Registering your option
Thank you for purchasing OPTIONS by IBM. Please take a few moments to register
your product and provide us with information that will help IBM to better serve you in
the future. Your feedback is valuable to us in developing products and services that
are important to you, as well as in developing better ways to communicate with you.
Register your option on the IBM Web site at:
http://www.pc.ibm.com/register
IBM will send you information and updates on your registered product unless you
indicate on the Web site questionnaire that you do not want to receive further
information.
iv 40X-17X Internal IDE CD-ROM Drive
About this book
This manual contains information on the 40X-17X Internal IDE CD-ROM Drive. It is
divided into the following parts:
Part 1: Installation instructions in the following languages:
English
German
French
Italian
Spanish
Brazilian Portuguese
Japanese
Part 2: Instructions for using and caring for the CD-ROM drive
Part 3: Device driver special configuration settings, problem solving, help and
service information, warranty, and notices
Note: The illustrations in this manual might be slightly different from your hardware.
v
vi 40X-17X Internal IDE CD-ROM Drive
Part 1: Installation guide
Product description
The IBM 40X-17X Internal IDE CD-ROM Drive can read a compact disc (CD)
containing approximately 680 MB1 of information. It is designed for installation in a
personal computer that uses the integrated drive electronics (IDE) or the enhanced IDE
architecture.
The CD-ROM drive delivers data up to 40 times the standard CD-ROM speed,
delivering data at up to 6000 KB
the ISO-9660 and High-Sierra Group (HSG) standards. It also reads multiple-session,
extended architecture (XA) discs, such as the Kodak Photo CD.
In addition to this book, the option package includes:
40X-17X Internal IDE CD-ROM Drive
Two audio cables
Four mounting screws (M3 x 5 mm, slotted)
Two system faceplates
40X-17X Internal IDE CD-ROM Drive Option Diskette
IDE cable for connecting two IDE devices
Laser Safety Guide for CD-ROMs
Electrical Safety Guide
Contact your place of purchase if an item is missing or damaged. Be sure to retain
your proof of purchase. It might be required to receive warranty service.
The Option Diskette includes installation and support programs, such as:
Installation programs for all supported operating systems
IDE CD-ROM device drivers
Audio CD-player program for DOS
READ.ME file with additional installation information
Diagnostic program
Note: Before installing this product, refer to the Electrical Safety Guide included in
this option package for important safety information.
2
per second. The drive reads compact discs meeting
You can find information on how to get help, technical support, and warranty service
in Appendix C, “Help and service” on page 3-15. Before calling for technical
support, refer to Appendix B, “Problem solving” on page 3-8.
1
MB equals approximately 1000 000 bytes when referring to storage capacity.
2
KB equals approximately 1024 bytes when referring to data transfer speeds.
Copyright IBM Corp. 1999
1-1
Before you begin
Read the following information before you start your installation.
The installer of the drive will have to complete the following steps:
1. Determine which IDE port to use and the corresponding configuration setting
2. Set the configuration jumper on the drive (and possibly make changes to the
configuration settings of other devices)
3. Physically install the drive in a drive bay
4. Configure the system
5. Install a device driver
If you do not understand these procedures, or are unsure about your ability to perform
all the procedures described, have a qualified computer technician install the CD-ROM
drive for you, or call an IBM technical-support representative.
System requirements
Before you begin installing the drive, be sure your computer meets the following
system requirements.
Minimum processor: 80486
Minimum RAM: 4 MB
3
3.5-inch, 1.44 MB or 2.88 MB diskette drive
Available IDE connection
Available internal power connection
Available drive bay
One of the following operating systems:
– Microsoft Windows NT 4.0 or later
– Microsoft Windows 95 or Windows 98
– OS/2 3.0 or later
Handling instructions
To protect your CD-ROM drive during installation, observe the following precautions.
Handle the drive with care. Dropping or jarring the drive can damage the
components inside the drive housing.
Keep the CD-ROM drive in its antistatic bag until you are ready to install the
drive in your computer. Limit your movement. Movement can cause static
electricity buildup.
Do not force insertion of the power cable. Doing so might damage the connector
or the drive.
3
When referring to memory storage capacity, MB means approximately 1000 000 bytes; total
user-accessible capacity may vary depending on operating environment.
