HYUNDAI MOBIS ADB10G8GG, ADC10G8GG User Manual

2VEUG07

(미국/영어-English)

CAR MULTIMEDIA SYSTEM

미국/영어-English

USER'S MANUAL

Thank you for purchasing this multimedia system.

This user's manual explains how to use the HYUNDAI Motor multimedia system.

Before using the product, read the contents of this user's manual carefully and use this product safely.

•

The screens shown in this manual may differ with the actual screens of the product.

•

The design and specification of this product may change without prior notification for product improvement.

•

When transferring the vehicle to another individual, include this user's manual so that the next driver can continue its use.

All Map Database cannot be copied without permission. Important Notice : This is protected by U.S. copyright laws. All rights not expressly granted are reserved. You may not otherwise reproduce, modify and distribute the content without HYUNDAI MnSoft, Inc’s prior written consent.

Precaution for safe usage

•

Driving while distracted can result in a loss of vehicle control, that may lead to an accident, severe personal injury, and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle.

•

Do not operate the while driving.

•

Do not disassemble, assemble, or modify the

multimedia system

•

Do not watch the screen for prolonged periods of time while driving.

•

Set the volume to a level which allows the driver to be aware of external conditions.

multimedia system

•

Do not operate the

multimedia system

prolonged periods of time with the vehicle ignition in ACC. Such operations may lead to battery discharge.

•

Be cautious not to spill water or introduce foreign objects into the device.

•

Do not cause severe shock to the device. Direct pressure onto the front side of the monitor may cause damage to the LCD or touch panel.

•

In case of product malfunction, please contact your place of purchase or service center.

•

When cleaning the touch screen, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents (alcohol, ammonia, benzene, thinners, etc.) as such materials may damage the device panel or cause color and quality deterioration.

for

•

SiriusXM service requires a subscription, sold separately, after 3-month trial included with vehicle purchase. If you decide to continue your SiriusXM service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call Sirius XM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm. com. Programming subject to change. Sirius satellite service is available only to those at least 18 and older in the 48 contiguous USA, D.C., and PR (with coverage limitations). Traffic information not available in all markets. See siriusxm.com/traffic for details. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.

WARNING

• Driving while distracted can result in a

loss of vehicle control that may lead to an accident, severe personal injury, and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle.

Read the following safety cautions for your safety

Notations used within this User's Manual

Before using the product, read the contents of this user's manual carefully and use this product safely.

※

The design and speciﬁ cations of this product may change without prior

notiﬁ cation for product and service improvement.

The actual features in the vehicle may differ from the illustrations. For more accurate information about the vehicle, please refer to the

catalogue.

※

For more information on open licenses and legal notices, refer to the website below.

http://www.mobiszone.co.kr/front/mall/jsp/manual/avn_download_

center_manual.jsp

WARNING

• Failure to observe the instructions within this category could result in death

or serious injury or damage to the vehicle.

CAUTION

• Information on matters that could potentially lead to injury or vehicle

damage/malfunction Information that could lead to higher user safety

Information

• Information and tips that provide additional user convenience in using the product

NOTICE

• Information on specific features that facilitate proper product use and

functional understanding

• Information on terminology used within this manual

Table of Contents

1. Basic

Warnings and Cautions .........................1-2

Key Product Features ...........................1-4

Component Names and Functions ......1-5

Head Unit ……………………………… 1-5 Steering Wheel Control ……………… 1-7

Starting the System for the

First Time .................................................1-9

Turning the System On/Off …………… 1-9 System Reset ………………………… 1-9 Battery Warning Message ……………1-10 Restrictions on Features for Safety

Measures ……………………………… 1-10 Home Screen …………………………1-11 On-Screen Touch Controls …………… 1-12

2. AV

FM/AM .....................................................2-2

Accessing FM/AM Mode …………… 2-2

HD Radio™ Technology ........................2-4

HD Radio™ Mode Display Controls … 2-5

SiriusXM™ ...............................................2-6

SiriusXM™ Display Controls …………… 2-6 Selecting through Channel/

Category List ………………………… 2-8 Direct Tune …………………………… 2-8 Viewing Menu ………………………… 2-8

