Hunter Fan HTF2161 Installation Guide

Model: 50284 Brushed Nickel
59216 Brushed Nickel
59217 Fresh White
59446 Noble Bronze
Fan weight ±2 lbs: 19.8 lbs (9.0 kg)

Dempsey

Installation Manual

©2019 Hunter Fan Co.

PG3775 r051619

1886

Congratulations on purchasing your new Hunter® ceiling fan!

Here are the tools you’ll need to complete your installation:

The ceiling fan you purchased will provide comfort and performance in your home or ofce for many years. This instruction manual contains

WARNING

complete instructions for installing and operating your fan. We are proud of our work and appreciate the opportunity to supply you with the
best ceiling fan available anywhere in the world.

We are here to help!

This Instruction Manual is designed to make installation as simple as possible. While working through this Instruction Manual, keep
your smartphone or tablet nearby. We have added video links to help you through the more technical sections. If you are unfamiliar or
uncomfortable with wiring, contact a qualied electrician. We also provide telephone support at 1.888.830.1326 or visit us
at HunterFan.com.

READ and SAVE These Instructions

Warning

w.1 - To reduce the risk of re, electrical shock, or personal injury, mount fan directly from building structure and/or an outlet box marked acceptable for fan support of 70 lbs (31.8 kg) and use the
mounting screws provided with the outlet box.

w.2 - To avoid possible electrical shock, before installing or servicing your fan, disconnect the power by turning off the circuit breakers to the outlet box and associated wall switch location. If you
cannot lock the circuit breakers in the off position, securely fasten a prominent warning device, such as a tag, to the service panel.

w.3 – To reduce the risk of electric shock, this fan must be installed with an isolating wall control/switch.
w.4 - To reduce the risk of personal injury, do not bend the blade brackets when installing the blade brackets, balancing the blades, or cleaning the fan. Do not insert foreign objects in between

rotating fan blades.
w.5 - Chemical burn hazard. Keep batteries away from children. This remote contains a lithium button cell battery. If a new or used lithium button/coin cell battery is swallowed or enters the body,

it can cause severe internal burns and can lead to death in as little as 2 hours. Always completely secure the battery compartment. If the battery compartment does not close securely, stop using
the product, remove the batteries, and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
Dispose of cells properly and keep away from children. Even used cells may cause injury.

Caution

c.1 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualied electrician.
c.2 - Use only Hunter replacement parts.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions
may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.
Caution: modications not approved by the party responsible for compliance could void user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This product conforms to UL Standard 507.

OPTIONAL

If mounting to a support structure, you will also need these tools.

Ladder

Pliers

1

Screwdriver

Wire Strippers

9/64” Drill BitDrill

1886

We recommend that you pull everything out of the box and lay it out. We have

Here is what comes in your box:

grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.

Hunter Pro Tip:

Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.

bag

Washer

x2

For installing the hanger bracket and wiring the fan

x12 x12

bag bag

Wood Screw

Wire Nut

x2

x4

Blade ScrewBlade Washer

Ceiling Bracket

Canopy

Downrod

bag

For installing the canopy

Motor

Upper Switch Housing

Canopy
Screw

x2

For installing the blades

Remote Control

Remote Receiver

Remote Components

Remote Cradle

Blade

x4

bag

For your convenience,
you may receive extra fasteners.

Extra Downrod

Spare Parts

Light Kit Assembly

bagx2

Glass

For installing the light kit

Find a part that is missing or damaged?

Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.

x6Light Kit Screw

M0233-01 r051619

2

1886

1886

Choosing the Right Installation Location

Checking the Ceiling Angle:

Angled Mounting

You probably bought this fan with a location in mind. Let’s check below to make sure it is a good t.

Installing the Downrod

Installing the Ceiling Bracket

Check the room dimensions: Check the outlet box:

30 inches

from blade tip to
nearest wall or
obstruction

7 feet

from bottom edge

of blade to the

oor

Standard Mounting

Support Structure

Outlet Box

(required)

Ceiling

You must be able to
secure the fan to building
structure or fan-rated
outlet box.

Support
Structure

Angled Mounting

Ceiling

Outlet Box

(required)

If you have a at ceiling:

Hang your fan by a standard downrod. Some fans come
with a shorter downrod for a Low Prole installation.

A little more information on Angled Mounting:

For optimum performance and appearance, a longer downrod should
be used with your Hunter ceiling fan when installing on high or angled
ceiling. If your ceiling is angled greater than 34° you will also need an
Angled Mounting Kit. Longer downrods and the Angled Mounting Kit are
sold separately at HunterFan.com.

Hunter Pro Tip:

Determining if you need an Angled Mounting Kit:

Fold on the dotted line. Place against edge againts
the wall. Slide towards the ceiling.

