Programmable Thermostat

installation and

operation manual

Model

English

44155c

Table of Contents

Important Information....................................... 5

Tools ................................................................ 6

Uninstalling the Existing Unit ........................... 7

Installing the Thermostat ............................... 12

installing the wall plate ................................ 12

connecting the wires ................................... 16

attaching the thermostat ............................. 18

Settings ......................................................... 22

Methods of Operation ................................... 26

manual operation ........................................ 28

default programs ......................................... 32

creating custom programs .......................... 34

Icons and Features ....................................... 38

Troubleshooting ............................................ 49

Set & Save

Programmable Thermostat

Model 44155C

Congratulations!

Thank you for choosing a Hunter programmable thermostat. Your new Hunter thermostat will provide years of reliable service and year-round energy savings.

Please read this manual before beginning installation and save this booklet for complete operation instructions.

IMPORTANT INFORMATION

This thermostat is designed to work on the following

heating and cooling systems:

Gas – Standing Pilot

Gas – Electronic Ignition

Gas – Fired Boilers

Gas – Milivolt Systems

Oil – Fired Boilers

Oil – Fired Furnace

Electric Furnace

Electric Air Conditioning

Single Stage Heat Pump - No auxilary

This thermostat is not designed for multi-stage heat pump systems or 110/220 V baseboard heating

systems.

If you are unsure what kind of heating and cooling

system you have, please contact a qualied HVAC

Technician for assistance.

TOOLS

This thermostat includes two #8 slotted screws

and two wall anchors for mounting.

To install your new thermostat, you will need the

following supplies:

....................................................................................

Small Phillips-head screwdriver

Flat-head screwdriver

....................................................................................

Hammer

....................................................................................

Electric drill and 3/16” bit

....................................................................................

Two 1.5 Volt (AA) size alkaline batteries

....................................................................................

NOTICE! Do not disconnect the

wires from the existing thermostat

before reading these instructions.

The wires must be labeled prior

to removal to ensure proper

reconnection.

UNINSTALLING THE EXISTING UNIT

1. Turn the system power OFF from the existing thermostat. Turn the power to the HVAC system OFF at the main power panel or at the furnace.

2. Remove the existing thermostat cover to access the wires from the wall.

(Some thermostats may have multiple covers, screws

or other locking devices that must be removed or disengaged.)

3. Locate, but do not disconnect the wires.

(If wires are not visible, they may be connected to the

back of the wall plate. Some models may have doors that open to expose the wires and mounting screws.)

if your existing

thermostat is marked...

label the wire

with this sticker:

G / F

W / H / B

W/B

Y / C* / M / O

Y/0

RC / VC

RH / R / VR / 4

24 Volt

24 Volt cool

air conditioning

compressor

heating

fan

heat pump

compressor

UNINSTALLING THE EXISTING UNIT, CONT.

4. Using the provided stickers, label each wire according to the chart.

(If the terminals are not labeled, contact

a qualied HVAC technician.)

Note: Wire colors do not always comply

with standards, so wire color should be

ignored. Refer to the existing terminal

designation for proper identication.

*If wires marked Y & C are both present, C may be a Common wire and should not be used. If you have a wire marked C, do not connect it to any terminal. This wire is used only for nonbattery powered thermostats.

5. Do not let the wires slip back into the wall during disconnection. You may want to secure the wires to the wall as you disconnect them. After all wires are labeled, disconnect each wire and remove the existing wall plate.

INSTALLING THE THERMOSTAT

INSTALLING THE WALL PLATE

1. Remove the wall plate from the new thermostat by pressing the release tab on the bottom of the thermostat.

2. Position the new wall plate on the wall and pull the labeled wires through the opening.

3. If the existing holes do not match those on the Hunter wall plate, or if there are no existing holes, visually level the wall plate and mark the wall for two holes.

INSTALLING THE THERMOSTAT, CONT.

4. Remove the wall plate and drill two 3/16” holes where marked.

5. Tap the plastic anchors into the holes until

they are ush with the wall.

6. Reposition the wall plate on the wall, pulling the wires through the opening. Insert the mounting screws through the wall plate and into the anchors. Verify that the wall plate is visually level and securely tighten both screws.

Y/0

W/B

RCRH

Y/0

W/B

Terminal Shield