USB ..........................................................2-11

Before Playing a USB MP3 …………… 2-11 USB MP3 Information and Precautions … 2-13 Supported Image Specifications……… 2-13 USB Music ……………………………2-14 USB Image ……………………………2-17

iPod .........................................................2-19

Using iPod Devices …………………… 2-19 iPod ……………………………………2-23

Bluetooth® Audio ..................................2-27

Bluetooth Audio Mode ………………… 2-27 Bluetooth Connections Settings ………2-28

My Music ...............................................2-29

2 I Table of Contents

AUX .........................................................2-26

Connecting an External Device ……… 2-26

3. Bluetooth

4. Blue Link® Control

5. Navigation

Before Using the Bluetooth®

Handsfree ................................................ 3-2

What is

Bluetooth®

Technology? …………………………… 3-2 Precautions for Safe Driving ………… 3-2 CAUTIONS upon Connecting

Bluetooth

Bluetooth Connection ............................3-4

Pairing a New Device ………………… 3-4 Connecting Bluetooth Devices ……… 3-4 Disconnecting Bluetooth Devices …… 3-5 Deleting Bluetooth Devices …………… 3-5

Bluetooth Phone ....................................3-6

Phone Status Icons ………………… 3-6 Dial …………………………………… 3-7 Accept/Reject Call …………………… 3-7 Using the Menu During a Phone Call … 3-8 Call History …………………………… 3-9 Contacts ………………………………3-10 Favorites ……………………………… 3-11

Phone …………………… 3-3

Wireless

Name and Function of Each Part ........ 4-2

Rear View Mirror Switch ……………… 4-2

Before Use ...............................................4-3

What Is Blue Link? …………………… 4-3 What Is Telematics? ………………… 4-3 About Transmission and

Reception of Radio Waves …………… 4-3

Getting Started with Blue Link ............ 4-4

Connecting with the Blue Link Center … 4-4 Blue Link Stolen Vehicle Recovery ……………… 4-5

Driving Info ..............................................4-6

Send to Car with Google .......................4-6

Vehicle Diagnostics ................................4-7

Blue Link Settings ..................................4-7

Blue Link Voice Local Search ..............4-8

What is Blue Link Voice Local Search? … 4-8 Starting Blue Link Voice Local Search … 4-8

Safety and Security Service …4-5

Basic Features ........................................5-2

Operating Navigation Screen ………… 5-2 Places ………………………………… 5-3 Changing Map View ………………… 5-3 Navigation Volume …………………… 5-3 Zoom In/Zoom Out …………………… 5-4 Map Scale …………………………… 5-4

Menu .........................................................5-5

Route ………………………………… 5-5 Map Display ………………………… 5-6 Navigation Volume …………………… 5-6 Nearby POIs ………………………… 5-7 Traffic ………………………………… 5-10 Save ……………………………………5-14

Search .....................................................5-15

Places …………………………………5-15 Address ………………………………5-16 Previous Destinations ………………… 5-17 Local Search ………………………… 5-18 POI Categories ……………………… 5-19 Gas Stations ………………………… 5-20 Restaurants ……………………………5-20

Table of Contents I 3

Emergency ……………………………5-20 Address Book ………………………… 5-21 Phone Number ……………………… 5-22 Freeway Exit/Entrance ……………… 5-23 Intersection ……………………………5-23 Coordinates ……………………………5-24 Favorite places ………………………… 5-25 Route Setting ………………………… 5-26 Route Guidance ………………………5-29

Route .......................................................5-31

Canceling Route ……………………… 5-31 Display Route Information …………… 5-31 Route Overview ………………………5-32 Route Preview ………………………… 5-32 Editing Route …………………………5-33 Route Options ………………………… 5-34 Avoid Street ……………………………5-34

