Hussmann C2X-LEP Specifications

E

B

E

D

A

E

D

C

F

H

G

C2X-LEP

Technical Data Sheet

P/N 0465999_K

NSF

®

Certified

April 2010

We reserve the right to change or
revise specifications and product
design in connection with any
feature of our products. Such
changes do not entitle the buyer
to corresponding changes,
improvements, additions or
replacements for equipment
previously sold or shipped.

Item Part # Description Wiring Item #

F

AN ASSEMBLIES

4 Ft, 8 Ft & 12 Ft

A. 7W Standard Fan Assembly (1)

0058698 Fan Motor, Evaporator

(MO.4410102)

0142780 Fan Blade (FB.0142780)
7W Energy Efficient Fan Assembly (1)
0477654 Fan Motor, Evaporator

(MO.4410545)

0142780 Fan Blade (FB.0142780)

6 Ft Only

A. 4W Standard Fan Assembly (1)

0392457 Fan Motor, Evaporator

(MO.4410101)

0382383 Fan Blade (FB.4780617)
4W Energy Efficient Fan Assembly (1)
0477653 Fan Motor, Evaporator

(MO.4410544)

0382383 Fan Blade (FB.4780617)

T

HERMOSTATS

B. Optional Adjustable Refrigeration Thermostat (2)

Item Part # Description Wiring Item #

H

EATERS

C. Canopy Anti-Sweat Heater (3)

0512499 4 ft (HE.4851174)
0512500 6 ft (HE.4851175)
0512501 8 ft (HE.4851176)
0512503 12 ft (HE.4851178)

L

AMPS AND BALLASTS

D. Ballast, Electronic (4)

0480130 2 lamps (BA.4481676)
0480131 3 lamps (BA.4481654)
0480132 4 lamps (BA.4481677)

E. Fluorescent Lamp (5)

Replace with like fixtures

LED F

IXTURES AND POWER SUPPLY

F. 0501213 Power Supply (EP.4481861) (6)

G. LED Canopy Fixture (7)

Replace with like fixtures — See Page 5.

H. LED Shelf Fixture (8)

Replace with like fixtures — See Page 5.

©2010 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM

P/N_0465999_K

Note: Revision K adds 4-ft length.

4 ft 6 ft 8 ft 12 ft

General

(A) Case Length (without ends or partitions) 48

3

/8 (1229) 72

3

/8 (1838) 96 3/8 (2448) 144 1/2 (3670)

(Each end and insulated partition adds 1 1/2

in. (38 mm) to case line up.)

Maximum O/S dimension of case back to front

(includes bumper) 42 (1064) 42 (1064) 42 (1064) 42 (1064)

Back of case to front of splashguard 33

1

/2

(851) 33

1

/2

(851) 33

1

/2

(851) 33

1

/2

(851)

Back of case to O/S edge of front leg

30 1/4 (768) 30

1

/4 (768) 30 1/4 (768) 30 1/4 (768)
Distance between edges of external legs and center legs NA 29 1/2 (750) 41 1/2 (1054) 41 1/2 (1054)
Distance between edges of center legs NA NA NA 43 7/8 (1114)
Distance between front legs and splashguard 2

3

/4 (70) 2

3

/4 (70) 2 3/4 (70) 2 3/4 (70)

Electrical Service (Electrical Field Wiring connection point)

(B) RH End of case to center of stub up area 36

1

/4 (921) 60

1

/4 (1530) 84 1/4 (2140) 132 3/8 (3363)
Back of case to center of stub up area 24 (612) 24 (612) 24 (612) 24 (612)
Length of electrical wireway 26

1

/2 (673) 26

1

/2 (673) 26 1/2 (673) 26 1/2 (673)

(C) RH End of case to LH end of wireway 42

1

/8 (1070) 66

1

/8 (1680) 90 1/8 (2289) 138 1/4 (3511)

Waste Outlets (One each end)

(D) RH End of case to the center of LH waste outlet 36

1

/4 (921) 60

1

/4 (1530) 84 1/4 (2140) 132 3/8 (3363)
RH End of case to the center of RH waste outlet

