IAI AM-200GE, AB-200GE User Manual

Download

User Manual

AM-200GE

AB-200GE

2M Digital Progressive Scan

Monochrome and Color Camera

Document Version:1.1

AM/AB-200GE_Ver.1.1_Sept2013

1035E-1110

AM-200GE

Supplement

The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。

方忖仝15々葎豚㍉15定。

AB-200GE

Supplement

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

方忖仝15々葎豚㍉15定。

AM-200GE / AB-200GE

Notice

The material contained in this manual consists of information that is proprietary to JAI Ltd.,

Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein. JAI Ltd., Japan reserves the right to make changes without notice.

Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners.

Warranty

For information about the warranty, please contact your factory representative.

Certifications

CE compliance

As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC (Electromagnetic compatibility), JAI Ltd., Japan declares that AM-200GE and AB-200GE complies with the following provisions applying to its standards. EN 61000-6-3 (Generic emission standard part 1) EN 61000-6-2 (immunity)

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning

Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could void the user’s authority to operate the equipment.

- 1 -

AM-200GE / AB-200GE

Table of Contents

JAI GigE® Vision Camera operation manuals ............................................ - 7 -

Introduction ................................................................................... - 7 -

Before using GigE Vision camera .......................................................... - 7 -

Software installation ......................................................................... - 7 -

Camera Operation ............................................................................ - 8 -

1. General ..................................................................................... - 8 -

2. Camera nomenclature ................................................................... - 8 -

3. Main Features .............................................................................. - 9 -

4. Locations and Functions ................................................................ - 10 -

4.1. Locations and functions ................................................................................ - 10 -

4.2. Rear panel indicator .................................................................................... - 11 -

5. Pin Assignment ........................................................................... - 12 -

5.1. 12-pin Multi-connector (DC-IN/Digital IO) ............................................................ - 12 -

5.2. Digital Output Connector for Gigabit Ethernet..................................................... - 12 -

5.3. D-Sub 9pin connector (For GPIO) ................................................................... - 13 -

5.4. DIP switch ................................................................................................. - 13 -

5.4.1 SW-900 .............................................................................................. - 13 -

5.4.2 SW-500 .............................................................................................. - 14 -

5.4.3 SW-901 .............................................................................................. - 14 -

6. Input and output Interface .......................................................... - 15 -

6.1. Digital Interface ......................................................................................... - 15 -

6.1.1 LineSelector ........................................................................................ - 15 -

6.1.2 LineInverter ........................................................................................ - 15 -

6.1.3 LineStatus ........................................................................................... - 15 -

6.1.4 LineSource .......................................................................................... - 15 -

6.1.5 LineMode ............................................................................................ - 15 -

6.1.6 LineFormat ......................................................................................... - 15 -

6.2. Opto-isolated Interface ................................................................................ - 16 -

6.2.1 Recommended External Input circuit diagram for customer .............................. - 16 -

6.2.2 Recommended External Output circuit diagram for customer ............................ - 16 -

6.2.3 Optical Interface Specifications ................................................................ - 17 -

6.3. Iris video output ......................................................................................... - 17 -

6.4. Trigger input ............................................................................................. - 19 -

6.5. Exposure Active output ................................................................................. - 19 -

7. Video signal output .................................................................... - 20 -

7.1. Video output image ..................................................................................... - 20 -

7.2. AOI (Area of Interest) ................................................................................... - 21 -

7.2.1 AOI parameters ................................................................................... - 21 -

7.2.2 AOI setting details ................................................................................ - 21 -

7.2.2.1 When only the image part is transmitted (OB is not transferred) .................... - 21 -

7.2.2.2 When the full image plus the vertical OB is transmitted .............................. - 22 -

7.2.2.3 When the full image plus the horizontal OB is transmitted ............................ - 22 -

7.2.3 Frame rate calculation in the AOI mode ...................................................... - 22 -

7.2.3.1 Binning control setting : off or 2x1 (Binning Vertical=1) ............................. - 22 -

7.2.3.2 Binning control setting : 1x2 or 2x2 (Binning Vertical=2) .............................. - 23 -

7.2.4 The relationship between LinePitch and Width .............................................. - 23 -

7.3. In case of vertical binning and horizontal binning (Only for AM-200GE) ....................... - 23 -

7.3.1 The relationship between Binning Horizontal and Width/LinePitch ..................... - 24 -

7.3.2 The relationship between Binning Vertical and Height ..................................... - 24 -

7.4. Digital video output (Bit allocation) ................................................................. - 24 -

7.5. Bayer output pattern ................................................................................... - 25 -

7.6. Pixel format and pixel type ............................................................................ - 25 -

7.6.1 GVSP_PIX_MONO8 (8bit output) ................................................................ - 25 -

- 2 -

AM-200GE / AB-200GE

7.6.2 GVSP_PIX_MONO10 (10bit output) .............................................................. - 26 -

7.6.3 GVSP_PIX_MONO10_Packed (10bit output) ................................................... - 26 -

7.6.4 GVSP_PIX_MONO12 (12bit ourput) .............................................................. - 26 -

7.6.5 GCSP_PIX_MONO12_Packed (12bit output) ................................................... - 26 -

7.6.6 GCSP_PIX_BAYERGR8 (8bit output)............................................................. - 26 -

7.6.7 GVSP_PIX_BAYERGR10 (10bit output) ......................................................... - 26 -

7.6.8 GVSP_PIX_BAYERGR10_Packed .................................................................. - 26 -

7.6.9 GVSP_PIX_BAYERGR12 (12bit output) ......................................................... - 27 -

7.6.10 GVSP_PIX_BAYERGR12_Packed ................................................................ - 27 -

7.6.11 GVSP_PIX_RGB8_PACKED (24bit) (Interpolation) ........................................... - 27 -

7.6.12 GVSP_PIX_ YUV422_PACKED (16bit) .......................................................... - 27 -

7.6.13 The relationship between PixelFormat and PixelSize. .................................... - 27 -

7.7 YUV output................................................................................................. - 28 -

7.8. Video output timing ..................................................................................... - 28 -

7.8.1 Vertical timing (8bit, 10 bit or 12bit for Bit allocation) .................................... - 28 -

7.8.1.1 If the binning control is OFF or 2x1, AOI default setting ............................... - 28 -

7.8.1.2 If the binning control is OFF or 2x1, AOI setting ........................................ - 29 -

7.8.1.3 If the binning control is 1x2 or 2x2, AOI default setting ............................... - 29 -

7.8.1.4 If the binning control is 1x2 or 2x2, AOI setting ........................................ - 30 -

7.8.2 Horizontal timing .................................................................................. - 30 -

7.8.2.1 If the binning control is OFF or 2x1 ........................................................ - 30 -

7.8.2.2 If the binning control is 1x2 or 2x2 ........................................................ - 31 -

6.4.3 DVAL output if the Binning control is set to 2=2x1 or 3=2x2 .............................. - 31 -

7.8.2.3 LVAL-LOW level period ....................................................................... - 31 -

8. Network configuration ................................................................ - 33 -

8.1. GigEVision Standard interface ......................................................................... - 33 -

8.2. Equipment to configure the network system ....................................................... - 33 -

8.2.1 PC .................................................................................................... - 33 -

8.2.2 Cables ............................................................................................... - 33 -

8.2.3 Network card (NIC) ................................................................................ - 33 -

8.2.4 Hub ................................................................................................... - 34 -

8.3. Recommended Network Configurations ............................................................. - 34 -

8.3.1 Guideline for network settings ................................................................. - 34 -

8.3.2 Video data rate (network bandwidth) ......................................................... - 35 -

8.3.2.1 Exposure function ............................................................................. - 35 -

8.3.3 Note for setting packet size ..................................................................... - 36 -

8.3.4 Calculation of Data Transfer Rate .............................................................. - 36 -

8.3.5 Simplified calculation (Approximate value) .................................................. - 37 -

8.4. GigE camera connecting examples ................................................................... - 38 -

8.4.1 Using a switching hub for 1 port ................................................................ - 38 -

8.4.2 Connecting a camera to each port of a multi-port NIC ..................................... - 38 -

8.4.3 The data transfer for multiple cameras ....................................................... - 39 -

8.4.3.1 If delayed readout is not used in continuous mode ..................................... - 39 -

8.4.3.2 If delayed readout is not used in trigger mode .......................................... - 39 -

8.4.3.3 If delayed readout is used ................................................................... - 40 -

9. Core functions ............................................................................ - 41 -

9.1. Acquisition function ..................................................................................... - 41 -

9.1.1 Basic image acquisition flow .................................................................... - 41 -

9.1.2 Acquisition mode .................................................................................. - 42 -

9.1.2.1 Single Frame ................................................................................... - 42 -

9.1.2.2 MultiFrame ..................................................................................... - 43 -

9.1.2.3 Continuous mode .............................................................................. - 44 -

9.1.3 AcquisitionAbort ................................................................................... - 44 -

9.1.4 AcquisitionFrameCount ........................................................................... - 45 -

9.1.5 AcquisitionFrameRate ............................................................................ - 45 -

9.1.6 AcquisitionStatus .................................................................................. - 45 -

- 3 -

AM-200GE / AB-200GE

9.2. Trigger Control ........................................................................................... - 47 -

9.2.1 TriggerSelector(TriggerMode) ................................................................... - 47 -

9.2.1.1 Acquisition ...................................................................................... - 47 -

9.2.1.2 Exposure ........................................................................................ - 47 -

9.2.2 Triggersoftware .................................................................................... - 48 -

9.2.3 Triggersource ....................................................................................... - 48 -

9.2.4 TriggerActivation ................................................................................... - 49 -

9.2.4.1 Initial Trigger Activation Set ................................................................ - 49 -

9.2.5 TriggerOverlap ..................................................................................... - 50 -

9.2.6 Triggerdelay ........................................................................................ - 50 -

9.3. Exposure Control ........................................................................................ - 50 -

9.3.1 Exposure Mode ..................................................................................... - 50 -

9.3.2 ExposureTime ...................................................................................... - 51 -

9.3.3 ExposureAuto....................................................................................... - 51 -

9.4. Counter function......................................................................................... - 51 -

9.4.1 CounterSelector ................................................................................... - 51 -

9.4.2 CounterEventSource .............................................................................. - 51 -

9.4.3 CounterEventActivation .......................................................................... - 52 -

9.4.4 CounterResetSource .............................................................................. - 52 -

9.4.5 CounterResetActivation .......................................................................... - 52 -

9.4.6 CounterReset ....................................................................................... - 52 -

9.4.7 CounterValue ....................................................................................... - 52 -

9.4.8 CounterDuration ................................................................................... - 52 -

9.4.9 CounterStatus ...................................................................................... - 52 -

9.4.10 CounterTriggerSource ............................................................................ - 53 -

9.4.11 CounterTriggerActivation ....................................................................... - 53 -

9.5. Timer Control ............................................................................................ - 54 -

9.5.1 TimerSelector ...................................................................................... - 54 -

9.5.2 TimerDuration ..................................................................................... - 54 -

9.5.3 TimerDelay ......................................................................................... - 54 -

9.5.4 TimerValue ......................................................................................... - 54 -

9.5.5 TimerStatus ........................................................................................ - 54 -

9.5.6 TimerTriggerSource ............................................................................... - 54 -

9.5.7 TimerTriggerActivation ........................................................................... - 55 -

9.6. Event Control ............................................................................................. - 55 -

9.6.1 EventSelector ...................................................................................... - 55 -

9.7. ActionControl............................................................................................. - 55 -

9.7.1 ActionDeviceKey ................................................................................... - 55 -

9.7.2 ActionSelector ..................................................................................... - 55 -

9.7.3 ActionGroupMask .................................................................................. - 55 -

9.7.4 ActionGroupKey.................................................................................... - 55 -

10. Operation modes ...................................................................... - 56 -

10.1. Continuous mode (Free run) ......................................................................... - 56 -

10.2. Trigger operation with “timed” exposure (Previously called EPS) ............................ - 57 -

10.2.1 TriggerOverlap = OFF ............................................................................ - 58 -

10.2.2 TriggerOverlap = Read out ..................................................................... - 58 -

10.2.3 SmearLess ON ..................................................................................... - 58 -

10.3. Trigger operation by “TriggerWidth” (Previously called PWC) ................................ - 59 -

10.3.1 TriggerOverlap = OFF ............................................................................ - 60 -

10.3.2 TriggerOverlap = Read out ..................................................................... - 60 -

10.4. Pre-dump mode (so-called RCT) (JAI Custom) .................................................... - 61 -

10.5. PIV (Particle Image Velocimetry) (JAI Custom) ................................................... - 62 -

10.6 Other JAI custom mode ................................................................................ - 63 -

10.6.1 Video Send Mode ................................................................................. - 63 -

10.6.1.1 Normal: Ordinal operation ................................................................. - 63 -

10.6.1.2 Sequence Trigger Mode ..................................................................... - 63 -

- 4 -

AM-200GE / AB-200GE

10.6.1.3 Multi ROI Mode ............................................................................... - 65 -

10.6.2 Delayed Readout Mode (JAI Custom Control) ............................................... - 65 -

10.6.3 OB transfer ........................................................................................ - 66 -

10.6.3.1 Vertical OB transferred ..................................................................... - 67 -

10.6.3.2 Horizontal OB transferred .................................................................. - 67 -

10.6.3.3 OB transfer is not activated ............................................................... - 68 -

10.7. Mode and function matrix table ..................................................................... - 68 -

11. Other functions ....................................................................... - 69 -

11.1. ALC ....................................................................................................... - 69 -

11.2 Black level control ...................................................................................... - 69 -

11.2.1 Black level control relations ................................................................... - 70 -

11.2.2 Black Level Selector ............................................................................. - 70 -

11.2.3 Black Level ........................................................................................ - 70 -

11.2.4 Black Level Auto ................................................................................. - 70 -

11.3. Gain control ............................................................................................. - 71 -

11.3.1 Gain control relations ........................................................................... - 71 -

11.3.2 Gain Control ...................................................................................... - 71 -

11.3.3 Gain selector ..................................................................................... - 72 -

11.3.4 Gain ................................................................................................ - 72 -

11.3.5 Gain Raw .......................................................................................... - 73 -

11.3.6 Gain Auto .......................................................................................... - 73 -

11.4. Tap Balance ............................................................................................. - 73 -

11.4.1 Gain Auto Balance ............................................................................... - 73 -

11.4.2 Automatic Tap Balance ......................................................................... - 74 -

11.4.3 Manual Tap Balance ............................................................................. - 74 -

11.4.4 Once Tap Balance ................................................................................ - 74 -

11.5. Exposure auto (Auto Shutter) ........................................................................ - 74 -

11.6. Balance Ratio (Only for AB-200GE) ................................................................. - 74 -

11.6.1 Balance Ratio ..................................................................................... - 75 -

11.6.2 Balance Ratio Auto .............................................................................. - 75 -

11.7. Blemish compensation ................................................................................ - 75 -

11.8. LUT ....................................................................................................... - 76 -

11.9 Gamma .................................................................................................... - 77 -

11.10. Shading Correction ................................................................................... - 78 -

11.11. Bayer color interpolation (Only for AB-200GE) .................................................. - 79 -

11.12. Test Image selector .................................................................................. - 79 -

11.13. Temperature sensor .................................................................................. - 80 -

12. Examples of operation using JAI Control Tool .................................. - 81 -

12.1. About GenICamTM SFNC1.3 ............................................................................ - 81 -

12.2. Examples of camera operation ...................................................................... - 81 -

12.2.1 Operational cautions ............................................................................. - 81 -

12.2.2 Connecting camera(s) ........................................................................... - 81 -

12.2.3 Camera setting layers ........................................................................... - 82 -

12.4. Input and output settings ............................................................................. - 83 -

12.4.1. Connection with the external devices ...................................................... - 83 -

12.4.2. Setting inputs and outputs .................................................................... - 84 -

12.4.2.1 Select signal to connect with Line which is selected by Line selector ............. - 84 -

12.4.2.2 Select Trigger Source ....................................................................... - 84 -

12.4.3. Specify the image size to be captured ...................................................... - 85 -

12.4.4. Acquisition of the image ....................................................................... - 86 -

12.4.4.1 Basic settings ................................................................................. - 86 -

12.4.5. Setting examples ................................................................................ - 88 -

12.4.5.1 Capture the image continuously with fastest frame rate ............................ - 88 -

12.4.5.2 Capture the image with half of the frame rate (increasing the sensitivity) ...... - 88 -

12.4.5.3 Capture one frame with preset exposure time using the external trigger ........ - 88 -

- 5 -

AM-200GE / AB-200GE

12.4.5.4 Capture multi frames of the image with preset exposure time using the external

trigger ...................................................................................................... - 89 -

12.4.5.5 Capture one frame image with the trigger width using the external trigger ..... - 89 -

12.4.5.6 Capture multi frames of the image with the trigger width using the external ... - 90 -

12.4.5.7 Capture the image continuously with preset exposure time by using the external

trigger ...................................................................................................... - 90 -

12.4.5.8 Capture the image using Software Trigger .............................................. - 90 -

12.4.5.9 Sequence Trigger setting ................................................................... - 91 -

12.4.5.10 Multi ROI setting ............................................................................ - 92 -

12.4.5.11 Delayed readout setting .................................................................. - 93 -

12.4.5.12 Operate the external strobe light ....................................................... - 93 -

12.4.6 How to view the XML file ....................................................................... - 94 -

12.4.7 Feature Tree Information ...................................................................... - 95 -

12.4.8 Feature Properties (Guru) ...................................................................... - 95 -

13. External Appearance and Dimensions .......................................... - 102 -

14. Specifications ........................................................................ - 103 -

14.1 Spectral response ...................................................................................... - 103 -

14.2 Specifications table .................................................................................... - 104 -

Appendix .................................................................................... - 106 -

1. Precautions ................................................................................................. - 106 -

2. Typical Sensor Characteristics .......................................................................... - 106 -

3. Caution when mounting a lens on the camera ....................................................... - 106 -

4. Caution when mounting the camera ................................................................... - 107 -

5. Caution for cleaning CCD and Low Pass Filter ........................................................ - 107 -

6. Exportation ................................................................................................. - 107 -

7. References ................................................................................................. - 107 -

Change history ............................................................................. - 108 -

User's Record ............................................................................... - 109 -

- 6 -

AM-200GE / AB-200GE

JAI GigE® Vision Camera operation manuals

To understand and operate this JAI GigE® Vision camera properly, JAI provides the following manuals.

