HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
C
D
D
E
B
E
A
P/N 0443113
Merchandisers
Item Part # Description Wiring Item #
F
AN A
SSEMBLIES AND THERMOSTATS
A. 9W Fan Assembly (1)
0047000 Fan Motor, Evaporator
0435961 Fan Blade
embossing toward motor
B. 0411744 Standard Non-adjustable (2)
Defrost Thermostat
C. 0137880 Optional Adjustable (3)
Refrigeration Thermostat
Item Part # Description Wiring Item #
L
AMPS AND
BALLASTS
D. 0376409 Ballast, 2 lamps (4)
D. 0376410 Ballast, 3 lamps (4)
D. 0376411 Ballast, 4 lamps (4)
E. Fluorescent Lamp (5)
Replace with like fixtures
C6LRE
Data Sheet Set
P/N 0443113
NSF
®
Certified
April, 2003
®
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
C6LRE Data Sheet Set
2 of 8
Engineering
Plan Views
Rear Stockable
Dairy and
Delicatessen
3-2003
Dimensions shown as in. & (mm).
8 ft 12 ft
General
(A) Case Length (without ends or partitions) 96
3
/
8 (2448) 144
1
/
2 (3670)
Maximum O/S dimension of case back to front
(includes bumper) 46
1
/4 (1174) 46 1/4 (1174)
Back of case to front of splashguard 35
5
/8 (981) 35 5/8 (981)
Back of case to O/S edge of front skid rail 29
1
/2 (749) 29 1/2 (749)
Width of skid rail 4
1
/2 (114) 4 1/2 (114)
RH end of case to outside edge of external support 5
1
/2 (140) 5 1/2 (140)
Distance between edges of external support and center support 40
5
/8 (1032) 40 5/8 (1032)
Distance between edges of center supports NA 44 (1118)
Stub-up area between front skid rail and splashguard 7 (178) 7 (178)
Electrical Service (Electrical Field Wiring connection point)
(B) RH End of case to center of farthest knockout 88
3
/8 (2245) 136 1/2 (3467)
(C) Back of case to center of knockout 35
3
/8 (899) 35 3/8 (899)
Length of electrical raceway
Waste Outlet
(D) RH End of case to the center of waste outlet 24
1
/8 (613) 74 1/4 (1835)
LH End of case to the center of waste outlet 74
1
/4 (1835) 74 1/4 (1835)
Water Seal
Edge of water seal to center of waste outlet 4 (102) 4 (102)
Outside diameter of the drip pipe 1
1
/2
(38) 1
1
/2
(38)
(NOTE: Water seal outlet must clear front skid rail
Refrigeration Outlet
Back of case to center of refrigeration outlet 30
5
/8 (778) 30 5/8 (778)
(E) RH end of case to center of refrigeration outlet 9 (230) 9 (230)
A
B
72 1/4 (1835)
4 1/8 (105)
D
51/2 (140)
13/8 (35)
41/2 (114)
27 1/2
Electrical
C
40 5/8
(1032)
7 (178)
(699)
Waste Outlet
Water Seal
(See note)
Front
40 5/8
(1032)
Refrigeration
30 5/8
(778)
4 (102)
Outlet
E
29 1/2
(749)
38 5/8
(981)
46 1/4
(1174)
3 of 8P/N 0443113
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
C6LRE
Refrigeration
Outlet
7 1/2
(191)
45
1
/2
(1156)
62
7
/8
(1597)
66
5
/8
(1693)
22
(559)
87
(2209)
5 3/4
(146)
4 3/8 (111)
7
(178)
19
(483)
27
1
/2 (699)
38
3
/4 (984)
46
5
/8 (1184)
29
1
/2 (749)
30
5
/8 (778)
35 3/8 (899)
30
1
/2 (775)
2
3
/4 (70)
FAN
COIL
Impact C6LRE
Dairy / Delicatessen
Dimensions shown as in. & (mm).
REFRIGERATION DATA
Note: This data is based on store temperature
and humidity that does not exceed 75°F and
55% R.H.
C6LRE
Discharge Air (°F) 32
Evaporator (°F) 21
Unit Sizing (°F) 19
Btu/hr/ft* C6LRE
Parallel
1870
Conventional
2040
*For all refrigeration equipment other than
Hussmann, use conventional Btu values.
DEFROST DATA
C6LRE
Frequency (hr) 6
Defrost Water (lb/ft/day) 10.5
(± 15% based on case configuration and
product loading).
OFFTIME C6LRE
Temp Term (°F) 48°
Failsafe (minutes) 35
ELECTRIC OR GAS
Not Recommended
Standard Defrost Thermostat
Close on rise: close 48°F — open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control
CI/CO (Temp °F)** 14 / 4
Indoor Unit Only, Pressure Defrost
Termination (Temp °F)** 48°
**Use a Temperature Pressure Chart to
determine PSIG conversions.
