IPPC1505-RE
IPPC1705-RE
IPPC1905-RE
Expandable Panel PC
User’s Manual
Version 1.0
(Mar. 2019)
ii
IPPC1505/1705/1905-RE User Manual
Copyright
© 2019 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
IPPC1505/1705/1905-RE User Manual
iii
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Compliance
This product may cause radio interference in which case users may be required to
take adequate measures.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
Operation is subject to the following two conditions:
• This product may not cause harmful interference
• This product must accept any interference received including interference that may cause
undesired operation.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment causes harmful interference to radio or television reception which can be
determined by turning the equipment off and on, you may correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the distributor or an experienced radio/TV technician for help.
WEEE
iv
IPPC1505/1705/1905-RE User Manual
This product complies with the current RoHS restrictions that prohibit
the use of the following substances in concentrations exceeding 0.1%
by weight (1000 ppm) except for cadmium, limited to 0.01% by weight
(100 ppm).
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent chromium (Cr6+)
• Polybrominated biphenyls (PBB)
• Polybrominated diphenyl ether (PBDE)
Green IBASE
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
• Put the device horizontally on a stable and solid surface during installation in
case the device may fall, causing serious damage.
• Leave plenty of space around the device for ventilation.
• Use this product in environments with ambient temperatures between 0˚C and
40˚C.
• DO NOT LEAVE THIS DEVICE IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY BE BELOW -20° C OR ABOVE 60° C. To
prevent from damages, the device must be used in a controlled environment.
• Keep the device away from humidity to avoid fog or condensation from
accumulating on the inner surface of the panel.
Care for your IBASE products:
• Before cleaning the device, turn it off and unplug all cables in case a small
amount of electrical current may still flow.
• Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
• Use a computer vacuum cleaner to remove dust to prevent the air vent or slots
from getting clogged.
IPPC1505/1705/1905-RE User Manual
v
WARNING
CAUTION
Attention during use:
• Do not use this product near water.
• Do not spill water or any other liquids on your device.
• Do not place heavy objects on the top of the device.
• Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
• Ensure to use the correct power supply voltage.
• Do not walk on the power cord or allow anything to rest on it.
• If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
Disassembly, modification, or any attempt at repair could generate hazards and
cause damage to the device, even bodily injury or property damage, and will void any
warranty on the product.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
• IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
• 3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices,
power adapter, panel and touch screen.
＊ Products, however, that fail due to misuse, accident, improper installation or
unauthorized repair shall be treated as out of warranty and customers shall be
billed for repair and shipping charges.
vi
IPPC1505/1705/1905-RE User Manual
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any assistance from your distributor or sales representative
concerning problems that you may have encountered, please prepare the
following information:
• Product model name
• Product serial number
• Detailed description of the problem
• Error messages in text or in screenshots if there is any
• The arrangement of the peripherals
• Software used (such as OS and application software, including the version
numbers)
3. For repair service, please download the RMA form from
http://www.ibase.com.tw/english/Supports/RMAService/.
Fill out the form and contact your distributor or sales representative.
IPPC1505/1705/1905-RE User Manual
vii
Table of Contents
Compliance.................................................................................................... iii
Important Safety Information ....................................................................... iv
WARNING ....................................................................................................... v
CAUTION ........................................................................................................ v
Warranty Policy .............................................................................................. v
Technical Support & Services ..................................................................... vi
Chapter 1 General Information ................................................................ 1
1.1 Introduction ............................................................................................. 2
1.2 Features .................................................................................................. 2
1.3 Packing List ............................................................................................ 3
1.4 Specifications .......................................................................................... 4
1.5 Overview ................................................................................................. 6
1.6 Dimensions ............................................................................................. 8
Chapter 2 Hardware Configuration ....................................................... 11
2.1 Installations ........................................................................................... 12
2.1.1 Rear Cover Disassembly ........................................................ 12
2.1.2 Memory Replacement ............................................................. 13
2.1.3 SSD Replacement .................................................................. 13
2.1.4 Mini-PCIe Installation .............................................................. 14
2.1.5 VESA Mounting Installation .................................................... 14
2.2 Pin out for COM1 & COM2 .................................................................... 15
2.3 Setting the Jumpers .............................................................................. 16
2.3.1 How to Set the Jumpers ......................................................... 16
2.4 Jumper & Connector Locations ............................................................. 17
2.5 Jumpers Quick Reference ..................................................................... 18
2.5.1 LVDS Power Selection (J16) ................................................ 18
2.5.2 PCIe (x16) Bifurcation Selection (J10 & J11) ........................ 19
2.5.3 Clearing ME Register (J21) .................................................. 20
2.5.4 Clearing CMOS Data (J22) .................................................. 21
2.6 Connectors Quick Reference ................................................................ 22
2.6.1 COM1 & COM2 RS-232/422/485 Ports (CN1) ...................... 23
2.6.2 COM3 ~ COM6 RS-232 Ports (J1, J2, J3, J4) ...................... 24
viii
IPPC1505/1705/1905-RE User Manual
2.6.3 20-pin ATX Power Connector (J5) ........................................ 25
2.6.4 Digital I/O Connector (J6) ..................................................... 26
2.6.5 4-pin ATX 12V Power Connector (J7) .................................. 26
2.6.6 Battery Connector (J24) ....................................................... 27
2.6.7 Front Panel Audio Connector (J23) ................................ ...... 27
2.6.8 Front Panel Settings Connector (J25) .................................. 28
2.6.9 LCD Backlight Connector (JP2)............................................ 29
2.6.10 LVDS Connector (JP3, JP4) ................................................. 29
2.6.11 USB 2.0 Connector (JP6, JP8) ............................................. 30
2.6.12 CPU Fan Power Connector (CPU_FAN1) ............................ 30
2.6.13 System Fan Power Connector (SYS_FAN1, SYS_FAN2) ....... 31
Chapter 3 Driver Installation ................................................................. 32
3.1 Introduction ........................................................................................... 33
3.2 Intel® Chipset Software Installation Utility .............................................. 33
3.3 HD Graphics Driver Installation ............................................................. 34
3.4 HD Audio Driver Installation .................................................................. 35
3.5 LAN Driver Installation .......................................................................... 36
3.6 Intel® Management Engine Driver Installation ....................................... 38
Chapter 4 BIOS Setup ............................................................................ 40
4.1 Introduction ........................................................................................... 41
4.2 BIOS Setup ........................................................................................... 41
4.3 Main Settings ........................................................................................ 42
4.4 Advanced Settings ................................................................................ 43
4.4.1 CPU Configuration .................................................................. 44
4.4.2 PCH-FW Configuration ........................................................... 45
4.4.3 Trusted Computing ................................................................. 46
4.4.4 ACPI Settings ......................................................................... 47
4.4.5 LVDS (eDP/DP) Configuration ................................................ 48
4.4.6 iSmart Controller ..................................................................... 49
4.4.7 Fintek Super IO Configuration ................................................ 50
4.4.8 Fintek Super I/O Hardware Monitor ........................................ 57
4.4.9 CSM Configuration ................................ ................................. 58
4.4.10 NVMe Configuration ............................................................... 59
4.4.11 USB Configuration .................................................................. 60
4.5 Chipset Settings .................................................................................... 61
4.5.1 System Agent (SA) Configuration ........................................... 61
4.5.2 PCH-IO Configuration ............................................................. 63
4.6 Security Settings ................................................................................... 65
4.7 Boot Settings......................................................................................... 66
IPPC1505/1705/1905-RE User Manual
ix
4.8 Save & Exit Settings.............................................................................. 67
Appendix ...................................................................................................... 68
A. I/O Port Address Map ............................................................................ 69
B. Interrupt Request Lines (IRQ) ............................................................... 72
C. Watchdog Timer Configuration .............................................................. 74
1
Chapter 1
General Information
The information provided in this chapter includes:
• Features
• Packing List
• Specifications
• Overview
• Dimensions
2
IPPC1505/1705/1905-RE User Manual
1.1 Introduction
IPPC1505-RE, IPPC1705-RE and IPPC1905-RE are 15”, 17” and 19”
expandable touch panel PC, ideal for industrial automation, factory
automation applications. The three products are powered by Intel® Core™
i7/i5/i3 based processor, and come with the level of IP65 ingress protection for
the front bezel to provide good quality of water-tight.