12

1

/8

(307) 12

1

/8

(307) 12

1

/8

(307) 12

1

/8

(307)

Back O/S of case to center of waste outlets

31 5/8 (804) 31

5

/8 (804) 31 5/8 (804) 31 5/8 (804)

Schedule 40 PVC drip pipe 1

1

/4 (32) 1

1

/4 (32) 1 1/4 (32) 1 1/4 (32)

Refrigeration Outlet

Back of case to center of refrigeration outlet 26

1

/4 (665) 26

1

/4 (665) 26 1/4 (665) 26 1/4 (665)

RH end of case to center of refrigeration outlet 8 (203) 8 (203) 8 (203) 8 (203)

2 of 11 C2X-LEP Technical Data Sheet

U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900

Engineering

Plan Views

Dimensions shown as inches and (mm).

Dairy/Delicatessen

Precut & Packaged Produce

05-2006

NOTE: Case-to-Case Electrical Connections
are made IN FRONT OF SPLASHGUARD.

4 3/4 (120)

Splashguard

31 5/8

(804)

42

(1064)

A

41 1/2

(1054)

3 In.

(77 mm)

Required

Air Gap

Refrigeration

Outlet

Electrical

Stub Up Area

6 x 6

(152x152)

Waste Outlet

Waste Outlet

FRONT

26 1/4

(665)

B

D

8 (203)

4 1/2 (115)

12 1/8 (307)

41 1/2

(1054)

43 7/8

(1114)

C

Wireway

4 3/4 (120)

26 1/2

(673)

4 1/4 (108)

24

(612)

33 1/2

(851)

Electrical
Field
Connection

30 1/4

(768)

C2X

PHYSICAL DATA

Merchandiser Drip Pipe (in.) 1 1/4
Merchandiser Liquid Line (in.)

3

/8

Merchandiser Suction Line (in.)

7

/8

Wireway

Dimensions shown as inches and (mm).

P/N 0465999_K 3 of 11

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

48 1/2

(1232)

30 1/4

(769)

31 5/8 (804)

4 3/4 (120)

30 1/4 (768)

42 (1064)

33 1/2 (851)

26 1/4 (665)

C2X-LEP

15 7/8

(403)

FAN

C
O

I

L

17 1/4

(435)

3 In. (77 mm)

Required

Air Gap

19 5/8

(500)

6 (152)

Electrical

Case to Case

Connections

17 1/8

(436)

Refrigeration

Outlet

3 5/8

(92)

33 7/8

(860)

24 5/8

(625)

Impact

Excel

C2X-LEP

Dairy/Delicatessen

Precut & Packaged Produce

Multi-deck, 3 Display Levels, Low Front, 48 In. Back

NSF Certification

This merchandiser model is manufactured to meet ANSI/NSF
(National Sanitation Foundation) Standard #7 requirements for
construction, materials & cleanability.

See Page 10 for
shelf arrangement.

REFRIGERATION DATA

Note: This data is based on store temperature and

humidity that does not exceed 75°F and 55% R.H.

C2X-LEP Dairy/Deli/Produce Meat

U

NLIT L

IT UNLIT LIT

Discharge Air °F 33 31 30 28

Evaporator °F 28 26 25 23

Unit Sizing °F 26 24 23 21

Btu/hr/ft

‡

— Unlit Shelves

‡‡

C2X-LEP Dairy/Deli/Produce Meat

P

ARALLEL

665 700

C

ONVENTIONAL 680 715

‡

Optional energy efficient motors reduce the

refrigeration load by 21 Btu/hr/ft (4 ft, 8 ft and 12 ft

models) and 18 Btu/hr/ft (6 ft models).
‡‡

Add 10 Btu/hr/ft per shelf row for LED fixtures.

Add 20 Btu/hr/ft per shelf row for fluorescent lamps.

DEFROST DATA

C2X-LEP

Frequency (hr) 12

Defrost Water (lb/ft/day) 6

(±15% based on case configuration and

product loading.

