IAI AT-200GE User Manual

Download

1014E-1101

AT-200GE

Digital 3CCD Progressive Scan

RGB Color Camera

Document Version:1.5

AT-200GE_Ver.1.5_Jan2015

User Manual

AT-200GE

- 1 -

Notice

The material contained in this manual consists of information that is proprietary to JAI Ltd.,

Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein. JAI Ltd., Japan reserves the right to make changes without notice.

Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners.

Warranty

For information about the warranty, please contact your factory representative.

Certifications

CE compliance

As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC (Electromagnetic compatibility), JAI Ltd., Japan declares that AT-200GE complies with the following provisions applying to its standards. EN 61000-6-3 (Generic emission standard part 1) EN 61000-6-2 (immunity)

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning

Changes or modifications to this unit not expressly approved by the party responsible for FCC

compliance could void the user’s authority to operate the equipment.

AT-200GE

Supplement

The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。

方忖仝15々葎豚㍉15定。

AT-200GE

- 2 -

Table of Contents

JAI GigE® Vision Camera operation manuals ............................................. - 6 -

Introduction .................................................................................... - 6 -

Before using GigE Vision camera ........................................................... - 6 -

Software installation ......................................................................... - 6 -

Camera Operation ............................................................................ - 7 -

1. General ...................................................................................... - 7 -

2. Camera nomenclature ................................................................... - 7 -

3. Main Features .............................................................................. - 8 -

4. Locations and Functions ................................................................. - 9 -

4.1. Locations and functions .................................................................................... - 9 -

4.2. Rear panel indicator ...................................................................................... - 10 -

5. Pin Assignment ............................................................................ - 11 -

5.1. 12-pin Multi-connector (DC-IN/Digital IO) .............................................................. - 11 -

5.2. Digital Output Connector for Gigabit Ethernet ...................................................... - 11 -

5.3. D-Sub 9pin connector (For GPIO) ..................................................................... - 12 -

5.4. DIP switch .................................................................................................. - 12 -

5.4.1 SW-600 ................................................................................................. - 12 -

5.4.2 SW-100 ................................................................................................. - 13 -

5.4.3 SW-700 ................................................................................................. - 13 -

6. Input and output Interface ........................................................... - 14 -

6.1. Digital Interface ........................................................................................... - 14 -

6.1.1 LineSelector .......................................................................................... - 14 -

6.1.2 LineInverter ........................................................................................... - 14 -

6.1.3 LineStatus ............................................................................................. - 14 -

6.1.4 LineSource ............................................................................................ - 14 -

6.1.5 LineMode .............................................................................................. - 14 -

6.1.6 LineFormat ............................................................................................ - 14 -

6.2. Opto-isolated Interface .................................................................................. - 14 -

6.2.1 Recommended External Input circuit diagram for customer ................................. - 15 -

6.2.2 Recommended External Output circuit diagram for customer .............................. - 15 -

6.2.3 Optical Interface Specifications ................................................................... - 15 -

6.3. Iris video output ........................................................................................... - 16 -

6.4. Trigger input ............................................................................................... - 16 -

6.5. Exposure Active output .................................................................................. - 17 -

7. Video signal output ..................................................................... - 18 -

7.1. Video output image ....................................................................................... - 18 -

7.2. AOI (Area of Interest) .................................................................................... - 19 -

7.2.1 AOI setting ........................................................................................... - 19 -

7.2.2 AOI setting in the AT-200GE ...................................................................... - 19 -

7.2.2.1 When only image part is transmitted (OB is not transferred) .......................... - 19 -

7.2.2.2 When the image including the vertical OB is transmitted ............................... - 19 -

7.2.2. When the image including horizontal OB is transmitted .................................... - 20 -

7.3. In case of vertical binning and horizontal binning .................................................. - 20 -

7.4. Digital video output (Bit allocation) ................................................................... - 20 -

7.5. Pixel format and pixel type ............................................................................. - 21 -

7.5.1 GVSP_PIX_RGB8_PACKED (RGB 24bit output) ................................................... - 21 -

7.5.2 GVSP_PIX_RGB10V1_PACKED (RGB 30bit output) .............................................. - 21 -

7.5.3 GVSP_PIX_RGB10V2_PACKED (RGB 30bit output) .............................................. - 21 -

7.6. Auto iris video output level ............................................................................. - 21 -

7.7. Video output timing ...................................................................................... - 22 -

7.7.1 Binning Vertical = 1 (OFF) .......................................................................... - 22 -

7.7.1.1 1 frame period .................................................................................. - 22 -

7.7.1.2 Horizontal period (In case of Normal mode, Full frame or AOI) ....................... - 23 -

AT-200GE

- 3 -

7.7.2 Binning Vertical =2 (ON) ............................................................................ - 24 -

7.2.2.1 Vertical period .................................................................................. - 24 -

7.7.2.2 Horizontal period .............................................................................. - 24 -

7.8. The calculation of AOI size and frame rate .......................................................... - 25 -

7.9. The relationship between LinePitch and Width ..................................................... - 25 -

7.10. The relationship between PxelSIze and PixelFormat.............................................. - 26 -

7.11. The relationship between Binning Horizontal and Width/LinePitch............................ - 26 -

7.12. The relationship between Binning Vertical and Height ........................................... - 26 -

8. Network configuration ................................................................. - 27 -

8.1. GigEVision Standard interface .......................................................................... - 27 -

8.2. Equipment to configure the network system ........................................................ - 27 -

8.2.1 PC ....................................................................................................... - 27 -

8.2.2 Cables .................................................................................................. - 27 -

8.2.3 Network card (NIC) .................................................................................. - 27 -

8.2.4 Hub ..................................................................................................... - 28 -

8.3. Recommended Network Configurations ............................................................... - 28 -

8.3.1 Guideline for network settings ................................................................... - 28 -

8.3.2 Video data rate (network bandwidth) ............................................................ - 29 -

8.3.3 Note for setting packet size ....................................................................... - 29 -

8.2.4 Calculation of Data Transfer Rate ................................................................ - 29 -

8.3.5 Simplified calculation (Approximate value) ..................................................... - 30 -

8.3.6 Note for 100BASE-TX connection .................................................................. - 30 -

8.4. GigE camera connecting examples..................................................................... - 31 -

8.4.1 Using a switching hub for 1 port .................................................................. - 31 -

8.4.2 Connecting a camera to each port of a multi-port NIC ....................................... - 31 -

8.4.3 The data transfer for multiple cameras ......................................................... - 32 -

8.4.3.1 If delayed readout is not used in continuous mode ...................................... - 32 -

8.4.3.2 If delayed readout is not used in trigger mode............................................ - 32 -

8.4.3.3 If delayed readout is used .................................................................... - 33 -

9. Core functions ............................................................................ - 34 -

9.1. Acquisition function ...................................................................................... - 34 -

9.1.2 Acquisition mode ..................................................................................... - 35 -

9.1.2.1 Single Frame ..................................................................................... - 35 -

9.1.2.2 MultiFrame ....................................................................................... - 36 -

9.1.2.3 Continuous mode ............................................................................... - 37 -

9.1.3 AcquisitionAbort ................................................................................... - 38 -

9.1.4 AcquisitionFrameCount .......................................................................... - 38 -

9.1.5 AcquisitionFrameRate ............................................................................ - 38 -

9.1.5.1 Setting the free running mode (Trigger OFF) .............................................. - 39 -

9.1.5.2 The calculation of the frame rate for the setting area .................................. - 39 -

9.1.6 AcquisitionStatus .................................................................................. - 39 -

9.2. Trigger Control ............................................................................................ - 41 -

9.2.1 TriggerSelector(TriggerMode) ..................................................................... - 41 -

9.2.1.1 Acquisition ....................................................................................... - 41 -

9.2.1.2 Exposure .......................................................................................... - 42 -

9.2.2 Memory readout control ............................................................................ - 43 -

9.2.3 Triggersoftware ...................................................................................... - 43 -

9.2.4 Triggersource ......................................................................................... - 43 -

9.2.5 TriggerActivation .................................................................................... - 44 -

9.2.6 Triggeroverlap ........................................................................................ - 44 -

9.2.7 Triggerdelay .......................................................................................... - 44 -

9.3. Exposure Control .......................................................................................... - 44 -

9.3.1 Exposure Mode ....................................................................................... - 44 -

9.3.2 ExposureTime ......................................................................................... - 45 -

9.3.3 ExposureAuto ......................................................................................... - 46 -

9.4. UserOutputSelector ....................................................................................... - 46 -

AT-200GE

- 4 -

9.5. Counter function .......................................................................................... - 46 -

9.5.1 CounterSelector ...................................................................................... - 46 -

9.5.2 CounterEventSource ................................................................................. - 46 -

9.5.3 CounterEventActivation ............................................................................ - 46 -

9.5.4 CounterResetSource ................................................................................. - 47 -

9.5.5 CounterResetActivation............................................................................. - 47 -

9.5.6 CounterValue ......................................................................................... - 47 -

9.5.7 CounterValueAtReset................................................................................ - 47 -

9.5.8 CounterDuration ..................................................................................... - 47 -

9.5.9 CounterStatus ........................................................................................ - 47 -

9.5.10 CounterTriggerSource .............................................................................. - 48 -

9.5.11 CounterTriggerActivation .......................................................................... - 48 -

9.6. Timer Control .............................................................................................. - 49 -

9.6.1 TimerSelector ........................................................................................ - 49 -

9.6.2 TimerDuration ........................................................................................ - 49 -

9.6.3 TimerDelay ............................................................................................ - 49 -

9.6.4 TimerValue ............................................................................................ - 49 -

9.6.5 TimerStatus ........................................................................................... - 49 -

9.6.6 TimerTriggerSource ................................................................................. - 49 -

9.6.7 TimerTriggerActivation ............................................................................. - 50 -

9.7. Event Control .............................................................................................. - 50 -

9.7.1 EventSelector ......................................................................................... - 50 -

9.8. Video Send Mode .......................................................................................... - 50 -

9.9. ActionControl .............................................................................................. - 50 -

10. Operation modes ...................................................................... - 51 -

10.1. Continuous mode (Free run) ........................................................................... - 51 -

10.2. Trigger operation with “timed” exposure (Previously called EPS) ............................. - 51 -

10.3. Trigger operation by “TriggerWidth” (Previously called PWC) ................................. - 52 -

10.4. Trigger operation by TriggerControlled ............................................................. - 53 -

10.5. Trigger input and exposure start timing............................................................. - 54 -

10.5.1 Synchronous reset timing ......................................................................... - 54 -

10.5.1.1 In the case of Expsoure mode = Timed, Trigger = ON (Full frame)................... - 54 -

10.5.1.2 In the case of Expsoure mode = Trigger width, Trigger = ON (Full frame) .......... - 55 -

10.5.2 Asynchronous reset timing ........................................................................ - 55 -

10.5.2.1 In the case of Expsoure mode = Timed, Trigger = ON (Full frame)................... - 55 -

10.5.2.2 In the case of Expsoure mode = Trigger width, Trigger = ON (Full frame) .......... - 55 -

10.6. Sequence Trigger Mode ................................................................................. - 56 -

10.7. Multi ROI Mode ........................................................................................... - 57 -

10.8. Delayed Readout Mode (JAI Custom Control)....................................................... - 58 -

9.9. Mode and function matrix table ....................................................................... - 58 -

11. Image processing ...................................................................... - 59 -

11.1. Basic construction ....................................................................................... - 59 -

11.2. Shading compensation .................................................................................. - 59 -

11.3. Auto White balance ..................................................................................... - 60 -

11.4. Gain ........................................................................................................ - 61 -

11.4.1 GainAuto ............................................................................................. - 61 -

11.5. BlackLevel ................................................................................................ - 61 -

11.6. Linear matrix ............................................................................................. - 61 -

11.7. LUT (Look Up Table) and gamma ..................................................................... - 62 -

11.8. Test pattern generator ................................................................................. - 62 -

12. Examples of operation using JAI Control Tool ................................... - 63 -

12.1. About GenICamTM SFNC1.3 ............................................................................. - 63 -

12.2. JAI SDK Ver.1.3 .......................................................................................... - 63 -

12.3. Examples of camera operation ........................................................................ - 64 -

12.3.1 Operational cautions ............................................................................... - 64 -

12.3.2 Connecting camera(s) ............................................................................. - 64 -

AT-200GE

- 5 -

12.4. Input and output settings .............................................................................. - 66 -

12.4.1. Connection with the external devices ......................................................... - 66 -

12.4.2. Setting inputs and outputs ....................................................................... - 66 -

12.4.2.1 Select signal to connect with Line which is selected by Line selector .............. - 66 -

12.4.2.2 Select Trigger Source ......................................................................... - 67 -

12.4.3. Specify the image size to be captured ........................................................ - 67 -

12.4.4. Acquisition of the image ......................................................................... - 69 -

12.4.4.1 Basic settings .................................................................................. - 70 -

12.4.5. Setting examples .................................................................................. - 72 -

12.4.5.1 Capture the image continuously with fastest frame rate .............................. - 72 -

12.4.5.2 Capture the image with a half of the frame rate (increasing the sensitivity) ..... - 72 -

12.4.5.3 Capture one frame of the image with preset exposure time using the external .. - 72 -

trigger ........................................................................................................ - 72 -

12.4.5.4 Capture multi frames of the image with preset exposure time using the external

trigger ........................................................................................................ - 73 -

12.4.5.5 Capture one frame of the image with the trigger width using the external trigger - 73

12.4.5.6 Capture multi frames of the image with the trigger width using..................... - 74 -

12.4.5.7 Capture the image continuously with preset exposure time by using the external

trigger ........................................................................................................ - 74 -

12.4.5.8 Capture the image by Exposure Start trigger and stop by Exposure End. ........... - 75 -

12.4.5.9 Capture the image using Software Trigger ............................................... - 76 -

12.4.5.10 Sequence Trigger setting ................................................................... - 77 -

12.4.5.11 Multi ROI setting ............................................................................. - 77 -

12.4.5.12 Delayed readout setting .................................................................... - 78 -

12.4.5.13 Operate the external strobe light ........................................................ - 78 -

12.4.5.14 Achieve white balance using individual exposure time for R,G,B ................... - 79 -

12.4.6 How to view the XML file ......................................................................... - 79 -

13. External Appearance and Dimensions ............................................ - 80 -

14. Specifications ............................................................................ - 81 -

14.1. Camera sensitivity response ........................................................................... - 81 -

14.2. Specification table ...................................................................................... - 82 -

Appendix ...................................................................................... - 84 -

1. Precautions ................................................................................................... - 84 -

2. Typical Sensor Characteristics ............................................................................ - 84 -

3. Caution when mounting a lens on the camera ......................................................... - 84 -

4. Caution when mounting the camera ..................................................................... - 85 -

5. Exportation ................................................................................................... - 85 -

6. References .................................................................................................... - 85 -

Change history ............................................................................... - 86 -

User's Record ................................................................................. - 87 -

AT-200GE

- 6 -

JAI GigE® Vision Camera operation manuals

To understand and operate this JAI GigE® Vision camera properly, JAI provides the following manuals.

