MB968
8-port (Haswell + C226)
Networking Motherboard
USER’S MANUAL
Version 1.1
INSTALLATIONS
2
Acknowledgments
AMI is a registered trademark of American Megatrends, Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel is a registered trademark of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
All other product names or trademarks are properties of their
respective owners.
MB968 User’s Manual
INSTALLATIONS
3
Table of Contents
Introduction .............................................................. 5
Product Description ............................................................. 5
Specifications ...................................................................... 6
Checklist .............................................................................. 9
Board Dimensions ............................................................. 10
Block Diagram .................................................................. 11
Installations ............................................................ 12
Installing the CPU ............................................................. 13
Installing the Memory ....................................................... 14
Setting the Jumpers ........................................................... 15
Jumper Locations on MB968............................................. 16
Jumper Settings on MB968 ............................................... 17
JP2: Clear CMOS Setting .................................................. 17
JP3: Clear ME Setting ....................................................... 17
JP9: AT / ATX Mode Setting ............................................ 17
JP12: BIOS Flash Security Setting .................................... 17
JP15: LED Function Selection ........................................... 17
J17, J18: PCIE Config Setting ........................................... 18
Connectors on MB968 ...................................................... 19
J2: System Function Connector ......................................... 20
J5: VGA Connectors .......................................................... 21
J6, J7, J8: USB6~USB11 Ports .......................................... 21
J9: Compact Flash Socket .................................................. 21
J10: Mini PCI- E / mSATA Socket ................................... 21
J11: SPI Debug Port .......................................................... 21
J12: Digital IO 4-IN / 4-OUT Connector ........................... 22
J13: LPC Debug Port ................................ ......................... 22
J19, J25: ATX Power Connector ....................................... 22
J21, J22, J23: Power Connector, Pitch 2.54mm ................ 22
J24: Power Connector, Pitch 2.0mm ................................. 23
J27: mSATA Socket .......................................................... 23
CN1, CN3: HDD Serial ATA Connector .......................... 23
CPU_FAN1: CPU Fan Connector ..................................... 23
FAN1, FAN2, FAN3: System Fan Connectors ................. 23
LED4: Status LED ............................................................. 23
Digital I/O Sample Configuration .......................... 25
Watchdog Timer Configuration ............................. 29
BIOS Setup ............................................................. 33
INSTALLATIONS
4
BIOS Introduction .............................................................. 34
BIOS Setup ........................................................................ 34
Advanced Settings ............................................................. 36
Chipset Settings ................................................................. 47
Boot Settings ...................................................................... 53
CSM16 parameters ............................................................ 54
Security Settings ................................................................ 55
Drivers Installation ................................................. 57
Intel Chipset Software Installation Utility ......................... 58
VGA Drivers Installation .................................................. 60
LAN Drivers Installation ................................................... 63
Intel® Management Engine Interface ............................... 66
Intel® USB 3.0 Drivers ..................................................... 68
Appendix................................................................. 71
A. I/O Port Address Map ................................................... 71
B. Interrupt Request Lines (IRQ) ...................................... 72
C. Register of the LAN Bypass Controller ........................ 73
MB968 User’s Manual
INSTALLATIONS
5
Introduction
Product Description
The MB968 networking motherboard is based on the latest Intel® C226
chipset. The platform supports LGA1150 Haswell processors. Four
DDR3 UDIMM sockets allows up to 32GB system memory.
The motherboard supports a total of eight Ethernet ports with the port 5
to port8 supporting Bypass function. It also has two fast SATA III 6Gbps
ports, two USB 3.0 ports, two USB 2.0 ports and one USB 2.0 for Mini
PCI-e. MB968 utilizes the dramatic increase in performance provided
this Intel’s latest cutting-edge technology. Measuring 355mm x 185mm,
MB968 features Intel® Active Management Technology 8.0, offers eight
GbE LAN ports, two fast 6Gbps SATA ports and two USB3.0 ports.
MB968 Features
Supports Intel® Shark Bay DT LGA1150 Haswell processors
Supports Intel® Lynx Point C226 PCH chipset
Four DDR3 UDIMM for maximum 32GB total, 1600MHz,
Unbuffered
Intel CPU integrated graphics
Intel® Clarkville I217LM GbE PHY for Eth1, No Bypass
Eth2~4: Intel® Springville I210-AT, No Bypass
Eth5~6: Intel® Springville I210-AT, supports Bypass
Eth7~8: Intel® Springville I210-AT, supports Bypass
Two SATA III (6.0Gb/s)
One cableless 2.5” HDD (use IP332)
Optional 3.5” HDD x1, 2.5” HDD x2
INSTALLATIONS
6
Product
Name
MB968
Processor
Support for Intel® Shark Bay DT LGA1150 Haswell processors
TDP = 35W ~ 95W (DC / QC)
CPU Speed
TBD
Cache Size
Up to 8MB
Chipset
Intel® Lynx Point C226 PCH
Package =23 mm x 22 mm , 0.65 mm ball pitch
BIOS
AMI BIOS
Memory
Four DDR3 UDIMM total for 32GB max memory (4Gb chip support)
Support DDR3 at 1.5V
Dual channel DDR3 up to 1600 MHz
Unbuffered
ECC or non-ECC
Video
Intel® CPU integrated graphics
IBASE VGA4 pin header on board
Network
Controller
Eth1: Intel® Clarkville I217LM GbE PHY, 6mm x 6mm, QFN48
with iAMT 9.0 supporting. No Bypass
Eth2~4: Intel® Springville I210-AT. No Bypass.
Eth5~6: Intel® Springville I210-AT.. Support Bypass.
Eth7~8: Intel® Springville I210-AT.. Support Bypass.
SATA Ports
Two SATA III (6.0Gb/s), 7-pin SATA Blue connector
One for Front PCI-e Golden Finger #1 (to IP332)
Two for mSATA (Mini PCI-e)
One for CF Card
Fan
Connector
4-pin smart fan connectors:
Three for CPU Fan (Smart Fan reference to CPU temperature in
BIOS)
One for System Fans (Smart Fan reference to CPU temperature in
BIOS))
Compact
Flash
Marvell 88SA8052 SATA to PATA for Compact Flash type II
Digital IO
4 in & 4 out, 2x5 pin-header
Front Panel
LED
#1 LED: Power
(Green = Power On, Off= No Power)
#2 LED: Bypass or HDD (Jumper Select)
Bypass: Green = LAN 5-6 or 7-8 Bypass,
Off = LAN Normal
#3 LED: Status (GPIO control, Yellow / Red)
Specifications
MB968 User’s Manual
INSTALLATIONS
7
USB Ports
Two USB 3.0 + 2.0 ports at front panel
One USB 2.0 for Mini PCI-e
Six USB 2.0 pin headers (pitch 2.54)
Network
Bypass
Two segment hardware Bypass (Eth5 & 6; Eth7 & 8)
Bypass mode selection in BIOS
LPC I/O
Fintek F81866AD-I (128-pin LQFP [14mm x 14 mm])
COM1: RJ-45 Console x1
COM2~4: RS-232 [2x5] Pin Header Onboard x3
Hardware monitors
Fan Connector x4
Digital IO 4in & 4 Out
Smart Fan
Control
The active temperature may be adjusted based on system thermal test
result. All reference to CPU temperature.
Active
Temperature
Tolerance
Default Smart Fan
Enable or Disable
CPU Fan
50
+/- 5
Enable
System Fan
50
+/- 5
Enable
RTC
Intel C226 built-in RTC with on-board lithium battery & holder
Expansion
Slot
(CPU PEG
port)
CPU jumper setting PEG port to following configurations for golden
fingers & riser cards
Configuration
Golden Finger #1
Compatible Riser Cards
Golden Finger #2
Compatible Riser Cards
1
IP332
IP331
N/A
2
IP333
IP333
IP331 or IP333
Expansion
Interface
Mini PCI-e Socket x1 (m-SATA compatible)
Mini PCI-e Socket x1 (support m-SATA only)
Front Panel
Buttons &
Connector
Two RJ-45 1x4 connectors for Eth1~4 & 5~6
USB 3.0 x2
RJ-45 (for console, COM1)
Three LEDs for Power, Bypass or HDD & Status
Factory Mode Restore Reset Switch
Rear I/O
interface
PSU AC inlet
1x or 2x Slot (Depend on product SKU)
Jumper /
Pin Header /
Switch
AT or ATX mode selection jumper
ATX mode power on / off pin header
Power on LED pin header
HDD active LED pin header
System Reset pin header
Clear CMOS
Clear ME RTC
Golden finger (1x16 or 2x8) switch jumper
INSTALLATIONS
8
Watchdog
Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
TPM
Nuvoton WPCT210AA0WX
Operating
Temperature
0C ~ 45C
Storage
Temperature
-20C ~ 70C
Operational
Humidity
5% ~ 95% Relative Humidity (non-condensing)
RoHS
Compliant
Yes
Board Size
355 x 185mm, FR-4, 1.6mm thickness
Compatible
Cards
IBP161: 4-port Realtek GbE LAN Card
IBP162: 2-port Intel 10GbE Fiber LAN Card
IBP163: 2+2 ports Intel I350-AM2 Fiber + Copper LAN Card
IBP164: Crypto acceleration Card
IBP165: 4-port Intel® I210-AT GbE LAN Card
IBP167: 8-port Intel® I350-AM4 GbE LAN Card
IP331: PCI-e 1-to-1 Riser Card
IP332: PCI-e Adapter Card (with 2.5” HDD Interface)
IP333: PCI-e 2-to-2 Riser Card
MB968 User’s Manual
INSTALLATIONS
9
Checklist
Your MB968 package should include the items listed below.
