IBASE MB900 User Manual

MB900-R

Socket LGA775 Pentium® 4

Intel® 945G/945GC Chipset

Industrial Motherboard

USER’S MANUAL

Version 1.1

Acknowledgments

Award is a registered trademark of Award Software International,
Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Pentium 4 are registered trademarks of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.

ii MB900-R User’s Manual

Table of Contents

Introduction ....................................................... 1

Checklist .............................................................................. 1

MB900-R Specifications ..................................................... 2

Board Dimensions ............................................................... 3

Installations ....................................................... 5

Installing the CPU ............................................................... 6

ATX Power Installation ...................................................... 7

Installing the Memory ......................................................... 7

Setting the Jumpers ............................................................. 8

Connectors on MB900-R .................................................. 12

Watchdog Timer Configuration ........................................ 21

BIOS Setup ....................................................... 27

Drivers Installation ...................................... 49

Appendix ........................................................... 59

A. I/O Port Address Map ................................................... 59

B. Interrupt Request Lines (IRQ) ...................................... 60

MB900-R User’s Manual iii

This page is intentionally left blank.

iv MB900-R User’s Manual

Introduction

Checklist

Your MB900-R Pentium
items listed below:

• The MB900-R motherboard

• This User’s manual

• 1 Back I/O shield

• 1 IDE cable

• 1 Floppy cable

• 1 SATA cable

• 1 Serial-Port cable

• 1 CD containing the following:

• Chipset Drivers

• Flash Memory Utility

®

4 motherboard package should include the

INTRODUCTION

MB900-R User’s Manual 1

INSTALLATIONS

d

MB900-R Specifications

Form Factor Micro-ATX / 244mm x 244mm
CPU Type Intel Pentium D (dual core) / Pentium 4 / Celeron D
CPU Voltage 0.8375V~1.6V (VRD 10.1)
System Speed 3.8GHz
CPU FSB 533/800/1066MHz
Green /APM APM1.2
CPU Socket Socket 775
Cache 256K/1M/2M Level 2 (CPU integrated)
Chipset Intel 945G/945GC Chipset

GMCH: 945G/945GC, 1202-pin FCBGA

ICH: ICH7/ICH7R 652-pin mBGA; FWH
BIOS Award BIOS Support ACPI Function
Memory 2x DDRII 533/667 DIMM Modules (w/o ECC), Max. 2GB

(Dual Channels)
VGA 945G/945GC built-in, support CRT
LAN 1. ICH7/ICH7R LAN (10/100Mb) + PHY 82562ET

2. Marvel 88E8052 PCI-Exp Gigabit LAN controller x1

USB CH7/ICH7R built-in USB 2.0 host controller, supports 8

ports
SATA II ICH7/ICH7R (RAID 0,1) built-in Serial ATA II controller

(300MB/s), 2 ports
Parallel IDE ICH7/ICH7R built-in one channel Ultra DMA 33/66/100,

IDE1 40-pin, 2.5mm; Compact Flash Socket x1 on IDE1
Audio ICH7/ICH7R Built-in Audio controller + AC97 Codec

ALC880 8 Channel (Line-out, Line-in & Mic.)
LPC I/O Winbond W83627EHG: Parallel x1, FDC 1.44MB, COM1

(RS232), COM2 (RS232/422/485), Hardware monitor (3

thermal inputs, 4 voltage monitor inputs, VID0-4 & 3 Fan

n

2

LPC I/O Fintek F81216, supports COM3, 4 (RS232)

headers). Not use IrDA

Expansion Slots PCI Express x16 slot x1

PCI Express x1 slot x1

PCI slot x2
Edge Connectors PS/2 KB/Mouse, LPT, VGA, COM1, Dual triple DIN for

high definition audio, RJ45, USB x4
On Board Headers
/ Connectors

USB x 4, SATA x2, IDE1, FDD, COM2/3/4, IrDA, audio

(line out / Mic.)
Power Connector ATX 12V (24 pin + 8 pin)
System Voltage +5V, +3.3V, +12V, -12V & 5VSB (2A)
Watchdog Timer Yes (256 segments: 0, 1, 2…, 255 sec/min)
Digital I/O 4 In / 4 Out
BIOS Function

- Power on after power fail

- Boot from USBCDROM/USBZIP/USBHDD/USB/HDD

& PXE boot

- Supports PC health monitoring for CPU, power supply,
Aux temperatures and voltages. Supports CPU
overheating protection

Remarks: MB900-R supports both Pentium® D dual core CPU and
Pentium® 4 single core CPU. It also supports EMT64 processors.

