D
P/N0453529B
E5
Technical Data Sheet
P/N 0453529_B
NSF
®
Certified
April 2010
Item Part # Description Wiring Item #
F
AN ASSEMBLIES AND THERMOSTATS
A. 12W Standard Fan Assembly (1)
0047000 Fan Motor, Evaporator
(MO.4410311)
0315470 Fan Blade, (FB.0315470)
embossing toward motor
12W Energy Efficient Fan Assembly (1)
0477655
Fan Motor, Evaporator
(MO.4410546)
0315470 Fan Blade, (FB.0315470)
embossing toward motor
B. 0411744 Standard Non-adjustable (2)
Defrost Thermostat (CT.0411744)
C. Optional Adjustable Refrigeration Thermostat (3)
Item Part # Description Wiring Item #
L
AMPS AND BALLASTS
D. Ballast, Electronic (4)
0466234 2 lamps (BA.4480823)
0466235 3 lamps (BA.4480901)
0466236 4 lamps (BA.4481095)
E. Fluorescent Lamp (5)
Replace with like fixtures
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
©2010 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
Note: Revision B adds Btu note for energy efficient fans on page 3, adds page 5, revises load limit line on page 8 and updates
pages 1, 2 & 4, . Changes are underlined, circled or marked with a bar in margin.
B
D
C
E
E
A
2 of 8 E5 Technical Data Sheet
U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900
4 ft 6 ft 8 ft 12 ft
General
(A) Case Length (without ends or partitions) 48 1/8 (1222) 72 1/8 (1832) 96 1/4 (2445) 144 3/8 (3667)
NOTE: Each end or insulated partition adds 1 inch to lineup.
Maximum O/S dimension back to front (with bumper) 46 1/
2 (1181) 46
1
/
2 (1181) 46
1
/
2 (1181) 46
1
/
2 (1181)
Back of case to front of front panel 34
1
/2 (876) 34 1/2 (876) 34 1/2 (876) 34 1/2 (876)
Back of case to O/S edge of front skid rail 29 3/8 (746) 29 3/8 (746) 29 3/8 (746) 29 3/8 (746)
Width of skid rail 4 1/
2 (114) 4
1
/
2 (114) 4
1
/
2 (114) 4
1
/
2 (114)
RH end of case to outside edge of external support 1
3
/
8 (34) 1
3
/
8 (34) 1
3
/
8 (34) 1
3
/
8 (34)
Distance between edges of
external support and center support NA 28
1
/2 (724) 40 1/2 (1029) 40 1/2 (1029)
Distance between edges of center supports NA NA NA 44 (1118)
Stub-up area between front skid rail and front panel 5 3/4 (146) 5 3/4 (146) 5 3/4 (146) 5 3/4 (146)
Electrical Service (Electrical Field Wiring connection point)
(B) Length of electrical raceway 18 3/8 (467) 18 3/8 (467) 37 (940) 37 (940)
(C) RH End of case to center of farthest knockout 36 5/8 (930) 60 3/4 (1543) 84 3/4 (2153) 132 3/4 (3372)
Back of case to center of end knockout 29 5/8 (752) 29 5/8 (752) 29 5/8 (752) 29 5/8 (752)
(D) RH End of case to RH end of raceway 27 5/8 (702) 51 5/8 (1311) 57 1/4 (1454) 105 1/8 (2670)
LH End of case to LH end of raceway 2
1
/8 (54) 2 1/8 (54) 2 1/8 (54) 2 1/8 (54)
Waste Outlet
(E) RH End of case to the center of waste outlet 24 1/4 (616) 24 1/4 (616) 24 1/2 (622) 72 1/4 (1834)
LH End of case to the center of waste outlet 23
7
/8 (606) 47 7/8 (1216) 71 3/4 (1822) 72 1/8 (1832)
Back O/S of case to center of waste outlet 27 5/8 (702) 27 5/8 (702) 27 5/8 (702) 27 5/8 (702)
Water Seal
Edge of water seal to center of waste outlet 4 (102) 4 (102) 4 (102) 4 (102)
Schedule 40
diameter of the drip pipe 1 1/2 (38) 1 1/2 (38) 1 1/2 (38) 1 1/2 (38)
NOTE: Water seal outlet must clear front skid rail;
water seal rotation in forward direction only due to low base.
Refrigeration Outlet
Back of case to center of refrigeration outlet 30 3/4 (781) 30 3/4 (781) 30 3/4 (781) 30 3/4 (781)
RH end of case to center of refrigeration outlet 8 3/8 (213) 8 3/8 (213) 8 3/8 (213) 8 3/8 (213)
Engineering
Plan Views
Dimensions shown as inches and (mm).
