Your new Hunter® ceiling fan is an addition to your home or oce that
will provide comfort and performance for many years. is installation
and operation manual gives you complete instructions for installing
and operating your fan.
We are proud of our work. We appreciate the opportunity to supply
you with the best ceiling fan available anywhere in the world.
Before installing your fan, for your records and warranty assistance,
record information from the carton and Hunter nameplate label
(located on the top of the fan motor housing).
Cautions and Warnings
• Read this entire manual carefully before beginning installation. Save
these instructions.
• Use only Hunter replacement parts.
• To reduce the risk of personal injury, attach the fan directly to the
support structure of the building according to these instructions,
and use only the hardware supplied.
• To avoid possible electrical shock, before installing your fan,
disconnect the power by turning o the circuit breakers to the
outlet box and associated wall switch location. If you cannot lock
the circuit breakers in the o position, securely fasten a prominent
warning device, such as a tag, to the service panel.
• All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
qualied electrician.
• To reduce the risk of personal injury, do not bend the blade
attachment system when installing, balancing, or cleaning the fan.
Never insert foreign objects between rotating fan blades.
• To reduce the risk of re, electrical shock, or motor damage, do not
use a solid-state speed control with this fan. Use only Hunter speed
controls.
For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: _______________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
Table of Contents
1 • Getting Ready ...................................................4
2 • Installing the Ceiling Plate..........................5
3 • Assembling and Hanging the Fan..........6
4 • Wiring the Fan.................................................. 7
5 • Installing the Canopy and
Canopy Trim Ring............................................ 8
6 • Assembling the Blades .................................9
7 • Installing the Switch Housing................ 10
8 • Setting the Remote Transmitter and
Receiver..............................................................11
9 • Completing Your Installation ............... 12
10 • Operating the Remote Control and
Mounting the Holder............................... 13
11 • Operating and Cleaning Your Fan ...14
12 • Troubleshooting......................................... 15
Welcome
© 2005 Hunter Fan Company
42501 Sunset Boulevard.indd 10/24/2005, 11:03 AM2
Page 3
3
42501-01 • 10/24/05 Hunter Fan Company
Installer’s Choice and Optional Accessories
Understanding Mounting and Installer’s Choice®
Hunter’s patented 3-position mounting system provides you maximum
installation exibility and ease. You can install your Hunter fan in one
of three ways, depending on ceiling height and your preference: Low
Prole, Standard, or Angle mounting. e steps in this manual include
instructions for all three Installer’s Choice mounting methods.
Considering Optional Accessories
Consider using Hunter’s optional accessories, including a wall-mounted
or remote speed control. To install and use the accessories, follow
the instructions included with each product. For quiet and optimum
performance of your Hunter fan, use only Hunter speed controls.
Low Prole Mounting ts close to the
ceiling, recommended for ceilings less
than 8 feet high
Standard Mounting hangs from
the ceiling by a downrod (included),
recommended for ceilings 8 feet or higher
Angle Mounting recommended for a
vaulted or angled ceiling
For ceilings higher than 8 feet, you
can purchase Hunter extension
downrods. All Hunter fans use sturdy
3/4” diameter pipe to assure stability
and wobble-free performance.
42501 Sunset Boulevard.indd 10/24/2005, 11:03 AM3
Page 4
4
Hunter Fan Company 42501-01 • 10/24/05
To install a ceiling fan, be sure you can do the following:
• Locate the ceiling joist or other suitable support in ceiling.
• Drill holes for and install wood screws.
• Identify and connect electrical wires.
• Lift 40 pounds.
If you need help installing the fan, your Hunter fan dealer can direct
you to a licensed installer or electrician.
Gathering the Tools
You will need the following tools for installing the fan:
• Electric drill with 9/64” bit
• Standard screwdriver
• Phillips-head screwdriver
• Wrench or pliers
Checking Your Fan Parts
Carefully unpack your fan to avoid damage to the fan parts. Check
for any shipping damage to the motor or fan blades. If one of the fan
blades was damaged in shipment, return all the blades for replacement.
If any parts are missing or damaged, contact your Hunter dealer or call
Hunter Parts Department at 888-830-1326.
