4.0 system.
1. On your desktop, click My Computer → Control Panel → SCSI Adapters.
2. Click the Drivers tab and click Add.
3. Select QLogic from the list of manufacturers and click Have Disk.
4. Insert the IBM FAStT Host Adapter driver diskette you created for Windows NT.
At the prompt type:
a:\nt
where a is the diskette drive letter. Click OK.
5. If you are installing the drivers from a CD-ROM, at the prompt type:
z:\NT4\22\NT
where z is the CD-ROM drive letter.
6. Select IBM Netfinity QLA2200 PCI Fibre Channel Adapter and click OK.
7. Click Yes to restart your server so the driver settings can take effect now or
click No to restart your system at a later time.
16 FAStT Host Adapter Installation and User's Guide
Adding the Windows 2000 driver
Perform the following steps to add the Windows 2000 device driver to a previously
installed Windows 2000 system.
1. After you install the IBM FAStT Host Adapter, restart the system. The system
searches for the newly installed device. If the system finds the new device, it
indicates that the device has been detected.
2. If prompted to insert the device driver diskette, insert the IBM FAStT Host
Adapter device driver for Windows 2000 diskette that you created in Chapter 4.
When prompted, follow the instructions.
If you want to update a previously installed version of the device driver, follow the
procedures in “Updating the Windows 2000 device driver” on page 18.
Updating the Windows NT device driver
Perform the following steps if you want to replace an existing Windows NT device
driver with an updated version.
1. Open a DOS command prompt.
2. Change the current directory to the Windows NT device driver directory. For
example, type:
CD \WINNT\SYSTEM32\DRIVERS
3. Make a backup copy of the old device driver. You can copy the file into the
same directory with a .SAV extension, indicating that it is the saved file. For
example, type:
copy QL22.SYS QL22.SAV
4. Insert the IBM FAStT Host Adapter device driver for Windows NT diskette that
you created in Chapter 4 into your diskette drive.
5. Copy the new device driver over the old device driver. For example, type:
copy a:\NT\QL22.SYS
Where a is the diskette drive letter.
6. If you are installing drivers from the CD-ROM, type:
copy z:\NT4\22\NT\QL22.sys
Where z is the CD-ROM drive letter.
7. Remove the IBM FAStT device drivers for Windows NT diskette or the IBM
FAStT Host Adapter Support CD.
8. Restart your system to install the device driver.
Chapter 5. Installing the Windows NT and Windows 2000 device drivers 17
Updating the Windows 2000 device driver
Perform the following steps if you want to replace the existing Windows 2000
device driver with an updated version.
1. Click Start → Settings → System → Hardware → Device Manager → SCSI
and RAID Controllers
2. Select the QLogic adapter you want to update.
3. Click on the adapter and select Properties.
4. Select the Driver tab.
5. Click the Update driver button and follow the instructions that display in the
window.
18 FAStT Host Adapter Installation and User's Guide
Chapter 6. Installing the Novell NetWare device driver
This section provides instructions for installing the NetWare device driver in an
installed Novell NetWare system.
NetWare device driver files and parameters
The following files are provided on the IBM FAStT Host Adapter device drivers
diskette that you created in Chapter 4 for the NetWare 5.1 device driver installation:
NETWARE\QL2200.HAM: Driver for NetWare 5.1
NETWARE\QL2200.DDI: Installation information file for QL2200.HAM driver
README.TXT: Helpful hints about the device driver and setting options for
NetWare 5.1
RELEASE.TXT: History of release fixes
Be sure to review the README.TXT file for both new and changed information.
To customize the interface between the device driver and Novell NetWare, load the
QL2200.HAM device driver with the following parameters.
Parameter Description
SLOT Provides support for multiple IBM FAStT Host Adapters and installs
the device driver for each adapter individually. This parameter is
mandatory if you have more than one adapter.
/LUN Enables support for multiple LUN (logical unit number) devices.
This parameter is optional.
Installing the NetWare 5.1 device driver
The QL2200.HAM device driver might not be compatible with NetWare versions
earlier than 5.1.
Note: You can enter the LOAD command lines in your NetWare STARTUP.NCF
file to install the driver automatically when your system starts.
Perform the following steps to install the NetWare 5.1 device driver in a previously
installed NetWare system.
1. Insert the IBM FAStT Host Adapter device drivers for NetWare diskette that you
created in Chapter 4 in the diskette drive.
2. Copy the QL2200.HAM device driver file from the diskette to the server root
directory. For example, type:
copy a:\NETWARE\QL22.HAM c:\NWSERVER\
Where a is the diskette drive letter and c is the root directory.
3. If you are installing the driver from a CD-ROM, type:
copy z:\NW51\22\NETWARE\QL22.HAM c:\NWSERVER\
Where z is the CD-ROM drive letter and c is the root directory.
Copyright IBM Corp. 1998, 2002 19
4. Install the device driver at the NetWare server prompt (:) by typing the LOAD
command with the SLOT parameter.
The following LOAD example works for a default (factory setting)
QL2200/2200F adapter.
LOAD QL22.HAM SLOT=X
Replace the X in the load line example with the slot identification number of the
slot in which the adapter is installed.
5. If you are attaching multiple LUN devices, such as tape changers, add the
/LUN switch to the LOAD line. For example, type:
LOAD QL22.HAM SLOT=X /LUN
20 FAStT Host Adapter Installation and User's Guide
Part III. Appendices
Appendix A. Fast!UTIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Fast!UTIL options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Configuration settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Host adapter settings ................................ 23
Selectable boot settings .............................. 24
Adapter hard ID settings .............................. 24
Restore default settings .............................. 24
Raw NVRAM data .................................. 24
Advanced adapter settings ............................. 24
Extended firmware settings ............................ 26
Scan Fibre Channel devices ............................ 28
Fibre Channel disk utility .............................. 28
Select host adapter ................................. 29
Appendix B. Adapter operating environment and specifications ..... 31
Appendix C. Getting help and technical assistance ............. 33
Before you call ..................................... 33
Using the documentation .............................. 33
Getting help and information from the World Wide Web ............ 34
Software service and support ........................... 34
Hardware service and support ........................... 34
Appendix D. Warranty information . . . . . . . . . . . . . . . . . . . . . . . . 35
Warranty period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Problem determination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Warranty service and support ........................... 36
International Warranty Service ........................... 37
Purchasing additional services .......................... 37
IBM Statement of Limited Warranty ......................... 38
Part 1 - General Terms ............................... 38
Part 2 - Country-unique Terms .......................... 40
Appendix E. Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Edition Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Electronic emission notices .............................. 48
Federal Communications Commission (FCC) Statement ........... 48
Industry Canada Class A emission compliance statement ........... 49
Australia and New Zealand Class A statement ................. 49
United Kingdom telecommunications safety requirement ........... 49
European Union EMC Directive conformance statement ............ 49
Taiwan electrical emission statement ....................... 49
Japanese Voluntary Control Council for Interference (VCCI) statement ... 50
Copyright IBM Corp. 1998, 2002 21
22 FAStT Host Adapter Installation and User's Guide
Appendix A. Fast!UTIL
This appendix provides detailed configuration information for advanced users who
want to customize the configuration of the IBM FAStT Host Adapter and the
connected devices. You can configure the adapter using the Fast!UTIL utility.
