Hunter Fan HTF10213 Installation & Assembly

Model: 59608 Matte Silver
59609 Matte Black
59610 Fresh White
Fan weight ±2 lbs: 18.7 lbs (8.5 kg)

Trimaran

Installation Manual

©2019 Hunter Fan Co.

PG3791 r100719

Congratulations on purchasing your new Hunter® ceiling fan!

Here are the tools you’ll need to complete your installation:

The ceiling fan you purchased will provide comfort and performance in your home or ofce for many years. This

WARNING

instruction manual contains complete instructions for installing and operating your fan. We are proud of our work and
appreciate the opportunity to supply you with the best ceiling fan available anywhere in the world.

We are here to help!

This Instruction Manual is designed to make installation as simple as possible. While working through this Instruction
Manual, keep your smartphone or tablet nearby. We have added video links to help you through the more technical
sections. If you are unfamiliar or uncomfortable with wiring, contact a qualied electrician. We also provide telephone
support at 1.888.830.1326 or visit us at HunterFan.com.

READ and SAVE These Instructions

Warning

w.1 - To reduce the risk of re, electrical shock, or personal injury, mount fan directly from building structure and/or an outlet box marked acceptable for fan support of 70 lbs (31.8 kg) and use the

mounting screws provided with the outlet box.

w.2 - To avoid possible electrical shock, before installing or servicing your fan, disconnect the power by turning off the circuit breakers to the outlet box and associated wall switch location. If you

cannot lock the circuit breakers in the off position, securely fasten a prominent warning device, such as a tag, to the service panel.
w.3 – To reduce the risk of electric shock, this fan must be installed with an isolating wall control/switch.
w.4 - To reduce the risk of personal injury, do not bend the blade brackets when installing the blade brackets, balancing the blades, or cleaning the fan. Do not insert foreign objects in between

rotating fan blades.

Caution

c.1 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualied electrician.
c.2 - Use only Hunter replacement parts.

Ladder

Screwdriver

This product conforms to UL Standard 507.

OPTIONAL

If mounting to a support structure, you will also need these tools.

9/64” Drill BitDrill

Pliers

1

© 2019 Hunter Fan Company
7130 Goodlett Farms Pkwy, Suite 400

Wire Strippers

Memphis TN 38016

1886

We recommend that you pull everything out of the box and lay it out. We have

Here is what comes in your box:

grouped the drawn components below with the hardware you’ll need for those

parts. The screws below are drawn to scale to make it easier to identify what

piece of hardware is needed to install each component.

Hunter Pro Tip:

Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.

bag

Washer

x2

For installing the hanger bracket and wiring the fan

x9 x9

bag bag

Ceiling Gasket

Ceiling Plate

Wood Screw

Wire Nut

x2

Ceiling Bracket

bag

x4

Canopy

Downrod

Adapter Cover

Blade ScrewBlade Washer

bag

For installing the canopy

Ceiling Plate
Screw

x4

Flange Nut

x4

Canopy
Screw

x2

x3

Housing
Screw

Blade

For installing the blades

Wall Control and Extra Downrod

bag

For your convenience,
you may receive extra fasteners.

Spare Parts

x3

Motor

Gasket

Upper Switch Housing

Lower Switch Housing

Lower Switch Housing Cap

bag

x3

Short Housing
Screw

x4

Cap Screw

M3756-01 r100719

Note:

Fan style may vary.

Find a part that is missing or damaged?

Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.

2

1886

1886

Preparing the Ceiling Bracket

Installing the Ceiling Bracket

Choosing the Right Installation Location

Checking the Ceiling Angle:

Angled Mounting

You probably bought this fan with a location in mind. Let’s check below to make sure it is a good t.

Check the room dimensions: Check the outlet box:

30 inches

from blade tip to
nearest wall or
obstruction

7 feet

from bottom edge

of blade to the

oor

Standard Mounting

Support Structure

Outlet Box

(required)

Ceiling

You must be able to
secure the fan to building
structure or fan-rated
outlet box.

Support
Structure

Angled Mounting

Ceiling

Outlet Box

(required)

If you have a at ceiling:

Hang your fan by a standard downrod. Some fans come
with a shorter downrod for a Low Prole installation.

A little more information on Angled Mounting:

For optimum performance and appearance, a longer downrod should
be used with your Hunter ceiling fan when installing on high or angled
ceiling. If your ceiling is angled greater than 34° you will also need an
Angled Mounting Kit. Longer downrods and the Angled Mounting Kit are
sold separately at HunterFan.com.

Hunter Pro Tip:

Determining if you need an Angled Mounting Kit:

WALL

Fold on the dotted line. Place against edge againts
the wall. Slide towards the ceiling.

