1

IPPCxxA7-RE User Manual

CHAPTER 1 INTRODUCTION

1.1 General Description

IPPC-xxA7-RE series is a fanless design panel pc, powered by Intel Atom processor D2550 1.86GHz and supporting 2 x SO-DIMM, up to 4GB DDRIII 1066MHz FSB, 4x USB connector, 1x COM Port, support 1x SATA HDD space, 1x PCI slot expansion, DC power 12V input etc. It is ideal for industrial automation, factory automation applications.

2

IPPCxxA7-RE User Manual

Model Name

IPPC-12A7-RE

IPPC-15A7-RE

IPPC-17A7-RE

IPPC19A7-RE

System Mainboard

IB806

CPU

Intel Atom Process D2550 1M Cache, 1.86GHz

Chipset

Intel NM10 Express Chipset

Memory

2 x DDR3 1600MHz DIMM, Max. 16GB (Non-ECC)

I/O Interface

2 x Gigabit LAN (RJ45) 4 x USB 2.0 (USB Host. A-Type) 1 x COM1 RS-232/422/485 1 x 12V DC-in 1 x VGA 1 x speaker-out microjack 1 x Mic-in microjack 1 x Digital I/O

Storage

1 x 2.5” 320GB SATA HDD

Expansion Slots

1 x PCI slot

Power Supply

+ 12C DC-in, 84W power adaptor

LCD Size

12” TFT LCD

15” TFT LCD

17” TFT LCD

19” TFT LCD

LCD Color

16.7M colors

LCD Resolution

1024 x 768

1280 x 1024

LCD Brightness

500 cd/m2

400 cd/m2

350 cd/m2

LCD Viewing Angle

160(H)/160(V)

170(H)/170(V)

170(H)/160(V)

Backlight MTBF

50,000 hrs

Touch Screen

Resistive Touch Panel

Construction

Aluminum & SGCC

Aluminum & SPCC

Mounting

Panel Mount / VESA Mount 75x75 and 100x100 mm

Dimensions (W)x(H)x(D) mm

320 x 270 x 60.5

390 x 315 x 65.5

430 x 365 x 73

465 x 390 x 73

Operating Temperature

0°C ~ 45°C

Storage Temperature

-10°C ~ 60°C

-20°C ~ 80°C

Relative Humidity

5~90% @45°C (non-condensing)

Protection Class

IP65 (Front panel with wall mount)

1.2 System Specification

1.2.1 Hardware Specifications

‧

This specification is subject to change without prior notice.

3

IBASE Technology Inc.

1.2.2 Dimensions

IPPC12A7-RE

IPPC15A7-RE

4

IPPCxxA7-RE User Manual

IPPC17A7-RE

IPPC19A7-RE

5

IBASE Technology Inc.

1.2.3 I/O View

6

IPPCxxA7-RE User Manual

7

IBASE Technology Inc.

Part NO.

Description

Qty

1

Driver CD

1 pc

2

Mounting Kits

1 set

3

Power Cord

1 pc

1.3 Packing List

1.4 Installation

1.4.1 Installing the Panel Mount

8

IPPCxxA7-RE User Manual

9

IBASE Technology Inc.

1.4.2 Installing the VESA Mount

10

IPPCxxA7-RE User Manual

1.4.3 Installing the PCI and WIFI module

11

IBASE Technology Inc.

8. Connect the WIFI internal antenna onto the WIFI module.

12

IPPCxxA7-RE User Manual

9. Push the WIFI module into the slot.

10. Use a screwdriver to turn the screw to its unlocked position.

13

IBASE Technology Inc.

11. Push the internal antenna into the position as picture.

12. Lock the screw as picture.

14

IPPCxxA7-RE User Manual

13. Connect the external antenna to its position as picture.

15

IBASE Technology Inc.

1.4.4 Disassembly and Assembly of control box and display module

16

IPPCxxA7-RE User Manual

17

IBASE Technology Inc.