1.2 Features
• Resistive touch screen and fanless design
• Cost effective model & Low power consumption
• IP65-rated front bezel
• Front side accessible USB port and rich I/O interface
• Two PCIe (x8) expansion slots
General Information
IPPC1505/1705/1905-RE User Manual
3
1
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
have purchased the product.
IPPC1505-RE:
• IPPC1505-RE x 1
• Power Adapter x 1
• Power Cord x 1
• Panel Mounting Triangle Bracket x 8
• Short Screws x 16
(M3*6, for mounting the triangle brackets onto the device)
• Long Screws x 8
(M4*35, for mounting the device on wall)
• Rubber Spacer (D2.7mm) x 1
• Silicon Rubber x 1
IPPC1705-RE:
• IPPC1705-RE x 1
• Power Adapter x 1
• Power Cord x 1
• Panel Mounting Triangle Bracket x 8
• Short Screws x 16
(M3*6, for mounting the triangle brackets onto the device)
• Long Screws x 8
(M4*35, for mounting the device on wall)
• Rubber Spacer (D2.7mm) x 1
• Silicon Rubber x 1
IPPC1905-RE:
• IPPC-1905-RE x 1
• Power Adapter x 1
• Power Cord x 1
• Panel Mounting Triangle Bracket x 10
• Short Screws x 20
(M3*6, for mounting the triangle brackets onto the device)
• Long Screws x 10
(M4*35, for mounting the device on wall)
• Rubber Spacer (D2.7mm) x 1
• Silicon Rubber x 1
4
IPPC1505/1705/1905-RE User Manual
Product Name
IPPC1505-RE
IPPC1705-RE
IPPC1905-RE
Display & Touch Screen
Display Size
15” TFT-LCD
17” TFT-LCD
19” TFT-LCD
Max. Resolution
1024 x 768
1280 x 1024
1280 x 1024
Luminance (cd/m2)
420
350
350
Contrast
600:1
800:1
1000:1
Max. Color
16.2M
16.7M
16.7M
View Angle (H°/V°)
160/160
160/140
170/160
Backlight Lifetime
(hrs)
50,000
Touch Type
Resistive
Touch Interface
USB
Light Transmission
(%)
79
Point of Touch
1
I/O Interface
USB 3.0
6
USB 2.0
1 at front bezel
RS-232/422/485
(Selectable under
BIOS)
1
RS-232
1
LAN
2 x GbE
Additional
Graphics
• 1 x DVI-D
• 1 x DisplayPort
• 1 x HDMI (1.4)
Audio
Line-In, Line-Out, Mic-In jacks (3.5 mm)
Digital I/O
Optional 4-In/4-Out GPIO
Power Connector
3-Pin Terminal Block
Power Button
Rocker Switch
Mechanical
Dimensions (mm)
410 x 335 x 126.3
442 x 377 x 132.8
480 x 415 x 127.6
Net Weight (kg)
9.3
10
10.5
1.4 Specifications
General Information
IPPC1505/1705/1905-RE User Manual
5
1
System
Processor
Intel® Core™
• i7-6822EQ
• i5-6442EQ
• i3-6102E
Memory
2 x DDR4 SO-DIMM, up to 32 GB, default 4 GB
Thermal Design
Fanless
Membrane Control
N/A
Built-in Speaker /
Mic
N/A
Motherboard
MI992
Operating System
Windows 10, 7 (32/64-bit) & Linux Kernel 3+
Expansion
Internal Expansion
Bus
• 1 x M.2 M2280
• 1 x Mini-PCIe full/half size with mSATA
Expansion Slot
2 x PCIe (x8) slots
Wireless
Optional
Storage Space
SSD
2 x 2.5” SATA3 SSD
(One 64G SSD is included by default)
Removable
N/A
Power
Power Input Range
12V / 24V DC Input
Construction
Chassis Material
Aluminum & SGCC
Color (Front /Back)
Black / Black
IP Rating
IP65 for front panel
Mounting
VESA 75 x 75 mm / 100 x 100 mm
Environment
Operating
Temperature
• With SSD: 0 ~ 50°C (32 ~ 122°F)
• With HDD: 0 ~ 40°C (32 ~ 104°F)
Storage
Temperature
-20 ~ 70 °C (-4 ~ 158 °F)
Storage Humidity
10 ~ 90% (non-condensing) at 40 °C
Certification
CE, FCC Class B, LVD
All specifications are subject to change without prior notice.
6
IPPC1505/1705/1905-RE User Manual
(with a USB 2.0 Port)
1.5 Overview
Front View
Oblique View
IPPC1505/1705/1905-RE User Manual
7
1
No.
Name
No.
Name
1
DC-In Power Connector
(3-pin terminal block, 12 ~
24V)
7
DisplayPort
2
Power Switch
8
USB 3.0 Ports
3
Reserved Shutoffs for Digital
I/O and COM3/4 Ports
9
Audio Jacks
(From top to bottom: Line-In,
Line-Out, Mic-In)
4
COM1 RS-232/422/485 &
COM2 RS-232 Ports
10
PCIe (x8) Expansion Card
Slots
5
HDMI Port
11
GbE LAN Port
6
DVI-D Port
I/O View
General Information
8
IPPC1505/1705/1905-RE User Manual
1.6 Dimensions
IPPC1505-RE:
Unit: mm
IPPC1505/1705/1905-RE User Manual
9
1
IPPC1705-RE:
General Information
Unit: mm
10
IPPC1505/1705/1905-RE User Manual
IPPC1905-RE:
Unit: mm
11
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
• Memory installation and membrane keypad extension
• Information and locations of connectors
12
IPPC1505/1705/1905-RE User Manual
2.1 Installations
Avoid device disassembly: Disassembly, modification, or any attempt at repair
could generate hazards and cause damage to the device, injury, or property damage,
and will void any warranty. If you need to make any changes to the device, be sure to
unplug the power cord of the device and have qualified engineers or technicians do
the disassembly or installation.
2.1.1 Rear Cover Disassembly
In case you need to remove the rear cover to install a memory module, a miniPCIe card or any expansion card, unscrew the 17 screws as shown below to
remove the rear cover.
Hardware Configuration
IPPC1505/1705/1905-RE User Manual
13
2
2.1.2 Memory Replacement
To replace or install memory modules, perform the following steps after
removing the system rear cover.
