Page 1
Illustrated
2008-01
531 30 70-05
Sleeve Hitch
(23 inch tire) (45-03021)
Parts List
I0807213
Repair Parts Manual
Page 2
• Safety
• Assembly
• Operation
• Maintenance
• Parts
45-03021
™
FORM NO. 49949 (10/05)
the fastest way to purchase parts
www.speedepart.com
Page 3
ve hi cle un at tend ed.
A 2 Hex Bolt, 5/8" x 2"
B 2 Hex Bolt, 5/8" x 1-3/4"
C 4 Hex Bolt, 3/8" x 1-1/4"
D 1 Hex Bolt, 5/16" x 1"
E 4 Carriage Bolt, 3/8" x 1"
F 3 Clevis Pin
G 2 Jam Nut, 5/8"
H 2 Nylock Nut, 5/8"
I 1 Nylock Nut 5/16"
KEY QTY. DESCRIPTION
KEY QTY. DESCRIPTION
J 4 Nylock Nut, 3/8"
K 4 Hex Nut, 3/8"
L 4 Lock Washer, 3/8"
M 2 Flat Washer, 3/8"
N 1 Spacer
O 1 Spacer Plate
P 3 3/32" Hair Cotter Pin
Q 1 5/32" Hair Cotter Pin
Bolt (C), Lock Washer (L) and Nut (K) will not be
A B
D
E
C
H
J
F
G
K
L
M
N
I
O
Q
P
Page 4
ORIGINAL NUT
LEFT MOUNTING
BRACKET
3/8" FLAT WASHER
(TOP HOLE ONLY)
REMOVE NUTS
FROM BOLTS
RIGHT MOUNTING
BRACKET
3/8" LOCK WASHER
(If new bolt and nut are needed)
1
3
4
5
6
2
7
8
If no bolt and nut are present in a hole, use a 3/8" x
5/16" X 1"
HEX BOLT
5/16" NYLOCK
NUT
SPACER
PIVOT
BRACKET
3/8" HEX NUT
3/8" LOCK WASHER
LEFT MOUNTING BRACKET
3/8" x 1-1/4"
HEX BOLT
RIGHT MOUNTING BRACKET
Page 5
3/8-16 x 1"
CARRIAGE
BOLT
3/8" NYLOCK NUT
LIFT LEVER
ASSEMBLY
SLEEVE HITCH FRAME
L.H. PIVOT BRACKET
R.H. PIVOT BRACKET
5/8"x 2"
HEX BOLT
5/8" NYLOCK NUT
5/8" JAM NUT
5/8"x 1-3/4"
HEX BOLT
LIFTING LINK
LIFT LEVER
ASSEMBLY
SLEEVE HITCH
FRAME ASSEMBLY
WELD
PIN
5/8" NYLOCK NUT
SPACER PLATE
(SEE NOTE)
HEX BOLT
5/8" x 1-3/4"
(3) 3/32" HAIR
COTTER PINS
5/32" HAIR
COTTER PIN
HITCH PIN
(3) CLEVIS PINS
jam nuts against the welded nuts. See fi gure 5.
If your tractor hitch has ridges that prevent the
Page 6
Some im ple ments may require that the
Page 7
27
1
4
2
5
6
7
8
11
11
11
12
12
13
14
15
15
22
15
16
A
A
17
18
19
3
21
20
25
26
24
9
10
13
23
2 25715 1 Pivot Bracket, Left
3 25714 1 Pivot Bracket, Right
4 43350 4 Bolt, Carriage 3/8-16 x 1"
5 HA21362 4 Hex Lock Nut, 3/8-16
6 65404 1 Sleeve Hitch Lift Assembly
7 64625 1 Lift Lever Assembly
8 24732 1 Lifting Link Plate
9 47947 2 Bolt, Hex 5/8-11 x 2"
10 712-0242 2 Hex Jam Nut, 5/8-11
11 HA3980 3 Clevis Pin, 5/8" x 1-3/4"
12 47951 2 Bolt, Hex 5/8-11 x 1-3/4"
13 712-0261 2 Nylock Nut, 5/8-11
14 47950 1 Pin, Sleeve Hitch
15 43343 3 Pin, Hair Cotter 3/32"
16 46471 1 Grip, Plastic
17 43063 1 Bolt, 5/16-18 x 1"
18 23625 1 Spacer
19 47810 1 Nylock Nut, 5/16"
20 65370 1 Mounting Bracket, Right
21 65369 1 Mounting Bracket, Left
22 714-0117 1 Pin, Hair Cotter, 5/32"
23 25685 1 Spacer Plate
24 43070 2 Flat Washer
25 43087 4 Bolt, Hex 3/8-16 x 1-1/4"
26 43003 4 Lock Washer, 3/8"
27 43015 4 Hex Nut, 3/8-16
49949 1 Owner's Manual
Page 8
Page 9
the fastest way to purchase parts
www.speedepart.com
© 2004 Agri-Fab, Inc