Navigation Settings ..............................5-35

General ………………………………5-35 Display …………………………………5-35 Guidance ………………………………5-36 Route …………………………………5-36

Traffic ………………………………… 5-36

Troubleshooting ....................................5-37

6. Voice Recognition

What is Voice Recognition? .................6-2

Precautions Required for Successful

Voice Recognition .................................. 6-2

Starting/Ending and Setting

Voice Recognition .................................. 6-3

Starting Voice Recognition …………… 6-3 Ending Voice Recognition …………… 6-3 Combining Voice Recognition

with On-Screen Commands ………… 6-3 Extending the Listening Time ………… 6-4 Skipping Prompt Messages ………… 6-5 Adjusting Voice Recognition Volume … 6-5

Voice Recognition Screen Overview ..6-6

Start Screen …………………………… 6-6 Help Display …………………………… 6-6 Instructions for Using Voice Recognition …6-7

Voice Commands ....................................6-8

Types of Commands ………………… 6-8

Call Commands ……………………… 6-8 Navigation Commands ……………… 6-9 Radio Commands …………………… 6-11 Media Commands …………………… 6-12 Other Commands List

(Commands used in List/Help) ……… 6-14 “Find <Category>” List ………………… 6-15

Siri Eyes Free ........................................6-21

How to start Siri ……………………… 6-21 How to use Siri ………………………… 6-21

7. Info

Pandora Radio .........................................7-2

Pandora Radio Mode Screen Controls

Download Center ...................................7-6

Apps List ……………………………… 7-6 My Apps ……………………………… 7-7

SiriusXM™ Data .....................................7-8

About SiriusXM™ Data Service ……… 7-8 Accessing SiriusXM™ Data ………… 7-8 SiriusXM™ Weather Announcement … 7-8 SiriusXM™ Traffic Information………… 7-9

… 7-2

4 I Table of Contents

SiriusXM™ Fuel Price Information …… 7-10 SiriusXM™ Stock Information ………… 7-11 SiriusXM™ Sports Information ……… 7-12 SiriusXM™ Movie Information ……… 7-14

SoundHound ..........................................7-16

Accessing SoundHound ……………7-16 SoundHound Main Screen …………… 7-16 Recognizing Music …………………… 7-17 Searching Music ……………………… 7-17 Song Main Screen …………………… 7-18

8. Other Features

Climate Mode ..........................................8-2

Operating Climate Mode ……………… 8-2 Basic Mode Screen …………………… 8-2

Camera ......................................................8-3

About Rear Detection Camera ……… 8-3

9. Setup

Setup .........................................................9-2

Navigation Settings ................................ 9-3

Sound Settings ........................................9-3

Display Settings ...................................... 9-4

Bluetooth Settings .................................9-4

Bluetooth Settings …………………… 9-4 Bluetooth Connection Settings ……… 9-4 Auto Connection Priority ……………… 9-5 Phone Ringtone ……………………… 9-6 Bluetooth System Information………… 9-6

Blue Link Settings ..................................9-7

Service Activation …………………… 9-7 Modem Information …………………… 9-8

Voice Recognition Settings ..................9-8

Clock Settings .........................................9-8

Wi-Fi Settings .........................................9-9

Wi-Fi Settings Screen ………………… 9-9 How to Connect to a Network ………… 9-9

Downloaded Apps Settings ................9-10

Screen Saver Settings .........................9-10

System Info ............................................9-11

System Update ……………………… 9-11

10. Appendix

Product Specification ..........................10-2

Troubleshooting ....................................10-4

FAQ .........................................................10-7

About Pairing Mobile Phones ………… 10-7 About Making/Answering Phone Calls … 10-8

About

Bluetooth

Head Unit Use Environment …………10-8

Wireless Technology/

Language Settings .................................9-9

Keyboard Settings ................................9-10

Table of Contents I 5

CAUTIONS upon Using SD Cards

Ejecting and Inserting SD Cards

•

Ejecting and inserting SD cards while the multimedia system is operating may result in SD Card or System errors. To eject or insert the SD card, ﬁ rst turn off the m the vehicle ignition.