User’s manual (this booklet) Describes functions and operation of the hardware JAI SDK & Control Tool User Guide Describes functions and operation of the Control Tool JAI SDK Getting Started Guide Describes the network interface

User’s manual is available at www.jai.com JAI SDK & Control Tool User Guide and JAI SDK Getting Started Guide are provided with the JAI SDK which is available at www.jai.com.

Introduction

GigE Vision is the new standard interface using Gigabit Ethernet for machine vision applications and it was mainly set up by AIA (Automated Imaging Association) members. GigE Vision is capable of transmitting large amounts of uncompressed image data through an inexpensive general purpose LAN cable for a long distance.

GigE Vision also supports the GenICamTM standard which is mainly set up by the EMVA (European Machine Vision Association). The purpose of the GenICam standard is to provide a common program interface for various machine vision cameras. By using GenICam, cameras from different manufactures can seamlessly connect in one platform.

For details about the GigE Vision standard, please visit the AIA web site, www.machinevisiononline.org and for GenICam, the EMVA web site, www.genicam.org.

JAI GigE Vision cameras comply with both the GigE Vision standard and the GenICam standard.

Before using GigE Vision camera

All software products described in this manual pertain to the proper use of JAI GigE Vision cameras. Product names mentioned in this manual are used only for the explanation of operation. Registered trademarks or trademarks belong to their manufacturers. To use the JAI SDK, it is necessary to accept the “Software license agreement” first.

This manual describes necessary equipment and the details of camera functions.

Software installation

The JAI GigE Vision SDK & Control Tool can be downloaded from the JAI web site at www.jai.com. The JAI SDK is available for Windows XP and Vista, 32-bit and 64-bit. For the details of software installation, please refer to the “Getting Started Guide” supplied on the JAI SDK download page.

- 7 -

AM-200GE / AB-200GE

Camera Operation

1. General

The AB-200GE and AM-200GE comply with the GigEVision® standard and also GenICamTM with its Standard Feature Naming Convention (SFNC) ver.1.3. Functions described in this booklet are described based on this standard.For further information about the GigE Vision standard, please go to www.machinevisiononline.org and about GenICam, please go to www.genicam.org.

The AM-200GE is a 2/3 inch monochrome progressive scan CCD camera and the AB-200GE is the equivalent Bayer mosaic progressive scan CCD camera. Both have 2 million pixels resolution and utilize 2-tap output from the Kodak KAI-02050 sensor. They provide 40.6 frames per second (8-bit Mono/Bayer output) for continuous scanning with full 1600 x 1200 pixel resolution.

Both AM-200GE and AB-200GE are suitable for automated optical inspection applications, such as solid state device inspection or material surface inspection.

They incorporate various processing circuits such as LUT, FFC (Flat Field Compensation), blemish compensation and Bayer interpolation. The AM-200GE and AB-200GE work in continuous, single frame, and multi-frame modes for acquisition control together with timed and trigger width exposure controls. Both cameras also have pre-dump and PIV modes.

As an application programming interface, JAI provides an SDK (Software Development Kit). This SDK includes GigE Vision Filter Driver, JAI control tool, software documentation and code examples. The JAI SDK can be downloaded from www.jai.com. The latest version of this manual can be downloaded from www.jai.com For camera revision history, please contact your local JAI distributor.

2. Camera nomenclature

The camera is available in the following versions:

AM-200GE

Where A stands for "Advanced" family, M stands for "Monochrome", 200 represents the resolution "2 million pixel" , 200 for the product dependent, and GE stands for "GigEVision" interface

AB-200GE

Where A stands for "Advanced" family, B stands for "Bayer mosaic color", 200 represents the resolution "2 million pixel" , 200 for the product dependent, and GE stands for "GigEVision" interface

- 8 -

AM-200GE / AB-200GE

3. Main Features

 C3 Advanced series 2/3 ” progressive scan camera  Monochrome and Bayer mosaic color versions  1600 (h) x 1200 (v) active pixels  5.5μm square pixels  57dB or more S/N for AM-200GE and 55dB or more for AB-200GE  8-bit, 10-bit or 12-bit output for monochrome and Bayer, or 8-bit output RGB color or

YUV422 output for AB-200GE

 40.6 frames/second with full resolution in continuous operation for monochrome or

Bayer 8-bit output

 19.2 frames/second for AB-200GE RGB output (in-camera interpolation) and 28.8

frames/second for AB-200GE YUV422 output

 Various readout modes, horizontal and vertical binning (AM-200GE only) and AOI (Area

Of Interest) modes for faster frame rates

 -3dB to +24dB gain control for AM-200GE and 0dB to +24dB for AB-200GE  10μs (1/100,000) to 2 seconds exposure control in 1μs steps ( Exposure/Timed control

mode)

 Timed and trigger width for exposure control  Pre-dump (RCT) and PIV modes for specific applications  ALC to automatically control exposure for changing lighting conditions by combining

auto gain control, auto shutter and auto iris functions

 Various pre-processing circuits are provided

Programmable LUT Gamma correction from 0.45 to 1.0 Shading Correction Bayer white balance with manual, one-push auto, or continuous (AB-200GE only) Bayer color interpolation (AB-200GE only) Blemish compensation

 Test pattern signal generator built in  Auto iris lens video output with H-sync  Setup by Windows XP/Vista/7 via serial communication

- 9 -

AM-200GE / AB-200GE

LINK ACT.

DCIN/TRIG

GPIO

POWER/TRIG

GigE

Front View

Top View

Bottom View

Rear View

Side View

①

②

③

④

⑤

⑥ ⑦

⑧

⑨

⑩

⑨

4. Locations and Functions

4.1. Locations and functions

1. Lens mount Lens mount of C-mount type. *1)

2. CCD sensor 2/3 inch CCD

3. 12-pin connector DC+12V, Trigger IN and EEN out

4. RJ-45 connector GigE Vision interface with thumb screws

5. D-sub 9-pin connector LVDS IN and TTL IN and OUT

6. LED Power and trigger indications

7. LINK Indication for Network connection

8. ACT Indication for GigE communication

9.Holes for RJ-45 thumbscrews Vertical type and horizontal type (*2)

10.Mounting holes M3, max length 4.5mm (*3)

*1) Note: Rear protrusion on C-mount lens must be less than 10mm. *2) Note: When an RJ-45 cable with thumb screws is connected to the camera, please do not

excessively tighten screws by using a driver. The RJ-45 receptacle on the camera might be damaged. For security, the strength to tighten screws is less than 0.147 Newton meter (Nm). Tightening by hand is sufficient in order to achieve this.

*3) Note: The tripod adapter plate MP-41 can be used.

Fig. 1. Locations

- 10 -

AM-200GE / AB-200GE

4.2. Rear panel indicator

The rear panel mounted LED provides the following information:

 Amber : Power connected - initiating

 Steady green : Camera is operating in Continuous mode  Flashing green : The camera is receiving external trigger

Ethernet connector indicates,

 Steady green : 1000 Base-T has been connected  Flashing green : 100 Base/10Base have been connected

(Note)

 Flashing amber : Network active in communication

Note: When 100BASE/10BASE are connected, the green is also

flashing. However, the video is not streamed through Ethernet.

Fig.2 Rear Panel

- 11 -

AM-200GE / AB-200GE

Pin No

In/Out

Name

In/Out

MX1+ (DA+)

In/Out

MX1- (DA-)

In/Out

MX2+ (DB+)

In/Out

MX3+ (DC+)

In/Out

MX3- (DC-)

In/Out

MX2- (DB-)

In/Out

MX4+ (DD+)

In/Out

MX4- (DD-)

Pin no.

Signal

Remarks

GND

DC input

+12V to +24V

Opt In 2(-) / GND (*1)

Line 6

Opt In 2 (+) / Iris video(*1)

Opt In 1 (-)

Line 5

Opt In 1 (+)

Opt Out 1 (-)-

Line 3

Opt Out 1 (+)

Opt Out 2 (-)

Line 4

Opt Out 2 (+)

DC input

+12V to +24V

GND

5. Pin Assignment

5.1. 12-pin Multi-connector (DC-IN/Digital IO)

Type: HR10A-10R-12PB-01 (Hirose) male. (Seen from rear of camera.)

Fig. 3. 12-pin connector. *1) Default is Opt In 2. DIP switch SW901 changes to

iris video output.

5.2. Digital Output Connector for Gigabit Ethernet

Type: RJ-45 HFJ11-1G02E-L21RL or equivalent

The AM-200GE AND AB-200GE cameras also accept industrial RJ-45 connectors with thumbscrews. This assures that the connector does not come undone in tough industrial environments. Please contact the nearest JAI distributor for details on recommended industrial RJ-45 connectors.

Fig. 4. Gigabit Ethernet connector

The digital output signals follow the Gigabit Ethernet interface using RJ-45 conforming connector. The following is the pin assignment for the Gigabit Ethernet connector.

- 12 -

AM-200GE / AB-200GE

I/O

Name

Note

1 I LVDS In 1-

Line 8

2 I LVDS In 1+

3 I TTL IN 1

Line 7

75ohm Termination (Note 1)

4 O TTL Out 1

Line 1

5 GND

6 NC

7 NC

8 O TTL OUT 2

Line 2

9 GND

Functions

Setting

OFF

Trigger input termination

75Ω

TTL

SW900

Right side for 75 ohms termination

5.3. D-Sub 9pin connector (For GPIO)

Type : DD-09SSG

Fig. 5．D Sub 9pin connector

Note1) Can be changed by DIP switch (SW900).

5.4. DIP switch

DIP switches are located on circuit boards. When the top cover is removed, please pay careful attention so that circuit boards are not damaged.

5.4.1 SW-900

This switch sets the 75 ohm trigger input termination to ON or OFF. The factory default setting is OFF which is TTL level.

The 75 ohm termination DIP switch is located the right side as looking from the lens

when the top cover is removed. The photo in the right shows the default setting. In order to change to the 75 ohm termination, the switch in the front should be set downwards.

Fig.6. SW900

- 13 -

AM-200GE / AB-200GE

Function

Setting

OFF

Exposure Active output select

Open Collector signal

TTL signal

NC - -

Functions

Setting

OFF

OPT IN(+) / Iris video OUT select

Iris video

OPT IN (+)

OPT IN(-) / Iris video OUT select

GND for iris video

OPT IN (-)

SW500

Sensor side

Open Collector ooutput

TTL output

SW901

Opt output

Iris output

5.4.2 SW-500

This switch selects the ExposureActive signal. The factory default setting is TTL signal and it can be changed to the open collector signal.

Sensor side

SW500 is located in the upper board when the top cover is removed.

Fig. 7 SW500

back side

5.4.3 SW-901

Fig.8 SW901

This DIP switch can select OPT IN or Iris video output through pin#3 and #4 of the HIROSE 12 pin connector. The default setting is OPT IN.

- 14 -

AM-200GE / AB-200GE

Output

Input

TTL

Line 1

Opt

Line 5

TTL

Line 2

Opt

Line 6

Opt

Line 3

TTL

Line 7

Opt

Line 4

LVDS

Line 8

6. Input and output Interface

6.1. Digital Interface

In the AM-200GE AND AB-200GE, the input and output interfaces for Hirose 12P and D-

Sub 9P are configured as follows.

6.1.1 LineSelector

The following input and output signals are configured on Line 1 through Line 8.

① Line 1(TTL out1) ② Line 2(TTL out2) ③ Line 3(Opt out1) ④ Line 4(Opt out2) ⑤ Line 5(Opt in1) ⑥ Line 6(Opt in2) ⑦ Line 7(TTL in1) ⑧ Line 8(LVDS in)

6.1.2 LineInverter

This function changes the polarity of the signal.

6.1.3 LineStatus

The user can ascertain the status of input and output signals.

6.1.4 LineSource

This function lets you designate the signal source to output through Line 1 to Line 4 as

part of the LineSelector configuration. Each signal is selected from the following

five signals.

① AcquisitionTriggerWait ② AcquisitionActive ③ FrameTriggerWait ④ FrameActive ⑤ ExposureActive ⑥ JAI_Acquisitionwait ⑦ Counter1Active ⑧ Timer1Active ⑨ UserOut0 ⑩ UserOut1 ⑪ UserOut2 ⑫ UserOut3

6.1.5 LineMode

The current mode of signals (input or output) is displayed.

6.1.6 LineFormat

The interface of input and output circuits is displayed.

- 15 -

AM-200GE / AB-200GE

6.2. Opto-isolated Interface

The control interface of the C3 GigE Vision camera series has opto-isolated inputs and outputs, providing galvanic separation between the camera's inputs/outputs and peripheral equipment. In addition to galvanic separation, the opto-isolated inputs and outputs can cope with a wide range of voltages; the voltage

range for inputs is +3.3V to +24V DC whereas Fig.9 Opto-coupler

outputs will handle +5V to +24V DC.

The figure at the right shows the functional principle (opto-coupler) of the opto-isolated inputs/outputs.

6.2.1 Recommended External Input circuit diagram for customer

Fig.10 External Input Circuit, OPT IN 1 and 2

6.2.2 Recommended External Output circuit diagram for customer

Fig.11 External Output Circuit, OPT OUT 1 and 2

- 16 -

AM-200GE / AB-200GE

User Power (VCC)

3.3V

12V

24V

Time Delay Rising TDR(µs)

0.54

0.62

0.68

Rising Time RT(µs)

1.2

2.0

3.0

Falling Delay Time FDR(µs)

1.5

2.4

2.1

Falling Time FT(µs)

3.6

3.4

4.5

6.8

１μ１Ｋ

０．１μ

＋５Ｖ

IRIS Video Out

DA IN

DAC

10K

12K

Iris Sync

6.2.3 Optical Interface Specifications

The relation of the input signal and the output signal through the optical interface is as follows.

Fig.12 Optical Interface Performance

6.3. Iris video output

This signal can be used for lens iris control in Continuous and pre-dump modes. The signal is 1.0 V p-p (with H-sync) from 75  without termination.

Fig. 13 Iris video output. The iris video signal is composed to average the video level in the center area of each frame and can be output as a composite signal with H-sync. As shown in the following figure, each frame has its own video level which is averaged.

Fig.14 Iris signal details

- 17 -

AM-200GE / AB-200GE

Note: These interpolated controls are calculated based on the “Gain Auto Reference” value. If the system is operating with a frame rate of less than 20fps, the set point of the lens should match the value of “Gain Auto Reference”, even if ALC is being controlled by only the auto iris. Also, when using an auto iris lens with its own speed and level controls, it is recommended that these controls first be adjusted on the lens before using

the camera controls above to avoid possible conflicts.

The following parameters of this auto iris control signal output can be changed.