Preparing the Fan Site
Before you begin installing the fan, follow all the instructions in
the pullout sheet called “Preparing the Fan Site.” Proper ceiling fan
location and attachment to the building structure are essential for
safety, reliable operation, maximum eciency, and energy savings.
1 • Getting Ready
Installing Multiple Fans?
If you are installing more than
one fan, keep the fan blades in
sets, as they were shipped.
42501 Sunset Boulevard.indd 10/24/2005, 11:03 AM4
Page 5
5
42501-01 • 10/24/05 Hunter Fan Company
2-1. Drill two pilot holes into the wood support structure through
the outermost holes in the outlet box. e pilot holes should
be 9/64” in diameter.
2-2. Your fan comes with four neoprene noise isolators (“Isolators”).
Position the isolators between the ceiling plate and ceiling
by inserting the raised areas on each isolator into the holes in
the ceiling plate.
2-3. read the lead wires from the outlet box down through the
hole in the middle of the ceiling plate.
2-4. Align the slotted holes in the ceiling plate with the pilot holes
you drilled in the wood support structure. For proper
alignment use slotted holes directly across from each other.
Note: e isolators should be ush against the ceiling.
2-5. Place a at washer on each of the two 3” screws and pass the
screws through the slotted holes in the ceiling plate into the
pilot holes you drilled.
Tighten the screws into the 9/64” pilot holes; do not use
lubricants on the screws. Do not over tighten.
Step 2-2
Flat Washer
3” Screw
Steps 2-3 – 2-5
2 • Installing the Ceiling Plate
For Angled Ceilings: Be sure to
orient the ceiling plate so that the
arrows printed on the ceiling plate are
pointing towards the ceiling peak.
Ceiling
Plate
42501 Sunset Boulevard.indd 10/24/2005, 11:04 AM5
Page 6
6
Hunter Fan Company 42501-01 • 10/24/05
3 • Assembling and Hanging the Fan
Steps 3-3 – 3-4
#8-32 x 3/4” Screw
Low Prole Washer
Step 3-5
U-shaped
Hole
You can assemble your fan for standard mounting (steps 3-1 – 3-2) or
for low prole mounting (steps 3-3 – 3-4).
3-1. To assemble the fan to hang down from a at or angled ceiling,
insert the downrod through the canopy and canopy trim ring.
Feed the wires from the fan through the downrod.
3-2. Loosen the set screw on the adapter to install the pipe and ball
assembly. Note: When the pipe and ball assembly is fully installed,
2-3 threads on the pipe will still be visible; this is normal. Securely
retighten the set screw with a wrench or pliers. Skip to Step 3-5.
CAUTION: e adapter has a special coating on the threads.
Do not remove this coating; the coating prevents the downrod
from unscrewing. Once assembled, do not remove the downrod.
3-3. Place the low prole washer (lip up) into the canopy. Be sure the
green ground wire is pointing up toward the ceiling.
Note: For low prole mounting, the downrod is replaced with
the low prole washer. See Steps 3-3 – 3-4.
3-4. Align the holes in the washer with the holes in the adapter.
Assemble securely with three #8-32 x 3/4” screws.
3-5. Raise the fan and place the hook on the ceiling plate through the
U-shaped hole in the rim. Go to 4 • Wiring the Fan.
WARNING: Fan may fall if not assembled as directed in these
installation instructions.
Steps 3-1 – 3-2
Downrod
Canopy
Canopy
Trim Ring
Set Screw
42501 Sunset Boulevard.indd 10/24/2005, 11:04 AM6
Page 7
7
42501-01 • 10/24/05 Hunter Fan Company
4 • Wiring the Fan
All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
qualied electrician.
4-1. Disconnect the power by turning o the circuit breakers to the
outlet box and associated wall switch location.
4-2. To connect the wires, hold the bare metal leads together and
place a wire nut over them, then twist clockwise until tight.
4-3. Connect the wires as follows:
• Connect the green ground wire from the fan to the ground
wire from the ceiling
• Connect the white wire from the fan to the common wire from
the ceiling
• Connect the black wire and the black and white striped wire
from the fan to the black wire from the ceiling
CAUTION: Be sure no bare wire or wire strands are visible
after making connections.
4-4. Push all wires and wire nuts back through the ceiling plate hole
into the outlet box.