O

FFTIME C2X-LEP

Time (minutes) 30

ELECTRIC OR GAS Not Recommended

CONVENTIONAL CONTROLS

Low Pressure Backup Control

C2X-LEP Dairy/Deli/Produce Meat

CI/CO* 19°F / 9°F16°F / 6°F

Indoor Unit Only, Pressure Defrost

Termination* 48°F

*Use a Temperature Pressure Chart to determine
PSIG conversions.

Estimated Charge ** C2X-LEP

4 ft 1.4 lb 22 oz 0.6 kg
6 ft 1.9 lb 30 oz 0.9 kg
8 ft 2.7 lb 43 oz 1.2 kg

12 ft 3.9 lb 62 oz 1.8 kg

**This is an average for all refrigerant types. Actual
refrigerant charge may vary by approximately half a
pound.

4 of 11 C2X-LEP Technical Data Sheet

U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900

Impact

Excel

C2X-LEP

Dairy/Delicatessen
Precut & Packaged Produce

Electrical Data

4 ft 6 ft 8 ft 12 ft
Number of Fans—7W 1 — 2 3
Number of Fans—4W — 2 — —

Amperes Watts

4 ft 6 ft 8 ft 12 ft 4ft 6 ft 8 ft 12 ft
Evaporator Fan

120V 60Hz Standard 0.50 0.62 1.00 1.50 39 48 78 117

120V 50Hz Standard 0.55 0.76 1.10 1.65 42 54 84 126

230V 60Hz Export 0.25 0.30 0.50 0.75 39 48 78 117

230V 50Hz Export 0.28 0.36 0.56 0.84 42 54 84 126

120V 60Hz Energy Efficient 0.19 0.24 0.38 0.57 14 16 28 42

230V 60Hz Energy Efficient 0.10 0.12 0.20 0.30 14 16 28 42

Minimum Circuit Ampacity †

120V 60Hz Standard 0.70 0.82 1.20 1.70

120V 50Hz Standard 0.75 0.96 1.30 1.85

230V 60Hz Export 0.45 0.50 0.70 0.95

230V 50Hz Export 0.48 0.56 0.76 1.04

120V 60Hz Energy Efficient 0.39 0.44 0.58 0.77

230V 60Hz Energy Efficient 0.30 0.32 0.40 0.50

Maximum Over Current Protection 120V 20 20 20 20
Maximum Over Current Protection 230V 15 15 15 15

Anti-sweat Heaters

120V 50/60Hz Standard 0.10 0.15 0.20 0.30 12 18 24 36

Standard Lighting (T-8 Fluorescent)

1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85

Optional Lighting (T-8 Fluorescent)

Additional 1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85

1 Row Rail Light 0..26 0.51 0.51 0.77 30 59 59 85

2 Rows of Shelves 0.51 1.02 1.02 1.54 59 118 118 170

Optional EcoShine LED Lighting — Normal CRI

2 Row Canopy 0.28 0.41 0.55 0.82 33 49 66 98

2 Rows of shelves 0.20 0.29 0.39 0.58 24 35 47 70

Optional EcoShine LED Lighting — High CRI

2 Row Canopy 0.32 0.47 0.63 0.93 38 56 75 112
2 Rows of Shelves 0.23 0.35 0.47 0.70 28 42 56 84

Optional Always*Bright LED Lighting

2 Row Canopy 0.38 0.55 0.71 1.08 45 66 85 130

2 Rows of Shelves 0.26 0.34 0.47 0.67 31 41 56 80

120V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting

230V Lighting Circuit Total = Multiply 120V Lighting Circuit Total by 0.52

† MCA does not include Canopy A/S Heaters because heaters are wired separately from fans.

ESTIMATED SHIPPING WEIGHT

4

Case Solid End

4 ft 6 ft 8 ft 12 ft (each)

lb (kg) 600 (272) 800 (363) 1000 (454) 1200 (544) 75 (34)

4

Actual weights will vary according to optional kits included.

