4-BIT SINGLE CHIP MICROCOMPUTERS

GMS340 SERIES

USER`S MANUAL

• GMS34004

• GMS34012

• GMS34112

• GMS34120

• GMS34140

• GMS30000 EVA

JUNE. 2001 Rev. 3.0

INTRODUCTION

We hereby introduce the manual for CMOS 4-bit microcomputer GMS340 Series. This manual is prepared for the users who should understand fully the functions and features of GMS340 Series so that you can utilize this product to its fullest capacity. A detailed explanations of the specifications and applications regarding the hardware is hereby provided.

The contents of this user`s manual are subject to change for the reasons of later improvement of the features. The information, diag ram s, a nd other data in this user`s manual are correct and reliable; however, HYNIX Semicond uctor Inc. is in no way res ponsible for any violations of patents or other rights of the third party generated by the use of this manual

Table of Contents

Table of Conten ts

Chapter 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Outline of Characteristics . . . . . . . . . . . . . . . . . . . . . 1-1

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Pin Assignment and Dimension . . . . . . . . . . . . . . . . . . . . 1-3

I/O circuit types and options . . . . . . . . . . . . . . . . . . . . . . . 1-7

Electrical Characteristics of GMS300 Series . . . . . . . . . . 1-10

Chapter 2

Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . .. . .. . . 2-1

Program Memory (ROM). . . . . . . . . . . . . . . . . . . . . . . . . 2-1

ROM Address Register . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Data Me m o ry (RAM) . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

X-Register (X) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Y-Register (Y) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Accumulator (Acc) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

State Counter (SC) . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 2-5

Clock Ge nerato r . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Pulse Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Initial Reset Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Internal Power On Reset . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Watch Dog Timer (WDT) . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Stop Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Maske d Op tions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Chapter 3

Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Instruction format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Instruction Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Details of Instruction System . . . . . . . . . . . . . . . . . . . . 3-5

Detailed Description . . . . . . . . . . . . . . . . . . . . . . . 3-6

Table of Contents

Chapter 4

Evaluation Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Product Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Optional Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Caution of Operation . . . . . . . . . . . . . . . . . . . . . .. . . . . 4-6

Chapter 5

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Configuration of Assembler . . . . . . . . . . . . . . . . . . . . . . 5-1

Booting up Assembler . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Configuration of Simulator . . . . . . . . . . . . . . . . . . . . . . . 5-2

Booting up Simulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Simulator commands . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15

Description of commands . . . . . . . . . . . . . . . . . . . . . . . . 5-18

File typ es used in th e simulato r . . . . . . . . . . . . . . . . . . . 5-48

Error message and troubleshooting . . . . . . . . . . . . . . . . 5-49

Appendix

Mask option list

INTRODUCTION 1

ARCHITECTURE 2

INSTRUCTION 3

EVALUATION BOARD 4

SOFTWARE 5

APPENDIX 6

1 - 1

CHAPTER 1. Introduction

OUTLINE OF CHARACTERISTICS

The GMS340 series are remote contol transmitter which uses CMOS technology. This enables transmission code outputs of different configurations, multiple custom code output, and double push key output for easy fabrication. The GMS340 sereis are suitable for remote control of TV, VCR, FANS, Airconditioners, Audio Equipments, Toys and Games etc.

Characteristics

¡Ü Program memory : 512 bytes for GMS34004/012

1024 bytes for GMS34112/120/140

¡Ü Data memory : 32

¡¿

4 bits

¡Ü 43 types of instruction set ¡Ü 3 levels of subroutine nesting ¡Ü 1 bit output port for a large current (REMOUT signal) ¡Ü Operating frequency : 300~500KHz or 2.4~4MHz for 300~500KHz operation

(Masked option)

¡Ü Instruction cycle : f

OSC

/6 (at 300~500KHz)

OSC

/48 (at 2.4~4MHz)

¡Ü CMOS process (Single 3.0V power supply) ¡Ü Stop mode (Through internal instruction) ¡Ü Released stop mode by key input (Masked option) ¡Ü Built in capacitor for ceramic oscillation circuit (Masked option) ¡Ü Built in a watch dog timer (WDT) ¡Ü Low operating voltage : 2.0~4.0V (at 300~500KHz)

2.2~4.0V (at 2.4~4MHz)

Series

Program memory Data memory I/O ports

Input ports

Output ports

Package

GMS34004

512

32 ¡¿ 4

4 6

D0 ~ D5

16DIP/SOP

GMS34012

¡ç ¡ç

¡ç

D0 ~ D5

20DIP/SOP

GMS34112

1024

¡ç ¡ç

¡ç

D0 ~ D5

¡ç

GMS34120

¡ç ¡ç ¡ç

¡ç

D0 ~ D7

24DIP/SOP

GMS34140

¡ç ¡ç ¡ç

¡ç

D0 ~ D9

¡ç

Table 1-1 GMS340 series members

Chapter 1. Introduction

1 - 2

Block Diagram

RAM

16word x

2page x 4bit

RAM Word

Selector

Y-Reg

ACC

R-Latch D-Latch

Pluse

Generator

X-Reg

MUX

ALU

23 22 7 8 9 4 2110 3 5 6 11 12 13 14 15 16 17 18 19 20

Instruction

Decoder

Program counter

Stack

Reset

Watchdog

timer

1 24

ROM

64word ¡¿

16page

¡¿

8bit

4 10

OSC1 OSC2 K0 ~ K3 R0 ~ R3 D0 ~ D9 REMOUT

RESET VDD GND

OSC

Fig 1-1 Block Diagram (In case of GMS34140)

Chapter 1. Introduction

Control Signal

1 - 3

Pin Assignment and terminals

Pin Assignment

2 23 3 22 4 21 5 20 6 19 7 18 8 17 9 16 10 15 11 14 12 13

1 24

VDD OSC1

OSC2 REMOUT

D7 D6 D5 D4 D3 D2 D1 NC

RESET

GND

R0 R1 R2 R3 K0 K1 K2 K3 D0

Fig 1-2 GMS34004 Pin Assignment Fig 1-3 GMS34012/112 Pin Assignment

Fig 1-5 GMS34120 Pin Assignment

Chapter 1. Introduction

2 15 3 14 4 13 5 12 6 11 7 10 8 9

1 16

VDD OSC1

OSC2 REMOUT

D5 D4 D3 D2

RESET

GND

K0 K1 K2 K3 D0 D1

2 19 3 18 4 17 5 16 6 15 7 14 8 13 9 12 10 11

1 20

R3 R2

R1 R0

GND RESET VDD OSC1 OSC2 REMOUT

K0 K1

K2 K3 D0 D1 D2 D3 D4 D5

2 23 3 22 4 21 5 20 6 19 7 18 8 17 9 16 10 15 11 14 12 13

1 24

VDD OSC1

OSC2 REMOUT

D7 D6 D5 D4 D3 D2 D1 D9

RESET

GND

R0 R1 R2 R3 K0 K1 K2 K3 D0 D8

Fig 1-6 GMS34140 Pin Assignment

1 - 4

Chapter 1. Introduction

Pin Dimension

1 2 3 4 5 6 7 8

16 15 14 13 12 11 10 9

0.785MAX

0.745MIN

0.040MAX

0.020MIN

0.065MAX

0.015MIN

0.140MAX

0.120MIN

¡æ ¡ç

0~15¡Ç

0.280MAX

0.240MIN

0.300BSC

0.014MAX

0.008MIN

Outline (Unit:Inch)

0.050MIN

0.022MAX

0.015MIN

0.100BSC

Fig 1-7 16PDIP Pin Dimension

0.125MIN

0.135MAX

0.170MAX

Outline (Unit : Inch)

0.392MAX

0.386MIN

0.050BSC

0.0200MAX

0.0098MAX

0.0040MIN

1 2 3 4 5 6 7 8

16 15 14 13 12 11 10 9

0.0688MAX

0.0600MIN

¡æ ¡ç

¡æ

¡ç

0.157MAX

0.150MIN

0.244MAX

0.035MAX

0.016MIN

0.230MIN

0 ~ 8

¡Ç

¡æ ¡ç

0.0098MAX

0.0075MIN

Fig 1-8 16SOP Pin Dimension (150Mil)

Base Plane

Seating Plane

1 - 5

1 2 3 4 5 6 7 8 9 10

20 19 18 17 16 15 14 13 12 11

0.984MAX

0.968MIN

0.065MAX

0.055MIN

0.022MAX

0.015MIN

0.1TYP

0.170MAX

0.015MIN

0.135MAX

0.125MIN

¡æ ¡ç

0~15¡Ç

0.270MAX

0.250MIN

0.3TYP

0.012MAX

0.008MIN

Outline (Unit : Inch)

Fig 1-10 20PDIP Pin Dimension

0.5118MAX

0.4961MIN

0.020MAX

0.014MIN

0.05TYP

0.0118MAX

0.004MIN

1 2 3 4 5 6 7 8 9 10

20 19 1 8 17 16 15 14 13 12 11

¡æ ¡ç

¡æ

¡ç

0.299MAX

0.292MIN

0.419MAX

0.125MAX

0.0091MIN

0.104MAX

0.093MIN

0.042MAX

0.016MIN

Outline (Unit : Inch)

0.398MIN

Fig 1-11 20SOP Pin Dimension

Chapter 1. Introduction

1 - 6

1 2 3 4 5 6 7 8 9 10 11

24 23 22 21 20 19 18 17 16 15 14

1.255MAX

1.245MIN

0.065MAX

0.055MIN

0.022MAX

0.015MIN

0.1TYP

0.170MAX

0.015MIN

0.135MAX

0.125MIN

¡æ ¡ç

0~15¡Ç

0.270MAX

0.250MIN

0.3TYP

0.012MAX

0.008MIN

Outline (Unit : Inch)

Fig 1-12 24PDIP Pin Dimension

0.618MAX

0.595MIN

0.020MAX

0.014MIN

0.05TYP

0.018MAX

0.004MIN

1 2 3 4 5 6 7 8 9 10 11 12

24 23 22 21 20 19 18 17 16 15 14

¡æ ¡ç

¡æ

¡ç

0.299MAX

0.292MIN

0.419MAX

0.125MAX

0.0091MIN

0.104MAX

0.093MIN

0.042MAX

0.016MIN

Outline (Unit : Inch)

0.396MIN

Fig 1-13 24SOP Pin Dimension

Chapter 1. Introduction

1 - 7

Pin Function

I/O circuit types and options

GMS340 series I/O port types

I/O

Connected to 2.0~4.0V power supply. Connected to 0V power supply. Used to input a manual reset. When the pin goes ¡ÈL¡È, the

D-output ports and REMOUT-output port are initialized to

¡ÈL¡È

, and ROM address is set to address 0 on page 0.

4-bit input port. Released STOP mode built in pull-up resistor by each pin as masked option. (It is released by ¡ÈL¡È input at STOP)

Each can be set and reset independently. The output is in the form of N-channel-open-drain.

4-bit I/O port. (Input mode is set only when each of them output ¡ÈH¡È.) In outputting, each can be set and reset independently(or at once.) The output is in the form of N-channel-open-drain. Pull-up resistor and STOP release mode can be respectively selected as masked option for each bit. (It is released by

¡ÈL¡È

input at STOP.)

High current output port. The output is in the form of C-MOS. The state of large current on is ¡ÈH¡È.

Oscillator input. Input to the oscillator circuit and connection point for ceramic resonator. Internal capacitors available as masked option. A feedback resistor is connected between this pin and OSC2

Connect a ceramic resonator between this pin and OSC1.