1. Press the ejector tab of the memory slot outwards with your fingertips.
2. Hold the meomry module and align the key of the module with that on the
memory slot.
3. Gently push the module in an upright position unitl the ejector tabs of the
memory slot close to hold the module in place when the module touches
the bottom of the slot.
To remove the module, press the ejector tabs outwards with your fingertips to
eject the module.
2.1.3 SSD Replacement
1. After removing the rear covers, unscrew the following 4 screws to remove
an SSD tray.
2. Unplug the cables of the SSD. Unscrew the 4 screws on the bottom of the
tray to release the SSD and replace it with a new one.
3. Secure the new SSD to the tray, fix it onto the motherboard, and connect
the cables.
14
IPPC1505/1705/1905-RE User Manual
2.1.4 Mini-PCIe Installation
To replace or install a mini-PCIe card, perform the following steps after
removing the rear cover.
1. Locate the mini-PCIe slot, align the key of the card to the interface, and
insert the card slantwise.
2. Push the card down and fix it with the supplied flat head screw.
2.1.5 VESA Mounting Installation
You will need to prepare the VESA mount bracket in advance. Tighten 4
VESA screws as shown below to mount the device onto your VESA bracket.
Hardware Configuration
IPPC1505/1705/1905-RE User Manual
15
2
➔
COM1
COM2
Pin
Signal Name
Pin
Signal Name
1
DCD, Data carrier detect
6
DSR, Data set ready
2
RXD, Receive data
7
RTS, Request to send
3
TXD, Transmit data
8
CTS, Clear to send
4
DTR, Data terminal ready
9
RI, Ring indicator
5
Ground
Pin
Signal Name
RS-232
RS-422
RS-485
1
DCD
TX-
DATA-
2
RX
TX+
DATA+
3
TX
RX+
NC
4
DTR
RX-
NC
5
Ground
Ground
Ground
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC
9
RI
NC
NC
Pin
Signal Name
Pin
Signal Name
1
DCD, Data carrier detect
6
DSR, Data set ready
2
RXD, Receive data
7
RTS, Request to send
3
TXD, Transmit data
8
CTS, Clear to send
4
DTR, Data terminal ready
9
RI, Ring indicator
5
Ground
1
6
5
9
1
6
5
9
2.2 Pin out for COM1 & COM2
• COM1 RS232/422/485 Port
COM 1 is features jumperless selection for RS-232/422/485 and configurable
in BIOS.
• COM2 RS-232 Port
16
IPPC1505/1705/1905-RE User Manual
A 3-pin jumper
A jumper cap
Pin closed
Oblique view
Illustration
Open
1-2
2-3
Pin# 1
2
3
1 2 3
1 2 3
1 2 3
2.3 Setting the Jumpers
Configure the jumpers with the settings required to be able to use the features
needed for your application. Contact your supplier if you have doubts about
the best configuration for your use.
2.3.1 How to Set the Jumpers
Jumpers are short-length conductors consisting of several metal pins with a
non-conductive base mounted on the circuit board. Jumper caps are used to
have the functions and features enabled or disabled. If a jumper has 3 pins,
you can connect either PIN1 to PIN2 or PIN2 to PIN3 by shorting with the
jumper cap.
Refer to the illustration below to set the jumpers.
When two pins of a jumper are encased in a jumper cap, this jumper is
closed, i.e. turned On.
When a jumper cap is removed from two jumper pins, this jumper is open, i.e.
turned Off.
IPPC1505/1705/1905-RE User Manual
17
2
2.4 Jumper & Connector Locations
Motherboard: MI992
Hardware Configuration
18
IPPC1505/1705/1905-RE User Manual
Function
Connector Name
Page
LVDS Power Selection
J16
18
PCIe (x16) Bifurcation Selection
J10, J11
19
ME Register Clearance
J21
20
CMOS Data Clearance
J22
21
Factory Use Only
J20
- -
Function
Pin closed
Illustration
3.3V
(default)
1-2
5V
2-3
1
1
1
2.5 Jumpers Quick Reference
2.5.1 LVDS Power Selection (J16)
Hardware Configuration
IPPC1505/1705/1905-RE User Manual
19
2
J10
J11
Function
Pin closed
Illustration
1 x PCIe
(x16)
(default)
J10: Open
J11: Open
2 x PCIe (x8)
J10: Open
J11: Close
1 x PCIe (x8)
2 x PCIe (x4)
J10: Close
J11: Close
1
111
111
2.5.2 PCIe (x16) Bifurcation Selection (J10 & J11)
20
IPPC1505/1705/1905-RE User Manual
Function
Pin closed
Illustration
Normal
(default)
1-2
Clear ME
2-3
1
1
1
2.5.3 Clearing ME Register (J21)
IPPC1505/1705/1905-RE User Manual
21
2
Function
Pin closed
Illustration
Normal
(default)
1-2
Clear CMOS
2-3
1
1
1
2.5.4 Clearing CMOS Data (J22)
Hardware Configuration
22
IPPC1505/1705/1905-RE User Manual
Function
Connector Name
Page
COM1 & COM2 RS-232/422/485 Ports
CN1
23
COM3 ~ COM6 RS-232 Ports
J1 (COM6), J2 (COM5),
J3 (COM4), J4 (COM3)
24
20-pin ATX Power Connector
J5
25
Digital I/O Connector
J6
26
4-pin ATX 12V Power Connector
J7
26
Battery Connetor
J24
27
Front Panel Audio Connector
J23
27
Front Panel Settings Connector
J25
28
LCD Backlight Connector
JP2
29
LVDS Connector
JP3, JP4
29
USB 2.0 Connector
JP6, JP8
30
CPU Fan Power Connector
CPU_FAN1
30
System Fan Power Connector
SYS_FAN1,
SYS_FAN2
31
DDR4 SO-DIMM Slot
J12, J13
- -
M.2 M2280 slot
J15
- -
Mini-PCIe / mSATA Slot
J18, J26*
- -
HDMI Port
CN2
- -
DVI-D
CN3
- -
USB 3.0 Port
CN4
- -
DisplayPort
CN5
- -
SATA 3.0 Port
CN6*, CN8*, CN9,
CN11
- -
GbE LAN & USB 3.0 Ports
CN7, CN10
- -
HD Audio Connector
CN12
- -
Factory Use Only
J20, JP5, JP7
- -
2.6 Connectors Quick Reference
* CN6, CN8, and J26 are only available for MI992VF only.