Access Fast!UTIL by pressing Alt+Q during the adapter BIOS initialization (it might
take a few seconds for the Fast!UTIL menu to appear). If you have more than one
IBM FAStT Host Adapter, Fast!UTIL prompts you to select the adapter you want to
configure. After changing the settings, Fast!UTIL restarts your system to load the
new parameters.
Attention: If the configuration settings are incorrect, your IBM FAStT Host Adapter
will not function properly.
Each host adapter has a unique serial number. Take a minute to write down the
serial number of the FAStT Host Adapter. In the event that the nonvolatile random
access memory (NVRAM) is damaged (see “Scan Fibre Channel devices” on
page 28), you will be prompted for the IBM FAStT Host Adapter serial number.
Fast!UTIL options
This section describes the Fast!UTIL options.
Configuration settings
This is the first option on the Fast!UTIL Options menu. These settings configure
the Fibre Channel (FC) devices and the IBM FAStT Host Adapter to which they are
attached.
Host adapter settings
You can access this option from the Configuration Settings menu. The current
default settings for the host adapter are listed in Table 1 and are described
immediately following the table.
Note: The host adapter settings and default values will vary, based on the version
of BIOS code installed for the adapter.
Table 1. Host adapter settings
Setting Options Default
Host adapter BIOS Enabled or Disabled Disabled
Frame size 512, 1024, 2048 2048
Loop reset delay 0–15 seconds 5 seconds
Adapter hard loop ID Enabled or Disabled Enabled
Hard loop ID 0–125 125
Host adapter BIOS: When this option is set to Disabled, the ROM BIOS on
the IBM FAStT Host Adapter is disabled, freeing space in upper memory. The
default is Disabled.
Copyright IBM Corp. 1998, 2002 23
Frame size: Specifies the maximum frame length supported by the IBM FAStT
Host Adapter. The default size is 2048. If you are using F-Port (point-to-point)
connections, the default is best for maximum performance.
Loop reset delay: After resetting the loops, the firmware does not initiate any
loop activity for the number of seconds specified in this setting. The default is
5 seconds.
Adapter hard loop ID: Forces the adapter to use the ID specified in the Hard
Loop ID setting. The default is Enabled.
Hard loop ID: When the Adapter Hard Loop ID is set to Enabled, the adapter
uses the ID specified in this setting. The default ID is 125.
Selectable boot settings
You can access this option from the Configuration Settings menu. When this
option is set to Enabled, you can select the node name from which you want to
start up (boot). When this option is set to Disabled, the Boot ID and Boot LUN
parameters have no effect.
Note: This option applies only to disk devices; it does not apply to CD-ROMs,
tape drives, and other nondisk devices.
Adapter hard ID settings
You can access this option from the Configuration Settings menu. It forces the IBM
FAStT Host Adapter to use the selected hard ID (0–125).
Restore default settings
You can access this option from the Configuration Settings menu. It restores the
IBM FAStT Host Adapter default settings.
Raw NVRAM data
This option displays the adapter nonvolatile random access memory (NVRAM)
contents in hexadecimal format. This is a troubleshooting tool; you cannot modify
the data.
Advanced adapter settings
You can access this option from the Configuration Settings menu. The default
settings for the host adapter are listed in Table 2 on page 25 and are described
immediately following the table.
24 FAStT Host Adapter Installation and User's Guide
Table 2. Advanced adapter settings
Setting Options Default
Execution throttle 1–256 256
Fast command posting Enabled or Disabled Enabled
>4GByte addressing Enabled or Disabled Disabled
LUNs per target 0, 8, 16, 32, 64, 128, 256 8
Enable LIP reset Yes or No No
Enable LIP full login Yes or No Yes
Enable target reset Yes or No Yes
Login retry count 0–255 30
Port down retry count 0–255 30
Drivers load RISC code Enabled or Disabled Enabled
Enable database updates Yes or No No
Disable database load Yes or No No
IOCB allocation 1–512 buffers 256 buffers
Extended error logging Enabled or Disabled Disabled
Execution throttle: Specifies the maximum number of commands executing
on any one port. When a port reaches its execution throttle, Fast!UTIL does
not run any new commands until the current command is completed. The valid
options for this setting are 1–256. The default (optimum) is 256.
Fast command posting: Decreases command execution time by minimizing
the number of interrupts. The default is Enabled.
>4GByte addressing: Enable this option when the system has more than 4
GB of memory available. The default is Disabled.
LUNs per target: Specifies the number of LUNs per target. Multiple logical
unit number (LUN) support is typically for redundant array of independent disks
(RAID) enclosures that use LUNs to map drives. The default is 8. If you do
not need multiple LUN support, set the number of LUNs to 0.
Enable LIP reset: Determines the type of loop initialization process (LIP) reset
that is used when the operating system initiates a bus reset routine. When this
option is set to Yes, the device driver initiates a global LIP reset to clear the
target device reservations. When this option is set to No, the device driver
initiates a global LIP reset with full login. The default is No.
Enable LIP full login: Instructs the ISP chip to log in to all ports after any LIP.
The default is Yes.
Enable target reset: Enables the drivers to issue a Target Reset command to
all devices on the loop when a SCSI Bus Reset command is issued. The
default is No.
Login retry count: Specifies the number of times the software tries to log in to
a device. The default is 30 retries.
Appendix A. Fast!UTIL 25
Port down retry count: Specifies the number of times the software retries a
command to a port that is returning port-down status. The default is 30 retries.
Drivers load RISC code: When this option is set to Enabled, the host adapter
uses the RISC firmware that is embedded in the software device driver. When
this option is set to Disabled, the software device driver loads the RISC
firmware found on the system. The default is Enabled.
Note: To load the embedded device driver software, the device driver being
loaded must support this setting. If the driver does not support this
setting, the result is the same as if this option is set to Disabled,
regardless of the setting. Leaving this option enabled ensures a
certified combination of software driver and RISC firmware.
Enable database updates: When this option is set to Enabled, it allows the
software to save the loop configuration information in flash memory as the
system powers down. The default is No.
Disable database load: When this option is set to Enabled, the device
database is read from the Registry during driver initialization. When this option
is set to Disabled, the device database is created dynamically during device
driver initialization. The default is No.
Note: This option usually applies to the Windows NT and Windows 2000
operating environments.
