EXPRESS JUICER
OWNER’S MANUAL
Model HI-410E
Thank you for purchasing Hyvox Express
Juicer, from Hyvox Ingenious Home Collection
of products. Please read your owner’s manual
carefully as it provides important information
regarding safety, operation and maintenance.
Please kindly retain this manual and model
number for future reference.
®
Ingenious Home Collection
Changing life concepts!
Thank you.
We appreciate your business. Thank you for
purchasing Hyvox Express Juicer from the
Hyvox Ingenious Home Collection of products.
We hope you enjoy a new life concept of juicing.
Changing Life Concepts!
CONTENTS
Important safety measures......................... 05
Express Juicer............................................. 07
Anatomy of the juicer.................................. 08
Assembling instructions............................. 09
Operating instructions................................ 11
Operating steps.......................................... 12
Juicing instructions.................................... 13
Diassembling instructions.......................... 14
Care and Cleaning...................................... 16
Troubleshooting...........................................17
Fruits and vegetables facts........................ 18
Warranty information.................................. 20
HYVOX Express Juicer User Manual
IMPORTANT SAFETY MEASURES
To reduce the risk of fire, electric shock, or injury, basic precautions
mentioned below should be followed.
Please read all instructions, guides and hints mentioned
in this manual before use. We advice you to save this
document in safe place for future reference.
Unpack and remove all packing materials from the box.
When the appliance is used for the rst time, it is normal
for the motor to give off a small amount of smoke and
odor.
Do not let the appliance run without food or overload use.
The appliance is with superheat protection system. When
the motor runs long-term or overload, the appliance would
automatically stop, but it can run after about 1 minute
again.
Do not touch the small cutting blades in the base of the
stainless steel lter basket.
Do not use harsh abrasives, caustic cleaner or oven cleaner
when cleaning this appliance.
Always make sure the appliance is properly and completely
assembled before operating.
Careful supervision is necessary when any appliance is
used by or near children. Do not let the children use the
appliance.
Place the power juicer on a dry level place. Do not place
on or near a hot gas or electric burner or in a heated oven.
Please handle the appliance carefully. If the unit is dropped
or bumped, it may cause the unit to malfunction.
To protect against electric shock, do not immerse cord,
plug or motor base in water or other liquid.
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
11.
12.
05.
HYVOX Express Juicer User Manual
Do not operate any appliance with a damaged cord
or plug or after the appliance malfunction or has been
damaged in any manner. Return the appliance to our
service center for examination.
If your AC wall outlet becomes loose, it may get
overheated. Should this happen, consult a qualied
technician.
Always use the food pusher provided in this package to
push source into the food chute. Never use hands.
Do not leave your Hyvox Express Juicer unattended when
in use. Close supervision is necessary especially when used
near children.
Do not allow children to use Express Juicer at any
circumstances.
Always operate only when assembled completely. The
Express Juicer will not operate if not assembled properly.
Always operate on a dry surface. Operating this unit in a
wet place may damage and void your warranty.
Always turn the switch to ‘0’ position. Leave the appliance
unplugged when not in use or assembling and also after
using.
Always remove the power cord from socket if Express
Juicer is not in use, is left unattended or before cleaning.
13.
14.
15.
16.
17.
18.
19.
20.
06.
HYVOX Express Juicer User Manual
EXPRESS JUICER HI-410E
Hyvox brings you another Ingenious Home Collection that will brighten
your day with easy juicing life.
A powerful and time saving fresh juicing machine. it will change
the way you juice as you no longer need to cut the fruits and
vegetables into pieces . No more adding water or other additives.
Insert the whole apple, carrot and other similar fruits and
vegetables as it is and Express Juicer will serve you the 100% pure
healthy fresh juice in a few seconds. Perfect for daily juicing.
ADVANTAGEOUS FEATURES
Prepares juice in a few seconds much faster than average
juicers in the market.
Drink fresh and healthy juice, the most economical way.
It’s easy to clean. It is also easy to disassembble blade, lter
net, container parts and main body to clean.
Its safe and reliable. This product comes with safety
protection system inside. When the latch or handle doesn’t
raise up to proper position, it can’t work.
Includes 5L pulp container.
RPM: 18,000 - 23,000 RPM
Power: 220-240V / 450-500W
01.
02.
03.
04.
05.
06.
07.
07.
HYVOX Express Juicer User Manual
ANATOMY OF HYVOX EXPRESS JUICER
Here we explain to you the various parts of the Express Juicer.
