1. WELKOM AT HYTORC
Thank you for buying HYTORC equipment.
This user manual and safety instructions is designed to provide you with the basic knowledge
required to operate and maintain your new HYTORC equipment.
Please read this manual carefully and follow the instructions provided. If you still have any
questions regarding HYTORC bolting equipment, please do not hesitate and call us at
+31 (0) 24 3660 660 or contact us at info@hytorc.nl.
You also find more information on our website www.hytorc.nl
2. GENERAL INFORMATION
Your purchase of HYTORC equipment entitles you to the following HYTORC services:
Instructions to your employees within your organization by a HYTORC specialist
Free annual inspection of your HYTORC equipment
24-hour service
When you need help abroad? No problem! We help you!
HYTORC equipment according to the newest technology
A full year complete warranty
In case of failure under warranty of standard tools, substitutional rental equipment can be
supplied at request
Qualified work force employable for solutions at difficult challenges
3. SAFETY INSTRUCTIONS
Warning: Your HYTORC torque machine is a power tool, and as with any power tool, certain
safety precautions should be observed to avoid accidents or personal injury. The following
instructions will assist you.
Read all instructions.
Keep work area clean and well lit.
Consider work area environment. Electrical Pumps should never be used in an
atmosphere that can be considered potentially volatile. If there is any doubt, use an air
pump. Note: Metal-to-metal contact can cause sparks, precautions should be taken.
Avoid premature tool starting. The Pump Remote Control is for the TOOL OPERATOR
only.
Stay clear during operation. In most cases, the tool will allow “hands free” operation. If
the tool must be held or steadied during operation, use alternative means of securing the
tool to the application.
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 4
Guard against electric shock. Ensure the pump is properly grounded and the proper
voltage is being used.
Store equipment properly. When not in use, tools and accessories should be properly
stored to avoid deterioration.
Use right tool. Do not force small tools or attachments to do the job of a larger tool. Do
not use a tool for purposes not intended.
Proper safety attire. When handling/operation hydraulic equipment use work gloves, hard
hats, safety shoes and other applicable clothing.
Use safety glasses with side covers.
Moving equipment. Do not use hydraulic hoses, uni-swivels, pump power or remote
cords as means of moving the equipment.
Maintain your HYTORC equipment with care. For top performance, inspect tools, power
pack and accessories for visual damage frequently and always prior to use. Always follow
instruction for proper tool and pump maintenance. Refer to the Operations Maintenance
Section in chapter 10 for further clarification.
Stay alert! Watch what you are doing. Use Common sense. Do not use power equipment
under the influence of any mood altering substances.
Prior to operation:
- Ensure that all hydraulic connections are securely connected and there is no leakage;
- Verify that the hydraulic hoses are not kinked or otherwise damaged;
- Ensure the square drive and its retainer are fully and securely engaged;
- Be certain that all connectors, elbows, fitting and swivels are not bent, loose or
damaged.
Prior to use:
- Check sockets for size, quality and flaws (do not use if questionable);
- Cycle tool to ensure proper function;
- Locate a solid, secure reaction point;
- Be sure the reaction arm retaining clamp is fully engaged;
- Be sure the hydraulic hoses are free of the reaction point;
- Pressurize the system momentarily; if the tool tends to “ride up" or to “creep", stop and
re-adjust the reaction arm to a more solid and secure position..
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 5
Stay away of the reaction points. Remain clear of the reaction arm during operation and
never punt body parts between reaction arm and reaction
surfaces.
Always use quality accessories. Always use top quality impact sockets in good condition
that are the correct size and fully engage the nut. Hidden flaws, however, remain a
possibility that could cause breakage, so stay clear of sockets during operation.
Do not use other equipment to enhance performance. For example a hammer on the
socket or tool.
Comment:
HYTORC pumps are designed to operate HYTORC tools only and otherwise. Damage may
occur to the pump or the product that is being operated due to misuse.
You can find a version of the instructions on the reverse side of the torque charts.
STORE THESE SAFETY INSTRUCTIONS WITH YOUR HYTORC TOOL!
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 6
4. INTRODUCTION
The MXT/XLT-series is an advanced torque wrench, specially designed for applications with a
limited free radius. This is possible because the reaction arm is adjustable in 60 different
positions.
HYTORC has several low clearance wrenches to tighten or loosen nuts with limited height
clearance, such as the Stealth, XLCT and Versa.
5. BEFORE USE
All HYTORC products have been tested and are ready for use at delivery. In some cases, you
need to fill the supplied hydraulic oil in the pump unit before use.
The system accuracy of your HYTORC tool is within ± 3%. This accuracy maybe certified
through calibration by our own calibration system. All new tools are delivered with a calibration
certificate.
A HYTORC torque tool is only complete with a hydraulic pump and a high-pressure twin hose.