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.)3/8
Merchandiser Suction Line (in.)7/8
Estimated Charge (lb)***
8 ft 3.2
12 ft 4.5
***This is an average for all refrigerant types.
Actual refrigerant charge may vary by
approximately half a pound.
Length (in.) added to Lineup by Each
End or Insulated Partition 1
1
/2
Multideck, 6 Display Levels, and Sliding Rear Doors
NSF Certification
These merchandisers are manufactured to meet ANSI /National
Sanitation Foundation (NSF
®
) Standard #7 requirements.
NOTE: The bumpers are 4 in. (102 mm) wide. The center of the top bumper is
14
1
/
8 in. (359 mm) from the floor and the center of the lower bumper
is 6 in. (152 mm) from the floor.
Impact C6LRE
Dairy / Delicatessen
Electrical Data
8 ft 12 ft
Number of Fans — 9W 4 6
Number of Fans — 9W (Export) 4 6
(Export: 230V 50 hz shown)
Amperes Watts
Merchandiser 8 ft 12 ft 8 ft 12 ft
Fans
Standard: 120V 60 hz 2.80 4.20 220 330
Energy Efficient: 120V 60 hz 1.40 2.80 112 168
Export: 230V 50 hz 1.52 2.28 228 342
Anti-sweat Heaters
Constant on NA NA
Cycling NA NA
Minimum Circuit Ampacity
With Standard Fans 3.0 4.4
With Energy Efficient Fans 1.6 3.0
With Export Fans 2.0 2.5
Maximum Over Current Protection 20 20
Supplemental Gas Heaters NA NA
208V 1ΦΦElectric Defrost NA NA
Standard Lighting
1 Row Canopy 0.51 0.77 59 85
Optional Lighting
1 Row Canopy and 1 Row Rail 1.02 1.54 118 170
2 Rows Canopy 1.02 1.54 118 170
2 Rows Canopy and 1 Row Rail 1.53 2.31 177 255
1 Row Ledge Lights 0.51 0.77 59 85
Optional Shelf Lighting
Not Recommended
4 of 8
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
C6LRE Data Sheet Set
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
5 of 8P/N 0443113
Fan Wiring
4 & 6 Fans
Fans
120V NEUTRAL
B
1
ROWN BAND
Off-time Defrost
120V POWER
B
ROWN BAND
Defrost
Termination
Thermostat
Dark Blue
2
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
Grayed components in 12 foot models only.
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V P
OWER = 120V NEUTRAL = Field GROUND = Case GROUND
Refrigeration
Thermostat
Light Blue
3
To
Condensing
Unit
}
C6LRE Data Sheet Set6 of 8
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Light Circuits
Standard Lighting — 1 Row Canopy
Optional Lighting — 1 Row Rail or 1 Row Ledge
120V NEUTRAL
ORANGE OR TAN BAND
120V POWER
ORANGE OR TAN
BAND
Light
Switch
W
B
4
BL
Optional Lighting — 2 Rows Canopy
120V NEUTRAL
ORANGE OR TAN BAND
120V POWER
ORANGE OR TAN
BAND
Light
Switch
W
B
B
4
W
BL
BL
R
BL
R
5
R
BL
5
5
BL
R
5
R
5
R
5
4
R
BL
BL
5
BL
R
5
R
5
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
C
IRCLED NUMBERS = PARTS LIST ITEM NUMBERS
Grayed components in 12 foot models only.
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER
= 120V NEUTRAL
Doors
Fully Opened
Doors
Fully Closed
Double-walled telescoping doors slide both left and right.
NOTE: Consult Cooler Close-off Kit for instructions on connecting the merchandiser to the cooler.
Rear View of 8 Foot Merchandiser
23 3/4
(603)
Rear Coil Grilles
84 1/4
(2140)
37 3/4
(958)
73 1/8
(1858)
85 1/8
(2162)
7 of 8P/N 0443113
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
NOTE: Consult Cooler Close-off Kit for Instructions on
connecting the merchandiser to the cooler.
Rear View of 12 Foot Merchandiser
23
3
/4
(603)
23
3
/4
(603)
Doors
Fully Opened
Doors
Fully Closed
Double-walled telescoping doors slide both left and right.
Doors
Fully Opened
Rear Coil Grille
Rear Coil Grille
Rear Coil Grille
73
1
/8
(1858)
85
1
/8
(2162)
37
3
/4
(958)
130
1
/4
(3308)
C6LRE Data Sheet Set8 of 8
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