If the guide touches the wall but not the ceiling, you
need an angled mounting kit.

WALL

If you have an angled or vaulted ceiling:

1. You will need a longer downrod. (sold separately at HunterFan.com)

2. If your ceiling angle is greater than 34°, you will also need an
Angled Mounting Kit. (Sold separately at HunterFan.com)

3

34°

CEILING

1886

You have two options for installation. Pick which one works best for your location. Remove any existing

Installing the Downrod

WARNING

Installing the Ceiling Bracket

bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box.

Do this rst!

Turn Power

OFF

Hunter Pro Tip:

The machine screws are the ones
that came with your outlet box.

x2

Washer

Option 1:
Machine Screws

Use machine screws
(provided with outlet box)
and washers when securing
to existing ceiling fan-rated
outlet box. Make sure it is
securely installed and is
acceptable for fan support of

31.8 kg (70 lbs) or less.

ANGLED

For angled ceilings,
point opening
toward peak.

Follow below if you are using the downrod that came pre-assembled in your box. Need to
install a longer or shorter downrod? Check out the guide at the end of this manual.

MOUNTING TIP

2

STEP

3/8”

Hunter Pro Tip:

The ground wire attached to the
downrod is approximately 8 inches.

T

U

C

P

I

R

T

S

&

Option 2:

Wood Screws

Use wood screws and
washers (included) when
securing to support structure
with approved electrical
outlet box. Drill 9/64” pilot
holes in support structure
to aid in securing ceiling
bracket with hardware found
in the hardware bag.

3

STEP

bag

x2

Wood Screw

1

STEP

E

E

P

K

!

Remove the pre-installed
setscrew so that the
downrod can be inserted.

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

8”

(not to scale)

Pass all wires to one side of horizontal
bar in downrod assembly. Hand tighten
the downrod (at least 4–5 full turns)
until it stops. Trim the wires coming
from the fan so that 8-inches remain
coming from the top of the downrod.

Tighten the setscrew
with pliers. DO NOT

HAND TIGHTEN.

FAN FALL HAZARD
To prevent SERIOUS INJURY or DEATH:

• A LWAY S tighten setscrew with pliers.

• DO NOT hand tighten setscrew.

• CHECK the setscrew is tight using pliers

each time you change fan direction.

4

1886

1886

Hanging the Fan

S

NOTICE

Wiring the Fan

l

i

d

e

c

a

n

o

p

y

o

v

e

r

d

o

w

n

r

o

d

a

n

d

w

i

r

e

s

.

Progress Check:

Your fan should look like this.

To prevent damage to fan,
ALWAYS lift holding either the
fan housing or the downrod.

Place the downrod ball into
the slot in the ceiling bracket.

5

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

1886

We know wiring is hard. Let’s make it easier.

Wiring the Fan

NOTICE

WARNING

Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch
setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualied electrician.

Hunter Pro Tip:

Here is how to connect the wires:

The Exeter ceiling fan is designed to be operated by
the included remote. Keep your switches in the “On”
position to ensure proper functionality.

All wiring must be in accordance with
national and local electrical codes ANSI/NFPA

70. If you are unfamiliar with wiring or in
doubt, consult a qualied electrician.

Push the bare metal ends of the wires together and slide a wire
nut over them. Then, twist the wire nut clockwise until tight.

Give it a gentle pull to make sure none of the wires are loose.

Slide the remote
receiver onto the
top of the bracket.

Hunter Pro Tip:

Have extra wiring?

Turn the wires upward and push them carefully back through
the hanger bracket into the outlet box. Make sure that the
wires are still attached to the wire nuts.

Connect the black
(ungrounded) wire from
the ceiling to the black
wire from the receiver.

Connect the white (grounded)
wire from the ceiling to both
the white wire from the
receiver and the white wire
from the fan.

bag

Wire Nut

Black

Grounded

x4

Ungrounded

White

White

Black

Yellow

Blue

Blue

Connect the blue wire
from the receiver to the
blue wire from the fan.

Connect the yellow
wire from the
receiver to the black
wire from the fan.

Grounding

Green/Yellow Stripe

Blue

Blue

G

r

e

e

n

/

Y

e

l

l

o

w

S

t

r

i

p

e

Connect the three
grounding wires (green,
green/yellow stripe, or
bare copper) coming from
the ceiling, downrod, and
hanging bracket.

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

6

1886

1886

Installing the Glass

Installing the Blades:

Installing the Canopy

Insert the two canopy screws

Assembling the Light Kit

found in the hardware bag.

x2

Canopy Screw

bag

F

i

t
t

h

e

c

a

n

o

p

y

i

n

p

l

a

c

e

a

s

s

h

.

o

n

w

Lift the canopy into place so that
the screw holes are aligned.