To assure a safe and good operation of your equipment it is necessary to operate correctly
and maintain regularly.
6. CONNECTING THE HYDRAULIC PUMP UNIT
Important
Before use you have to fill the HYTORC pump units with, separate delivered, hydraulic oil
(if it is not already done prior to delivery).
If you operate your HYTORC torque tool with another pump brand, please note the
restricted pressure of 700 BAR maximum.
6.1 Before use – Check pumps
Air driven pump units
Use as minimum ¾” air hose and ½” couplers. The working pressure is 6-10 BAR. During
running the air pressure is not allowed to drop under 4,5 BAR.
Check the water separator by opening the drain.
Check if the oil level in the lubricator is sufficient. And check during running if the lubricator
drops the subscribed drops of oil, approximately 4-6 drops per minute for most pumps.
Electrical driven pump units
Assure yourself of using the right voltage according the pump specifications. You find
these on the pump cover or electrical box.
Beware of overvoltage and undervoltage! (too long or too thin extension cable will cause a
voltage decrease).
Use the hydraulic pomp only if the green/yellow grounding cables are connected.
If needed, use an 2,5 mm² electrical extension cable, unreel the cable wince completely
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 7
6.2 Hose connection
A twin hose connects the torque wrench and the hydraulic pump unit. Each hose has couplers
at each end. One hose has female couplers at both ends and the other hose has male
couplers at both ends. To avoid tool malfunction, do not reverse connectors!
We have three different types of couplers; rotating couplers, rotating couplers with locking
devices and quick couplers. The different types cannot be connected between each other.
IMPORTANT
You cannot connect 2 or 4 hoses to each other. If necessary, you can connect 3 or 5 hoses.
Use always an odd number of hoses.
Push the hose parts and couplers to each other.
Screw the couplers hand tight. Do not use locking pliers.
If you want to detach, disconnect the return hose first. If impossible, press briefly once on
the remote control push button.
Attention! During operation the couplers can become loose unnoticed, what makes oil flow
impossible. The tool operates no longer.
ASSURE YOURSELF THAT ALL COUPLERS ON THE PUMP
AS WELL AS ON THE TOOL ARE TIGHTENED PROPERLY!
THIS IS THE MOST COMMON OPERATION FAILURE!
6.3 After use
Reel the hoses.
Protect the couplers against dirt and damage by connecting the end parts of the hose to
each other.
PUMP
TOOL
PUMP
TOOL
PUMP
TOOL
WRONG
RIGHT
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 8
7. SETTING OF TORQUE VALUE / BOLT LOAD
The HYTORC hydraulic pump unit has a working range of 20 BAR until maximum 700 BAR.
Within this range the pressure is infinitely adjustable.
Follow the next steps to adjust the right torque:
1. Every tool type has his own pressure/torque chart, supplied with your HYTORC tool.
Search for the right torque in the preferable column (Nm, kgm or ft.lbs.) in the chart and
read the right pressure to adjust the
pump in BAR (right) or PSI (left).
2. Turn the wing nut (on the tank cover of the pomp unit) completely leftwards = upwards. If a
locking knob exists, please release this one first.
3. Put the torque tool somewhere on the ground or another safe place without placing on a
nut.
4. Pick up the remote control and push the start/run button. The pump starts running
and the tool makes one stroke. Repeat twice and check if the tool turns fine.
5. NEXT: AS FROM NOW KEEP THE START BUTTON PRESSED!
6. Turn the wing nut to the right
until the pressure gauge presents the
desirable pressure. After setting, you
can release the start button.
7. Push the button after several
seconds again and check the
pressure. Fix the locking if adjustment is fine.
Finally, check the pressure again.
Important
To change the pressure you first have to turn
the wing nut back to lower pressure (0). Next
you can set the desired pressure like explained
in this chapter.
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 9
8. USE OF SOCKET WRENCH
Secure the socket with the locking pin to the torque tool.
Place tool and socket on the nut and beware that the socket covers the nut as far as
possible. Even when the nut is painted or rusted!
Never use a socket with extension piece!
Never use a 12 points socket when not required!
Never use any thin wall or turned off socket!
In above mentioned cases it is possible something brakes or causes injury!
8.1 Changing rotation direction
Push the button of the drive retainer which fixes the square drive to the tool.
Pull the square drive axle out of the tool and place it back on the other side of the tool.
Place the fixation drive retainer.
Some HYTORC types have the possibility to push the square drive through the tool to the
other side.
Loosening Tightening
8.2 Reaction arm
All HYTORC torque tools have a universal changeable reaction arm. This reaction arm bears
the reaction forces that have been generated by the tool. The reaction arm needs to be
retracted in the same direction as the square drive and, if necessary, changed of placement
when the square drive is changed.
Place the tool on the bolted connection and place the reaction arm to a reaction point by
hand. Check if hoses and tool are free of obstacles.
