iBall iB-W3GM021N User Manual

21Mbps GSM MiFi Router

Model No.: iB-W3GM021N

User Manual

Ver.: 1.0.0

2

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

 Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that

may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

FCC RF Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This device and its antenna must not be co-located or
operating in conjunction with any other antenna or transmitter.

“To comply with FCC RF exposure compliance requirements, this grant is applicable

to only Mobile Configurations. The antennas used for this transmitter must be installed
to provide a separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter.”

3

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.

Safety Precautions

Read the safety precautions carefully to ensure the correct and safe use of your wireless
device.

Do not switch on your device when the device use is prohibited or when
the device use may cause interference or danger.

Follow the rules or regulations in hospitals and health care facilities.
Switch off your device near medical apparatus.

Switch off your device in an aircraft. The device may cause interference
to control signals of the aircraft.

Switch off your device near high-precision electronic devices. The
device may affect the performance of these devices.

Do not attempt to disassemble your device or its accessories. Only
qualified personnel are allowed to service or repair the device.

Do not place your device or its accessories in containers with strong
electromagnetic field.

Do not place magnetic storage media near your device. Radiation from
the device may erase the information stored on them.

Do not put your device in a high-temperature place or use it in a place
with flammable gas such as a gas station.

Keep your device and its accessories away from children. Do not allow
children to use your device without guidance.

Use approved batteries and chargers only to avoid explosion.

Observe the laws or regulations on device use. Respect others’ privacy

and legal rights when using your device.

4

Contents

Safety Precautions ........................................................................ 3

Package Contents ......................................................................... 5

1.Overview & Benefits: .................................................................. 5

1.1. Product Features………………………………………………….6

1.2. Hardware Overview ................................................................ 7

2. Install the Card .......................................................................... 8

2.1. System requirement ............................................................... 9

3. Power ON/OFF Router .............................................................. 9

4. Turn Router to WiFi mode ......................................................... 9

5. Router Web Management page .............................................. 10

6. Multi Device Access ................................................................ 14

7. Specifications……..………………………………………………..15

8. FAQ………………….………………………………………………16

Contact Information ..................................................................... 16

5

Package Contents:

The following contents should be found in the product packaging:

 21Mbps GSM MiFi Router

 USB Cable

 User Manual

Brief introduction:

iB-W3GM021N is GSM Router to access Internet Anytime & Anywhere through 2G/3G
Internet.

Router as used for a long time in a enclosed space, the temperature of the device will
increase. Then it will turn off automatically. When this phenomenon appears, please put it
in ventilation space to dissipate the heat and when the temperature of the device
decrease, you can use it as normal.

• Please change default (SSID) and change password for wireless security purpose.

Conventions

The Router or iB-WGM021N mentioned in this guide stands for iBall Baton 21Mbps GSM MiFi
Router without any explanation.