18

IPPCxxA7-RE User Manual

Specifications – Mainboard

Model

IB806

Form Factor

Customized

CPU Type

Intel® “Cedar view” Processor, 32nm Bulk AtomTM D2500 [TDP= 10W] Package = FCBGA Type[ 22 mm x 22 mm] Cores / Threads = 2/2 [D2500]

CPU Speed

1.86GHz for D2500

Cache

1MB

CPU Socket

BGA437 @ component side

Chipset

Intel® “Tiger Point” NM10 PCH, CG82NM10 [TDP = 2.1W, 130nm] Package = BGA360, 17mm x 17 mm

BIOS

AMI BIOS, support ACPI Function

Memory

DRAM: Intel® Atom TM on-die memory controller supporting up to 4GB One DDR3-1066 SO-DIMM socket [Horizontal type], Non-ECC, Unbuffered, 1.5V

SRAM: CPLD EPM1270 + ST M40SZ100W x 4 SRAM 2Mb Battery: CR2450

LVDS

24-bit single channels LVDS interface w/PCIEx8 golden finger

VGA

Support DirectX 10.1 / OpenGL 3.0 IGP DB15 connector for VGA

LAN

Realtek® 8111E (GbE) as 1st LAN Realtek® 8111E (GbE) as 2nd LAN

Audio

Intel® NM10 PCH built-in HD Audio controller + Realtek ALC662 Codec w/class-D speaker amplifier (2.3W per channel @ 5V power supply) [7mm x 7mm @ 48-QFN] ; support 2-channel audio out + amp

CHAPTER 2 MOTHERBOARD INTRODUCTION

2.1 Introduction

The IB806 Embedded Flex Motherboard is based on the Intel® Atom Cedarview chipset. Cedar Trail is a platform that uses the Intel Cedarview-D or Cedarview-M processor and Intel NM10 Express Chipset family in the desktop platforms.

The role of the processor in the system is to manage the flow of information between the following interfaces: DDR3 System Memory interface, DVI display interface, VGA graphics interface, Low Voltage Differential Signaling (LVDS) and the Direct Media Interface (DMI). The processor supports single channel, one DDR3 SODIMMs. The Intel® processors provide advanced performance in both computing and graphics quality. This meets the requirement of customers in the gaming, POS, digital signage and server market segment.

The processor is built on 32-nanometer Hi-K process technology with Micro-FCBGA11 packaging. Dimensions of the board are 190mm x 110mm.

19

IBASE Technology Inc.

USB

Intel® NM10 PCH integrated USB 2.0 host controller:

1. 4 ports in the rear panel

2. 1 port via onboard Mini-PCIE

3. 2 ports via edge golden-finger for connecting with ID910

4. 1 ports via edge golden-finger for connecting with IP930 **Total 8 x USB 2.0 ports**

LPC I / O

Nuvoton NCT6627UD [128-pin QFP, 14x14x1.4mm]

- COM #1 (RS232/422/485 jumper-less) support ring-in with power @500 mA (selectable for 5V or 12V)

- COM #2 (RS232 only) support ring-in with power @500 mA (cable selectable by pin#9 or pin#10 for 5V or 12V) via onboard pin-header

- COM #3(TTL for MCU usage) thru golden finger to expansion module (ID910)

- COM #4 (TTL for daughter board usage) thru golden finger to expansion module

[Hardware Monitor] 2x Thermal inputs; 2x Voltage monitoring

Expansion Slot

Mini PCI-e socket x 1, Full-sized type, reserved one mounting hole for half-sized type, [USB device support]

Digital IO

2 in & 2 out with 5V Vcc 0.5A and GND [thru edge connector @ 1x6 pins Terminal block type] Connector type Dinkle ECH350R-06P

Edge Connector

VGA DB15 connector, DB9 1 for COM1 Digital I/O connector @ 1x6 pin type RJ45 x2 for GbE LAN, USB 2.0 connector x 4 for USB1~4 Line-out microjack, Mic-in microjack x 1

Onboard Header/Conn ector

2 ports x SATA II 4-pin power connector x2 for SATA HDD 2x5-pin box header for COM #2 2x5-pin header for LPC (Debug purpose only) Mini PCI-e(1x) connector [Full-sized] 5-pin box header for smart battery interface 2x2-pin power connector, 2x2-pin power vertical type connector 1x power button

Watchdog Timer

Yes (256 segments, 0, 1, 2…255 sec/min)