GND

RESET

K0~K3

D0~D9

R0~R3

REMOUT

OSC1

OSC2

Input

Output

I/O

Output

Input

Output

Chapter 1. Introduction

1 - 8

I/O circuit types and options

Hysteresis Input Type Built in pull-upresistor Typical 400

§Ú

(option) Built in pull-up resistor Typical 800

§Ú

Reset I

Pin I/O Note

¡æ ¡ç

Open drain output

¡ÈH¡È

output at reset

(Option) Built in MOS Tr for pull-up About 120

§Ú

R0~R3 I/O

Built in MOS Tr for pull-up About 120

§Ú

K0~K3 I

Open drain output

¡ÈL¡È

output at reset

D0~D9

¡æ ¡ç

CMOS output

¡ÈL¡È

output at reset High current source output

REMOUT O

I/O circuit

Chapter 1. Introduction

¡æ ¡ç

¡æ

¡ç

¡æ ¡ç

¡æ

1 - 9

Built in feedbackResister About 1

§Û

OSC2 O

Pin I/O Note

(Option) Built in resonance Capacitor C1/C2 = 100pF

¡¾

N% [C1/C2 are not available for MHz operation]

OSC1 I

I/O circuit

¡æ

¡ç

¡æ

¡ç

¡è ¡è

OSC2

OSC1

OSCSTB

Built in dumping-Resister [No resistor in MHz operation]

: Masked option

Chapter 1. Introduction

*. Recommendable circuit

Frequency Resonator Maker Part Name Load Capacitor Operating Voltage

455KHz

Murata CSB455E C1=C2=Open 2.0 ~ 4.0V

Kyocera KBR-455BKTL70 C1=C2=Open 2.0 ~ 4.0V

OSC1

OSC2

TDK FCR455K3 C1=C2=Open 2.0 ~ 4.0V

CSB480E C1=C2=Open 2.0 ~ 4.0V

TDK FCR480K3 C1=C2=Open 2.0 ~ 4.0V

480KHz

Murata

3.64MHz

Murata CSA3.64MG C1=C2=30pF 2.2 ~ 4.0V Murata CST3.64MGW C1=C2=Open 2.2 ~ 4.0V

TDK FCR3.64MC5 C1=C2=Open 2.2 ~ 4.0V

3.84MHz

Murata CSA3.84MG C1=C2=30pF 2.2 ~ 4.0V Murata CST3.84MGW C1=C2=Open 2.2 ~ 4.0V

TDK FCR3.84MC5 C1=C2=Open 2.2 ~ 4.0V

¡Ø

CST type is building in load capacitior

1 - 10

Parameter

Supply Voltage Power dissipation Storage temperature range

Input voltage Output voltage

Unit

¡É

V V

Electrical Characteristics for GMS300 series

Absolute maximum ratings (Ta = 25¡É)

Symbol

Tstg

OUT

Max. rating

-0.3 ~ 5.0 700

¡É

-55 ~ 125

-0.3 ~ VDD+0.3

* Thermal derating above 25¡É : 6mW per degree ¡É rise in temperature.

Parameter

Supply Voltage

Operating temperature

Unit

¡É

Recommended operation condition

Rating

2.0 ~ 4.0

2.2 ~ 4.0

-20 ~ +70

Chapter 1. Introduction

Condition

300 ~ 500KHz

2.4 ~ 4MHz

Symbol

Topr

1 - 11

Parameter

Electrical characteristics (Ta=25Î, VDD=3V)

Symbol

Limits

Unit Condition

Chapter 1. Introduction

OSC

/48 f

OSC

Input H current

RESET input L current

K, R input L current

K, R input H voltage

RESET in p ut H voltage RESET input L voltage D. R output L voltage

REMOUT output L voltage

REMOUT output H current OSC2 output L voltage

OSC2 output H voltage D, R output leak age

current Current on STOP mode Operating supply current 1

Operating supply current 2 System

clock frequency

K, R input L voltag e

OSC

DD2

DD1

STOP

OH3

OL3

OH1

OL2

IL2

IH2

IL1

IH1

IL1

IL2

OL1

2.4

300

2.1

-32

2.25

2.1

-9

-2

0.5

0.3

2.5

0.4

-23

0.15

-25

-7.5

0.15

Min. Typ. Max.

500

1.5

1.0

0.9

-17

0.4

0.75

0.9

-50

-16

0.4

MHz

KHz

OSC

=4MHz

OSC

=455KHz

At STOP mode

0=VDD

, Output off

=70uA

OH1

=0V

=1mA

VI=GND, Output off, Pull-Up resistor provided.

VI=GND

VI=V

IOL=100uA

*1 Refer to

Fig.1-14 I

OH1

vs. V

OH1

Graph

*2 I

DD1

, I

DD2

, is measured at RESET mode.

1 - 12

Chapter 1. Introduction

Fig 1-14. I

OH1

vs V

OH1

Graph (REMOUT Port)

OVW

OVR

OUW

OUR

OTW

OTR

OSW

OSR

RPR RPW SPR SPW TPR TPW UPR UPW VPR

xqjS JxK

kq j S J

xee _ TPRx

xee _ UPRx

xee _ VPRx

v _ TW

INTRODUCTION 1

ARCHITECTURE 2

INSTRUCTION 3

EVALUATION BOARD 4

SOFTWARE 5

APPENDIX 6

2 - 1

CHAPTER 2. Architecture

BLOCK DESCRIPTION

Characteristics

The GMS340 series can incorporate maximum 1024 words (64 words ¡¿ 16 pages ¡¿ 8bits) for program memory. Program counter PC (A0~A5) and page address register (A6~A9) are used to address the whole area of program memory having an instruction (8bits) to be next executed. The program memory consists of 64 words on each page, and thus each page can hold up to 64 steps of instructions. The program memory is composed as shown below.

Program counter (PC) Page address register (PA) Page buffer (PB)

6 4

(Level ¡È1¡È)

(Level ¡È2¡È)

(Level ¡È3¡È)(PRS)(SR)

Stack register

Page 0 Page 1 Page 2 Page 15

A0~A5

0 1 2 15

A6~A9

Program capacity (pages)

Fig 2-1 Configuration of Program Memory

Chapter 2. Architecture

2 - 2

ROM Address Register

The following registers are used to address the ROM.

• Page address register (PA) : Holds ROM`s page number (0~Fh) to be addressed.

• Page buffer register (PB) : Value of PB is loaded by an LPBI command when newly addressing a page. Then it is shifted into the PA when rightly executing a branch instruction (BR) and a subroutine call (CAL).

• Program counter (PC) : Available for addressing word on each page.

• Stack register (SR) : Stores returned-word address in the subroutine call mode.

(1) Page address register and page buffer register :

Address one of pages #0 to #15 in the ROM by the 4-bit binary counter. Unlike the program counter, the page address register is usually unchanged

so that the program will repeat on the same page unless a page changing command is issued. To change the page address, take two steps such as (1) writing in the page buffer what page to jump to (execution of LPBI) and (2) execution of BR or CAL, because and instruction code is of eight bits so that page and word cannot be specified at the same time. In case a return instruction (RTN) is executed within the subroutine that has been called in the other page, the page address will be changed at the same time.

(2) Program counter :

This 6-bit binary counter increments for each fetch to address a word in the currently addressed page having an instruction to be next executed. For easier programming, at turning on the power, the program counter is reset to the zero location. The PA is also set to ¡È0¡È. Then the program counter specifies the next ROM address in random sequence. When BR, CAL or RTN instructions are decoded, the switches on each step are turned off not to update the address. Then, for BR or CAL, address data are taken in from the instruction operands (a0 to a5), or for RTN, and address is fetched from stack register No. 1.

(3) Stack register :

This stack register provides two stages each for the program counter (6 bits) and the page address register (4bits) so that subroutine nesting can be mode on two levels.

Chapter 2. Architecture

2 - 3

Data memory (RAM)

Up to 32 nibbles (16 words ¡¿ 2pages ¡¿ 4bits) is incorporated for storing data. The whole data memory area is indirectly specified by a data pointer (X,Y). Page number is specified by zero bit of X register, and words in the page by 4 bits in Y-register. Data memory is composed in 16 nibbles/page. Figure 2.2 shows the configuration.

Output port

Y-register (Y) X-register (X)

D0 D9 R0 R3 REMOUT

Page 0 Page 1

0 14 A0~A3

Data memory page (0~1)

X-register (X)

X-register is consist of 2bit, X0 is a data pointer of page in the RAM, X1 is only used for selecting of D8~D9 with value of Y-register

Fig 2-2 Composition of Data Memory

X1=1X1=0

D8 D9

Y=0 Y=1 D1

Table 2-1 Mapping table between X and Y register

Chapter 2. Architecture

4 2

2 - 4

Y-register (Y)

Y-register has 4 bits. It operates as a data pointer or a general-purpose register. Y-register specifies and address (a0~a3) in a page of data memory, as well as it is used to specify an output port. Further it is used to specify a mode of carrier signal outputted from the REMOUT port. It can also be treated as a generalpurpose register on a program.

Accumulator (ACC)

The 4-bit register for holding data and calculation results.

Arithmetic and Logic Unit (ALU)

In this unit, 4bits of adder/comparator are connected in parallel as it`s main components and they are combined with status latch and status logic (flag.)

(1) Operation circuit (ALU) :

The adder/comparator serves fundamentally for full addition and data comparison. It executes subtraction by making a complement by processing an inversed output of ACC (ACC+1)

(2) Status logic :

This is to bring an ST, or flag to control the flow of a program. It occurs when a specified instruction is executed in two cases such as overflow in operation and two inputs unequal.

Chapter 2. Architecture

2 - 5

State Counter (SC)

A fundamental machine cycle timing chart is shown below. Every instruction is one byte length. Its execution time is the same. Execution of one instruction takes 6 clocks for fetch cycle and 6 clocks for execute cycle (12 clocks in total). Virtually these two cycles proceed simultaneously, and thus it is apparently completed in 6 clocks (one machine cycle). Exceptionally BR, CAL and RTN instructions is normal execution time since they change an addressing sequencially. Therefore, the next instruction is prefetched so that its execution is completed within the fetch cycle.

T1 T2 T3 T4 T5 T6 T1 T2 T3 T4 T5 T6

Fetch cycle N

Execute cycle N-1

Execute cycle N

Fetch cycle N-1

Machine

Cycle

Machine

Cycle

Phase

¥°

Phase

¥±

Phase

¥²

Fig. 2-3 Fundamental timing chart

Chapter 2. Architecture

2 - 6

Clock Generator

The GMS340 series has an internal clock oscillator. The oscillator circuit is designed to operate with an external ceramic resonator. Internal capacitors are available as a masked option. Oscillator circuit is able to organize by connecting ceramic resonator to outside. (In order to built in capacitor for oscillation as masked option.) * It is necessary to connect capacitor to outside in order to change ceramic resonator, You must examine refer to a manufacturer`s

OSC1 OSC2

C1 C2

23 22

OSC1 OSC2

23 22

Oscillation Circuit

Operating Frequency

Circuit 1 Circuit 2

OSC

= 2.4 ~ 4MHz

OSC

= 300 ~ 500KHz

Internal capacitor option

No Internal capacitor option Circuit 1

Chapter 2. Architecture

2 - 7

Pulse generator

The following frequency and duty ratio are selected for carrier signal outputted from the REMOUT port depending on a PMR (Pulse Mode Register) value set in a program.

REMOUT signal

T=1/f

PUL

= 12/f

OSC

[96/f

OSC

], T1/T = 1/20

PMR

2 3 4 5

T=1/f

PUL

= 12/f

OSC

[96/f

OSC

], T1/T = 1/3

T=1/f

PUL

= 8/f

OSC

[64/f

OSC

], T1/T = 1/2

T=1/f

PUL

= 8/f

OSC

[64/f

OSC

], T1/T = 1/4

T=1/f

PUL

= 11/f

OSC

[88/f

OSC

], T1/T = 4/11

No Pulse (same to D0~D9)

* Default value is ¡È0

¡È

* [ ] means the value of ¡ÈT¡È, when Instruction cycle is f

OSC

/48

Table 2-2 PMR selection table

6 T=1/f

PUL

= 12/f

OSC

[96/f

OSC

], T1/T = 1/4

Chapter 2. Architecture

2 - 8

Initial Reset Circuit

RESET pin must be down to ¡ÈL¡È more than 4 machine cycle by outside capacitor or other for power on reset. The mean of 1 machine cycle is below. 1 machine cycle is 6/f

OSC

, however, operating voltage must be in recommended operating conditions, and clock oscillating stability. * It is required to adjust C value depending on rising time of power supply.

(Example shows the case of rising time shorter than 10ms.)

RESET

0.1uF

Chapter 2. Architecture

Watch Dog Timer (WDT)

Watch dog timer is organized binary of 14 steps. By the selected oscillation option, the signal of f

OSC

/6 cycle comes in the first step of WDT. If this counter was overflowed, come out reset signal automatically, internal circuit is initialized. The overflow time is 6¡¿2 13/f

OSC

(108.026ms at f

OSC

=455KHz.)