User’s manual (this booklet) Describes functions and operation of the hardware JAI SDK & Control Tool User Guide Describes functions and operation of the Control Tool JAI SDK Getting Started Guide Describes the network interface

User’s manual is available at www.jai.com JAI SDK & Control Tool User Guide and JAI SDK Getting Started Guide are provided with the JAI SDK which is available at www.jai.com.

Introduction

GigE Vision is the new standard interface using Gigabit Ethernet for machine vision applications and it was mainly set up by AIA (Automated Imaging Association) members. GigE Vision is capable of transmitting large amounts of uncompressed image data through an inexpensive general purpose LAN cable for a long distance.

GigE Vision also supports the GenICamTM standard which is mainly set up by the EMVA (European Machine Vision Association). The purpose of the GenICam standard is to provide a common program interface for various machine vision cameras. By using GenICam, cameras from different manufactures can seamlessly connect in one platform.

For details about the GigE Vision standard, please visit the AIA web site,

www.machinevisiononline.org and for GenICam, the EMVA web site, www.genicam.org.

JAI GigE Vision cameras comply with both the GigE Vision standard and the GenICam standard.

Before using GigE Vision camera

All software products described in this manual pertain to the proper use of JAI GigE Vision cameras. Product names mentioned in this manual are used only for the explanation of operation. Registered trademarks or trademarks belong to their manufacturers. To use the JAI SDK, it is necessary to accept the “Software license agreement” first.

Software installation

The JAI GigE Vision SDK & Control Tool can be downloaded from the JAI web site at

www.jai.com. The JAI SDK is available for Windows XP and Vista, 32-bit and 64-bit.

For the details of software installation, please refer to the “Getting Started Guide” supplied

on the JAI SDK download page.

AT-200GE

- 7 -

Camera Operation

1. General

The AT-200GE complies with GenICam Standard Features Naming Conversion (SFNC) ver.1.3 and functions described in this booklet are described based on this standard. The AT-200GE is a digital 3CCD progressive scan RGB color camera. It employs three 1/1.8inch 1624 (h) x 1236 (v), 2 Megapixel CCDs and runs at 15.45 frames per second in full resolution mode. The AT-200GE has a GigE Vision interface and its output can be either 24-bit or 32-bit RGB. JAI developed a new 1/1.8-inch compact F4.0 prism optical system and in combination with a linear color matrix, the AT-200GE provides a higher fidelity of color reproduction. The AT-200GE also incorporates a dynamic shading circuit, gamma correction circuit and knee correction circuit to provide high picture quality. Functions like AOI and vertical binning allow higher frame rates.

The latest version of this manual can be downloaded from: www.jai.com The latest version of the JAI GigE Vision SDK & Control Tool for the AT-200GE can be downloaded from: www.jai.com

For camera revision history, please contact your local JAI distributor.

2. Camera nomenclature

The standard camera composition consists of the camera main body and C-mount protection cap.

The camera is available in the following versions:

AT-200GE

Where A stands for "Advanced" family, T stands for "3 CCD", 200 represents the resolution "2 million pixels" , and GE stands for "GigE Vision " interface.

AT-200GE

- 8 -

3. Main Features

 3 x 1/1.8" CCD progressive scan RGB color camera for vision applications  3 x 1624(h) x 1236 (v) 4.4m effective square pixels  Compact RGB prism for C-mount lenses  Shading reduction permits wider choice of lenses  Maximum 15.45 frames per second with 1624 (h) x 1236 (v) pixels  Maximum 123.56 fps with 1624 (h) x 8 (v) pixels in AOI mode  Vertical binning for higher sensitivity and frame rate of 27.68 fps  Horizontal binning is also available for increasing sensitivity (frame rate is not

changed)

 24-bit RGB output or 30-bit RGB output (RGB 8, RGB 10V1 or RGB 10V2 pixel format)  Gamma can be set from 1.0(OFF) to 0.45 and LUT is also available (selectable)  Linear matrix circuit with sRGB or Adobe RGB pre-setting

 Shading compensation circuit for color shading and flat field shading built in  Acquisition control includes single frame, multi frame and continuous  Exposure mode includes Off, timed, trigger width and trigger controlled  Trigger control includes frame start, exposure start and exposure end.  Combination of Acquisition Control, Exposure Mode and Trigger Control make

various image capture operation

 Manual, continuous, or one push white balance  Analog iris video output for lens iris control  LVAL synchronous/asynchronous operation (Trigger Overlap function)  Comprehensive software tools and SDK for Windows XP/Vista/7 (32 bit “x86” and 64

bit “x64” JAI SDK Ver. 1.3.0 and after )

AT-200GE

- 9 -

4. Locations and Functions

4.1. Locations and functions

1. Lens mount Lens mount of C-mount type. *1)

2. CCD sensor 1/1.8 inch CCD

3. RJ-45 connector GigE Vision interface with thumb screws

4. 12-pin connector DC+12V, Trigger IN and EEN out

5. D-sub 9-pin connector LVDS IN and TTL IN and OUT

6. LED Power and trigger indications

7. LINK Indication for Network connection

8. ACT Indication for GigE communication

9. Holes for RJ-45 thumbscrews Vertical type and horizontal type (*2)

10. Mounting holes M3, max length 5mm (*3)

*1) Note: Applicable C-mount lens should be designed for 3-CCD cameras. Rear protrusion on

C-mount lens must be less than 4mm.

Be advised: when using a lens with the iris diaphragm fully open, vignetting on corners

may occur.

*2) Note: When an RJ-45 cable with thumb screws is connected to the camera, please do not

excessively tighten screws by using a driver. The RJ-45 receptacle on the camera might be damaged. For security, the strength to tighten screws is less than 0.147 Newton meter (Nm). Tightening by hand is sufficient in order to achieve this.

*3) Note: The tripod adapter plate MP-41 can be used.

Fig. 1. Locations

AT-200GE

- 10 -

4.2. Rear panel indicator

The rear panel mounted LED provides the following information:

 Amber : Power connected - initiating

 Steady green : Camera is operating in Continuous mode  Flashing green : The camera is receiving external trigger

Ethernet connector indicates,

 Steady green : 1000 Base-T has been connected  Flashing green : 100 Base-TX has been connected (Note)

 Flashing amber : Network active in communication

Note: When 10BASE-T is connected, the green is also flashing.

However, the video is not streamed through Ethernet.

Fig.2 Rear Panel

AT-200GE

- 11 -

5. Pin Assignment

5.1. 12-pin Multi-connector (DC-IN/Digital IO)

Type: HR10A-10R-12PB-01 (Hirose) male. (Seen from rear of camera.)

Fig. 3. 12-pin connector. *1) Default is Opt In 2.DIP switch SW700 changes to

iris video output.

5.2. Digital Output Connector for Gigabit Ethernet

Type: RJ-45 HFJ11-1G02E-L21RL or equivalent

The AT-200GE cameras also accept industrial RJ-45 connectors with thumbscrews. This assures that the connector does not come undone in tough industrial environments. Please contact the nearest JAI distributor for details on recommended industrial RJ-45 connectors.

Fig. 4. Gigabit Ethernet connector

The digital output signals follow the Gigabit Ethernet interface using RJ-45 conforming connector. The following is the pin assignment for the Gigabit Ethernet connector.

Pin No

In/Out

Name

In/Out

MX1+ (DA+)

In/Out

MX1- (DA-)

In/Out

MX2+ (DB+)

In/Out

MX3+ (DC+)

In/Out

MX3- (DC-)

In/Out

MX2- (DB-)

In/Out

MX4+ (DD+)

In/Out

MX4- (DD-)

Pin no.

Signal

Remarks

GND

DC input

+12V to +24V

Opt In 2(-) / GND (*1)

Line 6

Opt In 2 (+) / Iris video(*1)

Opt In 1 (-)

Line 5

Opt In 1 (+)

Opt Out 1 (-)-

Line 3

Opt Out 1 (+)

Opt Out 2 (-)

Line 4

Opt Out 2 (+)

DC input

+12V to +24V

GND

AT-200GE

- 12 -

5.3. D-Sub 9pin connector (For GPIO)

Type : DD-09SSG

Fig. 5．D Sub 9pin connector

I/O

Name

Note

1 I LVDS In 1-

Line 8

2 I LVDS In 1+

3 I TTL IN 1

Line 7 75ohm Terminator (Note 1)

4 O TTL Out 1

Line 1

5 GND 6 NC 7 NC

8 O TTL OUT 2

Line 2

9 GND

Note1) Can be changed by DIP switch (SW600).

5.4. DIP switch

DIP switches are located on circuit boards. When the top cover is removed, please pay careful attention so that circuit boards may not be damaged.

5.4.1 SW-600

This switch sets the 75 ohm trigger input termination to ON or OFF. The factory default setting is OFF which is TTL level.

Functions

Setting

OFF

Trigger input termination

75Ω

TTL

Fig.6. SW600 (On rear panel)

SW600

Right side for 75 ohms termination

AT-200GE

- 13 -

5.4.2 SW-100

This switch selects ExposreActive signal. The factory default setting is TTL signal and it can be changed to the open collector signal.

Function

Setting

OFF

Exposure Active output select

Open Collector signal

TTL signal

NC - -

Fig.7 SW100 (the right board as looking from the lens side)

5.4.3 SW-700

This DIP switch can select OPT IN or Iris video output through pin#3 and #4 of the

HIROSE 12 pin connector.

The default setting is OPT IN.

Functions

Setting

OFF

OPT IN(+) / Iris video OUT select

Iris video

OPT IN (+)

OPT IN(-) / Iris video OUT select

GND for iris video

OPT IN (-)

Fig.8 SW700 (On the top board)

AT-200GE

- 14 -

6. Input and output Interface

6.1. Digital Interface

In the AT-200GE, the input and output interface for Hirose 12P and D-Sub 9P are

configured as the following.

6.1.1 LineSelector

The following input and output signal are configured on Line 1 through Line 8.

① Line 1(TTL out1) ② Line 2(TTL out2) ③ Line 3(Opt out1) ④ Line 4(Opt out2) ⑤ Line 5(Opt in1) ⑥ Line 6(Opt in2) ⑦ Line 7(TTL in1) ⑧ Line 8(LVDS in)

6.1.2 LineInverter

This function changes the polarity of the signal.

6.1.3 LineStatus

The customer can notify the status of input and output signals.

6.1.4 LineSource

The signal source to output through Line1 to Line4 is selected from the following

fivesignals.

① AcquisitionTriggerWait ② AcquisitionActive ③ FrameTriggerWait ④ FrameActive ⑤ ExposureActive

6.1.5 LineMode

The current status of inputs and outputs is displayed.

6.1.6 LineFormat

The interface of input and output circuits is displayed.

6.2. Opto-isolated Interface

The control interface of the C3 GigE Vision camera series has opto-isolated inputs and outputs,providing galvanic separation between the camera's inputs/outputs and peripheral equipment. In addition to galvanic separation, the opto-isolated inputs and outputs can cope with a wide range of voltages; the voltage

range for inputs is +3.3V to +24V DC whereas Fig.9 Opto-coupler

outputs will handle +5V to +24V DC.

The figure below shows the functional principle (opto-coupler) of the opto-isolated inputs/outputs.

AT-200GE

- 15 -

6.2.1 Recommended External Input circuit diagram for customer

Fig.10 External Input Circuit, OPT IN 1 and 2

6.2.2 Recommended External Output circuit diagram for customer

Fig.11 External Output Circuit, OPT OUT 1 and 2

6.2.3 Optical Interface Specifications

The relation of the input signal and the output signal through the optical interface is as follows.

AT-200GE

- 16 -

User Power (VCC)

3.3V

1/1.8V

24V

Time Delay Rising TDR(µs)

0.54

0.62

0.68

Rising Time RT(µs)

1.2

2.0

3.0

Falling Delay Time FDR(µs)

1.5

2.4

2.1

Falling Time FT(µs)

3.6

3.4

4.5

6.8

Fig.12 Optical Interface Performance

6.3. Iris video output

This signal can be used for lens iris control In self running mode. The signal is NUM luminance signal and passes through the gain circuit. However, due to reversed compensation applied, the gain settings do not influence this signal. The iris video output is 0.7 V p-p from 75  and without sync.

Fig. 13 Iris video output.

6.4. Trigger input

The trigger input is on Opt in pins #4 or #6 on the 12-pin connector(see section 6.2 for voltages and schematic) or pin#3 on the Dsub 9-pin connector. As shown in the diagram to the right, the input on the 9-pin connector is AC coupled. To allow a long pulse width, the input circuit is a flip-flop, which is toggled by the negative or positive differentiated spikes caused by the falling or rising trigger edges. The trigger polarity can be changed. Trigger input level is 4 V 2 V. It can be terminated by SW600: ON for 75. OFF for TTL(Factory default). Fig.14 9-pin trigger input.

DAC

Iris Video

2K2

１μ

0.1μ

+5V

●

SW600

TTL

100K

0.001μ

0.1μ

１K2

15K

39K

D-Sub 9P #3

AT-200GE

- 17 -

6.5. Exposure Active output

Exposure Active signal (positive) is found on Opt-out on Hirose 12P (see section 6.2) or TTL out on D-sub 9-pin connector. The output circuit on the 9-pin (right) is 75  complementary emitter followers. Output level 3 V from 75. (No termination). It can be changed to the open collector signal. When the open collector is used, the maximum current is 1/1.80mA. However, if a current of more than 50mA is flowed, it is necessary to use bigger diameter wires for connecting pin#8 and 9. In case of narrower wires, due to its resistance, it may not work properly. This output can be changed to Open collector signal by SW100. Fig.15 ExposureActive TTL output

+５Ｖ

１Ｋ

０．１

１０Ｋ

１０

２２０

EEN

D-SUB

１２０

１５０

Open

Collector

Push

Pull

１０Ｋ

１Ｋ

180

●

SW100

AT-200GE

- 18 -

7. Video signal output

7.1. Video output image

Note: The following OB area can be transferred.

For vertical : 4 pixels in *1 For horizontal : 16 pixels in *2

Fig.16 CCD sensor layout

OB (Optical Black) (High Speed dump by 2 lines)

OB (Optical Black) (High Speed dump by 6 lines)

OB (Optical Black)

Ｒｅａｄ　ｏｕｔ

(Vertical)

Read out (Horizontal)

1243

1926 clock

1624 32

238

blank

1248

1236

１

1688

Active Pixelｓ

1624（Ｈ）　ｘ　1236（Ｖ）

blank

* 2

* 1

AT-200GE

- 19 -

7.2. AOI (Area of Interest)

In the AT-200GE, the output image size can be determined by setting the output area.