Ensure if the steel endpoint of the reaction arm abuts solidly to the chosen reaction point.
Stay clear of the tool and reaction point with your fingers or other body parts!
Push the start button for one second to find out if everything is working properly.
ATTENTION!
The yellow reaction arm cover needs to support as low as possible against the reaction point
or on the same height as the grip of the socket on the nut. If the reaction arm leans higher
than this grip point, a bending force arises that causes a higher risqué of spoiling the thread.
Assure yourself that the reaction arm is pushed over the square
drive as far as possible and that the fixation clip is secured in the
groove of the tool.
Comment: if the reaction point cannot be reached due to a short
reaction arm, we can lengthen the arm with an accessory.
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 10
8.3 To tighten a bolted connection
By pushing down on the remote control button in the advance position, the tool starts turning
until the reaction arm will contact its reaction point. That is why you have to place the reaction
arm to the reaction point first, ensuring reaction arm and reaction point are free of any
obstacles. Continue to hold down the advance button as the nut turns until you hear a “click”
which will signify the hydraulic cylinder inside the tool is fully extended and will not turn the nut
further. Continuing to hold down the remote control button will result in a rapid build-up of
pressure to the point of where the gauge reads what was pre-set prior to applying the wrench.
Attention: The rising of the oil pressure till the pre-set value does not mean that the desired
torque value is reached. It only indicates that the cylinder is fully extended and cannot turn the
nut further until the tool automatically resets itself. Release the remote control button and the
cylinder will retract.
The tool will automatically reset itself and the operator will hear a “click”.
Push the button again for the next stroke.
Repeat this step till the nut stops turning.
Successive cycles are made until the tool “stalls” at the desired torque value with accuracy
within ±3%.
8.4 The reaction pawl
The reaction pawl is a blocking system for the driving ratchet. It is possible
that the reaction pawl is stuck in the sprocket wheel after reaching the
desired torque value. You will notice that the tool is under pressure and
cannot been taken from the nut.
The built-in reaction pawl is doing its job by intercepting the torsion and
tolerance.
Press again the start button of the remote control and keep it pressed till
the oil pressure is build up to adjusted maximum.
Slide the small reaction pawl button away from its covered position
and keep it there.
Let go off the start button on the remote control. You can remove
the tool now.
8.5 To loosen a bolted connection
Adjust the pressure of the pomp to its maximum of 700 BAR or 10.000 PSI.
Check the rotating direction of the hexagon or square drive and change if necessary.
Check the position of the reaction arm and change if necessary.
Ensure that the reaction arm is secured.
Place the tool on the bolted connection.
Press the button of the remote control and keep it pressed till the socket or ratchet turns
and stops again. As the cylinder extends fully, you will hear a “click”.
Release the remote control button and wait till the cylinder automatically retracts, you
again will hear a “click”.
Press the button again till the “click” and repeat this as long as necessary till the
connection is loose.
Comment: If the bolted connection does not loosen, it is an indication that you may require
the next larger size tool to loosen the bolt. If you do not have this in your possession, please
contact HYTORC to find a good solution.
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 11
9. MALFUNCTIONS AND SOLUTION
9.1 Torque wrench
The tool does not operate anymore check if all couplers (as well on tool as on the
pump) are tightened properly. The coupling nut of the female coupler has to be tightened
completely to the collar of the male coupler.
9.2 Pumps
The pump pressure at a fixed adjustment repeats inaccurately pump pressure adjusting
valve is dirty or damaged loose the valve and cover the hole with a towel, start the
motor for 2 seconds, clean valve and assemble it again renew the valve if the problem
is not solved.
Pump runs and produces pressure but the tool does not turn check coupler
connections.
The tool turns in the wrong direction probably two or an even number of hoses is
connected to each other or the male and female couplers are interchanged.
The tool is running slower than usually adjust pump pressure to 700 BAR and shut off
the pump when the start button is pressed the pressure drops quickly to about 100
BAR but has to remain there. If the pressure drops to zero, it indicates an internal
leakage. Please contact HYTORC Nederland B.V. +31 (0)24-3660660
9.2.1 Air pump units
Pump motor does not start kink in the air hose of the remote control unreel the hose
completely.
Pump motor does not start starter valve (position 21) is defect press small knob of
the starter valve while ON/OFF handle (position 9) stands at ON.
Pump runs slowly or irregular too low air pressure minimum of 4 BAR with running
motor clean dirty filter dirt in the air motor.
The motor does not run or switch this indicates a defect of the control valve in the
pump unit.
If necessary, contact HYTORC Nederland B.V. at +31 (0)24-3660660.
9.2.2 Electrical pump units
Motor makes strange noise and produces no pressure check rotating direction.
Motor runs to slow or stops automatically after starting voltage drop in the power.
Usually too thin or too long extension cable is used. Check pump unit with the main plug
directly in the electric point.