•

Eject/insert SD cards only to update the multimedia system with a new version.

Usage of SD Cards

•

The SD Card is formatted to include only Map and new system update ﬁ les.

•

The SD Card cannot be used to save and play Music.

•

Do not add, delete, or format ﬁ les within the SD Card.

ultimedia system and

iPod

iPod® is a registered trademark of Apple Inc.

Bluetooth®

Wireless Technology

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HYUNDAI is under license. Other trademarks and trade names are those of their respective owners.

HD Radio™ Technology

HD Radio™ Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio, and "Arc" logos are proprietary trademarks of iBiquity Digital Corp.

Wi-Fi

The Wi-Fi CERTIFIED™ Logo is a certiﬁ cation mark of Wi-Fi Alliance.

Bluetooth

Wireless Technology enabled cell phone is required to use

Wireless Technology.

Bluetooth

Wireless Technology phone compatibility can be checked by visiting https://www.hyundaiusa.com/ bluetooth.

part.1

Component Names and Functions

Starting the System for the First Time

Basic

Warnings and Cautions

Key Product Features

Basic

Safety Warnings

•Even when receiving route guidance from the Navigation system, please abide by actual traffic and road regulations. Following only the Navigation route guidance ma actual traffic and road regulations and lead to traffic accidents.

•Do not stare at the screen while driving. Staring at the screen f periods of time could lead to traffic accidents.

•Do not operate the Navigation system while driving, such as enter conducting route searches. Such acts could lead to accidents, fire, or electric shock. Park the vehicle before oper the device.

•Do not disassemble, assemble, or modify the Multimedia system. Such acts could result in accidents, fire, or electr shock.

y lead to violations of

or prolonged

ing POIs or

ating

•Heed caution not to spill water or introduce foreign objects into the device. Such acts could lead to smoke, fire, or product malfunction.

•If y

ou use phone related functions while driving, you will find it difficult to concentrate on operating the vehicle and the current traffic conditions, so the possibility of an accident may increase. use phone related functions only when par

ked.

•Please refrain from use if the screen is blank or no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (fires, electric shock) or product malfunctions.

•Do not touch the antenna during thunder or lightening as such acts ma to lightning induced electric shock.

•Do not stop or park in parking-restr areas to operate the product. Such acts could lead to tr

affic accidents.

Please

y lead

icted

•For most Audio and multimedia modes, the display will not operate when the vehicle is in motion. For your safety, first park the vehicle to watch or view the screen.(The screen will only operate when the parking brake is ON for manual transmission v parking brake is ON or the gearshift is in the P (PARK) position for automatic.)

•Some functions other than the one

mentioned above driving. These functions operate only when the vehicle is parked.

ehicles and when the

cannot be used while

1-2 I Basic

Safety Cautions

Pay attention to traffic conditions while driving.

•In some instances, the navigation may provide guidance through restricted areas.

•Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. In addition, the touch screen may not work for some functions when the vehicle is in motion. The touch screen feature will be supported once the vehicle has stopped.

•Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to accidents.

•Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.)

•If you want to change the position of device installation, please inquire with your place of purchase or service maintenance center. Technical expertise is required to install or disassemble the device.

•Turn on the car ignition before using this device. Do not operate the Multimedia system for long periods of time with the ignition turned off as such operations may lead to battery discharge.

•Upon using the Multimedia system for more than 10 minutes with the car engine turned off, the following warning will be displayed. After 10 minutes, the warning will be displayed for 5 seconds every 1 minute.

•Do not subject the device to severe shock or impact. Direct pressure onto the front side of the monitor may cause damage to the LCD or touch screen.

•When cleaning the device, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents(alcohol, benzene, thinners, etc.) as such materials may damage the device panel or cause color/quality deterioration. When experiencing product with y

our place of purchase or service

maintenance center.