Power management

MSP430G2433

Power Connector

+12V DC-in only for AT/ATX mode

RoHS

Yes

Golden Finger

A. PCIE(x16) golden finger x 1 for connecting with IP930 Including the signals below:

- PCIe(1x) x1, PCI x1, COM(TTL) x1, USB 2.0 x 1

- 12V 4A power, 5V 2A, 3.3V 2A

**Each pin for PCI-express is 1A** B. PCIE(8x) for ID910 board

- COM (TTL) x1, USB 2.0 x2, 24-bit LVDS, DVI x1

- PWR button x1, Reset button x1, LED signal HDD x1

- Audio x1, Audio detect pin for AMP x1

- 12V 4A power, 5V 4A power, 3.3V 4A power

- SCI x1

20

IPPCxxA7-RE User Manual

Board Dimensions

2.2 Installing the Memory

The IB806 board supports two DDR3 memory socket for a maximum total memory of 2GB in DDR3 memory type.

Installing and Removing Memory Modules

To install the DDR3 modules, locate the memory slot on the board and perform the following steps:

1. Hold the DDR3 module so that the key of the DDR3 module aligned with that on the memory slot.

2. Gently push the DDR3 module in an upright position until the clips of the slot close to hold the DDR3 module in place when the DDR3 module touches the bottom of the slot.

3. To remove the DDR3 module, press the clips with both hands.

21

IBASE Technology Inc.

JP7, JP3

Setting

Function

Pin 1-2

Short/Closed

+12V

Pin 3-4

Short/Closed

RI

Pin 5-6

Short/Closed

+5V

2.3 Setting Jumpers

Jumpers are used on IB806 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on IB806 and their respective functions.

Jumper Locations on IB806

JP7, JP3: COM1, COM2 RS232 RI/+5V/+12V Power Setting

Note: The suggested setting is RI, with maximum current lower than 1A.

22

IPPCxxA7-RE User Manual

JP4

Setting

Function

Pin 1-2

Short/Closed

Normal

Pin 2-3

Short/Closed

Clear CMOS

JP4: Clear CMOS Contents

2.4 Connectors

Connector Locations on IB806

CN1, CN2: SATA Connector

CN3: Gigabit LAN (RTL8111E-VL)

This RJ45 LAN connector features for EUP LAN wakeup.

23

IBASE Technology Inc.

Signal Name

Pin #

Signal Name

Red

1 2 Green

Blue

3 4 N.C.

GND

5 6 GND

GND

7 8 GND

VCC

9

10

GND

N.C.

11

12

DDCDATA

HSYNC

13

14

VSYNC

DDCCLK

15

Signal Name

Pin #

Signal Name

DCD, Data carrier detect

1 6 DSR, Data set ready

RXD, Receive data

2 7 RTS, Request to send

TXD, Transmit data

3 8 CTS, Clear to send

DTR, Data terminal ready

4 9 RI, Ring indicator

GND, ground

5

10

Not Used

Pin #

Signal Name

RS-232

R2-422

RS-485

1

DCD

RX+

DATA-

2

RX

RX-

DATA+

3

TX

TX+

DATA-

4

DTR

TX-

DATA+

5

Ground

6

DSR

NC

7

RTS

NC

8

CTS

NC

9

RI

NC

10

NC

CN4: DB9+CRT Connector

(COM1) is a DB-9 connector.

COM1 is jumper-less for RS-232, RS-422 and RS-485 and configured with BIOS Selection.

[

24

IPPCxxA7-RE User Manual

Pin #

Signal Name

1

Out2

2

Out3 3 In2

4

In3

5

VCC

6

GND

Signal Name

Pin #

Signal Name

DCD, Data carrier detect

1

2

RXD, Receive data

TXD, Transmit data

3 4 DTR, Data terminal ready

GND, ground

5 6 DSR, Data set ready

RTS, Request to send

7 8 CTS, Clear to send

RI, Ring indicator

9

10

Not Used

Pin #

Signal Name

1

+5V

2

Ground

3

Ground

4

+12V

CN5: Mic Phone-Jack Connector

CN6: Line-out Phone-Jack Connector

CN7: Gigabit LAN (RTL8111E-VL)

This RJ45 LAN connector features for LAN wakeup.