8¡¿6¡¿213/f

OSC

(108.026ms at f

OSC

= 3.64MHz) Normally, the binary counter must be reset before the overflow by using reset instruction (WDTR) or / and REMOUT port (Y-reg=8, So instruction execution) at masked option.

* It is constantly reset in STOP mode. When STOP is released, counting is restarted. (Refer to 2-10 STOP function>)

Binary counter (14 steps) RESET (edge-trigger)

OSC

/6 or f

OSC

/48

CPU reset

Reset by instruction

REMOUT output

Mask Option

2 - 9

STOP Function

Stop mode can be achieved by STOP instructions. In stop mode :

1. Oscillator is stopped, the operating current is low.

2. Watch dog timer is reset, D8~D9 output and REMOUT output are ¡ÈL¡È.

3. Part other than WDT, D8~D9 output and REMOUT output have a value before come into stop mode.

¡ÈBut, the state of D0~D7 output in stop mode is able to choose as masked option. ¡ÈL¡È output or same level before come into stop mode.

The function to release stop mode is able to choose each bit of K or R input. Stop mode is released when one of K or R input is going to ¡ÈL¡È.

1. State of D0~D7 output and REMOUT output is return to state of before stop mode is achieved.

2. After 1024¡¿8 enable clocks for stable oscillating. First instruction start to operate.

3. In return to normal operation, WDT is counted from zero again.

But, at executing stop instruction, if one of K or R input is chosen to ¡ÈL¡È, stop instruction is same to NOP instruction.

Masked options

The GMS340 series offer the following optional features. These options are masked.

1. Watch dog timer reset by REMOUT output signal.

2. Input terminals having STOP release mode : K0~K3, R0~R3.

3. I/O terminals having pull-up resistor : R0~R3

4. Ceramic oscillation circuit contained (or not contained). [This option is not available for MHz Ceramic oscillator]

5. Output form at stop mode

D0~D7 : ¡ÈL¡È or keep before stop mode

6. Instruction cycle selection: T=48/f

OSC

or T=6/f

OSC

Chapter 2. Architecture

INTRODUCTION 1

ARCHITECTURE 2

INSTRUCTION 3

EVALUATION BOARD 4

SOFTWARE 5

APPENDIX 6

3 - 1

Chapter 3. Instruction

CHAPTER 3. Instruction

INSTRUCTION FORMAT

All of the 43 instruction in GMS340 series is format in two fields of OP code and operand which consist of eight bits. The following formats are available with different types of operands.

Format

¥°

All eight bits are for OP code without operand.

Format

¥±

Two bits are for operand and six bits for OP code. Two bits of operand are used for specifying bits of RAM and X-register (bit 1 and bit 7 are fixed at ¡È0¡È)

Format

¥²

Four bits are for operand and the others are OP code. Four bits of operand are used for specifying a constant loaded in RAM or Yregister, a comparison value of compare command, or page addressing in ROM.

Format

¥³

Six bits are for operand and the others are OP code. Six bits of operand are used for word addressing in the ROM.

3 - 2

INSTRUCTION TABLE

The GMS340 series provides the following 43 basic instructions.

Category

26 27 28

Arithmetic

DY EORM NEGA

Mnemonic

Y ¡ç Y - 1

Function

A ¡ç A + M (X,Y) A ¡ç A + 1

B S Z

29 30

Comparison

ALEM ALEI i

TEST A ¡Â M(X,Y) TEST A ¡Â i

E 31 32

MNEZ

YNEA

TEST M(X,Y) ¡Á 0 TEST Y ¡Á A

N 33 34

YNEI i

KNEZ

TEST Y ¡Á i TEST K ¡Á 0

N 35 RNEZ TEST R ¡Á 0 N 36 37

Input /

Output

LAK

LAR

A ¡ç K A ¡ç R

S 38 39

SO RO

Output(Y) ¡ç 1

Output(Y) ¡ç 0

S 40 41

Control

WDTR

STOP

Watch Dog Timer Reset Stop operation

S 42 43

LPY

NOP

PMR ¡ç Y No operation

Note) i = 0~f, n = 0~3, a = 6bit PC Address *1 Column ST indicates conditions for changing status. Symbols have the following

meanings

S : On executing an instruction, status is unconditionally set. C : Status is only set when carry or borrow has occurred in operation. B : Status is only set when borrow has not occurred in operation. E : Status is only set when equality is found in comparison. N : Status is only set when equality is not found in comparison. Z : Status is only set when the result is zero.

Chapter 3. Instruction

3 - 4

Value of X-reg

0 or 1 SO : D(Y) ¡ç 1, RO : D(Y) ¡ç 0

Operation

REMOUT port repeats ¡ÈH¡È and ¡ÈL¡È in pulse frequency. (when PMR = 5, it is fixed at ¡ÈH¡È) SO : REMOUT (PMR) ¡ç 1 RO : REMOUT (PMR) ¡ç 0

Value of Y-reg

0~7

0 or 1 8

0 or 1

SO : D0 ~ D9 ¡ç 1 (High-Z) R0 : D0 ~ D9 ¡ç 0

0 or 1 SO : R(Y-Ah) ¡ç 1, RO : R(Y-Ah) ¡ç 0A ~ D 0 or 1 SO : R0 ~ R3 ¡ç 1, RO : R0~R3 ¡ç 0E

0 or 1

SO : D0 ~ D9 ¡ç 1 (High-Z) R0~R3 ¡ç 1 R0 : D0 ~ D9 ¡ç 0 R0~R3 ¡ç 0

2 or 3 SO : D(8) ¡ç 1, RO : D(8) ¡ç 00 2 or 3 SO : D(9) ¡ç 1, RO : D(9) ¡ç 01

*2 Operation is settled by a value of Y-register.

Chapter 3. Instruction

3 - 5

DETAILS OF INSTRUCTION SYSTEM

All 43 basic instructions of the GMS340 Series are one by one described in detail below.

Description Form

Each instruction is headlined with its mnemonic symbol according to the instructions table given earlier. Then, for quick reference, it is described with basic items as shown below. After that, detailed comment follows.

• Items :

- Naming : Full spelling of mnemonic symbol

- Status : Check of status function

- Format : Categorized into ¥° to

¥³

- Operand : Omitted for Format

¥°

- Function

Chapter 3. Instruction

3 - 6

Detailed Description

(1) LAY

Naming : Load Accumulator from Y-Register Status : Set Format : I Function : A ¡ç Y <Comment> Data of four bits in the Y-register is unconditionally transferred

to the accumulator. Data in the Y-register is left unchanged.

(2) LYA

Naming : Load Y-register from Accumulator Status : Set Format : I Function : Y ¡ç A <Comment> Load Y-register from Accumulator

(3) LAZ

Naming : Clear Accumulator Status : Set Format : I Function : A ¡ç 0 <Comment> Data in the accumulator is unconditionally reset to zero.

(4) LMA

Naming : Load Memory from Accumulator Status : Set Format : I Function : M(X,Y) ¡ç A <Comment> Data of four bits from the accumulator is stored in the RAM

location addressed by the X-register and Y-register. Such data is left unchanged.

(5) LMAIY

Naming : Load Memory from Accumulator and Increment Y-Register Status : Set Format : I Function : M(X,Y) ¡ç A, Y ¡ç Y+1 <Comment> Data of four bits from the accumulator is stored in the RAM

location addressed by the X-register and Y-register. Such data is left unchanged.

Chapter 3. Instruction

3 - 7

(6) LYM

Naming : Load Y-Register form Memory Status : Set Format : I Function : Y ¡ç M(X,Y) <Comment> Data from the RAM location addressed by the X-register and

Y-register is loaded into the Y-register. Data in the memory is left unchanged.

(7) LAM

Naming : Load Accumulator from Memory Status : Set Format : I Function : A ¡ç M(X,Y) <Comment> Data from the RAM location addressed by the X-register and

Y-register is loaded into the Y-register. Data in the memory is left unchanged.

(8) XMA

Naming : Exchanged Memory and Accumulator Status : Set Format : I Function : M(X,Y) ¡ê A <Comment> Data from the memory addressed by X-register and Y-register

is exchanged with data from the accumulator. For example, this instruction is useful to fetch a memory word into the accumulator for operation and store current data from the accumulator into the RAM. The accumulator can be restored by another XMA instruction.

(9) LYI i

Naming : Load Y-Register from Immediate Status : Set Format :

¥²

Operand : Constant 0 ¡Â i ¡Â 15 Function : Y ¡ç i <Purpose> To load a constant in Y-register. It is typically used to specify

Y-register in a particular RAM word address, to specify the address of a selected output line, to set Y-register for specifying a carrier signal outputted from OUT port, and to initialize Y-register for loop control. The accumulator can be restored by another XMA instruction.

<Comment> Data of four bits from operand of instruction is transferred to

the Y-register.

Chapter 3. Instruction

3 - 8

(10) LMIIY i

Naming : Load Memory from Immediate and Increment Y-Register Status : Set Format :

¥²

Operand : Constant 0 ¡Â i ¡Â 15 Function : M(X,Y) ¡ç i, Y ¡ç Y + 1 <Comment> Data of four bits from operand of instruction is stored into the

RAM location addressed by the X-register and Y-register. Then data in the Y-register is incremented by one.

(11) LXI n

Naming : Load X-Register from Immediate Status : Set Format :

¥±

Operand : X file address 0 ¡Â n ¡Â 3 Function : X ¡ç n <Comment> A constant is loaded in X-register. It is used to set X-register in

an index of desired RAM page. Operand of 1 bit of command is loaded in X-register.

(12) SEM n

Naming : Set Memory Bit Status : Set Format :

¥±

Operand : Bit address 0 ¡Â n ¡Â 3 Function : M(X,Y,n) ¡ç 1 <Comment> Depending on the selection in operand of operand, one of four

bits is set as logic 1 in the RAM memory addressed in accordance with the data of the X-register and Y-register.

(13) REM n

Naming : Reset Memory Bit Status : Set Format :

¥±

Operand : Bit address 0 ¡Â n ¡Â 3 Function : M(X,Y,n) ¡ç 0 <Comment> Depending on the selection in operand of operand, one of four

bits is set as logic 0 in the RAM memory addressed in accordance with the data of the X-register and Y-register.

Chapter 3. Instruction

3 - 9

(14) TM n

Naming : Test Memory Bit Status : Comparison results to status Format :

¥±

Operand : Bit address 0 ¡Â n ¡Â 3 Function : M(X,Y,n) ¡ç 1?

ST ¡ç 1 when M(X,Y,n)=1, ST ¡ç 0 when M(X,Y,n)=0

<Purpose> A test is made to find if the selected memory bit is logic. 1

Status is set depending on the result.

(15) BR a

Naming : Branch on status 1 Status : Conditional depending on the status Format :

¥³

Operand : Branch address a (Addr) Function : When ST =1 , PA ¡ç PB, PC ¡ç a(Addr)

When ST = 0, PC ¡ç PC + 1, ST ¡ç 1 Note : PC indicates the next address in a fixed sequence that is actually pseudo-random count.

<Purpose> For some programs, normal sequential program execution can

be change. A branch is conditionally implemented depending on the status of results obtained by executing the previous instruction.

• Branch instruction is always conditional depending on the status. a. If the status is reset (logic 0), a branch instruction is not rightly executed but the next instruction of the sequence is executed. b. If the status is set (logic 1), a branch instruction is executed as follows.

• Branch is available in two types - short and long. The former is for addressing in the current page and the latter for addressing in the other page. Which type of branch to exeute is decided according to the PB register. To execute a long branch, data of the PB register should in advance be modified to a desired page address through the LPBI instruction.

Chapter 3. Instruction

3 - 10

(16) CAL a

Naming : Subroutine Call on status 1 Status : Conditional depending on the status Format :

¥³

Operand : Subroutine code address a(Addr) Function : When ST =1 , PC ¡ç a(Addr) PA ¡ç PB

SR1 ¡ç PC + 1, PSR1 ¡ç PA SR2 ¡ç SR1 PSR2 ¡ç PSR1

SR3 ¡ç SR2 PSR3 ¡ç PSR2 When ST = 0 PC ¡ç PC + 1 PB ¡ç PS ST ¡ç 1 Note : PC actually has pseudo-random count against the next instruction.