Wire Nut
Step 4-3
42501 Sunset Boulevard.indd 10/24/2005, 11:04 AM7
Page 8
8
Hunter Fan Company 42501-01 • 10/24/05
5 • Installing the Canopy and Canopy Trim Ring
5-1. Holding the canopy, raise the fan o the hook.
5-2. Align the slots in the canopy with the tabs on the ceiling plate.
5-3. Raise the canopy over the ceiling plate. Rotate the canopy
clockwise until the tabs on the ceiling plate totally engage with
the slots in the canopy.
5-4. Loosely assemble the three canopy screws into the canopy one at
a time. Once all three screws are in, tighten them.
5-5. Using both hands, push the canopy trim ring up to the top of the
canopy. e canopy trim ring will snap and lock into place.
Should you need to remove the canopy
trim ring, follow these steps:
1. Locate the tab indicators, small
bumps on top of tabs.
2. Press rmly on opposite sides of the
ring towards the canopy. e tabs
will ex out releasing the trim ring
from the canopy.
Canopy
Screw
Step 5-2
Canopy Trim
Ring
Canopy
Ceiling Plate
Step 5-3
Steps 5-4 – 5-5
42501 Sunset Boulevard.indd 10/24/2005, 11:04 AM8
Page 9
9
42501-01 • 10/24/05 Hunter Fan Company
6 • Assembling the Blades
Hunter fans use several styles of fan blade irons (brackets that hold the
blade to the fan).
6-1. Your fan may include blade grommets. If your fan has grommets,
insert them by hand into the holes on the blades.
6-2. Install three blade assembly screws through the the blade iron
and blade, into the medallion. If you used grommets, the blades
may appear slightly loose after screws are tightened. is is
normal.
6-3. Remove the blade armature screws and rubber shipping bumpers
from the motor. Save the screws for the following step and
discard the shipping bumpers.
6-4. For each blade, insert one blade armature screw through the
blade iron, and attach loosely to the fan. Insert the second blade
armature screw, then securely tighten both armature screws.
Blade
Armature
Screw
Step 6-4
Steps 6-1 – 6-2
Blade
Assembly
Screws
42501 Sunset Boulevard.indd 10/24/2005, 11:05 AM9
Page 10
10
Hunter Fan Company 42501-01 • 10/24/05
7 • Installing the Switch Housing
7-1. To attach the upper switch housing, partially install two #6-32 x
3/8” housing assembly screws into the switch housing mounting
plate.
7-2. Feed the upper plug connector through the center opening of
the housing.
7-3. Align the keyhole slots in the housing with the housing assembly
screws.
7-4. Turn the housing counterclockwise until the housing assembly
screws are rmly situated in the narrow end of the keyhole slots.
Install the remaining #6-32 x 3/8” screw into the housing. Tighten
all three screws rmly.
Steps 7-1 – 7-3
Housing
Assembly
Screw
Upper
Switch
Housing
Step 7-4
42501 Sunset Boulevard.indd 10/24/2005, 11:05 AM10
Page 11
11
42501-01 • 10/24/05 Hunter Fan Company
CAUTION: e remote control device complies with part 15 of the FCC rules.
Changes or modications not expressly approved by Hunter Fan Company could void
your authority to operate this equipment.
Operation is subject to the following two conditions:
1. is device may not cause harmful interference.
2. is device must accept any interference received, including interference that may
cause undesired operation.
WARNING: Maximum fan load is 1 Amp; maximum lamp is 100 Watts. Do not use
any speed control with this product.
You must now set the jumper switches in the remote transmitter and
receiver so that they match.
8-1. Change the position of the jumper switches in the transmitter
and the receiver. Be sure the position of the jumper switches
matches. If they don’t match, the controller will not function.
For instructions on how to set the jumper switches, read the box
below.
8-2. Install the included 12-volt battery into the transmitter.
Setting Jumper Switches
When two or more fans are located near each other, you may desire to have the
receiver/transmitter for each fan set to a dierent code, so that the operation of
one fan does not aect the operation of the other fans.
In the transmitter you can access the jumpers from the battery compartment.
e jumpers are very small. You can move them most easily using a small pair of
pliers or tweezers. IMPORTANT! Before you change jumper switches, make sure
the battery is not connected to the transmitter.