Motor runs but does not switch from forward to reverse rupture in the remote control
cable valve block defect.
Motor does not run no electrical power or rupture in supply cable.
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 12
10. MAINTENANCE
10.1 Inspection before each use
Check if both oil levels of the pump unit are sufficient.
Check power supply (air pressure minimum 5 BAR or the right E-voltage).
Check if the cables and air hose supply of the remote control are not damaged.
Unreel the hose of the remote control at air pumps completely. Bending of the small air
hose can cause failures.
Check if supply cables are not damaged.
Check if the hydraulic hoses are not damaged. The working pressure is 700 BAR.
Adjust pump pressure at 200 BAR. Check if the needle returns repeatable. Resume at
400 BAR and 700 BAR.
Drain if there is water in the separator.
Oil pressure gauges are filled with glycerine. If glycerine level drops, you have a leakage
and repair is needed. When gauge is getting filled with hydraulic oil, this is also an
indication of internal leakage.
After each time the tool is used, clean it and check the grease inside the tool.
10.2 Small maintenance
Hydraulic oil:
Change the oil after 40 operation hours completely or at least 2 times a year. Use only
High-grade oil, ISO VG 46 or 32.
Filter at the pump:
This filter must be changed 3 times a year at normal use and more often if the unit is used
each day.
Quick couplers hoses:
Clean dirty or rigid couplers or replace them.
Coal brush assembly (electrical unit):
Check and if necessary renew
10.3 Maintenance at HYTORC
Torque wrench:
Depending of the usage, but at least once a year, disassemble the complete tool, clean,
inspect, change small springs and lubricate again. Inspection on capacity at 100, 200, 300
and 700 BAR.
Pump unit:
Calibrate pump pressure gauge 1 time a year and fill glycerine level.
Motor (electrical and air driven):
The rotor axle and bearings; 1 time a year cleaning and lubrication.
Remote control (air driven unit):
Check the air hoses at flow obstructions and if necessary repair. The operation buttons
are supplied with a small spring and have to open and close easily.
Clean the control valves.
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 13
11. PART LIST MXT-SERIES
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 14
ITEM
QTY.
DESCRIPTION
MXT-.7
MXT-1
MXT-3
MXT-5
MXT-10
1 1 Housing (with end cap, shroud, access plug and seal kit)
MXT-.7-01
MXT-01 -01
MXT-03-01
MXT-05-01
MXT-10-01
3 1 Rear Reaction Arm Assembly
MXT-.7-03
MXT-01-03
MXT-03-03
MXT-05-03
MXT-10-03
4 2 Drive Plate Universal
MXT-.7-04
XLT-01-04
XLT-03-04
XLT-05-04
XLT-10-04
5 1 Sq Drive Assembly
MXT-.7-05
XLT-01-05-1
XLT-03-05-1
XLT-05-05-1
XLT-10-05-1
6 1 Ratchet
MXT-.7-06
XLT-01-06-1
XLT-03-06-1
XLT-05-06-1
XLT-10-06-1
7 2 Sq Drive Bushing
MXT-.7-07
XLT-01-07-1
XLT-03-07-1
XLT-05-07-1
XLT-10-07-I
8 2 Drive Sleeve Spline