IOCB allocation: Specifies the maximum number of buffers from the firmware
buffer pool that are allocated to any one port. The default setting is 256
buffers.
Extended error logging: Provides additional error and debug information to
the operating system. When this option is set to Enabled, events are logged
into the Windows NT Event Viewer or Windows 2000 Event Viewer (depending
on the environment you are in). The default is Disabled.
Extended firmware settings
You can access this option from the Configuration Settings menu. The default
settings for the host adapter are listed in Table 3 on page 27 and are described
immediately following the table.
26 FAStT Host Adapter Installation and User's Guide
Table 3. Extended firmware settings
Setting Options Default
Extended control block Enabled or Disabled Enabled
RIO operation mode 0, 1, 2, 3, 4 0
Connection options 0, 1, 2, 3 3
NonParticipating hard ID Enabled or Disabled Disabled
Class 2 service Enabled or Disabled Disabled
ACK0 Enabled or Disabled Disabled
Fibre Channel tape support Enabled or Disabled Disabled
Fibre Channel confirm Enabled or Disabled Disabled
Command reference
number
Read transfer ready Enabled or Disabled Disabled
Response timer 0–255 0
Interrupt delay timer 0–255 0
Enabled or Disabled Disabled
Extended control block: Enables all other extended firmware settings. The
default is Enabled.
RIO operation mode: Specifies the reduced interrupt operation (RIO) modes,
if supported by the software device driver. RIO modes enable posting multiple
command completions in a single interrupt (see Table 4). The default is 0.
Table 4. RIO operation modes
Option Operation mode
0 No multiple responses
1 Multiple responses, 16-bit handles, interrupt host
2 Multiple responses, 32-bit handles, interrupt host
3 Multiple responses, 16-bit handles, delay host interrupt
4 Multiple responses, 32-bit handles, delay host interrupt
Connection options: Defines the type of connection (loop or point-to-point) or
connection preference (see Table 5 on page 28). The default is 3.
Appendix A. Fast!UTIL 27
Table 5. Connection options
Option Type of connection
0 Loop only
1 Point-to-point only
2 Loop preferred; otherwise, point-to-point
3 Point-to-point; otherwise, loop
NonParticipating hard ID: This setting is reserved. The default is Disabled.
Class 2 service: Enables Class 2 service parameters to be provided during all
automatic logins (loop ports). The default is Disabled.
ACK0: Determines the type of acknowledgment (ACK) used. When this option
is set to Enabled, sequence ACK is used. When this option is set to Disabled,
frame ACK is used. The default is Disabled.
Note: You must enable the Class 2 service setting to use the ACK0 setting.
Fibre Channel tape support: This setting is reserved for Fibre Channel tape
support. The default is Disabled.
Fibre Channel confirm: This setting is reserved for Fibre Channel tape
support. The default is Disabled.
Command reference number: This setting is reserved for Fibre Channel tape
support. The default is Disabled.
Read transfer ready: This setting is reserved. The default is Disabled.
Response timer: Contains the value (in 100-microsecond increments) used by
a timer to limit the wait time for accumulating multiple responses. For example,
if this field is 8, the time limit is 800 microseconds. The default is 0.
Interrupt delay timer: Contains the value (in 100-microsecond increments)
used by a timer to set the wait time between accessing (DMA) a set of handles
and generating an interrupt. The default is 0.
Scan Fibre Channel devices
Use this option to scan the Fibre Channel loop and list all the connected devices by
loop ID. Information about each device is listed, for example, vendor name,
product name, and revision. This information is useful when configuring your IBM
FAStT Host Adapter and attached devices.
Fibre Channel disk utility
Use this option to scan the Fibre Channel loop bus and list all the connected
devices by loop ID. You can select a disk device and perform a low-level format or
verify the disk media.
Attention: Performing a low-level format removes all data on the disk.
28 FAStT Host Adapter Installation and User's Guide
Select host adapter
Use this option to select a specific adapter if you have multiple adapters in your
system.
Appendix A. Fast!UTIL 29
30 FAStT Host Adapter Installation and User's Guide
Appendix B. Adapter operating environment and specifications
This appendix contains the IBM FAStT Host Adapter operating environment and
specification information.
Table 6. Adapter operating environment
Environment Minimum Maximum
Operating temperature 0°C (32°F) 55°C (131°F)
Storage temperature -20°C (-4°F) 70°C (158°F)
Relative humidity (noncondensing) 10% 90%
Storage humidity (noncondensing) 5% 95%
Table 7 (Page 1 of 2). Adapter specifications
Type Specification
Host bus Conforms to PCI Local Bus Specification, revision 2.2
PCI signaling environment 3.3 V and 5.0 V buses supported
PCI transfer rate 264 MB per second maximum burst rate for 33 MHz operation
(ISP2200A chip)
Supports dual address bus cycles
Fibre Channel
specifications
Processor Single chip design that includes a RISC processor, Fibre Channel
Host data transfer 64-bit, bus master DMA data transfers to 528 MB per second
RAM 128 KB of SRAM
BIOS ROM 128 KB of flash ROM in two 64 KB, software selectable banks.
NVRAM 256 bytes, field programmable
Onboard DMA Three independent DMA channels: two data and one command.
Connectors (external) SC-style connector that supports non-OFC, multimode fibre
Form factor 17.8 cm x 10.7 cm (7.0 in. x 4.2 in.)
Operating power Less than 15 watts
Bus type: fibre optic media (shortwave 50 micron)
Bus transfer rate: 100 MB per second maximum (200
full-duplex)
Supports both FCP-SCSI and IP protocols
Supports point-to-point fabric connection: F-Port Fabric Login
Supports FCAL public loop profile: FL-Port Login
Supports Fibre Channel services class 2 and 3
FCP SCSI initiator and target operation
Full-duplex operation
protocol manager, PCI DMA controller, and 1-gigabit transceivers
The flash is field programmable.
Integrated 4 KB frame buffer FIFO for each data channel
optic cabling using 1 x 9 fibre optic transceiver module
Total cable length cannot exceed 500 meters
Two three-position, point-to-point cable (internal)
Copyright IBM Corp. 1998, 2002 31
Table 7 (Page 2 of 2). Adapter specifications
Type Specification
Other compliance PCI 98, including ACPI
Less than 28% processor utilization as measured in a TPCC
benchmark
Operation system support for Windows NT version 4, Windows
2000 version 1, and NetWare version 5.1
Worldwide agency compliance as defined for IBM
xSeries products
100% Plug and Play compatibility with our existing FAStT Fibre
Channel RAID Controller
32 FAStT Host Adapter Installation and User's Guide
Appendix C. Getting help and technical assistance
If you need help, service, or technical assistance or just want more information
about IBM products, you will find a wide variety of sources available from IBM to
assist you. This section contains information about where to go for additional
information about IBM and IBM products, what to do if you experience a problem
with your xSeries or IntelliStation system, and whom to call for service, if it is
necessary.