•Prevent caustic solutions such as perfume and cosmetic oil from contacting the dashboard because they may cause damage or discoloration.

concerns, inquire

Warnings and Cautions I 1-3

Key Product Features

This device is a Multimedia system equipped with a multifunctional player that supports Radio (FM, AM), HD Radio™ technology, SiriusXM™, USB, iPod, AUX, Bluetooth Audio and My Music features. The WIDE VGA LCD provides a high quality resolution while the powerful and rich sound system adds to the driving enjoyment.

Wide TFT-LCD Display

Display

Radio

•Provides high quality video through a Wide TFTLCD Display using an LED Back Light.

•Touch screen for maximum user convenience.

Digital Tuner Feature

•Digital Tuner using PLL method that supports memory of 12 broadcast stations for each AM and FM modes.

Radio broadcast station name

•Displays broadcast station names.

HD Radio™/Satellite Radio feature

•Supports HD Radio™ reception and Satellite Radio (SiriusXM™).

Multimedia

Player

Navigation

Miscellaneous

Support for various Media Formats

•Support for various media formats, including Radio, USB, iPod, AUX and Bluetooth

Audio

Streaming modes

My Music

•Supports copying of music stored within USB devices into My Music (internal memory) mode

Voice Guidance

•Voice route guidance to safely and conveniently reach set destinations

•Various map scales that enable drivers to accu-

ately view map and surrounding areas

Automatic Correction for Current Location

•Automatically corrects current position using map matching and GPS information.

Bluetooth

Wireless Technology

•Convenient use of Bluetooth

Handsfree by

using buttons within the steering wheel control

Digital Screen Control Features

•Easy control of features through touch screen options

Steering Wheel Control

•Control over audio features, voice recognition and Bluetooth

through the steering wheel con-

trol for maximum convenience

1-4 I Basic

Component Names and Functions

Head Unit

Name Description

Converts to FM/AM/SiriusXM™ mode

RADIO

•Each time the key is pressed, the mode is changed in order of FM → AM → SiriusXM™ → FM

Converts to MEDIA mode

MEDIA

•

Selects MEDIA mode If the media is not connected MEDIA mode will not be activated.

Displays the Blue Link mode

MAP

VOICE

NAVI

Displays the map for the current position

Takes you to the menu screen where you can find your destination and set the route.

Takes user to phone screen

Displays the information mode

SD card insert slot

Displays the Setup mode

※

The actual feature in the vehicle may differ from the illustration.

Component Names and Functions I 1-5

Head Unit

Name Description

•

When power is off, press to turn power on

POWER/

VOL

TUNE

•

When po seconds) to turn power off

•

When power is on, press quickly (under 0.8 seconds) to turn Audio off

•

Turn left/right to control volume

•

FM/AM mode : changes the frequency

•

Sir

•

MEDIA (USB/iPod/My Music) mode :

wer is on, press and hold (over 0.8

iusXM™ mode : changes the channel

the file or title changes the file or title (except USB Image, Bluetooth Audio and AUX)

When key is pressed shortly. (under 0.8 seconds)

•

FM/AM mode : plays previous/next frequency

•

SiriusXM™ mode : plays the previous/next channel

•

MEDIA (USB/iPod/My Music) mode : the file or title (except USB Image and AUX)

SEEK/TRACK

When key is pressed and held. (over 0.8 seconds)

•

FM/AM mode : continuously changes the frequency until the key is released

•

SiriusXM™ mode : continuously changes the channel until the key is released and plays the current channel

•

MEDIA (USB/iPod/My Music) mode : rewinds or fastforwards the or file (except USB Image, Bluetooth Audio and AUX)

RESET

Resets the system settings. (Preset radio channels and other data will not be deleted)

changes

1-6 I Basic

Steering Wheel Control

Name Description

•

Each time this ke

y is pressed, mode is changed in the order FM → AM → SiriusXM™ → USB Music or iPod → AUX → Bluetooth Audio → My Music

•

MODE

If the media is not connected, the corresponding modes will be disabled

•

Press and hold the key

(more than 0.8 seconds)

to turn the Audio system on/off

•

When power is off, press the key to turn power back on

VOL+

VOL-

Controls the volume

When keys are pressed quickly. (less than 0.8 seconds)