MXT-.7-08
XLT-01-08-1
XLT-03-08-1
XLT-05-08-1
XLT-10-08-1
10 1 Reaction Pawl Assembly
MXT-.7-10
MXT-01-10
MXT-03-10
MXT-05-10
MXT-10-10
11 1 Drive Retainer Assembly
MXT-.7-11
XLT-01-11
XLT-03-11
XLT-05-11
MXT-10-11
13 1 Drive Plate Roll Pin
MXT-.7-13
XLT-01-13
XLT-03-13
XLT-05-13
XLT-10-13
14 1 Left and Right Lever Assembly
MXT-.7-14
MXT-01-14
MXT-03-14
MXT-05-14
MXT-10-14
18 1 Reaction Pawl Spring
MXT-.7-18
MXT-01-18
MXT-03-18
MXT-05-18
MXT-10-18
19 1 Rod End Pin
MXT-.7-19
XLT-01-19
XLT-03-19
XLT-05-19
XLT-10-19
26 1 End Cap
MXT-.7-26
MXT-01-26
MXT-03-26
MXT-05-26
MXT-10-26
27 2 Drive Pawl Spring
MXT-.7-27
XLT-01-27
XLT-03-27
XLT-05-27
XLT-10-27
28 1 Reaction Arm Lever Assembly
MXT-.7-28
MXT-01-28
MXT-03-28
MXT-05-28
MXT-10-28
30 2 Drive Sleeve Retaining Ring
MXT-.7-30
XLT-01-30
XLT-03-30
XLT-05-30
XLT-10-30
31 1 Shroud
MXT-.7-31
MXT-01-31
MXT-03-31
MXT-05-31
MXT-10-31
32 2 Shroud Screw
MXT-.7-32
XLT-01-32
MXT-03-32
MXT-03-32
XLT-10-32
33 1 Drive Pawl Spring Secondary
n/a
n/a
n/a
n/a
n/a
34 1 Reaction Arm Thrust Plate
MXT-.7-367
MXT-01-367
MXT-03-367
MXT-05-367
MXT-10-367
37 2 Thrust Plate Screw
MXT-.7-503
MXT-01-503
MXT-03-503
MXT-05-503
MXT-10-503
39 1 Catch Lever, Reaction Arm
MXT-.7-328
MXT-01-328
MXT-03-328
MXT-05-328
MXT-10-328
38 1 Reaction Arm Lever Spring
MXT-.7-508
MXT-01-508
MXT-03-508
MXT-05-508
MXT-10-508
40 1 Roll Pin Drive Pawl Primary
MXT-.7-40
XLT-01-40
XLT-03-40
XLT-05-40
XLT-10-40
41 1 Roll Pin Drive Pawl Secondary
MXT-.7-41
XLT-01-41
XLT-03-41
XLT-05-41
XLT-10-41
42 1 Roll Pin Reaction Pawl
MXT-.7-42
XLT-01-42
XLT-03-42
XLT-05-42
XLT-10-42
43 1 Reactin Arm Boot
MXT-.7-43
XLT-01-43
XLT-03-43
XLT-05-43
XLT-10-43
44 2 Reaction Arm Boot Pin
MXT-.7-44
MXT-01-44
MXT-03-44
MXT-05-44
MXT-10-44
45 1 Reaction Arm Lever Pin
MXT-.7-509
MXT-01-509
MXT-03-509
MXT-05-509
MXT-10-509
46 1 Serial Plate Right/Left Set
MXT-.7-46
MXT-01-46
MXT-03-46
MXT-05-46
MXT-10-46
48 2 Access Plug (with 0 ring)
MXT-.7-02
MXT-01-02
MXT-03-02
MXT-05-02
MXT-10-02
58 1 Shroud Spring Screw
MXT-.7-58
XLT-01-58
XLT-03-58
XLT-05-58
XLT-10-58
59 1 Shroud Spring
MXT-.7-59
XLT-01-59
XLT-03-59
XLT-05-59
XLT-10-59
61 1 Piston Assembly
MXT-.7-61
XLT-01-61
XLT-03-61
XLT-05-61
XLT-10-61
63 1 Drive Pawl Assembly
MXT-.7-63
XLT-01-63
XLT-03-63
XLT-05-63
XLT-10-63
1 1 Uniswivel Assembly
MXT-001ACL
MXT-001ACL
MXT-003ACL
MXT-003ACL
MXT-010ACL
Model 1 & 3 refer to the 1st letter of serial # to determine A or D style
MXT-001CL
MXT-001CL
MXT-003CL
MXT-003CL
MXT-010ACL
001A 1 Male Coupler (comes with nipple)
090155-1/8
090155-1/8
090155-1/4
090155-1/4
090155-1/4
001B 1 Female Coupler
090156-1
090156-1
90156
90156
90156
001C 1 Uniswivel Seal Kit
MXT-001-00
MXT-001-00
MXT-003-00
MXT-003-00
MXT-010-00
1 Housing Seal Kit
MXT-.7-62
MXT-01-62
MXT-03-62
MXT-05-62
MXT-10-62
1 Maintenance Kit
MK-HY-.7MXT
MK-HY-1MXT
MK-HY-3MXT
MK -HY-5MXT
MK-HY-10MXT
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 15
ITEM
QTY.