Auto Iris Control Signal Output:

ON : The auto iris control can be connected with AGC and ASC as ALC function OFF : The auto iris control is not connected with AGC and ASC.

Iris Reverse Gain:

ON : The auto iris control signal is multiplied by the inverse of AFE gain (VGA

gain). If ALC is used, this setting is recommended. Auto iris control signal is not affected by AGC gain.

OFF: The auto iris control signal is not multiplied by the inverse of AFE gain (VGA

gain).

Iris State Control:

Video: Use the iris control in auto mode. Close: Force the iris to close.

Open: Force the iris to open. Iris Sync Level: Adjust the H sync level added to the video between 0 to 255. Iris Control Gain:

0 – 255: Set a separate control gain for the auto iris control signal. If oscillation

occurs when the auto iris diaphragm reaches the set point, this setting may reduce the phenomenon.

Iris Interpolate Gain (Note): 0 – 255: At frame rates below 20fps, the auto iris operation may appear “jumpy”

as it rapidly moves from one level to the next. This function prevents this so-called “hunting” phenomenon by interpolating new auto iris control levels between each frame, thereby smoothing the rate of the auto iris changes.

Iris Calculate Ratio (Note): 20 – 160: This function compensates Iris Interpolate Gain to allow for the varying

diaphragm ranges of different auto iris lenses. This can be helpful if the auto iris is not able to find the appropriate point by hunting when operating at frame rates of less than 20fps.

- 18 -

AM-200GE / AB-200GE

○

＋５V

Trigger INI B Trigger INI A

1000

0.1μ

Trigger

0.1μ

1K22K

15K

100K

●

●●

● ●

●

● ● ●

●

●●

●

● ●

●

○

Open

Collector

TTL

SW500

Exposure Active

150

120

10K

220

0.1μ

180

100

10K

0.1μ

+5V

TTL Out 1/2

Initial Trigger Activation Set: If the TTL trigger signal is input through D-SUB 9 pin, there are several functions inside the camera using TTL. And each function has the setting of the trigger activation, the camera sets the initial processing in accordance with its priority. The initial Trigger Activation Set function, however, forces to set the input polarity after the power is ON.

Refer to 9.2.4.1 Initial Trigger Activation Set.

6.4. Trigger input

An external trigger input can be applied to the input selected Line Selector. The input is AC coupled. To allow long pulses the input circuit is designed as a flip-flop circuit. The leading and trailing edges of the trigger pulse activate the circuit. The trigger polarity can be changed by Trigger Activation. Trigger input level is 4 V 2 V.

Fig.15 Trigger input circuit

6.5. Exposure Active output

Exposure Active signal (positive) is found on Opt-out on Hirose 12P or TTL out on D-sub 9pin connector. The output circuit is 75  complementary emitter followers. Output level 3 V from 75 (no termination). It can be changed to the open collector signal. When the open collector is used, the maximum current is 120mA. However, if a current of more than 50mA is flowed, it is necessary to use bigger diameter wires for connecting pins #8 and 9. If narrower-gauge wires are used, it may not work properly due to resistance issues. This output can be changed to open collector signal by SW500. Fig.16 Exposure Active output

- 19 -

7. Video signal output

7.1. Video output image

AM-200GE / AB-200GE

Note: The following OB area can be transferred.

For vertical : 4 pixels for upper side For horizontal : 16 pixels on right and left sides

Fig.17 CCD sensor layout

- 20 -

AM-200GE / AB-200GE

WidthMax

HeightMax

OffsetY

OffsetX

Width

Height

(1,1)

OB 4 lines

OB 16 pixels

(1,1)

(1,1204)

(1632,1204)

(16,4)

(1616,1204)

OB 16 pixels

(1616,4)

(1632,1)

(16,1204)

Height

Width

7.2. AOI (Area of Interest)

In the AM-200GE and AB-200GE, the output image size can be determined by setting the output area.

7.2.1 AOI parameters

In order to set the output area, 4 parameters including OffsetY, OffsetX, Width and

Height should be specified.

Fig.18 AOI setting

7.2.2 AOI setting details

In the AM-200GE and AB-200GE, AOI settings must consider the optical black areas

when specifying the area to be transferred.

Fig.19 OB transfer

7.2.2.1 When only the image part is transmitted (OB is not transferred)

Offset X=16 (Note) Offset Y=4 Width =1600 Height = Effective lines

Note: If the horizontal binning is x2, the value is 8.

- 21 -

AM-200GE / AB-200GE

Area

Offset

Height

Frame rate （fps）

1/2

304

600

Continuous

64.05673 Timed (EPS)

（Smearless OFF）

Trigger Width

1/4

454

300

Continuous

89.91026 Timed (EPS)

(Smearless OFF)

Trigger Width

1/8

528

150 Continuous

112.8964 Timed (EPS)

Trigger Width

7.2.2.2 When the full image plus the vertical OB is transmitted

Offset X=16(Note) Offset Y=0 Width =1600

Height = Effective lines ＋4

Note: If the horizontal binning is x2, the value is 8.

7.2.2.3 When the full image plus the horizontal OB is transmitted

Offset X=0 Offset Y=4 Width =1632 (Note1)(Note2) Height = Effective lines

Note1: When the horizontal OB is transferred, the width must be set at its maximum. Note2: If the horizontal binning is used, the OB on both side is 8 and total 1616.

7.2.3 Frame rate calculation in the AOI mode

The frame rate in AOI mode depends on each setting of Offset, Height, Bit allocation

or Binning control. In the following formula, the part labelled ( decimal values rounded up.

7.2.3.1 Binning control setting : off or 2x1 (Binning Vertical=1)

In case of Offset Y < 4

Frame line number = ((1203 - (Height + (Offset Y - 4))) / 4)

rounddown

(Height - (4 – Offset Y)) + 29

In case of Offset Y ≧ 4 Frame line Number = (Offset Y / 4)

+ ((1203 – (Height + (Offset Y - 4))) /4)

roundup

+ Height + 28

Frame rate (Hz) = 1/ (Frame line number x 0.00002004)

Setting examples (8-bit output)

round up

) has its

rounddown

- 22 -

AM-200GE / AB-200GE

Area

Offset

Height

Frame rate （fps）

1/2

154

300

Continuous

96.09841 Timed (EPS)

(SmearLess OFF)

Trigger Width

1/4

228

150

Continuous

114.2074 Timed (EPS)

(SmearLess OFF)

Trigger Width

266

76 Continuous

125.9129 Timed (EPS)

Trigger Width

7.2.3.2 Binning control setting : 1x2 or 2x2 (Binning Vertical=2)

In case of Offset Y < 4 Frame line number = ((1203 – (((Height - (4 - Offset Y)) x 2) +

((Offset Y x 2) – 4))) / 4)

rounddown

In case of Offset Y ≧ 4 Frame line 数 = ((Offset Y / 4) x 2)

((Offset Y x 2) - 4))) / 4)

+ ((1203 – ((Height x 2) +

roundup

rounddown

Frame rate (Hz) = 1/ (Frame line 数 x 0.00002200)

Setting example (8-bit output)

+ (Height - (4 - Offset Y)) + 24

+ Height + 22

7.2.4 The relationship between LinePitch and Width

The setting range of LinePitch is changed according to PixelFormat setting. LinePitch can be set as follows.

Mono8/Bayer8 : 8-1632, by 8 pixels step Mono10/Bayer10_Packed : 12-2448, by 12 pixels step Mono10/12/bayer10/12 : 16-3264, by 16 pixels step RGB8_Packed : 24-4896, by 24 pixels step YUV422_Packed : 16-3264, by 16 pixels step

As for LinePitch and Width, if one is changed, the other will also be changed. The relationship between LinePitch and width is;

Mono8/Bayer8 : Linepitch Mono10/Bayer10_Packed : Linepitch/1.5 Mono10/12/Bayer10/12 : Linepitch/2 RGB8_Packed : Linepitch/3 YUV422_Packed : Linepitch/2

7.3. In case of vertical binning and horizontal binning (Only for AM-200GE)

This function is available only for AM-200GE. In binning mode, adjacent pixels in the horizontal direction and/or vertical direction are combined and output as one pixel. The possible combinations are shown below.

- 23 -

AM-200GE / AB-200GE

H x V (Pixels)

Sensitivity

Spatial resolution

H direction

V direction

1 x 2

2 times

Unchanged

1/2

2 x 1

2 times

1/2

Unchanged

2 x 2

4 times

1/2

CCD out

Analog Out

(Equivalent)

Digital Out

8bit

10bit

12bit

Black

Setup 3.6%, 25mV

8LSB

32LSB

128LSB

AM-200GE

350mV

100%

700mV

222LSB

890LSB

3560LSB

AB-200GE

290mV

AM-200GE

404mV

115%

808mV

255LSB

1023LSB

4095LSB

AB-200GE

334mV

Horizontal

Vertical

1 pixel

1 Pixel

2 Pixels

2 pixels

Fig. 20 Binning modes Binning achieves a higher frame rate, as well as better sensitivity. On the other hand, the resolution becomes less than the full frame readout.

7.3.1 The relationship between Binning Horizontal and Width/LinePitch

If Binning Horizontal is set at 1 or 2, Width/LinePitch is changed accordingly. Binning Horizontal = 1 Width is 1632 as the maximum Binning Horizontal = 2 Width is 816 as the maximum

Note: If Binning Horizontal is reset to 1 after setting to 2, the maximum value is not

changed. It is necessary to set manually.

7.3.2 The relationship between Binning Vertical and Height

If Binning Vertical is set at 1 or 2, Height is changed accordingly. Binning Vertical = 1 Height is 1204 as the maximum Binning Vertical = 2 Height is 604 as the maximum

Note: If Binning Vertical is reset to 1 after setting to 2, the maximum value is not changed.

It is necessary to set manually.

7.4. Digital video output (Bit allocation)

Although the AM-200GE and AB-200GE are digital cameras, the image is generated by an analog component, the CCD sensor. The table and diagram below show the relationship between the analog CCD output level and the digital output.

- 24 -

AM-200GE / AB-200GE

Digital Out [LSB]

70025

Analog Ou t [mV ]

890

1023

Black L eve l

White Cli p Lev el

800

100% Le vel

signal out

Gｒ

RGｒR

GbBGb

H3H4H5

Gｒ

Model

Pixel Type supported

AM-200GE

Mono8, Mono10, Mono10_Packed, Mono 12, Mono12_Packed

AB-200GE

BayGR8, BayGR10, BayGR12, BayGR10_Packed, BayGR12_Packed,RGB8_PACKED, YUV422_PACKED

0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

Y0Y1Y2

Fig.21 Bit allocation

7.5. Bayer output pattern

The AB-200GE starts with GRG on odd lines and BGB on even lines as shown below. If AOI is used, Offset Y can be set every 2 lines and therefore, it always starts with a GRG sequence.

Fig. 22 Bayer sequence

7.6. Pixel format and pixel type

In the GigE Vision Interface, GVSP (GigE Vision Streaming Protocol) is used for an application layer protocol relying on the UDP transport layer protocol. It allows an application to receive image data, image information and other information from a device. As for the sensors in the AM-200GE AND AB-200GE, the following pixel types supported by GVSP are available. With regard to the details of GVSP, please refer to the GigE Vision Specification available from the AIA (www.machinevisiononline.org).

7.6.1 GVSP_PIX_MONO8 (8bit output)

- 25 -

AM-200GE / AB-200GE

0 1 2 3 4 5 6 7 8 9 X X X X X X 0 1 2 3 4 5 6 7 8 9 X X X X X X

Y0Y0Y1

2 3 4 5 6 7 8 9 0 1 X X 0 1 X X 2 3 4 5 6 7 8 9 2 3 4 5 6 7 8 9 0 1 X X 0 1 X X 2 3 4 5 6 7 8 9

Y3Y1Y0

0 1 2 3 4 5 6 7 8 9 10 11 X X X X 0 1 2 3 4 5 6 7 8 9 10 11 X X X X

Y0Y0Y1

4 5 6 7 8 9 10 11 0 1 2 3 0 1 2 3 4 5 6 7 8 9 10 11 4 5 6 7 8 9 10 11 0 1 2 3 0 1 2 3 4 5 6 7 8 9 10 11

Y3Y1Y0

0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

G0R1G2

0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

B0G1B2

0 1 2 3 4 5 6 7 8 9 X X X X X X 0 1 2 3 4 5 6 7 8 9 X X X X X X

G0G0R1

0 1 2 3 4 5 6 7 8 9 X X X X X X 0 1 2 3 4 5 6 7 8 9 X X X X X X

B0B0G1

2 3 4 5 6 7 8 9 0 1 X X 0 1 X X 2 3 4 5 6 7 8 9

7.6.2 GVSP_PIX_MONO10 (10bit output)

7.6.3 GVSP_PIX_MONO10_Packed (10bit output)

7.6.4 GVSP_PIX_MONO12 (12bit ourput)

7.6.5 GCSP_PIX_MONO12_Packed (12bit output)

7.6.6 GCSP_PIX_BAYERGR8 (8bit output)

Odd Line

Even Line

7.6.7 GVSP_PIX_BAYERGR10 (10bit output)

Odd Line

Even Line

7.6.8 GVSP_PIX_BAYERGR10_Packed

Odd Line

Even Line

- 26 -

AM-200GE / AB-200GE

0 1 2 3 4 5 6 7 8 9 10 11 X X X X 0 1 2 3 4 5 6 7 8 9 10 11 X X X X

G0G0R1

0 1 2 3 4 5 6 7 8 9 10 11 X X X X 0 1 2 3 4 5 6 7 8 9 10 11 X X X X

B0B0G1

4 5 6 7 8 9 10 11 0 1 2 3 0 1 2 3 4 5 6 7 8 9 10 11

R R R R R R R R G G G G G G G G B B B B B B B B 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

U U U U U U U U Y Y Y Y Y Y Y Y V V V V V V V V Y Y Y Y Y Y Y Y

0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

AM-200GE

AB-200GE

Pixel format

Pixel size

Pixel format

Pixel size

Mono8

Bpp8

BayerGR8

Bpp8

Mono10

Bpp16

BayerGR10

Bpp16

Mono10_Packed

Bpp12

BayerGR10_Packed

Bpp12

Mono12

Bpp16

BayerGR12

Bpp16

Mono12_Packed

Bpp12

BayerGR_Packed12

Bpp12

RGB8_PACKED

Bpp24

YUV422_PACKED

Bpp16

7.6.9 GVSP_PIX_BAYERGR12 (12bit output)

Odd Line

Even Line

7.6.10 GVSP_PIX_BAYERGR12_Packed

Odd Line

Even Line

7.6.11 GVSP_PIX_RGB8_PACKED (24bit) (Interpolation)

1Byte 2Byte 3Byte

7.6.12 GVSP_PIX_ YUV422_PACKED (16bit)

1Byte 2Byte 3Byte 4Byte

7.6.13 The relationship between PixelFormat and PixelSize.

The pixel format and pixel size are related and if one is changed, the other is

automatically changed.

- 27 -

AM-200GE / AB-200GE

7.7 YUV output

The AB-200GE has a YUV output, as well as an ordinal RGB interpolated output. The conversion formula is as follows and cannot be controlled externally.

Y = 0.299*R + 0.587*G + 0.114*B Cb = 0.5*B – 0.169*R -0.331*G +128 Cr = 0.5*R – 0.419*G – 0.0813*B + 128

While RGB output is 24-bit (8 bits per color), YUV takes advantage of the human visual

system's lower acuity for color variations than for luminance.

The color information (chrominance) is sub-sampled at half the rate of the brightness

component (luminance). Thus, YUV can be compressed into 16-bit output for a faster full color frame rate that is visually perceived as close to RGB, albeit with lower actual color precision.