Hardware Configuration
IPPC1505/1705/1905-RE User Manual
23
2
COM1:
COM2:
Pin
Signal Name
Pin
Signal Name
1
DCD, Data carrier detect
6
DSR, Data set ready
2
RXD, Receive data
7
RTS, Request to send
3
TXD, Transmit data
8
CTS, Clear to send
4
DTR, Data terminal ready
9
RI, Ring indicator
5
Ground
Pin
Signal Name
RS-232
RS-422
RS-485
1
DCD
TX-
DATA-
2
RX
TX+
DATA+
3
TX
RX+
NC
4
DTR
RX-
NC
5
Ground
Ground
Ground
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC 9 RI
NC
NC
1
6
5
9
1
6
5
9
2.6.1 COM1 & COM2 RS-232/422/485 Ports (CN1)
24
IPPC1505/1705/1905-RE User Manual
J4: COM3
J3: COM4
J2: COM5
J1: COM6
Pin
Signal Name
Pin
Signal Name
1
DCD#
2
SIN#
3
SOUT
4
DSR#
5
GND
6
DTR#
7
RTS#
8
CTS#
9
RI#
10
KEY
10
2
9
1
2.6.2 COM3 ~ COM6 RS-232 Ports (J1, J2, J3, J4)
IPPC1505/1705/1905-RE User Manual
25
2
Pin
Signal Name
Pin
Signal Name
1
3.3V
11
3.3V
2
3.3V
12
-12V
3
Ground
13
Ground
4
+5V
14
PS-ON
5
Ground
15
Ground
6
+5V
16
Ground
7
Ground
17
Ground
8
Power good
18
-5V
9
5VSB
19
+5V
10
+12V
20
+5V
2.6.3 20-pin ATX Power Connector (J5)
Hardware Configuration
26
IPPC1505/1705/1905-RE User Manual
(4-In, 4-Out)
Pin
Signal Name
Pin
Signal Name
1
Ground
2
+5V
3
Out3
4
Out1
5
Out2
6
Out0
7
IN3
8
IN1
9
IN2
10
IN0
Pin
Signal Name
Pin
Signal Name
1
Ground
3
+12V
2
Ground
4
+12V
102
91
3
4
1
2
2.6.4 Digital I/O Connector (J6)
2.6.5 4-pin ATX 12V Power Connector (J7)
IPPC1505/1705/1905-RE User Manual
27
2
Pin
Signal Name
Pin
Signal Name
1
Battery+
2
Ground
Pin
Signal Name
Pin
Signal Name
1
MIC IN_L
2
Ground
3
MIC IN_R
4
DET
5
LINE_R
6
Ground
7
Sense
8
KEY
9
LINE_L
10
Ground
1
9
1
10
2
2.6.6 Battery Connector (J24)
Hardware Configuration
2.6.7 Front Panel Audio Connector (J23)
28
IPPC1505/1705/1905-RE User Manual
Pin
Signal Name
Pin
Signal Name
1
Power BTN
2
Power BTN
3
HDD LED+
4
HDD LED-
5
Reset BTN
6
Reset BTN
7
Power LED+
8
Power LED-
1
2
8
7
2.6.8 Front Panel Settings Connector (J25)
J25 is utilized for system indicators to provide light indication of the computer
activities and switches to change the computer status. It provides interfaces
for the following functions.
• ATX Power ON Switch (Pins 1 and 2)
The 2 pins make an “ATX Power Supply On/Off Switch” for the system
that connects to the power switch on the case. When pressed, the power
switch will force the system to power on. When pressed again, it will
power off the system.
• Hard Disk Drive LED Connector (Pins 3 and 4)
This connector connects to the hard drive activity LED on control panel.
This LED will flash when the HDD is being accessed.
• Reset Switch (Pins 5 and 6)
The reset switch allows you to reset the system without turning the main
power switch off and then on again. Orientation is not required when
making a connection to this header.
• Power LED (Pins 7 and 8)
This connector connects to the system power LED on control panel. This
LED will light when the system turns on.
IPPC1505/1705/1905-RE User Manual
29
2
Pin
Signal Name
Pin
Signal Name
1
+12V
3
Brightness Control
2
Backlight Enable
4
Ground
JP4: Channel A
JP3: Channel B
Pin
Signal Name
Pin
Signal Name
1
TX0P
2
TX0N
3
Ground
4
Ground
5
TX1P
6
TX1N
7
Ground
8
Ground
9
TX2P
10
TX2N
11
Ground
12
Ground
13
CLKP
14
CLKN
15
Ground
16
Ground
17
TX3P
18
TX3N
19
Power
20
Power
1
20 19
2 1
2.6.9 LCD Backlight Connector (JP2)
Hardware Configuration
2.6.10 LVDS Connector (JP3, JP4)
30
IPPC1505/1705/1905-RE User Manual
JP6
JP8
Pin
Signal Name
Pin
Signal Name
1
VCC
2
Ground
3
D0-
4
D1+
5
D0+
6
D1-
7
Ground
8
VCC
(PWM mode only)
Pin
Signal Name
Pin
Signal Name
1
Ground
3
Rotation detection
2
+12V
4
Control
7
2
8
1
1
2.6.11 USB 2.0 Connector (JP6, JP8)
2.6.12 CPU Fan Power Connector (CPU_FAN1)
Hardware Configuration
IPPC1505/1705/1905-RE User Manual
31
2
SYS_FAN1
SYS_FAN2
(PWM / DC mode)
Pin
Signal Name
Pin
Signal Name
1
Ground
3
Rotation detection
2
+12V
4
Control
1
2.6.13 System Fan Power Connector (SYS_FAN1, SYS_FAN2)
32
Chapter 3
Driver Installation
The information provided in this chapter includes:
• Intel
• HD Graphics Driver
• HD Audio Driver
• LAN Driver
• Intel
®
Chipset Software Installation Utility
®
Management Engine Drivers
Driver Installation
IPPC1505/1705/1905-RE User Manual
33
3
3.1 Introduction
This section describes the installation procedures for software drivers. The
software drivers are available on IBASE website www.ibase.com.tw. Register
as a member on our website to download all the necessary drivers.
Note: After installing your Windows operating system, you must install the Intel®
Chipset Software Installation Utility first before proceeding with the
drivers installation.
3.2 Intel® Chipset Software Installation Utility
The Intel® Chipset drivers should be installed first before the software drivers
to install INF files for Plug & Play function for the chipset components. Follow
the instructions below to complete the installation.
1. Insert the disk enclosed in the package with the board. Click Intel on the
left pane and then Intel(R) Skylake/Kabylake Chipset Drivers on the
right pane.
2. Click Intel(R) Chipset Software Installation Utility.
34
IPPC1505/1705/1905-RE User Manual
3. When the Welcome screen to the Intel® Chipset Device Software appears,
click Next to continue.
4. Accept the software license agreement and proceed with the installation
process.
5. On the Readme File Information screen, click Install for installation.
6. After the driver is completely installed, restart the computer for changes to
take effect.
3.3 HD Graphics Driver Installation
1. Click Intel on the left pane and then Intel(R) Skylake/Kabylake Chipset
Drivers on the right pane.
2. Click Intel(R) HD Graphics Driver.
Driver Installation
IPPC1505/1705/1905-RE User Manual
35
3
3. When the Welcome screen appears, click Next to continue.
4. Accept the license agreement and click Next.
5. On the Readme File Information screen, click Next until the installation
starts.
6. After the driver is completely installed, restart the computer for changes to
take effect.
3.4 HD Audio Driver Installation
1. Click Intel on the left pane and then Intel(R) Skylake/Kabylake Chipset
Drivers on the right pane.
36
IPPC1505/1705/1905-RE User Manual
2. Click Realtek High Definition Audio Driver.
3. On the Welcome screen of the InstallShield Wizard, click Next.
4. Click Next until the installation starts.
5. After the driver is completely installed, restart the computer for changes to
take effect.
3.5 LAN Driver Installation
1. Click Intel on the left pane and then Intel(R) Skylake/Kabylake Chipset
Drivers on the right pane.