DESCRIPTION
MXT-15
MXT-20
MXT-35
1 1 Housing (with end cap, shroud, access plug and seal kit)
MXT-15-01
MXT-20-01
MXT-35-01
3 1 Rear Reaction Arm Assembly
MXT-15-03
MXT-20-03
MXT-35-03
4 2 Drive Plate Universal
MXT-15-04
XLT-20-04
MXT-35-04
5 1 Sq Drive Assembly
MXT-15-05
XLT-20-05
MXT-35-05
6 1 Ratchet
MXT-15-06
XLT-20-06
MXT-35-06
7 2 Sq Drive Bushing
MXT-15-07
XLT-20-07
MXT-35-07
8 2 Drive Sleeve Spline
MXT-15-08
XLT-20-08
MXT-35-08
10 1 Reaction Pawl Assembly
MXT-15-10
MXT-20-20
MXT-35-35
11 1 Drive Retainer Assembly
MXT-15-11
XLT-20-11
MXT-35-11
13 1 Drive Plate Roll Pin
MXT-15-13
XLT-20-13
MXT-35-13
14 1 Left and Right Lever Assembly
MXT-15-14
MXT-20-14
MXT-35-14
18 1 Reaction Pawl Spring
MXT-15-18
MXT-20-18
MXT-35-18
19 1 Rod End Pin
MXT-15-19
XLT-20-19
MXT-35-19
26 1 End Cap
MXT-15-26
MXT-20-26
MXT-35-26
27 2 Drive Pawl Spring
MXT-15-27
XLT-20-27
MXT-35-27
28 1 Reaction Arm Lever Assembly
MXT-15-28
MXT-20-28
MXT-35-28
30 2 Drive Sleeve Retaining Ring
MXT-15-30
XLT-20-30
MXT-35-30
31 1 Shroud
MXT-15-31
MXT-20-31
MXT-35-31
32 2 Shroud Screw
MXT-15-32
XLT-20-32
MXT-35-32
33 1 Drive Pawl Spring Secondary
n/a
XLT-20-33
MXT-35-33
34 1 Reaction Arm Thrust Plate
MXT-15-367
MXT-20-367
MXT-35-367
37 2 Thrust Plate Screw
MXT-15-503
MXT-20-503
MXT-35-503
39 1 Catch Lever, Reaction Arm
MXT-10-328
MXT-20-328
MXT-35-328
38 1 Reaction Arm Lever Spring
MXT-10-508
MXT-20-508
MXT-35-508
40 1 Roll Pin Drive Pawl Primary
MXT-15-40
XLT-20-40
MXT-35-40
41 1 Roll Pin Drive Pawl Secondary
MXT-15-41
XLT-20-41
MXT-35-41
42 1 Roll Pin Reaction Pawl
MXT-15-42
XLT-20-42
MXT-35-42
43 1 Reactin Arm Boot
MXT-10-43
XLT-20-43
MXT-35-43
44 2 Reaction Arm Boot Pin
MXT-15-44
MXT-20-44
MXT-35-44
45 1 Reaction Arm Lever Pin
MXT-15-509
MXT-20-509
MXT-35-509
46 1 Serial Plate Right/Left Set
MXT-15-46
MXT-20-46
MXT-35-46
48 2 Access Plug (with 0 ring)
MXT-15-02
MXT-20-02
MXT-35-02
58 1 Shroud Spring Screw
MXT-15-58
XLT-20-58
MXT-35-58
59 1 Shroud Spring
MXT-15-59
XLT-20-59
MXT-35-59
61 1 Piston Assembly
MXT-15-61
XLT-20-61
MXT-35-61
63 1 Drive Pawl Assembly
MXT-15-63
XLT-20-63
MXT-35-63
1 1 Uniswivel Assembly
MXT-010ACL
MXT-010ACL
MXT-010ACL
Model 1 & 3 refer to the 1st letter of serial # to determine A or D style
MXT-010ACL
MXT-010ACL
MXT-010ACL
001A 1 Male Coupler (comes with nipple)
090155-1/4
090155-1/4
090155-1/4
001B 1 Female Coupler
90156
90156
90156
001C 1 Uniswivel Seal Kit
MXT-010-00
MXT-010-00
MXT-010-00
1 Housing Seal Kit
MXT-15-62
MXT-20-62
MXT-35-62
1 Maintenance Kit
MK-HY-15MXT
MK-HY-20MXT
MK-HY-35MXT
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 16
12. PART LIST XLT SERIES
FOR MORE INFORMATION
HYTORC Nederland BV | Platinawerf 8 - 6641 TL Beuningen - NEDERLAND | Tel: +31(0)24 - 3 660 660 | www.hytorc.nl
HYTORC Benelux BVBA | Ysselaarlaan 65B - 2630 Aartselaar - BELGIË | Tel : +32(0)38 - 705 220 | www.hytorc-benelux.be
ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 17
ID
Spare parts description
HY-.5XLT
HY-1XLT
HY-3XLT
HY-5XLT
HY-8XLT
HY-10XLT
HY-20XLT
HY-25XLT
1*
Housing Complete
XLT-.5-01-
XLT-01-01-E
XLT-03-01-E
XLT-05-01-E
XLT-08-01-
XLT-10-01-E
XLT-20-01-E
XLT-25-01-E
3
Reaction Arm
XLT-.5-03
XLT-01-03
XLT-03-03
XLT-05-03
XLT-08-03
XLT-10-03
XLT-20-03
XLT-25-03
4
Drive Plate Universal
XLT-.5-04
XLT-01-04
XLT-03-04
XLT-05-04
XLT-08-04
XLT-10-04
XLT-20-04
XLT-25-04 5 Square Drive Square Through
XLT-.5-05-A
XLT-01-05-A
XLT-03-05-A
XLT-05-05A
XLT-08-05-A
XLT-10-05-A
XLT-20-05-A
XLT-25-05A 5 Square Drive Spline
XLT-.5-05-1
XLT-01-05-1
XLT-03-05-1
XLT-05-05-1
XLT-08-05-1
XLT-10-05-1
XLT-20-05-1
XLT-25-05-1 6 Ratchet Square
XLT-.5-06-A
XLT-01-06-A
XLT-03-06-A
XLT-05-06-A
XLT-08-06-A
XLT-10-06-A
XLT-20-06-A
XLT-25-06-A 6 Ratchet Spline
XLT-.5-06-1
XLT-01-06-1
XLT-03-06-1
XLT-05-06-1
XLT-08-06-1
XLT-10-06-1
XLT-20-06-1
XLT-25-06-1
7
Drive Bushing for Steel Sleeve
XLT-.5-07-0
XLT-01-07-0
XLT-03-07-0
XLT-05-07-0
XLT-08-07-0
XLT-10-07-0
XLT-20-07-0
XLT-25-07-0
7
Drive Bushing for A/B Sleeve
XLT-.5-07-1
XLT-01-07-1
XLT-03-07-1
XLT-05-07-1
XLT-08-07-1
XLT-10-07-1
XLT-20-07-1
XLT-25-07-1 8 Drive Sleeve Round steel
XLT-.5-08-0
XLT-01-08-0
XLT-03-08-0
XLT-05-08-0
XLT-08-08-0
XLT-10-08-0
XLT-20-08-0
XLT-25-08-0
8
Drive Sleeve Square BR/ALU
XLT-.5-08-A
XLT-01-08-A
XLT-03-08-A
XLT-05-08-A
XLT-08-08-A
XLT-10-08-A
XLT-20-08-A
XLT-25-08-A
8
Drive Sleeve Spline BR/ALU
XLT-.5-08-1
XLT-01-08-1
XLT-03-08-1
XLT-05-08-1
XLT-08-08-1
XLT-10-08-1
XLT-20-08-1
XLT-25-08-1
10
Reaction Pawl
XLT-.5-10
XLT-01-10
XLT-03-10
XLT-05-10
XLT-08-10
XLT-10-10
XLT-20-10
XLT-25-10
11
Drive Retainer
XLT-.5-11
XLT-01-11
XLT-03-11
XLT-05-11
XLT-08-11
XLT-10-11
XLT-20-11
XLT-25-11
13
Drive Plate Roll Pin
XLT-.5-13
XLT-01-13
XLT-03-13
XLT-05-13
XLT-08-13
XLT-10-13
XLT-20-13
XLT-25-13
15
Lever
XLT-.5-15
XLT-01-15
XLT-03-15
XLT-05-15
XLT-08-15
XLT-10-15
XLT-20-15
XLT-25-15
17
Piston Connector Rod
XLT-.5-17
XLT-01-17
XLT-03-17
XLT-05-17
XLT-08-17
XLT-10-17
XLT-20-17
XLT-25-17
18
Reaction Pawl Spring
XLT-.5-18
XLT-01-18
XLT-03-18
XLT-05-18
XLT-08-18
XLT-10-18
XLT-20-18
XLT-25-18
19
Rod Spring
XLT-.5-19
XLT-01-19
XLT-03-19
XLT-05-19
XLT-08-19
XLT-10-19
XLT-20-19
XLT-25-19
20
Drive Sleeve O-Ring
XLT-.5-20
XLT-01-20
XLT-03-20
XLT-05-20
XLT-08-20
XLT-10-20
XLT-20-20
XLT-25-20
24
Piston Sleeve
XLT-.5-24
XLT-01-24
XLT-03-24
XLT-05-24
XLT-08-24
XLT-10-24
XLT-20-24
XLT-25-24
25
Piston with Seals
XLT-.5-25
XLT-01-25
XLT-03-25
XLT-05-25
XLT-08-25
XLT-10-25
XLT-20-25
XLT-25-25
26
End Cap with Screws
XLT-.5-26-1
XLT-01-26-1
XLT-03-26-1
XLT-05-26-1
XLT-08-26-1
XLT-10-26-1
XLT-20-26-1
XLT-25-26-1
26
End Cap used with E style housing
only
XLT-.5-26-E
XLT-01-26-E
XLT-03-26-E
XLT-05-26-E
XLT-08-26-E
XLT-10-26-E
XLT-20-26-E
XLT-25-26-E
27
Drive Pawl Spring (2)
XLT-.5-27
XLT-01-27
XLT-03-27