Before you call
Before you call, make sure that you have taken these steps to try to solve the
problem yourself:
Check all cables to make sure that they are connected.
Check the power switches to make sure that the system is turned on.
Use the troubleshooting information in your system documentation, and use the
diagnostic tools that come with your system.
Go to the IBM Support Web site at http://www.ibm.com/pc/support/ to check for
technical information, hints, tips, and new device drivers.
Use an IBM discussion forum on the IBM Web site to ask questions.
You can solve many problems without outside assistance by following the
troubleshooting procedures that IBM provides in the online help or in the
publications that are provided with your system and software. The information that
comes with your system also describes the diagnostic tests that you can perform.
Most xSeries and IntelliStation systems, operating systems, and programs come
with information that contains troubleshooting procedures and explanations of error
messages and error codes. If you suspect a software problem, see the information
for the operating system or program.
Using the documentation
Information about your IBM xSeries or IntelliStation system and preinstalled
software, if any, is available in the documentation that comes with your system.
That documentation includes printed books, online books, README files, and help
files. See the troubleshooting information in your system documentation for
instructions for using the diagnostic programs. The troubleshooting information or
the diagnostic programs might tell you that you need additional or updated device
drivers or other software. IBM maintains pages on the World Wide Web where you
can get the latest technical information and download device drivers and updates.
To access these pages, go to http://www.ibm.com/pc/support/ and follow the
instructions. Also, you can order publications through the IBM Publications
Ordering System at
http://www.elink.ibmlink.ibm.com/public/applications/publications/cgibin/pbi.cgi.
Copyright IBM Corp. 1998, 2002 33
Getting help and information from the World Wide Web
On the World Wide Web, the IBM Web site has up-to-date information about IBM
xSeries and IntelliStation products, services, and support. The address for IBM
xSeries information is http://www.ibm.com/eserver/xseries/. The address for IBM
IntelliStation information is http://www.ibm/com/pc/intellistation/.
You can find service information for your IBM products, including supported options,
at http://www.ibm.com/pc/support/. If you click Profile from the support page, you
can create a customized support page. The support page has many sources of
information and ways for you to solve problems, including:
Diagnosing problems, using the IBM Online Assistant
Downloading the latest device drivers and updates for your products
Viewing Frequently Asked Questions (FAQ)
Viewing hints and tips to help you solve problems
Participating in IBM discussion forums
Setting up e-mail notification of technical updates about your products
Software service and support
Through IBM Support Line, you can get telephone assistance, for a fee, with usage,
configuration, and software problems with xSeries servers, IntelliStation
workstations, and appliances. For information about which products are supported
by Support Line in your country or region, go to
http://www.ibm.com/services/sl/products/.
For more information about Support Line and other IBM services, go to
http://www.ibm.com/services/, or go to http://www.ibm.com/planetwide/ for support
telephone numbers.
Hardware service and support
You can receive hardware service through IBM Integrated Technology Services or
through your IBM reseller, if your reseller is authorized by IBM to provide warranty
service. Go to http://www.ibm.com/planetwide/ for support telephone numbers.
In the U.S. and Canada, hardware service and support is available 24 hours a day,
7 days a week. In the U.K., these services are available Monday through Friday,
from 9 a.m. to 6 p.m.
34 FAStT Host Adapter Installation and User's Guide
Appendix D. Warranty information
This section contains the warranty period for your product and the service and
support that are provided by your warranty.
Warranty period
The warranty period varies by machine type and country or region.
Contact your place of purchase for warranty service information. Some IBM
Machines are eligible for on-site warranty service depending on the country or
region where service is performed.
Prior to on-site warranty service, you are required to go through problem
determination with an IBM service specialist call center technician.
A warranty period of 3 years on parts and 1 year on labor means that IBM will
provide warranty service without charge for:
1. parts and labor during the first year of the warranty period
2. parts only, on an exchange basis, in the second and third years of the warranty
period. IBM will charge you for any labor it provides in performance of the
repair or replacement.
The IBM Machine Warranties Web site at
http://www.ibm.com/servers/support/machine_warranties/ contains a worldwide
overview of the IBM Statement of Limited Warranty for IBM Machines, a glossary of
terms used in the Statement of Limited Warranty, Frequently Asked Questions
(FAQ), and links to Product Support Web pages. The IBM Statement of Limited
Warranty is available from this Web site in 29 languages in Portable Document
Format (PDF).
Machine - IBM FAStT Host Adapter
Warranty period - Three Years
Problem determination
Prior to on-site warranty service, you are required to go through problem
determination with an IBM service specialist call center technician. The service
specialist will run diagnostic tests on the hardware and check the software.
Running diagnostics
The IBM service specialist will help you determine whether your equipment is
functioning as specified. It might be necessary to isolate the failing xSeries,
Netfinity, or IntelliStation system; IBM component; or both from any active
production environment to run diagnostics and perform defect-isolation programs.
You are responsible for making the system, IBM component, or both available for
running diagnostics and defect-isolation programs.
Copyright IBM Corp. 1998, 2002 35
Checking software
The IBM service specialist will help you ensure that the correct BIOS code,
firmware, device drivers, and other supporting IBM software are installed and
correctly configured. It might be necessary to manually gather information about
the relevant software levels or run IBM-approved utility programs to gather this
information. It might be necessary to isolate the failing system from any active
production environment to gather this information. You are responsible, with
assistance from the service specialist, for gathering this information. The IBM
Statement of Limited Warranty does not include on-site assistance with this activity.
Warranty service and support
With the original purchase of an IBM xSeries or IntelliStation system, you have
access to extensive support. During the IBM Machine warranty period, you may
call IBM or your reseller for problem-determination assistance under the terms of
the IBM Statement of Limited Warranty.
The following services are available during the warranty period:
Problem determination - Trained personnel are available to assist you with
determining if you have a hardware problem and deciding what action is
necessary to fix the problem.
IBM hardware repair - If the problem is determined to be caused by IBM
hardware under warranty, trained service personnel are available to provide the
applicable level of service, either on-site or at an IBM service center as
determined by IBM.
Engineering Change management - Occasionally, there might be changes
that are required after a product has been shipped from IBM. In those
instances, IBM will make Engineering Changes (ECs) available that apply to
your hardware.
Customer replaceable units (CRUs) - Some parts of IBM xSeries and
IntelliStation systems are designated as customer replaceable units. IBM ships
CRUs to you for replacement by you. CRUs include keyboards, monitors,
memory, diskette drives, hard disk drives, and mice (this list is not inclusive of
all CRUs).
The following items are not covered under warranty service:
Replacement or use of non-IBM parts. All IBM parts contain a 7-character
identification in the format IBM FRU XXXXXXX.
Identification of software problem sources.
