Hyundai H-1501 User Manual [ru]

H-1501

ALARM CLOCK RADIO

РАДИОПРИЕМНИК

С БУДИЛЬНИКОМ

Руководство по эксплуатации Instruction manual

Instruction manual Instruction manual

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended
to read this manual carefully before connecting, operating and/or adjusting the
product and keep the manual for reference in future.

Description

1. TIME button

2. ALARM button

3. HOUR button

4. MIN button

5. SNOOZE button

6. SLEEP button

7. TUNING regulator

8. AM/FM band switch

9. Display

10. Dial scale

11. VOLUME regulator

Not indicated: Bottom of the unit:
battery compartment for 1x9V battery (not
included). Left panel: ALARM/ON/OFF/
AUTO switch

1 2 3 4 5 6 7 8

9 10 11

Important safeguards

• The instruction manual contains
important operating and maintenance
instructions. For your safety, it is
necessary to refer the manual. Keep the
manual for use in future.

• Do not hit or drop the unit.

• Do not expose the unit to vibration,
direct sunlight, too high or low
temperature or humidity.

• If you are not going to use the unit
within a long period of time, remove the

2 3

batteries to avoid their leakage.

• Do not disassemble the unit
yourselves. Refer servicing to qualified
service personnel.

Power supply

Battery operation

• Insert 1x9V battery (not included)
to the terminal inside the battery
compartment. Your set will not work
normally from the battery supply, but

there is now the advantage that, in case
there is a mains current failure, your clock
will continue to work. The clock display
will not light up, the clock time will be held
in the clock memory by the battery back­up system.

This enables you to move the set
from place to place without re-setting
the clock every time. The battery back­up system is only meant to be used
from short temporary power failures.
For longer durations the battery may
become exhausted or there may be some
deviation in accuracy.

• When the battery is exhausted,
it should be removed from the set to
prevent leakage. If you do not wish to
take advantage of the battery back-up
system, your set will work normally without
a battery. However, if disconnected from
the mains, the clock figures will flash when
the mains are re-connected and you must
re-set the clock as described in the “AC
operation” paragraph.

AС operation

• The appliance is for household use
only.

• Before the first connecting of the unit
check that voltage indicated on the rating
label corresponds the mains voltage in
your home.

• Insert the plug into the power supply.

• The set is now working as an
electronic clock. Figures will blink on the
display showing that clock should be set.

HOUR button or MIN button to set the
clock display to the correct time.

• Release all the buttons when finished

the setting.

Radio operation

Tuner operations

• Slide ALARM/ON/OFF/AUTO switch

to ON and turn on the volume.

• Slide AM/FM switch to AM or FM

position to select the needed band.

• Adjust the program using TUNING

regulator.

• Use VOLUME regulator to adjust

volume level.

Sleep to music

The radio can be set to play and to

switch off automatically after a preset time.

• Slide ALARM/ON/OFF/AUTO switch

to AUTO or OFF position.

• Press SLEEP button once.

• You can have 59 minutes playing the

radio to accompany you to sleep.

• To set for a desired period of sleep
(maximum 1 hour 59 minutes), simply
press and hold SLEEP button and then
press HOUR button or MIN button to set
the desired period of the sleep function.

• If you want to turn off the radio before
sleep time expires, press SNOOZE button.

Alarm operation

Setting the clock

• Press and hold TIME button.

• Do not release TIME button; press

Setting the alarm

• Press and hold ALARM button.

• Without releasing ALARM button,
press HOUR button or MIN button to set
the desired wake up time.