7.8. Video output timing

7.8.1 Vertical timing (8bit, 10 bit or 12bit for Bit allocation)

7.8.1.1 If the binning control is OFF or 2x1, AOI default setting

 Frame rate:1229L, 40.6fps

Fig.23 Vertical timing (AOI default)

- 28 -

AM-200GE / AB-200GE

Offset

HEGHT

(L) B (L) C (L)

Total line

(L)

Acquisition Frame rate

(fps)

204

800

929

53.71388

304

600

779

64.05673

454

300

130

300

121

555

89.91026

528

150

148

150

140

442

112.8964

7.8.1.2 If the binning control is OFF or 2x1, AOI setting

Fig.24 Vertical timing for partial scanning (AOI)

Frame rate examples when the start line and the end line are set as follows

7.8.1.3 If the binning control is 1x2 or 2x2, AOI default setting

 Frame rate: 624L, 72.83fps

Fig.25 Vertical timing for the vertical binning

- 29 -

AM-200GE / AB-200GE

Offset

HEGHT

(L) B (L) C (L)

Total line

(L)

Acquisition Frame rate

(fps)

104

400

524

86.91118

154

300

474

96.09841

228

150

124

150

121

399

114.2074

266

143

139

362

125.9129

7.8.1.4 If the binning control is 1x2 or 2x2, AOI setting

Fig.26 Vertical timing (Vertical binning, AOI setting)

7.8.2 Horizontal timing

7.8.2.1 If the binning control is OFF or 2x1

(Exposure start line 1LVAL 1055 clk = 21.98μs)

1LVAL 962clk = 20.04μs 1clk=20.83ns

Fig.27 Horizontal timing (Vertical binning OFF)

- 30 -

AM-200GE / AB-200GE

Binning Control

LVAL-LOW period

LVAL cycle

Ordinary

Exposure start

Ordinary

Exposure start

OFF, 2x1

138clk

231clk(1st)

165clk(2nd)

962ck 20.04 us

1055ck 21.98 us

1x2, 2x2

232clk

325clk(1st)

300clk(2nd)

1056ck 22.0 us

1149ck 23.94 us

7.8.2.2 If the binning control is 1x2 or 2x2

1LVAL 1056clk = 22.0μs 1clk=20.83ns

(Exposure starting line 1LVAL 1149 clk = 23.94μs)

Fig.28 Horizontal timing (Vertical binning ON)

6.4.3 DVAL output if the Binning control is set to 2=2x1 or 3=2x2

If the Binning control is set to 2=2x1 or 3=2x2, DVAL is output in one pixel period

within the effective output period. Data is output by adding two pixels in horizontally as described below.

Fig.29 DVAL in the vertical binning

7.8.2.3 LVAL-LOW level period

1. When waiting for a trigger signal or at the exposure start line, LVAL-LOW period

varies as shown in the following table.

- 31 -

AM-200GE / AB-200GE

ExpopsureActive

int-LVAL

1st

2nd

Trigger

ExposureActive

int-LVAL

LVAL-LOW period just after the exposure starts: “138clk ⇒231clk” (Binning Vertical=1 ,OFF, 2x1)

“232clk ⇒325clk” (Binning Vertical=2, 1x2, 2x2)

Maximum 1 LVAL + LVAL Low period

LVAL-LOW period just after the exposure starts: “138clk ⇒165clk” (Binning Vertical=1 ,OFF, 2x1)

“232clk ⇒300clk” (Binning Vertical=2, 1x2, 2x2)

Exposure start line

2. When the trigger control mode is set to ON and Overlap is set to Readout,

LVAL-LOW period is 1LVAL as the maximum.

Fig.31 LVAL-LOW period if Overlap is set to Readout

Fig.30 LVAL-LOW period varies

- 32 -

AM-200GE / AB-200GE

8. Network configuration

 For details of the network settings, please refer to the “Getting Started

Guide” supplied with the JAI SDK.

8.1. GigEVision Standard interface

The AM-200GE / AB-200GE is designed in accordance with the GigE Vision standard. Digital images are transmitted over Cat5e or Cat6 Ethernet cables. All camera functions are also controlled via the GigE Vision interface.

The camera can operate in Continuous mode, providing an endless stream of images. For capturing individual images related to a specific event, the camera can also be triggered. For precise triggering, it is recommended to use a hardware trigger applied to the Hirose 12-pin connector. It is also possible to initiate a software trigger through the GigE Vision interface. However, when using a software trigger, certain latency inherent to the GigE interface must be expected. This latency, which manifests itself as jitter, greatly depends on the general conditions and traffic on the GigE connection. The frame rate described in this manual is for the ideal case and may deteriorate depending on conditions.

When using multiple cameras (going through a switch and/or a single path) or when operating in a system with limited transmission bandwidth the Delayed Readout Mode and Inter-Packet Delay functions can be useful.

8.2. Equipment to configure the network system

8.2.1 PC

The PC used should have the following performance or better

1) Recommended CPU : Core2 Duo 2.4GHz or better, Better than Core2 Extreme

2) Recommended memory : 2Gbyte or more

3) Video card : Better than PCI Express Bus Ver.1.0 x16

VRAM should be better than 256MByte, DDR2

4) Other : The resident software should not be used

8.2.2 Cables

GigEVision configures the system by using 1000BASE-T. In the market, CAT5e (125MHz), CAT6 (250MHz) and CAT7 (600MHz) cables are available for 1000BASE-T. There are crossover cables and straight through cables available. Currently, as most equipment complies with Auto MDI/MDI-X, please use straight through cables. (Among crossover cables, a half crossover type exists, which the Ethernet will recognize as 100BASE-T).

8.2.3 Network card (NIC)

The network card should comply with 1000BASE-T and also have the capability of JUMBO FRAMES. When the jumbo frame size is set at a larger number, the load on the CPU will be decreased. Additionally, as the overhead of the packet is decreased, the

transmission will have more redundancy.

JAI confirms the following network cards.

- 33 -

AM-200GE / AB-200GE

NIC Manufacture

Type

PCI-X Bus

PCI-Express

Bus

Intel

PRO/1000MT Server Adapter





32bit or 64bit

33/66/100/133 MHz

Intel

PRO/1000MT Dual Port Server Adapter





32bit or 64bit

33/66/100/133 MHz

Intel

PRO/1000GT Quad Port Server Adapter





32bit or 64bit

66/100/133 MHz

Intel

PRO/1000PT Server Adapter

―

 ( x1 )

2.5Gbps uni-directional 5Gbps bi-directional

Intel

Pro/1000 CT Desktop adaptor

―

 ( x1 )

2.5Gbps uni-directional 5Gbps bi-directional

Intel

Gigabit ET2 Quad port Server Adapter

―

 ( x4 )

10Gbps uni-directional

20Gbps bi-directional

Intel

Gigabit ET Dual port Server Adapter

―

 ( x4 )

10Gbps uni-directional

20Gbps bi-directional

Intel

Gigabit EF Dual port Server Adapter

―

 ( x4 )

10Gbps uni-directional

20Gbps bi-directional

8.2.4 Hub

It is recommended to use the metal chassis type due to the shielding performance. As the hub has a delay in transmission, please note the latency of the unit.

8.3. Recommended Network Configurations

Although the AM-200GE and AB-200GE conforms to Gigabit Ethernet (IEEE 802.3) not all combinations of network interface cards (NICs) and switches/routers are suitable for use with the GigE Vision compliant camera. JAI will endeavor to continuously verify these combinations, in order to give users the widest choice of GigE components for their system design.

 For details of the network settings, please refer to the “Getting Started

Guide” supplied with the JAI SDK.

8.3.1 Guideline for network settings

To ensure the integrity of packets transmitted from the camera, it is recommended to follow these simple guidelines:

1. Whenever possible use a peer-to-peer network.

2. When connecting several cameras going through a network switch, make sure it is

capable of handling jumbo packets and that it has sufficient memory capacity.

3. Configure inter-packet delay to avoid congestion in network switches.

4. Disable screen saver and power save functions on computers.

5. Use high performance computers with multi-CPU, hyper-thread and 64-bit CPU,

etc.

6. Only use Gigabit Ethernet equipment and components together with the camera.

7. Use at least Cat5e and preferably Cat6 Ethernet cables.

8. Whenever possible, limit the camera output to 8-bit.

- 34 -

AM-200GE / AB-200GE

Model

Pixel Type

Frame Rate

Packet size (Packet size is

1500)

AM-200GE

MONO8

40.6Frame/s

663Mbps

MONO10_PACKED MONO12_PACKED

38.4Frame/s

939Mbps

MONO10 MONO12

28.8Frame/s

939Mbps

AB-200GE

BAYGR8

40.6Frame/s

662Mbps

BAYGR10_PACKED BAYGR12_PACKED

38.4Frame/s

939Mbps

BAYGR10 BAYGR12

28.8Frame/s

939Mbps RGB8_PACKED

14.5Frame/s

709Mbps

YUV422Packed

28.8Frame/s

939Mbps

Exposure SensorReadOut Tap1,2

Transfer

Next Exposure

Next SensorReadOut Tap1,2

8.3.2 Video data rate (network bandwidth)

In the GigE Vision Interface, it is important to know the packet data volume in order to configure the system. the following table shows the reference value for each output at Normal Mode (AcquisitionMode Continuous, FrameTrigger OFF).

*1) The above data is if OB transfer mode is ON.

*2) If Jumbo Frames are not used, the frame rate except MONO8 and BAYGR8 will be

reduced by maximum 2%. Depending on Pixel Type, if Jumbo frames are used, the

packet size may be automatically optimized to a smaller size.

8.3.2.1 Exposure function

During sensor readout, the next exposure will start

1,2,3 ------------- 1199,1200th Line

1,2,3 -------------------1199,1200th Line

Fig. 32 Exposure behaviour

- 35 -

AM-200GE / AB-200GE

Output

Usable packet size

8bit

36 + 8 x n 34 ≤ n ≤ 3488

10bit_Packed, 12bit_Packed

36 + 12 x n 31 ≤ n ≤ 320

10bit,12bit

36 + 16 x n 29 ≤ n ≤ 296

RGB 8bit

36 + 24 x n 25 ≤ n ≤ 258

YUV422

36 + 16 x n 29 ≤ n ≤ 296

Item

Unit

Symbol

Image Width

[pixels]

Image Height

[pixels]

Bits per Pixel

[bits]

Frame Rate

[fps]

Packet Size

[Bytes]

Number of Packets (including Data Leader & Trailer Packet)

[packets]

Data Transfer Rate

[Mbit/s]

Item

Unit

value

Data Leader Packet Size

[Bytes]

Data Trailer Packet Size

[Bytes]

J=｛90+64+(E+18)*(G-2)｝*8*D/1000000

Where, G=ROUNDUP{A*B*C/8/(E-36)}+2

8.3.3 Note for setting packet size

The packet size is set to 1428 as the factory default. Users may enter any value for the packet size and the value will be internally adjusted to an appropriate, legal value that complies with the GenICam standard. The packet size can be modified in the GigE Vision Transport Layer Control section of the camera control tool.

Regarding data transfer rate, a larger packet size produces a slightly lower data transfer rate. The AM-200GE and AB-200GE can support a maximum of 16020 byte packets provided the NIC being used has a Jumbo Frames function with a setting of a 16020 bytes or larger.

Caution: Do not set the packet size larger than the maximum setting available in

the NIC or switch to which the camera is connected . Doing so will cause output to be blocked.

The usable packet size for each output is shown in the following table.

8.3.4 Calculation of Data Transfer Rate

In order to calculate the data transfer rate, the following parameters and formula are required.

Setting parameter

Fixed value

Formula to calculate Data Transfer Rate

- 36 -

The following table shows Bits per Pixel (Item C) which depends on the pixel format.

Pixel format

Bit

RGB8,bayerGR8

Mono10_Packed,Mono12_Packed

Bayer10_Packed, ayer12_Packed

Mono10, Mono12

Bayer10, Bayer12

RGB8_Packed

YUV422Packed

Item

Unit

Symbol

Setting

Image Width (Max)

[pixels]

1632

Image Height (Max)

[pixels]

1204

Bits per Pixel

[bits] C 8

Frame Rate

[fps]

40.6

Packet Size

[Bytes]

1500

Number of Packets (including Data Leader & Trailer Packet)

[packets]

Data Transfer Rate

[Mbit/s]

Calculation example: AM-200GE/AB-200GE Pixel type Mono/Bayer8

AM-200GE / AB-200GE

G=ROUNDUP {(1632 x 1204 x 8 / 8 / (1500-36)) + 2 = 1343+ 2 = 1345 J={90+62+(1500+18)x(1345-2)} x 8 x 40.6 / 1000000 = 663 Mbit/s

8.3.5 Simplified calculation (Approximate value)

A simple way to calculate the approximate data transfer rate is the following. Transfer data = image width (pixel) x Image Height (pixel) x depth per pixel

(depending on the pixel format) x frame rate / 1,000,000 (convert to mega bit)

In the case of the AM-200GE and AB-200GE with the full image and Mono 8bit pixel

format;

The data transfer rate = 1632 x 1204 x 8 x 40.6 / 1000000 = 639 Mbit/s

- 37 -

AM-200GE / AB-200GE

8.4. GigE camera connecting examples

8.4.1 Using a switching hub for 1 port

 All cameras and NIC belong to the same subnet  The accumulated transfer rate for all cameras should be within 800Mbps  The packet size and the packet delay should be set appropriately in order

for the data not to overflow in the switching hub.

8.4.2 Connecting a camera to each port of a multi-port NIC

 This is the example for using a 4-port NIC  The pair of the connecting camera and the NIC constructs one subnet. As for

the IP configuration, it is appropriate to use the persistent IP.

 In this case, each camera can use the maximum 800Mbps band width.

However, the load for the internal bus, CPU and the application software become heavy, so a powerful PC will most likely be required.

- 38 -

AM-200GE / AB-200GE

8.4.3 The data transfer for multiple cameras

8.4.3.1 If delayed readout is not used in continuous mode

 The packet delay should be set larger. The data traffic is controlled by the

buffer of the hub. It is necessary to check the buffer value of the unit.

8.4.3.2 If delayed readout is not used in trigger mode

 The packet delay should be set larger. The data traffic is controlled by the

buffer of the hub. It is necessary to check the buffer value of the unit.

- 39 -

AM-200GE / AB-200GE

8.4.3.3 If delayed readout is used

 The packet delay should be set smaller, and the packet delay trigger

controls the data traffic. If the camera has a pulse generator, it can control the data traffic.

- 40 -

AM-200GE / AB-200GE

Acquisition

State

Control

Exposure Control

Trigger

Selector

[Acquisition

Start]

Trigger

Selector

[Acquisition

Stop]

Trigger Mode

[JAI Acquisition

Transfer Start]

Acquisition Control

Active

Trigger / Exposure Control

Acquisition Start

Acquisition Stop

Acquisition Abort

Acquisition Mode

Acquisition Frame count

Trigger Selecctor

[Frame Start]

Trigger Selector

[Exposure Start]

Trigger Selector

[Exposure End]

Acquisition Frame Rate

Stream Control

Acquisition Status Control

Internal Stream Control

Acquisition

Status

Internal

Exposure

Control

9. Core functions

 The function naming of the AM-200GE and AB-200GE complies with GenICam SFNC

ver.1.3.

Most of the camera’s core operation is controlled by a combination of standard GenICam features related to acquisition, triggering, and exposure. Additional control is provided via built-in counter, timer, and event functions.

9.1. Acquisition function

Before using trigger and exposure controls, various acquisition controls must be set. The operation of the camera depends on the interrelationship of all three feature sets.

9.1.1 Basic image acquisition flow

The basic commands for acquiring images are as follows:

Acquisition mode To determine the number of the frame to be captured

Trigger Selector

Acquisition End Select if the acquisition end is controlled externally

Fig.34 Acquisition control, Trigger/Exposure control work flow

Acquisition Start Trigger Select if the acquisition start is controlled externally

Trigger Selector

Frame start Select if the acquisition of the frame is controlled

externally.

- 41 -

AM-200GE / AB-200GE

Acquisition

Trigger Wait

Frame Start Trigger Wait

Acquisition Active

Acquisition

Start Command Executed

Acquisition

Trigger Wait

Acquisition

Start

Trigger

Frame Start

Trigger

Acquisition

Start

Trigger

Acquisition

Status

Frame Start Trigger Wait

Acquisition Active

Acquisition

Start Command Executed

Frame Start

Trigger Wait

Frame Start

Trigger

Acquisition

Status

Frame Start

Trigger

Exposure mode To set the exposure method

The flow of these commands is shown below. The following drawings are based on the conditions that the Acquisition mode is Single and the Trigger selector is Frame Start.

If the acquisition start is set at ON (The acquisition is controlled externally)

If the acquisition start is set at OFF (The acquisition is controlled internally)

The following sections provide the details for each command set.

9.1.2 Acquisition mode

The AM-200GE and AB-200GE has three settings for capturing images.

 Single frame

AcquisitionStart command outputs one frame. Then the acquisition is stopped.

 MultiFrame

AcquisitionStart command outputs frames which are set by AcquisitionFrameCount. After the set frames are output, the acquisition is stopped.

 Continuous

AcquisitionStart command outputs frames until AcquisitionEnd is initiated.

9.1.2.1 Single Frame

In single frame mode, executing the AcquisitionStart command causes one frame to be captured. After one frame is captured, this operation is automatically stopped. In order to restart the capture, it is necessary to input the AcquisitionStart command again. BlockID is not reset until AcquisitionEnd is input and is incremented when the AcquisitionStart command is called. In case of PIV operation, this is not working.