1-2 40X-17X Internal IDE CD-ROM Drive
Front view of the drive
Refer to the illustration to identify parts which might be referred to in the installation
instructions.
1 Headphone jack
This jack provides audio output to the headphones.
2 Volume control
This controls the audio output volume.
3 CD tray
This is where you load and unload a CD.
4 Busy indicator
This light comes on when the drive reads a data CD or plays an audio CD.
5 Manual-eject hole
This provides access to the manual eject mechanism to remove a CD from the drive.
6 Eject/Load button
Opens and closes the CD tray
Back view of the drive
Refer to the illustration to identify parts which might be referred to in the installation
instructions.
1 Reserved
2 Audio-out connector
Connects the analog audio signals to a sound adapter
3 Configuration pins
Sets the drive configuration
Part 1: Installation guide 1-3
4 IDE connector
Connects the CD-ROM drive to the IDE cable
5 DC power connector
Connects the dc power cord to the CD-ROM drive
Installing the Drive
Follow these steps to install the CD-ROM drive into your computer.
Step 1. Opening the computer
1. Turn off the computer and all attached devices.
2. Unplug the power cords for the computer and all attached devices.
3. Remove the cover from the computer.
Step 2. Unpacking the drive
1. Before opening the bag the drive is packed in, touch it to an unpainted metal
surface for at least two seconds. This will drain the static electricity from the
package and your body.
2. Remove the drive from the bag.
If you must put the drive down, place the antistatic bag on a flat padded surface,
such as a magazine, and place the drive on the bag with the component side
facing up.
Step 3. Selecting an IDE port
Newer computers typically have two IDE ports, each of which can support two
devices. Typically, the primary IDE port connects to your hard disk drive, and the
other IDE port is the secondary port. The IDE port and the cable position that you
select determine which configuration jumper setting you will use for the drive.
If you have two IDE ports, connect the CD-ROM drive to the secondary IDE port
on your system board (sometimes called the motherboard) or IDE adapter. If the
CD-ROM drive is the only device on the secondary IDE port, use the master
configuration setting. If the CD-ROM drive is the second device on the
secondary port, use the slave configuration setting.
If you must attach the CD-ROM drive to the primary IDE port (the same port as
a hard disk drive or other fast device), use the slave setting for the CD-ROM
drive and the master setting for the faster device. In some instances, you might
need to change the hard disk drive configuration setting to
master-with-slave-present when attaching a slave device on the same cable. For
further information on setting configuration jumpers on other devices, refer to the
documentation that comes with your computer or with the device in question.
1-4 40X-17X Internal IDE CD-ROM Drive
Some non-IBM computers support the cable-select setting, where the position of
the device on the cable determines whether a device is master or slave. See the
documentation that comes with your computer to determine if your system
supports this setting.
Step 4. Setting the configuration jumper
The illustration above shows the master 1 setting, the slave 2 setting, and the
cable-select 3 setting. Configure the CD-ROM drive by placing a jumper over the
set of pins corresponding to the setting you chose in “Step 3. Selecting an IDE port”.
If you are configuring the CD-ROM drive as master, set the jumper to the master
1 device setting. (This is how the drive is set when it is shipped.) If there is a
second device on the IDE port, make sure that device is configured as slave.
If you are configuring the CD-ROM drive as slave, set the jumper to the slave
2 device setting. Make sure that the other device on the IDE port is configured
as master (or master-with-slave-present).
If you are configuring the CD-ROM drive as cable-select, set the jumper to the
cable-select 3 device setting. If there is another device on the IDE port, make
sure that the second device is also configured for cable-select.
Step 5. Mounting the drive in the bay
Attention: Be sure to use the M3 x 5 mm mounting screws in the option
package. Using screws that are too long might damage the drive.
You can mount the CD-ROM drive horizontally or vertically in the computer. If you
mount the drive vertically, you must secure any CDs you place into the drive before
the drive tray is closed, or the CD-ROM drive will not be able to read the CD
properly. For further instructions on securing your CDs in a vertically mounted drive,
go to page 2-2.
1. Slide the drive into the bay. Your computer might have specific required
procedures for installing storage devices. Refer to the documentation that comes
with your computer for further instructions.
