IBM 48X-20X User Manual

IBM

48X-20X Internal IDE CD-ROM Drive

User’s Guide

OPTIONS

by IBM

Note: Before using this information and the product it supports, read the information under Appendix D, ″Product warranties and notices″ on page D-1.

First Edition (September 2000)

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

About this book.....................v

Safety information ...................vii

Part 1: Installation and user’s guide .............1-1

Appendix A. Customizing device driver configuration settings . . . A-1

Appendix B. Problem solving ...............B-1

Appendix C. Help and service information ...........C-1

Appendix D. Product warranties and notices ..........D-1

iv 48X-20X Internal IDE CD-ROM Drive: User’s Guide

About this book

This manual contains instructions for installing, configuring, and troubleshooting the IBM

48X-20X Internal IDE CD-ROM Drive. The manual is

divided into the following parts:

Part 1: Installation and user’s guide

This part contains the product description and expanded installation instructions in the following languages:

v English v French v Spanish v Italian v Brazilian Portuguese v Traditional Chinese v Simplified Chinese v Japanese

Part 2: Appendixes

The appendixes contain inofrmation about product specifications, problem solving, warranties, and help and service. It also contains the product warranties and notices.

Note: The illustrations in this manual might be slightly different from your

hardware.

Registering your option

Thank you for purchasing OPTIONS by IBM. Please take a few moments to register your product and provide us with information that will help IBM to better serve you in the future. Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you. Register your option on the IBM Web site at

http://www.ibm.com/pc/register

IBM will send you information and updates on your registered product unless you indicate on the Web site questionnaire that you do not want to receive further information.

vi 48X-20X Internal IDE CD-ROM Drive: User’s Guide

Safety information

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

red inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.

Antes de instalar este producto lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

viii 48X-20X Internal IDE CD-ROM Drive: User’s Guide

Part 1: Installation and user’s guide

The IBM®48X-20X Internal IDE CD-ROM Drive can read a compact disc (CD)

containing approximately 680 MB

of information. It is designed for installation in a personal computer that uses the integrated drive electronics (IDE) or the enhanced IDE architecture.

The CD-ROM device delivers data up to 48 times the standard CD-ROM speed, delivering data at up to 7200 KB

per second. The drive reads compact discs that meet the ISO-9660 and High-Sierra Group (HSG) standards. It also reads multiple-session, extended architecture (XA) discs, such as the Kodak Photo CD.

Product description

In addition to this book, the option package includes:

v 48X-20X Internal IDE CD-ROM Drive v One “Y” audio cable, one audio cable v Four mounting screws (M3 x 5 mm, slotted) v One IDE cable for connecting two IDE devices v Laser Safety Guide for CD-ROM drives

Contact your place of purchase if an item is missing or damaged. Be sure to retain your proof of purchase. It might be required to receive warranty service.

You can find information on how to get help, technical support, and warranty service in “Appendix C. Help and service information” on page C-1. Before calling for technical support, refer to “Appendix B. Problem solving” on page B-1.

Before you begin

Determine whether your computer meets the minimum requirements; see “System requirements” on page 1-2 for details. Read the following information before you start your installation.

You must complete the following steps to install the drive:

1. Determine which IDE connector to use and the corresponding configuration

setting.

1. MB equals approximately 1 000 000 bytes when referring to storage capacity.

2. KB equals approximately 1024 bytes when referring to data transfer speeds.

1-1

2. Place or change the configuration jumper on the drive (and possibly make

changes to the configuration jumpers of other devices).

If you do not understand these procedures or are unsure about your ability to perform all the procedures described, have a qualified computer technician install the CD-ROM drive for you.