MB968 motherboard
Driver DVD
INSTALLATIONS
10
Board Dimensions
MB968 User’s Manual
INSTALLATIONS
11
CPU
Haswell
DDR3-1600
UDIMM x4
Lynx Point
C226
USB 3.0+2.0
DMI 2.0 x4
SATA III x2
SATA
Fintek F81866AD-I
Super I/O
I217LM
PCI-e
Eth1
LPC
COM
Front x2
FDI
Golden Finger 1:
PCI-e x8 for front LAN module
or One PCI-e x8
I210AT
PCI-e
VGA
KB/Mouse
I210AT
PCI-e
Eth5~6
Bypass
I210AT
PCI-e
Eth2~4
Console
Smart Fan
Mini PCI-e
Socket
Port2
Status LED
PEX
8603
Port1
I210AT
PCI-e
Eth7~8
Bypass
m-SATA x1
SATA
Bypass LED
USB 2.0
Pin header x6
USB 2.0
SATA
Golden Finger 2:
One PCI-e x8
Marvell
88SA8052
SATA
CF Card
GPIO x8
Block Diagram
INSTALLATIONS
12
Installations
This section provides information on how to use the jumpers and
connectors on the MB968 in order to set up a workable system. The
topics covered are:
Installing the CPU ................................................................................ 12
Installing the Memory .......................................................................... 13
Setting the Jumpers .............................................................................. 14
Jumper Locations on MB968 ............................................................... 15
Connectors on MB968 ......................................................................... 18
MB968 User’s Manual
INSTALLATIONS
13
NOTE:
Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.
Installing the CPU
The MB968 board supports an LGA1150 Socket (shown below) for Intel
Clarkdale processors.
To install the CPU, unlock first the socket by pressing the lever
sideways, then lift it up to a 90-degree. Then, position the CPU above the
socket such that the CPU corner aligns with the gold triangle matching
the socket corner with a small triangle. Carefully insert the CPU into the
socket and push down the lever to secure the CPU. Then, install the heat
sink and fan.
INSTALLATIONS
14
DDR3 Module
Lock
Lock
Lock
Lock
Installing the Memory
The MB968 board supports four DDR3 memory socket for a maximum
total memory of 32GB in DDR3 DIMM memory type.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and
perform the following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligned
with that on the memory slot.
2. Gently push the DDR3 module in an upright position until the clips of
the slot close to hold the DDR3 module in place when the DDR3
module touches the bottom of the slot.
3. To remove the DDR3 module, press the clips with both hands.
MB968 User’s Manual
INSTALLATIONS
15
Setting the Jumpers
Jumpers are used on MB968 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on MB968 and their respective functions.
Jumper Locations on MB968............................................................... 16
Jumper Settings on MB968 ................................................................. 17
JP2: Clear CMOS Setting .................................................................... 17
JP3: Clear ME Setting ......................................................................... 17
JP9: AT/ATX Mode Setting ................................................................ 17
JP12: Flash Security Override Setting ................................................. 17
J17, J18: PCIE Config Setting ............................................................. 18
INSTALLATIONS
16
Jumper Locations on MB968
MB968 User’s Manual
17
JP2
Setting
Normal
Clear CMOS
JP3
Setting
Normal
Clear ME
JP9
Setting
ATX
AT
JP12
Setting
Normal
For BIOS Update
JP15
Setting
HDD Activate
Bypass Activate
Jumper Settings on MB968
JP2: Clear CMOS Setting
JP3: Clear ME Setting
JP9: AT / ATX Mode Setting
INSTALLATIONS
JP12: BIOS Flash Security Setting
JP15: LED Function Selection
INSTALLATIONS
18
J18
J17
Setting
2 x 8 for Golden Finger PCIE1 & PCIE2
1x16 for Golden Finger PCIE2
J17, J18: PCIE Config Setting
MB968 User’s Manual
19
Connectors on MB968
J2: System Function Connector ........................................................... 19
J5: VGA Connectors ............................................................................ 21
J6, J7, J8: USB6~USB11 Ports ............................................................ 21
J9: Compact Flash Socket .................................................................... 21
J10: Mini PCI- E(x1) / mSATA Socket .............................................. 21
J11: SPI Debug Port ............................................................................ 21
J12: Digital IO 4IN/4OUT Connector ................................................. 22
J13: LPC Debug Port ........................................................................... 22
J19, J25: ATX Power Connector ......................................................... 22
J21, J22, J23: External CF Power Connector ...................................... 22
J24: External CF Power Connector ..................................................... 23
J27: mSATA Socket ............................................................................ 23
CN1, CN3: Serial ATA Port ................................................................ 23
CPU_FAN1: CPU Fan Power Connector ............................................ 23
FAN1, FAN2, FAN3: System Fan Power Connector .......................... 23
LED4: Status LED ............................................................................... 22
INSTALLATIONS
INSTALLATIONS
20
Pin #
Signal Name
2
SPEAKER
4
NC
6
GND
8
+5V
Pin #
Signal Name
1
+5V
3
NC
5
GND
Pin #
Signal Name
13
GND
14
Power_ON
Pin #
Signal Name
17
GND
18
PM_SYSRST#
J2: System Function Connector
J2 provides connectors for system indicators that provide light indication
of the computer activities and switches to change the computer status. J2
is a 20-pin header that provides interfaces for the following functions
Pin 2, 4, 6, 8: Speaker
This connector provides an interface to a speaker for audio tone
generation. An 8-ohm speaker is recommended.
Pin 1, 3, 5: Power LED
The power LED indicates the status of the main power switch.
Pin 13, 14: ATX Power ON Switch
This 2-pin connector is an “ATX Power Supply On/Off Switch” on
the system that connects to the power switch on the case. When
pressed, the power switch will force the system to power on. When
pressed again, it will force the system to power off.
Pin 17, 18: Reset Switch
The reset switch allows the user to reset the system without turning
the main power switch off and then on again. Orientation is not
required when making a connection to this header.
MB968 User’s Manual
INSTALLATIONS
21
Pin #
Signal Name
19
+3.3V
20
-HDD_LED
Signal Name
Pin #
Pin #
Signal Name
VGA_R
1 2 VGA_PWR
VGA_G
3 4 GND
VGA_B
5 6 NC
NC
7 8 VGADDCDATA
GND
9
10
HSYNC
GND
11
12
VSYNC
GND
13
14
VGADDCCLK
GND
15
Signal Name
Pin #
Pin #
Signal Name
+5V
1 2 GND
D-
3 4 D+
D+
5 6 D-
GND
7 8 +5V
Pins 19, 20: HDD LED
This connector connects to the hard drive activity LED on control
panel. This LED will flash when the HDD is being accessed.
J5: VGA Connectors
J6, J7, J8: USB6~USB11 Ports
J9: Compact Flash Socket
Note: CF card supports IDE mode only.
If CF card applied, please set the SATA configuration to “IDE
mode” in BIOS.
J10: Mini PCI- E / mSATA Socket
J11: SPI Debug Port
INSTALLATIONS
22
Signal Name
Pin #
Pin #
Signal Name
2 NC
SPI_CS#0
3 4 +3.3V
SPI_SO
5
6
SPI0_HOLD#
SPI0_WP#
7 8 SPI_CLK
GND
9
10
SPI_SI
Signal
Name
Pin #
Pin #
Signal
Name
GND 1 2
+5V
OUT3 3 4
OUT1
OUT2 5 6
OUT0
IN3 7 8
IN1
IN2 9 10
IN0
Signal
Name
Pin #
Pin #
Signal
Name
LPC_AD0
1 2 SIO_PLTRST#
LPC_AD1
3 4 LPC_FRAME#
LPC_AD2
5 6 +3.3V
LPC_AD3
7 8 Ground
LPC_CLK
9
Signal
Name
Pin #
Pin #
Signal
Name
DCD# 1 6
DSR#
SIN 2 7
RTS#
SOUT 3 8
CTS#
DTR# 4 9
RI#
GND 5
Pin #
Signal Name
J12: Digital IO 4-IN / 4-OUT Connector
J13: LPC Debug Port
J15, J16, J20: Serial Port (COM1~COM3)
J19, J25: ATX Power Connector
J21, J22, J23: Power Connector, Pitch 2.54mm
MB968 User’s Manual
23
1
+5V
2
Ground
3
Ground
4
+12V
Pin #
Signal Name
1
+5V
2
Ground
3
Ground
4
+12V
Pin #
Signal Name
1
Ground
2
+12V
3
Rotation detection
4
Rotation control
Pin #
Signal Name
1
Ground
2
+12V
3
Rotation detection
4
Rotation control
J24: Power Connector, Pitch 2.0mm
J27: mSATA Socket
CN1, CN3: HDD Serial ATA Connector
CPU_FAN1: CPU Fan Connector
CPU_FAN1 is a 4-pin header for the CPU fan.
