CardBus 10/100 TX M56
HYNEP61056
USER GUIDE
Information in this document is subject to change without notice. All
rights reserved. All brand names are registered trademarks of their
respective companies.
standards. Records maintained by Hypertec continue to reflect that units being produced
under this Declaration of Conformity, within the variation that can be expected due to
quantity production and tested on a statistical basis, continue to comply with the applicable
technical standards.
The CardBus Modem 56k Card complies with Part 68 of the FCC rules.
FCC rules permit this device to be directly connected to the telephone network,
using a standardised jack.
Do not use this equipment on a party line or coin line.
Malfunctioning equipment may damage the telephone network. If this device is
not functioning properly, disconnect it until the problem has been determined and
the device has been repaired. Otherwise, the telephone
company may temporarily disconnect service.
CardBus 56k Modem repair can only be performed by Hypertec. It is the
responsibility of the user to report the need for any service of the device to
Hypertec or to one of our authorised agents.
If you encounter any problems with your telephone after installing any new
device, disconnect it from the telephone line to see if the device is the source of
the problem.
The telephone company may change its technical operations and procedures. If
such changes affect the compatibility or use of the device, the telephone company
is required to provide adequate notice of the changes.
European Community (EC) Electromagnetic Compatibility
Directive.
This equipment has been tested and found to comply with the protections requirements of
European Emission Standard EN55022 and the Generic European Immunity Standard
EN50082-1. This equipment is designed to operate in a domestic environment and as such
is tested to the EN55022 ITE domestic emissions limit. The domestic immunity standard
EN50082-1 calls for the following basic standards:
(a) IEC 801-2 Electrostatic Discharge
(b) IEC 801-3 RF Immunity
(c) IEC 801-4 Transient Burst
What to do if interference occurs
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of Subpart B of the FCC Rules. These limits provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own expense.
There is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
RE-orient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Relocate the CardBus 56k Modem away from the receiving antenna and / or
equipment.
Plug the CardBus 56k modem into a different outlet so that the CardBus 56k
Modem and the receiving equipment are on different electrical circuits.
If none of these actions resolve the problem, consult your distributor or an experienced
radio / television technician for additional suggestions.
Repeat Calling
The host computer software must not initiate repeat call attempts within intervals shorter
than thirty (30) seconds. The user should ensure that the software is set correctly.
©1998 Hypertec, Ltd. All rights reserved.
PC Card standard compatibility and Plug and Play features are assured with full support of
all major operating systems. Compatibility with all major Network Operating Systems is
guaranteed by Silicom’s wide range of thoroughly tested NOS drivers. The Data/Fax
Modem is installed as a COM port and runs an extended AT command set, enabling it to
work with all major Fax/Modem software.
The video-ready interface supplied by the CardBus 10/100 TX M56 provides
videoconferencing capability using traditional POTS lines.
The Hypertec CardBus 10/100 TX M56 Card is compliant with the OnNow Network
Device Class Power Management Specification, the PCI Power Management Interface, and
the ACPI Specification. The Hypertec CardBus 10/100 TX M56 Card supports all PC 97
Design Guide and the PC 98 Draft Design Guide network device class requirements.
56Kbps Technology
The Hypertec CardBus 10/100 TX M56 Card uses K56flex× and V.90 modem
technologies to reach speeds of up to 56Kbps over standard phone lines. This, together
with downstream speeds of up to 56Kbps provided by the
user’s Internet Service Provider (ISP) results in dramatically faster delivery of Internet
information.
The higher speeds are achieved by using only one digital-to-analog line conversion in the
connection between the user and the Internet Service Provider. This requires the ISP to
have a direct digital connection, and the modems at both ends must be compatible. Using
V.90 and K56flex× technologies, data is downloaded from the server at speeds of up to
56Kbps, while data sent upstream by the user travels at the standard V.34 maximum rate of
33.6Kbps.
• Automatic sensing and switching between 10 Mbps or 100 Mbps
operation
• Full Duplex. Independent receive and transmit circuits allow full duplex
operation at both 10 Mbps and 100 Mbps, allows for maximum throughput of 200
Mbps
•
A single RJ-45 female connector supports both 10 Mbps and 100 Mbps
operation
• Platform independent. Supports all type II CardBus PC Card
compliant PCs
• Easy installation and configuration
• Wide Network Operating Systems support (Including Windows 98,
Windows 95, Windows NT, Novell NetWare and more)
• Problem-free upgrade from 10 Mbps to 100 Mbps networks
• Simultaneous Data/Fax Modem and Ethernet / Fast Ethernet LAN
operation
• Compliant with Advanced Configuration and Power Interface ACPI
• Supports modem speeds of up to 56Kbps
• International country support - Certified and approved for use
in many countries
• Supports V.90, K56flex*, V.34, V.32 terbo, V.32bis, V.22bis, V.22A/B,
V.23, V.21, Bell 212A and 103J data transmission
•
Video-ready modem interface (VRM) V.80.