J2: Debug 80 Port Connector (factory use only)

J3: Digital I/O 2in/2out Connector

J4: COM2/RS232 Serial Port

J5: SPI Flash Connector (Factory use only)

J6, J8: SATA HDD Power Connector

25

IBASE Technology Inc.

Pin #

Signal Name

1

Ground

2

Ground

3

+12V

4

+12V

Pin #

Signal Name

1

RST

2

EXTSMI

3

Ground

4

DATA

5

CLK

Pin #

Signal Name

1

Out0

2

Out1

3

In0

4

In1

5

VCC

6

GND

J7: DDR3 SO-DIMM Socket

J9: Mini PCIE Connector

J10, J11: 12V Power Connector

This connector supplies the CPU operating voltage.

J13: Smart Battery Interface Connector

J16, J17, J18, J19: USB2.0 Connectors

J20: Digital I/O 2in/2out Connector

J22: SRAM CPLD Flash Connector (factory use only)

J23: MCU Flash Connector (factory use only)

26

IPPCxxA7-RE User Manual

Signal Name

Pin #

Signal Name

Ground

1 2 PWR_SW

PWR_LED+

3 4 PWR_LED-(GND)

HDD_LED+

5 6 HDD_LED-

Ground

7 8 RESET

JP2: Front Panel Connector

The following table shows the pin outs of the 2x4 pin header

PCIE1: PCIEx8 Goledn Finger

(Includes DVI, USBx2, COMx1, LVDS Single Channel 24bit Signal)

PCIE2: PCIEx16 Goledn Finger

(Includes PCI 32bit master x2, USBx1, COMx1, PCIEx1 Signal)

27

IBASE Technology Inc.

CHAPTER 3 BIOS SETUP

3.1 BIOS Introduction

The BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel processors. The BIOS provides critical low-level support for a standard device such as disk drives, serial ports and parallel ports. It also password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system.

3.2 BIOS Setup

The BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the BIOS is immediately activated. Pressing the <Del> key immediately allows you to enter the Setup utility. If you are a little bit late pressing the <Del> key, POST (Power On Self Test) will continue with its test routines, thus preventing you from invoking the Setup. If you still wish to enter Setup, restart the system by pressing

the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys.

You can also restart by turning the system Off and back On again. The following message will appear on the screen:

Press <DEL> to Enter Setup

In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc> to quit.

When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices.

28

IPPCxxA7-RE User Manual

Warning:

It is strongly recommended that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases.

System Language

Choose the system default language.

System Date

Set the Date. Use Tab to switch between Data elements.

System Time

Set the Time. Use Tab to switch between Data elements.

29

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

Legacy OpROM Support

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Launch PXE OpROM

Disabled

Launch Storage OpROM

Enabled ► PCI Subsystem Settings

► ACPI Settings

► Wake up event setting

► CPU Configuration

► iSmart Configuration

► IDE Configuration

► USB Configuration

► Super IO Configuration

► H/W Monitor

► PPM Configuration

3.3 Advanced Settings

This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

Aptio Setup Utility

Launch PXE OpROM

Enable or Disable Boot Option for Legacy Network Devices.

Launch Storage OpROM

Enable or Disable Boot Option for Legacy Mass Storage Devices with Option ROM.

30

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

PCI Bus Driver Version V 2.05.01

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

PCI ROM Priority

Legacy ROM

PCI Common Settings

PCI Latency Timer

32 PCI Bus Clocks

VGA Palette Snoop

Disabled

PERR# Generation

Disabled

SERR# Generation

Disabled

PCI Subsystem Settings

Aptio Setup Utility

PCI ROM Priority

In case of multiple Option ROMs (Legacy and EFI Compatible), specifies what PCI Option ROM to launch.

PCI Latency Timer

Value to be programmed into PCI Latency Timer Register.

VGA Palette Snoop

Enables or Disables VGA Palette Registers Snooping.

PERR# Generation

Enables or Disables PCI Device to Generate PERR#.

SERR# Generation

Enables or Disables PCI Device to Generate SERR#.