04-2010
E5
Delicatessen
Precut & Packaged
Produce
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.)
3
/8
Merchandiser Suction Line (in.)
7
/8
B
Electrical Service
1
2
/8
(54)
29 5/8
(752)
Waste Outlet
A
C
L
C
Water Seal
D
27 5/8
(702)
E
30 3/4
(781)
8 3/8 (213)
34 1/2
(876)
46 1/2
(1182)
Front
3 of 8P/N 0453529_B
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
FAN
C
O
I
L
Refrigeration
Outlet
15 3/4
(400)
25 3/8
(645)
73
(1854)
4 1/4
(108)
12
(305)
22
(559)
46 1/2
(1182)
12
(305)
27 5/8
(702)
31
(787)
30 3/4
(781)
34 1/2
(876)
52
(1321)
E5
Impact
Elite
E5
Delicatessen
Precut & Packaged Produce
Elite Specialty Merchandiser Multi-deck, 5 Display Levels
Dimensions shown as inches and (mm).
See Page 8 for
recommended
shelf configuration.
NSF Certification
This merchandiser model is manufactured to meet ANSI/NSF
(National Sanitation Foundation) Standard #7 requirements for
construction, materials & cleanability.
REFRIGERATION DATA
Note: This data is based on store temperature
and humidity that does not exceed 75 (°F)
and 55% R.H.
E5
Discharge Air (°F) 29
Evaporator (°F) 21
Unit Sizing (°F) 19
Btu/hr/ft
‡
— Unlit Shelves
‡‡
E5
Parallel 1375
Conventional 1500
‡
Optional energy efficient motors reduce the
refrigeration load by 27 Btu/hr/ft.
‡‡
Add 20 Btu/hr/ft per shelf row for
fluorescent lamps.
DEFROST DATA
E5
Frequency (hr) 6
Defrost Water (lb/ft/day)8
(± 15% based on case configuration and
product loading).
OFFTIME E5
Temp Term (°F) 48
Failsafe (minutes) 35
ELECTRIC OR GAS Not Recommended
Standard Defrost Thermostat
Close on rise: close 48°F – open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control
CI/CO
* E5
Temp (°F) 14 / 4
Indoor Unit Only, Pressure Defrost
Termination (Temp °F)
*
48°F
*Use a Temperature Pressure Chart to
determine PSIG conversions.
Estimated Charge ** E5
4 ft 1.40 lb 22 oz 0.6 kg
6 ft 2.10 lb 34 oz 1.0 kg
8 ft 2.70 lb 43 oz 1.2 kg
12 ft 3.90 lb 62 oz 1.8 kg
**This is an average for all refrigerant types
actual refrigerant charge may vary by
approximately half a pound.
Electrical Data
4 ft 6 ft 8 ft 12 ft
Number of Fans — 12W 1223
Amperes Watts
4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
Evaporator Fans
120V 60Hz Standard 0.65
1.30 1.30 1.95
50 100 100 150
120V 50Hz Standard 0.75 1.50 1.50 2.25 57 114 114 171
230V 60Hz Export NA
230V 50Hz Export NA
120V 60 Hz Energy Efficient 0.30 0.60 0.60 0.90 18 36 36 54
230V 60Hz Energy Efficient NA
Cycling Anti-sweat Heaters NA
Minimum Circuit Ampacity
120V 60Hz Standard 0.85 1.50 1.50 2.15
120V 50Hz Standard 0.95 1.70 1.70 2.45
230V 60Hz Export NA
230V 50Hz Export NA
120V 60 Hz Energy Efficient 0.50 0.80 0.80 1.10
230V 60Hz Energy Efficient NA
Maximum Over Current Protection 120V 20 20 20 20
Maximum Over Current Protection 230V NA
Electric Defrost Heaters (208V 1Ph) NA
Standard Lighting (T-8 fluorescent)
2 Rows Canopy 0.51 1.02 1.02 1.54 59 118 118 170
Optional Lighting (T-8 fluorescent)
1 Row Rail Lights 0.51 0.51 0.51 0.77 59 59 59 85
1 Row Ledge Lights 0.51 0.51 0.51 0.77 59 59 59 85
Optional Shelf Lighting (T-8 fluorescent)
1 Row of Shelves 0.51 0.51 0.51 0.77 29 59 59 85
2 Rows of Shelves 0.51 1.02 1.02 1.54 59 118 118 170
3 Rows of Shelves 1.02 1.53 1.53 2.31 85 177 177 255
4 Rows of Shelves 1.53 2.04 2.04 3.08 118 236 236 340
5 Rows of Shelves 2.04 2.55 2.55 3.85 236 295 295 425
120V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting
4 of 8 E5 Technical Data Sheet
U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900
Impact
Elite
E5
Delicatessen
Precut & Packaged Produce
5 of 8P/N 0453529_B
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Impact
Elite
E5
Delicatessen
Precut & Packaged Produce
ESTIMATED SHIPPING WEIGHT
4
Case Solid End
4 ft 6 ft 8 ft 12 ft (each)
lb (kg) 400 (181) 600 (272) 800 (363) 1000 (454) 100 (45)
4
Actual weights will vary according to optional kits included.