7.2.1 AOI setting

In order to set the output area, 4 parameters including OffsetY, OffsetX, Width and

Height should be determined.

Fig.17 AOI setting

7.2.2 AOI setting in the AT-200GE

In the AT-200GE, the area including OB is defined as the maximum width and

maximum height as considering transferring OB parts.

Fig.18 OB transfer

7.2.2.1 When only image part is transmitted (OB is not transferred)

Offset X=0 Offset Y=4 Width =1624 Height = Effective lines

7.2.2.2 When the image including the vertical OB is transmitted

Offset X=0 Offset Y=0 Width =1624

Height = Effective lines ＋4

WidthMax

HeightMax

OffsetY

OffsetX

Width

Height

(0,0)

OB 4 lines

OB 16 pixels

(0,0)

(0,1240) (1640,1240)

(0,4)

(1624,1240)

AT-200GE

- 20 -

7.2.2. When the image including horizontal OB is transmitted

Offset X=0 Offset Y=4 Width =1640 Height = Effective lines

Note: When the horizontal OB is transferred, the width must be set its maximum.

7.3. In case of vertical binning and horizontal binning

Fig.19 Vertical binning

Fig.20 Horizontal binning

7.4. Digital video output (Bit allocation)

Although the AT-200GE is a digital camera, the image is generated by an analog component, the CCD sensor. The table and diagram below show the relationship between the analog CCD output level and the digital output.

CCD out

Analog Signal *

Digital Out(24-

bit)

Digital Out(32-bit)

Black

Setup 3.6%,

25mV

8LSB

32LSB

200mV

700mV

222LSB

890LSB

230mV

800mV

255LSB

1023LSB

The standard setting for 10-bit video level is 890 LSB. 200 mV CCD output level equals 100% video output.

Fig.21 Digital output (10-bit output)

Analog Signal [mV]

Black Level

1023

890

700

Digital Out [LSB]

White Clip Level

100% Level

800

(0,0)

(0.622)

(1640,622)

OB 2 lines

OB 16 pixels

(0,4)

(1624,622)

(0,0)

(0,1240)

OB 4 lines)

OB 8 pixels

(820, 0)

(820, 1240)

(0, 4)

(812, 1240)

AT-200GE

- 21 -

7.5. Pixel format and pixel type

In the GigE Vision Interface, GVSP (GigE Vision Streaming Protocol) is used for an application layer protocol relying on the UDP transport layer protocol. It allows an application to receive image data, image information and other information from a device. As for the sensors in the AT-200GE, the following pixel types supported by GVSP are available. With regard to the details of GVSP, please refer to the GigE Vision Specification available from the AIA (www.machinevisiononline.org).

7.5.1 GVSP_PIX_RGB8_PACKED (RGB 24bit output)

1 Byte 2 Byte 3 Byte 4 Byte

0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

R0G0B0

7.5.2 GVSP_PIX_RGB10V1_PACKED (RGB 30bit output)

1 Byte 2 Byte 3 Byte 4 Byte

0 1 0 1 0 1 X X 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

B0G0R0

7.5.3 GVSP_PIX_RGB10V2_PACKED (RGB 30bit output)

1 Byte 2 Byte 3 Byte 4 Byte

0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 X X

7.6. Auto iris video output level

This video output signal is NUM luminance signal and does not have SYNC. It is available only in Self running operation. It is also not available in the AOI operation. This signal is not affected by the gain control.

CCD out

Analog Out

200mV

700mV

230mV↑

800mV

Fig.22 Iris video output

100% Level700

200

Analog Out [mV]

CCD Out [mV]

265

930

AT-200GE

- 22 -

7.7. Video output timing

7.7.1 Binning Vertical = 1 (OFF)

7.7.1.1 1 frame period

*1) int_FVAL is “High” in the period of effective lines and OB. *2) int_LVAL is always output. *3) int_DVAL is output in the period of effective lines *4) This timing chart explains the camera operating timing and the output is

converted in the GigE vision interface. The transferred image is 1236 lines of effective lines. When OB is transferred, OB parts is also included.

Fig.23 Vertical timing

2 3 45

Effective Lines

DV AL

S UB

S G E x po s ur e

P e r i o d

i n t _ FV AL

i n t _ LV AL

F r a me Ac t i v e

E x po s ur e A c t i v e

FVAL

VAL

1 FVAL per i od

0 .5L

DA TA OUT

1236 L

1248 L

1L = 1926 Cl ock ( 51. 88us )

Blank

124 3L

Reserved 2L

1236

Reserved 1L

Reserved 2L

AT-200GE

- 23 -

7.7.1.2 Horizontal period (In case of Normal mode, Full frame or AOI)

*1) 1 clock is 1 pixel clock and OB is optical black period *2) int_LVAL is “High” in the period of effective pixels and OB. *3) This timing chart explains the camera operating timing and the output is

converted in the GigE vision interface. The transferred image is 1236 lines of effective lines. When OB is transferred, OB parts is also included.

Fig.24 Horizontal timing

1 LVAL per i od

Du mmy+

Bl a nk

8 6

( 2 0u s )

OB R es er v ed

Re s er v ed

2 9c k

1 67

2 38 c k

1 68 8c k

1 92 6c k

1 c k = 3 7. 1 2 5MHz ( 26 . 94 ns / ck )

7 42 ck

8 28 ck

2 c k

1 62 4c k

2 c k

4 8c k

2 38 ck

1 62 4c k 1 68 8c k

1 2c k

8 6c k

1 54

1 78 1c k

int_LVAL

int_FVAL

SUB

Exposure

Period

Exposure

Active

DATA OUT

CCD OUT

Effective Pixels

FVAL rising edge

FVAL falling edge

AT-200GE

- 24 -

7.7.2 Binning Vertical =2 (ON)

In this mode, the vertical transfer and the horizontal transfer functions are arranged

to add adjacent pixels in vertical direction and to output as one pixel. This results in reducing the vertical resolution to 618 lines but the frame rate can be increased.

7.2.2.1 Vertical period

Fig.25 Vertical timing in Binning Vertical ON

7.7.2.2 Horizontal period

Fig.26 Horizontal timing in Binning Vertical ON

2 3 4 5

Effective Lines

S U B

S G

E x p o s u r e

P e r i o d

i n t _ F V A L

i n t _ L V A L

F r a m e A c t i v e

E x p o s u r e A c t i v e

FV AL

LV AL

1 FV AL pe rio d

0 .5L

Bl ank

D A T A O U T

1L = 21 36 Clo ck (57 .5 4us )

628L

624L

618L

i n t _ D V A L

Reserved 2L

618

Reserved 2L

Reserved 1L

( 3 0 u s )

8 6

8 6 c k

D u m m y +

B l a n kR e s e r v e d

9 2 7

1 0 1 3

O B

2 9 c k

9 2

1 6 8 8

2 0 4 8

1 2 c k

O B

2 c k

R e s e r v e d

2 c k

4 8 c k

2 9 c k

1 6 8 8

1 6 2 4

5 0 c k

1 4 c k

1 c k = 37 . 1 2 5 M H z ( 2 6 . 9 4 n s / c k )

2 1 3 6

4 4 8

6 3 9

2 7 0

1 LVAL period

FVAL rising edge

FVAL falling edge

Effective pixels

int_LVAL

int_FVAL

SUB

Exposure

Period

Exposure

Active

DATA OUT

int_DVAL

CCD OUT

AT-200GE

- 25 -

7.8. The calculation of AOI size and frame rate

The frame rate in the AOI setting is calculated by the following formula.

Frame rate (fps) = Horizontal frequency(19.27KHz) / Total lines

Total lines =  OB period +  Transition period before start line(L) +

 Effective image period (L) +  Transition period after end line(L) +  Blank period (L)

Where,

OB period = 4L (Fixed)

Blank period =5L (Fixed)

Transition period before start line =  󰇡





󰇢  

Transition period after end line =  󰇡





󰇢

Calculation example Readout: 1/2 partial scan at the center (618L), Start line (310L), End line (927L)

OB period = 4L Blank period =5L Transition period before start line = (6+310-1) ÷9 +1= 35 + 1=36  36

Transition period after end line = (1236-927+2) ÷ 9 =34.6  35 Total lines = 4+36+618+35 +5 = 698 Frame rate = 19.27/ 698 =27.6 fps

7.9. The relationship between LinePitch and Width

The setting range of LinePitch is changed when the output is set at 8-bit or 10-bit. LinePitch can be set as follows.

RGB8Packed ：24-4920 REB10V1Packed：32-6560 REB10V2Packed：32-6560

Note: The unit is byte.

If the minimum is 8 pixels and the output is RGB 8bit, 8 pixels x 3Byte =24Byte If the maximum is 1640 pixels and the output is RGB 8bit, 1640 pixels x 3Byte = 4224Byte.

As for LinePitch and Width, if one is changed, the other will also be changed. The relationship between LinPitch and width is;

RGB8Packed ：Linepitch/3 REB10V1Packed：Linepitch/4 REB10V2Packed：Linepitch/4

As the width is change, the output area will also be changed.

AT-200GE

- 26 -

Full Image Full Image Full Image LinePitch 4904 LinePitch 2452 LinePitch 2452 Offset x 348

7.10. The relationship between PxelSIze and PixelFormat

PixelSize and PixelFormat are interlocked for each setting. If PixelSize is Bpp24, PixelFormat is RGB8Packed If PixelSize is Bpp32, PixelFormat is RGB10V18Packed or RGB10V2Packed

This relationship works reversely too.

7.11. The relationship between Binning Horizontal and Width/LinePitch

If Binning Horizontal is set at 1(OFF) or 2(ON), Width/LinePitch is changed accordingly. Binning Horizontal = 1 Width is 1640 as the maximum Binning Horizontal = 2 Width is 820 as the maximum

Note: If Binning Horizontal is reset to 1 after setting to 2, the maximum value is not

changed. It is necessary to reset manually.

7.12. The relationship between Binning Vertical and Height

If Binning Vertical is set at 1(OFF) or 2(ON), Height is changed accordingly. Binning Vertical = 1 Height is 1240 as the maximum Binning Vertical = 2 Height is 622 as the maximum

Note: If Binning Vertical is reset to 1 after setting to 2, the maximum value is not

changed. It is necessary to reset manually.

AT-200GE

- 27 -

8. Network configuration

 For details of the network settings, please refer to the “Getting Started

Guide” supplied with the JAI SDK.

8.1. GigEVision Standard interface

The AT 20- 0GE is designed in accordance with the GigE Vision standard. Digital images are transmitted over Cat5e or Cat6 Ethernet cables. All camera functions are also controlled via the GigE Vision interface.

The camera can operate in Continuous mode, providing an endless stream of images. For capturing individual images related to a specific event, the camera can also be triggered. For precise triggering, it is recommended to use a hardware trigger applied to the Hirose 12-pin connector. It is also possible to initiate a software trigger through the GigE Vision interface. However, when using a software trigger, certain latency inherent to the GigE interface must be expected. This latency, which manifests itself as jitter, greatly depends on the general conditions and traffic on the GigE connection. The frame rate described in this manual is for the ideal case and may deteriorate depending on conditions.

When using multiple cameras (going through a switch and/or a single path) or when operating in a system with limited transmission bandwidth the Delayed Readout Mode and Inter-Packet Delay functions can be useful.

8.2. Equipment to configure the network system

8.2.1 PC

The PC used should have the following performance or better

1) Recommended CPU : Core2 Duo 2.4GHz or better, Better than Core2 Extream

2) Recommended memory : 2Gbyte or more

3) Video card : Better than PCI Express Bus Ver.1.0 x16

VRAM should be better than 256MByte, DDR2

4) Other : The resident software should not be used

8.2.2 Cables

GigEVision configures the system by using 1000BASE-T. (100BASE-T can be used with some restriction. Refer to chapter 8.3.5). In the market, CAT5e (125MHz), CAT6 (250MHz) and CAT7 (600MHz) cables are available for 1000BASE-T. There are crossover cables and straight through cables available. Currently, as most equipment complies with Auto MDI/MDI-X, please use straight through cables. (Among crossover cables, a half crossover type exists, which the Ethernet will recognize as 100BASE-T).

8.2.3 Network card (NIC)

The network card should comply with 1000BASE-T and also have the capability of JUMBO FRAMES. When the jumbo frame size is set at a larger number, the load on the CPU will be decreased. Additionally, as the overhead of the packet is decreased, the

transmission will have more redundancy.

JAI confirms the following network cards.

AT-200GE

- 28 -

NIC Manufacture

Type

PCI-X Bus

PCI-Express

Bus

Intel

PRO/1000MT Server Adapter





32bit or 64bit

33/66/100/133 MHz

Intel

PRO/1000MT Dual Port Server Adapter





32bit or 64bit

33/66/100/133 MHz

Intel

PRO/1000GT Quad Port Server Adapter





32bit or 64bit

66/100/133 MHz

Intel

PRO/1000PT Server Adapter

―

 ( x1 )

2.5Gbps uni-directional 5Gbps bi-directional

Intel

Pro/1000 CT Desktop adaptor

―

 ( x1 )

2.5Gbps uni-directional 5Gbps bi-directional

Intel

Gigabit ET2 Quad port Server Adapter

―

 ( x4 )

10Gbps uni-directional

20Gbps bi-directional

Intel

Gigabit ET Dual port Server Adapter

―

 ( x4 )

10Gbps uni-directional

20Gbps bi-directional

Intel

Gigabit EF Dual port Server Adapter

―

 ( x4 )

10Gbps uni-directional

20Gbps bi-directional

8.2.4 Hub

It is recommended to use the metal chassis type due to the shielding performance. As the hub has a delay in transmission, please note the latency of the unit.

8.3. Recommended Network Configurations

Although the AT-200GE conforms to Gigabit Ethernet (IEEE 802.3) not all combinations of network interface cards (NICs) and switches/routers are suitable for use with the GigE Vision compliant camera. JAI will endeavor to continuously verify these combinations, in order to give users the widest choice of GigE components for their system design.

 For details of the network settings, please refer to the “Getting Started

Guide” supplied with the JAI SDK.

8.3.1 Guideline for network settings

To ensure the integrity of packets transmitted from the camera, it is recommended to follow these simple guidelines:

1. Whenever possible use a peer-to-peer network.

2. When connecting several cameras going through a network switch, make sure it is

capable of handling jumbo packets and that it has sufficient memory capacity.

3. Configure inter-packet delay to avoid congestion in network switches.

4. Disable screen saver and power save functions on computers.

5. Use high performance computers with multi-CPU, hyper-thread and 64-bit CPU,

etc.