31

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

Enable ACPI Auto Configuration Disabled

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Enable Hibernation

Enabled

ACPI Sleep State

S1 (CPU Stop Clock)

S3 Video Report

Disabled

ACPI Settings

Aptio Setup Utility

Enabled ACPI Auto Configuration

Enables or Disables BIOS ACPI Auto Configuration.

Enable Hibernation

Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS.

ACPI Sleep State

Select the highest ACPI sleep state the system will enter, when the SUSPEND button is pressed.

S3 Video Report

The default setting is Disabled.

32

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Wake on Ring

Disabled

Wake on PCI PME Wake on PCIE PME

Disabled Disabled

Wake up event settings

Aptio Setup Utility

Wake on Ring

The options are Disabled and Enabled.

Wake on PCI PME

The options are Disabled and Enabled.

Wake on PCIE PME

The options are Disabled and Enabled.

33

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

CPU Configuration

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Processor Type

Intel(R) Atom(TM) CPU

EMT64

Not Supported

Processor Speed

2132 MHz

System Bus Speed

533 MHz

Ratio Status

16

Actual Ratio

16

System Bus Speed

533 MHz

Processor Stepping

30661

Microcode Revision

262

L1 Cache RAM

2x56 k

L2 Cache RAM

2x512 k

Processor Core

Dual

Hyper-Threading

Supported

Hyper-Threading

Enabled

Execute Disable Bit

Enabled

Limit CPUID Maximum

Disabled

CPU Configuration

This section shows the CPU configuration parameters.

Aptio Setup Utility

Hyper-threading

Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When Disabled, only one thread per enabled core is enabled.

Execute Disable Bit

XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, Re33dHat Enterprise 3 Update 3.)

Limit CPUID Maximum

Disabled for Windows XP.

34

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

iSmart Controller

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

EuP/ErP standby power Control

Keep standby power

Power-On after Power failure

Disabled

Schedule Slot 1

None

Schedule Slot 2

None

iSmart Controller

Aptio Setup Utility

EuP/ErP standby power Control

Saving the power consumption on power off.

Power-On after Power failure

This field sets the system power status whether on or off when power returns to the system from a power failure situation.

Schedule Slot

None / Power On / Power On/Off – Setup the hour/minute for system power on

35

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

SATA Port0

Not Present

SATA Port1

Not Present

SATA Controller(s)

Enabled

Configure SATA as

IDE

IDE Configuration

Aptio Setup Utility

SATA Controller(s)

Enable / Disable Serial ATA Controller.

Configure SATA as

(1) IDE Mode. (2) AHCI Mode.

36

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

USB Devices:

None

Legacy USB Support

Enabled

EHCI Hand-off

Enabled

USB hardware delays and time-outs:

USB Transfer time-out

20 sec

Device reset tine-out

20 sec

Device power-up delay

AUTO

USB Configuration

Aptio Setup Utility

Legacy USB Support

Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

EHCI Hand-off

Enabled/Disabled. This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver.

USB Transfer time-out

The time-out value for Control, Bulk, and Interrupt transfers.

Device reset tine-out

USB mass Storage device start Unit command time-out.

Device power-up delay

Maximum time the device will take before it properly reports itself to the Host Controller. ‘Auto’ uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor.

37

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

W83627UHG Super IO Configuration

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Super IO Chip

Winbond W83627UHG

► W83627UHG Serial Port 0 Configuration

► W83627UHG Serial Port 1 Configuration

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

System temperature

+33 C

CPU temperature

+57 C

VCORE

+1.192 V

+12V

+11.230 V

+3.3V

+3.312 V

AVCC

+4.832 V

CPU Shutdown Temperature

Disabled

Super IO Configuration

Aptio Setup Utility

Serial Port Configuration

Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device.

H/W Monitor

Aptio Setup Utility

CPU Smart Fan Control

Disabled (default) 70 ℃ / 75 ℃ / 80 ℃ / 85 ℃ / 90 ℃ / 95 ℃

Temperatures/Voltages

These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status.

CPU Shutdown Temperature

The default setting is Disabled.

[

38

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

PPM Configuration

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

EIST

Enabled

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

► Host Bridge

► South Bridge

PPM Configuration

Aptio Setup Utility

3.4 Chipset Settings

This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

Aptio Setup Utility

Host Bridge

This item shows the Host Bridge Parameters.