The fan must be 12V (Max. 1A).
INSTALLATIONS
FAN1, FAN2, FAN3: System Fan Connectors
FAN1, FAN2, FAN3 is a 4-pin header for system fans.
The fan must be 12V (Max. 1A).
LED4: Status LED
A1 & C1 : Status LED
A2 & C2 : Bypass or HDD status LED
INSTALLATIONS
24
Signal
Name
Pin #
Pin #
Signal
Name
SIO_GPIO33
A1
C1
SIO_GPIO32
+5 V
A2
C2
JP15 Selection
+3.3 V
A3
C3
GND
Status
Bypass or HDD
Power
A3 & C3 : Power LED
MB968 User’s Manual
INSTALLATIONS
25
Digital I/O Sample Configuration
Filename：Main.cpp
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#include <dos.h>
#include <conio.h>
#include <stdio.h>
#include <stdlib.h>
#include "F81865.H"
#define BIT0 0x01
#define BIT1 0x02
#define BIT2 0x04
#define BIT3 0x08
#define BIT4 0x10
#define BIT5 0x20
#define BIT6 0x40
#define BIT7 0x80
//--------------------------------------------------------------------------int main (void);
void Dio5Initial(void);
void Dio5SetOutput(unsigned char);
unsigned char Dio5GetInput(void);
void Dio5SetDirection(unsigned char);
unsigned char Dio5GetDirection(void);
//--------------------------------------------------------------------------int main (void)
{
char SIO;
unsigned char DIO;
printf("Fintek 81865/81866 digital I/O test program\n");
SIO = Init_F81865();
if (SIO == 0)
{
printf("Can not detect Fintek 81865/81866, program abort.\n");
return(1);
}//if (SIO == 0)
Dio5Initial();
/*
//for GPIO50..57
Dio5SetDirection(0xF0); //GP50..53 = input, GP54..57=output
printf("Current DIO direction = 0x%X\n", Dio5GetDirection());
printf("Current DIO status = 0x%X\n", Dio5GetInput());
printf("Set DIO output to high\n");
Dio5SetOutput(0x0F);
printf("Set DIO output to low\n");
Dio5SetOutput(0x00);
*/
//for GPIO50..57
Dio5SetDirection(0xF0); //GP50..53 = input, GP54..57=output
Dio5SetOutput(0x00); //clear
// DIO = Dio5GetInput() & 0x0F;
INSTALLATIONS
26
Dio5SetOutput(0x00); //clear
DIO = Dio5GetInput() & 0x0F;
if (DIO != 0x0A)
{
printf("The Fintek 81865 digital IO abnormal, abort.\n");
return(1);
}//if (DIO != 0x0A)
Dio5SetOutput(0xA0); //clr# is high
Dio5SetOutput(0xF0); //clk and clr# is high
Dio5SetOutput(0xA0); //clr# is high
DIO = Dio5GetInput() & 0x0F;
if (DIO != 0x05)
{
printf("The Fintek 81865 digital IO abnormal, abort.\n");
return(1);
}
printf("!!! Pass !!!\n");
return 0;
}
//--------------------------------------------------------------------------void Dio5Initial(void)
{
unsigned char ucBuf;
//switch GPIO multi-function pin for gpio 50~57
//gpio53~57 UR5_FULL_EN(bit1), clear UR6_FULL_EN(bit3)
//set UR5_FULL_EN,should set UR_GP_PROG_EN = 1 (reg26,bit0) first
ucBuf = Get_F81865_Reg(0x26);
ucBuf |= BIT0;
Set_F81865_Reg(0x26, ucBuf);
//set UR5_FULL_EN(bit1), clear UR6_FULL_EN(bit3)
ucBuf = Get_F81865_Reg(0x2A);
ucBuf &= ~BIT3;//clear bit 3,
ucBuf |= BIT1;//set bit 1,
Set_F81865_Reg(0x2a, ucBuf);
//GPIO51 ~ GPIO52
//clear UR6_ALT_EN(bit5), IR_ALT_EN(bit4),set FDC_GP_EN(bit3)
//GPIO50
//set FDC_GP_EN(bit3), clear RTS6_ALT_EN(RTS6_2_ALT_EN)(bit6)
ucBuf = Get_F81865_Reg(0x2A);
ucBuf &= ~(BIT4+BIT5+BIT6); //clear UR6_ALT_EN(bit5), IR_ALT_EN(bit4),
RTS6_ALT_EN(RTS6_2_ALT_EN)(bit6)
Set_F81865_Reg(0x2a, ucBuf);
//set FDC_GP_EN(bit3), should clear UR_GP_PROG_EN (reg26,bit0) first
ucBuf = Get_F81865_Reg(0x26);
ucBuf &= ~BIT0;
Set_F81865_Reg(0x26, ucBuf);//clear UR_GP_PROG_EN = 0 (reg26,bit0)
ucBuf = Get_F81865_Reg(0x2A);
ucBuf |= BIT3; //set FDC_GP_EN(bit3),
Set_F81865_Reg(0x2a, ucBuf);
Set_F81865_LD(0x06); //switch to logic device 6
//enable the GP5 group
ucBuf = Get_F81865_Reg(0x30);
ucBuf |= 0x01;
Set_F81865_Reg(0x30, ucBuf);
Set_F81865_Reg(0xA0, 0x00); //define as input mode
Set_F81865_Reg(0xA3, 0xFF); //push pull mode
}
//---------------------------------------------------------------------------
MB968 User’s Manual
INSTALLATIONS
27
void Dio5SetOutput(unsigned char NewData)
{
Set_F81865_LD(0x06); //switch to logic device 6
Set_F81865_Reg(0xA1, NewData);
}
//--------------------------------------------------------------------------unsigned char Dio5GetInput(void)
{
unsigned char result;
Set_F81865_LD(0x06); //switch to logic device 6
result = Get_F81865_Reg(0xA2);
return (result);
}
//--------------------------------------------------------------------------void Dio5SetDirection(unsigned char NewData)
{
//NewData : 1 for input, 0 for output
Set_F81865_LD(0x06); //switch to logic device 6
Set_F81865_Reg(0xA0, NewData);
}
//--------------------------------------------------------------------------unsigned char Dio5GetDirection(void)
{
unsigned char result;
Set_F81865_LD(0x06); //switch to logic device 6
result = Get_F81865_Reg(0xA0);
return (result);
}
//---------------------------------------------------------------------------
Filename：81865.cpp
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#include "F81865.H"
#include <dos.h>
//--------------------------------------------------------------------------unsigned int F81865_BASE;
void Unlock_F81865 (void);
void Lock_F81865 (void);
//--------------------------------------------------------------------------unsigned int Init_F81865(void)
{
unsigned int result;
unsigned char ucDid;
F81865_BASE = 0x4E;
result = F81865_BASE;
ucDid = Get_F81865_Reg(0x20);
if (ucDid == 0x07||ucDid == 0x10) //Fintek 81865/66
{ goto Init_Finish; }
F81865_BASE = 0x2E;
result = F81865_BASE;
ucDid = Get_F81865_Reg(0x20);
if (ucDid == 0x07||ucDid == 0x10) //Fintek 81865/66
{ goto Init_Finish; }
F81865_BASE = 0x00;
result = F81865_BASE;
Init_Finish:
INSTALLATIONS
28
return (result);
}
//--------------------------------------------------------------------------void Unlock_F81865 (void)
{
outportb(F81865_INDEX_PORT, F81865_UNLOCK);
outportb(F81865_INDEX_PORT, F81865_UNLOCK);
}
//--------------------------------------------------------------------------void Lock_F81865 (void)
{
outportb(F81865_INDEX_PORT, F81865_LOCK);
}
//--------------------------------------------------------------------------void Set_F81865_LD( unsigned char LD)
{
Unlock_F81865();
outportb(F81865_INDEX_PORT, F81865_REG_LD);
outportb(F81865_DATA_PORT, LD);
Lock_F81865();
}
//--------------------------------------------------------------------------void Set_F81865_Reg( unsigned char REG, unsigned char DATA)
{
Unlock_F81865();
outportb(F81865_INDEX_PORT, REG);
outportb(F81865_DATA_PORT, DATA);
Lock_F81865();
}
//--------------------------------------------------------------------------unsigned char Get_F81865_Reg(unsigned char REG)
{
unsigned char Result;
Unlock_F81865();
outportb(F81865_INDEX_PORT, REG);
Result = inportb(F81865_DATA_PORT);
Lock_F81865();
return Result;
}
//---------------------------------------------------------------------------
Filename：81865.h
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#ifndef __F81865_H
#define __F81865_H 1
//--------------------------------------------------------------------------#define F81865_INDEX_PORT (F81865_BASE)
#define F81865_DATA_PORT (F81865_BASE+1)
//--------------------------------------------------------------------------#define F81865_REG_LD 0x07
//--------------------------------------------------------------------------#define F81865_UNLOCK 0x87
#define F81865_LOCK 0xAA
//--------------------------------------------------------------------------unsigned int Init_F81865(void);
void Set_F81865_LD( unsigned char);
void Set_F81865_Reg( unsigned char, unsigned char);
unsigned char Get_F81865_Reg( unsigned char);
//--------------------------------------------------------------------------#endif //__F81865_H
MB968 User’s Manual
INSTALLATIONS
29
Watchdog Timer Configuration
The WDT is used to generate a variety of output signals after a user
programmable count. The WDT is suitable for use in the prevention of
system lock-up, such as when software becomes trapped in a deadlock.