6. Only use Gigabit Ethernet equipment and components together with the camera.

7. Use at least Cat5e and preferably Cat6 Ethernet cables.

8. Whenever possible, limit the camera output to 8-bit.

AT-200GE

- 29 -

8.3.2 Video data rate (network bandwidth)

The video bit rate for the AT-200GE in Normal mode is:

Model

Pixel Type

Frame Rate

Packet data volume (assumes the packet size is 4036)

AT-200GE

RGB8Packed

15.45 fps

769 Mbit/s

RGB10V1Packed RGB10V2Packed

Approx.

14.5fps

966 Mbit/s

Note1: Depending on the packet size, the frame rate of 15.45 fps may not be achieved. This figure will depend of the system configuration used (RESEND not possible)

 If Jumbo Frames (Max.16020) are not used, the packet data will be bigger by 2%.  If Jumbo frames are used, the packet size may be automatically optimized to a

smaller size.

 For details of setting Jumbo Frames, please refer to the “Getting Started

Guide”.

8.3.3 Note for setting packet size

The packet size is set to 1428 as the factory default. Users may enter any value for the packet size and the value will be internally adjusted to an appropriate, legal value that complies with the GenICam standard. The packet size can be modified in the GigE Vision Transport Layer Control section of the camera control tool.

Regarding data transfer rate, a larger packet size produces a slightly lower data transfer rate. The AT-140GE can support a maximum of 16020 byte packets provided the NIC being used has a Jumbo Frames function with a setting of a 16020 bytes or larger.

Caution: Do not set the packet size larger than the maximum setting available in

the NIC or switch to which the camera is connected . Doing so will cause output to be blocked.

8.2.4 Calculation of Data Transfer Rate

In order to calculate the data transfer rate, the following parameters and formula are required.

Setting parameter

Item

Unit

Symbol

Image Width

[pixels]

Image Height

[pixels]

Bits per Pixel

[bits]

Frame Rate

[fps]

Packet Size

[Bytes]

Number of Packets (including Data Leader & Trailer Packet)

[packets]

Data Transfer Rate

[Mbit/s]

Fixed value

Item

Unit

value

Data Leader Packet Size

[Bytes]

Data Trailer Packet Size

[Bytes]

AT-200GE

- 30 -

Formula to calculate Data Transfer Rate

J=｛90+64+(E+18)*(G-2)｝*8*D/1000000

Where, G=ROUNDUP{A*B*C/8/(E-36)}+2

The following table shows Bits per Pixel (Item C) which depends on the pixel format.

Pixel format

Bit

RGB8

RGB10V1Packed

RGB10V2Packed

Calculation example: AT-200GE Pixel type RGB8

Item

Unit

Symbol

Setting

Image Width

[pixels]

1624

Image Height

[pixels]

1236

Bits per Pixel

[bits] C 24

Frame Rate

[fps]

15.45

Packet Size

[Bytes]

4036

Number of Packets (including Data Leader & Trailer Packet)

[packets]

Transfer Data Rate

[Mbit/s]

G=ROUNDUP {(1624 x 1236 x 24/ 8 / (4036-36)) + 2 = 1506 + 2 = 1508 J={90+64+(4036+18)x(1508-2)} x 8 x 15.45/ 1000000 = 755 Mbit/s

8.3.5 Simplified calculation (Approximate value)

A simple way to calculate the approximate data transfer rate is the following.

Transfer data = image width (pixel) x Image Height (pixel) x depth per pixel(depending

on the pixel format) x frame rate / 1,000,000 (convert to mega bit)

In the case of the AT-200GE with the full image and RGB 8bit pixel format; The data transfer rate = 1624 x 1236 x 24 x 15.45 / 1000000 = 744 Mbit/s

8.3.6 Note for 100BASE-TX connection

 In order to use 100Mbps network, 100BASE-TX and Full Duplex are available. Half

Duplex cannot be used.

 In the case of connecting on 100BASE-TX, the maximum packet size should be 1500

bytes.

 In the case of connecting on 100BASE-TX, the specifications such as frame rate,

trigger interval and so on described in this manual cannot be satisfied.

Pixel Type

Frame rate at Full Frame scan[fps]

RGB8_Packed

Approx. 1.5

RGB10V1_Packed,RGB10V2_Packed

Approx.1.1

Note: The above frame rates are based on approx. 70Mbps of total frame transfer data.

AT-200GE

- 31 -

8.4. GigE camera connecting examples

8.4.1 Using a switching hub for 1 port

 All cameras and NIC belong to the same subnet  The accumulated transfer rate for all cameras should be within 800Mbps  The packet size and the packet delay should be set appropriately in order

for the data not to overflow in the switching hub.

8.4.2 Connecting a camera to each port of a multi-port NIC

 This is the example for using a 4-port NIC  The pair of the connecting camera and the NIC constructs one subnet. As for

the IP configuration, it is appropriate to use the persistent IP.

 In this case, each camera can use the maximum 800Mbps band width.

However, the load for the internal bus, CPU and the application software become heavy, so a powerful PC will most likely be required.

AT-200GE

- 32 -

8.4.3 The data transfer for multiple cameras

8.4.3.1 If delayed readout is not used in continuous mode

 The packet delay should be set larger. The data traffic is controlled by the

buffer of the hub. It is necessary to check the buffer value of the unit.

8.4.3.2 If delayed readout is not used in trigger mode

 The packet delay should be set larger. The data traffic is controlled by the

buffer of the hub. It is necessary to check the buffer value of the unit.

AT-200GE

- 33 -

8.4.3.3 If delayed readout is used

 The packet delay should be set smaller, and the packet delay trigger

controls the data traffic. If the camera has a pulse generator, it can control the data traffic.

AT-200GE

- 34 -

9. Core functions

 The function naming of the AT-200GE complies with GenICam SFNC ver.1.3.

Most of the camera’s core operation is controlled by a combination of standard GenICam

features related to acquisition, triggering, and exposure. Additional control is provided via built-in counter, timer, and event functions.

9.1. Acquisition function

Before using trigger and exposure controls, various acquisition controls must be set. The operation of the camera depends on the interrelationship of all three feature sets.

Fig.27 Acquisition control, Trigger/Exposure control work flow

9.1.1 Basic image acquisition flow The basic commands for acquiring images are as follows:

Acquisition mode To determine the number of the frame to be captured

Trigger Selector

Acquisition Start Trigger Select if the acquisition start is controlled externally

Acquisition End Select if the acquisition end is controlled externally

Trigger Selector

Frame & Exposure start Select if the acquisition of the frame is controlled

externally.

Exposure mode To set the exposure method

Acquisition

State

Control

Exposure Control

Trigger

Selector

[Acquisition

Start]

Trigger

Selector

[Acquisition

Stop]

Trigger Mode

[JAI Acquisition

Transfer Start]

Acquisition Control

Active

Trigger / Exposure Control

Acquisition Start

Acquisition Stop

Acquisition Abort

Acquisition Mode

Acquisition Frame count

Trigger Selecctor

[Frame Start]

Trigger Selector [Exposure Start]

Trigger Selector

[Exposure End]

Acquisition Frame Rate

Stream Control

Acquisition Status Control

Internal Stream Control

Acquisition

Status

Internal

Exposure

Control

AT-200GE

- 35 -

The flow of these commands is shown below. The following drawings are based on the conditions that the Acquisition mode is Single and the Trigger selector is Frame Start.

If the acquisition start is set at ON (The acquisition is controlled externally)

If the acquisition start is set at OFF (The acquisition is controlled internally)

The following sections provide the details for each command set.

9.1.2 Acquisition mode

The AT-200GE has three settings for capturing images.  Single frame

AcquisitionStart command outputs one frame. Then the acquisition is

stopped.

 MultiFrame AcquisitionStart command outputs frames which are set by AcquisitionFrameCount. After the set frames are output, the acquisition is stopped.

 Continuous

AcquisitionStart command outputs frames until AcquisitionEnd is initiated.

9.1.2.1 Single Frame

In single frame mode, executing the AcquisitionStart command causes one frame to be captured. After one frame is captured, this operation is automatically stopped. In order to restart the capture, it is necessary to input the AcquisitionStart command again. BlockID is not reset until AcquisitionEnd is input and is incremented when the AcquisitionStart command is called.

◆ Normal single frame operation

1) AcquisitionStart command is input

2) AcquisitionActive becomes “TRUE” (accepts capture)

3) 1 frame is output

4) AcquisitionActive becomes “FALSE” (stop capturing)

Acquisition

Trigger Wait

Frame Start Trigger Wait

Acquisition Active

Acquisition

Start Command Executed

Acquisition

Trigger Wait

Acquisition

Start

Trigger

Frame Start

Trigger

Acquisition

Start

Trigger

Acquisition

Status

Frame Start Trigger Wait

Acquisition Active

Acquisition

Start Command Executed

Frame Start

Trigger Wait

Frame Start

Trigger

Acquisition

Status

Frame Start

Trigger

AT-200GE

- 36 -

Fig.28 Single frame timing

This drawing shows a case where the AcquisitionStart trigger is “ON”. If the acquisition trigger is OFF, FrameActive is always high.

◆ Forcing acquisition to stop

While AcquisitionActive is “TRUE”, if AcquisitionEnd or AcquisitionAbort is initiated, AcquisitionActive becomes “FALSE” (stop capturing).

Related functions: AcquisitionStart、AcquisitionStop、AcquisitionAbort

9.1.2.2 MultiFrame

In this mode, the AcquisitionStart command captures the number of frames which are specified by AcquisitionFrameCount. AcquisitionFrameCount can be set in the range of 1 to 255 frames. After all frames are captured , this operation is automatically stopped.

◆ Normal multi-frame operation

1) AcquisitionStart command is input

2) AcquisitionTriggerWait becomes effective

3) AcquisitionActive becomes “TRUE”

4) Output N frames as specified by AcquisitionFrameCount

5) AcquisitionActive becomes “FALSE”. Then the output stops. (See the following

diagram)

Fig.29 Multi Frame timing

AcquisitionS tart

Acquisition

Trigger

Wait

Acquisition

Active

Acquisition TriggerWait

ExposureAct ive

CCD Readout

FrameActive

Stream Active

AcquisitionStatus

AcquisitionStart

Acquisition TriggerWait

AcquisitionActive

Acquisition

TriggerWait

If AcquisitionFrameCount＝N

・ Setting range of AcquisitionFrameCount

1≦ AcquisitionFrameCount ≦255（0xFF）

ExposureActive

CCD Readout

FrameActive

Stream Active

Frame 1 Frame N

AcquisitionStatus

AT-200GE

- 37 -

This diagram shows a case where the AcquisitionStart trigger is “ON”. If the AcquisitionStart trigger is OFF, FrameActive is always high.

◆ Forcing acquisition to stop

While AcquisitionActive is “TRUE”, if AcquisitionEnd or AcquisitionAbort is initiated, AcquisitionActive becomes “FALSE” (stop capturing). Once the operation is set to “FALSE”, the internal FrameCount is reset.

Related functions: AcquisitionStart、AcquisitionFrameCount, AcquisitionEnd、

AcquisitionAbort

9.1.2.3 Continuous mode

In this mode, when the AcquisitionStart command is set, the image is continuously output at the current frame rate. This is the default setting for the AT-140GE.

1) AcquisitionStart command is input

2) AcquisitionTriggerWait becomes effective

3) AcquisitionActive becomes “TRUE”

4) Images begin outputting continuously

5) AcquisitionEnd command is sent

6) AcquisitionActive becomes “FALSE”. At this moment, the output stops.

Fig.30 Continuous timing

This drawing shows a case where the AcquisitionStart trigger is “ON”. If the AcquisitionStart trigger is OFF, FrameActive is always high.

Related functions: AcquisitionStart、AcquisitionStop、AcquisitionAbort

AcquisitionStart

Acquisition

Trigger

Wait

AcquisitionActive

Acquisition

Trigger

Wait

AcquisitionStop

ExposureActive

CCD Readout

FrameActive

Stream Active

Frame 1 Frame N

AcquisitionStatus

AT-200GE

- 38 -

9.1.3 AcquisitionAbort

AcquisitionAbort forces capture to stop if the AcquisitionAbort command is set while AcquisitionTriggerWait is effective or during exposure. The exact behaviour depends on the status of acquisition and readout:

Condition 1 - While reading out from CCD:

CCD readout and streaming continue. After they are completed, AcquisitionActive becomes “FALSE”(stop capturing).

At this moment, if AcquisitionStart is set, restart the capturing.

Condition 2 – Acquisition is active, but CCD readout is not yet initiated:

After the exposure is completed, the output is not initiated. AcquisitionActive becomes “FALSE”.

Condition 3 - Awaiting a trigger:

AcquisitionActive immediately becomes “FALSE”(capturing is not possible).

9.1.4 AcquisitionFrameCount

If Acquisition Mode is set to MultiFrame, AcquisitionFrameCount can set the number of frames to be captured each time the AcqusitionStart command is input. Setting range is 1 to 255 frames.

Fig.31 Acquisition Frame Count

9.1.5 AcquisitionFrameRate

1) In the trigger OFF mode (self running mode), it is possible to set the exposure period longer than the number of lines required for CCD drive in the designated area of interest (AOI).

2) The number of lines set by AcquisitionFrameRate determines the frame period.

3) The range of lines which can be set by AcquisitionFrameRate is 1 to 65535(16-bits).

The shortest period is dictated by the number of lines required for the desired

partial scan/AOI readout (see formula in section 7.8).

4) AcquisitionFrameRate cannot be used if the trigger mode is ON.

5) This function is useful for a long term exposure or time lapse output.

ReadOut TotalLine

1H1

・ If AcquisitionFrameRate is valid,

FrameStart is OFF ExposureStart is OFF

・Setting range of AcquisitionFrameRate

Min Lines≦AcquisitionFrameRate≦65535（0xFFFF） ※Min Lines vary depending on readout lines

AcquisitionFrameRate

Presetting1Frame

AT-200GE

- 39 -

9.1.5.1 Setting the free running mode (Trigger OFF)

The free running mode can be utilized under one of the following conditions:

① ExposureMode is OFF ② ExposureMode is Timed and FrameStart is OFF and ExposureStart is OFF. ③ ExposureMode is TriggerWidth and FrameStart is OFF and ExposureStart is OFF. ④ ExposureMode is TriggerControlled and ExposureStart or ExposureEnd is OFF.

The following table shows the configurations for“free running”the camera. If the exposure mode is set Timed and the frame start and exposure start of the

trigger selector are set OFF, the exposure can be controlled.