Installation of customer replaceable units (CRUs).
Installation and configuration of BIOS code, firmware, or device drivers that are
designated as customer installable.
See the IBM Statement of Limited Warranty for a full explanation of IBM
warranty terms. Be sure to retain your proof of purchase to obtain warranty
service.
Please have the following information ready when you call:
The machine type and model of your IBM hardware product (if available)
Serial numbers of your IBM hardware products
36 FAStT Host Adapter Installation and User's Guide
A description of the problem
The exact wording of any error messages
Hardware and software configuration information
International Warranty Service
If you travel with your xSeries or IntelliStation system or relocate it to a country or
region where your system is sold and serviced by IBM or IBM resellers authorized
to perform warranty service, International Warranty Service (IWS) is available
during the warranty period. Eligible IBM systems are identified by their four-digit
machine types.
You can obtain IWS through the service delivery method (such as depot, carry-in,
or on-site) provided in the servicing country or region. Service methods and
procedures vary by country or region, and some service or parts might not be
available in all countries and regions. Service centers in certain countries or
regions might not be able to service all models of a particular machine type. In
addition, some countries or regions might have fees and restrictions that apply at
the time of service.
To determine whether your system is eligible for IWS, go to
http://www.ibm.com/pc/support/ and click Warranty lookup.
Purchasing additional services
During and after the warranty period, you can purchase additional services, such as
support for IBM and non-IBM hardware, operating system, and application
programs; network setup and configuration; upgraded or extended hardware repair
services; and custom installations. Service availability and service name might vary
by country or region.
For more information about these services, contact your IBM marketing
representative.
Appendix D. Warranty information 37
IBM Statement of Limited Warranty
Z125-4753-06 8/2000
Part 1 - General Terms
This Statement of Limited Warranty includes Part 1 - General Terms and Part 2 Country-unique Terms. The terms of Part 2 replace or modify those of Part 1. The
warranties provided by IBM in this Statement of Limited Warranty apply only to
Machines you purchase for your use, and not for resale, from IBM or your reseller.
The term “Machine” means an IBM machine, its features, conversions, upgrades,
elements, or accessories, or any combination of them. The term “Machine” does
not include any software programs, whether pre-loaded with the Machine, installed
subsequently or otherwise. Unless IBM specifies otherwise, the following
warranties apply only in the country where you acquire the Machine. Nothing in
this Statement of Limited Warranty affects any statutory rights of consumers that
cannot be waived or limited by contract. If you have any questions, contact IBM or
your reseller.
The IBM Warranty for Machines
IBM warrants that each Machine 1) is free from defects in materials and
workmanship and 2) conforms to IBM's Official Published Specifications
(“Specifications”). The warranty period for a Machine is a specified, fixed period
commencing on its Date of Installation. The date on your sales receipt is the Date
of Installation unless IBM or your reseller informs you otherwise.
If a Machine does not function as warranted during the warranty period, and IBM or
your reseller are unable to either 1) make it do so or 2) replace it with one that is at
least functionally equivalent, you may return it to your place of purchase and your
money will be refunded.
Extent of Warranty
The warranty does not cover the repair or exchange of a Machine resulting from
misuse, accident, modification, unsuitable physical or operating environment,
improper maintenance by you, or failure caused by a product for which IBM is not
responsible. The warranty is voided by removal or alteration of Machine or parts
identification labels.
THESE WARRANTIES ARE YOUR EXCLUSIVE WARRANTIES AND REPLACE
ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THESE WARRANTIES GIVE YOU SPECIFIC LEGAL RIGHTS AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM JURISDICTION
TO JURISDICTION. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF EXPRESS OR IMPLIED WARRANTIES, SO THE ABOVE
EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU. IN THAT EVENT,
SUCH WARRANTIES ARE LIMITED IN DURATION TO THE WARRANTY
PERIOD. NO WARRANTIES APPLY AFTER THAT PERIOD.
Items Not Covered by Warranty
IBM does not warrant uninterrupted or error-free operation of a Machine.
38 FAStT Host Adapter Installation and User's Guide
Any technical or other support provided for a Machine under warranty, such as
assistance via telephone with “how-to” questions and those regarding Machine
set-up and installation, will be provided WITHOUT WARRANTIES OF ANY KIND.
Warranty Service
To obtain warranty service for a Machine, contact IBM or your reseller. If you do
not register your Machine with IBM, you may be required to present proof of
purchase.
During the warranty period, IBM or your reseller, if approved by IBM to provide
warranty service, provides without charge certain types of repair and exchange
service to keep Machines in, or restore them to, conformance with their
Specifications. IBM or your reseller will inform you of the available types of service
for a Machine based on its country of installation. At its discretion, IBM or your
reseller will 1) either repair or exchange the failing Machine and 2) provide the
service either at your location or a service center. IBM or your reseller will also
manage and install selected engineering changes that apply to the Machine.
Some parts of IBM Machines are designated as Customer Replaceable Units
(called “CRUs”), e.g., keyboards, memory, or hard disk drives. IBM ships CRUs to
you for replacement by you. You must return all defective CRUs to IBM within 30
days of your receipt of the replacement CRU. You are responsible for downloading
designated Machine Code and Licensed Internal Code updates from an IBM
Internet Web site or from other electronic media, and following the instructions that
IBM provides.
When warranty service involves the exchange of a Machine or part, the item IBM or
your reseller replaces becomes its property and the replacement becomes yours.
You represent that all removed items are genuine and unaltered. The replacement
may not be new, but will be in good working order and at least functionally
equivalent to the item replaced. The replacement assumes the warranty service
status of the replaced item. Many features, conversions, or upgrades involve the
removal of parts and their return to IBM. A part that replaces a removed part will
assume the warranty service status of the removed part.
Before IBM or your reseller exchanges a Machine or part, you agree to remove all
features, parts, options, alterations, and attachments not under warranty service.
You also agree to
1. ensure that the Machine is free of any legal obligations or restrictions that
prevent its exchange;
2. obtain authorization from the owner to have IBM or your reseller service a
Machine that you do not own; and
3. where applicable, before service is provided:
a. follow the problem determination, problem analysis, and service request
procedures that IBM or your reseller provides;
b. secure all programs, data, and funds contained in a Machine;
c. provide IBM or your reseller with sufficient, free, and safe access to your
facilities to permit them to fulfill their obligations; and
d. inform IBM or your reseller of changes in a Machine's location.
Appendix D. Warranty information 39
IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM's
possession or 2) in transit in those cases where IBM is responsible for the
transportation charges.
Neither IBM nor your reseller is responsible for any of your confidential, proprietary
or personal information contained in a Machine which you return to IBM or your
reseller for any reason. You should remove all such information from the Machine
prior to its return.