2. Click Intel(R) PRO LAN Network Drivers.
Driver Installation
IPPC1505/1705/1905-RE User Manual
37
3
3. When the Welcome screen appears, click Next.
4. Accept the license agreement and click Next.
5. On the Setup Options screen, click the checkbox to select the desired
driver(s) for installation. Then click Next to continue.
6. The wizard is ready for installation. Click Install.
7. As the installation is complete, restart the computer for changes to take
effect.
38
IPPC1505/1705/1905-RE User Manual
3.6 Intel® Management Engine Driver Installation
1. Click Intel on the left pane and then Intel(R) Skylake/Kabylake Chipset
Drivers on the right pane.
2. Click Intel(R) ME 11.x Drivers.
3. When the Welcome screen appears, click Next.
Driver Installation
IPPC1505/1705/1905-RE User Manual
39
3
4. Accept the license agreement and click Next until the installation starts.
5. After the installation is complete, restart the computer for changes to take
effect.
40
Chapter 4
BIOS Setup
This chapter describes the different settings available in the AMI
BIOS that comes with the board. The topics covered in this chapter
are as follows:
• Main Settings
• Advanced Settings
• Chipset Settings
• Security Settings
• Boot Settings
• Save & Exit
BIOS Setup
IPPC1505/1705/1905-RE User Manual
41
4
4.1 Introduction
The BIOS (Basic Input/Output System) installed in the ROM of your computer
system supports Intel® processors. The BIOS provides critical low-level
support for standard devices such as disk drives, serial ports and parallel
ports. It also provides password protection as well as special support for
detailed fine-tuning of the chipset controlling the entire system.
4.2 BIOS Setup
The BIOS provides a Setup utility program for specifying the system
configurations and settings. The BIOS ROM of the system stores the Setup
utility. When you turn on the computer, the BIOS is immediately activated.
Press the <Del> key immediately allows you to enter the Setup utility. If you
are a little bit late pressing the <Del> key, POST (Power On Self Test) will
continue with its test routines, thus preventing you from invoking the Setup.
If you still need to enter Setup, restart the system by pressing the ”Reset”
button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys.
You can also restart by turning the system Off and back On again.
The following message will appear on the screen:
Press <DEL> to Enter Setup
In general, press the arrow keys to highlight items, <Enter> to select, the
<PgUp> and <PgDn> keys to change entries, <F1> for help, and <Esc> to
quit.
When you enter the BIOS Setup utility, the Main Menu screen will appear on
the screen. The Main Menu allows you to select from various setup functions
and exit choices.
Warning: It is strongly recommended that you avoid making any changes to
the chipset defaults.
These defaults have been carefully chosen by both AMI and your
system manufacturer to provide the absolute maximum
performance and reliability. Changing the defaults could make the
system unstable and crash in some cases.
42
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
System Date
Sets the date.
Use the <Tab> key to switch between the data
elements.
System Time
Set the time.
Use the <Tab> key to switch between the data
elements.
4.3 Main Settings
BIOS Setup
IPPC1505/1705/1905-RE User Manual
43
4
BIOS Setting
Description
CPU Configuration
Displays CPU configuration parameters.
PCH-FW Configuration
Configures management engine technology
parameters.
Trusted Computing*
Trusted computing settings.
ACPI Settings
Displays system ACPI parameters.
LVDS (eDP/DP)
Configuration
Configures LVDS (eDP/DP).
iSmart Controller
Sets up the power on time for the system.
Fintek Super IO
Configuration
Displays super IO chip parameters.
Fintek Super IO
Hardware Monitor
Shows super IO monitor hardware status.
CSM Configuration
Enables / Disables option ROM execution
settings, etc.
NVMe Configuration
NVMe device option settings.
USB Configuration
Displays USB configuration parameters.
4.4 Advanced Settings
This section allows you to configure, improve your system and allows you to
set up some system features according to your preference.
* Trusted Computing is available for MI992VF series only.
44
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Intel (VMX) Virtualization
Technology
Enables / Disables a VMM to utilize the
additional hardware capabilities provided by
Vanderpool Technology.
Active Processor Cores
Number of cores to enable in each processor
package.
Options: All, 1, 2, 3
Hyper-Threading
Enabled for Windows XP and Linux (OS
optimized for Hhyper-Threading Technology)
and Disabled for other OS (OS not optimized
for Hyper-Threading Technology).
AES
Enables / Disables AES (Advanced Encription
Standard).
Intel Trusted Execution
Technology
Enables / Disables utilization of additional
hardware capabilities provided by Intel(R)
Trusted Execution Technology. Changes
require a full power cycle to take effect.
4.4.1 CPU Configuration
IPPC1505/1705/1905-RE User Manual
45
4
BIOS Setting
Description
AMT BIOS Features*
When disabled AMT BIOS features are no
longer supported and user is no longer able to
access MEBx Setup.
Note: This option does not disable
Manageability features in FM.
4.4.2 PCH-FW Configuration
BIOS Setup
* AMT BIOS Features is available for MI992VF series only.
46
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Security Device Support
Enables / Disables BIOS support for security
device. OS will not show security device. TCG
EFI protocol and INTIA interface will not be
available.
4.4.3 Trusted Computing
Note: PCH-FW Configuration is only available for MI992VF only.
IPPC1505/1705/1905-RE User Manual
47
4
BIOS Setting
Description
Enable Hibernation
Enables / Disables the system ability to
hibernate (OS/S4 Sleep State). This option
may not be effective with some OS.
ACPI Sleep State
Selects a ACPI sleep state for the system to
enter.
Options: Suspend Disabled, S3 (Suspend to
RAM)
4.4.4 ACPI Settings
BIOS Setup
48
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
LVDS (eDP/DP) Support
Enables / Disables LVDS (eDP/DP).
4.4.5 LVDS (eDP/DP) Configuration
IPPC1505/1705/1905-RE User Manual
49
4
BIOS Setting
Description
Power-On after Power
failure
Enables / Disables the system to be turned on
automatically after a power failure.
Temperature Guardian
Generate the reset signal when system hands
up on POST.
Schedule Slot 1 / 2
Sets up the hour / minute / day for the poweron schedule for the system.
1-1
Options:
• None
• Power On
• Power On / Off
Important: If you would like to set up a
schedule between adjacent days, configure two
schedule slots.
For example, if setting up a schedule from
Wednesday 5 p.m. to Thursday 2 a.m.,
configure two schedule slots. But if setting up a
schedule from 3 p.m to 5 p.m. on Wednesday,
configure only a schedule slot.
4.4.6 iSmart Controller
BIOS Setup
50
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Standby Power on S5
(ErP)*
Enable the function to provide the standby
power for device.
Disable the function to shutdown the standby
power.
Options: All Enable, Enable Ethernet for
WOL, All Disable.
Serial Port Configuration
Sets parameters of Serial Ports.
Enables / Disables the serial port and select
an optimal setting for the Super IO device.
4.4.7 Fintek Super IO Configuration
IPPC1505/1705/1905-RE User Manual
51
4
BIOS Setting
Description
Serial Port
Enables / Disables the serial port.
Change Settings
Selects an optimal settings for Super I/O
device.
Options:
• Auto
• IO = 3F8h; IRQ = 4
• IO = 3F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
Device Mode Select
Changes the serial port mode to RS-232 / 422
/ 485.