Trigger Selector

ExposureMode

Frame Start

Exposure Start

Exposure End

Operation

OFF

―

Trig OFF (Free run) No exposure Control

Timed

OFF

―

Trig OFF (Free run)

Exposure can be controlled

TriggerWidth

OFF

―

Trig OFF (Free run) No exposure control

Trigger Controlled

―

OFF

Trig OFF (Free run) No exposure control

―

OFF

―

Trig OFF (Free run) No exposure control

Note: "-" means that this setting does not impact the operation.

The shortest frame period varies depending on the number of lines to be read out (e.g., partial scanning 618 image lines requires a total of 698 lines to be read out – see formula in section 7.8). If the line number setting is smaller than the number of lines required to support the AOI, the line number setting is ignored and the frame

period is based on the total number of OB, blanking, transition, and image lines. If all pixels are read out, the maximum frame rate is 19.27KHz which is 1248 total lines.

9.1.5.2 The calculation of the frame rate for the setting area

1. Binning Vertical=1 (OFF)

Line frequency ＝37125000Hz/1926clk=19276Hz Frame frequency＝19276Hz /total number of lines

Note: for the minimum 8-line partial scan, the total line number is 366.

2. Binning Vertical=2 (ON)

Line frequency ＝37125000Hz/2136clk=17381Hz Frame frequency ＝17381Hz / Setting total line number

Please refer to chapter 7.8 for the formula for line number calculation.

9.1.6 AcquisitionStatus

AcquisitionStatus can show the operating status of the following signals set by AcquisitionStatusSelector.

AT-200GE

- 40 -

Each function is:

AcquisitionTriggerWait： Effective if waiting for a trigger AcquisitionActive ： Effective if capture is allowed AcquisitionTransfer： Effective while the data is transferring FrameTriggerWait： Effective if waiting for FrameTrigger FrameActive： Effective during FrameEffective period FrameTransfer： Effective while the data is transferring ExposureActive： The longest exposure period is provided if R, G and B

channel exposure times are different.

The following diagrams show different scenarios for Exposure Mode and Trigger Mode and their effect on AcquisitionStatus.

① If ExposureMode=OFF

Fig.32 Acqusition Status

② If ExposureMode=On, Trigger mode=OFF

Fig.33 Acquisition status

Acquisi tionStart

Acquisition

Trigger

Wait

Acquis itionActive

Acquis ition TriggerWait

Acquisi tionStop

Acquisi tion

start

com mand

Acquis ition

stop

com mand

Expos ureActive

CCD Reado ut

FrameActive

FrameTransfer

Frame1 FrameN

FrameTriggerWait

Acquisi tionStatus

Acquisi tionStart

Acquisition

Trigger

Wait

Acquisi tionActive

Acquis ition TriggerWait

Acquis itionStop

Acquisi tion

start

com mand

Acquis ition

stop

com mand

Expos ureActive

CCD Reado ut

FrameActive

FrameTransfer

Frame1 FrameN

FrameTriggerWait

Acquis itionStatus

AT-200GE

- 41 -

③ If ExposureMode=On, trigger mode =ON

Fig.34 Acqusiition status

9.2. Trigger Control

9.2.1 TriggerSelector(TriggerMode)

This is the function to set the trigger operation. This will set how to control the output and the exposure.

9.2.1.1 Acquisition

This is the trigger function to control the output. This controls AcquisitionStart and AcquisitionEnd. A description of the configuration process is as follows:

 AcquisitionStart trigger: Set whether the capture start is to be controlled

externally or not.

TriggerMode On： After AcquisitionStart command is input, input the

signal selected by AcquisitionStart trigger as the trigger, and make AcquisitionActive effective.

TriggerMode Off： AcquisitionStart command is input. It makes

AcquisitionActive effective regardless of AcquisitionStart.

 AcquisitionEnd trigger: Set whether the end of the capture is to be controlled

externally or not.

TriggerMode On： While AcquisitionActive is effective, input the signal

selected by AcquisitionEnd as the trigger, and make AcquisitionActive invalid.

TriggerMode Off： AcquisitionStart command is input. It makes

AcquisitionActive invalid regardless of the trigger

source.

Note: Refer also to section 9.1.1

AcquisitionStart

Acquisition

Trigger

Wait

Acquis itionActive

Acquis ition TriggerWait

Acquis itionStop

Acquisi tion

start

com mand

Acquisi tion

stop

com mand

Expos ureActive

CCD Readout

FrameActive

FrameTransfer

Frame1 Frame N

FrameTriggerWait

FrameTrigger

Acquisi tionStatus

AT-200GE

- 42 -

9.2.1.2 Exposure

These commands are used for setting the exposure control. They include FrameStart、ExposureStart、and ExposureEnd. If ExposureMode is set to any setting except OFF, the combination of the

ExposureMode setting and the TriggerControl setting will determine the type of exposure and whether triggering is OFF or ON. The following table shows the combination and the operation.

TriggerSelector

ExposureMode

Frame Start

Exposure Start

Exposure End

Operation

Previous JAI

trigger name

OFF

―

Trig OFF(Free run) No Exposure Control

Trigger OFF

Timed

OFF

―

Trig OFF(Free run) Exposure Control Is possible

Trigger OFF

―

Trig On FrameStart Trigger

EPS

OFF

―

Trig On ExposureStart Trigger

EPS

TriggerWidth

OFF

―

Trig OFF(Free run) No Exposure Control

Trigger OFF

ON ― OFF

Trig On FrameStart Trigger

PWC

OFF

―

Trig On ExposureStart Trigger

PWC

Trigger Controlled

―

OFF

Trig OFF(Free run) No Exposure Control

Trigger OFF

―

OFF

―

Trig OFF(Free run) No Exposure Control

Trigger OFF

OFF

Trig On

Start/Stop

Note: “―”means that this setting does not impact the operation.

 FrameStart trigger：Set whether the start of the frame is to be controlled

externally or not.

TriggerMode On： While AcquisitionActive is effective and ExposureMode is set

at Timed or TriggerWidth, start exposure using the signal selected by FrameStart trigger.

TriggerMode Off： While AcquisitionActive is effective, self running operation

takes place.

 ExposureStart trigger: Under the following conditions, this works the trigger to

start the exposure.

・Frame start trigger is OFF and ・ExposureMode is set at Timed or TriggerWidth orTriggerControlled.

Note: If TriggerControlled is selected, ExposureEnd must be ON too.

TriggerMode On： While AcquisitionActive is effective , FrameStart is OFF

and is set at Timed, TriggerWidth or TriggerControlled, starts the exposure by using the signal selected by ExposureStart as the trigger signal.

AT-200GE

- 43 -

TriggerMode Off： While AcquisitionActive is effective, self

running operation takes place.

 ExposureEnd trigger：When ExposureMode is set at TriggerControlled, this

controls the stop timing only when ExposureStart is ON.

TriggerMode On： While AcquisitionActive is effective, ExposureMode is

TriggerControlled and ExposureStart is ON, the exposure is stopped by using the signal selected by ExposureEnd as the trigger and the data is output.

TriggerMode Off： While AcquisitionActive is effective, self

running operation takes place.

9.2.2 Memory readout control

It is possible to control the readout timing after the signal from the CCD is stored in the Frame Memory.

 JAI_AcquisitionTransferStart：This activates the memory readout control.

TriggerMode ON ： While AcquisitionActive is effective,

AcquisitionTransferStart outputs the stored data.

TriggerMode OFF ： While AcquisitionActive is effective, the stream is

output.

9.2.3 Triggersoftware

This is one of the trigger sources and is the software trigger command. This has one command signal to each of the 6 items of TriggerSelector. To use this function, TriggerSource must be set at TriggerSoftware.

9.2.4 Triggersource

The following signals can be selected as the trigger signal source.

① Off ② Software ③ Line 1(TTL out1) ④ Line 2(TTL out2) ⑤ Line 3(Opt out1) ⑥ Line 4(Opt out2) ⑦ Line 5(Opt in1) ⑧ Line 6(Opt in2) ⑨ Line 7(TTL in1) ⑩ Line 8(LVDS in) ⑪ Timer1Start ⑫ Timer1End ⑬ Counter1Start ⑭ Counter1End ⑮ UserOut1 ⑯ UserOut2 ⑰ UserOut3

AT-200GE

- 44 -

⑱ UserOut4 ⑲ Action1 ⑳ Action2

9.2.5 TriggerActivation

This determines the behaviour of the trigger. RisingEdge： Initiate at the signal rising edge FallingEdge： Initiate at the signal falling edge AnyEdge： Initiate at either the signal rising edge or falling edge LevelHigh： Initiate during the signal high level When receiving the trigger, if this is effective, the trigger is

automatically received.

LevelLow： Initiate during the signal low level

When receiving the trigger, if this is effective, the trigger is automatically received.

Note: When TriggerWidth is used, TriggerActivation should be set at either LevelHigh or LevelLow.

9.2.6 Triggeroverlap

This function sets whether the trigger can be received during the data readout when FrameStart or ExposureStart is ON.

Off： The trigger cannot be accepted during CCD readout.

This works the same as LVAL asynchronous trigger.

ReadOut： The trigger can be accepted during CCD readout. This works as LVAL synchronous trigger if the CCD is reading out the

data. If CCD is not reading out the data, it works as LVAL async.

9.2.7 Triggerdelay

This function delays the trigger signal against the trigger input.

Step is 1usec/Step.

The setting range is from 0 to 65,535usec at 16bit.

9.3. Exposure Control

This is the function to manage the exposure settings.

9.3.1 Exposure Mode

The exposure mode can be selected from the following choices.

Off： No exposure control.

Timed： The exposure time is to be set in microseconds. If FrameStart and ExposureStart in TriggerSelector are“OFF”,

the exposure is controlled in Free Run. If FrameStart or ExposureStart in TriggerSelector is “ON”, this functions as the EPS mode.

AT-200GE

- 45 -

TriggerWidth： This mode controls the exposure time by the pulse width.

If FrameStart and ExposureStart in TriggerSelector is “OFF”, The camera operates in Free Run. If FrameStart or ExposureStart in the TriggerSelector is “ON”, this functions as the PWC mode.

TriggerControlled：The exposure is controlled by ExposureStart and ExposureEnd.

The following is the table for the combination of ExposureMode and TriggerControl

and its function.

TriggerSelector

ExposureMode

Frame Start

Exposure Start

Exposure End

Operation

Previous JAI

trigger name

OFF

―

Trig OFF(Free run) Exposure control

Trigger OFF

Timed

OFF

―

Trig OFF(Free run) Exposure control is possible

Trigger OFF

―

Trig On FrameStart Trigger

EPS

OFF

―

Trig On ExposureStart Trigger

EPS

TriggerWidth

OFF

―

Trig OFF(Free run) No Exposure control

Trigger OFF

ON ― OFF

Trig On FrameStart Trigger

PWC

OFF

―

Trig On ExposureStart Trigger

PWC

Trigger Controlled

―

OFF

Trig OFF(Free run) No Exposure control

Trigger OFF

―

OFF

―

Trig OFF(Free run) No Exposure control

Trigger OFF

OFF

Trig On

Start/Stop

Note: “―”means that this setting does not impact the operation.

9.3.2 ExposureTime

This is effective only if ExposureMode is set to“Timed”. This command can set the exposure time.

By using JAI_Exposure_Time Enable, the exposure time of R, G and B channels can be set the same time or set independently.

False： ExposureTime is effective. True： JAI_ExposureTime_R, JAI_ExposureTime_G and

JAI_ExposureTime_B are effective.

The setting step for the exposure time;

Trigger On： 1μsec/Step Trigger OFF : 1Line/Step

The setting range of the exposure time;

Trigger On： 69μs - 65535μs

Trigger Off： 1L - the maximum value which can be set

AT-200GE

- 46 -

9.3.3 ExposureAuto

This is auto exposure control function and is effective only in the “Timed”mode.

The brightness is controlled by JAI AGC Reference.

ExposureAuto includes OFF, Once and Continuous modes.

The setting range is; JAI AGC Reference： 0-255 ExposureTime ： 72L - the maximum value which can be set

9.4. UserOutputSelector

In addition to TriggerSoftware, the user can use the following commands as the trigger

input sources.

UserOutput1 UserOutput2 UserOutput3 UserOutput4

The setting value is “False” or “True”.

9.5. Counter function

This function can count up the internal pulse counts.

9.5.1 CounterSelector

The AT-140GE has one counter. The counter function is activated by setting ConterEventSource, CounterResetSource or CounterTriggerSource.

9.5.2 CounterEventSource

CounterEventSource can be selected from the following signals.

CounterEventSource works as the trigger to start the count up.

① Off ② AcquisitionTrigger ③ AcquisitionStart ④ AcquisitionEnd ⑤ FrameStart ⑥ Line 1(TTL out1) ⑦ Line 2(TTL out2) ⑧ Line 3(Opt out1) ⑨ Line 4(Opt out2) ⑩ Line 5(Opt in1) ⑪ Line 6(Opt in2) ⑫ Line 7(TTL in1) ⑬ Line 8(LVDS in)

9.5.3 CounterEventActivation

This selects the timing for when the counter starts up.

RisingEdge： The counting starts at the signal rising edge.

AT-200GE

- 47 -

FallingEdge：The counting starts at the signal falling edge. AnyEdge： The counting starts at any edge of the signal.

9.5.4 CounterResetSource

The reset source can be selected from the following signals.

The reset source works as the trigger to reset the counter.

① Off ② Software ③ Line 1(TTL out1) ④ Line 2(TTL out2) ⑤ Line 3(Opt out1) ⑥ Line 4(Opt out2) ⑦ Line 5(Opt in1) ⑧ Line 6(Opt in2) ⑨ Line 7(TTL in1) ⑩ Line 8(LVDS in) ⑪ Action1 ⑫ Action2

9.5.5 CounterResetActivation

This selects the timing for resetting the counter.

RisingEdge： The counter is reset at the signal rising edge. FallingEdge：The counter is reset at the signal falling edge. AnyEdge： The counter is reset at any edge. LevelHigh： The counter is reset during the signal “HIGH” level.

LevelLow： The counter is reset during the signal “LOW” level.

9.5.6 CounterValue

This can read the counter value or set the default value when the counter starts.

9.5.7 CounterValueAtReset

This can store the value just before reset and read the value.

9.5.8 CounterDuration

This can set the CounterCompleted value of the counter. The counter itself can count up to the maximum (FFFF).

9.5.9 CounterStatus

This shows the counter status.

CounterIdle： The counter is not operating.

The CounterTriggerSource is “Off”. CounterTriggerWait： When the counter is waiting for the start trigger CounterActive： The counter is operating. CounterCompleted： When the counting value reaches CounterDuration CounterOverflow： If the counter counts past the maximum value

AT-200GE

- 48 -

Fig.35 Counter Status

9.5.10 CounterTriggerSource

This is used to select the counter trigger from the following signals. The counter trigger is the trigger that starts the count up.