South Bridge

This item shows the South Bridge Parameters.

39

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen ↑↓ Select Item Enter: Select

+- Change Field F1: General Help F2: Previous Values F3: Optimized Default

F4: Save ESC: Exit

► Memory Frequency and Timing

► Intel IGD Configuration

************Memory Information************

Memory Frequency

1067 MHz(DDR3)

Total Memory

2048 MB

DIMM#1

2048 MB

Main Advanced Chipset Boot Security Save & Exit

Memory Frequency and Timing

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save & Exit ESC: Exit

MRC Fast Boot

Enabled

Host Bridge

This section allows you to configure the Host Bridge Chipset.

Aptio Setup Utility

Memory Frequency and Timing

Aptio Setup Utility

MRC Fast Boot

The options are Disabled and Enabled.

40

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save & Exit ESC: Exit

IGFX-Boot Type

VBIOS Default

LCD Panel Type

1024x768 LVDS

Panel Scaling

Auto

Active LFP

Int-LVDS

Intel IGD Configuration

Aptio Setup Utility

IGFX-Boot Type

Select the video Device which will be activated during POST .

Panel Color Depth

Select the LFP Panel Color Depth: 18 Bit, 24 Bit.

LCD Panel Type

Select LCD panel used by Internal Graphics Device by selecting the appropriate setup item: 640x480 LVDS ~ 2048x1536 LVDS.

Panel Scaling

Select the LCD panel scaling option used by the Internal Graphics Device: Auto, Off, Force Scaling.

Active LFP

Select the Active LFP Configuration. No LVDS: VBIOS does not enable LVDS. Int-LVDS: VBIOS enables LVDS driver by Integrated encoder.

41

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

► TPT Device

► PCI Express Root Port0

► PCI Express Root Port1

► PCI Express Root Port2

► PCI Express Root Port3

DMI Link ASPM Control

Enabled

PCI-Exp. High Priority Port

Disabled

High Precision Event Timer Configuration

High Precision Timer

Enabled

SLP_SP4 Assertion Width

1-2 Seconds

South Bridge

This section allows you to configure the South Bridge Chipset.

Aptio Setup Utility

DMI Clink ASPM Control

The control of Active State Power Management on both NB side and SB side of the DMI Link.

PCI-Exp. High Priority Port

The options are Disabled, Port1, Port2, Port3, and Port4.

High Precision Event Timer Configuration

Enable/or Disable the High Precision Event Timer.

SLP_S4 Assertion Stretch Enable

Select a minimum assertion width of the SLP_S4# signal.

42

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Azalia Controller

HD Audio

UHCI #1 (port 0 and 1)

Enabled

UHCI #2 (port 2 and 3)

Enabled

UHCI #3 (port 4 and 5)

Enabled

UHCI #4 (port 6 and 7)

Enabled

USB 2.0(UHCI) Support

Enabled

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

PCI Express Port 0

Enabled

Port 0 IOxAPIC

Disabled

Automatic ASPM

Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

PCI Express Port 1

Auto

Port 0 IOxAPIC

Disabled

Automatic ASPM

Auto

TPT Device

PCI Express Root Port0

Aptio Setup Utility

PCI Express Root Port1

Aptio Setup Utility

43

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default

PCI Express Port 2

Auto

Port 0 IOxAPIC

Disabled

Automatic ASPM

Auto

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default

F4: Save ESC: Exit

PCI Express Port 3

Enabled

Port 0 IOxAPIC

Disabled

Automatic ASPM

Auto

PCI Express Root Port2

PCI Express Root Port3

Aptio Setup Utility

44

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Setup Prompt Timeout

1

Bootup NumLock State

On

Quiet Boot

Disabled

Fast Boot

Disabled

CSM16 Module Version

07.68

GateA20 Active

Upon Request

Option ROM Messages

Force BIOS

Interrupt 19 Canture

Disabled

CSM Support

Enabled

Boot Option Priorities

Boot Settings

Setup Prompt Timeout

Aptio Setup Utility

Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.

Bootup NumLock State

Select the keyboard NumLock state.

Quiet Boot

Enables/Disables Quiet Boot option.

Fast Boot

Enables/Disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options.