• In a program, control is allowed to be transferred to a mutual subroutine. Since a call instruction preserves the return address, it is possible to call the subroutine from different locations in a program, and the subroutine can return control accurately to the address that is preserved by the use of the call return instruction (RTN). Such calling is always conditional depending on the status.

a. If the status is reset, call is not executed. b. If the status is set, call is rightly executed.

The subroutine stack (SR) of three levels enables a subroutine to be manipulated on three levels. Besides, a long call (to call another page) can be executed on any level.

• For a long call, an LPBI instruction should be executed before the CAL. When LPBI is omitted (and when PA=PB), a short call (calling in the same page) is executed.

Chapter 3. Instruction

3 - 11

(17) RTN

Naming : Return from Subroutine Status : Set Format :

¥°

Function : PC ¡ç SR1 PA, PB ¡ç PSR1

SR1 ¡ç SR2 PSR1 ¡ç PSR2 SR2 ¡ç SR3 PSR2 ¡ç PSR3 SR3 ¡ç SR3 PSR3 ¡ç PSR2

ST ¡ç 1

<Purpose> Control is returned from the called subroutine to the calling

program.

<Comment> Control is returned to its home routine by transferring to the PC

the data of the return address that has been saved in the stack register (SR1). At the same time, data of the page stack register (PSR1) is transferred to the PA and PB.

(18) LPBI i

Naming : Load Page Buffer Register from Immediate Status : Set Format :

¥²

Operand : ROM page address 0 ¡Â i ¡Â 15 Function : PB ¡ç i <Purpose> A new ROM page address is loaded into the page buffer

<Comment> The PB register is loaded together with three bits from 4 bit

operand.

(19) AM

Naming : Add Accumulator to Memory and Status 1 on Carry Status : Carry to status Format :

¥°

Function : A ¡ç M(X,Y)+A, ST ¡ç 1(when total>15),

ST ¡ç 0 (when total ¡Â15)

<Comment> Data in the memory location addressed by the X and Y-register

is added to data of the accumulator. Results are stored in the accumulator. Carry data as results is transferred to status. When the total is more than 15, a carry is caused to put ¡È1

¡È

in the status. Data in the memory is not changed.

Chapter 3. Instruction

3 - 12

(20) SM

Naming : Subtract Accumulator to Memory and Status 1 Not Borrow Status : Carry to status Format :

¥°

Function : A ¡ç M(X,Y) - A ST ¡ç 1(when A ¡Â M(X,Y))

ST ¡ç 0(when A > M(X,Y))

<Comment> Data of the accumulator is, through a 2`s complemental

addition, subtracted from the memory word addressed by the Y-register. Results are stored in the accumulator. If data of the accumulator is less than or equal to the memory word, the status is set to indicate that a borrow is not caused. If more than the memory word, a borrow occurs to reset the status to ¡È0¡È.

(21) IM

Naming : Increment Memory and Status 1 on Carry Status : Carry to status Format :

¥°

Function : A ¡ç M(X,Y) + 1 ST ¡ç 1(when M(X,Y) ¡Ã 15)

ST ¡ç 0(when M(X,Y) < 15)

<Comment> Data of the memory addressed by the X and Y-register is

fetched. Adding 1 to this word, results are stored in the accumulator. Carry data as results is transferred to the status. When the total is more than 15, the status is set. The memory is left unchanged.

(22) DM

Naming : Decrement Memory and Status 1 on Not Borrow Status : Carry to status Format :

¥°

Function : A ¡ç M(X,Y) - 1 ST ¡ç 1(when M(X,Y) ¡Ã1)

ST ¡ç 0 (when M(X,Y) = 0)

<Comment> Data of the memory addressed by the X and Y-register is

fetched, and one is subtracted from this word (addition of Fh)>

Results are stored in the accumulator. Carry data as results is

transferred to the status. If the data is more than or equal to

one, the status is set to indicate that no borrow is caused. The

memory is left unchanged.

Chapter 3. Instruction

3 - 13

(23) IA

Naming : Increment Accumulator Status : Set Format :

¥°

Function : A ¡ç A+1 <Comment> Data of the accumulator is incremented by one. Results are

returned to the accumulator.

A carry is not allowed to have effect upon the status.

(24) IY

Naming : Increment Y-Register and Status 1 on Carry Status : Carry to status Format :

¥°

Function : Y ¡ç Y + 1 ST ¡ç 1 (when Y = 15)

ST ¡ç 0 (when Y < 15)

<Comment> Data of the Y-register is incremented by one and results are

returned to the Y-register.

Carry data as results is transferred to the status. When the

total is more than 15, the status is set.

(25) DA

Naming : Decrement Accumulator and Status 1 on Borrow Status : Carry to status Format :

¥°

Function : A ¡ç A - 1 ST ¡ç 1(when A ¡Ã1)

ST ¡ç 0 (when A = 0)

<Comment> Data of the accumulator is decremented by one. As a result

(by addition of Fh), if a borrow is caused, the status is reset to

¡È0¡È

by logic. If the data is more than one, no borrow occurs

and thus the status is set to ¡È1¡È.

Chapter 3. Instruction

3 - 14

(26) DY

Naming : Decrement Y-Register and Status 1 on Not Borrow Status : Carry to status Format :

¥°

Function : Y ¡ç Y -1 ST ¡ç 1 (when Y ¡Ã 1)

ST ¡ç 0 (when Y = 0) <Purpose> Data of the Y-register is decremented by one. <Comment> Data of the Y-register is decremented by one by addition of

minus 1 (Fh). Carry data as results is transferred to the status. When the results is equal to 15, the status is set to indicate that no borrow has not occurred.

(27) EORM

Naming : Exclusive or Memory and Accumulator Status : Set Format :

¥°

Function : A ¡ç M(X,Y) + A <Comment> Data of the accumulator is, through a Exclusive OR,

subtracted from the memory word addressed by X and Yregister. Results are stored into the accumulator.

(28) NEGA

Naming : Negate Accumulator and Status 1 on Zero Status : Carry to status Format :

¥°

Function : A ¡ç A + 1 ST ¡ç 1(when A = 0)

ST ¡ç 0 (when A != 0) <Purpose> The 2`s complement of a word in the accumulator is obtained. <Comment> The 2`s complement in the accumulator is calculated by adding

one to the 1`s complement in the accumulator. Results are stored into the accumulator. Carry data is transferred to the status. When data of the accumulator is zero, a carry is caused to set the status to ¡È1¡È.

Chapter 3. Instruction

3 - 15

(29) ALEM

Naming : Accumulator Less Equal Memory Status : Carry to status Format :

¥°

Function : A ¡Â M(X,Y) ST ¡ç 1 (when A ¡Â M(X,Y))

ST ¡ç 0 (when A > M(X,Y)) <Comment> Data of the accumulator is, through a complemental addition,

subtracted from data in the memory location addressed by the X and Y-register. Carry data obtained is transferred to the status. When the status is ¡È1¡È, it indicates that the data of the accumulator is less than or equal to the data of the memory word. Neither of those data is not changed.

(30) ALEI

Naming : Accumulator Less Equal Immediate Status : Carry to status Format :

¥²

Function : A ¡Â i ST ¡ç 1 (when A ¡Â i)

ST ¡ç 0 (when A > i) <Purpose> Data of the accumulator and the constant are arithmetically

compared.

<Comment> Data of the accumulator is, through a complemental addition,

subtracted from the constant that exists in 4bit operand. Carry data obtained is transferred to the status. The status is set when the accumulator value is less than or equal to the

constant. Data of the accumulator is left unchanged.

(31) MNEZ

Naming : Memory Not Equal Zero Status : Comparison results to status Format :

¥°

Function : M(X,Y) ¡Á 0 ST ¡ç 1(when M(X,Y) ¡Á 0)

ST ¡ç 0 (when M(X,Y) = 0) <Purpose> A memory word is compared with zero. <Comment> Data in the memory addressed by the X and Y-register is

logically compared with zero. Comparison data is thransferred to the status. Unless it is zero, the status is set.

Chapter 3. Instruction

3 - 16

(32) YNEA

Naming : Y-Register Not Equal Accumulator Status : Comparison results to status Format :

¥°

Function : Y ¡Á A ST ¡ç 1 (when Y ¡Á A)

ST ¡ç 0 (when Y = A) <Purpose> Data of Y-register and accumulator are compared to check if

they are not equal.

<Comment> Data of the Y-register and accumulator are logically compared.

Results are transferred to the status. Unless they are equal, the status is set.

(33) YNEI

Naming : Y-Register Not Equal Immediate Status : Comparison results to status Format :

¥²

Operand : Constant 0 ¡Â i ¡Â 15 Function : Y ¡Á i ST ¡ç 1 (when Y ¡Á i)

ST ¡ç 0 (when Y = i) <Comment> The constant of the Y-register is logically compared with 4bit

operand. Results are transferred to the status. Unless the operand is equal to the constant, the status is set.

(34) KNEZ

Naming : K Not Equal Zero Status : The status is set only when not equal Format :

¥°

Function : When K ¡Á 0, ST ¡ç 1 <Purpose> A test is made to check if K is not zero. <Comment> Data on K are compared with zero. Results are transferred to

the status. For input data not equal to zero, the status is set.

(35) RNEZ

Naming : R Not Equal Zero Status : The status is set only when not equal Format :

¥°

Function : When R ¡Á 0, ST ¡ç 1 <Purpose> A test is made to check if R is not zero. <Comment> Data on R are compared with zero. Results are transferred to

the status. For input data not equal to zero, the status is set.

Chapter 3. Instruction

3 - 17

(36) LAK

Naming : Load Accumulator from K Status : Set Format :

¥°

Function : A ¡ç K <Comment> Data on K are transferred to the accumulator

(37) LAR

Naming : Load Accumulator from R Status : Set Format :

¥°

Function : A ¡ç R <Comment> Data on R are transferred to the accumulator

(38) SO

Naming : Set Output Register Latch Status : Set Format :

¥°

Function : D(Y) ¡ç 1 0 ¡Â Y ¡Â 7

REMOUT ¡ç 1(PMR=5) Y = 8 D0~D9 ¡ç 1 (High-Z) Y = 9 R(Y) ¡ç 1 Ah ¡Â Y ¡Â Dh R ¡ç 1 Y = Eh D0~D9, R ¡ç 1 Y = Fh

<Purpose> A single D output line is set to logic 1, if data of Y-register is

between 0 to 7. Carrier frequency come out from REMOUT port, if data of Y-register is 8. All D output line is set to logic 1, if data of Y-register is 9. It is no operation, if data of Y-register between 10 to 15. When Y is between Ah and Dh, one of R output lines is set at logic 1. When Y is Eh, the output of R is set at logic 1. When Y is Fh, the output D0~D9 and R are set at logic 1.

<Comment> Data of Y-register is between 0 to 7, selects appropriate D

output. Data of Y-register is 8, selects REMOUT port. Data of Y-register is 9, selects all D port. Data in Y-register, when between Ah and Dh, selects an appropriate R output (R0~R3). Data in Y-register, when it is Eh, selects all of R0~R3. Data in Y-register, when it is Fh, selects all of D0~D9 and R0~R3.

Chapter 3. Instruction

3 - 18

(39) RO

Naming : Reset Output Register Latch Status : Set Format :

¥°

Function : D(Y) ¡ç 0 0 ¡Â Y ¡Â 7

REMOUT ¡ç 0 Y = 8 D0~D9 ¡ç 0 Y = 9 R(Y) ¡ç 0 Ah ¡Â Y ¡Â Dh R ¡ç 0 Y = Eh D0~D9, R ¡ç 0 Y = Fh

<Purpose> A single D output line is set to logic 0, if data of Y-register is

between 0 to 9. REMOUT port is set to logic 0, if data of Y-register is 9. All D output line is set to logic 0, if data of Y-register is 9. When Y is between Ah and Dh, one of R output lines is set at logic 0. When Y is Eh, the output of R is set at logic 0 When Y is Fh, the output D0~D9 and R are set at logic 1.

<Comment> Data of Y-register is between 0 to 7, selects appropriate D

output. Data of Y-register is 8, selects REMOUT port. Data of Y-register is 9, selects D port. Data in Y-register, when between Ah and Dh, selects an appropriate R output (R0~R3). Data in Y-register, when it is Eh, selects all of R0~R3. Data in Y-register, when it is Fh, selects all of D0~D9 and R0~R3.

