EILEEN 7438
DESIGNER COLLECTION
PV C Sy St em S In Cl ud e:
• 8 or 10 Fully directional adjustable
PVC jets
• Anti-vortex safety suction
• Color matched system trim
• HydroOzone ozone sanitation system
• Rigid PVC piping
• Self draining pump and system
• Soft Touch electronic on/off control
with 30-minute integral times
• 2.25 HP single speed pump
• Cable waste and overflow
• Requires 20 Amp Dedicated GFCI
(standard whirlpool only)
The Eileen is for those of you who are looking for clean lines and the simplicity of
a larger bathtub. The Eileen is your choice. Visit http://www.hydrosystem.com for
more details on our options and accessories.
OP tI On S
• *Grab Bars
• *Integral waste and overflow (linear)
• * Chromatherapy-LED Lighting System
• Chromatherapy-LED Mini Spotlights
• Microban Antibacterial Protection
• Extra high density fiberglass
• Armrests available
• Tile flange molded
• Custom jet and pump locations
• Plated Metallic finish
• Additional directional Jets
• Swirling, Rotating, or Jumbo Jets
• Micro Therapy Jet
• Integral waste and overflow (circular)
• 1.5 HP Variable Speed Pump (digital
temperature display optional)
• Electronic low water protection
• In-line heater
• Mood Light
• Back Masseuse
• Neck Masseuse Pillow
• Hydro Fragrance
• Hydro Fusion
• Hydro Coat
• Hydro Express quick ship
29132 Avenue Paine. Valencia, CA, 91355
661.775.0686 | hydrosystem.com
Page 1 of 2
* Indicates options that are shown (listed in order from top to bottom/
left to right)
Page 2
EILEEN 7438
11
54
19
DESIGNER COLLECTION
AS S hO wn :
Whirlpool option with standard jet
location
Fe Atu re S Sh Ow n:
• Jets
• Overflow location
• Drain location
Al SO A VAI lA bl e:
• Soaking tub only
• Whirlpool
• Thermal Air
• Combo
SI ze :
74.38.19
wAt er CAPA CI ty :
95 Gallons
we Ig ht :
80-140 Pounds
mO de l7 43 8 dI me nS IO nS :
• (L)ength- 74”
• (W)idth- 38”
• (H)eight Finish- 19”
CODES AND COMPLIANCES
Massachusetts code File no: P1-0614-491
ACrylIC tub
• Acrylic models finished in 1/8” thick layer of deep lustrous acrylic
• Extra thick reinforced fiberglass
• Pre-wired pump on pump platform (standard pump location only)
• Integral E-Z level platform facilitates installation
• Tub must be set in a mortar base
28
37
74
1.75
16.5
38
29132 Avenue Paine. Valencia, CA, 91355
661.775.0686 | hydrosystem.com
Page 2 of 2
All specications and options subject to change without notice please
contact a Hydro Systems representative for more information.
Certain options or altering the pump/blower location may cause
the pump/blower to extend beyond the tub decking. For cutout
dimensions wait for unit to arrive. All specications subject to change
without notice.