Limitation of Liability
Circumstances may arise where, because of a default on IBM's part or other
liability, you are entitled to recover damages from IBM. In each such instance,
regardless of the basis on which you are entitled to claim damages from IBM
(including fundamental breach, negligence, misrepresentation, or other contract or
tort claim), except for any liability that cannot be waived or limited by applicable
laws, IBM is liable for no more than
1. damages for bodily injury (including death) and damage to real property and
tangible personal property; and
2. the amount of any other actual direct damages, up to the charges (if recurring,
12 months' charges apply) for the Machine that is subject of the claim. For
purposes of this item, the term “Machine” includes Machine Code and Licensed
Internal Code.
This limit also applies to IBM's suppliers and your reseller. It is the maximum
for which IBM, its suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS IBM LIABLE FOR ANY OF THE FOLLOWING:
1) THIRD-PARTY CLAIMS AGAINST YOU FOR DAMAGES (OTHER THAN
THOSE UNDER THE FIRST ITEM LISTED ABOVE); 2) LOSS OF, OR DAMAGE
TO, YOUR RECORDS OR DATA; OR 3) SPECIAL, INCIDENTAL, OR INDIRECT
DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES, LOST
PROFITS OR LOST SAVINGS, EVEN IF IBM, ITS SUPPLIERS OR YOUR
RESELLER IS INFORMED OF THEIR POSSIBILITY. SOME JURISDICTIONS DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION
MAY NOT APPLY TO YOU.
Governing Law
Both you and IBM consent to the application of the laws of the country in which you
acquired the Machine to govern, interpret, and enforce all of your and IBM's rights,
duties, and obligations arising from, or relating in any manner to, the subject matter
of this Agreement, without regard to conflict of law principles.
Part 2 - Country-unique Terms
AMERICAS
BRAZIL
Governing Law: The following is added after the first sentence:
Any litigation arising from this Agreement will be settled exclusively by the court of
Rio de Janeiro.
40 FAStT Host Adapter Installation and User's Guide
NORTH AMERICA
Warranty Service: The following is added to this Section:
To obtain warranty service from IBM in Canada or the United States, call
1-800-IBM-SERV (426-7378).
CANADA
Governing Law: The following replaces “laws of the country in which you acquired
the Machine” in the first sentence:
laws in the Province of Ontario.
UNITED STATES
Governing Law: The following replaces “laws of the country in which you acquired
the Machine” in the first sentence:
laws of the State of New York.
ASIA PACIFIC
AUSTRALIA
The IBM Warranty for Machines: The following paragraph is added to this
Section:
The warranties specified in this Section are in addition to any rights you may have
under the Trade Practices Act 1974 or other similar legislation and are only limited
to the extent permitted by the applicable legislation.
Limitation of Liability: The following is added to this Section:
Where IBM is in breach of a condition or warranty implied by the Trade Practices
Act 1974 or other similar legislation, IBM's liability is limited to the repair or
replacement of the goods or the supply of equivalent goods. Where that condition
or warranty relates to right to sell, quiet possession or clear title, or the goods are
of a kind ordinarily acquired for personal, domestic or household use or
consumption, then none of the limitations in this paragraph apply.
Governing Law: The following replaces “laws of the country in which you acquired
the Machine” in the first sentence:
laws of the State or Territory.
CAMBODIA, LAOS, AND VIETNAM
Governing Law: The following replaces “laws of the country in which you acquired
the Machine” in the first sentence:
laws of the State of New York.
The following is added to this Section:
Disputes and differences arising out of or in connection with this Agreement shall
be finally settled by arbitration which shall be held in Singapore in accordance with
the rules of the International Chamber of Commerce (ICC). The arbitrator or
arbitrators designated in conformity with those rules shall have the power to rule on
their own competence and on the validity of the Agreement to submit to arbitration.
The arbitration award shall be final and binding for the parties without appeal and
the arbitral award shall be in writing and set forth the findings of fact and the
conclusions of law.
Appendix D. Warranty information 41
All proceedings shall be conducted, including all documents presented in such
proceedings, in the English language. The number of arbitrators shall be three,
with each side to the dispute being entitled to appoint one arbitrator.
The two arbitrators appointed by the parties shall appoint a third arbitrator before
proceeding upon the reference. The third arbitrator shall act as chairman of the
proceedings. Vacancies in the post of chairman shall be filled by the president of
the ICC. Other vacancies shall be filled by the respective nominating party.
Proceedings shall continue from the stage they were at when the vacancy
occurred.
If one of the parties refuses or otherwise fails to appoint an arbitrator within 30 days
of the date the other party appoints its, the first appointed arbitrator shall be the
sole arbitrator, provided that the arbitrator was validly and properly appointed.
The English language version of this Agreement prevails over any other language
version.
HONG KONG AND MACAU
Governing Law: The following replaces “laws of the country in which you acquired
the Machine” in the first sentence:
laws of Hong Kong Special Administrative Region.
INDIA
Limitation of Liability: The following replaces items 1 and 2 of this Section:
1. liability for bodily injury (including death) or damage to real property and
tangible personal property will be limited to that caused by IBM's negligence;
2. as to any other actual damage arising in any situation involving
nonperformance by IBM pursuant to, or in any way related to the subject of this
Statement of Limited Warranty, IBM's liability will be limited to the charge paid
by you for the individual Machine that is the subject of the claim.
JAPAN
Governing Law: The following sentence is added to this Section:
Any doubts concerning this Agreement will be initially resolved between us in good
faith and in accordance with the principle of mutual trust.
NEW ZEALAND
The IBM Warranty for Machines: The following paragraph is added to this
Section:
The warranties specified in this Section are in addition to any rights you may have
under the Consumer Guarantees Act 1993 or other legislation which cannot be
excluded or limited. The Consumer Guarantees Act 1993 will not apply in respect
of any goods which IBM provides, if you require the goods for the purposes of a
business as defined in that Act.
Limitation of Liability: The following is added to this Section:
Where Machines are not acquired for the purposes of a business as defined in the
Consumer Guarantees Act 1993, the limitations in this Section are subject to the
limitations in that Act.
42 FAStT Host Adapter Installation and User's Guide
PEOPLE'S REPUBLIC OF CHINA (PRC)
Governing Law: The following replaces this Section:
Both you and IBM consent to the application of the laws of the State of New York
(except when local law requires otherwise) to govern, interpret, and enforce all your
and IBM's rights, duties, and obligations arising from, or relating in any manner to,
the subject matter of this Agreement, without regard to conflict of law principles.
Any disputes arising from or in connection with this Agreement will first be resolved
by friendly negotiations, failing which either of us has the right to submit the dispute
to the China International Economic and Trade Arbitration Commission in Beijing,
the PRC, for arbitration in accordance with its arbitration rules in force at the time.
The arbitration tribunal will consist of three arbitrators. The language to be used
therein will be English and Chinese. An arbitral award will be final and binding on
all the parties, and will be enforceable under the Convention on the Recognition
and Enforcement of Foreign Arbitral Awards (1958).
