Hypertherm HT2000LHF User Manual

Plasma Arc Cutting System

Product Configuration Manual 803050 – Revision 3

HySpeed HT2000LHF

Product Configuration Manual

(P/N 803050)

Revision 3 – March, 2003

Hypertherm, HT, LongLife, and HySpeed are trademarks of Hypertherm, Inc.

and may be registered in the United States and/or other countries

Hypertherm, Inc.

Hanover, NH USA

www.hypertherm.com

Hypertherm, Inc.

Etna Road, P.O. Box 5010

Hanover, NH 03755 USA

603-643-34 41 Tel (Main Office)

603-643-5352 Fax (All D epartments)

800-643-9 878 Tel (Technical Service)

800-737-2978 Tel (Customer Service)

Hypertherm Automation, LLC

5 Technology Drive

West Lebanon, NH 03755 USA

603-298-7970 Tel

603-298-7977 Fax

Hypertherm Plasmatechnik, GmbH

Technologiepark Hanau

Rodenbacher Chaussee 6

63457 Hanau-Wolfgang, Deutschland

49 6181 58 2100 Tel

49 6181 58 2134 Fax

49 6181 58 2123 (Technical Service)

Hypertherm (S) Pte Ltd

No. 19 Kaki Bukit Road 2

K.B. Warehouse Complex

Singapore 417847, Republic of Singapore

65 6 841 2489 Tel

65 6 841 2490 Fax

65 6 841 24 89 (Technical Service)

Japan

1952-14 Yata-Natsumegi

Mishima City, Shizuoka Pref.

411-0801 Japan

81 0 559 75 7387 Tel

81 0 559 75 7376 Fax

Hypertherm UK , Ltd

9 Berkeley Court, Manor Park

Runcorn, Cheshire, England WA7 1TQ

44 1928 579 074 Tel

44 1928 579 604 Fax

France

15 Impasse des Rosiers

95610 Eragny, France

00 800 3324 9737 Tel

00 800 4973 7329 Fax

Hypertherm S.r.l.

Via Torino 2

20123 Milano, Italia

39 02 725 46 312 Tel

39 02 725 46 400 Fax

39 02 725 46 314 (Technical Service)

Hypertherm Europe B.V.

Vaartveld 9

4704 SE Roosendaal, Nederland

31 165 596908 Tel

31 165 59 6901 Fax

Technical Service:

00 800 49 73 7843 – toll-free in Europe

31 165 59 6900 Tel

Hypertherm Brasil Ltda.

Rua Visconde de Santa Isabel, 20 – Sala 611

Vila Isabel, RJ

Brasil CEP 205 60-1 20

55 21 2278 6162 Tel

55 21 2578 0947 Fax

3/27/03

TABLE OF CONTENTS

HySpeed HT2000LHF Product Configuration Manual i

Section 1 SPECIFICATIONS................................................................................................................................1-1

System Components ................................................................................................................................................1-1

LHF Power Supply...........................................................................................................................................1-1

LHF Machine Torch..........................................................................................................................................1-1

LHF Gas Console.............................................................................................................................................1-1

Argon-Hydrogen Manifold – Optional...............................................................................................................1-1

Digital Remote Voltage & Current Control Console.........................................................................................1-1

Programmable Remote Voltage & Current Control Console............................................................................1-1

Remote Current Control Console.....................................................................................................................1-1

Initial Height Sensing – Optional......................................................................................................................1-2

Timer/Counter – Optional.................................................................................................................................1-2

Water Muffler – Optional..................................................................................................................................1-2

CommandTHC – Optional................................................................................................................................1-2

Specifications............................................................................................................................................................1-2

System Requirements......................................................................................................................................1-2

LHF Power Supply...........................................................................................................................................1-3

LHF Machine Torch..........................................................................................................................................1-3

LHF Gas Console.............................................................................................................................................1-4

Argon-Hydrogen Manifold – Optional...............................................................................................................1-4

Digital Remote Voltage & Current Control Console.........................................................................................1-5

Programmable Remote Voltage & Current Control Console............................................................................1-5

Remote Current Control Console.....................................................................................................................1-5

Initial Height Sensing – Optional......................................................................................................................1-6

Timer/Counter – Optional.................................................................................................................................1-6

Water Muffler – Optional..................................................................................................................................1-6

CommandTHC – Optional................................................................................................................................1-6

Section 2 ORDERING PROCEDURE ..................................................................................................................2-1

TABLE OF CONTENTS

ii HySpeed HT2000LHF Product Configuration Manual

HySpeed HT2000LHF Product Configuration Manual 1-1

Section 1

SPECIFICATIONS

System Components

LHF Power Supply

The LHF power supply houses two 100-amp, 15 kHz choppers, the torch’s high-frequency starting circuit and an optional internal Torch Height Control (THC).