•

FM/AM mode : searches broadcast frequencies saved to Presets

•

SiriusXM™ mode : searches broadcast channels sa

ved to Presets

•

MEDIA (USB/iPod/My Music) mode : changes the file or title (e

xcept USB Image, AUX) When keys are pressed and held. (more than 0.8 seconds)

•

FM/AM mode :

automatically searches broadcast

frequencies

•

Sir

iusXM™ mode : automatically searches broad-

cast channels

•

MEDIA (USB/iPod/My Music) mode : quickly looks up songs (excluding USB images, AUX and Bluetooth audio files)

Component Names and Functions I 1-7

Steering Wheel Control

Name Description

When pressed quickly. (less than 1.2 seconds)

•When pressed in the dial screen, makes a call

•When pressed in the incoming call screen, answers the call

•When pressed during call waiting, switches to waiting call (Call Waiting)

When pressed and held. (more than 1.2 seconds)

•When pressed in Bluetooth

Hands-free, redials

the last dialed call

•When pressed dur

ing a Bluetooth® Hands-free

call, switches call back to mobile phone (Private)

•When pressed while calling on the mobile phone, switches call back to Bluetooth (operates only when Bluetooth

Hands-free

Hands-free is

connected)

•When pressed during a call, ends the phone call

•When pressed in the incoming call screen, rejects the call

When pressed quickly. (less than 0.8 seconds)

•Activates voice recognition

When pressed and held. (more than 0.8 seconds)

•Ends voice recognition

•Activates Siri Eyes Free

※

The actual feature in the vehicle may differ from the illustration.

1-8 I Basic

Starting the System for the First Time

Turning the System On/Off

Press the engine start button or set the ignition key to On or ACC. Each time you turn on the system, a boot logo and safety warning will appear.

Pressing the power key on the head unit will display the user confirm screen. To change the system language between English, French, Spanish and Korean press the Change

Language

button.

NOTICE

• Cannot operate the system while it is booting

up. It may take some time for all of features of the system, particularly the voice recognition system, to be ready for use.

Pressing and holding the power key on the head unit will turn off the system. You can change Screen Saver Settings in Setup to display a clock or another chosen image on the Screen Saver.

Information

• If you turn off the system during a phone call using the Hands-free feature, then the call will automatically switch to your mobile phone.

NOTICE

• Check the volume when turning on the

system. Before turning on the system, adjust the volume to a reasonable level.

System Reset

The System Reset function restores the system when it is not operating correctly. Press and hold the ond or longer. (It is recommended that you press the a pin or a clip.)

• Resetting the system restores all existing

RESET

NOTICE

settings and configurations (e.g. volume, display, etc.) back to their factory defaults.

RESET

or a sec-

ey f

key

using a tool, such as

Starting the System for the First Time I 1-9

Battery Warning Message

Always use the system while the car engine is running. If you turn on the system while the engine is off, a battery warning message will appear. When the engine starts, the message will disappear.

Restrictions on Features for Safety Measures

The restriction screen will disappear when shifting gears into P or putting the parking brake on.

WARNING

- Touching the Antenna During A Thunder Storm

• Do not touch the antenna during thunder or

lightning as such acts may lead to lightning induced electric shock.

NOTICE

• If you use the system for a long time with

the engine off, the battery may become completely discharged.

1-10 I Basic

WARNING

- Blank Screen

• Refrain from use if the screen is blank or

no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (ﬁ res, electric shock).

Home Screen

Controls Menu Conﬁ guration for the Home Screen

Features Description

•

Navigation Widget

AV Widget

All Menus

Places

My Menu

Provides a brief view of the navigation map and the route screen.

•

ouch any area on the screen to move to

the navigation screen.

•

Shows brief information on the radio media current playing.

•

ouch the area to mo

ve to the mode for

what you are listening to. Shows all of the items in the system menu. Directly moves to the screen where you can

search for your destination.