(40) WDTR

Naming : Watch Dog Timer Reset Status : Set Format :

¥°

Function : Reset Watch Dog Timer (WDT) <Purpose> Normally, you should reset this counter before overflowed

counter for dc watch dog timer. this instruction controls this reset signal.

Chapter 3. Instruction

3 - 19

(41) STOP

Naming : STOP Status : Set Format :

¥°

Function : Operate the stop function <Purpose> Stopped oscillator, and little current.

(See 1-12 page, STOP function.)

(42) LPY

Naming : Pulse Mode Set Status : Set Format :

¥°

Function : PMR ¡ç Y <Comment> Selects a pulse signal outputted from REMOUT port.

(43) NOP

Naming : No Operation Status : Set Format :

¥°

Function : No operation

Chapter 3. Instruction

INTRODUCTION 1

ARCHITECTURE 2

INSTRUCTION 3

EVALUATION BOARD 4

SOFTWARE 5

APPENDIX 6

4 - 1

Chapter 4. Evaluation Board

CHAPTER 4. Evaluation Board

OUTLINE

The GMS 30000 EVA is an evaluation board for GMS340 series, 4-bit, 1-chip microcomputer. It is designed to evaluate and confirm the operations of the application system in the nearest possible form of final products while it is under development.

The major features are as follows :

• The GMS 30000 EVA is used for the evaluation chip.

• The board is connected to the application system through an connection cable (DIP24).

• EPROM of 2764, 27128, and 27256 are used for the program memory.

• The instruction system and I/O specifications are basically the same as those of the GMS340 series.

Product Specifications

• GMS 30000 EVA board module Dimensions 64 ¡¿ 82 (mm)

Supply Voltage 2.5 ~ 5.5 (V) Operating temperature 0~50 (¡É)

• Connection cable DIP 24 cable

4 - 2

Connection

Perform emulation with the following connectors. [User] Connection socket

The cable for the target system is connected.

Pin No.

Signal

Reset

Pin No.

Signal

D9 2 GND 14 D1 3 R0 15 D2 4 R1 16 D3 5 R2 17 D4 6 R3 18 D5 7 K0 19 D6 8 K1 20 D7 9 K2 21 Remout

10 K3 22 OSC2 11 D0 23 OSC1 12 D8 24 VDD

[M1] Monitor pin

Operations inside the GMS 30000 EVA can be monitored. Signals that can be monitored are as follows.

AC0~AC3, X0, X1, Y0~Y3, REMDATA, CK2, CK5, WDTR, GND

[M2] Oscillation monitoring pin

The oscillation output signal can be monitored.

[T1] D8 output monitoring pin

The D8 output signal can be monitored.

[T2] D9 output monitoring pin

The D9 output signal can be monitored.

Chapter 4. Evaluation Board

4 - 3

Optional setting

The following optional setting in accordance with the application system specifications is required :

[S1] Optional mask setting

Optional masks available with GMS300 series units can be set by selecting short posts.

1. Setting of K-input and R-Port for STOP release Shorting the KSR0 ~ KSR3 and RSR0 ~ RSR3 with the side of H can set the STOP releasing function by the corresponding KSR0 ~ KSR3 and RSR0 ~ RSR3. If no STOP releasing function is desired, short them with the side of L.

Setting pin

Short post

KSR0

Setting of STOP

No setting of STOP

H L

KSR1

H L

KSR2

KSR3

RSR0

H L

RSR1

H L

RSR2

H L

RSR3

H L

2. Setting of pull-up resistor built-in R-Port pull-up resistor can be built in the R-Port by shorting the corresponding RPU0 ~ RPU3 with the side of H. If installation of built-in pull-up resistor is not desired, short them with the side of L.

Setting pin

Short post

Built-in pull-up resistor installation

No built-in pull-up resistor installation

RPU0

H L

RPU1

H L

RPU2

RPU3

H L

Chapter 4. Evaluation Board

4 - 4

3. Setting of output condition of D0~D7 in STOP Shorting the DSC0~DSC7 with the side of H can set the output condition of corresponding D-output in STOP at ¡ÈL¡È forcibly. To set the condition of usual output (the condition before STOP started is maintained), short them with the side of L.

Setting pin

Short post

DSC0

Forced setting at

¡ÈL¡È

in STOP

release

Usual output in

STOP released

DSC1

DSC2

DSC3

DSC4

DSC5

DSC6

DSC7

4. Setting of watch dog timer release with REMOUT output The watch dog timer can be reset with REMOUT output signals by shorting the WDTM with the side of L. If the WDT resetting with REMOUT output signals is not desired, short it with the side of H.

Short post

Reset timer

WDTM

L HDo not reset timer

[S2] External STOP setting

STOP can be set from the outside by shorting the S2 toward the side of H. Usually, short it toward the side of L.

[S3] Power supply connection

This selection should be strapped to VDD.

Chapter 4. Evaluation Board

4 - 5

Short post

2764/128

H L27256

[S4] EPROM 2764/128, and 27256 can be installed by switching over the S4. For

EPROM, however, right-justify ROM chip pin 1 from socket pin 3.

Short post

External clock input

S5 & S6

U XInternal self-induced oscillation

[S5, S6] Clock input selection

Self-induced oscillation with the external clock input and oscillator can be set by switching over the S5 & S6

For internal clock input, install an oscillator on the PCB. Since the oscillation circuit constant varies depending on the oscillator, adjust the constant by

referring to the oscillator manufacture`s recommendable values.

Chapter 4. Evaluation Board

Short post

MHz oscillation

S7 & S8 & JP

KKHz oscillation

[S7, S8, JP] Clock input selection

MHz and KHz oscillation can be selected by switching over the S7, S8 and JP.

4 - 6

Caution on Operation

• It is required to install a 24DIP IC socket in the application system. The connection cable is connected to the socket.

• There is a possibility that the ceramic oscillator on the application system cannot oscillate properly due to the influence of connection cable wiring capacitor or other reasons. In such a case, install the oscillator on the evaluation board.

• Since the GMS 30000 EVA is designed to evaluate the program operations, there is a case where the AC and DC characteristics differ from those of the mass produced chips

Chapter 4. Evaluation Board

S3 S5 S6

H L U X U X M K

1 28

Connector

EPROM

E V A

GND

CX3 CX2

X0 AC3 AC2 AC1 AC0

WDTR

REM DATA

H L

BKPOINT

WDTM

DSC7 DSC6 DSC5 DSC4 DSC3 DSC2 DSC1 DSC0

H L

RSR0 RSR1 RSR2 RSR3 RPU0 RPU1 RPU2 RPU3 KSR0 KSR1 KSR2 KSR3

(80QFP)

Connector

(24Pin Socket)

GSEN EVA30000

USER

GND

S4 S7 S8

H L M K M K

Fig 4-1 Layout Diagram

INTRODUCTION 1

ARCHITECTURE 2

INSTRUCTION 3

EVALUATION BOARD 4

SOFTWARE 5

APPENDIX 6

5 - 1

Chapter 5. Software

CHAPTER 5. Software

Configuration of Assembler

Execute File

GA80.EXE

Description

Assembler Create assembler list fileGMSLST.EXE

GMSHEX.EXE Create HEX.file

Create cross refere nce fileGMSCRF.EXE

GMSTST.EXE Create instruction check file

Create ROM dump fileGMSROM.EXE

GS.BAT Batch processing of the above

Instruction library fileGMS30K.LIB

Boothing up Assembler

Creating your own source file with the extension name of SRC and execute batch file (GS.BAT). This batch file converts the source code written in mnemonic into machine language and generate a kind of useful file.

C> GS Source file (.SRC)

Input File

EX.SRC

Content

List file Hexa file (for EPROM, simulator) Cross r eference file Instruction check file ROM dump file (for masking data) Symbol file

Output File

EX.LST EX.RHX EX.CRF EX.TST EX.DMP EX.SYM

* HEX and PRN file is intermediate file

5 - 2

Configu r at io n of Sim ulator

1. Overvi ew

The simulator is a program for GMS300 Series 4-bit one-chip microcomputer. The environment is organized based upon Hexa file of *.RHX and Cross Reference file of *.CRF generated by assembling the source program coded by programmer.

Execution Environment

System : IBM-PC/AT or higher (MS-DOS or PC-DOS) Video : Hercules, EGA or VGA color

Organizing files

GSSIM.EXE : Simulator execution file GMS30K.GSP : Store the simulator environment. It is

generated automatically when executing the program initially (Selected CPU.

Store the file names previously loaded.). GMS30K.HLP : Help file of simulator commands. GMS30K.LOG : Record the working history of users. Generated

by LOG ON and LOG OFF commands. *.BAT : List a set of simulator command. Generated by

user. PORTIN.DAT : Provide the port input-value when executing

the simulator. Generated by user.

Supporting CPU

GMS30004, GMS30012, GMS30112, GMS30120, GMS30140

Chapter 5. Software

5 - 3

2. Characteristics of Simulator

- User-friendly pop-up window menu. Select the necessary command and display the screen in windows format so that users can know the execution results.

- Display always the register window in the right side so that programmer can check easily the change of data memory value as program proceeds.

- Maintain the previous simulator environment if user does not make the extra changes when re-executing after logging out completely from the simulator previously executed by loading the source program. In other words, the previously-

executed file is automatically loaded when the simulator is executed (GMS30K.GSP file).

- When trace command ([F8] or > T command) is executed, the changed values are

noticed easily by displaying the highlighted changed values in register and memory windows, if the contents of each register or data memory is changed as command line is processed.

- When trace command ([F8] or > T command) is executed, the current execution

line is highlighted.

- Out of the simulator commands, load or save commands is executable in pop-up

windows. In-line command is executable as prompt command in the command window.

Chapter 5. Software

5 - 4

3. Screen Or ga ni zat io n of S imu la to r

Screen is basically organized with four windows; Memory, Source, Command and Register. Source and Command windows can be enlarged up to the full screen size (CTRL-[F10]). Movement between windows is made by [F6].

3.1 Memory Window

Data memory contents of the currently selected micom is displayed. 32 nibble data values of 00~1F(h) addresses are displayed.

3.2 Source Window

The contents of *.RHX file called by load command is displayed in the state of

being disassembled. Addresses are displayed randomly in the state of polynomial together with instruction code and mnemonic. If *.CRF file is called, label is displayed at the corresponding position. Display position of source program is adjustable with Up/Down arrow keys and Page Up/Down keys.

3.3 Command Window

All kinds of commands provided by simulator is executed by In-line command,

and the execution results of the commands are displayed. Command window

size is adjustable with [CTRL]-[F10].

Chapter 5. Software

5 - 5

3.4 Reg ister Window

Display each register value inside micom, I/O port value and machine cycle altogether. When trace command is executed by function key [F8], the register value after the previous command before the current program counter is executed is displayed. All kinds of register and I/O ports displayed in register window are as follows.

PC : Program co unt er 2digit 6bit [Hexa] ACC : Accumulato r 1digit 4bit [Hexa] PA : Page addre ss 1di gi t 4bit [Hexa] PB : Page buffe r 1digit 4bit [Hexa] X : X register 1digit 1 or 2 [Hexa] Y : Y reg ist er 1digit 4bit [Hexa] ST : Status register 1digit 1bit [Binary] PMR : Pulse mode register 1digit [Hexa] WDT : Watch dog timer 1digit 14bit {Hexa] SP : Stack pointer level 1digit SR0 : Stack level 0 4digit SR1 : Stack level 1 4digit SR2 : Stack level 2 4digit OUT : Remocon out output [Binary] K : K port input register 4bit [Binary] Rin : R port input register [Binary] Rout : R port output register [Binary] D : output port 6or8 10bit [Binary] Machine Cycle : The number of command execution is displayed in decimal.

Chapter 5. Software

5 - 6

4. Commands in Each Menu

^stands for [CTRL] key, while @ stands for [ALT] key.

4.1 File Menu

Use the function key behind each command as a hot key or execute each command through selecting [ALT]-[F ] key and pressing the highlighted character.

Load RHX F2 : Load the file named *.RHX, analyze the selected Hexa file

and disassemble it. Display the program address, assemble code and mnemonic. The order of displayed program addresses follows the POLYNOMIAL form. Even when the extention is not input in case of selection, .RHX extension is presumed to include.

Load CRF @F2 : If Cross reference file of loaded file loads the *.CRF file,

labels and variables assigned by programmer are displayed at accurate position of Source window so that programmer can read the program easily. Even when the extension is not input in case of file selection, .CRF extension is presumed to include.

