Specialty
Q3-M/FS-EP
Q-Series Family
Multi-Deck Merchandiser with Straight Glass
for Meat and Seafood (non ice) Applications
Enhanced Performance with OptiCool™ Technology
www.hussmann.com
Hussmann Q-Series Multi-Deck Merchandiser
Q3-M/F-EP
DOE 2017
Energy Efficiency
Compliant
Hussmann refrigerated merchandisers
configured for sale for use in the United States
meet or surpass the requirements of the
DOE 2017 energy efficiency standards.
with Straight Glass for Meat and Seafood (non ice) Applications
Q3-M/FS-EP
Increase shelf life. Save 35% on Energy‡
Day
1
For optimum performance, reference the merchandising requirements †
Day
2
EXTENDED
Day
Bloom
Enhanced performance with OptiCool™ Technology
• Reduces dehydration by 60%‡
• Increases humidity by 12%‡
• Reduces temperature variance‡
Reduced system complexity, costs
• Simple installation
• All DX refrigeration at +28 F evap
• No glycol pump station required
EcoShine II Plus LEDs (Standard)
• 85+ CRI for bringing out natural colors
(especially meat, deli and seafood)
• Diused lighting eliminates pixilation,
hot spots on product packaging
• Increased reliability with
industry leading IP67
certification
Remote Lengths: 4', 6', 8', and 12'
Q3-M/FS-EP Service Meat or Fish
10 (254)
(257)
14 3/8
(365)
45 3/8
Gravity Coil
33
72
(1829)96(2438)
1/2 (851)
Spiral Coil
29 1/2
(749)
C
L
(127)
201/4
(514)
wrapping
57/8
(149)
5
Drain
17 1/8
(435)
144
(3658)
45 5/8
(1159)
29
(737)
23
(584)
8
(203)
End Panels
1 1/8 (29)
20
(508)
10 1/8
Optional
board
(1321)
25
(635)
Refrig
14
(356)
End Panels
1 1/8 (29)
52
Ergonomics
Large rear door opening
and angled back improves
product access.
Note.
Use Hussmann’s technical
data sheets to get precise
dimensions for all store
layout purposes.
6 1/8
(156)
3
Features and Benefits:
- Anti reflective, tempered, lift-up,
straight front clear glass
- Large clear glass sliding rear doors
- Gravity/conduction coil (Meat)
- Gravity coil, conduction coil (non ice) (Fish)
- Ecoshine II IP67 rated LED lights
- Stainless steel interior pans
- Adjustable deck for flexible merchandising
- Adjustable stainless steel legs
- Stainless steel top cover
- Black matrix on the glass to hide the coil
- Black powder-coated coil cover
- Solar digital thermometer
- Front glass air sweep
- Digital thermostat and suction stop installed
- Black vinyl cart bumper
- Please reference color chart for choice of standard
Hussmann paint and finish options
Options Include:
- Coil corrosion protective coating
- Automatic or manual water flush (reduces the
need for manual case cleaning)
- Corian®, granite or other solid surface front
and/or top ledge (NSF approved material)
- Mirrored rear doors
- Thermoplastic wrapping boards w/adjustable riser
- View or solid ends
- Mirror bright stainless steel inside end panels
- Stainless steel pedestals
- Top mounted scale stand extensions with
dedicated scale outlet and Cat 5 scale connections
- Liquid line shut-o hand valve
- 15 amp GFCI duplex outlet
- Custom trim and decor
- Custom lengths and options*
(consult your Hussmann sales representative)
- Special exterior finishes*
(consult your Hussmann sales representative)
Additional Information:
- Q-Series Entire Family: Q-Series Family
- Single-Deck Service Deli Straight Glass: Q1-DS
- Single-Deck Self-Service Deli: Q1-SS
- Service Hot Curved Glass: Q-HC
- Multi-Deck Service Bakery Straight Glass: Q3-BS
- Multi-Deck Service Deli Straight Glass: Q3-DS
- Multi-Deck Self-Service Deli: Q3-SS or Q4-SS
- Multi-Deck Self-Service w/ Service Top Deli: Q3-SP
* Some optional features may need to be certified by UL, NSF, and/
or other 3rd party certification agencies. Contact Hussmann for
verification or questions for availability.
† For optimum performance product must be in direct contact
of the deck. Reference detailed merchandising requirements
located in the Installation guide @ www.hussmann.com
‡ Performance results based on equivalent standard Hussmann
models
NOTE: These merchandisers are designed for use in stores when
temperature and humidity do not exceed 75°F and 55% R.H. We
reserve the right to change or revise specifications and product
design in connection with any feature of our products. Such
changes do not entitle the buyer to corresponding changes,
improvements, additions, or replacements for equipment previously
sold or shipped.
Printed in U.S.A. ©2015 Hussmann Corporation Q3M/FS-EP_022515
Hussmann Specialty
13770 Ramona Avenue
Chino, California 91710-5423
Ph: 800.395.9229
www.hussmann.com
