i3 International Ax50D Specifications

[Application & Benefits]

Ax50D All-purpose Indoor Dome Camera

[Features]

Full HD day/night indoor vandal-bubble, network camera
Superb image quality with 2MP/ 1080P
1/3'' 2MP sensor
H.264/MJPEG/MPEG4 triple streaming
Mechanical Infrared Cut Filter with Digital Day/night functionality
3~9mm F1.2 megapixel lens
Vandal resistant dome camera
3 year limited warranty

AX50D is an all-purpose indoor dome camera that does not require mounting adapters for
various environments, reducing installation time. Rich with practical enhancements such as
D-WDR and Day & Night mode, the Ax50D is ideal for most installation applications

With multiple video streams  H.264, MPEG4, and Motion JPEG  users can select the best
option for their needs. H.264 compression, for example, greatly reduces bandwidth and
storage requirements without compromising image quality.

This camera is ideal for situations where maximum image quality is vital, such as being able to
identify people or specific objects. Unlike traditional megapixel cameras, Ax49 offers clear and
detailed HD quality images in all conditions as well as better frame rate as per the international
industry standard. Individuals and objects of interest come through with perfect clarity.

The AX50D offers digital pan/tilt/zoom with multi-view streaming. The versatility of this
network camera makes it suitable for a range of video surveillance applications, including
industrial buildings, retail environments, government installations, airports, railway stations and
schools.

i3 cameras have been tested by experts, who understand the rigorous conditions of your
business. We wouldnt have it any other way because at i3 we believe that partnering with
the right people gives our company the technological advantage that helps develop business
relationships built on trust. At i3 we work hard at securing your business.

International Standards
Organization RegisteredFirm;
ISO 9001QualitySystem

©2011 i³International.Thei³logo is property of i³International Inc. All rights reserved. Specifications, configurations, components and options listed are subject to change without notice. This data sheet may not be reproduced without permission.

www.i3international.com

1.866.840.0004

U.S.A. 440 Lawrence Bell Drive,
Suite 16, Williamsville.

----- -----

Canada 780 Birchmount Road

NY, 14221

Unit 16, Scarborough

ON, M1K 5H4

Ax50D All-purpose Indoor Dome Camera Specifications

Featuers

Image sensor 1/3" 2 MP image sensor optimized for low-light performance
Effective pixels Effective 16:9 1920 (H) X 1080 (V)
Image compression method Triple Streaming : H.264 / MPEG4 / Motion JPEG
Video codec/resolution H.264: HDTV(16:9):1920X1080(2M) /1280X720 OR SDTV(4:3): 1280x960(SXVGA), MPEG4:

HDTV(16:9):1920X1080(2M)/1280X720 OR SDTV(4:3): 1280x960(SXVGA), MJPEG: HDTV(16:9):1920X1080(2M)/1280X720

OR SDTV(4:3): 1280x960(SXVGA)

Frame rate Frame rate up to 15fps(NTSC) and 12.5fps(PAL) at 1920x1080; up to 30fps(NTSC) and 25fps(PAL) at 1280x720
Lens Built-in Mechanical ICR Filter varifocal lens f=3~9mm, F1.2 (Mega pixel lens
Sync system Internal
AES 1/10000 s to 1/3.75s (selectable)
Minimum illumination 0.06 Lux @10IRE; 0.24Lux @50IRE
Exposure mode Auto/Manual
White balance 5 x 5 zones selectable
Sharpness, saturation, brightness and contrast 255 level sensitivity
Motion detection Yes; 5 x 5 Motion detection zones & 5 level sensitivity or customized threshold
ATR/D-WDR D-WDR (Digital): 5 level sensitivity
Privacy zone Customized thresholdprivacy zone
Intelligent video Audio detection / Blur detection / Smart Codec/ Smart Focus/ e-PTZ, Mirror, Flip, System log, Snapshot, CBR/VB

Electric

Video port BNC X1, 1.0Vp-p, 75O / RCA x 1"

Power Supply

Power requirement POE(IEEE 802.3af)
Power consumption Max. 5W

Network

Ethernet 10Base-T/100Base-TX Ethernet connection for LAN / WAN
Internet protocol TCP/IP, UDP, HTTP, HTTPs, SMTP, DNS, DHCP, NTP, FTP, RTP,RTSP, ICMP, uPNP
IP IPv4
Remote Connection Connector:RJ-45, RemoteConnection: SRX-Pro Remote AgentOR IE browser 6.0or above

Environment

Operating temperature -10ºC ~ 50ºC (14ºF ~ 122 ºF)
Operating humidity 10~ 90% RH
Storage temperature -20ºC ~ 60ºC (-4ºF ~ 140 ºF)
Dimensions (øxH) F138mm x 101mm
Weight 1.13kg

Warranty

Standard Warranty 3 years parts and labour