Under these sorts of circumstances, the timer will count to zero and the
selected outputs will be driven. Under normal circumstance, the user will
restart the WDT at regular intervals before the timer counts to zero.
SAMPLE CODE:
This code and information is provided "as is" without warranty of any
kind, either expressed or implied, including but not limited to the
implied warranties of merchantability and/or fitness for a particular
purpose.
//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#include <dos.h>
#include <conio.h>
#include <stdio.h>
#include <stdlib.h>
#include "F81866.H"
//--------------------------------------------------------------------------int main (int argc, char *argv[]);
void EnableWDT(int);
void DisableWDT(void);
//--------------------------------------------------------------------------int main (int argc, char *argv[])
{
unsigned char bBuf;
unsigned char bTime;
char **endptr;
char SIO;
printf("Fintek 81866 watch dog program\n");
SIO = Init_F81866();
if (SIO == 0)
{
printf("Can not detect Fintek 81866, program abort.\n");
return(1);
}//if (SIO == 0)
if (argc != 2)
{
printf(" Parameter incorrect!!\n");
return (1);
}
bTime = strtol (argv[1], endptr, 10);
printf("System will reset after %d seconds\n", bTime);
if (bTime)
{ EnableWDT(bTime); }
else
{ DisableWDT(); }
INSTALLATIONS
30
return 0;
}
//--------------------------------------------------------------------------void EnableWDT(int interval)
{
unsigned char bBuf;
bBuf = Get_F81866_Reg(0x2B);
bBuf &= (~0x20);
Set_F81866_Reg(0x2B, bBuf); //Enable WDTO
Set_F81866_LD(0x07); //switch to logic device 7
Set_F81866_Reg(0x30, 0x01); //enable timer
bBuf = Get_F81866_Reg(0xF5);
bBuf &= (~0x0F);
bBuf |= 0x52;
Set_F81866_Reg(0xF5, bBuf); //count mode is second
Set_F81866_Reg(0xF6, interval); //set timer
bBuf = Get_F81866_Reg(0xFA);
bBuf |= 0x01;
Set_F81866_Reg(0xFA, bBuf); //enable WDTO output
bBuf = Get_F81866_Reg(0xF5);
bBuf |= 0x20;
Set_F81866_Reg(0xF5, bBuf); //start counting
}
//--------------------------------------------------------------------------void DisableWDT(void)
{
unsigned char bBuf;
Set_F81866_LD(0x07); //switch to logic device 7
bBuf = Get_F81866_Reg(0xFA);
bBuf &= ~0x01;
Set_F81866_Reg(0xFA, bBuf); //disable WDTO output
bBuf = Get_F81866_Reg(0xF5);
bBuf &= ~0x20;
bBuf |= 0x40;
Set_F81866_Reg(0xF5, bBuf); //disable WDT
}
//--------------------------------------------------------------------------//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#include "F81866.H"
#include <dos.h>
//--------------------------------------------------------------------------unsigned int F81866_BASE;
void Unlock_F81866 (void);
void Lock_F81866 (void);
//--------------------------------------------------------------------------unsigned int Init_F81866(void)
{
unsigned int result;
unsigned char ucDid;
F81866_BASE = 0x4E;
result = F81866_BASE;
MB968 User’s Manual
INSTALLATIONS
31
ucDid = Get_F81866_Reg(0x20);
if (ucDid == 0x07) //Fintek 81866
{ goto Init_Finish; }
F81866_BASE = 0x2E;
result = F81866_BASE;
ucDid = Get_F81866_Reg(0x20);
if (ucDid == 0x07) //Fintek 81866
{ goto Init_Finish; }
F81866_BASE = 0x00;
result = F81866_BASE;
Init_Finish:
return (result);
}
//--------------------------------------------------------------------------void Unlock_F81866 (void)
{
outportb(F81866_INDEX_PORT, F81866_UNLOCK);
outportb(F81866_INDEX_PORT, F81866_UNLOCK);
}
//--------------------------------------------------------------------------void Lock_F81866 (void)
{
outportb(F81866_INDEX_PORT, F81866_LOCK);
}
//--------------------------------------------------------------------------void Set_F81866_LD( unsigned char LD)
{
Unlock_F81866();
outportb(F81866_INDEX_PORT, F81866_REG_LD);
outportb(F81866_DATA_PORT, LD);
Lock_F81866();
}
//--------------------------------------------------------------------------void Set_F81866_Reg( unsigned char REG, unsigned char DATA)
{
Unlock_F81866();
outportb(F81866_INDEX_PORT, REG);
outportb(F81866_DATA_PORT, DATA);
Lock_F81866();
}
//--------------------------------------------------------------------------unsigned char Get_F81866_Reg(unsigned char REG)
{
unsigned char Result;
Unlock_F81866();
outportb(F81866_INDEX_PORT, REG);
Result = inportb(F81866_DATA_PORT);
Lock_F81866();
return Result;
}
//--------------------------------------------------------------------------//--------------------------------------------------------------------------//
// THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY
// KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
// PURPOSE.
//
//--------------------------------------------------------------------------#ifndef __F81866_H
#define __F81866_H 1
//--------------------------------------------------------------------------#define F81866_INDEX_PORT (F81866_BASE)
#define F81866_DATA_PORT (F81866_BASE+1)
//--------------------------------------------------------------------------#define F81866_REG_LD 0x07
//---------------------------------------------------------------------------
INSTALLATIONS
32
#define F81866_UNLOCK 0x87
#define F81866_LOCK 0xAA
//--------------------------------------------------------------------------unsigned int Init_F81866(void);
void Set_F81866_LD( unsigned char);
void Set_F81866_Reg( unsigned char, unsigned char);
unsigned char Get_F81866_Reg( unsigned char);
//--------------------------------------------------------------------------#endif //__F81866_H
MB968 User’s Manual
BIOS SETUP
33
BIOS Setup
This chapter describes the different settings available in the AMI BIOS
that comes with the board. The topics covered in this chapter are as
follows:
BIOS Introduction ............................................................................... 32
BIOS Setup .......................................................................................... 32
Advanced Settings ............................................................................... 34
Chipset Settings ................................................................................... 46
Boot Settings ....................................................................................... 52
CSM parameters .................................................................................. 54
Security Settings .................................................................................. 55
BIOS SETUP
34
Warning:
It is strongly recommended that you avoid making any
changes to the chipset defaults. These defaults have been
carefully chosen by both AMI and your system manufacturer
to provide the absolute maximum performance and
reliability. Changing the defaults could cause the system to
become unstable and crash in some cases.
BIOS Introduction
The BIOS (Basic Input/Output System) installed in your computer
system’s ROM supports Intel processors. The BIOS provides critical
low-level support for a standard device such as disk drives, serial ports
and parallel ports. It also password protection as well as special support
for detailed fine-tuning of the chipset controlling the entire system.
