INSTALLATION INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.

WARNING: WHEN USING YOUR HYDRO SYSTEMS TUB, BASIC PRECAUTIONS SHOULD BE FOLLOWED, SEE BELOW

WARNING: This product can expose you to chemicals including styrene, which is known to the State of California to cause
cancer. For more information, go to www.P65Warnings.ca.gov.

READ AND FOLLOW ALL INSTRUCTIONS

1. DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised at all times.

2. Use this unit only for its intended use as described in this manual. Do not use attachments not recommended by the
manufacturer.

3. Never drop or insert any object into any opening.

4. Do not operate this unit without the cover over the suction fitting.

5. The unit must be connected only to a dedicated electrical supply circuit that is protected by a Ground Fault Circuit
Interrupter (GFCI). The GFCI must be provided by the installer and should be tested on a routine basis by the homeowner.
To test the GFCI push the test button. The GFCI should interrupt power. Push the RESET button. Power should be restored.
If the GFCI fails to operate in this manner there is a ground current flowing, indicating the possibility of an electric shock.
Do not use the tub. Disconnect the power and have the problem corrected by a qualified service representative. Re-test
the GFCI, only when it is operating properly may the whirlpool tub be used.

6. A green colored terminal marked “Ground” is provided on the exterior of the control box. To reduce the risk of electric
shock, connect this terminal to the grounding terminal of your electrical service or supply panel with a conductor equivalent
in size to the circuit conductors supplying this equipment.

SAVE THESE INSTRUCTIONS FOR LATER REFERENCE

INSTALLATION INSTRUCTIONS

Read all instructions before proceeding with installation.

•

Inspect the tub before installation. If any damage or defects are found, do not install the tub. If the tub is not the right

•

size, model or color do not install the tub. Contact tech support at 661-775-0686 or email [e-mail]

INSTALLATION OF A THE METRO COLLECTION BATHTUB MUST MEET ALL APPLICABLE CODES AND REGULATIONS.

•

IMPORTANT­All tub and systems are thoroughly tested and inspected at the factory prior to shipment. However, it is possible for

damage to occur during shipment and installation. Such damage is not always readily visible. To maintain the warranty, it
is important to water test the tub, integral overflow and thermal system a minimum of 30 minutes for leaks during rough
inspection before enclosing the tub. Hydro Systems is not responsible for the cost to remove/reinstall a tub.

USER MAINTENANCE INSTRUCTIONS

CARE AND CLEANING­To assure a long lasting “like new” look on your Metro Collection bathtub we recommend the following easy
care procedures:

1) For normal maintenance, especially after use, clean with a soft cloth or sponge and a mild soap or liquid detergent.

2) DO NOT USE abrasives such as scouring compounds, scouring pads, steel wool or harsh chemicals on your

Hydro Systems bathtub. For deeper stains, hard scale deposits or any other cleaning or maintenance problem,

contact your Hydro Systems dealer.

1

CLEANING INSTRUCTIONS

The Metro Collection Tubs are manufactured from High-Quality HydroLuxe, a blend of both organic minerals
and the best in engineered composites. This blend combines a cast acrylic polymer for it’s benefits in durability
and bonding strength, and ATH which is derived from Bauxite Ore. Bauxite is an aluminum ore, found mostly in
tropical regions, and is the main source of aluminum. ATH is also natural fire-retardant. The nonporous surface
is able to prevent dirt from gathering and withstands stains better than the other materials. To keep this high
quality look on your Metro tub, please follow these instructions:

MATTE FINISH

• Remove dust with a soft damp cloth, for example; microfiber or calico cloths.

• Clean surface with water and any mild detergent or dish soap.

• For a more difficult stain such as oil, paint, ink or grease clean with rubbing alcohol and dry with a soft cloth.

• Please do not use any sharp objects because that might result in scratching the surface of the tub.

• Use 180 grit wet/dry sandpaper and clean it with a soft scrub.

GLOSS FINISH

• Clean with mild dish soap and water, any non abrasive product to clean high-gloss counter surfaces will work.

• Remove dust with a soft damp cloth, for example; microfiber or calico cloths.

• Clean oil, paint, ink or grease with rubbing alcohol and dry with a soft cloth.

• Avoid using abrasive cleaners, it is not safe to use these on your glossed product.

• Please do not use any sharp objects because that might result in scratching the surface of the tub.

Please do not use anything else other than what was instructed. Improper use can result in damage to the tub or
its finish and may void the warranty. Keep in mind, if you do end up damaging the tub, scratches can usually be
removed, buffed or polished out by an Authorized Hydro Systems Service Agent.

Please refer to www.hydrosystem.com for videos on how to install your bathtub and get specific dimensions on your

model bathtub

FREESTANDING INSTALLATION

FIGURE 1

(For exposed drain see Page 6)

PREPARATION

1

Clean, level, and prepare the floor for installation.

Place the unit in the exact installed position on the floor

2

and trace the outline of the bath with a pencil or any
erasable marking (Figure 1). Templates for Freestanding
bathtubs come with the tub.

3

Determine the location of the drain pipe on the floor
by taking measurements of the drain and waste location
underneath the unit (Figure 2).

Note: Drain, waste locations, and trim options
vary by model.

FIGURE 2

Using a blanket, cardboard, or other clean protective

4

surface, turn the unit on its side so that the unit is
properly supported during drain installation.

Clean the drain hole area in preparation of setting the

5

drain. The area should be dry and free of any debris.

2

Please refer to www.hydrosystem.com for videos on how to install your bathtub and get specific dimensions on your

model bathtub

FIGURE 3

INSTALL DRAIN HARDWARE

Apply plumbers putty around the Drain Body and pass it

6

thrugh the drain hole (Figure 3).

Apply rubber gasket and slide it over the

7

bottom of the Drain Body (Figure 3)

FIGURE 4

FIGURE 5

FIGURE 5

Slide the rubber washer over the drain body.

8

Attach the drain Body to the ABS/ PVC Shoe fitting and

9

tighten until the Gasket has created a seal with the bottom
of the bathtub. DO NOT OVERTIGHTEN (Figure 4).

PREPARE TAIL PIECE

Drain waste vent must always be installed according to

10

local standard. Verify the placement of the bathtub before
drilling the hole for the drain waste vent.

tail piece (shoe)

Install 1 ½"rubber slip gasket over the drain body.

11

Thread in shoe.

12

13

Glue shoe to tail piece.