Product Data
Recommended Usable Cube 1(Cu Ft/Ft) 6.14 ft3 /ft (0.57 m3 /m)
AHRI Total Display Area 2(Sq Ft/Ft) 4.64 ft2/ft (1.41 m2 /m)
Shelf Area
3
(Sq Ft/Ft) 9.42 ft2/ft (2.87 m2 /m)
1
AHRI Refrigerated Volume less shelving and other unusable space: Refrigerated Volume/Unit of Length, ft3/ft [m3/m]
2
Computed using AHRI 1200 standard methodology: Total Display Area, ft2[m2]/Unit of Length, ft [m]
3
Shelf surface area is composed of bottom deck plus standard shelf complement, as shown in the Hussmann Product
Reference Guide. The standard shelf complement for this model is (1) row of 12-inch shelves, (1) row of 14-inch shelves,
(1) row of 16-inch shelves, (1) row of 18-inch shelves and (1) row of 22-inch shelves.
Defrost
Termination
Thermostat
Refrigeration
Thermostat
Dark Blue
3
To
Condensing
Unit
}
Light Blue
2
2 & 3 Fans
120V NEUTRAL
B
ROWN BAND
120V POWER
Fans
1
B
ROWN BAND
5
Connector
Connector
G
R
BL
R
G
G
5
Connector
120 V
Power
BK
W
G
BK
BL
BL
BL
G
W
BL
Shelf Light Circuits
4
W
BL
R
G
G
R
R
R
G
R
BL
BL
Connector
Connector
BK
G
Connector
Connector
G
R
BL
BL
G
BL
Connector Connector
Optional Shelf Harness and Light Circuits for
One Row of Shelves
Shelf Harness
5
R
G
6 of 8 E5 Technical Data Sheet
U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900
Fan Wiring
Offtime Defrost
Shelf Lighting
All components must have mechanical ground, and the merchandiser must be grounded.
= 120VPOWER
R = Red Y = Yellow G = Green BL = Blue BK = Black W = White
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
Grayed components in 12 foot models only
= 120V NEUTRAL = FIELD GROUND
WARNING
= CASE GROUND
Standard Lighting 2 Rows Canopy
7 of 8P/N 0453529_B
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Light Circuits
120V NEUTRAL
ORANGE OR TAN BAND
120V POWER
ORANGE OR TAN
AND
B
BK
Light
Switch
BK
W
4
W
4
BL
R
BL
R
BL
BL
5
BL
5
R
5
BL
R
5
R
5
R
5
Optional Lighting: 1 Row Ledge or 1 Row Rail
120V NEUTRAL
ORANGE OR TAN BAND
120V POWER
ORANGE OR TAN
AND
B
Light
Switch
BK
W
4
R
BL
BL
55
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
BL
R
R
5
R = Red Y = Yellow G = Green BL = Blue BK = Black W = White
= 120VPOWER
Grayed components in 12 foot models only
= 120V NEUTRAL = FIELD GROUND
= CASE GROUND
SHELF CONFIGURATION
This merchandiser is designed for five
shelves.
This illustration shows recommended
shelf depth and shelf angle for the five
locations.
It is critical to case performance that no
product, shelf or stop extend beyond the
load limit, as shown in this illustration.
This configuration supports the air
curtain and provides optimal case
performance.
Check with Hussmann engineering
before using a different configuration.
8 of 8
E5 Technical Data Sheet
U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900
Impact
Elite
E5
Delicatessen
Precut & Packaged Produce
Load Limit
Recommended
Angle
Shelf
Size
12 in.
14 in.
16 in.
18 in.
22 in.
Loading...