•You can add and save up to eight menu items.

•

Add your favorite menu items to have quick

and easy access to them.

Information Display on the Status Bar

Displays the date and time, along with the system status shown by the various icons to the right of the clock. The icons in the following table indicate the various types of system status details and events.

Navigation-

ICON

Description

ICON

Description

ICON

Description

ICON

Description

Information

AV-Mute

Mute AV

sound

Mute

Navigation

sound

Making a call and Bluetooth connection

Bluetooth

phone

remaining

battery

Handsfree connection

Connecting to music stream

Handsfree+

streaming

connection

Downloading

contacts/

recent calls

Making a call using Bluetooth

phone

Mute

Bluetooth

phone

microphone

Bluetooth

phone

reception

sensitivity

• Received signal strength indicator of Blue Link and 2G/3G/Wi-Fi information are displayed only in the devices that support the telematics system.

Starting the System for the First Time I 1-11

2G/3G/

Wi-Fi

Wi-Fi is

connected

Connecting

to Wi-Fi

2G/3G data connection

(displayed only when connected

to a 2G/3G

data net-

work)

Blue Link received

signal

strength

indication

Adding Your Favorite Menu Items to My Menu

From the Home screen, select and then

Edit

My Menu

From the Edit My Menu screen, select menu items from the list on the right, then drag and drop them to a desired place on the left. To remove the item from My Menu, draft item from the left and drop them on the right.

Information

• Up to eight items can be added to My Menu.

▶

On-Screen Touch Controls

Learn how to touch the screen to operate the system.

Select

Tap lightly on a menu or an item to select it.

NOTICE

• The system will not recognize your touch if

you wear a glove or other non-conductive material. Touch the screen using your ﬁ nger, an electrostatic touch-screen glove, or a stylus pen.

Drag & Drop

Select a menu or item you want, then drag and drop it to where you want to place it.

Drag or touch the slider along the play bar in the music screens to jump to the point that you want to play from.

1-12 I Basic

Flick (Quick Scrolling)

Drag the frequency bar to the left or right to move to the frequency that you want.

From the Edit My Menu screen, drag and drop icons to add, delete, or move to from My Menu.

Quickly moves up and down in the list.

NOTICE

• Moving the list when there are many items will

display a handler on the right of the display. You can easily move many items at a time with the handler

You can view the previous or next image by flicking left/right on an image on the USB Image screen.

Flick left/right on the frequency bar in the radio player to look up the previous/next frequency available.

Starting the System for the First Time I 1-13

Press and Hold

Pressing the and buttons in the music or video player will fast forward/rewind the music or video.

1-14 I Basic

part.2

HD Radio™ Technology

SiriusXM™

Bluetooth

My Music

FM/AM

USB

iPod

AUX

Audio

FM/AM

Accessing FM/AM Mode

You can access the radio player either by pressing the key or by selecting the Radio menu option from All Menus on the Home screen.

Information

• If you press the n on and a radio broadcast will be tuned up.

tur

• If you are in the FM/AM mode, select the FM/AM radio widget from the

Home screen to access the radio player.

RADIO

key when the power is off, then the power will

RADIO

Features Description

Mode Display

Preset

Frequency Bar

Frequency Broadcast

station

Scan

HD Radio

•Displays current operating mode

•If select wanted mode tap, it will change to selected mode in Radio.

•Shows saved presets for user selection

•After selecting frequency → press and hold (over 0.8 seconds) the preset button. A 'beep' will sound and the frequency is saved to the selected preset button.

A total of 24 frequencies with 12 preset

frequencies each for FM/AM modes can be

saved.

•Flick the frequency bar left/right to search for available radio channels to the left or right of the current channel.

agging: Drag the frequency bar to the left/

•Dr right to find the radio channel that you want.

Displays the current frequency

Displays the current broadcast station name.

Plays frequencies with superior reception for 5 seconds each

When the HD Radio soft button is ON (the blue indicator on the HD Radio button is illuminated), HD Radio signals will be received.