LHF Machine Torch

The LHF machine torch is liquid-cooled and capable of cutting most metals from gauge to 2-inch (50 mm) thickness and from gauge to 1-inch (25 mm) thickness for production cutting. To achieve consumable long life, all cuts

must begin and end on the plate surface.

LHF Gas Console

This unit houses metering and solenoid valves for shield and plasma gases, flow meters, pressure gauges for plasma gases, and a pressure gauge for the shield gas supply.

Argon-Hydrogen Manifold – Optional

This unit houses a flowmeter for argon-hydrogen, a metering valve, a plasma gas outlet switch and a plasma-off valve.

Digital Remote Voltage & Current Control Console

This unit includes LED displays that indicate the setpoints for volts and amperes prior to starting the arc. The displays then automatically display the actual values of the voltage and current while cutting. The digital remote has potentiometers to set and adjust the voltage and current.

Programmable Remote Voltage & Current Control Console

This unit includes LED displays that indicate the setpoints for volts and amperes prior to starting the arc. The displays then automatically display the actual values of the voltage and current while cutting. The programmable remote functions are controlled by the CNC.

Remote Current Control Console

This unit contains a manually adjustable thumbwheel to set arc current only.

SPECIFICATIONS

1-2 HySpeed HT2000LHF Product Configuration Manual

Specifications

System Requirements

Power Requirements:

Refer to power supply specifications below:

Gas Requirements:

Plasma Gas Types...............................................Oxygen, Nitrogen, Air,

Argon-Hydrogen (H35 = 35% Hydrogen/ 65% Argon)

Shield Gas Types.................................................Air, Nitrogen, Carbon Dioxide

Gas Quality:

Oxygen.................................................................99.5% pure (liquid gas recommended)

Nitrogen................................................................99.995% pure (liquid gas recommended)

Air.........................................................................Clean, dry, oil-free (compressed or liquid gas

recommended)

Carbon Dioxide ....................................................99.5% pure (compressed or liquid gas recommended)

Plasma Gas Inlet Pressures and Flow Rates:

Air............................................................................90 psi +/- 10 psi (6.2 bar +/- 0.7 bar) at 82 scfh (2322 l/h)

Oxygen....................................................................120 psi +/- 10 psi (8.3 bar +/- 0.7 bar) at 90 scfh (2549 l/h)

Nitrogen...................................................................120 psi +/- 10 psi (8.3 bar +/- 0.7 bar) at 80 scfh (2265 l/h)

Argon-Hydrogen......................................................120 psi +/- 10 psi (8.3 bar +/- 0.7 bar) at 105 scfh (2973 l/h)

Shield Gas Inlet Pressures and Flow Rates:

Air.........................................................................90 psi +/- 10 psi (6.2 bar +/- 0.7 bar) at 280 scfh (7929 l/h)

Carbon Dioxide ....................................................90 psi +/- 10 psi (6.2 bar +/- 0.7 bar) at 220 scfh (6230 l/h)

Nitrogen................................................................90 psi +/- 10 psi (6.2 bar +/- 0.7 bar) at 275 scfh (7787 l/h)

Initial Height Sensing – Optional

This unit, used with 2 inductive probes, is designed to automatically detect the workpiece surface and move the torch to the pierce position. This system can be used for underwater cutting, cutting at the water line, or cutting above water.

Timer/Counter – Optional

The timer/counter allows the operator to monitor the number of arc starts and the cumulative time that the arc is on in hours. The arc starts can be reset.

Water Muffler – Optional

The water muffler for the LHF system is an option which greatly improves cutting safety and pollution control capabilities. The water muffler can be used to cut above, below and at the water line. Refer to the Water Muffler instruction manual 802050 for more detailed information. The water muffler cannot be used with the stainless steel torch.

CommandTHC – Optional

The CommandTHC is an external torch height control and initial height sensing system designed for plasma cutting applications on an x-y cutting table. Refer to the CommandTHC instruction manual 802780 for more detailed information. Refer to the CommandTHC Product Configuration Manual 802600 to order a CommandTHC system.