• Flash software upgradeable to future ITU 56K standards
•
Supports CCITT V.17, V.29, V.27ter and V.21 ch 2 send and receive
fax transmission (Class 1 & 2)
• Increased modem throughput with V.42bis and MNP5 data compression
• Error detection and correction using V.42 LAPM and MNP 2-4 protocol
• Fax/Modem installed as a COM port, runs extended AT command set
•
Automatic Modem sleep mode for longer PC battery life
• 16550 UART
• Card and Socket Services support
•
Direct Enablers to reduce memory requirements included
•
Advanced Wizard Utility for easy, straightforward installation
Static Electricity Warning
Static electricity is accumulated naturally in the human body, and can be discharged
through electrical components by touching them. This shock can potentially cause
permanent internal damage to the component.
When installing the adapter, please observe the following precautions:
Discharge yourself before commencing by touching a grounded metal appliance, such as
the metal frame of a computer - while it is tuned off, but still plugged into the wall socket.
Hold the adapter or any other boards by their edges only. Never touch any exposed pins on
the adapter.
If possible, install the adapter as soon as you remove it from its anti-static bag, without
putting it down. If you must put it down, place it on the anti-static bag in which it was
packed.
Do not place the adapter on any metal surface.
Installation Procedures
To install the WMPC56 PC Card follow the instructions on the Online User Guide. To do
so, install the Online User Guide.
1. Start Windows.
2. Insert the WMPC56 distribution diskette into the PC diskette drive.
3. From the TaskBar click Start and then click Run
4. Type A:\SETUP and click OK.
5. Follow the Help utility’s on-screen instructions for the setup process.
The Drivers for the card come on a single disc, and for Windows 95 there are two different
drivers available. For users of WIN95B (Osr2) then use the drivers in A:\WIN95b
otherwise use the drivers in WIN95a.
SPECIFICATIONS
Interface Standards:
32-bit CardBus PC Card, 3.3V
PC Card Software Support:
Card and Socket Services
Direct Enablers
Weight:
92 gr., 3.3 oz (including the media unit)
PC Card Size:
Length – 3.37" (85 mm)
Width - 2.13" (54 mm)
Thickness - 0.197" (5 mm)
Power Consumption:
100BaseTx + Modem active – 450mA @ 3.3V (1.49W)
100BaseTx + Modem sleep – 290mA @ 3.3V (0.96W)
10BaseT + Modem active – 400mA @ 3.3V (1.32W)
10BaseT + Modem sleep – 250mA @ 3.3V (0.83W)
Operating Temperature:
0!-50!C
Operating Humidity:
0% - 90% non-condensing
Certifications:
FCC Part 15, Subpart B class B
FCC Part 68
CE
Various European PTT's
Fax Rates:
CCITT V.17 (14,400 bps)
CCITT V.29 (9,600 bps)
CCITT V.27ter (4,800 bps)
CCITT V.21 channel 2 (300 bps)
Video-ready modem interface (VRM):
CCITT V.80
Data Compression:
CCITT V.42bis (up to 4:1 compression ratio)
MNP5 (up to 2:1 compression ratio)
Error Correction:
CCITT V.42 LAPM
MNP 2-4
16550 UART:
Enhanced UART interface provides buffering of data. This feature is essential in providing
reliable high speed communication, when used in multitasking environments such as
Windows or OS/2.
Data Command Set:
Fully AT command compatible
Fax Command Set:
CCITT Group 3
Class 1 (EIA-578)
Class 2 (EIA-592)
Diagnostics:
Power-on self test
Communication Software:
Runs all popular software (including remote LAN access)
Connector:
RJ-11C, female
NDIS3 MiniPort driver for Windows 95
County change utility program for various countries
Ethernet Media Connections:
Unshielded RJ-45 female connector
Product Warranty
Hypertec Limited warrants the hardware components of the product to be in good working
order for the life of the product from the date of purchase of the product from Hypertec or
an authorised Hypertec dealer. Should the hardware components of the product fail to be in
good working order at any time, Hypertec will, at its option, repair or replace the product.
Repair parts and replacement products will be furnished on an exchange basis, and will be
either reconditioned or new. All replaced parts will become the property of Hypertec.
This warranty applies only to the original registered end user purchaser of the product and
does not include service to repair damage resulting from accident, disaster, misuse, abuse
or non-Hypertec modification of the product.
Additional components installed by the dealer or end user are not covered by this warranty.
Apart from the above, no warranty is expressed or implied, including warranty of
merchantability or warranty of fitness for use for a particular purpose.
The liability of Hypertec is limited to the repair or replacement of the product with a
functionally equivalent or better product. Hypertec is not liable for any accidental, general,
special, exemplary or consequential damages resulting from any product failure, even if
Hypertec has been advised of the possibility of such damages.
Hypertec Limited
Units 1-3 Station Road
Hungerford, Berkshire RG17 0DY
Ph: +44 (0)1488 686844
Fax: +44 (0)1488 686845
Web: www.hypertec.co.uk
Email: sales@hypertec.co.uk