① Off ② AcquisitionTrigger ③ AcquisitionStart ④ AcquisitionEndFrame ⑤ TriggerFrameStart ⑥ FrameEnd ⑦ Line 1(TTL out1) ⑧ Line 2(TTL out2) ⑨ Line 3(Opt out1) ⑩ Line 4(Opt out2) ⑪ Line 5(Opt in1) ⑫ Line 6(Opt in2) ⑬ Line 7(TTL in1) ⑭ Line 8(LVDS in) ⑮ Action1 ⑯ Action2

9.5.11 CounterTriggerActivation

This selects the timing for starting the count up.

RisingEdge： The counter starts at the signal rising edge. FallingEdge：The counter starts at the signal falling edge. AnyyEdge： The counter starts at any edge. LevelHigh： The counter starts when the signal becomes “HIGH” level. LevelLow： The counter starts when the signal becomes “LOW” level.

CounterTrigger

Counter

Idle

CounterActive

Counter

Overflow

CounterReset

Counter

“0000”

CountUp

Count

NoChange

CounterEvent CounterEvent

Counter

“0000”

Count = CounterDuration

Counter

Completed

CounterIdle

Counter

Trigger

Wait

Count = FFFF

CounterStatus

16bit Counter

“0000” CountUp “FFFF”

Counter

“0000”

CounterValue

“0000” “FFFF”

CounterValue

AtReset

Count = CounterValue In

Event Active

Event NoActive Event NoActive

AT-200GE

- 49 -

9.6. Timer Control

9.6.1 TimerSelector

There is one internal timer. The timer function starts if the start trigger, TimerDelay

and TimerDuration are set.

9.6.2 TimerDuration

This is used to set the maximum value of the timer.

9.6.3 TimerDelay

This can set the period to start the timer. This results in the delay of the timer start.

9.6.4 TimerValue

This can set the default value of the timer and read the current setting value.

9.6.5 TimerStatus

This checks the current status of the timer and provides one of the following.

TimerIdle： When the timer is not operating.

When TimerTriggerSource is OFF.

TimerTriggerWait： When the timer is waiting for the start trigger

TimerActive： When the timer is operating TimerCompleted： When the timer reaches its maximum value

Fig.36 Timer Status

9.6.6 TimerTriggerSource

The start trigger signal to the timer can be selected from the following list.

① Off ② AcquisitionTrigger ③ AcquisitionStart ④ AcquisitionEnd ⑤ FrameTrigger ⑥ FrameStart ⑦ FrameEnd ⑧ Line 1(TTL out1)

TimerTrigger

TimerIdle TimerActive

Delay

Timer

“0000”

Timer = TimerDuration

Timer

TriggerWai

TimerStatus

16bit DelayTimer

Delay Timer

DelayTimer= TimerDelay

Timer

Completed

TimerIdle

DelayTimer N oChange

Timer

TimerValue

Timer

TimerNoChange

16bit Timer

AT-200GE

- 50 -

⑨ Line 2(TTL out2) ⑩ Line 3(Opt out1) ⑪ Line 4(Opt out2) ⑫ Line 5(Opt in1) ⑬ Line 6(Opt in2) ⑭ Line 7(TTL in1) ⑮ Line 8(LVDS in) ⑯ Timer1End ⑰ Timer2End ⑱ Action1 ⑲ Action2

9.6.7 TimerTriggerActivation

The timing of the start trigger to the timer can be selected from the following.

RisingEdge： The timer starts at the signal rising edge. FallingEdge：The timer starts at the signal falling edge. AnyEdge： The timer starts at any edge. LevelHigh： The timer starts when the signal becomes “HIGH” level. LevelLow： The timer starts when the signal becomes “LOW” level.

9.7. Event Control

9.7.1 EventSelector

The event can be selected from the following list.

AcquisitionTrigger、FrameStart、FrameEnd、ExposureStart、ExposureEnd、 Line1RisingEdge、 Line1FallingEdge、Line2RisingEdge、Line2FallingEdge、Line3RisingEdge、 Line3FallingEdge, Line4RisingEdge、Line4FallingEdge、Line5RisingEdge、 Line5FallingEdge、Line6RisingEdge、Line6FallingEdge、Line7RisingEdge、 Line7FallingEdge、Line8RisingEdge、Line8FallingEdge

9.8. Video Send Mode

The Video Send Mode is the function to select how the image information will be read out from the camera.

Normal： Ordinary operation Sequence Mode： Sequence ROI operation Multi Mode： Multi ROI operation

9.9. ActionControl

ActionControl is used to activate the specific functions of multiple cameras on the same network at the same time. For instance, it can be used to trigger multiple cameras at the same time.

ActionControl appears as two inputs (Action 1, Action 2) and is connected with 6 Triggers, CounterReset of the counter, CounterTrigger and Timer. If ActionControl is used, the input source to the trigger should be set to Action 1 or Action 2 in advance.

AT-200GE

- 51 -

10. Operation modes

10.1. Continuous mode (Free run)

For applications not requiring asynchronous external triggering, this mode should be used. In this mode it is possible to use a lens with a video controlled iris. As for the timing, please refer to chapter 7.7 “Video output timing”. In continuous mode, exposure time can be controlled by the frame rate or by the electronic shutter. The following examples describe the GenICam settings used to configure the camera for continuous operation.

10.2. Trigger operation with “timed” exposure (Previously called EPS)

An external trigger pulse initiates the capture, and the exposure time (accumulation time) is set in advance. The minimum active period of the trigger is 66μsec and the minimum trigger interval is shown below.

Mode

Minimum trigger interval

Overlap is set at “Readout” and the trigger is input during the readout (LVAL Sync)

1248L + 3L

Overlap is set at “OFF” or “Readout” and the trigger is input during the readout is not activated. (LVAL Async)

Exposure time + 1248L + 3L

Note: 1) On the above table, 1248L is FVAL interval on normal continuous mode

2) If BinningVertical is effective, 1L is different from the normal scanning. So, the minimum trigger interval will be different.

Fig. 37 Trigger control by Timed (Full pixels readout)

2 L

D A T A O U T

Effecti ve Li nes

Mi n : 2 L ~ M a x : 1 V

Fr om most l ong es t c hanne l

E x t . T r i g 1

Rc h S UB

Rc h S G

Rch Exposur e Peri od

Gc h S UB

Gc h S G

Gch Exposure Per i od

Bc h S UB

Bc h S G

Bch Exposur e Peri od

Sa me a s mos t s hor te st c hanne l

Wh en t he LVA L S ync Ac cum. : 2 .5 L Wh en t he L VAL Ay snc Ac cum 2 .0 t o 3. 0L

R e s e r v e d

OB 4 L + R e s e r v e d 2 L

6 L

1 2 4 4 L

i n t _ F V A L

i n t _ L V A L

i n t _ D V A L

1L i ne = 19 26 Cl ock ( 51 . 88us )

Exposure Active

1236

AT-200GE

- 52 -

Note: If the exposure time of R channel is 1/15sec. and the exposure time of G channel is

1/50,000sec., the image quality of the green channel at the 1/50,000 sec exposure time speed may not be guaranteed due to the fundamental CCD operation. In this mode, it is recommended to use the same exposure time for all three channels. If it is necessary to use with the different exposure time, please check the image quality first.

10.3. Trigger operation by “TriggerWidth” (Previously called PWC)

In this mode the accumulation time is equal to the trigger pulse width. Here it is possible to have a long time exposure. The minimum active period of the trigger is 2L and the minimum trigger interval is shown as follows.

Mode

Minimum trigger interval

Overlap is set at “Readout” and the trigger is input during the readout (LVAL Sync)

1.Exposure time < 1248L

1248L + 3L

2.Exposure time ≥ 1248L

Exposure time +2L

Overlap is set at “OFF” or “Readout” and the trigger is input during the readout is not activated. (LVAL Async)

Exposure time + 1248L + 3L

Note: 1) On the above table, 1248L is FVAL interval in normal continuous mode

2) In BinningVertical, 1L is different from the normal scanning. So, the minimum trigger

interval will be different.

Accumulation

LVAL sync operation

1.5L to 2.5L

2.5L

LVAL async operation

1.5L

2.0 to 3.0L

Fig.38 Trigger control by TriggerWidth (Full pixel readout)

2 L

Eff ecti ve Li nes

D A T A O U T

Mi n : 2 L~ Ma x : 3 0 V ( 2 37 6 0 L )

t 1

t 2

S U B

S G

E x t . T r i g

E x p o s u r e

P e r i o d

R e s e r v ed

OB 4L + R e s e r v ed 2 L

1 24 4 L

1 23 6 L

i n t _ F V A L

i n t _ L V A L

i n t _ D V A L

E x p o s u r e

A c t i v e

1L = 1926Cl ock ( 51.88us)

1236

AT-200GE

- 53 -

10.4. Trigger operation by TriggerControlled

The timing of the exposure start and the exposure end is controlled by consecutive triggers. After the start trigger is input, the exposure is activated. When the end trigger is received, the exposure is stopped to output the image data.

The minimum active period of the trigger is 66μsec. and the minimum trigger interval

is shown as follows.

Mode

Minimum trigger interval

Overlap is set at “Readout” and the trigger is input during the readout (LVAL Sync)

1.Exposure time < 1248L

1054L + 3L

2.Exposure time ≥ 1248L

Exposure time +2L

Overlap is set at “OFF” or “Readout” and the trigger is input during the readout is not activated. (LVAL Async)

Exposure time + 1248L + 3L

Note: 1) On the above table, 1248L is FVAL interval in the normal continuous mode

2) In BinningVertical, 1L is different from the normal scanning. So, the minimum trigger

interval will be different.

Accumulation

LVAL sync operation

1.5 to 2.5L

2.5L

LVAL async operation

1.5L

2.0 to 3.0L

Fig. 39 Trigger operation by TriggerControlled

2 L

Eff ecti ve Li nes

D A T A O U T

t 1

t 2

S U B

S G

E x p o s u r e

P e r i o d

T r i g

E x po s ur e s t a r t E x po s ur e E n d

R e s e r v ed

OB 4 L+ Re s e r v ed 2L

1 24 4 L

1 23 6 L

i n t _ F V A L

i n t _ L V A L

E x p o s u r e

A c t i v e

i n t _ D V A L

1L = 1926Cl ock ( 51. 88us )

1236

AT-200GE

- 54 -

10.5. Trigger input and exposure start timing

Triggeroverlap

This function is used to set whether the trigger can be accepted during the data readout in cases where FrameStart trigger or ExposureStart trigger are “ON”.

OFF: While the CCD reads out the data, the trigger cannot be accepted.

This works as LVAL asynchronous operation.

ReadOut: While the CCD reads out the data, the trigger can be accepted.

In this mode, if the trigger is input during CCD readout, it works as LVAL synchronous and if the trigger is input while the CCD is not reading out, it works as LVAL asynchronous.

This is the same behaviour as LVAL SYNC/ASYNC auto detection.

Note: During synchronous reset, a jitter of up to 1 LVAL will occur from trigger input

to exposure start and end. During asynchronous reset, there is no jitter.

The minimum trigger interval is shown as follows. The synchronous reset shows the shorter interval.

Mode

Minimum trigger interval

Synchronous reset

1248L + 3L

Asynchronous reset)

Maximum exposure time + 1248L + 3L

Note: The above table is based on Exposure mode Timed, Trigger ON.

1248L is FVAL interval in the normal continuous mode.

10.5.1 Synchronous reset timing

10.5.1.1 In the case of Expsoure mode = Timed, Trigger = ON (Full frame)

Fig.40 Synchronous reset （Timed）

2. 5L

DATA out

t1+1L( Max)

Ext. Trigger

Exposure Period

Exposure Delay

Data Out Delay

Exposure Period

Exposure Active

14.5L

int-FVAL

int-LVAL

AT-200GE

- 55 -

10.5.1.2 In the case of Expsoure mode = Trigger width, Trigger = ON (Full frame)

Fig.41 Synchronous reset (Trigger width)

10.5.2 Asynchronous reset timing

10.5.2.1 In the case of Expsoure mode = Timed, Trigger = ON (Full frame)

Fig.42 Asynchronous reset (Timed)

10.5.2.2 In the case of Expsoure mode = Trigger width, Trigger = ON (Full frame)

Note: In BinningVertical, the delay of exposure end is 57.54μsec. (1L=2136clock)

Fig. 43 Asynchronous reset (Trigger width）

DATA out

Ext. Tri g

9. 7us

Exposure

Exposure Period

Exposure delay

Data Out Delay

Exposure

Active

2 to 3L

14 to 15L

int-FVAL

int-LVAL

Data out Del ay

Del ay of Expos ure S t ar

( Exposur e)

DATA out

Ext . Tri g

Exposur e Pr i od

Del ay of Expos ure End

9. 7us

29.7us

Exposure

Active

2 to 3L

14 to 15L

int-FVAL

int-LVAL

AT-200GE

- 56 -

10.6. Sequence Trigger Mode

This mode allows the user to define a preset sequence of up to 10 images, each with its own ROI, Exposure time and Gain values. As each trigger input is received, the image data within the preset sequence is output as described below.

Trigger

Sequence Operation

Fig.44 Sequential Trigger Mode

This function is effective when the video send mode is set at the sequence mode. In the sequence mode, the following parameters can be set.

Sequence ROI index: This is the index to set. Sequence ROI FrameCount: Set the frame number in the current index Sequence ROI Next index: Set the next index Sequence ROI Width: Set the horizontal readout width Sequence ROI Height: Set the vertical readout lines Sequence ROI Offset X: Set the horizontal offset Sequence ROI Offset Y: Set the vertical offset Sequence ROI Gain: Set the gain Sequence ROI Exposure Time: Set the exposure time.

The following default settings can be modified by the user to define a sequence.

ROI

Exposure

time(μsec)

Gain

Frame

count

Width

Height

Offset

Frame

count

1624

1236 0 1

20000

1624

1236 0 1

20000

0 1 3

1624

1236 0 1

20000

0 1 4

1624

1236 0 1

20000

0 1 5

1624

1236 0 1

20000

0 1 6

1624

1236 0 1

20000

0 1 7

1624

1236 0 1

20000

0 1 8

1624

1236 0 1

20000

1624

1236 0 1

20000

0 1 10

1624

1236 0 1

20000

The other necessary register for the sequence ROI mode is Sequence Repetition. It sets the number of times the sequence will repeat in the range of 1 to 255 or indefinitely (Sequence Repetition = 0).

Sequence 1 Sequence 4Sequence 3Sequence 2

AT-200GE

- 57 -

10.7. Multi ROI Mode

A maximum of 5 preset ROI images can be taken from one image. Using this function, the total data can be smaller than a full frame.

