IAI GO-2401M-PGE, GO-2401C-PGE User Manual

Download

User Manual

Thank you for purchasing this product.

Be sure to read this manual before use.

GO-2401M-PGE GO-2401C-PGE

2.35M Digital Progressive Scan

Monochrome and Color Camera

Document V ersion: 1.0

GO-2401-PGE_Ver.1.0_Oct2015

This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation, and store it safely for future use.

Contents

GO-2401M-PGE / GO-2401C-PGE

Notice ............................................................................3

Warranty .......................................................................3

Certifications .................................................................3

Warning ........................................................................3

Usage Precautions .......................................................6

Features ........................................................................7

Parts Identification ........................................................8

Preparation...........................................................12

Preparation Process ...................................................12

Step 1: Installing the Software (first time only) ............12

Step 2: Connecting Devices ........................................13

Step 3: Verifying the Camera’s Network Connection

Status ..........................................................................15

Step 4: Configuring Initial Settings for the Camera .....15

Connecting to the Camera to Control Tool .............15

Configuring the Output Format ...............................16

Configuring Exposure and External Trigger

Settings ...................................................................17

Control via External Triggers .......................................18

When Controlling the Exposure Time Using

Specified Exposure Times ......................................18

When Controlling the Exposure Time using

the Pulse Width of the Trigger Input Signal ............19

Control Without External Triggers ...............................20

When Controlling the Exposure Time Using

Specified Exposure Times ......................................20

When not Controlling the Exposure Time ...............20

Step 5: Adjusting the Image Quality............................20

Adjusting the Gain ..................................................21

Manual adjustment .............................................21

Adjusting the White Balance

(GO-2401C-PGE only) ............................................21

Manual white balance adjustment ......................21

Automatic white balance adjustment .................21

Adjusting the Black Level .......................................22

Step 6: Configuring Various Other Settings ................22

Step 7: Saving the Settings .........................................22

To save user settings ..........................................23

To load user settings ...........................................23

Basic Function Matrix .................................................24

Main Functions ....................................................25

GPIO (Digital Input/Output Settings) ...........................25

Valid Input/Output Combinations ............................25

Acquisition Control (Image Acquisition Controls) ........26

Changing the Frame Rate ......................................26

Maximum Frame Rate .............................................26

Maximum frame rate period formula ..................27

Exposure Mode ...........................................................27

Trigger Control ............................................................28

Shortest Repetition Period for Triggers ...................28

When [Exposure Mode] is [Timed] .....................28

When [Exposure Mode] is [Trigger Width] .........29

During normal continuous operation (both

[Exposure Mode] and [Trigger Mode]

disabled) ........................................................29

Event Control ..............................................................30

Event message occurrence diagram .................30

Internal camera blocks .......................................30

To use the event control function ........................31

Gain Control ................................................................31

LUT (Lookup Tab le) ....................................................32

To use the LUT function ......................................32

LUT values ..........................................................32

Gamma Function ........................................................33

To use the gamma function ................................33

Line Status ..................................................................34

Shading Correction .....................................................34

Flat Shading ........................................................34

Color Shading (GO-2401C-PGE only) ................35

To use the shading correction function ..............35

Binning Function .........................................................35

ROI (Regional Scanning Function) .............................36

ROI Settings ............................................................36

Video Send Mode .......................................................37

Video Send Mode ...................................................37

To switch the video send mode ..........................37

Multi ROI Mode ...................................................37

Sequence Trigger function .................................38

Delayed Readout [Acquisition Transfer Start] ........40

ALC (Automatic Level Control) Function .....................41

To use the ALC function ......................................41

Automatic gain level control ...............................41

Detailed Settings for Gain Auto

(Automatic Gain Level Control) ..............................42

Counter and Timer Control Function

(counter support only) .................................................43

Counter occurrence diagram .............................43

Internal camera blocks .......................................43

To use the counter function ................................44

Video Process Bypass Mode ......................................44

Differences in camera operation ........................44

To enable video process bypass mode..............44

Settings List .........................................................45

Feature Properties ......................................................45

Settings .......................................................................53

Miscellaneous ......................................................55

Updates ......................................................................55

Troubleshooting ..........................................................55

Specifications ..............................................................56

Frame Rate Reference ...............................................58

Spectral Response .....................................................58

Dimensions .................................................................59

User’s Record .............................................................60

Index .....................................................................61

— 2 —

GO-2401M-PGE / GO-2401C-PGE

Notice

The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein. JAI Ltd., Japan reserves the right to make changes without notice.

Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners.

Warranty

For information about the warranty, please contact your factory representative.

Certifications

CE compliance

As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC (Electromagnetic compatibility), JAI Ltd., Japan declares that GO-2401M-PGE and GO-2401C-PGE comply with the following provisions applying to its standards. EN 61000-6-3 (Generic emission standard part 1) EN 61000-6-2 (Generic immunity standard part 1)

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Warning

Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could void the user



s authority to operate the equipment.

— 3 —

GO-5000M-PGE

GO-2401M-PGE / GO-2401C-PGE

Supplement

The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。

方忖仝15々葎豚㍉15定。

— 4 —

GO-5000C-PGE

GO-2401M-PGE / GO-2401C-PGE

Supplement

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

方忖仝15々葎豚㍉15定。

— 5 —

Notes on cable configurations

The presence of lighting equipment and television receivers nearby may result in video and audio noise. In such cases, change the cable configurations or placement.

Notes on LAN cable connection

Secure the locking screws on the connector manually, and do not use a driver. Do not secure the screws too tightly. Doing so may wear down the screw threads on the camera. (Tightening torque: 0.147 Nm or less)

Notes on attaching the lens

Avoiding dust particles

When attaching the lens to the camera, stray dust and other particles may adhere to the sensor surface and rear surface of the lens. Be careful of the following when attaching the lens.

•Work in a clean environment.

•Do not remove the caps from the camera and lens until immediately before you attach the lens.

•To prevent dust from adhering to surfaces, point the camera and lens downward and do not allow the

lens surface to come into contact with your hands or other objects.

•Always use a blower brush to remove any dust that adheres. Never use your hands or cloth, blow with your mouth, or use other methods to remove dust.

GO-2401M-PGE / GO-2401C-PGE

Usage Precautions

Secure manually. Do not secure too tightly.

Phenomena specific to CMOS image sensors

The following phenomena are known to occur on cameras equipped with CMOS image sensors. These do not indicate malfunctions.

•

Aliasing

When shooting straight lines, stripes, and similar patterns, vertical aliasing (zigzag distortion) may appear on the monitor.

•

Blooming

When strong light enters, more than the allowable amount of charge of the sensor element in the CMOS image sensor (pixel) and the charge is overflowing, enters into the surrounding pixels, and blooming may occur. However, this does not affect actual operation.

•

Fixed pattern noise

When shooting dark objects in high-temperature conditions, fixed pattern noise may occur throughout the entire video monitor screen.

•

Defective pixels

Defective pixels (white and black pixels) of the CMOS image sensor are minimized at the factory according to shipping standards. However, as this phenomenon can be affected by the ambient temperature, camera settings (e.g., high sensitivity and long exposure), and other factors, be sure to operate within the camera’s specified operating environment.

Notes on exportation

When exporting this product, please follow the export regulations of your country or region.

— 6 —

GO-2401M-PGE / GO-2401C-PGE

Features

The GO-2401M-PGE/GO-2401C-PGE is an industrial progressive scan camera equipped with a 1/1.2-inch global shutter CMOS image sensor with 2.35 effective megapixels (1936 × 1216). The unit is compact and lightweight in design and is equipped with GigE Vision Ver. 1.1 interface.

 The GO-2401M-PGE produces monochrome output while the GO-2401C-PGE produces Bayer output.

Compact and lightweight

The unit’s compact (approx. 29 × 29 × 41.5 mm, excluding lens mount) and lightweight (approx. 46 g) design allows for easy assembly and installation.

Gigabit Ethernet interface supporting GigE Vision Ver. 1.1

•High-speed transfer at up to 1 Gbps of uncompressed data, the ideal format for image processing.

•Connection of multiple cameras and computers supported through use of a switching hub, etc.

•Maximum cable length of 100 m.

•Support for IEEE802.af-compliant PoE (Power over Ethernet) allowing you to supply power to the

camera via the LAN cable.

Note

Interface card or switching hub must support PoE. Alternatively, power can be supplied via the 6-pin connector using an optional +12 to +24V DC power supply.

Output formats

You can choose from 8-bit, 10-bit, and 12-bit* output for both monochrome and Bayer.

* As the color camera cannot perform white balance when using 12-bit output, perform white balance on the

application.

High frame rate

The GO-2401M-PGE and GO-2401C-PGE are both capable of frame rates of up to 32.8 fps (8-bit format) for full 2.35-megapixel output.

ALC (automatic level control) function

Combine the automatic gain control and automatic exposure control functions to allow handling of changes in various brightnesses.

Variety of pre-process functions

•LUT (lookup table)

For programmable control over gamma and contrast.

•Gamma correction

Gamma can be set to 0.45, 0.60, or 1.0 (off).

•Shading correction (flat field and color shading)

Non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment can be corrected.

•Bayer white balance (GO-2401C-PGE only)

White balance can be automatically adjusted continuously. It can also be adjusted manually using R, and B gain.

— 7 —

Connection example:

Camera

Parts Identification

GO-2401M-PGE / GO-2401C-PGE

PoE-compatible switching hub

AC adapter

External trigger

Computer

⑤ ④

①

⑦

Lens mount (C-mount)

Mount a C-mount lens, microscope adapter, etc. here.

 Before mounting a lens, be sure to refer to “Step 2: Connecting Devices” (page 13) and confirm the

precautions for attaching a lens and the supported lens types.

②

③

⑥

— 8 —

GO-2401M-PGE / GO-2401C-PGE

RJ-45 connector

Connect a Gigabit Ethernet compatible LAN cable (Category 5e or higher, Category 6 recommended) here.

123

45678

Pin No.

1 In/Out MX1+ (DA+) 2 In/Out MX1– (DA–) 3 In/Out MX2+ (DB+) 4 In/Out MX3+ (DC+) 5 In/Out MX3– (DC–) 6 In/Out MX2– (DB–) 7 In/Out MX4+ (DD+) 8 In/Out MX4– (DD–)

Power/trigger LED

Input/

output

Description

Indicates the power and trigger input status.

ACT LED

Indicates the GigE network status.

LINK LED

Indicates whether the GigE network connection is 1000BASE-T or 100BASE-TX.

 The specifications described in this manual, such as those for frame rate and trigger frequency, cannot be

met when using a 100BASE-TX connection.

LED status and camera status

LED Light Status

Power / trigger LED Lit amber Camera initializing.

Lit green Camera in operation. Blinking green During operation in trigger mode, trigger signals are being

input.

 The blinking interval is not related to the actual input interval

of the external trigger.

ACT LED Lit amber GigE network communication not established.

Blinking amber GigE network communication in progress.

LINK LED Lit green 1000BASE-T connection established.

Blinking green 100BASE-TX connection established.

— 9 —

DC IN / trigger IN connector (6-pin round)

Connect the cable for a power supply (optional) or for DC IN / trigger IN here.

HR-10A-7R-6PB (73) (Hirose Electric or equivalent)

Pin No.

1 DC IN +12 to +24 V 2 In Opto IN 1 GPIO 5 3 Out Opto OUT 1 GPIO 1 4 Out Opto OUT 2 GPIO 2 5 Opto Common 6 GND

Input/

output

Signal Description

GO-2401M-PGE / GO-2401C-PGE

Recommended external input circuit diagram (reference example)

JAI camera

USER POWER1

+3.3V to +24V

User side

JAI GO Series CAMERA side

HIROSE_6Pin_No.2

HIROSE_6Pin_No.5

BF545C

180CS

TLP2366

1SS400

+3.3V 6 5 4

— 10 —

Recommended external output circuit diagram (reference example)

Standard circuit diagram example

GO-2401M-PGE / GO-2401C-PGE

User side

Userload (resistor/lamp/relay/etc)

330~

OUT

2SC6033

USER POWER2 +5V to +24V

330

4k7

HIROSE_6Pin_No.5

R1, R4 = 330 Ω PULL_UP

User side

HIROSE_6Pin_NO.3 or 4

GO Series CAMERA side

1SS400

2SC6033

3.3 V 5.0 V 12 V 24 V

JAI

220BS

User power (Vcc)

JAI camera

TLP109(TPR,E)

6 5

180BS

100KBS

Time Delay Rise TDR (µs) 0.78 0.82 1.8 2.65 Rise Time RT (µs) 4.1 4.7 6.1 9.1 Time Delay Fall TDF (µs) 0.26 0.48 0.56 0.78 Fall Time FT (µs) 1.3 1.6 3.1 4.8

OUT from camera

Characteristics of the recommended circuits for Opto OUT

OUTPUT LINE RESPONSE TIME

Camera Output Signal

Output Line Voltage

TDR

Camera locking screw holes (M3, 3 mm depth)

TDF

90%

Output LEVEL = User Vcc- (0.8 to 1.1)

10%

Use these holes when attaching an MP-43 tripod adapter plate (optional) or mounting the camera directly to a wall or other structural system.