Write RHX F3 : When any modifications are made to source program or

program memory after the simulator is loaded once, the modifications are stored in the same or new filename as loaded. It has the same command and function as > WP [filename] of In-line command.

Log ON/OFF F4 : After the simulator is executed, all the input and results are

stored in the filename GMS30K.LOG Once function key [F4] is pressed, log-in starts, and if the key is pressed one more time, log-in file is closed in a toggling way. The ON/OFF state of log-in is displayed in the upper-right corner. It has the same function as > LOGON and > LOGOFF of In-line commands.

Os shell @S : When users want to work temporarily under DOS environment,

this command is used. When users want to back to Windows environment, input > EXIT.

Exit @X : Used when getting completely out of the simulator environment.

Chapter 5. Software

5 - 7

4.2 Window Menu

Use the function key behind each command as a hot key or execute each command through selecting [ALT]-[W ] key and pressing the highlighted character. Function key [F6] provides the return function to each window.

Command Box: Position the cursor in command window to make it possible to

use In-line command provided by the simulator.

Source Box : Position the cursor in source window to make it possible for

programmer to see the disassembled source program. It is possible to use Up/Down arrow keys and Page Up/Down keys.

Zoom ^F10 : Position the cursor in command or source window, and then

select Zoom or press [CTRL]-[F10] key to enlarge the window to the full screen size.

Chapter 5. Software

5 - 8

4.3 Run Menu

Use the function key behind each command as a hot key or execute each command through selecting [ALT]-[R] key and pressing the highlighted character.

MCU Reset ^F9 : Initialize the execution environment of the simulator. In

other words, initialize the register value to 0 or 1, and machine cycle value is changed to 0. It has the same command and function as > CR command of In-line command.

Go F5 : Program executes from the current value of program counter.

Press [ESC], [Enter] or [Space] key to stop execution, and display the current register value.

Animate @5 : Program executes from the current value of program counter.

The value of data memory or registers are highlighted in the corresponding window. Press [ESC], [Enter] or [Space] key to stop execution. Because of speed difference among system, the speed is adjustable from 0 to 40. (0 : fastest, 40 : slowest)

Trace F8 : Program executes line by line from the current value of

program counter. The changing values of registers and memory are highlighted in register window and memory window respectively.

Execute Batch : When the batch filename consisted of a set of commands

made by user using editor is input, each command executes automatically as In-line command is input. It has the same function as > BAT command of In-line command.

Chapter 5. Software

5 - 9

4.4 Option Menu

To execute each command, select [ALT]-[O] key and press the highlighted

character in each command line. Or select the menu and press the [Enter] key.

MCU Select : Select according to the kind of micom. Able to select on of

GMS30004, 30012, 30112, 30120 or 30140 among GMS300 series. Once the command is executed, the window indicating the characteristics of each micom is open. Press Left, Right, Up Down key to select the micom to work.

Setup : Set the execution mode of selected micom. It has the same

function as > SET command of In-line command. Once the function is executed, a small <Setup> window is open. Position the cursor in either of I/O Input and Output mode, Symbol, Execution Mode of Watch Dog Timer with the item to change. Assign the corresponding execution mode with Left, Right arrow key.

Execution Mode to be Assigned in <Setup>

I/O Input [pi] = [0] Port Input from I/O register

[1] Port input from keyboard [2] Port input from file (PORTIN.DAT)

I/O Output = [0] No display

[1] Display [2] Display & Break

Symbol = [0] Search

[1] Unsearch

Watch Dog Timer = [0] OFF

[1] ON (No option) [2] ON (Option)

Chapter 5. Software

5 - 10

5. Simulator Execution

5.1 File Loa d

Use one of three ways to load the file to run from the simulator. First execute

the GSSIM.EXE file from DOS and name it as a parameter. >a:\GSSIM TEST.RHX (Here the extention needs not be input.) The following screen will be displayed.

)LOH :LQGRZ 5XQ 2SWLRQ /RJ 2)) *06

5HJLVWHU

     

6RXUFH $?7(675+;  & /;,   ) /<, )  ' 62  ) /$= )  /0$ ) & '< ) ) %5 ) (  /<,  ' & 5

&RPPDQG &38 *06 520  %\WHV 5$0  1LEEOHV ,2 ,QSXW >SL@ >@ 3RUW,QSXW )URP ,2 5HJLVWHU ,2 2XWSXW >SR@ >@ 1R 'LVSOD\ 6\PERO >@ >@6HDUFK :DWFK 'RJ 7LPHU>:G@ >@ 2)) !

3&  $FF  3$  3% 

;  <  67  305  :'7 

63  65  65  65 

,2 3RUWV

287 

.  5LQ  5RXW  ' 

0DFKLQH &\FOH



)  +(/3! &WUO  )  =220! )  6ZLWFK! *6(1*06. 6LPXODWRU 9HU 

Chapter 5. Software

5 - 11

Second, execute the GSSIM.EXE file and then the Load RHX (Hot key is [F2]). The following small window is open at the center of screen waiting for user to input the Hexa filename to work.

* File Name *

A : \UNNAMED .R HX

When no file is selected, Unnamed.rhx filename is displayed. When the filename to work is input immediately, the file from the current directory is called. If the specific directory is assigned, the file from the assigned directory is called.

Third, call the file to work through using the >LP [filename] from command window by in-line command.

Here for example, load the TEST.RHX file

* File Name *

A : \TEST.RH X

TEST.RHX file is called and the contents of HEXA file is analyzed from the simulator. The source contents in the state of being disassembled is displayed from Source window. Incase of filename input, although RHX is not input, .RHX extension presumed to include by default.

Chapter 5. Software

5 - 12

Also when there is Cross Reference File of working file, press Load CRF (Hot key [ALT]-[F2]). The following small window is open at the center of screen waiting for user to input *.CRF filename.

* File Name *

A : \TEST.CR F

The filename called by Load RHX command is displayed by default as .CRF filename. When .CRF file is called, the label of source program created by programmer is displayed at the label position of Source window for easy reading of program by user.

Chapter 5. Software

5 - 13

5.2 File Store

When the specific part of source program is changed under the simulator

environment by calling the working file, the corresponding Hexa file needs to be stored. Use one of the following two methods.

First, when executing the pop-up command Save RHX (Hot key is [F3]), the following small window is open at the center of screen waiting for user to input the Hexa filename. The filename called by file load command by default is displayed. When the filename is not changed, hit just the [Enter] key. When user wants to change the filename to store, input the filename to change.

* File Name *

A : \TEST.RH X

Second, store the processed Hexa file using > WP [filename] from command

window with In-line command. Here when the same filename to store already exists in the disk,

File

Already ExistÌ message comes up asking user by [YES/NO] if user overwrite

or not.

Chapter 5. Software

5 - 14

5.3 Closing the Simulator

Using the pop-up command Exit (Hot key [ALT]-[X]) or In-line command > Q,

exit from the simulator environment. When execute the command, the following message comes up for the check-

up asking the user`s intention to store, if user does not store the changed file after changing the loaded file to work. Use Tab key or left, right direction key to select YES/NO.

Also for recording the work contents, even when exiting the simulator without

Log OFF, Log OFF is done automatically and GMS30K.LOG file is stored.

Program have changed. Save it ?

Yes No

Chapter 5. Software

5 - 15

6. Simulator Commands

6.1 Command Syntax

1) A (Assemble) To assemble what is commanded for every line from the specified <address> and write in the memory.

2) BAT (Batch) To execute what is commanded in the command file in a batch. When there is a format error, command error is issued and execution is stopped at the error point.

3) BP (Break Point set), BL (Break point List) To set break point. To display the set break Point.

4) BS (Break point set step) To set break point with No. of steps.

5) BC (Break point Clear) To clear the specified No. break point.

6) CR (CPU Reset) To reset the simulator to the initial state.

7) DPP (Dump Program memory)

To display the content of the memory in the area of the No. of pages specified with <In> from the specified <address> in hexadecimal. The address here is polynomial.

8) DPS (Dump Program memory)

To display the content of the memory in the area of the No. of pages

specified with <In> from the specified <address> in hexadecimal.

9) DD (Dump Data memory)

To display all the data in Data Memory in hexadecimal.

10) EPP (Exchange Program memory)

To display and modify the specified data in the program memory.

Address here is polynomial.

Chapter 5. Software

5 - 16

11) EPS (Exchange Program memory) To display and modify the specified data in the program memory.

12) ED (Exchan ge Data memo ry) To display or modify data in the specified data memory.

13) FPP (Fill Program memory) To fill the area of the program memory specified with <In> from the specified <address> with the specified byte data. The address here is polynomial.

14) FPS (Fill Program memory) To fill the area of the program memory specified with <In> from the specified <address> with the specified byte data.

15) FD (Fill Data memory) To fill the area of the data memory specified with <In> from the specified <address> with the specified nibble data.

16) G (Go) To execute the program in the specified program memory.

17) H (Hex calculate) To add or subtract in hexadecimal.

18) LOGON (LOGIN) To log the commands executed after this command.

19) LOGOFF (LOGOUT) To end logging.

20) LP (Load Program from MS-DOS* file) To load `files` on MS-DOS* to the memory.

21) MPP ( Move Program memo ry) To transfer data in the memory area to another area. The address here is polynomial.

Chapter 5. Software

5 - 17

22) MPS (Move Program memory) To transfer data in the memory area to another area.

23) P (Port set) To set the specified data at the specified I/O register.

24) Q (Quit) To return to MS-DOS*.

25) R (Register dump or change) To display or modify the register data.

26) SET (setup ) To set the operation Mode for the simulator.

27) SL (Symbol file Load) To load symbol tables from the specified symbol file.

28) ST (Status) To display the simulator status.

29) T (Trace) To execute the program in the specified program memory address a single step.

30) TMT (Ti m e ) To obtain time from the No. of machine cycles and clock frequency.

31) TMC (Time) To obtain No. of machine cycle from the time and clock frequency.

32) U (Unassemble) To unassemble data in the area specified with <In> from the specified <address> and display in mnemonic.

33) Wp (Write Program to MS-DOS* file) To read-out data in all the ROM area and write the Intel hexa data in the files specified with <file name>.

34) ? (Help) To display the list of commands of this simulator

Chapter 5. Software

5 - 18

6.3 Description of Commands

The symbols used in this chapter are defined as in below.

1) XXXX Indicates input from the keyboard.

Indicates Return key.

3) _ Indicates insertion of space characters.

4) In Indicates range.

5) [ ] Indicates it is omittable.

6) No. used on this system are hexadecimal. However, the machine cycles are decimal. (Common items on this simulator)

1) This simulator accepts up to 132 characters per each line. Before pressing `ã` key, data can be modified in the following procedure. <BS> Key deletes one character and the cursor sets back by one character.

2) Commands can be input both in block and small letters and both are treated as the same.

3) Commands can be terminated by inputting `.`.

4) Command history (recall) This simulator has 16 command buffers and each time `Control A` is pressed, command immediately before the current one is displayed.

5) When `!XX` is executed to `*`, MS-DOS* commands can be executed

temporarily.

6) Regarding the omission indicated with [ ], when one [<address>] or [In] is omitted, the area may not be recognized. In this case, be careful as the current operation cannot be ensured.

7) When `.XXXX` is specified, it is treated as a symbol. Therefore, before using this specification, specification of Symbol file should have been made.

8) When `ESC` key is pressed, command execution is stopped and the system moves to `*` mode.

9) When In is LXX< XX indicates No. of words and when there is no L, XX indicates an address.

10) For command separator (indicated with_in this Manual), `_` or `,` can be used.

11) When `Control C` is pressed, the system goes back to `MS-DOS*`.

12) In case of both sequential and polynomial address, the first two digits of an <address> indicate No. of page and the latter two digits indicate the address.

Hereunder is the explanation on each command used on this system.

Chapter 5. Software

5 - 19

A (Assemble)

[Function]

To assemble commands for each line from the specified <address> and write them in the memory.

[Format]

> A_ [<address>]

[Explanation]

With this, the system assembles commands for each line from the specified <address> and writes them in the memory. When <address> is omitted, data is written from the current `PC` address. Assemble can be finished by keying in `.`. When `_` is keyed in, the system goes back the address just before the current one.

[e.g.]