Attach each blade to a blade iron using
three blade washers, found in the
hardware bag, and three blade assembly
screws, found in the hardware bag.

bag

Blade Screw

x12

Repeat x4

bag

Blade Washer

x12

7

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

1886

Installing the Glass

WARNING

Assembling the Light Kit

WARNING

bag

2 of 6

Light Kit Screw

bag

1 of 6

Light Kit Screw

Screw two housing assembly screws from the
hardware bag halfway into the motor housing. It
does not matter which two screw holes you choose.

2 of 6

Light Kit Screw

bag

Screw two housing assembly screws from the

hardware bag halfway into the upper switch
housing. It does not matter which two screw
holes you choose.

Feed the wire plug through the center hole
of the upper switch housing, then wrap
keyhole slots around the screws and twist
counterclockwise.

Connect the plugs from the upper and lower
switch housings. Make sure to line up the
colored markings on the connectors.Wrap light
kit keyhole slots around the screws and twist
counterclockwise.

Insert the third screw, found in the

hardware bag, into place and then

tighten all three screws.

1 of 6

bag Light Kit Screw

Insert the third screw, found in the bag of
materials, into place and tighten the three
screws.

FAN FALL HAZARD

Make sure all screws are tight to secure
the light xture.

Tab

Notch

Attach the globe by lifting and

Install the included bulbs
into the sockets. When
necessary, replace with
bulbs of same wattage.

Lift the globe and align the
notches in the globe with
the tabs in the light kit.

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

turning clockwise one third of a
full turn of the glass until it stops.

NOTE: Check to ensure
proper engagement.

GLASS FALL HAZARD

To prevent SERIOUS INJURY or DEATH, make
sure that glass is properly secured.

8

1886

1886

Preparing the Remote Control

Using the Remote Control Cradle

The remote control is already
paired for use.

For your convenience, a
remote function card is
packed in with your remote.

Turn Power

ON

Battery Door

Phillips Head
Screw

To access the battery compartment, remove the
small Phillips head screw that secures the battery
door to the transmitter assembly. The battery
should be installed with the positive (+) side up.
Replace with a CR2032 battery when necessary.

The remote transmitter should already be paired
to the receiver and ready to use.

Note: If your need to pair your remote, turn fan
power off and back on at the wall switch. Within
3 minutes, press and hold both the Fan Off button
and the High button for 4 seconds to pair the
remote. To prevent faulty operation, please

ensure all other ceiling fans within range are
turned off at the wall switch while pairing.

Fan Medium

Fan Off

Fan Low

Light On/Off

To turn on fan, press a fan speed
button. Speeds range from off (0)
to high (3). Quickly press the Light
button to turn the lights off and on.

Fan High

Switch Cover
Plate

To install the transmitter cradle, remove the two
screws holding the switch cover plate. Do not remove
the cover plate. Orient the cradle by lining up the two
mounting holes with those on the cover plate. Insert
and tighten the screws. Do not over tighten.

Rocker Style
Plate

Removed Tabs

Note: For rocker-style cover plates, break off the
tabs by pushing outward.

9

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

1886

Troubleshooting

Reverse

Controlling Your Fan

Fan Doesn’t Work

Excessive Wobbling

Noisy Operation

Remote Control of Fan is Erratic

Remote Only Works Close to Fan

Remote Pairing Issues

Multiple Remote Issues

Switch

Ceiling fans work in two directions: downdraft
(counterclockwise rotation) and updraft
(clockwise rotation). To change the direction
of air ow, turn the fan off and let it come to a
complete stop. The reversing switch is located
inside the light xture. It can only be accessed
when the glass is removed. Slide the reversing
switch to the opposite position. Restart the fan.

Updraft (clockwise rotation)
creates a more indirect airow.
Updraft airow is great for
moving warm air downward.

Downdraft (counterclockwise
rotation) creates a direct breeze
and maximum cooling effect.

• Make sure power switch is on.

• Push the motor reversing switch rmly left or right to
ensure that it is engaged.

• Check the circuit breaker to ensure the power is
turned on.

• Make sure the blades spin freely.

• Turn off power from the circuit breaker, then loosen
the canopy and check all the connections according
to the wiring diagram.

• Check the plug connection in the switch housing.

• Make sure the blades are properly installed on the
blade iron posts.

• Turn the power off, support the fan carefully, and
check that the hanger ball is properly seated.

• Use the provided balancing kit and instructions to
balance the fan.

• Make sure the blades are properly installed.

• Check to see if any of the blades are cracked. If so,

replace all of the blades.

• Make sure the battery is installed correctly.

• Install a fresh battery.

• Change battery.

