HYUNDAI MOBIS ACB10C1GG User Manual

Model name : ACB00C1GG, ACB10C1GG, ACB00C1GN, ACB10C1GN, ACB00C1GE, ACB10C1GE,

ACB00C1EE, ACB10C1EE, ACB00C1GL, ACB10C1GL, ACB01C1GG, ACB11C1GG

<Head-Unit>

<Accessory :External keyboard>

1

2 3 4 5 6 7

10

11

8 9

Audio system

9

4

Steering wheel remote control

❈ The actual features in the vehicle

may differ from the illustration.

(1) MODE

• Press the button to change the
mode in the following order: Radio
➟ Media.

• Press and hold the button to turn
off.

(2) VOLUME

• Press to adjust the volume.

(3) UP/DOWN

• Press the button in radio mode to
search Presets.

• Press and hold the button in radio
mode to search frequencies.

• Press the button in media mode to
change the current song.

• Press and hold the button in media
mode to quick search through
songs.

(4) CALL

• Pressing the button

- If not in Bluetooth

®

Handsfree

mode or receiving a phone call.
First press: Display Dial Number

screen.
Second press: Automatically dis-

play the most recently Dialed
Call number.

Third press: Dial the phone num­ber entered.

- Press in the Incoming Call notifi-

cation screen to accept the
phone call.

- Press in Bluetooth

®

Handsfree
mode to switch to the waiting
call.

• Pressing and holding the button

- If not in Bluetooth

®

Handsfree
mode or receiving a phone call,
the most recently Dialed Call
number is dialed.

- Press in Bluetooth

®

Handsfree
mode to transfer the call to your
cell phone.

- Press in cell phone mode to
switch to Bluetooth

®

Handsfree

mode.

(5) END

• Press in Bluetooth

®

Handsfree

mode to end the phone call.

• Press in the incoming call screen
to reject the call.

Audio system

410

WARNING

- Audio System Safety
Warnings

• Do not stare at the screen
while driving. Staring at the
screen for prolonged periods
of time could lead to traffic
accidents.

• Do not disassemble, assem­ble, or modify the audio sys­tem. Such acts could result in
accidents, fire, or electric
shock.

• Using the phone while driving
may lead to a lack of attention
of traffic conditions and
increase the likelihood of
accidents. Use the phone fea­ture after parking the vehicle.

• Exercise caution not to spill
water or introduce foreign
objects into the device. Such
acts could lead to smoke, fire,
or product malfunction.

(Continued)

(Continued)

• Please refrain from use if the
screen is blank or no sound
can be heard as these signs
may indicate product malfunc­tion. Continued use in such
conditions could lead to acci­dents (fires, electric shock) or
product malfunctions.

• Do not touch the antenna dur­ing thunder or lightening as
such acts may lead to light­ning induced electric shock.

• Do not stop or park in park­ing-restricted areas to operate
the product. Such acts could
lead to traffic accidents.

• Use the system with the vehi­cle ignition turned on.
Prolonged use with the igni­tion turned off could result in
battery discharge.

WARNING - Distracted

Driving

Driving while distracted can
result in a loss of vehicle con­trol that may lead to an acci­dent, severe personal injury,
and death. The driver’s primary
responsibility is in the safe and
legal operation of a vehicle, and
use of any handheld devices,
other equipment, or vehicle sys­tems which take the driver’s
eyes, attention and focus away
from the safe operation of a
vehicle or which are not permis­sible by law should never be
used during operation of the
vehicle.

Audio system

11

4

(Continued)

• If you want to change the posi­tion of device installation,
please inquire with your place
of purchase or service mainte­nance center. Technical
expertise is required to install
or disassemble the device.

• Turn on the car ignition before
using this device. Do not oper­ate the audio system for long
periods of time with the igni­tion turned off as such opera­tions may lead to battery dis­charge.

• Do not subject the device to
severe shock or impact. Direct
pressure onto the front side of
the monitor may cause damage
to the LCD or touch screen.