2 MB900-R User’s Manual

Board Dimensions

INTRODUCTION

MB900-R User’s Manual 3

INSTALLATIONS

This page is intentionally left blank.

4 MB900-R User’s Manual

INSTALLATIONS

Installations

This section provides information on how to use the jumpers and
connectors on the MB900-R in order to set up a workable system. The
topics covered are:

Installing the CPU ................................................................................. 6

ATX Power Installation ......................................................................... 7

Installing the Memory ........................................................................... 7

Setting the Jumpers ................................................................................ 8

Connectors on MB900-R ..................................................................... 12

Watchdog Timer Configuration........................................................... 21

MB900-R User’s Manual 5

INSTALLATIONS

Installing the CPU

The MB900-R motherboard supports an LGA 775 processor socket for
Intel® Pentium® 4 processors.

The LGA 775 processor socket comes with a lever to secure the
processor. Refer to the pictures below, from left to right, on how to place
the processor into the CPU socket. Please note that the cover of the

LGA775 socket must always be installed during transport to avoid
damage to the socket.

6 MB900-R User’s Manual

INSTALLATIONS

ATX Power Installation

The system power is provided to the motherboard with the ATX1 and
ATX_12V power connectors. ATX1 is a 24-pin power connector and
ATX_12V is a 8-pin 12V power connector.

The 24-pin power connector can to be connected to a standard 20-pin
ATX power connector in a standard ATX power supply (Min. 400watt).

Note: The power supply 5VSB voltage must be at least 2A.

Installing the Memory

The MB900-R motherboard supports two DDR2 memory sockets for a
maximum total memory of 2GB in DDR memory type. It supports
DDR2 533/667.

Basically, the system memory interface has the following features:

Supports two 64-bit wide DDR data channels
Available bandwidth up to 5.3GB/s (DDR2 667) for single-channel
mode and 10.7GB/s (DDR2 667) in dual-channel mode.
Supports 256Mb, 512Mb, 1Gb DDR2 technologies.
Supports only x8, x16, DDR2 devices with four banks
Supports only unbuffered DIMMs
Supports opportunistic refresh
Up to 32 simultaneously open pages (four per row, four rows
maximum)

MB900-R User’s Manual 7

INSTALLATIONS

Setting the Jumpers

Jumpers are used on MB900-R to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on MB900-R and their respective functions.

Jumper Locations on MB900-R ...................................................... 9

JP1, JP2, JP3: RS232/422/485 (COM2) Selection ....................... 10

JP4: IDE DMA Mode Setting ....................................................... 10

JP6: Clear CMOS Contents .......................................................... 10

JP7: CF Socket Master / Slave Selection ...................................... 11

8 MB900-R User’s Manual

INSTALLATIONS

Jumper Locations on MB900-R

JP1, JP2, JP3: RS232/422/485 (COM2) Selection .............................. 10

JP4: IDE DMA Mode Setting .............................................................. 10

JP6: Clear CMOS Contents ................................................................. 10

JP7: CF Socket Master / Slave Selection ............................................. 11

MB900-R User’s Manual 9

INSTALLATIONS

JP1, JP2, JP3: RS232/422/485 (COM2) Selection

COM1 is fixed for RS-232 use only.
COM2 is selectable for RS232, RS-422 and R S-485. COM3 and C OM4
are fixed for RS-232 use only. The following table describes the jumper
settings for COM2 selection.

