PW-E
Excel Wide Island Produce
Display Merchandiser
www.hussmann.com
Hussmann Excel Wide Island Display Merchandiser
Waste Outlet & Water Seal
A
Base Rail
Refrigeration Outlet
Access Area
C
L
57/
8
(149)
17
(432)
575/
8
(1464)
745/
8
(1895)
Dimension 6 FT 8 FT 12 FT
A 72 1/4 (1835) 96 3/8 (2448) 144 1/2 (3670)
FRONT
for Bulk Produce Applications
PW-E - Refrigerated Island
PWEE - Refrigerated Island End Case
Available in 6’, 8’ and 12’ lengths and with a 5” extended center flue (PW-E).
PW-E PWEE
44
(1118)
30 3/8
(772)
5 (127)
27 3/4
(705)
30 3/8
25 1/8
(648)
17 3/8
(441)
8 1/4 (210)
25 1/2
52 3/8
(1331)
Plan View
PW-E PWEE
74 11/16
(1898)
Notes:
Overall case length
without ends or
partitions.
Front
Waste
Outlet
& Water
Seal
17
(432)
37
(946)
Base Rail
1
4
/
1
20
(514)
7
5
/
8
(149)
Access Area
15 (381)
24 1/2
44
16 5/8
20 1/4
37 1/4
4
/
Notes:
Maximum outside
dimension of case
5
8
57
/
74
(1895)
17
(side-to-side)
includes bumper.
Overall case length
without ends or
5
/8
partitions.
(1464)
7
8
5
/
(149)
(432)
Note
Use Hussmann’s technical data sheets to get precise dimensions for all store layout purposes.
Excellent Refrigeration Performance.
Designed for bulk produce applications, the PW provides dramatic advances in
refrigeration performance for produce island displays. A unique coil, center flue
and air discharge design forces cold air through products. Produce is kept colder
with very stable and consistent temperatures throughout the entire display area.
Each end case also has a dedicated coil and fan package to ensure superior
refrigeration performance.
Less Refrigerant Needed.
Hussmann modular coils require 50% to 60% less refrigerant within the coil
than full length coils.
Pre-Set Expansion Valves.
All TXVs used with modular coils are adjusted at the factory.
This produces two important benefits:
1. Faster installations.
2. Valves that operate at peak performance settings.
Printed in U.S.A. ©2012 Hussmann Corporation PWE_101712
Quick, Easy Cleaning.
High impact polystyrene bottoms with seamless, radius corners are leak-proof,
rust-proof and much easier to clean. Lift-out back panels provide quick access to
fan assembly.
Solid Durability.
Heavy-duty corner assemblies are designed to stand up to the punishment of daily
abuse. True shock absorbing dual bumper system further protects case exterior.
Heavy-duty base and skids.
Hussmann refrigerated merchandisers configured for sale
for use in the United States meet or surpass the requirements
of the DOE 2012 energy efficiency standards.
NOTE: These merchandisers are designed for use in stores when temperature and humidity
do not exceed 75°F and 55% R.H.
NOTE: We reserve the right to change or revise specifications and product design in connection
with any feature of our products. Such changes do not entitle the buyer to corresponding
changes, improvements, additions, or replacements for equipment previously sold or shipped.
For additional resources, contact your representative or visit www.hussmann.com.