Part 1: Installation guide 1-5
2. Align the drive-bay screw holes with the threaded holes in the drive housing or
mounting bracket; then thread the screws in loosely to check their positions.
Usually two screws are used on each side.
3. Check to make sure the alignment is correct; then tighten the screws to secure the
drive. Do not overtighten.
Step 6. Attaching the cables to the drive
1. Connect the cables to the CD-ROM drive as follows.
a. Attach a 40-pin IDE-cable connector 2 to the IDE connector on the drive.
Align the cable so that the color-coded edge is closest to the power cable
connector 3 . Use the IDE cable provided with this option if there is no
cable attached to the IDE port or if there is only one device connector on the
IDE cable.
b. Attach a four-pin power-cable connector 3 to the device dc-power
connector.
c. If you have a sound card, locate the included audio cables and determine
which cable best fits the CD audio-in port on your sound card. Connect one
end of the selected audio cable to the device audio-out connector 1 , and
the other end of the cable to your sound card CD audio-in port. Save the
other cable in case you use a different sound card in the future.
Step 7. Completing the hardware installation
1. Be sure that the drive is securely mounted and the connectors are firmly attached.
2. Be sure the cables do not interfere with the computer cover and do not block the
power-supply fan blades or air-flow paths.
3. Reinstall the computer cover.
4. Reconnect all devices and check any devices that might have become
disconnected, such as the keyboard, mouse, and monitor.
5. Plug all power cords into electrical outlets.
1-6 40X-17X Internal IDE CD-ROM Drive
Step 8. Attaching the faceplates
This option package includes two faceplates that conform to the curved design of
certain systems. If your computer system has a curved design, you can attach one of
the included faceplates so that the front of the CD-ROM drive matches the exterior
cabinet. Choose the faceplate that best fits your system, and attach it after you have
mounted the CD-ROM drive in the appropriate bay.
Step 9. Updating your computer configuration
After you have completed the hardware installation, restart your computer. Usually,
the configuration-setup information screen will be displayed. If this screen is not
displayed, check your computer documentation for information about accessing the
configuration or setup utility program.
To see the configuration information for most IBM computers, press F1 during startup
when the graphic displays in the upper right corner of the screen. When you have
finished reviewing the information, save the changes and exit.
Note: Some older computers with one IDE port might not display the CD-ROM
drive information when you review the configuration-setup information. You still
can use the CD-ROM drive in this situation as long as you have properly
completed the installation.
Step 10. Installing device drivers
This section contains the instructions for installing device drivers for the CD-ROM
drive, based on the operating system you are using. Go to the section which
corresponds to your operating system.
Note: User requirements vary; if you are using DOS or OS/2 as your operating
system, the device driver settings for those operating systems can be customized.
If your system does not work well with the default settings given in the
installation instructions in this section, refer to Appendix A, “Customizing device
driver configuration settings” on page 3-1 for information on how to customize
your device driver configuration settings.
Installing the device driver for Windows 95 and Windows 98
In most instances, Windows 95 and Windows 98 will automatically detect the
CD-ROM drive and not present any installation screens. If Windows 95 or Windows
98 is in 32-bit mode for IDE, the CD-ROM drive will be recognized by the operating
system and the driver installation screens will be displayed.
Part 1: Installation guide 1-7
Installing the device driver for DOS and OS/2
1. Turn on your computer and start your operating system, if you have not already
done so.
2. Go to a command line.
3. Insert the 40X-17X Internal IDE CD-ROM Drive Option Diskette into your
diskette drive.
4. Type A:CDSETUP in the command line; then press Enter.
5. Using your mouse or the arrow keys, select Setup; then press Enter.
6. Follow the instructions on your screen to properly install the driver.
7. When setup is complete, select Exit.
8. When prompted, restart your system; the changes will not take effect until you do
so.
Note: To resolve resource conflicts or if you need options that are not found in
the CDSETUP device-driver installation program, refer to the READ.ME file on
the Option Diskette. If you have problems installing the device driver, refer to the
CDSETUP program help information.