XLT-05-27
XLT-08-27
XLT-10-27
XLT-20-27
XLT-25-27
28
Reaction Arm Clamp
XLT-.5-28
XLT-01-28
XLT-03-28
XLT-05-28
XLT-08-28
XLT-10-28
XLT-20-28
XLT-25-28
29
Piston Rod
XLT-.5-29
XLT-01-29
XLT-03-29
XLT-05-29
XLT-08-29
XLT-10-29
XLT-20-29
XLT-25-29
30
Retainer Ring
XLT-.5-30
XLT-01-30
XLT-03-30
XLT-05-30
XLT-08-30
XLT-10-30
XLT-20-30
XLT-25-30
31-0
Shroud, 4-Screw Type
XLT-.5-31-0
XLT-01-31-0
XLT-03-31-0
XLT-05-31-0
XLT-08-31-0
XLT-10-31-0
XLT-20-31-0
XLT-25-31-0
40574
Shroud, Spring Type
XLT-.5-31-1
XLT-01-31-1
XLT-03-31-1
XLT-05-31-
XLT-08-31-1
XLT-10-31-1
XLT-20-31-1
XLT-25-31-
32
Screw, Shroud
XLT-.5-32
XLT-01-32
XLT-03-32
XLT-05-32
XLT-08-32
XLT-10-32
XLT-20-32
XLT-25-32
33
Spring, Secondary Drive Pawl
XLT-.5-33
XLT-01-33
XLT-03-33
XLT-05-33
XLT-08-33
XLT-10-33
XLT-20-33
XLT-25-33
34
Screws, End Cap
XLT-.5-34
XLT-01-34
XLT-03-34
XLT-05-34
XLT-08-34
XLT-10-34
XLT-20-34
XLT-25-34
37
Screw, RA Clamp
XLT-.5-37
XLT-01-37
XLT-03-37
XLT-05-37
XLT-08-37
XLT-10-37
XLT-20-37
XLT-25-37
38
Spring, RA Clamp
XLT-.5-38
XLT-01-38
XLT-03-38
XLT-05-38
XLT-08-38
XLT-10-38
XLT-20-38
XLT-25-38
39
Lever screw
XLT-.5-39
XLT-01-39
XLT-03-39
XLT-05-39
XLT-08-39
XLT-10-39
XLT-20-39
XLT-25-39
40
Roll Pin, Primary DP/ reaction Pawl
XLT-.5-40
XLT-01-40
XLT-03-40
XLT-05-40
XLT-08-40
XLT-10-40
XLT-20-40
XLT-25-40
41
Roll Pin, Secondary Drive Pawl
XLT-.5-41
XLT-01-41
XLT-03-41
XLT-05-41
XLT-08-41
XLT-10-41
XLT-20-41
XLT-25-41
42
Roll Pin, Reaction Pawl
XLT-.5-42
XLT-01-42
XLT-03-42
XLT-05-42
XLT-08-42
XLT-10-42
XLT-20-42
XLT-25-42
43
Reaction Arm Boot with Screws
XLT-.5-43
XLT-01-43
XLT-03-43
XLT-05-43
XLT-08-43
XLT-10-43
XLT-20-43
XLT-25-43
44
Boot Screw
XLT-.5-44
XLT-01-44
XLT-03-44
XLT-05-44
XLT-08-44
XLT-10-44
XLT-20-44
XLT-25-44
45
Screw, End Cap Jacking
XLT-.5-45
XLT-01-45
XLT-03-45
XLT-05-45
XLT-08-45
XLT-10-45
XLT-20-45
XLT-25-45
58
Screw, Shroud Spring
XLT-.5-58
XLT-01-58
XLT-03-58
XLT-05-58
XLT-08-58
XLT-10-58
XLT-20-58
XLT-25-58
59
Shroud Sping
XLT-.5-59
XLT-01-59
XLT-01-59
XLT-01-59
XLT-08-59
XLT-10-59
XLT-20-59
XLT-25-59
61**
Piston Rod Assembly
XLT-.5-61
XLT-01-61
XLT-03-61
XLT-05-61
XLT-08-61
XLT-10-61
XLT-20-61
XLT-25-61
62**
Seal Kit Universal
XLT-.5-62
XLT-01-62
XLT-03-62
XLT-05-62
XLT-08-62
XLT-10-62
XLT-20-62
XLT-25-62
#,++63
Drive Pawl Assembly Kit
XLT-.5-63
XLT-01-63
XLT-03-63
XLT-05-63
XLT-08-63
XLT-10-63
XLT-20-63
XLT-25-63
#64
Roll Pin Kit (All roll pins)
XLT-.5-64
XLT-01-64
XLT-03-64
XLT-05-64
XLT-08-64
XLT-10-64
XLT-20-64
XLT-25-64
#00
Uniswivel Assembly
XLT-001
XLT-001
XLT-003
XLT-003
XLT-001
XLT-001
XLT-003
XLT-003
#00
Uniswivel Seal Kit
XLT-01-00
XLT-01-00
XLT -001-00
XLT -001-00
XLT-01-00
XLT-01-00
XLT -001-00
XLT -001-00
* E Serie Housing Includes 01-E, 07-1, 26-E and 31-1
** Piston Rod Assembly Includes 24, 25, and 29
++ Drive Pawl Assembly Kit includes 17 and 19
# Available only as an assembly
Loading...