1 2 3
4 5 6
7 8 9
Food pusher Feed tube Safety lock
Juicer tray base Spout Main body
Power switch Cover Pulp container
1
2
3
4
5
6
7
8
9
08.
HYVOX Express Juicer User Manual
Place juicer tray
base on top of main
body.
ASSEMBLING INSTRUCTIONS
Place the juicer cover
over the lter base.
Place stainless steel
lter basket on top
of base, slightly press
down. Be aware of the
small cutting blades
at the base of lter
basket.
Step 1
Step 3
Step 2
09.
HYVOX Express Juicer User Manual
Raise the safety
locking handle up
into the vertical
position. Locate the
locking handle into
the two grooveon
both sides of the
juicer cover.
Slide the food pusher
down the feed tube by
aligning the groove in
the food pusher with the
small protrusion on the
inside of the top of the
feed tube. Place a jug or
glass under the spout on
the right hand side of
the juice extractor.
Place the pulp
container into position
by tilting the pulp
container slightly.
Step 4
Step 6
Step 5
You are now ready to begin juicing!
10.
HYVOX Express Juicer User Manual
OPERATING INSTRUCTIONS
Please follow the instructions below carefully. They contain important
juicing instructions and guidelines.
Always make sure the appliance is properly and completely
assembled before operating.
Wash the fruit or vegetables before juicing. Most fruit and
vegetables such as apples, carrots and cucumbers will not
need to be cut to size as these will t into the feed tube.
Make sure to place a glass or container under the spout
while juicing. The pulp container should be put under the
pulp spout.
Plug the power cord into a suitable power outlet and turn
the power to ‘1’ position.
With the motor running, place food down the feed tube.
Using the food pusher, gently guide food down the feed tube.
To extract the maximum mount of juice, always push the
food pusher down slowly.
Never use hands or foreign objects to push food down the
feed tube or to clear the feed tube. Always use the food
pusher provided.
Juice will ow into the glass or container and the separated
pulp will accumulate in the pulp container. Do not allow the
pulp container to overll as this may damage the unit.
Please switch off the appliance when emptying the pulp
container.
After juicing, the power should be removed from socket.
Running the unit without food may cause damage.
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
11.
HYVOX Express Juicer User Manual
OPERATING STEPS
Please follow the steps below carefully to avoid any malfunction or
damage. Express Juicer will last long if taken care of properly.
Step 1
Wash the fruits and vegetables ready for juicing. Cucumbers,
carrots, apples, tomatoes and other similar foods do not need
to be cut into pieces as they will t in the food chute. Decide
the order of juicing and lay them out. Peel off fruits like
oranges. Refer to Juicing Instructions.
Step 2
Conrm the Hyvox Juicer Express is assembled correctly. Refer
to Page x, Assembling instructions. Also conrm that the pulp
container has been installed and a juice jug has been placed
under the spout. You may use the jug provided in the box or of
your own choice.
Step 3
To make cleaning easy, place a plastic bag in the pulp
container to collect the pulp.
Step 4
Plug the power cord onto your power socket and turn the
power switch on your Hyvox Juicer Express to ‘|’ position.
Step 5
While the motor is running, place down the food gently onto
the food chute and use food pusher to gently guide the food
down the chute. Pressing the food pusher softly and gently will
extract the maximum juice.
Step 6
Juice will ow into the jug and the separated pulp will
accumulate in the pulp container. Do not let the pulp container
over ll. Empty the pulp container when it has accumulated
three fourth.
12.
HYVOX Express Juicer User Manual
JUICING INSTRUCTIONS
Please follow the instructions below carefully. They contain important
juicing instructions and guideslines.
Peel off the fruit or vegetables, such as orange, lemon,
pineapple, kiwi, mango, pumpkin and other similar fruits
and vegetables.
Fruit with small pits and seeds, such as lemon, orange,
watermelon, grape, can be put into food tube for juicing.
Fruit with big pits and seeds, such as nectarines, peaches,
apricots, plums and cherries must be pitted before juicing.
Fruits or vegetables with caudex or leaf are suitable into
the food tube. Bundle the leaves of the fruit or vegetable
before putting into the food tube.
Soft food, such as banana, g not suitable for juicing. The
pulp would block the appliance and damage motor.
Fresh juice will lose its nutrition if stored out for too long.
Drink soon.