BIOS Setup
The BIOS provides a Setup utility program for specifying the system
configurations and settings. The BIOS ROM of the system stores the
Setup utility. When you turn on the computer, the BIOS is immediately
activated. Pressing the <Del> key immediately allows you to enter the
Setup utility. If you are a little bit late pressing the <Del> key, POST
(Power On Self Test) will continue with its test routines, thus preventing
you from invoking the Setup. If you still wish to enter Setup, restart the
system by pressing the ”Reset” button or simultaneously pressing the
<Ctrl>, <Alt> and <Delete> keys. You can also restart by turning the
system Off and back On again. The following message will appear on
the screen:
Press <DEL> / <F2> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter> to select,
the <PgUp> and <PgDn> keys to change entries, <F1> for help and
<Esc> to quit.
When you enter the Setup utility, the Main Menu screen will appear on
the screen. The Main Menu allows you to select from various setup
functions and exit choices.
MB968 User’s Manual
BIOS SETUP
35
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
Choose the system default
language
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
System Language
[English]
System Date
System Time
[Fri 02/21/2014]
[10:30:55]
Access Level
Administrator
Main Settings
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
System Language
Choose the system default language.
System Date
Set the Date. Use Tab to switch between Data elements.
System Time
Set the Time. Use Tab to switch between Data elements.
BIOS SETUP
36
Main Advanced Chipset Boot Security Save & Exit
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
► PCI Subsystem Settings
► ACPI Settings
► Wake up event setting
► CPU Configuration
► SATA Configuration
► Thermal Configuration
► Shutdown Temperature Configuration
► LAN Bypass Configuration
► Intel(R) Rapid Start Technology
► Intel TXT(LT) Configuration
► Intel(R) Anti-Theft Technology Configura…
► AMT Configuration
► Acoustic Management Configuration
► USB Configuration
► F81866 Super IO Configuration
► F81866 H/W Monitor
► Serial Port Console Redirection
Main Advanced Chipset Boot Security Save & Exit
PCI Bus Driver Version V 2.05.02
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
PCI Common Settings
PCI Latency Timer
[32 PCI Bus Clocks]
VGA Palette Snoop
[Disabled]
PERR# Generation
[Disabled]
SERR# Generation
[Disabled]
► PCI Express Settings
Advanced Settings
This section allows you to configure and improve your system and
allows you to set up some system features according to your preference.
PCI Subsystem Settings
Aptio Setup Utility
Aptio Setup Utility
PCI Latency Timer
Value to be programmed into PCI Latency Timer Register.
VGA Palette Snoop
Enables or disables VGA Palette Registers Snooping.
PERR# Generation
Enables or disables PCI device to generate PERR#.
MB968 User’s Manual
37
Main Advanced Chipset Boot Security Save & Exit
PCI Express Device Register Settings
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Relaxed Ordering
[Disabled]
Extended Tag
[Disabled]
No Snoop
[Enabled]
Maximum Payload
[Auto]
Maximum Read Request
[Auto]
PCI Express Link Register Settings
ASPM Support
[Disabled]
WARNING: Enabling ASPM may cause
some
PCI-E devices to fail
Extended Synch
[Disabled]
Link Training Retry
[5] Link Training Timeout
100 Unpopulated Links
[Keep Link ON]
Restore PCIE Register
[Disabled]
SERR# Generation
Enables or disables PCI device to generate SERR#.
PCI Express Settings
Change PCI Express devices settings.
PCI Express Settings
Aptio Setup Utility
BIOS SETUP
Relaxed Ordering
Enables or disables PCI Express Device Relaxed Ordering.
Extended Tag
If ENABLED allows device to use 8-bit Tag field as a requester.
No Snoop
Enables or disables PCI Express Device No Snoop option.
Maximum Payload
Set Maximum Payload of PCI Express Device or allow System BIOS to
select the value.
Maximum Read Request
Set Maximum Read Request Size of PCI Express Device or allow
System BIOS to select the value.
ASPM Support
BIOS SETUP
38
Main Advanced Chipset Boot Security Save & Exit
ACPI Settings
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Enable ACPI Auto Conf
[Disabled]
Enable Hibernation
[Enabled]
ACPI Sleep State
[S1 only (CPU Stop C…]
Lock Legacy Resources
S3 Video Repost
[Disabled]
[Disabled]
Set the ASPM Level: Force L0s – Force all links to L0s State:
AUTO – BIOS auto configure : DISABLE – Disables ASPM.
Extended Synch
If ENABLED allows generation of Extended Synchronization patterns.
Link Training Retry
Defines number of Retry Attempts software will take to retrain the link if
previous training attempt was unsuccessful.
Link Training Timeout
Defines number of Microseconds software will wait before polling ‘Link
Training’ bit in Link Status register. Value range from 10 to 1000 uS.
Unpopulated Links
In order to save power, software will disable unpopulated PCI Express
links, if this option set to ‘Disable Link’.
ACPI Settings
Aptio Setup Utility
Enable Hibernation
Enables or Disables System ability to Hibernate (OS/S4 Sleep State).
This option may be not effective with some OS.
ACPI Sleep State
Select ACPI sleep state the system will enter, when the SUSPEND
button is pressed.
Lock Legacy Resources
Enabled or Disabled Lock of Legacy Resources.
S3 Video Repost
Enable or disable S3 Video Repost.
MB968 User’s Manual
BIOS SETUP
39
Main Advanced Chipset Boot Security Save & Exit
Wake system with Fixed Time [Disabled]
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Wake on Ring
[Enabled]
Wake on PCI PME
[Enabled]
Wake on PCIE Wake Event
[Enabled]
Main Advanced Chipset Boot Security Save & Exit
Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Security Device Sup
[Disabled]
Current TPM Status Information
SUPPORT TUREND OFF
Wake up event settings
Aptio Setup Utility
Wake system with Fixed Time
Enables or Disables System wake on alarm event. When enabled,
System will wake on the hr::min:: sec specified.
Wake on PCIE PME Wake Event
The options are Disabled and Enabled.
Trusted Computing
Aptio Setup Utility
Security Device Support
Enables or disables BIOS support for security device. O.S. will not show
Security Device. TCG EFI protocol and INT1A interface will not be
available.
BIOS SETUP
40
Main Advanced Chipset Boot Security Save & Exit
CPU Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Intel(R) Xeon(R) CPU E3-1268L v3 @ 2.30GHz
CPU Signature
Processor Family
306c3 6 Microcode Patch
FSB Speed
16
100 MHz
Max CPU Speed
2300 MHz
Min CPU Speed
800 MHz
CPU Speed
2700 MHz
Processor Cores
4
Intel HT Technology
Supported
Intel VT-x Technology
Supported
Intel SMX Technology
Supported
64-bit
Supported
EIST Technology
CPU C3 state
CPU C6 state
CPU C7 state
L1 Data Cache
L1 Code Cache
L2 Cache
L3 Cache
Supported
Supported
Supported
Supported
32 kB x 4
32 kB x 4
256 kB x 4
8192 kB
Hyper-threading
[Enabled]
Active Processor Cores
[All]
Limit CPUID Maximum
[Disabled]
Execute Disable Bit
[Enabled]
Intel Virtualization
[Enabled]
Hardware Prefetcher
[Enabled]
Adjacent Cache Line Prefetch
[Enabled]
CPU AEC
[Enabled]
CPU Configuration
This section shows the CPU configuration parameters.
Aptio Setup Utility
Hyper-threading
Enabled for Windows XP and Linux (OS optimized for
Hyper-Threading Technology) and Disabled for other OS (OS not
optimized for Hyper-Threading Technology). When Disabled, only one
thread per enabled core is enabled.
Active Processor Cores
Number of cores to enable in each processor package.
Limit CPUID Maximum
Disabled for Windows XP.
Execute Disable Bit
MB968 User’s Manual
BIOS SETUP
41
Main Advanced Chipset Boot Security Save & Exit
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
SATA Controller(s)
[Enabled]
SATA Mode Selection
[AHCI]
SATA Port0
Empty
Software Preserve
Unknown
SATA Port1
Empty
Software Preserve
Unknown
SATA Port2
Empty
Software Preserve
Unknown
SATA Port3
Empty
Software Preserve
Unknown
SATA Port4
Empty
Software Preserve
Unknown
SATA Port5
Empty
Software Preserve
Unknown
XD can prevent certain classes of malicious buffer overflow attacks
when combined with a supporting OS (Windows Server 2003 SP1,
Windows XP SP2, SuSE Linux 9.2, Re33dHat Enterprise 3 Update 3.)
Intel Virtualization Technology
When enabled, a VMM can utilize the additional hardware capabilities
provided by Vanderpool Technology.
Hardware Prefetcher
To turn on/off the Mid level Cache (L2) streamer Prefetcher.
Adjacent Cache Line Prefetch
To turn on/off prefetching of adjacent cache lines.
SATA Configuration
SATA Devices Configuration.
Aptio Setup Utility
SATA Controller(s)
Enable / Disable Serial ATA Controller.
SATA Mode Selection
(1) IDE Mode.
(2) AHCI Mode.
(3) RAID Mode.
