RLNE
Narrow Reach-In End Case
for Frozen Food and Ice Cream Applications
Available with Hussmann Innovator, Innovator II,
or Innovator III Glass Doors
www.hussmann.com
RLNE
RLNE -
Reach-In, Low Temp, Narrow Front-to-Back Dimension End Case
82 1/4
(2089)
67
65 1/2
(1664)
Door
13 1/8
(333)
Frame
Electrical
Field
Connection at
the Terminal
6 1/4
(159)
2 1/8
(54)
36 1/2
(927)
61 1/4
(1556)
34 3/8
(873)
24 (610)
1/2
(13)
84 1/8
(2137)
Features and Benefits
- A line-up using the RLNE end case can save up to
7-1/8” in length per end compared with the same
line-up using an RLN for the end case. This 7-1/8”
reduction in length is made up of:
- No back brace or air gap = 4”
- No end panel, thin partition = 1-3/4”
- Flat front option = 1-3/8”
- With the RLNE on both ends, you can save up to
14-1/4” in length compared with the same line-up
using RLN end cases.
- There is no stand-off frame on the back of the RLNE.
It is attached directly to the end of the reach-in
line-up with a thin partition.
- The RLNE can be used as an end for back-to-back
RL or RLN line-ups.
- It can be used as an end case for an RLNI line-up.
- When used with one row of RL or RLN cases, dry
shelving can be used on the back of the line-up.
Options Include
- Standard or flat front.
- Various shelves, racks, lighting, paint
and bumper colors.
- Innovator, Innovator II or Innovator III doors available.
28 (711)
25 3/8 (645)
Notes
- Use Hussmann’s technical data sheets to get precise
dimensions for all store layout purposes.
Electrical
Stub - Up
Area
3 1/2
(89)
35 1/4 (895)
37 1/8 (943)
Plan View
A
B
Refrigeration
Outlet
Case to Case
Joining Bracket
35
(895)
Electrical Field
Connection at
the Terminal
Skid Base
6
4
(152)
(102)
1/4
Splashguard
12
1/4
(311)
Skid Base
Bottom
Front Support
Front
48
(1219)
Waste
Outlet
Door Swing Clearance
C
12
1/4
(311)
1
3/4
(44)
NOTE: These merchandisers are designed for use in stores when temperature and humidity do not exceed 75°F and 55% R.H.
NOTE: We reserve the right to change or revise specifications and product design in connection with any feature of our
products. Such changes do not entitle the buyer to corresponding changes, improvements, additions, or replacements for
equipment previously sold or shipped.
For additional resources, contact your representative or visit www.hussmann.com.
2
3/8
(60)
5
5/8
(143)
25
3/8
28
(711)
35
(889)
(645)
4
(102)
37
(943)
63
5/8
(1616)
1/8
Hussmann refrigerated merchandisers configured for sale
for use in the United States meet or surpass the requirements
of the DOE 2012 energy efficiency standards.
RLNE
2-Door
RLNI
2
7/8
(73)
2
7/8
(73)
RLNE
2-Door
RLNI
2
7/8
(73)
2
7/8
(73)
RLNE
3-Door
RLN
RL
2
7/8
(73)
37
(940)
41
(1041)
56
3/8
(1432)
Above shows case lineup on left.
RLNE
2-Door
RLNI
2
7/8
(73)
2
7/8
(73)
RLNE
2-Door
RLN
RL
2
7/8
(73)
37
(940)
41
(1041)
25
7/8
(657)
Above shows case lineup on left.
Lineup may also be joined on the right.
(Top View)
(Top View)
Reach In Line-up
Reach In Line-up
RLNE Space Savings
Reduce line-up length by
up to 14-1/4” with RLNE
vs. RLN end cases.
Line-Up Options
41
2
7/8
(73)
37
(940)
RLN
(1041)
RL
25
(657)
7/8
RLN
RLN
(Top View)
Reach In Line-up
RLNE RLNE
SAVE UP TO
14-1/4”
with Two RLNE
Cases*
41
2
7/8
(73)
2
2
7/8
(73)
(73)
7/8
RLNI
(1041)
37
(940)
RL
RLN RLN
15
(391)
RLN
RLN
3/8
* Savings includes
flat front option
on RLNE cases
41
(1041)
37
(940)
RL
2
7/8
(73)
Lineup may also be joined on the right.
RLNE
2-Door
Above shows case lineup on left.
RL or RLN Single Row,
RLNE 2-Door End Cap
RLNE
2-Door
RLNI Line-Up
with 2-Door End Cap
Enabling excellence in food retailing.
RLNE
3-Door
RL or RLN Back-To-Back Line-Ups
with RLNE 3-Door End Cap
2
7/8
(73)
41
37
(940)
(1041)
56
(1432)
3/8
RL
RLN
RLNE
3-Door
Above shows case lineup on left.
Lineup may also be joined on the right.
RL or RLN Single Row,
RLNE 3-Door End Cap
Hussmann Corporation
12999 St. Charles Rock Rd.
Bridgeton, MO 63044-2483
Ph: 314.291.2000
www.hussmann.com
Printed in U.S.A. ©2015 Hussmann Corporation RLNE_041615