- 42 -

AM-200GE / AB-200GE

AcquisitionSt art

Acquisition

Trigger

Wait

Acquisition

Active

AcquisitionTriggerWait

ExposureActive

CCD Readout

FrameActive

Stream Active

AcquisitionStatus

AcquisitionStart

Acquisition TriggerWait

AcquisitionActive

Acquisition

TriggerWait

If AcquisitionFrameCount＝N

・ Setting range of AcquisitionFrameCount

1≦ AcquisitionFrameCount ≦255（0xFF）

ExposureActive

CCD Readout

FrameActive

Stream Active

Frame 1 Frame N

AcquisitionStatus

◆ Normal single frame operation

1) AcquisitionStart command is input

2) AcquisitionActive becomes “TRUE” (accepts capture)

3) 1 frame is output

4) AcquisitionActive becomes “FALSE” (stop capturing)

Fig.35 Single frame timing

This drawing shows a case where the trigger is “OFF”. If the trigger is ON, FrameActive becomes “TRUE” on the different timing of AcquisitionActive.

◆ Forcing acquisition to stop

While AcquisitionActive is “TRUE”, if AcquisitionEnd or AcquisitionAbort is initiated, AcquisitionActive becomes “FALSE” (stop capturing).

9.1.2.2 MultiFrame

In this mode, the AcquisitionStart command captures the number of frames which are specified by AcquisitionFrameCount. AcquisitionFrameCount can be set in the range of 1 to 255 frames. After all frames are captured , this operation is automatically stopped. In case of PIV operation, this has to be set to an even number.

◆ Normal multi-frame operation

1) AcquisitionStart command is input

2) AcquisitionTriggerWait becomes effective

3) AcquisitionActive becomes “TRUE”

4) Output N frames as specified by AcquisitionFrameCount

5) AcquisitionActive becomes “FALSE”. Then the output stops. (See the following

diagram)

Fig.36 MultiFrame timing

- 43 -

This diagram shows a case where the trigger is “ON”. If the trigger is OFF,

AcquisitionStart

Acquisition

Trigger

Wait

AcquisitionActive

Acquisition

Trigger

Wait

AcquisitionStop

ExposureActive

CCD Readout

FrameActive

Stream Active

Frame 1 Frame N

AcquisitionStatus

FrameActive becomes “TRUE” at the same timing as AcquisitionActive.

◆ Forcing acquisition to stop

While AcquisitionActive is “TRUE”, if AcquisitionEnd or AcquisitionAbort is initiated, AcquisitionActive becomes “FALSE” (stop capturing). Once the operation is set to “FALSE”, the internal FrameCount is reset.

9.1.2.3 Continuous mode

In this mode, when the AcquisitionStart command is set, the image is continuously output at the current frame rate. This is the default setting for the AM-200GE and AB-200GE.

1) AcquisitionStart command is input

2) AcquisitionTriggerWait becomes effective

3) AcquisitionActive becomes “TRUE”

4) Images begin outputting continuously

5) AcquisitionEnd command is sent

6) AcquisitionActive becomes “FALSE”. At this moment, the output stops.

AM-200GE / AB-200GE

This drawing shows a case where the trigger is “ON”. If the trigger is OFF, FrameActive becomes “TRUE” at the same timing as AcquisitionActive.

9.1.3 AcquisitionAbort

AcquisitionAbort forces capture to stop if the AcquisitionAbort command is set while AcquisitionTriggerWait is effective or during exposure. The exact behaviour depends on the status of acquisition and readout:

Condition 1 - While reading out from CCD:

CCD readout and streaming continue. After they are completed, AcquisitionActive becomes “FALSE”(stop capturing).

At this moment, if AcquisitionStart is set, restart the capturing.

Condition 2 – Acquisition is active, but CCD readout is not yet initiated:

After the exposure is completed, the output is not initiated. AcquisitionActive becomes “FALSE”.

Fig.37 Continuous timing

- 44 -

Condition 3 - Awaiting a trigger:

AcquisitionActive immediately becomes “FALSE”(capturing is not possible).

9.1.4 AcquisitionFrameCount

If Acquisition Mode is set to MultiFrame, AcquisitionFrameCount can set the number of frames to be captured each time the AcqusitionStart command is input. Setting range is 1 to 255 frames.

9.1.5 AcquisitionFrameRate

Please also refer to the chapter 7.2.3 Frame rate calculation in the AOI mode.

1) In the trigger OFF mode (self-running mode), it is possible to set the exposure period longer than the number of lines required for CCD drive in the designated area of interest (AOI).

2) The number of lines set by AcquisitionFrameRate determines the frame period.

3) The range of lines which can be set by AcquisitionFrameRate is the shortest period to 0.5 seconds. The shortest period is dictated by the number of lines required for the desired AOI readout.

4) AcquisitionFrameRate cannot be used if the trigger mode is ON.

5) If the exposure time is longer than the frame rate, the exposure time has priority and the frame rate might be reduced.

AM-200GE / AB-200GE

9.1.6 AcquisitionStatus

AcquisitionStatus can show the operating status of the following signals set by AcquisitionStatusSelector. Each function is:

AcquisitionTriggerWait： Effective if waiting for a trigger AcquisitionActive ： Effective if capture is allowed AcquisitionTransfer： Effective while the data is transferring FrameTriggerWait： Effective if waiting for FrameTrigger FrameActive： Effective during FrameEffective period FrameTransfer： Effective while the data is transferring ExposureActive： The longest exposure period is provided if R, G and B

JAIAcquisitionWait: When the status of the stream becomes waiting, then

The following diagrams show different scenarios for Exposure Mode and Trigger Mode and their effect on AcquisitionStatus.

channel exposure times are different.

it becomes active.

- 45 -

AM-200GE / AB-200GE

AcquisitionStart

Acquisitio n

Trigger

Wait

Acquis itionActive

Acquis ition TriggerWait

AcquisitionStop

Acquisition

start

com mand

Acquis ition

stop

com mand

ExposureActive

CCD Readout

FrameActive

FrameTransfer

Frame1 FrameN

FrameTriggerWait

AcquisitionStatus

AcquisitionStart

Acquisition

Trigger

Wait

AcquisitionActive

Acquis ition TriggerWait

Acquis itionStop

Acquisition

start

com mand

Acquis ition

stop

com mand

ExposureActive

CCD Readout

FrameActive

FrameTransfer

Frame1 FrameN

FrameTriggerWait

Acquis itionStatus

AcquisitionStart

Acquisitio n

Trigger

Wait

Acquis itionActive

Acquis ition TriggerWait

Acquis itionStop

Acquisition

start

com mand

Acquisition

stop

com mand

ExposureActive

CCD Reado ut

FrameActive

FrameTransfer

Frame1 Fram eN

FrameTriggerWait

FrameTrigger

AcquisitionStatus

① If ExposureMode=OFF

Fig.38 Acqusition Status

② If ExposureMode=On, Trigger Mode=OFF

Fig.39 Acquisition Status

③ If ExposureMode=On, Trigger Mode =ON

Fig.40 Acqusiition Status

- 46 -

AM-200GE / AB-200GE

Acquisition Start

Acquisition

Set the capture start externally

Acquisition End

Acquisition

Set the capture stop externally

Frame Start

Trigger

Set the frame start externally

JAI Acquisition Transfer Start

Stream

Set the stream start externally

9.2. Trigger Control

9.2.1 TriggerSelector(TriggerMode)

This is the function to set the trigger operation. This will set how to control the output and the exposure.

9.2.1.1 Acquisition

This is the trigger function to control the output. This controls AcquisitionStart and AcquisitionEnd. A description of the configuration process is as follows:

 AcquisitionStart trigger: Set whether the capture start is to be controlled

TriggerMode On： After AcquisitionStart command is input, input the

TriggerMode Off： AcquisitionStart command is input. It makes

 AcquisitionEnd trigger: Set whether the end of the capture is to be controlled

TriggerMode On： While AcquisitionActive is effective, input the signal

TriggerMode Off： AcquisitionStart command is input. It makes

AcquisitionActive invalid regardless of the trigger

Note: Refer also to section 9.1.1

9.2.1.2 Exposure

These commands are used for setting the exposure control. FrameStart is used for trigger input. If ExposureMode is set to Timed or TriggerWidth except OFF, the combination of the ExposureMode setting and FrameStart setting will determine the type of exposure and whether triggering is OFF or ON. The following table shows the combination and the operation.

externally or not.

signal selected by AcquisitionStart trigger as the trigger, and make AcquisitionActive effective.

AcquisitionActive effective regardless of AcquisitionStart trigger.

externally or not.

selected by AcquisitionEnd as the trigger, and make AcquisitionActive invalid.

source.

- 47 -

AM-200GE / AB-200GE

TriggerSelector

ExposureMode

Frame Start

Operation

Previous JAI

trigger name

(for reference)

OFF

OFF or

Trig OFF(Free run) No Exposure Control

Trigger OFF

Timed

OFF

Trig OFF(Free run) Exposure Control Is possible

Trigger OFF

Trig On

EPS

TriggerWidth

OFF

Trig OFF(Free run) No Exposure Control

Trigger OFF

Trig On

PWC

 FrameStart trigger： Set whether the start of the frame is to be controlled

externally or not.

TriggerMode On： While AcquisitionActive is effective and ExposureMode is

set at Timed or TriggerWidth, start exposure using the signal selected by FrameStart trigger.

TriggerMode Off： While AcquisitionActive is effective, self-running operation

takes place.

9.2.1.3 Stream control The signal readout from the CCD can be stored in the frame memory and the stream

control determines the timing of the readout as the stream. This can be compared to delayed readout in the previous model.

◆ JAI Acquisition Transfer Start: Set the start of the stream externally.

Trigger Mode ON : When AcquisitionActive is active, the

stream is output by JAI Acquisition Transfer Start.

Trigger Mode OFF: If AcquisitionActive is active status, the

stream can be output.

9.2.2 Triggersoftware

This is one of the trigger sources and is the software trigger command. This has one command signal to each of the 6 items of TriggerSelector. To use this function, TriggerSource must be set at TriggerSoftware.

9.2.3 Triggersource

The following signals can be selected as the trigger signal source.

- 48 -

AM-200GE / AB-200GE

RisingEdge

FallingEdge

LevelHigh

LevelLow

Timed

○ ○ ×

TrigegrWidth

× × ○

○

Timed-JAI PIV

○ ○ ×

Timed-JAI Pre-Dump

○ ○ ×

Priority

Function

Acquisition Start Trigger

Acquisition End Trigger

Frame Start Trigger

JAI Acquisition Transfer Start

Timer Trigger Source(Timer1)

Counter Trigger Source(Counter1)

Counter Event Source(Counter1)

Counter Reset Source(Counter1)

9.2.4 TriggerActivation

This determines the behaviour of the trigger. RisingEdge： Initiate at the signal rising edge FallingEdge： Initiate at the signal falling edge LevelHigh： Initiate during the signal high level LevelLow： Initiate during the signal low level

Note: When TriggerWidth is used, TriggerActivation should be set at either LevelHigh or LevelLow.

9.2.4.1 Initial Trigger Activation Set

The hardware used as TTL input through D-SUB 9 pin for GPIO, is designed as the

circuit to minimize the influence of noise. Therefore, the input polarity is set at either Hi-Active or Low-Active and on every time if High or Low is selected, the input polarity is automatically changed. However, just after the power is ON, it is not possible to recognize the initial status on TTL signal, it is determined by the trigger activation setting of function used TTL signal and initialized accordingly. However, as there are several functions used TTL signal and each has own trigger activation setting, the camera initializes according to its priority. The initial Trigger Activation Set function forces to set the input polarity after the power is ON and the user can always use the fixed setting regardless of its priority. The following is the selection.

Hi-Active: At the first time if the power is ON, detect the “LOW to HIGH” of

the TTL input.

Low-Active: At the first time if the power is ON, detect the “HIGH to LOW” of

the TTL input.

Auto(Default): At the first time if the power is ON, use the trigger activation

setting of the first priority function.

The following table shows the priority of the trigger activation at AUTO setting.

- 49 -

AM-200GE / AB-200GE

Trigger delay

AcquisitionStart

AcquisitionEnd

FrameStart

○

JAIAcquisitionTransferStart

9.2.5 TriggerOverlap

This function is used to set whether the trigger can be accepted during the data readout in cases where FrameStart trigger or ExposureStart trigger are “ON”.

OFF: While the CCD reads out the data, the trigger cannot be accepted.

This works as LVAL asynchronous operation.

ReadOut: While the CCD reads out the data, the trigger can be accepted.

In this mode, if the trigger is input during CCD readout, it works as LVAL synchronous and if the trigger is input while the CCD is not reading out, it works as LVAL asynchronous.

This is the same behaviour as LVAL SYNC/ASYNC auto detection.

Note: During synchronous reset, a jitter of up to 1 LVAL will occur from trigger input

to exposure start and end. During asynchronous reset, there is no jitter.

9.2.6 Triggerdelay

This function delays the trigger signal against the trigger input.

Step is 1usec/Step.

The setting range is 16bit and from 0 to 65,535usec.

9.3. Exposure Control

This is the function to manage the exposure settings.

9.3.1 Exposure Mode

The exposure mode can be selected from the following choices.

Off： No exposure control. Timed： The exposure time is to be set in microseconds.

If FrameStart in TriggerSelector is“OFF”, the exposure is

controlled in Free Run. If FrameStart in TriggerSelector is “ON”, this functions as the EPS mode.

Note: JAI Pre-Dump or JAI PIV can be available by using TriggerOption.

TriggerWidth： This mode controls the exposure time by the pulse width.

If FrameStart in TriggerSelector is “OFF”, The camera operates in Free Run. If FrameStart in the TriggerSelector is “ON”, this functions as the PWC mode.

The following is the table for the combination of ExposureMode and TriggerControl

- 50 -

AM-200GE / AB-200GE

TriggerSelector

ExposureMode

Frame Start

Operation

Previous JAI

trigger name

(for reference)

OFF

OFF or

Trig OFF(Free run) Exposure controllable

Trigger OFF

Timed

OFF

Trig OFF(Free run) Exposure control is possible

Trigger OFF

Trig On

EPS

TriggerWidth

OFF

Trig OFF(Free run) No Exposure control

Trigger OFF

Trig On

PWC

and its function.

9.3.2 ExposureTime

This is effective only if ExposureMode is set to“Timed”. This command can set the exposure time.

The setting can be done in 1μs / step. Minimum: 10μs

Maximum: 2sec - 194μs (1.999806sec)

9.3.3 ExposureAuto

This is auto exposure control function and is effective only in the “Timed”mode. The reference video level is controlled by JAI AGC Reference. ExposureAuto includes OFF, Once and Continuous modes.

The following detailed settings are aslo possible. ExposureAuto speed: The reaction speed can be controlled ExposureAuto Max: Set the maximun expsoure time ExposureAuto Min: Set the minimum expsoure time GainAutoReference: Set the reference video level for operation ALC channel area Set the portion of the image to be used for exposure

control

Note: Please also refer to section 11.1. ALC

9.4. Counter function

This function can count up the internal pulse counts.

9.4.1 CounterSelector

The AM-200GE and AB-200GE has one counter. The counter function is activated by setting ConterEventSource, CounterResetSource or StartSource.

9.4.2 CounterEventSource

CounterEventSource works as the trigger to start the count up.

CounterEventSource can be selected from the following signals.

① Off ② AcquisitionTrigger ③ AcquisitionStart ④ AcquisitionEnd

- 51 -

AM-200GE / AB-200GE

⑤ FrameStart

⑥ Line 1(TTL out1) ⑦ Line 2(TTL out2) ⑧ Line 3(Opt out1) ⑨ Line 4(Opt out2) ⑩ Line 5(Opt in1) ⑪ Line 6(Opt in2) ⑫ Line 7(TTL in1) ⑬ Line 8(LVDS in)

9.4.3 CounterEventActivation

This selects the timing for when the counter starts up.

RisingEdge： The counting starts at the signal rising edge. FallingEdge：The counting starts at the signal falling edge.

9.4.4 CounterResetSource

The reset source can be selected from the following signals.

The reset source works as the trigger to reset the counter.

① Off ② Software ③ Line 1(TTL out1) ④ Line 2(TTL out2) ⑤ Line 3(Opt out1) ⑥ Line 4(Opt out2) ⑦ Line 5(Opt in1) ⑧ Line 6(Opt in2) ⑨ Line 7(TTL in1) ⑩ Line 8(LVDS in) ⑪ Action1 ⑫ Action2

9.4.5 CounterResetActivation

This selects the timing for resetting the counter.