Fig 45. Multi ROII

If the Video Send Mode Selector is set to Multi Mode, this function becomes effective. In the Multi ROI Mode, the following items can be set (see section 12.4.5.11 for an example).

Multi ROI Index： This is the index (0-4) to which the setting will be applied Multi ROI Next Index： Indicate the next index to read out Multi ROI Width： Set the horizontal readout width Multi ROI Height： Set the vertical readout lines Multi ROI Offset X： Set the horizontal offset

Multi ROI Offset Y: Set the vertical offset

Each ROI can be overlapped.

ROI 1

ROI 2

ROI 3

ROI 4

ROI 5

AT-200GE

- 58 -

10.8. Delayed Readout Mode (JAI Custom Control)

If multiple cameras need to be simultaneously triggered by one trigger pulse, this function can be used in order for the Ethernet bandwidth to accommodate the added traffic without conflicts. Refer to the chapter 8.4 too. This function can be set by the following;

Set VideosendmodeSelector in the JAI Custom Control to Multi ROI and Set JAI_AcqusitionTransferStart to ON, then the readout can be controlled by the external trigger signal which is selected in JAI_AcqusitionTransferStart.

Fig.46 Delayed Read Out

9.9. Mode and function matrix table

The following table shows the possible combination of mode and function. ○ for effective and × for invalid

Trigger

operation mode

Binning

Vertical

Exposure

Time

Frame

Count

Multi

ROI

Sequence

ROI

Auto

Iris

out

Auto

Exposure

/Gain

Continuous

OFF/ON

○ ○ × ○ ○

Timed continuous

OFF/ON

○

○ ○ × ○ ○

Timed triggered

OFF/ON

○

× ○ ○ × ×

TriggerWidth

triggered

OFF/ON

× ○ × × ×

TriggerControlled

triggered

OFF/ON

× ○ × × ×

Exposure

CCD output

Store in GigE

GigE output

Frame Start Trigger

CCD　surface

CCD readout

Frame memory

JAI Acquisition Transfer Start Trigger

Ethernet　output

AT-200GE

- 59 -

11. Image processing

11.1. Basic construction

The AT-200GE is a 3CCD camera equipped with F4, 1/1.8 inch prism optics. Red, green and blue color signals are taken from each 2 mega CCD which are filtered to the red, green and blue spectral wavelengths. A 32-bit microprocessor controls all functions in the AT-200GE camera. The CCD sensor output is normalized in CDS and preamplifiers. The signals are then digitized to 16 bits. Digital gain control, color matrix, look-up tables and setup can do signal processing in 16 bits before the signal is converted to a 30- or 24-bit RGB pixel format via GigE Vision interface.

Fig.47 Principle diagram for signal processing

11.2. Shading compensation

The AT-200GE implements a digital shading compensation circuit for the white shading which could be caused in the prism or optical system. The whole image is divided horizontally and vertically and uses the center level as the reference. The circuit will compensate the difference between the center and each divided area. The range for compensation is a maximum of 25%. In the factory, the shading compensation is activated and stored in the “Factory” area of the memory. The user can uses this data if the shading compensation is ON.The factory default is OFF. The AT-200GE has two shading compensation circuits.

1. Color shading compensation

In this mode, the shading is compensated using the G channel as the reference. Adjust R and B channels to match the characteristics of the G channel. Use white

balance to match R, G and B levels.

Fig.48 Conceptual drawing for color shading compensation

750 nm700650600550

50 0

450

4 0 0

Light

CCD

B ch A/D & process circuit Blemish compensation Shading compensation Color matrix LUT/Gamma/Knee

GigE Interface

G ch A/D & process circuit Blemish compensation Shading compensation Color matrix LUT/Gamma/Knee

R ch A/D & process circuit Blemish compensation Shading compensation Color matrix LUT/Gamma/Knee

750 nm700650600550

50 0

450

4 0 0

750 nm700650600550

450

4 0 0

Video Level

AT-200GE

- 60 -

2. Flat shading compensation In this mode, each channel can be adjusted to achieve flat characteristics.

Fig.49 Conceptual drawing for flat shading compensation

Note: The maximum level of the shading compensation is 25%. In a certain

circumstances such as lighting conditions or used lenses, it may not be compensated. The following is the lens condition. Use 1/1.8 inch type and lens designed for 3CCD camera. The shading depends on the focal length and F number. The wide angle lenses or using a lens in fully open iris condition may deteriorate the shading characteristics.

In order to perform the shading compensation,

Shading correction mode: Select Flat shading or Color shading Shading Enable: True Shading selector: Select R, G or B In case of color shading, select R or B Shading correct: Perform Shading Calibration In order to store the data, select user I or 2 in User selector and activate User set

load.

11.3. Auto White balance

The AT-200GE has 2 auto white balance modes: one push auto white balance or continuous auto white balance. The white balance can adjust R channel and B channel using G channel as the reference in order to set three channels equal. The reference color temperature is 7500K.

The measuring area for the auto while balance is the same as the area of the output(AOI).

Continuous

One push

OFF(Manual)

Tracking range

0.5 to 2.0

Adjustable range(R and B)

-6dB ～ +6dB

Store the setting value

Yes

Note: In continuous mode, if the white part is not enough to make an adjustment, the white

balance may not achieve a proper white color.

Note: The completion of one push auto white requires a maximum of 5 seconds to complete.

Video Level

AT-200GE

- 61 -

11.4. Gain

The analogue gain and the digital gain can be set from the external. Each functions are the following. Analog All: This is the master gain control. This can set R,G and B simultaneously.

The range is 0 to 15dB. Analog Red: R gain for WihteBalance and the range is ±6dB. Analog Blue: B gain for WihteBalance and the range is ±6dB. Digital All: This is for the fine tuning of the master gain. The range is ±3dB. Digital Red: This is for the fine tuning of R channel and the range is ±3dB. Digital Blue: This is for the fine tuning of B channel and the range is ±3dB.

Note: If WhiteBalace(Balance Ratio) is set, the level of Analog Red and Analog Blue is

applied.

11.4.1 GainAuto

This is the auto level control using Gain command. JAI AGC Reference can control the brightness of the auto gain. GainAuto select OFF, Once or Continuous. The adjusting range is:

JAI AGC Reference： 0 to 255 Gain ： 0 to 15dB（5.6 times）

11.5. BlackLevel

The black level of the image can be controlled by 1 LSB step for 10bit output.

11.6. Linear matrix

The AT-200GE incorporates a linear color matrix circuit to improve color reproduction. As this circuit processes signals in the linear stage, before the gamma correction circuit, the gamma circuit does not affect color reproduction. The linear matrix is set by “Color Transformation Selector”. This is “OFF” at the default setting.

This circuit has:

1. Linear : OFF

2. RGB to RGB : The individual setting for R,G or B is possible.

3. RGB to Custom 1 : sRGB setting. Standard which HP and Microsoft

specify for printers and monitors. This preset is based on this standard.

4. RGB to Custom 2 : Adobe RGB setting. Standard which Adobe systems specify. This preset is based on this standard.

Important Note:

If sRGB or Adobe RGB is used, please note the following procedure.

1) Achieve the white balance under the condition of D65 (6500K) illumination.

2) Gamma should be set at 0.45 and set the linear matrix at either sRGB or Adobe RGB.

3) Monitor should comply with sRGB or Adobe RGB color reproduction capability.

AT-200GE

- 62 -

11.7. LUT (Look Up Table) and gamma

The AT-200GE uses LUT(Look UP Table) to adjust the gamma. JAI LUT mode is used for this function. If LUT is selected, the required gamma characteristics can be achieved. The gamma can be set from 1.0 to 0.45.

Fig.50 Gamma setting

Note: The analog signal is used only internally.

11.8. Test pattern generator

The AT-200GE has an internal test pattern generator. These signals are output as the last process of the digital signal processing circuit and can be used for adjustment of the related system. The AT-200GE has a total of 6 test pattern types.

Gray Horizontal ramp Gray Vertical Ramp Gray Horizontal Ramp Moving

(The starting point of the gradation

moves to the right.)

Gray Vertical Ramp Moving Color Bar

(The starting point of the gradation moves to the bottom.)

Fig.51 Test patterns

CCD out

Analog Signal

Digital Out(32bit)

Digital Out(24bit)

Black

Setup 3.6%, 25mV

32LSB

8LSB

200mV

700mV

890LSB

222LSB

230mV↑

800mV

1023LSB

255LSB

AT-200GE

- 63 -

12. Examples of operation using JAI Control Tool

Special attention: In this chapter, the images for AT-140GE are used for

explanation purpose.

12.1. About GenICamTM SFNC1.3

The AT-200GEis designed as conforming to GenICam SFNC1.3. GenICam SFNC stands for GenICam Standard Feature Naming Convention. By defining the standard cases and the standard features, general-purpose software can control cameras from any manufacturers which conform to the GenICam standard.

JAI, in the past, used traditional feature names in order to maintain naming continuity with previous cameras. However, starting with the AT-140GE and after, JAI GigE Vision cameras will now fully comply with GenICam SFNC feature names.

Accordingly, terminologies used for functions will be much different from previous models. This manual explains the basic operation using feature names specified in the GenICam SFNC 1.3 specification.

The latest version of JAI GigE Vision cameras comply with GenICam SFNC1.3. However, JAI can offer the following options for customers who use older versions of GIgE Vision cameras.

JAI provides the following software.

1. Version prior to SFNC 1.3 for older camera version

2. Downgrade to old version from the latest SFNC 1.3 version

Please contact local sales representatives for the details

12.2. JAI SDK Ver.1.3

JAI SDK has also been upgraded to version 1.3. In a GigE Vision compliant camera, all features are described in the XML file inside the camera and after connecting JAI Control Tool software, all features are downloaded to the JAI Control Tool software. If customers use older versions of cameras together with the Control Tool software ver.1.3, feature properties shown in the Control Tool exhibit old features name, enabling customers to operate cameras in a familiar way.

If the latest version of the camera is connected, some traditional JAI feature names such as JAI Preset Shutter, will display in the Feature Properties in addition to the newer GenICam SFNC 1.3 names.

These feaures can be set as usual and settings for those features are reflected automatically in the GenICam SFNC 1.3 feature names.

The features shown above will vary depending on the specific camera.

AT-200GE

- 64 -

12.3. Examples of camera operation

The following explains the operation of the camera using the GenICam SFNC 1.3 Control Tool.

12.3.1 Operational cautions

1. Features shaded gray in the Features Properties can not be set.

2. If the image size is to be changed, image capturing should first be stopped before setting the size parameters.

12.3.2 Connecting camera(s)

Connect the camera to the network. If the connection is established, start the JAI Control Tool. The model name of the connected camera and icon will be displayed in the screen.

After clicking the icon, the status will change to indicate the camera is successfully

connected to the Control Tool.

12.2.3 Camera setting layers

GenICam has 3 levels of settings. Those are Beginner, Expert and Guru. The number of available settings increase with each level up to a maximum in the Guru layer.

The following examples of Acquisition control menus illustrate how settings expand from level to level.

AT-200GE

- 65 -

Beginner

Expert

Guru

AT-200GE

- 66 -

12.4. Input and output settings

12.4.1. Connection with the external devices

The relation of the line input and output (Digital I/O) and the external terminal in the JAI GigE Vision cameras is fixed. Refer to section 6.1 for the details.

In the Control Tool, they are displayed as Line1-TTL Out 1.

Note: These settings are only available in the Expert and Guru setting layers.

12.4.2. Setting inputs and outputs

12.4.2.1 Select signal to connect with Line which is selected by Line selector

This function determines which signal is connected with Digital I/O (Line 1 through

Line 8). The following figure is an example of setting Line 5 –Opt In 1. In this case, Line Source is the signal to connect with Line 5 -Opt In 1. But Frame Active is available for only output and accordingly, it is not selectable in the Control tool. Line Format is automatically set at Opto Coupled.

The following figure is an example of setting output so that the signal output from Line1 – TTL Out 1is selected from signals in the Line Source. In this case, Exposure Activeis selected to output through TTL Out 1. TTL is automatically selected as Line Format.

AT-200GE

- 67 -

12.4.2.2 Select Trigger Source

Which signal is used as the trigger signal can be configured by the Trigger Source in the Trigger Selector of Acquisition Control. In the following figure, Frame Start is selected as the trigger and the trigger source is configured Line7 – TTL In 1. In the following picture, Trigger Mode is OFF. But to activate the trigger, it should be set ON.

12.4.3. Specify the image size to be captured

Refer also to the chapter 7.2. The following parameters are required to specify the image size. OFFSET X Specify the starting position of the image in the horizontal

direction Width Specify the width of the image OFFSET y Specify the starting line of the image Height Specify the height of the image

AT-200GE

- 68 -

In order to readout full pixels,

OFFSET x = 0

Width = Maximum number of pixels in the horizontal direction

OFFSET y =4

Height= Maximum number of pixels in the vertical direction

In the AT-200GE, total pixels include pixels in the OB. In order to transfer the full pixel image without OB, a setting of OFFSET x = 0 and OFFSET y = 4 is the starting point. Refer to the chapter 7.2.2.

Beginner

Expert , Guru

Full pixels readout Full pixels and OB ( part )

AT-200GE

- 69 -

Line Pitch is explained in chapter 7.9. The resulting image is shown on the right. This is the result of Line Pitch set to 2088 which is half of full width. The half image, starting from the beginning of the full image is enlarged and output. (This is a picture captured in TIFF)

12.4.4. Acquisition of the image

The settings related to image acquisition are configured in the Acquisition Control. The following shows theAcquisition Control screen (Guru layer)

AT-200GE

- 70 -

After setting the acquisition, click Start Acquisition button.

12.4.4.1 Basic settings

The basic setting items are Acquisition Mode, Trigger Selector, Exposure Mode.

Acquisition Mode

Acquisition Mode can be selected from Continuous, Single Frame and Multi Frame.

Continuous: If the trigger is input, the image is continuously captured.

In order to stop the acquisition, Acquisition End command must be executed.

Single Frame: If the trigger is input, only one frame is captured and after the

completion of capturing, the acquisition is automatically stopped.

Multi Frame: If the trigger is input, frames which are set by Acquisition Frame

Count are captured and after the completion of capturing, the acquisition is automatically stopped.

Trigger Selector

AT-200GE

- 71 -

Trigger Selector includes Acquisition Start and Acquisition End commands which determine the start point and end point of acquisition, and Trigger commands which set the trigger timing.

Acquisition Start has ON or OFF setting. Refer to chapter XX for the details.

ON: In this case, if Acquisition Start Trigger is applied, the status is waiting the

trigger input. The acquisition starts in the order of Acquisition start Trigger input and Trigger signal input.

OFF: In this case, the camera runs freely. If the trigger signal is input, the

acquisition starts immediately.