Installing the device driver for Windows NT 4.0
Windows NT 4.0 automatically detects the presence of the CD-ROM drive. No
additional steps are required to activate the device drivers. If your operating system
does not automatically detect the CD-ROM drive, refer to the documentation that
comes with your operating system to see what course of action you need to take.
Some computers that come with Windows NT pre-installed contain a PIIXIDE device
driver. This device driver replaces the Windows NT native ATAPI device driver, and
provides DMA support. The IDE CD-ROM will not work if both the ATAPI and
PIIXIDE device drivers are enabled at the same time. To determine which device
driver is enabled:
1. Click Start --> Settings --> Control Panel.
2. Double-click System.
3. Click the Device Manager tab.
4. Double-click CD-ROM to display a list of available device drivers.
5. Click one of the listed device drivers; then click the Properties button.
6. Click the Settings tab and determine if the driver is enabled or not.
7. Perform the above steps for the other driver.
8. Enable the driver you wish to use.
9. Shut down and restart your computer.
1-8 40X-17X Internal IDE CD-ROM Drive
Installation guide (Translated)
Product description
The IBM 40X-17X Internal IDE CD-ROM Drive can read a compact disc (CD)
containing approximately 680 MB4 of information. It is designed for installation in a
personal computer that uses the integrated drive electronics (IDE) or the enhanced IDE
architecture.
The CD-ROM drive delivers data up to 40 times the standard CD-ROM speed,
5
delivering data at up to 6000 KB
per second. The drive reads compact discs meeting
the ISO-9660 and High-Sierra Group (HSG) standards. It also reads multiple-session,
extended architecture (XA) discs, such as the Kodak Photo CD.
In addition to this book, the option package includes:
40X-17X Internal IDE CD-ROM Drive
Two audio cables
Four mounting screws (M3 x 5 mm, slotted)
Two system faceplates
40X-17X Internal IDE CD-ROM Drive Option Diskette
IDE cable for connecting two IDE devices
Laser Safety Guide for CD-ROMs
Electrical Safety Guide
Contact your place of purchase if an item is missing or damaged. Be sure to retain
your proof of purchase. It might be required to receive warranty service.
The Option Diskette includes installation and support programs, such as:
Installation programs for all supported operating systems
IDE CD-ROM device drivers
Audio CD-player program for DOS
READ.ME file with additional installation information
Diagnostic program
Note: Before installing this product, refer to the Electrical Safety Guide included in
this option package for important safety information.
You can find information on how to get help, technical support, and warranty service
in Appendix C, “Help and service” on page 3-15. Before calling for technical
support, refer to Appendix B, “Problem solving” on page 3-8.
4
MB equals approximately 1000 000 bytes when referring to storage capacity.
5
KB equals approximately 1024 bytes when referring to data transfer speeds.
Part 1: Installation guide 1-9
Before you begin
Read the following information before you start your installation.
The installer of the drive will have to complete the following steps:
1. Determine which IDE port to use and the corresponding configuration setting
2. Set the configuration jumper on the drive (and possibly make changes to the
configuration settings of other devices)
3. Physically install the drive in a drive bay
4. Configure the system
5. Install a device driver
If you do not understand these procedures, or are unsure about your ability to perform
all the procedures described, have a qualified computer technician install the CD-ROM
drive for you, or call an IBM technical-support representative.
System requirements
Before you begin installing the drive, be sure your computer meets the following
system requirements.
Minimum processor: 80486
Minimum RAM: 4 MB
6
3.5-inch, 1.44 MB or 2.88 MB diskette drive
Available IDE connection
Available internal power connection
Available drive bay
One of the following operating systems:
– Microsoft Windows NT 4.0 or later
– Microsoft Windows 95 or Windows 98
– OS/2 3.0 or later
Handling instructions
To protect your CD-ROM drive during installation, observe the following precautions.
Handle the drive with care. Dropping or jarring the drive can damage the
components inside the drive housing.
Keep the CD-ROM drive in its antistatic bag until you are ready to install the
drive in your computer. Limit your movement. Movement can cause static
electricity buildup.
Do not force insertion of the power cable. Doing so might damage the connector
or the drive.
6
When referring to memory storage capacity, MB means approximately 1000 000 bytes; total
user-accessible capacity may vary depending on operating environment.