If the guide touches the wall but not the ceiling, you
need an angled mounting kit.

If you have an angled or vaulted ceiling:

1. You will need a longer downrod. (sold separately at HunterFan.com)

2. If your ceiling angle is greater than 34°, you will also need an
Angled Mounting Kit. (Sold separately at HunterFan.com)

3

34°

CEILING

1886

Preparing the Ceiling Bracket

Installing the Ceiling Bracket

Do this rst!

WARNING

To avoid possible electrical shock, before
installing your fan, disconnect the power by
turning off the circuit breakers to the outlet box
associated with the wall switch location.

Turn Power

OFF

To avoid possible electrical shock, before
installing your fan, disconnect the power by
turning off the circuit breakers to the outlet
box associated with the wall switch location.

1

STEP

2

STEP

bag

x4

Canopy Plate Screw

x4

Flange Nuts

STEP

3

Align the tapered mounting holes in the ceiling plate
with the holes in the ceiling bracket. Install the four
ceiling plate screws found in the hardware bag and
secure with the ange nuts using an 11/32” wrench.

Remove all four
mounting isolators.

Hold the ceiling bracket assembly up to the outlet box
and mark the screw locations. To mount to support
structure, also mark the ceiling for drilling pilot holes.

You have two options for installation. Pick which one works best for your location. Remove any existing
bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box.

Hunter Pro Tip:

The machine screws are the ones
that came with your outlet box.

Option 1:
Machine Screws

Use machine screws (pro­vided with outlet box) when
securing to existing ceiling
fan-rated outlet box. Make
sure it is securely installed
and is acceptable for fan
support of 31.8 kg (70 lbs)
or less.

Option 2:

Wood Screws

Use wood screws (included)
when securing to support
structure with approved
electrical outlet box. Drill
9/64” pilot holes in support
structure to aid in securing
ceiling bracket with
hardware found in the
hardware bag.

MOUNTING TIP

Install the ceiling plate gasket onto
the ceiling plate. The four holes in
the ceiling plate should lineup with
the four posts in the gasket.

x2

Washer

bag

ANGLED

For angled ceilings,
point opening
toward peak.

Ceiling Bracket Downrod Hanging Fan Wiring Canopy Blades Control

Use the wood screw to poke holes
through the rubber gasket in
order to install the ceiling bracket
assembly to your support structure
or ceiling fan-rated outlet box.

x2

Wood Screw

4

1886

1886

Hanging the Fan

NOTICE

Follow below if you are using the downrod that came pre-assembled in your box. Need to

Installing the Downrod

WARNING

Wiring the Fan

install a longer or shorter downrod? Check out the guide at the end of this manual.

Hunter Pro Tip:

1

STEP

Slide the adapter cover onto
the downrod until it rests
against the hanger ball.

Hunter Pro Tip:

The adapter cover is not used for
low-prole mounting.

4

STEP

2

STEP

Remove the pre-installed
setscrew so that the
downrod can be inserted.

5

STEP

3

STEP

E

E

P

K

!

Pass all wires to one side of horizontal bar
in downrod assembly. Hand tighten the
downrod (at least 4–5 full turns) until it
stops. Trim the wires coming from the fan
so that 8-inches remain coming from the
top of the downrod.

The ground wire attached to the
downrod is approximately 8 inches.

Tighten the setscrew
with pliers. DO NOT

HAND TIGHTEN.

S

l

i

d

e

c

a

n

o

p

y

o

v

e

r

d

o

w

n

r

o

d

a

n

FAN FALL HAZARD

To prevent SERIOUS INJURY or DEATH:

• A LWAY S tighten setscrew with pliers.

• DO NOT hand tighten setscrew.

• CHECK the setscrew is tight using pliers

each time you change fan direction.
Lower the adapter cover until it rests ush
against the motor housing.

To prevent damage to fan,
ALWAYS lift holding either the
fan housing or the downrod.

d

w

i

r

e

s

.

Place the downrod ball into
the slot in the ceiling bracket.

5

Ceiling Bracket Downrod Hanging Fan Wiring Canopy Blades Control

1886

Installing the Canopy

We know wiring is hard. Let’s make it easier.

Wiring the Fan

WARNING

WARNING

Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch
setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualied electrician.

You are going to need these:

4 Wire Nuts (these are in the bag)

Have a single switch?

Follow these steps:

Connect the white
(grounded) wire
from the ceiling
to the white wire
from the fan.

Connect the black (live)
wire from the ceiling to the
black and blue wires from
the fan.