1. To prevent faulty operation, please ensure all other
ceiling fans within range are turned off at the wall
switch while pairing.

2. If your need to pair your remote, turn fan power off
and back on at the wall switch. Within 3 minutes,
press and hold both the Fan Off button and the High
button for 4 seconds to pair the remote.

• If you have multiple remotes or multiple remote­controlled fans installed on the same circuit breaker
and you are experiencing interference or faulty
operation of your remote controls, please go to
www.HunterFan.com/FAQs and click “How do I

properly install multiple remote-controlled fans?” for

information on how to correct this issue.

Hunter Pro Tip:

Cleaning the Fan

Use soft brushes or cloths to prevent scratching.
Cleaning products may damage the nishes.

Ceiling Bracket Hanging Fan Wiring Blades Light Remote Trouble Shooting

10

1886

1886

Hunter Fan Company grants this limited warranty to the original purchaser of this Hunter

Limited Lifetime Warranty

Downrod

WARNING

ceiling fan. This document can be found at www.HunterFan.com.
Thank you for choosing Hunter!

How Can Warranty Service Be Obtained?

Proof of purchase is required when requesting warranty service. The original

purchaser must present a sales receipt or other document that establishes proof of
purchase. Hunter, at its sole discretion, may accept a gift receipt. To obtain service,
contact Hunter Fan Company online or by phone.

www.HunterFan.com/Support/Contact-Us/

1-888-830-1326

Please do not ship your fan or any fan parts to Hunter. Delivery will be refused.

What Does This Warranty Cover?

Motor — Limited Lifetime Warranty

If any part of your ceiling fan motor fails during your ownership of the fan due to a
defect in material or workmanship, as determined solely by Hunter, Hunter will provide
you with a replacement fan free of charge.* The foregoing limited warranty applies only
to the motor itself and does not apply to electronic controls – such as remote control
transmitters, remote control receivers, or capacitors – used in conjunction with the
motor. Such electronic control items are included in the one-year limited warranty below.

Other — One-Year Limited Warranty

Except as otherwise indicated throughout this warranty, if any part of your Hunter ceiling
fan fails at any time within one year of the date of purchase due to a defect in material
or workmanship, as determined solely by Hunter, Hunter will provide a replacement part
free of charge.*

Light Kits — Warranty May Vary

Light kits are included in the one-year limited warranty. However, you may qualify for
additional warranty coverage if your fan includes one of the following:

• LED Light Kits — Three-Year Limited Warranty
If your LED light kit module (not including glass components) or LED bulb
fails at any time within three years of the date of purchase due to a defect
in material or workmanship, as determined solely by Hunter, Hunter will
provide a replacement part free of charge.*

What Does This Warranty NOT Cover?

Labor Excluded. This warranty does not cover any costs or fees associated with the labor
(including electrician’s fees) required to install, remove, or replace a fan or any fan parts.
There is no warranty for light bulbs (except where otherwise noted); remote control
batteries; fans purchased or installed outside the United States; fans owned by
someone other than the original purchaser; fans for which proof of purchase has not
been established; fans purchased from an unauthorized dealer; ordinary wear and tear;
minor cosmetic blemishes; refurbished fans; and fans that are damaged due to any
of the following: improper installation, misuse, abuse, improper care, failure to follow
Hunter instructions, accidental damage caused by the fan owner or related parties,
modications to the fan, improper or incorrectly performed maintenance or repair,
improper voltage supply or power surge, use of improper parts or accessories, failure to
provide maintenance to the fan, or acts of God (e.g. ood).
ORIGINAL PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR A CLAIM OF ANY KIND
WITH RESPECT TO THIS PRODUCT SHALL BE THE REMEDIES SET FORTH HEREIN.
HUNTER FAN COMPANY IS NOT RESPONSIBLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES, DUE TO PRODUCT FAILURE, WHETHER ARISING OUT OF BREACH OF
WARRANTY, BREACH OF CONTRACT, OR OTHERWISE. Some States do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE APPLICABLE TO THIS PRODUCT ARE LIMITED IN DURATION TO THE PERIOD OF
COVERAGE OF THE APPLICABLE LIMITED WARRANTIES SET FORTH ABOVE. Some States
do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.

How Does State Law Affect Warranty Coverage?

This warranty gives you specic legal rights. You may also have other rights which vary
from state to state.

FAN FALL HAZARD
To prevent SERIOUS INJURY or DEATH:

• A LWAYS follow the downrod assembly

If you need a different downrod length follow these steps:

instructions exactly.

• VERIFY the downrod is assembled correctly
by rmly pulling on the hanger ball.

Follow steps 1-5 to remove standard downrod pipe

1 2 3 4 5

11

Follow steps 6-10 to reassemble with new downrod

678910