5 of 11P/N 0465999_K

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

Impact

Excel

C2X-LEP

Dairy/Delicatessen

Precut & Packaged Produce

Product Data

Recommended Usable Cube

1

(Cu Ft/Ft) 3.08 ft3 /ft (0.29 m3 /m)

AHRI Total Display Area

2

(Sq Ft/Ft) 3.11 ft2/ft (0.95 m2 /m)

Shelf Area 3(Sq Ft/Ft) 5.04 ft2/ft (1.54 m2 /m)

1 AHRI Refrigerated Volume less shelving and other unusable space: Refrigerated Volume/Unit of Length, ft

3

/ft [m3/m]

2

Computed using AHRI 1200 standard methodology: Total Display Area, ft2[m2]/Unit of Length, ft [m]

3

Shelf surface area is composed of bottom deck plus standard shelf complement, as shown in the Hussmann
Product Reference Guide. The standard shelf complement for this model is (1) row of 12-inch shelf and
(1) row of 18-inch shelf.

PARTS LIST (Continued from Page 1)

Note: Always*Bright lamps will be replaced with the latest generation of EcoShine lamps.

Item Part # Description

LED FIXTURES AND POWER SUPPLY

F. 0501213 Power Supply (EP.4481861) (6)

G. EcoShine LED Canopy Fixture (7)

4441720 Front 48-inch 2900K HCRI
4441722 Front 48-inch 3500K HCRI
4441724 Front 48-inch 3500K
4441726 Front 48-inch 4100K
4441721 Rear 48-inch 2900K HCRI
4441723 Rear 48-inch 3500K HCRI
4441725 Rear 48-inch 3500K
4441727 Rear 48-inch 4100K

4441712 Front 36-inch 2900K HCRI
4441714 Front 36-inch 3500K HCRI
4441716 Front 36-inch 3500K
4441718 Front 36-inch 4100K

Item Part # Description

G.

(CONTINUED) EcoShine LED Canopy Fixture

4441713 Rear 36-inch 2900K HCRI
4441715 Rear 36-inch 3500K HCRI
4441717 Rear 36-inch 3500K
4441719 Rear 36-inch 4100K

H. EcoShine LED Shelf Fixture (8)

4441590 48-inch 2900K HCRI
4441591 48-inch 3500K HCRI
4441592 48-inch 3500K
4441593 48-inch 4100K

4441586 36-inch 2900K HCRI
4441587 36-inch 3500K HCRI
4441588 36-inch 3500K
4441589 36-inch 4100K

6 of 11 C2X-LEP Technical Data Sheet

Refrigeration

Thermostat

2

To
Condensing
Unit

}

Light Blue

1, 2 & 3 Fans

120V NEUTRAL

BROWN BAND

120V POWER

Fans

1

B

ROWN BAND

4 ft
6 ft
8 ft

12 ft

12 ft

6 ft or 8 ft4 ft

5

5

4

4

5

5

5

5

Optional

Two Row

Canopy

Connector

BL

BL

W

G

R

BL

W

R

R

R

BL

BL

R

BL

R

R

R

B

B

Orange or Tan Band

3 Row Canopy

5

4

55

Connector

W

B

BL

BL

R

BL

R

R

R

B

6 ft or 8 ft

6 ft or 8 ft

12 ft

12 ft

Ballast Plug for Optional Light Rail (if applied)

W

B

Field Connections

Case

Ground

Bar

4 ft

4 ft

R = Red Y = Yellow G = Green BL = Blue BK = Black W = White

= 120V P

OWER = 120V NEUTRAL = FIELD GROUND

= CASE GROUND

WARNING

All components must have mechanical ground, and the merchandiser must be grounded.

CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS

U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900

Fan Wiring
Offtime Defrost

Canopy Light Circuits — Fluorescent Fixtures

7 of 11P/N 0465999_K

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

Purple BAND

3

120V Power

Purple BAND

120V Neutral

Anti-Sweat Heater

5

4

5

BK

W

R

R

W

BL

BL

R

BK

BL

BL

R

R = Red Y = Yellow G = Green BL = Blue BK = Black W = White

= 120V P

OWER = 120V NEUTRAL = FIELD GROUND

= CASE GROUND

WARNING

All components must have mechanical ground, and the merchandiser must be grounded.

CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS

Connector

5

4

5

BK

W

Connector

6 ft or 8 ft case

12 ft case

R

R

W

BL

BL

R

BK

BL

BL

R

5

4

5

BK

W

R

R

W

BL

BL

R

BK

BL

BL

R

Optional Shelf Harness and Fluorescent Light Circuits for Two Rows of Shelves

4 ft case

Canopy Anti-Sweat

Heater

Optional Shelf Lighting

Fluorescent Fixtures

8 of 11 C2X-LEP Technical Data Sheet

U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900

R = Red Y = Yellow G = Green BL = Blue BK = Black W = White

= 120V P

OWER = 120V NEUTRAL = FIELD GROUND

= CASE GROUND

WARNING

All components must have mechanical ground, and the merchandiser must be grounded.

CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS

7

7

7

7

7

7

7

7

7

7

7

7

6

6

6

6

Optional Canopy Lighting
LED Fixtures

9 of 11P/N 0465999_K

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

6 ft or 8 ft case

12 ft case

R

BL

R

BL

8

8

R

BL

6

BK

W

W

BL

R

G

Connector

Connector

BK

W

BK

W

BK

W

R

BL

R

BL

8

8

R

BL

R

BL

R

BL

8

8

R

BL

R

BL

BL

BL

(TYP)

Shelf Light

Plug & Receptacle

R = Red G = Green BL = Blue BK = Black W = White

= 120V P

OWER = 120V NEUTRAL = FIELD GROUND

= CASE GROUND

WARNING

All components must have mechanical ground, and the merchandiser must be grounded.

CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS

Optional Shelf Harness and LED Light Circuits for Two Rows of Shelves

R

R

BK

4 ft case

Optional Shelf Lighting

LED Fixtures

10 of 11 C2X-LEP Technical Data Sheet

Top Eight (8)
Shelf Hole
Locations

18 in.

18 in.

14 in.

12 in.

Angle

Maximum

Shelf

Size

18 in.

Do NOT load

PRODUCT

above

this line

SHELF CONFIGURATION

This merchandiser is designed for
one or two shelves.

The depth of the shelf used in the
top eight (8) shelf hole locations
is critical to case performance.

If a shelf is placed in one of the
top eight (8) locations it must
comply with the angle/depth
requirements listed below.

Maximum Shelf

Shelf Angle Depth

0 º 12 in.

15 º 14 in.

or less

30 º 18 in.

or less

45 º 18 in.

or less

NOTE: Shelves placed in the
lower positions may be up to
18 in. deep when positioned
at a 0 º angle.

U.S. & Canada 1-800-922-1919 • Mexico 1-800-522-1900

Impact

Excel

C2X-LEP

Dairy/Delicatessen

Precut & Packaged Produce

Impact

Excel

C2X-LEP

Dairy/Delicatessen

Precut & Packaged Produce

11 of 11P/N 0465999_K

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

Remove Screws

Light Channel

Light Channel

Hinge

Ballast

Light

Channel

Foil-covered
Anti-sweat
Heater

Canopy

Canopy

Anti-Sweat Heater Wires
with Purple Markers

Electrical Wireway

The ballast for the canopy and shelf lamps is
located behind the canopy on the left-hand end
(when facing case) of the merchandiser.

To access the ballast:

1. Remove screws at bottom edge of canopy and
rear of light channel.

2. Lower light channel which will pivot on
hinge.

3. Service or replace ballasts as required.

4. Reassemble items as they were originally
installed.

NOTE: Rail lamp ballast is located in the
electrical raceway.

CANOPY ANTI-SWEAT HEATER

The canopy anti-sweat heater location is shown
below. Connections are in the electrical wireway.