JP4: IDE DMA Mode Setting

COM2

Function

Jumper
Setting

(pin closed)

RS-232 RS-422 RS-485

JP1:

1-2

JP2:

3-5 & 4-6

JP3:

3-5 & 4-6

JP1:

3-4

JP2:

1-3 & 2-4

JP3:

1-3 & 2-4

JP1:

5-6

JP2:

1-3 & 2-4

JP3:

1-3 & 2-4

JP4 Setting Function

Pin 1-2

Short/Closed

Pin 2-3

Short/Closed

UDMA66 (default)

Forced UDMA33

JP6: Clear CMOS Contents

Use JP6, a 3-pin header, to clear the CMOS contents. Note that the
ATX-power connector should be disconnected from the motherboard
before clearing CMOS.

JP6 Setting Function

Pin 1-2

Short/Closed

Pin 2-3

Short/Closed

10 MB900-R User’s Manual

Normal

Clear CMOS

JP7: CF Socket Master / Slave Selection

JP7 CF Mode

Slave

Master

INSTALLATIONS

MB900-R User’s Manual 11

INSTALLATIONS

[

Connectors on MB900-R

The connectors on MB900-R allows you to connect external devices
such as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on MB900-R and their respective
functions.

ATX1: 24-pin ATX Power Connector ................................................. 14

ATX2: ATX 12V Power Connector .................................................... 14

MB900-R Edge Connectors ................................................................. 14

CN1: PS/2 Keyboard and PS/2 Mouse Connectors ............................. 15

CN2, J2, J7, J8: COM1/2/3/4 Serial Ports ........................................... 15

CN3: Parallel Port Connector .............................................................. 16

CN4: VGA CRT Connector ................................................................. 16

CN5: Audio Connector ........................................................................ 17

CN6: 10/100 RJ-45 and USB0/1 Connector ........................................ 17

CN7: GbE RJ-45 and USB2/3 Connector ............................................ 17

CN11, CN10: SATA0/1 Connector ..................................................... 17

J1: Digital I/O Connector (4 in, 4 out) ................................................. 18

J3: Audio Front Header ....................................................................... 18

J5: USB4/USB5 Connector ................................................................. 18

J6: USB6/USB7 Connector ................................................................. 18

J9: Wake On LAN Connector .............................................................. 19

J10: System Function Connector ......................................................... 19

J11: IrDA Connector ............................................................................ 19

FAN1: CPU Fan Power Connector ..................................................... 19

FAN2, FAN3, FAN4: Fan Power Connectors ..................................... 20

IDE1: Primary IDE Connectors ........................................................... 20

PCIE_1: x16 PCI Express Slot ............................................................ 20

PCIE_2: x1 PCI Express Slot .............................................................. 20

PCI1, PCI5: PCI Slots .......................................................................... 20

CN12: CF Socket ................................................................................. 20

J12: SMBus .......................................................................................... 20

12 MB900-R User’s Manual

INSTALLATIONS

Connector Locations on MB900-R

ATX1: 24-pin ATX Power Connector ................................................................................................................ 14

ATX2: ATX 12V Power Connector .................................................................................................................... 14

MB900-R Edge Connectors ................................................................................................................................ 14

CN1: PS/2 Keyboard and PS/2 Mouse Connectors ............................................................................................. 15

CN2, J2, J7, J8: COM1/2/3/4 Serial Ports ........................................................................................................... 15

CN3: Parallel Port Connector .............................................................................................................................. 16

CN4: VGA CRT Connector ................................................................................................................................ 16

CN5: Audio Connector ........................................................................................................................................ 17

CN6: 10/100 RJ-45 and USB0/1 Connector ....................................................................................................... 17

CN7: GbE RJ-45 and USB2/3 Connector ........................................................................................................... 17

CN11, CN10: SATA0/1 Connector ..................................................................................................................... 17

J1: Digital I/O Connector (4 in, 4 out) ................................................................................................................ 18

J3: Audio Front Header ....................................................................................................................................... 18

J5: USB4/USB5 Connector ................................................................................................................................. 18

J6: USB6/USB7 Connector ................................................................................................................................. 18

J9: Wake On LAN Connector ............................................................................................................................. 19

J10: System Function Connector ......................................................................................................................... 19