RisingEdge： The counter is reset at the signal rising edge. FallingEdge：The counter is reset at the signal falling edge.

9.4.6 CounterReset

This is the command to reset the counter.

9.4.7 CounterValue

This can read the counter value or set the default value when the counter starts.

9.4.8 CounterDuration

This can set the CounterCompleted value of the counter. The counter can be set in 16bit.

9.4.9 CounterStatus

This shows the counter status.

CounterIdle： The counter is not operating.

- 52 -

AM-200GE / AB-200GE

CounterTrigger

Counter

Idle

CounterActive

Counter

Overflow

CounterReset

Counter

“0000”

CountUp

Count

NoChange

CounterEvent C ounterEvent

Counter

“0000”

Count = CounterDuration

Counter

Completed

CounterIdle

Counter

Trigger

Wait

Count = FFFF

CounterStatus

16bit Counter

“0000” CountUp “FFFF”

Counter

“0000”

CounterValue

“0000” “FFFF”

CounterValue

AtReset

Count = CounterValue In

Event Active

Event NoActive Event NoActive

The CounterTriggerSource is “Off”. CounterTriggerWait： When the counter is waiting for the start trigger CounterActive： The counter is operating.

CounterCompleted： When the counting value reaches CounterDuration CounterOverflow： If the counter counts past the maximum value

Note: The counter itself counts up to its maximum value.

Fig.40 Counter Status

9.4.10 CounterTriggerSource

This is used to select the counter trigger from the following signals. The counter trigger is the trigger that starts the count up.

① Off ② AcquisitionTrigger ③ AcquisitionStart ④ AcquisitionEnd ⑤ FrameTrigegr ⑥ FrameStart ⑦ FrameEnd ⑧ Line 1(TTL out1) ⑨ Line 2(TTL out2) ⑩ Line 3(Opt out1) ⑪ Line 4(Opt out2) ⑫ Line 5(Opt in1) ⑬ Line 6(Opt in2) ⑭ Line 7(TTL in1) ⑮ Line 8(LVDS in) ⑯ Action1 ⑰ Action2

9.4.11 CounterTriggerActivation

This selects the timing for starting the count up.

RisingEdge： The counter starts at the signal rising edge.

- 53 -

FallingEdge：The counter starts at the signal falling edge.

AM-200GE / AB-200GE

TimerTrigger

TimerIdle TimerActive

Delay

Timer

“0000”

Timer = TimerDuration

Timer

TriggerWai

TimerStatus

16bit DelayTimer

Delay

Timer

DelayTimer= TimerDelay

Timer

Completed

TimerIdle

DelayTimer N oChange

Timer

TimerValue

Timer

TimerNoChange

16bit Timer

9.5. Timer Control

9.5.1 TimerSelector

There is one internal timer. The timer function starts if the start trigger, TimerDelay

and TimerDuration are set.

9.5.2 TimerDuration

This is used to set the maximum value of the timer.

The internal timer counter can be set in 16bit.

9.5.3 TimerDelay

This can set the period to start the timer. This results in the delay of the timer start. The internal delay counter can be set in 16bit.

9.5.4 TimerValue

This can set the default value of the timer and read the current setting value.

9.5.5 TimerStatus

This checks the current status of the timer and provides one of the following.

TimerIdle： When the timer is not operating.

When TimerTriggerSource is OFF.

TimerTriggerWait： When the timer is waiting for the start trigger

TimerActive： When the timer is operating

TimerCompleted： When the timer reaches its maximum value

Fig.41 Timer Status

9.5.6 TimerTriggerSource

The start trigger signal to the timer can be selected from the following list.

① Off ② AcquisitionTrigger ③ AcquisitionStart ④ AcquisitionEnd ⑤ FrameTrigger ⑥ FrameStart ⑦ FrameEnd

- 54 -

AM-200GE / AB-200GE

⑧ Line 1(TTL out1) ⑨ Line 2(TTL out2) ⑩ Line 3(Opt out1) ⑪ Line 4(Opt out2) ⑫ Line 5(Opt in1) ⑬ Line 6(Opt in2) ⑭ Line 7(TTL in1) ⑮ Line 8(LVDS in) ⑯ Timer1End ⑰ Action1 ⑱ Action2

9.5.7 TimerTriggerActivation

The timing of the start trigger to the timer can be selected from the following.

RisingEdge： The timer starts at the signal rising edge. FallingEdge：The timer starts at the signal falling edge.

9.6. Event Control

9.6.1 EventSelector

The event can be selected from the following list.

AcquisitionTrigger、FrameStart、FrameEnd、、Line1RisingEdge、 Line1FallingEdge、Line2RisingEdge、Line2FallingEdge、Line3RisingEdge、 Line3FallingEdge, Line4RisingEdge、Line4FallingEdge、Line5RisingEdge、 Line5FallingEdge、Line6RisingEdge、Line6FallingEdge、Line7RisingEdge、 Line7FallingEdge、Line8RisingEdge、Line8FallingEdge

9.7. ActionControl

ActionControl is used to activate the specific functions of multiple cameras on the same network at the same time. For instance, it can be used to trigger multiple cameras at the same time.

ActionControl appears as two inputs (Action 1, Action 2) and is connected with 6 Triggers, CounterReset of the counter, CounterTrigger and Timer. If ActionControl is used, the input source to the trigger should be set to Action 1 or Action 2 in advance.

9.7.1 ActionDeviceKey

Set the same value to cameras which are operated at the same time.

9.7.2 ActionSelector

Select Action 1 or Action 2.

9.7.3 ActionGroupMask

Set the mask value for grouping Action 1 operation.

9.7.4 ActionGroupKey

Set the key (value) to operate Action 1.

- 55 -

AM-200GE / AB-200GE

10. Operation modes

This camera can operate in the following functions.

1. Continuous

2. Timed (Seamless OFF)(EPS)

3. Timed (Seamless ON )

4. Trigger Width (PWC)

The followings are JAI Custom modes.

5. Pre-Dump (RCT)

6. Particle Image Velocimetry (PIV)

7. Sequential trigger

8. Delayed Readout trigger

9. ROI readout

10. OB transfer readout

10.1. Continuous mode (Free run)

For applications not requiring asynchronous external triggering, this mode should be used. In this mode it is possible to use a lens with a video controlled iris. As for the timing, please refer to chapter 7.7 “Video output timing”. In continuous mode, exposure time can be controlled by the frame rate or by the electronic shutter. The following examples describe the GenICam settings used to configure the camera for continuous operation.

To use this mode: Acquisition mode : Continuous Trigger selector : Frame Start Trigger mode : OFF Exposure mode : OFF or Timed

Note: If ExposureMode is set to Timed, the exposure can be controlled.

or Acquisition mode : Continuous Trigger selector : Frame Start Trigger mode : ON Exposure mode : OFF

- 56 -

AM-200GE / AB-200GE

Full scan

1229L

1/2 Partial

929L

2/3 partial

779L

1/4 Partial

554L

1/8 Partial

442L

1/2 V Binning (AM-200GE only)

622L

The above is figures if the pixel format is MONO8 or Bayer 8

Full scan

1231L

1/2 Partial

931L

2/3 partial

781L

1/4 Partial

556L

1/8 Partial

444L

1/2 V Binning (AM-200GE only)

626L

 Line number of a frame

10.2. Trigger operation with “timed” exposure (Previously called EPS)

An external trigger pulse initiates the capture, and the exposure time (accumulation time) is set in advance.

To use this mode:

Acquisition mode : Continuous, Single Frame, Multi Frame Acquisition Frame Count : Required number (if Multi Frame is selected) Trigger Selector : Frame Start

Trigger Mode : On Trigger Source : Select from the pull down menu Trigger Overlap : OFF or Read out

Exposure Mode : Timed

Important notes on using this mode

 Trigger pulse >2 LVAL to <1 FVAL)  The following table shows minimum trigger interval in synchronous accumulation mode

The above is figures if the pixel format is MONO8 or Bayer 8 In case of asynchronous mode, the exposure time should be added to the above table.

- 57 -

10.2.1 TriggerOverlap = OFF

Binning Control

OFF, 2x1

4.55μs ± 0.05μs

2L (min)

2.5L ～ 3.5L

1x2, 2x2

6.7μs ± 0.05μs

2L (min)

2.5L ～ 3.5L

Binning Control

OFF, 2x1

24.6μs ± 0.05μs

2L (min)

1x2, 2x2

28.6μs ± 0.05μs

2L (min)

Trigger

CCD exposure

Exposure

Int_FVAL

Expsoure period

Active

Trigger

CCD Exposure

Exposure

Int_FVAL

Exposure period

Active

This works as LVAL asynchronous operation.

AM-200GE / AB-200GE

Fig.42 TriggerOverlap=OFF（Timed）

10.2.2 TriggerOverlap = Read out

In this mode, if the trigger is input during CCD readout, it works as LVAL synchronous and if the trigger is input while the CCD is not reading out, it works as LVAL asynchronous.

10.2.3 SmearLess ON

In this mode, in addition to the trigger setting for “Timed”, the trigger option

Fig.43 TriggerOverlap = READOUT (Timed)

should be set at smearless. The timing is the same as Timed(Pre-Dump). Please refer to 10.4. Pre-dump mode (so-called RCT) (JAI Custom)

- 58 -

AM-200GE / AB-200GE

Full scan

1560L

1/2 Partial

1260L

2/3 partial

1110L

1/4 Partial

886L

1/8 Partial

773L

The above is figures if the pixel format is MONO8 or Bayer 8

Full scan

1233L

1/2 Partial

933L

2/3 Partial

783L

1/4 Partial

559L

1/8 Partial

446L

1/2 V Binning (AM-200GE only)

626L

In this mode, Trigegr OverLap can be set only OFF.

 Minimum trigger interval

10.3. Trigger operation by “TriggerWidth” (Previously called PWC)

In this mode the accumulation time is equal to the trigger pulse width. Here it is possible to have a long time exposure. The minimum active period of the trigger is 2L and the minimum trigger interval is shown in the following table.

To use this mode:

Acquisition mode : Continuous, Single Frame, Multi Frame Acquisition Frame Count : Required number (if Multi Frame is selected) Trigger Selector : Frame Start

Trigger Mode : On Trigger Source : Select from the pull down menu Trigger Overlap : OFF or Read out

Exposure Mode : Trigger Width

Important notes on using this mode

 Trigger pulse width >2 LVAL to <2 seconds  The following table shows minimum trigger interval in synchronous accumulation mode

The above is figures if the pixel format is MONO8 or Bayer 8

In case of asynchronous mode, the exposure time should be added to the above table.

- 59 -

10.3.1 TriggerOverlap = OFF

Binning Control

OFF, 2x1

4.08μs ± 0.05μs

2L (min)

2.5L ～ 3.5L

30.15μs ± 0.05μs

1x2, 2x2

6.3μs ± 0.05μs

2L (min)

2.5L ～ 3.5L

21.28μs ± 0.05μs

Binning Control

OFF, 2x1

24.12μs ± 0.05μs

2L (min)

3.5L(70.78μs)

51.51μs ± 0.05μs

1x2, 2x2

28.31μs ± 0.05μs

2L (min)

3.5L(70.78μs)

53.4μs ± 0.05μs

Trigger

CCD Exposure

Exposure

Int_FVAL

Exposure Period

Active

Trigger

CCD Exposure

Exposure period

Int_FVAL

Exposure

Active

This works as LVAL asynchronous operation.

AM-200GE / AB-200GE

Fig.44 Trigger OberLap = OFF (Trigger width)

10.3.2 TriggerOverlap = Read out

In this mode, if the trigger is input during CCD readout, it works as LVAL synchronous and if the trigger is input while the CCD is not

reading out, it works as LVAL asynchronous.

Fig. 45 Trigger OverLap = READOUT (Trigger width）

- 60 -

AM-200GE / AB-200GE

Full scan

1560L

2/3 Partial

1260L

1/2 Partial

1110L

1/4 Partial

886L

1/8 Partial

773L

The above is figures if the pixel format is MONO8 or Bayer 8

Binning Control

OFF, 2x1

6.587ms ± 0.05μs

2.5L ～ 3.5L

1x2, 2x2

6.587ms ± 0.05μs

2.5L ～ 3.5L

Trigger

CCD Exposure

Exposure Active

int-FVAL

int-DVAL

10.4. Pre-dump mode (so-called RCT) (JAI Custom)

Until the trigger is input, the camera operates continuously. At this moment, the video signal, FVAL and LVAL are output but DVAL is not output. When the trigger is input, the fast dump is activated to read out the electronic charge very quickly, after which the accumulation and the readout are performed. This fast dump period is 14.325ms. When the accumulated signal against the trigger is read out, FVAL , LVAL and DVAL are output too.

To use this mode;

Acquisition Mode : Multi Acquisition frame Count : 2 Trigger selector : Frame Start Trigger mode : ON Exposure Mode : Timed Trigger option (JAI Custom Control) : Pre Dump

In this mode, Trigger Overlap is automatically set to OFF.

Important notes on using this mode

 The following table shows minimum trigger interval in asynchronous accumulation mode

Fig.46 Pre-dump mode timing

- 61 -

AM-200GE / AB-200GE

Exposure

External Trigger

Int_FVAL

Int_DVAL

te1 ift

te2

tframe1

tframe24LVAL

Exposure Active

time name

description

time td

Exposure beginning delay

4.4us

te1

First exposure time period

10us ～ 31.04ms

te2

Second exposure time

24.63ms (frame rate)

itf

Inter framing time

6.64us

tframe1

First Frame read out

24.63ms max

tframe2

Second Frame read out

24.63ms max

10.5. PIV (Particle Image Velocimetry) (JAI Custom)

The Particle Image Velocimetry mode can be used in applications where 2 images must be taken with a very short time interval. It can only be used with strobe flash as illumination. The first accumulation time is 10sec to 98.05ms. Then, the second exposure will be taken. The accumulation is LVAL asynchronous. The first strobe is activated in the first exposure duration and the second strobe is taken during the first frame being readout. In this way, two strobe pulses produce two video outputs.

To use this mode:

Acquisition Mode : Multi (note) Acquisition Frame Count : 2 or even number (Note) Trigger selector : Frame Start

Trigger mode : ON Exposure mode : Timed Trigger option (JAI Custom Control) : PIV

Note: These two features are exclusively set to “Multi” and “2” , if they are set to

others. In this mode, Trigger Overlap is automatically set to OFF.

Fig.47 PIV mode

- 62 -

AM-200GE / AB-200GE

Sequence 1 Sequence 4Sequence 3Sequence 2

10.6 Other JAI custom mode

10.6.1 Video Send Mode

The Video Send Mode is the function to select how the image information will be read out from the camera.

Normal： Ordinary operation Sequence Mode： Sequence Trigger Mode: Multi Mode： Multi ROI operation

10.6.1.1 Normal: Ordinal operation

In this mode, the stream is output without any control.

10.6.1.2 Sequence Trigger Mode

This mode allows the user to define a preset sequence of up to 10 images, each with its own ROI, Exposure time and Gain values. As each trigger input is received, the image data within the preset sequence is output as described below.

Trigger

Sequence Operation

Fig.44 Sequential Trigger Mode

This function is effective when the video send mode selector is set at the Sequence Trigger Mode. In Sequence Trigger Mode, the following parameters can be set.

Sequence ROI index: The index (ID) to which the settings will be applied Sequence ROI FrameCount: The number of frames to capture at this index Sequence ROI Next index: Indicate the next index (ID) in the sequence Sequence ROI Width: Set the horizontal readout width Sequence ROI Height: Set the vertical readout lines Sequence ROI Offset X: Set the horizontal offset Sequence ROI Offset Y: Set the vertical offset Sequence ROI Gain: Set the gain Sequence ROI Exposure Time: Set the exposure time

- 63 -

AM-200GE / AB-200GE

Index

ROI

Exposure

time

Gain

Frame

count

Index

Width

Height

Offset

Frame

count

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

1600

1200

16 4 0

24501

1 1 0

The following default settings can be modified by the user to define a sequence.

The other necessary register for the Sequence Trigger Mode is Sequence Repetition. It sets the number of times the sequence will repeat in the range of 1 to 255 or indefinitely (Sequence Repetition = 0).

Note: If the Binning Horizontal/Vertical mode is changed from OFF to ON after ROI size is set. the area setting value is reduced to 1/2, however, if the Binning Horizontal/Vertical mode is changed from ON to OFF, the area setting value is not changed. Please reset by manually.