GateA20 Active

UPON REQUEST – GA20 can be disabled using BIOS services. ALWAYS – do not allow disabling GA20.

Option ROM Messages

Set display mode for Option ROM. Options: Force BIOS and Keep Current.

Interrupt 19 Capture

Enable: Allows Option ROMs to trap Int 19.

CSM Support

Enables/Disables/Auto CSM Support.

Boot Option Priorities

Sets the system boot order.

[[

45

IBASE Technology Inc.

Main Advanced Chipset Boot Security Save & Exit

Password Description

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights

Administrator Password

User Password

3.5 Security Settings

This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

Aptio Setup Utility

Administrator Password

Set Setup Administrator Password.

User Password

Set User Password.

46

IPPCxxA7-RE User Manual

Main Advanced Chipset Boot Security Save & Exit

→ ← Select Screen

↑↓ Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit

Discard Changes and Exit

Save Changes and Reset

Discard Changes and Reset

Save Options

Save Changes

Discard Changes

Restore Defaults

Save as User Defaults

Restore User Defaults

Boot Override

3.6 Save & Exit Settings

Aptio Setup Utility

Save Changes and Exit

Exit system setup after saving the changes.

Discard Changes and Exit

Exit system setup without saving any changes.

Save Changes and Reset

Reset the system after saving the changes.

Discard Changes and Reset

Reset system setup without saving any changes.

Save Changes

Save Changes done so far to any of the setup options.

Discard Changes

Discard Changes done so far to any of the setup options.

Restore Defaults

Restore/Load Defaults values for all the setup options.

Save as User Defaults

Save the changes done so far as User Defaults.

Restore User Defaults

Restore the User Defaults to all the setup options.

Boot Override

Pressing ENTER causes the system to enter the OS.

47

IBASE Technology Inc.

CHAPTER 4 DRIVERS INSTALLATION

This section describes the installation procedures for software and drivers. The software and drivers are included with the motherboard.

IMPORTANT NOTE:

After installing your Windows operating system, you must install first the Intel Chipset Software Installation Utility before proceeding with the drivers installation.

4.1 Intel Chipset Software Installation Utility

The Intel Chipset Drivers should be installed first before the software drivers to enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation.

1. Insert the disc that comes with the board. Click Intel and then Intel(R) Cedarview Chipset Drivers.

2. Click Intel(R) Chipset Software Installation Utility.

3. When the Welcome screen to the Intel® Chipset Device Software appears, click Next to continue. Click Yes to accept the software license agreement and proceed with the installation process.

4. On the Readme File Information screen, click Next to continue the installation.

5. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect.

48

IPPCxxA7-RE User Manual

4.2 VGA Drivers Installation

1. Click Intel(R) Cedarview Graphics Driver.

2. When the Welcome screen appears, click Next to continue.

4. Click Yes to to agree with the license agreement and continue the installation.

5. On the Readme File Information screen, click Next to continue the installation of the Intel® Graphics Media Accelerator Driver.

6. On Setup Progress screen, click Next to continue.

7. Setup complete. Click Finish to restart the computer and for changes to take effect.

49

IBASE Technology Inc.

4.3 Realtek HD Audio Driver Installation

1. Click Realtek High Definition Audio Driver.

2. On the Welcome to the InstallShield Wizard screen, click Next to proceed with and complete the installation process.

4. Restart the computer when prompted.

50

IPPCxxA7-RE User Manual

4.4 LAN Drivers Installation

1. Click Realtek LAN Controller Driver.

2. Click Next to proceed with and complete the installation process.

3. The wizard is ready to begin installation. Click Install to begin the installation.

4. When setup is complete, click Finish to restart the computer and for changes to take effect.

51

IBASE Technology Inc.

4.5 ALTERA FPGA Driver Installation

1. Insert the drivers DVD into the DVD drive. Click Intel and then ALTERA FPGA Driver.

2. When the Welcome to Peripheral Controller Driver 2.0 for Windows XP/Vista Setup Wizard screen appears, click Next to continue.

3. When the Ready to Install screen appears, click Install to continue.

4. The Setup process is now complete, Click Finish to restart the computer.

IBASE IPPCXXA7-RE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
