Hunter Fan 30374, 30375, 30380 User Manual

HEPAtech

Air Purification System

HEPAtech™ 374 (Model 30374)

HEPAtech™ 375 (Model 30375)

HEPAtech™ 380 (Model 30380)

HEPAtech™ 200 (Model 30200)

HEPAtech™ 250 (Model 30250)



HEPAtech™ 255 (Model 37255)

This air purifier uses Model 30930 replacement filters.

WWW.HUNTERFAN.COM

FORM 41365-01 06/17/2004

1

©2004 HUNTER FAN CO.

41365-01_Rev 6-17-04.pmd

1

6/17/04, 11:58 AM

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING THIS AIR PURIFIER AND SAVE THESE IMPORTANT INSTRUCTIONS

1.This Air Purifier is designed for use on a flat, level surface and may not work properly on an uneven surface. ALWAYS place this Air Purifier on a firm, level surface. ALWAYS place the Air Purifier at least six (6) inches away from walls and heat sources such as stoves, radiators, or heaters.

2.Place the Air Purifier in an area that is out of the reach of children.

3.Before using the Air Purifier, extend the cord and inspect for any signs of damage. DO NOT use the product if the cord has been damaged.

4.This product has a polarized plug (one blade is wider than the other) as a safety feature. This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT attempt to defeat or override this safety feature.

5.ALWAYS UNPLUG the Air Purifier when it is not in operation, while the filter is being changed, and while it is being cleaned.

6.DO NOT tilt or move the Air Purifier while it is in operation. Shut off and unplug before moving.

7.DO NOT immerse the Air Purifier in water as permanent damage will occur. Refer to and follow the CLEANING AND FILTER REPLACEMENT instructions.

Introduction

Thank you for purchasing the HEPAtech™ Air Purification System from Hunter Fan Company. You have purchased our latest development in portable Air Purification Systems. This system has been developed to improve the quality of the air you breathe.

Our HEPAtech™ Air Purification System out performs other air purification systems by quickly and effectively removing dust, smoke, and pollen particles as small as .1 microns in size. Room air is pulled in through the front grill and cleaned across the HEPAtech™ filter. Clean air is then released out the top grill in order to avoid stirring up settled particles.

Using the Ionizer

Using the ionizer improves the quality of air in the room. Negative ions are released into the air and positively charged dust, smoke, and pollen particles are attracted to the negative ions. These particles settle out of the air and can be vacuumed up during normal cleaning. These particles are also more easily captured by the HEPAtech™ filter as they pass through the HEPAtech™ Air Purification System. To ensure the best air circulation in the room, we recommend that you place your air purifier six inches away from any walls.

FORM 41365-01

2

©2004 HUNTER FAN CO.

41365-01_Rev 6-17-04.pmd

2

6/17/04, 11:58 AM

Air Purifier Features

Models 30374, 30375 and Model 30380 Electronic Key Pad Control

1.On/Speed Control: Press this button to turn the unit ‘on’. When you press it once, the unit will be on low speed. Keep pressing the button to change speeds until you reach the speed you desire.

2.Automatic Shut-off: If you desire the air purifier to shut off automatically, you can set the timer. Press the timer button to choose the amount of time you would like the air purifier to run (1, 2, 4, or 8 hours). Press the button repeatedly to change the length of time.

3.Ionizer: Press this button to turn ‘on’ the ionizer. When the ionizer is ‘on’, the green light to the left of the button will be illuminated.

4.Check Filter: When the check filter light is illuminated, you should open the front grill and compare the filter to the check filter chart. If the filter is dark, you should replace the filter.

5.Reset: When you change the filter, press the reset button. Use the tip of a pen or pencil to press the reset button.

Models 30200, 30250 and 37255

1.On/Speed Control: Rotate this knob to turn the unit ‘on’. The knob rotates through “Off ”, “Low”, “Medium” and “High”. Keep rotating the knob to change speeds until you reach the speed you desire. When the power is “on”, the red light will be illuminated.

2.Ionizer: Press this button to turn ‘on’ the ionizer. When the ionizer is ‘on’, the green light near the button will be illuminated.

AIR PURIFIER PARTS



RECESS FOR

FILTER

FINGERS TO

PULL OPEN





FRONT GRILL

FRONT



GRILL



HEPAtech™ 200

FIGURE 1A

FORM 41365-01

3

©2004 HUNTER FAN CO.

41365-01_Rev 6-17-04.pmd

3

6/17/04, 11:58 AM