BIOS SETUP
42
Main Advanced Chipset Boot Security Save & Exit
► Platform Thermal Configuration
Main Advanced Chipset Boot Security Save & Exit
Platform Thermal Configuration
Automatic Thermal Rep
[Enabled]
Active Trip Point 0 F
100
Active Trip Point 1
[55 C]
Active Trip Point 1 F
Passive TC1 Value
Passive TC2 Value
Passive TSP Value
75
1
5
10
PCH Thermal Device
[Disabled]
Main Advanced Chipset Boot Security Save & Exit
APCI Shutdown Temperature
[Disabled]
Thermal Configuration
Aptio Setup Utility
Platform Thermal Configuration
Aptio Setup Utility
Automatic Thermal Reporting
Configure CRT, PSV and ACO automatically based on values
recommended in BWG’s thermal reporting for thermal management
settings. Set to Disable for manual configuration.
Shutdown Temperature Configuration
Aptio Setup Utility
ACPI Shutdown Temperature
Set function Disabled or 70/75/80/85/90/95/100 ℃
LAN Bypass Configuration
MB968 User’s Manual
Aptio Setup Utility
BIOS SETUP
43
Main Advanced Chipset Boot Security Save & Exit
LAN Bypass Configuration
Bypass Quick Setting
[Normal]
Main Advanced Chipset Boot Security Save & Exit
LAN Bypass Configuration
Bypass Quick Setting
[Custom Define]
WDT Reset Signal
WDT Bypass Setting
LAN5 LAN6 Bypass
LAN7 LAN8 Bypass
Ext LAN1 LAN2 Bypass
Ext LAN3 LAN4 Bypass
[Disabled]
[Normal]
[Normal]
[Normal]
[Normal]
System OFF Bypass Setting
LAN5 LAN6 Bypass
LAN7 LAN8 Bypass
Ext LAN1 LAN2 Bypass
Ext LAN3 LAN4 Bypass
[Normal]
[Normal]
[Normal]
[Normal]
Main Advanced Chipset Boot Security Save & Exit
Bypass Quick Setting
Set LAN Bypass to Normal, Bypass, Firewall or Custom Define Mode
Normal mode: All LAN ports in NORMAL. When Watchdog monitor system
hangs, software will initiates a system reboot.
Bypass mode: All LAN ports in BYPASS during power-off or watchdog initiates
Bypass. System will not reboot.
Firewall mode: All LAN ports in BYPASS until software change it to NORMAL
under OS. When watchdog monitors system hang, software will
initiates a system reboot.
Custom Define mode: Customer defines watchdog reset, watchdog Bypass and
power-off Bypass settings.
Aptio Setup Utility
Note: “Ext LAN Bypass” items only appear when extended IBASE LAN
module card installed.
AMT Configuration
Aptio Setup Utility
BIOS SETUP
44
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Intel AMT
[Enabled]
BIOS Hotkey Pressed
[Disabled]
MEBx Selection Screen
[Disabled]
Hide Un-Configure ME Confirmation
[Disabled]
Un-Configure ME
[Disabled]
Amt Wait Timer
0
Disable ME
ASF
Activate Remote Assistance Process
[Disabled]
[Enabled]
[Disabled]
USB Configure
[Enabled]
PET Progress
[Enabled]
AMT CIRA Timeout
0
Watchdog
[Disabled]
OS Timer
0
BIOS Timer
0
Main Advanced Chipset Boot Security Save & Exit
Acoustic Management Configuration
Automatic Acoustic Management
[Disabled]
AMT Configuration
Options are Enabled and Disabled.
Note: iAMT H/W is always enabled. This option just controls the BIOS
extension execution. If enabled, this requires additional firmware in the
SPI device.
Unconfigure ME
Perform AMT/ME unconfigure without password operation.
Amt Wait Timer
Set timer to wait before sending ASF_GET_BOOT_OPTIONS.
Activate Remote Assistance Process
Trigger CIRA boot.
PET Progress
User can Enable/Disable PET Events progress to receive PET events or
not.
Watchdog Timer
Enable/Disable Watchdog Timer.
Acoustic Management Configuration
MB968 User’s Manual
Aptio Setup Utility
45
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Smart fan function Enable or Disable.
Main Advanced Chipset Boot Security Save & Exit
USB Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
USB Devices:
1 Keyboard, 1 Mouse, 2 Hubs
Legacy USB Support
[Enabled]
USB3.0 Support
[Enabled]
XHCI Hand-off
[Enabled]
EHCI Hand-off
[Disabled]
Port 60/64 Emulation
[Enabled]
USB hardware delays and time-outs:
USB Transfer time-out
[20 sec]
Device reset tine-out
[20 sec]
Device power-up delay
[Auto]
USB Configuration
Aptio Setup Utility
BIOS SETUP
Legacy USB Support
Enables Legacy USB support.
AUTO option disables legacy support if no USB devices are connected.
DISABLE option will keep USB devices available only for EFI
applications.
USB3.0 Support
Enable/Disable USB3.0 (XHCI) Controller support.
XHCI Hand-off
This is a workaround for OSes without XHCI hand-off support. The
XHCI ownership change should be claimed by XHCI driver.
EHCI Hand-off
Enabled/Disabled. This is a workaround for OSes without EHCI
hand-off support. The EHCI ownership change should be claimed by
EHCI driver.
BIOS SETUP
46
Main Advanced Chipset Boot Security Save & Exit
Super IO Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
F81866 Super IO Chip
F81866
► Serial Port 0 Configuration
► Serial Port 1 Configuration
Power Failure
KB/MS Power On
[Always off]
[None]
Port 64/60 Emulation
Enables I/O port 60h/64h emulation support. This should be enabled for
the complete USB keyboard legacy support for non-USB aware OSes.
USB Transfer time-out
The time-out value for Control, Bulk, and Interrupt transfers.
Device reset tine-out
USB mass Storage device start Unit command time-out.
Device power-up delay
Maximum time the device will take before it properly reports itself to the
Host Controller. ‘Auto’ uses default value: for a Root port it is 100ms, for
a Hub port the delay is taken from Hub descriptor.
F81866 Super IO Configuration
Aptio Setup Utility
Serial Port Configuration
Set Parameters of Serial Ports. User can Enable/Disable the serial port
and Select an optimal settings for the Super IO Device.
MB968 User’s Manual
BIOS SETUP
47
Main Advanced Chipset Boot Security Save & Exit
PC Health Status
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Fan1 smart fan control
[50 C]
Fan2 smart fan control
[50 C]
Fan3 smart fan control
[Disabled]
System temperature1
System temperature2
+41 C
+38 C
System temperature3
+37 C
FAN1 Speed
1545 RPM
FAN2 Speed
1550 RPM
FAN3 Speed
1546 RPM
VIN1
+1.776 V
VIN2
+5.171 V
VIN3
+12.408 V
VSB5V
+5.016 V
VCC3V
+3.392 V
VSB3V
+3.392 V
VBAT
+3.264 V
Main Advanced Chipset Boot Security Save & Exit
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
► PCH-IO Configuration
► System Agent (SA) Configuration
F81866 H/W Monitor
Aptio Setup Utility
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as
monitored by the system and show the PC health status.
Fan1/Fan2/Fan3 Smart Fan Control
This field enables or disables the smart fan feature. At a certain
temperature, the fan starts turning. Once the temperature drops to a
certain level, it stops turning again.
Chipset Settings
This section allows you to configure and improve your system and
allows you to set up some system features according to your preference.
Aptio Setup Utility
BIOS SETUP
48
Main Advanced Chipset Boot Security Save & Exit
Intel PCH RC Version 1.6.2.0
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Intel PCH SKU Name
C226
Intel PCH Rev ID
O5/C2
► PCI Express Configuration
► USB Configuration
► PCH Azalia Configuration
► BIOS Security Configuration
PCH LAN Controller
[Enabled]
Wake on LAN
DeepSx Power Policies
Display Logic
CLKRUN# Logic
SB CRID
[Enabled]
[Disabled]
[Enabled]
[Enabled]
[Disabled]
SLP_S4 Assertion Width
[4-5 Seconds]
Restore AC Power Loss
[Last State]
PCH-IO Configuration
This section allows you to configure the North Bridge Chipset.
Aptio Setup Utility
PCH LAN Controller
Enable or disable onboard NIC.
Wake on LAN
Enable or disable integrated LAN to wake the system. (The Wake On
LAN cannot be disabled if ME is on at Sx state.)
SLP_S4 Assertion Width
Select a minimum assertion width of the SLP_S4# signal.
Restore AC Power Loss
Select AC power state when power is re-applied after a power failure.