(Continued)

(Continued)

• When cleaning the device,
make sure to turn off the
device and use a dry and
smooth cloth. Never use
tough materials, chemical
cloths, or solvents (alcohol,
benzene, thinners, etc.) as
such materials may damage
the device panel or cause
color/quality deterioration.

• Do not place beverages close
to the audio system. Spilling
beverages may lead to system
malfunction.

• In case of product malfunc­tion, please contact your
place of purchase or After
Service center.

• Placing the audio system with­in an electromagnetic environ­ment may result in noise inter­ference.

• Prevent caustic solutions such
as perfume and cosmetic oil
from contacting the dashboard
because they may cause dam­age or discoloration.

CAUTION

• Operating the device while
driving could lead to acci­dents due to a lack of atten­tion to external surroundings.
First park the vehicle before
operating the device.

• Adjust the volume to levels
that allow the driver to hear
sounds from outside of the
vehicle. Driving in a state
where external sounds cannot
be heard may lead to acci­dents.

• Pay attention to the volume
setting when turning the
device on. A sudden output of
extreme volume upon turning
the device on could lead to
hearing impairment. (Adjust
the volume to a suitable levels
before turning off the device.)

(Continued)

Audio system

412

Information on status icons

Icons showing audio status are shown in the upper-right
corner of the screen.

Icon Description

Mute Mute engaged

Battery

Remaining battery life of a connected
Bluetooth®device

Handsfree +

Audio streaming

connection

Bluetooth®Handsfree call and audio stream­ing available

Handsfree

connection

Bluetooth®Handsfree call available

Bluetooth

®

audio streaming

Bluetooth®audio streaming available

Downloading

contacts

Downloading contacts through Bluetooth®wire­less communications

Downloading

call history

Downloading call history through Bluetooth

®

wireless communications

Line busy Phone call in progress

Mute mic

Mic muted during a call
(caller cannot hear your voice)

Phone signal

strength

Display the phone signal strength for a cell
phone connected by Bluetooth

®

Audio system

13

4

RDS Radio (if equipped)

FM/AM

Switching between FM and AM

Press the [RADIO] button on the
audio system to switch between FM
and AM.

Searching channels

Search channels by pressing the
[SEEK/TRACK] button on the prod­uct.

Presets

Save up to 36 frequently used sta­tions.

1. Press and hold the desired slot
from 1 through 36. This saves the
current station in the selected slot.
If the slot is empty, simply press­ing saves the station to the slot.

2. To save in slots numbered 7 or
higher, press the [PRESET] but-
ton to move to the previous/next
page and save.

To listen to a preset station, press
the desired station in the list.

Menu

Press the [MENU] button, and select
the desired function.

• List: A list of all stations available in
the current location of the vehicle is
displayed. Press the desired sta­tion.

• Traffic Announcement (TA): Enable
or disable Traffic Announcements.

• Scan: All available stations are
played for five seconds each.

• Sound Settings: Audio sound set­tings can be changed.

Audio system

414

Radio

FM/AM

Switching between FM and AM

Press the [RADIO] button on the
audio system to switch between FM
and AM.

Searching channels

Search channels by pressing the
[SEEK/TRACK] button on the prod­uct.

Presets

Save up to 36 frequently used sta­tions.

1. Press and hold the desired slot
from 1 through 36. This saves the
current station in the selected slot.

2. To save in slots numbered 7 or
higher, press the [PRESET] but-
ton to move to the previous/next
page and save.

To listen to a preset station, press
the desired station in the list.

Menu

Press the [MENU] button, and select
the desired function.

• List: A list of all stations available in
the current location of the vehicle is
displayed. Press the desired sta­tion. Press the [Refresh] to update
the list of available stations.

• Scan: All stations available in the
current location of the vehicle are
played for five seconds each.

• Sound Settings: Audio sound set­tings can be changed.