Mix green vegetable juice, such as spinage, celery, with
soft, sweet fruit juice, such as apple, carrot, to get sweeter
juice.
When juicing variety of fruits and vegetables, it is
recommended to alternate between soft and hard
ingredients. For example, when juicing hard vegetable like
carrot, then juice softer ones such as tomatoes.
For maximum extraction of juice always push the Food
Pusher down slowly.
If you wish to include herbs, sprouts and other similar
smaller leafs, wrap them in large spinach leaf or lettuce for
better extraction of juice.
Please be advised that the pulp also contains some
important nutrients for the daily diet and can be used in
sevaral ways.
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
13.
HYVOX Express Juicer User Manual
Turn the Express
Juicer off and
remove the pulp
container.
DISASSEMBLING INSTRUCTIONS
Remove the cover by
lifting upwards.
Using two hands on
either sides of the
locking handle, lift
upwards slightly and
pull back.
Step 1
Step 3
Step 2
14.
HYVOX Express Juicer User Manual
Hold on the side,
pull upwards
slightly. Do not use
force. Pull gently
and rmly.
Now lift gently the
stainless stell lter
bowl.
Caution: Please be
cautious of the sharp
blades. Remove the
lter over the sink or
bin.
Step 4
Step 5
You have now disambbled the Express Juicer. Clean the
Express Juicer as soon as you have nished juicing. It is quite
normal to nd the pulp with certain amount of liquid. Do not
immerse the motor (main body) and power cord in water or
wet place. When cleaning the lter bowl, avoid touching the
sharp blades. Use force water to clean between the blades.
15.
HYVOX Express Juicer User Manual
CARE AND CLEANING
Do not try to repair it. Take it to our service center if servicing is
needed. There are no user serviceable parts.
Turn the power switch to ‘0’ position and unplug the
appliance before cleaning.
Disassemble the appliance. Lift off the juicer tray base
with the stainless steel lter basket inside, then, turn the
juicer tray base upside down and carefully remove the lter
basket.
Except the motor base, all detachable parts can be
immersed in water or any other liquid.
Wash with warm soapy water and a sponge or cloth. Do
not use harsh abrasives or caustic cleaners. Rinse with
water thoroughly & wipe dry with cloth.
For the stainless steel lter basket, wash under running
water & brush from the inside of the basket out with the
nylon cleaning brush provided. Always handle the lter
basket with care as it can be easily damaged.
Discolouration of the plastic may occur with strongly
coloured fruits and vegetables.
To help prevent this, wash the stained parts immediately
after use.
Wipe the motor base with a damp sponge or paper towel.
All parts of the appliance are not dish-washer safe.
Make sure all the parts are dry enough before storing in
clean and dry place.
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
16.
HYVOX Express Juicer User Manual
TROUBLESHOOTING
Before contacting customer services or retail, please read the
troubleshooting for self-solving.
Problem Solution
Motor stalls while
juicing.
This happens when wet pulp builds under the cover.
Progress either by cleaning or by slowing down the
juicing action by pushing the food pusher down slowly.
Express Juicer wont
turn power on.
Express Juicer is build sith safety protection system.
If the safety locking handle is not properly assembled
and locked, the machine won’t turn on. Please refer to
assembling instructions.
Pulp is too wet or
insufcient juice
extraction.
It is quite normal to have wet pulp. But if the juice
extraction is insufcient, try a slower juicing action.
Push the food pusher into the feed tube slowly and
gently.
Juice leaks between the
rim of stainless steel
lter bowl and cover.
It is possible that they have not been assembled
properly. Refer to assembling instructions and lock
rmly. This can also happen due to violent juicing
action.Try slower acion.
Motor stopped in
between juicing.
Hyvox Express Juicer has a heat protective system.
When juiced for long time continuously, the motor will
stop automatically. Turn the power off and pull the
power cord. Wait for couple of minutes and try.
17.