>A 200

0200 40 LYI 0

0201 21 LAM

LMA

0203 77 ALEI 14

0201 03 LMA

0200 0D SO

BAT (Batch)

[Function]

To execute commands in the command file in a batch. When there is a format error, execution is stopped there and command error is issued.

[Format]

BAT_<File Name>

[Explanation]

With this command, the system executes commands in the command file in a batch. When there is a format error, execution is stopped there and command error is issued. In order to execute this command, it is required to create the command file on the editor in advance.

[e.g]

>BAT test.bat

>R PA 0 >R PB 0BATCH END >

Chapter 5. Software

5 - 20

BP (Break Point set), BL (Break point List)

[Function]

BP To set the break point. BL To display the set break point BPS To set step break point.

[Format]

BP[n]_adr[_m]

n : Set break No. 0~9. adr : Set address for setting break m : Valid only when n=0, setting No. of times to pass the break

point. The m range is 1

õmõ

255. m value should be set in

hexadecimal.

BPS_st

st : Set No. of steps.

st range is 1õstõ2147483647. st value should be set in decimal.

BPI

BPO

[Explanation]

This command is used to the break point. Break on this simulator is to stop after executing the command on the specified address. When `BPS st` is specified, the system stops when the value on the machine cycle register becomes equal to st. When `BPI` is specified, the system stops before command execution every time command input is made. Unassemble displayed in this case is the address with input command. When `BPO` is specified, the system displays the value on that occasion on CRT and stops every time output command is made. When `BP` only or `BL` is specified, the state of the currently set break point is displayed. It is possible to used symbols for specifying adr. When `n` is omitted in break setting command, No. shall be allocated from 1 to all empty No.

Chapter 5. Software

5 - 21

[e.g .]

1) Example to occur break after passing page 1 address 0 three times.

>BP0 100 3

2) Example to set a break point at page 5 address 0.

>BP 500

>BL

0 = 0100 ( 3)

1 = 0500

3) Example to occur break on the main label (in case the main label is at page 5 address 0.)

>BP .main

>BL

0 = 0100 ( 3)

1 = 0500 .MAIN

4) Example to occur break by No. of steps (50 steps).

>BPS 50

>BL

0 = 0100 ( 3)

1 = 0500 .MAIN

S50

5) Example to occur break with input command.

>BPI

RUN

******** MC Step Break ********

0004 00 NOP

PC=00 PA=09 PB=00 A=0 X=0 Y=0 ST=1 PMR=0 WD=0000 MC=50

>R R 00

Chapter 5. Software

6) Example to occur break with output command.

>BP0

RUN

Rout=1111 D=11111111 OUT=0 MC=125

******** Break AT Port Out !! ******** 002F 0D SO

PC=00 PA=1E PB=00 A=0 X=0 Y=F ST=1 PMR=0 WD=0000 MC=125

Chapter 5. Software

BC (Break Point Clear)

[Function]

To clear the break point at the specified No.

[Format]

BC_n

[Explanation]

With this, the system clear the break point at the specified No. When n is omitted, the state of the currently set break shall be displayed. When n is `*`, all the break points shall be cleared.

[e.g]

>BL

0 = 0100 ( 3) 1 = 0200 2 = 0500 S 50 I O >BC 1

>BC S

>BC I

>BC O

>BC

0 = 0100 ( 3) 2 = 0500 >BC *

>BL

5 - 22

CR (CPU Reset)

[Function]

To set simulator to the initial state.

[Format]

[Explanation]

When this command is executed, the simulator is set back to the initial state. In this case, the registers are also initialized according to each CPU. However, MC is cleared irregardless of the CPU status. Initial State of each register.

PA, PC, PB, SP and D PORT become 0. All the ports of R PORT become 1. The other registers are undefined.

[e.g]

>CR

CPU GMS30140

ROM 1024 Byte RAM 32 Nibble

I/O Input [pi] = [0] Port input I/O register

I/O Output [po] = [0] No Display

SYMBOL [1] = [0] Search

Watch Dog Timer [wd] = [0] off

PC=00 PA=00 PB=00 A=0 X=0 Y=0 ST=0 PMR=0 WD=0000 MC=0

SP=0 SR1=0000 SR2=0000 SR3=0000 I/O Reg. Rin=1111 Rout=1111 D=00000000 OUT=0 K=0000(0h) >

Chapter 5. Software

5 - 23

DPP (Dump Program memory)

[Function]

To display data in the program memory area specified with <In> from the specified <address> in hexadecimal.

[Format]

DPP_[<address>_<In>]

[Explanation]

When this the system displays data in the program memory area specified with <In> from the specified <address> in hexadecimal. When [ ] is omitted, 64 bytes of data from the succeeding address shall be displayed. The address used with this command is polynomial.

[e.g]

>DPP 0 20

0000 : 00 01 02 03 04 05 06 07 - 08 09 0A 0B 0C 0D 0E 0F 0027 : 10 11 12 13 14 15 16 17 - 18 19 1A 1B 1C 1D 1E 1F 001C : 20 21 22 23 24 25 26 27 - 28 29 2A 2B 2C 2D 2E 2F 0022 : 31 32 33 33 34 35 36 37 - 38 39 3A 3B 3C 3E 3E 3F >

DPS (Dump Program memory)

[Function]

To display data in the program memory area specified with <In> from the specified <address> in hexadecimal.

[Format]

DPS_[<address>_<In>]

[Explanation]

[e.g]

>DPS_0_3F

0000 : 00 01 03 07 0F 1F 3F E3 - 3D 3B 37 2F 1E 3C 39 33 0010 : 27 0E 1D 3A 35 2B 16 2C - 18 30 21 02 05 0B 17 2E 0020 : 1C 38 31 23 06 0D 1B 36 - 2D 1A 34 29 12 24 08 11 0030 : 22 04 09 13 26 0C 19 32 - 25 0A 15 2A 14 28 10 20 >

Chapter 5. Software

5 - 24

DD (Dump Data memory)

[Function]

To display data in the data memory in hexadecimal.

[Format]

[Explanation]

With this, the system displays all the data in the data memory in hexadecimal.

[e.g]

>DD

000 : 6 C 6 0 0 0 0 0 - 0 0 0 0 0 0 0 0 010 : 1 2 3 4 0 0 0 0 - 3 2 1 0 0 1 0 1 >

ED (Exchange Data memory)

[Function]

To display and modify the specified data memory.

[Format]

ED_[<address>

[Explanation]

When this the system displays and modifies the specified data memory. This Mode is continuous and processing shall be continued until *.* is pressed. When `_` is pressed, the system goes back to the address immediately before.

[e.g]

>ED 0

00 : 7 >

01 : 6 >

02 : 7 >

Chapter 5. Software

5 - 25

EPP (Exchange Program memory)

[Function]

To display and modify the specified program memory.

[Format]

EPP_<Address>

[Explanation]

With this, the system displays and modifies the specified program memory. This mode is continuous and each time `ã` is pressed, the succeeding address shall be displayed, setting operation shall be performed continuously until `.` is pressed. When `_` is pressed, the system goes back to the address immediately before. The address used with this command is polynomial. It is possible to use symbols in <address>.

[e.g]

>EPP_100

100 : 0D>37

101 : 77>AF

103 : 42> .

EPS (Exchange Program memory)

[Function]

To display and modify the specified data memory.

[Format]

EPS_<Address>

[Explanation]

With this, the system displays and modifies the specified program memory. This Mode is continuous and each time `ã` is pressed, the succeeding address shall be displayed and setting operation shall be performed continuously until `.` is pressed. When `_` is pressed, the system goes back to the address immediately before. The address used with this command is sequential. It is possible to use symbols in <address>.

[e.g]

>EPS_100

100 : 48>6

101 : 04>45

102 : 53>.

Chapter 5. Software

5 - 26

FPP (Fill Program memory)

[Function]

To fill the program memory area specified with <In> from the specified <address> with 1 byte data.

[Format]

FPP_<Address>_<In>_<Data>

[Explanation]

With this, the system fills the program memory area specified with <In> from the specified <address> with 1 byte data. It is possible to use symbols in <address>.

[e.g]

>FPP 10 0 L10 55

>DPP 100

0100 : 55 55 55 55 55 55 55 55 - 55 55 55 55 55 55 55 55 0127 : 10 11 12 13 14 15 16 17 - 18 19 1A 1B 1C 1D 1E 1F 011C : 20 21 23 24 25 26 27 29 - 29 2A 2B 2C 2D 2E 2F 30 0122 : 31 32 33 34 35 36 37 38 - 39 3A 3B 3C 3D 3E 3F 40 >

FPS (Fill Program memory)

[Function]

To fill the program memory area specified with <In> from the specified <address> with 1 byte data.

[Format]

FPS_<Address>_<In>_<Data>

[Explanation]

With this, the system fills the program memory area specified with <In> from the specified <address> with 1 byte data. It is possible to use symbols in <address>.

[e.g]

>FPS 10 0 L10 55

>DPS 100

0100 : 55 55 55 55 55 55 55 55 - 55 55 55 55 55 55 55 55 0110 : 01 00 11 01 01 20 00 00 - 01 00 00 0C 01 00 55 55 0120 : 01 00 11 01 01 20 00 00 - 01 00 00 0C 01 00 00 55 0130 : 01 00 11 35 01 20 00 55 - 01 55 00 55 55 55 55 55 >

Chapter 5. Software

5 -27

FD (Fill Dat a memory)

[Function]

To fill the program memory area specified with <In> from the specified <address> with one specified nibble data.

[Format]

FD_<Address>_<In>_<Data>

[Explanation]

With this, the system fills the data memory area specified with <In> from the specified <address> with one specified nibble data. It is possible to use symbols in <address>.

[e.g]

>FD 0 L3 4

>DD

000 : 4 4 4 0 0 0 0 0 - 0 0 0 0 0 0 0 0 010 : 0 0 0 0 0 0 0 0 - 0 0 0 0 0 0 0 0 >

Chapter 5. Software

5 - 28

G (Go)

[Function]

To execute the program in the specified program memory

[Format]

G_[<Address 1>][_<Address 2>].. .[ _<A ddress 8>]

[Explanation]

With this, the system executes the program address specified with =, [=<address 1>] is omittable. When omitted, the command is executed from the present `PC`

address. The system also sets a break point in the specified address after [_<address2>] . When `g` command is executed, simulation is started after outputting `RUN` message. When any key is pressed in this state, simulation is

stopped.

It is possible to use symbols in the <address>. [e.g]

RUN ******** User Break Point !! ******** 010E 20 LMAIY PC=01 PA=1D PB=01 A=7 X=1 Y=8 ST=1 PMR=0 WD=0000 MC=297 >

>G=.START 37 3

******** Go Break Point !! ******** 0003 BF BR 3F PC=00 PA=07 PB=06 A=F X=3 Y=5 ST=1 PMR=0 WD=0000 MC=808 >

Chapter 5. Software

5 - 29

H (Hex calculate)

[Function]

To add and subtract hexadecimal No. [Format]

H_XXXX_ XXXX

[Explanation]

Hexadecimal Nos. are added or subtracted. [e.g]

>H_e6ab _b7fc

9ea7 2ea f

LOGON (LOGIN)

[Function]

To log the commands executed after this command. [Format]

LOGON

[Explanation]

After executing this command, all the information displayed on CRT shall be

written consecutively until LOGOFF command is given. The file created in this

event is

LOG.DAT`.

[e.g]

>LOGON

Chapter 5. Software

5 - 30

LOGOFF (LOGOUT)

[Function]

To end logging [Format]

LOGOFF

[Explanation]

Logging is finished when this command is executed. [e.g]

>LOGOFF

LP (Load Program from MS-DOS* file)

[Function]

To read `file` on MS-DOS* and write it to the program memory of the simulator [Format]

LP_<file name>

[Explanation]

The system reads the file specified with <file name. RHX> and writes the data to

the address specified with <address>.

The file format is the Intel hexa format. [e.g]

>LP TEST. RHX

. . . . . . . . . . . . . . . . . . . . . . . . . .

. . . .

Program load OK!

Chapter 5. Software

5 - 31

MPP (Move Program memory)

[Function]

To transfer memory area data to other area. [Format]

MPP_<address_s>_<In>_<address_d>

[Explanation]

With this command, the system transfers data upto the No. of words specified

with <In> from the address specified with <address_s> to the area specified with

<address_d>.