8 • Setting the Remote Transmitter and Receiver
42501 Sunset Boulevard.indd 10/24/2005, 11:05 AM11
Page 12
12
Hunter Fan Company 42501-01 • 10/24/05
9-1. To attach the lower switch housing, connect the plug connector
from the motor to the plug connector from the receiver in the
lower switch housing assembly.
Note: Both plug connectors are polarized and will only t
together one way. Make sure the connectors are properly aligned
before connecting them. Incorrect connection could cause
improper operation and damage to the product.
9-2. Place the lower switch housing assembly over the upper switch
housing. Align the side screw holes in the upper and lower switch
housings. Attach the lower switch housing to the upper switch
housing with three #6-32 x 1/2” housing assembly screws.
Lower Switch
Housing
Plug
Connector
Plug
Connector
Detail
Steps 9-1 – 9-2
Housing
Assembly Screw
9 • Completing Your Installation
42501 Sunset Boulevard.indd 10/24/2005, 11:05 AM12
Page 13
13
42501-01 • 10/24/05 Hunter Fan Company
10-1. e remote transmitter has individual buttons for turning the fan
o and on and controlling the light and fan speed.
10-2. For best operation, start the fan by pressing high, then select your
desired speed.
10-3. e light button turns the light on to full brightness. To dim the
light, hold the light button down until you reach your desired
brightness. Push the light button again to turn o the light.
10-4. Press the OFF button to turn the fan o.
10-5. When necessary, replace the battery with a 12-volt type 23A,
MN-21 battery or equivalent.
10-6. You can mount the remote holder to any toggle switch plate with
the screws already in the switch plate. Or, you can simply mount
the remote holder on the wall.
Fan Light
Steps 10-1 – 10-4
Step 10-6
Step 10-5
Fan Speed
High
Fan Speed
Medium
Fan Speed
Low
Fan O
10 • Operating the Remote Control and Mounting the Holder
Fan Reverse
42501 Sunset Boulevard.indd 10/24/2005, 11:06 AM13
Page 14
14
Hunter Fan Company 42501-01 • 10/24/05
11-1. Turn on electrical power to the fan.
11-2. Ceiling fans work best by blowing air downward (counterclockwise
blade rotation) in warm weather to cool the room with a direct
breeze. In winter, having the fan draw air upward (clockwise blade
rotation) will distribute the warmer air trapped at the ceiling
around the room without causing a draft.
11-3. For cleaning nishes, use a soft brush or lint-free cloth to prevent
scratching. A vacuum cleaner brush nozzle can remove heavier
dust. Remove surface smudges or accumulated dirt and dust using
a mild detergent and a slightly dampened cloth. You may use
an artistic agent, but never abrasive cleaning agents as they will
damage the nish.
11-4. Clean wood nish blades with a furniture polishing cloth.
Occasionally, apply a light coat of furniture polish for added
protection and beauty. Clean painted and high-gloss blades in the
same manner as the fan nish.
In warm weather, use
downward air ow pattern
In cold weather, use upward
air ow pattern
11 • Operating and Cleaning Your Ceiling Fan
42501 Sunset Boulevard.indd 10/24/2005, 11:06 AM14
Page 15
15
42501-01 • 10/24/05 Hunter Fan Company
12 • Troubleshooting
Problem: Nothing happens; fan does not move.
1. Turn power on, replace fuse, or reset breaker.
2. Loosen canopy, check all connections according to the wiring the
fan section.
3. Check the plug connection in the switch housing.
4. Pull the pull chain to ensure it is on.
5. Remove the shipping bumpers.
Problem: Noisy operation.
1. Tighten the blade bracket screws until snug.
2. Check to see if the blade is cracked. If so, replace all the blades.
Problem: Excessive wobbling.
1. If your fan wobbles when operating, use the enclosed balancing kit
and instructions to balance the fan.
2. Tighten all blade iron screws.
3. Turn power o, support fan very carefully, and check that the
hanger ball is properly seated.
If you need parts or service assistance, please call
888-830-1326 or visit us at our Web site at
http://www.hunterfan.com.
Hunter Fan Company
2500 Frisco Avenue
Memphis, Tennessee 38114
42501 Sunset Boulevard.indd 10/24/2005, 11:06 AM15
Loading...
