Hydro Systems HYDR1401 Specification sheet

Hydro Systems, Inc.

Mystique

The Mystique is designed with

a Mediterranean inuence,
adding classical elegance to
any bathroom. The Mystique
features molded armrests and
pillows at both ends of the tub
and six fully recessed swirling
back jets.

29132 Avenue Paine, Valencia, CA 91355

Phone [phone] • Fax [phone]

[e-mail] • www.hydrosystem.com

Available Sizes:

78”L x 44”W x 22¼”D
110 Gallons

Acrylic Tub – construction features

Acrylic models finished in 1/8” thick layer

of deep lustrous acrylic.

Extra thick reinforced fiberglass.
Pre-wired pump on pump platform

(standard pump location only)
Integral E-Z Level platform facilitates

installation.

Non-skid bottom.

PVC Systems – include:

4 Fully directional adjustable PVC jets
6 Swirling PVC jets
Anti-vortex safety suction.

Color matched system trim

HydrOzone ozone sanitation system
Rigid PVC piping
Self draining pump and system
Soft Touch electronic on/off control with

30-min. integral timer

2.25 HP Single Speed Pump
Cable waste & overflow

Hydro Systems – Options:

Available as Tub only, Thermal Air,

Whirlpool or Combo

Microban Antibacterial Protection
Extra High Density Fiberglass
Available less jet recess (TO;TAS)
Waterfall Fill Spout (recirculating

option available)

Custom jet and pump locations
Plated Metallic finish
Additional directional Jets
Swirling, Rotating, or Jumbo Jets
Micro Therapy Jet
Integral Waste & Overflow

1.5 HP Variable Speed Pump (digital

temperature display optional)

Electronic low water protection
In-line Heater
Chromatherapy-LED Lighting System
Chromatherapy-LED Mini Spotlights
Mood Light

Grab Bars
Back Masseuse
Neck Masseuse Pillow
Hydro Fragrance
Hydro Fusion
Hydro Coat
Hydro Express quick ship

Approvals & Listings

Commonwealth of Massachusetts

UPC & USPC - US & Canada

Page 1 of 2

Hydro Systems, Inc.

29132 Avenue Paine, Valencia, CA 91355

Phone [phone] • Fax [phone]

[e-mail] • www.hydrosystem.com

AS SHOWN:

Whirlpool option w/ standard jets

Must be set in Mortar Base

Must be set in mortar base.

Mystique

ALSO AVAILABLE:

Soaking Tub Only, Whirlpool, Thermal Air, Combo

Model GC AC A B C D E F G H I J K L M N Jet Pump

7844 N/A ✓ 77½” 43¾” 38¼” 10¼” 6¾” 6¼” 53” 22¼” 3” 18¼” 29” 4½” 24” 21½” 4 Std/

6 Swirl’g

Amps Volts Breaker

13.5 120 20 amp GFCI Protected 110 gal.

Dedicated Service Wat.Cap.

Island Drop-In

Model (L)ength (W)idth (H)eigth Finish

7844 75½” 41¾” 20¼”

Disclaimer: Certain options or altering the pump/blower location
may cause the pump/blower to extend beyond the tub decking.
For cutout dimensions wait for unit to arrive. All specifications
subject to change without notice.

2.25