Options:
• RS232
• RS485 TX Low Active
• RS485 with Termination TX Low Active
• RS422
• RS422 with Termination
4.4.7.1. Serial Port 1 Configuration
BIOS Setup
52
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Serial Port
Enables / Disables the serial port.
Change Settings
Selects an optimal settings for Super I/O
device.
Options:
• Auto
• IO = 2F8h; IRQ = 3
• IO = 3F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
Device Mode Select
Changes the serial port mode to RS-232 / 422
/ 485.
Options:
• RS232
• RS485 TX Low Active
• RS485 with Termination TX Low Active
• RS422
• RS422 with Termination
4.4.7.2. Serial Port 2 Configuration
IPPC1505/1705/1905-RE User Manual
53
4
BIOS Setting
Description
Serial Port
Enables / Disables the serial port.
Change Settings
Selects an optimal settings for Super I/O
device.
Options:
• Auto
• IO = 3E8h; IRQ = 7
• IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2F0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
4.4.7.3. Serial Port 3 Configuration
BIOS Setup
54
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Serial Port
Enables / Disables the serial port.
Change Settings
Selects an optimal settings for Super I/O
device.
Options:
• Auto
• IO = 2E8h; IRQ = 7
• IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2F0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
4.4.7.4. Serial Port 4 Configuration
IPPC1505/1705/1905-RE User Manual
55
4
BIOS Setting
Description
Serial Port
Enables / Disables the serial port.
Change Settings
Selects an optimal settings for Super I/O
device.
Options:
• Auto
• IO = 2E0h; IRQ = 7
• IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2F0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
4.4.7.5. Serial Port 5 Configuration
BIOS Setup
56
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Serial Port
Enables / Disables the serial port.
Change Settings
Selects an optimal settings for Super I/O
device.
Options:
• Auto
• IO = 2F0h; IRQ = 7
• IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2F0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
• IO = 2E0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12
4.4.7.6. Serial Port 6 Configuration
IPPC1505/1705/1905-RE User Manual
57
4
BIOS Setting
Description
CPU Smart Fan Control
Enables / Disables the CPU smart fan feature.
Options: Disabled / 50 °C / 60 °C / 70 °C / 80
°C
System Smart Fan
Control
Enables / Disables the system smart fan
feature.
Options: Disabled / 50 °C / 60 °C / 70 °C / 80
°C
Temperatures / Voltages
These fields are the parameters of the
hardware monitoring function feature of the
motherboard. The values are read-only values
as monitored by the system and show the PC
health status.
CPU Shutdown
Temperature
Options: Disabled / 70 °C / 75 °C / 80 °C / 85
°C / 90 °C / 95 °C
4.4.8 Fintek Super I/O Hardware Monitor
BIOS Setup
58
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
EIST
Enables / Disables Intel SpeedStep.
CSM Support
Enables / Disables CSM support.
GateA20 Active
• Upon Request disables GA20 when using
BIOS services.
• Always cannot disable GA20, but is useful
when any RT code is executed above 1 MB.
Option ROM Messages
Sets display mode for Option ROM.
Options: Force BIOS, Keep Current
INT19 Trap Response
Sets how BIOS reacts on INT19 trap by Option
ROM.
• Immediate executes the trap right away.
• Postponed executes the trap during legacy
boot.
Boot option filter
Controls the priority of Legacy and UEFI
ROMs.
Options: UEFI and Legacy / Legacy only / UEFI
only
Network
Controls the execution of UEFI and Legacy
PXE OpROM.
Options: Do not launch / Legacy
4.4.9 CSM Configuration
IPPC1505/1705/1905-RE User Manual
59
4
BIOS Setting
Description
Storage
Controls the execution of UEFI and Legacy
Storage OpROM.
Options: Do not lanuch / UEFI / Legacy
Video
Controls the execution of UEFI and Legacy
Video OpROM.
Options: Do not lanuch / UEFI / Legacy
Other PCI devices
Determines OpROM execution policy for
devices other than network, storage or video.
Options: Do not lanuch / UEFI / Legacy
4.4.10 NVMe Configuration
BIOS Setup
60
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Legacy USB Support
Enables Legacy USB support.
• Auto disables legacy support if there is no
USB device connected.
• Disable keeps USB devices available only
for EFI applications.
XHCI Hand-off
This is a workaround for OSes without XHCI
hand-off support. The XHCI ownership change
should be claimed by XHCI driver.
USB Mass Storage Driver
Support
Enables / Disables the support for USB mass
storage driver.
Port 60/64 Emulation
Enables / Disables I/O port 60h/64h emulation
support. This should be enabled for the
complete USB keyboard legacy support for
non-USB aware OSes.
USB Transfer time-out
The time-out value for control, bulk, and
Interrupt transfers.
Options: 1 sec / 5 sec / 10 sec / 20 sec
Device reset time-out
Seconds of delaying execution of start unit
command to USB mass storage device.
Options: 10 sec / 20 sec / 30 sec / 40 sec
Device power-up delay
The maximum time the device will take before it
properly reports itself to the Host Controller.
Auto uses default value for a Root port it is
100ms. But for a Hub port, the delay is taken
from Hub descriptor.
Options: Auto / Manual
4.4.11 USB Configuration
IPPC1505/1705/1905-RE User Manual
61
4
BIOS Setting
Description
System Agent (SA)
Configuration
System Agent (SA) parameters
PCH-IO Configuration
PCH parameters
BIOS Setting
Description
Graphics Configuration
Configures the graphics settings.
VT-d
Checks if VT-d function on MCH is supported.
4.5 Chipset Settings
BIOS Setup
4.5.1 System Agent (SA) Configuration
62
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Skip Scanning of External
Gfx Card
If enabled, it will not scan for external Gfx
Card on PEG and PCH PCIE ports.
External Gfx Card Primary
Display Configuration
Configures the external Gfx card primary
display.
• Primary PEG: Selects the primary PEG
(options: Auto / PEG11 / PEG12).
• Primary PCIE: Selects the primary PCIe
(options: Auto / PCIE1 ~ PCIE18)
Internal Graphics
Keep IGFX enabled based on the setup
options.
Options: Auto / Disabled / Enabled
GTT Size
Sets the GTT size as 2 MB, 4 MB, or 8 MB.
Aperture Size
Sets the aperture size as 128 MB / 256 MB /
512 MB / 1024 MB / 2048 MB.
Note: Above 4 GB MMIO BIOS assignment is
automatically enabled when selecting 2048
MB aperture. To use this feature, disable
CSM support.
DVMT Pre-Allocated
Sets DVMT 5.0 pre-allocated (fixed) graphics
memory size used by the internal graphics
devce.
Options: 0M / 32M / 64M / 4M / 8M / 12M /
16M / 20M / 24M / 28M / 32M/F7 / 36M / 40M
/ 44M / 48M / 52M / 56M / 60M
DVMT Total Gfx Mem
Selects DVMT 5.0 total graphic memory size
used by the internal graphcis device.
Options: 256M / 128M / MAX
4.5.1.1. Graphics Configuration
IPPC1505/1705/1905-RE User Manual
63
4
BIOS Setting
Description
SATA and RST
Configuration
Configures SATA devices.
PCH LAN Controller
Enables / Disables the onboard NIC.
Wake on LAN Enable
Enables / Disables the integrated LAN to wake
up the system.
4.5.2 PCH-IO Configuration
BIOS Setup
64
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
SATA Controller(s)
Enables / Disables the SATA device.