HYVOX Express Juicer User Manual
FRUIT AND VEGETABLE FACTS
Fruits /
Vegetables
Best season
to buy
Nutritional
value
Grams = Kilojoul
[Calories]
Apples Autumn /
Winter
High in dietary ber
and vitamin C
200g = 300kj
[72 cals]
Apricots Summer High in dietary ber
and potassium
30g = 85kj
[20 cals]
Beet Winter Dietary ber, folate,
Vitamin C, potassium
160g = 190kj
[45 cals]
Blueberries Summer Vitamin C 125g = 295kj
[70 cals]
Broccoli Autumn /
Winter
Dietary Fiber, Folate,
Vitamin B2, B5, B6,
C, E
100g = 195kj
[23 cals]
Brussels
Sprouts
Autumn /
Winter
Dietary Fiber, Folate,
VitaminB2, B6, C, E
100g = 110kj
[26 cals]
Cabbage Winter Dietary Fiber, Folate,
Potassium, Vitamin
B6, C
100g = 110kj
[26 cals]
Carrots Winter Dietary Fiber, Vita-
min A, C, B6
120g = 125kj
[30 cals]
Cauliower Autumn /
Winter
Vitamins C, B5, B6,
K, Folate, Potassium
100g = 55kj
[13 cals]
Celery Autumn /
Winter
Vitamin C, Potassium 80g = 55kj
[7 cals]
Cucumber Summer Vitamin C 280g = 120kj
[29 cals]
18.
HYVOX Express Juicer User Manual
Fennel Winter /
Spring
Dietary Fiber,
Vitamin C
300g = 145kj
[35 cals]
Grapes Summer Vitamin B6, C,
Potassium
125g = 355kj
[35 cals]
Kiwi Winter /
Spring
Vitamin C, Potassium 100g = 100kj
[40 cals]
Mangoes Summer Vitamin A, B1, B6,
C, Potassium
240g = 200kj
[102 cals]
Melons Summer /
Autumn
Dietary Fiber, Folate,
Vitamin A, C
200g = 210kj
[50 cals]
Nectarines Summer Dietary Fiber, Potas-
sium, Vitamin B3, C
180g = 355kj
[85 cals]
Oranges Winter /
Autumn /
Spring
Vitamin C 150g = 160kj
Peaches Summer Dietary Fiber, Potas-
sium, Vitamin B3, C
150g = 205kj
[49 cals]
Pears Autumn Dietary Fibre 150g = 250kj
[60 cals]
Pineapples Summer Vitamin C 150g = 245kj
[59 cals]
Plums Summer Dietary Fiber 70g = 110kj
[26 cals]
Raspberries Summer Vitamin C, Iron, Po-
tassium, Magnesium
125g = 130kj
[31 cals]
Tomatoes Summer Dietary Fiber, Folate
Vitamin A, C, E
100g = 90kj
[22 cals]
19.
HYVOX Express Juicer User Manual
What Is Not Covered
This warranty does not cover any damage caused due to physical abuse
of the product by misuse or use other than as intended and described in
the instruction manual, or damage caused by failure to properly clean and
maintain this product or damages caused by natural disaster or acts of war.
The warranty is voided if connected to any voltage or specications other
than prescribed on the product. Also, if the unit is opened for self repair, the
warranty will be void for any further repair or problem analysis. The warranty
may not be used if the product is served in public places such as lodging house,
training centres etc. Warranty does not cover any shipping and handling
charges. Hyvox Inc. deserves the right to refuse any warranty claim without
any valid reasons.
What Will We Do
Should you detect any malfunction, please return the damaged product along
with the purchase receipt with a brief explanation of the problem, either
directly to a distributor of Hyvox products near you or to the shop you had
purchased from. We will repair any defects in materials or workmanship
within one year of purchase. If the defective is found un-repairable within
the warranty period, Hyvox with its discretion will replace it for a new unit.
However, Hyvox reserves complete rights in decision making in regards to
processing the warranty, rejecting any claim without any valid reason or
arranging a replacement.
If you have questions, please feel free to contact our customer service e-mail
or our local distributors near you. Please visit www.hyvox.com to nd a local
distributor near you.
WARRANTY INFORMATION
This warranty covers only manufacturer defectives for one year, with
the exceptions stated below.
20.
Send us your valuable suggestions and feedback.
Login to www.hyvox.com.
You can also nd a copy of this document for download and other
supportive materials on our website. Thank you once again for
purchasing Hyvox Express Juicer, your Ingenious Home Collection.
www.hyvox.com
Find more Hyvox Ingenious Home Collection products at
Changing life concepts!
Hyvox Inc.
Mississauga, Ontario
Canada
info@hyvox.com
www.hyvox.com
®
‘Hyvox’ brand name and logo, ‘Ingenious Home Collection’ and ‘Changing
life concepts!’ are registered trademarks of Hyvox Inc., Ontario, Canada.
Copyright © Hyvox Inc. 2005. E&OE.
Ingenious Home Collection
Changing life concepts!
Loading...