Trigger setting

Select from Frame Start, Exposure Start, Exposure End and JAI Acquisition Transfer Start and set the details.

Frame Start: The exposure starts at the point of frame start. Exposure Start : The exposure starts at the point of exposure start. Exposure End : This command stops the exposure. This is used together with Exposure Start and Trigger Controlled. JAI Acquisition Transfer Start : This command makes the delayed readout from the

camera effective.

Exposure Mode setting

Timed : The exposure is effective only for setting duration. Trigger Width : The exposure time is equal to the trigger width. Trigger Controlled : Exposure Start Trigger starts the exposure and

Exposure End stops the exposure.

AT-200GE

- 72 -

12.4.5. Setting examples

12.4.5.1 Capture the image continuously with fastest frame rate

Acquisition Mode

Continuous

Acquisition Frame Rate

20.814 fps

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : OFF

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

OFF or Timed

Exposure Time

Any value

If Exposure Mode is Timed

12.4.5.2 Capture the image with a half of the frame rate (increasing the sensitivity)

Acquisition Mode

Continuous

Acquisition Frame Rate

10 fps

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : OFF

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

OFF or Timed

Exposure Time

Any value

If Exposure Mode is Timed

12.4.5.3 Capture one frame of the image with preset exposure time using the external trigger

Acquisition Mode

Single Frame

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : ON

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Timed

Exposure Time

Any value

AT-200GE

- 73 -

Frame Start settings

Trigger Source

Choose from the above selection

Trigger Activation

Rising Edge, Falling Edge, Any Edge

Trigger Overlap

Off or Read Out

Trigger Delay

Any value、 Normally set to 0

12.4.5.4 Capture multi frames of the image with preset exposure time using the external trigger

In the 12.4.5.3 example, the following setting should be changed.

Acquisition Mode

Multi Frame

Acquisition Frame Count

Any value which can be set

12.4.5.5 Capture one frame of the image with the trigger width using the external trigger

Acquisition Mode

Single Frame

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : ON

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Trigger Width

AT-200GE

- 74 -

Frame Start setting

Trigger Source

Choose from the above selection

Trigger Activation

Level High or Level Low

Trigger Overlap

Off or Read Out

Trigger Delay

Any value、 Normally set to 0

12.4.5.6 Capture multi frames of the image with the trigger width using

the external trigger

In the example 12.4.5.5, the following setting should be changed.

Acquisition Mode

Multi Frame

Acquisition Frame Count

Any value which can be set

12.4.5.7 Capture the image continuously with preset exposure time by using the external trigger

Acquisition Mode

Continuous

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : ON

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Timed

Exposure Time

Any value

AT-200GE

- 75 -

Frame Start setting

Trigger Source

Choose from the above selection

Trigger Activation

Rising Edge, Falling Edge, Any Edge

Trigger Overlap

Off or Read Out

Trigger Delay

Any value、 Normally set to 0

12.4.5.8 Capture the image by Exposure Start trigger and stop by Exposure End.

Acquisition Mode

Single Frame

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : OFF

Exposure Start

Trigger mode : ON

Exposure Stop

Trigger Mode: ON

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Trigger controlled

Exposure Start and Exposure End setting

For each item, the following should be set.

Trigger Source

Choose from the above selection

Trigger Activation

Rising Edge, Falling Edge, Any Edge

Trigger Overlap

Off

Trigger Delay

AT-200GE

- 76 -

12.4.5.9 Capture the image using Software Trigger

Acquisition Mode

Continuous

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition Stop

Trigger mode : OFF

Frame Start

Trigger mode : ON

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

OFF or Timed

Exposure Time

Any value

Exposure Mode=Timed の場合

Frame Start setting

Select “Software” in the Trigger Source and execute Trigger Software command.

Software trigger is generated inside the camera and the settings are not changed. Therefore, it is useful if the customer tests the trigger function.

In order to use the software trigger, use “User Output”.

Select User Output, and select the same user output in the Trigger Source.

AT-200GE

- 77 -

12.4.5.10 Sequence Trigger setting

Set Video Send mode selector in the JAI Custom Control to Sequence mode. Then, set each image by Sequence ROI Index in the JAI Custom Control.

The following example is for Index0 and one frame is captured.

Then, in the Sequence ROI Next Index, the next image is set. Other images are set in the same manner. Next index can also set the order of capturing the images. In order to stop the sequence, the next index of the last index should be set “OFF”.

12.4.5.11 Multi ROI setting

Set “Video Send Mode Selector” in the JAI Custom Control to “Multi ROI mode”.

Set the image selected by ROI Index. The following example is Index 0.

AT-200GE

- 78 -

Then, the next image is set by Multi ROI Next Index. The following example is for Index 1.

After that, set the image of Index 1 by Multi ROI Index.

While repeating the above procedure, set the necessary ROI. Maximum of 5 images

can be set. On the last image setting, set “Multi ROI Next Index” to “OFF”.

12.4.5.12 Delayed readout setting

If a system using multiple cameras is configured, it can use delayed

readout in order to improve the traffic in the PC port. Refer to the chapter xx.

Setting: Trigger selector: JAI Acquisition Transfer Start Trigger mode: ON

This should be applied to all connecting cameras.

12.4.5.13 Operate the external strobe light

“Exposure Active” can be used as the strobe driven signal.

Then set “LINE” for signal output. The following example selects Line 1- TTL Out 1 as the output terminal.

AT-200GE

- 79 -

12.4.5.14 Achieve white balance using individual exposure time for R,G,B

In the AT-200GE, if “Exposure Mode” is set to “Timed” , it is possible to

white balance by adjusting individual exposure times for R, G and B channels.

A better S/N ratio can be achieved as compared to using gain.

Select each R, G or B channel in the ”JAI Exposure Time Selector”.

Set the exposure time for each channel in the “JAI Exposure Time”.

12.4.6 How to view the XML file

All features and registers are stored in the camera as an XML file. The XML file is stored in the following folder. This is for SDK 1.4.0 version.

Program ⇒ JAI ⇒ SDK ⇒ GenICam ⇒ XML ⇒ Transportlayers ⇒ JAI

AT-200GE

- 80 -

13. External Appearance and Dimensions

Note: Rear protrusion on C-mount lens must be less than 4.0mm

Fig. 52 Outline

AT-200GE

- 81 -

14. Specifications

14.1. Camera sensitivity response

Fig.53 AT-200GE Camera Sensitivity response

0.000

10.000

20.000

30.000

40.000

50.000

60.000

70.000

80.000

90.000

100.000

400 45 0 50 0 550 60 0 65 0 70 0 750 80 0

Gch

Bch Rch

AT-200GE Camera Sensitivity Response

Wave Length (nm)

Relative Sensitivity Response (%)

AT-200GE

- 82 -

14.2. Specification table

Specifications

AT-200GE

Optical system

1/1.8 inch F4.0 prism

Scanning system

Progressive

Synchronization

Int. X-tal

CCD sensors

3 x 1/1.8” IT CCD on prism. Sony ICX274AL

Sensing area

7.15 (h) x 5.44 (v) mm 1/1.8 inch diagonal

Cell size

4.4 (h) x 4.4 (v) m

Active Image Output pixels

1624 (h) x 1236 (v)

Pixel clock

37.125 MHz

Scanning lines

More than 1248 lines (Binning Vertical=1, Full area readout)

Horizontal frequency / Vertical frequency (Frame rate) at Continuous mode

Effective/total line

Horizontal freq.

Frame rate

Full area

Binning Vertical=1

1236 / 1248

19.276 KHz

15.45 fps (*1)

Minimum line setting

Binning Vertical=1

8 / 156

19.276 KHz

123.56 fps (*2)

Vertical binning

Binning Vertical=2

618 / 628

17.381 KHz

27.68 fps

*1: In the condition of full area readout and fastest frame rate

*2: In the condition of 8 lines readout and fasted frame rate

Horizontal Binning

Binning horizontal= 1(OFF), 2(ON)

The frame rate and line rate is not changed.

OB transfer mode

ON / OFF

Digital Video output

GigE Vision interface

RGB8Packed, RGB10V1Packed, RGB10V2Packed

Video output for lens iris

0.7 V p-p, 75  NUM luminance signal w/o Sync

Sensitivity (on sensor) (min.)

0.62 Lux, (full frame, gain=+15dB, trigger=OFF, 50% video

S/N ratio

>50 dB. (0dB gain)

Inputs

HIROSE 12 pin: OPT x 2

HIROSE 9 pin : TTL/75Ω x 1, LVDS x 1

Outputs

HIROSE 12 pin: OPT x 2

HIROSE 9 pin: TTL x 2

Gain Gain range

Analog Analog All (Master gain) : 0db to +15dB (0.0359dB/step) Analog Red (R gain) : -6dB to +6dB (0.0359dB/step) Analog Blue (B gain) : -6dB to +6dB (0.0359dB/step)

Digital Digital All (Digital Master gain) : -3dB to +3dB (0.0541dB /step) Digital Red (R gain) : -3dB to +3dB (0.0541dB /step) Digital Blue All (B gain) : -3dB to +3dB (0.0541dB /step)

Acquisition Control

Single frame, Multi frame ,Continuous

Trigger Control

Acquisition start, Acquisition end, Frame start, Exposure start, Exposure end

JAI Acquisition transfer start

Exposure Control

In conjunction with the trigger control, the operation mode can be set.

1.OFF

2.Timed: Setting unit is: Trigger mode OFF(Self running) : 1 line step (*1) Trigger mode ON: 1μ second step (*2)

3.Trigger width: Exposure for the pulse width duration

4.Trigger controlled : Exposure the duration between start and stop

*1) Timed: Trigger mode OFF Clock =1 line, Counter for exposure =16bit *2)Trigger mode ON Clock 1MHz, Counter for exposure=16bit

Timer function

X 1 ( Clock=1MHz, Timer counter and timer delay counter = 16bit)

Counter function

X 1 (Counter=16bit)

Event message

The internal signal status can be output as the event message

White balance

Manual/one push, continuous,

Gain range: -6 to +6 dB / tracking range 4000K to 9000K

White balance setting in factory: 7500K

AT-200GE

- 83 -

LUT / Gamma

LUT or gamma can be selected

LUT :Setting point 1024, 10bit

Gamma :1.0 to 0.45

Linear Matrix

Manual for R, G and B / Preset (sRGB, Adobe RGB)

Shading Compensation

ON /OFF (Color shading and flat field shading)

Black level

± 128LSB (at 10bit output)

Event message

Exposure start, Exposure end, Trigger IN, Video start, Video end, GPIO status

Video output connector

RJ-45 x 1

Control interface

Gigabit Ethernet (IEEE802.3, ATA GigE Vision Standard)

Packet size can be set from 1476 bytes to 16K(16020) bytes. (Default is 1476)

Operating temperature

-5C to +45C.

Humidity

20 - 80% non-condensing

Storage temp./humidity

-25C to 60C/20% - 80% non-condensing

Vibration

3 G (15 Hz – 200 Hz in XYZ)

Shock

50 G

Regulations

CE (EN 61000-6-2, EN 61000-6-3), FCC part 15 class B, RoHS

Power

10.8V to 26.4V DC, 0.67 A (Typical , Full frame, DC +12V in)

Lens mount

C-mount (Rear protrusion on C mount must be less than 4mm)

The lens used should be designed for 3CCD cameras.

Flange back

17.526mm, Tolerance +0 to –0.05mm

Optical axis

Center 0.1mm

Dimensions

55 x 55 x 98.3 mm (HxWxD)

Weight

340g

Note: 1) Above specifications are subject to change without notice

2) Specifications are valid after a 30 min. warm up period.

AT-200GE

- 84 -

Appendix

1. Precautions

Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera. Do not expose this camera to rain or moisture. Do not face this camera towards the sun, extreme bright light or light reflecting objects. When this camera is not in use, put the supplied lens cap on the lens mount. Handle this camera with the maximum care. Operate this camera only from the type of power source indicated on the camera. Power off the camera during any modification, such as changes of jumper and switch settings.

2. Typical Sensor Characteristics

The following effects may be observed on the video monitor screen. They do not indicate any fault of the camera, but are associated with typical sensor characteristics.

V. Aliasing

When the CCD camera captures stripes, straight lines or similar sharp patterns, jagged image on the monitor may appear.

Blemishes

All cameras are shipped without visible image sensor blemishes. Over time some pixel defects can occur. This does not have a practical effect on the operation of the camera. These will show up as white spots (blemishes). Exposure to cosmic rays can cause blemishes to appear on the image sensor. Please take care to avoid exposure to cosmic rays during transportation and storage. It is recommended using sea shipment instead of air flight in order to limit the influence of cosmic rays on the camera. Pixel defects/blemishes also may emerge due to prolonged operation at elevated ambient temperature, due to high gain setting, or during long time exposure. It is therefore recommended to operate the camera within its specifications.

Patterned Noise

When the sensor captures a dark object at high temperature or is used for long time integration, fixed pattern noise may appear on the video monitor screen.

3. Caution when mounting a lens on the camera

When mounting a lens on the camera dust particles in the air may settle on the surface of the lens or the image sensor of the camera. It is therefore important to keep the protective caps on the lens and on the camera until the lens is mounted. Point the lens mount of the camera downward to prevent dust particles from landing on the optical surfaces of the camera. This work should be done in a dust free environment. Do not touch any of the optical surfaces of the camera or the lens.

AT-200GE

- 85 -

4. Caution when mounting the camera

When you mount the camera on your system, please make sure to use screws of

the recommended length described in the following drawing. Longer screws may cause serious damage to the PCB inside the camera.

If you mount the tripod mounting plate, please use the provided screws.

5. Exportation

When exporting this product, please follow the export regulation of your own country.

6. References

1. This manual and datasheet for the AT-200GE can be downloaded from www.jai.com

2. Camera control software can be downloaded from www.jai.com

Camera chassis

Fixing plate

Mounting the camera to fixing plate

4.5mm　±　0.2mm

Camera chassis

Tripod mount

4.5mm　±　0.2mm

Attaching the tripod mount

AT-200GE

- 86 -

Change history

Date

Revision

Changes

Jan.2011

1.0

New release

Oct 2011

1.1

Correct typo

Mar. 2012

1.2

Add the description of how to perform the shading compensation

May 2012

1.3

Delete Blemish Compensation function

May 2012

1.4

Change the description on section 6.4 and 6.5. Change fig 14 and 15.

Jan. 2015

1.5

Correct the white balance reference color temperature from 7800K to 7500K.

AT-200GE

- 87 -

User's Record

Camera type: AT-200GE

Revision: ……………..

Serial No. ……………..

Firmware version. ……………..

For camera revision history, please contact your local JAI distributor.

User's Mode Settings.

User's Modifications.

Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