SATA Mode Selection
Determines how SATA controller(s) operate.
Options: AHCI / Intel RST Premium
Serial ATA Ports
Enables / Disables serial ports.
SATA Ports Hot Plug
Enables / Disables SATA Ports HotPlug.
4.5.2.1. SATA and RST Configuration
IPPC1505/1705/1905-RE User Manual
65
4
BIOS Setting
Description
Administrator Password
Sets an administrator password for the setup
utility.
User Password
Sets a user password.
4.6 Security Settings
BIOS Setup
66
IPPC1505/1705/1905-RE User Manual
BIOS Setting
Description
Setup Prompt Timeout
Number of seconds to wait for setup activation
key.
65535(0xFFFF) means indefinite waiting.
Bootup NumLock State
Selects the keyboard NumLock state.
Quiet Boot
Enables / Disables Quiet Boot option.
Fast Boot
Enables / Disables boot with initialization of a
minimal set of devices required to launch active
boot option. Has no effect for BBS boot options.
New Boot Option Policy
Controls the placement of newly detected UEFI
boot option.
Boot mode select
Selects a Boot mode, Legacy / UEFI.
Boot Option Priorities
Sets the system boot order.
4.7 Boot Settings
IPPC1505/1705/1905-RE User Manual
67
4
BIOS Setting
Description
Save Changes and Exit
Exits system setup after saving the changes.
Discard Changes and
Exit
Exits system setup without saving any changes.
Save Changes and Reset
Resets the system after saving the changes.
Discard Changes and
Reset
Resets system setup without saving any
changes.
Save Changes
Saves changes done so far to any of the setup
options.
Discard Changes
Discards changes done so far to any of the
setup options.
Restore Defaults
Restores / Loads defaults values for all the
setup options.
Save as User Defaults
Saves the changes done so far as User
Defaults.
Restore User Defaults
Restores the user defaults to all the setup
options.
4.8 Save & Exit Settings
BIOS Setup
68
Appendix
This section provides the mapping addresses of peripheral
devices and the sample code of watchdog timer configuration.
• I/O Port Address Map
• Interrupt Request Lines (IRQ)
• Digital I/O Sample Code
• Watchdog Timer Configuration
Appendix
IPPC1505/1705/1905-RE User Manual
69
Address
Device Description
0x00000A00-0x00000A0F
Motherboard resources
0x00000A10-0x00000A1F
Motherboard resources
0x00000A20-0x00000A2F
Motherboard resources
0x0000002E-0x0000002F
Motherboard resources
0x0000004E-0x0000004F
Motherboard resources
0x00000061-0x00000061
Motherboard resources
0x00000063-0x00000063
Motherboard resources
0x00000065-0x00000065
Motherboard resources
0x00000067-0x00000067
Motherboard resources
0x00000070-0x00000070
Motherboard resources
0x00000070-0x00000070
System CMOS/real time clock
0x00000080-0x00000080
Motherboard resources
0x00000092-0x00000092
Motherboard resources
0x000000B2-0x000000B3
Motherboard resources
0x00000680-0x0000069F
Motherboard resources
0x0000FFFF-0x0000FFFF
Motherboard resources
0x0000FFFF-0x0000FFFF
Motherboard resources
0x0000FFFF-0x0000FFFF
Motherboard resources
0x00001800-0x000018FE
Motherboard resources
0x0000164E-0x0000164F
Motherboard resources
0x00000040-0x00000043
System timer
0x00000050-0x00000053
System timer
0x00000800-0x0000087F
Motherboard resources
0x0000F000-0x0000F03F
Intel(R) HD Graphics 630
0x000003B0-0x000003BB
Intel(R) HD Graphics 630
0x000003C0-0x000003DF
Intel(R) HD Graphics 630
0x0000F090-0x0000F097
Standard SATA AHCI Controller
A. I/O Port Address Map
Each peripheral device in the system is assigned a set of I/O port addresses
which also becomes the identity of the device. The following table lists the I/O
port addresses used.
70
IPPC1505/1705/1905-RE User Manual
Address
Device Description
0x0000F080-0x0000F083
Standard SATA AHCI Controller
0x0000F060-0x0000F07F
Standard SATA AHCI Controller
0x000003F8-0x000003FF
Communications Port (COM1)
0x000002F8-0x000002FF
Communications Port (COM2)
0x000003E8-0x000003EF
Communications Port (COM3)
0x000002E8-0x000002EF
Communications Port (COM4)
0x000002F0-0x000002F7
Communications Port (COM5)
0x000002E0-0x000002E7
Communications Port (COM6)
0x0000E000-0x0000EFFF
Intel(R) 100 Series/C230 Series Chipset
Family PCI Express Root Port #3 - A112
0x00000000-0x00000CF7
PCI Express Root Complex
0x00000D00-0x0000FFFF
PCI Express Root Complex
0x00000020-0x00000021
Programmable interrupt controller
0x00000024-0x00000025
Programmable interrupt controller
0x00000028-0x00000029
Programmable interrupt controller
0x0000002C-0x0000002D
Programmable interrupt controller
0x00000030-0x00000031
Programmable interrupt controller
0x00000034-0x00000035
Programmable interrupt controller
0x00000038-0x00000039
Programmable interrupt controller
0x0000003C-0x0000003D
Programmable interrupt controller
0x000000A0-0x000000A1
Programmable interrupt controller
0x000000A4-0x000000A5
Programmable interrupt controller
0x000000A8-0x000000A9
Programmable interrupt controller
0x000000AC-0x000000AD
Programmable interrupt controller
0x000000B0-0x000000B1
Programmable interrupt controller
0x000000B4-0x000000B5
Programmable interrupt controller
0x000000B8-0x000000B9
Programmable interrupt controller
0x000000BC-0x000000BD
Programmable interrupt controller
0x000004D0-0x000004D1
Programmable interrupt controller
0x0000F0A0-0x0000F0A7
Intel(R) Active Management Technology SOL (COM7)
0x00001854-0x00001857
Motherboard resources
0x0000FF00-0x0000FFFE
Motherboard resources
IPPC1505/1705/1905-RE User Manual
71
Address
Device Description
0x0000F040-0x0000F05F
Intel(R) 100 Series/C230 Series Chipset
Family SMBus - A123
0x00000060-0x00000060
Standard PS/2 Keyboard
0x00000064-0x00000064
Standard PS/2 Keyboard
0x000000F0-0x000000F0
Numeric data processor
Appendix
72
IPPC1505/1705/1905-RE User Manual
Level
Function
IRQ 0
System timer
IRQ 1
Standard PS/2 Keyboard
IRQ 3
Communications Port (COM2)
IRQ 4
Communications Port (COM1)
IRQ 5
Communications Port (COM3)
IRQ 7
Communications Port (COM4)
IRQ 8
System CMOS/real time clock
IRQ 11
Communications Port (COM6)
IRQ 11
Intel(R) Xeon(R) E3 - 1200/1500 v5/6th Gen Intel(R)
Core(TM) Gaussian Mixture Model - 1911
IRQ 11
Intel(R) 100 Series/C230 Series Chipset Family SMBus
- A123
IRQ 11
Intel(R) 100 Series/C230 Series Chipset Family Thermal
subsystem - A131
IRQ 12
Microsoft PS/2 Mouse
IRQ 13
Numeric data processor
IRQ 14
Motherboard resources
IRQ 16
High Definition Audio Controller
IRQ 19
Intel(R) Active Management Technology - SOL (COM7)
IRQ 54 ~ IRQ 204
Microsoft ACPI-Compliant System
IRQ 256 ~ IRQ 511
Microsoft ACPI-Compliant System
IRQ 4294967283
Intel(R) Management Engine Interface
IRQ 4294967284
Intel(R) I211 Gigabit Network Connection
IRQ 4294967285
Intel(R) I211 Gigabit Network Connection
IRQ 4294967286
Intel(R) I211 Gigabit Network Connection
IRQ 4294967287
Intel(R) I211 Gigabit Network Connection
IRQ 4294967288
Intel(R) I211 Gigabit Network Connection
IRQ 4294967289
Intel(R) I211 Gigabit Network Connection
IRQ 4294967291
Intel(R) HD Graphics 630
B. Interrupt Request Lines (IRQ)
Peripheral devices use interrupt request lines to notify CPU for the service
required. The following table shows the IRQ used by the devices on board.