MB968 User’s Manual
BIOS SETUP
49
Main Advanced Chipset Boot Security Save & Exit
PCI Express Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
PCI Express Clock Gating
[Enabled]
DMI Link ASPM Control
[Enabled]
DMI Link Extended Synch Control
[Disabled]
PCIE Root Port Function
[Disabled]
Subtractive Decode
[Disabled]
PCIE Port 1 is assign
► PCI Express Root Port 2
► PCI Express Root Port 3
► PCI Express Root Port 4
► PCI Express Root Port 5
► PCI Express Root Port 6
► PCI Express Root Port 7
► PCI Express Root Port 8
PCI Express Configuration
PCI Express Clock Gating
Enable or disable PCI Express Clock Gating for each root port.
DMI Link ASPM Control
The control of Active State Power Management on both NB side and SB
side of the DMI link.
PCIE Root Port Function
Enable or disable PCI express Root Port function swapping.
BIOS SETUP
50
Main Advanced Chipset Boot Security Save & Exit
USB Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
USB Precondition
[Disabled]
XHCI Mode
[Smart Auto]
BTCG
[Enable]
USB Ports Per-Port Disable Control
[Disabled]
Main Advanced Chipset Boot Security Save & Exit
PCH Azalia Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Azalia
Azalia Docking Support
Azalia PME
[Auto]
[Disabled]
[Disabled]
USB Configuration
USB Precondition
Precondition work on USB host controller and root ports for faster
enumeration.
xHCI Mode
Mode of operation of xHCI controller
BTCG
Enable or disable trunk clock gating.
USB Ports Per-Port Disable Control
Control each of the USB ports (0~13) disabling.
PCH Azalia Configuration
Azalia
Control Detection of the Azalia device.
Disabled = Azalia will unconditionally disabled.
Enabled Azalia will be unconditionally enabled.
Auto = Azalia will enabled if present, disabled otherwise.
System Agent (SA) Configuration
MB968 User’s Manual
Aptio Setup Utility
51
Main Advanced Chipset Boot Security Save & Exit
System Agent Bridge Name Haswell
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
System Agent RC Version
1.6.2.0
VT-d Capability
Supported
VT-d
[Enabled]
CHAP Device (B0:D7:F0)
[Disabled]
Thermal Device (B0:D4:F0)
[Disabled]
Enable NB CRID
[Disabled]
BDAT ACPI Table Support
[Disabled]
► Graphics Configuration
► DMI Configuration
► NB PCIe Configuration
► Memory Configuration
► Memory Thermal Configuration
► GT – Power Management Control
VT-d
Check to enable VT-d function on MCH.
Enable NB CRID
Enable or disable NB CRID WorkAround.
BIOS SETUP
BIOS SETUP
52
Main Advanced Chipset Boot Security Save & Exit
Graphics Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
IGFX VBIOS Version
2164
IGfx Frequency
Graphics Turbo IMON
700 MHz
31
Primary Display
[Auto]
Internal Graphics
[Auto]
GTT Size
[2MB]
Aperture Size
[256MB]
DVMT Pre-Allocated
[32M]
DVMT Total Gfx Mode
Gfx Low Power Mode
Graphics Performance
[256M]
[Enabled]
[Disabled]
► LCD Control
Graphics Configuration
Aptio Setup Utility
Primary Display
Select which of IGFX/PEG/PCI graphics device should be primary
display or select SG for switchable Gfx.
Internal Graphics
Keep IGD enabled based on the setup options.
DVMT Pre-Allocated
Select DVMT 5.0 Pre-Allocated (Fixed) graphics memory size used by
the internal graphics device.
DVMT Total Gfx Mem
Select DVMT 5.0 total graphics memory size used by the internal
graphics device.
Gfx Low Power Mode
This option is applicable for SFF only.
Primary IGFX Boot Display (LCD Control)
Select the Video Device that will be activated during POST. This has no
effect if external graphics present. Secondary booty display selection
will appear based on your selection. VGA modes will be supported only
on primary display.
MB968 User’s Manual
BIOS SETUP
53
Main Advanced Chipset Boot Security Save & Exit
Memory Information
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Memory Frequency
1600 MHz
Total Memory
32768 MB (DDR3)
DIMM#0
8192 MB (DDR3)
DIMM#1
8192 MB (DDR3)
DIMM#2
8192 MB (DDR3)
DIMM#3
8192 MB (DDR3)
CAS Latency (tCL)
11
Minimum delay time
CAS to RAS (tRCDmin)
11
Row Precharge (tRPmin)
11
Active to Precharge (tRASmin)
XMP Profile 1
XMP Profile 2
28
Not Supported
Not Supported
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Setup Prompt Timeout
1
Bootup NumLock State
[On]
Quiet Boot
[Disabled]
Fast Boot
[Disabled]
Boot mode select
[LEGACY]
FIXED BOOT ORDER Priorities
Boot Option #1
[Hard Disk]
Boot Option #2
[CD/DVD]
Boot Option #3
[USB Hard Disk]
Boot Option #4
Boot Option #5
Boot Option #6
Boot Option #7
[USB CD/DVD]
[USB Key]
[USB Floppy]
[Network] ► CSM16 parameters
Memory Configuration
Boot Settings
Aptio Setup Utility
Aptio Setup Utility
Setup Prompt Timeout
Number of seconds to wait for setup activation key.
65535(0xFFFF) means indefinite waiting.
Bootup NumLock State
Select the keyboard NumLock state.
BIOS SETUP
54
Main Advanced Chipset Boot Security Save & Exit
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
CSM16 Parameters
CSM16 Module Version
07.70
GateA20 Active
[Upon Request]
Option ROM Messages
[Force BIOS]
INT19 Trap Response
[Immediate]
Quiet Boot
Enables/Disables Quiet Boot option.
Fast Boot
Enables/Disables boot with initialization of a minimal set of devices
required to launch active boot option. Has no effect for BBS boot
options.
Boot Option Priorities
Sets the system boot order.
CSM16 parameters
This section allows you to configure the boot settings.
GateA20 Active
UPON REQUEST: GA20 can be disabled using BIOS services
ALWAYS: do not allow disabling GA20; this option is useful when any
RT code is executed above 1MB.
Option ROM Messages
Set display mode for Option ROM
INT19 Trap Response
BIOS reaction on INT19 trapping by option ROM:
IMMEDIATE: execute the trap right away.
POSTPONED: execute the trap during legacy boot.
Aptio Setup Utility
MB968 User’s Manual
BIOS SETUP
55
Main Advanced Chipset Boot Security Save & Exit
Password Description
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
If ONLY the Administrator’s password is set, then
this only limit access to Setup and is only asked for
when entering Setup.
If ONLY the User’s password is set, then this is a
power on password and must be entered to boot
or enter Setup. In Setup the User will have
Administrator rights
The password length must be
in the following range:
Minimum length
3
Maximum length
20
Administrator Password
User Password
Security Settings
This section allows you to configure and improve your system and
allows you to set up some system features according to your preference.
Administrator Password
Set Setup Administrator Password.
User Password
Set User Password.
Aptio Setup Utility
BIOS SETUP
56
Main Advanced Chipset Boot Security Save & Exit
Save Changes and Exit
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Discard Changes and Exit
Save Changes and Reset
Discard Changes and Reset
Save Options
Save Changes
Discard Changes
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
Launch EFI Shell from filesystem device
Save & Exit Settings
Aptio Setup Utility
Save Changes and Exit
Exit system setup after saving the changes.
Discard Changes and Exit
Exit system setup without saving any changes.
Save Changes and Reset
Reset the system after saving the changes.
Discard Changes and Reset
Reset system setup without saving any changes.
Save Changes
Save Changes done so far to any of the setup options.
Discard Changes
Discard Changes done so far to any of the setup options.
Restore Defaults
Restore/Load Defaults values for all the setup options.
Save as User Defaults
Save the changes done so far as User Defaults.
Restore User Defaults
Restore the User Defaults to all the setup options.
MB968 User’s Manual
DRIVERS INSTALLATION
57
Drivers Installation
This section describes the installation procedures for software and
drivers. The software and drivers are included with the motherboard. If
you find the items missing, please contact the vendor where you made
the purchase. The contents of this section include the following:
Intel Chipset Software Installation Utility ........................................... 56
VGA Drivers Installation ..................................................................... 58
LAN Drivers Installation ..................................................................... 61
Intel® Management Engine Interface .................................................. 64
Intel® USB 3.0 Drivers ....................................................................... 66
IMPORTANT NOTE:
After installing your Windows operating system, you must install first
the Intel Chipset Software Installation Utility before proceeding with the
drivers installation.
DRIVERS INSTALLATION
58
Intel Chipset Software Installation Utility
The Intel Chipset Drivers should be installed first before the software
drivers to enable Plug & Play INF support for Intel chipset components.
Follow the instructions below to complete the installation.
1. Insert the DVD that comes with the board. Click Intel and then
Intel(R) 8 Series Chipset Drivers.
