Hydro Systems A P18 User Manual
Mini Washing Machine
This manual is for
A P18
User's manual
Please read this manual
carefully before using.
Retain it for future reference.
The machine is for cold water
connection only.
0030807309
Contents
Packing list........................................................................................the 2ndcover
Names of the parts................................................................................................1
Safety precautions .............................................................................................2
Installation and adjustment ...................................................................................4
Preparation before washing .................................................................................5
Putting clothes in ..............................................................................................6
Usage of the detergent.........................................................................................6
Process washing...................................................................................................7
Disposal after washing .......................................................................................8
Trouble shooting ...........................................................................................9
Specifications.....................................................................................9
Packing list
Name
User's manual
Warranty manual
Water inlet hose
Washing machine
Quantity
One
One
One
One
Top lid
Names of the parts
Filter cover
Control panel
Button
Cabinet
Base frame
Knob
MAX
3
2
1
Pulsator
Power line
fixed foot
Meaning and description of the symbols
Warning sign
Forbidden sign
Contents marked with this symbol are related to the safety
of the product and the personal safety of the users. Please
operate in strict conformity to the instructions, otherwise it
may cause damage to the machine or endange the
personal safety of the user.
Contents marked with this symbol are actions forbidden to
perform. Performing of those actions may result in
destruction of the machine or permanent injury to the user.
Water-filling
entrance
Handle
Drain hose
1
Safety precautions
Please plug the washer into a
220V-240V a.c receptacle. Be sure
to use single-phase three pin
receptacle. Ensure the earthing
prong of the power receptacle is
earthed reliably. Use leakage
protector if possible.
Earth
Do not twist pinch or otherwise damage the cord,
if the cord or plug becomes damaged.Return the
unit to the supplier for repair.
Do not put the machine in damp places like
the bathroom. Never wash it with water.
Do not put wet clothes on the control panel.
In normal usage of the washing machine,
the power plug should be ready to be pulled
out easily. Be sure to pull the plug out and
close the water faucet in following cases:
power failure, installing the machine,
leaving the machine idle or cleaning the
machine. Do not push or pull the power plug
with wet hand.
If the appliance is supplied from an
extension cord or electrical portable outlet
device the plug
should be positioned
so it is not subject to
splashing or ingress
of moisture.
Do not use water hotter than 50 C .
If the washing machine is installed on
carpet, do not block the ventilation hole
with carpet.
soft items
Do not let the machine share one power point with other
electric appliances. If the power plug is damaged or
loose, do not use the plug any more.
The ventilation holes
at the bottom
Do not wash water-proof items like
the raincoat, bike covers etc.
2