System requirements

Before you begin installing the drive, be sure your computer meets the following system requirements.

v Minimum microprocessor: 80486 v Minimum RAM: 4 MB v 5.25-inch diskette drive v Available IDE connection v Available internal power connection v Available drive bay v One of the following operating systems:

– Microsoft – Microsoft Windows – Microsoft – Microsoft Windows 2000 Professional – Microsoft Windows Millennium Edition (Me)

Handling instructions

To protect your device during installation, observe the following precautions: v Handle the drive with care. Dropping or jarring the drive can damage the

components inside the drive housing.

v Keep the device in its antistatic bag until you are ready to install the drive in

your computer. Limit your movements. Movement can cause static electricity buildup.

v Do not force insertion of the power cable. Doing so might damage the

connector or the drive.

Windows®95

Windows NT®4.0

1-2 48X-20X Internal IDE CD-ROM Drive: User’s Guide

Front view of the drive

Refer to the illustration to identify parts that might be referred to in the installation instructions.

«1¬Headphone jack. Plug headphones in here for audio output.

«2¬Volume control. Adjust this dial to control volume.

«3¬CD tray. Use the CD tray to load a CD into the drive.

«4¬Busy indicator. This light comes on when the drive reads a data CD or

plays an audio CD.

«5¬Manual-eject hole. Use this to eject the CD tray if the Eject/Load button is not operating correctly.

«6¬Eject/Load button. Push this button to open or close the CD tray.

Back view of the drive

Refer to the illustration to identify parts that might be referred to in the installation instructions.

«1¬Reserved.

«2¬Audio-out connector. This connector is used to connect the CD-ROM drive

to an audio adapter.

«3¬Configuration pins. The jumper placement on these pins determines the priority of the CD-ROM drive on the IDE bus.

Part 1: Installation and user’s guide 1-3

«4¬IDE connector. This is used to connect the CD-ROM drive to the IDE cable.

«5¬DC power connector. This is used to connect the dc power cord to the

CD-ROM drive.

Installing the drive

Follow these steps to install the CD-ROM drive in your computer.

Step 1. Opening the computer

1. Turn off the computer and all attached devices.

2. Unplug the power cords for the computer and all attached devices.

3. Remove the cover from the computer.

Step 2. Unpacking the drive

1. Before opening the antistatic bag that the drive is packed in, touch it to an

unpainted metal surface for at least two seconds. This will drain the static electricity from the package and your body.

2. Remove the drive from the antistatic bag. If you must put the drive down,

place the antistatic bag on a flat padded surface, such as a magazine, and place the drive on the antistatic bag.

Step 3. Selecting the IDE port

Newer computers typically have two IDE ports, each of which can support two devices. Typically, the IDE port to which your hard disk drive is connected is the primary IDE port. The other IDE port is the secondary port. The IDE port and the cable position that you select determine which configuration jumper setting that you use for the drive.

v If you have two IDE ports, connect the CD-ROM drive to the secondary IDE

port on your system board or IDE adapter. If the CD-ROM drive is the only device on the secondary IDE port, use the primary configuration setting. If the CD-ROM drive is the second device on the secondary port, use the secondary configuration setting.

v If you must attach the CD-ROM drive to the primary IDE port (the same

port as a hard disk drive or other fast device), use the secondary setting for the CD-ROM drive and the primary setting for the faster device. In some instances, you might need to change the hard disk drive configuration setting to master-with-secondary-present when attaching a secondary device on the same cable. For further information on setting configuration jumpers on other devices, refer to the documentation that came with your computer or with the device in question.

v Some non-IBM computers support the cable-select setting, where the

position of the device on the cable determines whether a device is primary

1-4 48X-20X Internal IDE CD-ROM Drive: User’s Guide

or secondary. See the documentation that came with your computer to determine if your computer supports this setting.

