RLNIE Back-to-Back
RLNIE End Case
RLNI/RLNIE
The Ultimate Reach-In Merchandising Solution
for Frozen Food Applications
– Available with Hussmann “Innovator”,
“Innovator II” or “Innovator III” Glass Doors.
www.hussmann.com
Hussmann Ultimate Reach-In Merchandising Solution
2, 3, 4, and 5 Door
26
1
/
2
(673)
Refrigeration
Outlet
A
Front Relay & Terminal
Block Location
Front
5-Door Shown
72
3
/
8
(1838)
Electrical Wireway
Bottom
Front
Support
Skid/
External
Base
Electrical Wireway
Refrigeration Outlet
Rear Relay & Terminal Block Location
Splashguard
Waste Outlet
26
1
/
2
(673)
125
3
/
8
(3185)
Door Swing
Door Swing
Dimension 2 DOOR 3 DOOR 4 DOOR 5 DOOR
A 62 (1575) 92 1/2 (2350) 122 7/8 (3121) 153 3/8 (3896)
for Frozen Food Applications
RLNI - Back-to-Back Reach-In
RLNIE - Back-to-Back Reach-In End Case
Available with 2, 3, 4, and 5 doors.
1
(1689)
66
RLNI
2 1/8
(54)
/2
RLNIE
82 1/4
(2089)
67
(1702)
Frame
65 1/2
(1664)
Door
13 1/8
(333)
Frame
1
6
/4
(159)
72 (1838)
70 (1778)
Plan Views
RLNI
Notes:
Overall case length
without ends or
partitions.
Less Floor Space Required.
Installing standard reach-ins back to back requires about
88-inch of floor space, from bumper to bumper. The RLNI is
72-inch wide, bumper to bumper, saving about 16-inch.
Reduced Installation Labor.
Because the RLNI and the RLNIE are unitized, there is no need
(2108)
83
to set and line up two rows of back-to-back cases or add
separate end cases.
Perfect for Wide Island Replacement.
If you want to increase frozen food product facing, this is an
ideal way to do it. Most wide islands are about 82-inch wide.
You can replace them with the 72-inch RLNI and watch your
product facing skyrocket.
3
4
/4
(120)
Same Product Capacity
as Standard Reach-Ins.
The product capacity per door in the RLNI is identical to
the capacity of the standard depth RL. Maximum shelf depth
of 22-inch is the same in both cases.
Greater Energy Efficiency.
Innovator III doors are 43% more efficient than Innovator doors
and provide 13% total case energy savings compared to a case
with Innovator doors. Innovator III is a lower energy heated door
that can be used in all climate conditions.
For even more energy savings, Innovator II is a no-heat door that
offers 32% case energy savings.
4
126 1/
(3207)
Door
Swing
Clearance
Relay &
Terminal
Block
Location
1
2
/
26
(673)
1
2
26
/
Relay & Terminal
(673)
Block Location
Electrical Wireway
Electrical Terminal Block
1
2
/
26
(673)
Electrical Wireway
Waste Outlet
RLNIE
Printed in U.S.A. ©2012 Hussmann Corporation RLNI_RMNIE_111212
Front of Case
Waste Outlet
Electrical Wireway
Rear of Case
99 3/
4
(2534)
Relay & Terminal
Block LocationMain Field Connection
Splashguard
Refrigeration
Outlet
Door Swing
Clearance
Door Swing
Clearance
72 3/8
(1838)
125 3/
(3185)
Standard LED Lighting.
EcoShine II LED lighting is standard. The lights are optimized
for uniform brightness and substantially lower energy costs
compared to fluorescents.
Hussmann refrigerated merchandisers configured for sale
for use in the United States meet or surpass the requirements
of the DOE 2012 energy efficiency standards.
NOTE: These merchandisers are designed for use in stores when
temperature and humidity do not exceed 75°F and 55% R.H.
NOTE: We reserve the right to change or revise specifications and product
design in connection with any feature of our products. Such changes do
not entitle the buyer to corresponding changes, improvements, additions,
or replacements for equipment previously sold or shipped.
For additional resources, contact your representative or visit
www.hussmann.com.
8
Note
Use Hussmann’s technical data sheets to
get precise dimensions for all store layout
purposes.