2-2 I AV

Features Description

Turns the Radio Text information on and off

•If the ON Text On button is displayed (Te state), information will not be displayed even if there is information being transmitted from

Info

the broadcast station.

•If the Off Text Off button is displayed (Text on state), then broadcast information will be displayed. Information may not be displayed if there is no information being transmitted from the broadcast station.

xt off

Features Description

•Autostore Saves frequencies with good reception to Preset buttons While Auto Store is operating, pressing the Auto Store button again will cancel the func-

tion and play the previous frequency.

•

Preset Scan

Plays preset frequencies for 5 or 10 seconds each

•HD on : 10 seconds

•HD off :

5 seconds

Scan/ Auto Scan/ Preset Scan

Displays an activated mode from the Scan/Auto Scan/Preset Scan modes.

Runs the SoundHound feature.

SoundHound

For more detailed feature, please refer to SoundHound section in Info part.

•Pressing this button briefly (less than 0.8 seconds) : Seeks the previous/next frequency.

•Pressing and holding this b

SEEK/TRACK

0.8 seconds) : Moves quickly through all of the frequencies. From the moment that you release the button, the system will seek the next available frequency.

TUNE

knob to manually seek avail-

TUNE

Turn the able frequencies.

•FM : Increment/decrement by 200 kHz

•AM : Increment/decrement by 10 kHz

utton (longer than

FM/AM I 2-3

HD Radio™ Technology

Contributes to the superior user experience of HD Radio™ Technology. Presents song name, artist, station IDs, HD2/HD3 Channel Guide, and other relevant data streams.

nal music as well as deep cuts into traditional genre.

signal. AM sounds like today’s FM and FM sounds like a CD.

Program Service Data :

Adjacent traditional main stations are extra local FM channels. These HD2/HD3 Channels provide new, origi-

Digital, CD-quality sound. HD Radio™ Technology enables local radio stations to broadcast a clean digital

If an HD Radio™ broadcast is received, the radio mode will switch from analog broadcast to HD Radio™ broadcast.

Information

• The

HD Radio™

when a HD Radio™ broadcast is being received

screen is displayed only

2-4 I AV

HD Radio™ Mode Display Controls

Name Description

Displays main HD Radio™ channels and used to directly select the current available channels.

HD Radio technology allows AM and FM radio

stations to transmit audio and data using a digital signal. The HD Radio format allows stations to simultaneously broadcast one or more differ-

HD Radio™

Reception & Channel buttons

HD Channel

Number

Broadcast

Info

HD Radio

ent programs in addition to the program being transmitted on the station’s analog channel. When the HD Radio soft button on the screen is ON (blue indicator on the HD Radio button is illuminated), HD Radio reception will become active whenever a broadcast channel sends an HD Radio signal and when the vehicle is in areas where the signal reception is strong. If multiple HD Radio programs are available, a soft button for each channel will appear on the screen allowing you to select from HD1, HD2, etc.

Analog station and corresponding HD Radio channel number saved in the preset list.

Displays detailed information about the current broadcast. (the details of the information shown are different depending on whether the Info button is selected)

When the HD Radio soft button is ON (the blue indicator on the HD Radio button is illuminated), HD Radio signals will be received.

HD Radio™ Technology I 2-5

SiriusXM™

You can access the radio player either by pressing the key or by selecting the Radio menu option from All Menus on the Home screen. Select the SiriusXM™ tab from the radio player.

SiriusXM™ Display Controls

Information

• If you press the n on and a radio broadcast will be tuned up.

tur

• If you are in the SiriusXM™ mode, select the SiriusXM™ radio widget

from the Home screen to access the radio player.

• When the power is off, pressing the

and play a SiriusXM™ Radio broadcast.

RADIO

key when the power is off, then the power will

RADIO

key will turn the power on

RADIO

Features Description

Mode Display

Preset

Channel Logo Channel Info

Contents Info

Category Info Scan

Direct Tune