2. Click Intel(R) Chipset Software Installation Utility.
MB968 User’s Manual
DRIVERS INSTALLATION
59
3. When the Welcome screen to the Intel® Chipset Device Software
appears, click Next to continue.
4. Click Yes to accept the software license agreement and proceed with
the installation process.
5. On the Readme File Information screen, click Next to continue the
installation.
6. The Setup process is now complete. Click Finish to restart the
computer and for changes to take effect.
DRIVERS INSTALLATION
60
VGA Drivers Installation
1. Insert the DVD that comes with the board. Click Intel and then
Intel(R) 8 Series Chipset Drivers.
2. Click Intel(R) Core(TM) i3/i5/i7 Graphics Driver.
MB968 User’s Manual
DRIVERS INSTALLATION
61
3. When the Welcome screen appears, click Next to continue.
4. Click Yes to to agree with the license agreement and continue the
installation.
DRIVERS INSTALLATION
62
5. On the screen shown below, click Install to continue.
6. Setup complete. Click Finish to restart the computer and for changes
to take effect.
MB968 User’s Manual
DRIVERS INSTALLATION
63
LAN Drivers Installation
1. Insert the DVD that comes with the board. Click Intel and then
Intel(R) 8 Series Chipset Drivers.
2. Click Intel(R) PRO LAN Network Driver.
DRIVERS INSTALLATION
64
3. Click Install Drivers and Software.
4. When the Welcome screen appears, click Next.
MB968 User’s Manual
DRIVERS INSTALLATION
65
5. Click Next to to agree with the license agreement.
6. Click the checkbox for Drivers in the Setup Options screen to select it
and click Next to continue.
7. The wizard is ready to begin installation. Click Install to begin the
installation.
8. When InstallShield Wizard is complete, click Finish.
DRIVERS INSTALLATION
66
Intel® Management Engine Interface
Follow the steps below to install the Intel Management Engine.
1. Insert the DVD that comes with the board. Click Intel and then
Intel(R) 8 Series Chipset Drivers and then Intel(R) AMT 9.0 Drivers.
MB968 User’s Manual
DRIVERS INSTALLATION
67
2. When the Welcome screen to the InstallShield Wizard for Intel®
Management Engine Components, click the checkbox for Install Intel®
Control Center & click Next.
3. Click Yes to to agree with the license agreement.
4. When the Setup Progress screen appears, click Next. Then, click
Finish when the setup progress has been successfully installed.
DRIVERS INSTALLATION
68
Intel® USB 3.0 Drivers
1. Insert the DVD that comes with the board. Click Intel and then
Intel(R) 8 Series Chipset Drivers.
2. Click Intel(R) USB 3.0 Drivers.
MB968 User’s Manual
DRIVERS INSTALLATION
69
3. When the Welcome screen to the InstallShield Wizard for Intel® USB
3.0 eXtensible Host Controller Driver, click Next.
4. Click Yes to to agree with the license agreement and continue the
installation.
DRIVERS INSTALLATION
70
5. On the Readme File Information screen, click Next to continue the
installation of the Intel® USB 3.0 eXtensible Host Controller Driver.
6. Setup complete. Click Finish to restart the computer and for changes
to take effect.
MB968 User’s Manual
DRIVERS INSTALLATION
71
Address
Device Description
000h - 01Fh
DMA Controller #1
020h - 03Fh
Interrupt Controller #1
040h - 05Fh
System Timer
060h - 064h
Keyboard Controller
070h - 07Fh
Real Time Clock
080h - 09Fh
DMA Controller #2
0A0h - 0BFh
Interrupt Controller #2
0C0h - 0DFh
DMA Controller #3
0F0h
Clear Math Coprocessor Busy Signal
0F1h
Reset Math Coprocessor
3B0h- 3DFh
Graphics adapter Controller
3F8h - 3FFh
Serial Port #0 (COM1)
2F8h - 2FFh
Serial Port #1 (COM2)
3E8h – 3EFh
Serial Port #2 (COM3)
2E8h – 2EFh
Serial Port #3 (COM4)
3E8h - 3EFh
Serial Port #4 (COM5)
2E8h - 2EFh
Serial Port #5 (COM6)
360h - 36Fh
Network Ports
Appendix
A. I/O Port Address Map
Each peripheral device in the system is assigned a set of I/O port
addresses which also becomes the identity of the device. The following
table lists the I/O port addresses used.
APPENDIX
72
Level
Function
IRQ0
System Timer Output
IRQ1
Keyboard
IRQ4
Serial Port #1
IRQ3
Serial Port #2
IRQ5
Serial Port #3
IRQ11
Serial Port #4
IRQ8
Real Time Clock
IRQ14
Primary IDE
IRQ15
Secondary IDE
B. Interrupt Request Lines (IRQ)
Peripheral devices use interrupt request lines to notify CPU for the
service required. The following table shows the IRQ used by the devices
on board.
MB968 User’s Manual
DRIVERS INSTALLATION
73
I2C Address (8bit)
Remark
1st Controller
0x68
2nd Controller
0x6A
Optional
Bit
LAN
Port#
Read /
Write
Description
0
Eth5, 6
Read /
Write
Enable / Disable LAN Bypass
function when the system is
power On.
1 = Enable LAN Bypass function
0 = Disable LAN Bypass
function
1
Eth7, 8
2
Expansion
LAN Card
Eth1, 2
3
Expansion
LAN Card
Eth3, 4
C. Register of the LAN Bypass Controller
To fulfill the varied requests on LAN Bypass controller, IBASE provide
the smart LAN Bypass controller. User can define the Bypass function
behavior when the system is power-on, power-off and WDT signal is
asserted.
The controller is behind the SMBus controller. The I2C address is listed
as below:
CR 0x22 : System-On Bypass Register
Attribute : Read / Write
Reset default : 0x0000
APPENDIX
74
Bit
LAN
Port#
Read /
Write
Description
0
Eth5, 6
Read /
Write
Enable / Disable LAN Bypass
function when the system is
power Off.
1 = Enable LAN Bypass function
0 = Disable LAN Bypass function
1
Eth7, 8
2
Expansion
LAN Card
Eth1, 2
3
Expansion
LAN Card
Eth3, 4
Bit
Read /
Write
Description
0
Read /
Write
WDT_OUT# Generator
The capacity use the WDT to reset the
system
1 = Generate 100ms pulse to reset signal
when WDT signal is asserted.
0 = Ignore the WDT signal.
1
Read /
Write
WDT LAN Bypass Enable
The capacity use the WDT to set LAN
Bypass function
1 = Enable LAN Bypass function when the
WDT signal is asserted.
CR 0x28 and CR 0x2A will be available
if this bit is set to "1".
0 = Disable WDT LAN Bypass function.
2 ~ 7
Reserved
CR 0x24 : System-Off Bypass Register
Attribute : Read / Write
Reset default : 0x0000
CR 0x26 : Watchdog (WDT) WDT_IN# Signal Control Register
Attribute : Read / Write
Reset default : 0x00
MB968 User’s Manual
DRIVERS INSTALLATION
75
Bit
LAN
Port#
Read /
Write
Description
0
Eth5, 6
Read /
Write
Enable / Disable WDT Bypass
function for each LAN port.
1 = Follow the setting in "WDT
Bypass Register CR 0x2A"
when the WDT signal is
asserted.
0 = Ignore to control the bypass
when the WDT is asserted.
1
Eth7, 8
2
Expansion
LAN Card
Eth1, 2
3
Expansion
LAN Card
Eth3, 4
Bit
LAN
Port#
Read /
Write
Description
0
Eth5, 6
Read /
Write
The function works when the bit
in CR 0x28 is “1”. It controls
LAN Bypass function should be
Enabled / Disabled when the
WDT signal is asserted.
If the bit is set to "1" in "WDT
Bypass Control Register
CR 0x28", it will follow below
setting:
1 = Enable LAN Bypass
function
0 = Disable LAN Bypass
function
1
Eth7, 8
2
Expansion
LAN Card
Eth1, 2
3
Expansion
LAN Card
Eth3, 4
CR 0x28 : Watchdog (WDT) Bypass Control Register
Attribute : Read / Write
Reset default : 0x0000
CR 0x2A : Watchdog (WDT) Bypass Register
Attribute : Read / Write
Reset default : 0x0000
APPENDIX
76
Bit
LAN
Port#
Read /
Write
Description
0
Eth5, 6
Read
1 = The expansion slot is
populated & support LAN
Bypass function
0 = The expansion slot is empty
or does not support LAN
Bypass function
1
Eth7, 8
2
Expansion
LAN Card
Eth1, 2
3
Expansion
LAN Card
Eth3, 4
CR 0x2C : Card Plugged and Bypass Status Register
Attribute : Read
Reset default : N/A
MB968 User’s Manual
Loading...