To use this mode:

Acquisition mode : Single Frame Trigger Selector : Frame Start

Trigger Mode : On

Trigger Source : Select from the pull down menu

Trigger Overlap : OFF or Read out

Exposure Mode : Timed, Trigger Width

For each sequence,

The following table shows the minimum trigger interval in asynchronous accumulation mode. In the sequential mode, only asynchronous mode is functional. Therefore, the trigger timing should be set so that the timing is not in synchronous mode.

 The conditions for this table are that shutter speed should be set the same for all

sequences. If the shutter speed is different, the difference of exposure time should be added. It is recommended to set the exposure time in order of the shortest to the longest one.

 Do not input the trigger just after the sequence is reset. It requires at least 500ms delay.

In sequential mode, the exposure should be adjusted so that the LVAL async mode can always function.

Minimum interval of the trigger pulse (note: V binning is AM-200GE only)

- 64 -

AM-200GE / AB-200GE

Readout mode

FULL

2/3 AOI

1/2 AOI

1/4 AOI

1/8 AOI

Binning

Minimum frame line

1231

931

781

556

444

624

The above is figures if the pixel format is MONO8 or Bayer 8

ROI 1

ROI 2

ROI 3

ROI 4

ROI 5

10.6.1.3 Multi ROI Mode

A maximum of 5 preset ROI images can be taken from one image. Using this function, the total data can be smaller than a full frame.

Fig 49. Multi ROI

If the Video Send Mode Selector is set to Multi Mode, this function becomes effective. In the Multi ROI Mode, the following items can be set.

Multi ROI Index： This is the index (0-4) to which the setting will be applied Multi ROI Next Index： Indicate the next index to read out Multi ROI Width： Set the horizontal readout width Multi ROI Height： Set the vertical readout lines Multi ROI Offset X： Set the horizontal offset

Multi ROI Offset Y: Set the vertical offset

Each ROI can be overlapped.

10.6.2 Delayed Readout Mode (JAI Custom Control)

If multiple cameras need to be simultaneously triggered by one trigger pulse, this function can be used in order for the Ethernet bandwidth to accommodate the added traffic without conflicts. Refer to the chapter 8.4 too.

- 65 -

AM-200GE / AB-200GE

Exposure

CCD output

Store in GigE

GigE output

Frame Start Trigger

CCD　surface

CCD readout

Frame memory

JAI Acquisition Transfer Start Trigger

Ethernet　output

This function can be set by the following;

Set the necessary parameters of the trigger setting to capture the image and set JAI_AcqusitionTransferStart in Trigger Selector to ON, then the readout can be controlled by the external trigger signal which is selected in JAI_AcqusitionTransferStart.

Trigger settings:

Readout settings:

Fig.50 Delayed Read Out

10.6.3 OB transfer

It is possible for the user to decide whether the optical black (OB) portion of the image will be transferred or not. The optical black part can be used for black reference in the application software. The default setting is only for the image.

- 66 -

AM-200GE / AB-200GE

Normal

When OB is transferred

Binning Vertical=1 Binning Horizontal=1

16 1616 4

1204

1 16 1616 1632 1

1204

Only for AM-200GE

Binning Vertical=2 Binning Horizontal =1

16 1616 4

604

1 16 1616 1632 1

ます

604

Only for AM-200GE

Binning Vertical=1 Binning Horizontal =2

8 608 4

1204

1 8 608 616 1

ます

1204

Only for AM-200GE

Binning Vertical=2 Binning Horizontal =2

8 608 4

604

1 8 608 616 1

ます

604

The following table shows the total image size transferred at each condition.

10.6.3.1 Vertical OB transferred

Set as follows. Offset X=16(Note) Offset Y=0 Width =1600

Height = Effective lines ＋4

Note: If Binning Horizontal is set to x2, Offset X should be 8.

10.6.3.2 Horizontal OB transferred

Set as follows.

In this case, the width should be set at maximum. Offset X=0 Offset Y=4

Width =1632(Note)

Height = Effective lines

Note: If Binning Horizontal is set to x2, the width is 1616 due to 8 pixels OB on both

sides.

- 67 -

AM-200GE / AB-200GE

Trigger Mode

Binning Vert

※

Binning Hori

※

Exposure Time

AOI

Multi ROI

Sequence ROI

ALC

Auto Exposure /Gain

Over lap

AIC

AGC/ ASC

Exposure OFF Trigger OFF

１ ○ ×

○ × ×

○ ○ ×

２ ○ ×

○ × ×

○ ○ ×

Timed Trigger OFF

１ ○ ○

○ × ×

○ ○ ○

× ２ ○

○

○ × ×

○ ○ ○

Timed Trigger On (EPS)

１ ○ ○

○ ○ ○

× × ×

○

２ ○ ○

○ ○ ○

× × ×

○

TriggerWidth (PWC)

１ ○ ×

○ ○ ×

× × ×

○ ２ ○

○ ○ ×

× × ×

○

Timed– JAI_PreDump (RCT)

１ ○ ○

○ ○ ×

○ ○ ○

２ × ×

× × ×

TimedJAI_PIV

１ ○ ×

○ × ×

× × ×

２ × ×

× × ×

10.6.3.3 OB transfer is not activated

Set as follows.

Offset X=16 (Note)

Offset Y=4 Width =1600 Height = Effective lines

Note: If Binning Horizontal is set to x2, offset X should be 8.

10.7. Mode and function matrix table

The following table shows the possible combinations of mode and function.

○ for effective and × for invalid

※Only for AM-200GE

- 68 -

11. Other functions

Gain is fixed at Min.

Dark　　　　　　　　　　 Light changes　　　　　　　　　 Bright

Auto Shutter

Max

Auto shutter operation

Max ～ Min (User set)

Auto Shutter

fixed at Min

Iris diaphragm fixed (Open)

Auto iris

operation

AGC works:

Auto shutter works:

Auto iris works:

AGC operation

Max ～　Min (User set)

AGC

Max

Iris stops just

before close

Operation if light changes from dark to bright

Operation if light changes from bright to dark

11.1. ALC

In the AM-200GE and AB-200GE, auto gain, auto shutter and auto iris functions can be combined to provide a wide ranging automatic exposure control from dark to bright or vice versa. The functions are applied in the sequence shown below and if one function is disabled, the linkage between the other two is maintained.

In order to make ALC function effective, set the Auto Iris Lens Control Signal Output to “ON”. The auto iris function is worked together with AGC and Exposure Auto.

If the lighting condition is changed from bright to dark AIC ― ASC ― AGC If the lighting condition is changed from dark to bright AGC ― ASC ― AIC

AM-200GE / AB-200GE

GainAutoReferecne will determine the target video level for AGC, Auto Shutter and/or Auto iris. For instance, if GainAutoReference is set to 100% video level, AGC, Auto Shutter and/or Auto iris will function to maintain 100% video level.

 Please note that ALC function is available only for the continuous mode.

11.2 Black level control

This function adjusts the setup level. This can be adjusted from -256 to 255 LSB in the 10bit output.

Fig.51 ALC function concept

- 69 -

AM-200GE / AB-200GE

Digital All

Digital Tap 2 All

Digital All

Digital Red All

Digital Blue All

Digital Tap 2 All

Digital Tap 2

Rch

Digital

Tap 2

Bch

Tap 1 Tap 2

Tap1

Gch

Tap1

Rch

Tap1

Bch

Tap1

Gch

Tap1

Rch

Tap1

Bch

11.2.1 Black level control relations

Fig.52 Black level control relations

11.2.2 Black Level Selector

The following parameters can be set.

AM-200GE : DigitalAll/Tap2All AB-200GE : DigitalAll/DigitalRed/DigitalBlue/Tap2All/Tap2Red/Tap2Blue

11.2.3 Black Level

Each parameter can be adjusted in the following range.

AM-200GE :

DigitalAll ：-1024～+1023 Tap2All ：-512～ +511

AB-200GE :

DigitalAll ：-1024～+1023 DigitalRed ：-512～ +511 DigitalBlue ：-512～ +511 Tap2All ：-512～ +511 Tap2Red ：-512～ +511 Tap2Blue ：-512～ +511

11.2.4 Black Level Auto

The tap balance can be adjusted. Use lens cap for adjustement. OFF: Adjust manually Once : Adjust only one time

- 70 -

AM-200GE / AB-200GE

Analog All

Digital All

Digital Tap 2 All

Analog All

Digital All

Digital Red All

Digital Blue All

Digital Tap 2 All

Digital Tap 2

Rch

Digital

Tap 2

Bch

Tap 1 Tap 2

Tap1

Gch

Tap1

Rch

Tap1

Bch

Tap1

Gch

Tap1

Rch

Tap1

Bch

11.3. Gain control

11.3.1 Gain control relations

In the gain control, there are several parameters to be set. AnalogueALL can be used

as the master gain control. DigitalGain and TapGain are set by multiplying as follows.

11.3.2 Gain Control

The AM-200GE can adjust the gain level from -3dB to +24dB using 0dB as the reference (Factory default). In the AB-200GE, the master gain can be adjusted from 0dB to +24dB and R and B gains can be adjusted in the range of -7dB to + 10dB using the master gain as the reference.

The AM-200GE and AB-200GE has the resolution of x0.00012/step using both analog gain (0.00359db/step) and digital gain. In the AB-800CL, blue and red channels can adjust in x0.00012/step by using digital gain. Refer to the following drawing.

Fig.53 Gain control relations

- 71 -

AM-200GE / AB-200GE

34dB

24dB

17dB

10dB

0dB

-3dB

-7dB

672

-84

Gain

Gain Setting Value

Gain Control Range(AM-800CL)

34dB

24dB

17dB

10dB

0dB

-3dB

-7dB

672

Gain

Gain Setting Value

+17713

-4533

+17713

-4533

Gain Setting Value

Master

R&B

Master Red

Blue

Gain Control Range for AB-800CL

Fig. 54 Gain control

The following is the formula for calculating digital gain (magnification) for red or blue. Digital gain = (Gain value + 8192) / 8192

11.3.3 Gain selector

The following parameters can be set.

AM-200GE :

AnalogAll/DigitalAll/Digital Tap2

AB-200GE :

AnalogALL/DigitalAll/DigitalTap2All/DigitalRedAll/DigitalBlueAll/DigitalTap2Red/ DigitalTap2Blue

11.3.4 Gain

Each parameter can be adjusted in the following range.

AM-200GE:

AnalogAll ：0.7079～16 / DigitalAll ：0.7079～1.4125/ Digital Tap2All ：0.8912～1.1220

AB-200GE:

AnalogAll ：1.0～16/ DigitalAll ：0.7079～1.4125/ Digital Tap2All ：0.8912～1.1220/ Digital Red ：0.4466～3.1623/ Digital Blue ：0.4466～3.1623/ Digital Tap2Red ：0.8912～1.1220/ Digital Tap2Blue ：0.8912～1.1220

- 72 -

AM-200GE / AB-200GE

Tap 1

Tap 2

11.3.5 Gain Raw

Each parameter can be adjusted in the following range.

AM-200GE:

AnalogAll ：-84 ～ 672 / DigitalAll ：-2393～+3379/ Digital Tap2All ：-891～+1000

AB-200GE:

AnalogAll ：0 ～ 672/ DigitalAll ：-2393～+3379/ Digital Tap2All ：-891～+1000/ Digital Red ：-4533～17713/ Digital Blue ：-4533～17713/ Digital Tap2Red ：-891～+1000/ Digital Tap2Blue ：-891～+1000

11.3.6 Gain Auto

This function works only in the FrameTrigger OFF and Pre-dump modes. In JAI AGC Reference, the brightness level can be controlled. In Gain Auto, there are three modes. OFF : Gain auto is disabled Once : The gain auto control is done only when it is enabled. Continuous : The gain auto control is always active.

The detailed settings are:

GainAuto speed ：Set the reaction speed of auto gain GainAuto Max ：Set the maximum level of the gain auto control GainAuto Min ：Set the minimum level of the gain auto control Gain Auto Reference ：Set the target level of video.

For instance, set 100% of the video as the reference

video level

ALC Channel area ：Set the portion of the image to be used for gain

auto control

11.4. Tap Balance

The Tap control function adjusts automatically or manually the OFFSET and the gain differences between the left and right taps. The sensor used in the AM-200GE and AB-200GE divides the effective image area into 2 areas as shown in the gain control or black control sections of this manual. The reference tap for all adjustments is Tap ”1”.

11.4.1 Gain Auto Balance

This feature selects the tap balance mode.

- 73 -

AM-200GE / AB-200GE

OFF : Use for the manual setting Once : Use for adjusting once Continuous : Use for adjusting continuously

11.4.2 Automatic Tap Balance

Using Tap “1”(left) as the reference, adjust automatically Tap”2”(right) for black level and gain level. This is effective only when the gain auto balance is set at Continuous.

11.4.3 Manual Tap Balance

Using Tap “1”(left) as the reference, adjust manually Tap “2”(right) for black level

and gain level.

This is effective only when the gain auto balance is set at OFF.

11.4.4 Once Tap Balance

Using Tap “1”(left) as the reference, adjust Tap “2”(right) for black level and gain level once.

This is effective only when the gain auto balance is set at Once.

11.5. Exposure auto (Auto Shutter)

The exposure can be automatically controlled . This function works only in the exposure mode, “Timed”.

In the JAI AGC Reference, the brightness level can be controlled. In Exposure Auto, there are three modes. OFF : Exposure auto is disabled Once : The exposure control is done only when it is enabled. Continuous : The exposure control is always active.

The detailed settings are:

ExposureAuto speed ：Set the reaction speed of exposure control ExpsoureAuto Max ：Set the maximum level of the exposure control ExposureAuto Min ：Set the minimum level of the exposure control Gain Auto reference ：Set the target level of video.

For instance, set 100% of the video as the reference

video level

ALC Channel area ：Set the portion of the image to be used for

exposure control

11.6. Balance Ratio (Only for AB-200GE)

This is the function to set the white balance.

This adjusts both red channel and blue channel to get proper white balance.

The adjusting range is -7dB (0.446 times) to +10dB (3.162 times).

- 74 -

11.6.1 Balance Ratio

B/W

Color

Blemish Compensation Principle

Defective Pixel

The value can be set in the following range: R ch/ B ch : 0.446 times to 3.162 times The formula is R gain/G gain or B gain / G gain. After setting these parameters, the result is applied to Digital RedAll and Digital

BlueAll.

11.6.2 Balance Ratio Auto

Thefollowing modes are available.

Once : One-time auto white balance Continuous : Always tracking

11.7. Blemish compensation

The AM-200GE and AB-200GE have a blemish compensation circuit. This function compensates blemishes on the CCD sensor (typically pixels with extremely high response or extremely low response). This applies to both monochrome and color versions. Pixels that fulfill the blemish criteria can be compensated by adjacent pixels on both columns and, in the case of the AB-200GE, the defective pixels can be compensated by the same Bayer color pixels in the nearest adjacent columns on both sides. The number of pixels that can be compensated is up to 512 pixels . The built-in compensation circuit for the AM-200GE and AB-200GE uses compensation data collected in the factory and can be turned ON or OFF. The default setting is OFF. Users can recalibrate the high response blemishes (White) and store for use. However, the low response (Black) can be used only with the factory default setting.

Note: If defective pixels are found consecutively in the horizontal direction, the blemish compensation circuit does not work.

AM-200GE / AB-200GE

OFF : Manual adjustment

Fig. 55 Blemish compensation

- 75 -

AM-200GE / AB-200GE

512

CCD output

LUT parameter

The required characteristics can be achieved by multiplying LUT parameter and each of 512 points.

11.8. LUT

This function can be used to convert the input to the desired output characteristics.

The Look-Up Table (LUT) has 512 points for setup and each point has a 9-bit gain

value. The output level can be created by multiplying the gain data by the input level.

In the AB-200GE, the same LUT characteristic is applied independent of the color

value.

If input data is not in the LUT, the weighted mean average data from upper point and

the lower point are used. Video output = Video input x LUT value

Fig. 56 LUT concept drawing

In order to use LUT control, set:

JAI LUT mode : LUT

LUT Enable : True

- 76 -

AM-200GE / AB-200GE

By clicking the Processing tab, the following settings screen can be accessed.

This screen includes Look-up table settings and image transformation settings.

11.9 Gamma

This command is used for setting the required gamma characteristics. In order to use Gamma, set; JAI LUT Mode : Gamma

Fig. 57 Look up table values

- 77 -

AM-200GE / AB-200GE

Adjustable range

Less 30%

11.10. Shading Correction

This function compensates for shading caused by the lens or the light source used. There are two methods of correction.

Flat shading correction:

The method to compensate the shading is to measure the highest luminance level in the image and use that data as the reference. Luminance levels of other areas are then adjusted so that the level of the entire area is equal. The block for compensation is 128pixels(H) x 128 pixels(V) and the complementary process is applied to produce the compensation data with less error.

Fig. 58 Gamma compensation

Fig. 59 Flat shading correction concept drawing

- 78 -

AM-200GE / AB-200GE

GｒRGｒ

BGbB

GｒRGｒRGｒ

Gｒ

BGbBGbB

Gｒ

Gb2

Gb1

Gｒ1RGｒ2

Gb3B2Gb4

Gb1B1Gb2

R1GｒR2

Gｒ2

Gｒ1

Gb1BGb2

Color shading correction( For AB-200GE only):

In this case, R channel and B channel are adjusted to match with G channel characteristics. The block for compensation is 128pixels(H) x 128 pixels(V) and the complementary process is applied to produce the compensation data with less error.

Before adjustment After adjustment

Fig.60 Color shading correction concept drawing

11.11. Bayer color interpolation (Only for AB-200GE)

This function is available only for AB-800CL. The AB-800CL uses a CCD with an RGB Bayer pattern. If the Bayer color interpolation is not used, the following RAW data can be output.

Fig. 61 Bayer pattern

The RAW data contains only luminance information for each color and outputs as a monochrome signal. The Bayer color interpolation can complement lacking color information on each pixel and output RGB color data as the result. Color interpolation compensates for the lack of color information by using information from adjacent pixels. The following is the concept drawing for the color interpolation process.

Fig. 62 Color interpolation concept drawing

11.12. Test Image selector

One of the following signals can be output through GigE interface.

- 79 -

AM-200GE / AB-200GE

Gray Vertical Ramp Moving

Gray Horizontal Ramp Moving

Color Bar (AB-200GE only)

Gray Horizontal Ramp Gray Vertical Ramp

Fig. 63 Test pattern

11.13. Temperature sensor

This function reads out the temperature inside the camera. The measuring range : -55 to +125ºC Resolution : 0.0625 ºC

The following table shows examples of values which can be read out by the TMPO command.

The display resolution in the JAI camera control tool is 1 ºC.

- 80 -

AM-200GE / AB-200GE

Note: In this section, the pictures of AMAB-800GE are used.

12. Examples of operation using JAI Control Tool

For more details regarding the JAI control Tool, please refer to the Operation manual provided in the JAI SDK.

12.1. About GenICamTM SFNC1.3

The AM-200GE and AB-200GE are designed as conforming to GenICam SFNC1.3. GenICam SFNC stands for GenICam Standard Feature Naming Convention. By defining the standard cases and the standard features, general-purpose software can control cameras from any manufacturers which conform to the GenICam standard.

JAI, in the past, used traditional feature names in order to maintain naming continuity with previous cameras. However, starting with the AM-200GE AND AB-200GE and after, JAI GigE Vision cameras will now fully comply with GenICam SFNC feature names.

Accordingly, terminologies used for functions may be different from those used with previous models. Refer also to chapter 9. Core functions.

12.2. Examples of camera operation

The following explains the operation of the camera using the GenICam SFNC 1.3 Control Tool.

12.2.1 Operational cautions

1. Features shaded gray in the Features Properties cannot be set.

2. If the image size is to be changed, image capturing should first be stopped before setting the size parameters.

12.2.2 Connecting camera(s)

Connect the camera to the network. If the connection is established, start the JAI Control Tool. The model name of the connected camera and icon will be displayed on the screen.

After clicking the icon, the status will change to indicate the camera is successfully connected to the Control Tool.

Waiting for connection Connected

- 81 -

AM-200GE / AB-200GE

12.2.3 Camera setting layers

GenICam has 3 levels of settings. Those are Beginner, Expert and Guru. The number of available settings increase with each level up to a maximum in the Guru layer.

The following examples of Acquisition control menus illustrate how settings expand from level to level.

Beginner

Expert / Guru

- 82 -

AM-200GE / AB-200GE

Guru /Expert

12.4. Input and output settings

12.4.1. Connection with the external devices

The relation of the line input and output (Digital I/O) and the external terminal in the JAI GigE Vision cameras is fixed. Refer to chapter 6.1. Digital Interface, for the details.

In the Control Tool, they are displayed as Line1-TTL Out 1.

Note: This settings menu is only available in the Expert and Guru setting layers.

- 83 -

AM-200GE / AB-200GE

12.4.2. Setting inputs and outputs

12.4.2.1 Select signal to connect with Line which is selected by Line selector

This function determines which signal is connected with Digital I/O (Line 1 through Line 8). The following figure is an example of setting Line 5 –Opt In 1. In this case, Line Source is the signal to connect with Line 5 -Opt In 1. But Frame Active is available for only output and accordingly, it is not selectable in the Control tool. Line Format is automatically set at Opto Coupled.

The following figure is an example of setting output so that the signal output from Line1 – TTL Out 1is selected from signals in the Line Source. In this case, there is no selection, OFF.

12.4.2.2 Select Trigger Source

Which signal is used as the trigger signal can be configured by the Trigger Source in the Trigger Selector of Acquisition Control. In the following figure, Frame Start is selected as the trigger and the trigger source is configured Line7 – TTL In 1.

- 84 -

AM-200GE / AB-200GE

12.4.3. Specify the image size to be captured

Refer also to the chapter 7.2. AOI (Area of Interest). The following parameters are required to specify the image size. OFFSET X: Specify the starting position of the image in the horizontal

direction Width: Specify the width of the image OFFSET Y: Specify the starting line of the image Height: Specify the height of the image

In order to readout full pixels, OFFSET X = 0

Width = Maximum number of pixels in the horizontal direction

OFFSET Y = 0

Height= Maximum number of pixels in the vertical direction

The above setting includes OB in both horizontal and vertical.

- 85 -

AM-200GE / AB-200GE

12.4.4. Acquisition of the image

The settings related to image acquisition are configured in the Acquisition Control. The following shows the Acquisition Control screen (Guru layer)

After setting the acquisition, click Start Acquisition button.

12.4.4.1 Basic settings

The basic setting items are Acquisition Mode, Trigger Selector, Exposure Mode.

Acquisition Mode

Acquisition Mode can be selected from Continuous, Single Frame and Multi Frame.

Continuous: If the trigger is input, the image is continuously captured.

In order to stop the acquisition, Acquisition End command must be executed.

- 86 -

AM-200GE / AB-200GE

Single Frame: If the trigger is input, only one frame is captured and after the

completion of capturing, the acquisition is automatically stopped.

Multi Frame: If the trigger is input, frames which are set by Acquisition Frame

Count are captured and after the completion of capturing, the acquisition is automatically stopped.

Trigger Selector

Trigger Selector includes Acquisition Start and Acquisition End commands which determine the start point and end point of acquisition, and Trigger commands which set the trigger timing.

Acquisition Start has ON or OFF setting. Refer to chapter 9.1 for the details.

ON: In this case, if Acquisition Start Trigger is applied, the status is waiting the

trigger input. The acquisition starts in the order of Acquisition start Trigger input and Trigger signal input.

OFF: In this case, the camera runs freely. If the trigger signal is input, the

acquisition starts immediately.

Trigger setting

Select from Frame Start, Exposure Start, Exposure End and JAI Acquisition Transfer Start and set the details.

Frame Start: The exposure starts at the point of frame start.

JAI Acquisition Transfer Start : This command makes the delayed readout from the

camera effective.

Exposure Mode setting

Timed : The exposure is effective only for setting duration. Trigger Width : The exposure time is equal to the trigger width.

- 87 -

AM-200GE / AB-200GE

Acquisition Mode

Continuous(Free run)

Acquisition Frame Rate

10.2 fps

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

OFF or Timed

Exposure Time

Any value

If Exposure Mode is Timed

Acquisition Mode

Continuous (Free run)

Acquisition Frame Rate

5fps

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

OFF or Timed

Exposure Time

Any value

If Exposure Mode is Timed

Acquisition Mode

Single Frame

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : ON

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Timed

Exposure Time

Any value

12.4.5. Setting examples

12.4.5.1 Capture the image continuously with fastest frame rate

12.4.5.2 Capture the image with half of the frame rate (increasing the sensitivity)

12.4.5.3 Capture one frame with preset exposure time using the external trigger

Frame Start settings

- 88 -

AM-200GE / AB-200GE

Trigger Source

Choose from the above selection

Trigger Activation

Rising Edge, Falling Edge

Trigger Overlap

Off or Read Out Trigger Delay

Any value, Normally set to 0

Acquisition Mode

Multi Frame

Acquisition Frame Count

Any value which can be set

Acquisition Mode

Single Frame

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : ON

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Trigger Width

Trigger Source

Choose from the above selection

Trigger Activation

Rising Edge(Level High) or Falling edge (Level Low)

Trigger Overlap

Off or Read Out

Trigger Delay

Any value、 Normally set to 0

12.4.5.4 Capture multi frames of the image with preset exposure time using the external trigger

In the 12.4.5.3 example, the following setting should be changed.

When PIV operation is selected, this should be set even number.

12.4.5.5 Capture one frame image with the trigger width using the external trigger

Frame Start setting

- 89 -

AM-200GE / AB-200GE

Acquisition Mode

Multi Frame

Acquisition Frame Count

Any value which can be set

Acquisition Mode

Continuous

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition End

Trigger mode : OFF

Frame Start

Trigger mode : ON

Exposure Start

Trigger mode : OFF

Exposure Stop

Trigger Mode: OFF

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

Timed

Exposure Time

Any value

Trigger Source

Choose from the above selection

Trigger Activation

Rising Edge, Falling Edge

Trigger Overlap

Off or Read Out

Trigger Delay

Any value, Normally set to 0

Acquisition Mode

Continuous

Trigger selector

Acquisition Start

Trigger mode : OFF

Acquisition Stop

Trigger mode : OFF

Frame Start

Trigger mode : ON

JAI Acquisition Transfer Start

Trigger Mode: OFF

Exposure Mode

OFF or Timed

Exposure Time

Any value

If Exposure Mode=Timed

12.4.5.6 Capture multi frames of the image with the trigger width using the external

trigger

In the example 12.4.5.5, the following setting should be changed.

12.4.5.7 Capture the image continuously with preset exposure time by using the external trigger

Frame Start setting

12.4.5.8 Capture the image using Software Trigger

- 90 -

Frame Start setting

AM-200GE / AB-200GE

Select “Software” in the Trigger Source and execute Trigger Software command. Software trigger is generated inside the camera and the settings are not changed. Therefore, it is useful if the customer tests the trigger function.

In order to use the software trigger, use “User Output”.

Select User Output, and select the same user output in the Trigger Source.

12.4.5.9 Sequence Trigger setting

First of all, it is necessary to set acquisition mode described before.

Set Video Send mode selector in the JAI Custom Control to Sequence mode.

Then, set each image by Sequence ROI Index in the JAI Custom Control.

- 91 -

AM-200GE / AB-200GE

The following example is for Index0 and one frame is captured.

Then, in the Sequence ROI Next Index, the next image is set. Other images are set in the same manner. Next index can also set the order of capturing the images. In order to stop the sequence, the next index of the last index should be set “OFF”.

12.4.5.10 Multi ROI setting

First of all, it is necessary to set acquisition mode described before.

Set “Video Send Mode Selector” in the JAI Custom Control to “Multi Mode”.

- 92 -

AM-200GE / AB-200GE

Set the image selected by ROI Index. The following example is Index 0.

Then, the next image is set by Multi ROI Next Index. The following example is for Index 1.

After that, set the image of Index 1 by Multi ROI Index.

While repeating the above procedure, set the necessary ROI. Maximum of 5 images

can be set. On the last image setting, set “Multi ROI Next Index” to “OFF”.

12.4.5.11 Delayed readout setting

If a system using multiple cameras is configured, it can use delayed readout in order to improve the traffic in the PC port. Refer to the chapter 8.4.3 The data transfer for multiple cameras.

Setting: Trigger selector: JAI Acquisition Transfer Start Trigger mode: ON

This should be applied to all connected cameras.

12.4.5.12 Operate the external strobe light

“Exposure Active” can be used as the strobe driven signal.

Then set “LINE” for signal output.

The following example selects Line 1- TTL Out 1 as the output terminal.

- 93 -

AM-200GE / AB-200GE

12.4.6 How to view the XML file

All features and registers are stored in the camera as an XML file. The XML file is stored in the following folder.

Program ⇒ JAI ⇒ SDK ⇒ XML ⇒ Transportlayers ⇒ JAI

- 94 -

AM-200GE / AB-200GE

12.4.7 Feature Tree Information

12.4.8 Feature Properties (Guru)

a) Device Control

- 95 -

b) Image Format Control

AM-200GE / AB-200GE

c) Acquisition Control & d) Digital IO Control

- 96 -

e) Counter And Timer Control

AM-200GE / AB-200GE

f) Event Control

- 97 -

IAI AM-200GE, AB-200GE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

JAI GigE® Vision Camera operation manuals

Introduction

Before using GigE Vision camera

Software installation

Camera Operation

1. General

2. Camera nomenclature

3. Main Features

4. Locations and Functions

4.1. Locations and functions

4.2. Rear panel indicator

5. Pin Assignment

5.1. 12-pin Multi-connector (DC-IN/Digital IO)

5.2. Digital Output Connector for Gigabit Ethernet

5.3. D-Sub 9pin connector (For GPIO)

5.4. DIP switch

5.4.1 SW-900

5.4.2 SW-500

5.4.3 SW-901

6. Input and output Interface

6.1. Digital Interface

6.1.1 LineSelector

6.1.2 LineInverter

6.1.3 LineStatus

6.1.4 LineSource

6.1.5 LineMode

6.1.6 LineFormat

6.2. Opto-isolated Interface

6.2.1 Recommended External Input circuit diagram for customer

6.2.2 Recommended External Output circuit diagram for customer

6.2.3 Optical Interface Specifications

6.3. Iris video output

6.4. Trigger input

6.5. Exposure Active output

7. Video signal output

7.1. Video output image

7.2. AOI (Area of Interest)

7.2.1 AOI parameters

7.2.2 AOI setting details

7.2.2.1 When only the image part is transmitted (OB is not transferred)

7.2.2.2 When the full image plus the vertical OB is transmitted

7.2.2.3 When the full image plus the horizontal OB is transmitted

7.2.3 Frame rate calculation in the AOI mode

7.2.3.1 Binning control setting : off or 2x1 (Binning Vertical=1)

7.2.3.2 Binning control setting : 1x2 or 2x2 (Binning Vertical=2)

7.2.4 The relationship between LinePitch and Width

7.3. In case of vertical binning and horizontal binning (Only for AM-200GE)

7.3.1 The relationship between Binning Horizontal and Width/LinePitch

7.3.2 The relationship between Binning Vertical and Height

7.4. Digital video output (Bit allocation)

7.5. Bayer output pattern

7.6. Pixel format and pixel type

7.6.1 GVSP_PIX_MONO8 (8bit output)

7.6.2 GVSP_PIX_MONO10 (10bit output)

7.6.3 GVSP_PIX_MONO10_Packed (10bit output)

7.6.4 GVSP_PIX_MONO12 (12bit ourput)

7.6.5 GCSP_PIX_MONO12_Packed (12bit output)

7.6.6 GCSP_PIX_BAYERGR8 (8bit output)

7.6.7 GVSP_PIX_BAYERGR10 (10bit output)

7.6.8 GVSP_PIX_BAYERGR10_Packed

7.6.9 GVSP_PIX_BAYERGR12 (12bit output)

7.6.10 GVSP_PIX_BAYERGR12_Packed

7.6.11 GVSP_PIX_RGB8_PACKED (24bit) (Interpolation)

7.6.12 GVSP_PIX_ YUV422_PACKED (16bit)

7.6.13 The relationship between PixelFormat and PixelSize.

7.7 YUV output

7.8. Video output timing

7.8.1 Vertical timing (8bit, 10 bit or 12bit for Bit allocation)

7.8.1.1 If the binning control is OFF or 2x1, AOI default setting

7.8.1.2 If the binning control is OFF or 2x1, AOI setting

7.8.1.3 If the binning control is 1x2 or 2x2, AOI default setting

7.8.1.4 If the binning control is 1x2 or 2x2, AOI setting

7.8.2 Horizontal timing

7.8.2.1 If the binning control is OFF or 2x1

7.8.2.2 If the binning control is 1x2 or 2x2

6.4.3 DVAL output if the Binning control is set to 2=2x1 or 3=2x2