1-10 40X-17X Internal IDE CD-ROM Drive
Front view of the drive
Refer to the illustration to identify parts which might be referred to in the installation
instructions.
1 Headphone jack
This jack provides audio output to the headphones.
2 Volume control
This controls the audio output volume.
3 CD tray
This is where you load and unload a CD.
4 Busy indicator
This light comes on when the drive reads a data CD or plays an audio CD.
5 Manual-eject hole
This provides access to the manual eject mechanism to remove a CD from the drive.
6 Eject/Load button
Opens and closes the CD tray
Back view of the drive
Refer to the illustration to identify parts which might be referred to in the installation
instructions.
1 Reserved
2 Audio-out connector
Connects the analog audio signals to a sound adapter
3 Configuration pins
Sets the drive configuration
Part 1: Installation guide 1-11
4 IDE connector
Connects the CD-ROM drive to the IDE cable
5 DC power connector
Connects the dc power cord to the CD-ROM drive
Installing the Drive
Follow these steps to install the CD-ROM drive into your computer.
Step 1. Opening the computer
1. Turn off the computer and all attached devices.
2. Unplug the power cords for the computer and all attached devices.
3. Remove the cover from the computer.
Step 2. Unpacking the drive
1. Before opening the bag the drive is packed in, touch it to an unpainted metal
surface for at least two seconds. This will drain the static electricity from the
package and your body.
2. Remove the drive from the bag.
If you must put the drive down, place the antistatic bag on a flat padded surface,
such as a magazine, and place the drive on the bag with the component side
facing up.
Step 3. Selecting an IDE port
Newer computers typically have two IDE ports, each of which can support two
devices. Typically, the primary IDE port connects to your hard disk drive, and the
other IDE port is the secondary port. The IDE port and the cable position that you
select determine which configuration jumper setting you will use for the drive.
If you have two IDE ports, connect the CD-ROM drive to the secondary IDE port
on your system board (sometimes called the motherboard) or IDE adapter. If the
CD-ROM drive is the only device on the secondary IDE port, use the master
configuration setting. If the CD-ROM drive is the second device on the
secondary port, use the slave configuration setting.
If you must attach the CD-ROM drive to the primary IDE port (the same port as
a hard disk drive or other fast device), use the slave setting for the CD-ROM
drive and the master setting for the faster device. In some instances, you might
need to change the hard disk drive configuration setting to
master-with-slave-present when attaching a slave device on the same cable. For
further information on setting configuration jumpers on other devices, refer to the
documentation that comes with your computer or with the device in question.
1-12 40X-17X Internal IDE CD-ROM Drive
Some non-IBM computers support the cable-select setting, where the position of
the device on the cable determines whether a device is master or slave. See the
documentation that comes with your computer to determine if your system
supports this setting.
Step 4. Setting the configuration jumper
The illustration above shows the master 1 setting, the slave 2 setting, and the
cable-select 3 setting. Configure the CD-ROM drive by placing a jumper over the
set of pins corresponding to the setting you chose in “Step 3. Selecting an IDE port”.
If you are configuring the CD-ROM drive as master, set the jumper to the master
1 device setting. (This is how the drive is set when it is shipped.) If there is a
second device on the IDE port, make sure that device is configured as slave.
If you are configuring the CD-ROM drive as slave, set the jumper to the slave
2 device setting. Make sure that the other device on the IDE port is configured
as master (or master-with-slave-present).
If you are configuring the CD-ROM drive as cable-select, set the jumper to the
cable-select 3 device setting. If there is another device on the IDE port, make
sure that the second device is also configured for cable-select.
Step 5. Mounting the drive in the bay
Attention: Be sure to use the M3 x 5 mm mounting screws in the option
package. Using screws that are too long might damage the drive.
You can mount the CD-ROM drive horizontally or vertically in the computer. If you
mount the drive vertically, you must secure any CDs you place into the drive before
the drive tray is closed, or the CD-ROM drive will not be able to read the CD
properly. For further instructions on securing your CDs in a vertically mounted drive,
go to page 2-2.
1. Slide the drive into the bay. Your computer might have specific required
procedures for installing storage devices. Refer to the documentation that comes
with your computer for further instructions.
Part 1: Installation guide 1-13
Loading...