IPPC1505/1705/1905-RE User Manual
73
Level
Function
IRQ 4294967292
Intel(R) Ethernet Connection (2) I219-LM
IRQ 4294967293
Standard SATA AHCI Controller
IRQ 4294967294
Intel(R) 100 Series/C230 Series Chipset Family PCI
Express Root Port #3 - A112
Appendix
74
IPPC1505/1705/1905-RE User Manual
C. Watchdog Timer Configuration
The Watchdog Timer (WDT) is used to generate a variety of output signals
after a user programmable count. The WDT is suitable for the use in the
prevention of system lock-up, such as when software becomes trapped in a
deadlock. Under these sorts of circumstances, the timer will count to zero and
the selected outputs will be driven.
Under normal circumstance, you will need to restart the WDT at regular
intervals before the timer counts to zero.
Sample Code:
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#include <dos.h>
#include <conio.h>
#include <stdio.h>
#include <stdlib.h>
#include "F81866.H"
//--------------------------------------------------------------------------int main (int argc, char *argv[]);
void EnableWDT(int);
void DisableWDT(void);
//--------------------------------------------------------------------------int main (int argc, char *argv[])
{
unsigned char bBuf;
unsigned char bTime;
char **endptr;
char SIO;
printf("Fintek 81866 watch dog program\n");
SIO = Init_F81866();
if (SIO == 0)
{
printf("Can not detect Fintek 81866, program abort.\n");
return(1);
}//if (SIO == 0)
if (argc != 2)
{
printf(" Parameter incorrect!!\n");
return (1);
}
bTime = strtol (argv[1], endptr, 10);
printf("System will reset after %d seconds\n", bTime);
IPPC1505/1705/1905-RE User Manual
75
if (bTime)
{ EnableWDT(bTime); }
else
{ DisableWDT(); }
return 0;
}
//--------------------------------------------------------------------------void EnableWDT(int interval)
{
unsigned char bBuf;
bBuf = Get_F81866_Reg(0x2B);
bBuf &= (~0x20);
Set_F81866_Reg(0x2B, bBuf); //Enable WDTO
Set_F81866_LD(0x07); //switch to logic device 7
Set_F81866_Reg(0x30, 0x01); //enable timer
bBuf = Get_F81866_Reg(0xF5);
bBuf &= (~0x0F);
bBuf |= 0x52;
Set_F81866_Reg(0xF5, bBuf); //count mode is second
Set_F81866_Reg(0xF6, interval); //set timer
bBuf = Get_F81866_Reg(0xFA);
bBuf |= 0x01;
Set_F81866_Reg(0xFA, bBuf); //enable WDTO output
bBuf = Get_F81866_Reg(0xF5);
bBuf |= 0x20;
Set_F81866_Reg(0xF5, bBuf); //start counting
}
//--------------------------------------------------------------------------void DisableWDT(void)
{
unsigned char bBuf;
Set_F81866_LD(0x07); //switch to logic device 7
bBuf = Get_F81866_Reg(0xFA);
bBuf &= ~0x01;
Set_F81866_Reg(0xFA, bBuf); //disable WDTO output
bBuf = Get_F81866_Reg(0xF5);
bBuf &= ~0x20;
bBuf |= 0x40;
Set_F81866_Reg(0xF5, bBuf); //disable WDT
}
//---------------------------------------------------------------------------
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//---------------------------------------------------------------------------
Appendix
76
IPPC1505/1705/1905-RE User Manual
#include "F81866.H"
#include <dos.h>
//--------------------------------------------------------------------------unsigned int F81866_BASE;
void Unlock_F81866 (void);
void Lock_F81866 (void);
//--------------------------------------------------------------------------unsigned int Init_F81866(void)
{
unsigned int result;
unsigned char ucDid;
F81866_BASE = 0x4E;
result = F81866_BASE;
ucDid = Get_F81866_Reg(0x20);
if (ucDid == 0x07) //Fintek 81866
{ goto Init_Finish; }
F81866_BASE = 0x2E;
result = F81866_BASE;
ucDid = Get_F81866_Reg(0x20);
if (ucDid == 0x07) //Fintek 81866
{ goto Init_Finish; }
F81866_BASE = 0x00;
result = F81866_BASE;
Init_Finish:
return (result);
}
//--------------------------------------------------------------------------void Unlock_F81866 (void)
{
outportb(F81866_INDEX_PORT, F81866_UNLOCK);
outportb(F81866_INDEX_PORT, F81866_UNLOCK);
}
//--------------------------------------------------------------------------void Lock_F81866 (void)
{
outportb(F81866_INDEX_PORT, F81866_LOCK);
}
//--------------------------------------------------------------------------void Set_F81866_LD( unsigned char LD)
{
Unlock_F81866();
outportb(F81866_INDEX_PORT, F81866_REG_LD);
outportb(F81866_DATA_PORT, LD);
Lock_F81866();
}
//--------------------------------------------------------------------------void Set_F81866_Reg( unsigned char REG, unsigned char DATA)
{
Unlock_F81866();
outportb(F81866_INDEX_PORT, REG);
outportb(F81866_DATA_PORT, DATA);
Lock_F81866();
}
//---------------------------------------------------------------------------
IPPC1505/1705/1905-RE User Manual
77
unsigned char Get_F81866_Reg(unsigned char REG)
{
unsigned char Result;
Unlock_F81866();
outportb(F81866_INDEX_PORT, REG);
Result = inportb(F81866_DATA_PORT);
Lock_F81866();
return Result;
}
//---------------------------------------------------------------------------
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#ifndef F81866_H
#define F81866_H 1
//--------------------------------------------------------------------------#define F81866_INDEX_PORT (F81866_BASE)
#define F81866_DATA_PORT (F81866_BASE+1)
//--------------------------------------------------------------------------#define F81866_REG_LD 0x07
//--------------------------------------------------------------------------#define F81866_UNLOCK 0x87
#define F81866_LOCK 0xAA
//--------------------------------------------------------------------------unsigned int Init_F81866(void);
void Set_F81866_LD( unsigned char);
void Set_F81866_Reg( unsigned char,
unsigned char); unsigned char
Get_F81866_Reg( unsigned char);
//--------------------------------------------------------------------------#endif // F81866_H
Appendix
Loading...