Step 4. Setting the configuration jumper

The illustration shows the primary «1¬setting, the secondary (or slave) «2¬setting, and the cable-select «3¬setting. Configure the CD-ROM drive by

placing the jumper over the set of pins corresponding to the setting you chose in Step 3. See “Step 3. Selecting the IDE port” on page 1-4.

v If you are configuring the CD-ROM device as primary, set the jumper to the

master «1¬ device setting. (This is how the drive is set when it is shipped.) If there is a second device on the IDE port, make sure that device is configured as secondary.

v If you are configuring the CD-ROM device as secondary, set the jumper to

the secondary «2¬ device setting. Make sure that the other device on the IDE port is configured as primary (or primary-with-secondary-present).

v If you are configuring the CD-ROM device as cable-select, set the jumper to

the cable-select «3¬ device setting. If there is another device on the IDE port, make sure that the second device is also configured for cable-select.

Step 5. Mounting the drive in the bay

Attention: Be sure to use the M3 x5 mm mounting screw in the option package. Using screws that are too long might damage the drive

You can mount the CD-ROM drive horizontally or vertically in the computer. If you mount the drive vertically, you must secure any CDs you place into the drive before the drive tray is closed, or the CD-ROM drive will not be able to read the CD correctly. For further instructions on securing your CDs in a vertically mounted drive, go to “Loading a CD” on page 1-9.

1. Slide the drive into the bay. Your computer might have specific required

procedures for installing storage devices. Refer to the documentation that came with your computer for further instructions.

2. Align the drive-bay screw holes with the threaded holes in the drive

housing or mounting bracket; then thread the screws in loosely to check their positions. Usually two screws are used on each side.

Part 1: Installation and user’s guide 1-5

3. Check to make sure the alignment is correct; then tighten the screws to

secure the drive. Do not overtighten.

Step 6. Attaching the cables to the drive

Connect the cables to the CD-ROM drive as follows.

1. If you have an audio adapter, locate the included audio cables and

determine which cable best fits the CD audio-in port on your audio adapter. Connect one end of the selected audio cable to the device audio-out connector «1¬, and the other end of the cable to your audio adapter CD audio-in port. Save the other cable in case you use a different audio adapter in the future.

2. Attach a 40-pin IDE cable connector «2¬to the IDE connector on the drive.

Align the cable so that the color-coded edge is closest to the power cable connector «3¬. Use the IDE cable provided with this option if there is no cable attached to the IDE port or if there is only one device connector on the IDE cable.

3. Attach a four-pin power cable «3¬ to the device dc power connector.

Step 7. Completing the hardware installation

1. Be sure that the drive is securely mounted and the connectors are firmly

attached.

2. Be sure that the cables do not interfere with the computer cover and do not

block the power-supply fan blades or air-flow paths.

3. Reinstall the computer cover.

4. Reconnect all devices and check any devices that might have become

disconnected, such as the keyboard, mouse, and monitor.

5. Connect all power cords to electrical outlets.

1-6 48X-20X Internal IDE CD-ROM Drive: User’s Guide

Step 8. Updating your computer configuration

After you have completed the hardware installation, restart your computer. Usually, the configuration-setup information screen is displayed. If this screen is not displayed, check your computer documentation for information about accessing the configuration or setup utility program.

To see the configuration information for most IBM computers, press the F1 button during startup. When you have finished reviewing the information, save the changes and exit.

Note: Some older computers with one IDE port might not display the

CD-ROM drive information when you review the configuration-setup information. You still can use the CD-ROM drive in this situation if you have correctly completed the installation.

Step 9. Installing device drivers

This section contains the instructions for installing device drivers for the CD-ROM drive, based on the operating system you are using.

Note: User requirements vary; the device driver settings for that operating

system can be customized. If your computer does not work well with the default settings given in the installation instructions in this section, refer to “Appendix A. Customizing device driver configuration settings”

on page A-1 for information on customizing your device driver

configuration settings.

Device driver for Windows 95, Windows 98, Windows NT, Windows 2000, and Windows Me

Windows 98 and Windows Me automatically detect the CD-ROM drive and do not present any installation screens. If the driver installation screens are displayed after your operating system starts, follow the instructions on the screen to install the device drivers. Consult the documentation that comes with your operating system for more information.

Part 1: Installation and user’s guide 1-7