The arbitration fee will be borne by the losing party unless otherwise determined by
the arbitral award.
During the course of arbitration, this Agreement will continue to be performed
except for the part which the parties are disputing and which is undergoing
arbitration.
EUROPE, MIDDLE EAST, AFRICA (EMEA)
THE FOLLOWING TERMS APPLY TO ALL EMEA COUNTRIES:
The terms of this Statement of Limited Warranty apply to Machines purchased from
IBM or an IBM reseller.
Warranty Service:
If you purchase an IBM Machine in Austria, Belgium, Denmark, Estonia, Finland,
France, Germany, Greece, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg,
Netherlands, Norway, Portugal, Spain, Sweden, Switzerland or United Kingdom,
you may obtain warranty service for that Machine in any of those countries from
either (1) an IBM reseller approved to perform warranty service or (2) from IBM. If
you purchase an IBM Personal Computer Machine in Albania, Armenia, Belarus,
Bosnia and Herzegovina, Bulgaria, Croatia, Czech Republic, Georgia, Hungary,
Kazakhstan, Kirghizia, Federal Republic of Yugoslavia, Former Yugoslav Republic
of Macedonia (FYROM), Moldova, Poland, Romania, Russia, Slovak Republic,
Slovenia, or Ukraine, you may obtain warranty service for that Machine in any of
those countries from either (1) an IBM reseller approved to perform warranty
service or (2) from IBM.
If you purchase an IBM Machine in a Middle Eastern or African country, you may
obtain warranty service for that Machine from the IBM entity within the country of
purchase, if that IBM entity provides warranty service in that country, or from an
IBM reseller, approved by IBM to perform warranty service on that Machine in that
country. Warranty service in Africa is available within 50 kilometers of an IBM
authorized service provider. You are responsible for transportation costs for
Machines located outside 50 kilometers of an IBM authorized service provider.
Governing Law:
Appendix D. Warranty information 43
The applicable laws that govern, interpret and enforce rights, duties, and obligations
of each of us arising from, or relating in any manner to, the subject matter of this
Statement, without regard to conflict of laws principles, as well as Country-unique
terms and competent court for this Statement are those of the country in which the
warranty service is being provided, except that in 1) Albania, Bosnia-Herzegovina,
Bulgaria, Croatia, Hungary, Former Yugoslav Republic of Macedonia, Romania,
Slovakia, Slovenia, Armenia, Azerbaijan, Belarus, Georgia, Kazakhstan,
Kyrgyzstan, Moldova, Russia, Tajikistan, Turkmenistan, Ukraine, and Uzbekistan,
the laws of Austria apply; 2) Estonia, Latvia, and Lithuania, the laws of Finland
apply; 3) Algeria, Benin, Burkina Faso, Cameroon, Cape Verde, Central African
Republic, Chad, Congo, Djibouti, Democratic Republic of Congo, Equatorial Guinea,
France, Gabon, Gambia, Guinea, Guinea-Bissau, Ivory Coast, Lebanon, Mali,
Mauritania, Morocco, Niger, Senegal, Togo, and Tunisia, this Agreement will be
construed and the legal relations between the parties will be determined in
accordance with the French laws and all disputes arising out of this Agreement or
related to its violation or execution, including summary proceedings, will be settled
exclusively by the Commercial Court of Paris; 4) Angola, Bahrain, Botswana,
Burundi, Egypt, Eritrea, Ethiopia, Ghana, Jordan, Kenya, Kuwait, Liberia, Malawi,
Malta, Mozambique, Nigeria, Oman, Pakistan, Qatar, Rwanda, Sao Tome, Saudi
Arabia, Sierra Leone, Somalia, Tanzania, Uganda, United Arab Emirates, United
Kingdom, West Bank/Gaza, Yemen, Zambia, and Zimbabwe, this Agreement will be
governed by English Law and disputes relating to it will be submitted to the
exclusive jurisdiction of the English courts; and 5) in Greece, Israel, Italy, Portugal,
and Spain any legal claim arising out of this Statement will be brought before, and
finally settled by, the competent court of Athens, Tel Aviv, Milan, Lisbon, and
Madrid, respectively.
THE FOLLOWING TERMS APPLY TO THE COUNTRY SPECIFIED:
AUSTRIA AND GERMANY
The IBM Warranty for Machines: The following replaces the first sentence of the
first paragraph of this Section:
The warranty for an IBM Machine covers the functionality of the Machine for its
normal use and the Machine's conformity to its Specifications.
The following paragraphs are added to this Section:
The minimum warranty period for Machines is six months. In case IBM or your
reseller is unable to repair an IBM Machine, you can alternatively ask for a partial
refund as far as justified by the reduced value of the unrepaired Machine or ask for
a cancellation of the respective agreement for such Machine and get your money
refunded.
Extent of Warranty: The second paragraph does not apply.
Warranty Service: The following is added to this Section:
During the warranty period, transportation for delivery of the failing Machine to IBM
will be at IBM's expense.
Limitation of Liability: The following paragraph is added to this Section:
The limitations and exclusions specified in the Statement of Limited Warranty will
not apply to damages caused by IBM with fraud or gross negligence and for
express warranty.
44 FAStT Host Adapter Installation and User's Guide
The following sentence is added to the end of item 2:
IBM's liability under this item is limited to the violation of essential contractual terms
in cases of ordinary negligence.
EGYPT
Limitation of Liability: The following replaces item 2 in this Section:
as to any other actual direct damages, IBM's liability will be limited to the total
amount you paid for the Machine that is the subject of the claim. For purposes of
this item, the term “Machine” includes Machine Code and Licensed Internal Code.
Applicability of suppliers and resellers (unchanged).
FRANCE
Limitation of Liability: The following replaces the second sentence of the first
paragraph of this Section:
In such instances, regardless of the basis on which you are entitled to claim
damages from IBM, IBM is liable for no more than: (items 1 and 2 unchanged).
IRELAND
Extent of Warranty: The following is added to this Section:
Except as expressly provided in these terms and conditions, all statutory conditions,
including all warranties implied, but without prejudice to the generality of the
foregoing all warranties implied by the Sale of Goods Act 1893 or the Sale of
Goods and Supply of Services Act 1980 are hereby excluded.
Limitation of Liability: The following replaces items one and two of the first
paragraph of this Section:
1. death or personal injury or physical damage to your real property solely caused
by IBM's negligence; and
2. the amount of any other actual direct damages, up to 125 percent of the
charges (if recurring, the 12 months' charges apply) for the Machine that is the
subject of the claim or which otherwise gives rise to the claim.
Applicability of suppliers and resellers (unchanged).
The following paragraph is added at the end of this Section:
IBM's entire liability and your sole remedy, whether in contract or in tort, in respect
of any default shall be limited to damages.