J11: IrDA Connector ........................................................................................................................................... 19

FAN1: CPU Fan Power Connector .................................................................................................................... 19

FAN2, FAN3, FAN4: Fan Power Connectors..................................................................................................... 20

IDE1: Primary IDE Connectors ........................................................................................................................... 20

PCIE_1: x16 PCI Express Slot ............................................................................................................................ 20

PCIE_2: x1 PCI Express Slot .............................................................................................................................. 20

PCI1, PCI5: PCI Slots ......................................................................................................................................... 20

CN12: CF Socket ................................................................................................................................................. 20

J12: SMBus ......................................................................................................................................................... 20

MB900-R User’s Manual 13

INSTALLATIONS

ATX1: 24-pin ATX Power Connector

Signal Name Pin # Pin # Signal Name

3.3V 13 1 3.3V

-12V 14 2 3.3V

Ground 15 3 Ground

PS-ON 16 4 +5V
Ground 17 5 Ground
Ground 18 6 +5V
Ground 19 7 Ground

-5V 20 8 Power good
+5V 21 9 5VSB
+5V 22 10 +12V
+5V 23 11 +12V

Ground 24 12 +3.3V

ATX2: ATX 12V Power Connector

Signal Name Pin # Pin # Signal Name

+12V 5 1 Ground
+12V 6 2 Ground
+12V 7 3 Ground
+12V 8 4 Ground

MB900-R Edge Connectors

14 MB900-R User’s Manual

INSTALLATIONS

CN1: PS/2 Keyboard and PS/2 Mouse Connectors

Keyboard

Signal

Pin # Mouse

Signal

Keyboard data 1 Mouse data

N.C. 2 N.C.

GND 3 GND

Mouse (top)

Keyboard (bottom)

5V 4 5V

Keyboard clock 5 Mouse clock

N.C. 6 N.C.

CN2, J2, J7, J8: COM1/2/3/4 Serial Ports

CN2 (COM1) is a DB-9 connector, while J2, J7 and J8 are COM
pin-header connectors.

COM1 COM2

Signal Name Pin # Pin # Signal Name

DCD, Data carrier detect 1 6 DSR, Data set ready

RXD, Receive data 2 7 RTS, Request to send

TXD, Transmit data 3 8 CTS, Clear to send

DTR, Data terminal ready 4 9 RI, Ring indicator

GND, ground 5 10 Not Used

COM2 is jumper selectable for RS-232, RS-422 and RS-485.

Pin # Signal Name

RS-232 R2-422 RS-485

1 DCD TX- DATA­2 RX TX+ DATA+
3 TX RX+ NC
4 DTR RX- NC
5 Ground Ground Ground
6 DSR RTS- NC
7 RTS RTS+ NC
8 CTS CTS+ NC
9 RI CTS- NC

10 NC NC NC

MB900-R User’s Manual 15

INSTALLATIONS

CN3: Parallel Port Connector

CN3 is a DB-25 external connector on top of the VGA and serial ports.

CN4 Parallel Port

Signal Name Pin # Pin # Signal Name

Line printer strobe 1 14 AutoFeed
PD0, parallel data 0 2 15 Error
PD1, parallel data 1 3 16 Initialize
PD2, parallel data 2 4 17 Select
PD3, parallel data 3 5 18 Ground
PD4, parallel data 4 6 19 Ground
PD5, parallel data 5 7 20 Ground
PD6, parallel data 6 8 21 Ground
PD7, parallel data 7 9 22 Ground
ACK, acknowledge 10 23 Ground

Busy 11 24 Ground

Paper empty 12 25 Ground

Select 13 N/A N/A

CN4: VGA CRT Connector

CN4 is a DB-15 VGA connector located beside the COM1 port. The
following table shows the pin-out assignments of this connector.

Signal Name Pin # Pin # Signal Name

Red 1 2 Green

Blue 3 4 N.C.
GND 5 6 GND
GND 7 8 GND
VCC 9 10 GND

N.C. 11 12 DDCDATA

HSYNC 13 14 VSYNC

DDCCLK 15

16 MB900-R User’s Manual