Grounded

White

Blue

Black

Live

Hunter Pro Tip:

Here is how to connect the wires:

Push the bare metal ends of the wires together and slide a wire
nut over them. Then, twist the wire nut clockwise until tight.

Give it a gentle pull to make sure none of the wires are loose.

G

r

e

e

n

/

Y

e

l

l

Grounding

Green/Yellow Stripe

o

w

S

bag

Connect the three
grounding wires (green,

t

r

i

p

e

green/yellow stripe, or
bare copper) coming from
the ceiling, downrod, and
hanging bracket.

Wire Nut

x4

The ceiling fan must be grounded. If the
ground wire for the installation site is not
present, immediately STOP installation and
consult a qualied electrician.

F

i

t
t

h

e

c

a

n

o

p

y

i

n

p

l

a

c

e

a

s

s

h

.

o

n

w

All wiring must be in accordance with
national and local electrical codes ANSI/NFPA

70. If you are unfamiliar with wiring or in
doubt, consult a qualied electrician.

Lift the canopy into place so that
the screw holes are aligned.

Hunter Pro Tip:

Have extra wiring?

Turn the wires upward and push them carefully back through
the hanger bracket into the outlet box. Make sure that the
wires are still attached to the wire nuts.

Insert the two canopy screws
found in the hardware bag.

Canopy Screw

bag

x2

Ceiling Bracket Downrod Hanging Fan Wiring Canopy Blades Control

6

1886

1886

Installing the Switch Housing and Cap

Installing Wall Control

Installing the Blades

Put the blade washers found in the hardware
bag onto the blade screws found in the
hardware bag. Then install the blade screws to
secure each blade to the fan.

Repeat x3

bag

x9

Blade Screw

NOTE: Follow the instructions on the blade. Installing it
incorrectly could result in your fan not functioning.

bag bag

Partially install two switch housing screws, found
in the hardware bag, through the gasket
halfway into the motor housing as shown. It does
not matter which two screw holes you choose.

IMPORTANT

bag

Blade Washer

2 of 3 1 of 3

Switch Housing
Screw

Feed the wire plug through the center hole of the uppers
switch housing. Align the keyhole slots in the upper
switch housing with the two screws you just installed.
Lift the upper switch housing so that the keyhole slots
engage the two screws, and twist counterclockwise to
lock the upper switch housning into place.

Insert the third screw found in the
hardware bag, into place and then tighten all
three screws.

x9

Switch Housing
Screw

Lift the the lower switch housing and
connect the plugs. Make sure to line up the
colored markings on the connectors and
that the connectors latch.

Lift the cap and align cap
holes with the extend tabs
of the fan housing.

Using the three short housing
screws found in the hardware
bag, mount the lower switch
housing to the upper switch housing.

Insert the cap screws found in
the hardware bag

bag

4 of 4

Cap Screw

Note:

Fan style may vary.

bag

3 of 3

Short Housing

Screw

Turn Power

ON

7

Ceiling Bracket Downrod Hanging Fan Wiring Canopy Blades Control

1886

Installing Wall Control

Turning off the power

WARNING

1

Ensure the power is OFF at the outlet box
and wall switch location before proceeding
with installation.

To avoid possible electrical shock, before
installing your fan, disconnect the power by
turning off the circuit breakers to the outlet
box associated with the wall switch location.

Turn Power

OFF

Preparing the Wall Switch

2

After removing the switch plate cover,
remove all wiring from the switch.

Wiring the Wall Control

3

Using the wire connectors, connect each
black wire from the wall control to a
black wire from the switch box. Connect
the green with yellow stripe wire to the
grounding wire from the switch box.

Note: If two white wires are present in the
switch box, connect them to each other if
they are not already connected.

Installing the Wall Control

4

Insert the wall control into the outlet
box and secure the two metal tabs to
the tabs on the switch box using the
two at head screws that came with the
switch box.

1.

1.

1.

2.

2.

2.

Installing the Wall Plate

5

Remove the knob from the wall
control and mount the faceplate (not
included) to the wall control using the
two #6-32 screws you removed earlier
from the faceplate.

Installing the Wall Plate (CONT)

6

Reattach the knob onto the wall
control and turn it to the left for the
OFF position.

1.

2.

Turning

7

on the
power

Turn Power

ON

Ceiling Bracket Downrod Hanging Fan Wiring Canopy Blades Control

8

1886

1886

Reversing the Fan

Ceiling fans work in two directions: downdraft (counterclockwise

Troubleshooting

Fan Doesn’t Work

Excessive Wobbling

Noisy Operation

rotation) and updraft (clockwise rotation). To change the direction
of air ow, turn the fan off and let it come to a complete stop. The
cap must be removed in order to access the reversing switch.
Slide the reversing switch to the opposite position. Restart the fan.

Reverse
Switch

Updraft (clockwise rotation)
creates a more indirect airow.
Updraft airow is great for
moving warm air downward.

Downdraft (counterclockwise
rotation) creates a direct breeze
and maximum cooling effect.

• Push the motor reversing switch rmly left or right to ensure that it is engaged.

• Check the circuit breaker to ensure the power is turned on.

• Make sure the blades spin freely.

• Turn off power from the circuit breaker, then loosen the canopy and check all the
connections according to the wiring diagram.

• Make sure the blades are properly installed on the blade iron posts.

• Turn the power off, support the fan carefully, and check that the hanger ball is
properly seated.

• Use the provided balancing kit and instructions to balance the fan.

Hunter Pro Tip:

Cleaning the Fan

Use soft brushes or cloths to prevent scratching.
Cleaning products may damage the nishes.

• Make sure the blades are properly installed.

• Check to see if any of the blades are cracked. If so, replace all of the blades.

9

1886

Hunter Fan Company grants this limited warranty to the original purchaser of this Hunter

Limited Lifetime Warranty

Downrod

WARNING

ceiling fan. This document can be found at www.HunterFan.com.
Thank you for choosing Hunter!

How Can Warranty Service Be Obtained?

Proof of purchase is required when requesting warranty service. The original

purchaser must present a sales receipt or other document that establishes proof of
purchase. Hunter, at its sole discretion, may accept a gift receipt. To obtain service,
contact Hunter Fan Company online or by phone.

www.HunterFan.com/Support/Contact-Us/

1-888-830-1326

Please do not ship your fan or any fan parts to Hunter. Delivery will be refused.

What Does This Warranty Cover?

Motor — Limited Lifetime Warranty

If any part of your ceiling fan motor fails during your ownership of the fan due to a
defect in material or workmanship, as determined solely by Hunter, Hunter will provide
you with a replacement fan free of charge.* The foregoing limited warranty applies only
to the motor itself and does not apply to electronic controls – such as remote control
transmitters, remote control receivers, or capacitors – used in conjunction with the
motor. Such electronic control items are included in the one-year limited warranty below.

Other — One-Year Limited Warranty

Except as otherwise indicated throughout this warranty, if any part of your Hunter ceiling
fan fails at any time within one year of the date of purchase due to a defect in material
or workmanship, as determined solely by Hunter, Hunter will provide a replacement part
free of charge.*

* If no replacement product/part can be provided for your fan, we will provide a comparable or
superior replacement product/part at the sole discretion of Hunter.

What Does This Warranty NOT Cover?

Labor Excluded. This warranty does not cover any costs or fees associated with the labor
(including electrician’s fees) required to install, remove, or replace a fan or any fan parts.
There is no warranty for light bulbs (except where otherwise noted); remote control
batteries; fans purchased or installed outside the United States; fans owned by

someone other than the original purchaser; fans for which proof of purchase has not
been established; fans purchased from an unauthorized dealer; ordinary wear and tear;
minor cosmetic blemishes; refurbished fans; and fans that are damaged due to any
of the following: improper installation, misuse, abuse, improper care, failure to follow
Hunter instructions, accidental damage caused by the fan owner or related parties,
modications to the fan, improper or incorrectly performed maintenance or repair,
improper voltage supply or power surge, use of improper parts or accessories, failure to
provide maintenance to the fan, or acts of God (e.g. ood).
ORIGINAL PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR A CLAIM OF ANY KIND
WITH RESPECT TO THIS PRODUCT SHALL BE THE REMEDIES SET FORTH HEREIN.
HUNTER FAN COMPANY IS NOT RESPONSIBLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES, DUE TO PRODUCT FAILURE, WHETHER ARISING OUT OF BREACH OF
WARRANTY, BREACH OF CONTRACT, OR OTHERWISE. Some States do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE APPLICABLE TO THIS PRODUCT ARE LIMITED IN DURATION TO THE PERIOD OF
COVERAGE OF THE APPLICABLE LIMITED WARRANTIES SET FORTH ABOVE. Some States
do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.

How Does State Law Affect Warranty Coverage?

This warranty gives you specic legal rights. You may also have other rights which vary
from state to state.

If you need a different downrod length follow these steps:

Follow steps 1-5 to remove standard downrod pipe

1 2 3 4 5

Follow steps 6-10 to reassemble with new downrod

678910

FAN FALL HAZARD

To prevent SERIOUS INJURY or DEATH:

• A LWAYS follow the downrod assembly

instructions exactly.

• VERIFY the downrod is assembled correctly
by rmly pulling on the hanger ball.

10