ITALY
Limitation of Liability: The following replaces the second sentence in the first
paragraph:
In each such instance unless otherwise provided by mandatory law, IBM is liable
for no more than:
1. (unchanged)
2. as to any other actual damage arising in all situations involving nonperformance
by IBM pursuant to, or in any way related to the subject matter of this
Statement of Warranty, IBM's liability, will be limited to the total amount you
paid for the Machine that is the subject of the claim.
Appendix D. Warranty information 45
Applicability of suppliers and resellers (unchanged).
The following replaces the third paragraph of this Section:
Unless otherwise provided by mandatory law, IBM and your reseller are not liable
for any of the following: (items 1 and 2 unchanged) 3) indirect damages, even if
IBM or your reseller is informed of their possibility.
SOUTH AFRICA, NAMIBIA, BOTSWANA, LESOTHO AND SWAZILAND
Limitation of Liability: The following is added to this Section:
IBM's entire liability to you for actual damages arising in all situations involving
nonperformance by IBM in respect of the subject matter of this Statement of
Warranty will be limited to the charge paid by you for the individual Machine that is
the subject of your claim from IBM.
UNITED KINGDOM
Limitation of Liability: The following replaces items 1 and 2 of the first paragraph
of this Section:
1. death or personal injury or physical damage to your real property solely caused
by IBM's negligence;
2. the amount of any other actual direct damages or loss, up to 125 percent of the
charges (if recurring, the 12 months' charges apply) for the Machine that is the
subject of the claim or which otherwise gives rise to the claim;
The following item is added to this paragraph:
3. breach of IBM's obligations implied by Section 12 of the Sale of Goods Act 1979
or Section 2 of the Supply of Goods and Services Act 1982.
Applicability of suppliers and resellers (unchanged).
The following is added to the end of this Section:
IBM's entire liability and your sole remedy, whether in contract or in tort, in respect
of any default shall be limited to damages.
46 FAStT Host Adapter Installation and User's Guide
Appendix E. Notices
IBM may not offer the products, services, or features discussed in this document in
other countries. Consult your local IBM representative for information on the
products and services currently available in your area. Any reference to an IBM
product, program, or service is not intended to state or imply that only that IBM
product, program, or service may be used. Any functionally equivalent product,
program, or service that does not infringe any IBM intellectual property right may be
used instead. However, it is the user's responsibility to evaluate and verify the
operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you any
license to these patents. You can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
Edition Notice
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or
implied warranties in certain transactions; therefore, this statement may not apply to
you.
This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. IBM may make improvements
and/or changes in the product(s) and/or the program(s) described in this publication
at any time without notice.
Any references in this information to non-IBM Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those
Web sites. The materials at those Web sites are not part of the materials for this
IBM product and use of those Web sites is at your own risk.
IBM may use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you.
COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 1998,
2002. All rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights —
Use, duplication or disclosure is subject to restrictions set forth in GSA ADP
Schedule Contract with IBM Corp.
Copyright IBM Corp. 1998, 2002 47
Trademarks
The following terms are trademarks of International Business Machines Corporation
in the United States, other countries, or both:
IBM
IntelliStation
Netfinity
e-business logo
xSeries
Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in
the United States, other countries, or both.
Intel is a trademark of Intel Corporation in the United States, other countries, or
both.
UNIX is a registered trademark of The Open Group in the United States and other
countries.
Other company, product, or service names may be the trademarks or service marks
of others.
Electronic emission notices
Federal Communications Commission (FCC) Statement
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the
interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to
meet FCC emission limits. IBM is not responsible for any radio or television
interference caused by using other than recommended cables and connectors or by
unauthorized changes or modifications to this equipment. Unauthorized changes or
modifications could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
48 FAStT Host Adapter Installation and User's Guide
Industry Canada Class A emission compliance statement
This Class A digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d'Industrie Canada
Cet appareil numérique de classe A est conforme à la norme NMB-003 du Canada.
Australia and New Zealand Class A statement
Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
United Kingdom telecommunications safety requirement
Notice to Customers
This apparatus is approved under approval number NS/G/1234/J/100003 for
indirect connection to public telecommunication systems in the United Kingdom.
European Union EMC Directive conformance statement
This product is in conformity with the protection requirements of EU Council
Directive 89/336/EEC on the approximation of the laws of the Member States
relating to electromagnetic compatibility. IBM cannot accept responsibility for any
failure to satisfy the protection requirements resulting from a nonrecommended
modification of the product, including the fitting of non-IBM option cards.
This product has been tested and found to comply with the limits for Class A
Information Technology Equipment according to CISPR 22/European Standard EN
55022. The Limits for Class A equipment were derived for commercial and
industrial environments to provide reasonable protection against interference with
licensed communication equipment.
Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
Taiwan electrical emission statement
Appendix E. Notices 49
Japanese Voluntary Control Council for Interference (VCCI) statement
50 FAStT Host Adapter Installation and User's Guide
Index
A
about this book ix
adapter
installing 5
installing the IBM FAStT Host Adapter 6
operating environment 31
overview 3
preinstallation procedures 5
specifications 31
adapter features 3
adding
Windows 2000 device driver 17
Windows NT device driver 16
B
before you begin installing device drivers 13
C
cables
removing vi
safety vii
caution
handling static-sensitive devices 5
connecting
cables vii
G
getting help and technical assistance 33
H
handling static-sensitive devices 5
hardware installation 1
help and technical assistance, getting 33
I
installing
Novell NetWare device driver 19
the FAStT Host Adapter 5
Windows NT and Windows 2000 device drivers 15
N
notices
electronic emission 48
in this book x
product 47
safety information v
trademarks 48
Novell NetWare device driver
files and parameters 19
installing 19
D
device
static-sensitive, handling 5
device drivers, before you begin installing 13
disconnecting
cables vii
E
electrical
safety vii
electronic emission notices 48
F
Fast!UTIL utility 23
Fibre Channel
adapter features 3
what is it 3
files, Novell NetWare device driver 19
O
options, Fast!UTIL 23
overview, adapter 3
overview, software 13
P
parameters, Novell NetWare device driver 19
preface ix
problem solving 9
product notices 47
R
removing, cables vi
S
software installation 11
software, overview 13
solving problems 9
specifications
adapter 31
Copyright IBM Corp. 1998, 2002 51
static-sensitive devices, handling 5
T
tools for installation 5
trademarks 48
troubleshooting 9
U
updating
Windows 2000 device driver 18
Windows NT device driver 17
W
what you need
for the adapter installation 5
Windows 2000 device driver
adding to a previously installed system 17
updating 18
Windows NT and Windows 2000 device drivers
installing 15
Windows NT device driver
adding to a previously installed system 16
updating 17
52 FAStT Host Adapter Installation and User's Guide
