Ax49D All-purpose Indoor Dome Camera
i³ Part# Ax49D
[Features]
Full HDday/nightindoorvandal-bubble, network camera
Superb image quality with 1.3MP/ 960P
1/3'' 2MP sensor
H.264/MJPEG/MPEG4 triple streaming
Mechanical Infrared Cut Filter with Digital Day/night functionality
3~9mm F1.2 megapixel lens
Vandal resistant dome camera
3 year limited warranty
[Application & Benefits]
Ax49D is an all-purpose indoor dome camera that does not require mounting adapters for
various environments, reducing installation time. Rich with practical enhancements such as
D-WDR and Day & Night mode, the Ax49D is ideal for most installation applications.
With multiple video streams H.264, MPEG4, and Motion JPEG users can select the best
option for their needs. H.264 compression, for example, greatly reduces bandwidth and
storage requirements without compromising image quality.
This camera is ideal for situations where maximum image quality is vital, such as being able to
identify people or specific objects. Unlike traditional megapixel cameras, Ax49 offers clear and
detailed HD quality images in all conditions as well as better frame rate as per the international
industry standard. Individuals and objects of interest come through with perfect clarity.
The Ax49D offers digital pan/tilt/zoom with multi-view streaming. The versatility of this
network camera makes it suitable for a range of video surveillance applications, including
industrial buildings, retail environments, government installations, airports, railway stations and
schools.
i3 cameras have been tested by experts, who understand the rigorous conditions of your
business. We wouldnt have it any other way because at i3 we believe that partnering with
the right people gives our company the technological advantage that helps develop business
relationships built on trust. At i3 we work hard at securing your business.
International Standards
Organization Registered Firm;
ISO 9001 Quality System
©2011 i³International. The i³ logo is property of i³International Inc. All rights reserved. Specifications, configurations, components and options listed are subject to change without notice. This data sheet may not be reproduced without permission.
www.i3international.com
1.866.840.0004
U.S.A. 440 Lawrence Bell Drive,
Suite 16, Williamsville.
----- -----
Canada 780 Birchmount Road
NY, 14221
Unit 16, Scarborough
ON, M1K 5H4
Page 2
Ax49D All-purpose Indoor Dome Camera Specifications
Featuers
Image sensor 1/3" 1.3 MP image sensor optimized for low-light performance
Effective pixels 16:9 1280 (H) X 1024 (V)
Image compression method Triple Streaming: H.264 / MPEG4 / Motion JPEG
Video codec/resolution H.264: HDTV(16:9)
SDTV(4:3): 1280x960(SXVGA), MPEG4: HDTV(16:9)
SDTV(4:3): 1280x960(SXVGA), MJPEG: HDTV(16:9)
SDTV(4:3): 1280x960(SXVGA)
Frame rate 1280x960: up to 15 fps (NTSC) / 12.5 fps (PAL)
1280x720: up to 30 fps (NTSC) / 25 fps (PAL)
Lens Built-in Mechanical ICR Filter varifocal lens f=3~9mm, F1.2 (Mega pixel lens)
AES 1/10000 s to 1/3.75s (selectable)
Minimum illumination 0.06 Lux @10IRE; 0.24Lux @50IRE
Exposure mode Auto/Manual
White balance 5 x 5 zones selectable
Sharpness, saturation, brightness and contrast 255 level sensitivity
Motion detection Yes; 5 x 5 Motion detection zones & 5 level sensitivity or customized threshold
ATR/D-WDR Digital: 5 level sensitivity
Privacy zone Customizedthreshold privacy zone
Intelligent video Audio detection / Blur detection / Smart Codec/ Smart Focus/ e-PTZ, Mirror, Flip, System log, Snapshot, CBR/VB
Electric
Video port BNC X1, 1.0Vp-p, 75O / RCA x 1"
Power Supply
Power requirement POE(IEEE 802.3af)
Power consumption Max. 5W
Network
Ethernet 10Base-T/100Base-TX Ethernet connection for LAN / WAN
Internet protocol TCP/IP, UDP, HTTP, HTTPs, SMTP, DNS, DHCP, NTP, FTP, RTP,RTSP, ICMP, uPNP
IP IPv4
Remote Connection Connector:RJ-45, Remote Connection: SRX-Pro Remote Agent OR IE browser 6.0 or above
Environment
Operating temperature -10ºC ~ 50ºC (14ºF ~ 122 ºF)
Operating humidity 10 ~ 90% RH
Dimensions (øxH) F138mm x 101mm
Weight 1.13kg
Warranty
Standard Warranty 3 years parts and labour
