Page 1
Round Coloured Nest of Tables
Assembly Instructions - Please keep for future reference
228/7591
Dimensions - Large
Width - 50.0cm
Depth - 50.0cm
Height - 42.0cm
Dimensions - Medium
Width - 35.0cm
Depth - 35.0cm
Height - 37.0cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400
Dimensions - Small
Width - 30.0cm
Depth - 30.0cm
Height - 33.0cm
Ｉｍｐｏｒｔａｎｔ –
Issue 1 - 9/12/09
If
800
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
• Do not stand or put weight on
the product during assembly,
this could cause damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• From time to time check that
there are no loose screws on
this unit.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Page 3
Components - Panels
Please check you have all the panels listed below
Large table top (1.8 x 50cm)
Large support x 2 (3 x 42cm)
(extra holes)
Medium table top (1.8 x 35cm)
Large base (3 x 42cm)
Large leg x 3(3.5 x 40.2cm)
Medium base (3 x 27cm)
Medium support x 2 (3 x 27cm)
(extra holes)
Small table top (1.8 x 30cm)
Small support x 2 (3 x 25cm)
(extra holes)
Medium leg x 3(3.5 x 35.2cm)
Small base (3 x 25cm)
Small leg x 3(3.5 x 31.2cm)
2
Page 4
If you have damaged or missing components,
Components - Fittings
call the Customer Helpline: 0345 6400 800
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
A B
50mm Screw x 18
Tools required
Phillips screwdriver
(medium)
40mm Screw x 18
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
Ruler/tape
measure
Small
hammer
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
3
Page 5
Assembly Instructions
Step 1
Attaching legs
Attach large legs to
large base and large
support .
Secure using screws
as shown.
Important note:
One end of Legs has
been labelled 'B'. This
must be located at the
bottom, for assembly to
large base .
Screws are longer
than screws . Take
care to ensure the
correct length screws
are used in each step.
LARGE TABLE
Step 2
Attaching top
Place large table top
upside down onto a
clean flat surface.
Carefully align the leg
frame and secure using
screws .
Note:
Screws are slightly
shorter than screws .
Take care to ensure the
correct length screws are
used in each step.
4
Page 6
Assembly Instructions
Step 3
Assemble Medium Table
Repeat steps 1 and 2 to
assemble the medium
table, using components
and .
Note:
Again, the bottoms of legs
are labelled 'B'. Assemble
to medium base .
MEDIUM TABLE
Step 4
Assemble Small Table
Repeat again to assemble
the small table using
components
and .
Note:
Legs are labelled 'B'
on the bottom. Assemble
to small base .
SMALL TABLE
5
Page 7
Assembly Instructions
Step 5
Carefully turn all 3
tables upright.
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400
Argos Ltd MK9 2NW
6
800