The address used with this command is polynomial. [e.g]

>MPP 100 200 300

MPS (Move Program memory)

[Function]

To transfer memory area data to other area. [Format]

MPS_<address_s>_<In>_<address_d>

[Explanation]

With this command, the system transfers data upto the No. of words specified

with <In> from the address specified with <address_s> to the area specified with

<address_d>.

The address used with this command is sequential. [e.g]

>MPS 10 0 200 300

Chapter 5. Software

5 - 32

P (Port Set)

[Function]

To display and modify the specified I/O set registers. [Format]

P_aa_bb_cã (When setting R, D port)

aa : I/O set register name bb : Specify in or out c : Set value (0 or 1)

P_aa_cc ã / P_aa_cã (when setting K)

aa : I/O set register name bb : set value (one digit of a hexadecimal No.) c : Set value (0 or 1)

[Explanation]

The system sets the value in the specified I/O set register. [e.g]

Example of setting K > P K 8

> P

I/O Regs. Rin=0000 Rout=1111 D=00000000 OUT=0 K=1000(8h) >

2) Example of K0-K3 setting > P OUT 1

> P K1 1

> P

I/O Regs. Rin=0000 Rout=1111 D=00000000 OUT=1 K=0010(2h) >

(I/O setting registers used on this simulator)

• Dout (D port output register 6 or 8 or 10bit)

• K (K input register 4bit)

• Rout (R port output register 4bit)

• Rin (R port input register 4bit)

• OUT (OUT port output register 10bit(

Chapter 5. Software

5 - 33

Q (Quit)

[Function]

To return to PC-DOS

[Format]

[Explanation]

When this command is executed on the system with prompt (*display) waiting for a command, the system moves from `simulator` Mode to `MS-DOS*` Mode.

[e.g]

R (Register dump or change)

[Function]

To display and modify the register data.

[Format]

R_x

R_a=x

[Explanation]

With this, the register data is displayed and modified. When `Rã` only is executed, all the registers are displayed.

[e.g]

PC=00 PA=3E PB=00 A=0 X=0 Y=1 ST=1 PMR=0 WD=0000 MC=10392

SP=0 SR0=0000 SR1=0000 SR2=0000

>R PC=23

>R PC

PC=23 >R MC =0

>R MC

MC=0 >

Chapter 5. Software

5 - 34

(Registers used on this simulator)

Simulator setting registers

• MC (Machine cycle register 32bit)

GMS300 series

• PC (Program counter 6bit)

• PA (Page address register 4bit)

• PB (Page buffer register 4bit)

• A (Acc register 4bit)

• X (X register 2bit)

• Y (Y register 4bit)

• SP (Stack pointer register 2bit)

• SR (Stack register 10bit) Ø3

• ST (Status register 1bit)

• PMR (Pulse mode register 4bit)

• WD (Watch dog timer register 14bit)

Chapter 5. Software

5 - 35

SET (SETUP)

[Function]

To setup the operating mode for the simulator.

[Format]

SET_c_x

[Explanation]

This is used to setup the simulator. The following commands can be executed with this command.

• When setting symbols for Assembler and Unassembler.

SET L x

Here, the range of X is defined as in the below. 0 : Symbol shall be used. (Default) 1 : Symbol shall not be used.

•

SET PO x

0 : When I/O WRITE command is executed while executing G command, no

display shall be mode. (Default)

1 : When I/O WRITE command is executed while executing G command, the

values in the event shall be displayed on CRT screen.

2 : When I/O WRITE command is executed while executing G command, the

values in the event shall be displayed on CRT screen and the operating shall be stopped.

•

SET PI x

0 : In case I/O READ command is to be executed while simulating, the

system reads the value set on the port input register. The port input register setting is to be performed with `R` command.

1 : In case I/O READ command is to be executed while simulating, the

system stops before the execution. In this case, set the value on the port input register.

2 : Value is set on the port input register from I/O file (PORT.DAT).

The file is opened when this command is executed and the file shall not be reread. If there is no I/O file, error shall be issued.

Chapter 5. Software

5 - 36

Timing for setting port input register is :

a) When machine cycle of the file <current machine cycle after executing this

command, values shall be set on the port input register until the machine cycle of the file> current machine cycle while executing the first G or T command.

b) When machine cycle of the file = current machine cycle, setting is made

immediately before the next command is executed. In case there is a format error in I/O file while simulating, error message shall be output and the operation is stopped. In order to execute G or T command again, this mode has to be canceled first. (Execute SET PI 0 or SET PI 1.) Default value here is 0. All the I/O READ commands are read from the port input register. PORT.DAT format Machine cycle I Port Name I Data

(I indicates space or tab)

•

SET WD x

0 : Watch dog timer shall not be used. 1 : Watch dog timer shall be used. (No option)

Resetting watch dog timer

1) After executing WDTR command

2) After executing STOP command

3) After executing CR command

4) While converting to 0 with R command

5) When the set value is reached.

2 : Watch dog timer shall be used. (With option)

For resetting watch dog timer.

1) When SO command is executed to REMOUT output is added to the above 1) ~ 5). Defalut value here is 0.

Chapter 5. Software

5 - 37

[e.g]

1) Example of setting port input I/O file and measure in case of file format error.

>SET PO 1

>SET PI 2

>SET

CPU GMS30140 ROM 1024 Byte RAM 32 Nibble I/O Input [pi] = [2] Port Input file (PORT.DAT) I/O Output [po] = [1] Display Symbol [1] = [0] Search Watch Dog timer [wd] = [0] off >G

RUN ******** `PORTIN.DAT` File format error ******** 0001 07 DA PC=0 PA=01 PB=00 A=0 X=0 Y=0 ST=1 PMR=0 WD=0000 MC=235

In this case, execute SET PI 0 or SET PI 1 and cancel the Mode. Then you can execute the command again.

>SET PI 1

RUN

2) Example of setting watch dog timer

>SET WD 1

>SET

CPU GMS30140 ROM 1024 Byte RAM 32 Nibble I/O Input [pi] = [0] Port Input I/O register I/O Output [po] = [0] No Display Symbol [1] = [0] Search Watch Dog timer [wd] = [1] ON (no option) >

Chapter 5. Software

5 - 38

SL (Symbo l f ile Lo ad )

[Function]

To load the symbol table from the specified symbol file.

[Format]

SL_<file name>

[Explanation]

The system reads the symbol table from the specified symbol file. When symbols are use d w ith `U` or `A` or other comma nds on this system, this command should be executed first prior to the execution of those commands. When executing this command, the symbol table in the memory shall be cleared. Data not in the set format shall not be loaded. File format : Address_symbol_I

(_indicates space or tab. Space or tab after the symbol is valid but those coming later shall be ignored.) Address should be polynomial here.

[e.g]

>SL_TEST. CRF

. . . . . . . . . . . . . . . . . . . . . . . . . .

Symbol lo ad OK ! >

Chapter 5. Software

5 - 39

ST (Status)

[Function]

To display the internal set condition of the simulator.

[Format]

[Explanation]

The status of the simulator shall be displayed.

[e.g]

>ST

CPU GMS30140 ROM 1024 Byte RAM 32 Nibble I/O Input [pi] = [0] Port input I/O register I/O Output [po] = [0] No Display Symbol [1] = [0] Search Watch Dog timer [WD] = [0] OFF PC=00 PA=00 PB=00 A=0 X=0 Y=0 ST=0 PMR=0 WD=000 MC=0

SP=0 SR0=0000 SR1=0000 SR2=0000 I/O Reg. Rin=1111 Rout=1111 D=00000000 OUT=0 K=0000(0h) >

Chapter 5. Software

5 - 40

T (Trace)

[Function]

To execute the program in the specified program memory address in a single step.

[Format]

T_[=<address>] [_<step>]

[Explanation]

With this, the system executes the program in the specified program memory address by a single step. This command shall be valid until `.` key is pressed. That is, every time `ã` key is pressed after executing this command, the command is executed by one step. The No. of steps set here is in hexadecimal.

[e.g]

>T =F00 2

COUNT = 0000 LPBI 0D 0F00 1B PC=0F PA=01 PB=0D A=0 X=0 Y=0 ST=1 PMR=0 WD=0001 MC=0 COUNT = 0001 0F01 87 BR 07 PC=0D PA=07 PB=0D A=0 X=0 Y=0 ST=1 PMR=0 WD=0002 MC=2 .

Chapter 5. Software

5 - 41

TMT (Time calculate)

[Function]

To calculate time from No. of machine cycles and clock frequency.

[Format]

TMT_m_c

m : No. of machine cycles

Without any calculating factors.

c : Clock frequency (1K -10m)

Calculating factors must always be input in small letters. k (kilohertz) m (megahertz)

[Explanation]

With this, the system calculates time from No. of machine cycles and clock frequency. Range of obtainable time :

6ns - 7158h 16m 43s 770ms (nano second) (hour) (minute) (second) (millisecond) Calculating equation : machine cycle Ø (1/clock frequency Ø 6)

[e.g]

>TMT_1000_1m

6ms 0m 0ns >

Chapter 5. Software

5 - 42

TMC (Time calculate)

[Function]

To calculate No. of machine cycles from time and clock frequency.

[Format]

TMC_t_c

t : Time

Calculating factors must always be input in small letters. h (hour) m (minute) s (second) ms (millisecond) us (microsecond) ns (nano second)

c : Clock frequency (1K -10m)

Calculating factor must always be input in small letters. k (kilohertz) m (megahertz)

[Explanation]

With this, the system calculates No. of machine cycles and clock from time and clock frequency. Range of obtainable machine cycle : 1-14984999833500 Calculating equation : Time

(1/clock frequency Ø 6)

[e.g]

>TMC 6ms 1m

MC=1000 >

Chapter 5. Software

5 - 43

U (Unassemble)

[Function]

To unassemble the area specified with <In> from the specified <address> and to display in mnemonic.

[Format]

U_[<address>] [_<In>]

[Explanation]

With this, the system unassembles the area specified with <In> from the specified <address> and displays in mnemonic. When [<address>] [<In>] are omitted, unassembling is performed from the

address immediately after the display start address.

Default value for <In> is 16. However, [<address>] cannot be omitted separately.

[e.g]

>U 200 L4

0200 40 LYI 00 0201 21 LAM 0203 77 ALEI 0E 0207 AF BR 2F >

WP (Write Program to MS-DOS * file)

[Function]

To read data from the whole ROM area and write data in the file specified with <file name>.

[Format]

WP_<file name>

[Explanation]

With this, the system reads data from the whole ROM area and writes data in the file specified with <file name>. The file format is the same as the Intel hexa.

[e.g]

>WP_test. rhx

. . . . . . . . . . . . .. . . . . . . . . .

Program write

Chapter 5. Software

5 - 44

? (help)

[Function]

To display the list of commands of this simulator.

[Format]

[Explanation]

With this, the system displays the list of commands of this simulator.

[e.g]

GSEN-GMS30K Simulator Processor is GMS30K Series Version 1.0 A[<address>] - assemble LOGON - command logging start

BAT <filename> - command repeat LOGOFF - command logging end BC [bc] - breakpoint clear LP <filename>-load program from PC-DOS BL -list breakpoint(s) MPP <range> <address> - move BP [bp] <address> - set breakpoint MPS <range> <address> - move [S] <step> - set step breakpoint P <address> - port input/output CR - CPU reset Q - quit DD - dump data memory R [<reg>] [[=] <value>] - register DPP [<range>] - dump program memory SET <value> <range> - simulator setup DPS [<range>] - dump program memory SL - <filename> - symbol file load ED [<address>]-exchange data memory ST - simulator status dump EPP[<address>]-exchange program memory TMT <mc> <clock rate> - machine time EPS[<address>]-exchange program memor y TMC <time> <cl ock rate> - step FD <range> <h> - fill program memory T [=<address>] [<value>] - trace FPP <range> <hh> - fill program memory U [<range>] - unassemble FPS <range> <hh> - fill program memory WP <filename> - write program G [=<address> [<address>..]] - go ? - help dump H <value> <value> - hexa add, hexa sub ^A - command recall

![DOS command] - shell escape

DPP, EPP, FPP, MPP=polynomial address DPS, EPS, FPS, MPS=sequential address

Chapter 5. Software

5 - 45

HYNIX GMS34140, GMS34120, GMS34004, GMS34112, GMS34012 Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual
