OWNER’S MANUAL
Model No. QC42A
42 Inch Mower
Grass Catcher
• Assembly
• Operation
• Customer Responsibilities
• Repair Parts
171112 Rev. 3 11.1.01 rad
Printed in U.S.A. 954 04 05-10
Page 2
SAFETY RULES
Safe Operation Practices for Ride-On Mowers
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS.
FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
I. GENERAL OPERATION
• Read, understand, and follow all instructions in the manual
and on the machine before starting.
• Only allow responsible adults, who are familiar with the
instructions, to operate the machine.
• Clear the area of objects such as rocks, toys, wire, etc., which
could be picked up and thrown by the blade.
• Be sure the area is clear of other people before mowing. Stop
machine if anyone enters the area.
• Never carry passengers.
• Do not mow in reverse unless absolutely necessary. Always
look down and behind before and while backing.
• Be aware of the mower discharge direction and do not point
it at anyone. Do not operate the mower without either the
entire grass catcher or the guard in place.
• Slow down before turning.
• Never leave a running machine unattended. Always turn off
blades, set parking brake, stop engine, and remove keys
before dismounting.
• Turn off blades when not mowing.
• Stop engine before removing grass catcher or unclogging
chute.
• Mow only in daylight or good artificial light.
• Do not operate the machine while under the influence of
alcohol or drugs.
• Watch for traffic when operating near or crossing roadways.
• Use extra care when loading or unloading the machine into
a trailer or truck.
• Data indicates that operators, age 60 years and above, are
involved in a large percentage of riding mower-related
injuries. These operators should evaluate their ability to
operate the riding mower safely enough to protect themselves
and others from serious injury.
• Keep machine free of grass , leaves or other debris build-up
which can touch hot exhaust / engine parts and burn. Do not
allow the mower deck to plow leaves or other debris which
can cause build-up to occur. Clean any oil or fuel spillage
before operating or storing the machine. Allow machine to
cool before storage.
II. SLOPE OPERATION
Slopes are a major factor related to loss-of-control and tipover
accidents, which can result in severe injury or death. All slopes
require extra caution. If you cannot back up the slope or if you feel
uneasy on it, do not mow it.
DO:
• Mow up and down slopes, not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine.
• Use slow speed. Choose a low gear so that you will not have
to stop or shift while on the slope.
• Follow the manufacturer’s recommendations for wheel
weights or counterweights to improve stability.
• Use extra care with grass catchers or other attachments.
These can change the stability of the machine.
• Keep all movement on the slopes
make sudden changes in speed or direction.
• Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly
slope.
Tall grass can hide obstacles.
slow
and
gradual
straight
. Do not
down the
DO NOT:
•
Do not
slowly and gradually downhill, if possible.
•
Do not
mower could suddenly turn over if a wheel is over the edge
of a cliff or ditch, or if an edge caves in.
•
Do not
sliding.
•
Do not
ground.
•
Do not
turn on slopes unless necessary, and then, turn
mow near drop-offs, ditches, or embankments. The
mow on wet grass. Reduced traction could cause
try to stabilize the machine by putting your foot on the
use grass catcher on steep slopes.
III. CHILDREN
Tragic accidents can occur if the operator is not alert to the
presence of children. Children are often attracted to the machine
and the mowing activity.
where you last saw them.
• Keep children out of the mowing area and under the watchful
care of another responsible adult.
• Be alert and turn machine off if children enter the area.
• Before and when backing, look behind and
children.
• Never carry children. They may fall off and be seriously
injured or interfere with safe machine operation.
• Never allow children to operate the machine.
• Use extra care when approaching blind corners, shrubs,
trees, or other objects that may obscure vision.
Never
assume that children will remain
down
for small
IV. SERVICE
• Use extra care in handling gasoline and other fuels. They
are flammable and vapors are explosive.
- Use only an approved container.
- Never remove gas cap or add fuel with the engine
running. Allow engine to cool before refueling. Do not
smoke.
- Never refuel the machine indoors.
- Never store the machine or fuel container inside where
there is an open flame, such as a water heater.
• Never run a machine inside a closed area.
• Keep nuts and bolts, especially blade attachment bolts, tight
and keep equipment in good condition.
• Never tamper with safety devices. Check their proper
operation regularly.
• Keep machine free of grass, leaves, or other debris build-up.
Clean oil or fuel spillage. Allow machine to cool before
storing.
• Stop and inspect the equipment if you strike an object.
Repair, if necessary, before restarting.
• Never make adjustments or repairs with the engine running.
• Grass catcher components are subject to wear, damage,
and deterioration, which could expose moving parts or allow
objects to be thrown. Frequently check components and
replace with manufacturer's recommended parts, when
necessary.
• Mower blades are sharp and can cut. Wrap the blade(s) or
wear gloves, and use extra caution when servicing them.
• Check brake operation frequently. Adjust and service as
required.
2
Page 3
SAFETY RULES
Safe Operation Practices for Ride-On Mowers
• Be sure the area is clear of other people before mowing.
Stop machine if anyone enters the area.
• Never carry passengers or children even with the blades
off.
• Do not mow in reverse unless absolutely necessary. Always
look down and behind before and while backing.
• Never carry children. They may fall off and be seriously
injured or interfere with safe machine operation.
• Keep children out of the mowing area and under the
watchful care of another responsible adult.
• Be alert and turn machine off if children enter the area.
• Before and when backing, look behind and down for small
children.
• Mow up and down slopes (15° Max), not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine. Tall grass can hide obstacles.
• Use slow speed. Choose a low gear so that you will not have
to stop or shift while on the slope.
• Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly straight down
the slope.
• If machine stops while going uphill, disengage blades, shift
into reverse and back down slowly.
• Do not turn on slopes unless necessary, and then, turn
slowly and gradually downhill, if possible.
Look for this symbol to point out important safety precautions. It means CAUTION!!! BECOME ALERT!!! YOUR
SAFETY IS INVOLVED.
CAUTION: Do not coast down a hill in
neutral, you may lose control of the
tractor.
CAUTION: Tow only the attachments
that are recommended by and comply
with specifications of the manufacturer of your tractor. Use common
sense when towing. Operate only at
the lowest possible speed when on a
slope. Too heavy of a load, while on
a slope, is dangerous. Tires can lose
traction with the ground and cause
you to lose control of your tractor.
CAUTION: In order to prevent
accidental starting when setting up,
transporting, adjusting or making
repairs, always disconnect spark plug
wire and place wire where it cannot
contact spark plug.
CONGRATULATIONS on your purchase of a new Grass Catcher. It has been designed, engineered and manufactured to give
you the best possible dependability and performance.
Should you experience any problems you cannot easily remedy, please contact your nearest authorized service center/
department. They have competent, well trained technicians and the proper tools to service or repair this unit.
Please read and retain this manual. The instructions will enable you to assemble and maintain your Grass Catcher properly.
Always observe the "SAFETY RULES".
NOTE: To make debris disposal easier 30 gallon plastic trash bags may be inserted in plastic grass containers. To order, see
repair parts section of this manual.
TABLE OF CONTENTS
SAFETY RULES ........................................................ 2-3
BAG OF PARTS ............................................................ 4
ASSEMBLY................................................................ 5-9
OPERATION................................................................ 10
CUSTOMER RESPONSIBILITIES .............................. 11
STORAGE ................................................................... 11
REPAIR PARTS .................................. Center of Manual
3
Page 4
KNOW YOUR GRASS CATCHER
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE ASSEMBLING OR OPERATING YOUR GRASS
CATCHER. Compare the illustrations with the carton contents to familiarize yourself with the parts before starting the assembly.
Study the operating instructions and safety precautions thoroughly to insure proper functioning of your Grass Catcher and to
prevent injury to yourself and others. Save this manual for future reference.
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in
severe eye damage. Always wear safety glasses or eye shields before starting your tractor and
while mowing. We recommend a wide vision safety mask for over the spectacles or standard safety
glasses.
UNPACKING INSTRUCTIONS
• Remove all parts and packing materials from carton.
• Check carton contents against list. Be sure all parts are
there.
BAG OF PARTS CONTENTS
ASSEMBLY
LOCATION
GROUP "A"
REAR
MOUNTING
BRACKET
TO
DRAW BAR
(4) Shoulder Bolts 5/16 - 18 Self Tapping
GROUP "B"
HARDWARE SHOWN ACTUAL SIZE
(1) Bracket Support Pin
CARTON CONTENTS:
(2) Container Tops
(2) Container Bottoms
(1) Upper Chute
(1) Lower Chute
(4) Bolts 5/16 - 18 x 3/4
(1) Mounting Bracket
(1) Support Post and
Cover Assembly
(1) Bag of Parts
(1) Owner's Manual
(4) Locknuts 5/16-18
SUPPORT
POST
TO
MOUNTING
BRACKET
(1) Retainer Spring
4
Page 5
PARTS IDENTIFICATION
e
G
w
o
N
I
m
d
e
N
t
d
a
n
R
r
a
e
.
A
r
p
d
a
o
e
e
t
W
g
o
w
a
n
o
m
t
o
a
t
D
c
d
e
r
j
o
b
u
d
s
e
k
c
a
r
c
GRASS
CATCHER
CONTAINERS
ASSEMBLY
COVER
UPPER CHUTE
DUMP
BAG
INDICATOR
s
i
r
e
n
i
a
t
n
n
o
e
h
C
.
w
d
.
r
e
e
l
l
e
c
a
n
a
i
t
l
s
a
p
t
n
e
n
s
R
o
i
.
c
y
y
l
l
t
r
t
n
e
n
e
p
e
o
m
u
r
e
q
p
c
e
r
s
a
f
i
l
r
p
g
e
e
a
r
n
b
i
d
a
k
t
e
c
n
d
e
o
n
h
c
e
C
s
m
.
s
n
e
m
l
o
o
i
n
t
c
u
a
e
r
r
r
o
i
a
r
e
y
i
l
t
n
e
o
e
s
U
s
i
r
e
n
i
a
t
n
n
o
e
h
C
.
w
d
.
r
e
e
l
l
e
c
a
n
a
i
t
l
s
a
p
t
n
e
n
s
R
o
i
.
c
y
y
l
l
t
r
t
n
e
n
e
p
e
o
u
m
r
q
e
p
c
e
r
s
a
f
i
l
r
p
g
e
e
a
r
n
b
i
d
a
k
t
e
c
n
d
e
o
n
h
c
e
C
s
m
.
s
n
e
m
l
o
o
i
n
t
c
u
a
e
r
r
r
o
e
i
a
G
r
w
e
y
i
o
l
N
t
n
I
e
m
o
d
e
N
t
e
d
s
a
n
R
r
U
a
e
.
A
r
p
d
a
o
e
e
t
W
g
o
w
a
n
o
m
t
o
a
t
D
c
d
e
r
j
o
b
u
d
s
e
k
c
a
r
c
LOWER CHUTE
CHUTE LATCH
LOWER CHUTE
ATTACHING
STRAPS
NOTE: When right hand (R.H.) and left hand (L.H.) are mentioned in this manual, it means when you are seated on the tractor,
in the operator's position.
CAUTION: BEFORE ASSEMBLING GRASS CATCHER TO TRACTOR:
• Depress clutch/brake pedal fully and set parking brake.
• Place gearshift/motion control lever in neutral (N) position.
• Place attachment clutch in "DISENGAGED" position.
• Turn ignition key "OFF" and remove key.
• Make sure the blade and all moving parts have completely stopped.
• Disconnect spark plug wire from spark plug and place wire where it cannot come in contact with
plug.
5
Page 6
ASSEMBLY
REAR MOUNTING BRACKET
1
NOTE: If your tractor already has four (4) shoulder bolts
installed on the rear drawbar, simply hang the mounting
bracket, lanced tabs towards bottom, on the bolts. Discard
hardware group "A" and disregard the remaining Step 1
instructions.
(See Figs. 1A, 1B & 1C)
SHOULDER
BOLTS
LANCED TABS
TOWARD BOTTOM
FIG. 1A
If your tractor does not have four (4) shoulder bolts installed
on the drawbar, follow the instructions below.
Use Hardware - - GROUP "A"
Only one set of hardware in GROUP "A" will be used to mount
the rear mounting bracket. To determine which set is correct
for your tractor, check to see if there are (2) two upper corner
ribs on each side of drawbar. If your tractor has the upper
corner ribs, use the (4) four self tapping shoulder bolts. If your
tractor does not have the corner ribs, use the set of (4) four
bolts and locknuts.
SELF TAPPING SHOULDER BOLTS (SEE FIG. 1B)
1. Using the four formed holes in the drawbar, install the
four shoulder bolts as shown and tighten securely.
2. Hang the mounting bracket, lanced tabs towards bottom,
on the bolts.
UPPER CORNER
UPPER CORNER
RIBS
SELF
TAPPING
SHOULDER
BOLTS
RIBS
LANCED TABS
TOWARD BOTTOM
FIG. 1B
BOLTS AND LOCKNUTS (SEE FIG. 1C)
1. Assemble the mounting bracket, lanced tabs towards
bottom, using the four smaller inside holes on the
drawbar.
2. Install the four bolts and locknuts as shown and tighten
securely.
LOCKNUTS
LANCED TABS
TOWARD BOTTOM
BOLTS
FIG. 1C
6
Page 7
ASSEMBLY
MOUNTING TO TRACTOR (See Fig. 2)
2
NOTE: For ease of assembly, you may wish to obtain the
assistance of another person for mounting assembly to
tractor.
1. Raise seat on tractor to allow assembly to be mounted.
2. With cover closed, lift assembly and place support post
3. Line up holes in mounting bracket with holes in support
4. Unlatch and open cover.
BRACKET
SUPPORT PIN
Use Hardware - - GROUP "B"
inside mounting bracket. Allow assembly to rest on
lanced tabs of mounting bracket.
post and insert bracket support pin. Secure with retainer
spring.
COVER ASSEMBLY
RETAINER
SPRING
CONTAINER ASSEMBLY (See Fig. 3)
3
1. Place bottom half inside of top half, as shown.
2. Place one foot inside bottom half and lift top half to meet
bottom half.
3. Press halves tightly together while lifting top to lock into
place as shown.
IMPORTANT: BEFORE LOCKING THE TABS, HOOKED
EDGES ON BOTH HALVES MUST OVERLAP TO FORM
SEAL AS SHOWN IN INSET.
4. Repeat for second container.
CONTAINER
BOTTOM
HALF
No hardware required
CONTAINER
BOTTOM
HALF
CONTAINER
TOP HALF
SUPPORT POST
LANCED TABS
PRESS TOGETHER
TO FORM SEAL
WHILE LIFTING
TOP HALF
LOCKING
TAB
ASSEMBLY CHECK: Squeeze sides of lower half of container and check that there is no gap between upper and
lower halves. If a gap appears, unlock tabs to separate
container halves and repeat instructions above.
s
i
r
e
n
i
a
t
n
n
e
o
h
C
.
w
.
d
r
e
e
e
l
c
l
n
a
i
a
l
t
a
p
t
s
e
n
n
o
R
s
i
c
.
y
y
t
l
l
t
r
n
n
e
e
e
p
m
u
o
r
e
q
c
p
e
a
r
l
s
f
i
p
r
g
e
e
r
a
n
b
i
d
a
k
e
t
c
d
n
e
n
o
h
e
c
C
m
s
.
s
n
m
e
o
l
o
i
t
c
n
a
e
u
r
r
r
o
i
a
e
r
G
w
y
e
l
i
o
t
n
N
e
o
m
I
d
e
e
t
N
d
s
a
n
r
U
R
a
.
e
r
d
p
A
a
e
o
e
g
t
W
w
a
o
n
o
m
t
a
o
t
d
c
D
r
e
j
o
b
d
u
s
e
k
c
a
r
c
MOUNTING
BRACKET
FIG. 3
FIG. 2
7
Page 8
ASSEMBLY
B
B
B
LOWER CHUTE (See Fig. 4)
4
1. Lower mower deck to its lowest cutting position.
2. With your right hand, raise and hold deflector shield in
upright position.
3. With your left hand, hold lower chute as shown and
position lower rear edge of chute between gauge wheel
bracket tab and mower housing. Align "B" on lower chute
extended edge with "B" on mower housing.
4. With your right hand, push firmly on the lower chute until
the extended edge slides under the deflector shield and
along side the hinge bracket as shown.
5. With chute in proper position, hold the chute securely, so
it does not move, while hooking the rear and front latches
to the mower deck.
NOTE: While hooking the latches, the deflector shield may
try to push the chute away from the mower deck opening. It
is important to hold the chute in position while hooking the
latches to the mower deck.
• If your tractor is equipped with gage wheels on the deck,
then it will be necessary to hook the rear latch into the
hole in the R.H. gage wheel bracket.
No hardware required
CAUTION: Do not remove discharge
guard from mower. Raise and hold guard
when attaching lower chute and allow it
to rest on chute while in operation.
OPTIONAL
GAUGE
WHEEL
AND
BRACKET
LOWER REAR EDGE
BETWEEN GAUGE WHEEL
BRACKET TAB AND
MOWER HOUSING
ALIGN CHUTE "B"
WITH MOWER "B"
B
B
PUSH IN
R.H. GAGE
WHEEL
BRACKET
FIG. 4
EXTENDED EDGE "B"
Must be under deflector shield
and along side the hinge bracket
DEFLECTOR
SHIELD
DEFLECTOR SHIELD
HINGE BRACKET
FRONT
LATCH
WITH
GAGE WHEELS
REAR LATCH
GAGE WHEELS
REAR LATCHWITHOUT
8
Page 9
ASSEMBLY
ARNING
Do not operate mower unless container is properlyis
nstalled.Container is
subject to wear and detierioration. Check bag frequently
. Replace when
cracked or damaged. Use only a recommended replacement container
ARNING
Do not operate mower unless container is properlyis
nstalled.Container is
subject to wear and detierioration. Check bag frequently
. Replace when
cracked or damaged. Use only a recommended replacement container
CONTAINER MOUNTING (See Fig. 5)
5
1. Install one container to left side first with warning to
outside of unit. Install other container to right side.
NOTE: Right container should always overlap left container
at center support.
2. Close cover and lock latch handle over center support
tube.
COVER LATCH
HANDLE
CONTAINER
WARNING
CONTAINER
HANDLE
No hardware required
WA
R
D
o
N
n
I
o
N
s
t
u
o
b
G
p
j
e
e
c
r
c
a
t
r
t
a
t
e
o
c
k
m
w
e
o
e
d
w
a
o
r
e
r
a
r
d
n
u
a
d
n
m
l
d
e
a
e
s
g
t
s
i
e
e
c
d
r
o
i
.
o
n
U
r
t
a
a
s
t
i
e
i
n
o
e
n
o
r
.
n
i
C
l
s
y
h
p
a
e
r
c
o
r
e
k
p
c
e
b
o
r
a
m
l
y
g
i
m
s
f
r
e
n
e
n
s
q
d
t
u
a
e
e
l
l
d
n
e
t
d
r
l
e
y
.
C
p
.
l
o
R
a
n
c
e
t
e
a
p
m
i
l
n
a
e
e
c
n
e
r
t
i
w
s
c
h
o
e
n
n
t
a
i
n
e
r
.
s
i
r
e
n
i
a
t
n
n
o
e
C
h
.
w
d
e
.
r
e
l
l
e
c
a
n
a
t
i
l
s
a
p
t
n
e
n
s
R
o
i
c
y
.
l
y
l
t
r
t
n
e
n
e
p
e
o
u
m
r
q
e
p
e
c
r
s
a
i
f
l
r
p
g
e
e
a
r
n
i
b
d
a
k
t
e
c
n
d
e
o
n
h
c
e
C
s
m
.
s
n
e
m
l
o
o
i
n
t
c
u
a
e
r
r
r
o
e
i
G
a
r
w
e
y
o
i
l
N
t
I
n
m
e
o
d
e
N
t
e
d
a
s
R
n
r
U
a
e
.
p
r
d
o
a
e
t
e
WA
g
o
w
a
n
o
t
m
o
t
a
D
c
d
e
r
j
o
b
u
d
s
e
k
c
a
r
c
CENTER
SUPPORT
TUBE
CONTAINER
WARNING
UPPER CHUTE (See Figs. 6A & 6B)
6
• Lower mower deck to its lowest cutting position.
• Assemble upper chute by inserting curved end into hole
in back of cover.
NOTE: Handle carefully so as not to damage dump bag
indicator.
• Push in and turn upper chute until it is in line with lower
chute.
• Align the bosses on lower chute with alignment slots on
upper chute and slide together.
• Secure with rubber latch by hooking hole in latch over
latch pin.
COVER
No hardware required
DUMP BAG
INDICATOR
LOWER
CHUTE
FIG. 6A
HANDLE
UPPER
CHUTE
ALIGNMENT
SLOT
FIG. 5
LATCH PIN
RUBBER
LATCH
BOSSES
FIG. 6B
LEVEL MOWER DECK
No hardware required
7
Be sure deck is properly leveled for best mower performance. See your tractors owner's manual for instructions.
9
Page 10
OPERATION
TIPS FOR IMPROVED BAGGING
OPERATION:
Follow the mower operation instructions in your tractor
owner's manual.
When operating your grass catcher on a lawn where grass
and leaf bagging equipment has not been used, you are
picking up thatch and debris that has accumulated for long
periods of time. The amount collected and the total time of
operation may be greater than you will experience with
regular use of your grass catcher.
• Always run throttle at full speed when bagging.
• Select a gear low enough to give good mower cutting
performance, good quality cut and good bagging performance.
NOTE: It may be necessary to overlap width of cut to suit
your conditions.
• If grass is extremely tall, it should be mowed twice. The
first time relatively high, the second time to desired
height.
• Use left hand side of mower for trimming.
• Plastic trash bags can be inserted inside grass catcher
containers for ease of debris disposal. To remove the
plastic trash bags when full:
a. Disengage blades, shift into neutral, engage the
parking brake and stop the engine.
b. Raise seat. Unlatch and raise cover.
c. Remove one container at a time by grasping contai-
ner handles and pulling toward the rear, off of the
tube rails.
d. With the container resting on the ground, close and
secure the top of the plastic lawn bag.
e. Tip the container on its side and slide the filled bag
from the container.
f. Install a new plastic lawn bag with the edges of the
bag draped over upper lip of the Container (for
replacement bags refer to REPLACEMENT
PARTS).
g. Repeat for other container.
h. Reinstall containers making sure right container
overlaps left container at center support.
j. Close cover and secure latch over center support
tube.
• Avoid cutting wet grass or in the morning while the dew
is still heavy. Grass clippings collected under these
conditions tend to be sticky and adhere to the walls of
the flow path causing clogging.
• Your bagger is equipped with a dump bag indicator. As
the bags become full, the flow indicating ball will drop
down in its slot, indicating that the bags are full or the
chutes have become clogged. Care should be taken not
to damage the parts and that the ball moves freely at the
beginning of each use.
• If the grass catcher fails to pick up cut grass or leaves,
it is an indication that clogging has occurred in the
system or that the grass catcher containers are full.
a. Disengage blades, shift into neutral, engage the
parking brake and stop the engine.
- Raise seat. Unlatch and raise cover.
- Slide out containers and dispose of clippings .
- Replace containers, close cover, and latch.
b. Unlatch chutes and check for clogging
- Remove all debris in chutes.
- Reassemble and latch chutes
c. Check to insure dump bag indicator has not become
clogged.
- The air passage hole must be clear of debris.
Gently insert a small twig or wire into passageway to clear.
CAUTION
• Do not operate mower with grass catcher
partially installed.
• Disengage blades and stop engine before
leaving tractor seat to empty containers, unclogging chutes, etc.
• Close cover before starting.
• Disengage mower when crossing driveways
or gravel surfaces and other areas where thrown
objects could be a hazard.
• Do not attempt to vacuum up cans or other
potentially hazardous projectiles.
10
Page 11
CUSTOMER RESPONSIBILITIES
GENERAL RECOMMENDATIONS
Always observe safety rules when performing any maintenance.
• Before each use check for loose fasteners.
• Clean unit thoroughly after each use.
BLADE CARE
For best results mower blades must be kept sharp. Replace
bent or damaged blades.
• See BLADE CARE instructions in your tractor owner's
manual.
CAUTION: BEFORE PERFORMING ANY
MAINTENANCE, SERVICE OR ADJUST
MENTS:
• Depress clutch brake pedal fully and set
parking brake.
• Place gearshift/motion control lever in neutral (N) position.
• Place clutch control in "DISENGAGED" position.
• Turn ignition key to "OFF" position.
• Make sure blades and all moving parts have
completely stopped.
• Disconnect spark plug wire(s) from spark
plug(s) and place wire where it cannot come in
contact with plug.
STORAGE
When grass catcher is to be stored for a period of time, clean
it thoroughly, remove all dirt, grass, leaves, etc. Store in a
clean, dry place.
CAUTION: Do not leave grass in bagger
containers. Empty containers after each
use and before storing. Failure to do so
may result in spontaneous combustion
which could develop into a fire.
CAUTION: Grass catcher components
are subject to wear, damage and
deterioration, which could expose
moving parts or allow objects to be
thrown. Frequently check components
and replace with manufacturer's
recommended parts, when necessary.
11
Page 12
REPAIR PARTS / PIÈCES DE RECHANGE
GRASS CATCHER - - MODEL NUMBER QC42A / RAMASSE-HERBE - - NUMÉRO DE MODÈLE QC42A
PRODUCT NUMBER 954 04 05-10 / NUMÉRO DE PRODUIT 954 04 05-10
12
38
2
3
5
6
7
4
8
9
20
20
2
12
13
9
10
9
11
14
39
24
18
16
20
16
15
9
12
14
25
20
20
2
2
2
W
A
R
D
o
N
n
o
I
s
N
t
u
o
b
G
p
j
e
e
c
c
r
a
r
t
a
t
t
e
o
c
k
m
w
e
d
e
o
a
w
o
r
e
r
a
r
d
n
u
a
d
n
m
l
d
e
a
e
s
g
t
s
e
i
e
d
c
r
o
.
i
o
U
n
r
t
a
s
a
t
e
i
i
n
o
o
e
n
n
r
.
l
C
y
i
s
h
a
p
e
r
r
c
o
e
k
p
c
b
o
e
a
m
r
l
g
y
m
i
s
f
r
e
e
n
n
q
s
d
u
t
e
a
e
d
l
l
n
e
r
t
d
l
e
y
.
p
.
C
R
l
a
o
e
c
n
p
e
t
a
l
m
a
i
n
c
e
e
e
n
r
t
w
i
c
s
h
o
e
n
n
t
a
i
n
e
r
.
35
20
15
20
20
34
2
33
21
22
23
32
36
s
i
r
e
n
i
a
t
n
n
o
e
h
C
.
w
d
.
e
r
e
l
l
e
c
a
n
a
t
i
l
s
a
p
t
n
e
n
s
R
o
i
.
c
y
l
y
l
t
r
t
n
e
n
e
p
e
o
u
m
r
q
e
p
c
e
r
s
a
i
f
l
r
p
g
e
e
a
r
n
i
b
d
a
k
t
e
c
n
d
e
o
n
h
c
e
C
s
m
.
s
n
e
m
l
o
i
o
n
t
c
u
a
e
r
r
r
o
e
i
a
G
r
w
e
y
i
o
l
N
t
I
n
e
m
o
d
e
N
t
e
d
a
s
n
R
r
a
U
e
.
A
r
p
d
a
o
e
e
t
W
g
o
w
a
n
o
t
m
o
t
a
D
c
d
e
r
j
o
b
u
d
s
e
k
c
a
r
c
31
40
26
29
31
40
27
29
27
31
30
25
26
25
28
Page 13
REPAIR PARTS / PIÈCES DE RECHANGE
GRASS CATCHER - - MODEL NUMBER QC42A / RAMASSE-HERBE - - NUMÉRO DE MODÈLE QC42A
PRODUCT NUMBER 954 04 05-10 / NUMÉRO DE PRODUIT 954 04 05-10
KEY PART DESCRIPTION DESCRIPTION
NO. NO.
2 532069180 Nut, Crownlock #10-24 Écrou auto-serrant #10-24
3 532127533 Screen, Cover Grillage de couvercle
4 532171061 Cover Asm.(Incl. 3,38,39) Couvercle Ens.
(Y combris 3,38,39)
5 532126840 Chute, Upper Glissière supérieure
6 818021008 Screw, Special #10-14x1/2 Vis spéciale #10-14x1/2
7 532140572 Dump Bag Indicator Indicateur de sac de
13
8 532087175 Screw, #10-24 x 1-1/8 Vis #10-24 x 1-1/8
9 819061216 Washer 3/16x3/4x16 Ga. Rondelle 3/16x3/4x16 Ja.
10 532007206 Spacer, Split Entretoise fendue
11 532060867 Nut, Acorn #10-24 Écrou borgne #10-24
12 810071000 Washer, lock Rondelle frein
13 532109808 Latch, Chute Loquet de glissière
14 532125004 Nut, Weld Axe du loquet
15 532130760 Latch, H ook Crochet de loquet
16 532130759 Rubber, Latch Loquet de caoutchoc
18 532162803 Chute, Lower Glissière inférieure
20 871161010 Screw #10-24 x 5/8 Vis #10-24 x 5/8
21 532132796 Spring, Cover L.H. (black) Ressort de couvercle C.G.
22 532133235 Spacer, Cover Entretoise de couvercle
23 532132983 Spring, Cover R.H. (gray) Ressort de couvercle C.D.
déchargement
KEY PART DESCRIPTION DESCRIPTION
NO. NO.
24 532126813 Post, Support Poteau de soutien
25 532063124 Locknut 5/16 x 18 Écrou frein 5/16 x 18
26 532124670 Sp ring, Retai ner Ressort de retenue
27 874760512 Bolt, Hex 5/16-18 x 3/4 Boulon H 5/16-18 x 3/4
28 532170053 Bracket, Mounting Support de montage
29 532170165 Shoulder Bolt Boulon
30 532131137 Pin, Support Post Goupille du poteau de soutien
31 532134496 Plug, Tubing End Chapeau de l’extrémité de
tuyau
32 532126919 Bagger, Frame Cadre de ramasse-herbe
33 532128600 Pin, Hinge Goupille de charnière
34 532127534 Gasket, Cover Garniture de couvercle
35 532129585 Container, Top Conteneur supérieur
36 532129586 Container, Bottom Conteneur inférieur
38 532130895 La tch Handle, Cover Poignée de loquet de couvercle
39 532155042 Strip, Reinforcement Bande
40 872110506 Carriage Bolt 5/16-18 x 3/4 Boulon de chariot 5/16-18 x 3/4
— 532104419 Bag, 3.0 mil. 30 Gallon Sac-poubelle; 3,0 mil. 30 gallon
Trash (not included (N'y pas compris avec le
with bagger) ramasse-herbe)
— 532171112 Own er's Manual Manuel du propriétaire
Loading...
