Page 1
VICTORIA
DESIGNER COLLECTION
PV C Sy St em S In Cl ud e:
• 8 Fully directional adjustable PVC jets
• Anti-vortex saftey suction
• Color matched system trim
• HydroOzone ozone sanitation system
• Rigid PVC piping
• Self draining pump and system
• Soft Touch electronic on/off control
with 30-minute integral times
• 2.25 HP single speed pump
• Cable waste and overflow
• Requires 20 Amp Dedicated GFCI
The Victoria offers an oversized bathing well that allows two bathers complete
relaxation and space while seated on either the elevated footrest or against the
gently sloping backrest. Visit http://www.hydrosystem.com for more details on our
options and accessories.
OP tI On S
• Grab Bars
• Chromatherapy-LED Lighting System
• Chromatherapy-LED Mini Spotlights
• Microban Antibacterial Protection
• Extra high density fiberglass
• Custom jet and pump locations
• Armrests available
• Waterfall Fill Spout (recirculating
option available)
• Plated Metallic finish
• Additional directional Jets
• Swirling, Rotating, or Jumbo Jets
• Micro Therapy Jet
• Integral Waste and Overflow
• 1.5 HP Variable Speed Pump (digital
temperature display optional)
• Electronic low water protection
• In-line heater
• Mood Light
• Back Masseuse
• Neck Masseuse Pillow
• Hydro Fragrance
• Hydro Fusion
• Hydro Coat
• Hydro Express quick ship
29132 Avenue Paine. Valencia, CA, 91355
661.775.0686 | hydrosystem.com
Page 1 of 2
* Indicates options that are shown (listed in order from top to bottom/
left to right)
Page 2
VICTORIA
DESIGNER COLLECTION
AS S hO wn :
Whirlpool option with standard jets
Fe Atu re S Sh Ow n:
• Jets
• Anti-vortex suction
• Overflow location
Al SO A VAI lA bl e:
• Soaking tub only
• Whirlpool
• Thermal Air
• Combo
SI ze :
73.48.24
wAt er CAPA CI ty :
105 Gallons
we Ig ht :
XXX Pounds
mO de l 73 48 d Im en SI On S:
• (L)ength- 73”
• (W)idth- 48”
• (H)eight Finish- 24”
ACrylIC tub
• Acrylic models finished in 1/8” thick layer of deep lustrous acrylic
• Extra thick reinforced fiberglass
• Pre-wired pump on pump platform (standard pump location only)
• Integral E-Z level platform facilitates installation
• Non-skid bottom
72.5
CODES AND COMPLIANCES
Massachusetts code File no: P1-0614-491
29132 Avenue Paine. Valencia, CA, 91355
661.775.0686 | hydrosystem.com
9.5
19.75
36.25
Page 2 of 2
48
1.75
24
All specications and options subject to change without notice please
contact a Hydro Systems representative for more information.
Certain options or altering the pump/blower location may cause
the pump/blower to extend beyond the tub decking. For cutout
dimensions wait for unit to arrive. All specications subject to change
without notice.