 The smaller holes (×4) are M2 with a depth of 3 mm.

— 11 —

Preparation

Preparation Process

Step 1 Installing the Software (first time only)

Install the software for configuring and controlling the camera (JAI SDK) on the computer.

Step 2 Connecting Devices

Connect the lens, LAN cable, AC adapter, computer, and other devices.

Step 3 Verifying the Camera’s Network Connection Status

Verify whether the camera is ready for use via the LEDs at the rear of the camera.

Step 4 Configuring Initial Settings for the Camera

• Configure the output format.

• Configure settings related to the exposure and external trigger.

Step 5 Adjusting the Image Quality

• Adjust the gain and white balance.

• Adjust the exposure (shutter).

Step 6 Configuring Various Other Settings

Configure various other settings as necessary.

Step 7 Saving the Settings

Save the current setting configurations in user memory.

GO-2401M-PGE / GO-2401C-PGE



Step 1: Installing the Software (first time only)

When using the camera for the first time, install the software for configuring and controlling the camera (JAI SDK) on the computer.

 When you install JAI SDK, JAI Camera Control Tool will also be installed.

Download the “JAI - Getting Started Guide” and JAI SDK from the JAI website.

URL: http://www.jai.com/en/support/download-jai-software

Refer to the “JAI - Getting Started Guide,” and install JAI SDK on the computer.

The computer will restart when installation is complete.

Note

When the JAI SDK is installed, a camera driver for the GigE interface is also part of the default installation. This GigE Vision Filter Driver is added to every NIC/port on the host computer. As the driver is also added to the NIC/ port for Internet connection, it may, on some systems, affect Internet access speed. If you think your Internet speed is affected, configure the following settings to disable the filter driver on that port.

Open [Control Panel]  [Network and Internet]  [Connect to a network], and right-click the port

used for Internet connection to open the properties dialog box.

— 12 —

Clear the [JAI GigE Vision Filter Driver] checkbox, and save.

Step 2: Connecting Devices

GO-2401M-PGE / GO-2401C-PGE

Connect the lens, LAN cable, AC adapter, and other devices. Attach the lens in a clean environment to prevent dust from adhering to the unit.

(or direct connection)

Lens

Camera body

Direct connection

(or MP-43 tripod adapter plate)

DC IN / trigger IN

connection cable

LAN cable

AC adapter (not supplied)

(power supply)

Network card

Computer

Switching hub

to external trigger

Lens

•C-mount lenses with lens mount protrusions of 9 mm or less can be attached.

9 mm or less

Lens

Lens mount protrusion

•The diagonal of the camera’s CMOS image sensor is 13.4 mm, which is larger than the 11 mm size of standard 2/3-inch lenses. To prevent vignetting and to obtain the optimal resolution, use a lens that will cover the 13.4 mm diagonal. Some lens manufacturers offer lenses with a 13.4 mm format. If not, a 1-inch lens is recommended.

— 13 —

GO-2401M-PGE / GO-2401C-PGE

Caution

• The maximum performance of the camera may not be realized depending on the lens.

• Attaching a lens with a mount protrusion of 9.1 mm or longer may damage the lens or camera.

Note

The following formula can be used to estimate the focal length. focal length = WD / (1 + W/w) WD: Working distance (distance between lens and object) W: Width of object w: Width of sensor (11.3 mm on this camera)

Direct connection (or MP-43 tripod adapter plate)

When mounting the camera directly to a wall or other device, use screws that match the camera locking screw holes on the camera. (Large: M3, small: M2, depth: 3 mm) Use the supplied screws to attach the tripod adapter plate.

Caution

For heavy lenses, be sure to support the lens itself. Do not use configurations in which its weight is supported by the camera.

LAN cable

Connect a LAN cable to the RJ-45 connector.

•Use a LAN cable that is Category 5e or higher (Category 6 recommended).

•When supplying power via PoE, connect to a PoE-compatible switching hub or a PoE-compatible

network card.

•Refer to the specifications of the cable for details on its bend radius.

Caution

Secure manually. Do not secure too tightly.

Network card

Install this in the computer that will be used to configure and operate the camera. As the GO-2401-PGE supports PoE, you can also use PoE-compatible network cards. Refer to the instruction manual of the network card, and configure settings on the computer as necessary.

Computer

Use a computer that meets the following requirements.

Operating system (OS):

Microsoft Windows 7/8 32-bit/64-bit edition

CPU: Intel Core i3 or higher Memory:

Windows 7/8 32-bit edition: DDR3, 4 GB or higher Windows 7/8 64-bit edition: DDR3, 8 GB or higher

Graphics card: PCI-Express 3.0 or higher Network card: We recommend using a network card that uses an Intel chip.

DC IN / trigger IN connection cable

AC adapter (power supply) (if necessary)

Connect the AC adapter and the round connector of the connection cable to the DC IN / trigger IN connector on the camera.

 The AC adapter is not required when using PoE.

— 14 —

GO-2401M-PGE / GO-2401C-PGE

Step 3: Verifying the Camera’s Network Connection Status

When power is supplied to the camera while the necessary equipment is connected, the power / trigger LED and ACT LED at the rear of the camera light amber, and initialization of the camera starts. When initialization is complete, the power / trigger LED lights green. The ACT LED and LINK LED will light or blink according to the network status.

Verify whether power is being supplied to the camera and whether the camera is connected to the network by checking the rear LEDs.

During normal status

Lights or blinks according to the network status

 For details on how to read the LEDs, see “LED status and camera status” (page 9) in the “Parts

Identification” section.

Lit green

Note

Initialization of the camera will not complete unless it is connected to the network. If the power / trigger LED does not switch to green within minutes of supplying power, check the LAN cable and other connections. After initialization is completed once, the power / trigger LED will remain green, even if the network is disconnected.

Step 4: Configuring Initial Settings for the Camera

Start Control Tool, connect the camera to the network, and configure initial settings for the output format, exposure, external trigger, etc.

Connecting to the Camera to Control Tool

Start JAI Control Tool.

Cameras connected to the network are detected and displayed in a window. If they do not appear, right-click inside the window and select [Search for Cameras].

Select the camera you want to configure.

Check that the settings of the selected camera are displayed.

— 15 —

Configuring the Output Format

Configure the size, position, and pixel format of the images to be acquired. The factory settings are as follows. Change the settings as necessary.

Factory default values

Image Format Control Width 1936 (pixels)

Height 1216 (pixels) Offset X (horizontal position) 0 (pixels) Offset Y (vertical position) 0 (pixels) Pixel Format GO-2401M-PGE: 8 Bit Monochrome

 You can specify the image acquisition area. For details, see “ROI (Regional Scanning Function)” (page 36).

Select the [Feature Properties] tab, and select the item you want to configure under [Image

Format Control].

when a configurable item is selected.

GO-2401M-PGE / GO-2401C-PGE

Item Default value

GO-2401C-PGE: 8 Bit Bayer RG

Note

Settings can only be changed when image acquisition on the camera is stopped. If an item is grayed out and

does not appear even when you select it, click (Stop Acquisition) to stop image acquisition.

Click and change the setting value.

Example: When changing [Width]

— 16 —

Example: When changing [Pixel Format]

Note

Direct entry of numerical and text values is possible for some setting items.

Configuring Exposure and External T rigger Settings

Configure settings related to exposure control methods and trigger control. The factory settings are as follows. Change settings as necessary, according to the intended purpose or application.

Factory default values

Item Default value

Trigger Selector (trigger operation) Frame Start

Trigger Mode Off Trigger Source (trigger signal source) Line 5 - Optical In 1

Trigger Activation (trigger polarity) Rising Edge (rising edge of input signal) Exposure Mode Timed (control via exposure time) Exposure Time 30172 (µs) Exposure Auto* Off

GO-2401M-PGE / GO-2401C-PGE

* This item is only enabled when [Exposure Mode] is set to [Timed].

Caution

When [Exposure Mode] is set to [Off], [Trigger Mode] cannot be set to [On]. Other settings may also be restricted depending on the exposure mode, so be sure to set the exposure mode before configuring the trigger settings.

Adjusting Packet Size: With [Trigger Mode] set to [Off] and [Exposure Mode] set to [Continuous], clicking the (Start Acquisition) button should produce a live image. If, however, you can only see a black screen, it may be the result of the packet size setting in the camera being larger than the packet size setting in the GigE NIC or switch. To correct the problem, you can either reduce the [Packet Size] setting to a value less than 1500 in the JAI Control Tool (under [Transport Layer Control] / [Stream Channel Selector], or set your NIC or switch to support “Jumbo Frames.” This setting is typically found in the Advanced Adapter Settings for the NIC or switch which can be accessed through the Device Manager on your PC.

— 17 —

GO-2401M-PGE / GO-2401C-PGE

Configure the settings by expanding [Acquisition Control] and configuring the following items.

Caution

Settings can only be configured when image acquisition on the camera is stopped. If an item is grayed out and the setting cannot be changed, stop image acquisition beforehand.

Control via External Triggers

When Controlling the Exposure Time Using Specified Exposure Times

Configure the settings as follows.

Item Setting value / selectable range

Trigger Selector (trigger operation) Frame Start

Trigger Mode On

Trigger Source (trigger signal source) Any

Trigger Activation (trigger polarity) Rising Edge (rising edge of input signal), Falling Edge (falling

edge of input signal) Exposure Mode Timed (control via exposure time) Exposure Time 73 to 7999685 (µs) (1 µs/step)* Exposure Auto Off, Continuous

* 1 The maximum value for [Exposure Time] varies depending on the value configured for the [Acquisition Frame

Rate Raw] setting. Max. value for [Exposure Time] = [Acquisition Frame Rate Raw] value - 315 µs The minimum value will differ depending on the [Pixel Format] setting value.

Set [Exposure Mode] to [Timed].

([Timed] is the default setting.)

Specify the exposure time in [Exposure Time].

The setting value for the exposure time can only be changed when [Exposure Auto] is set to [Off]. If [Exposure Auto] is set to [Continuous], temporarily set it to [Off] before changing the exposure time.

Set [Trigger Selector] to [Frame Start].

([Frame Start] is the default setting.)

— 18 —

GO-2401M-PGE / GO-2401C-PGE

Set [Trigger Mode] to [On].

If necessary, change the [Trigger Source], [Trigger Activation], and [Exposure Auto]

settings.

When Controlling the Exposure Time using the Pulse Width of the Trigger Input Signal

Configure the settings as follows.

Item Setting value / selectable range

Trigger Selector (trigger operation) Frame Start

Trigger Mode On Trigger Source (trigger signal source) Any Trigger Activation (trigger polarity) Level High (high-level duration), Level Low (low-level

duration) Exposure Mode Trigger Width (control via trigger width)

Set [Exposure Mode] to [Trigger Width] .

When you select [Trigger Width], [Trigger Mode] will automatically be set to [On].

Set [Trigger Selector] to [Frame Start].

([Frame Start] is the default setting.)

If necessary, change the [Trigger Source] and [Trigger Activation] settings.

Other controls

In addition to exposure time, the following can also be controlled by external triggers. Select these control operations in [Trigger Selector].

Acquisition Start Start image acquisition. Acquisition End Stop image acquisition. Acquisition Transfer Start Output acquired images at a specified timing. (Up to 7

[Trigger Selector] setting Description

frames for 8-bit, and up to 3 frames for 10-/12-bit.)

— 19 —

GO-2401M-PGE / GO-2401C-PGE

Control Without External Triggers

When Controlling the Exposure Time Using Specified Exposure Times

Configure the settings as follows.

Item Setting value / selectable range

Trigger Selector (trigger operation) Frame Start

Trigger Mode Off Exposure Mode Timed (control via exposure time) Exposure Time 73 to 7999685 (µs) (1 µs/step)* Exposure Auto Off, Continuous

*1 The maximum value for [Exposure Time] varies depending on the value configured for the [Acquisition Frame

Rate Raw] setting. Max. value for [Exposure Time] = [Acquisition Frame Rate Raw] value - 315 µs The minimum value will differ depending on the [Pixel Format] setting value.

Set [Exposure Mode] to [Timed].

([Timed] is the default setting.)

Specify the exposure time in [Exposure Time].

Set [Trigger Mode] to [On].

If necessary, change the [Exposure Auto] setting.

When not Controlling the Exposure Time

Configure the settings as follows.

Item Setting value / selectable range

Exposure Mode Off

The exposure will be performed with an exposure time equal to 1 / frame rate.

Step 5: Adjusting the Image Quality

Adjust the image quality using the gain and white balance (GO-2401C-PGE only) functions.

To adjust the image quality

The display level must be changed from [Beginner] to [Guru].

— 20 —

Adjusting the Gain

Adjust the sensitivity via the analog gain (i.e., master gain).

 For details on gain control, see “Gain Control” (page 31) in the “Main Functions” section.

■ Manual adjustment

Expand [Analog Control], and set [Gain Auto] to [Off].

([Off] is the default setting.)

Configure the gain.

Expand [Analog Control], and select the gain you want to configure in [Gain Selector].

•For the GO-2401M-PGE, only [Analog All] (master gain) can be configured.

•For the GO-2401C-PGE, [Analog All] (master gain), [Digital Red] (digital R gain), and [Digital

Blue] (digital B gain) can be configured individually.

Configure the gain value in [Gain].

•[Analog All] (master gain) can be set to a value from x1 to x16 (0 dB to +24 dB). The resolution is set in x0.01 steps (0.05 dB to 0.08 dB depending on the setting value). Values are configured by multipliers. For example, the values set for x1 and x16 are 100 and 1600 respectively.

GO-2401M-PGE / GO-2401C-PGE

•For the GO-2401C-PGE, the [Digital Red] (digital R gain) and [Digital Blue] (digital B gain) can be set to a value from x0.45 to x5.62 (–7 dB to +15 dB) the [Analog All] (master gain) value. The resolution is set in 0.1 dB steps. Specify 0 for 0 dB, negative values for settings below 0, and positive values for settings above 0.

Adjusting the White Balance (GO-2401C-PGE only)

Adjust the white balance using R and B gain. The white balance can also be adjusted automatically.

■ Manual white balance adjustment

Expand [Analog Control], and set [Balance White Auto] to [Off].

([Off] is the default setting.)

Select the gain to configure in [Gain Selector], and set the gain value in [Gain].

■ Automatic white balance adjustment

Place a white sheet of paper or similar object under the same lighting conditions as the

intended subject, and zoom in to capture the white.

White objects near the subject, such as a white cloth or wall, can also be used.

Be sure to prevent the high-intensity spot lights from entering the screen.

Select the [Balance White Auto] tab, and click [Continuous] or [Once] depending on your

intended application.

The white balance is automatically adjusted.

— 21 —

Adjusting the Black Level

Expand [Analog Control], and select the black level you want to configure in [Black Level

Selector].

For the GO-2401M-PGE, only [Digital All] (master black) can be configured.

For the GO-2401C-PGE, [Digital All] (master black), [Digital Red] (digital R), and [Digital Blue] (digital B) can be configured individually.

Specify the adjustment value in [Black Level].

Step 6: Configuring Various Other Settings

See “Settings List” (page 45) and configure settings as necessary.

Step 7: Saving the Settings

GO-2401M-PGE / GO-2401C-PGE

The setting values configured in Control Tool will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary. You can save up to three sets of user settings (User Set1 to 3) in the camera.

User memory Temporary memory

User Set1

User Set2

User Set3

Note

Changes to settings are not saved to the computer (Control Tool).

Save

Current

setting values

Control Tool

— 22 —

■ To save user settings

Stop image acquisition.

Expand [User Set Control], and select the save destination ([User Set1] to [User Set3]) in

[User Set Selector].

Note

The factory default setting values are stored in [Default] and cannot be overwritten.

GO-2401M-PGE / GO-2401C-PGE

Caution

Settings can only be saved when image acquisition on the camera is stopped.

Select [User Set Save], and click [Execute ‘User Set Save’ Command].

The current setting values are saved as user settings.

■ To load user settings

Stop image acquisition.

User settings can only be loaded when image capture on the camera is stopped.

Select the settings to load (User Set1 to User Set3) in [User Set Selector].

Select [User Set Load], and click [Execute ‘User Set Load’ Command].

The selected user settings are loaded.

— 23 —

GO-2401M-PGE / GO-2401C-PGE

Basic Function Matrix

The combinations of settings for the basic functions that can be used together are as follows.

Exposure Mode

Frame Start Trigger

Binning Vertical*

Binning Horizontal*

Exposure Time

ROI

Balance White

Auto*

Gain Auto

Exposure Auto

Video Send Mode

Sequence Mode

Multi ROI

Trigger

Sequence Mode

Command

Off Off 1 × 1 (Off) ×

1 × 2 ×

2 × 1 ×

2 × 2 ×

Timed Off 1 × 1 (Off)

1 × 2

2 × 1

2 × 2

Timed (EPS) On 1 × 1 (Off)

1 × 2

2 × 1

2 × 2

Trigger Width On 1 × 1 (Off) ×

1 × 2 ×

2 × 1 ×

2 × 2 ×

*1 Operates only on the GO-2401M-PGE *2 Operates only on the GO-2401C-PGE

  

     

   

    



  

× ×



— 24 —

Main Functions

GPIO (Digital Input/Output Settings)

The camera is equipped with GPIO (general-purpose input/output) functions for generating and using combinations of triggers and other necessary signals within the camera and of signals output from the camera to the system such as those used for lighting equipment control.

Valid Input/Output Combinations

The following signals can be used as sources for each output destination (Trigger Selector, Line Selector, Pulse Generator Selector). You can also connect two different sources to NAND paths in the GPIO and reuse the signal generated there as a source for a different selector.

The combinations of source signals and output destinations are indicated in the following.

Selector

(Cross point

switch output)

Trigger Selector Line Selector

Acquisition Start

Acquisition Stop

Transfer Start

Frame Start

(GPIO 1)

Output destination

Line2 OPT Out 1

Time Stamp Reset

Line3 OPT Out 2

(GPIO 2)

NAND 0 In 1

NAND 0 In 2

GO-2401M-PGE / GO-2401C-PGE

Pulse

Generator

Selector

NAND 1 In 1

NAND 1 In 2

Pulse Generator 0

Source signal (Cross point switch input)

LOW

HIGH

Line5 OPT 1 In

NAND 0 Out

NAND 1 Out

Signals to use as output

Pulse Generator 0

User Output 0

User Output 1

Software Trigger

Action 1

Action 2

FVAL

LVAL

Exposure Active

Frame Trigger Wait

Frame Active

Acquisition Trigger Wait

           

      

        

          

           

   

× × × ×

× × × × × ×

× × × ×

Trigger Source Line Source

× ×

× × × × × × ×

       

× ×



× × × × ×



× × × ×

Use

  

× ×

Pulse

Generator

Clear Source



: Indicates default values for each selector. “Factory default values” (page 17) shows the

default values for [Frame Start].

— 25 —

Acquisition Control (Image Acquisition Controls)

Perform operations and configure settings related to image acquisition in [Acquisition Control].

The following acquisition modes are available on the camera.

Acquisition Mode Description

Single Frame Acquire a single frame when the [Acquisition Start] command is executed. Multi Frame Acquire the number of frames specified in [Acquisition Frame Count] when the

[Acquisition Start] command is executed.

Continuous Acquire images continuously until the [Acquisition Stop] command is executed.

Changing the Frame Rate

When [Trigger Mode] is disabled, you can change the frame rate in [Acquisition Frame Rate].

Note

• The shortest frame period varies depending on the ROI, pixel format, and binning mode selected. The longest frame period is 0.125 Hz (8 sec.).

• When [Trigger Mode] is enabled, the [Acquisition Frame Rate] setting is disabled.

GO-2401M-PGE / GO-2401C-PGE

Maximum Frame Rate

The maximum frame rate is as follows depending on the sensor’s scanning range and the GigE bandwidth.

Maximum frame rate (A)

(Value derived from sensor

scanning range)

Maximum frame rate (B)

Compared

(A) < (B) (A) > (B)

Maximum frame rate (A) Maximum frame rate (B)

(Value derived from GigE

bandwidth)

— 26 —

GO-2401M-PGE / GO-2401C-PGE

■ Maximum frame rate period formula

•<sensor output max. frame rate>

During [Continuous] mode: 1 / ((Height_s + 40) ×Hperiod) During [Trigger Mode]: 1 / (Exposure Time[sec] + (Height_s + 40) × Hperiod)

•<GigE output bandwidth max. frame rate> = 920 × 1000000 / (Height_g × Width_g × Pack value)

max. frame rate (unit: fps) = Min*3 (<sensor output max. frame rate>, <GigE output bandwidth max. frame rate>)

Pixel

Format

8-bit

10-/12-bit

10-/12-bit packed

Binning User settings

Height Width

B.V&B.H 1

(Off) B.V 2 (On) B.H 2 (On)

B.V & B.H 2

(On)

B.V & B.H 1

(Off) B.V 2 (On) B.H 2 (On)

B.V & B.H 2

(On)

B.V & B.H 1

(Off) B.V 2 (On) B.H 2 (On)

B.V & B.H 2

(On)

1216 1936 1216 1216 1936 24.2425 × 10

608 968 1216 608 1936 32.8

1216 1936 1216 1216 968 32.8

608 968 1216 608 968 32.8

1216 1936 1216 1216 1936 24.2425 × 10-616 24.4

608 968 1216 608 1936 32.8

1216 1936 1216 1216 968 32.8

608 968 1216 608 968 32.8

1216 1936 1216 1216 1936 24.2425 × 10-612 32.6

608 968 1216 608 1936 32.8

1216 1936 1216 1216 968 32.8

608 968 1216 608 968 32.8

Height_s*1Height_g*2Width_g*

H period Pack

value

-6

Maximum frame rate

(fps)

8 32.8

* The values during [Continuous] *1 Height_s: Line scanned by the sensor. *2 Height_g, Width_g: Height and width of output streams. *3 Minimum value (the smaller value is enabled).

Caution

Although the maximum frame rate value is determined by the GigE bandwidth range, when ROI is configured, the frame rate cannot exceed the sensor output's allowable frame rate value.

Exposure Mode

The following exposure modes are available on the camera.

Exposure Mode Description

Off Exposure control is not performed (free-running operation). Timed Mode in which control is performed using exposure time. Acquire images using an

exposure time configured beforehand for or free-running an external trigger.

Trigger Width Mode in which control of the exposure time is performed using the pulse width of the

trigger input signal. The exposure time will be the same as the pulse width of the trigger input signal. This allows long exposure.

 The settings for exposure control and triggers are related to each other. Be sure to configure the settings

described in “Configuring Exposure and External Trigger Settings” (page 17).

— 27 —

Trigger Control

The camera allows the following controls to be performed via external trigger signals.

Trigger Selector Description

Frame Start Start exposure in response to the external trigger signal input. Select this to perform

exposure control using external triggers. Acquisition Start Start image acquisition in response to the external trigger signal input. Acquisition End Stop image acquisition in response to the external trigger signal input. Acquisition Transfer Start Output acquired images at a specified timing in response to an external trigger

signal input. (Up to 7 frames for 8-bit, and up to 3 frames for 10-/12-bit.)

 The settings for exposure control and triggers are related to each other. Be sure to configure the settings

described in “Configuring Exposure and External Trigger Settings” (page 17).

Shortest Repetition Period for Triggers

The reciprocal of the maximum frame rate is the time required to output one frame. The shortest repetition periods for triggers cannot be lower than that value.

■ When [Exposure Mode] is [Timed]

GO-2401M-PGE / GO-2401C-PGE

Example: When [Trigger Source] is set to [Line 5 - Optical In 1] and [OptIn Filter Selector] is set to [10 µs]

Scanning range

Full 30.782 ms ROI 2/3 (Height = 810) 30.782 ms ROI 1/2 (Height = 608) 30.782 ms ROI 1/4 (Height = 304) 30.782 ms ROI 1/8 (Height = 152) 30.782 ms Binning Vertical 2* 30.782 ms

* GO-2401M-PGE only

Shortest period of trigger

8-/10-bit

Exposure and readout cannot overlap on the GO-2401-PGE. The above table indicates the shortest trigger periods for the shortest exposure times. By adding the value of the exposure time you are using to the values in the table, you can determine the shortest trigger periods under your own usage environment.

Trigger

CMOS exposure

Next trigger disabled

Next trigger input enabled

Exposure active

FVAL

8-/10-bit packed 10 µs (minimum) 80.0 µs 827.8 µs 336 µs 10-bit 10.6 ms

Exposure duration

t1 t2 t3 t4

— 28 —

GO-2401M-PGE / GO-2401C-PGE

■ When [Exposure Mode] is [Trigger Width]

Example: When [Trigger Source] is set to [Line 5 - Optical In 1] and [OptIn Filter Selector] is set to [10 µs]

Scanning range

Full 30.782 ms ROI 2/3 (Height = 810) 30.782 ms ROI 1/2 (Height = 608) 30.782 ms ROI 1/4 (Height = 304) 30.782 ms ROI 1/8 (Height = 152) 30.782 ms Binning Vertical 2* 30.782 ms

* GO-2401M-PGE only

Shortest period of trigger

8-/10-bit

Trigger

CMOS exposure

Exposure active

FVAL

8-/10-bit packed 72.7 µs 80.0 µs 80.0 µs 827.8 µs 336 µs 10-bit 10.6 ms

Exposure duration

t1 t2 t3 t4 t5

Next trigger disabled

Next trigger input enabled

■ During normal continuous operation (both [Exposure Mode] and [Trigger Mode] disabled)

When using an application that does not require external triggers, the shortest repetition period will be as follows.

Scanning range

Full 30.782 ms ROI 2/3 (Height = 810) 30.782 ms ROI 1/2 (Height = 608) 30.782 ms ROI 1/4 (Height = 304) 30.782 ms ROI 1/8 (Height = 152) 30.782 ms Binning Vertical 2* 30.782 ms

Shortest period

8-/10-bit

* GO-2401M-PGE only

— 29 —

GO-2401M-PGE / GO-2401C-PGE

Event Control

“Event control” is a function that uses GVCP (GigE Vision Control Protocol) to output points of change in the camera’s internal signal as event occurrence information or “event messages.” When this information is output, the camera’s internal timestamp counter value is added.

■ Event message occurrence diagram

First signal on which an event is configured

Second signal on which an event is configured

and sent via GVCP with

GVCP transmission line

Event occurrence

The event

occurrence is verified

a timestamp

added.

Event occurrence

The event

occurrence is verified

and sent via GVCP with

a timestamp

added.

■ Internal camera blocks

Event signal

Selection of signal for detection

Event detection

The event occurrence time, event type, and timestamp value is retained.

Interrupt signal

Internal MCU of camera

Timestamp

32 bit Counter

After the event information is sent, the event is reset.

Event reset Counter reset

Information sent via GVCP at event occurrence time

— 30 —

GO-2401M-PGE / GO-2401C-PGE

24dB

■ To use the event control function

Configure the settings as follows.

Item Setting value / selectable range Description

Event Selector Acquisition Trigger,

Frame Start, Frame End, FVAL Start, FVAL End, Exposure Start, Exposure End, Line2(Opt Out1) RisingEdge, Line3(Opt Out2) RisingEdge, Line5(Opt In1) RisingEdge, Line2(Opt Out1) FallingEdge, Line3(Opt Out2) FallingEdge, Line5(Opt In1) FallingEdge

Event Notification On Output event messages.

Note

[Event Notification] is set to [Off] and event messages will not be output under factory default settings.

Select the event for which to send notifications.

Gain Control

[Analog All] can be used for gain control for both the monochrome and color camera. [Analog All] (master gain) uses the sensor's internal gain function and consists of analog gain + digital gain. Analog gain is used for lower gain, and analog gain + digital gain is used when the gain becomes high. R and B can be configured individually as digital gain on the GO-2401C-PGE.

 For details on how to configure the settings, see “Adjusting the Gain” (page 21).

The relationship between the gain setting value, gain amplification, and dB value is as follows. For example, a gain amplification of x5.62 will be 15 dB.

Monochrome

Gain

setting

value

1600

Gain

amplification

x16

Gain adjustment range (monochrome)

100

0dB

— 31 —

Bayer color

R&B

Gain

setting

value

Master Master

1600

Gain

amplification

X89.12

X16

Gain adjustment range (Bayer color)

39dB

24dB

Red

Blue

15dB

0dB

Gain setting

value (scaling)

37876 (X5.62)

0 (X1)

GO-2401M-PGE / GO-2401C-PGE

X7.15

X5.62

X0.45

–7dB

15dB

0dB

–7dB

-7dB

–4533 (X0.45)

37876 (X5.62)

0 (X1)

–4533 (X0.45)

LUT (Lookup T able)

The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. You can specify the output curve using 256 setting points (indexes).

■ To use the LUT function

Configure the settings as follows.

Item Setting value / selectable range Description

JAI LUT Mode LUT Use LUT. LUT Selector* R, G, B Select the LUT channel to control. LUT Index GO-2401M-PGE: 0 to 255

GO-2401C-PGE: 0 to 255

LUT Value 0 to 4095 Set the LUT output value for the selected index.

Select the LUT index to configure. Indexes represent the possible pixel values captured on the sensor, from the lowest value (Index 0) to the highest (Index 255). For example, Index 0 represents a full black pixel and Index 255 represents a full white pixel on the GO-2401M-PGE.

* GO-2401C-PGE only

Note

For the GO-2401C-PGE, separate characteristic curves are configured for R, G, and B.

■ LUT values

LUT values range from 0 at the lowest to 4095 at the highest. Linear interpolation is used to calculate LUT values between the index points.

— 32 —

4095

GO-2401M-PGE / GO-2401C-PGE

LUT Value [1]

LUT Value [0]

Index0

Index1

Linear interpolation using data to the left and right is used to determine values between points.

Index255

Gamma Function

The gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing. The gamma function can be used to correct the camera signals with an opposite-direction curve and produce a display that is close to linear.

Example of the light-emitting properties of the monitor display

■ To use the gamma function

Configure the settings as follows.

Item Setting value / selectable range Description

Gamma 0.45, 0.60, 1.0 (Off) Select the gamma correction value. JAI LUT Mode Gamma Use gamma.

Note

You can use the LUT function to configure a curve with more detailed points. For details, see “LUT (Lookup Table)” (page 32).

— 33 —

GO-2401M-PGE / GO-2401C-PGE

Line Status

The line status function allows you to verify the status of external input/output signals. You can verify the status of the following signals.

•Opt Out 1, Opt Out 2, Opt In 1

•Time Stamp Reset

•NAND Gate 0 In 1, NAND Gate 0 In 2, NAND Gate 1 In 1, NAND Gate 1 In 2

Shading Correction

The shading correction is a function that corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V).

The size of the correction block is 16 (H) × 10 (V) blocks and calculation errors in the correction data are minimized due to the small interpolation block. Each block is 128 × 128 pixels. The total size of the blocks is 2048 (H) × 1280 (V), but the actual number of effective pixels for the camera is 1936 (H) × 1216 (V). The ineffective peripheral areas will be deleted internally on the camera automatically.

2048 (Total size)

1936 (Effective pixels)

1216 (Effective pixels)

1280 (Total size)

128

The following shading correction modes are available on the camera. Be aware that the shading function may not operate properly when ROI settings are configured.

■ Flat Shading

Correction is performed using the area of the screen with the highest brightness level as the reference, and adjusting the brightness levels of the other areas to match this level.

— 34 —

GO-2401M-PGE / GO-2401C-PGE

Within 30% of adjustment range

■ Color Shading (GO-2401C-PGE only)

R-channel and B-channel properties are adjusted to using the G-channel shading properties as a reference.

Pre-correction Post-correction

Caution

Proper correction is not possible under the following conditions.

•If an area with a brightness level that is more than 30% less than the reference level exists within the screen

•If the brightness level is saturated in parts or all of the screen

•If the area in the screen with the highest brightness level is 300 LSB or less (during 10-bit video

output)

■ To use the shading correction function

Configure the settings as follows.

Item Setting value Description

Shading Correction Mode GO-2401M-PGE:

Flat Shading (fixed)

GO-2401C-PGE:

Flat Shading, Color Shading

Shading Mode User 1, User 2, User 3 Select the user area to which to save the

Display a white chart under a uniform light, and execute [Perform Shading Calibration].

Note

After shading correction is executed, the shading correction value is automatically saved to the user area selected in [Shading Mode].

Select the shading correction mode.

shading correction value.

Binning Function

The binning function allows you to combine the signal values of clusters of adjacent pixels on the sensor to create improved virtual pixels. Using the function results in images with lower pixel resolution and higher sensitivity. Common methods of binning include “horizontal binning” where two horizontally adjacent pixels are combined, and “vertical binning” where two vertically adjacent pixels are combined. By combining the horizontal and vertical methods to create a group of four pixels (2×2 binning), you can create images with x4 sensitivity.

— 35 —

ROI (Regional Scanning Function)

The ROI (region of interest) function allows you to output images by specifying the areas to scan.

ROI Settings

Specify the area to scan by specifying width, height, and horizontal/vertical offset values under [Image Format Control].

 For details on how to configure the settings, see “Configuring the Output Format” (page 16).

Specifying a lower height will decrease the number of lines scanned, but it will not increase the frame rate. The minimum area is as follows.

Width (pixels) Height (pixels)

GO-2401M-PGE Binning Off: 16

Binning 2 On: 8

 The minimum value for Monochrome varies

depending on the [Binning] setting.

GO-2401C-PGE 16 2

Example 1: Without binning

[Binning Horizontal] *: 1 [Binning Vertical] *: 1

Scanning range

OffsetX

Width

GO-2401M-PGE / GO-2401C-PGE

Example 2: With binning

[Binning Horizontal] *: 2 [Binning Vertical] *: 2

Scanning range

OffsetX

Width

OffsetY

Height

1216 Height Max

1936 Width Max

* GO-2401M-PGE only

 For details on the frame rates for common ROI sizes, see “Frame Rate Reference” (page 58).

OffsetY

Height

968 Width Max

608 Height Max

— 36 —

Video Send Mode

Switch the video send mode to configure and operate Multi ROI, Sequence Trigger, and other JAI Custom Control functions.

Video Send Mode

■ To switch the video send mode

Select the video send mode in [Video Send Mode Selector].

[Video Send Mode Selector] option Description

Normal Mode Normal camera operation. Multi Mode (Multi ROI) Multi ROI mode that allows you to configure ROI settings for up to

Trigger Sequence Mode Sequence Trigger mode that executes presets in a predefined order based

Command Sequence Mode Sequence Trigger mode that executes the preset listed in [Command

GO-2401M-PGE / GO-2401C-PGE

5 images.

on [Sequence Roi Frame Count] and [Sequence Roi Next Index]. Starts at Index #1.

Sequence Index] each time a trigger is received. Can jump to new preset by sending a new index value to [Command Sequence Index].

■ Multi ROI Mode

In the multi ROI mode, you can specify up to five scanning areas (Index 1 to 5) for a single-frame image. On the GO-2401-PGE, the areas can overlap, and a separate frame will be output for each area.

Index 4

Offset Y

Height

Index 4

Index 3

Offset Y

Height

Index 3

Index 2

Offset Y

Height

Index 2

Index 1

Offset Y

Height

Index 1

Index 3

Offset X

Index 1

Offset X

Index 2

Offset X

Index 1

Offset X

Width

ROI 1

Index 4

Index 3

Width

Index 2

Width

ROI 2

ROI 3

Index 4

Width

ROI 4

V-Binning Off

Height Max = 1216

H-Binning Off

Width Max = 1936

Specify the areas by specifying width, height, and horizontal/vertical offset values for each index under [JAI Custom Control MultiROI].

— 37 —

GO-2401M-PGE / GO-2401C-PGE

MulROI On Mode

Sensor

Frame

Memory

Specify an ROI in the area scanned by Sensor ROI and output as a separate stream.

■ Sequence T rigger function

The Sequence Trigger function lets you define up to 128 preset combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received. This is particularly useful for quickly capturing multiple exposures of objects under inspection to adjust for areas or components with significantly different levels of reflectance. The order of execution and the repetition of particular presets are based on user-defined parameters stored in the sequence, as well as the sequence mode selected in the [Video Send Mode Selector].

Two operation modes (Trigger Sequence and Command Sequence) are available for the Sequence Trigger function.

Trigger Sequence mode

With this mode, the Sequence Trigger “pattern” is predetermined by the user. The user defines up to 128 different “indexes.” Each index represents a combination of the following parameters:

•ROI (width, height, offset X, and offset Y)

•Exposure Time

•Gain Level (R/B Gain can also be configured on the color model)

•Black Level

•Binning Mode (monochrome only)

•LUT Enable (whether or not to enable the use of LUT for this index)

•Frame Count (the number of times to repeat this index before moving to the next)

•Next Index to execute in the predetermined pattern

In addition to these individual index parameters, two other parameters are applied to the entire sequence:

[Sequence LUT Mode] defines whether Gamma or LUT is to be applied to the sequence. If Gamma is selected, the Gamma setting defined in the camera’s Analog Control section will be applied to all exposures in the sequence. If LUT is selected, the LUT characteristics defined in Analog Control will be applied to any index where [Sequence LUT enable] has been set to ON.

[Reset Sequence Index] causes the index selector to be reset to Index 1. Thus, the sequence pattern will start over at the next trigger.

In Trigger Sequence mode, patterns always begin with Index1. Subsequent triggers follow the userdefined values in [Sequence Index Frame Count] and [Sequence ROI Next Index]. Assigning a Next Index value of “1” to an index creates a loop back to the start of the sequence pattern. Setting a Next Index value to “OFF” causes the value of [Sequence Repetition] to be applied as described below.

— 38 —

GO-2401M-PGE / GO-2401C-PGE

User-defined Indexes (up to 128)

[Sequence Repetition]

This parameter applies to Trigger Sequence patterns which include an index whose [Sequence ROI Next Index] is set to OFF. When the index whose [Sequence ROI Next Index] is set to OFF is finished executing, the value of Sequence Repetition (range = 1-255) is decremented internally. If the result of the decrement is not zero, the Trigger Sequence pattern starts over from Index1. If the result of the decrement is zero, the status changes to Acquisition Stop and external triggers are not accepted.

Trigger Sequence example

Index1 Index2

ROI Exposure Gain LUT Binning Frame Count = 2 Next Index = 3

ROI Exposure Gain LUT Binning Frame Count = 1 Next Index = 1

Triggers / Image Frames

Index structure for Trigger Sequence

Index

Current

Index

Selector

(MUX)

Reset Sequence

Index1

Index2

Index128 ROI128

ROI1

ROI2

Exposure

128

ROI Exposure Gain LUT Binning Frame Count = 1 Next Index = 4

Gain1

(M/Red/Blue)

Gain2

(M/Red/Blue)

Gain128

(M/Red/Blue)

Level1

Level2

Level128

Black

ROI Exposure Gain LUT Binning Frame Count = 2 Next Index = 2

Binning1

(H/V)

Binning2

(H/V)

Binning128

(H/V)

Index4 Index3

LUT

Enable1

LUT

Enable2

LUT

Enable128

Frame

Count1

Frame

Count2

Frame

Count128

Index1

Index2

Index128

Index Table

Index Next Index

・

Command Sequence mode

This mode allows the user to vary the “pattern” of the sequence in response to external factors. Changes in the sequence can be initiated manually or in a programmatic fashion as the result of data from sensors/controllers or from the analysis of previous images.

In this mode, the user can define up to 128 different “indexes” each incorporating a combination of:

•ROI (width, height, offset X, and offset Y)

•Exposure Time

•Gain Level (R/B Gain can also be configured on the color model)

•Black Level

•Binning Mode (monochrome only)

•LUT Enable (whether or not to enable the use of LUT for this index)

The user must also enter a value from 1 to 128 in [Command Sequence Index]. This indicates which index to execute each time a trigger is received. The same index will continue to be executed for all subsequent triggers as long as the value of [Command Sequence Index] remains unchanged.

Command

・

Reset Sequence Index

Common Settings

Sequence LUT mode

・

— 39 —

GO-2401M-PGE / GO-2401C-PGE

Changing the value of [Command Sequence Index] to one of the other predefined indexes causes that index to be executed in response to subsequent triggers. This mode of operation enables users to develop applications that continually send new values to [Command Sequence Index] in response to external factors such as changing light conditions, different types or sizes of objects being inspected, or other factors. This allows applications to change ROI, exposure, gain, etc., without being restricted to a predefined pattern.

As with Trigger Sequence, [Sequence LUT Mode] defines whether Gamma or LUT is to be applied to the sequence. If Gamma is selected, the Gamma setting defined in the camera’s Analog Control section will be applied to all exposures in the sequence. If LUT is selected, the LUT characteristics defined in Analog Control will be applied to any index where [Sequence LUT enable] has been set to ON.

[Sequence Index Frame Count], [Sequence ROI Next Index], and [Reset Sequence Index] are not used in Command Sequence mode and entered values are ignored.

Command Sequence Example

User-defined Indexes (up to 128)

Index1 Index2

ROI Exposure Gain LUT Binning

Command

Set to

Index1

Set to

Index3

Set to

Index1

Sequence Index

Camera Triggers

Image Frames

Settings Used

Index1

Settings

Index3

Settings

Index1

Settings

Index structure for Command Sequence

Index

Selector

(MUX)

Index1

Index2

ROI Exposure Gain LUT Binning

Set to

Index2

ROI1

ROI2

Settings

Exposure1

Exposure2

Index2

Index3

ROI Exposure Gain LUT Binning

Set to

Index1

Gain1

(M/Red/Blue)

Gain2

(M/Red/Blue)

Index1

Settings

Level1

Level2

Set to

Index2

Black

Index2

Settings

Binning1

(H/V)

Binning2

(H/V)

LUT

Enable1

LUT

Enable2

Current

Index

Index128

Common Settings

Command Sequence Index (1 to 128)

ROI128

— 40 —

Exposure

128

Gain128

(M/Red/Blue) (H/V)

Black

Level128

Binning128

Common Settings

Sequence LUT mode

LUT

Enable128

Delayed Readout [Acquisition Transfer Start]

Delayed readout enables images captured by a Frame Start trigger command to be stored inside the camera and read out on demand at a later time using Acquisition Transfer Start trigger. This can be especially useful when multiple cameras need to be triggered at the same time, but simultaneous readout of all images would overwhelm the available network bandwidth. The delayed readout buffer can hold up to 7 frames in 8-bit mode or 3 frames in 10-bit or 12-bit modes.

 For details, see “Trigger Control” (page 28).

ALC (Automatic Level Control) Function

The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions, and is capable of handling various changes in brightness. The function operates as follows in response to changes in brightness.

Change from bright to dark: ASC  AGC Change from dark to bright: AGC  ASC

Dark Bright

Change in brightness

GO-2401M-PGE / GO-2401C-PGE

AGC operation

ASC (auto shutter) operation

AGC

Max

Fixed at max. ASC value Fixed at min. ASC value

AGC operation

Max. to min. (user specified)

ASC operation

Max. to min. (user specified)

Operation during change from dark to bright

Fixed at min. gain value

Operation during change from bright to dark

■ To use the ALC function

Set [Gain Auto] or [Exposure Auto] or both to [Continuous] mode. Configure the minimum value, maximum value, etc. for AGC and ASC under [JAI Custom Control ALC]. The target video levels for AGC and ASC are configured in [ALC Reference]. For example, when [ALC Reference] is set to 100%, video levels will be maintained at 100% for AGC and ASC.

■ Automatic gain level control

Set [Gain] to [Continuous].

— 41 —

Detailed Settings for Gain Auto (Automatic Gain Level Control)

When [Gain Auto] is set to [Continuous], you can configure the conditions for automatic adjustment in detail.

Item Description

ALC Reference Specify the target level for automatic gain control. (This

setting is also used for automatic exposure control.)

ALC Area Enable All Select whether to specify all areas as auto gain metering

areas or whether to specify the areas individually.

[0]: Specify areas as auto gain metering areas (16 areas)

individually.

[1]: Specify all areas as auto gain metering areas.

ALC Area Selector Individually select any of 16 areas for automatic gain

metering. (This setting is also used for automatic exposure control.)

ALC Area Enable Select [True] to enable the metering area selected in [ALC

Area Selector], or select [False] to disable it.

AGC Max. Specify the maximum value for the automatic gain control

range.

AGC Min. Specify the minimum value for the automatic gain control

range.

AGC/ASC Control Speed Specify the reaction speed for automatic gain control. (This

setting is also used for automatic exposure control.)

GO-2401M-PGE / GO-2401C-PGE

Auto gain metering areas (16 areas)

High

Left

Mid-High

Left

Mid-Low

Left

Low

Left

High

Mid-left

Mid-High

Mid-left

Mid-Low

Mid-left

Low

Mid-left

High

Mid-right

Mid-High

Mid-right

Mid-Low

Mid-right

Low

Mid-right

High Right

Mid-High

Right

Mid-Low

Right

Low Right

— 42 —

GO-2401M-PGE / GO-2401C-PGE

Counter and Timer Control Function (counter support only)

The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations. Counting is performed at frame trigger, frame start, exposure start, and exposure transfer end, and by comparing these values, you can determine the internal camera state at which missed triggers will occur.

■ Counter occurrence diagram

Frame trigger

Frame trigger counter Set to count 1 Exposure Start

Exposure start counter Set to count 2

GVCP transmission

GVCP reception

Event occurrence

Count up

Event occurrence

Count up

Count 2 request

Count 1

Request

Read count value

Note

To reset the counter itself, execute [Counter Reset] or enter “1” in [Counter Reset].

■ Internal camera blocks

Frametrigger

Exposure Start

Frame Start

FrameTransfer End

Event detection

Counter At event occurrence or count up

Counter

Counter reset

Read count value

Counter reset

Count 1 reset

Count 2 reset

Counter

Counter reset Internal MCU of camera

— 43 —

Read requested counter value

Send information via GVCP

GO-2401M-PGE / GO-2401C-PGE

■ To use the counter function

Configure the settings as follows. Three counters can be configured (Counter 0 to 2).

Item Setting value / selectable range Description

Counter 0 to 2 Counter 0 to 2 Select the counter.

Counter 0 to 2 Event Source Off,

Frame Trigger,

Select the counter event signal for

which to read the count value. Frame Start, Exposure Start, Exposure Transfer End

Counter 0 to 2 Event Activation Rising Edge (fixed)

Specify the timing at which to count. or Falling Edge

Note

The four counter event signals are always counted up internally on the camera.

Video Process Bypass Mode

The video process bypass mode is a function that bypasses internal video processing on the camera. When bypass is enabled, the sensor output and camera output data can be set to the same bit width. Operation using 12-bit outputs must be performed in bypass mode.

Video process bypass mode On Off

Camera operation All video processes except Gain all

All video processes are enabled. (excluding R/B Gain) and Blemish Compensation are disabled.

Camera output 8-/10-/12-bit 8-/10-bit

■ Differences in camera operation

When video process bypass mode is disabled

All video processes are enabled.

Sensor Block

Gain All

Black Level

Block

R/B Black

Level

Pixel Gain

Block

R/B Gain

Blemish

Comp Block

Blemish Comp

Shading/

LUT Block

LUT

When video process bypass mode is enabled

All video processes except Gain all (excluding R/B Gain) and Blemish Compensation are disabled.

Sensor Block

Gain All

Blemish

Comp Block

Blemish Comp

BlackSetup

Black Setup

Block

■ To enable video process bypass mode

Item Setting value / selectable range Description

Video Process Bypass Mode On Enable video process bypass

mode.

— 44 —

Settings List

Feature Properties

: Settings that can only be configured when image acquisition on the camera is stopped.

Item Setting range Default value Description

a) Device Control

Device Vendor Name — — Display the manufacturer name.

Device Model Name — — Display the model name.

Device Manufacturer Info — — Display the device information.

Device Version — — Display the hardware version.

Device Firmware Version — — Display the firmware version.

Device ID — — Display the device ID.

Device User ID Any — Set the user ID for the camera.

Device Temperature in degrees Celsius

Device Reset — — Reset the device.

b) Image Format Control

Width Max — 1936 Display the maximum image width.

Height Max — 1216 Display the maximum image height.

Width Binning Off: 16 to 1936

Height GO-2401M-PGE:

Offset X — 0 Set the horizontal position.

GO-2401M-PGE / GO-2401C-PGE

Display/configure information related to the device.

— — Display the internal temperature (°C) of

the camera.

Configure image format settings.

1936 Set the image width.

Binning 2 On: 8 to 968

❖ The minimum value for

Monochrome varies depending on the [Binning] setting.

1216 Set the image height. Binning Off: 1 to 1216 Binning 2 On: 1 to 608

GO-2401C-PGE: 2 to 1216

❖ The minimum value for

Monochrome varies depending on the [Binning] setting.

Offset Y — 0 Set the vertical position.

Binning Horizontal (GO-2401M-PGE only)

Binning Vertical (GO-2401M-PGE only)

Pixel Format GO-2401M-PGE:

Test Image Selector Off,

1, 2 1 Set the number of pixels in the horizontal

1, 2 1 Set the number of pixels in the vertical

8 Bit Monochrome, 10 Bit Monochrome, 10 Bit Monochrome Packed, 12 Bit Monochrome, 12 Bit Monochrome Packed

GO-2401C-PGE:

8 Bit Bayer RG, 10 Bit Bayer RG (Unpacked), 10 Bit Bayer RG Packed, 12 Bit Bayer RG (Unpacked), 12 Bit Bayer RG Packed

Grey Horizontal Ramp, Grey Vertical Ramp, Grey Horizontal Ramp Moving

GO-2401M-PGE:

8 Bit Monochrome

GO-2401C-PGE：

8 Bit Bayer RG

Off Select the test image.

direction for which to perform binning.

Set the pixel format.

— 45 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

c) Acquisition Control

Acquisition Mode Single Frame, Multi Frame,

Acquisition Start — — Start image acquisition.

Acquisition Stop — — Stop image acquisition.

Acquisition Frame Count 1 to 255 153 In [Multi Frame] mode, set the number of

Acquisition Frame Rate*

* Max. frequency/min. frame

period depends on ROI, pixel format, and binning mode selected.

Acquisition Frame Rate Raw*

* Max. frequency/min. frame

period depends on ROI, pixel format, and binning mode selected.

Trigger Selector Acquisition Start,

Trigger Mode Off, On Off Select the trigger mode.

Trigger Software — — Execute a software trigger.

Trigger Source Low, High, Software,

Trigger Activation Rising Edge, Falling Edge,

Trigger OverLap Off (fixed) Off Select the trigger overlap operation.

Exposure Mode Off, Timed, Trigger Width Timed (control

Exposure Time 73 to 7999685 (µs) 30172 (µs) Set the exposure time. The maximum

Exposure Time Raw 73 to 7999685 (µs) 30172 (µs) Set the raw exposure time.

Exposure Auto Off, Continuous Off Set whether to enable auto exposure.

d) Event Control

Event Selector Acquisition Trigger,

Event Notification Off, On Off Select whether to output event messages.

e) Analog Control

Gain Selector GO-2401M-PGE: Analog All

Gain Analog All: 1 to 16

Continuous

0.125 to 32.8423 32.8423

30448 to 8000000 30448 Set the frame rate as a time. (unit: µs)

Acquisition End, Frame Start, Acquisition Transfer Start

Pulse Generator 0, User Output 0, User Output 1, Action 1, Action 2, Line 5 - Optical In 1, NAND0 Out, NAND1 Out

Level High, Level Low

Frame Start, Frame End, FVAL Start, FVAL End, Exposure Start, Exposure End, Line2(Opt Out1) Rising Edge, Line3(Opt Out2) Rising Edge, Line5(Opt In1) Rising Edge, Line2(Opt Out1) Falling Edge, Line3(Opt Out2) Falling Edge, Line5(Opt In1) Falling Edge

GO-2401C-PGE: Analog All,

Digital Red, Digital Blue

Digital Red & Blue:

0.447 to 5.624 (color only)

Continuous Select the image acquisition mode.

Frame Start Select the trigger operation.

Line 5 - Optical

In 1

Rising Edge

(rising edge of

input signal)

via exposure

time)

Analog All

(master gain)

Master gain: 1

R, B: 1

Configure image acquisition settings.

frames to acquire.

Set the frame rate as a frequency. (unit: Hz)

Select the trigger signal source.

Select the polarity of the trigger signal (i.e., location of signal at which trigger is applied).

Select the exposure mode.

value varies depending on the [Acquisition Frame Rate Raw] value.

Configure event control settings.

Select the event for which to send notifications.

Configure analog control settings.

Select the gain to configure.

Set the gain value.

— 46 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

Black Level Selector GO-2401M-PGE: Digital All

Black Level Digital All: –133 to 255

Gain Auto Off, Continuous Off Enable/disable gain auto adjustment.

Balance White Auto (GO-2401C-PGE only)

Gamma 0.45, 0.60, 1.0 0.45 Set the gamma value.

JAI LUT Mode Off, Gamma, LUT Off Select the JAI LUT mode.

f) LUT Control

LUT Selector (GO-2401C-PGE only)

LUT Index GO-2401M-PGE: 0 to 255

LUT Value 0 to 4095 0 Set the LUT value.

g) Digital IO Control

Line Selector Line2 - Opt Out 1,

Line Mode — Output Display the input/output status (whether it

Line Inverter True, False False Enable/disable polarity inversion for the

Line Status — True Display the status of the input signal or

LineSource Low, High,

Source Format — Opto Coupled Display the current I/F type.

User Output Selector User Output 0,

User Output Value True, False False

h) Pulse Generators

Clock Pre-scaler 1 to 4096 1 Set the division value for the prescaler

Pulse Generator Clock (MHz) 0.018127 to 74.25 74.25 Set the clock value (MHz) for the pulse

GO-2401C-PGE: Digital All,

Digital Red, Digital Blue

Digital Red & Blue:

–133 to 255 (color only)

Off, On Off Enable/disable auto white balance.

R, G, B R Select the LUT channel to control.

GO-2401C-PGE: 0 to 255

Line3 - Opt Out 2, Line5 - Opt In 1, Time Stamp Reset, NAND Gate 0 In 1, NAND Gate 0 In 2, NAND Gate 1 In 1, NAND Gate 1 In 2

Acquisition Trigger Wait, Frame Trigger Wait, Frame Active, Exposure Active, FVAL, User Output 0, User Output 1, Line 5 - Opt In 1, Pulse Generator 0, Nand 0 Out, Nand 1 Out

User Output 1

Digital All

(master black)

0 Set the black level value.

0 Set the LUT index table number.

Line2 - Opt Out 1 Select the input/output to configure.

Low Select the line source signal for the item

User Output 0 Set the user output signal.

Select the black level to configure.

Configure LUT settings.

Configure settings for digital input/output.

is input or output).

selected input signal or output signal.

output signal (True: High, False: Low).

selected in [Line Selector].

Configure pulse generator settings.

using the pixel clock as the base clock.

generator.

— 47 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

Pulse Generator Selector Pulse Generator 0

Pulse Generator Length 1 to 1048575 1 Set the count-up value (clock value) for

Pulse Generator Length (ms)

Pulse Generator Frequency (Hz)

Pulse Generator Start Point 0 to 1048574 0 Set the active output start count value for

Pulse Generator Start Point (ms)

Pulse Generator End Point 1 to 1048574 1 Set the active output stop count value for

Pulse Generator End Point (ms)

Pulse Generator pulsewidth (ms)

Pulse Generator Repeat Count

Pulse Generator Clear Activation

Pulse Generator Clear Source

Pulse Generator Clear Inverter

Pulse Generator Clear Sync Mode

i) Transport Layer Control

Payload Size — 2354176 Display the payload size.

GigE Vision Major Version — 1 Display the GigE version.

GigE Vision Minor Version — 1

Is Big Endian — True Display the endianness.

Character Set — UTF8 Display the character set.

1.3E-05 to 14.1222 1.3468E-05 Set the count-up value for the pulse

70.810386 to 74250000 7.425E+0.7 Set the frequency for the pulse generator.

0 to 14.122209 0 Set the active output start count value for

1.3E-05 to 14.122222 1.3468E-05 Set the active output stop count value for

— 1.3468E-05 Display the pulse width of the pulse

0 to 255 0 Set the repeat count for the pulse

Off, High Level, Low Level, Rising Edge, Falling Edge

Low, High, Acquisition Trigger Wait, Frame Trigger Wait, Frame Active, Exposure Active, FVAL, User Output 0, User Output 1, Action 1, Action 2, Line 5 - Opt In 1, Nand 0 Out, Nand 1 Out

True, False False Select whether to invert the polarity of the

Async Mode, Sync Mode Async Mode Select the sync mode for the count clear

Pulse Generator 0

Off Set the clear signal condition for the

Low Select the count clear input signal source.

Select the pulse generator.

the pulse generator.

generator. (unit: ms)

the pulse generator.

the pulse generator. (unit: ms)

the pulse generator.

the pulse generator. (unit: ms)

generator. (unit: ms)

generator.

count clear input of the pulse generator.

count clear input signal.

input signal.

Display information on transport layer control.

— 48 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

Interface Selector — 0 Set the interface.

Mac Address — XX-XX-XX-XX-

Supported LLA — True Display whether LLA (link-local address)

Supported DHCP — True Display whether DHCP is supported.

Supported Persistent IP — True Display whether persistent IP is

Current IP Configuration LLA

Current IP Configuration DHCP

Current IP Configuration Persistent IP

Current IP Address — XXX.XXX.XXX.

Current Subnet Mask — 255.255.0.0 Display the subnet.

Current Default Gateway — 0.0.0.0 Display the default gateway.

Persistent IP Address 000.000.000.000 to

Persistent Subnet Mask 000.000.000.000 to

Persistent Default Gateway 000.000.000.000 to

GigE Vision Supported Option Selector

Supported Option — True Enable/disable the supported options.

First URL — Local:XXXXXX Display the first URL.

Second URL — Display the second URL.

Number Of Interfaces — 1 Display the number of interfaces.

Message Channel Count — 1 Display the message channel count.

Stream Channel Count — 1 Display the stream channel count.

Supported Optional Commands EVENTDATA

Supported Optional Commands EVENT

Supported Optional Commands PACKET RESEND

Supported Optional Commands WRITEMEM

Supported Optional Commands Concatenation

Heartbeat Timeout 500 to 4294967295 3000 Set the timeout value for heartbeat.

Timestamp Tick Frequency — 1000000000 Display the timestamp frequency.

Timestamp Control Latch — — Latch the timestamp value.

Timestamp Control Reset — — Reset the timestamp value.

— True Display whether the current IP

True, False True Select whether to set the IP configuration

True, False False Select whether to set the IP configuration

255.255.255.255

Link Local Address configuration, DHCP configuration, Persistent IP configuration, Stream Channel Source Socket, Message Channel Source Socket, Command Concatenation, Write Mem, Packet Resend, Event, Event Data, Pending Ack, Action, Extended Status Codes, Discovery Ack Delay, Discovery Ack Delay Writable, Test Data, Manifest Table, CCP Application Socket, Link Speed, Heartbeat Disable, Serial Number

— False Display whether EVENTDATA support is

— True Display whether EVENT support is

— True Display whether PACKET RESEND

— True Display whether WRITEMEM support is

— True Display whether Concatenation support is

XX-XX

XXX

192.168.100.1 Set the persistent IP address.

255.255.255.0 Set the persistent subnet mask.

0.0.0.0 Set the persistent default gateway.

Link Local

Address

configuration

Display the MAC address.

is supported.

supported.

configuration is calibrated by LLA (linklocal address).

to DHCP.

to persistent IP.

Display the IP address.

Select the supported options for GigE Vision.

enabled or disabled.

support is enabled or disabled.

enabled or disabled.

— 49 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

Timestamp Tick Value — 0 Display the timestamp value.

Control Channel Privilege —

Message Channel Port 0 to 65535 XXXXX Set the port number for the message

Message Channel Destination Address

Message Channel Transmission Timeout (ms)

Message Channel Retry Count 0 to 4294967295 2 Set the retry count for the message

Message Channel Source Port — XXXXX Display the port number of the message

Stream Channel Selector — 0 Select the stream channel.

Stream Channel Port 0 to 4294967295 0 Set the port number for the stream

Do Not Fragment True, False True Enable/disable “Do Not Fragment.”

Packet Size 1476 to 16020 1476 Set the packet size.

Packet Delay 0 to 4000000 0 Set the packet delay.

Stream Channel Destination Address

Stream Channel Source Port

j) Action Control

Action Device Key — 0x00 Set the action device key.

Action Selector 1 to 2 1 Select the action.

Action Group Key — 0x00 Set the key that executes action 1.

Action Group Mask — 0x00 Set the mask value that creates the action

k) User Set Control

User Set Selector Default,

User Set Load — — Load user settings.

User Set Save — — Save the current setting values as user

l) JAI Custom Control ALC

ALC Reference 10 to 100 50 Set the target level for ALC. (unit: %)

ALC Area Selector Low Right to High Left Low Right Select an ALC metering area.

ALC Area Enable True, False False Enable/disable the metering area where

ALC Area Enable All 0 to 1 1 Set whether to enable ALC for all areas.

ASC Min. 73 to 7999899 100 Set the minimum value for the ASC range.

ASC Max. 74 to 7999900 8000000 Set the maximum value for the ASC

AGC Min. 100 to 1599 100 Set the minimum value for the AGC

AGC Max. 101 to 1600 1600 Set the maximum value for the AGC

AGC/ASC Control Speed 1 to 8 4 Set the reaction speed for AGC/ASC.

m) JAI Custom Control Blemish

Blemish Enable True, False True Set whether to enable white blemish

Blemish Detect — — Detect white blemishes.

Blemish Detect Threshold 0 to 100 10 Set the white blemish detection threshold.

Blemish Detect Position Index 0 to 255 0 Select the index table for the white

Blemish Detect Position X –1 to 1935 –1 Set the horizontal position.

Blemish Detect Position Y –1 to 1215 –1 Set the vertical position.

000.000.000.000 to

255.255.255.255

0 to 4294967295 300 Set the transmission timeout for the

000.000.000.000 to

255.255.255.255

— 0 Display the port number of the stream

User Set1 to User Set3

ControlAccess

XXX.XXX.XXX.

XXX

0.0.0.0 Set the destination IP address for the

Default (factory

default values)

Display the control channel privilege.

channel.

Set the destination IP address for the message channel.

message channel. (unit: ms)

channel.

channel source.

channel.

stream channel.

channel source.

Configure action control settings.

0 group,

Configure user settings.

Select the user settings.

settings.

Configure JAI ALC settings. These settings are also used for AGC (auto gain control).

selected metering area.

range.

These settings are also used for auto exposure control.

Configure settings for JAI white blemish correction.

correction.

blemish detection position.

— 50 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

n) JAI Custom Control Shading

Shading Correction Mode GO-2401M-PGE:

Shading Mode Off, User 1, User 2, User 3 Off Select whether to use shading correction.

Perform Shading Calibration — — Execute shading correction. After

Shading Detect Result — — Display the shading detection results.

o) JAI Custom Control Sequence ROI

Video Send Mode Selector Normal Mode, Trigger

Sequence Roi Index Index 1 to 128 Index 1 Select the sequence ROI index table.

Sequence Roi Frame Count

Sequence Roi Next Index Index 1 to 128, Off Index 1 Select the next index.

Sequence Roi Width 16 to 1936 1936 Set the width.

Sequence Roi Height GO-2401M-PGE: 1 to 1216

Sequence Roi Offset X — 0 Set the horizontal position.

Sequence Roi Offset Y — 0 Set the vertical position.

Sequence Roi Gain (GO-2401M-PGE only)

Sequence Roi Gain All (GO-2401C-PGE only)

Sequence Roi Gain Red (GO-2401C-PGE only)

Sequence Roi Gain Blue (GO-2401C-PGE only)

Sequence Roi Exposure Time

Sequence Roi Black Level 0 to 255 0 Set the black level.

Sequence Lut enable Off, On Off Set whether to enable the LUT.

Sequence Roi H Binning (GO-2401M-PGE only)

Sequence Roi V Binning (GO-2401M-PGE only)

Sequence Repetition 1 to 255 1 Set the repeat count for the sequence.

Command Sequence Index Index 1 to 128 Index 1 Set the sequence index command.

Current Sequence Index Index 1 Display the current sequence index table.

Sequence LUT Mode Gamma, LUT Gamma Set the sequence LUT mode.

Reset Sequence Index — — Reset the sequence index table.

Flat Shading (fixed)

GO-2401C-PGE:

Flat Shading, Color Shading

Sequence Mode, Command Sequence Mode, Multi Mode

1 to 255 1 Set the frame count.

GO-2401C-PGE: 2 to 1216

100 to 1600 100 Set the gain value.

100 to 1600 100

–4533 to 37876 0

73 to 8000000 18000 Set the exposure time.

1 to 2 1 Set the number of pixels in the horizontal

1 to 2 1 Set the number of pixels in the vertical

Flat Shading Select the shading correction mode.

Normal Mode Select the video send mode.

1216 Set the height.

Configure shading correction settings.

When using the function, select the user area to which to save the shading correction value.

execution, the shading correction value is automatically saved to the selected user area.

Configure settings for JAI sequence ROI.

When [Off] is selected, sequence operation will stop with this index.

direction for which to perform binning.

— 51 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value Description

p) JAI Custom Control MultiROI

Multi Roi Index Index 1 to 5 Index 1 Set the Multi ROI index table.

Multi Roi Width 16 to 1936/16 steps 1936 Set the width. When binning is enabled

Multi Roi Height GO-2401M-PGE:

Multi Roi Offset X 0 to 1920/16 steps

Multi Roi Offset Y GO-2401M-PGE:

Multi Roi Index Max 1 to 5 1 Set the Multi ROI index count.

q) Counter And Timer Control

Counter 0 to 2 Counter 0 to 2 — Select the counter.

Counter 0 to 2 Event Source

Counter 0 to 2 Event Activation

Counter 0 to 2 Reset — — Reset the counter.

Counter 0 to 2 Refresh — — Update the count value.

Counter 0 to 2 Value — 0 Display the count value.

Counter 0 to 2 Status — Counter Active Display the counter status.

r) JAI Custom control features Misc.

Video Process Bypass Mode

Dark Compression Linear, Dark Compression Linear (no

AWB Area Selector (GO-2401C-PGE only)

AWB Area Enable True, False False Enable (True) / disable (False) the

AWB Control Speed 1 to 8 4 Select the AWB reaction speed. (for

Binning Gain Enable (GO-2401M-PGE only)

OptIn Filter Selector 10 us, 100 us, 500 us, 1 ms,

1 to 1216/1 step

GO-2401C-PGE:

2 to 1216/2 steps

❖ maximum value

= 1936 - width value

0 to 1215/1 step

GO-2401C-PGE:

0 to 1214/2 step

❖ maximum value

= 1216 - height value

Off, Frame Trigger, Frame Start, Exposure Start, Exposure Transfer End

Rising Edge (fixed) Rising Edge Specify the timing at which to count.

On, Off Off Enable / disable video process bypass

Low Right to High Left Low Right Select from the 16 metering areas for

Off, On On Enable/disable gain binning.

5 ms, 10 ms

1216 Set the height. When binning is enabled

0 Set the horizontal position. When binning

0 Set the vertical position. When binning is

Off Select the counter event signal for which

compression)

10 us Select the surge protection filter.

When using the JAI Multi ROI function, set the scanning area.

on the GO-2401M-PGE, the maximum value will change.

is enabled on the GO-2401M-PGE, the maximum value will change.

enabled on the GO-2401M-PGE, the maximum value will change.

Configure counter settings. (This camera only supports counter functions.)

to read the count value.

Configure settings for other JAI functions.

mode.

Set whether to compress signals for dark areas.

AWB individually.

selected AWB metering area.

continuous)

— 52 —

Settings

 For details on the setting items, refer to the JAI Control Tool User’s Guide

32-bit Factory Transport Layers

Available 32-bit Transport Layers —

JAI_GigE_Vision —

Transport name — JAI_GigE_Vision

Full path to cti file — $(JAI_SDK_BIN)\

Enabled True, False True

Display name — GevTL

64-bit Factory Transport Layers

Available 64-bit Transport Layers —

JAI_GigE_Vision —

Transport name — JAI_GigE_Vision

Full path to cti file — $(JAI_SDK_BIN_64)\

Enabled True, False True

Display name — GenTL

Asynchronous Image Recording

Recording Count — 25

Recording Skip Count — 0

Recording mode List, CyclicBuffer List

Optimize the AVI-file creation for Mono8 True, False True

Prompt user for AVI Encoder True, False True

Camera Link Transport Layer

Automatically probe for CameraLink devices at startup True, False True

Use Highest Baud rate for XML download from camera True, False False

Show CameraLink Warning Dialog True, False True

CXP Transport Layer

Sync Remote And Local Devices True, False True

File Save

File Format Tiff, Jpeg, Bmp, Jai, RAW Tiff

Encoder parameter — 75

GigE Transport Layer

Preferred Drive Type FilterDriver, SocketDriver FilterDriver

Preferred Device Access Mode None, ReadOnly, Control Control

Enable Automatic Force IP True, False True

Enable Subnet Conflict Warning? True, False True

Look-and-feel

Visibility Level Beginner, Expert, Guru Beginner

HEX display True, False False

Display ToolTips True, False True

Floating-Point Display Notation Automatic, Fixed, Scientific Automatic

Floating-Point Display Precision — 5

Display the Remote device layer at the top of the tree (transport at the bottom)

Refresh Property Grid After Editing True, False False

Override TrackBar Floating-point display precision settings

Make the control tool appear on top of images True, False False

Timestamp display format Ticks, MSec, PTP Ticks

Plugins

Search path for plugin DLLs — .\plugins

Enable the plug-in button on the menu tab True, False False

Support

Open settings file after save True, False True

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value

JaiGevTL.cti

—

JaiGenTL.cti

True, False True

True, False False

— 53 —

GO-2401M-PGE / GO-2401C-PGE

Item Setting range Default value

Support EMail Address — camerasupport@jai.com

Logging Properties

Enable logging True, False False

Use custom properties file True, False False

Custom logging properties file path

Output log file path

Enable GenApi logging True, False False

Enable GenTL logging True, False False

Enable CIProtocol logging True, False False

Enable USB logging True, False False

Log Level FATAL, ALERT, CRIT, ERROR, WARN,

NOTICE, INFO, DEBUG, NOTEST

Format string — LOG %d %x: %c :

Append To Log file True, False False

Video Display

Stretch Live Video True, False True

Restore Live Video Window True, False True

Skip image display when busy True, False True

Enable Color Interpolation True, False True

Color Interpolation BayerStandard,

BayerStandardMultiprocessor, BayerExtended, BayerExtendedMultiprocessor, BayerSimple, BayerSimpleMultiprocessor, BayerFast, BayerFastMultiprocessor

Show Zoom Navigation window True, False True

Show Cursor Information window True, False False

Enable Mouse Zoom True, False True

Enable Mouse Cursor Display True, False False

INFO

%m%n

BayerStandard

— 54 —

GO-2401M-PGE / GO-2401C-PGE

Miscellaneous

Updates

You can obtain update information and the latest update information from the following URL.

http://www.jai.com/EN/Partner/CameraInformation/Pages/Revision_Notes.aspx

 Registration and login are required for viewing.

Check the version of the unit, and update if necessary. You can check the version of the unit under [Device Control] in the [Feature Properties] tab after starting Control Tool.

Troubleshooting

Check the following before requesting help. If the problem persists, contact your local JAI distributor.

■ Power supply and connections

Problem Cause and solution

The power / trigger LED remains lit amber and does not turn green, even after power is supplied to the camera.

Camera initialization may not be complete due to lack of a network connection. Check the LAN cable conection.

■ Image display

Problem Cause and solution

Gradation in dark areas is not noticeable. Use the gamma function to correct the display.

As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing. Using the gamma function performs correction to produce a display that is close to linear. For details, see “Gamma Function” (page 33).

■ Settings and operations

Problem Cause and solution

Settings cannot be saved to user memory. You cannot save to user memory while images are being

acquired by the camera. Stop image acquisition before performing the save operation.

I want to restore the factory default settings. Load [Default] under [User Set Selector] in the [Feature

Properties] tab to restore the factory default settings.

— 55 —

Specifications

Scanning system Progressive scan, 1 tap

Synchronization Internal

Interface 1000BASE-T Ethernet (GigE Vision 1.1), IEEE 802.3af

Image sensor 1/1.2-inch monochrome CMOS 1/1.2-inch Bayer color CMOS

Image size (effective image) 11.3 (H) × 7.13 (V), 13.4 mm diagonal

Pixel size 5.86 (H) × 5.86 (V) µm

Effective image pixel output 1936 (H) × 1216 (V) 1936 (H) × 1216 (V)

Acquisition Frame Rate (max)

❖ The minimum

value is 0.125 fps for all.

EMVA 1288 parameters Absolute sensitivity Maximum SN ratio

SN ratio (traditional method) 60 dB or more (typical)

Digital image output format

Acquisition modes Continuous, Single Frame, Multi Frame (1 to 255)

Trigger selector Acquisition Acquisition Start, Acquisition Stop

Exposure modes Off, Timed (EPS), Trigger Width (PWC)

Trigger overlap Off

Trigger input signals Line 5 (Opt In), Software, PG0, NAND Out 0/1, Action 1/2

Option filter 6 steps (10 µs (Typ), 100 µs, 500 µs, 1ms, 5ms, 10ms)

Exposure modes Timed 73 µs (min) to 8 s (max), variable unit: 1 µs

Auto exposure (Exposure Auto) Off, Continuous

Auto exposure response speed (AGC/ASC Control Speed)

Video Send Mode Selector Normal ROI, Multi ROI (1 to 5), Trigger Sequence,

Digital I/O Line Selector (6P): GPIO IN / GPIO OUT

GO-2401M-PGE / GO-2401C-PGE

Item GO-2401M-PGE GO-2401C-PGE

8-bit H1, V1 32.8 fps 32.8 fps

Binning H1, V2 32.8 fps —

H2, V1 32.8 fps —

H2, V2 32.8 fps —

10-bit packed / 12-bit packed

10-bit / 12-bit

Full pixel 1936 (H) × 1216 (V)

ROI Width 16 to 1936, 16 pixels/step 16 to 1936, 16 pixels/step

Binning H 1 1936 (H) 1936 (H)

Pixel Format Mono8, Mono10, Mono10

Exposure Frame Start

Transfer Acquisition Transfer Start

Trigger Width 73 µs (min) to ∞ (max)

H1, V1 32.5 fps 32.5 fps

Binning H1, V2 32.8 fps —

H2, V1 32.8 fps —

H2, V2 32.8 fps —

H1, V1 32.8 fps 24.4 fps

Binning H1, V2 32.8 fps —

H2, V1 32.8 fps —

H2, V2 32.8 fps —

At 10-bit

TBD

(0 dB gain, Black)

Offset X 0 to 1920, 16 pixels/step 0 to 1920, 16 pixels/step

Height 1 to 1216, 1 line/step 2 to 1216, 2 lines/step

Offset Y 0 to 1215, 1 line/step 0 to 1214, 2 lines/step

2 968 (H) —

V 1 1216 (V) 1216 (V)

2 968 (V) —

Packed, Mono12,

Mono12 Packed

output

p (λ = 525 nm)

45.22 dB

BayerRG10 Packed, BayerRG12,

❖ Performance verified for up to 1 second.

1 to 8

Command Sequence, Delayed Readout

At 10-bit

TBD

60 dB or more (typical)

Dark compression ON: 50 dB

(0 dB gain, Green Black)

Bayer 1936 (H) × 1216 (V)

BayerRG8, BayerRG10,

BayerRG12 Packed

output

p (λ = 525 nm)

45.26 dB

(typical)

— 56 —

GO-2401M-PGE / GO-2401C-PGE

Item GO-2401M-PGE GO-2401C-PGE

Black level adjustment

Gain adjustment Manual adjustment range 0 dB to +24 dB

Blemish correction Detection Detect white blemishes using threshold values

ALC Can be adjusted automatically together with AGC and auto exposure

Gamma 0.45, 0.6, 1.0 (OFF) (3 steps available)

LUT

Power supply 6-pin

Lens mount C-mount

Flange back 17.526, tolerance: 0 mm to –0.05 m

Optical filter Protective glass: Not provided IR cut filter (half value of 670 nm)

Verified performance temperature / humidity –5°C to +45°C / 20% to 80% (non-condensing)

Storage temperature / humidity –25°C to +60°C / 20% to 80% (non-condensing)

Regulations CE (EN61000-6-2 and EN61000-6-3), FCC part 15 class B, RoHS,

Dimensions (housing) 29 × 29 × 41.5 mm (WHD) (excluding mount protrutions)

Weight 46 g

Default level 33LSB (during 10-bit output)

Video level adjustment range 0 to 100 (during 10-bit output)

Adjustment range –33LSB to +64LSB against reference level (during 10-bit output)

Resolution adjustment 1 STEP = 0.25LSB

0 dB to +24 dB

1 step = x0.01 (0.005 dB to

Auto gain Off, Continuous Off, Continuous

WB gain — R / B: –7 dB to +15 dB, 1 step =

WB area — 16 (4 × 4) Area

WB range — 3000 K to 9000 K

White balance — Off, Continuous, Once

Correction Interpolation using adjacent pixels (continuous blemishes not

Correctable pixels 256 pixels

connector

PoE Input range DC 36 V to 57 V

Input range DC +12 V to +24 V ±10% (via input terminal)

Current 220 mA ±20 mA (at 12 V input, full pixel) (Typical)

Current 2.64 W (at 12 V input, full pixel) (Typical)

Current 63 mA ±6 mA (at 48 V input, full pixel) (Typical)

Current 3.02 W (at 48 V input, full pixel) (Typical)

0.08 dB)

(varies by setting value)

(black blemish correction performed only at factory)

corrected)

OFF: γ = 1.0, ON = 256 points can be set

Lens mount protrusion length of 9 mm or less is supported

1 step = x0.01 (0.005 dB to

0.08 dB)

(varies by setting value)

0.1 dB

WEEE

Approximately 5 minutes of warm-up are required to achieve these specifications.

Package contents

Camera body (1) Sensor protection cap (1) Dear Customer (sheet) (1)

Optional accessories (not supplied)

MP-43 tripod mount AC adapter

Design and specifications are subject to change without notice.

— 57 —

Frame Rate Reference

Pixel count

2.35 MP 1936 × 1216 Full pixel 5.86 × 5.86 1/1.2" (13.40 mm) 32.8 fps (@8 bit)

2 MP 1920 × 1080 ROI 5.86 × 5.86 1/1.2" (12.91 mm) 32.8 fps (@8 bit)

1.4 MP 1400 × 1050 ROI 5.86 × 5.86 1/1.6" (10.26 mm) 32.8 fps (@8 bit)

1.3 MP 1280 × 1024 ROI 5.86 × 5.86 1/1.7" (9.61 mm) 32.8 fps (@8 bit)

0.5 MP 800 × 600 ROI 5.86 × 5.86 1/2.7" (5.86 mm) 32.8 fps (@8 bit)

0.3 MP 640 × 480 ROI 5.86 × 5.86 1/3.4" (4.69 mm) 32.8 fps (@8 bit)

Resolution

(screen size)

Spectral Response

GO-2401M-PGE

GO-2401M-PGE / GO-2401C-PGE

(Theoretical value: decimal values are dropped, during Unpacked)

ROI/Binning Pixel size(μm) Image size Frame rate

0.9

0.8

0.7

0.6

0.5

Sensitivity

0.4

0.3

0.2

0.1

400 500 600 700 800 900 1000

wave length (nm)

B&W

— 58 —

GO-2401C-PGE

0.9

0.8

0.7

0.6

GO-2401M-PGE / GO-2401C-PGE

0.5

Sensitivity

0.4

0.3

0.2

0.1

400 500 600 700 800 900 1000

Dimensions

wave length (nm)

10 41.5

Rch

Gch

Bch

C Mount

12.5

14 22

23.7

4-M2 Depth3

3-M3 Depth3

Dimensional tolerance: ±0.3 mm Unit: mm

— 59 —

User’s Record

Camera type: GO-2401M-PGE / GO-2401C-PGE

Revision: ……………..

Serial No. ……………..

Firmware version. ……………..

For camera revision history, please contact your local JAI distributor.

GO-2401M-PGE / GO-2401C-PGE

Trademarks

• GigE Vision is a registered trademark of AIA (Automated Imaging Association).

• Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other

countries.

• Intel and Intel Core are trademarks of Intel Corporation in the United States and other countries. Other system and product names described in this document are trademarks or registered trademarks of their respective

owners. The ™ and ® symbols are not used in this document.

— 60 —

Index

GO-2401M-PGE / GO-2401C-PGE

6-pin round

AC adapter

Acquisition Control

acquisition modes

ACT LED

Adjusting the Black Level

Adjusting the Gain

Adjusting the White Balance

ALC

Automatic Level Control Function

black level

Camera locking screw holes

C-mount

Configuring Exposure

Connecting Devices

Counter and Timer Control Function

JAI Camera Control Tool

JAI SDK

LAN cable

LED

Lens

Lens mount

LINK LED

Lookup Table

LUT

Multi ROI

Network card

Optional accessories (not supplied)

Output format

Verifying the Camera’s Network

Connection Status

Video Process Bypass Mode

white balance

DC IN

DC IN / trigger IN connector

Digital Input/Output Settings

Dimensions

Event Control

exposure

Exposure Mode

External Trigger Settings

factory default settings

Feature Properties

Frame Rate

Frame Rate Reference

Gain Auto

Gain Control

Gain Level

Gamma Function

GPIO

Initial Settings for the Camera

Installing the Software

Parts Identification

Power/trigger LED

Regional Scanning Function

RJ-45 connector

ROI

Saving the Settings

Settings

Settings List

Shading Correction

software

Specifications

Spectral Response

Trigger Control

trigger IN

Trigger Selector

Troubleshooting

28 55

Updates

— 61 —

IAI GO-2401M-PGE, GO-2401C-PGE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Notice

Warranty

Certifications

Warning

Usage Precautions

Features

Parts Identification

Preparation

Preparation Process

Step 1: Installing the Software (first time only)

Step 2: Connecting Devices

Step 3: Verifying the Camera’s Network Connection Status

Step 4: Configuring Initial Settings for the Camera

Connecting to the Camera to Control Tool

Configuring the Output Format

Configuring Exposure and External T rigger Settings

Control via External Triggers

When Controlling the Exposure Time Using Specified Exposure Times

When Controlling the Exposure Time using the Pulse Width of the Trigger Input Signal

Control Without External Triggers

When Controlling the Exposure Time Using Specified Exposure Times

When not Controlling the Exposure Time

Step 5: Adjusting the Image Quality

Adjusting the Gain

Adjusting the White Balance (GO-2401C-PGE only)

Adjusting the Black Level

Step 6: Configuring Various Other Settings

Step 7: Saving the Settings

Basic Function Matrix

Main Functions

GPIO (Digital Input/Output Settings)

Valid Input/Output Combinations

Acquisition Control (Image Acquisition Controls)

Changing the Frame Rate

Maximum Frame Rate

Exposure Mode

Trigger Control

Shortest Repetition Period for Triggers

Event Control

Gain Control

LUT (Lookup T able)

Gamma Function

Line Status

Shading Correction

Binning Function

ROI (Regional Scanning Function)

ROI Settings

Video Send Mode

Video Send Mode

ALC (Automatic Level Control) Function

Detailed Settings for Gain Auto (Automatic Gain Level Control)

Counter and Timer Control Function (counter support only)

Video Process Bypass Mode

Settings List

Feature Properties

Settings

Miscellaneous

Updates

Troubleshooting

Specifications

Frame Rate Reference

Spectral Response

Dimensions

User’s Record

Index
